York THGD18 User Manual
TECHNICAL GUIDE
V
A
w
SPLIT-SYSTEM
HEAT PUMPS
13 SEER – R-410A
MODELS:
THGD18 THRU 60
(1.5 THRU 5 NOMINAL TONS, 1 PHASE)
LISTED
Due to continuous product improvement, specifications
are subject to change without notice.
isit us on the web at www.york.com
dditional rating information can be found at
ww.ahridirectory.org
ISO 9001
Certified Quality
Management System
397763-YTG-B-0508
DESCRIPTION
The heat pump condensing unit is the outdoor part of a versatile system of heating and air conditioning. It is designed to be
custom-matched with one of UPG’s complete line of evaporator sections, with each serving a specific function. Matching
Air Handlers are available for upflow, downflow, or horizontal
applications to provide a complete system. Electric Heaters
are available, if required. Add-on coils are available for use
with upflow, downflow, or horizontal furnaces and air handlers.
WARRANTY
Single Phase Units:
5-year limited parts warranty.
5-year limited compressor warranty.
FEATURES
• QUALITY CONDENSER COILS - The coil is constructed
of copper tubing and enhanced aluminum fins for
increased efficiency and corrosion protection.
• PROTECTED COMPRESSOR - The compressor is internally protected against high pressure, temperature, and
externally by a factory installed high pressure switch. This
is accomplished by the simultaneous operation of high
pressure relief valve and a temperature sensor which protects the compressor if undesirable operating conditions
occur. A liquid line filter-drier further protects the compressor.
• DURABLE FINISH - The cabinet is made of pre-painted
steel. The pre-treated galvanized steel provides a better
paint to steel bond, which resists corrosion and rust creep.
Special primer formulas and matted-textured finish insure
less fading when exposed to sunlight.
• LOWER INSTALLED COST - Installation time and costs
are reduced by easy power and control wiring connections. Available in sweat connect models only. The unit
contains enough refrigerant for matching indoor coils and
15 feet of interconnecting piping. The small base dimension means less space is required on the ground or roof.
• TOP DISCHARGE - The warm air from the top mounted
fan is blown up away from the structure and any landscaping. This allows compact location on multi-unit applications.
• LOW OPERATING SOUND LEVEL - The upward air flow
carries the normal operating noise away from the living
area. The rigid top panel effectively isolates any motor
sound. Isolator mounted compressor and the rippled fins
of the condenser coil muffle the normal fan motor and
compressor operating sounds.
• LOW MAINTENANCE - Long life permanently lubricated
motor-bearings need no annual servicing.
• EASY SERVICE ACCESS - Fully exposed refrigerant connections, and a single panel covering the electrical controls make for easy servicing of the unit.
• SECURED SERVICE VALVES - Secured re-usable ser-
vice valves are provided on both the liquid and vapor
sweat connections for ease of evacuating and charging.
• U.L. and C.U.L. listed - approved for outdoor application.
Certified in accordance with the Unitary Small Equipment certification program, which is based on ARI Standard 210/240.
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
397763-YTG-B-0508
Physical and Electrical Data
MODEL
THGD18
S41S1
THGD24
S41S1
THGD30
S41S1
THGD36
S41S1
THGD42
S41S1
THGD48
S41S1
THGD60
S41S1
Unit Supply Voltage 208-230V, 1φ, 60Hz
Normal Voltage Range
1
187 to 252
Minimum Circuit Ampacity 9.6 12.0 15.4 19.6 28.6 30.9 37.4
Max. Overcurrent Device Amps
Min. Overcurrent Device Amps
2
3
15 20 25 30 50 50 60
15 15 20 20 30 35 40
Compressor Type Recip Recip Recip Recip Scroll Scroll Scroll
Compressor Amps
Rated Load 7.12 8.9 11.65 14.72 21.76 23.61 28.79
Locked Rotor 47.0 48.0 60.0 83.0 105.0 150.0 150
Crankcase Heater Yes Yes Yes Yes No No No
Fan Motor Amps Rated Load 0.70 0.80 0.80 1.5 1.5 1.5 1.5
Fan Diameter Inches 24 24 24 24 24 24 24
Rated HP 1/10 1/8 1/8 1/4 1/4 1/4 1/4
Fan Motor
Nominal RPM 825 1075 1075 850 850 850 850
Nominal CFM 2200 2900 3100 3800 3200 3000 3000
Face Area Sq. Ft. 15.7 18.3 21.0 23.58 23.58 23.58 23.58
Coil
Rows Deep 1 1 1 1 1 2 2
Fin / Inches 22 22 22 22 22 18 18
Liquid Line Set OD (Field Installed) 3/8 3/8 3/8 3/8 3/8 3/8 3/8
Vapor Line Set OD (Field Installed) 3/4 3/4 3/4 3/4 7/8 7/8 7/8
Unit Charge (Lbs. - Oz.)
4
6 - 5 8 - 7 9 - 12 9 - 15 9 - 12 13 - 9 13 - 6
Charge Per Foot, Oz. .62 .62 .62 .62 .67 .67 .67
Operating Weight Lbs. 172 184 196 208 208 275 280
1. Rated in accordance with ARI Standard 110, utilization range “A”.
2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.
3. Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.
4. The Unit Charge is correct for the outdoor unit, matched indoor coil and 15 feet of refrigerant tubing. For tubing lengths other than 15 feet,
add or subtract the amount of refrigerant, using the difference in length multiplied by the per foot value.
All dimensions are in inches. They are subject to change
without notice. Certified dimensions will be provided upon
C
A
B
request.
Unit
Model
18 28
24 32 34 34
30 36 34 34
36 40 34 34
42 40 34 34
60 40 34 34
1. Including Fan Guard.
Dimensions
(Inches)
1
A
Refrigerant Connection
Service Valve Size
B C Liquid Vapor
34 34
3/4”
3/8”
7/8”48 40 34 34
2 Johnson Controls Unitary Products
397763-YTG-B-0508
Additional R-410A Charge / Orifice Size for Various Matched Systems
Outdoor Unit
Required Orifice or TXV
THGD18
S41S1
1,2
1TVM0901 1TVM0903 1TVM0903 1TVM0904 1TVM0904 1TVM0905 1TVM0906
Factory Charge, lbs-oz 6 - 5 8 - 7 9 - 12 9 - 15 9 - 12 13 - 9 13 - 6
Indoor Coil
3,4
FC/MC/PC/UC18AB 0 ––––––
FC/MC/PC/UC24AB + 4 0 –––––
FC/MC/PC30AB –0 –––––
FC/MC/PC32A –0 0 ––––
FC/MC/PC35BC –0 0 ––––
FC/MC/PC37A ––0 0 –––
FC/MC/PC43BC ––0 0 –––
FC/MC/PC/UC48CD – – – + 10 0 0 –
FC/MC/PC/UC60CD ––––0 0 –
FC/MC62D –––––+ 12 0
HC18A + 1 ––––––
HC30A + 10 0 –––––
HC36B –0 0 ––––
HC42 – – 0 0 0 – –
HC60 ––––0 0 –
HD24 + 14 ––––––
HD36 –+ 2 –––––
HD48 – – + 8 + 8 – – –
HD60 ––––0 + 7 –
AHP18 0 ––––––
AHP30 –0 –––––
AHP36 ––0 0 –––
AHP/SHP48 ––––0 0 –
AHP/SHP60 –––––0 –
AV24 + 3 0 –––––
AV36 – 6 0 0 – – –
AV/SV48 ––––0 0 –
AV/SV60 –––––0 –
F4FP24
F4FP30
F4FP40
F4FP45
F5FP48
F4FV60
F5FP60
See Caution below
See Caution below
See Caution below
See Caution below
See Caution below
See Caution below
See Caution below
0 ––––––
–0 –––––
––0 ––––
–––0 0 ––
––––0 0 –
–––––0 –
–––––0 –
FOOTNOTES:
1. For applications requiring a TXV use 1TVM900 series kit.
2. Approved orifice shipped with outdoor unit.
3. Systems matched with furnace or air handlers not equipped with blower-off delays may require blower Time Delay Kit 2FD06700224.
4. PC coils cannot be used in downflow or horizontal applications. FC coils cannot be used in horizontal applications.
PROCEDURES:
1. Unit factory charge listed on the unit nameplate includes refrigerant for the condenser, the smallest evaporator and 15 feet of interconnecting line tubing.
2. Verify the TXV or orifice and additional charge required for specific evaporator coil in the system using the above table.
3. Additional charge for the amount of interconnecting line tubing greater than 15 feet at the rate specified in Physical and Electrical Data
Table.
4. For TXV match charge weight needs to be weighed in for specififc coil match and lineset length.
5. Permanently mark the unit nameplate with the total system charge. Total System Charge = Base Charge (as shipped) + adder for evaporator + adder for line set.
THGD24
S41S1
THGD30
S41S1
THGD36
S41S1
Additional Charge, Oz
THGD42
S41S1
THGD48
S41S1
THGD60
S41S1
F*FP Air Handlers come with a factory installed R-22 TXV which MUST BE CHANGED OUT to R-410A TXV or an orifice for proper operation. If the TXV is not changed out system damage will occur.
Johnson Controls Unitary Products 3
397763-YTG-B-0508
COOLING CAPACITY - With Air Handler Coils
UNIT
MODEL
THGD18S41S1
THGD24S41S1
THGD30S41S1
THGD36S41S1
THGD42S41S1
THGD48S41S1
THGD60S41S1 MA20D 24 MC62D 1800 54.0 42.5 13.00 11.00
THGD18S41S1
THGD24S41S1
THGD30S41S1
THGD36S41S1
THGD42S41S1
THGD48S41S1
THGD60S41S1 MV20D 24 MC62D 1800 54.5 43.0 13.50 11.60
For Notes See Page 5.
AIR HANDLER
MODEL W
MA08B 17 FC/MC/PC18B 600 17.0 12.6 13.00 11.00
MA08B 17 FC/MC/PC24B 600 17.0 12.9 13.50 11.00
MA08B 17 FC/MC/PC24B 800 23.0 17.1 13.00 11.00
MA08B 17 FC/MC/PC30B 800 23.0 17.2 13.00 11.00
MA08B 17 FC/MC/PC35B 800 23.0 17.5 13.00 11.00
MA12B 17 FC/MC/PC35B 1000 29.0 23.2 13.00 11.00
MA12B 17 FC/MC/PC43B 1000 29.0 23.4 13.00 11.00
MA12B 17 FC/MC/PC43B 1200 35.0 26.8 13.00 11.00
MA14D 24 FC/MC/PC48D 1200 35.0 27.0 13.00 11.00
MA14D 24 FC/MC/PC48D 1400 41.5 31.4 13.00 11.00
MA16C 21 FC/MC/PC48C 1400 41.5 31.4 13.00 11.00
MA14D 24 FC/MC/PC60D 1400 41.0 31.2 13.00 11.00
MA16C 21 FC/MC/PC60C 1400 41.0 31.2 13.00 11.00
MA16C 21 FC/MC/PC48C 1600 47.0 35.2 13.00 11.00
MA20D 24 FC/MC/PC48D 1600 47.0 35.2 13.00 11.00
MA16C 21 FC/MC/PC60C 1600 47.0 35.6 13.00 11.00
MA20D 24 FC/MC/PC60D 1600 47.0 35.6 13.00 11.00
MA20D 24 MC62D 1600 47.0 35.6 13.00 11.00
13 SEER HP WITH MV - VARIABLE SPEED
MV12B 17 FC/MC/PC18B 600 17.0 12.9 14.00 12.00
MV12B 17 FC/MC/PC24B 600 17.0 13.2 14.00 12.00
MV12B 17 FC/MC/PC24B 800 23.0 17.6 14.00 12.00
MV12B 17 FC/MC/PC30B 800 23.0 17.6 14.00 12.00
MV12B 17 FC/MC/PC35B 800 23.0 17.9 14.00 12.00
MV16C 21 FC/MC/PC35C 800 23.0 17.9 14.00 12.00
MV12B 17 FC/MC/PC35B 1000 29.0 23.6 14.00 12.00
MV16C 21 FC/MC/PC35C 1000 29.0 23.6 14.00 12.00
MV12B 17 FC/MC/PC43B 1000 29.0 23.8 14.00 12.00
MV16C 21 FC/MC/PC43C 1000 29.0 24.0 14.00 12.00
MV12B 17 FC/MC/PC43B 1200 35.0 27.0 13.50 11.50
MV16C 21 FC/MC/PC43C 1200 35.0 27.2 13.50 11.50
MV12D 24 FC/MC/PC48D 1150 35.0 26.8 13.50 11.50
MV16C 21 FC/MC/PC48C 1200 35.0 27.4 13.50 11.50
MV20D 24 FC/MC/PC48D 1200 35.0 27.4 13.50 11.50
MV16C 21 FC/MC/PC48C 1400 42.0 31.8 14.00 12.00
MV20D 24 FC/MC/PC48D 1400 42.0 32.0 14.00 12.00
MV20D 24 FC/MC/PC60D 1400 41.5 31.8 14.00 12.00
MV16C 21 FC/MC/PC48C 1600 47.5 35.6 14.00 11.80
MV20D 24 FC/MC/PC48D 1600 47.5 35.6 14.00 11.80
MV20D 24 FC/MC/PC60D 1600 47.5 36.0 14.00 11.80
MV20D 24 MC62D 1600 47.5 36.0 14.00 12.00
COIL
1
MODEL
13 SEER HP WITH MA
RATED
CFM
TOTAL SENS.
COOLING
NET MBH
SEER EER
4 Johnson Controls Unitary Products
397763-YTG-B-0508
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER
MODEL W
COIL
MODEL
1
RATED
CFM
TOTAL SENS.
13 SEER HP WITH AV / SV / F*FV - VARIABLE SPEED
THGD18S41S1 AV24 17 – 550 17.0 13.0 14.00 12.00
THGD24S41S1
AV24 17 – 750 23.0 17.2 14.00 12.00
AV36 21 – 750 23.0 18.0 14.00 12.00
THGD30S41S1 AV36 21 – 1000 29.0 24.4 14.00 12.00
THGD36S41S1 AV36 21 – 1250 35.0 28.0 13.50 11.50
THGD42S41S1 AV/SV48 24 – 1400 41.5 32.0 14.00 12.00
AV/SV48 24 – 1600 47.5 36.2 14.00 11.80
THGD48S41S1
AV/SV60 24 – 1650 47.5 36.6 14.00 11.80
F4FV060 24 – 1600 47.5 36.2 14.00 11.80
13 SEER HP WITH AHP / SHP / F*FP
THGD18S41S1
THGD24S41S1
THGD30S41S1
THGD36S41S1
AHP18 17 – 600 17.0 12.7 13.00 11.00
F4FP024 17 – 600 17.0 12.6 13.00 11.00
AHP30 17 – 800 23.0 17.2 13.00 11.00
F4FP030 17 – 800 23.0 16.9 13.00 11.00
AHP36 21 – 1000 29.0 23.2 13.00 11.00
F4FP040 21 – 1000 29.0 22.6 13.00 11.00
AHP36 21 – 1200 35.0 26.8 13.00 11.00
F4FP045 24 – 1200 35.0 26.8 13.00 11.00
AHP/SHP48 21 – 1400 41.5 31.4 13.00 11.00
THGD42S41S1
F4FP045 24 – 1400 41.0 31.2 13.00 11.00
F5FP048 24 – 1450 41.0 32.6 13.00 11.00
AHP/SHP60 24 – 1600 47.0 36.0 14.00 11.50
THGD48S41S1
F5FP048 24 – 1700 47.5 36.6 14.00 11.50
F5FP060 24 – 1700 47.5 36.8 14.00 11.50
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210.
Cooling MBH based on 80°F entering air temperature, 50% RH, and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTU’s at 95°F outd oor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTU’s during a normal annual usage period for cooling divided by the total electric power
input in watt-hours during the same period.
COOLING
NET MBH
SEER EER
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
— = Not applicable.
Johnson Controls Unitary Products 5
397763-YTG-B-0508
COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils
FURNACE**
UNIT MODEL
THGD18S41S1
THGD24S41S1
THGD30S41S1
THGD36S41S1
THGD42S41S1
THGD48S41S1
THGD60S41S1 1600 - 2000 21,24 MC62 1800 54.0 42.5 13.00 11.00
1. Requires a 2FD06700224 Blower Time Delay unless a standard furnace is equipped with one.
** Refer to Quick Selection Chart for specific furnace match-up.
CFM RANGE
(Min.-max.)
450 - 750 14,17 FC/MC/PC18 600 17.0 12.6 13.00 11.00
450 - 750 14,17 FC/MC/PC24 600 17.0 12.9 13.50 11.00
450 - 750 14 HC18 600 17.0 12.6 13.00 11.00
450 - 750 14 HC30 600 17.0 12.8 13.00 11.00
450 - 750 14 HD24 600 17.0 13.0 13.50 11.00
600 - 1000 14,17 FC/MC/PC24 800 23.0 17.1 13.00 11.00
600 - 1000 14,17 FC/MC/PC30 800 23.0 17.2 13.00 11.00
600 - 1000 14 FC/MC/PC32 800 23.0 17.5 13.00 11.00
600 - 1000 17,21 FC/MC/PC35 800 23.0 17.5 13.00 11.00
600 - 1000 14 HC30 800 23.0 17.2 13.00 11.00
600 - 1000 17 HC36 800 23.0 17.5 13.00 11.00
600 - 1000 14,17 HD36 800 23.0 16.4 13.00 11.00
800 - 1200 14 FC/MC/PC32 1000 29.0 23.2 13.00 11.00
800 - 1200 17,21 FC/MC/PC35 1000 29.0 23.2 13.00 11.00
800 - 1200 14 FC/MC/PC37 1000 29.0 23.4 13.00 11.00
800 - 1200 17,21 FC/MC/PC43 1000 29.0 23.4 13.00 11.00
800 - 1200 17 HC36 1000 29.0 23.2 13.00 11.00
800 - 1200 21 HC42 1000 29.0 23.4 13.00 11.00
800 - 1200 21,24 HD48 1000 29.0 23.4 13.00 11.00
1000 - 1400 14 FC/MC/PC37 1200 35.0 26.6 13.00 11.00
1000 - 1400 17,21 FC/MC/PC43 1200 35.0 26.8 13.00 11.00
1000 - 1400 21,24 FC/MC/PC48 1200 35.0 27.0 13.00 11.00
1000 - 1400 21 HC42 1200 35.0 26.8 13.00 11.00
1000 - 1400 21,24 HD48 1200 35.0 26.8 13.00 11.00
1200 - 1600 21,24 FC/MC/PC48 1400 41.5 31.4 13.00 11.00
1200 - 1600 21,24 FC/MC/PC60 1400 41.0 31.2 13.00 11.00
1200 - 1600 21 HC42 1400 41.0 31.2 13.00 11.00
1200 - 1600 24 HC60 1400 41.0 31.2 13.00 11.00
1200 - 1600 21,24 HD60 1400 41.5 31.4 13.00 11.00
1400 - 1800 21,24 FC/MC/PC48 1600 47.0 35.2 13.00 11.00
1400 - 1800 21,24 FC/MC/PC60 1600 47.0 35.6 13.00 11.00
1400 - 1800 24 HC60 1600 47.0 35.6 13.00 11.00
1400 - 1800 21,24 HD60 1600 47.0 35.4 13.00 11.00
1400 - 1800 21,24 MC62 1600 47.0 35.6 13.00 11.00
W
COIL
MODEL
RATED
CFM
TOTAL SENS.
COOLING
NET MBH
SEER
1
EER
6 Johnson Controls Unitary Products
COOLING CAPACITY - With Variable Speed Furnaces
UNIT MODEL
THGD18S41S1
THGD24S41S1
THGD30S41S1
For Notes See Page 9.
VARIABLE SPEED
FURNACE MODEL
13 SEER HP WITH VARIABLE SPEED FURNACES
PV8*A12 FC/MC/PC18A 14 600 17.0 12.9 14.00 12.00
PV9*A12 FC/MC/PC18A 14 600 17.0 12.9 14.00 12.00
P(C,V)9*B12 FC/MC/PC18B 17 600 17.0 12.9 14.00 12.00
PV8*B16 FC/MC/PC/UC18B 17 600 17.0 12.9 14.00 12.00
PV8*A12 FC/MC/PC24A 14 600 17.0 13.2 14.00 12.00
PV9*A12 FC/MC/PC24A 14 600 17.0 13.2 14.00 12.00
P(C,V)9*B12 FC/MC/PC24B 17 600 17.0 13.2 14.00 12.00
PV8*B16 FC/MC/PC/UC24B 17 600 17.0 13.2 14.00 12.00
PV8*A12 HC18A 14 600 17.0 12.9 14.00 12.00
PV9*A12 HC18A 14 600 17.0 12.9 14.00 12.00
PV8*A12 HC30A 14 600 17.0 13.2 14.00 12.00
PV9*A12 HC30A 14 600 17.0 13.1 14.00 12.00
PV8*A12 HD24A 14 600 17.0 13.3 14.00 12.00
PV9*A12 HD24A 14 600 17.0 13.3 14.00 12.00
P(C,V)9*B12 HD24 17 600 17.0 13.3 14.00 12.00
PV8*B16 HD24 17 600 17.0 13.3 14.00 12.00
PV8*A12 FC/MC/PC24A 14 750 23.0 17.1 14.00 12.00
PV9*A12 FC/MC/PC24A 14 800 23.0 17.4 14.00 12.00
P(C,V)9*B12 FC/MC/PC24B 17 800 23.0 17.5 14.00 12.00
PV8*A12 FC/MC/PC30A 14 750 23.0 17.2 14.00 12.00
PV9*A12 FC/MC/PC30A 14 800 23.0 17.5 14.00 12.00
P(C,V)9*B12 FC/MC/PC30B 17 800 23.0 17.5 14.00 12.00
PV8*A12 FC/MC/PC32A 14 750 23.0 17.4 14.00 12.00
PV9*A12 FC/MC/PC32A 14 800 23.0 17.7 14.00 12.00
P(C,V)9*B12 FC/MC/PC35B 17 800 23.0 17.8 14.00 12.00
P(C,V)9*C16 FC/MC/PC35C 21 850 23.0 18.6 14.00 12.00
PV8*A12 HC30A 14 750 23.0 17.2 14.00 12.00
PV9*A12 HC30A 14 800 23.0 17.6 14.00 12.00
P(C,V)9*B12 HC36B 17 800 23.0 17.8 14.00 12.00
PV8*A12 HD36A 14 750 23.0 16.7 14.00 12.00
PV9*A12 HD36A 14 800 23.0 16.8 14.00 12.00
P(C,V)9*B12 HD36B 17 800 23.0 16.8 14.00 12.00
PV8*A12 FC/MC/PC32A 14 1000 29.0 23.4 14.00 12.00
PV9*A12 FC/MC/PC32A 14 1000 29.0 23.4 13.50 12.00
PV8*B16 FC/MC/PC35B 17 1050 29.0 24.4 14.00 12.00
PV8*C16 FC/MC/PC35C 21 1000 29.0 23.6 14.00 12.00
PV8*C20 FC/MC/PC35C 21 1100 29.0 25.0 14.00 12.00
P(C,V)9*B12 FC/MC/PC35B 17 1000 29.0 23.6 14.00 12.00
P(C,V)9*C16 FC/MC/PC35C 21 1000 29.0 23.6 14.00 12.00
P(C,V)9*C20 FC/MC/PC35C 21 1050 29.0 23.4 13.50 12.00
PV8*A12 FC/MC/PC37A 14 1000 29.0 23.8 13.50 12.00
PV9*A12 FC/MC/PC37A 14 1000 29.0 23.6 13.50 12.00
PV8*B16 FC/MC/PC43B 17 1050 29.0 24.6 14.00 12.00
PV8*C16 FC/MC/PC43C 21 1000 29.0 24.0 14.00 12.00
PV8*C20 FC/MC/PC43C 21 1100 29.0 25.6 14.00 12.00
P(C,V)9*B12 FC/MC/PC43B 17 1000 29.0 23.8 14.00 12.00
P(C,V)9*C16 FC/MC/PC43C 21 1000 29.0 23.8 14.00 12.00
P(C,V)9*C20 FC/MC/PC43C 21 1050 29.0 23.8 14.00 12.00
PV8*B16 HC36B 17 1050 29.0 24.2 14.00 12.00
P(C,V)9*B12 HC36B 17 1000 29.0 23.6 14.00 12.00
COIL
MODEL
1
397763-YTG-B-0508
COOLING
W
RATED
CFM
Net MBH
TOTAL SENS.
2
SEER EER
Johnson Controls Unitary Products 7
397763-YTG-B-0508
COOLING CAP ACITY - With Variable Speed Furnaces (Continued)
UNIT MODEL
THGD30S41S1
THGD36S41S1
THGD42S41S1
For Notes See Page 9.
VARIABLE SPEED
FURNACE MODEL
13 SEER HP WITH VARIABLE SPEED FURNACES
PV8*C16 HC42C 21 1000 29.0 24.0 14.00 12.00
PV8*C20 HC42C 21 1100 29.0 25.6 14.00 12.00
P(C,V)9*C16 HC42C 21 1000 29.0 23.8 14.00 12.00
P(C,V)9*C20 HC42C 21 1050 29.0 23.8 14.00 12.00
PV8*C16 HD48C 21 1000 29.0 24.0 14.00 12.00
PV8*C20 HD48C 21 1100 29.0 25.4 14.00 12.00
P(C,V)9*C16 HD48C 21 1000 29.0 23.8 14.00 12.00
P(C,V)9*C20 HD48C 21 1050 29.0 23.8 14.00 12.00
P(C,V)9*D20 HD48D 24 1050 29.0 24.6 14.00 12.00
PV8*A12 FC/MC/PC37A 14 1150 35.0 26.8 13.35 11.50
PV9*A12 FC/MC/PC37A 14 1100 35.0 25.8 13.20 11.50
PV8*B16 FC/MC/PC43B 17 1200 35.0 27.2 13.50 11.50
PV8*C16 FC/MC/PC43C 21 1200 35.0 27.2 13.50 11.50
PV8*C20 FC/MC/PC43C 21 1200 35.0 27.2 13.50 11.50
P(C,V)9*B12 FC/MC/PC43B 17 1200 35.0 27.0 13.50 11.50
P(C,V)9*C16 FC/MC/PC43C 21 1200 35.0 27.2 13.50 11.50
P(C,V)9*C20 FC/MC/PC43C 21 1200 35.0 27.2 13.50 11.50
PV8*C16 FC/MC/PC48C 21 1200 35.0 27.4 13.50 11.50
PV8*C20 FC/MC/PC48C 21 1200 35.0 27.4 13.50 11.50
P(C,V)9*C16 FC/MC/PC48C 21 1200 35.0 27.4 13.50 11.50
P(C,V)9*C20 FC/MC/PC48C 21 1200 35.0 27.4 13.50 11.50
P(C,V)9*D20 FC/MC/PC48D 24 1200 35.0 27.4 13.50 11.50
PV8*C16 HC42C 21 1200 35.0 27.2 13.50 11.50
PV8*C20 HC42C 21 1200 35.0 27.2 13.50 11.50
P(C,V)9*C16 HC42C 21 1200 35.0 27.2 13.50 11.50
P(C,V)9*C20 HC42C 21 1200 35.0 27.2 13.50 11.50
PV8*C16 HD48C 21 1200 35.0 27.2 13.50 11.50
PV8*C20 HD48C 21 1200 35.0 27.2 13.50 11.50
P(C,V)9*C16 HD48C 21 1200 35.0 27.2 13.50 11.50
P(C,V)9*C20 HD48C 21 1200 35.0 27.2 13.50 11.50
P(C,V)9*D20 HD48D 24 1200 35.0 27.2 13.50 11.50
PV8*C16 FC/MC/PC48C 21 1400 42.0 31.6 13.50 11.50
PV8*C20 FC/MC/PC48C 21 1400 42.0 31.8 14.00 11.50
P(C,V)9*C16 FC/MC/PC48C 21 1400 41.5 31.6 13.50 11.50
P(C,V)9*C20 FC/MC/PC48C 21 1350 42.0 31.6 14.00 11.50
P(C,V)9*D20 FC/MC/PC48D 24 1350 42.0 31.8 14.00 12.00
PV8*C16 FC/MC/PC60C 21 1400 41.5 31.4 13.50 11.50
PV8*C20 FC/MC/PC60C 21 1400 41.5 31.6 13.50 11.50
P(C,V)9*C16 FC/MC/PC60C 21 1400 41.0 31.4 13.50 11.50
P(C,V)9*C20 FC/MC/PC60C 21 1350 41.5 31.4 13.50 11.50
P(C,V)9*D20 FC/MC/PC60D 24 1350 41.5 31.6 14.00 11.50
PV8*C16 HC42C 21 1400 41.5 31.4 13.50 11.50
PV8*C20 HC42C 21 1400 41.5 31.4 13.50 11.50
P(C,V)9*C16 HC42C 21 1400 41.5 31.4 13.50 11.50
P(C,V)9*C20 HC42C 21 1350 41.5 31.4 13.50 11.50
P(C,V)9*D20 HC60D 24 1350 41.5 31.6 14.00 11.50
PV8*C16 HD60C 21 1400 42.0 31.8 13.50 11.50
PV8*C20 HD60C 21 1400 42.0 31.8 14.00 11.50
P(C,V)9*C16 HD60C 21 1400 42.0 31.6 13.50 11.50
P(C,V)9*C20 HD60C 21 1350 42.0 31.8 14.00 11.50
P(C,V)9*D20 HD60D 24 1350 42.0 31.8 14.00 12.00
COIL
MODEL
1
W
RATED
CFM
COOLING
Net MBH
TOTAL SENS.
2
SEER EER
8 Johnson Controls Unitary Products
COOLING CAP ACITY - With Variable Speed Furnaces (Continued)
UNIT MODEL
THGD48S41S1
THGD60S41S1
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2. Variable speed furnaces have B.O.D (Blower on Delay) standard.
VARIABLE SPEED
FURNACE MODEL
13 SEER HP WITH VARIABLE SPEED FURNACES
PV8*C16 FC/MC/PC48C 21 1500 46.5 34.2 13.00 11.00
PV8*C20 FC/MC/PC48C 21 1600 47.0 35.4 13.00 11.50
P(C,V)9*C16 FC/MC/PC48C 21 1600 47.0 35.2 13.00 11.00
P(C,V)9*C20 FC/MC/PC48C 21 1600 47.0 35.4 14.00 11.50
P(C,V)9*D20 FC/MC/PC48D 24 1550 47.0 35.6 14.00 11.50
PV8*C16 FC/MC/PC60C 21 1500 46.5 34.6 13.00 11.00
PV8*C20 FC/MC/PC60C 21 1600 47.0 35.8 14.00 11.50
P(C,V)9*C16 FC/MC/PC60C 21 1600 47.0 35.6 13.00 11.00
P(C,V)9*C20 FC/MC/PC60C 21 1600 47.0 35.6 14.00 11.50
P(C,V)9*D20 FC/MC/PC60D 24 1550 47.0 35.8 14.00 11.50
P(C,V)9*D20 HC60D 24 1550 47.0 35.8 14.00 11.50
PV8*C16 HD60C 21 1500 46.5 34.4 13.00 11.00
PV8*C20 HD60C 21 1600 47.0 35.4 14.00 11.50
P(C,V)9*C16 HD60C 21 1600 47.0 35.4 13.00 11.00
P(C,V)9*C20 HD60C 21 1600 47.0 35.4 14.00 11.50
P(C,V)9*D20 HD60D 24 1550 47.0 35.6 14.00 11.50
PV8*C20 MC62C 21 1600 47.5 35.8 14.00 11.50
P(C,V)9*C16 MC62C 21 1600 47.0 35.6 13.00 11.00
P(C,V)9*C20 MC62C 21 1600 47.0 35.8 14.00 11.50
P(C,V)9*D20 MC62D 24 1550 47.5 36.0 14.00 11.80
PV8*C20 MC62C 21 1750 54.0 43.0 13.00 11.45
P(C,V)9*C20 MC62C 21 1650 53.0 41.0 13.00 11.25
P(C,V)9*D20 MC62D 24 1600 53.5 41.0 13.50 11.50
COIL
MODEL
1
W
RATED
CFM
Net MBH
TOTAL SENS.
2
397763-YTG-B-0508
COOLING
SEER EER
Johnson Controls Unitary Products 9
Loading...
