TECHNICAL GUIDE
95.5% AFUE SINGLE STAGE
RESIDENTIAL GAS FURNACES
MULTI-POSITION
MODELS: TG9S
NA TURAL GAS
40 - 130 MBH INPUT
Due to continuous product improvement, specifications
are subject to change without notice.
Visit us on the web at www.york.com
Additional rating information can be found at
www.ahridirectory.org
WARRANTY SUMMARY
A 20-year limited warranty on heat exchangers in residential applications.
A 10-year warranty on the heat exchanger in commercial
applications.
Standard 5-year limited Parts warranty.
Extended lifetime heat exchanger and 1 0-year limited
parts warranty when product is registered online
within 90 days of purchase for replacement or closing
for new home construction.
See Limited Warranty certificate in Users Information Manual for details.
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
400991-YTG-H-0615
DESCRIPTION
These compact units employ induced combustion, reliable hot surface ignition and high heat transfer aluminized tubular heat
exchangers. The units are factory shipped for installation in upflow
or horizontal applications an d may be con verted for downf low applications.
These furnaces are designed for residential installation in a basement, closet, alcove, attic, recreation room or garage and are also
ideal for commercial applications. All units are factory assembled,
wired and tested to assure safe dependable and economical installation and operation.
These units are Category IV, National Fuel Gas Code and may be
vented either through side wall or roof applications using approved
plastic combustion air and vent piping. Approved plastic combustion air and vent piping include Polyflue (a polypropylene venting
systems).
FEATURES
• Easily applied in upflow, horizontal left or right, or downflow
installation with minimal conversion necessary.
• Compact, easy to install, ideal height 33" tall cabinet.
• Blower-off delay for cooling SEER improvement.
• Easy access to controls to connect power/control wiring.
• Built-in, high level self diagnostics with fault code displays
standard on integrated control module for reliable operation.
• Low unit amp requirement for easy replacement application.
• Single wire twinning or staging feature available.
• All models are convertible to use propane (LP) gas.
• Electronic Hot Surface Ignition saves fuel cost with increased
dependability and reliability.
• 100% shut off main gas valve for extra safety.
• 4 speed, direct drive PSC motor.
• 24V, 40 VA control transformer and blower relay supplied for
add-on cooling.
• Hi-tech tubular aluminized steel primary heat exchanger.
• Secondary heat exchanger made of corrosion resistant stai nless steel materials.
• Timed on, adjustable off blower capability for maximum comfort.
• Blower door safety switch.
• Solid removable bottom panel allows easy conversion.
• Airflow leakage less than 1% of nominal airflow at ductblaster
conditions.
• No knockouts to deal with, making installation easier.
• Movable duct connector flanges for application flexibil ity.
• Quiet inducer operation.
• Inducer rotates for easy conversion of venting options.
• Fully supported blower assembly for easy acce ss and removal
of blower.
• External air filters used for maximum flexibility in meeting customers IAQ needs.
• Protection included from air intake, exhaust vent, or condensate blockage.
• No special vent termination required.
• 1/4 turn knobs provided for easy door removal.
• Internal condensate trap design (patent pending) provides
condensate management options and is self-priming to prevent nuisance problems.
• Venting appli cations - may be inst alled as either 2-pi pe (sealed
combustion) or single-pipe vent (using indoor combustion air).
400991-YTG-H-0615
FRONT
33
A
LEFT SIDE
Combustion Air Inlet
Condensate Drain
(Downflow)
Vent Outlet
Thermostat
Wiring
28.5”
Gas Pipe
Entry
Electrical
Entry
Condensate
Drain
Thermostat
Wiring
RIGHT SIDE
Vent Outlet
Condensate Drain
(Downflow)
14”
1”
1.5”
23”
Combustion Air Inlet
Gas Pipe
Entry
Electrical
Entry
Condensate
Drain
Optional Return Air
Cutout (Either side)
29.5”
C
SUPPLY END
.56”
.56”
20”
B
3”
23.8”
.56”
Combustion
Air Inlet
Vent
Outlet
RETURN END
B
24.25”
Cabinet & Duct Dimensions
Models
Nominal
CFM (m
3
/min)
Cabinet
Size
Cabinet Dimensions (Inches)
ABC Lbs
TG9S040A08MP11 800 A 14 1/2 13 3/8 11 3/4 113
TG9S060A10MP11 1000 A 14 1/2 13 3/8 11 3/4 118
TG9S060B12MP11 1200 B 17 1/2 16 3/8 13 1/4 122
TG9S080B12MP11 1200 B 17 1/2 16 3/8 14 3/4 126
TG9S080C16MP11 1600 C 21 19 7/8 16 1/2 136
TG9S080C22MP11 2200 C 21 19 7/8 16 1/2 139
TG9S100C16MP11 1600 C 21 19 7/8 18 1/4 142
TG9S100C20MP11 2000 C 21 19 7/8 18 1/4 145
TG9S120D16MP11 1600 D 24 1/2 23 3/8 21 3/4 153
TG9S120D20MP11 2000 D 24 1/2 23 3/8 21 3/4 156
TG9S130D20MP11 2000 D 24 1/2 23 3/8 No Hole 160
Ratings & Physical / Electrical Data
Models
TG9S040A08MP11 40 38 95.5 30-60 160 1/3 4.8 11x8 15 8.0 14
TG9S060A10MP11 60 57 95.5 30-60 160 1/2 7.1 11x8 15 10.0 14
TG9S060B12MP11 60 57 95.5 30-60 160 1/2 7.1 11x8 15 10.0 14
TG9S080B12MP11 80 76 95.5 35-65 165 1/2 7.1 11x8 15 10.0 14
TG9S080C16MP11 80 76 95.5 35-65 165 3/4 8.8 11x10 15 11.5 14
TG9S080C22MP11 80 76 95.5 35-65 165 1 14.5 11x11 20 17.0 12
Input Output
MBH MBH °F °F HP Amps
AFUE
%
Air Temp.
Rise
Max. Outlet
Air Temp
Blower
TG9S100C16MP11 100 95 95.5 35-65 165 3/4 8.8 11x10 15 11.5 14
Blower
Size
Over-Current
Max
Protect
Total Unit
TG9S100C20MP11 100 95 95.5 35-65 165 1 14.5 11x11 20 17.0 12
TG9S120D16MP11 120 114 95.5 40-70 170 3/4 8.8 11x10 15 11.5 14
TG9S120D20MP11 120 114 95.5 35-65 165 1 14.5 11x11 20 17.0 12
TG9S130D20MP11 130 123.5 95.5 45-75 175 1 14.5 11x11 20 17.0 12
Annual Fuel Utilization Efficiency (AFUE) numbers are determined in accordance with DOE Test procedures.
Wire size and over current protection must comply with the National Electrical Code (NFPA-70-latest edition) and all local codes.
The furnace shall be installed so that the electrical components are protected from water.
2 Johnson Controls Unitary Products
Approximate
Operating Weights
Min. wire Size
Amps
(awg) @ 75 ft
one way
