R-410A
ZH/ZR/XP SERIES
6-1/2 - 12-1/2 TON
60 Hertz
®
Description
ASHRAE 90.1 COMPLIANT
®
YORK
common footprint cabinet and common roof curb for all 6-1/2
through 12-1/2 ton models. All units have two compressors with
independent refrigeration circuits to provide 2 stages of cooling.
The units were designed for light commercial applications and
can be easily installed on a roof curb, slab, or fra me.
All Predator
full perimeter base rails allowing for 3-way forklift access and
overhead rigging. Every unit is completely charged, wired,
piped, and tested at the factory to provide a quick and easy field
installation.
All units are convertible between side and down airflow.
Independent economizer designs are used on side and down
discharge applications, as well as all tonnage sizes.
Predator
cooling only, cooling with electric heat, cooling with gas heat,
heat pump, and heat pump with electric heat. Electric heaters
are available as factory-installed options or field-installed
accessories.
Predator® units are convertible single packages with a
®
units are self-contained and assembled on rigid
®
units are available in the following configurations:
6-1/2 THROUGH 10 TON
12-1/2 TON
Tested in accordance with:
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
Slide-out motor and
blower assembly for
easy adjustment
and service
Belt-drive
blower motor
Power ventor motor
20-
gauge aluminized steel tubular
heat exchanger for
long life (stainless
steel option)
Two-stage gas
heating to maintain
warm, comfortable
temperature
Intelligent control
board for safe and
efficient operation
2Johnson Controls Unitary Products
Heat Pump
246824-YTG-G-1208
Simplicity
board w/screw connectors for T-stat wiring and
Terminal block
for hi-voltage
connection
Second Model
Nameplate Inside
Control Door
Dual stage cooling for maximum
comfort (7-1/2 12-1/2 Only)
Compressor #2
Access (High-Eff
Compressor)
Base Rails w/ Forklift Slots (3 Sides)
& Lifting Holes
Roof curbs in eight- and
fourteen-inch heights. Roof
curbs for transitioning from
Sunline™ footprint to the
XP series footprint are also
available (field installed
accessory)
network connection
®
Control
Toolless
Door Latch
Disconnect location
(optional disconnect switch)
Side entry power
and control wiring
knockouts
Filter access
(2” throw-away)
Compressor #1 Access
(High-Eff Compressor)
Filter drier (solid core)
Condenser
section
Slide-out motor and
blower assembly for
easy adjustment and
service.
Belt-drive
blower
motor
Slide-out drain pain
with steel 3/4” NPT,
Female Connection
Johnson Controls Unitary Products3
246824-YTG-G-1208
Nomenclature
6.5-12.5 Ton York® Model Number Nomenclature
Z H 090 N10 A 2 A AA 4 0 1 2 4 A
Product Category
Z = A/C, Single Pkg., R-410A
X = HP, Single Pkg., R-410A
Product Identifier
H = 11.0+ EER A/C
P = 11.0 EER HP
R = Reheat
Nominal Cooling Capacity
078 = 6.5 Ton
090 = 7.5 Ton
102 = 8.5 Ton
120 = 10.0 Ton
150 = 12.5 Ton
• High Efficiency – High efficiency units reach as high as
11.5 EER. Gas/electric units have electronic spark ignition
and power vented combustion with steady state efficiencies
of 80%. These efficiencies exceed all legislated minimum
levels and provide low operating costs.
• Service Friendly – The Predator
of enhancements which improve serviceability.
The motor and blower slide out of the unit as a common
assembly. This facilitates greater access to all the indoor
airflow components, thus simplifying maintenance and
adjustment.
Service time is reduced through the use of hinged,
toolless panels. Such panels provide access to frequently
inspected components and areas, including the control
box, compressors, filters, indoor motor & blower, and the
heating section. The panels are screwed in place at the
factory to prevent access by children or other
unauthorized persons. It is recommended that the panels
be secured with screws once service is complete.
Service windows have been placed in both condenser
section walls. Rotation of the cover allows easy access to
the condenser coils for cleaning or inspection.
Both the unit control board and ignition control board utilize
flash codes to aid in diagnosis of unit malfunctions. Unique
alarm codes quickly identify the source of the unit alarm.
All units use the same standard filter size. This
standardization removes any confusion on which filter
sizes are needed for replacement.
The non-corrosive drain pan slides out of the unit to permit
easy cleaning. The drain pan is accessed by removing the
drain pan cover plate on the rear of the unit. Once the plate is
removed, the drain pan slides out through the rear of the unit.
®
All Predator
units have a second model nameplate
located inside the control access door. This is to prevent
deterioration of the nameplate through weathering.
• Environmentally Aware – For improved Indoor Air
Quality, foil faced insulation is used exclusively
throughout the units.
• Balanced Heating – The Predator
Heating Comfort” with a balance between 1
gas heating. The first stage of a gas heat Predator
provides 60% of the heating capacity. Balanced heating
allows the unit to better maintain desired temperatures.
• Convertible Airflow Design – The side duct openings
are covered when they leave the factory. If a side supply/
return is desired, the installer simply removes the two side
duct covers from the outside of the unit and installs them
over the down shot openings. No panel cutting is required.
Convertible airflow design allows maximum field flexibility
and minimum inventory.
• System Protection - Suction line freezestats are supplied
on all units to protect against loss of charge and coil frosting
when the economizer operates at low outdoor air
temperatures while the compressors are running. Every unit
has solid-core liquid line filter-driers and high and low-
®
incorporates a number
®
offers “Ultimate
st
and 2nd stage
®
unit
pressure switches. Internal compressor protection is
standard on all compressors. Crankcase heaters are
standard on reciprocating compressors. Scroll compressors
do not require crankcase heaters. Phase Monitors are
standard on units with scroll compressors. This accessory
monitors the incoming power to the unit and protects the
unit from phase loss and reversed phase rotation.
•Advanced Controls - Simplicity® control boards have
standardized a number of features previously available
only as options or by utilizing additional controls.
•Low Ambient - An integrated low-ambient control
allows all units to operate in the cooling mode down to
0°F outdoor ambient without additional assistance.
Optionally, the control board can be programmed to
lockout the compressors when the outdoor air temper
-
ature is low or when free cooling is available.
The Simplicity® control board used in this product
will effectively operate the cooling system down to
0°F when this product is applied in a comfort cooling
application for people. An economizer is typically
included in this type of application. When applying
this product for process cooling applications (computer rooms, switchgear, etc.), please reference
applications bulletin AE-011-07 or call the applications department for Unitary Products @ 1-877UPG-SERV for guidance. Additional accessories
may be needed for stable operation at temperatures
below 30° F.
•Anti-Short Cycle Protection - To aid compressor life,
an anti-short cycle delay is incorporated into the standard controls. Compressor reliability is further ensured
by programmable minimum run times. For testing, the
anti-short cycle delay can be temporarily overridden
with the push of a button.
•Fan Delays - Fan on and fan off delays are fully pro-
grammable. Furthermore, the heating and cooling fan
delay times are independent of one another. All units
are programmed with default values based upon their
configuration of cooling and heat.
•Safety Monitoring - The control board monitors the
high and low-pressure switches, the freezestats, the
gas valve, if applicable, and the temperature limit
switch on gas and electric heat units. The unit control
board will alarm on ignition failures, compressor lock
-
outs and repeated limit switch trips.
•Nuisance Trip Protection and Strikes - To prevent
nuisance trouble calls, the control board uses a “three
times, you’re out” philosophy. The high and low-pres
sure switches and the freezestats must trip three times
within two hours before the unit control board wi ll lock
out the associated compressor.
•On Board Diagnostics - Each alarm will energize a
trouble light on the thermostat, if so equipped, and
Johnson Controls Unitary Products5
246824-YTG-G-1208
flash an alarm code on the control board LED. Each
high and low-pressure switch alarm as well as each
freezestat alarm has its own flash code. The control
board saves the five most recent alarms in memory,
and these alarms can be reviewed at any time.
Alarms and programmed values are retained through
the loss of power.
• Reliable – From the beginning – All units undergo
computer automated testing before they leave the factory.
Units are tested for refrigerant charge and pressure, unit
amperage, and 100% functionality. For the long term – All
Predator
®
units are painted with a long lasting, powder
paint that stands up over the life of the unit. The paint
used has been proven by a 1000 hour salt spray test.
• Flexible Placement – All models and configurations
share the same cabinet/footprint and thus the same roof
curb. You have the flexibility to set one curb and choose
the correct tonnage size and heating option after the
internal loads have been determined.
®
To further simplify planning and installation, Predator
ZH/ZR/XP cabinets are designed to fit your roof. With the
optional roof curb, the unit ductwork is designed to fit
around 24” on-center joists or between 48” on-center
joists.
The drain pan can be rotated to drain to either the front or
the rear of the unit. Additionally, the drain pan can be
fitted to drain through the roof curb. As it is sometimes
difficult to have a level installation, the drain pan features
a generous slope to ensure proper drainage.
• Full Perimeter Base Rails – The permanently attached
base rails provide a solid foundation for the entire unit and
protect the unit during shipment. The rails offer forklift
access from 3 sides, and rigging holes are available so that
an overhead crane can be used to place the units on a roof.
• Easy Installation – Gas and electric utility knockouts are
supplied in the unit underside as well as the side of the unit.
A clearly identified location is provided to mount a field
supplied electrical disconnect switch. Utility connections can
be made quickly and with a minimum amount of field labor.
All units are shipped with 2” throw-away filters installed.
• Wide Range of Indoor Airflows – All indoor fan motors
are belt-drive type providing maximum flexibility to handle
most airflow requirements. For high static applications,
factory installed alternate indoor fan motors are available.
With the optional indoor fan motor, all units can supply
nominal airflow at a minimum of 1.5” ESP.
• Warranty - All models include a 1-year limited warranty
on the complete unit. Compressors and electric heater
elements each carry a 5-year warranty. Aluminized steel
and stainless steel tubular heat exchangers carry a 10year warranty.
Factory Installed Options
YORK® offers several equipment options factory installed, for
the Predator
• Optional Factory Installed Economizers - Predator units
®
line.
offer a variety of optional factory installed economizers
with low leak dampers. The outdoor air enthalpy sensor
enables economizer operation if the outdo or e nth al py i s
less than the setpoint of the economizer logic module. See
economizer options section to determine the correct
economizer for your application.
• Downflow Economizer - (With barometric relief) The economizer is provided with a single enthalpy input.
The economizer is 2% low leakage type, and is shipped
installed and wired. The installer needs only to
assemble and mount the outdoor air hood (Provided).
The economizer has spring return, fully modulating
damper actuators and is capable of introducing up to
100% outdoor air. As the outdoor air intake dampers
open, the return air dampers close. The changeover
from mechanical refrigeration to economizer operation is
regulated by the standard single enthalpy input. There is
an optional input dual dry bulb available. To meet
regulated air standards, the economizer control accepts
an optional CO
input fordemand ventilation. With
2
single enthalpy input, the economizer control monitors
outdoor air. The dual enthalpy kit provides a second
input used to monitor the return air. With a dual input kit
installed, the economizer control compares the values of
the two enthalpy or temperature inputs and positions the
dampers to provide the maximum efficiency possible.
• Horizontal Economizer - (Without barometric relief) All features of the downflow economizer exist except you
must order the duct mount barometric relief separately.
You must order a 1EH0408 if you are installing a
power exhaust. You can order a 1RD0411 Barometric
Relief for horizontal flow economizers only.
• BAS Ready Economizer -(With barometric relief) The economizer is provided with an actuator that
requires a 0-10V DC input from an external source (i.e.,
field installed building automation system controller).
Power exhaust options are available. The economizer is
2% low leakage type with spring return and fully
modulating dampers capable of introducing up to 100%
outside air. Also include 2” pleated filters.
• Slab Economizer for Energy Recovery Ventilators(With barometric relief and Fresh Air Hood) - The
economizer is provided with a single enthalpy input. The
economizer is 2% low leakage type, and is shipped
installed and wired. The economizer has spring return,
fully modulating damper actuators and is capable of
introducing up to 100% outdoor air. As the outdoor air
intake dampers open, the return air dampers close. The
changeover from mechanical refrigeration to
economizer operation is regulated by the standard
single enthalpy input. There is an optional input dual dry
bulb available. To meet regulated air standards, the
economizer control accepts an optional CO
input for
2
demand ventilation.With single enthalpy input, the
economizer control monitors outdoor air. The dual
enthalpy kit provides a second input used to monitor the
return air. With a dual input kit installed, the economizer
control compares the values of the two enthalpy or
temperature inputs and positions the dampers to
provide the maximum efficiency possible.
• Power Exhaust (Downflow only) - This accessory
installs in the unit with a down flow economizer.
6Johnson Controls Unitary Products
246824-YTG-G-1208
• Motorized Outdoor Air Damper - The motorized outdoor
air damper includes a slide-in/plug-in damper assembly
with an outdoor air hood and filters. The outdoor air
dampers open to the preset position when the indoor fan
motor is energized. The damper has a range of 0% to
100% outdoor air entry. Factory installed option or field
installed accessory.
• Alternate Indoor Blower Motor - For applications with
high static restrictions, units are offered with optional
indoor motors that provide higher static output and/or
higher airflow, depending upon the installer’s needs.
• Aluminized Steel Gas Heat Exchanger - For
applications in non-corrosive environments.
• Stainless Steel Gas Heat Exchanger - For applications
in corrosive environments, this option provides a full
stainless steel heat exchanger assembly.
• Stainless Steel Drain Pan - An optional rust-proof
stainless steel drain pan is available to provide years of
trouble-free operation in corrosive environments.
• Electric Heaters - The electric heaters range from 9kW to
54kW and are available in all the voltage options of the
base units. All heaters are dual staged. All heaters are
intended for single point power supply.
• Disconnect Switch - For gas heat units and cooling units
with electric heat, a HACR breaker sized to th e unit is
provided. For cooling only units, a switch sized to the
largest electric heat available for the particular unit is
provided. Factory installed optio n onl y.
• Convenience Outlet - (Non-Powered/Powered) - This
option locates a 120V single-phase GFCI outlet with cover,
on the corner of the unit housing adjacent to the
compressors. The “Non-powered” option requires the
installer to provide the 120V single-phase power source and
wiring. The “Powered” option is powered by a stepdown
transformer in the unit. Factory installed option only.
• Smoke Detectors - The smoke detectors stop operation
of the unit by interrupting power to the control board if
smoke is detected within the air compartment. Available
for both the supply and/or return air.
Factory installed smoke detectors in the return air, may be
subjected to freezing temperatures during "off" times due
to out side air infiltration. These smoke detectors have an
operational limit of 32 °F to 131°F. Smoke detectors
installed in areas that could be out side those limitations
will have to be moved to prevent having false alarms.
• Phase Monitors - Designed to prevent unit damage. The
phase monitor will shut the unit down in an out-of phase
condition. (Standard on units with Scroll Compressors.)
• Coil Guard - Customers can purchase a coil guard kit to
protect the condenser coil from damage. Additionally, this
kit stops animals and foreign objects from entering the
space between the inner condenser coil and the main
cabinet. This is not a hail guard kit.
• Dirty Filter Switch - This kit includes a differential
pressure switch that energizes the fault light on the unit
thermostat, indicating that there is an abnormally high
pressure drop across the filters. Factory installed option or
field installed accessory.
• Technicoat Condenser Coils - The condenser coils are
coated with a phenolic coating for protection against
corrosion due to harsh environments.
• Technicoat Evaporator Coil - The evaporator coils are
coated with a phenolic coating for protection against
corrosion due to harsh environments.
• Hot Gas Bypass - Allows operation during low load
conditions while avoiding coil frosting and damage to
compressor. When suction pressure falls below valve
setpoint, the valve modulates hot gas to the inlet of the
evaporator.
Control Options
• BAS - Building Automation System Controls Simplicity®
INTELLI-Comfort™ Control - The York® Simplicity®
INTELLI-Comfort™ control is factory installed. It includes a
supply air sensor, a return air sensor, and an outside air
sensor. There are provisions for a field installed dirty filter
indicator switch, an air-proving switch, an Outside Air
Humidity sensor, a Return Air Humidity sensor, an Inside
IAQ sensor, and an Outside Air IAQ sensor. Construction
mode operation, 365-day real time clock with 7 day
programming plus holiday scheduling is built-in. Two
different modes of demand ventilation are achieved through
the INTELLI-Comfort™ using CO
inside CO2 sensor to perform Demand Ventilation. It can
also use an Outside CO2 sensor to perform Differential
Demand Ventilation. It uses a Patented Comfort Ventilation
algorithm to provide comfortable ventilation air
temperature. The patented economizer-loading algorithm
will protect the equipment when harsh operating conditions
exist. Humidity in the occupied space or return duct can be
monitored and controlled via humidity sensors and the onboard connection for hot gas re-heat system. It uses the
INTELLI-Start™ algorithm to maximize energy savings by
recovering the building from the Unoccupied Setpoints to
the Occupied Setpoints just in time for the Occupied Time
Period to begin. The Simplicity
balances space temperature, ventilation air temperature,
and humidity for ultimate comfort.
CO
2
• Simplicity® INTELLI-Comfort™ with ModLINC
Control - The York® Simplicity
ModLINC control is factory installed. It includes all the
features of the INTELLI-Comfort™ control with an
additional control to translate communications from
MODBUS to the BACnet MSTP protocol.
• Novar® BAS Control - The Novar® building automation
system controller is factory installed. Incudes supply air
sensor, return air sensor, dirty filter indicator switch, and
air proving switch.
• Johnson Controls BAS Control - The Johnson Control
YK-UNT-1126 building automation system controller is
factory installed. Includes supply air sensor, return air
sensor, dirty filter indicator switch, and air proving switch.
sensors. It uses an
2
®
INTELLI-Comfort™
®
INTELLI-Comfort™ with
Johnson Controls Unitary Products7
246824-YTG-G-1208
• CPC BAS Control - The Computer Process Controls
Model 810-3060 ARTC Advanced Rooftop building
automation system controller is factory installed. Includes
supply air sensor, return air sensor, dirty filter indicator
switch and air proving switch.
• Honeywell BAS Control - The Honeywell W7750C
building automation system controller is factory installed.
Includes air supply sensor, return air sensor, dirty filter
indicator switch, and air proving switch.
• York Commercial Comfort System (YCCS) - Provides
rooftop system integration for YCCS single zone and
change-over bypass systems.
Field Installed Accessories
YORK® offers several equipment accessories for field
installation, for the Predator
• Downflow Economizer - (With barometric relief) - The
economizer is provided with a single enthalpy input. The
economizer is 2% low leakage type. The economizer has
spring return, fully modulating damper actuators and is
capable of introducing up to 100% outdoor air. As the
outdoor air intake dampers open, the return air dampers
close. The changeover from mechanical refrigeration to
economizer operation is regulated by the standard single
enthalpy input. There is an optional input dual dry bulb
available. To meet regulated air standards, the economizer
control accepts an optional CO
ventilation. With single enthalpy input, the economizer
control monitors outdoor air. The dual enthalpy kit provides a
second input used to monitor the return air. With a dual input
kit installed, the economizer control compares the values of
the two enthalpy or temperature inputs and positions the
dampers to provide the maximum efficiency possible.
• Horizontal Economizer - (Without barometric relief) All features of the downflow economizer exist except you
must order the duct mount barometric relief separately.
You must order a 1EH0408 if you are installing a
power exhaust. You can order a 1RD0411 Barometric
Relief for horizontal flow economizer.
• Slab Economizer for Energy Recovery Ventilator(Without barometric relief or Fresh Air Hood) - The
economizer is provided with a single enthalpy input. The
economizer is 2% low leakage type. The economizer has
spring return, fully modulating damper actuators and is
capable of introducing up to 100% outdoor air. As the
outdoor air intake dampers open, the return air dampers
close. The changeover from mechanical refrigeration to
economizer operation is regulated by the standard single
enthalpy input. There is an optional input dual dry bulb
available. To meet regulated air standards, the economizer
control accepts an optional CO
ventilation.With single enthalpy input, the economizer control
monitors outdoor air. The dual enthalpy kit provides a
second input used to monitor the return air. With a dual input
kit installed, the economizer control compares the values of
the two enthalpy or temperature inputs and positions the
dampers to provide the maximum efficiency possible.
You can order 1EH0409 Barometric Relief/FA Hood for
field installations without an ERV.
®
line.
input fordemand
2
input fordemand
2
• Dual Enthalpy Control, Accessory - This kit contains
the required components to convert a single enthalpy
economizer to dual enthalpy.
• Barometric Relief Damper - Zero to 100% capacity
barometric relief dampers for use with horizontal flow, or
field installed slab economizers.
• Power Exhaust - This accessory installs in the unit with a
down flow economizer. Power exhaust plugs into the
connector in the unit bulkhead. You must purchase
1EH0408 barometric relief when applying to a
horizontal flow application.
• Manual Outdoor Air Damper - Like the motorized outdoor
air damper, each manual outdoor air damper incl udes a
slide-in damper assembly with an outdoor air hood and
filters. Customers have a choice of dampers with ranges of
0% to 100% or 0% to 35% outdoor air entry.
• Motorized Outdoor Air Damper - The motorized outdoor
air damper includes a slide-in/plug-in damper assembly with
an outdoor air hood and filters. The outdoor air dampers
open to the preset position when the indoor fan motor is
energized. The damper has a range of 0% to 100% outdoor
air entry. Factory installed option or field installed accessory.
• Smoke Detectors - The smoke detectors stop operation
of the unit by interrupting power to the control board if
smoke is detected within the air compartment.
Sensor- Senses CO2 levels and automatically
• CO
2
overrides the economizer when levels rise above the
preset limits.
• Dirty Filter Switch - This kit includes a differential
pressure switch that energizes the fault light on the unit
thermostat, indicating that there is an abnormally high
pressure drop across the filters.
• Coil Guard - Field installed decorative wire coil guard.
• Hail Guard - This kit includes a sloped hood which installs
over the outside condenser coil and prevents damage to
the coil fins from hail strikes. Field installed accessory only.
• Flue Exhaust Extension Kit - In locations with wind or
weather conditions which may interfere with proper
exhausting of furnace combustion products, this kit can be
installed to prevent the flue exhaust from entering nearby
fresh air intakes.
• -60°F Gas Heat Kit - For installations which require gas
heat units to perform in low ambient temperatures, a gas
section heating kit is available. This kit provides electric
heat in the gas heat controls section to ensure the gas
valve and controls will continue to function properly at
extremely low temperatures.
• Gas Heat High Altitude Kit - This kit converts a gas heat
unit to operate at high altitudes, 2,000 to 6,000 feet.
Conversion kits are available for natural gas and propane.
• Gas Heat Propane Conversion Kit - This kit converts a
gas-fired heater from natural gas to propane. It contains the
main burner orifices and gas valve replacement springs.
• Gas Piping Kit - Contains pipe nipples, fittings and gas cock
required for gas supply connection with external shut off.
• Electric Heaters - The electric heaters range from 9 kW
to 54kW and are available in all the voltage options of the
base units. All heaters are dual staged. Cooling units
8Johnson Controls Unitary Products
246824-YTG-G-1208
include an adapter panel for easy installation of the
electric heaters. Necessary hardware and connectors are
included with the heaters. All heaters are intended for
single point power supply.
• Low Limit / Compressor Lockout Kit
• Compressor Lockout (CLO): To prevent mechanical
(compressorized) operation of the unit during cold
outdoor conditions where there is a risk of returning
liquid refrigerant back to the compressors.
• Low Limit Control (LLC): To prevent the supply air
from dropping below a specified setpoint by utilizing the
units first stage heating means when there is a demand
for cooling during cold outside conditions.
• Metal Frame Filter Kit - Metal frame with polyester filter
medium.
• Permanent Filters - Permanent filters are available.
• Roof Curbs - The roof curbs have insulated decks and are
shipped disassembled The roof curbs are available in 8” and
14” heights. For applications with security concerns, burglar
bars are available for the duct openings of the roof curbs.
• Roof Curb Transition - Single Piece Adapter (10” High) Roof curbs for transitioning from Sunline™ units to
Predator
®
units. Fits 7.5 to 12.5 Sunline™ roof curbs only.
• Burglar Bars - Mount in the supply and return openings
to prevent entry into the duct work.
• Thermostat - The units are designed to operate with 24volt electronic and electro-mechanical thermostats. All
units (with or without an economizer) operate with twostage heat/two-stage cool or two-stage cooling only
thermostats, depending upon unit configuration.
2EC04700924Dual Enthalpy Control (Use with Single Enthalpy Economizer)
1EH0407Hood Kit, Downflow Economizer (Included with all Do wnflow Economizers)
1RD0411Barometric Relief Kit, Ductmount for Horizontal Application (Incl. Damper & Hood)
1EH0408Barometric Relief Kit, Ductmount for Horizontal Application w/Power Exhaust (Incl. Damper & Hood)
1EH0409Barometric Relief / Hood Kit, for Field Installed Slab Econ. w/o ERV (Incl. Barometric Relief & FA Hood)
2AQ04700424CO2 Detector Unit Mount
2AQ04700324CO2 Detector Space Mount
2SD04700424Smoke Detector, Supply or Return (Return Not Available with Horizontal Economizer)
2MK04700624Low Limit / Compressor Lockout Kit
1CG0419Coil Guard (Electric / Electric & HP models), 8-1/2 and 10 Ton
1CG0420Coil Guard (Gas / Electric models), 8-1/2 and 10 Ton
1CG0424Coil Guard (Electric / Electric and HP models), 12-1/2 Ton
1CG0425Coil Guard (Gas / Electric models), 12-1/2 Ton
1CG0427Coil Guard (Electric / Electric & HP Models), 6-1/2 and 7-1/2 Ton
1CG0428Coil Guard (Gas / Electric Models), 6-1/2 and 7-1/2 Ton
1HG0411Hail Guard Kit
1HG0415Hail Guard Kit, 42" Tall Cabinet
1GP0405Gas Piping Kit
1NP0442Propane Conversion Kit
1HA0442High Altitude Kit for Natural Gas
1HA0443High Altitude Kit for Propane
1FE0412Flue Exhaust Extension Kit
2BC04700106Gas Heat Kit, -60 deg F, 230V
2BC04700151Gas Heat Kit, -60 deg F, 460V
2BC04700154Gas Heat Kit, -60 deg F, 575V
1FL0402Permanent Filter Kit
1FL0423Permanent Filter Kit, 42" Tall Cabinet
2DF0401Dirty Filter Switch
1FF0410Filter Frame Kit, Metal
1FF0411Metal Filter Frame Kit, 42" Tall Cabinet
Guide Specifications
GENERAL
Units shall be manufactured by York International Unitary
Products in an ISO 9001 certified facility. YORK® Predator
units are convertible single packages with a common footprint
cabinet and common roof curb for all 6-1/2 through 12-1/2 ton
models. All units have two compressors with independent R410a refrigeration circuits to provide 2 stages of cooling. The
units were designed for light commercial applications and can
be easily installed on a roof curb, slab, or frame. All Predator
units are self-contained and assembled on rigid full perimeter
base rails allowing for 3-way forklift access and overhead
rigging. Every unit is completely charged with R-410a, wired,
piped, and tested at the factory to provide a quick and easy
field installation. All units are convertible between side and
down airflow. Independent economizer designs are used on
side and down discharge applications, as well as all tonnage
sizes. Predator
®
units are available in the following
configurations: cooling only, cooling with electric heat, cooling
with gas heat, heat pump, and heat pump with electric heat.
Electric heaters are available as factory-installed options or
field-installed accessories.
®
DESCRIPTION
Units shall be factory assembled, single package, (Elec/Elec, Gas/
Elec), designed for outdoor installation. They shall have built in
field convertible duct connections for down discharge supply/return
or horizontal discharge supply/return and be available with factory
installed options or field installed accessories. The units shall be
factory wired, piped and charged with R-410a refrigerant and
factory tested prior to shipment. All unit wiring shall be both
numbered and color coded. The cooling performance shall be
rated in accordance with DOE and ARI test procedures. Units shall
®
be CSA certified to ANSI Z21.47 and UL 1995/CAN/CSA No. 236M90 standards.
UNIT CABINET
Unit cabinet shall be constructed of G90 galvanized steel with
exterior surfaces coated with a non-chalking, powder paint
finish, certified at 1000 hour salt spray test per ASTM-B117
standards. Indoor blower sections shall be insulated with up to
1” thick insulation coated on the airside. Aluminum foil faced
insulation shall be used in the unit’s compartments and be
fastened to prevent insulation from entering the air stream.
Cabinet doors shall be hinged with toolless access for easy
servicing and maintenance. Full perimeter base rails shall be
provided to assure reliable transit of equipment, overhead
rigging, fork truck access and proper sealing on roof curb
applications. Disposable 2” filters shall be furnished and be
10Johnson Controls Unitary Products
246824-YTG-G-1208
accessible through hinged access door. Fan performance
measuring ports shall be provided on the outside of the cabinet
to allow accurate air measurements of evaporator fan
performance without removing panels or creating bypass of the
coils. Condensate pan shall be slide out design, constructed of
a non corrosive material, internally sloped and conforming to
ASHRAE 62-B9 standards. Condensate connection shall be a
minimum of ¾” I.D. female and be rigid mount connection.
INDOOR (EVAPORATOR) FAN ASSEMBLY
Fan shall be a belt drive assembly and include an adjustable
pitch motor pulley. Job site selected brake horsepower shall not
exceed the motors nameplate horsepower rating plus the service factor. Units shall be designed to operate within the service
factor. Fan wheel shall be double inlet type with forward curve
blades, dynamically balanced to operate smoothly throughout
the entire range of operation. Airflow design shall be constant
volume. Bearings shall be sealed and permanently lubricated
for longer life and no maintenance. Entire blower assembly and
motor shall be slide out design.
OUTDOOR (CONDENSER) FAN ASSEMBLY
The outdoor fans shall be of the direct drive type, discharge air
vertically, have aluminum blades riveted to corrosion resistant
steel spider brackets and shall be dynamically balanced for
smooth operation. The outdoor fan motors shall have permanently
lubricated bearings internally protected against overload
conditions and staged independently. A cleaning window shall be
provided on two sides of the units for coil cleaning.
REFRIGERANT COMPONENTS
Compressors:
a. Shall be fully hermetic type, direct drive, internally
protected with internal high-pressure relief and over
temperature protection. The hermetic motor shall be
suction gas cooled and have a voltage range of + or –
10% of the unit nameplate voltage.
b. Shall have internal spring isolation and sound muffling to
minimize vibration and noise, and be externally isolated
on a dedicated, independent mounting.
Coils:
a. Evaporator and condenser coils shall have aluminum
plate fins mechanically bonded to seamless internally
enhanced copper tubes with all joints brazed. Special
Phenolic coating shall be available as a factory option.
b. Evaporator and condenser coils shall be of the direct
expansion, draw-thru design.
Refrigerant Circuit and Refrigerant Safety Components shall
include:
a. Independent fixed-orifice or thermally operated
expansion devices.
b. Solid core filter drier/strainer to eliminate any moisture or
foreign matter.
c. Accessible service gage connections on both suction
and discharge lines to charge, evacuate, and measure
refrigerant pressure during any necessary servicing or
troubleshooting, without losing charge.
d. The unit shall have two independent refrigerant circuits,
equally split in 50% capacity increments.
Unit Controls:
a. Unit shall be complete with self-contained low-voltage
control circuit protected by a resettable circuit breaker on
the 24-volt transformer side.
b. Unit shall incorporate a lockout circuit which provides
reset capability at the space thermostat or base unit
should any of the following standard safety devices trip
and shut off compressor:
c. Loss-of-charge/Low-pressure switch.
• High-pressure switch.
• Freeze-protection thermostat, evaporator coil. If any of
the above safety devices trip, an LED (light-emitting
diode) indicator shall flash a diagnostic code that
indicates which safety switch has tripped.
d. Unit shall incorporate “AUTO RESET” compressor over
temperature, over current protection.
e. Unit shall operate with conventional thermostat designs
and have a low voltage terminal strip for easy hook-up.
f. Unit control board shall have on-board diagnostics and
fault code display.
g. Standard controls shall include anti-short cycle and low
voltage protection, and permit cooling operation down to
0 ºF.
h. Control board shall monitor each refrigerant safety switch
independently.
i. Control board shall retain last 5 fault codes in non-
volatile memory, which will not be lost in the event of a
power loss.
GAS HEATING SECTION (IF EQUIPPED)
Heat exchanger and exhaust system shall be constructed of
aluminized steel and shall be designed with induced draft combustion with post purge logic, energy saving direct spark ignition, and redundant main gas valve. The heat exchanger shall
be of the tubular type, constructed of T1-40 aluminized steel for
corrosion resistance and allowing minimum mixed air entering
temperature of 40 ºF. Burners shall be of the in-shot type, constructed of aluminum-coated steel. All gas piping shall enter the
unit cabinet at a single location, through either the side or bottom, without any field modifications. An integrated control board
shall provide timed control of evaporator fan functioning and
burner ignition. Heating section shall be provided with the following minimum protection:
a. Primary and auxiliary high-temperature limit switches.
b. Induced draft pressure sensor.
c. Flame roll out switch (manual reset).
Johnson Controls Unitary Products11
246824-YTG-G-1208
d. Flame proving controls. Unit shall have two independent
stages of capacity (60% 1st stage, 100% 2nd stage).
ELECTRIC HEATING SECTION (IF EQUIPPED)
An electric heating section, with nickel chromium elements,
shall be provided in a range of 9 thru 54 KW, offering two states
of capacity all sizes. The heating section shall have a primary
limit control(s) (automatic reset) to prevent the heating element
system from operating at an excessive temperature. The Heating Section assembly shall slide out of the unit for easy maintenance and service. Units with Electric Heating Sections shall be
wired for a single point power supply with branch circuit fusing
(where required).
UNIT OPERATING CHARACTERISTICS
Unit shall be capable of starting and running at 125 ºF outdoor
temperature, exceeding maximum load criteria of ARI Standard
340/360. The compressor, with standard controls, shall be
capable of operation down to 0 ºF outdoor temperature. Unit
shall be provided with fan time delay to prevent cold air delivery
before heat exchanger warms up. (Gas heat only)
ELECTRICAL REQUIREMENTS - All unit power wiring shall
enter unit cabinet at a single factory provided location and be
capable of side or bottom entry to minimize roof penetrations
and avoid unit field modifications. Separate side and bottom
openings shall be provided for the control wiring.
ST ANDARD LIMITED WARRANTIES - Compressor – 5 Years,
Heat Exchanger – 10 Years, Elect. Heat Elem. – 5 Years,
Parts – 1 Year
FACTORY INSTALLED OPTIONAL OUTDOOR AIR (Shall be
made available by either/or):
• ELECTRONIC ENTHALPY AUTOMATIC ECONOMIZER
– Outdoor and return air dampers that are interlocked and
positioned by a fully-modulating, spring-return damper
actuator. The maximum leakage rate for the outdoor air
intake dampers shall not exceed 2% when dampers are
fully closed and operating against a pressure differential
of 0.5 IWG. A unit-mounted potentiometer shall be
provided to adjust the outdoor and return air damper
assembly to take in outdoor air to meet the minimum
ventilation requirement of the conditioned space during
normal operation. During economizer operation, a mixedair temperature control shall modulate the outdoor and
return air damper assembly to prevent the supply air
temperature from dropping below 55 ºF. Changeover from
compressor to economizer operation shall be provided by
an integral electronic enthalpy control that feeds input into
the basic module. The outdoor intake opening shall be
covered with a rain hood that matches the exterior of the
unit. Water eliminator/filters shall be provided.
Simultaneous economizer/compressor operation is also
possible. Dampers shall fully close on power loss.
Available with barometric relief or power exhaust.
• MOTORIZED OUTDOOR AIR DAMPERS – Outdoor and
return air dampers that are interlocked and positioned by
a 2-position, spring-return damper actuator. The
maximum leakage rate for the outdoor air intake dampers
shall not exceed 2% when dampers are fully closed and
operating against a pressure differential of 0.5 IWG. A
unit-mounted potentiometer shall be provided to adjust
the outdoor and return air damper assembly to take in the
design CFM of outdoor air to meet the ventilation
requirements of the conditioned space during normal
operation. Whenever the indoor fan motor is energized,
the dampers open up to one of two pre-selected positions
– regardless of the outdoor air enthalpy. Dampers return
to the fully closed position when the indoor fan motor is
de-energized. Dampers shall fully close on power loss.
ADDITIONAL FACTORY INSTALLED OPTIONS
• ALTERNATE INDOOR BLOWER MOTOR – For
applications with high restrictions, units are available with
optional indoor blower motors that provide higher static
output and/or higher airflow.
• CONVENIENCE OUTLET (POWERED/NON-POWERED)–
Unit can be provided with an optional 120VAC GFCI outlet
with cover on the corner of the unit housing the compressors.
• ELECTRIC HEAT - Electric Heaters range from 9 kW to
54 kW and are available in all the voltage options of the
base unit.
• PHASE MONITOR - Designed to prevent damage in outof-phase condition.
• COIL GUARD
damage.
• BAS CONTROLS - Include supply air sensor, return air
sensor, dirty filter indicator and air proving switch.
• DIRTY FILTER SWITCH – This kit includes a differential
pressure switch that energizes the fault light on the unit
thermostat, indicating that there is an abnormally highpressure drop across the filters.
• BREAKER – An HACR breaker can be factory installed
on gas heat units or cooling units with electric heat.
• DISCONNECT SWITCH - A disconnect can be factory
installed on a cooling only units sized for the largest
electric heat available.
• STAINLESS STEEL HEAT EXCHANGER – For
applications in a corrosive environment, this option
provides a full stainless steel heat exchanger assembly.
• SMOKE DETECTOR – A smoke detector can be factory
mounted and wired in the supply and/or return air
compartments.
OTHER PRE-ENGINEERED ACCESSORIES AVAILABLE
• ROOF CURB - 14” and 8” high, full perimeter knockdown
curb, with hinged design for quick assembly.
• BAROMETRIC RELIEF DAMPER – (Unit mounted –
Downflow, Duct Mounted – Horizontal) – Contains a rain
hood, air inlet screen, exhaust damper and mounting
hardware. Used to relieve internal air pressure through
the unit during economizer operation.
- Designed to prevent condenser coil
12Johnson Controls Unitary Products
246824-YTG-G-1208
• PROPANE CONVERSION KIT – Contains new orifices
and gas valve springs to convert from natural to L.P. gas.
• 60ºF GAS HEAT KIT – Provides an electric heat kit for the
gas compartment for use in extreme low ambient
conditions.
• ECONOMIZER (Downflow and Horizontal flow)
• POWER EXHAUST – (Unit mount – Downflow, Duct
mount – Horizontal flow)
• DUAL ENTHALPY KIT - Provides a second input to
economizer to monitor return air.
REHEAT MODE SEQUENCE OF OPERATION
The reheat control board allows the user to select two different
modes of operation via a jumper connection on the board. (See
Figure 3.) Each mode is described below.
“NORMAL” MODE
When the reheat control board (RCB) detects a need for dehumidification (24VAC) at "HUM" via the field supplied dehumidistat connected to RHTB-1 and RHTB-2 and there is not a call for
cooling, it energizes the hot gas relay (HGR), which energizes
the 3-way valve (SOL 3), the condenser coil valve (SOL 2), and
de-energizes the reheat coil bleed valve (SOL 1). (In the
ZR150, SOL 2 is only energized when the discharge pressure
in circuit #1 rises above 400 psig and de-energizes SOL 2 after
the discharge pressure falls below 320 psig. Both outdoor fans
of circuit #1 in the ZR150 also disengage to conserve energy.)
The Y1 signal is passed to the unit control board (UCB), which
engages circuit # 1, resulting in circuit #1 reheat mode opera
tion.
When the room thermostat calls for first stage cooling, with or
without a call for dehumidification, the RCB senses a signal
through "Y1", de-energizing the HGR, which de-energizes SOL
3 and SOL 2 and energizes SOL 1, engaging circuit #1, result
ing in circuit #1 cooling mode operation.
When the room thermostat calls for second stage cooling, the
RCB senses a signal through "Y1" & "Y2" and engages circuit
#1 and circuit #2 in cooling mode.
Indoor blower operation is initiated upon a call for first stage
cooling, second stage cooling or dehumidification.
Anytime there is a call for 2 stages of cooling, the unit will not
operate in the reheat mode, even if there is a call for dehumidification at "HUM".
The unit will not operate in the reheat mode if there is any call
for heating.
On units with economizers, the unit will not operate in the
reheat mode if there is a call for cooling and the economizer is
operating as first stage of cooling.
All safety devices function as previously described.
"ALTERNATE” MODE
When the RCB detects a need for dehumidification (24VAC) at
"HUM" via the field supplied dehumidistat connected to RHTB-1
and RHTB-2, and there is not a call for cooling, it energizes the
HGR, which energizes the SOL 3, SOL 2, and de-energizes
SOL 1. (In the ZR150, SOL 2 is only energized when the dis
charge pressure in circuit #1 rises above 400 psig and de-energizes SOL 2 after the discharge pressure falls below 320 psig.
Both outdoor fans of circuit #1 in the ZR150 also disengage to
conserve energy.) The unit then operates with circuit #1 in
reheat mode and circuit #2 in cooling mode.
When the room thermostat calls for first stage cooling while
there is still a call for dehumidification, no operational change is
made. The call for cooling is ignored and the unit continues to
operate with circuit #1 in reheat mode and circuit #2 in co oling
mode.
When the room thermostat calls for second stage cooling, the
RCB senses a signal through "Y1" and "Y2" and de-energizes
-
the HGR, which de-energizes SOL 3 and SOL 2, and energizes
SOL 1. Both circuits operate in the cooling mode.
Indoor blower operation is initiated upon a call for first stage
cooling, second stage cooling or dehumidification.
Anytime there is a call for 2 stages of cooling, the unit will not
-
operate in the reheat mode, even if there is still a call for dehu
midification at "HUM".
The unit will not operate in the reheat mode if there is any call
for heating.
All safety devices function as previously described.
-
-
Johnson Controls Unitary Products13
246824-YTG-G-1208
Reheat Control Board
R
Y1
Y2
W1
W2
OCC
P4
K1
G
K2
C
COM
`
P6
HGR
P5
P3
HGRR
HUM
K4
K3
MODE
SELECTION
JUMPER
DEHUMIDISTAT
HARNESS
CONNECTION
14Johnson Controls Unitary Products
Physical Data
ZH078-150 Physical Data
246824-YTG-G-1208
Component
Nominal Tonnage6.57.58.51012.5
ARI COOLING PERFORMANCE
Gross Capacity @ ARI A point (Btu)7900093000106000126000156000
ARI net capacity (Btu) 7600090000102000122000150000
EER11.411.411.511.511.2
SEER----IPLV12.712.412.412.112.7
Nominal CFM26003000340040005000
System power (KW)6.677.908.8710.6113.40
Refrigerant typeR-410aR-410aR-410aR-410aR-410a
Refrigerant charge (lb-oz)
System 19-48-811-811-819-8
System 26-08-411-011-819-8
ARI HEATING PERFORMANCE
Heating model10151015101515201520
Heat input (K Btu)120180120180120180180240180240
Heat output (K Btu)961449614496144144192144192
AFUE %---------Steady state efficiency (%)80808080808080808080
No. burners4646466868
No. stages2222222222
Temperature Rise Range (ºF)20-5035-6515-4530-6010-4025-5520-5035-6510-4025-55
Gas Limit Setting (ºF)165165165165215195195160195160
Gas piping connection (in.)3/43/43/43/43/43/43/43/43/43/4
Face area (Sq. Ft.)23.823.829.029.047.5
Rows2 / 12222
Fins per inch2020202015
Tube diameter (in.)3/83/83/83/83/8
Circuitry TypeSplit-faceSplit-faceSplit-faceSplit-faceSplit-face
EVAPORATOR COIL DATA
Face area (Sq. Ft.)10.610.613.213.213.2
Rows33444
Fins per inch1515151515
Tube diameter0.3750.3750.3750.3750.375
Circuitry TypeSplit-faceSplit-faceSplit-faceSplit-faceSplit-face
Refrigerant controlTXVTXVTXVTXVTXV
CONDENSER FAN DATA
ZH078ZH090ZH102ZH120ZH150
Models
Johnson Controls Unitary Products15
246824-YTG-G-1208
ZH078-150 Physical Data (Continued)
Component
Nominal Tonnage6.57.58.51012.5
Quantity22224
Fan diameter (Inch)2424242424
TypePropPropPropPropProp
Drive typeDirectDirectDirectDirectDirect
No. speeds11111
Number of motors22224
Motor HP each1/31/33/43/41/3
RPM85085011101110850
Nominal total CFM680068008800880014000
BELT DRIVE EVAP FAN DATA
Quantity11111
Fan Size (Inch)12 x 1212 x 1215 x 1515 x 1515 x 15
TypeCentrifugalCentrifugalCentrifugalCentrifugalCentrifugal
Motor Sheave1VM501VM501VM501VM501VM501VM501VM501VM501VM501VP56
Blower SheaveAK74AK64AK74AK61AK89AK74AK84AK74AK74BK77
BeltA49A49A49A49A56A54A56A54A54BX55
Motor HP each1-1/221-1/23232335
RPM1725172517251725172517251725172517251725
Frame size565656565656565656184T
FILTERS
Quantity - Size4 - 25 x 16 x 24 - 25 x 16 x 24 - 25 x 20 x 24 - 25 x 20 x 24 - 25 x 20 x 2
ZH078ZH090ZH102ZH120ZH150
Models
16Johnson Controls Unitary Products
ZR078-150 Physical Data
246824-YTG-G-1208
Component
Nominal Tonnage6.57.58.51012.5
ARI COOLING PERFORMANCE
Gross Capacity @ ARI A point (Btu)8000091000106000125000156000
ARI net capacity (Btu)7800088000102000120000150000
EER11.211.211.211.211.2
SEER----IPLV13.012.312.312.312.7
Nominal CFM26003000340040005000
System power (KW)6.967.869.1110.7113.39
Refrigerant typeR-410aR-410aR-410aR-410aR-410a
Refrigerant charge (lb-oz)
System 19-09-1211-812-018-8
System 25-88-811-010-818-8
ARI HEATING PERFORMANCE
Heating model10151015101515201520
Heat input (K Btu)120180120180120180180240180240
Heat output (K Btu)961449614496144144192144192
AFUE %---------Steady state efficiency (%)80808080808080808080
No. burners4646466868
No. stages2222222222
Temperature Rise Range (ºF)20-5035-6515-4530-6010-4025-5520-5035-6510-4025-55
Gas Limit Setting (ºF)165165165165215195195160195160
Gas piping connection (in.)3/43/43/43/43/43/43/43/43/43/4
Face area (Sq. Ft.)23.823.829.029.047.5
Rows2 / 12222
Fins per inch2020202015
Tube diameter (in.)3/83/83/83/83/8
Circuitry TypeSplit-faceSplit-faceSplit-faceSplit-faceSplit-face
EVAPORATOR COIL DATA
Face area (Sq. Ft.)10.610.613.213.213.2
Rows33444
Fins per inch1515151515
Tube diameter3/83/83/83/83/8
Circuitry TypeSplit-faceSplit-faceSplit-faceSplit-faceSplit-face
Refrigerant controlTXVTXVTXVTXVTXV
ZR078ZR090ZR102ZR120ZR150
Models
Johnson Controls Unitary Products17
246824-YTG-G-1208
ZR078-150 Physical Data (Continued)
Component
Nominal Tonnage6.57.58.51012.5
REHEAT COIL DATA
Face area (Sq. Ft.)6.666.66101010
Rows22222
Fins per inch1313131313
Tube diameter (in.)3/83/83/83/83/8
CONDENSER FAN DATA
Quantity22224
Fan diameter (Inch)2424242424
TypePropPropPropPropProp
Drive typeDirectDirectDirectDirectDirect
No. speeds11111
Number of motors22224
Motor HP each1/31/31/31/31/3
RPM850850850850850
Nominal total CFM680068006800680014000
BELT DRIVE EVAP FAN DATA
Quantity11111
Fan Size (Inch)12 x 1212 x 1215 x 1515 x 1515 x 15
TypeCentrifugalCentrifugalCentrifugalCentrifugalCentrifugal
Motor Sheave1VM501VM501VM501VM501VM501VM501VM501VM501VM501VP56
Blower SheaveAK74AK64AK74AK61AK89AK74AK84AK74AK74BK77
BeltA49A49A49A49A56A54A56A54A54BX55
Motor HP each1-1/221-1/23232335
RPM1725172517251725172517251725172517251725
Frame size565656565656565656184T
FILTERS
Quantity - Size4 - 25 x 16 x 24 - 25 x 16 x 24 - 25 x 20 x 24 - 25 x 20 x 24 - 25 x 20 x 2
ZR078ZR090ZR102ZR120ZR150
Models
18Johnson Controls Unitary Products
XP078-150 Physical Data
246824-YTG-G-1208
Component
Nominal Tonnage6.57.58.51012.5
ARI COOLING PERFORMANCE
Gross Capacity @ ARI A point (Btu)8000095000104000122000156000
ARI net capacity (Btu) 7800092000100000118000150000
EER11.011.011.011.011.0
SEER----IPLV12.412.412.412.411.9
Nominal CFM26003000340040005000
System power (KW)7.108.359.1010.7013.60
Refrigerant typeR-410aR-410aR-410aR-410aR-410a
Refrigerant charge (lb-oz)
System 19-09-813-814-016-0
System 29-49-013-014-016-0
ARI HEATING PERFORMANCE
47°F capacity rating (MBH)78.092.094.0110.0144.0
System power (KW) / COP6.5 / 3.507.6 / 3.507.8 / 3.509.2 / 3.5013.2 / 3.20
17°F capacity rating (MBH48.055.057.066.090.0
System power (KW) / COP6.2 / 2.307.0 / 2.307.3 / 2.308.3 / 2.3011.9 / 2.20
HSPF (Btu/Watts-hr)-----
Face area (Sq. Ft.)23.823.829.029.047.5
Rows22222
Fins per inch2020202015
Tube diameter (in.)3/83/83/83/83/8
Circuitry TypeSplit-faceSplit-faceSplit-faceSplit-faceSplit-face
EVAPORATOR COIL DATA
Face area (Sq. Ft.)10.610.613.213.213.2
Rows33444
Fins per inch1515151515
Tube diameter3/83/83/83/83/8
Circuitry TypeSplit-faceSplit-faceSplit-faceSplit-faceSplit-face
Refrigerant controlTXVTXVTXVTXVTXV
XP078XP090XP102XP120XP150
Models
Johnson Controls Unitary Products19
246824-YTG-G-1208
XP078-150 Physical Data (Continued)
Component
Nominal Tonnage6.57.58.51012.5
REHEAT COIL DATA
Quantity22224
Fan diameter (Inch)2424242424
TypePropPropPropPropProp
Drive typeDirectDirectDirectDirectDirect
No. speeds11111
Number of motors22224
Motor HP each1/31/31/31/31/3
RPM850850850850850
Nominal total CFM680068006800680014000
CONDENSER FAN DATA
Quantity22224
Fan diameter (Inch)2424242424
TypePropPropPropPropProp
Drive typeDirectDirectDirectDirectDirect
No. speeds11111
Number of motors22224
Motor HP each1/31/31/31/31/3
RPM850850850850850
Nominal total CFM680068006800680014000
BELT DRIVE EVAP FAN DATA
Quantity11111
Fan Size (Inch)12 x 1212 x 1215 x 1515 x 1515 x 15
TypeCentrifugalCentrifugalCentrifugalCentrifugalCentrifugal
Motor Sheave1VM501VM501VM501VM501VM501VM501VM501VM501VM501VP56
Blower SheaveAK74AK64AK74AK61AK89AK74AK84AK74AK74BK77
BeltA49A49A49A49A56A54A56A54A54BX55
Motor HP each1-1/221-1/23232335
RPM1725172517251725172517251725172517251725
Frame size565656565656565656184T
FILTERS
Quantity - Size4 - 25 x 16 x 24 - 25 x 16 x 24 - 25 x 20 x 24 - 25 x 20 x 24 - 25 x 20 x 2
1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower
Performance Table for the kW of the supply air blower motor.
2. These ratings include the condenser fan motors (total 1 kW) and the compressor motors but not the supply air blower motor.
1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower
Performance Table for the kW of the supply air blower motor.
2. These ratings include the condenser fan motors (total 1 kW) and the compressor motors but not the supply air blower motor.
1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower
Performance Table for the kW of the supply air blower motor.
2. These ratings include the condenser fan motors (total 1 kW) and the compressor motors but not the supply air blower motor.
1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower
Performance Table for the kW of the supply air blower motor.
2. These ratings include the condenser fan motors (total 1 kW) and the compressor motors but not the supply air blower motor.
