Yanmar
4TNV98-ZNMS
4TNV98T-ZNMS
4TNV98-ZNTBL
4TNV98T-ZNTBL
Engines
(P/N’s 192809, 192808,
242474, 241451, 196108,
196340)
Form No.
917304
Revision C
07/09
Mustang 2066/76/86, 2700V
and Gehl 56/6640E, V270
Skid-Steer Loaders
Gehl CTL65/75 and
Mustang MTL316/320
Compact
Track
Loaders
ENGINE PARTS MANUAL
Introduction
This manual covers the Yanmar 4TNV98-ZNMS (and Turbocharged version) and 4 TNV98-ZNTBL (and
Turbocharged version) engines with the following part numbers:
Part Number 192809: Mustang 2066 (naturally-aspirated)
Part Number 192808: Mustang 2076 and 2086 (turbocharged)
Part Number 242474: Mustang 2066 (naturally-aspirated)
Part Number 241451: Mustang 2076/2086/2700V and Gehl 5640E/6640E/V270 (turbocharged)
Part Number 196108: Gehl CTL65 and Mustang MTL316 (naturally-aspirated)
Part Number 196340: Gehl CTL75 and Mustang MTL320 (turbocharged)
When ordering service parts, specify the correct part number, full description, quantity required, and the en-
gine model number and serial number.
Items shown that do not have a part number are shown for reference purposes only and are not available for
purchase. Part numbers may change. Your Gehl or Mustang dealer will have the latest part number.
Gehl® Company and the Mustang® Manufacturing Co., Inc., reserve the r ight to make changes or improve-
ments in the design or construction of any part of the unit without incurring the obligation to install such
changes on any previously delivered units.
IMPORTANT
For maximum engine life, when shutting the engine down, allow the engine to idle, without load, for five min-
utes. This will allow engine compon ents that operate at high temperatures to cool slightly before the engine
itself is shut down.
GEHL is a registered trademark of the Gehl Company.
MUSTANG is a registered trademark of the Mustang Manufacturing Co., In c.
TABLE OF CONTENTS
DESCRIPTION PAGE
ENGINE SERVICE PARTS
Cylinder Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Gear Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Flywheel Housing and Oil Sump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Cylinder Head and Bonnet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Suction Manifold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Exhaust Manifold and Silencer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Camshaft and Driving Gear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Crankshaft and Piston. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Lubrication Oil System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Cooling Water System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Fuel Injection Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Governor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Fuel Injection Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Fuel Line. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Starting Motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Electric Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Tool and Gasket Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Turbine (Turbocharged) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
Lubrication Oil Line (Turbocharged). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Generator (-ZNTBL engine) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Numerical Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
CYLINDER BLOCK
1 917304/CP0709 PRINTED IN USA
CYLINDER BLOCK
Ref. Part Quantity
No. No. Description 4TNV98
1 197827 BLOCK ASSY, CYLINDER (ZNMS AND ZNTBL) 1
197831 BLOCK ASSY, CYLINDER (T-ZNMS AND T-ZNTBL) 1
4 186486 PLUG 55 1
5 425-34722 PLUG 1
6 186491 BOLT, METAL CAP 10
9 186493 BUSH, CAMSHAFT 1
10 425-34783 SPRING PIN 6X12 2
11 425-36260 PLUG PT3/8,SCREW 1
12 425-36260 PLUG PT3/8,SCREW 1
13 425-36260 PLUG PT3/8,SCREW 1
14 188757 PLUG 30 8
24 186494 BEARING ASSY, THRUST 2
27 186485 BOLT, HEAD 18
28 186513 GASKET,CYLINDER HEAD 1
29 186635 MAIN BEARING SET 5
32 197591 MAIN BEARING US=0.25 5
35 197592 BEARING,THRUST .25OS 2
PRINTED IN USA 917304/CP0709 2
GEAR HOUSING
3 917304/CP0709 PRINTED IN USA
GEAR HOUSING
Ref. Part Quantity
No. No. Description 4TNV98
1 188573 PARALLEL PIN 8X16 4
3 186586 CASE, GEAR (ZNMS AND ZNTBL) 1
197697 HOUSING,GEARS (T-ZNMS AND T-ZNTBL) 1
4 186543 PUMP ASSY, LUB.OIL (ZNMS AND ZNTBL) 1
197614 PUMP ASSY, LUB.OIL (T-ZNMS AND T-ZNTBL) 1
15 138139 STUD BOLT 4
16 138100 O-RING P20 1
17 138101 O-RING P14 1
18 186607 O-RING 1A P-7.0 1
19 186612 PACKING, 3075 1
20 425-34733 BOLT M 8X 16 PLATED 1
21 425-34746 BOLT M 8X 20 PLATED 3
22 425-34747 BOLT M 8X 45 PLATED 3
23 138141 NUT 4
24 425-34740 COVER,FILLER 1
25 425-34745 O-RING 1A P-32.0 1
26 186487 COVER, F.I. PUMP 1
27 186466 BOLT M 8X 70 PLATED 1
28 425-34733 BOLT M 8X 16 PLATED 1
29 188742 BOLT M 8X 40 PLATED 5
30 137948 COVER, HO-P 1
31 138127 O-RING 1A G-85.0 1
32 138133 BOLT M10X 20 PLATED 2
33 197826 HOUSING ASSY,COVER,G 1
35 186664 SEAL, OIL 1
36 186489 COVER ASSY 1
37 186490 SPONGE 1
38 186466 BOLT M 8X 70 PLATED 6
39 425-34733 BOLT M 8X 16 PLATED 3
40 188742 BOLT M 8X 40 PLATED 5
41 197593 BEARING #6205 1
42 186507 BALL BEARING 2
43 137947 CAP, LUB.OIL SUPPLY 1
44 185643 ADAPTOR, OIL FILLER (ZNTBL AND T-ZNTBL) 1
45 137949 PIPE (ZNTBL AND T-ZNTBL) 1
46 185644 NUT, OIL FILLER (ZNTBL AND T-ZNTBL) 1
47 185645 O-RING 1A P-30.0 ZNTBL AND T-ZNTBL) 1
PRINTED IN USA 917304/CP0709 4
FLYWHEEL HOUSING AND OIL SUMP
5 917304/CP0709 PRINTED IN USA
FLYWHEEL HOUSING AND OIL SUMP
Ref. Part Quantity
No. No. Description 4TNV98
1 188573 PARALLEL PIN 8X16 2
2 197590 COVER ASSY,FLYWHEEL (ZNMS AND T-ZNMS) 1
186576 HOUSING, FLYWHEEL (ZNTBL AND T-ZNTBL) 1
4 425-34756 CAP, FLY WHEEL COVER 1
5 186622 BOLT M10X 35 PLATED 9
6 186623 BOLT M10X 70 PLATED 4
7 197620 SEAL, OIL 1
8 197753 PAN ASSY, LUB. OIL (ZNMS) 1
197470 SUMP ASSY, LUB.OIL (T-ZNMS) 1
425-36120 SUMP ASSY, OIL (ZNTBL) 1
197664 SUMP ASSY, OIL (T-ZNTBL) 1
9 425-36121 DRAIN PLUG M22 1
11 138113 SEAL WASHER 22S 1
12 425-34729 BOLT M 8X 12 PLATED 16
PRINTED IN USA 917304/CP0709 6
CYLINDER HEAD AND BONNET
ZNMS AND ZNTBL Engines
7 917304/CP0709 PRINTED IN USA
CYLINDER HEAD AND BONNET
Ref. Part Quantity
No. No. Description ZNMS/ZNTBL
1 186519 LIFTER, ENGINE (ZNMS) 2
186519 LIFTER, ENGINE (ZNTBL) 1
197733 LIFTER,ENGINE (ZNTBL) 1
2 425-34733 BOLT M 8X 16 PLATED 4
3 186406 SEAT A,VALVE BRIDGE 8
4 197622 HEAD ASSY, CYLINDER 1
8 186602 PLUG PT1/4,SCREW 1
9 425-36260 PLUG PT3/8,SCREW 4
10 425-34779 PLUG 40 1
11 186520 VALVE(INT 8
12 186521 VALVE(EXH 8
13 186522 VALV E SPRING 16
14 425-35188 RETAINER, SPRING 16
15 197472 SEAL, VALVE STEM(EXH 8
16 425-35191 SEAL, VALVE STEM(INT 8
17 186529 BRIDGE ASSY,VALVE 8
19 425-34791 NUT M8XP1.0 8
20 186411 SCREW,VALVE BRIDGE 8
21 186410 GUIDE,VALVE BRIDGE 8
22 425-35189 COTTER ASSY 16
24 186533 GUIDE, VALVE 16
25 186337 PROTECTOR, NOZZLE 4
26 425-34796 SEAT, NOZZLE 4
27 186534 RETAINER,F.I.VALVE 4
28 197603 FLANGE BOLT,RETAINER 4
29 425-34776 O-RING 1A P 12.0 4
30 186314 BOLT 8X80 2
31 186528 SUPPORT CMP 1
32 186523 SHAFT,ROCKER ARM 1
33 186524 SUPPORT A 3
34 186525 SUPPORT B 2
35 186401 WAVE WASHER 8
36 186530 ARM ASSY, ROCKER 4
38 188596 SCREW, VALVE 4
39 425-34791 NUT M8XP1.0 4
40 186531 ARM ASSY, ROCKER 4
42 188596 SCREW, VALVE 4
43 425-34791 NUT M8XP1.0 4
44 186535 PEDESTAL,RETAINER 4
45 186624 STUD M 8X 22 PLATED 2
46 188742 BOLT M 8X 40 PLATED 2
47 188746 BOLT M 8X 60 PLATED 4
48 188746 BOLT M 8X 60 PLATED 2
49 138140 NUT 2
50 425-34740 COVER,FILLER 1
51 197621 BONNET ASSY 1
52 197601 BAFFLE PLATE 1
53 197602 BAFFLE 1
54 186518 BAFFLE 1
55 186388 DIAPHRAGM,BREATHER 1
56 186389 CENTER PLATE 1
57 186390 PLATE,BREATHER 1
58 186391 SPRING, DIAPHRAGM 1
60 197698 GASKET, BONNET 1
61 186335 PLUG 1
62 197779 CLIP 2
63 186598 SCREW 5X10,TAPPING 6
64 186598 SCREW 5X10,TAPPING 6
65 186615 BOLT M 6X 12 PLATED 2
66 425-34775 KNOB 4
67 425-34776 O-RING 1A P 12.0 4
68 425-34745 O-RING 1A P-32.0 1
PRINTED IN USA 917304/CP0709 8
CYLINDER HEAD AND BONNET
T-ZNMS and T-ZNTBL
9 917304/CP0709 PRINTED IN USA
CYLINDER HEAD AND BONNET
Ref. Part Quantity
No. No. Description T-ZNMS/T-ZNTBL
1 186519 LIFTER, ENGI N E 1
2 197668 LIFTER, ENGI N E 1
3 425-34733 BOLT M 8X 16 PLATED 2
4 425-34746 BOLT M 8X 20 PLATED 2
5 186406 SEAT A,VALVE BRIDGE 8
6 197670 HEAD ASSY, CYLINDER 1
12 186602 PLUG PT1/4,SCREW 1
13 425-36260 PLUG PT3/8,SCREW 4
14 425-34779 PLUG 40 1
15 186520 VALVE(INT 8
16 186521 VALVE(EXH 8
17 186522 VALV E SPRING 16
18 425-35188 RETAINER, SPRING 16
19 197472 SEAL, VALVE STEM(EXH 8
20 425-35191 SEAL, VALVE STEM(INT 8
21 186529 BRIDGE ASSY,VALVE 8
23 425-34791 NUT M8XP1.0 8
24 186411 SCRWE,VALVE BRIDGE 8
25 186410 GUIDE,VALVE BRIDGE 8
26 425-35189 COTTER ASSY 16
28 186533 GUIDE, VALVE 16
29 186337 PROTECTOR, NOZZLE 4
30 425-34796 SEAT, NOZZLE 4
31 186534 RETAINER,F.I.VALVE 4
32 197603 FLANGE BOLT,RETAINER 4
33 425-34776 O-RING 1A P 12.0 4
34 186314 BOLT 8X80 2
35 186528 SUPPORT CMP 1
36 186523 SHAFT,ROCKER ARM 1
37 186524 SUPPORT A 3
38 186525 SUPPORT B 2
39 186401 WAVE WASHER 8
40 186530 ARM ASSY, ROCKER 4
42 188596 SCREW, VALVE 4
43 425-34791 NUT M8XP1.0 4
44 186531 ARM ASSY, ROCKER 4
46 188596 SCREW, VALVE 4
Parts Listing Continued On Next Page
PRINTED IN USA 917304/CP0709 10
CYLINDER HEAD AND BONNET
T-ZNMS and T-ZNTBL
11 917304/CP0709 PRINTED IN USA
CYLINDER HEAD AND BONNET
continued from previous page
Ref. Part Quantity
No. No. Description T-ZNMS/T-ZNTBL
47 425-34791 NUT M8XP1.0 4
48 186535 PEDESTAL,RETAINER 4
49 186624 STUD M 8X 22 PLATED 2
50 188742 BOLT M 8X 40 PLATED 2
51 188746 BOLT M 8X 60 PLATED 4
52 188746 BOLT M 8X 60 PLATED 2
53 138140 NUT 2
54 425-34740 COVER,FILLER 1
55 197669 BONNET ASSY 1
56 197601 BAFFLE PLATE 1
57 197602 BAFFLE 1
58 186518 BAFFLE 1
60 197698 GASKET, BONNET 1
61 197449 JOINT, BREATHER 1
62 197572 CLIP 2
63 186598 SCREW 5X10,TAPPING 6
64 186615 BOLT M 6X 12 PLATED 2
65 425-34775 KNOB 4
66 425-34776 O-RING 1A P 12.0 4
67 425-34745 O-RING 1A P-32.0 1
68 197665 PIPE, BREATHER 1
69 197666 HOSE CMP, BREATHER 1
71 188632 CLAMP 22 2
72 197666 HOSE CMP, BREATHER 1
74 188632 CLAMP 22 2
76 425-34772 RETAINER 1
77 197475 HOSE, RETURN (T-ZNMS) 1
197667 HOSE ASSY,BREAZER (T-ZNTBL, INCLUDES PIPE PROTECTOR) 1
197692 PROTECTOR, PIPE 19 1
78 197749 MISTSEPARATOR ASSY 1
79 197747 COVER,SEPARATOR 1
80 197748 MISTSEPARATOR 1
81 138479 WOOL, STEEL 3
82 197810 BOLT M 5X 10 PLATED 4
83 197789 CLAMP 22 2
84 197792 HOSE, 16 X 250 1
85 425-36260 PLUG PT3/8,SCREW 1
86 425-34729 BOLT M 8X 12 PLATED 2
87 188736 BOLT 8X 14 PLATED 2
PRINTED IN USA 917304/CP0709 12
SUCTION MANIFOLD
ZNMS AND ZNTBL Engines
13 917304/CP0709 PRINTED IN USA
SUCTION MANIFOLD
Ref. Part Quantity
No. No. Description ZNMS/ZNTBL
1 186538 PACKING(INT.MANIFOLD 1
2 197624 MANIFOLD CMP,INTAKE 1
3 MANIFOLD,INTAKE 1
4 425-34780 STUD M 6X 20 PLATED 2
5 425-34747 BOLT M 8X 45 PLATED 6
6 425-34800 BOLT M 8X 80 PLATED 4
7 197450 GASKET 1
8 425-36318 GASKET, (NON-ASB.) 1
9 197705 HEATER, AIR 1
10 197451 BEND 1
11 188742 BOLT M 8X 40 PLATED 2
12 186618 BOLT M 8X 90 PLATED 2
PRINTED IN USA 917304/CP0709 14
SUCTION MANIFOLD
T-ZNMS and T-ZNTBL Engines
15 917304/CP0709 PRINTED IN USA
SUCTION MANIFOLD
Ref. Part Quantity
No. No. Description T-ZNMS/T-ZNTBL
1 186538 PACKING(INT.MANIFOLD 1
2 197672 MANIFOLD CMP,INTAKE 1
3 197671 MANIFOLD,INTAKE 1
4 197677 REEDVALVE 1
5 197678 SPACER(EGR VALVE 1
6 197679 GASKET(EGR-V SPACER 1
7 188732 BOLT M 6X 20 PLATED 3
8 188732 BOLT M 6X 20 PLATED 2
9 425-34780 STUD M 6X 20 PLATED 2
10 425-34747 BOLT M 8X 45 PLATED 6
11 425-34800 BOLT M 8X 80 PLATED 4
12 197750 RUBBER HOSE 1
13 197483 JOINT B 1
14 197476 DUCT,SUCTION 1
15 425-36131 CLAMP 54 3
16 425-36133 CLAMP 70 1
17 197450 GASKET 1
18 425-36318 GASKET, (NON-ASB.) 1
19 197705 HEATER, AIR 1
20 197451 BEND 1
21 188742 BOLT M 8X 40 PLATED 2
22 186618 BOLT M 8X 90 PLATED 2
PRINTED IN USA 917304/CP0709 16
EXHAUST MANIFOLD AND SILENCER
ZNMS Engine
ZNTBL Engine
17 917304/CP0709 PRINTED IN USA
EXHAUST MANIFOLD AND SILENCER
Ref. Part Quantity
No. No. Description ZNMS/ZNTBL
1 197469 MANIFOLD,EXHAUST (ZNMS) 1
197625 MANIFOLD,EXHAUST (ZNTBL) 1
2 197507 STUD 2
3 425-36128 GASKET 1
4 197462 BOLT, M8X90 6
5 425-36249 BOLT M 8X 22 4
6 138512 STUD BOLT M8X20 2
7 138140 NUT 2
8 197626 PIPE(EGR CMP 1
9 197627 GASKET, EGR PIPE 1
10 197807 BOLT M10X 30 PLATED 2
11 138140 NUT (ZNMS) 2
138140 NUT (ZNTBL) 4
12 197628 EGR VALVE 1
13 197629 GASKET(EGR-V IN 1
14 197630 GASKET(EGR-V OUT 1
15 197807 BOLT M10X 30 PLATED 1
16 138522 BOLT M10X 95 PLATED 1
17 138104 GASKET, SILENCER 1
18 186567 SILENCER 1
19 186568 STAY, SILENCER 1
20 186593 WASHER 8 2
21 197507 BOLT, M8X100 2
22 425-34733 BOLT, M8X16 PLATED 2
23 425-34746 BOLT, M8X20 PLATED 4
PRINTED IN USA 917304/CP0709 18
EXHAUST MANIFOLD AND SILENCER
T-ZNMS and T-ZNTBL Engine
19 917304/CP0709 PRINTED IN USA
EXHAUST MANIFOLD AND SILENCER
Ref. Part Quantity
No. No. Description T-ZNMS/T-ZNTBL
1 197674 MANIFOLD ASSY,EXH (T-ZNTBL) 1
2 197673 MANIFOLD, EXHAUST (T-ZNTBL) 1
197737 MANIFOLD, EXHAUST (T-ZNMS) 1
3 138512 STUD BOLT M8X20 2
4 425-36249 BOLT M 8X 22 4
5 425-36128 GASKET 1
6 186375 BOLT 8X80 8
7 197609 SILENCER (T-ZNTBL) 1
8 197699 STAY, SILENCER (T-ZNTBL) 1
9 138488 PK(T/C OUT 1
10 425-34733 BOLT M8X16 PLATED (T-ZNTBL) 3
11 425-34746 BOLT M8 X 20 PLATED (T-ZNTBL) 4
12 138140 NUT (T-ZNTBL) 4
13 197675 EGR COOLER 1
14 197676 GASKET, EGR COOLER 1
15 197676 GASKET, EGR COOLER 1
16 197463 BOLT, M8X25 2
17 197680 PIPE(EGR IN 1
18 197627 GASKET, EGR PIPE 1
19 197681 PIPE(EGR OUT 1
20 425-34761 BOLT M 8X 35 PLATED 1
21 425-34747 BOLT M 8X 45 PLATED 1
22 425-34748 BOLT M 8X 55 PLATED 2
23 425-35772 BOLT M10X 25 PLATED 2
24 138140 NUT 2
25 197628 EGR VALVE 1
26 197629 GASKET(EGR-V IN 1
27 197630 GASKET(EGR-V OUT 1
28 197808 BOLT M10X 40 PLATED 1
29 197809 BOLT M10X105 PLATED 1
30 138104 GASKET, SILENCER (T-ZNTBL) 1
PRINTED IN USA 917304/CP0709 20
CAMSHAFT AND DRIVING GEAR
21 917304/CP0709 PRINTED IN USA
CAMSHAFT AND DRIVING GEAR
Ref. Part Quantity
No. No. Description 4TNV98
1 186471 TAPPET 8
2 186539 PUSH ROD 8
3 197610 CAMSHFT ASSY (ZNMS AND T-ZNMS) 1
197611 CAMSHFT ASSY (ZNTBL AND T-ZNTBL) 1
4 425-34656 METAL,THRUST(CAM 1
6 138097 GEAR, CAMSHAFT 1
7 425-34810 KEY 7X 14 1
8 425-34733 BOLT M 8X 16 PLATED 2
9 138020 SHAFT(GEAR,IDLE 1
10 197597 GEAR ASSY , IDLE (ZNMS AND T-ZNMS) 1
186505 GEAR ASSY , IDLE (ZNTBL AND T-ZNTBL) 1
13 425-34813 BUSH, IDLE GEAR 1
14 425-34748 BOLT M 8X 55 PLATED 3
15 186579 BOLT 4
16 197605 GEAR,F.I.PUMP 1
17 186590 FLANGE 1
18 186596 SPRING WASHER 18 1
19 186626 NUT M18,LOCK 1
20 197752 GEAR, H.O. PUMP (ZNMS AND T-ZNMS) 1
186506 GEAR, H.O. PUMP (ZNTBL AND T-ZNTBL) 1
PRINTED IN USA 917304/CP0709 22
CRANKSHAFT AND PISTON
23 917304/CP0709 PRINTED IN USA
CRANKSHAFT AND PISTON
Ref. Part Quantity
No. No. Description 4TNV98
1 197598 CRANKSHAFT COMP (ZNMS) 1
197612 CRANKSHAFT COMP (T-ZNMS) 1
186510 CRANKSHAFT COMP (ZNTBL) 1
197613 CRANKSHAFT ASSY (T-ZNTBL) 1
3 138098 GEAR, CRANKSHAFT 1
186498 GEAR, CRANKSHAFT (T-ZNTBL) 1
4 137957 PARALLEL PIN 1
5 137958 PARALLEL PIN 10X22 1
6 425-34810 KEY 7X 14 1
7 186663 BOLT, V - PULLEY 1
8 186585 WASHER 1
9 197604 V-PULLEY,CRANKSHAFT (ZNMS AND T-ZNMS) 1
186662 V-PULLEY,CRANKSHAFT (ZNTBL AND T -ZNTBL) 1
10 186611 O-RING 1A S-53.0 1
11 137956 BOLT, FLYWHEEL 6
12 186578 FLYWHEEL ASSY 1
197739 FLYWHEEL ASSY (T-ZNTBL) 1
14 186499 GEAR, RING 1
15 197632 PISTON ASSY (ZNMS AND ZNTBL) 4
197682 PISTON ASSY (T-ZNMS AND T-ZNTBL) 4
17 197631 RING SET, PISTON 4
21 186343 PIN, PISTON 4
22 197783 CIRCLIP 30 8
23 197594 ROD ASSY, CONNECTING 4
26 186501 BOLT, ROD 8
27 186502 METAL ASSY, CRANKPIN 4
29 197596 BUSH, PISTON PIN 4
30 197595 BEARING,PIN U.S=0.25 4
32 197828 PISTON W/RING,0.25OS (ZNMS AND ZNTBL) 4
197832 PISTON W/RING,0.25OS (T-ZNMS AND T-ZNTBL) 4
34 197829 RING SET, 0.25OS 4
PRINTED IN USA 917304/CP0709 24
LUBRICATION OIL SYSTEM
ZNMS Engine
25 917304/CP0709 PRINTED IN USA
LUBRICATION OIL SYSTEM
Ref. Part Quantity
No. No. Description ZNMS
1 425-34825 GUIDE, DIPSTICK 1
2 197607 DIPSTICK 1
3 197683 DIPSTICK 1
4 425-34827 O-RING 1A P-10A 1
5 425-34733 BOLT M 8X 16 PLATED 1
6 186302 STUD, LUB.OIL FILTER 1
7 194315 FILTER 80X80L 1
8 138100 O-RING P20 1
9 197743 PIPE ASY,L.OIL INLET 1
14 425-34729 BOLT M 8X 12 PLATED 1
15 425-34733 BOLT M 8X 16 PLATED 1
16 425-36085 SENDER, OIL PRES SURE 1
17 197633 PIPE ASSY, LUB.OIL 1
19 186421 SUPPORT,PIPE 1
21 186468 BOLT ASSY, JOINT 2
22 425-34750 SEAL WASHER 8S 2
23 186600 JOINT BOLT 3 2
24 425-34750 SEAL WASHER 8S 2
25 425-34729 BOLT M 8X 12 PLATED 1
26 186565 PIPE 1
27 186300 BOLT, PIPE JOINT 2
28 425-34750 SEAL WASHER 8S 4
PRINTED IN USA 917304/CP0709 26
LUBRICATION OIL SYSTEM
T-ZNMS Engine
27 917304/CP0709 PRINTED IN USA
LUBRICATION OIL SYSTEM
Ref. Part Quantity
No. No. Description T-ZNMS
1 197615 COOLER ASSY, OIL 1
2 197481 O-RING 1
3 138072 BOLT, L.O.COOLER 1
4 197616 BRACKET,OIL COOLER 1
5 188567 JOINT 1
6 197619 PIPE, COOLING WATER 1
7 138093 ELBOW PT3/8 1
8 186442 PIPE, C.W. 1
10 186443 PROTECTER,CW-T 1
11 137953 CLAMP 140 1
12 197790 CLAMP 25 4
13 186609 O-RING 1A G-60.0 1
14 425-34825 GUIDE, DIPST ICK 1
15 197607 DIPSTICK 1
16 197683 DIPSTICK 1
17 425-34827 O-RING 1A P-10A 1
18 425-34733 BOLT M 8X 16 PLATED 1
19 194315 FILTER 80X80L 1
20 138100 O-RING P20 1
21 197743 PIPE ASY,L.OIL INLET 1
26 425-34729 BOLT M 8X 12 PLATED 1
27 425-34733 BOLT M 8X 16 PLATED 1
28 270970 PLUG, DRAIN 1
PRINTED IN USA 917304/CP0709 28
LUBRICATION OIL SYSTEM
ZNTBL and T-ZNTBL Engines
29 917304/CP0709 PRINTED IN USA
LUBRICATION OIL SYSTEM
Ref. Part Quantity
No. No. Description ZNTBL/T-ZNTBL
1 197615 COOLER ASSY, OIL (T-ZNTBL) 1
2 197481 O-RING (T-ZNTBL) 1
3 186587 STUD, LUB.OIL FILTER (ZNTBL) 1
138072 BOLT, L.O.COOLER (T-ZNTBL) 1
4 197616 BRACKET,OIL COOLER (T-ZNTBL) 1
5 188567 JOINT (T-ZNTBL) 1
6 197619 PIPE, COOLING WATER (T-ZNTBL) 1
7 138093 ELBOW PT3/8 (T-ZNTBL) 1
8 186442 PIPE, C.W. (T-ZNTBL) 1
10 186443 PROTECTER,CW-T (T-ZNTBL) 1
11 137953 CLAMP 140 (T-ZNTBL) 1
12 197790 CLAMP 25 (T-ZNTBL) 4
13 186609 O-RING 1A G-60.0 1
14 197606 DIPSTICK (ZNTBL) 1
197870 DIPSTICK (T-ZNTBL) 1
15 425-34825 GUIDE, DIPST ICK 1
16 425-34827 O-RING 1A P-10A 1
17 186569 CASE ASSY, LUB. OIL (ZNTBL) 1
186451 CASE ASSY, LUB. OIL (T-ZNTBL) 1
19 186582 ADAPTER 1
20 186580 COVER 1
21 186302 STUD, LUB.OIL FILTER 1
22 194315 FILTER 80X80L 1
23 197734 BRACKET ASSY , LUB.OIL (ZNTBL) 1
186570 SPACER(LO, FILTER (ZNTBL ONLY - NOT SHOWN) 1
197740 BRACKET ASSY , LUB.OIL (T-ZNTBL) 1
25 186582 ADAPTER 2
26 197735 PIPE, LUB.OIL (ZNTBL) 1
197744 PIPE, LUB.OIL (ZNTBL) 1
197482 LO-T (T-ZNTBL) 2
27 186665 CLAMP 200 (T-ZNTBL) 1
28 186666 PROTECTOR (T-ZNTBL) 1
29 186595 SEAL WASHER 30S 1
30 186610 O-RING 1A G70.0,NBR (T-ZNTBL) 1
31 425-34766 BOLT M8X50 PLATED (ZNTBL) 2
138136 BOLT M10X45 PLATED (T-ZNTBL AND ZNTBL ) 2
32 138100 O-RING P20 1
33 186508 PIPE ASSY, LUB.OIL 1
38 425-34729 BOLT M8X12 PLATED 2
39 197710 GUIDE, DIPSTICK 1
40 186574 DIPSTICK (ZNTBL) 1
197712 OIL,DIPSTICK (T-ZNTBL) 1
Following Parts Are For ZNTBL Engines
Ref. Part Quantity
No. No. Description ZNTBL
41 425-34684 SWITCH, (0.5KG)L.O. 1
42 197633 PIPE ASSY, LUB.OIL 1
43 186421 SUPPORT, PIPE 1
44 186468 BOLT ASSY, JOINT 2
45 425-34750 SEAL WASHER 8S 2
46 186600 JOINT BOLT 3 2
47 425-34750 SEAL WASHER 8S 2
48 425-34729 BOLT M8X12 PLATED 1
49 186565 PIPE 1
50 186300 BOLT, PIPE JOINT 2
51 425-34750 SEAL WASHER 8S 4
52 197711 GUIDE, LO GAUGE, CMP 1
PRINTED IN USA 917304/CP0709 30
COOLING WATER SYSTEM
ZNMS Engine
31 917304/CP0709 PRINTED IN USA
COOLING WATER SYSTEM
Ref. Part Quantity
No. No. Description ZNMS
1 197634 PUMP ASSY,WA TER 1
11 425-36113 GASKET, CW-P 1
12 425-35165 BOLT M 6X 30 PLATED 2
13 425-34748 BOLT M 8X 55 PLATED 5
14 197695 PULLEY 1
15 186615 BOLT M 6X 12 PLATED 4
16 197638 CASE ASSY,THERMOSTAT 1
17 197635 THERMOMETER 1
19 186564 COVER, THERMOSTAT 1
21 425-36114 GASKET, THERMOSTAT 1
22 186370 GASKET, THERMOSTAT 1
23 186371 THERMOSTAT 1
25 425-35959 SEAL WASHER 12 1
26 138123 PLUG PT3/8,STEEL 2
27 188732 BOLT M 6X 20 PLATED 4
28 425-36319 GASKET, CASE 1
29 425-34727 GASKET 8, ROUND 1
30 425-34729 BOLT M 8X 12 PLATED 1
31 188746 BOLT M 8X 60 PLATED 3
32 270970 PLUG, DRAIN 1
33 425-34851 PLUG M16 1
34 197459 SWITCH, THERMO 111 1
35 160427 GASKET 16 2
36 197636 PIPE ASSY, WATER A 1
39 197793 CLAMP 12 2
40 197637 PIPE ASSY, WATER B 1
43 197793 CLAMP 12 2
44 197802 V-BELT A44 1
PRINTED IN USA 917304/CP0709 32
COOLING WATER SYSTEM
T-ZNMS and T-ZNTBL Engines
ZNTBL Engine
33 917304/CP0709 PRINTED IN USA
COOLING WATER SYSTEM
Quantity
Ref. Part ZNTBL/T-ZNTBL/
No. No. Description T-ZNMS
1 197634 PUMP ASSY,WA TER 1
11 425-36113 GASKET, CW-P 1
12 425-35165 BOLT M 6X 30 PLATED 2
13 425-34748 BOLT M 8X 55 PLATED 5
14 197695 PULLEY (T-ZNMS) 1
197696 PULLEY (ZNTBL) 1
183543 PULLEY (T-ZNTBL) 1
15 186615 BOLT M 6X 12 PLATED 4
16 197689 CASE ASSY,THERMOSTAT (T-ZNMS) 1
197702 CASE ASSY,THERMOSTAT (ZNTBL) 1
197741 CASE ASSY,THERMOSTAT (T-ZNTBL) 1
17 197635 THERMOMETER 1
18 197685 JOINT CMP 1
19 197686 JOINT 1
20 138123 PLUG PT3/8,STEEL 1
22 186564 COVER, THERMOSTAT 1
24 425-36114 GASKET, THERMOSTAT 1
25 186370 GASKET, THERMOSTAT 1
26 186371 THERMOSTAT 1
28 425-35959 SEAL WASHER 12 1
29 138123 PLUG PT3/8,STEEL 1
30 188732 BOLT M 6X 20 PLATED 4
31 425-36319 GASKET, CASE 1
32 425-34727 GASKET 8, ROUND 1
33 425-34729 BOLT M 8X 12 PLATED 1
34 188746 BOLT M 8X 60 PLATED 3
35 425-34851 PLUG M16 1
36 197459 SWITCH, THERMO 111 1
37 160427 GASKET 16 2
38 197636 PIPE ASSY, WATER A 1
41 197793 CLAMP 12 2
42 197637 PIPE ASSY, WATER B 1
45 197793 CLAMP 12 2
46 197687 JOINT 1
47 197738 PIPE ASSY, WATER IN 1
48 197745 HOSE CLIP 22 2
51 197688 PIPE ASSY, WATER OUT 1
52 197745 HOSE CLIP 22 2
55 197694 CRIP150-M8 1
56 425-34729 BOLT M 8X 12 PLATED 1
57 197802 V-BELT A44 (T-ZNMS) 1
197803 V-BELT (ZNTBL) 1
184405 V-BELT A41 (T-ZNTBL) 1
60 186563 FAN (ZNTBL) 1
61 186303 SPACER, FAN (ZNTBL) 1
197446 SPACER, FAN (T-ZNTBL) 1
62 425-34761 BOLT M8X35 PLATED (ZNTBL) 4
425-34747 BOLT M8X45 PLATED (T-ZNTBL) 4
63 425-34736 JOINT PT1/4 (T-ZNMS AND T-ZNTBL) 1
64 186311 SENSOR, THERMO. (T-ZNMS AND T-ZNTBL) 1
65 425-34707 GASKET 10 (T-ZNMS AND T-ZNTBL) 1
66 186479 SUBTANK (T-ZNMS AND T-ZNTBL) 1
67 186360 PLUG, SUBTANK 1
68 186359 CAP 1
69 186461 CLAMP 1
70 186361 GASKET 1
71 186358 PIPE 1
72 425-34854 COCK ASSY, 3-WAY 1
73 425-35273 COCK, DRAIN 1
74 197454 GASKET 1
75 186301 PIPE, FUEL 1
PRINTED IN USA 917304/CP0709 34
FUEL INJECTION PUMP
35 917304/CP0709 PRINTED IN USA
FUEL INJECTION PUMP
Ref. Part Quantity
No. No. Description 4TNV98
1 197835 INJECTON PUMP ASSY (ZNMS) 1
197837 INJECTON PUMP ASSY (T-ZNMS) 1
197834 INJECTON PUMP ASSY (ZNTBL) 1
197836 INJECTON PUMP ASSY (T-ZNTBL) 1
9 197754 KEY 5X19 1
18 197772 STOPPER 1
19 197770 O-RING 1
20 197770 O-RING 1
21 197640 VALV E ASSY, DELIVERY 4
30 186678 SPRING 4
31 197641 HOLDER,DELIVERY (ZNMS AND ZNTBL) 4
197690 HOLDER,DELIVERY (T-ZNMS AND T-ZNTBL) 4
52 197773 PLUG 1
53 197608 PLUG 1
54 186676 PK(BARREL PLUG 4
55 PLUG 1
56 197599 PACKING, PLUG 1
57 LIFTER 1
58 TIMER SET 1
59 TIMER CMP 1
62 O-RING, 1011 1
63 BACKUP RING 1
64 O RING 1
65 P ACKING, 1020 1
66 RING, BACKUP T2 P 15 1
67 197768 PACKING, HEAD 1
68 SPRING,TIMER 1
69 CAP,TIMER 1
71 197477 VALVE,SOLENOID 1
74 PACKING,TIMER 1
95 PISTON 1
96 DAMPER ASSY 1
97 PLUG 1
98 425-35959 SEAL WASHER 12 1
99 192294 SEAL WASHER 18 1
100 425-35174 PLUG M12,HEX. 1
102 192297 O-RING 1
103 192299 O-RING 4E S42 1
105 425-35959 SEAL WASHER 12 2
106 186596 SPRING WASHER 18 1
107 PARALLEL PIN 5X14 2
108 425-34892 SPRING PIN 5X10 2
109 186607 O-RING 1A P-7 .0 1
110 197799 PACKING, 1020 1
111 197800 O RING 1
112 425-35263 BOLT 6X 10 PLATED 1
113 425-35705 BOLT M 6X 35 PLATED 4
116 197816 BOLT M10X 45 4
117 186626 NUT M18,LOCK 1
120 197642 HARNESS CMP 1
121 197643 HARNESS ,CSD 1
122 197510 CAP,RUBBER 1
123 192292 JOINT
124 197644 BRACKE T ,CSD 1
125 192290 JOINT 1
127 192295 PUMP ASS Y,FEED 1
128 192296 O-RING(FEED P INNER 1
129 192298 JOINT,PIPE 1
130 425-35959 SEAL WASHER 12 1
131 425-34968 SPRING WASHER 5 1
132 186615 BOLT M 6X 12 PLATED 1
133 197817 NUT M 5 1
134 197818 PLUG 16 1
136 197639 RETAINER(FOP 1
137 425-34746 BOLT M 8X 20 PLATED 3
138 425-34760 BOLT M 8X 30 PLATED 3
1
PRINTED IN USA 917304/CP0709 36
GOVERNOR
37 917304/CP0709 PRINTED IN USA
GOVERNOR
Ref. Part Quantity
No. No. Description 4TNV98
2 197769 PACKING, CASE 1
3 197653 CASE ASSY, GOVERNOR 1
4 197652 CASE, GOVERNOR 1
5 197654 LINK 1
6 197693 PIN,GOVERNOR LEVER 1
7 197762 SHAFT,GOV.LEVER 1
8 197763 SCREW 1
9 197764 SPACER,GOV.LEVER 2
10 197655 LEVER, GOVERNOR 1
11 197765 SPRING 1
12 197766 LOCK,SPRING 1
13 197782 WASHER 4 2
14 197784 CIRCLIP E- 3 2
15 425-34969 CIRCLIP E- 4 1
16 197786 SPRING PIN 2X10 1
17 197795 O-RING 1A P-6.0 1
18 197813 BOLT M 5X 10 1
19 425-35343 NUT, GOVERNOR WEIGHT 1
197488 NUT, GOVERNOR WEIGHT (T-ZNTBL) 1
20 197657 ACTUATOR (ZNMS AND T-ZNMS) 1
197656 ACTUATOR (ZNTBL AND T-ZNTBL) 1
21 197658 BOLT,ECO 1
22 197767 SENSOR 1
23 197760 GEAR,SENSOR 1
24 425-34935 GASKET 12, ROUND 1
25 425-35174 PLUG M12,HEX. 1
26 197797 O-RING 1A S-48.0 1
27 197805 BOLT M 6X 25 PLATED 10
28 425-34765 BOLT M 8X 25 PLATED 3
PRINTED IN USA 917304/CP0709 38
FUEL INJECTION VALVE
39 917304/CP0709 PRINTED IN USA
FUEL INJECTION VALVE
Ref. Part Quantity
No. No. Description 4TNV98
1 197830 FUEL INJECTOR(RDG (ZNMS AND ZNTBL) 4
197833 FUEL INJECTOR(RDN (T-ZNMS AND T-ZNTBL) 4
2 197645 NOZZLE ASSY (ZNMS AND ZNTBL) 4
197691 NOZZLE ASSY (T-ZNMS AND T-ZNTBL) 4
5 425-34903 NUT, NOZZLE CASE 4
6 197646 HOLDER ASSY, NOZZLE (ZNMS AND ZNTBL) 4
186553 HOLDER ASSY, NOZZLE (T-ZNMS AND T-ZNTBL) 4
9 425-34666 SPRING, NOZZLE 4
10 425-34905 SEAT, NOZZLE SPRING 4
11 425-34906 PLATE, STOP 4
12 188447 PIN 8
13 188448 SHIM PACK 4
25 186407 PIPE SEAL 4
26 137962 BRACKET 2
27 425-35452 RETAINER, INJ. PIPE 1
30 186473 BOLT M4X14,HEX.SCKT. 2
32 197648 PIPE ASSY, INJECTION 1
33 197649 PIPE ASSY, INJECTION 1
34 197650 PIPE ASSY, INJECTION 1
35 197651 PIPE ASSY, INJECTION 1
36 188754 NUT M 6 2
PRINTED IN USA 917304/CP0709 40
FUEL LINE
41 917304/CP0709 PRINTED IN USA
FUEL LINE
Ref. Part Quantity
No. No. Description 4TNV98
1 186467 BRACKET,FUEL FILTE R 1
2 193024 FILTER, FUEL OIL 1
3 425-34760 BOLT M 8X 30 PLATED 2
4 186478 PIPE ASSY, FUEL 1
5 425-34916 CLAMP 12 2
6 138107 PROTECTOR, FUEL PIPE 1
7 425-36289 PIPE, FUEL OIL 1
8 197746 PIPE ASSY, FUEL 1
9 425-34916 CLAMP 12 2
10 197500 PIPE, FUEL OIL 1
11 188691 TUBE 1
12 137953 CLAMP 140 1
13 186554 PIPE ASSY,F.O.RETURN 1
14 186430 JOINT BOLT M6 5
15 186431 PACKING,FUEL RETURN 5
16 197647 PIPE, FUEL RETURN 1
17 197508 CORRUGATED TUBE 1
18 186464 CLAMP 9 2
20 186432 HOSE JOINT 4 1
21 425-34750 SEAL WASHER 8S 1
22 186308 PUMP ASSY, FUEL FEED (ZNMS AND T-ZNMS) 1
186483 PUMP ASSY, FUEL FEED (ZNTBL AND T-ZNTBL) 1
23 194317 SEPARATOR ASSY 1
24 425-34924 RING, RETAINING 1
25 186340 ELEMENT 1
26 270981 CUP ASSY(SERVICE PAR 1
27 425-34744 O-RING 1A P-16.0 1
28 425-34927 O-RING 1A G-65.0 1
PRINTED IN USA 917304/CP0709 42
STARTING MOTOR
43 917304/CP0709 PRINTED IN USA
STARTING MOTOR
Ref. Part Quantity
No. No. Description 4TNV98
1 194316 STARTER 12V,3KW 1
2 197716 ARMATURE ASSY 1
5 197717 COIL ASSY, FIELD 1
6 197718 SCREW, POLE CORE SET 4
7 197719 O-RING 1
8 197720 BRUSH (+) 2
9 197721 COVER, REAR 1
10 197722 HOLDER, BRUSH 1
11 197723 SPRING, BRUSH 1
12 197724 BRUSH (-) 2
13 197725 SWITCH ASSY,MAGNETIC 1
14 197726 HOUSING, GEARS 1
15 197727 RETAINER, BEARING 1
16 197728 SHIFT LEVER SET 1
17 197729 COVER ASSY, DUST 1
18 197730 THROUGHT BOLT 2
19 197731 BOLT M6X 20 4
20 197732 SCREW M4X 10 2
21 138056 PINION ASSY 1
22 138057 CLUTCH ASSY 1
23 BALL BEARING (3 2
24 138058 SHAFT, PINION 1
25 137930 STOPPER KIT, PINION 1
29 425-35916 TERMINAL COV ER (ZNMS, T-ZNMS AND T-ZNTBL) 1
186463 COVER, TERMINAL (ZNTBL) 1
30 197444 BOLT M 6X 37 2
31 188748 BOLT M12X 25 PLATED 2
425-36301 BOLT M12 X 30 PLATED (T-ZNTBL) 2
PRINTED IN USA 917304/CP0709 44
ELECTRIC PARTS
45 917304/CP0709 PRINTED IN USA
ELECTRIC PARTS
Ref. Part Quantity
No. No. Description 4TNV98
1 197713 ECU,CMP (ZNMS) 1
197742 ECU CMP (T-ZNMS) 1
197714 ECU,CMP (ZNTBL) 1
197659 ECU, CMP (T-ZNTBL) 1
11 197660 SHIELD,ECU 1
12 197661 COLLAR, CONTROLLER 3
13 197452 RUBBER, CUSHION 3
14 197788 SCREW, 5.0 X 8 6
19 193206 RELAY CA,TYPE C 2
20 197703 ACCEL SENSOR ASSY 1
21 197781 NUT W/ WASHER 6 1
22 197448 SPRING, RETURN 1
23 197493 SENSOR ASSY, ACCEL 1
24 197780 BODY 1
25 197494 SUPPORT 1
26 197495 GASKET, SUPPORT 1
27 197496 SHAFT ASSY 1
28 186607 O-RING 1A P-7.0 1
29 197804 SCREW M4X20 2
30 197704 ACCEL SENSOR LEVER 1
31 186615 BOLT M6X12 PLATED 2
32 186336 RELAY, POWER 1
33 186336 RELAY, POWER 1
34 197662 RELAY(SIO,90A 1
35 160888 RELAY, MAGNETIC 1
36 160891 TIMER 1
37 197663 RELAY(ISO,70A 1
PRINTED IN USA 917304/CP0709 46
TOOL AND GASKET SET
ZNMS Engine
47 917304/CP0709 PRINTED IN USA
TOOL AND GASKET SET
Ref. Part Quantity
No. No. Description -ZNMS
1 197503 GASKET SET(NON-ASB.) 1
2 186513 GASKET ,CYLINDER HEAD 1
3 138100 O-RING P20 2
4 138101 O-RING P14 1
5 186607 O-RING 1A P-7.0 1
6 186612 PACKING, 3075 1
7 425-34745 O-RING 1A P-32.0 2
8 138127 O-RING 1A G-85.0 1
9 138113 SEAL WASHER 22S 1
10 197472 SEAL, VALVE STEM(EXH 8
11 425-35191 SEAL, VALVE STEM(INT 8
12 186337 PROTECTOR, NOZZLE 4
13 425-34796 SEAT, NOZZLE 4
14 425-34776 O-RING 1A P 12.0 8
15 197698 GASKET, BONNET 1
16 186538 PACKING(INT.MANIFOLD 1
17 197450 GASKET 1
18 425-36318 GASKET, (NON-ASB.) 1
19 425-36128 GASKET 1
20 197627 GASKET, EGR PIPE 1
21 197629 GASKET(EGR-V IN 1
22 197630 GASKET(EGR-V OUT 1
23 138104 GASKET, SILENCER 1
24 186611 O-RING 1A S-53.0 1
25 425-34827 O-RING 1A P-10A 1
26 425-34750 SEAL WASHER 8S 9
27 425-36113 GASKET, CW-P 1
28 425-36114 GASKET, THERMOSTAT 1
29 186370 GASKET, THERMOSTAT 1
30 425-35959 SEAL WASHER 12 1
31 425-36319 GASKET, CASE 1
32 425-34727 GASKET 8, ROUND 1
33 160427 GASKET 16 2
34 186431 PACKING,FUEL RETURN 5
35 138091 FLEX HONE 1
36 138154 GASKET.LIQUID 1
PRINTED IN USA 917304/CP0709 48
TOOL AND GASKET SET
ZNTBL, T-ZNTBL and T-ZNMS Engines
49 917304/CP0709 PRINTED IN USA
TOOL AND GASKET SET
Quantity
Ref. Part ZNTBL/T-ZNTBL/
No. No. Description T-ZNMS
1 197504 GASKET SET(NON-ASB.) (T-ZNMS) 1
197503 GASKET SET(NON-ASB.) (ZNTBL) 1
197871 GASKET SET(NON-ASB.) (T-ZNTBL) 1
2 186513 GASKET ,CYLINDER HEAD 1
3 138100 O-RING P20 2
4 138101 O-RING P14 1
5 186607 O-RING 1A P-7.0 1
6 186612 PACKING, 3075 1
7 425-34745 O-RING 1A P-32.0 (T-ZNMS) 2
425-34745 O-RING 1A P- 32.0 (ZNTBL AND T-ZNTBL) 4
185645 O-RING 1A P-30.0 (ZNTBL AND T-ZNTBL) 1
8 138127 O-RING 1A G-85.0 1
186610 O-RING 1A G70.0,NBR (T-ZNTBL) 1
9 138113 SEAL WASHER 22S (T-ZNMS AND T-ZNTBL) 1
186595 SEAL WASHER 30S (ZNTBL) 1
10 197472 SEAL, VALVE STEM(EXH 8
11 425-35191 SEAL, VALVE STEM(INT 8
12 186337 PROTECTOR, NOZZLE 4
13 425-34796 SEAT, NOZZLE 4
14 425-34776 O-RING 1A P 12.0 8
15 197698 GASKET, BONNET 1
16 186538 PACKING(INT.MANIFOLD 1
17 197679 GASKET(EGR-V SPACER 1
18 197450 GASKET 1
19 425-36318 GASKET, (NON-ASB.) 1
20 425-36128 GASKET 1
21 197676 GASKET, EGR COOLER 2
22 197627 GASKET, EGR PIPE 1
23 197629 GASKET(EGR-V IN 1
24 197630 GASKET(EGR-V OUT 1
25 138488 PK(T/C OUT 1
26 197514 GASKET (T-ZNMS) 1
138104 GASKET, SILENCER (ZNTBL AND T-ZNTBL) 2
27 186611 O-RING 1A S-53.0 1
28 186609 O-RING 1A G-60.0 1
29 425-34827 O-RING 1A P-10A 1
30 425-34750 SEAL WASHER 8S (T-ZNMS AND T-ZNTBL) 11
425-34750 SEAL WASHER 8S (ZNTBL) 9
31 425-34837 GASKET 10, ROUND (T-ZNMS AND T-ZNTBL) 2
425-34707 GASKET 10 (ZNTBL) 1
32 197618 GASKET,LO-T RETURN 1
33 425-36113 GASKET, CW-P 1
34 425-36114 GASKET, THERMOSTAT 1
35 186370 GASKET, THERMOSTAT 1
36 425-35959 SEAL WASHER 12 1
37 425-36319 GASKET, CASE 1
38 425-34727 GASKET 8, ROUND 1
39 160427 GASKET 16 (T-ZNMS) 2
160427 GASKET 16 (ZNTBL AND T-ZNTBL) 1
40 186431 PACKING,FUEL RETURN 5
41 138091 FLEX HONE 1
42 138154 GASKET.LIQUID 1
PRINTED IN USA 917304/CP0709 50
TURBINE
T-ZNMS and T-ZNTBL Engines
51 917304/CP0709 PRINTED IN USA
TURBINE
Ref. Part Quantity
No. No. Description T-ZNMS/T-ZNTBL
1 197700 TURBINE, RH F5 1
2 197514 GASKET 1
3 138140 NUT 4
PRINTED IN USA 917304/CP0709 52
LUBRICATION OIL LINE
T-ZNMS and T-ZNTBL Engines
53 917304/CP0709 PRINTED IN USA
LUBRICATION OIL LINE
Ref. Part Quantity
No. No. Description T-ZNMS/T-ZNTBL
1 425-36085 SENDER, OIL PRESSURE (T-ZNMS) 1
425-34684 SENDER, OIL PRES SURE (T-ZNTBL) 1
2 197502 PIPE ASSY,LUB OIL (T-ZNMS) 1
197684 PIPE ASSY,LUB OIL (T-ZNTBL) 1
3 138510 RETAINER 1
4 138471 BOLT, PIPE JOINT 1
5 186468 BOLT ASSY, JOINT 1
6 425-34750 SEAL WASHER 8S 1
7 186600 JOINT BOLT 3 1
8 425-34750 SEAL WASHER 8S 1
9 425-34837 GASKET 10, ROUND 2
10 425-34729 BOLT M 8X 12 PLATED 1
11 197633 PIPE ASSY, LUB.OIL 1
13 186421 SUPPORT,PIPE 1
15 186468 BOLT ASSY, JOINT 2
16 425-34750 SEAL WASHER 8S 2
17 186600 JOINT BOLT 3 2
18 425-34750 SEAL WASHER 8S 2
19 425-34729 BOLT M 8X 12 PLATED 1
20 186565 PIPE 1
21 186300 BOLT, PIPE JOINT 2
22 425-34750 SEAL WASHER 8S 4
23 138509 ELBOW (PT3/8) 1
24 197751 PIPE ASSY, LUB. OIL (T-ZNMS) 1
197701 PIPE ASSY, LUB. OIL (T-ZNTBL) 1
425-34729 BOLT M 8X 12 PLATED (T-ZNTBL) 1
197480 RETAINER (T-ZNTBL) 1
25 197618 GASKET,LO-T RETURN 1
26 138492 HOSE 1
27 197790 CLAMP 25 2
28 425-35164 BOLT M 6X 16 PLATED 2
29 197617 VALVE ASSY, CHECK 4
35 197445 NOZZLE, PISTON JET 4
36 138117 SPRING PIN 3X10 4
PRINTED IN USA 917304/CP0709 54
GENERATOR
ZNTBL and T-ZNTBL Engines
55 917304/CP0709 PRINTED IN USA
GENERATOR
Ref. Part Quantity
No. No. Description ZNTBL/T-ZNTBL
1 186484 STUD 1
2 184401 ALTERNATOR 1
3 186315 ROTOR AS S Y 1
4 188508 BEARING, BALL 1
5 186325 COVER, BEARIN G 1
6 186316 FLAME ASSY, DRIVE 1
7 186321 BALL BEARING 1
8 186322 PLATE 1
9 186323 SCREW 4
10 186324 BOLT, STUD 2
11 186317 FLAME ASSY, REAR 1
12 186318 PULLEY 1
13 186319 NUT 1
14 186320 COLLAR 1
15 186475 REGULATOR 1
16 186326 HOLDER 1
17 186469 HOLDER, BRUSH 1
18 186327 SCREW 6
19 186328 SCREW 1
20 186476 COVER, END, RR 1
21 186329 BOLT 3
22 186477 NUT 1
23 186330 SCREW W/ WASHER 2
24 186331 BOLT 2
25 186332 INSULATION BUSH 1
26 186333 NUT 2
27 186334 THRUST WASHER 1
28 138141 NUT 1
29 197600 ADJUSTER, BELT 1
30 137950 SPACER 1
31 197453 BROCK, GENERATOR CMP 1
33 197806 BOLT 8*100 1
34 138140 NUT 1
35 425-35026 BOLT M8X25 1
36 425-34748 BOLT M8X55 PLATED 1
PRINTED IN USA 917304/CP0709 56
SECTION NOTES
57 917304/CP0709 PRINTED IN USA
INDEX
Part Page Ref.
No. No. No.
137930 44 25
137947 4 43
137948 4 30
137949 4 45
137950 56 30
137953 28 11
137953 30 11
137953 42 12
137956 24 11
137957 24 4
137958 24 5
137962 40 26
138020 22 9
138056 44 21
138057 44 22
138058 44 24
138072 28 3
138072 30 3
138091 48 35
138091 50 41
138093 28 7
138093 30 7
138097 22 6
138098 24 3
138100 4 16
138100 26 8
138100 28 20
138100 30 32
138100 48 3
138100 50 3
138101 4 17
138101 48 4
138101 50 4
138104 18 17
138104 20 30
138104 48 23
138104 50 26
138107 42 6
138113 6 11
138113 48 9
138113 50 9
138117 54 36
138123 32 26
138123 34 20
138123 34 29
138127 4 31
138127 48 8
138127 50 8
138133 4 32
138136 30 31
138139 4 15
138140 8 49
138140 12 53
138140 18 7
138140 18 11
138140 18 11
138140 20 12
138140 20 24
Part Page Ref.
No. No. No.
138140 52 3
138140 56 34
138141 4 23
138141 56 28
138154 48 36
138154 50 42
138471 54 4
138479 12 81
138488 20 9
138488 50 25
138492 54 26
138509 54 23
138510 54 3
138512 18 6
138512 20 3
138522 18 16
160427 32 35
160427 34 37
160427 48 33
160427 50 39
160427 50 39
160888 46 35
160891 46 36
183543 34 14
184401 56 2
184405 34 57
185643 4 44
185644 4 46
185645 4 47
185645 50 7
186300 26 27
186300 30 50
186300 54 21
186301 34 75
186302 26 6
186302 30 21
186303 34 61
186308 42 22
186311 34 64
186314 8 30
186314 10 34
186315 56 3
186316 56 6
186317 56 11
186318 56 12
186319 56 13
186320 56 14
186321 56 7
186322 56 8
186323 56 9
186324 56 10
186325 56 5
186326 56 16
186327 56 18
186328 56 19
186329 56 21
186330 56 23
186331 56 24
Part Page Ref.
No. No. No.
186332 56 25
186333 56 26
186334 56 27
186335 8 61
186336 46 32
186336 46 33
186337 8 25
186337 10 29
186337 48 12
186337 50 12
186340 42 25
186343 24 21
186358 34 71
186359 34 68
186360 34 67
186361 34 70
186370 32 22
186370 34 25
186370 48 29
186370 50 35
186371 32 23
186371 34 26
186375 20 6
186388 8 55
186389 8 56
186390 8 57
186391 8 58
186401 8 35
186401 10 39
186406 8 3
186406 10 5
186407 40 25
186410 8 21
186410 10 25
186411 8 20
186411 10 24
186421 26 19
186421 30 43
186421 54 13
186430 42 14
186431 42 15
186431 48 34
186431 50 40
186432 42 20
186442 28 8
186442 30 8
186443 28 10
186443 30 10
186451 30 17
186461 34 69
186463 44 29
186464 42 18
186466 4 27
186466 4 38
186467 42 1
186468 26 21
186468 30 44
186468 54 5
Part Page Ref.
No. No. No.
186468 54 15
186469 56 17
186471 22 1
186473 40 30
186475 56 15
186476 56 20
186477 56 22
186478 42 4
186479 34 66
186483 42 22
186484 56 1
186485 2 27
186486 2 4
186487 4 26
186489 4 36
186490 4 37
186491 2 6
186493 2 9
186494 2 24
186498 24 3
186499 24 14
186501 24 26
186502 24 27
186505 22 10
186506 22 20
186507 4 42
186508 30 33
186510 24 1
186513 2 28
186513 48 2
186513 50 2
186518 8 54
186518 12 58
186519 8 1
186519 8 1
186519 10 1
186520 8 11
186520 10 15
186521 8 12
186521 10 16
186522 8 13
186522 10 17
186523 8 32
186523 10 36
186524 8 33
186524 10 37
186525 8 34
186525 10 38
186528 8 31
186528 10 35
186529 8 17
186529 10 21
186530 8 36
186530 10 40
186531 8 40
186531 10 44
186533 8 24
186533 10 28
NUMERICAL INDEX
PRINTED IN USA 917304/CP0709 58
INDEX
Part Page Ref.
No. No. No.
186534 8 27
186534 10 31
186535 8 44
186535 12 48
186538 14 1
186538 16 1
186538 48 16
186538 50 16
186539 22 2
186543 4 4
186553 40 6
186554 42 13
186563 34 60
186564 32 19
186564 34 22
186565 26 26
186565 30 49
186565 54 20
186567 18 18
186568 18 19
186569 30 17
186570 30 23
186574 30 40
186576 6 2
186578 24 12
186579 22 15
186580 30 20
186582 30 19
186582 30 25
186585 24 8
186586 4 3
186587 30 3
186590 22 17
186593 18 20
186595 30 29
186595 50 9
186596 22 18
186596 36 106
186598 8 63
186598 8 64
NUMERICAL INDEX
186598 12 63
186600 26 23
186600 30 46
186600 54 7
186600 54 17
186602 8 8
186602 10 12
186607 4 18
186607 36 109
186607 46 28
186607 48 5
186607 50 5
186609 28 13
186609 30 13
186609 50 28
186610 30 30
186610 50 8
186611 24 10
Part Page Ref.
No. No. No.
186611 48 24
186611 50 27
186612 4 19
186612 48 6
186612 50 6
186615 8 65
186615 12 64
186615 32 15
186615 34 15
186615 36 132
186615 46 31
186618 14 12
186618 16 22
186622 6 5
186623 6 6
186624 8 45
186624 12 49
186626 22 19
186626 36 117
186635 2 29
186662 24 9
186663 24 7
186664 4 35
186665 30 27
186666 30 28
186676 36 54
186678 36 30
188447 40 12
188448 40 13
188508 56 4
188567 28 5
188567 30 5
188573 4 1
188573 6 1
188596 8 38
188596 8 42
188596 10 42
188596 10 46
188632 12 71
188632 12 74
188691 42 11
188732 16 7
188732 16 8
188732 32 27
188732 34 30
188736 12 87
188742 4 29
188742 4 40
188742 8 46
188742 12 50
188742 14 11
188742 16 21
188746 8 47
188746 8 48
188746 12 51
188746 12 52
188746 32 31
188746 34 34
Part Page Ref.
No. No. No.
188748 44 31
188754 40 36
188757 2 14
192290 36 125
192292 36 123
192294 36 99
192295 36 127
192296 36 128
192297 36 102
192298 36 129
192299 36 103
193024 42 2
193206 46 19
194315 26 7
194315 28 19
194315 30 22
194316 44 1
194317 42 23
197444 44 30
197445 54 35
197446 34 61
197448 46 22
197449 12 61
197450 14 7
197450 16 17
197450 48 17
197450 50 18
197451 14 10
197451 16 20
197452 46 13
197453 56 31
197454 34 74
197459 32 34
197459 34 36
197462 18 4
197463 20 16
197469 18 1
197470 6 8
197472 8 15
197472 10 19
197472 48 10
197472 50 10
197475 12 77
197476 16 14
197477 36 71
197480 54 24
197481 28 2
197481 30 2
197482 30 26
197483 16 13
197488 38 19
197493 46 23
197494 46 25
197495 46 26
197496 46 27
197500 42 10
197502 54 2
197503 48 1
Part Page Ref.
No. No. No.
197503 50 1
197504 50 1
197507 18 2
197507 18 21
197508 42 17
197510 36 122
197514 50 26
197514 52 2
197572 12 62
197590 6 2
197591 2 32
197592 2 35
197593 4 41
197594 24 23
197595 24 30
197596 24 29
197597 22 10
197598 24 1
197599 36 56
197600 56 29
197601 8 52
197601 12 56
197602 8 53
197602 12 57
197603 8 28
197603 10 32
197604 24 9
197605 22 16
197606 30 14
197607 26 2
197607 28 15
197608 36 53
197609 20 7
197610 22 3
197611 22 3
197612 24 1
197613 24 1
197614 4 4
197615 28 1
197615 30 1
197616 28 4
197616 30 4
197617 54 29
197618 50 32
197618 54 25
197619 28 6
197619 30 6
197620 6 7
197621 8 51
197622 8 4
197624 14 2
197625 18 1
197626 18 8
197627 18 9
197627 20 18
197627 48 20
197627 50 22
197628 18 12
917304/CP0709 PRINTED IN USA59
INDEX
Part Page Ref.
No. No. No.
197628 20 25
197629 18 13
197629 20 26
197629 48 21
197629 50 23
197630 18 14
197630 20 27
197630 48 22
197630 50 24
197631 24 17
197632 24 15
197633 26 17
197633 30 42
197633 54 11
197634 32 1
197634 34 1
197635 32 17
197635 34 17
197636 32 36
197636 34 38
197637 32 40
197637 34 42
197638 32 16
197639 36 136
197640 36 21
197641 36 31
197642 36 120
197643 36 121
197644 36 124
197645 40 2
197646 40 6
197647 42 16
197648 40 32
197649 40 33
197650 40 34
197651 40 35
197652 38 4
197653 38 3
197654 38 5
197655 38 10
197656 38 20
197657 38 20
197658 38 21
197659 46 1
197660 46 11
197661 46 12
197662 46 34
197663 46 37
197664 6 8
197665 12 68
197666 12 69
197666 12 72
197667 12 77
197668 10 2
197669 12 55
197670 10 6
197671 16 3
197672 16 2
Part Page Ref.
No. No. No.
197673 20 2
197674 20 1
197675 20 13
197676 20 14
197676 20 15
197676 50 21
197677 16 4
197678 16 5
197679 16 6
197679 50 17
197680 20 17
197681 20 19
197682 24 15
197683 26 3
197683 28 16
197684 54 2
197685 34 18
197686 34 19
197687 34 46
197688 34 51
197689 34 16
197690 36 31
197691 40 2
197692 12 77
197693 38 6
197694 34 55
197695 32 14
197695 34 14
197696 34 14
197697 4 3
197698 8 60
197698 12 60
197698 48 15
197698 50 15
197699 20 8
197700 52 1
197701 54 24
197702 34 16
197703 46 20
197704 46 30
197705 14 9
197705 16 19
197710 30 39
197711 30 52
197712 30 40
197713 46 1
197714 46 1
197716 44 2
197717 44 5
197718 44 6
197719 44 7
197720 44 8
197721 44 9
197722 44 10
197723 44 11
197724 44 12
197725 44 13
197726 44 14
Part Page Ref.
No. No. No.
197727 44 15
197728 44 16
197729 44 17
197730 44 18
197731 44 19
197732 44 20
197733 8 1
197734 30 23
197735 30 26
197737 20 2
197738 34 47
197739 24 12
197740 30 23
197741 34 16
197742 46 1
197743 26 9
197743 28 21
197744 30 26
197745 34 48
197745 34 52
197746 42 8
197747 12 79
197748 12 80
197749 12 78
197750 16 12
197751 54 24
197752 22 20
197753 6 8
197754 36 9
197760 38 23
197762 38 7
197763 38 8
197764 38 9
197765 38 11
197766 38 12
197767 38 22
197768 36 67
197769 38 2
197770 36 19
197770 36 20
197772 36 18
197773 36 52
197779 8 62
197780 46 24
197781 46 21
197782 38 13
197783 24 22
197784 38 14
197786 38 16
197788 46 14
197789 12 83
197790 28 12
197790 30 12
197790 54 27
197792 12 84
197793 32 39
197793 32 43
197793 34 41
Part Page Ref.
No. No. No.
197793 34 45
197795 38 17
197797 38 26
197800 36 111
197802 32 44
197802 34 57
197803 34 57
197804 46 29
197805 38 27
197806 56 33
197807 18 10
197807 18 15
197808 20 28
197809 20 29
197810 12 82
197813 38 18
197816 36 116
197817 36 133
197818 36 134
197826 4 33
197827 2 1
197828 24 32
197829 24 34
197830 40 1
197831 2 1
197832 24 32
197833 40 1
197834 36 1
197835 36 1
197836 36 1
197837 36 1
197870 30 14
197871 50 1
270970 28 28
270970 32 32
270981 42 26
425-34656 22 4
425-34666 40 9
425-34684 30 41
425-34684 54 1
425-34707 34 65
425-34707 50 31
425-34722 2 5
425-34727 32 29
425-34727 34 32
425-34727 48 32
425-34727 50 38
425-34729 6 12
425-34729 12 86
425-34729 26 14
425-34729 26 25
425-34729 28 26
425-34729 30 38
425-34729 30 48
425-34729 32 30
425-34729 34 33
425-34729 34 56
425-34729 54 10
NUMERICAL INDEX
PRINTED IN USA 917304/CP0709 60
INDEX
Part Page Ref.
No. No. No.
425-34729 54 19
425-34729 54 24
425-34733 4 20
425-34733 4 28
425-34733 4 39
425-34733 8 2
425-34733 10 3
425-34733 18 22
425-34733 20 10
425-34733 22 8
425-34733 26 5
425-34733 26 15
425-34733 28 18
425-34733 28 27
425-34736 34 63
425-34740 4 24
425-34740 8 50
425-34740 12 54
425-34744 42 27
425-34745 4 25
425-34745 8 68
425-34745 12 67
425-34745 48 7
425-34745 50 7
425-34745 50 7
425-34746 4 21
425-34746 10 4
425-34746 18 23
425-34746 20 11
425-34746 36 137
425-34747 4 22
425-34747 14 5
425-34747 16 10
425-34747 20 21
425-34747 34 62
425-34748 20 22
425-34748 22 14
425-34748 32 13
425-34748 34 13
425-34748 56 36
NUMERICAL INDEX
425-34750 26 22
425-34750 26 24
425-34750 26 28
425-34750 30 45
425-34750 30 47
425-34750 30 51
425-34750 42 21
425-34750 48 26
425-34750 50 30
425-34750 50 30
425-34750 54 6
425-34750 54 8
425-34750 54 16
425-34750 54 18
425-34750 54 22
425-34756 6 4
425-34760 36 138
425-34760 42 3
Part Page Ref.
No. No. No.
425-34761 20 20
425-34761 34 62
425-34765 38 28
425-34766 30 31
425-34772 12 76
425-34775 8 66
425-34775 12 65
425-34776 8 29
425-34776 8 67
425-34776 10 33
425-34776 12 66
425-34776 48 14
425-34776 50 14
425-34779 8 10
425-34779 10 14
425-34780 14 4
425-34780 16 9
425-34783 2 10
425-34791 8 19
425-34791 8 39
425-34791 8 43
425-34791 10 23
425-34791 10 43
425-34791 12 47
425-34796 8 26
425-34796 10 30
425-34796 48 13
425-34796 50 13
425-34800 14 6
425-34800 16 11
425-34810 22 7
425-34810 24 6
425-34813 22 13
425-34825 26 1
425-34825 28 14
425-34825 30 15
425-34827 26 4
425-34827 28 17
425-34827 30 16
425-34827 48 25
425-34827 50 29
425-34837 50 31
425-34837 54 9
425-34851 32 33
425-34851 34 35
425-34854 34 72
425-34892 36 108
425-34903 40 5
425-34905 40 10
425-34906 40 11
425-34916 42 5
425-34916 42 9
425-34924 42 24
425-34927 42 28
425-34935 38 24
425-34968 36 131
425-34969 38 15
425-35026 56 35
Part Page Ref.
No. No. No.
425-35164 54 28
425-35165 32 12
425-35165 34 12
425-35174 36 100
425-35174 38 25
425-35188 8 14
425-35188 10 18
425-35189 8 22
425-35189 10 26
425-35191 8 16
425-35191 10 20
425-35191 48 11
425-35191 50 11
425-35263 36 112
425-35273 34 73
425-35343 38 19
425-35452 40 27
425-35916 44 29
425-35705 36 113
425-35772 20 23
425-35959 32 25
425-35959 34 28
425-35959 36 98
425-35959 36 105
425-35959 36 130
425-35959 48 30
425-35959 50 36
425-36085 26 16
425-36085 54 1
425-36113 32 11
425-36113 34 11
425-36113 48 27
425-36113 50 33
425-36114 32 21
425-36114 34 24
425-36114 48 28
425-36114 50 34
425-36120 6 8
425-36121 6 9
425-36128 18 3
425-36128 20 5
425-36128 48 19
425-36128 50 20
425-36131 16 15
425-36133 16 16
425-36249 18 5
425-36249 20 4
425-36260 2 1 1
425-36260 2 12
425-36260 2 13
425-36260 8 9
425-36260 10 13
425-36260 12 85
425-36289 42 7
425-36301 44 31
425-36318 14 8
425-36318 16 18
425-36318 48 18
Part Page Ref.
No. No. No.
425-36318 50 19
425-36319 32 28
425-36319 34 31
425-36319 48 31
425-36319 50 37
917304/CP0709 PRINTED IN USA61
TORQUE SPECIFICATIONS
Use these torque values when tightening hardware (excluding locknuts, and self-tapping, thread-forming,
and sheet metal screws) unless otherwise specified.
UNIFIED
NATIONAL
THREAD
8-32
8-36
10-24
10-32
1/4-20
1/4-28
5/16-18
5/16-24
3/8-16
3/8-24
7/16-14
7/16-20
1/2-13
1/2-20
9/16-12
9/16-18
5/8-11
5/8-18
3/4-10
3/4-16
7/8-9
7/8-14
1-8
1-12
GRADE 2 GRADE 5 GRADE 8
DRY LUBED DRY LUBED DRY LUBED
19*
20*
27*
31*
66*
76*
11
12
20
23
32
36
50
55
70
80
100
110
175
200
170
180
250
270
14*
15*
21*
23*
50*
56*
9
9
15
17
24
27
35
40
55
60
75
85
130
150
125
140
190
210
30*
31*
43*
49*
9
10
17
19
30
35
50
55
75
90
110
120
150
180
260
300
430
470
640
710
22*
23*
32*
36*
75*
86*
13
14
23
25
35
40
55
65
80
90
110
130
200
220
320
360
480
530
41*
43*
60*
68*
12
14
25
25
45
50
70
80
110
120
150
170
220
240
380
420
600
660
900
1000
31*
32*
45*
51*
9
10
18
20
35
35
55
60
80
90
110
130
170
180
280
320
460
500
680
740
METRIC
COARSE
THREAD
M6-1
M8-1.25
M10-1.5
M12-1.75
M14-2
M16-2
*All torque values are in ft-lbs except those marked with an * which are in lbs.
For metric torque value (N·m) multiply ft-lbs value by 1.355 or the in-lbs value by 0.113.
GRADE 8.8 GRADE 10.9 GRADE 12.9
DRY LUBED DRY LUBED DRY LUBED
8
19
37.5
65
103.5
158.5
6
14
28
48
76.5
117.5
11
27
53
91.5
145.5
223.5
8
20
39
67.5
108
165.5
13.5
32.5
64
111.5
176.5
271
10
24
47
82
131
200
®
Gehl Company 143 Water Street, P.O. Box 179, West Bend, WI 53095-0179 USA
www.gehl.com
917304/CP0709
© 2009 GEHL COMPANY PRINTED IN USA
All Rights Reserved.
Loading...
