Congratulations and thank you for purchasing the Yamaha PLG150-DR Drums Plug-in Board/ PLG150-PC Percussion Plug-in Board!

The PLG150-DR/PLG150-PC is a custom tone generator designed for use with a variety of Yamaha electronic musical instruments. Foremost, the PLG150-DR/PLG150-PC can be installed to and integrated with instruments of the Modular Synthesis Plug-in System (such as the MOTIF, S80, etc.) It can also be used seamlessly with the MU128 Tone Generator (as well as other MU-series instruments and the SW1000XG PCI Audio/MIDI Board). To install your PLG150-DR/PLG150-PC correctly and to ensure full enjoyment of its sophisticated functions, be sure to read this manual very carefully. When ﬁnished, keep the manual in a secure and convenient place for future reference.

SPECIAL NOTICE

• The product and this owner's manual are exclusive copyrights of Yamaha Corporation.

• Use of the software and this manual is governed by the SOFTWARE LICENCING AGREEMENT which the purchaser fully agrees to upon breaking the seal of software packing. (Please read carefully the AGREEMENT at the end of this manual before installing the application.)

• Copying of the software or reproduction of this manual in whole or in part by any means is expressly forbidden without the written consent of the manufacturer.

• Yamaha makes no representations or warranties with regard to the use of the software and documentation and cannot be held responsible for the results of the use of this manual and software.

• This product incorporates and bundles computer programs and contents in which Yamaha owns copyrights or with respect to which it has license to use others' copyrights. Such copyrighted materials include, without limitation, all computer software, styles ﬁles, MIDI ﬁles, WAVE data and sound recordings. Any unauthorized use of such programs and contents outside of personal use is not permitted under relevant laws. Any violation of copyright has legal consequences. DON'T MAKE, DISTRIBUTE OR USE ILLEGAL COPIES.

• Copying of the commercially available music sequence data and/or digital audio ﬁles is strictly prohibited except for your personal use.

• Future upgrades of application and system software and any changes in speciﬁcations and functions will be announced separately.

About the Modular Synthesis Plug-in System

The Yamaha Modular Synthesis Plug-in System offers powerful expansion and upgrade capabilities for Modular Synthesis-Plug-in-compatible synthesizers, tone generators and sound cards. This enables you to easily and effectively take advantage of the latest and most sophisticated synthesizer and effects technology, allowing you to keep pace with the rapid and multifaceted advances in modern music production.

About the XG Plug-in System

The Yamaha XG Plug-in System offers powerful expansion and upgrade capabilities for XGPlug-in-compatible tone generators and sound cards. This enables you to easily and effectively take advantage of the latest and most sophisticated synthesizer and effects technology, allowing you to keep pace with the rapid and multi-faceted advances in modern music production.

Overview of the PLG150-DR/PLG150-PC ........................................................... 5

Main Features of the PLG150-DR/PLG150-PC................................................ 5

Included Items .................................................................................................. 5

Required and Recommended Items................................................................. 6

Installing the PLG150-DR/PLG150-PC ............................................................ 6

Specifications ................................................................................................... 6

Parameter Structure

.......................................................................................... 7

For Modular Synthesis Plug-in System Users

................................................ 8

Selecting DR/PC Voices................................................................................... 8

Editing the DR/PC Native Part Parameters ...................................................... 9

For XG Plug-in System Users............................................................................ 10

Editing the DR/PC Native Part Parameters .................................................... 12

Parameters.......................................................................................................... 13

Native Part Parameters .................................................................................. 13

Native System Parameter............................................................................... 15

Voice Edit Parameters.................................................................................... 15

About the Included CD-ROM ............................................................................... 18

For Windows Users ........................................................................................ 18

For Macintosh Users ...................................................................................... 24

Demonstration Songs ..................................................................................... 25

Appendix

................................................................................................................ 26

Voice List............................................................................................................ 26

DR/PC Plug-in Voice List ..................................................................................52

Effect List ...........................................................................................................53

Parameter List (XG/Modular Synthesis Plug-in System)...................................... 59

MIDI Data Format ...............................................................................................60

MIDI Implementation Chart ...............................................................................70

Table of Contents

Overview of the PLG150-DR/PLG150-PC

● Once connected and installed, the PLG150-DR/PLG150-PC becomes a seamless additional sound

source for the host tone generator or synthesizer — providing a total of 88 drum/percussion voices (80 Preset, 8 User), which can be edited from the panel of the host device. The PLG150-DR/ PLG150-PC can be easily installed to any device compatible with the Modular Synthesis Plug-in System or the XG Plug-in System.

● A single PLG150-DR/PLG150-PC Plug-in Board functions as one part for the host device, provid-

ing up to 32 different voices (in mono sampling), and several boards can be installed to the same host device.

● Thanks to the built-in effect processing power, the PLG150-DR/PLG150-PC has two separate

effect blocks — Insertion and Reverb — that can be applied to each kit.

● With the included Voice Editor, you can easily edit the sound for each note in the kit as well as the

effect parameters, and create up to eight original User kits — all from your Windows computer.

● The PLG150-DR also features a special drum kit based on the stunning stereo drum kit of the pop-

ular Yamaha MOTIF. (Not all of the sounds are exactly the same.) For MOTIF users, this means you can use the PLG150-DR to play high-quality drum tracks and free up maximum polyphony for other sounds on the MOTIF.

● The PLG150-DR also has drum kits that have the same note mapping as XG kits — making them

fully compatible with any XG song data. This means you can simply enter desired program changes, and your drum tracks will play and sound exactly as intended — or even better!

The following items have been included in the package of your new PLG150-DR/PLG150-PC. Please make sure that you have them all before starting to setup and use the instrument. If an item is missing, contact the store or dealer from which you purchased the PLG150-DR/PLG150-PC.

• PLG150-DR/PLG150-PC Plug-in Board

• PLG150-DR/PLG150-PC Owner’s Manual (this book)

• CD-ROM

Main Features of the PLG150-DR/PLG150-PC

Included Items

Overview of the PLG150-DR/PLG150-PC

In addition to the included items listed above, you should also have the following:

■ Synthesizer/Tone Generator/Sound Card Compatible with the Modular Synthesis or XG Plug-in Systems

In order to use the PLG150-DR/PLG150-PC, you’ll need a synthesizer, tone generator or sound card that is compatible with the Modular Synthesis Plug-in System or the XG Plug-in System. Compatible instruments include the MOTIF, MU128, and the SW1000XG. The synthesizer/tone generator/sound card should also have an available slot or space for installing the PLG150-DR/PLG150-PC.

For detailed instructions on installing the PLG150-DR/PLG150-PC, refer to the owner’s manual of the Plug-in-compatible “mother” device (e.g., MOTIF, MU128, etc.).

Tone Generation System : AWM2 (Advanced Wave Memory 2) Polyphony : 32 (when using mono-sampled voices) Number of voices : 80 Preset voices, 8 User voice area Interface : Plug-in connector Effects : Insertion, Reverb Dimensions (W x H x D) : 138.5 x 89.0 x 8.5mm Weight : 62g Included Items : Owner’s Manual, CD-ROM

* Speciﬁcations subject to change without notice.

Required and Recommended Items

Installing the PLG150-DR/PLG150-PC

Speciﬁcations

Parameter Structure

* See page 13 for details.

Part Parameters

XG Part Parameters

DR/PC Native Part Parameters

Plug-in Platform

Part Parameters

Plug-in Board

Offset

The Board voices are created with these parameters.

Voice Edit Parameters*

System Parameters

XG System Parameters

DR/PC Native System Parameters*

XG Effect Parameters

Reverb

Chorus

Variation

Insertion1

Insertion2

Part Parameters

XG Part Parameters

DR/PC Native Part Parameters*

Voice Reverb

Voice Insertion

DR/PC Voice Parameters

Inst128

Inst3

Inst2

Inst1

For Modular Synthesis Plug-in System Users

When the PLG150-DR/PLG150-PC is installed to a synthesizer compatible with the Modular Synthesis Plug-in System, the DR/PC voices can be selected in the same way as the internal voices of the synthesizer.

• When several boards are installed to the same host device, set the “PolyExpand” parameter on the synthesizer to off.

• The example displays used in the following explanations are all taken from the MOTIF.

1 Enter the Voice Play mode.

Press the [VOICE] button.

2 Select a Plug-in voice.

Press any of the [PLG1] - [PLG3] buttons. The following display (or one similar) appears.

3 Select a Group.

Press any of the GROUP [A] - [H] buttons.

4 Select a Voice.

Press any of the NUMBER [1] - [16] buttons.

When using the PLG150-DR in the Song mode on the MOTIF, make sure to make these settings:

• Set the Receive Channel of the [PLG] part (the part to which the PLG150-DR has been assigned) to Channel 10.

• On the MOTIF, set the internal part assigned to Channel 10 to off.

Selecting DR/PC Voices

NOTE

For MOTIF6/MOTIF7/MOTIF8 users

To get the most out of your PLG150-DR/PLG150-PC, please go to the web address below and download the latest version of the MOTIF operating system.

http://www.yamahasynth.com

For Modular Synthesis Plug-in System Users

The following explanations show how to edit the DR/PC native part parameters when creating PLG voices, using the MOTIF Control Synthesizer as an example. For information on storing the PLG voices with your particular Modular Synthesis Plug-in System compatible instrument, refer to the owner’s manual of that instrument.

Keep in mind that the parameter values and settings below represent offsets of the actual voice settings. This means that adjustments made to the parameters may not make much change in the actual sound, depending on the original settings of the voice. For parameter values, a setting of “0” results in no change, while positive and negative values increase and decrease the value respectively.

1 Select the desired DR/PC voice, as described in “Selecting DR/PC Voices”

on page 8.

Enter the Voice Edit mode.

Press the [EDIT] button.

3 Select an element to be edited.

1) Press any one of the NUMBER buttons ([1] - [4]) to edit the element parameters.

2) Press the [F4] button to select the “NATIVE” element.

Select the desired parameter.

Use the cursor buttons to select the desired parameter.

For a list of available parameters, see page 13.

5 Adjust the value or change the setting for the selected parameter.

Use the [INC/YES] and [DEC/NO] buttons or the data dial.

Editing the DR/PC Native Part Parameters

NOTE

For XG Plug-in System Users

The PLG150-DR/PLG150-PC voices can be selected just like the voices of the XG tone generator. Keep in mind, though, that they can only be selected when the Sound Module Mode is set to XG or Performance. Also, the Part Assign parameter in the Utility mode (see below) must be set to the desired Part.

The example displays used in the following explanations are all taken from the MU128.

■ Enabling and Selecting DR/PC Voices

1 Set the Sound Module Mode to “XG” or “PFM” (Performance).

Press the [MODE] button and use the [SELECT </>] buttons.

2 Set the Part Assign parameter to the desired Part number.

To do this:

1) Press the [UTIL] button.

2) Select the “PLUGIN” menu (with the [SELECT

>] button) and press [ENTER].

3) Select the “PLG150-DR/PLG150-PC” menu if necessary (with the [SELECT </>] buttons),

and press [ENTER]. The Part Assign menu appears.

4) Use the [VALUE –/+] buttons or dial to change the Part number.

The Part Assign range for the XG mode is 1 - 16 and “off”; for the Performance mode, it is 1 - 4 and “off.”

Press the [EXIT] button to return to the Play mode.

When several boards are installed to the same host device, assign them to the different parts.

NOTE

For XG Plug-in System Users

3 Enable the PLG150-DR/PLG150-PC board for the desired Part.

First, make sure that the appropriate Part is selected (using the [PART –/+] buttons), then press the [SELECT] button. The icon of the selected board appears in the display and the corresponding LED at the bottom of the panel (PLG-1, -2, or -3) ﬂashes brieﬂy.

4 Select the desired bank number.

Move the cursor to the Bank Number parameter with the [SELECT </>] buttons and use the [VALUE –/+] buttons to select the desired bank.

5 Select the desired voice number.

Move the cursor to the Voice (Program) Number parameter with the [SELECT </>] buttons and use the [VALUE –/+] buttons to select the desired voice.

• DR Preset voice : 000, 001-080

• DR User voice : 000, 001-008

• PC Preset voice : 001, 001-080

• PC User voice : 001, 001-008

Alternately, you can select voices from a connected MIDI keyboard, or from sequencing software on a connected computer.

For a list of available voices and their bank/voice numbers, see page 26.

Bank Number parameter

DR Preset voice PC Preset voice PC User voiceDR User voice

For XG Plug-in System Users

Any of the DR/PC voices can be freely edited from the front panel with the DR/PC Native Part parameters. Keep in mind that changing the Part parameters does not permanently affect the original voice settings. The edits that you make here temporarily change the settings of the currently selected voice. When you select a different voice for the Part, the settings are applied to the newly selected voice.

• The parameter values and settings below represent offsets of the actual voice settings. This means that adjustments made to the parameters may not make much change in the actual sound, depending on the original settings of the voice. For parameter values, a setting of “0” results in no change, while positive and negative values increase and decrease the value respectively.

• The Part parameter settings cannot be saved in Multi Play mode. If you wish to save your Part parameter edits, do it from the Performance mode or Plug-in Board Editor.

• The example displays used in the following explanations are all taken from the MU128.

Select the Part having the DR/PC voice, then select the desired voice.

Select the appropriate Part with the [PART –/+] buttons, then, with the cursor at the Voice Number parameter, select the desired voice.

2 Press the [EDIT] button to enter the Edit mode.

3 Select the “PLUGIN” menu.

Use the [SELECT >] button, then press the [ENTER] button. The PLG150-DR/PLG150-PC Edit menu appears.

4 Select the desired parameter.

Use the [SELECT </>] buttons.

5 Adjust the value or change the setting for the selected parameter.

Use the [VALUE +/–] buttons.

6 Return to the main Play display.

Press the [EXIT] button several times, or press the [PLAY] button once.

Editing the DR/PC Native Part Parameters

NOTE

Parameters

These parameters are used to offset the actual settings (made on the host device) of the voices of the PLG150-DR/PLG150-PC Plug-in Board. Tune, Pan, Level, and other settings can be made for each of any four instruments, and Insertion effects can also be applied. Keep in mind that these offset Part parameters do not permanently change the original kit settings. Also remember that for parameters with values, a setting of “0” results in no change to the original setting, while positive and negative values change the setting accordingly. For example, if the original Pan setting for a sound is all the way to the left, a setting of “0” for the Pan parameter here does NOT represent “center” — it simply keeps the sound at its current hard-left position.

● Note Select 1 - Note Select 4

This determines the speciﬁc note (instrument sound) for which the same numbered Native Part parameters will be effective. Set this parameter to the note (1 - 4) you wish to edit, then set the corresponding parameters (1 - 4) below to edit it.

Range: C-2 — G8, Off

● Note Select 1 Tune - Note Select 4 Tune

This determines the pitch of the selected note’s instrument. The greater the value the higher the pitch. Negative values lower the pitch.

Range: -64 — +00 — +63

● Note Select 1 Level - Note Select 4 Level

This determines the level or volume of the selected note’s instrument. Range: -64 — +00 — +63

● Note Select 1 Pan - Note Select 4 Pan

This determines the stereo position of the selected note’s instrument. The lower the value (more negative), the further left the sound is in the stereo image. The higher the value (more positive), the further right the sound is.

Range: -127 — +00 — +127

● Note Select 1 Ins Eff - Note Select 4 Ins Eff (Insertion Effect)

This determines whether the PLG150-DR/PLG150-PC’s built-in Insertion effect is applied to the selected note’s instrument or not. (When set to “on,” the Insertion effect is applied.) When this is set to “Inst,” the original setting for the kit is maintained.

Settings: off, on, Inst

● Note Select 1 Rev Send - Note Select 4 Rev Send (Reverb Send)

This determines the level of the selected note’s instrument that is sent to the PLG150-DR/PLG150PC’s built-in Reverb effect. This parameter has no effect if the Insertion effect (above) is on.

Range: -127 — +00 — +127

Native Part Parameters

Parameters

● INS L.Freq (Insertion Effect — EQ Low Frequency)

This determines the particular frequency which is boosted or cut (in the Low Gain parameter below) for the selected note’s instrument. When this is set to “Vce,” the original setting for the kit (voice) is maintained.

Settings/Range: 50Hz — 2.0kHz, Vce (**** : Not available)

● INS L.Gain (Insertion Effect — EQ Low Gain)

This determines the level of the speciﬁed frequency (in the Low Frequency parameter above) for the selected note’s instrument. When this is set to “Vce,” the original setting for the kit (voice) is maintained.

Settings/Range: -12 — +12dB, Vce (**** : Not available)

● INS H.Freq (Insertion Effect — EQ High Frequency)

This determines the particular frequency which is boosted or cut (in the High Gain parameter below) for the selected note’s instrument. When this is set to “Vce,” the original setting for the kit (voice) is maintained.

Settings/Range: 500Hz — 16kHz, Vce (**** : Not available)

● INS H.Gain (Insertion Effect — EQ High Gain)

This determines the level of the speciﬁed frequency (in the High Frequency parameter above) for the selected note’s instrument. When this is set to “Vce,” the original setting for the kit (voice) is maintained.

Settings/Range: -12 — +12dB, Vce (**** : Not available)

● INS LFOFrq (Insertion Effect — LFO Frequency)

This determines the frequency of LFO modulation for the PLG150-DR/PLG150-PC’s built-in Insertion effect.

Range: -127 — +00 — +127 (**** : Not available)

● INS LFODpt (Insertion Effect — LFO Frequency)

This determines the depth of LFO modulation for the PLG150-DR/PLG150-PC’s built-in Insertion effect.

Range: -127 — +00 — +127 (**** : Not available)

● INS DryWet (Insertion Effect — Dry/Wet Balance)

This determines the balance between the direct, unprocessed sound (dry) and the Insertion-processed sound (wet).

Range: -127 — +00 — +127 (**** : Not available)

● INS Drive (Insertion Effect — Drive)

This determines the amount of distortion overdrive for the PLG150-DR/PLG150-PC’s built-in Insertion effect.

Range: -127 — +00 — +127 (**** : Not available)

• Keep in mind that some of these parameters are offset controls; the actual resulting sound may differ depending on the selected kit.

• If the currently selected kit does not have any effect or uses an effect type not corresponding to a certain parameter, the parameter is unavailable for editing and is indicated by asterisks (****).

• Whether an Insertion effect parameter is available or not differs depending the selected kit and its preassigned Insertion effect types. For details, refer to the “DR/PC Voice Effect Parameter List” in the Reference section (page 53).

NOTE

Parameters

The Native System parameter “Part Assign” is added to the Utility parameters of the XG tone generator. For more details on how to edit this, refer to the section “Enabling and Selecting DR/PC Voices” on page 10. If you are using the PLG150-DR/PLG150-PC with an Modular Synthesis Plug-in System compatible synthesizer, the Parts assigned to Plug-in Boards are ﬁxed and this parameter cannot be changed.

● Part Assign

This determines the Part to which the PLG150-DR/PLG150-PC voice is assigned. If a Part is not properly assigned here, none of the PLG150-DR/PLG150-PC voices can be selected for the Part. (This applies to XG Plug-in System compatible “mother” devices.)

Settings: 1 -16, off

These parameters are used to create original voices, and as such are more detailed and offer greater sonic control than the Native parameters. Voice Edit parameters are divided into two groups: 1) the Common parameters, which affect all instruments in the kit (voice), and 2) the Instrument parameters, which are set independently for each instrument. For greater ease and convenience in editing, use the Plug-in Board Editor, contained on the included CD-ROM. For detailed instructions on using the Plug-in Board Editor, refer to the electronic documentation on the CD-ROM.

● Name

This determines the name for the voice or kit.

● Volume

This determines the overall volume of the kit (voice). Range: 0 — 127

● Rev Send (Reverb Send)

This determines the level of the kit’s sound that is sent to the Reverb effect. Range: 0 — 127

● Original Kit

This lets you select one of the eighty Preset kits. Range: 0 — 79

Native System Parameter

Voice Edit Parameters

Common Parameters

Parameters

● Reverb Type

● Reverb Parameter 1 - 16

This determines the Reverb type for the kit (voice) and allows you to set each of sixteen different parameters. For details, refer to the “DR/PC Voice Effect Parameter List” on page 53 in the Reference section.

● Reverb Return

This determines the return level of the Reverb signal for the kit (voice). Range: 0 — 127

● Reverb Pan

This determines the stereo position for the kit (voice). Range: L63 — R63

● Insertion Type

● Insertion Parameter 1 - 16

This determines the Insertion effect type for the kit (voice) and allows you to set each of sixteen different parameters. For details, refer to the “DR/PC Voice Effect Parameter List” on page 53 in the Reference section.

● Insertion Rev Send (Insertion Reverb Send)

This determines the level of the Insertion effect that is sent to the Reverb for the kit (voice). Range: 0 — 127

● Inst (Instrument) Pitch Coarse

This determines the coarse pitch setting of the selected instrument in semitones. Range: -64 — +0 — +63

● Inst (Instrument) Pitch Fine

This determines the ﬁne pitch setting of the selected instrument in 1-cent steps. Range: -64 — +0 — +63

● Inst (Instrument) Level

This determines the level of the selected instrument. Range: 0 — 127

● Inst (Instrument) Alternate Group

This determines the group assignment of the selected instrument. Instruments that are assigned to the same group cannot sound simultaneously, and mute one another — useful for sounds like hihat, where a closed hi-hat cuts off the sound of an open hi-hat.

Settings: 0: Off; 1 — 127

● Inst (Instrument) Pan

This determines the stereo position of the selected instrument. The “Random” setting randomly assigns the sound to a pan position — useful for having different drum/percussion instruments sound from various parts of the stereo image.

Settings/Range: 0: Random; L63 — R63

Instrument Parameters

Parameters

● Inst (Instrument) Reverb Send

This determines the level of the selected instrument that is sent to the Reverb effect. This parameter has no effect if the Insertion effect (below) is on.

Range: 0 — 127

● Inst (Instrument) Insertion On/Off

This determines whether the Insertion effect is applied to the selected instrument or not. Settings: 0: Off; 1: On

● Inst (Instrument) Key Assign

When several notes are played at the same time, this determines whether the kit (voice) will sound the notes simultaneously (Multi) or one sound at a time (Single).

Settings: 0: Single, 1: Multi

● Inst (Instrument) Rcv Note Off (Receive Note Off)

This determines whether the selected instrument responds to MIDI Note Off messages or not. Settings: 0: Off; 1: On

● Inst (Instrument) Rcv Note On (Receive Note On)

This determines whether the selected instrument responds to MIDI Note On messages or not. Settings: 0: Off; 1: On

● Inst (Instrument) Filter Cutoff Frequency

This determines the cutoff frequency for the ﬁlter applied to the selected instrument. The greater the value, the more “open” the ﬁlter, and the brighter the sound becomes. The lower the value, the more muted the sound.

Range: -64 — +0 — +63

● Inst (Instrument) Filter Resonance

This determines the ﬁlter resonance or emphasis for the selected instrument. Range: -64 — +0 — +63

● Inst (Instrument) EG Attack

This determines the attack rate of the EG (envelope generator) for the selected instrument. Range: -64 — +0 — +63

● Inst (Instrument) EG Decay 1

This determines the ﬁrst decay rate of the EG (envelope generator) for the selected instrument. Range: -64 — +0 — +63

● Inst (Instrument) EG Decay 2

This determines the second or ﬁnal decay rate of the EG (envelope generator) for the selected instrument.

Range: -64 — +0 — +63

About the Included CD-ROM

This CD-ROM includes two types of data: application software and sampled audio data. Please refer to page 19 (Windows) and 24 (Macintosh) for software instllation instructions. You can play back the audio data from an audio CD player (or any CD playing/ripping function on your computer.)

Never attempt to play back track 1 (containing the application software) on an audio CD player. Doing so may damage to your hearing as well as to your CD player/audio speakers.

Track 1 : Application software; do NOT attempt to play back this track. Track 2 : Demonstration song recorded on the PLG150-DR. Track 3 : Demonstration song recorded on the PLG150-PC.

The included CD-ROM contain editing software to make user voices for the PLG150-DR/PLG150PC as well as demonstration songs and Voice data for the “mother” device. You can start the editing software as either a stand-alone software or a plug-in application in the Open Plug-in Technology compatible application (SQ01, etc.) You can save the user voice edited on this software as SMF format ﬁle. The SMF format ﬁle is used for any sequencers. For playing back the demonstration songs, you can use any compatible sequence software or hardware sequencer capable of sending bulk data.

CAUTION

For Windows Users

About Open Plug-in Technology

Open Plug-in Technology (OPT) is a newly developed software format that allows control over MIDI devices from a music software sequencer. For example, this allows you to start up and operate various parts of your music system, such as plug-in board editors, and mixing control editors — directly from an OPT-compatible sequencer, without having to use each separately. This also makes it unnecessary to set MIDI drivers for each application, streamlining your music production system and making all operations more convenient and seamless.

OPT Level Implementation for the Plug-in Board Editor

The client application and its compatibility with OPT can be divided into three levels, as shown below. (For more information, refer to the documentation or help ﬁles included with the client application.) This chart shows the OPT-compatibility of the Plug-in Board Editor.

NOTE: Certain operations may not work as expected if there is no corresponding function in the cli-

ent application (sequencer, etc.). The highest level of implementation for the client application is indicated in the OPT logo (which appears along with the version information in the application).

OPT levels of the client

application

Plug-in Board Editor operation

Operation support Operation limits

VIEWS (Level 3)

Yes None

PROCESSORS (Level 2)

Yes None

PANELS (Level 1)

Yes None

About the Included CD-ROM

■ Contents of the CD-ROM

*1 These applications are supplied with PDF manuals. Refer to the PDF manual for operating these applications.

*2 These applications are started as either a stand-alone application or a plug-in software in the Open Plug-in

Technology compatible application.

*3 Unfortunately, Yamaha makes no guarantee concerning the stability of these programs nor can it offer user sup-

port for them.

*4 When the PLG150-DR/PLG150-PC is installed to PLG1, select the ﬁle “**PlgVc1.mid” ; when the board is

installed to PLG2, select the ﬁle “**PlgVc2.mid” ; when the board is installed to PLG3, select the ﬁle “**PlgVc3.mid.”

For more details of demonstration songs, refer to page 25.

For a complete list of these voices, refer to the “DR/PC Plug-in Voice List” (page 52).

■ Minimum System Requirements

Plug-in Board Editor for PLG150-DR Plug-in Board Editor for PLG150-PC (using as a stand alone application)

NOTE: When using the Editor as a plug-in with OPT-compatible software, keep in mind that the minimum system

requirements will be higher than that of the host software.

For the minimum system requirements of the other software programs, refer to the relevant manuals.

Folder Name Application Name Contents

DR Plug_ Plug-in Board Editor for

PLG150-DR *1 *2

Enables you to edit the PLG150-DR voices on your computer.

Motif Plug-in Editor ﬁles for MOTIF Editor Enables you to edit the PLG150-DR voices on the Voice

Editor for MOTIF6/MOTIF7/MOTIF8.

Data Demonstration phrases Demonstration phrases created using the PLG150-DR.

Demonstration song (Drum solo) Demonstration song created using the PLG150-DR.

Plug-in Voice Data *4 This is Plug-in voice data, featuring a total of 64 voices

that were created using the PLG150-DR Preset voices.

PC Plug_ Plug-in Board Editor for

PLG150-PC *1 *2

Enables you to edit the PLG150-PC voices on your computer.

Motif Plug-in Editor ﬁles for MOTIF Editor Enables you to edit the PLG150-PC voices on the Voice

Editor for MOTIF6/MOTIF7/MOTIF8.

Data Demonstration phrases Demonstration phrases created using the PLG150-PC.

Demonstration song (XG) Demonstration song for XG Plug-in System devices

(MU128, etc.) created using the PLG150-PC.

Plug-in Voice Data *4 This is Plug-in voice data, featuring a total of 64 voices

that were created using the PLG150-PC Preset voices.

Acroread_ Acrobat Reader *1 *3 Enables you to view each PDF manual for the applica-

tions.

CPU Pentium (or Celeron) 450MHz or faster OS Windows® 98/98SE/Me/2000/XP Home Edition/XP Professional Edition Available Memory 16MB or more Hard Disk 12MB or more Display 800 x 600, High Color (16 bit)

About the Included CD-ROM

■ Software Installation

● Plug-in Board Editor for PLG150-DR/PLG150-PC

Double-click on the “Plug_” folder in “DR”/“PC” folder. “Setup.exe” ﬁle will be displayed.

Double-click on “Setup.exe.” Setup Dialog box will be displayed.

Execute the installation by following the on-screen directions.

● Acrobat Reader

In order to view the electronic (PDF) manuals included with each application, you’ll need to install Acrobat Reader.

If an older version of Acrobat Reader is installed on your PC, you’ll need to uninstall it before proceeding.

Double-click on the “ACROREAD” folder. Four different language folders will be displayed.

Select the language you want to use and double-click on its folder. “arxxx***.exe” ﬁle will be displayed. (“xxx” indicates ﬁgures and “***” indicates the selected language; e.g.,“ar500enu.exe.”)

Double-click on “arxxx***.exe.” Acrobat Reader Setup Dialog box will be displayed.

Execute the installation by following the on-screen directions. After installation is complete, the Acrobat folder appears on your PC (in Program Files, as the default). For information on using the Acrobat Reader, refer to the Reader Guide in the Help menu.

● Plug-in Editor ﬁles for MOTIF Editor

If you use the MOTIF, you can edit plug-in voices of the PLG150-DR/PLG150-PC on the Voice Editor for MOTIF by installing this ﬁles.

Double click on the “Motif” folder in the “DR”/“PC” folder. Three ﬁles will be displayed:

2 Copy the above ﬁles in the following folder on your PC.

Voice Editor for Motif6\Module\VEditor\Motif6\PlugIn

By default, the folder “Voice Editor for Motif6” is located in Program Files\YAMAHA\Tools.

NOTE

For the PLG150-DR:

• PLG150DR_VceList.ini

• Plg150DR.tpg

• Plg150DR.tpm

For the PLG150-PC:

• PLG150PC_VceList.ini

• Plg150PC.tpg

• Plg150PC.tpm

NOTE

About the Included CD-ROM

■ Starting the Plug-in Board Editor

If you are using a Modular Synthesis Plug-in System (MSPS) compatible synthesizer —

About Plug-in

Voices and Board Voices

The voices built into and used directly from the Plug-in Board are referred to as “Board voices,” while the Plugin Board voices that are processed with the parameters and controls of the host synthesizer are referred to as “Plug-in voices.”

Precautions for Creating User Voices

Make sure to change to the appropriate bank in the Voice Play mode on the host synthesizer before starting the Plug-in Board Editor. Select the Plug-in Board Voice bank so that you can directly monitor the User voice as you edit it.

● When using the Board Voice bank :

In this condition, any parameter changes made from the host synthesizer are not applied to the User voice.

● When selecting Preset banks, etc. :

In this condition, you can hear the changes made to the User voice by the parameter edits on the host synthesizer.

NOTE

MSPS compatible synthesizer

Speaker

Plug-in Board

Editor

User voice

Board voice

Data transmission

Computer

PLG150-DR/ PLG150-PC

MSPS compatible synthesizer

Speaker

Plug-in Board

Editor

User voice

Board voice

Data transmission

Computer

PLG150-DR/ PLG150-PC

Plug-in voice

parameters

Plug-in

voice

Plug-in voices for the CS6x/CS6R/S30/S80/MOTIF

The included CD-ROM contains voice data for use with the Yamaha CS6x, CS6R, S30, S80, and MOTIF. This data features 64 Plug-in voices specially programmed for the PLG150-DR/PLG150-PC.

About the Included CD-ROM

● Start the Plug-in Board Editor as a stand-alone application

Select the Plug-in Board Editor from the Start menu. (Programs m YAMAHA OPT Tools m Plug-in Board Editor for PLG150-DR/PLG150-PC m Plug-in Board Editor for PLG150-DR/ PLG150-PC)

The Plug-in Board Editor can also be started by double-clicking on any Library ﬁle made with the Editor.

Click the [MIDI SETUP] button called up in step #1 above, then set the appropriate MIDI port.

Select the part in the “Select Part” dialog and click “OK”.

● Start the Plug-in Board Editor in the client application as a plug-in software

The Plug-in Board Editor can be used as a plug-in software in any client application compatible with Open Plug-in Technology (OPT). Refer to the owner’s manual of the client application for details on using plug-in software.

For SQ01 users

By installing the Plug-in Board Editor, you can select PLG150-DR/PLG150-PC voices on your SQ01 or XG Editor. In order to use this function, make sure that the software is of the listed version (below) or higher. (The latest versions can be downloaded from the Yamaha website.)

SQ01 : ver. 1.07 or higher XG Editor : ver. 5.05 or higher

NOTE

About the Included CD-ROM

■ MIDI port setting (MIDI Setup)

Before setting the MIDI port on the Plug-in Board Editor, you should set the MIDI port as follows. This is the port that you’ll use in the Plug-in Board Editor.

● Using the Plug-in Board Editor as a stand-alone application

Start the Plug-in Board Editor.

Click the MIDI Setup button in the Toolbar called up via step #1.

3 In the MIDI Setup window called up via step#2, select the MIDI In/Out/Thru port of the

“mother” device.

• MIDI driver software is needed to set the port here. The appropriate MIDI driver is contained in the CD-ROM included with the “mother” device.

• When the “mother” device and your PC are connected with a USB cable, select “YAMAHA USB OUT xxx.” When they are connected with serial cable, select “YAMAHA CBX Driver.” For details, refer to the owner’s manual of the “mother” device.

● Using the Plug-in Board Editor in the client application as a plug-in software

Select the relevant MIDI port from the MIDI Setup dialog in the client application. Refer to the client application owner’s manual.

MIDI Setup button

NOTE

About the Included CD-ROM

■ Contents of the CD-ROM

* When the PLG150-DR/PLG150-PC is installed to PLG1, select the ﬁle “**PlgVc1.mid” ; when the board is

installed to PLG2, select the ﬁle “**PlgVc2.mid” ; when the board is installed to PLG3, select the ﬁle “**PlgVc3.mid.”

For more details of demonstration songs, refer to page 25.

For a complete list of these voices, refer to the “DR/PC Plug-in Voice List” (page 52).

■ Plug-in Editor ﬁles for MOTIF Editor

If you use the MOTIF, you can edit plug-in voices of the PLG150-DR/PLG150-PC on the Voice Editor for MOTIF by installing this ﬁles.

1 Double click on the “Motif” folder in the “DR”/“PC” folder.

Three ﬁles will be displayed:

2 Copy the above ﬁles in the following folder on your computer.

Voice Editor for Motif 6\VEditor\PlugIn

By default, the folder “Voice Editor for Motif6” is located in the “YAMAHA Tools” folder.

Folder Name Application Name Contents

DR Motif Plug-in Editor ﬁle for MOTIF Editor Enables you to edit the PLG150-DR voices on the Voice

Editor for MOTIF6/MOTIF7/MOTIF8.

Data Demonstration phrases Demonstration phrases created using the PLG150-DR.

Demonstration song (Drum solo) Demonstration song created using the PLG150-DR.

Plug-in Voice Data * This is Plug-in voice data, featuring a total of 64 voices

that were created using the PLG150-DR Preset voices.

PC Motif Plug-in Editor ﬁle for MOTIF Editor Enables you to edit the PLG150-PC voices on the Voice

Editor for MOTIF6/MOTIF7/MOTIF8.

Data Demonstration phrases Demonstration phrases created using the PLG150-PC.

Demonstration song (XG) Demonstration song for XG Plug-in System devices

(MU128, etc.) created using the PLG150-PC.

Plug-in Voice Data * This is Plug-in voice data, featuring a total of 64 voices

that were created using the PLG150-PC Preset voices.

For Macintosh Users

For the PLG150-DR:

• PLG150DR_VceList.ini

• Plg150DR.tpg

• Plg150DR.tpm

For the PLG150-PC:

• PLG150PC_VceList.ini

• Plg150PC.tpg

• Plg150PC.tpm

NOTE

About the Included CD-ROM

This CD-ROM includes two types of demonstration songs : SMF format ﬁles and sampled audio data. The SMF format ﬁles are used for any sequencers. The audio data is played back on an audio CD player (or any CD playing/ripping function on your computer.) The SMF format ﬁles are contained on track1 (as recognized on an audio CD player) and the audio data is contained in the subsequent tracks.

Never attempt to play back track 1 (containing the application software) on an audio CD player. Doing so may damage to your hearing as well as to your CD player/audio speakers.

■ “Solo Phrases” (SMF format)

● Demonstration phrases for PLG150-DR

DS00ROCK.MID — DS14HOUS.MID Composed by Scott Plunkett & Philip A. Bloch DS15FUNK.MID — DS22AMB3.MID Composed by Ryuichi Sato

Demonstration phrases were created using the PLG150-DR.

● Demonstration phrases for PLG150-PC

PS00SALS.MID — PS04HIPH.MID Composed by Geoff Stradling PS05ETH1.MID — PS12AMB2.MID Composed by Ryuichi Sato

Demonstration phrases were created using the PLG150-PC.

When listening to the demo songs on an Modular Synthesis Plug-in System compatible instrument, make sure to ﬁrst make these settings:

• Select the appropriate multi-timbral mode on the instrument (on the MOTIF, this would be the Song mode).

• Set the Receive Channel of the [PLG] part (the part to which the PLG150-DR/PLG150-PC has been assigned) to Channel 1.

• Set all other parts to channels other than Channel 1.

When listening to the demo songs on an XG Plug-in System compatible instrument, make sure to ﬁrst make these settings:

• Set the Sound Module Mode of the instrument to “XG mode.”

• Set the Device Number to “1” or “All.”

■ “Drum Solo Demo” (SMF format)

● Demonstration song for PLG150-DR

DSL_DEMO.MID Composed by Junichi Omi

Demonstration song created using the PLG150-DR.

■ “XG Demo” (SMF format)

● Demonstration song for PLG150-PC

PXG_DEMO.MID Composed by Toshiro Imaizumi

Demonstration song for XG Plug-in System devices.

■ “MSPS Demos” (Audio data)

● Demonstration song for PLG150-DR (Track 2)

Composed by Scott Plunkett

● Demonstration song for PLG150-PC (Track 3)

Composed by Geoff Stradling

These songs were created on the MOTIF using PLG150-DR/PLG150-PC. The drum/percussion parts are played with PLG150-DR/PLG150-PC voices and the other parts are played with the MOTIF voices and other instruments.

Demonstration Songs

CAUTION

NOTE

Voice List

Appendix

■ Preset Voice List

● PLG150-DR MSB=79, LSB=0

■ User Voice List

● PLG150-DR MSB=47, LSB=0, Pgm#=1-8 LiveRm A

● PLG150-PC MSB=47, LSB=1, Pgm#=1-8 AfroCubn

* The User voice memory section of the Plug-in board lets you temporarily save the original kits you’ve created. (One Preset voice is already included in the User voices

by default.) However, since this is temporary and the edited data is lost when you turn off the power, you should save your important data to computer (using the Plugin Board Editor) or to Memory Card.

Pgm# Kit Name Reverb Insertion

1 LiveRm A Room3 2BandEQ 2 LiveRm B Room3 2BandEQ 3 PowrdStd Room1 Room1 4 Dr yStand Room1 Room1 5 RockSt1 Room1 Room1 6 RockSt2 Room1 Room1 7 Dr yKit A Hall1 2BandEQ 8 Dr yKit B Hall1 2BandEQ

9 SmlRoom1 Room1 Room1 10 SmlRoom2 Room1 Room1 11 HeavyKit Hall1 2BandEQ 12 RingSnrs Room3 2BandEQ 13 Rocky Room3 2BandEQ 14 Trashed1 Room3 Distortion 15 Trashed2 Hall1 Over Drive 16 Trashed3 Room1 Amp Simulator 17 Weirdo Basement Rotary Speaker 18 DarkBrk Room1 Over Drive 19 BriteBrk Plate Distortion 20 RockBrk Hall1 Amp Simulator 21 DirtyTek Hall1 Over Drive 22 Ethnic Hall1 Phaser1 23 DigiLoﬁ Hall1 Phaser1 *1 24 NoizElec Room1 Amp Simulator 25 BreakAmb Plate Delay L R 26 Electron Room1 Flanger1 27 EthncAmb Room1 Distortion

28 Flanger Room3 Flanger1 29 Phaser1 Room3 Phaser1 30 Phaser2 Room3 Phaser2 31 AM/PM Plate Tremolo 32 AutoPan Hall1 Auto Pan 33 Drone Room1 Karaoke1 34 SnareKit Hall1 Phaser2 35 Cym Amb Hall1 Hall1 36 KitA/Ht1 Room3 2BandEQ 37 KitB/Ht1 Room3 2BandEQ 38 KitA/Ht2 Room3 2BandEQ 39 KitB/Ht2 Room3 2BandEQ 40 Spread1 Room3 2BandEQ 41 Spread2 Room3 2BandEQ 42 Spread3 Room3 2BandEQ 43 Spread4 Room3 2BandEQ 44 Kicks Room1 2BandEQ 45 Snares Hall1 2BandEQ 46 Toms Hall2 2BandEQ 47 Hats Hall2 2BandEQ 48 Cymbals Hall2 2BandEQ 49 A--PlgPC *2 Room3 2BandEQ 50 B--PlgPC *2 Room3 2BandEQ 51 ABAA/Prc Room3 2BandEQ 52 AABA/Prc Room3 2BandEQ 53 AAAB/Prc Room3 2BandEQ 54 ABBA/Prc Room3 2BandEQ

Pgm# Kit Name Reverb Insertion

55 AABB/Prc Room3 2BandEQ 56 ABAB/Prc Room3 2BandEQ 57 ABBB/Prc Room3 2BandEQ 58 BABB/Prc Room3 2BandEQ 59 BBAB/Prc Room3 2BandEQ 60 BBBA/Prc Room3 2BandEQ 61 BAAB/Prc Room3 2BandEQ 62 BBAA/Prc Room3 2BandEQ 63 BABA/Prc Room3 2BandEQ 64 BAAA/Prc Room3 2BandEQ 65 AAAA/Kk Room3 2BandEQ 66 ABAA/Sn1 Room3 2BandEQ 67 AABA/Sn2 Room3 2BandEQ 68 AAAB/Tom Room3 2BandEQ 69 ABBA/Hat Room3 2BandEQ 70 AABB/Cym Room3 2BandEQ 71 ABAB/Sn1 Room3 2BandEQ 72 ABBB/Sn2 Room3 2BandEQ 73 BBBB/Kk Room3 2BandEQ 74 BABB/Sn1 Room3 2BandEQ 75 BBAB/Sn2 Room3 2BandEQ 76 BBBA/Tom Room3 2BandEQ 77 BAAB/Hat Room3 2BandEQ 78 BBAA/Cym Room3 2BandEQ 79 BABA/Sn1 Room3 2BandEQ 80 BAAA/Sn2 Room3 2BandEQ

Pgm# Kit Name Reverb Insertion

● PLG150-PC MSB=79, LSB=1

Pgm# Kit Name Reverb Insertion

1 AfroCubn Room1 2BandEQ

2 Brazil Room1 2BandEQ

3 MotifLtn Room1 2BandEQ

4 GM Perc Room1 2BandEQ

5 AfrCbn61 Room1 2BandEQ

6 Brazil61 Room1 2BandEQ

7 AC-PlgDR *3 Room1 2BandEQ

8 Br-PlgDR *3 Room1 2BandEQ

9 Lt-PlgDR *3 Room1 2BandEQ 10 GMLtnDrm Room1 2BandEQ 11 Live Pop Room1 2BandEQ 12 Kick&Snr Room1 2BandEQ 13 AfCbHand Room1 2BandEQ 14 BrzlHnd1 Room1 2BandEQ 15 BrzlHnd2 Room1 2BandEQ 16 Bells Room1 2BandEQ 17 Shakers Room1 2BandEQ 18 Skins Room1 2BandEQ 19 Sticks 1 Room1 2BandEQ 20 Sticks 2 Room1 2BandEQ 21 DlyAfrCb Hall1 2BandEQ 22 DlyBrazl Hall1 2BandEQ 23 DlyGMPrc Hall1 2BandEQ 24 DlyGMLtn Hall1 2BandEQ 25 NsDAfrCb Room1 Hall1 26 NsDBrazl Room1 Hall1 27 ODAfrCbn Room1 OverDrive

28 ODBrazil Room1 OverDrive 29 ODGMLatn Room1 OverDrive 30 ODKk&Snr Room1 OverDrive 31 Dst1AfCb Room1 Distortion 32 Dst1Brzl Room1 Distortion 33 Dst1GMLt Room1 Distortion 34 Dst1Kk&S Room1 Distor tion 35 Dst2AfCb Room1 Distortion 36 Dst2Brzl Room1 Distortion 37 Dst2GMLt Room1 Distortion 38 Dst2Kk&S Room1 Distor tion 39 FlgAfrCb Room1 Flanger1 40 FlgBrazl Room1 Flanger1 41 FlgShkrs Room1 Flanger1 42 PhsShkrs Room1 Phaser1 43 Rs1Skins Room1 Phaser1 44 Rs1Stick Room1 Phaser1 45 Rs2Kk&Sn Room1 Phaser1 46 Rs2Stick Room1 Phaser1 47 Md1AfrCb Room1 Celeste4 48 Md1Brazl Room1 Celeste4 49 Md2AfrCb Room1 Celeste4 50 Md2Brazl Room1 Celeste4 51 Md3Bells Room1 Celeste4 52 Md3Shkrs Room1 Celeste4 53 Md4BrHd1 Room1 Celeste1 54 Md4BrHd2 Room1 Celeste1

Pgm# Kit Name Reverb Insertion

55 Md5BrHd1 Room1 Symphonic 56 Md5BrHd2 Room1 Symphonic 57 PchBells Hall1 Flanger1 58 PchShkrs Hall1 AmpSimulator 59 PchSkins Room1 Phaser1 60 PchStick Room1 Hall1 61 RevAfrCb Hall1 2BandEQ 62 RevBrazl Hall1 2BandEQ 63 RevMotif Hall1 2BandEQ 64 RevGMPrc Hall1 2BandEQ 65 RevAfC61 Hall1 2BandEQ 66 RevBrz61 Hall1 2BandEQ 67 RvACPgDR *3 Hall1 2BandEQ 68 RvBrPgDR *3 Hall1 2BandEQ 69 RvLtPgDR *3 Hall1 2BandEQ 70 RevGMLtn Hall1 2BandEQ 71 RevLvPop Hall1 2BandEQ 72 RevKk&Sn Hall1 2BandEQ 73 RevACHnd Hall1 2BandEQ 74 RevBrHd1 Hall1 2BandEQ 75 RevBrHd2 Hall1 2BandEQ 76 RevBells Hall1 2BandEQ 77 RevShkrs Hall1 2BandEQ 78 RevSkins Hall1 2BandEQ 79 RevStck1 Hall1 2BandEQ 80 RevStck2 Hall1 2BandEQ

Pgm# Kit Name Reverb Insertion

*1 These sounds are unaffected by the LFO Frequency and LFO Depth parameters. *2 Drum voices in these kits are mapped to keys B2 and lower. *3 Percussion voices in these kits are mapped to keys C3 and higher. If you have both the PLG150-DR and the PLG150-PC installed, you can combine the relevant kits indicated by notes *2 and *3.

Voice List

■ DR Instrument Map

MSB=79, LSB=0

A : Alternate Group K : Key Off I : Insertion Effect : No sound

Program No.

123456

Kit Name LiveRm A LiveRm B PowrdStd DryStand RockSt1 RockSt2

Note#

Note Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I

13 C# -1 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 on Surdo Mute 3 on Surdo Mute 3 on Surdo Mute 3 on 14 D -1 Surdo Open 3 Surdo Open 3 Surdo Open 3 on Surdo Open 3 on Surdo Open 3 on Surdo Open 3 on 15 D# -1 Hi Q Hi Q Hi Q on Hi Q on Hi Q on Hi Q on 16 E -1 Whip Slap Whip Slap Whip Slap on Whip Slap on Whip Slap on Whip Slap on 17 F -1 Scratch H 4 Scratch H 4 Scratch H 4 on Scratch H 4 on Scratch H 4 on Scratch H 4 on 18 F# -1 Scratch L 4 Scratch L 4 Scratch L 4 on Scratch L 4 on Scratch L 4 on Scratch L 4 on 19 G -1 Finger Snap Finger Snap Finger Snap on Finger Snap on Finger Snap on Finger Snap on 20 G# -1 Click Noise Click Noise Click Noise on Click Noise on Click Noise on Click Noise on 21 A -1 Metronome Click Metronome Click Metronome Click on Metronome Click on Metronome Click on Metronome Click on 22 A# -1 Metronome Bell Metronome Bell Metronome Bell on Metronome Bell on Metronome Bell on Metronome Bell on 23 B -1 Seq Click L Seq Click L Seq Click L on Seq Click L on Seq Click L on Seq Click L on 24 C 0 Seq Click H Seq Click H Seq Click H on Seq Click H on Seq Click H on Seq Click H on 25 C# 0 Br ush Tap Brush Tap Brush Tap Brush Tap Brush Tap Brush Tap 26 D 0 Brush Swirl on Brush Swirl on Brush Swirl on Brush Swirl on Brush Swirl on Brush Swirl on 27 D# 0 Br ush Slap Brush Slap Br ush Slap Brush Slap Brush Slap Brush Slap 28 E 0 Brush Tap Swirl on Brush Tap Swirl on Br ush Tap Swirl on Brush Tap Swirl on Brush Tap Swirl on Brush Tap Swirl on 29 F 0 Snare Roll Rock on Snare Roll Hard on Snare Roll on Snare Roll on Snare Roll Hard on Snare Roll Hard on 30 F# 0

Hat 1/4-1/2 Brilliant Sw

1 Hat 1/4-1/2 Heavy Sw 1 Castanet on Castanet on Castanet on Castanet on

31 G 0

Snare Brass Piccolo Soft

Snare Loose Snap Soft

Snare Dry Lo Soft Snare Dry Lo Soft

Snare Rock Open1 Dry

Snare Rock Open2 Dry

32 G# 0 Sticks Sticks Sticks on Sticks on Sticks on Sticks on 33 A 0

Kick 18x22" Maple Dry Sw Kick 14x22" Maple Dry Sw

Kick Funk

Kick Funk Hard Sw

Kick Dry Heavy Sw

Kick Power Dry Lo

34 A# 0

Snare Brass Attack Rim

Snare Brass Rock Rim

Snare Dry Hi Sw

Snare Dry Hi mf-ff Sw

Snare Rock Rim1 Snare Rock Rim2

35 B 0

Kick 16x20" Maple Room Sw Kick 14x18" Birch Room Sw

Kick Power Dry Lo

Kick Dry Hi Kick Dry Hi Heavy Kick Dry ff

36 C 1

Kick 18x22" Maple Room Sw Kick 14x22" Maple Room Sw

Kick Power Dry Hi Kick Dry Sw Kick Rock1 Kick Rock2

37 C# 1

Sidestick Wood Knock Sw Sidestick Metal Knock Sw

Sidestick Dry Sidestick Dry Sidestick Rock1 Sidestick Rock2

38 D 1

Snare Brass Piccolo Sw

Snare Loose Snap Sw

Snare Power Dry Lo Sw

Snare Dry Lo Sw Snare Rock Open1

Snare Rock Open2

39 D# 1 Hand Clap Hand Clap Hand Clap on Hand Clap on Hand Clap Hand Clap 40 E 1

Snare Brass Attack Sw

on Snare Brass Rock Sw

Snare Power Dry Hi Sw Snare Dry Hi mp-mf Sw

Snare Rock Mute1

Snare Rock Mute2

41 F 1 Tom Power Lo Floor Tom Smooth Lo Floor Tom Dry Lo Floor Tom Dry Lo Floor Tom Rock Lo Floor

Tom Rock Lo Floor

42 F# 1

Hat Closed Brilliant Sw

1 Hat Closed Heavy Sw 1 Hat Closed Power 1

Hat Closed Dry Sw

Hat Closed Rock1 Sw

Hat Closed Rock2

43 G 1 Tom Power Hi Floor Tom Smooth Hi Floor Tom Dry Hi Floor Tom Dry Hi Floor Tom Rock Hi Floor

Tom Rock Hi Floor

44 G# 1 Hat Pedal Brilliant 1 Hat Pedal Heavy 1 Hat 1/2 Power 1 Hat Pedal Dry 1

Hat Closed-Pedal Rock1 Sw

1 Hat 1/2 Rock2 1

45 A 1 Tom Power Lo Tom Smooth Lo Tom Dry Lo Tom Dry Lo Tom Rock Lo Tom Rock Lo 46 A# 1 Hat Open Brilliant 1 Hat Open Heavy 1 Hat Open Power 1 Hat Open Dry 1 Hat Open Rock1 Sw 1 Hat Open Rock2 1 47 B 1 Tom Power Lo-Mid Tom Smooth Lo-Mid Tom Dry Lo-Mid Tom Dry Lo-Mid Tom Rock Lo-Mid Tom Rock Lo-Mid 48 C 2 Tom Power Hi-Mid Tom Smooth Hi-Mid Tom Dry Hi-Mid Tom Dry Hi-Mid Tom Rock Hi-Mid Tom Rock Hi-Mid 49 C# 2

Crash Cymbal 17" Thin Crash Cymbal 17" Thin

Crash Cymbal Crash Cymbal Crash Cymbal Rock1

Crash Cymbal Rock1

50 D 2 Tom Power Hi Tom Smooth Hi Tom Dry Hi Tom Dry Hi Tom Rock Hi Tom Rock Hi 51 D# 2 Ride Cymbal 21" Sw Ride Cymbal 22" Ride Cymbal Ride Cymbal Ride Cymbal Rock1

Ride Cymbal Rock1

52 E 2 China Cymbal 17" China Cymbal 17" China Cymbal China Cymbal China Cymbal Rock

China Cymbal Rock

53 F 2 Ride Cymbal Cup 21" Ride Cymbal Cup 22" Ride Cymbal Cup Ride Cymbal Cup

Ride Cymbal Cup Rock

54 F# 2 Tambourine Tambourine Tambourine on Tambourine on Tambourine Tambourine 55 G 2 Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal Splash Cymbal Splash Cymbal Rock

Splash Cymbal Rock

56 G# 2 Cowbell Cowbell Cowbell on Cowbell on Cowbell Cowbell 57 A 2 Crash Cymbal 14" Crash Cymbal 14"

Crash Cymbal R/L Crash Cymbal R/L

Crash Cymbal Rock2

58 A# 2 Vibraslap Vibraslap Vibraslap Vibraslap Vibraslap Vibraslap 59 B 2 Ride Cymbal 22" R/L Ride Cymbal 21" R/L Ride Cymbal R/L Ride Cymbal R/L Ride Cymbal Rock2

Ride Cymbal Rock2 Lo

60 C 3 Bongo H Bongo H Bongo H on Bongo H on Bongo H on Bongo H on 61 C# 3 Bongo L Bongo L Bongo L on Bongo L on Bongo L on Bongo L on 62 D 3 Conga H Mute Conga H Mute Conga H Mute on Conga H Mute on Conga H Mute on Conga H Mute on 63 D# 3 Conga H Open Conga H Open Conga H Open on Conga H Open on Conga H Open on Conga H Open on 64 E 3 Conga L Conga L Conga L on Conga L on Conga L on Conga L on 65 F 3 Timbale H Timbale H Timbale H on Timbale H on Timbale H on Timbale H on 66 F

# 3 Timbale L Timbale L Timbale L on Timbale L on Timbale L on Timbale L on

67 G 3 Agogo H Agogo H Agogo H on Agogo H on Agogo H on Agogo H on 68 G

# 3 Agogo L Agogo L Agogo L on Agogo L on Agogo L on Agogo L on

69 A 3 Cabasa Cabasa Cabasa on Cabasa on Cabasa on Cabasa on 70 A

# 3 Maracas Maracas Maracas on Maracas on Maracas on Maracas on

71 B 3 Samba Whistle H on Samba Whistle H on Samba Whistle H on on Samba Whistle H on on Samba Whistle H on on Samba Whistle H on on 72 C 4 Samba Whistle L on Samba Whistle L on Samba Whistle L on on Samba Whistle L on on Samba Whistle L on on Samba Whistle L on on 73 C

# 4 Guiro Short Guiro Short Guiro Short on Guiro Short on Guiro Short on Guiro Short on

74 D 4 Guiro Long on Guiro Long on Guiro Long on on Guiro Long on on Guiro Long on on Guiro Long on on 75 D

# 4 Claves Claves Claves on Claves on Claves on Claves on

76 E 4 Wood Block H Wood Block H Wood Block H on Wood Block H on Wood Block H on Wood Block H on 77 F 4 Wood Block L Wood Block L Wood Block L on Wood Block L on Wood Block L on Wood Block L on 78 F

# 4 Cuica Mute Cuica Mute Cuica Mute on Cuica Mute on Cuica Mute on Cuica Mute on

79 G 4 Cuica Open Cuica Open Cuica Open on Cuica Open on Cuica Open on Cuica Open on 80 G

# 4 Triangle Mute 2 Triangle Mute 2 Triangle Mute 2 on Triangle Mute 2 on Triangle Mute 2 on Triangle Mute 2 on

81 A 4 Triangle Open 2 Triangle Open 2 Triangle Open 2 on Triangle Open 2 on Triangle Open 2 on Triangle Open 2 on 82 A# 4 Shaker Shaker Shaker on Shaker on Shaker on Shaker on 83 B 4 Jingle Bells Jingle Bells Jingle Bells on Jingle Bells on Jingle Bells on Jingle Bells on 84 C 5 Bell Tree Bell Tree Bell Tree on Bell Tree on Bell Tree on Bell Tree on 85 C

# 5

86 D 5 87 D# 5 88 E 5 89 F 5 90 F# 5 91 G 5 92 G# 5 93 A 5 94 A# 5 95 B 5 96 C 6 97 C# 6 98 D 6 99 D# 6

100 E 6 101 F 6

Voice List

DR Instrument Map MSB=79, LSB=0

A : Alternate Group K : Key Off I : Insertion Effect : No sound

Program No.

789101112

Kit Name DryKit A DryKit B SmlRoom1 SmlRoom2 HeavyKit RingSnrs

Note#

Note Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I

13 C# -1 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 on Surdo Mute 3 on Surdo Mute 3 Surdo Mute 3 14 D -1 Surdo Open 3 Surdo Open 3 Surdo Open 3 on Surdo Open 3 on Surdo Open 3 Surdo Open 3 15 D# -1 Hi Q Hi Q Hi Q on Hi Q on Hi Q Hi Q 16 E -1 Whip Slap Whip Slap Whip Slap on Whip Slap on Whip Slap Whip Slap 17 F -1 Scratch H 4 Scratch H 4 Scratch H 4 on Scratch H 4 on Scratch H 4 Scratch H 4 18 F# -1 Scratch L 4 Scratch L 4 Scratch L 4 on Scratch L 4 on Scratch L 4 Scratch L 4 19 G -1 Finger Snap Finger Snap Finger Snap on Finger Snap on Finger Snap Finger Snap 20 G# -1 Click Noise Click Noise Click Noise on Click Noise on Click Noise Click Noise 21 A -1 Metronome Click Metronome Click Metronome Click on Metronome Click on Metronome Click Metronome Click 22 A# -1 Metronome Bell Metronome Bell Metronome Bell on Metronome Bell on Metronome Bell Metronome Bell 23 B -1 Seq Click L Seq Click L Seq Click L on Seq Click L on Seq Click L Seq Click L 24 C 0 Seq Click H Seq Click H Seq Click H on Seq Click H on Seq Click H Seq Click H 25 C# 0 Br ush Tap Brush Tap Brush Tap Brush Tap Brush Tap Brush Tap 26 D 0 Brush Swirl on Brush Swirl on Br ush Swirl on Br ush Swirl on Br ush Swirl on Brush Swirl on 27 D# 0 Br ush Slap Brush Slap Brush Slap Brush Slap Br ush Slap Brush Slap 28 E 0 Brush Tap Swirl on Br ush Tap Swirl on Brush Tap Swirl on Brush Tap Swirl on Brush Tap Swirl on Brush Tap Swirl on 29 F 0 Snare Roll Rock on Snare Roll Hard on Snare Roll Rock on Snare Roll Rock on Snare Roll Rock on Snare Roll Hard on 30 F# 0 Castanet Castanet Castanet on Castanet on Castanet Hat 1/4-1/2 Heavy Sw 1 31 G 0

Snare Brass Piccolo Soft

Snare Loose Snap Soft

Snare Brass Piccl Dry Sw

Snare Brass Attack Dry Sw

Snare Brass Piccolo Soft

Snare Loose Snap Soft

32 G# 0 Sticks Sticks Sticks on Sticks on Sticks Sticks 33 A 0

Kick 18x22" Maple Dry Sw Kick 14x22" Maple Dry Sw Kick 18x22" Maple Dry Sw

Kick Dry Hi

Kick 14x22" Dry Comp Sw

Kick 14x22" Maple Dry Sw

34 A# 0

Snare Brass Attck Rim Dry Snare Brass Rock Rim Dry

Snare Dry Hi Sw

Snare Brs Atk Dry p-mf Sw

Snare Snap Rim

Snare Brass Rock Rim

35 B 0

Kick16x20" Maple Dry Sw

Kick 14x18" Birch Dry Sw

Kick Dry ff Kick Dry ff Kick Long Sw

Kick 14x18" Birch Room Sw

36 C 1

Kick18x22" Maple Dry Sw Kick 14x22" Maple Dry Sw Kick 14x22" Maple Dry Sw

Kick Power Dry Hi Kick Punch Sw

Kick 14x22" Maple Room Sw

37 C# 1

Sidestick Wood Dry Sw

Sidestick Metal Dry Sw

Sidestick Wood Dry Sw Sidestick Metal Dry Sw

Sidestick Wood Knock Sw

Sidestick Metal Knock Sw

38 D 1

Snare Brass Piccl Dry Sw

Snare Loose Snap Dry Sw

Snare Power Dry Hi Sw Snare Power Dry Lo Sw

Snare Hi Sw on

Snare Loose Snap Sw

39 D# 1 Hand Clap Hand Clap Hand Clap Hand Clap Hand Clap Hand Clap 40 E 1

Snare Brass Attack Dry Sw

Snare Brass Rock Dry Sw Snare Brass Attack Dry Sw

Snare Dry Hi Sw

Snare Wide Snap Sw

Snare Brass Rock Sw

41 F 1

Tom Power Lo Floor Dry

Tom Smooth Lo Floor Dry

Tom Dry Lo Floor Tom Dry Lo Floor Tom Stick Lo Tom Smooth Lo Floor

42 F# 1

Hat Closed Brllant Dry Sw

Hat Closed Heavy Dry Sw

1 Hat Closed Dry Sw 1

Hat Closed Heavy Lo Sw

1 Hat Closed Heavy Sw 1

43 G 1

Tom Power Hi Floor Dry

Tom Smooth Hi Floor Dry

Tom Dry Hi Floor Tom Dry Hi Floor

Hat 1/4-1/2 Heavy Lo Sw

1 Tom Smooth Hi Floor

44 G# 1

Hat Pedal Brilliant Dry

Hat Pedal Heavy Dry

1 Hat Pedal Dry 1 Hat Pedal Heavy Lo 1 Hat Pedal Heavy 1

45 A 1 Tom Power Lo Dry Tom Smooth Lo Dry Tom Dry Lo Tom Dry Lo Tom Stick Lo-Mid Tom Smooth Lo 46 A# 1 Hat Open Brilliant 1 Hat Open Heavy 1 Hat Open Heavy 1 Hat Open Dry 1 Hat Open Heavy Lo 1 Hat Open Heavy 1 47 B 1

Tom Power Lo-Mid Dry

Tom Smooth Lo-Mid Dry

Tom Dry Lo-Mid Tom Dry Lo-Mid Tom Stick Mid Tom Smooth Lo-Mid

48 C 2

Tom Power Hi-Mid Dry

Tom Smooth Hi-Mid Dry

Tom Dry Hi-Mid Tom Dry Hi-Mid Tom Stick Hi Mid Tom Smooth Hi-Mid

49 C# 2

Crash Cymbal 17" Thin Crash Cymbal 17" Thin

Crash Cymbal Crash Cymbal

Crash Cymbal 17" Thin Lo

Crash Cymbal 17" Thin

50 D 2 Tom Power Hi Dry Tom Smooth Hi Dry Tom Dry Hi Tom Dry Hi Tom Stick Hi Tom Smooth Hi 51 D# 2 Ride Cymbal 21" Sw Ride Cymbal 22" Ride Cymbal 21" Sw Ride Cymbal 21" Sw

Ride Cymbal 21" Lo Sw

Ride Cymbal 22"

52 E 2 China Cymbal 17" China Cymbal 17" China Cymbal China Cymbal

China Cymbal 17" Hi

China Cymbal 17"

53 F 2

Ride Cymbal Cup 21" Ride Cymbal Cup 22" Ride Cymbal Cup 21" Ride Cymbal Cup 21" Ride Cymbal Cup 21"

Ride Cymbal Cup 22"

54 F# 2 Tambourine Tambourine Tambourine on Tambourine on Tambourine Tambourine 55 G 2 Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10"

Splash Cymbal 10" Hi

Splash Cymbal 10"

56 G# 2 Cowbell Cowbell Cowbell on Cowbell on Cowbell Cowbell 57 A 2 Crash Cymbal 14" Crash Cymbal 14"

Crash Cym 17" Thin R/L Lo Crash Cym 17" Thin R/L Lo

Crash Cymbal 14" Lo

Crash Cymbal 14"

58 A# 2 Vibraslap Vibraslap Vibraslap Vibraslap Vibraslap Vibraslap 59 B 2

Ride Cymbal 22" R/L Ride Cymbal 21" R/L

Ride Cymbal R/L Ride Cymbal R/L

Ride Cymbal 22" R/L Hi

Ride Cymbal 21" R/L

60 C 3 Bongo H Bongo H Bongo H on Bongo H on Bongo H Bongo H 61 C# 3 Bongo L Bongo L Bongo L on Bongo L on Bongo L Bongo L 62 D 3 Conga H Mute Conga H Mute Conga H Mute on Conga H Mute on Conga H Mute Conga H Mute 63 D# 3 Conga H Open Conga H Open Conga H Open on Conga H Open on Conga H Open Conga H Open 64 E 3 Conga L Conga L Conga L on Conga L on Conga L Conga L 65 F 3 Timbale H Timbale H Timbale H on Timbale H on Timbale H Timbale H 66 F

# 3 Timbale L Timbale L Timbale L on Timbale L on Timbale L Timbale L

67 G 3 Agogo H Agogo H Agogo H on Agogo H on Agogo H Agogo H 68 G

# 3 Agogo L Agogo L Agogo L on Agogo L on Agogo L Agogo L

69 A 3 Cabasa Cabasa Cabasa on Cabasa on Cabasa Cabasa 70 A

# 3 Maracas Maracas Maracas on Maracas on Maracas Maracas

71 B 3 Samba Whistle H on Samba Whistle H on Samba Whistle H on on Samba Whistle H on on Samba Whistle H on Samba Whistle H on 72 C 4 Samba Whistle L on Samba Whistle L on Samba Whistle L on on Samba Whistle L on on Samba Whistle L on Samba Whistle L on 73 C

# 4 Guiro Short Guiro Short Guiro Shor t on Guiro Short on Guiro Short Guiro Shor t

74 D 4 Guiro Long on Guiro Long on Guiro Long on on Guiro Long on on Guiro Long on Guiro Long on 75 D

# 4 Claves Claves Claves on Claves on Claves Claves

76 E 4 Wood Block H Wood Block H Wood Block H on Wood Block H on Wood Block H Wood Block H 77 F 4 Wood Block L Wood Block L Wood Block L on Wood Block L on Wood Block L Wood Block L 78 F

# 4 Cuica Mute Cuica Mute Cuica Mute on Cuica Mute on Cuica Mute Cuica Mute

79 G 4 Cuica Open Cuica Open Cuica Open on Cuica Open on Cuica Open Cuica Open 80 G

# 4 Triangle Mute 2 Triangle Mute 2 Triangle Mute 2 on Triangle Mute 2 on Triangle Mute 2 Triangle Mute 2

81 A 4 Triangle Open 2 Triangle Open 2 Triangle Open 2 on Triangle Open 2 on Triangle Open 2 Triangle Open 2 82 A# 4 Shaker Shaker Shaker on Shaker on Shaker Shaker 83 B 4 Jingle Bells Jingle Bells Jingle Bells on Jingle Bells on Jingle Bells Jingle Bells 84 C 5 Bell Tree Bell Tree Bell Tree on Bell Tree on Bell Tree Bell Tree 85 C

# 5

86 D 5 87 D# 5 88 E 5 89 F 5 90 F# 5 91 G 5 92 G# 5 93 A 5 94 A# 5 95 B 5 96 C 6 97 C# 6 98 D 6 99 D# 6

100 E 6 101 F 6

Voice List

A : Alternate Group K : Key Off I : Insertion Effect : No sound

13 14 15 16 17 18

Rocky Trashed1 Trashed2 Trashed3 Weirdo DarkBrk

Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I

Surdo Mute 3 Surdo Mute Dst 3 on Surdo Mute OD 3 on Surdo Mute Amp 3 on Surdo Mute SFX 3 Surdo Mute DBk 3 on Surdo Open 3 Surdo Open Dst 3 on Surdo Open OD 3 on Surdo Open Amp 3 on Surdo Open SFX 3 Surdo Open DBk 3 on Hi Q Hi Q Dst on Hi Q OD on Hi Q Amp on Hi Q SFX Hi Q DBk Whip Slap Whip Slap Dst on Whip Slap OD on Whip Slap Amp on Whip Slap SFX Whip Slap DBk Scratch H 4 Scratch H Dst 4 on Scratch H OD 4 on Scratch H Amp 4 on Scratch H SFX 4 Scratch H DBk 4 Scratch L 4 Scratch L Dst 4 on Scratch L OD 4 on Scratch L Amp 4 on Scratch L SFX 4 Scratch L DBk 4 Finger Snap Finger Snap Dst on Finger Snap OD on Finger Snap Amp on Finger Snap SFX Finger Snap DBk on Click Noise Click Noise Dst on Click Noise OD on Click Noise Amp on Click Noise SFX Click Noise DBk Metronome Click

Metronome Click Dst

on Metronome Click OD on Metronome Click Amp on Metronome Click SFX

Metronome Click DBk Metronome Bell Metronome Bell Dst on Metronome Bell OD on Metronome Bell Amp on Metronome Bell SFX Metronome Bell DBk Seq Click L Seq Click L Dst on Seq Click L OD on Seq Click L Amp on Seq Click L SFX Seq Click L DBk on Seq Click H Seq Click H Dst on Seq Click H OD on Seq Click H Amp on Seq Click H SFX Seq Click H DBk on Brush Tap Brush Tap Dst on Brush Tap OD on Brush Tap Amp on Brush Tap SFX Brush Tap DBk on Brush Swirl on Brush Swirl Dst on on Brush Swirl OD on on Brush Swirl Amp on on Br ush Swirl SFX on Brush Swirl DBk on on Brush Slap Brush Slap Dst on Brush Slap OD on Brush Slap Amp on Brush Slap SFX Brush Slap DBk on Brush Tap Swirl on Brush Tap Swirl Dst on on Brush Tap Swirl OD on on Brush Tap Swirl Amp on on Brush Tap Swirl SFX on Brush Tap Swirl DBk on on Snare Roll Rock on Snare Roll Hard Dst on on Snare Roll Rock OD on on Snare Roll Rock Amp on on Snare Roll Rock SFX on Snare Roll DBk on on Castanet

Hat 1/4-1/2 Heavy Dst Sw

1 on Castanet OD on Castanet Amp on Castanet SFX Castanet DBk on

Snare Brass Attack Sw

Snare Loose Snap Soft DstonSnare Brass Piccl Soft OD

Snare Brs Picl Dry Amp Sw

Snare Brs Attk Dry SFX Sw

Snare Dry Lo Soft DBk

on Sticks Sticks Dst on Sticks OD on Sticks Amp on Sticks SFX Sticks DBk on Kick18x22" Maple Room Sw

Kick 14x22" Dry Dst Sw

Kick 14x22" Dry Cmp OD Sw

Kick 18x22" Dry Amp Sw

on Kick Dry Hi SFX

Kick Power Dry Lo DBk

Snare Rock Rim2

Snare Brass Rock Rim Dst

on Snare Snap Rim OD on Snare Dr y Hi Amp Sw on

Snare BrAtDry p-mf SFX Sw

Snare Rock Open1 DBk

on Kick Rock2

Kick 14x18" Room Dst Sw

on Kick Long OD Sw on Kick Dry ff Amp on Kick Dry ff SFX

Kick Dry Heavy DBk Sw

on Kick Rock1

Kick 14x22" Room Dst Sw

on Kick Punch OD Sw on

Kick 14x22" Dry Amp Sw

Kick Power Dry Hi SFX

Kick Dry DBk Sw on

Sidestick Rock1

Sidestick Metal Dst Sw

Sidestick Wood OD Sw

Sidestick Wood Dry Amp Sw

Sidestick Mtl Dry SFX Sw

Sidestick Rock2 DBk on

Snare Rock Mute2

Snare Loose Snap Dst Sw

on Snare Hi OD Sw on

Snare Power Dry Hi Amp Sw

Snare Power Dry Lo SFX Sw

Snare Dry Lo DBk Sw

on Hand Clap Hand Clap Dst on Hand Clap OD on Hand Clap Amp on Hand Clap SFX Hand Clap DBk on Snare Brass Rock Sw

Snare Brass Rock Dst Sw

Snare Wide Snap OD Sw

Snare Brs Attk Dry Amp Sw

on Snare Dry Hi SFX Sw

Snare Rock Rim2 DBk

on Tom Power Lo Floor

Tom Smooth Lo Floor Dst

on Tom Stick OD Lo on

Tom Dry Lo Floor Amp

Tom Dry Lo Floor SFX Tom Dry Lo Floor DBk

on Hat Closed Rock2 1

Hat Closed Heavy Dst Sw

1on

Hat Closed Heavy Lo OD Sw

1on

Hat Closed Hvy Dry Amp Sw

1on

Hat Closed Dry SFX Sw

Hat Closed Dry DBk Sw

1on

Tom Power Hi Floor

Tom Smooth Hi Floor Dst

Hat 1/4-1/2 HeavyLo OD Sw

1 on Tom Dry Hi Floor Amp on Tom Dry Hi Floor SFX

Tom Dry Hi Floor DBk

on Hat Closed-Pedal Rock1 Sw

Hat Pedal Heavy Dst

1on

Hat Pedal Heavy Lo OD

1on

Hat Pedal Heavy Dry Amp

1 on Hat Pedal Dry SFX 1 Hat Pedal Dry DBk 1 on Tom Power Lo Tom Smooth Lo Dst on Tom Stick Lo-Mid OD on Tom Dry Lo Amp on Tom Dry Lo SFX Tom Dry Lo DBk on Hat Open Rock2 1 Hat Open Heavy Dst 1 on

Hat Open Heavy Lo OD

1 on Hat Open Heavy Amp 1 on Hat Open Dry SFX 1 Hat Open Dry DBk 1 on

Tom Power Lo-Mid

Tom Smooth Lo-Mid Dst

on Tom Stick Mid OD on Tom Dry Lo-Mid Amp on Tom Dry Lo-Mid SFX Tom Dry Lo-Mid DBk on

Tom Power Hi-Mid

Tom Smooth Hi-Mid Dst

on Tom Stick Hi Mid OD on Tom Dry Hi-Mid Amp on Tom Dry Hi-Mid SFX Tom Dry Hi-Mid DBk on

Crash Cymbal 17" Thin Lo

Crash Cymbal 17" Thin Dst

Crash Cym 17" Thin Lo OD

on Crash Cymbal Amp on Crash Cymbal SFX on

Crash Cymbal 17" Thin DBk

on Tom Power Hi Tom Smooth Hi Dst on Tom Stick Hi OD on Tom Dry Hi Amp on Tom Dry Hi SFX Tom Dry Hi DBk on Ride Cymbal 21" Lo Sw Ride Cymbal 22" Dst

Ride Cymbal 21" Lo OD SwonRide Cymbal 21" Amp Sw

Ride Cymbal 21" Sw SFX

Ride Cymbal 22" DBk

on China Cymbal 17" Hi

China Cymbal 17" Dst

China Cymbal 17" Hi OD

on China Cymbal Amp on China Cymbal SFX

China Cymbal 17" DBk

on Ride Cymbal Cup 21"

Ride Cymbal Cup 22" Dst

Ride Cymbal Cup 21" OD

Ride Cymbal Cup 21" Amp

Ride Cymbal Cup 21" SFX

Ride Cymbal Cup 22" DBk

on Tambourine Tambourine Dst on Tambourine OD on Tambourine Amp on Tambourine SFX on Tambourine DBk on Splash Cymbal 10"

Splash Cymbal 10" Dst

Splash Cymbal 10" Hi OD

Splash Cymbal 10" Amp

Splash Cymbal 10" SFX

Splash Cymbal 10" DBk

on Cowbell Cowbell Dst on Cowbell OD on Cowbell Amp on Cowbell SFX Cowbell DBk on Crash Cymbal R/L

Crash Cymbal 14" Dst

Crash Cymbal 14" Lo OD

Crash 17" Thin R/L Lo Amp

Crash 17" Thin R/L Lo SFX

Crash Cymbal 14" DBk

on Vibraslap Vibraslap Dst on Vibraslap OD on Vibraslap Amp on Vibraslap SFX Vibraslap DBk on Ride Cymbal 22" R/L Hi

Ride Cymbal 21" R/L Dst

Ride Cymbal 22" R/L Hi ODonRide Cymbal R/L Amp

on Ride Cymbal R/L SFX on

Ride Cymbal 22" DBk

on Bongo H Bongo H Dst on Bongo H OD on Bongo H Amp on Bongo H SFX Bongo H DBk Bongo L Bongo L Dst on Bongo L OD on Bongo L Amp on Bongo L SFX Bongo L DBk Conga H Mute Conga H Mute Dst on Conga H Mute OD on Conga H Mute Amp on Conga H Mute SFX Conga H Mute DBk Conga H Open Conga H Open Dst on Conga H Open OD on Conga H Open Amp on Conga H Open SFX Conga H Open DBk Conga L Conga L Dst on Conga L OD on Conga L Amp on Conga L SFX Conga L DBk Timbale H Timbale H Dst on Timbale H OD on Timbale H Amp on Timbale H SFX Timbale H DBk Timbale L Timbale L Dst on Timbale L OD on Timbale L Amp on Timbale L SFX Timbale L DBk Agogo H Agogo H Dst on Agogo H OD on Agogo H Amp on Agogo H SFX Agogo H DBk Agogo L Agogo L Dst on Agogo L OD on Agogo L Amp on Agogo L SFX Agogo L DBk Cabasa Cabasa Dst on Cabasa OD on Cabasa Amp on Cabasa SFX Cabasa DBk Maracas Maracas Dst on Maracas OD on Maracas Amp on Maracas SFX Maracas DBk Samba Whistle H on

Samba Whistle H Dst

on on Samba Whistle H OD on on

Samba Whistle H Amp

on on

Samba Whistle H SFX

on on

Samba Whistle H DBk

Samba Whistle L on

Samba Whistle L Dst

on on Samba Whistle L OD on on Samba Whistle L Amp on on Samba Whistle L SFX on on

Samba Whistle L DBk

on Guiro Short Guiro Short Dst on Guiro Shor t OD on Guiro Short Amp on Guiro Short SFX Guiro Short DBk Guiro Long on Guiro Long Dst on on Guiro Long on on Guiro Long Amp on on Guiro Long SFX on Guiro Long DBk on Claves Claves Dst on Claves OD on Claves Amp on Claves SFX Claves DBk on Wood Block H Wood Block H Dst on Wood Block H OD on Wood Block H Amp on Wood Block H SFX Wood Block H DBk Wood Block L Wood Block L Dst on Wood Block L OD on Wood Block L Amp on Wood Block L SFX Wood Block L DBk Cuica Mute Cuica Mute Dst on Cuica Mute OD on Cuica Mute Amp on Cuica Mute SFX Cuica Mute DBk Cuica Open Cuica Open Dst on Cuica Open OD on Cuica Open Amp on Cuica Open SFX Cuica Open DBk Triangle Mute 2 Triangle Mute Dst 2 on Triangle Mute OD 2 on Triangle Mute Amp 2 on Triangle Mute SFX 2 Triangle Mute DBk 2 on Triangle Open 2 Triangle Open Dst 2 on Triangle Open OD 2 on Triangle Open Amp 2 on Triangle Open SFX 2 on Triangle Open DBk 2 on Shaker Shaker Dst on Shaker OD on Shaker Amp on Shaker SFX Shaker DBk Jingle Bells Jingle Bells Dst on Jingle Bells OD on Jingle Bells Amp on Jingle Bells SFX Jingle Bells DBk on Bell Tree Bell Tree Dst on Bell Tree OD on Bell Tree Amp on Bell Tree SFX Bell Tree DBk on

Voice List

DR Instrument Map MSB=79, LSB=0

A : Alternate Group K : Key Off I : Insertion Effect : No sound

Program No.

19 20 21 22 23 24

Kit Name BriteBrk RockBrk DirtyTek Ethnic DigiLoﬁ NoizElec

Note#

Note Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I

13 C# -1 Surdo Mute BBk 3 Surdo Mute RBk 3 on Surdo Mute DTk 3 Surdo Mute Ethn 3 on Surdo Mute LoFi 3 on Surdo Mute Nz 3 14 D -1 Surdo Open BBk 3 Surdo Open RBk 3 on Surdo Open DTk 3 Surdo Open Ethn 3 on Surdo Open LoFi 3 on Surdo Open Nz 3 15 D# -1 Hi Q BBk Hi Q RBk on Hi Q DTk Hi Q Ethn Hi Q LoFi Hi Q Nz 16 E -1 Whip Slap BBk Whip Slap RBk on Whip Slap DTk on Whip Slap Ethn Whip Slap LoFi Whip Slap Nz on 17 F -1 Scratch H BBk 4 Scratch H RBk 4 on Scratch H DTk 4 on Scratch H Ethn 4 Scratch H LoFi 4 Scratch H Nz 4 18 F# -1 Scratch L BBk 4 Scratch L RBk 4 on Scratch L DTk 4 on Scratch L Ethn 4 Scratch L LoFi 4 Scratch L Nz 4 19 G -1 Finger Snap BBk Finger Snap RBk on Finger Snap DTk Finger Snap Ethn Finger Snap LoFi Finger Snap Nz 20 G# -1 Click Noise BBk Click Noise RBk Click Noise DTk Click Noise Ethn Click Noise LoFi Click Noise Nz 21 A -1 Metronome Click BBk

Metronome Click RBk

Metronome Click DTk

Metronome Click Ethn

Metronome Click LoFi Metronome Click Nz

22 A# -1 Metronome Bell BBk Metronome Bell RBk on Metronome Bell DTk on Metronome Bell Ethn Metronome Bell LoFi Metronome Bell Nz 23 B -1 Seq Click L BBk Seq Click L RBk Seq Click L DTk Seq Click L Ethn on Seq Click L LoFi Seq Click L Nz on 24 C 0 Seq Click H BBk Seq Click H RBk Seq Click H DTk Seq Click H Ethn on Seq Click H LoFi Seq Click H Nz on 25 C# 0 Br ush Tap BBk on Brush Tap RBk on Brush Tap DTk on Brush Tap Ethn Br ush Tap LoFi on Br ush Tap Nz 26 D 0 Brush Swirl BBk on on Br ush Swirl RBk on on Brush Swirl DTk on on Brush Swirl Ethn on Brush Swirl LoFi on on Brush Swirl Nz on 27 D# 0 Br ush Slap BBk on Brush Slap RBk on Br ush Slap DTk on Br ush Slap Ethn Brush Slap LoFi on Brush Slap Nz 28 E 0 Brush Tap Swirl BBk on on Brush Tap Swirl RBk on on Brush Tap Swirl DTk on on Brush Tap Swirl Ethn on Brush Tap Swirl LoFi on on Brush Tap Swirl Nz on 29 F 0 Snare Roll BBk on on Snare Roll Hard RBk on on Snare Roll Hard DTk on on

Snare Roll Hard Ethn

on Snare Roll LoFi on on Snare Roll Hard Nz on

30 F# 0 Castanet BBk

Hat 1/4-1/2 Heavy RBk SwonHat 1/4-1/2 Brllnt DTk Sw

on Castanet Ethn on Castanet LoFi on Castanet Nz

31 G 0

Snare Dry Lo Soft BBk

Snare Loose Snap Soft RBkonSnare Brass Picl Soft DTk

Snare Rock Open2 Ethn

Snare Dry Lo Soft LoFi

Snare Rock Mute1 Nz

32 G# 0 Sticks BBk on Sticks RBk on

Kick18x22" Dry DTk Sw

Sticks Ethn on Sticks LoFi on Sticks Nz

33 A 0 Kick Dry ff BBk

Kick18x22" Dry RBk Sw

Kick18x22" Dry DTk Sw

Kick Funk Hard Ethn Sw

on Kick Dry ff LoFi on

Kick16x20" Room Nz Sw

34 A# 0

Snare Rock Open2 Dry BBk

Snare Brass Rock Rim RBk

Snare Brass Attk Rim DTkonSnare Rock Rim1 Ethn

Snare Rock Open2 Dry LoFi

Snare Brass Piccl Soft Nz

35 B 0

Kick18x22" Dry BBk Sw

Kick 14x18" Room RBk Sw

Kick18x22" Room DTk Sw

Kick 14x18" Room Ethn SwonKick18x22" Dry LoFi Sw

Kick Dry Hi Heavy Nz

36 C 1

Kick Dry Heavy BBk Sw

Kick 14x22" Room RBk Sw

Kick18x22" Room DTk Sw

Kick Power Dry Lo Ethn

Kick Dry Heavy LoFi Sw

Kick 14x22" Room Nz Sw

37 C# 1 Sidestick Rock2 BBk on

Sidestick Metal RBk Sw

Sidestick Wood DTk Sw Sidestick Wood Ethn Sw

on Sidestick Rock2 LoFi on

Sidestick Wood Nz Sw

38 D 1

Snare Dry Lo BBk Sw

Snare Loose Snap RBk SwonSnare Brass Attack DTk Sw

Snare Loose Snap Ethn SwonSnare Dry Lo LoFi Sw

Snare Rock Mute2 Nz

39 D# 1 Hand Clap BBk on Hand Clap RBk on

Snare Brass Attack DTk Sw

Hand Clap Ethn on Hand Clap LoFi on Hand Clap Nz

40 E 1

Snare Brass Rock BBk Sw

Snare Brass Rock RBk Sw

Snare Brass Attk Rim DTkonSnare Brass Rock Rim Ethn

Snare Brass Rock LoFi Sw

Snare Rock Open2 Nz

41 F 1

Tom Power Lo Floor BBk

Tom Smooth Lo Floor RBk

Tom Power Lo DTk

Tom Dry Lo Floor Ethn

Tom Power Lo Floor LoFi

Tom Smooth Lo Floor Nz

42 F# 1

Hat Closed Dry BBk Sw

1on

Hat Closed Heavy RBk Sw

1on

Hat Closed Brllant DTk Sw

1on

Hat Closed Heavy Ethn Sw

1on

Hat Closed Dry LoFi Sw

1on

Hat Closed Heavy Nz Sw

1on

43 G 1

Tom Power Hi Floor BBk

Tom Smooth Hi Floor RBk

Tom Power Lo DTk

Tom Dry Hi Floor Ethn

Tom Power Hi Floor LoFi

Tom Smooth Hi Floor Nz

44 G# 1 Hat Pedal Dry BBk 1 on Hat Pedal Heavy RBk 1 on

Hat Pedal Brilliant DTk

1on

Hat Pedal Heavy Ethn

1 on Hat Pedal Dry LoFi 1 on Hat Pedal Heavy Nz 1 on

45 A 1 Tom Power Lo BBk Tom Smooth Lo RBk Tom Power Mid DTk Tom Dry Lo Ethn on Tom Power Lo LoFi on Tom Smooth Lo Nz on 46 A# 1 Hat Open Dry BBk 1 on Hat Open Heavy RBk 1 on

Hat Open Brilliant DTk

1on

Hat Open Heavy Ethn

1 on Hat Open Dr y LoFi 1 on Hat Open Heavy Nz 1 on

47 B 1

Tom Power Lo-Mid BBk

Tom Smooth Lo-Mid RBk

Tom Power Mid DTk Tom Dry Lo-Mid Ethn on

Tom Power Lo-Mid LoFi

Tom Smooth Lo-Mid Nz

48 C 2

Tom Power Hi-Mid BBk

Tom Smooth Hi-Mid RBk

Tom Power Hi DTk Tom Dry Hi-Mid Ethn on

Tom Power Hi-Mid LoFi

Tom Smooth Hi-Mid Nz

49 C# 2

Crash Cymbal 17" Thin BBk Crash Cymbal 17" Thin RBk

Crash Cymbal 17" Thin DTk

Crash Cym 17" Thin Ethn

Crash Cym 17" Thin LoFi

Crash Cymbal 17" Thin Nz

50 D 2 Tom Power Hi BBk Tom Smooth Hi RBk Tom Power Hi DTk Tom Dry Hi Ethn on Tom Power Hi LoFi on Tom Smooth Hi Nz on 51 D# 2

Ride Cymbal 21" BBk Sw

Ride Cymbal 22" RBk on

Ride Cymbal 21" DTk Sw

Ride Cymbal 22" Ethn

Ride Cymbal 21" LoFi Sw

Ride Cymbal 21" Sw Nz

52 E 2

China Cymbal 17" BBk

China Cymbal 17" RBk

Ride Cymbal 21" DTk Sw

China Cymbal 17" Ethn China Cymbal 17" LoFi

China Cymbal 17" Nz

53 F 2

Ride Cymbal Cup 21" BBk Ride Cymbal Cup 22" RBk

Ride Cymbal Cup 21" DTkonRide Cymbal Cup 22" Ethn

Ride Cymbal Cup 21" LoFi

Ride Cymbal Cup 21" Nz

54 F# 2 Tambourine BBk Tambourine RBk

Ride Cymbal Cup 21" DTk

Tambourine Ethn Tambourine LoFi Tambourine Nz

55 G 2

Splash Cymbal 10" BBk Splash Cymbal 10" RBk

Splash Cymbal 10" DTk

Splash Cymbal 10" Ethn

Splash Cymbal 10" LoFi

Splash Cymbal 10" Nz

56 G# 2 Cowbell BBk Cowbell RBk on

China Cymbal 17" DTk

China Cymbal Ethn Cowbell LoFi on Cowbell Nz

57 A 2

Crash Cymbal 14" BBk Crash Cymbal 14" RBk

Crash Cymbal 14" DTk Crash Cymbal 14" Ethn Crash Cymbal 14" LoFi

Crash Cymbal 14" Nz

58 A# 2 Vibraslap BBk Vibraslap RBk on

Ride Cymbal 22" DTk

on Splash Cymbal Ethn Vibraslap LoFi Vibraslap Nz

59 B 2 Ride Cymbal 22" BBk

Ride Cymbal 21" R/L RBk

Ride Cymbal 22" DTk

Ride Cymbal 21" R/L Ethn

Ride Cymbal 22" LoFi

Ride Cymbal 21" R/L Nz

60 C 3 Bongo H BBk Bongo H RBk Bongo H DTk on Bongo H Ethn on Bongo H LoFi on Bongo H Nz 61 C# 3 Bongo L BBk Bongo L RBk Bongo L DTk on Bongo L Ethn on Bongo L LoFi on Bongo L Nz 62 D 3 Conga H Mute BBk Conga H Mute RBk Conga H Mute DTk on Conga H Mute Ethn on Conga H Mute LoFi on Conga H Mute Nz 63 D# 3 Conga H Open BBk Conga H Open RBk Conga H Open DTk on Conga H Open Ethn on Conga H Open LoFi on Conga H Open Nz 64 E 3 Conga L BBk Conga L RBk Conga L DTk on Conga L Ethn on Conga L LoFi on Conga L Nz 65 F 3 Timbale H BBk Timbale H RBk on Timbale H DTk on Timbale H Ethn Timbale H LoFi on Timbale H Nz 66 F# 3 Timbale L BBk Timbale L RBk on Timbale L DTk on Timbale L Ethn Timbale L LoFi on Timbale L Nz 67 G 3 Agogo H BBk Agogo H RBk on Agogo H DTk on Agogo H Ethn Agogo H LoFi Agogo H Nz 68 G# 3 Agogo L BBk Agogo L RBk on Agogo L DTk on Agogo L Ethn Agogo L LoFi Agogo L Nz 69 A 3 Cabasa BBk Cabasa RBk on Cabasa DTk on Cabasa Ethn Cabasa LoFi Cabasa Nz 70 A# 3 Maracas BBk Maracas RBk Maracas DTk Maracas Ethn on Maracas LoFi Maracas Nz 71 B 3

Samba Whistle H BBk

Samba Whistle H RBk

on on

Samba Whistle H DTk

on on

Samba Whistle H Ethn

Samba Whistle H LoFi

Samba Whistle H Nz

72 C 4 Samba Whistle L BBk on

Samba Whistle L RBk

on on

Samba Whistle L DTk

on on

Samba Whistle L Ethn

Samba Whistle L LoFi

Samba Whistle L Nz

73 C# 4 Guiro Shor t BBk Guiro Short RBk Guiro Short DTk on Guiro Short Ethn Guiro Short LoFi Guiro Shor t Nz 74 D 4 Guiro Long BBk on Guiro Long RBk on Guiro Long DTk on on Guiro Long Ethn on Guiro Long LoFi on Guiro Long Nz on 75 D# 4 Claves BBk Claves RBk on Claves DTk on Claves Ethn on Claves LoFi Claves Nz 76 E 4 Wood Block H BBk Wood Block H RBk on Wood Block H DTk on Wood Block H Ethn on Wood Block H LoFi Wood Block H Nz 77 F 4 Wood Block L BBk Wood Block L RBk on Wood Block L DTk on Wood Block L Ethn on Wood Block L LoFi Wood Block L Nz 78 F# 4 Cuica Mute BBk Cuica Mute RBk on Cuica Mute DTk on on Cuica Mute Ethn Cuica Mute LoFi Cuica Mute Nz 79 G 4 Cuica Open BBk Cuica Open RBk on Cuica Open DTk on on Cuica Open Ethn Cuica Open LoFi Cuica Open Nz 80 G# 4 Triangle Mute BBk 2 on Triangle Mute RBk 2 Triangle Mute DTk 2 Triangle Mute Ethn 2 Triangle Mute LoFi 2 on Triangle Mute Nz 2 81 A 4 Triangle Open BBk 2 on Triangle Open RBk 2 Triangle Open DTk 2 Triangle Open Ethn 2 Triangle Open LoFi 2 on Triangle Open Nz 2 82 A# 4 Shaker BBk Shaker RBk Shaker DTk Shaker Ethn Shaker LoFi Shaker Nz 83 B 4 Jingle Bells BBk on Jingle Bells RBk on Jingle Bells DTk on Jingle Bells Ethn Jingle Bells LoFi Jingle Bells Nz 84 C 5 Bell Tree BBk on Bell Tree RBk on Bell Tree DTk on Bell Tree Ethn Bell Tree LoFi Bell Tree Nz on 85 C# 5 86 D 5 87 D# 5 88 E 5 89 F 5 90 F# 5 91 G 5 92 G# 5 93 A 5 94 A# 5 95 B 5 96 C 6 97 C# 6 98 D 6 99 D# 6

100 E 6 101 F 6

Voice List

A : Alternate Group K : Key Off I : Insertion Effect : No sound

25 26 27 28 29 30

BreakAmb Electron EthncAmb Flanger Phaser1 Phaser2

Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I

Surdo Mute BAmb 3 Surdo Mute Elc 3 on Surdo Mute EAmb 3 on Surdo Mute Flg 3 on Surdo Mute Ph1 3 on Surdo Mute Ph2 3 on Surdo Open BAmb 3 Surdo Open Elc 3 on Surdo Open EAmb 3 on Surdo Open Flg 3 on Surdo Open Ph1 3 on Surdo Open Ph2 3 on Hi Q BAmb Hi Q Elc Hi Q EAmb Hi Q Flg on Hi Q Ph1 on Hi Q Ph2 on Whip Slap BAmb on Whip Slap Elc Whip Slap EAmb Whip Slap Flg on Whip Slap Ph1 on Whip Slap Ph2 on Scratch H BAmb 4 on Scratch H Elc 4 Scratch H EAmb 4 on Scratch H Flg 4 on Scratch H Ph1 4 on Scratch H Ph2 4 on Scratch L BAmb 4 on Scratch L Elc 4 Scratch L EAmb 4 on Scratch L Flg 4 on Scratch L Ph1 4 on Scratch L Ph2 4 on Finger Snap BAmb on Finger Snap Elc on Finger Snap EAmb Finger Snap Flg on Finger Snap Ph1 on Finger Snap Ph2 on Click Noise BAmb on Click Noise Elc Click Noise EAmb Click Noise Flg on Click Noise Ph1 on Click Noise Ph2 on Metronome Click BAmb

on Metronome Click Elc

Metronome Click EAmb

Metronome Click Flg on

Metronome Click Ph1

Metronome Click Ph2

on Metronome Bell BAmb on Metronome Bell Elc Metronome Bell EAmb Metronome Bell Flg on Metronome Bell Ph1 on Metronome Bell Ph2 on Seq Click L BAmb Seq Click L Elc on Seq Click L EAmb Seq Click L Flg on Seq Click L Ph1 on Seq Click L Ph2 on Seq Click H BAmb Seq Click H Elc on Seq Click H EAmb Seq Click H Flg on Seq Click H Ph1 on Seq Click H Ph2 on Brush Tap BAmb on Brush Tap Elc on Brush Tap EAmb on Brush Tap Flg on Brush Tap Ph1 on Brush Tap Ph2 on Brush Swirl BAmb on Brush Swirl Elc on on Brush Swir l EAmb on Brush Swirl Flg on on Brush Swir l Ph1 on on Brush Swirl Ph2 on on Brush Slap BAmb Brush Slap Elc on Brush Slap EAmb on Brush Slap Flg on Brush Slap Ph1 on Brush Slap Ph2 on Brush Tap Swirl BAmb on Brush Tap Swirl Elc on Brush Tap Swirl EAmb on on Brush Tap Swirl Flg on on Brush Tap Swirl Ph1 on on Brush Tap Swirl Ph2 on on Snare Roll BAmb on on Snare Roll Hard Elc on on

Snare Roll Hard EAmb

on on Snare Roll Rock Flg on on Snare Roll Hard Ph1 on on Snare Roll Rock Ph2 on on

Castanet BAmb Castanet Elc on Castanet EAmb

Hat 1/4-1/2 Brllnt Flg Sw

1on

Hat 1/4-1/2 Heavy Ph1 Sw

1 on Castanet Ph2 on

Snare Power Dry L BAmb Sw

Snare Rock Mute1 Elc

Snare Rock Open2 EAmb

Snare Brass Picl Soft Flg

Snare Loose Snap Soft Ph1onSnare Brass Picl Soft Ph2

on Sticks BAmb Sticks Elc on Sticks EAmb Sticks Flg on Sticks Ph1 on Sticks Ph2 on Kick 14x18" Room BAmb Sw Kick16x20" Room Elc Sw

Kick 14x18" Room EAmb SwonKick 18x22" Dry Flg Sw

Kick 14x22" Dry Ph1 Sw

Kick 18x22" Dry Ph2 Sw

on Snare Rock Open1 Dry BAmb

Snare Brass Picl Soft Elc

Snare Rock Rim1 EAmb

Snare Brass Attck Rim Flg

Snare Brass Rock Rim Ph1

Snare Brass Attck Rim Ph2

on Kick18x22" Dry BAmb Sw

Kick Dry Hi Heavy Elc

Snare LooseSnap Soft EAmbonKick 16x20" Room Flg Sw

Kick 14x18" Room Ph1 Sw

Kick 16x20" Room Ph2 Sw

on Kick Dry Hi BAmb

Kick 14x22" Room Elc Sw

Snare Brass Rock Rim EAmb

Kick 18x22" Room Flg Sw

Kick 14x22" Room Ph1 Sw

Kick 18x22" Room Ph2 Sw

on Sidestick Wood BAmb Sw Sidestick Wood Elc Sw

Sidestick Wood EAmb Sw

Sidestick Wood Flg Sw

Sidestick Metal Ph1 Sw

Sidestick Wood Ph2 Sw

on Snare Dry Lo Soft BAmb Snare Rock Mute2 Elc

Snare Brass Piccl EAmb SwonSnare Brass Piccl Flg Sw

Snare Loose Snap Ph1 SwonSnare Brass Piccl Ph2 Sw

on Hand Clap BAmb Hand Clap Elc Hand Clap EAmb on Hand Clap Flg on Hand Clap Ph1 on Hand Clap Ph2 on Snare Power Dry H BAmb Sw

Snare Rock Open2 Elc

Hat Open Heavy EAmb

Snare Brass Attack Flg Sw

Snare Brass Rock Ph1 Sw

Snare Brass Attack Ph2 Sw

on Tom Smooth Dry LoFlr BAmb

Tom Smooth Lo Floor Elc

Tom Dry Lo Floor EAmb

Tom Power Lo Floor Flg

Tom Smooth Lo Floor Ph1

Tom Power Lo Floor Ph2

on Hat Closed Dry BAmb Sw

Hat Closed Heavy Elc Sw

1on

Hat Closed Heavy EAmb Sw

1on

Hat Closed Brllant Flg Sw

1on

Hat Closed Heavy Ph1 Sw

1on

Hat Closed Brllant Ph2 Sw

1on

Tom Smooth Dry HiFlr BAmb Tom Smooth Hi Floor Elc

Tom Dry Hi Floor EAmb

Tom Power Hi Floor Flg

Tom Smooth Hi Floor Ph1

Hat 1/4-1/2 Brllnt Ph2 Sw

1on

Hat Pedal Dry BAmb 1 Hat Pedal Heavy Elc 1 on

Hat Pedal Heavy EAmb

1on

Hat Pedal Brilliant Flg

1on

Hat Pedal Heavy Ph1

1on

Hat Pedal Brilliant Ph2

1on

Tom Smooth Dry Lo BAmb

Tom Smooth Lo Elc Tom Dry Lo EAmb Tom Power Lo Flg on Tom Smooth Lo Ph1 on Tom Power Lo Ph2 on

Hat Open Dry BAmb 1 Hat Open Heavy Elc 1 on

Hat Open Heavy EAmb

1on

Hat Open Brilliant Flg

1on

Hat Open Heavy Ph1

1on

Hat Open Brilliant Ph2

1on

Tom Smooth Dry LoMid BAmb

Tom Smooth Lo-Mid Elc Tom Dry Lo-Mid EAmb Tom Power Lo-Mid Flg

Tom Smooth Lo-Mid Ph1

Tom Power Lo-Mid Ph2

on Tom Smooth Dry HiMid BAmb

Tom Smooth Hi-Mid Elc Tom Dry Hi-Mid EAmb Tom Power Hi-Mid Flg

Tom Smooth Hi-Mid Ph1

Tom Power Hi-Mid Ph2

on Crash Cym 17" Thin BAmb

Crash Cymbal 17" Thin Elc

Hat Open Heavy EAmb

Crash Cymbal 17" Thin Flg

Crash Cymbal 17" Thin Ph1

Crash Cymbal 17" Thin Ph2

on Tom Smooth Dry Hi BAmb

Tom Smooth Hi Elc Tom Dry Hi EAmb Tom Power Hi Flg on Tom Smooth Hi Ph1 on Tom Power Hi Ph2 on

Ride Cymbal 22" BAmb

Ride Cymbal 21" Elc Sw

Ride Cymbal 22" EAmb

Ride Cymbal 21" Flg Sw

Ride Cymbal 22" Ph1

Ride Cymbal 21" Ph2 Sw

on China Cymbal 17" BAmb

China Cymbal 17" Elc

China Cymbal 17" EAmb

China Cymbal 17" Flg

China Cymbal 17" Ph1

China Cymbal 17" Ph2

on Ride Cymbal Cup 22" BAmb Ride Cymbal Cup 21" Elc

Ride Cymbal Cup 22" EAmb Ride Cymbal Cup 21" Flg

Ride Cymbal Cup 22" Ph1onRide Cymbal Cup 21" Ph2

on Tambourine BAmb Tambourine Elc Tambourine EAmb Tambourine Flg on Tambourine Ph1 on Tambourine Ph2 on Splash Cymbal 10" BAmb

Splash Cymbal 10" Elc

Hat Open Brilliant EAmb Splash Cymbal 10" Flg

Splash Cymbal 10" Ph1

Splash Cymbal 10" Ph2

on Cowbell BAmb Cowbell Elc on China Cymbal EAmb Cowbell Flg on Cowbell Ph1 on Cowbell Ph2 on Crash Cymbal 14" BAmb Crash Cymbal 14" Elc Hat Open Brilliant EAmb Crash Cymbal 14" Flg

Crash Cymbal 14" Ph1

Crash Cymbal 14" Ph2

on Vibraslap BAmb Vibraslap Elc on

Ride Cymbal Cup 22" EAmb

Vibraslap Flg on Vibraslap Ph1 on Vibraslap Ph2 on

Ride Cymbal 22" BAmb

Ride Cymbal 21" R/L Elc

Ride Cymbal Cup 21" EAmb Ride Cymbal 22" R/L Flg

Ride Cymbal 21" R/L Ph1

Ride Cymbal 22" R/L Ph2

on Bongo H BAmb Bongo H Elc on Bongo H EAmb Bongo H Flg on Bongo H Ph1 on Bongo H Ph2 on Bongo L BAmb Bongo L Elc on Bongo L EAmb Bongo L Flg on Bongo L Ph1 on Bongo L Ph2 on Conga H Mute BAmb Conga H Mute Elc on Conga H Mute EAmb Conga H Mute Flg on Conga H Mute Ph1 on Conga H Mute Ph2 on Conga H Open BAmb Conga H Open Elc on Conga H Open EAmb Conga H Open Flg on Conga H Open Ph1 on Conga H Open Ph2 on Conga L BAmb Conga L Elc on Conga L EAmb Conga L Flg on Conga L Ph1 on Conga L Ph2 on Timbale H BAmb Timbale H Elc on Ride Cymbal EAmb Timbale H Flg on Timbale H Ph1 on Timbale H Ph2 on Timbale L BAmb Timbale L Elc on

Ride Cymbal 22" EAmb

Timbale L Flg on Timbale L Ph1 on Timbale L Ph2 on

Agogo H BAmb on Agogo H Elc on

Ride Cymbal Cup 22" EAmb

Agogo H Flg on Agogo H Ph1 on Agogo H Ph2 on

Agogo L BAmb on Agogo L Elc on

Ride Cymbal Cup 21" EAmb

Agogo L Flg on Agogo L Ph1 on Agogo L Ph2 on Cabasa BAmb Cabasa Elc on Cabasa EAmb Cabasa Flg on Cabasa Ph1 on Cabasa Ph2 on Maracas BAmb Maracas Elc on Maracas EAmb Maracas Flg on Maracas Ph1 on Maracas Ph2 on Samba Whistle H BAmb

on on

Samba Whistle H Elc

on on Brush Tap Swirl EAmb on

Samba Whistle H Flg

on on

Samba Whistle H Ph1

on on

Samba Whistle H Ph2

on on

Samba Whistle L BAmb

on on Samba Whistle L Elc on on Brush Tap Swirl EAmb on Samba Whistle L Flg on on

Samba Whistle L Ph1

on on

Samba Whistle L Ph2

on on Guiro Short BAmb on Guiro Short Elc on Guiro Short EAmb Guiro Short Flg on Guiro Short Ph1 on Guiro Shor t Ph2 on Guiro Long BAmb on Guiro Long Elc on on Guiro Long EAmb on Guiro Long Flg on on Guiro Long Ph1 on on Guiro Long Ph2 on on Claves BAmb on Claves Elc on Claves EAmb Claves Flg on Claves Ph1 on Claves Ph2 on Wood Block H BAmb on Wood Block H Elc on Wood Block H EAmb Wood Block H Flg on Wood Block H Ph1 on Wood Block H Ph2 on Wood Block L BAmb on Wood Block L Elc on Wood Block L EAmb Wood Block L Flg on Wood Block L Ph1 on Wood Block L Ph2 on Cuica Mute BAmb on Cuica Mute Elc on Cuica Mute EAmb Cuica Mute Flg on Cuica Mute Ph1 on Cuica Mute Ph2 on Cuica Open BAmb Cuica Open Elc on Cuica Open EAmb Cuica Open Flg on Cuica Open Ph1 on Cuica Open Ph2 on Triangle Mute BAmb 2 Triangle Mute Elc 2 on Triangle Mute EAmb 2 Triangle Mute Flg 2 on Triangle Mute Ph1 2 on Triangle Mute Ph2 2 on Triangle Open BAmb 2 Triangle Open Elc 2 on Triangle Open EAmb 2 Triangle Open Flg 2 on Triangle Open Ph1 2 on Triangle Open Ph2 2 on Shaker BAmb Shaker Elc on Shaker EAmb Shaker Flg on Shaker Ph1 on Shaker Ph2 on Jingle Bells BAmb Jingle Bells Elc on Jingle Bells EAmb Jingle Bells Flg on Jingle Bells Ph1 on Jingle Bells Ph2 on Bell Tree BAmb on Bell Tree Elc on Bell Tree EAmb Bell Tree Flg on Bell Tree Ph1 on Bell Tree Ph2 on

Voice List

DR Instrument Map MSB=79, LSB=0

A : Alternate Group K : Key Off I : Insertion Effect : No sound

Program No.

31 32 33 34 35

Kit Name AM/PM AutoPan Drone SnareKit Cym Amb

Note#

Note Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I

13 C# -1 Surdo Mute Trm 3 on Surdo Mute APan 3 on Surdo Mute Dr n 3 on 14 D -1 Surdo Open Trm 3 on Surdo Open APan 3 on Surdo Open Dr n 3 on 15 D# -1 Hi Q Trm on Hi Q APan on Hi Q Drn on 16 E -1 Whip Slap Trm on Whip Slap APan on Whip Slap Drn on 17 F -1 Scratch H Trm 4 on Scratch H APan 4 on Scratch H Drn 4 on 18 F# -1 Scratch L Trm 4 on Scratch L APan 4 on Scratch L Drn 4 on 19 G -1 Finger Snap Trm on Finger Snap APan on Finger Snap Drn on 20 G# -1 Click Noise Trm on Click Noise APan on Click Noise Drn on 21 A -1 Metronome Click Trm on Metronome Click APan on Metronome Click Drn on 22 A# -1 Metronome Bell Trm on Metronome Bell APan on Metronome Bell Dr n on 23 B -1 Seq Click L Trm on Seq Click L APan on Seq Click L Drn on 24 C 0 Seq Click H Trm on Seq Click H APan on Seq Click H Drn on 25 C# 0 Br ush Tap Trm on Brush Tap APan on Brush Tap Drn on 26 D 0 Brush Swirl Trm on on Brush Swirl APan on on Brush Swirl Dr n on on 27 D# 0 Br ush Slap Trm on Brush Slap APan on Brush Slap Drn on 28 E 0 Brush Tap Swirl Trm on on Brush Tap Swirl APan on on Brush Tap Swirl Drn on on 29 F 0 Snare Roll Hard Trm on on Snare Roll Rock APan on on Snare Roll Rock Drn on on 30 F# 0 Castanet Trm on Castanet APan on Castanet Dr n on 31 G 0

Snare Rock Open1 Dry Trm

on Snare Brs Piccl Soft APan on Snare Brs Picl Dry Drn Sw on

32 G# 0 Sticks Trm on Sticks APan on Sticks Drn on 33 A 0 Kick Dry Heavy Trm Sw on Kick 14x22" Dry APan Sw on Kick 18x22" Dry Drn Sw on 34 A# 0 Snare Rock Rim1 Trm on Snare Snap Rim APan on Snare Dr y Hi Drn Sw on 35 B 0 Kick Dry Hi Heavy Kick Long Sw APan on Kick Dry ff Drn 36 C 1 Kick Rock1 Trm on Kick Punch Sw APan on Kick 14x22" Dry Drn Sw on

Kick Snare Power Dry H Sw

on Crash Cymbal Amb on

37 C# 1 Sidestick Rock1 Trm on Sidestick Wood APan Sw on

Sidestick Wood Dry Drn Sw

on Sidestick Snare Pwr Dry H Crash Cymbal Rock1 Amb on

38 D 1 Snare Rock Open1 Trm on Snare Hi APan Sw on

Snare Power Dry Hi Drn Sw

Snare Power Dry Hi mp Ana

Crash Cymbal 17" Thin Amb

39 D# 1 Hand Clap Trm on Hand Clap APan on Hand Clap Drn on

SFX Snare Power Dry Hi mf

Crash Cymbal 14" Amb on 40 E 1 Snare Rock Mute1 Snare Wide Snap APan Sw on Snare Brs Attk Dry Drn Sw Snare Power Dry Hi ff Ana on Crash Cymbal R/L Amb on 41 F 1 Tom Rock Lo Floor Trm on Tom Stick Lo APan on Tom Dry Lo Floor Drn on

Tom Snare Power Dry Lo Sw

on Splash Cymbal Amb on

42 F# 1 Hat Closed Rock1 Trm Sw 1 on

Hat Closed Hvy Lo APan Sw

1on

Hat Closed Hvy Dry Drn Sw

1 on Hat Snare Power Dry Lo p Splash Cymbal 10" Amb on

43 G 1 Tom Rock Hi Floor Trm on Hat 1/4-1/2 Hvy L APan Sw 1 on Tom Dry Hi Floor Drn on

Tom Snare Power Dry Lo mp

on China Cymbal Amb on

44 G# 1

Hat Close-Pedal Rk1Trm Sw

1 on Hat Pedal Heavy Lo APan 1 on Hat Pedal Heavy Dry Drn 1 on Hat Snare Power Dry Lo mf China Cymbal 17" Amb on

45 A 1 Tom Rock Lo Trm on Tom Stick Lo-Mid APan on Tom Dry Lo Drn on Tom Snare Power Dry Lo ff on Ride Cymbal Amb on 46 A# 1 Hat Open Rock1 Trm Sw 1 on Hat Open Heavy Lo APan 1 on Hat Open Heavy Drn 1 on Hat Snare Dry Hi Sw Ride Cymbal Cup Amb on 47 B 1 Tom Rock Lo-Mid Trm on Tom Stick Mid APan on Tom Dry Lo-Mid Drn on

Tom Snare Dry Hi mp-mf Sw

on Ride Cymbal 21" Amb Sw on

48 C 2 Tom Rock Hi-Mid Trm on Tom Stick Hi Mid APan on Tom Dry Hi-Mid Drn on Tom Snare Dry Hi mf-ff Sw on Ride Cymbal 21" mp Amb on 49 C# 2 Crash Cymbal Rock1 Trm on

Crash Cym17" Thin Lo APan

on Crash Cymbal Drn on SFX Snare Dr y Hi mp Ride Cymbal 21" mf Amb on

50 D 2 Tom Rock Hi Trm on Tom Stick Hi APan on Tom Dry Hi Drn on Tom Snare Dry Hi mf on Ride Cymbal Cup 21" Amb on 51 D# 2 Ride Cymbal Rock1 Trm on Ride Cym 21" Lo APan Sw on Ride Cymbal 21" Drn Sw on SFX Snare Dry Hi ff Ride Cymbal 22" Amb on 52 E 2 China Cymbal Rock Trm on China Cymbal 17" Hi APan on China Cymbal Drn on SFX Snare Dry Lo Sw Ride Cymbal Cup 22" Amb on 53 F 2

Ride Cymbal Cup Rock Trm

on Ride Cymbal Cup 21" APan on Ride Cymbal Cup 21" Dr n on SFX Snare Dr y Lo p Ride Cymbal R/L Amb on

54 F# 2 Tambourine Trm on Tambourine APan on Tambourine Drn on SFX Snare Dry Lo mp Ride Cymbal 21" R/L Amb on 55 G 2 Splash Cymbal Rock Trm on

Splash Cymbal 10" Hi APan

on Splash Cymbal 10" Drn on SFX Snare Dry Lo mf Ride Cymbal 22" R/L Amb on

56 G# 2 Cowbell Trm on Cowbell APan on Cowbell Drn on SFX Snare Dry Lo ff on 57 A 2 Crash Cymbal Rock2 Trm on Crash Cymbal 14" Lo APan on Crash 17" Thin R/L Lo Drn on SFX Snare Rock Mute1 58 A# 2 Vibraslap Trm on Vibraslap APan on Vibraslap Drn on SFX Snare Rock Open1 on 59 B 2 Ride Cymbal Rock2 Trm on Ride Cym 22" R/L Hi APan on Ride Cymbal R/L Dr n on SFX Snare Rock Rim1 60 C 3 Bongo H Trm on Bongo H APan on Bongo H Drn on

SFX Snare Rock Open1 Dry

61 C# 3 Bongo L Trm on Bongo L APan on Bongo L Drn on SFX Snare Rock Mute2 on 62 D 3 Conga H Mute Trm on Conga H Mute APan on Conga H Mute Drn on SFX Snare Rock Open2 on 63 D# 3 Conga H Open Trm on Conga H Open APan on Conga H Open Drn on SFX Snare Rock Rim2 on 64 E 3 Conga L Trm on Conga L APan on Conga L Drn on SFX Snare Brass Piccl Sw on 65 F 3 Timbale H Trm on Timbale H APan on Timbale H Drn on SFX Snare Brass Piccl p on 66 F# 3 Timbale L Trm on Timbale L APan on Timbale L Drn on SFX Snare Brass Piccl mp on 67 G 3 Agogo H Trm on Agogo H APan on Agogo H Drn on SFX Snare Brass Piccl mf on 68 G# 3 Agogo L Trm on Agogo L APan on Agogo L Drn on SFX Snare Brass Piccl ff on 69 A 3 Cabasa Trm on Cabasa APan on Cabasa Drn on

SFX Snare Brass Attack Sw

70 A# 3 Maracas Trm on Maracas APan on Maracas Drn on SFX Snare Brass Attack p 71 B 3 Samba Whistle H Trm on on Samba Whistle H APan on on Samba Whistle H Drn on on

SFX Snare Brass Attack mp

72 C 4 Samba Whistle L Trm on on Samba Whistle L APan on on Samba Whistle L Drn on on SFX Snare Brass Attack mf 73 C# 4 Guiro Shor t Trm on Guiro Shor t APan on Guiro Short Drn on SFX Snare Brass Attack ff 74 D 4 Guiro Long Trm on on Guiro Long APan on on Guiro Long Dr n on on SFX Snare Loose Snap Sw 75 D# 4 Claves Trm on Claves APan on Claves Drn on SFX Snare Loose Snap p 76 E 4 Wood Block H Trm on Wood Block H APan on Wood Block H Drn on SFX Snare Loose Snap mp on 77 F 4 Wood Block L Trm on Wood Block L APan on Wood Block L Drn on SFX Snare Loose Snap mf on 78 F# 4 Cuica Mute Trm on Cuica Mute APan on Cuica Mute Drn on SFX Snare Loose Snap ff on 79 G 4 Cuica Open Trm on Cuica Open APan on Cuica Open Dr n on SFX Snare Brass Rock Sw 80 G# 4 Triangle Mute Trm 2 on Triangle Mute APan 2 on Triangle Mute Drn 2 on SFX Snare Brass Rock p 1 on 81 A 4 Triangle Open Trm 2 on Triangle Open APan 2 on Triangle Open Drn 2 on SFX Snare Brass Rock mp 1 on 82 A# 4 Shaker Trm on Shaker APan on Shaker Drn on SFX Snare Brass Rock mf 83 B 4 Jingle Bells Trm on Jingle Bells APan on Jingle Bells Dr n on SFX Snare Brass Rock ff 84 C 5 Bell Tree Trm on Bell Tree APan on Bell Tree Drn on SFX Brush Tap 85 C# 5 SFX Brush Swirl on on 86 D 5 SFX Brush Slap on 87 D# 5 SFX Brush Tap Swirl on 88 E 5 SFX Snare Roll on on 89 F 5 SFX Snare Roll Hard on 90 F# 5 SFX Sidestick Dry on 91 G 5 SFX Sidestick Rock1 92 G# 5 SFX Sidestick Rock2 93 A 5 SFX Sidestick Wood Sw 94 A# 5 SFX Sidestick Wood mp 95 B 5 SFX Sidestick Wood mf 96 C 6 SFX Sidestick Metal Sw 97 C# 6 SFX Sidestick Metal mp 98 D 6 SFX Sidestick Metal mf 99 D# 6

100 E 6 101 F 6

Voice List

A : Alternate Group K : Key Off I : Insertion Effect : No sound

36 37 38 39 40 41

KitA/Ht1 KitB/Ht1 KitA/Ht2 KitB/Ht2 Spread1 Spread2

Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I

Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 Surdo Mute 9 Surdo Mute 9 Surdo Open 3 Surdo Open 3 Surdo Open 3 Surdo Open 3 Surdo Open 9 Surdo Open 9 Hi Q Hi Q Hi Q Hi Q Hi Q Hi Q Whip Slap Whip Slap Whip Slap Whip Slap Whip Slap Whip Slap Scratch H 4 Scratch H 4 Scratch H 4 Scratch H 4 Scratch H 10 Scratch H 10 Scratch L 4 Scratch L 4 Scratch L 4 Scratch L 4 Scratch L 10 Scratch L 10 Finger Snap Finger Snap Finger Snap Finger Snap Finger Snap Finger Snap Click Noise Click Noise Click Noise Click Noise Click Noise Click Noise Metronome Click Metronome Click Metronome Click Metronome Click Metronome Click Metronome Click Metronome Bell Metronome Bell Metronome Bell Metronome Bell Metronome Bell Metronome Bell Seq Click L Seq Click L Seq Click L Seq Click L Seq Click L Seq Click L Seq Click H Seq Click H Seq Click H Seq Click H Seq Click H Seq Click H Brush Tap Brush Tap Br ush Tap Brush Tap Brush Tap Br ush Tap Brush Swirl on Brush Swirl on Brush Swirl on Brush Swirl on Brush Swirl on Brush Swirl on Brush Slap Br ush Slap Brush Slap Brush Slap Brush Slap Brush Slap Brush Tap Swirl on Brush Tap Swirl on Brush Tap Swirl on Brush Tap Swirl on Br ush Tap Swirl on Br ush Tap Swirl on Snare Roll Rock on Snare Roll Hard on Snare Roll Rock on Snare Roll Hard on Snare Roll Rock on Snare Roll Rock on Castanet Castanet Castanet Castanet

Hat 1/4-1/2 Brilliant Sw

Snare Brass Piccolo Soft

Snare Loose Snap Soft

Snare Brass Piccolo Soft

Snare Loose Snap Soft

Snare Brass Piccolo Soft Snare Brass Piccolo Soft

Sticks Sticks Sticks Sticks

Kick 18x22" Maple Dry Sw

Kick 18x22" Maple Dry Sw Kick 14x22" Maple Dry Sw Kick 18x22" Maple Dry Sw Kick 14x22" Maple Dry Sw Kick 18x22" Maple Dr y Sw

Kick 18x22" Maple Dry Sw

Snare Brass Attack Rim

Snare Brass Rock Rim

Snare Brass Attack Rim

Snare Brass Rock Rim

Snare Brass Attack Rim

Kick 16x20" Maple Room Sw Kick 14x18" Birch Room Sw Kick 16x20" Maple Room Sw Kick 14x18" Birch Room Sw Kick 18x22" Maple Room Sw3Kick 16x20" Maple Room Sw

Kick 18x22" Maple Room Sw Kick 14x22" Maple Room Sw Kick 18x22" Maple Room Sw Kick 14x22" Maple Room Sw Kick 18x22" Maple Room Sw3Kick 16x20" Maple Room Sw

3 Sidestick Wood Knock Sw Sidestick Metal Knock Sw Sidestick Wood Knock Sw Sidestick Metal Knock Sw Sidestick Wood Knock Sw Sidestick Wood Knock Sw Snare Brass Piccolo Sw

Snare Loose Snap Sw

Snare Brass Piccolo Sw

Snare Loose Snap Sw Snare Brass Attack Sw

4on

Snare Brass Piccolo Sw

4 Hand Clap Hand Clap Hand Clap Hand Clap

Snare Brass Attack Sw

Snare Brass Piccolo Sw

4 Snare Brass Attack Sw

on Snare Brass Rock Sw

Snare Brass Attack Sw

on Snare Brass Rock Sw

Snare Brass Attack Rim

Snare Brass Piccolo Sw

4 Tom Power Lo Floor Tom Smooth Lo Floor Tom Power Lo Floor Tom Smooth Lo Floor Tom Power Lo Floor 5 Tom Power Lo Floor 5 Hat Closed Brilliant Sw

1 Hat Closed Heavy Sw 1

Hat Closed Brilliant mf

1 Hat Closed Heavy mf 1

Hat Closed Brilliant Sw

1 Hat 1/4-1/2 Brilliant Sw

1 Hat 1/4-1/2 Heavy Sw 1 Hat Closed Brilliant ff 1 Hat Closed Heavy ff 1 Tom Power Lo Floor 5 Tom Power Lo Floor 5 Hat Pedal Brilliant 1 Hat Pedal Heavy 1 Hat 1/4 Brilliant 1 Hat 1/4 Heavy 1 Hat Pedal Brilliant 1 Hat Pedal Brilliant 1 Tom Power Lo Tom Smooth Lo Hat 1/2 Brilliant 1 Hat 1/2 Heavy 1 Tom Power Mid 6 Tom Power Mid 6 Hat Open Brilliant 1 Hat Open Heavy 1 Hat Open Brilliant 1 Hat Open Heavy 1 Hat Open Brilliant 1 Hat Open Brilliant 1 Tom Power Lo-Mid Tom Smooth Lo-Mid Hat Pedal Brilliant Hat Pedal Heavy Tom Power Mid 6 Tom Power Mid 6 Tom Power Hi-Mid Tom Smooth Hi-Mid Tom Power Mid Tom Smooth Mid Tom Power Hi 7 Tom Power Hi 7 Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin Tom Power Hi Tom Smooth Hi Tom Power Hi Tom Smooth Hi Tom Power Hi 7 Tom Power Hi 7 Ride Cymbal 21" Sw Ride Cymbal 22" Ride Cymbal 21" Sw Ride Cymbal 22" Ride Cymbal 21" Sw Ride Cymbal 21" Sw China Cymbal 17" China Cymbal 17" China Cymbal 17" China Cymbal 17" Ride Cymbal 21" Sw Ride Cymbal 21" Sw Ride Cymbal Cup 21" Ride Cymbal Cup 22" Ride Cymbal Cup 21" Ride Cymbal Cup 22" Ride Cymbal Cup 21" Ride Cymbal Cup 21" Tambourine Tambourine Tambourine Tambourine Ride Cymbal Cup 21" Ride Cymbal Cup 21" Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" Cowbell Cowbell Cowbell Cowbell China Cymbal 17" China Cymbal 17" Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" Vibraslap Vibraslap Vibraslap Vibraslap Ride Cymbal 22" R/L Ride Cymbal 22" R/L Ride Cymbal 22" R/L Ride Cymbal 21" R/L Ride Cymbal 22" R/L Ride Cymbal 21" R/L Ride Cymbal 22" R/L Ride Cymbal 22" R/L Bongo H Bongo H Bongo H Bongo H Bongo H Bongo H Bongo L Bongo L Bongo L Bongo L Bongo L Bongo L Conga H Mute Conga H Mute Conga H Mute Conga H Mute Conga H Mute Conga H Mute Conga H Open Conga H Open Conga H Open Conga H Open Conga H Open Conga H Open Conga L Conga L Conga L Conga L Conga L Conga L Timbale H Timbale H Timbale H Timbale H Timbale H Timbale H Timbale L Timbale L Timbale L Timbale L Timbale L Timbale L Agogo H Agogo H Agogo H Agogo H Agogo H Agogo H Agogo L Agogo L Agogo L Agogo L Agogo L Agogo L Cabasa Cabasa Cabasa Cabasa Cabasa Cabasa Maracas Maracas Maracas Maracas Maracas Maracas Samba Whistle H on Samba Whistle H on Samba Whistle H on Samba Whistle H on Samba Whistle H on Samba Whistle H on Samba Whistle L on Samba Whistle L on Samba Whistle L on Samba Whistle L on Samba Whistle L on Samba Whistle L on Guiro Short Guiro Short Guiro Short Guiro Short Guiro Short Guiro Short Guiro Long on Guiro Long on Guiro Long on Guiro Long on Guiro Long on Guiro Long on Claves Claves Claves Claves Claves Claves Wood Block H Wood Block H Wood Block H Wood Block H Wood Block H Wood Block H Wood Block L Wood Block L Wood Block L Wood Block L Wood Block L Wood Block L Cuica Mute Cuica Mute Cuica Mute Cuica Mute Cuica Mute Cuica Mute Cuica Open Cuica Open Cuica Open Cuica Open Cuica Open Cuica Open Triangle Mute 2 Triangle Mute 2 Triangle Mute 2 Triangle Mute 2 Triangle Mute 8 Triangle Mute 8 Triangle Open 2 Triangle Open 2 Triangle Open 2 Triangle Open 2 Triangle Open 8 Triangle Open 8 Shaker Shaker Shaker Shaker Shaker Shaker Jingle Bells Jingle Bells Jingle Bells Jingle Bells Jingle Bells Jingle Bells Bell Tree Bell Tree Bell Tree Bell Tree Bell Tree Bell Tree

Voice List

DR Instrument Map MSB=79, LSB=0

A : Alternate Group K : Key Off I : Insertion Effect : No sound

Program No.

42 43 44 45 46 47

Kit Name Spread3 Spread4 Kicks Snares Toms Hats

Note#

Note Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I

13 C# -1 Surdo Mute 9 Surdo Mute 9 14 D -1 Surdo Open 9 Surdo Open 9 15 D# -1 Hi Q Hi Q 16 E -1 Whip Slap Whip Slap 17 F -1 Scratch H 10 Scratch H 10 18 F# -1 Scratch L 10 Scratch L 10 19 G -1 Finger Snap Finger Snap 20 G# -1 Click Noise Click Noise 21 A -1 Metronome Click Metronome Click 22 A# -1 Metronome Bell Metronome Bell 23 B -1 Seq Click L Seq Click L 24 C 0 Seq Click H Seq Click H 25 C# 0 Br ush Tap Brush Tap 26 D 0 Brush Swirl on Brush Swirl on 27 D# 0 Br ush Slap Brush Slap 28 E 0 Brush Tap Swirl on Brush Tap Swirl on 29 F 0 Snare Roll Hard on Snare Roll Hard on 30 F# 0 Hat 1/4-1/2 Heavy Sw 1

Hat 1/4-1/2 Heavy Sw

31 G 0

Snare Loose Snap Soft

32 G# 0

Kick 14x22" Maple Dry Sw

33 A 0

Kick 14x22" Maple Dry Sw

34 A# 0

Snare Brass Rock Rim

35 B 0

Kick 14x22" Maple Room Sw3Kick 14x18" Birch Room Sw

36 C 1

Kick 14x22" Maple Room Sw3Kick 14x18" Birch Room Sw

3 Kick Power Dry Hi

Snare Power Dry Hi Sw

Tom Dry1 Lo Floor

Hat Closed Power 1

37 C# 1

Sidestick Metal Knock Sw

Kick Power Dry Lo

Snare Power Dry Hi p Tom Dry1 Hi Floor

Hat 1/2 Power 1

38 D 1 Snare Brass Rock Sw 4

Snare Loose Snap Sw

4 Kick Funk

Snare Power Dry Hi mp

Tom Dry1 Lo Hat Open Power 1

39 D# 1 Snare Brass Rock Sw 4

Snare Loose Snap Sw

4 Kick Dry Sw

Snare Power Dry Hi mf

Tom Dry1 Lo-Mid

Hat Closed Dry Sw 2

40 E 1

Snare Brass Rock Rim

Snare Loose Snap Sw

4 Kick Dry mf

Snare Power Dry Hi ff

Tom Dry1 Hi-Mid

Hat Closed Dry p 2

41 F 1 Tom Smooth Lo Floor 5

Tom Smooth Lo Floor

5 Kick Dry ff

Snare Power Dry Lo Sw

Tom Dry1 Hi Hat Closed Dry mp 2

42 F# 1 Hat Closed Heavy Sw 1

Hat Closed Heavy Sw

1 Kick Funk Hard Sw

Snare Power Dry Lo p Tom Dry2 Lo Floor

Hat Closed Dry mf 2

43 G 1 Tom Smooth Lo Floor 5

Tom Smooth Lo Floor

5 Kick Funk Hard mf

Snare Power Dry Lo mp

Tom Dry2 Hi Floor

Hat Closed Dry ff 2

44 G# 1 Hat Pedal Heavy 1 Hat Pedal Heavy 1 Kick Funk Hard ff

Snare Power Dry Lo mf

Tom Dry2 Lo Hat Pedal Dry 2

45 A 1 Tom Smooth Mid 6 Tom Smooth Mid 6 Kick Dry Hi

Snare Power Dry Lo ff

Tom Dry2 Lo-Mid

Hat Open Dry 2

46 A# 1 Hat Open Heavy 1 Hat Open Heavy 1 Kick Rock1 Snare Dry Hi Sw

Tom Dry2 Hi-Mid Hat Closed Rock1 Sw

47 B 1 Tom Smooth Mid 6 Tom Smooth Mid 6 Kick Rock2

Snare Dry Hi mp-mf Sw

Tom Dry2 Hi

Hat Closed-Pedal Rock1 Sw

48 C 2 Tom Smooth Hi 7 Tom Smooth Hi 7 Kick Dry Hi Heavy

Snare Dry Hi mf-ff Sw

Tom Rock Lo Floor Hat Open Rock1 Sw

49 C# 2

Crash Cymbal 17" Thin

Kick Dry Heavy Sw Snare Dry Hi mp

Tom Rock Hi Floor

Hat 1/2 Rock2 3

50 D 2 Tom Smooth Hi 7 Tom Smooth Hi 7 Kick Dry Heavy mf Snare Dry Hi mf Tom Rock Lo

Hat Closed Brilliant Sw

51 D# 2 Ride Cymbal 22" Ride Cymbal 22" Kick Dry Heavy ff Snare Dry Hi ff

Tom Rock Lo-Mid Hat Closed Brilliant mf

52 E 2 Ride Cymbal 22" Ride Cymbal 22" Kick Dry ff Snare Dry Lo Sw

Tom Rock Hi-Mid

Hat Closed Brilliant ff 4

53 F 2 Ride Cymbal Cup 22"

Ride Cymbal Cup 22"

Kick Power Dry Lo Snare Dry Lo p Tom Rock Hi Hat Pedal Brilliant 4

54 F# 2 Ride Cymbal Cup 22"

Ride Cymbal Cup 22"

Kick 18x22" Maple Dry Sw

Snare Dry Lo mp

Tom Power Lo Floor

Hat 1/4-1/2 Brilliant Sw

55 G 2 Splash Cymbal 10" Splash Cymbal 10"

Kick18x22" Maple Dry mp

Snare Dry Lo mf

Tom Power Hi Floor

Hat 1/4 Brilliant 4

56 G# 2 China Cymbal 17" China Cymbal 17"

Kick18x22" Maple Dry mf

Snare Dry Lo ff Tom Power Lo Hat 1/2 Brilliant 4

57 A 2 Crash Cymbal 14" Crash Cymbal 14"

Kick18x22" Maple Dry ff

Snare Rock Mute1

Tom Power Lo-Mid

Hat Open Brilliant 4

58 A# 2 Ride Cymbal 21" R/L Ride Cymbal 21" R/L

Kick 14x22" Maple Dry Sw

Snare Rock Open1

Tom Power Hi-Mid

Hat Closed Heavy Sw

59 B 2 Ride Cymbal 21" R/L Ride Cymbal 21" R/L

Kick 14x22" Maple Dry mp

Snare Rock Rim1 Tom Power Hi Hat Closed Heavy mf 5

60 C 3 Bongo H Bongo H

Kick 14x22" Maple Dry mf

Snare Rock Open1 Dry

Tom Smooth Lo Floor

Hat Closed Heavy ff 5

61 C# 3 Bongo L Bongo L

Kick 14x22" Maple Dry ff

Snare Rock Mute2

Tom Smooth Hi Floor

Hat Pedal Heavy 5

62 D 3 Conga H Mute Conga H Mute

Kick16x20" Maple Dry Sw

Snare Rock Open2 Tom Smooth Lo

Hat 1/4-1/2 Heavy Sw

63 D# 3 Conga H Open Conga H Open

Kick 16x20" Maple Dry mp

Snare Rock Rim2

Tom Smooth Lo-Mid

Hat 1/4 Heavy 5

64 E 3 Conga L Conga L

Kick 16x20" Maple Dry mf

Snare Brass Piccolo Sw Tom Smooth Hi-Mid

Hat 1/2 Heavy 5

65 F 3 Timbale H Timbale H

Kick 16x20" Maple Dry ff Snare Brass Piccolo p

Tom Smooth Hi Hat Open Heavy 5

66 F

# 3 Timbale L Timbale L

Kick 14x18" Birch Dry Sw

Snare Brass Piccolo mp

67 G 3 Agogo H Agogo H

Kick 14x18" Birch Dry mp

Snare Brass Piccolo mf

68 G# 3 Agogo L Agogo L

Kick 14x18" Birch Dry mf Snare Brass Piccolo ff

69 A 3 Cabasa Cabasa

Kick 14x18" Birch Dry ff

Snare Brass Attack Sw

70 A# 3 Maracas Maracas

Kick 18x22" Maple Room Sw

Snare Brass Attack p

71 B 3 Samba Whistle H on Samba Whistle H on

Kick18x22" Maple Room mp

Snare Brass Attack mp

72 C 4 Samba Whistle L on Samba Whistle L on

Kick18x22" Maple Room mf

Snare Brass Attack mf

73 C# 4 Guiro Shor t Guiro Shor t

Kick18x22" Maple Room ff

Snare Brass Attack ff

74 D 4 Guiro Long on Guiro Long on

Kick 14x22" Maple Room Sw

Snare Loose Snap Sw

75 D# 4 Claves Claves

Kick 14x22" Maple Room mp

Snare Loose Snap p

76 E 4 Wood Block H Wood Block H

Kick 14x22" Maple Room mf

Snare Loose Snap mp

77 F 4 Wood Block L Wood Block L

Kick 14x22" Maple Room ff

Snare Loose Snap mf

78 F# 4 Cuica Mute Cuica Mute

Kick 16x20" Maple Room Sw

Snare Loose Snap ff

79 G 4 Cuica Open Cuica Open

Kick16x20" Maple Room mp

Snare Brass Rock Sw

80 G# 4 Triangle Mute 8 Triangle Mute 8

Kick16x20" Maple Room mf

Snare Brass Rock p

81 A 4 Triangle Open 8 Triangle Open 8

Kick16x20" Maple Room ff

Snare Brass Rock mp

82 A# 4 Shaker Shaker

Kick 14x18" Birch Room Sw

Snare Brass Rock mf

83 B 4 Jingle Bells Jingle Bells

Kick 14x18" Birch Room mp

Snare Brass Rock ff

84 C 5 Bell Tree Bell Tree

Kick 14x18" Birch Room mf

Brush Tap

85 C# 5

Kick 14x18" Birch Room ff

Brush Swirl on

86 D 5 Brush Slap 87 D# 5 Brush Tap Swirl on 88 E 5 Snare Roll on 89 F 5 Snare Roll Hard 90 F# 5 Sidestick Dry 91 G 5 Sidestick Rock1 92 G# 5 Sidestick Rock2 93 A 5

Sidestick Wood Knock Sw

94 A# 5

Sidestick Wood Knock mp

95 B 5

Sidestick Wood Knock mf

96 C 6

Sidestick Metal Knock Sw

97 C# 6

Sidestick Metal Knock mp

98 D 6

Sidestick Metal Knock mf

99 D# 6

100 E 6 101 F 6

Voice List

A : Alternate Group K : Key Off I : Insertion Effect : No sound

* These kits have been created by combining the Kick, Snare, Hi-hat and Tom sounds of the LiveRmA and LiveRmB voices.

Example : A B A A /Prc

48 49 50 51 52 53

Cymbals A--PlgPC B--PlgPC ABAA/Prc* AABA/Prc* AAAB/Prc*

Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I

Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 Surdo Open 3 Surdo Open 3 Surdo Open 3 Surdo Open 3 Surdo Open 3 Hi Q Hi Q Hi Q Hi Q Hi Q Whip Slap Whip Slap Whip Slap Whip Slap Whip Slap Scratch H 4 Scratch H 4 Scratch H 4 Scratch H 4 Scratch H 4 Scratch L 4 Scratch L 4 Scratch L 4 Scratch L 4 Scratch L 4 Finger Snap Finger Snap Finger Snap Finger Snap Finger Snap Click Noise Click Noise Click Noise Click Noise Click Noise Metronome Click Metronome Click Metronome Click Metronome Click Metronome Click Metronome Bell Metronome Bell Metronome Bell Metronome Bell Metronome Bell Seq Click L Seq Click L Seq Click L Seq Click L Seq Click L Seq Click H Seq Click H Seq Click H Seq Click H Seq Click H Brush Tap Brush Tap Br ush Tap Brush Tap Brush Tap Brush Swirl on Brush Swirl on Brush Swirl on Brush Swirl on Brush Swirl on Brush Slap Br ush Slap Brush Slap Brush Slap Brush Slap Brush Tap Swirl on Brush Tap Swirl on Brush Tap Swirl on Brush Tap Swirl on Br ush Tap Swirl on Snare Roll Rock on Snare Roll Hard on Snare Roll Rock on Snare Roll Rock on Snare Roll Rock on Hat 1/4-1/2 Brilliant Sw

1 Hat 1/4-1/2 Heavy Sw 1

Hat 1/4-1/2 Brilliant Sw

1 Hat 1/4-1/2 Heavy Sw 1

Hat 1/4-1/2 Brilliant Sw

Snare Brass Piccolo Soft

Snare Loose Snap Soft Snare Loose Snap Soft

Snare Brass Piccolo Soft Snare Brass Piccolo Soft Sticks Sticks Sticks Sticks Sticks Kick 18x22" Maple Dry Sw Kick 14x22" Maple Dry Sw Kick 18x22" Maple Dry Sw Kick 18x22" Maple Dry Sw Kick 18x22" Maple Dr y Sw Snare Brass Attack Rim

Snare Brass Rock Rim Snare Brass Rock Rim

Snare Brass Attack Rim Snare Brass Attack Rim Kick 16x20" Maple Room Sw Kick 14x18" Birch Room Sw Kick 16x20" Maple Room Sw Kick 16x20" Maple Room Sw Kick 16x20" Maple Room Sw

Crash Cymbal

Kick 18x22" Maple Room Sw Kick 14x22" Maple Room Sw Kick 18x22" Maple Room Sw Kick 18x22" Maple Room Sw Kick 18x22" Maple Room Sw

Crash Cymbal Rock1

Sidestick Wood Knock Sw Sidestick Metal Knock Sw Sidestick Metal Knock Sw Sidestick Wood Knock Sw Sidestick Wood Knock Sw

Crash Cymbal 17" Thin

Snare Brass Piccolo Sw

Snare Loose Snap Sw Snare Loose Snap Sw

Snare Brass Piccolo Sw Snare Brass Piccolo Sw

Crash Cymbal 14"

Hand Clap Hand Clap Hand Clap Hand Clap Hand Clap

Crash Cymbal R/L Snare Brass Attack Sw

on Snare Brass Rock Sw Snare Brass Rock Sw

Snare Brass Attack Sw

on Splash Cymbal Tom Power Lo Floor Tom Smooth Lo Floor Tom Power Lo Floor Tom Power Lo Floor Tom Smooth Lo Floor Splash Cymbal 10"

Hat Closed Brilliant Sw

1 Hat Closed Heavy Sw 1

Hat Closed Brilliant Sw

1 Hat Closed Heavy Sw 1

Hat Closed Brilliant Sw

1 China Cymbal Tom Power Hi Floor Tom Smooth Hi Floor Tom Power Hi Floor Tom Power Hi Floor Tom Smooth Hi Floor China Cymbal 17"

Hat Pedal Brilliant 1 Hat Pedal Heavy 1 Hat Pedal Brilliant 1 Hat Pedal Heavy 1 Hat Pedal Brilliant 1 Ride Cymbal Tom Power Lo Tom Smooth Lo Tom Power Lo Tom Power Lo Tom Smooth Lo Ride Cymbal Cup

Hat Open Brilliant 1 Hat Open Heavy 1 Hat Open Brilliant 1 Hat Open Heavy 1 Hat Open Brilliant 1 Ride Cymbal 21" Sw

Tom Power Lo-Mid Tom Smooth Lo-Mid Tom Power Lo-Mid Tom Power Lo-Mid Tom Smooth Lo-Mid Ride Cymbal 21" mp

Tom Power Hi-Mid Tom Smooth Hi-Mid Tom Power Hi-Mid Tom Power Hi-Mid Tom Smooth Hi-Mid Ride Cymbal 21" mf

Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin Ride Cymbal Cup 21"

Tom Power Hi Tom Smooth Hi Tom Power Hi Tom Power Hi Tom Smooth Hi Ride Cymbal 22" Ride Cymbal 21" Sw Ride Cymbal 22" Ride Cymbal 21" Sw Ride Cymbal 21" Sw Ride Cymbal 21" Sw Ride Cymbal Cup 22"

China Cymbal 17" China Cymbal 17" China Cymbal 17" China Cymbal 17" China Cymbal 17" Ride Cymbal R/L Ride Cymbal Cup 21" Ride Cymbal Cup 22" Ride Cymbal Cup 21" Ride Cymbal Cup 21" Ride Cymbal Cup 21" Ride Cymbal 21" R/L

Tambourine Tambourine Tambourine Tambourine Tambourine Ride Cymbal 22" R/L

Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10"

Cowbell Cowbell Cowbell Cowbell Cowbell

Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14"

Vibraslap Vibraslap Vibraslap Vibraslap Vibraslap

Ride Cymbal 22" R/L Ride Cymbal 21" R/L Ride Cymbal 22" R/L Ride Cymbal 22" R/L Ride Cymbal 22" R/L

Bongo H Bongo H Bongo H Bongo L Bongo L Bongo L Conga H Mute Conga H Mute Conga H Mute Conga H Open Conga H Open Conga H Open Conga L Conga L Conga L Timbale H Timbale H Timbale H Timbale L Timbale L Timbale L Agogo H Agogo H Agogo H Agogo L Agogo L Agogo L Cabasa Cabasa Cabasa Maracas Maracas Maracas Samba Whistle H on Samba Whistle H on Samba Whistle H on Samba Whistle L on Samba Whistle L on Samba Whistle L on Guiro Short Guiro Short Guiro Short Guiro Long on Guiro Long on Guiro Long on Claves Claves Claves Wood Block H Wood Block H Wood Block H Wood Block L Wood Block L Wood Block L Cuica Mute Cuica Mute Cuica Mute Cuica Open Cuica Open Cuica Open Triangle Mute 2 Triangle Mute 2 Triangle Mute 2 Triangle Open 2 Triangle Open 2 Triangle Open 2 Shaker Shaker Shaker Jingle Bells Jingle Bells Jingle Bells Bell Tree Bell Tree Bell Tree

Tom (from LiveRm A) Hi-hat (from LiveRm A) Snare (from LiveRm B) Kick (from LiveRm A)

Refers to the keys C3 and higher. Percussion sounds are mapped to these keys.

Prc : Percussion Kk : Kicks Sn1 : Snares1 Sn2 : Snares2 Tom : Tom-toms Hat : Hi-Hats Cym : Cymbals

Voice List

DR Instrument Map MSB=79, LSB=0

A : Alternate Group K : Key Off I : Insertion Effect : No sound

* These kits have been created by combining the Kick, Snare, Hi-hat and Tom sounds of the LiveRmA and LiveRmB voices.

Example : A B A A /Prc

Program No.

54 55 56 57 58

Kit Name ABBA/Prc* AABB/Prc* ABAB/Prc* ABBB/Prc* BABB/Prc*

Note#

Note Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I

13 C# -1 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 14 D -1 Surdo Open 3 Surdo Open 3 Surdo Open 3 Surdo Open 3 Surdo Open 3 15 D# -1 Hi Q Hi Q Hi Q Hi Q Hi Q 16 E -1 Whip Slap Whip Slap Whip Slap Whip Slap Whip Slap 17 F -1 Scratch H 4 Scratch H 4 Scratch H 4 Scratch H 4 Scratch H 4 18 F# -1 Scratch L 4 Scratch L 4 Scratch L 4 Scratch L 4 Scratch L 4 19 G -1 Finger Snap Finger Snap Finger Snap Finger Snap Finger Snap 20 G# -1 Click Noise Click Noise Click Noise Click Noise Click Noise 21 A -1 Metronome Click Metronome Click Metronome Click Metronome Click Metronome Click 22 A# -1 Metronome Bell Metronome Bell Metronome Bell Metronome Bell Metronome Bell 23 B -1 Seq Click L Seq Click L Seq Click L Seq Click L Seq Click L 24 C 0 Seq Click H Seq Click H Seq Click H Seq Click H Seq Click H 25 C# 0 Br ush Tap Brush Tap Brush Tap Brush Tap Brush Tap 26 D 0 Brush Swirl on Br ush Swirl on Brush Swirl on Brush Swirl on Brush Swirl on 27 D# 0 Br ush Slap Brush Slap Brush Slap Brush Slap Brush Slap 28 E 0 Brush Tap Swirl on Brush Tap Swirl on Brush Tap Swirl on Brush Tap Swirl on Brush Tap Swirl on 29 F 0 Snare Roll Rock on Snare Roll Rock on Snare Roll Rock on Snare Roll Rock on Snare Roll Hard on 30 F# 0 Hat 1/4-1/2 Heavy Sw 1 Hat 1/4-1/2 Heavy Sw 1 Hat 1/4-1/2 Brilliant Sw 1 Hat 1/4-1/2 Heavy Sw 1 Hat 1/4-1/2 Heavy Sw 1 31 G 0 Snare Loose Snap Soft Snare Brass Piccolo Soft Snare Loose Snap Soft Snare Loose Snap Soft Snare Brass Piccolo Soft 32 G# 0 Sticks Sticks Sticks Sticks Sticks 33 A 0 Kick 18x22" Maple Dry Sw Kick 18x22" Maple Dry Sw Kick 18x22" Maple Dr y Sw Kick 18x22" Maple Dry Sw Kick 14x22" Maple Dry Sw 34 A# 0 Snare Brass Rock Rim Snare Brass Attack Rim Snare Brass Rock Rim Snare Brass Rock Rim Snare Brass Attack Rim 35 B 0

Kick 16x20" Maple Room Sw Kick 16x20" Maple Room Sw Kick 16x20" Maple Room Sw Kick 16x20" Maple Room Sw Kick 14x18" Birch Room Sw

36 C 1

Kick 18x22" Maple Room Sw Kick 18x22" Maple Room Sw Kick 18x22" Maple Room Sw Kick 18x22" Maple Room Sw Kick 14x22" Maple Room Sw

37 C# 1 Sidestick Metal Knock Sw Sidestick Wood Knock Sw Sidestick Metal Knock Sw Sidestick Metal Knock Sw Sidestick Wood Knock Sw 38 D 1 Snare Loose Snap Sw Snare Brass Piccolo Sw Snare Loose Snap Sw Snare Loose Snap Sw Snare Brass Piccolo Sw 39 D# 1 Hand Clap Hand Clap Hand Clap Hand Clap Hand Clap 40 E 1 Snare Brass Rock Sw Snare Brass Attack Sw on Snare Brass Rock Sw Snare Brass Rock Sw Snare Brass Attack Sw on 41 F 1 Tom Power Lo Floor Tom Smooth Lo Floor Tom Smooth Lo Floor Tom Smooth Lo Floor Tom Smooth Lo Floor 42 F# 1 Hat Closed Heavy Sw 1 Hat Closed Heavy Sw 1 Hat Closed Brilliant Sw 1 Hat Closed Heavy Sw 1 Hat Closed Heavy Sw 1 43 G 1 Tom Power Hi Floor Tom Smooth Hi Floor Tom Smooth Hi Floor Tom Smooth Hi Floor Tom Smooth Hi Floor 44 G# 1 Hat Pedal Heavy 1 Hat Pedal Heavy 1 Hat Pedal Brilliant 1 Hat Pedal Heavy 1 Hat Pedal Heavy 1 45 A 1 Tom Power Lo Tom Smooth Lo Tom Smooth Lo Tom Smooth Lo Tom Smooth Lo 46 A# 1 Hat Open Heavy 1 Hat Open Heavy 1 Hat Open Brilliant 1 Hat Open Heavy 1 Hat Open Heavy 1 47 B 1 Tom Power Lo-Mid Tom Smooth Lo-Mid Tom Smooth Lo-Mid Tom Smooth Lo-Mid Tom Smooth Lo-Mid 48 C 2 Tom Power Hi-Mid Tom Smooth Hi-Mid Tom Smooth Hi-Mid Tom Smooth Hi-Mid Tom Smooth Hi-Mid 49 C# 2 Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin 50 D 2 Tom Power Hi Tom Smooth Hi Tom Smooth Hi Tom Smooth Hi Tom Smooth Hi 51 D# 2 Ride Cymbal 21" Sw Ride Cymbal 21" Sw Ride Cymbal 21" Sw Ride Cymbal 21" Sw Ride Cymbal 22" 52 E 2 China Cymbal 17" China Cymbal 17" China Cymbal 17" China Cymbal 17" China Cymbal 17" 53 F 2 Ride Cymbal Cup 21" Ride Cymbal Cup 21" Ride Cymbal Cup 21" Ride Cymbal Cup 21" Ride Cymbal Cup 22" 54 F# 2 Tambourine Tambourine Tambourine Tambourine Tambourine 55 G 2 Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" 56 G# 2 Cowbell Cowbell Cowbell Cowbell Cowbell 57 A 2 Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" 58 A# 2 Vibraslap Vibraslap Vibraslap Vibraslap Vibraslap 59 B 2 Ride Cymbal 22" R/L Ride Cymbal 22" R/L Ride Cymbal 22" R/L Ride Cymbal 22" R/L Ride Cymbal 21" R/L 60 C 3 Bongo H Bongo H Bongo H Bongo H Bongo H 61 C# 3 Bongo L Bongo L Bongo L Bongo L Bongo L 62 D 3 Conga H Mute Conga H Mute Conga H Mute Conga H Mute Conga H Mute 63 D# 3 Conga H Open Conga H Open Conga H Open Conga H Open Conga H Open 64 E 3 Conga L Conga L Conga L Conga L Conga L 65 F 3 Timbale H Timbale H Timbale H Timbale H Timbale H 66 F

# 3 Timbale L Timbale L Timbale L Timbale L Timbale L

67 G 3 Agogo H Agogo H Agogo H Agogo H Agogo H 68 G

# 3 Agogo L Agogo L Agogo L Agogo L Agogo L

69 A 3 Cabasa Cabasa Cabasa Cabasa Cabasa 70 A

# 3 Maracas Maracas Maracas Maracas Maracas

71 B 3 Samba Whistle H on Samba Whistle H on Samba Whistle H on Samba Whistle H on Samba Whistle H on 72 C 4 Samba Whistle L on Samba Whistle L on Samba Whistle L on Samba Whistle L on Samba Whistle L on 73 C

# 4 Guiro Short Guiro Short Guiro Shor t Guiro Short Guiro Short

74 D 4 Guiro Long on Guiro Long on Guiro Long on Guiro Long on Guiro Long on 75 D

# 4 Claves Claves Claves Claves Claves

76 E 4 Wood Block H Wood Block H Wood Block H Wood Block H Wood Block H 77 F 4 Wood Block L Wood Block L Wood Block L Wood Block L Wood Block L 78 F

# 4 Cuica Mute Cuica Mute Cuica Mute Cuica Mute Cuica Mute

79 G 4 Cuica Open Cuica Open Cuica Open Cuica Open Cuica Open 80 G

# 4 Triangle Mute 2 Triangle Mute 2 Triangle Mute 2 Triangle Mute 2 Triangle Mute 2

81 A 4 Triangle Open 2 Triangle Open 2 Triangle Open 2 Triangle Open 2 Triangle Open 2 82 A# 4 Shaker Shaker Shaker Shaker Shaker 83 B 4 Jingle Bells Jingle Bells Jingle Bells Jingle Bells Jingle Bells 84 C 5 Bell Tree Bell Tree Bell Tree Bell Tree Bell Tree 85 C

# 5

86 D 5 87 D# 5 88 E 5 89 F 5 90 F# 5 91 G 5 92 G# 5 93 A 5 94 A# 5 95 B 5 96 C 6 97 C# 6 98 D 6 99 D# 6

100 E 6 101 F 6

Tom (from LiveRm A) Hi-hat (from LiveRm A) Snare (from LiveRm B) Kick (from LiveRm A)

Refers to the keys C3 and higher. Percussion sounds are mapped to these keys.

Prc : Percussion Kk : Kicks Sn1 : Snares1 Sn2 : Snares2 Tom : Tom-toms Hat : Hi-Hats Cym : Cymbals

Voice List

A : Alternate Group K : Key Off I : Insertion Effect : No sound

* These kits have been created by combining the Kick, Snare, Hi-hat and Tom sounds of the LiveRmA and LiveRmB voices.

Example : A B A A /Prc

59 60 61 62 63 64

BBAB/Prc* BBBA/Prc* BAAB/Prc* BBAA/Prc* BABA/Prc* BAAA/Prc*

Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I

Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 Surdo Open 3 Surdo Open 3 Surdo Open 3 Surdo Open 3 Surdo Open 3 Surdo Open 3 Hi Q Hi Q Hi Q Hi Q Hi Q Hi Q Whip Slap Whip Slap Whip Slap Whip Slap Whip Slap Whip Slap Scratch H 4 Scratch H 4 Scratch H 4 Scratch H 4 Scratch H 4 Scratch H 4 Scratch L 4 Scratch L 4 Scratch L 4 Scratch L 4 Scratch L 4 Scratch L 4 Finger Snap Finger Snap Finger Snap Finger Snap Finger Snap Finger Snap Click Noise Click Noise Click Noise Click Noise Click Noise Click Noise Metronome Click Metronome Click Metronome Click Metronome Click Metronome Click Metronome Click Metronome Bell Metronome Bell Metronome Bell Metronome Bell Metronome Bell Metronome Bell Seq Click L Seq Click L Seq Click L Seq Click L Seq Click L Seq Click L Seq Click H Seq Click H Seq Click H Seq Click H Seq Click H Seq Click H Brush Tap Brush Tap Br ush Tap Brush Tap Brush Tap Br ush Tap Brush Swirl on Brush Swirl on Brush Swirl on Brush Swirl on Brush Swirl on Brush Swirl on Brush Slap Br ush Slap Brush Slap Brush Slap Brush Slap Brush Slap Brush Tap Swirl on Brush Tap Swirl on Brush Tap Swirl on Brush Tap Swirl on Br ush Tap Swirl on Br ush Tap Swirl on Snare Roll Hard on Snare Roll Hard on Snare Roll Hard on Snare Roll Hard on Snare Roll Hard on Snare Roll Rock on Hat 1/4-1/2 Brilliant Sw

1 Hat 1/4-1/2 Heavy Sw 1

Hat 1/4-1/2 Brilliant Sw

1 Hat 1/4-1/2 Heavy Sw 1

Hat 1/4-1/2 Brilliant Sw

Snare Loose Snap Soft Snare Loose Snap Soft

Snare Brass Piccolo Soft

Snare Loose Snap Soft

Snare Brass Piccolo Soft Snare Brass Piccolo Soft Sticks Sticks Sticks Sticks Sticks Sticks Kick 14x22" Maple Dry Sw Kick 14x22" Maple Dry Sw Kick 14x22" Maple Dry Sw Kick 14x22" Maple Dry Sw Kick 14x22" Maple Dr y Sw Kick 14x22" Maple Dry Sw Snare Brass Rock Rim Snare Brass Rock Rim

Snare Brass Attack Rim

Snare Brass Rock Rim

Snare Brass Attack Rim Snare Brass Attack Rim Kick 14x18" Birch Room Sw Kick 14x18" Birch Room Sw Kick 14x18" Birch Room Sw Kick 14x18" Birch Room Sw Kick 14x18" Birch Room Sw Kick 14x18" Birch Room Sw Kick 14x22" Maple Room Sw Kick 14x22" Maple Room Sw Kick 14x22" Maple Room Sw Kick 14x22" Maple Room Sw Kick 14x22" Maple Room Sw Kick 14x22" Maple Room Sw Sidestick Metal Knock Sw Sidestick Metal Knock Sw Sidestick Wood Knock Sw Sidestick Metal Knock Sw Sidestick Wood Knock Sw Sidestick Wood Knock Sw Snare Loose Snap Sw Snare Loose Snap Sw

Snare Brass Piccolo Sw

Snare Loose Snap Sw

Snare Brass Piccolo Sw Snare Brass Piccolo Sw Hand Clap Hand Clap Hand Clap Hand Clap Hand Clap Hand Clap Snare Brass Rock Sw Snare Brass Rock Sw

Snare Brass Attack Sw

on Snare Brass Rock Sw

Snare Brass Attack Sw

on Tom Smooth Lo Floor Tom Power Lo Floor Tom Smooth Lo Floor Tom Power Lo Floor Tom Power Lo Floor Tom Power Lo Floor Hat Closed Brilliant Sw

1 Hat Closed Heavy Sw 1

Hat Closed Brilliant Sw

1 Hat Closed Heavy Sw 1

Hat Closed Brilliant Sw

1 Tom Smooth Hi Floor Tom Power Hi Floor Tom Smooth Hi Floor Tom Power Hi Floor Tom Power Hi Floor Tom Power Hi Floor Hat Pedal Brilliant 1 Hat Pedal Heavy 1 Hat Pedal Brilliant 1 Hat Pedal Brilliant 1 Hat Pedal Heavy 1 Hat Pedal Brilliant 1 Tom Smooth Lo Tom Power Lo Tom Smooth Lo Tom Power Lo Tom Power Lo Tom Power Lo Hat Open Brilliant 1 Hat Open Heavy 1 Hat Open Brilliant 1 Hat Open Brilliant 1 Hat Open Heavy 1 Hat Open Brilliant 1 Tom Smooth Lo-Mid Tom Power Lo-Mid Tom Smooth Lo-Mid Tom Power Lo-Mid Tom Power Lo-Mid Tom Power Lo-Mid Tom Smooth Hi-Mid Tom Power Hi-Mid Tom Smooth Hi-Mid Tom Power Hi-Mid Tom Power Hi-Mid Tom Power Hi-Mid Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin Tom Smooth Hi Tom Power Hi Tom Smooth Hi Tom Power Hi Tom Power Hi Tom Power Hi Ride Cymbal 22" Ride Cymbal 22" Ride Cymbal 22" Ride Cymbal 22" Ride Cymbal 22" Ride Cymbal 22" China Cymbal 17" China Cymbal 17" China Cymbal 17" China Cymbal 17" China Cymbal 17" China Cymbal 17" Ride Cymbal Cup 22" Ride Cymbal Cup 22" Ride Cymbal Cup 22" Ride Cymbal Cup 22" Ride Cymbal Cup 22" Ride Cymbal Cup 22" Tambourine Tambourine Tambourine Tambourine Tambourine Tambourine Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" Cowbell Cowbell Cowbell Cowbell Cowbell Cowbell Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" Vibraslap Vibraslap Vibraslap Vibraslap Vibraslap Vibraslap Ride Cymbal 21" R/L Ride Cymbal 21" R/L Ride Cymbal 21" R/L Ride Cymbal 21" R/L Ride Cymbal 21" R/L Ride Cymbal 21" R/L Bongo H Bongo H Bongo H Bongo H Bongo H Bongo H Bongo L Bongo L Bongo L Bongo L Bongo L Bongo L Conga H Mute Conga H Mute Conga H Mute Conga H Mute Conga H Mute Conga H Mute Conga H Open Conga H Open Conga H Open Conga H Open Conga H Open Conga H Open Conga L Conga L Conga L Conga L Conga L Conga L Timbale H Timbale H Timbale H Timbale H Timbale H Timbale H Timbale L Timbale L Timbale L Timbale L Timbale L Timbale L Agogo H Agogo H Agogo H Agogo H Agogo H Agogo H Agogo L Agogo L Agogo L Agogo L Agogo L Agogo L Cabasa Cabasa Cabasa Cabasa Cabasa Cabasa Maracas Maracas Maracas Maracas Maracas Maracas Samba Whistle H on Samba Whistle H on Samba Whistle H on Samba Whistle H on Samba Whistle H on Samba Whistle H on Samba Whistle L on Samba Whistle L on Samba Whistle L on Samba Whistle L on Samba Whistle L on Samba Whistle L on Guiro Short Guiro Short Guiro Short Guiro Short Guiro Short Guiro Short Guiro Long on Guiro Long on Guiro Long on Guiro Long on Guiro Long on Guiro Long on Claves Claves Claves Claves Claves Claves Wood Block H Wood Block H Wood Block H Wood Block H Wood Block H Wood Block H Wood Block L Wood Block L Wood Block L Wood Block L Wood Block L Wood Block L Cuica Mute Cuica Mute Cuica Mute Cuica Mute Cuica Mute Cuica Mute Cuica Open Cuica Open Cuica Open Cuica Open Cuica Open Cuica Open Triangle Mute 2 Triangle Mute 2 Triangle Mute 2 Triangle Mute 2 Triangle Mute 2 Triangle Mute 2 Triangle Open 2 Triangle Open 2 Triangle Open 2 Triangle Open 2 Triangle Open 2 Triangle Open 2 Shaker Shaker Shaker Shaker Shaker Shaker Jingle Bells Jingle Bells Jingle Bells Jingle Bells Jingle Bells Jingle Bells Bell Tree Bell Tree Bell Tree Bell Tree Bell Tree Bell Tree

Tom (from LiveRm A) Hi-hat (from LiveRm A) Snare (from LiveRm B) Kick (from LiveRm A)

Refers to the keys C3 and higher. Percussion sounds are mapped to these keys.

Prc : Percussion Kk : Kicks Sn1 : Snares1 Sn2 : Snares2 Tom : Tom-toms Hat : Hi-Hats Cym : Cymbals

Voice List

DR Instrument Map MSB=79, LSB=0

A : Alternate Group K : Key Off I : Insertion Effect : No sound

* These kits have been created by combining the Kick, Snare, Hi-hat and Tom sounds of the LiveRmA and LiveRmB voices.

Example : A B A A /Prc

Program No.

65 66 67 68 69

Kit Name AAAA/Kk* ABAA/Sn1* AABA/Sn2* AAAB/Tom* ABBA/Hat*

Note#

Note Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I

13 C# -1 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 Surdo Mute 7 14 D -1 Surdo Open 3 Surdo Open 3 Surdo Open 3 Surdo Open 3 Surdo Open 7 15 D# -1 Hi Q Hi Q Hi Q Hi Q Hi Q 16 E -1 Whip Slap Whip Slap Whip Slap Whip Slap Whip Slap 17 F -1 Scratch H 4 Scratch H 4 Scratch H 4 Scratch H 4 Scratch H 8 18 F# -1 Scratch L 4 Scratch L 4 Scratch L 4 Scratch L 4 Scratch L 8 19 G -1 Finger Snap Finger Snap Finger Snap Finger Snap Finger Snap 20 G# -1 Click Noise Click Noise Click Noise Click Noise Click Noise 21 A -1 Metronome Click Metronome Click Metronome Click Metronome Click Metronome Click 22 A# -1 Metronome Bell Metronome Bell Metronome Bell Metronome Bell Metronome Bell 23 B -1 Seq Click L Seq Click L Seq Click L Seq Click L Seq Click L 24 C 0 Seq Click H Seq Click H Seq Click H Seq Click H Seq Click H 25 C# 0 Br ush Tap Brush Tap Br ush Tap Brush Tap Brush Tap 26 D 0 Brush Swirl on Brush Swirl on Brush Swirl on Brush Swirl on Brush Swirl on 27 D# 0 Br ush Slap Brush Slap Brush Slap Brush Slap Brush Slap 28 E 0 Brush Tap Swirl on Brush Tap Swirl on Brush Tap Swirl on Br ush Tap Swirl on Brush Tap Swirl on 29 F 0 Snare Roll Rock on Snare Roll Rock on Snare Roll Rock on Snare Roll Rock on Snare Roll Rock on 30 F# 0 Hat 1/4-1/2 Brilliant Sw 1 Hat 1/4-1/2 Brilliant Sw 1 Hat 1/4-1/2 Heavy Sw 1 Hat 1/4-1/2 Brilliant Sw 1 Hat 1/4-1/2 Heavy Sw 1 31 G 0 Snare Brass Piccolo Soft Snare Loose Snap Soft Snare Brass Piccolo Soft Snare Brass Piccolo Soft Snare Loose Snap Soft 32 G# 0 Sticks Sticks Sticks Sticks Sticks 33 A 0 Kick 18x22" Maple Dry Sw Kick 18x22" Maple Dr y Sw Kick 18x22" Maple Dry Sw Kick 18x22" Maple Dry Sw Kick 18x22" Maple Dry Sw 34 A# 0 Snare Brass Attack Rim Snare Brass Rock Rim Snare Brass Attack Rim Snare Brass Attack Rim Snare Brass Rock Rim 35 B 0

Kick 16x20" Maple Room Sw Kick 16x20" Maple Room Sw Kick 16x20" Maple Room Sw Kick 16x20" Maple Room Sw Kick 16x20" Maple Room Sw

36 C 1

Kick 18x22" Maple Room Sw Kick 18x22" Maple Room Sw Kick 18x22" Maple Room Sw Kick 18x22" Maple Room Sw Kick 18x22" Maple Room Sw

37 C# 1 Sidestick Wood Knock Sw Sidestick Metal Knock Sw Sidestick Wood Knock Sw Sidestick Wood Knock Sw Sidestick Metal Knock Sw 38 D 1 Snare Brass Piccolo Sw Snare Loose Snap Sw Snare Brass Piccolo Sw Snare Brass Piccolo Sw Snare Loose Snap Sw 39 D# 1 Hand Clap Hand Clap Hand Clap Hand Clap Hand Clap 40 E 1 Snare Brass Attack Sw on Snare Brass Rock Sw Snare Brass Attack Sw on Snare Brass Attack Sw on Snare Brass Rock Sw 41 F 1 Tom Power Lo Floor Tom Power Lo Floor Tom Power Lo Floor Tom Smooth Lo Floor Tom Power Lo Floor 42 F# 1 Hat Closed Brilliant Sw 1 Hat Closed Brilliant Sw 1 Hat Closed Heavy Sw 1 Hat Closed Brilliant Sw 1 Hat Closed Heavy Sw 1 43 G 1 Tom Power Hi Floor Tom Power Hi Floor Tom Power Hi Floor Tom Smooth Hi Floor Tom Power Hi Floor 44 G# 1 Hat Pedal Brilliant 1 Hat Pedal Brilliant 1 Hat Pedal Heavy 1 Hat Pedal Brilliant 1 Hat Pedal Heavy 1 45 A 1 Tom Power Lo Tom Power Lo Tom Power Lo Tom Smooth Lo Tom Power Lo 46 A# 1 Hat Open Brilliant 1 Hat Open Brilliant 1 Hat Open Heavy 1 Hat Open Brilliant 1 Hat Open Heavy 1 47 B 1 Tom Power Lo-Mid Tom Power Lo-Mid Tom Power Lo-Mid Tom Smooth Lo-Mid Tom Power Lo-Mid 48 C 2 Tom Power Hi-Mid Tom Power Hi-Mid Tom Power Hi-Mid Tom Smooth Hi-Mid Tom Power Hi-Mid 49 C# 2 Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin 50 D 2 Tom Power Hi Tom Power Hi Tom Power Hi Tom Smooth Hi Tom Power Hi 51 D# 2 Ride Cymbal 21" Sw Ride Cymbal 21" Sw Ride Cymbal 21" Sw Ride Cymbal 21" Sw Ride Cymbal 21" Sw 52 E 2 China Cymbal 17" China Cymbal 17" China Cymbal 17" China Cymbal 17" China Cymbal 17" 53 F 2 Ride Cymbal Cup 21" Ride Cymbal Cup 21" Ride Cymbal Cup 21" Ride Cymbal Cup 21" Ride Cymbal Cup 21" 54 F# 2 Tambourine Tambourine Tambourine Tambourine Tambourine 55 G 2 Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" 56 G# 2 Cowbell Cowbell Cowbell Cowbell Cowbell 57 A 2 Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" 58 A# 2 Vibraslap Vibraslap Vibraslap Vibraslap Vibraslap 59 B 2 Ride Cymbal 22" R/L Ride Cymbal 22" R/L Ride Cymbal 22" R/L Ride Cymbal 22" R/L Ride Cymbal 22" R/L 60 C 3 Kick Power Dry Hi Snare Power Dry Hi Sw Snare Brass Piccolo Sw Tom Dry1 Lo Floor Hat Closed Power 2 61 C# 3 Kick Power Dry Lo Snare Power Dry Hi p Snare Brass Piccolo p Tom Dry1 Hi Floor Hat 1/2 Power 2 62 D 3 Kick Funk Snare Power Dry Hi mp Snare Brass Piccolo mp Tom Dry1 Lo Hat Open Power 2 63 D# 3 Kick Dr y Sw Snare Power Dry Hi mf Snare Brass Piccolo mf Tom Dry1 Lo-Mid Hat Closed Dr y Sw 3 64 E 3 Kick Dry mf Snare Power Dry Hi ff Snare Brass Piccolo ff Tom Dry1 Hi-Mid Hat Closed Dry p 3 65 F 3 Kick Dry ff Snare Power Dry Lo Sw Snare Brass Attack Sw on Tom Dry1 Hi Hat Closed Dry mp 3 66 F

# 3 Kick Funk Hard Sw Snare Power Dry Lo p Snare Brass Attack p on Tom Dry2 Lo Floor Hat Closed Dry mf 3

67 G 3 Kick Funk Hard mf Snare Power Dry Lo mp Snare Brass Attack mp on Tom Dry2 Hi Floor Hat Closed Dry ff 3 68 G

# 3 Kick Funk Hard ff Snare Power Dry Lo mf Snare Brass Attack mf on Tom Dry2 Lo Hat Pedal Dry 3

69 A 3 Kick Dry Hi Snare Power Dry Lo ff Snare Brass Attack ff on Tom Dry2 Lo-Mid Hat Open Dry 3 70 A

# 3 Kick Rock1 Snare Dry Hi Sw Snare Loose Snap Sw Tom Dry2 Hi-Mid Hat Closed Rock1 Sw 4

71 B 3 Kick Rock2 Snare Dry Hi mp-mf Sw Snare Loose Snap p Tom Dry2 Hi

Hat Closed-Pedal Rock1 Sw

4 72 C 4 Kick Dry Hi Heavy Snare Dry Hi mf-ff Sw Snare Loose Snap mp Tom Rock Lo Floor Hat Open Rock1 Sw 4 73 C

# 4 Kick Dry Heavy Sw Snare Dry Hi mp Snare Loose Snap mf Tom Rock Hi Floor Hat 1/2 Rock2 4

74 D 4 Kick Dry Heavy mf Snare Dry Hi mf Snare Loose Snap ff Tom Rock Lo Hat Closed Brilliant Sw 5 75 D

# 4 Kick Dry Heavy ff Snare Dry Hi ff Snare Brass Rock Sw Tom Rock Lo-Mid Hat Closed Brilliant mf 5

76 E 4 Kick Dry ff Snare Dry Lo Sw Snare Brass Rock p Tom Rock Hi-Mid Hat Closed Brilliant ff 5 77 F 4 Kick Power Dry Lo Snare Dry Lo p Snare Brass Rock mp Tom Rock Hi Hat Pedal Brilliant 5 78 F

# 4 Kick 18x22" Maple Dr y Sw Snare Dry Lo mp Snare Brass Rock mf Tom Power Lo Floor Hat 1/4-1/2 Brilliant Sw 5

79 G 4 Kick18x22" Maple Dry mp Snare Dry Lo mf Snare Brass Rock ff Tom Power Hi Floor Hat 1/4 Br illiant 5 80 G

# 4 Kick18x22" Maple Dry mf Snare Dry Lo ff Snare Rock Open2 Tom Power Lo Hat 1/2 Brilliant 5

81 A 4 Kick18x22" Maple Dry ff Snare Rock Mute1 Snare Rock Rim2 Tom Power Lo-Mid Hat Open Brilliant 5 82 A# 4 Kick 14x22" Maple Dry Sw Snare Rock Open1 Brush Tap Tom Power Hi-Mid Hat Closed Heavy Sw 6 83 B 4 Kick 14x22" Maple Dry mp Snare Rock Rim1 Brush Swirl on Tom Power Hi Hat Closed Heavy mf 6 84 C 5 Kick 14x22" Maple Dry mf Snare Rock Open1 Dry Brush Slap Tom Smooth Lo Floor Hat Closed Heavy ff 6 85 C

# 5 Kick 14x22" Maple Dry ff Snare Rock Mute2 Br ush Tap Swirl on Tom Smooth Hi Floor Hat Pedal Heavy 6

86 D 5

Kick 18x22" Maple Room Sw

Snare Rock Open2 Snare Roll on Tom Smooth Lo Hat 1/4-1/2 Heavy Sw 6

87 D

# 5

Kick18x22" Maple Room mp

Snare Rock Rim2 Snare Roll Hard on Tom Smooth Lo-Mid Hat 1/4 Heavy 6

88 E 5

Kick18x22" Maple Room mf

Sidestick Dry Sidestick Dry Tom Smooth Hi-Mid Hat 1/2 Heavy 6 89 F 5 Kick18x22" Maple Room ff Sidestick Rock1 Sidestick Rock1 Tom Smooth Hi Hat Open Heavy 6 90 F

# 5

Kick 14x22" Maple Room Sw

Sidestick Rock2 Sidestick Rock2 91 G 5

Kick 14x22" Maple Room mp

Sidestick Wood Knock Sw Sidestick Wood Knock Sw 92 G# 5

Kick 14x22" Maple Room mf

Sidestick Wood Knock mp Sidestick Wood Knock mp 93 A 5 Kick 14x22" Maple Room ff Sidestick Wood Knock mf Sidestick Wood Knock mf 94 A# 5

Kick 16x20" Maple Room Sw

Sidestick Metal Knock Sw Sidestick Metal Knock Sw 95 B 5

Kick16x20" Maple Room mp

Sidestick Metal Knock mp Sidestick Metal Knock mp 96 C 6

Kick16x20" Maple Room mf

Sidestick Metal Knock mf Sidestick Metal Knock mf 97 C# 6 Kick16x20" Maple Room ff 98 D 6

Kick 14x18" Birch Room Sw

99 D# 6

Kick 14x18" Birch Room mp

100 E 6

Kick 14x18" Birch Room mf

101 F 6 Kick 14x18" Birch Room ff

Tom (from LiveRm A) Hi-hat (from LiveRm A) Snare (from LiveRm B) Kick (from LiveRm A)

Refers to the keys C3 and higher. Percussion sounds are mapped to these keys.

Prc : Percussion Kk : Kicks Sn1 : Snares1 Sn2 : Snares2 Tom : Tom-toms Hat : Hi-Hats Cym : Cymbals

Voice List

A : Alternate Group K : Key Off I : Insertion Effect : No sound

* These kits have been created by combining the Kick, Snare, Hi-hat and Tom sounds of the LiveRmA and LiveRmB voices.

Example : A B A A /Prc

70 71 72 73 74 75

AABB/Cym* ABAB/Sn1* ABBB/Sn2* BBBB/Kk* BABB/Sn1* BBAB/Sn2*

Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I

Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 Surdo Open 3 Surdo Open 3 Surdo Open 3 Surdo Open 3 Surdo Open 3 Surdo Open 3 Hi Q Hi Q Hi Q Hi Q Hi Q Hi Q Whip Slap Whip Slap Whip Slap Whip Slap Whip Slap Whip Slap Scratch H 4 Scratch H 4 Scratch H 4 Scratch H 4 Scratch H 4 Scratch H 4 Scratch L 4 Scratch L 4 Scratch L 4 Scratch L 4 Scratch L 4 Scratch L 4 Finger Snap Finger Snap Finger Snap Finger Snap Finger Snap Finger Snap Click Noise Click Noise Click Noise Click Noise Click Noise Click Noise Metronome Click Metronome Click Metronome Click Metronome Click Metronome Click Metronome Click Metronome Bell Metronome Bell Metronome Bell Metronome Bell Metronome Bell Metronome Bell Seq Click L Seq Click L Seq Click L Seq Click L Seq Click L Seq Click L Seq Click H Seq Click H Seq Click H Seq Click H Seq Click H Seq Click H Brush Tap Brush Tap Br ush Tap Brush Tap Brush Tap Br ush Tap Brush Swirl on Brush Swirl on Brush Swirl on Brush Swirl on Brush Swirl on Brush Swirl on Brush Slap Br ush Slap Brush Slap Brush Slap Brush Slap Brush Slap Brush Tap Swirl on Brush Tap Swirl on Brush Tap Swirl on Brush Tap Swirl on Br ush Tap Swirl on Br ush Tap Swirl on Snare Roll Rock on Snare Roll Rock on Snare Roll Rock on Snare Roll Rock on Snare Roll Rock on Snare Roll Rock on Hat 1/4-1/2 Heavy Sw 1

Hat 1/4-1/2 Brilliant Sw

1 Hat 1/4-1/2 Heavy Sw 1 Hat 1/4-1/2 Heavy Sw 1 Hat 1/4-1/2 Heavy Sw 1

Hat 1/4-1/2 Brilliant Sw

Snare Brass Piccolo Soft

Snare Loose Snap Soft Snare Loose Snap Soft Snare Loose Snap Soft

Snare Brass Piccolo Soft

Snare Loose Snap Soft Sticks Sticks Sticks Sticks Sticks Sticks Kick 18x22" Maple Dry Sw Kick 18x22" Maple Dry Sw Kick 18x22" Maple Dry Sw Kick 14x22" Maple Dry Sw Kick 14x22" Maple Dr y Sw Kick 14x22" Maple Dry Sw Snare Brass Attack Rim

Snare Brass Rock Rim Snare Brass Rock Rim Snare Brass Rock Rim

Snare Brass Attack Rim

Snare Brass Rock Rim Kick 16x20" Maple Room Sw Kick 16x20" Maple Room Sw Kick 16x20" Maple Room Sw Kick 14x18" Birch Room Sw Kick 14x18" Birch Room Sw Kick 14x18" Birch Room Sw Kick 18x22" Maple Room Sw Kick 18x22" Maple Room Sw Kick 18x22" Maple Room Sw Kick 14x22" Maple Room Sw Kick 14x22" Maple Room Sw Kick 14x22" Maple Room Sw Sidestick Wood Knock Sw Sidestick Metal Knock Sw Sidestick Metal Knock Sw Sidestick Metal Knock Sw Sidestick Wood Knock Sw Sidestick Metal Knock Sw Snare Brass Piccolo Sw

Snare Loose Snap Sw Snare Loose Snap Sw Snare Loose Snap Sw

Snare Brass Piccolo Sw

Snare Loose Snap Sw Hand Clap Hand Clap Hand Clap Hand Clap Hand Clap Hand Clap Snare Brass Attack Sw

on Snare Brass Rock Sw Snare Brass Rock Sw Snare Brass Rock Sw

Snare Brass Attack Sw

on Snare Brass Rock Sw Tom Smooth Lo Floor Tom Smooth Lo Floor Tom Smooth Lo Floor Tom Smooth Lo Floor Tom Smooth Lo Floor Tom Smooth Lo Floor Hat Closed Heavy Sw 1

Hat Closed Brilliant Sw

1 Hat Closed Heavy Sw 1 Hat Closed Heavy Sw 1 Hat Closed Heavy Sw 1

Hat Closed Brilliant Sw

1 Tom Smooth Hi Floor Tom Smooth Hi Floor Tom Smooth Hi Floor Tom Smooth Hi Floor Tom Smooth Hi Floor Tom Smooth Hi Floor Hat Pedal Heavy 1 Hat Pedal Brilliant 1 Hat Pedal Heavy 1 Hat Pedal Heavy 1 Hat Pedal Heavy 1 Hat Pedal Brilliant 1 Tom Smooth Lo Tom Smooth Lo Tom Smooth Lo Tom Smooth Lo Tom Smooth Lo Tom Smooth Lo Hat Open Heavy 1 Hat Open Brilliant 1 Hat Open Heavy 1 Hat Open Heavy 1 Hat Open Heavy 1 Hat Open Brilliant 1 Tom Smooth Lo-Mid Tom Smooth Lo-Mid Tom Smooth Lo-Mid Tom Smooth Lo-Mid Tom Smooth Lo-Mid Tom Smooth Lo-Mid Tom Smooth Hi-Mid Tom Smooth Hi-Mid Tom Smooth Hi-Mid Tom Smooth Hi-Mid Tom Smooth Hi-Mid Tom Smooth Hi-Mid Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin Tom Smooth Hi Tom Smooth Hi Tom Smooth Hi Tom Smooth Hi Tom Smooth Hi Tom Smooth Hi Ride Cymbal 21" Sw Ride Cymbal 21" Sw Ride Cymbal 21" Sw Ride Cymbal 22" Ride Cymbal 22" Ride Cymbal 22" China Cymbal 17" China Cymbal 17" China Cymbal 17" China Cymbal 17" China Cymbal 17" China Cymbal 17" Ride Cymbal Cup 21" Ride Cymbal Cup 21" Ride Cymbal Cup 21" Ride Cymbal Cup 22" Ride Cymbal Cup 22" Ride Cymbal Cup 22" Tambourine Tambourine Tambourine Tambourine Tambourine Tambourine Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" Cowbell Cowbell Cowbell Cowbell Cowbell Cowbell Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" Vibraslap Vibraslap Vibraslap Vibraslap Vibraslap Vibraslap Ride Cymbal 22" R/L Ride Cymbal 22" R/L Ride Cymbal 22" R/L Ride Cymbal 21" R/L Ride Cymbal 21" R/L Ride Cymbal 21" R/L Crash Cymbal

Snare Power Dry Hi Sw Snare Brass Piccolo Sw

Kick Power Dry Hi

Snare Power Dry Hi Sw Snare Brass Piccolo Sw Crash Cymbal Rock1 Snare Power Dry Hi p Snare Brass Piccolo p Kick Power Dry Lo Snare Power Dry Hi p Snare Brass Piccolo p Crash Cymbal 17" Thin

Snare Power Dry Hi mp Snare Brass Piccolo mp

Kick Funk

Snare Power Dry Hi mp Snare Brass Piccolo mp Crash Cymbal 14"

Snare Power Dry Hi mf Snare Brass Piccolo mf

Kick Dry Sw

Snare Power Dry Hi mf Snare Brass Piccolo mf Crash Cymbal R/L Snare Power Dry Hi ff Snare Brass Piccolo ff Kick Dry mf Snare Power Dry Hi ff Snare Brass Piccolo ff Splash Cymbal

Snare Power Dry Lo Sw

Snare Brass Attack Sw

on Kick Dry ff

Snare Power Dry Lo Sw

Snare Brass Attack Sw

on Splash Cymbal 10" Snare Power Dry Lo p Snare Brass Attack p on Kick Funk Hard Sw Snare Power Dry Lo p Snare Brass Attack p on China Cymbal

Snare Power Dry Lo mp

Snare Brass Attack mp

on Kick Funk Hard mf

Snare Power Dry Lo mp

Snare Brass Attack mp

on China Cymbal 17"

Snare Power Dry Lo mf Snare Brass Attack mf

on Kick Funk Hard ff

Snare Power Dry Lo mf Snare Brass Attack mf

on Ride Cymbal Snare Power Dry Lo ff Snare Brass Attack ff on Kick Dry Hi Snare Power Dry Lo ff Snare Brass Attack ff on Ride Cymbal Cup Snare Dry Hi Sw

Snare Loose Snap Sw

Kick Rock1 Snare Dry Hi Sw

Snare Loose Snap Sw

Ride Cymbal 21" Sw

Snare Dry Hi mp-mf Sw

Snare Loose Snap p Kick Rock2

Snare Dry Hi mp-mf Sw

Snare Loose Snap p

Ride Cymbal 21" mp Snare Dry Hi mf-ff Sw

Snare Loose Snap mp

Kick Dry Hi Heavy Snare Dry Hi mf-ff Sw

Snare Loose Snap mp Ride Cymbal 21" mf Snare Dry Hi mp Snare Loose Snap mf Kick Dry Heavy Sw Snare Dry Hi mp Snare Loose Snap mf Ride Cymbal Cup 21" Snare Dry Hi mf Snare Loose Snap ff Kick Dry Heavy mf Snare Dry Hi mf Snare Loose Snap ff Ride Cymbal 22" Snare Dry Hi ff Snare Brass Rock Sw Kick Dry Heavy ff Snare Dr y Hi ff Snare Brass Rock Sw Ride Cymbal Cup 22" Snare Dry Lo Sw Snare Brass Rock p Kick Dry ff Snare Dry Lo Sw Snare Brass Rock p Ride Cymbal R/L Snare Dry Lo p Snare Brass Rock mp Kick Power Dry Lo Snare Dry Lo p Snare Brass Rock mp Ride Cymbal 21" R/L Snare Dry Lo mp Snare Brass Rock mf

Kick 18x22" Maple Dry Sw

Snare Dry Lo mp Snare Brass Rock mf

Ride Cymbal 22" R/L Snare Dry Lo mf Snare Brass Rock ff

Kick18x22" Maple Dry mp

Snare Dry Lo mf Snare Brass Rock ff

Snare Dry Lo ff Snare Rock Open2

Kick18x22" Maple Dry mf

Snare Dry Lo ff Snare Rock Open2

Snare Rock Mute1 Snare Rock Rim2

Kick18x22" Maple Dry ff

Snare Rock Mute1 Snare Rock Rim2

Snare Rock Open1 Brush Tap

Kick 14x22" Maple Dry Sw

Snare Rock Open1 Brush Tap

Snare Rock Rim1 Brush Swirl on

Kick 14x22" Maple Dry mp

Snare Rock Rim1 Brush Swirl on

Snare Rock Open1 Dry

Brush Slap

Kick 14x22" Maple Dry mf

Snare Rock Open1 Dry

Brush Slap

Snare Rock Mute2 Brush Tap Swirl on

Kick 14x22" Maple Dry ff

Snare Rock Mute2 Brush Tap Swirl on

Snare Rock Open2 Snare Roll on

Kick 18x22" Maple Room Sw

Snare Rock Open2 Snare Roll on

Snare Rock Rim2 Snare Roll Hard on

Kick18x22" Maple Room mp

Snare Rock Rim2 Snare Roll Hard on

Sidestick Dry Sidestick Dry

Kick18x22" Maple Room mf

Sidestick Dry Sidestick Dry

Sidestick Rock1 Sidestick Rock1

Kick18x22" Maple Room ff

Sidestick Rock1 Sidestick Rock1

Sidestick Rock2 Sidestick Rock2

Kick 14x22" Maple Room Sw

Sidestick Rock2 Sidestick Rock2

Sidestick Wood Knock Sw Sidestick Wood Knock Sw

Kick 14x22" Maple Room mp

Sidestick Wood Knock Sw Sidestick Wood Knock Sw

Sidestick Wood Knock mp Sidestick Wood Knock mp

Kick 14x22" Maple Room mf

Sidestick Wood Knock mp Sidestick Wood Knock mp

Sidestick Wood Knock mf Sidestick Wood Knock mf

Kick 14x22" Maple Room ff

Sidestick Wood Knock mf Sidestick Wood Knock mf

Sidestick Metal Knock Sw Sidestick Metal Knock Sw

Kick 16x20" Maple Room Sw

Sidestick Metal Knock Sw Sidestick Metal Knock Sw

Sidestick Metal Knock mp Sidestick Metal Knock mp

Kick16x20" Maple Room mp

Sidestick Metal Knock mp Sidestick Metal Knock mp

Sidestick Metal Knock mf Sidestick Metal Knock mf

Kick16x20" Maple Room mf

Sidestick Metal Knock mf Sidestick Metal Knock mf Kick16x20" Maple Room ff Kick 14x18" Birch Room Sw Kick 14x18" Birch Room mp Kick 14x18" Birch Room mf Kick 14x18" Birch Room ff

Tom (from LiveRm A) Hi-hat (from LiveRm A) Snare (from LiveRm B) Kick (from LiveRm A)

Refers to the keys C3 and higher. Percussion sounds are mapped to these keys.

Prc : Percussion Kk : Kicks Sn1 : Snares1 Sn2 : Snares2 Tom : Tom-toms Hat : Hi-Hats Cym : Cymbals

Voice List

DR Instrument Map MSB=79, LSB=0

A : Alternate Group K : Key Off I : Insertion Effect : No sound

* These kits have been created by combining the Kick, Snare, Hi-hat and Tom sounds of the LiveRmA and LiveRmB voices.

Example : A B A A /Prc

Program No.

76 77 78 79 80

Kit Name BBBA/Tom* BAAB/Hat* BBAA/Cym* BABA/Sn1* BAAA/Sn2*

Note#

Note Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I Inst Name A K I

13 C# -1 Surdo Mute 3 Surdo Mute 7 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 14 D -1 Surdo Open 3 Surdo Open 7 Surdo Open 3 Surdo Open 3 Surdo Open 3 15 D# -1 Hi Q Hi Q Hi Q Hi Q Hi Q 16 E -1 Whip Slap Whip Slap Whip Slap Whip Slap Whip Slap 17 F -1 Scratch H 4 Scratch H 8 Scratch H 4 Scratch H 4 Scratch H 4 18 F# -1 Scratch L 4 Scratch L 8 Scratch L 4 Scratch L 4 Scratch L 4 19 G -1 Finger Snap Finger Snap Finger Snap Finger Snap Finger Snap 20 G# -1 Click Noise Click Noise Click Noise Click Noise Click Noise 21 A -1 Metronome Click Metronome Click Metronome Click Metronome Click Metronome Click 22 A# -1 Metronome Bell Metronome Bell Metronome Bell Metronome Bell Metronome Bell 23 B -1 Seq Click L Seq Click L Seq Click L Seq Click L Seq Click L 24 C 0 Seq Click H Seq Click H Seq Click H Seq Click H Seq Click H 25 C# 0 Br ush Tap Brush Tap Brush Tap Brush Tap Brush Tap 26 D 0 Brush Swirl on Brush Swirl on Brush Swirl on Brush Swirl on Brush Swirl on 27 D# 0 Br ush Slap Brush Slap Brush Slap Brush Slap Brush Slap 28 E 0 Brush Tap Swirl on Brush Tap Swirl on Brush Tap Swirl on Brush Tap Swirl on Brush Tap Swirl on 29 F 0 Snare Roll Rock on Snare Roll Rock on Snare Roll Rock on Snare Roll Rock on Snare Roll Rock on 30 F# 0 Hat 1/4-1/2 Heavy Sw 1 Hat 1/4-1/2 Brilliant Sw 1 Hat 1/4-1/2 Brilliant Sw 1 Hat 1/4-1/2 Heavy Sw 1 Hat 1/4-1/2 Brilliant Sw 1 31 G 0 Snare Loose Snap Soft Snare Brass Piccolo Soft Snare Loose Snap Soft Snare Brass Piccolo Soft Snare Brass Piccolo Soft 32 G# 0 Sticks Sticks Sticks Sticks Sticks 33 A 0 Kick 14x22" Maple Dry Sw Kick 14x22" Maple Dr y Sw Kick 14x22" Maple Dry Sw Kick 14x22" Maple Dry Sw Kick 14x22" Maple Dry Sw 34 A# 0 Snare Brass Rock Rim Snare Brass Attack Rim Snare Brass Rock Rim Snare Brass Attack Rim Snare Brass Attack Rim 35 B 0

Kick 14x18" Birch Room Sw Kick 14x18" Birch Room Sw Kick 14x18" Birch Room Sw Kick 14x18" Birch Room Sw Kick 14x18" Birch Room Sw

36 C 1

Kick 14x22" Maple Room Sw Kick 14x22" Maple Room Sw Kick 14x22" Maple Room Sw Kick 14x22" Maple Room Sw Kick 14x22" Maple Room Sw

37 C# 1 Sidestick Metal Knock Sw Sidestick Wood Knock Sw Sidestick Metal Knock Sw Sidestick Wood Knock Sw Sidestick Wood Knock Sw 38 D 1 Snare Loose Snap Sw Snare Brass Piccolo Sw Snare Loose Snap Sw Snare Brass Piccolo Sw Snare Brass Piccolo Sw 39 D# 1 Hand Clap Hand Clap Hand Clap Hand Clap Hand Clap 40 E 1 Snare Brass Rock Sw Snare Brass Attack Sw on Snare Brass Rock Sw Snare Brass Attack Sw on Snare Brass Attack Sw on 41 F 1 Tom Power Lo Floor Tom Smooth Lo Floor Tom Power Lo Floor Tom Power Lo Floor Tom Power Lo Floor 42 F# 1 Hat Closed Heavy Sw 1 Hat Closed Brilliant Sw 1 Hat Closed Brilliant Sw 1 Hat Closed Heavy Sw 1 Hat Closed Brilliant Sw 1 43 G 1 Tom Power Hi Floor Tom Smooth Hi Floor Tom Power Hi Floor Tom Power Hi Floor Tom Power Hi Floor 44 G# 1 Hat Pedal Heavy 1 Hat Pedal Brilliant 1 Hat Pedal Brilliant 1 Hat Pedal Heavy 1 Hat Pedal Brilliant 1 45 A 1 Tom Power Lo Tom Smooth Lo Tom Power Lo Tom Power Lo Tom Power Lo 46 A# 1 Hat Open Heavy 1 Hat Open Brilliant 1 Hat Open Brilliant 1 Hat Open Heavy 1 Hat Open Br illiant 1 47 B 1 Tom Power Lo-Mid Tom Smooth Lo-Mid Tom Power Lo-Mid Tom Power Lo-Mid Tom Power Lo-Mid 48 C 2 Tom Power Hi-Mid Tom Smooth Hi-Mid Tom Power Hi-Mid Tom Power Hi-Mid Tom Power Hi-Mid 49 C# 2 Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin Crash Cymbal 17" Thin 50 D 2 Tom Power Hi Tom Smooth Hi Tom Power Hi Tom Power Hi Tom Power Hi 51 D# 2 Ride Cymbal 22" Ride Cymbal 22" Ride Cymbal 22" Ride Cymbal 22" Ride Cymbal 22" 52 E 2 China Cymbal 17" China Cymbal 17" China Cymbal 17" China Cymbal 17" China Cymbal 17" 53 F 2 Ride Cymbal Cup 22" Ride Cymbal Cup 22" Ride Cymbal Cup 22" Ride Cymbal Cup 22" Ride Cymbal Cup 22" 54 F# 2 Tambourine Tambourine Tambourine Tambourine Tambourine 55 G 2 Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" Splash Cymbal 10" 56 G# 2 Cowbell Cowbell Cowbell Cowbell Cowbell 57 A 2 Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" Crash Cymbal 14" 58 A# 2 Vibraslap Vibraslap Vibraslap Vibraslap Vibraslap 59 B 2 Ride Cymbal 21" R/L Ride Cymbal 21" R/L Ride Cymbal 21" R/L Ride Cymbal 21" R/L Ride Cymbal 21" R/L 60 C 3 Tom Dry1 Lo Floor Hat Closed Power 2 Crash Cymbal Snare Power Dry Hi Sw Snare Brass Piccolo Sw 61 C# 3 Tom Dry1 Hi Floor Hat 1/2 Power 2 Crash Cymbal Rock1 Snare Power Dry Hi p Snare Brass Piccolo p 62 D 3 Tom Dry1 Lo Hat Open Power 2 Crash Cymbal 17" Thin Snare Power Dry Hi mp Snare Brass Piccolo mp 63 D# 3 Tom Dry1 Lo-Mid Hat Closed Dr y Sw 3 Crash Cymbal 14" Snare Power Dry Hi mf Snare Brass Piccolo mf 64 E 3 Tom Dry1 Hi-Mid Hat Closed Dry p 3 Crash Cymbal R/L Snare Power Dry Hi ff Snare Brass Piccolo ff 65 F 3 Tom Dry1 Hi Hat Closed Dry mp 3 Splash Cymbal Snare Power Dry Lo Sw Snare Brass Attack Sw on 66 F

# 3 Tom Dry2 Lo Floor Hat Closed Dry mf 3 Splash Cymbal 10" Snare Power Dry Lo p Snare Brass Attack p on

67 G 3 Tom Dry2 Hi Floor Hat Closed Dry ff 3 China Cymbal Snare Power Dry Lo mp Snare Brass Attack mp on 68 G

# 3 Tom Dry2 Lo Hat Pedal Dry 3 China Cymbal 17" Snare Power Dry Lo mf Snare Brass Attack mf on

69 A 3 Tom Dry2 Lo-Mid Hat Open Dry 3 Ride Cymbal Snare Power Dry Lo ff Snare Brass Attack ff on 70 A

# 3 Tom Dry2 Hi-Mid Hat Closed Rock1 Sw 4 Ride Cymbal Cup Snare Dry Hi Sw Snare Loose Snap Sw

71 B 3 Tom Dry2 Hi

Hat Closed-Pedal Rock1 Sw

4 Ride Cymbal 21" Sw Snare Dry Hi mp-mf Sw Snare Loose Snap p 72 C 4 Tom Rock Lo Floor Hat Open Rock1 Sw 4 Ride Cymbal 21" mp Snare Dry Hi mf-ff Sw Snare Loose Snap mp 73 C

# 4 Tom Rock Hi Floor Hat 1/2 Rock2 4 Ride Cymbal 21" mf Snare Dry Hi mp Snare Loose Snap mf

74 D 4 Tom Rock Lo Hat Closed Brilliant Sw 5 Ride Cymbal Cup 21" Snare Dry Hi mf Snare Loose Snap ff 75 D

# 4 Tom Rock Lo-Mid Hat Closed Brilliant mf 5 Ride Cymbal 22" Snare Dry Hi ff Snare Brass Rock Sw

76 E 4 Tom Rock Hi-Mid Hat Closed Brilliant ff 5 Ride Cymbal Cup 22" Snare Dr y Lo Sw Snare Brass Rock p 77 F 4 Tom Rock Hi Hat Pedal Brilliant 5 Ride Cymbal R/L Snare Dry Lo p Snare Brass Rock mp 78 F

# 4 Tom Power Lo Floor Hat 1/4-1/2 Brilliant Sw 5 Ride Cymbal 21" R/L Snare Dry Lo mp Snare Brass Rock mf

79 G 4 Tom Power Hi Floor Hat 1/4 Brilliant 5 Ride Cymbal 22" R/L Snare Dry Lo mf Snare Brass Rock ff 80 G

# 4 Tom Power Lo Hat 1/2 Brilliant 5 Snare Dry Lo ff Snare Rock Open2

81 A 4 Tom Power Lo-Mid Hat Open Brilliant 5 Snare Rock Mute1 Snare Rock Rim2 82 A

# 4 Tom Power Hi-Mid Hat Closed Heavy Sw 6 Snare Rock Open1 Brush Tap

83 B 4 Tom Power Hi Hat Closed Heavy mf 6 Snare Rock Rim1 Brush Swir l on 84 C 5 Tom Smooth Lo Floor Hat Closed Heavy ff 6 Snare Rock Open1 Dry Brush Slap 85 C# 5 Tom Smooth Hi Floor Hat Pedal Heavy 6 Snare Rock Mute2 Brush Tap Swirl on 86 D 5 Tom Smooth Lo Hat 1/4-1/2 Heavy Sw 6

Snare Rock Open2 Snare Roll on

87 D

# 5 Tom Smooth Lo-Mid Hat 1/4 Heavy 6 Snare Rock Rim2 Snare Roll Hard on

88 E 5 Tom Smooth Hi-Mid Hat 1/2 Heavy 6

Sidestick Dry Sidestick Dry

89 F 5 Tom Smooth Hi Hat Open Heavy 6

Sidestick Rock1 Sidestick Rock1

90 F

# 5 Sidestick Rock2 Sidestick Rock2

91 G 5

Sidestick Wood Knock Sw Sidestick Wood Knock Sw

92 G

# 5 Sidestick Wood Knock mp Sidestick Wood Knock mp

93 A 5

Sidestick Wood Knock mf Sidestick Wood Knock mf

94 A# 5 Sidestick Metal Knock Sw Sidestick Metal Knock Sw 95 B 5

Sidestick Metal Knock mp Sidestick Metal Knock mp 96 C 6 Sidestick Metal Knock mf Sidestick Metal Knock mf 97 C

# 6

98 D 6 99 D# 6

100 E 6 101 F 6

Tom (from LiveRm A) Hi-hat (from LiveRm A) Snare (from LiveRm B) Kick (from LiveRm A)

Refers to the keys C3 and higher. Percussion sounds are mapped to these keys.

Prc : Percussion Kk : Kicks Sn1 : Snares1 Sn2 : Snares2 Tom : Tom-toms Hat : Hi-Hats Cym : Cymbals

Voice List

■ PC Instrument Map

MSB=79, LSB=1

A : Alternate Group K : Key Off I : Insertion Effect : No sound

* The Alternate Group settings have been programmed only for the kits listed below.

Pgm# 4 GMPerc, Pgm#10 GMLtnDr, Pgm#23 DlyGMPrc, Pgm#24 DlyGMltn, Pgm#29 ODGMLtn, Pgm#33 Dst1GMLt, Pgm#37 Dst2GMLtn, Pgm#64 RvbGMPc, Pgm#69 RvbGMLtn

None of the other kits (excepting those above) have Alternate Group settings.

Program No. 1 2 3 4 5 6 7

Kit Name Afro Cubn Brazil MotifLtn GM Perc AfrCbn61 Brazil61 AC-PlgDR

Note#

Note A Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I

13 C# -1 3 14 D -1 3 15 D# -1 16 E -1 17 F -1 18 F# -1 19 G -1 20 G# -1 21 A -1 22 A# -1 23 B -1 24 C 0 SurdoL1 Sw on GMClick 25 C# 0 SurdoL2 Sw on 26 D 0 SurdoLLH Sw 27 D# 0 SurdoLRM 28 E 0 SurdoLRO 29 F 0 SurdoM1 Sw on 30 F# 0 SurdoM2 Sw on 31 G 0 SurdoMLH Sw 32 G# 0 SurdoMRM 33 A 0 SurdoMRO 34 A# 0 SurdoH1 Sw on 35 B 0 SurdoH2 Sw on 36 C 1 TumbaB Sw SurdoHLH Sw TumbaB Sw TumbaB Sw SurdoL1 Sw on 37 C# 1 TumbaT Sw SurdoHRM TumbaT Sw TumbaT Sw SurdoL2 Sw on 38 D 1 TumbaSC Sw SurdoHRO TumbaSC Sw TumbaSC Sw SurdoM1 Sw on 39 D# 1 TumbaM RepiniqueL1 Sw Claves2 Sw TumbaM SurdoM2 Sw on 40 E 1 TumbaO Sw RepiniqueL2 Sw TumbaO Sw TumbaO Sw SurdoH1 Sw on 41 F 1 CongaB Sw RepiniqueL3 Sw CongaB Sw CongaB Sw SurdoH2 Sw on 42 F# 1 CongaT Sw RepiniqueL4 Sw CongaT Sw CongaT Sw RepiniqueL1 Sw 43 G 1 CongaOS Sw RepiniqueL5 Sw CongaOS Sw CongaOS Sw RepiniqueL2 Sw 44 G# 1 CongaM RepiniqueL6 Sw HandBellMO Sw CongaM RepiniqueL3 Sw 45 A 1 CongaO Sw RepiniqueL7 on CongaO Sw CongaO Sw RepiniqueL4 Sw 46 A# 1 CongaStick RepiniqueL8 on HandBellSM Sw CongaStick RepiniqueL5 Sw 47 B 1 QuintoR Sw RepiniqueL9 on MamboBell Sw QuintoR Sw RepiniqueL6 Sw 48 C 2 QuintoB RepiniqueH1 Sw QuintoB QuintoB RepiniqueL10 on 49 C# 2 QuintoT RepiniqueH2 Sw QuintoT QuintoT RepiniqueH1 Sw 50 D 2 QuintoS Sw RepiniqueH3 Sw QuintoS Sw QuintoS Sw RepiniqueH2 Sw 51 D# 2 QuintoM RepiniqueH4 Sw ChaChaBell Sw QuintoM RepiniqueH3 Sw 52 E 2 QuintoO Sw RepiniqueH5 Sw QuintoO Sw QuintoO Sw RepiniqueH4 Sw 53 F 2 BongoL Sw RepiniqueH6 Sw BongoL Sw BongoL Sw RepiniqueH5 Sw 54 F# 2 BongoH1 Sw Pandeiro1 Sw BongoH1 Sw BongoH1 Sw RepiniqueH6 Sw 55 G 2 BongoH2 Sw Pandeiro2 Sw BongoH2 Sw BongoH2 Sw Pandeiro1 Sw 56 G# 2 TimbaleL1 Sw Pandeiro3 Sw TimbaleL3 GMCowbell TimbaleL1 Sw Pandeiro2 Sw 57 A 2 TimbaleLE Pandeiro4 Sw PailaL Sw TimbaleLE Pandeiro3 Sw 58 A# 2 TimbaleL2 Sw Pandeiro5 Sw on TimbaleH3 TimbaleL2 Sw Pandeiro4 Sw 59 B 2 TimbaleLM Pandeiro6 on PailaH Sw TimbaleLM Pandeiro5 Sw 60 C 3 PailaL Sw Pandeiro7 on

WoodBlockLarge Sw

GMBongoH PailaL Sw Caixa5 TumbaB Sw

61 C# 3 TimbaleH1 Sw Caixa1 Sw

WoodBlockSmall Sw

GMBongoL TimbaleH1 Sw Caixa2 Sw TumbaT Sw

62 D 3 PailaH Sw Caixa2 Sw ChekereS1 Sw

GMCongaHMute

PailaH Sw Caixa4 Sw TumbaSC Sw

63 D# 3 TimbaleH2 Sw Caixa3 Sw ChekereS3 Sw

GMCongaHOpen

TimbaleH2 Sw TamborimT Sw TumbaM 64 E 3 TimbaleHR Sw Caixa4 Sw ChekereST GMCongaL TimbaleHR Sw Tamborim1 Sw TumbaO Sw 65 F 3 TimbaleHE Sw TamborimT Sw Maracas1 Sw GMTimbaleH TimbaleHE Sw Tamborim2 Sw CongaB Sw 66 F

# 3 TimbaleF1 Tamborim1 Sw Maracas2 Sw GMTimbaleL TimbaleF1 Tamborim3 Sw CongaT Sw

67 G 3 TimbaleF2 Tamborim2 Sw Guiro1 Sw on GMAgogoH Guira1 on Tamborim4 Sw CongaOS Sw 68 G

# 3 TimbaleF3 Tamborim3 Sw Guiro3 Sw GMAgogoL Guira2 on Tamborim5 Sw CongaM

69 A 3 TimbaleF4 Tamborim4 Sw Guiro4 Sw GMCabassa on Guira5 on Tamborim6 Sw CongaO Sw 70 A

# 3 HandBellMO Sw Tamborim5 Sw SurdoL2 Sw on GMMaracas HandBellMO Sw Agogo1 Sw

WoodBlockLarge Sw

71 B 3 HandBellMM Sw Tamborim6 Sw SurdoL1 Sw on GMWhistleH on HandBellMM Sw Agogo2 Sw

WoodBlockSmall Sw

72 C 4 HandBellSO Sw Agogo1 Sw Pandeiro3 Sw GMWhistleL on HandBellSO Sw Agogo3 Sw QuintoB 73 C# 4 HandBellSM Sw Agogo2 Sw Pandeiro2 Sw GMGuiroShort HandBellSM Sw FunkBell1 QuintoT 74 D 4 HandBellC Sw Agogo3 Sw Pandeiro4 Sw GMGuiroLong on HandBellC Sw FunkBell2 QuintoS Sw 75 D

# 4 MamboBell Sw FunkBell1 Pandeiro1 Sw GMClaves MamboBell Sw

WoodBlockLarge Sw

QuintoM

76 E 4 ChaChaBell Sw FunkBell2 TamborimT Sw

GMWoodBlockH

ChaChaBell Sw

WoodBlockSmall Sw

QuintoO Sw

77 F 4 SongoBellH Sw

WoodBlockLarge Sw

Tamborim2 Sw GMWoodBlockL SongoBellH Sw TriangleL1 Sw on BongoL Sw

78 F# 4 SongoBellL Sw

WoodBlockSmall Sw

Tamborim1 Sw GMCuicaMute on SongoBellL Sw TriangleL2 Sw BongoH1 Sw 79 G 4 FunkBell1 TriangleL1 Sw on Agogo1 Sw GMCuicaOpen on FunkBell1 TriangleS1 Sw on BongoH2 Sw 80 G

# 4 2 FunkBell2 TriangleL2 Sw Agogo2 Sw

GMTriangleMute

FunkBell2 TriangleS2 Sw TimbaleL3

81 A 4 2

WoodBlockLarge Sw

TriangleS1 Sw on Agogo3 Sw

GMTriangleOpen WoodBlockLarge Sw

Shaker1 Sw TimbaleH3

82 A

# 4

WoodBlockSmall Sw

TriangleS2 Sw TriangleS1 Sw on GMShaker

WoodBlockSmall Sw

Shaker2 Sw PailaL Sw 83 B 4 ChekereS1 Sw Shaker1 Sw TriangleS2 Sw ChekereS1 Sw Shaker3 Sw PailaH Sw 84 C 5 ChekereS2 Sw Shaker2 Sw Shaker1 Sw ChekereS2 Sw CabassaL1 Sw on HandBellMO Sw 85 C# 5 ChekereS3 Sw Shaker3 Sw Shaker2 Sw ChekereS3 Sw CabassaL2 Sw on HandBellSM Sw 86 D 5 ChekereST CabassaL1 Sw on Shaker3 Sw

ChekereST CabassaL3 Sw on MamboBell Sw

87 D

# 5 ChekereL CabassaL2 Sw on CabassaL1 Sw on ChekereL CaxixiL1 Sw ChaChaBell Sw

88 E 5 ChekereLT CabassaL3 Sw on CabassaL3 Sw on

ChekereLT CaxixiL2 Sw SongoBellH Sw

89 F 5 Maracas1 Sw CabassaL4 on CaxixiS2 Sw

Maracas1 Sw CaxixiL3 Sw SongoBellL Sw

90 F

# 5 Maracas2 Sw CabassaL5 on CaxixiL1 Sw Maracas2 Sw CaxixiS1 Sw Maracas1 Sw

91 G 5 Guiro1 Sw on CaxixiL1 Sw Cuica3

Guiro1 Sw on CaxixiS2 Sw Maracas2 Sw

92 G

# 5 Guiro2 Sw on CaxixiL2 Sw Cuica6 Guiro2 Sw on Cuica3 on Guiro1 Sw on

93 A 5 Guiro3 Sw CaxixiL3 Sw Whistle3 on

Guiro3 Sw Cuica6 on Guiro2 Sw on

94 A# 5 Guiro4 Sw CaxixiS1 Sw Whistle7 on Guiro4 Sw Whistle1 Guiro3 Sw 95 B 5 Claves1 Sw CaxixiS2 Sw

Claves1 Sw Whistle2 Guiro4 Sw 96 C 6 Claves2 Sw Cuica1 on Claves2 Sw Whistle3 on Claves2 Sw 97 C

# 6 Guira1 on Cuica2 on

98 D 6 Guira2 on Cuica3 on 99 D# 6 Guira3 Cuica4 on

100 E 6 Guira4 Cuica5 on 101 F 6 Cuica6 on 102 F# 6 Cuica7 on 103 G 6 Whistle1 104 G# 6 Whistle2 105 A 6 Whistle3 on 106 A# 6 Whistle4 on 107 B 6 Whistle5 on 108 C 7 Whistle6 on

Voice List

PC Instrument Map MSB=79, LSB=1

A : Alternate Group K : Key Off I : Insertion Effect : No sound

* The Alternate Group settings have been programmed only for the kits listed below.

Pgm# 4 GMPerc, Pgm#10 GMLtnDr, Pgm#23 DlyGMPrc, Pgm#24 DlyGMltn, Pgm#29 ODGMLtn, Pgm#33 Dst1GMLt, Pgm#37 Dst2GMLtn, Pgm#64 RvbGMPc, Pgm#69 RvbGMLtn

None of the other kits (excepting those above) have Alternate Group settings.

Program No. 8 9 10 11 12 13 14

Kit Name Br-PlgDR Lt-PlgDR GMLtnDrm Live Pop Kick&Snr AfCbHand BrzlHnd1

Note#

Note A Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I

13 C# -1 3 GMSurdo1 on 14 D -1 3 GMSurdo2 on 15 D# -1 GMCuica1 on 16 E -1 GMTamborim1 17 F -1 GMCuica2 on 18 F# -1 GMCuica3 on 19 G -1 GMCabassa1 on 20 G# -1 GMTamborim2 21 A -1 GMCaixa1 22 A# -1 GMCaixa2 CongaT Sw 23 B -1 GMClaves1 CongaB Sw 24 C 0 GMClaves2 CongaO Sw 25 C# 0 GMShaker1 CongaM 26 D 0 GMShaker2 CongaOS2 Sw 27 D# 0 GMShaker3 CongaOS3 28 E 0 GMShaker4 QuintoS Sw 29 F 0 GMRepinique1 on TumbaT Sw 30 F# 0 GMClaves3 TumbaB Sw 31 G 0 GMCaixa3 TumbaO Sw 32 G# 0 GMCaixa4 TumbaM 33 A 0 GMSurdo3 on TumbaSC2 Sw 34 A# 0 GMCaixa5 TumbaSC3 35 B 0 GMSurdo4 on 36 C 1 GMSurdo5 on BongoH3 MenuSurdoL1 on

MenuHandBellMO1

MenuPandeiro1

37 C# 1 GMRepinique2 BongoH4 MenuSurdoL2 on

MenuHandBellMO2

MenuPandeiro2

38 D 1 GMCaixa6 BongoH5 MenuSurdoL3 on

MenuHandBellMM1

MenuPandeiro3

39 D# 1 GMRepinique3 on BongoH6 MenuSurdoL4 on

MenuHandBellMM2

MenuPandeiro4 40 E 1 GMCaixa7 BongoH7 MenuSurdoLLH1 MenuHandBellSO1 MenuPandeiro5 41 F 1 GMSurdo6 on BongoH8 MenuSurdoLLH2 MenuHandBellSO2 MenuPandeiro6 42 F# 1 GMAgogo1 BongoL2 MenuSurdoLRM MenuHandBellSM1 MenuPandeiro7 43 G 1 GMSurdo7 on BongoL3 MenuSurdoLRO MenuHandBellSM2 MenuPandeiro8 44 G# 1 GMAgogo2 BongoL4 MenuSurdoM1 on MenuHandBellSM3 MenuPandeiro9 45 A 1 GMSurdo8 on BongoH9 MenuSurdoM2 on MenuHandBellC1 MenuPandeiro10 46 A# 1 GMAgogo3 BongoH10 MenuSurdoM3 on MenuHandBellC2 MenuPandeiro11 47 B 1 GMSurdo9 on BongoL5 MenuSurdoM4 on MenuMamboBell1 MenuPandeiro12 48 C 2 GMSurdo10 on TimbaleL1 Sw

MenuSurdoMLH1

MenuMamboBell2 MenuPandeiro13 on

49 C# 2 GMTriangle1 on TimbaleLM

MenuSurdoMLH2

MenuMamboBell3 MenuPandeiro14 on

50 D 2 GMSurdo11 on TimbaleL2 Sw MenuSurdoMRM

MenuChaChaBellL1

MenuPandeiro15 on 51 D# 2 GMMamboBell TimbaleLE MenuSurdoMRO

MenuChaChaBellL2

MenuPandeiro16 on 52 E 2 GMSongoBell1 TimbaleF5 MenuSurdoH1 on MenuSongoBellH1 MenuPandeiro17 on 53 F 2 GMHandBell1 PailaL Sw MenuSurdoH2 on MenuSongoBellH2 MenuTamborimT1 54 F# 2 GMPandeiro TimbaleH4 Sw MenuSurdoH3 on MenuSongoBellL1 MenuTamborimT2 55 G 2 GMHandBell2 TimbaleLM MenuSurdoH4 on MenuSongoBellL2 MenuTamborim1 56 G# 2 GMFunkBell TimbaleHR Sw

MenuSurdoHLH1

MenuFunkBell1 MenuTamborim2

57 A 2 GMTriangle2 on TimbaleLE

MenuSurdoHLH2

MenuFunkBell2 MenuTamborim3

58 A# 2 GMRepinique4 on TimbaleF2 MenuSurdoHRM MenuWdBlkLarge1 MenuTamborim4 59 B 2 GMSongoBell2 PailaH Sw MenuSurdoHRO MenuWdBlkLarge2 MenuTamborim5 60 C 3 SurdoL1 Sw on SurdoL1 Sw on GMBongo1 HandBellMO Sw MenuCaixa1 MenuWdBlkSmall1 MenuTamborim6 61 C# 3 SurdoL2 Sw on SurdoL2 Sw on GMBongo2 MamboBell Sw MenuCaixa2 MenuWdBlkSmall2 MenuTamborim7 62 D 3 RepiniqueH1 Sw TriangleS1 Sw on GMConga1

WoodBlockSmall Sw

MenuCaixa3 MenuChekereS1 MenuTamborim8

63 D# 3 RepiniqueH2 Sw TriangleS2 Sw GMConga2

WoodBlockLarge Sw

MenuCaixa4 MenuChekereS2 MenuTamborim9 64 E 3 RepiniqueH3 Sw TumbaO Sw GMTumba Guiro3 Sw MenuCaixa5 MenuChekereS3 MenuTamborim10 65 F 3 RepiniqueH4 Sw CongaB Sw GMTimbale1 Guiro1 Sw on MenuCaixa6 MenuChekereS4 MenuTamborim11 66 F

# 3 RepiniqueH5 Sw CongaT Sw GMTimbale2 Claves2 Sw MenuCaixa7 MenuChekereS5 MenuTamborim12

67 G 3 RepiniqueH6 Sw CongaOS Sw GMAgogo4

MenuCaixa8 MenuChekereS6 MenuTamborim13 68 G# 3 RepiniqueL10 on Claves2 Sw GMAgogo5 MenuCaixa9 MenuChekereST MenuAgogo1 69 A 3 Pandeiro1 Sw CongaO Sw GMCabassa2 on MenuCaixa10 MenuChekereL MenuAgogo2 70 A# 3 Pandeiro2 Sw

WoodBlockLarge Sw

GMMaracas MenuCaixa11 MenuChekereLT MenuAgogo3

71 B 3 Pandeiro3 Sw

WoodBlockSmall Sw

GMWhistle1 on MenuCaixa12 MenuMaracas1 MenuAgogo4

72 C 4 Pandeiro4 Sw BongoL Sw GMWhistle2 on Maracas4 Sw

MenuMaracas2 MenuAgogo5

73 C# 4 Caixa5 BongoH1 Sw GMGuiro1 Shaker9 Sw MenuMaracas3 MenuAgogo6 74 D 4 Caixa2 Sw BongoH2 Sw GMGuiro2 on CabassaL1 Sw on MenuMaracas4 MenuAgogo7 75 D# 4 TamborimT Sw TamborimT Sw GMClaves4 Cuica2 on MenuGuiro1 on MenuAgogo8 76 E 4 Tamborim1 Sw Tamborim1 Sw

GMWoodBlock1

Cuica5 on MenuGuiro2 on MenuAgogo9

77 F 4 Tamborim2 Sw Tamborim2 Sw

GMWoodBlock2

Agogo3 Sw MenuGuiro3 on MenuFunkBell1

78 F# 4 Agogo1 Sw Agogo1 Sw GMCuica4 on Agogo1 Sw MenuGuiro4 on MenuFunkBell2 79 G 4 Agogo2 Sw Agogo2 Sw GMCuica5 on Agogo2 Sw MenuGuiro5

MenuWdBlkLarge1

80 G# 4 2 Agogo3 Sw Agogo3 Sw GMTriangle3 Agogo1 Sw MenuGuiro6

MenuWdBlkLarge2

81 A 4 2

WoodBlockLarge Sw

TimbaleL3 GMTriangle4 TriangleS2 Sw MenuGuiro7

MenuWdBlkSmall1

82 A# 4

WoodBlockSmall Sw

TimbaleH3 GMShaker5 TriangleS1 Sw on MenuGuiro8

MenuWdBlkSmall2 83 B 4 TriangleL1 Sw on PailaL Sw GMCaxixi on MenuGuira1 on 84 C 5 TriangleL2 Sw PailaH Sw GMCabassa3 on MenuGuira2 on 85 C# 5 TriangleS1 Sw on HandBellMO Sw MenuGuira3 86 D 5 TriangleS2 Sw HandBellSM Sw MenuGuira4 87 D# 5 Shaker1 Sw MamboBell Sw MenuClaves1 88 E 5 Shaker2 Sw Shaker1 Sw MenuClaves2 89 F 5 Shaker3 Sw Shaker2 Sw MenuClaves3 90 F# 5 CaxixiL1 Sw Shaker3 Sw MenuClaves4 91 G 5 CaxixiL3 Sw Maracas1 Sw 92 G# 5 Cuica3 on Maracas2 Sw 93 A 5 Cuica6 on Guiro1 Sw on 94 A# 5 Whistle1 Guiro2 Sw on 95 B 5 Whistle2 Guiro3 Sw 96 C 6 Whistle3 on Guiro4 Sw 97 C# 6 98 D 6 99 D# 6

100 E 6 101 F 6 102 F# 6 103 G 6 104 G# 6 105 A 6 106 A# 6 107 B 6 108 C 7

Voice List

A : Alternate Group K : Key Off I : Insertion Effect : No sound

* The Alternate Group settings have been programmed only for the kits listed below.

Pgm# 4 GMPerc, Pgm#10 GMLtnDr, Pgm#23 DlyGMPrc, Pgm#24 DlyGMltn, Pgm#29 ODGMLtn, Pgm#33 Dst1GMLt, Pgm#37 Dst2GMLtn, Pgm#64 RvbGMPc, Pgm#69 RvbGMLtn

None of the other kits (excepting those above) have Alternate Group settings.

15 16 17 18 19 20 21 22

BrzlHnd2 Bells Shakers Skins Sticks1 Sticks2 DlyAfrCb DlyBrazl

Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I

Dly SurdoL1 Sw on Dly SurdoL2 Sw on Dly SurdoLLH Sw Dly SurdoLRM Dly SurdoLRO Dly SurdoM1 Sw on Dly SurdoM2 Sw on Dly SurdoMLH Sw Dly SurdoMRM Dly SurdoMRO Dly SurdoH1 Sw on Dly SurdoH2 Sw on

MenuTriangleL1 on

MenuHandBellMO1

MenuShaker1

MenuTumbaB1

MenuSurdoL1 on

MenuTimbaleL1

Dly TumbaB Sw Dly SurdoHLH Sw

MenuTriangleL2 on

MenuHandBellMO2

MenuShaker2

MenuTumbaB2

MenuSurdoL2 on

MenuTimbaleL2

Dly TumbaT Sw Dly SurdoHRM

MenuTriangleL3 on

MenuHandBellMM1

MenuShaker3 MenuTumbaT1 MenuSurdoL3 on

MenuTimbaleL3

Dly TumbaSC Sw Dly SurdoHRO

MenuTriangleL4

MenuHandBellMM2

MenuShaker4 MenuTumbaT2 MenuSurdoL4 on

MenuTimbaleL4

Dly TumbaM Dly RepiniqueL1 Sw

MenuTriangleL5

MenuHandBellSO1

MenuShaker5

MenuTumbaSC1

MenuSurdoLLH1

MenuTimbaleLE

Dly TumbaO Sw Dly RepiniqueL2 Sw

MenuTriangleL6

MenuHandBellSO2

MenuShaker6

MenuTumbaSC2

MenuSurdoLLH2

MenuTimbaleLM

Dly CongaB Sw Dly RepiniqueL3 Sw

MenuTriangleS1

MenuHandBellSM1

MenuShaker7

MenuTumbaSC3

MenuSurdoLRM

MenuTimbaleH1

Dly CongaT Sw Dly RepiniqueL4 Sw

MenuTriangleS2

MenuHandBellSM2

MenuShaker8 MenuTumbaM MenuSurdoLRO

MenuTimbaleH2

Dly CongaOS Sw Dly RepiniqueL5 Sw

MenuTriangleS3

MenuHandBellSM3

MenuShaker9

MenuTumbaO1

MenuSurdoM1 on

MenuTimbaleH3

Dly CongaM Dly RepiniqueL6 Sw

MenuTriangleS4 MenuHandBellC1

MenuShaker10

MenuTumbaO2

MenuSurdoM2 on

MenuTimbaleH4

Dly CongaO Sw Dly RepiniqueL7 on

MenuTriangleS5 MenuHandBellC2

MenuShaker11

MenuTumbaO3

MenuSurdoM3 on

MenuTimbaleHR1

Dly CongaStick Dly RepiniqueL8 on

MenuTriangleS6 MenuMamboBell1

MenuShaker12 MenuCongaB1 MenuSurdoM4 on

MenuTimbaleHR2

Dly QuintoR Sw Dly RepiniqueL9 on

MenuShaker1

MenuMamboBell2

MenuCabassaL1

on MenuCongaB2

MenuSurdoMLH1

MenuTimbaleHE1

Dly QuintoB Dly RepiniqueH1 Sw

MenuShaker2

MenuMamboBell3

MenuCabassaL2

on MenuCongaT1

MenuSurdoMLH2

MenuTimbaleHE2

Dly QuintoT Dly RepiniqueH2 Sw

MenuShaker3

MenuChaChaBellL1

MenuCabassaL3

on MenuCongaT2 MenuSurdoMRM MenuPailaL1 Dly QuintoS Sw Dly RepiniqueH3 Sw

MenuShaker4

MenuChaChaBellL2

MenuCabassaL4

MenuCongaOS1

MenuSurdoMRO MenuPailaL2 Dly QuintoM Dly RepiniqueH4 Sw

MenuShaker5

MenuSongoBellH1 MenuCabassaL5

MenuCongaOS2

MenuSurdoH1 on MenuPailaH1 Dly QuintoO Sw Dly RepiniqueH5 Sw

MenuShaker7

MenuSongoBellH2 MenuCabassaL6

MenuCongaOS3

MenuSurdoH2 on MenuPailaH2 Dly BongoL Sw Dly RepiniqueH6 Sw

MenuShaker6

MenuSongoBellL1

MenuCabassaL7

on MenuCongaM MenuSurdoH3 on

MenuTimbaleF1

Dly BongoH1 Sw Dly Pandeiro1 Sw

MenuShaker8

MenuSongoBellL2

MenuCabassaL8

MenuCongaO1

MenuSurdoH4 on

MenuTimbaleF2

Dly BongoH2 Sw Dly Pandeiro2 Sw

MenuShaker9 MenuFunkBell1

MenuCabassaL9

MenuCongaO2 MenuSurdoHLH1 MenuTimbaleF3

Dly TimbaleL1 Sw Dly Pandeiro3 Sw

MenuShaker10 MenuFunkBell2

MenuCabassaL10onMenuCongaO3 MenuSurdoHLH2 MenuTimbaleF4

Dly TimbaleLE Dly Pandeiro4 Sw

MenuShaker11 MenuAgogo3 MenuCaxixiL1

MenuCongaStick

MenuSurdoHRM

MenuTimbaleF5

Dly TimbaleL2 Sw Dly Pandeiro5 Sw on

MenuShaker12 MenuAgogo1 MenuCaxixiL2

MenuQuintoR1

MenuSurdoHRO

MenuTimbaleF6

Dly TimbaleLM Dly Pandeiro6 on

MenuCabassaL1

on MenuAgogo2 MenuCaxixiL3

MenuQuintoR2

MenuRepiniqueL1

MenuCaixa1 Dly PailaL Sw Dly Pandeiro7 on

MenuCabassaL2

on MenuAgogo4 MenuCaxixiL4 MenuQuintoB

MenuRepiniqueL2

MenuCaixa2 Dly TimbaleH1 Sw Dly Caixa1 Sw

MenuCabassaL3

on MenuAgogo5 MenuCaxixiL5 MenuQuintoT

MenuRepiniqueL3

MenuCaixa3 Dly PailaH Sw Dly Caixa2 Sw

MenuCabassaL4

on MenuAgogo6 MenuCaxixiL6 MenuQuintoS1

MenuRepiniqueL4

MenuCaixa4 Dly TimbaleH2 Sw Dly Caixa3 Sw

MenuCabassaL5

on MenuAgogo7 MenuCaxixiS1 MenuQuintoS2

MenuRepiniqueL5

MenuCaixa5 Dly TimbaleHR Sw Dly Caixa4 Sw

MenuCabassaL6

on MenuAgogo8 MenuCaxixiS2 MenuQuintoM

MenuRepiniqueL6

MenuCaixa6 Dly TimbaleHE Sw Dly TamborimT Sw

MenuCabassaL7

on MenuAgogo9 MenuCaxixiS3

MenuQuintoO1

MenuRepiniqueL7

MenuCaixa7 Dly TimbaleF1 Dly Tamborim1 Sw

MenuCabassaL8

on MenuCaxixiS4

MenuQuintoO2

MenuRepiniqueL8

MenuCaixa8 Dly TimbaleF2 Dly Tamborim2 Sw

MenuCabassaL9

MenuChekereS1

MenuBongoL1

MenuRepiniqueL9

MenuCaixa9 Dly TimbaleF3 Dly Tamborim3 Sw

MenuCabassaL10

MenuChekereS2

MenuBongoL2

MenuRepiniqueL10

MenuCaixa10 Dly TimbaleF4 Dly Tamborim4 Sw

MenuCaxixiL1

MenuChekereS3

MenuBongoL3

MenuRepiniqueL11

MenuCaixa11 Dly HandBellMO Sw Dly Tamborim5 Sw

MenuCaxixiL2

MenuChekereS4

MenuBongoH1

MenuRepiniqueL12

MenuCaixa12 Dly HandBellMM Sw Dly Tamborim6 Sw

MenuCaxixiL3

MenuChekereS5

MenuBongoH2

MenuRepiniqueL13

on Dly HandBellSO Sw Dly Agogo1 Sw

MenuCaxixiL4

MenuChekereS6

MenuBongoH3

MenuRepiniqueL14

on Dly HandBellSM Sw Dly Agogo2 Sw

MenuCaxixiL5

MenuChekereST

MenuBongoH4

MenuRepiniqueL15

on Dly HandBellC Sw Dly Agogo3 Sw

MenuCaxixiL6

MenuChekereL

MenuBongoH5

MenuRepiniqueH1

Dly MamboBell Sw Dly FunkBell1

MenuCaxixiS1

MenuChekereLT

MenuBongoH6

MenuRepiniqueH2

Dly ChaChaBell Sw Dly FunkBell2

MenuCaxixiS2

MenuMaracas1

MenuRepiniqueH3

Dly SongoBellH Sw

Dly WoodBlockLarge Sw

MenuCaxixiS3 MenuMaracas2

MenuRepiniqueH4

Dly SongoBellL Sw

Dly WoodBlockSmall Sw

MenuCaxixiS4 MenuMaracas3

MenuRepiniqueH5

Dly FunkBell1 Dly TriangleL1 Sw on

MenuCuica1 on MenuMaracas4

MenuRepiniqueH6

Dly FunkBell2 Dly TriangleL2 Sw

MenuCuica2 on

MenuRepiniqueH7

Dly WoodBlockLarge Sw

Dly TriangleS1 Sw on

MenuCuica3 on

MenuRepiniqueH8

Dly WoodBlockSmall Sw

Dly TriangleS2 Sw

MenuCuica4 on

MenuRepiniqueH9

Dly ChekereS1 Sw Dly Shaker1 Sw

MenuCuica5 on

MenuRepiniqueH10

Dly ChekereS2 Sw Dly Shaker2 Sw

MenuCuica6 on

MenuRepiniqueH11

Dly ChekereS3 Sw Dly Shaker3 Sw

MenuCuica7 on

MenuRepiniqueH12

Dly ChekereST Dly CabassaL1 Sw on

MenuWhistle1

Dly ChekereL Dly CabassaL2 Sw on

MenuWhistle2

Dly ChekereLT Dly CabassaL3 Sw on

MenuWhistle3

Dly Maracas1 Sw Dly CabassaL4 on

MenuWhistle4 on

Dly Maracas2 Sw Dly CabassaL5 on

MenuWhistle5 on

Dly Guiro1 Sw on Dly CaxixiL1 Sw

MenuWhistle6 on

Dly Guiro2 Sw on Dly CaxixiL2 Sw

MenuWhistle7 on

Dly Guiro3 Sw Dly CaxixiL3 Sw MenuWhistle8 on Dly Guiro4 Sw Dly CaxixiS1 Sw MenuWhistle9 on

Dly Claves1 Sw Dly CaxixiS2 Sw MenuWhistle10 on Dly Claves2 Sw Dly Cuica1 on

Dly Guira1 on Dly Cuica2 on

Dly Guira2 on Dly Cuica3 on

Dly Guira3 Dly Cuica4 on

Dly Guira4 Dly Cuica5 on

Dly Cuica6 on Dly Cuica7 on Dly Whistle1 Dly Whistle2 on Dly Whistle3 on Dly Whistle4 on Dly Whistle5 on Dly Whistle6 on

Voice List

PC Instrument Map MSB=79, LSB=1

A : Alternate Group K : Key Off I : Insertion Effect : No sound

* The Alternate Group settings have been programmed only for the kits listed below.

Pgm# 4 GMPerc, Pgm#10 GMLtnDr, Pgm#23 DlyGMPrc, Pgm#24 DlyGMltn, Pgm#29 ODGMLtn, Pgm#33 Dst1GMLt, Pgm#37 Dst2GMLtn, Pgm#64 RvbGMPc, Pgm#69 RvbGMLtn

None of the other kits (excepting those above) have Alternate Group settings.

Program No. 23 24 25 26 27 28 29

Kit Name DlyGMPrc DlyGMLtn NsDAfrCb NsDBrazl ODAfrCbn ODBrazil ODGMLtn

Note#

Note A Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I

13 C# -1 3 Dly GMSurdo1 on OvrDrv GMSurdo1 on on 14 D -1 3 Dly GMSurdo2 on OvrDrv GMSurdo2 on on 15 D# -1 Dly GMCuica1 on OvrDrv GMCuica1 on on 16 E -1

Dly GMTamborim1 OvrDrv GMTamborim1

17 F -1 Dly GMCuica2 on OvrDrv GMCuica2 on on 18 F# -1 Dly GMCuica3 on OvrDrv GMCuica3 on on 19 G -1

Dly GMCabassa1

OvrDrv GMCabassa1

on on

20 G# -1

Dly GMTamborim2 OvrDrv GMTamborim2

21 A -1 Dly GMCaixa1 OvrDrv GMCaixa1 on 22 A# -1 Dly GMCaixa2 OvrDrv GMCaixa2 on 23 B -1 Dly GMClaves1 OvrDrv GMClaves1 on 24 C 0 Dly GMClick Dly GMClaves2

NoisDly SurdoL1 Sw

on on OvrDrv SurdoL1 Sw on on OvrDrv GMClaves2 on

25 C# 0 Dly GMShaker1

NoisDly SurdoL2 Sw

on on OvrDrv SurdoL2 Sw on on

OvrDrv GMShaker1

26 D 0 Dly GMShaker2

NoisDly SurdoLLH Sw

OvrDrv SurdoLLH SwonOvrDrv GMShaker2

27 D# 0 Dly GMShaker3 NoisDly SurdoLRM on OvrDrv SurdoLRM on

OvrDrv GMShaker3

28 E 0 Dly GMShaker4 NoisDly SurdoLRO on OvrDrv SurdoLRO on

OvrDrv GMShaker4

29 F 0

Dly GMRepinique1

NoisDly SurdoM1 Sw

on on

OvrDrv SurdoM1 Sw

on on

OvrDrv GMRepinique1

on on

30 F# 0 Dly GMClaves3

NoisDly SurdoM2 Sw

on on

OvrDrv SurdoM2 Sw

on on OvrDrv GMClaves3 on

31 G 0 Dly GMCaixa3

NoisDly SurdoMLH Sw

OvrDrv SurdoMLH Sw

on OvrDrv GMCaixa3 on

32 G# 0 Dly GMCaixa4 NoisDly SurdoMRM on OvrDr v SurdoMRM on OvrDr v GMCaixa4 on 33 A 0 Dly GMSurdo3 on NoisDly SurdoMRO on OvrDrv SurdoMRO on OvrDr v GMSurdo3 on on 34 A# 0 Dly GMCaixa5

NoisDly SurdoH1 Sw

on on

OvrDrv SurdoH1 Sw

on on OvrDrv GMCaixa5 on

35 B 0 Dly GMSurdo4 on

NoisDly SurdoH2 Sw

on on

OvrDrv SurdoH2 Sw

on on OvrDrv GMSurdo4 on on

36 C 1 Dly GMSurdo5 on NoisDly TumbaB Sw on

NoisDly SurdoHLH Sw

on OvrDrv TumbaB Sw on

OvrDrv SurdoHLH Sw

on OvrDrv GMSurdo5 on on

37 C# 1

Dly GMRepinique2

NoisDly TumbaT Sw on NoisDly SurdoHRM on OvrDrv TumbaT Sw on OvrDrv SurdoHRM on

OvrDrv GMRepinique2

38 D 1 Dly GMCaixa6

NoisDly TumbaSC Sw

on NoisDly SurdoHRO on

OvrDrv TumbaSC Sw

on OvrDrv SurdoHRO on OvrDrv GMCaixa6 on

39 D# 1

Dly GMRepinique3

on NoisDly TumbaM on

NoisDly RepiniqueL1 Sw

on OvrDrv TumbaM on

OvrDrv RepiniqueL1 SwonOvrDrv GMRepinique3

on on

40 E 1 Dly GMCaixa7 NoisDly TumbaO Sw on

NoisDly RepiniqueL2 Sw

on OvrDrv TumbaO Sw on

OvrDrv RepiniqueL2 Sw

on OvrDrv GMCaixa7 on

41 F 1 Dly GMSurdo6 NoisDly CongaB Sw on

NoisDly RepiniqueL3 Sw

on OvrDrv CongaB Sw on

OvrDrv RepiniqueL3 Sw

on OvrDrv GMSurdo6 on

42 F# 1 Dly GMAgogo1 NoisDly CongaT Sw on

NoisDly RepiniqueL4 Sw

on OvrDrv CongaT Sw on

OvrDrv RepiniqueL4 Sw

on OvrDrv GMAgogo1 on

43 G 1 Dly GMSurdo7

NoisDly CongaOS SwonNoisDly RepiniqueL5 SwonOvrDrv CongaOS Sw

OvrDrv RepiniqueL5 Sw

on OvrDrv GMSurdo7 on

44 G# 1 Dly GMAgogo2 NoisDly CongaM on

NoisDly RepiniqueL6 Sw

on OvrDrv CongaM on

OvrDrv RepiniqueL6 Sw

on OvrDrv GMAgogo2 on

45 A 1 Dly GMSurdo8 NoisDly CongaO Sw on

NoisDly RepiniqueL7

on on OvrDrv CongaO Sw on

OvrDrv RepiniqueL7

on on OvrDrv GMSurdo8 on

46 A# 1 Dly GMAgogo3 NoisDly CongaStick on

NoisDly RepiniqueL8

on on OvrDrv CongaStick on

OvrDrv RepiniqueL8

on on OvrDrv GMAgogo3 on

47 B 1 Dly GMSurdo9 NoisDly QuintoR Sw on

NoisDly RepiniqueL9

on on OvrDrv QuintoR Sw on

OvrDrv RepiniqueL9

on on OvrDrv GMSurdo9 on

48 C 2 Dly GMSurdo10 NoisDly QuintoB on

NoisDly RepiniqueH1 Sw

on OvrDrv QuintoB on

OvrDrv RepiniqueH1 SwonOvrDrv GMSurdo10

49 C# 2

Dly GMTriangle1

NoisDly QuintoT on

NoisDly RepiniqueH2 Sw

on OvrDrv QuintoT on

OvrDrv RepiniqueH2 SwonOvrDrv GMTriangle1

50 D 2 Dly GMSurdo11 NoisDly QuintoS Sw on

NoisDly RepiniqueH3 Sw

on OvrDrv QuintoS Sw on

OvrDrv RepiniqueH3 SwonOvrDrv GMSurdo11

51 D# 2

Dly GMMamboBell

NoisDly QuintoM on

NoisDly RepiniqueH4 Sw

on OvrDrv QuintoM on

OvrDrv RepiniqueH4 SwonOvrDrv GMMamboBell

52 E 2

Dly GMSongoBell1

NoisDly QuintoO Sw on

NoisDly RepiniqueH5 Sw

on OvrDrv QuintoO Sw on

OvrDrv RepiniqueH5 SwonOvrDrv GMSongoBell1

53 F 2

Dly GMHandBell1

NoisDly BongoL Sw on

NoisDly RepiniqueH6 Sw

on OvrDrv BongoL Sw on

OvrDrv RepiniqueH6 SwonOvrDrv GMHandBell1

54 F# 2 Dly GMPandeiro

NoisDly BongoH1 SwonNoisDly Pandeiro1 SwonOvrDrv BongoH1 SwonOvrDrv Pandeiro1 SwonOvrDrv GMPandeiro

55 G 2

Dly GMHandBell2

NoisDly BongoH2 SwonNoisDly Pandeiro2 SwonOvrDrv BongoH2 SwonOvrDrv Pandeiro2 SwonOvrDrv GMHandBell2

56 G# 2 Dly GMCowbell Dly GMFunkBell

NoisDly TimbaleL1 Sw

NoisDly Pandeiro3 SwonOvrDrv TimbaleL1 Sw

OvrDrv Pandeiro3 SwonOvrDrv GMFunkBell

57 A 2

Dly GMTriangle2

NoisDly TimbaleLE on

NoisDly Pandeiro4 SwonOvrDrv TimbaleLE

OvrDrv Pandeiro4 SwonOvrDrv GMTriangle2

58 A# 2

Dly GMRepinique4onNoisDly TimbaleL2 Sw

NoisDly Pandeiro5 Sw

on on

OvrDrv TimbaleL2 Sw

OvrDrv Pandeiro5 Sw

on on

OvrDrv GMRepinique4

on on

59 B 2

Dly GMSongoBell2

NoisDly TimbaleLM on NoisDly Pandeiro6 on on OvrDrv TimbaleLM on OvrDr v Pandeiro6 on on

OvrDrv GMSongoBell2

60 C 3 Dly GMBongoH Dly GMBongo1 NoisDly PailaL Sw on NoisDly Pandeiro7 on on OvrDrv PailaL Sw on OvrDrv Pandeiro7 on on OvrDrv GMBongo1 on 61 C# 3 Dly GMBongoL Dly GMBongo2

NoisDly TimbaleH1 Sw

on NoisDly Caixa1 Sw on

OvrDrv TimbaleH1 Sw

on OvrDrv Caixa1 Sw on OvrDr v GMBongo2 on

62 D 3

Dly GMCongaHMute

Dly GMConga1 NoisDly PailaH Sw on NoisDly Caixa2 Sw on OvrDrv PailaH Sw on OvrDrv Caixa2 Sw on OvrDrv GMConga1 on

63 D# 3

Dly GMCongaHOpen

Dly GMConga2

NoisDly TimbaleH2 Sw

on NoisDly Caixa3 Sw on

OvrDrv TimbaleH2 Sw

on OvrDrv Caixa3 Sw on OvrDr v GMConga2 on

64 E 3 Dly GMCongaL Dly GMTumba

NoisDly TimbaleHR Sw

on NoisDly Caixa4 Sw on

OvrDrv TimbaleHR Sw

on OvrDrv Caixa4 Sw on OvrDr v GMTumba on

65 F 3 Dly GMTimbaleH

Dly GMTimbale1

NoisDly TimbaleHE Sw

NoisDly TamborimT Sw

OvrDrv TimbaleHE Sw

OvrDrv TamborimT Sw

OvrDrv GMTimbale1

66 F# 3 Dly GMTimbaleL

Dly GMTimbale2

NoisDly TimbaleF1 on

NoisDly Tamborim1 Sw

on OvrDrv TimbaleF1 on

OvrDrv Tamborim1 Sw

OvrDrv GMTimbale2

67 G 3 Dly GMAgogoH Dly GMAgogo4 NoisDly TimbaleF2 on

NoisDly Tamborim2 Sw

on OvrDrv TimbaleF2 on

OvrDrv Tamborim2 Sw

on OvrDrv GMAgogo4 on

68 G# 3 Dly GMAgogoL Dly GMAgogo5 NoisDly TimbaleF3 on

NoisDly Tamborim3 Sw

on OvrDrv TimbaleF3 on

OvrDrv Tamborim3 Sw

on OvrDrv GMAgogo5 on

69 A 3 Dly GMCabassa on

Dly GMCabassa2

on NoisDly TimbaleF4 on

NoisDly Tamborim4 Sw

on OvrDrv TimbaleF4 on

OvrDrv Tamborim4 Sw

OvrDrv GMCabassa2

on on

70 A# 3 Dly GMMaracas Dly GMMaracas

NoisDly HandBellMO SwonNoisDly Tamborim5 Sw

OvrDrv HandBellMO SwonOvrDrv Tamborim5 Sw

OvrDrv GMMaracas

71 B 3 Dly GMWhistleH on Dly GMWhistle1 on

NoisDly HandBellMM SwonNoisDly Tamborim6 Sw

OvrDrv HandBellMM SwonOvrDrv Tamborim6 Sw

OvrDrv GMWhistle1

on on

72 C 4 Dly GMWhistleL on Dly GMWhistle2 on

NoisDly HandBellSO Sw

on NoisDly Agogo1 Sw on

OvrDrv HandBellSO Sw

on OvrDrv Agogo1 Sw on

OvrDrv GMWhistle2

on on

73 C# 4

Dly GMGuiroShort

Dly GMGuiro1

NoisDly HandBellSM Sw

on NoisDly Agogo2 Sw on

OvrDrv HandBellSM Sw

on OvrDrv Agogo2 Sw on OvrDr v GMGuiro1 on

74 D 4

Dly GMGuiroLong

on Dly GMGuiro2 on

NoisDly HandBellC Sw

on NoisDly Agogo3 Sw on

OvrDrv HandBellC Sw

on OvrDrv Agogo3 Sw on OvrDr v GMGuiro2 on on

75 D# 4 Dly GMClavess Dly GMClaves4

NoisDly MamboBell Sw

on NoisDly FunkBell1 on

OvrDrv MamboBell Sw

on OvrDrv FunkBell1 on OvrDrv GMClaves4 on

76 E 4

Dly GMWoodBlockH

Dly GMWoodBlock1 NoisDly ChaChaBell Sw

on NoisDly FunkBell2 on

OvrDrv ChaChaBell Sw

on OvrDrv FunkBell2 on

OvrDrv GMWoodBlock1

77 F 4

Dly GMWoodBlockL

Dly GMWoodBlock2

NoisDly SongoBellH SwonNoisDly WdBlkLarge Sw

OvrDrv SongoBellH SwonOvrDrv WdBlkLarge Sw

OvrDrv GMWoodBlock2

78 F# 4

Dly GMCuicaMute

on Dly GMCuica4 on

NoisDly SongoBellL SwonNoisDly WdBlkSmall Sw

OvrDrv SongoBellL SwonOvrDrv WdBlkSmall Sw

on OvrDrv GMCuica4 on on

79 G 4

Dly GMCuicaOpen

on Dly GMCuica5 on NoisDly FunkBell1 on

NoisDly TriangleL1 Sw

on on OvrDrv FunkBell1 on

OvrDrv TriangleL1 Sw

on on OvrDrv GMCuica5 on on

80 G# 42

Dly GMTriangleMute

Dly GMTriangle3

NoisDly FunkBell2 on

NoisDly TriangleL2 Sw

on OvrDrv FunkBell2 on

OvrDrv TriangleL2 Sw

OvrDrv GMTriangle3

81 A 4 2

Dly GMTriangleOpen

Dly GMTriangle4

NoisDly WdBlkLarge Sw

NoisDly TriangleS1 Sw

on on

OvrDrv WdBlkLarge Sw

OvrDrv TriangleS1 Sw

on on

OvrDrv GMTriangle4

82 A# 4 Dly GMShaker Dly GMShaker5

NoisDly WdBlkSmall Sw

NoisDly TriangleS2 Sw

OvrDrv WdBlkSmall Sw

OvrDrv TriangleS2 Sw

OvrDrv GMShaker5

83 B 4 Dly GMCaxixi on

NoisDly ChekereS1 Sw

on NoisDly Shaker1 Sw on

OvrDrv ChekereS1 Sw

on OvrDrv Shaker1 Sw on OvrDrv GMCaxixi on on

84 C 5

Dly GMCabassa3onNoisDly ChekereS2 Sw

on NoisDly Shaker2 Sw on

OvrDrv ChekereS2 Sw

on OvrDrv Shaker2 Sw on

OvrDrv GMCabassa3

on on

85 C# 5

NoisDly ChekereS3 Sw

on NoisDly Shaker3 Sw on

OvrDrv ChekereS3 Sw

on OvrDrv Shaker3 Sw on

86 D 5 NoisDly ChekereST on

NoisDly CabassaL1 Sw

on on OvrDrv ChekereST on

OvrDrv CabassaL1 Sw

on on

87 D# 5 NoisDly ChekereL on

NoisDly CabassaL2 Sw

on on OvrDrv ChekereL on

OvrDrv CabassaL2 Sw

on on

88 E 5 NoisDly ChekereLT on

NoisDly CabassaL3 Sw

on on OvrDrv ChekereLT on

OvrDrv CabassaL3 Sw

on on

89 F 5

NoisDly Maracas1 Sw

on NoisDly CabassaL4 on on

OvrDrv Maracas1 Sw

on OvrDrv CabassaL4 on on

90 F# 5

NoisDly Maracas2 Sw

on NoisDly CabassaL5 on on

OvrDrv Maracas2 Sw

on OvrDrv CabassaL5 on on

91 G 5 NoisDly Guiro1 Sw on on

NoisDly CaxixiL1 Sw

on OvrDrv Guiro1 Sw on on

OvrDrv CaxixiL1 Sw

92 G# 5 NoisDly Guiro2 Sw on on

NoisDly CaxixiL2 Sw

on OvrDrv Guiro2 Sw on on

OvrDrv CaxixiL2 Sw

93 A 5 NoisDly Guiro3 Sw on

NoisDly CaxixiL3 Sw

on OvrDrv Guiro3 Sw on

OvrDrv CaxixiL3 Sw

94 A# 5 NoisDly Guiro4 Sw on

NoisDly CaxixiS1 Sw

on OvrDrv Guiro4 Sw on

OvrDrv CaxixiS1 Sw

95 B 5 NoisDly Claves1 Sw on

NoisDly CaxixiS2 Sw

on OvrDrv Claves1 Sw on

OvrDrv CaxixiS2 Sw

96 C 6 NoisDly Claves2 Sw on NoisDly Cuica1 on on OvrDrv Claves2 Sw on OvrDr v Cuica1 on on 97 C# 6 NoisDly Guira1 on on NoisDly Cuica2 on on OvrDrv Guira1 on on OvrDr v Cuica2 on on 98 D 6 NoisDly Guira2 on on NoisDly Cuica3 on on OvrDrv Guira2 on on OvrDrv Cuica3 on on 99 D# 6 NoisDly Guira3 on NoisDly Cuica4 on on OvrDrv Guira3 on OvrDrv Cuica4 on on

100 E 6 NoisDly Guira4 on NoisDly Cuica5 on on OvrDrv Guira4 on OvrDrv Cuica5 on on 101 F 6 NoisDly Cuica6 on on OvrDrv Cuica6 on on 102 F# 6 NoisDly Cuica7 on on OvrDrv Cuica7 on on 103 G 6 NoisDly Whistle1 on OvrDrv Whistle1 on 104 G# 6 NoisDly Whistle2 on OvrDrv Whistle2 on 105 A 6 NoisDly Whistle3 on on OvrDrv Whistle3 on on 106 A# 6 NoisDly Whistle4 on on OvrDrv Whistle4 on on 107 B 6 NoisDly Whistle5 on on OvrDrv Whistle5 on on 108 C 7 NoisDly Whistle6 on on OvrDrv Whistle6 on on

Voice List

A : Alternate Group K : Key Off I : Insertion Effect : No sound

* The Alternate Group settings have been programmed only for the kits listed below.

Pgm# 4 GMPerc, Pgm#10 GMLtnDr, Pgm#23 DlyGMPrc, Pgm#24 DlyGMltn, Pgm#29 ODGMLtn, Pgm#33 Dst1GMLt, Pgm#37 Dst2GMLtn, Pgm#64 RvbGMPc, Pgm#69 RvbGMLtn

None of the other kits (excepting those above) have Alternate Group settings.

30 31 32 33 34 35 36 37

ODKk&Snr Dst1AfCb Dst1Brzl Dst1GMLt Dst1Kk&S Dst2AfCb Dst2Brzl Dst2GMLt

Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I

Dist1 GMSurdo1 on on Dist2 GMSurdo1 on on Dist1 GMSurdo2 on on Dist2 GMSurdo2 on on Dist1 GMCuica1 on on Dist2 GMCuica1 on on Dist1 GMTamborim1

Dist2 GMTamborim1

on Dist1 GMCuica2 on on Dist2 GMCuica2 on on Dist1 GMCuica3 on on Dist2 GMCuica3 on on Dist1 GMCabassa1

on on

Dist2 GMCabassa1

on on

Dist1 GMTamborim2

Dist2 GMTamborim2

on Dist1 GMCaixa1 on Dist2 GMCaixa1 on Dist1 GMCaixa2 on Dist2 GMCaixa2 on Dist1 GMClaves1 on Dist2 GMClaves1 on

Dist1 SurdoL1 Sw on on Dist1 GMClaves2 on Dist2 SurdoL1 Sw on on Dist2 GMClaves2 on Dist1 SurdoL2 Sw on on Dist1 GMShaker1 on Dist2 SurdoL2 Sw on on Dist2 GMShaker1 on Dist1 SurdoLLH Sw

on Dist1 GMShaker2 on

Dist2 SurdoLLH Sw

on Dist2 GMShaker2 on Dist1 SurdoLRM on Dist1 GMShaker3 on Dist2 SurdoLRM on Dist2 GMShaker3 on Dist1 SurdoLRO on Dist1 GMShaker4 on Dist2 SurdoLRO on Dist2 GMShaker4 on Dist1 SurdoM1 Sw

on on

Dist1 GMRepinique1

on on

Dist2 SurdoM1 Sw

on on

Dist2 GMRepinique1

on on

Dist1 SurdoM2 Sw

on on Dist1 GMClaves3 on

Dist2 SurdoM2 Sw

on on Dist2 GMClaves3 on

Dist1 SurdoMLH Sw

on Dist1 GMCaixa3 on

Dist2 SurdoMLH Sw

on Dist2 GMCaixa3 on Dist1 SurdoMRM on Dist1 GMCaixa4 on Dist2 SurdoMRM on Dist2 GMCaixa4 on Dist1 SurdoMRO on Dist1 GMSurdo3 on Dist2 SurdoMRO on Dist2 GMSurdo3 on Dist1 SurdoH1 Sw on on Dist1 GMCaixa5 on Dist2 SurdoH1 Sw on on Dist2 GMCaixa5 on Dist1 SurdoH2 Sw on on Dist1 GMSurdo4 on Dist2 SurdoH2 Sw on on Dist2 GMSurdo4 on

OvrDrv SurdoL1

on on Dist1 TumbaB Sw on

Dist1 SurdoHLH Sw

on Dist1 GMSurdo5 on Dist1 SurdoL1 on on Dist2 TumbaB Sw on

Dist2 SurdoHLH Sw

on Dist2 GMSurdo5 on

OvrDrv SurdoL2

on on Dist1 TumbaT Sw on Dist1 SurdoHRM on

Dist1 GMRepinique2

on Dist1 SurdoL2 on on Dist2 TumbaT Sw on Dist2 SurdoHRM on

Dist2 GMRepinique2

OvrDrv SurdoL3

on on

Dist1 TumbaSC Sw

on Dist1 SurdoHRO on Dist1 GMCaixa6 on Dist1 SurdoL3 on on

Dist2 TumbaSC Sw

on Dist2 SurdoHRO on Dist2 GMCaixa6 on

OvrDrv SurdoL4

on on Dist1 TumbaM on

Dist1 RepiniqueL1 SwonDist1 GMRepinique3

on on Dist1 SurdoL4 on on Dist2 TumbaM on

Dist2 RepiniqueL1 SwonDist2 GMRepinique3

on on

OvrDrv SurdoLLH1

on Dist1 TumbaO Sw on

Dist1 RepiniqueL2 Sw

on Dist1 GMCaixa7 on

Dist1 SurdoLLH1

on Dist2 TumbaO Sw on

Dist2 RepiniqueL2 Sw

on Dist2 GMCaixa7 on

OvrDrv SurdoLLH2

on Dist1 CongaB Sw on

Dist1 RepiniqueL3 Sw

on Dist1 GMSurdo6 on

Dist1 SurdoLLH2

on Dist2 CongaB Sw on

Dist2 RepiniqueL3 Sw

on Dist2 GMSurdo6 on

OvrDrv SurdoLRM

on Dist1 CongaT Sw on

Dist1 RepiniqueL4 Sw

on Dist1 GMAgogo1 on

Dist1 SurdoLRM

on Dist2 CongaT Sw on

Dist2 RepiniqueL4 Sw

on Dist2 GMAgogo1 on

OvrDrv SurdoLROonDist1 CongaOS SwonDist1 RepiniqueL5 Sw

on Dist1 GMSurdo7 on

Dist1 SurdoLRO

Dist2 CongaOS SwonDist2 RepiniqueL5 Sw

on Dist2 GMSurdo7 on

OvrDrv SurdoM1

on on Dist1 CongaM on

Dist1 RepiniqueL6 Sw

on Dist1 GMAgogo2 on

Dist1 SurdoM1

on on Dist2 CongaM on

Dist2 RepiniqueL6 Sw

on Dist2 GMAgogo2 on

OvrDrv SurdoM2

on on Dist1 CongaO Sw on Dist1 RepiniqueL7 on on Dist1 GMSurdo8 on

Dist1 SurdoM2

on on Dist2 CongaO Sw on Dist2 RepiniqueL7 on on Dist2 GMSurdo8 on

OvrDrv SurdoM3

on on Dist1 CongaStick on Dist1 RepiniqueL8 on on Dist1 GMAgogo3 on

Dist1 SurdoM3

on on Dist2 CongaStick on Dist2 RepiniqueL8 on on Dist2 GMAgogo3 on

OvrDrv SurdoM4

on on Dist1 QuintoR Sw on Dist1 RepiniqueL9 on on Dist1 GMSurdo9 on

Dist1 SurdoM4

on on Dist2 QuintoR Sw on Dist2 RepiniqueL9 on on Dist2 GMSurdo9 on

OvrDrv SurdoMLH1

on Dist1 QuintoB on

Dist1 RepiniqueH1 Sw

on Dist1 GMSurdo10 on

Dist1 SurdoMLH1

on Dist2 QuintoB on

Dist2 RepiniqueH1 Sw

on Dist2 GMSurdo10 on

OvrDrv SurdoMLH2

on Dist1 QuintoT on

Dist1 RepiniqueH2 SwonDist1 GMTriangle1

Dist1 SurdoMLH2

on Dist2 QuintoT on

Dist2 RepiniqueH2 SwonDist2 GMTriangle1

OvrDrv SurdoMRM

on Dist1 QuintoS Sw on

Dist1 RepiniqueH3 Sw

on Dist1 GMSurdo11 on

Dist1 SurdoMRM

on Dist2 QuintoS Sw on

Dist2 RepiniqueH3 Sw

on Dist2 GMSurdo11 on

OvrDrv SurdoMRO

on Dist1 QuintoM on

Dist1 RepiniqueH4 SwonDist1 GMMamboBellonDist1 SurdoMRO

on Dist2 QuintoM on

Dist2 RepiniqueH4 SwonDist2 GMMamboBell

OvrDrv SurdoH1

on on Dist1 QuintoO Sw on

Dist1 RepiniqueH5 SwonDist1 GMSongoBell1onDist1 SurdoH1

on on Dist2 QuintoO Sw on

Dist2 RepiniqueH5 SwonDist2 GMSongoBell1

OvrDrv SurdoH2

on on Dist1 BongoL Sw on

Dist1 RepiniqueH6 SwonDist1 GMHandBell1onDist1 SurdoH2

on on Dist2 BongoL Sw on

Dist2 RepiniqueH6 SwonDist2 GMHandBell1

OvrDrv SurdoH3

on on

Dist1 BongoH1 SwonDist1 Pandeiro1 Sw

Dist1 GMPandeiro

Dist1 SurdoH3

on on

Dist2 BongoH1 SwonDist2 Pandeiro1 Sw

Dist2 GMPandeiro

OvrDrv SurdoH4

on on

Dist1 BongoH2 SwonDist1 Pandeiro2 Sw

Dist1 GMHandBell2onDist1 SurdoH4

on on

Dist2 BongoH2 SwonDist2 Pandeiro2 Sw

Dist2 GMHandBell2

OvrDrv SurdoHLH1onDist1 TimbaleL1 Sw

Dist1 Pandeiro3 Sw

Dist1 GMFunkBell

Dist1 SurdoHLH1onDist2 TimbaleL1 Sw

Dist2 Pandeiro3 Sw

Dist2 GMFunkBell

OvrDrv SurdoHLH2

on Dist1 TimbaleLE on

Dist1 Pandeiro4 Sw

Dist1 GMTriangle2

Dist1 SurdoHLH2

on Dist2 TimbaleLE on

Dist2 Pandeiro4 Sw

Dist2 GMTriangle2

OvrDrv SurdoHRMonDist1 TimbaleL2 Sw

Dist1 Pandeiro5 Sw

on on

Dist1 GMRepinique4

on on

Dist1 SurdoHRMonDist2 TimbaleL2 Sw

Dist2 Pandeiro5 Sw

on on

Dist2 GMRepinique4

on on

OvrDrv SurdoHRO

on Dist1 TimbaleLM on Dist1 Pandeiro6 on on

Dist1 GMSongoBell2onDist1 SurdoHRO

on Dist2 TimbaleLM on Dist2 Pandeiro6 on on

Dist2 GMSongoBell2

on OvrDrv Caixa1 on Dist1 PailaL Sw on Dist1 Pandeiro7 on on Dist1 GMBongo1 on Dist1 Caixa1 on Dist2 PailaL Sw on Dist2 Pandeiro7 on on Dist2 GMBongo1 on OvrDrv Caixa2 on

Dist1 TimbaleH1 Sw

on Dist1 Caixa1 Sw on Dist1 GMBongo2 on Dist1 Caixa2 on

Dist2 TimbaleH1 Sw

on Dist2 Caixa1 Sw on Dist2 GMBongo2 on OvrDrv Caixa3 on Dist1 PailaH Sw on Dist1 Caixa2 Sw on Dist1 GMConga1 on Dist1 Caixa3 on Dist2 PailaH Sw on Dist2 Caixa2 Sw on Dist2 GMConga1 on OvrDrv Caixa4 on

Dist1 TimbaleH2 Sw

on Dist1 Caixa3 Sw on Dist1 GMConga2 on Dist1 Caixa4 on

Dist2 TimbaleH2 Sw

on Dist2 Caixa3 Sw on Dist2 GMConga2 on OvrDrv Caixa5 on

Dist1 TimbaleHR Sw

on Dist1 Caixa4 Sw on Dist1 GMTumba on Dist1 Caixa5 on

Dist2 TimbaleHR Sw

on Dist2 Caixa4 Sw on Dist2 GMTumba on OvrDrv Caixa6 on

Dist1 TimbaleHE Sw

Dist1 TamborimT Sw

Dist1 GMTimbale1

on Dist1 Caixa6 on

Dist2 TimbaleHE Sw

Dist2 TamborimT Sw

Dist2 GMTimbale1

OvrDrv Caixa7 on Dist1 TimbaleF1 on

Dist1 Tamborim1 Sw

Dist1 GMTimbale2

on Dist1 Caixa7 on Dist2 TimbaleF1 on

Dist2 Tamborim1 Sw

Dist2 GMTimbale2

OvrDrv Caixa8 on Dist1 TimbaleF2 on

Dist1 Tamborim2 Sw

on Dist1 GMAgogo4 on Dist1 Caixa8 on Dist2 TimbaleF2 on

Dist2 Tamborim2 Sw

on Dist2 GMAgogo4 on

OvrDrv Caixa9 on Dist1 TimbaleF3 on

Dist1 Tamborim3 Sw

on Dist1 GMAgogo5 on Dist1 Caixa9 on Dist2 TimbaleF3 on

Dist2 Tamborim3 Sw

on Dist2 GMAgogo5 on

OvrDrv Caixa10

on Dist1 TimbaleF4 on

Dist1 Tamborim4 Sw

Dist1 GMCabassa2

on on Dist1 Caixa10 on Dist2 TimbaleF4 on

Dist2 Tamborim4 Sw

Dist2 GMCabassa2

on on

OvrDrv Caixa11

Dist1 HandBellMO SwonDist1 Tamborim5 Sw

on Dist1 GMMaracas on Dist1 Caixa11 on

Dist2 HandBellMO SwonDist2 Tamborim5 Sw

on Dist2 GMMaracas on

OvrDrv Caixa12

Dist1 HandBellMM SwonDist1 Tamborim6 Sw

on Dist1 GMWhistle1 on on Dist1 Caixa12 on

Dist2 HandBellMM SwonDist2 Tamborim6 Sw

on Dist2 GMWhistle1 on on

Dist1 HandBellSO Sw

on Dist1 Agogo1 Sw on Dist1 GMWhistle2 on on

Dist2 HandBellSO Sw

on Dist2 Agogo1 Sw on Dist2 GMWhistle2 on on

Dist1 HandBellSM Sw

on Dist1 Agogo2 Sw on Dist1 GMGuiro1 on

Dist2 HandBellSM Sw

on Dist2 Agogo2 Sw on Dist2 GMGuiro1 on

Dist1 HandBellC Sw

on Dist1 Agogo3 Sw on Dist1 GMGuiro2 on on

Dist2 HandBellC Sw

on Dist2 Agogo3 Sw on Dist2 GMGuiro2 on on

Dist1 MamboBell Sw

on Dist1 FunkBell1 on Dist1 GMClaves4 on

Dist2 MamboBell Sw

on Dist2 FunkBell1 on Dist2 GMClaves4 on

Dist1 ChaChaBell Sw

on Dist1 FunkBell2 on

Dist1 GMWoodBlock1

Dist2 ChaChaBell Sw

on Dist2 FunkBell2 on

Dist2 GMWoodBlock1

Dist1 SongoBellH SwonDist1 WdBlkLarge Sw

Dist1 GMWoodBlock2

Dist2 SongoBellH SwonDist2 WdBlkLarge Sw

Dist2 GMWoodBlock2

Dist1 SongoBellL SwonDist1 WdBlkSmall Sw

on Dist1 GMCuica4 on on

Dist2 SongoBellL SwonDist2 WdBlkSmall Sw

on Dist2 GMCuica4 on on

Dist1 FunkBell1 on

Dist1 TriangleL1 Sw

on on Dist1 GMCuica5 on on Dist2 FunkBell1 on

Dist2 TriangleL1 Sw

on on Dist2 GMCuica5 on on

Dist1 FunkBell2 on

Dist1 TriangleL2 Sw

Dist1 GMTriangle3

on Dist2 FunkBell2 on

Dist2 TriangleL2 Sw

Dist2 GMTriangle3

Dist1 WdBlkLarge Sw

Dist1 TriangleS1 Sw

on on

Dist1 GMTriangle4

Dist2 WdBlkLarge Sw

Dist2 TriangleS1 Sw

on on

Dist2 GMTriangle4

Dist1 WdBlkSmall Sw

Dist1 TriangleS2 Sw

on Dist1 GMShaker5 on

Dist2 WdBlkSmall Sw

Dist2 TriangleS2 Sw

on Dist2 GMShaker5 on

Dist1 ChekereS1 Sw

on Dist1 Shaker1 Sw on Dist1 GMCaxixi on on

Dist2 ChekereS1 Sw

on Dist2 Shaker1 Sw on Dist2 GMCaxixi on on

Dist1 ChekereS2 Sw

on Dist1 Shaker2 Sw on

Dist1 GMCabassa3

on on

Dist2 ChekereS2 Sw

on Dist2 Shaker2 Sw on

Dist2 GMCabassa3

on on

Dist1 ChekereS3 Sw

on Dist1 Shaker3 Sw on

Dist2 ChekereS3 Sw

on Dist2 Shaker3 Sw on

Dist1 ChekereST on

Dist1 CabassaL1 Sw

on on Dist2 ChekereST on

Dist2 CabassaL1 Sw

on on

Dist1 ChekereL on

Dist1 CabassaL2 Sw

on on Dist2 ChekereL on

Dist2 CabassaL2 Sw

on on

Dist1 ChekereLT on

Dist1 CabassaL3 Sw

on on Dist2 ChekereLT on

Dist2 CabassaL3 Sw

on on

Dist1 Maracas1 Sw

on Dist1 CabassaL4 on on

Dist2 Maracas1 Sw

on Dist2 CabassaL4 on on

Dist1 Maracas2 Sw

on Dist1 CabassaL5 on on

Dist2 Maracas2 Sw

on Dist2 CabassaL5 on on

Dist1 Guiro1 Sw on on Dist1 CaxixiL1 Sw on Dist2 Guiro1 Sw on on Dist2 CaxixiL1 Sw on Dist1 Guiro2 Sw on on Dist1 CaxixiL2 Sw on Dist2 Guiro2 Sw on on Dist2 CaxixiL2 Sw on Dist1 Guiro3 Sw on Dist1 CaxixiL3 Sw on Dist2 Guiro3 Sw on Dist2 CaxixiL3 Sw on Dist1 Guiro4 Sw on Dist1 CaxixiS1 Sw on Dist2 Guiro4 Sw on Dist2 CaxixiS1 Sw on Dist1 Claves1 Sw on Dist1 CaxixiS2 Sw on Dist2 Claves1 Sw on Dist2 CaxixiS2 Sw on Dist1 Claves2 Sw on Dist1 Cuica1 on on Dist2 Claves2 Sw on Dist2 Cuica1 on on Dist1 Guira1 on on Dist1 Cuica2 on on Dist2 Guira1 on on Dist2 Cuica2 on on Dist1 Guira2 on on Dist1 Cuica3 on on Dist2 Guira2 on on Dist2 Cuica3 on on Dist1 Guira3 on Dist1 Cuica4 on on Dist2 Guira3 on Dist2 Cuica4 on on Dist1 Guira4 on Dist1 Cuica5 on on Dist2 Guira4 on Dist2 Cuica5 on on

Dist1 Cuica6 on on Dist2 Cuica6 on on Dist1 Cuica7 on on Dist2 Cuica7 on on Dist1 Whistle1 on Dist2 Whistle1 on Dist1 Whistle2 on Dist2 Whistle2 on Dist1 Whistle3 on on Dist2 Whistle3 on on Dist1 Whistle4 on on Dist2 Whistle4 on on Dist1 Whistle5 on on Dist2 Whistle5 on on Dist1 Whistle6 on on Dist2 Whistle6 on on

Voice List

PC Instrument Map MSB=79, LSB=1

A : Alternate Group K : Key Off I : Insertion Effect : No sound

* The Alternate Group settings have been programmed only for the kits listed below.

Pgm# 4 GMPerc, Pgm#10 GMLtnDr, Pgm#23 DlyGMPrc, Pgm#24 DlyGMltn, Pgm#29 ODGMLtn, Pgm#33 Dst1GMLt, Pgm#37 Dst2GMLtn, Pgm#64 RvbGMPc, Pgm#69 RvbGMLtn

None of the other kits (excepting those above) have Alternate Group settings.

Program No. 38 39 40 41 42 43 44

Kit Name Dst2Kk&S FlgAfrCb FlgBrazl FlgShkrs PhsShkrs Rs1Skins Rs1Stick

Note#

Note A Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I

13 C# -1 3 14 D -1 3 15 D# -1 16 E -1 17 F -1 18 F# -1 19 G -1 20 G# -1 21 A -1 22 A# -1 23 B -1 24 C 0 Flanger SurdoL1 Sw on on 25 C# 0 Flanger SurdoL2 Sw on on 26 D 0

Flanger SurdoLLH Sw

27 D# 0 Flanger SurdoLRM on 28 E 0 Flanger SurdoLRO on 29 F 0 Flanger SurdoM1 Sw on on 30 F# 0 Flanger SurdoM2 Sw on on 31 G 0

Flanger SurdoMLH Sw

32 G# 0 Flanger SurdoMRM on 33 A 0 Flanger SurdoMRO on 34 A# 0 Flanger SurdoH1 Sw on on 35 B 0 Flanger SurdoH2 Sw on on 36 C 1 Dist2 SurdoL1 on on Flanger TumbaB Sw on

Flanger SurdoHLH Sw

on Flanger Shaker1 on Phaser Shaker1 on

Resntr1 TumbaB1

Resntr1 TimbaleL1

37 C# 1 Dist2 SurdoL2 on on Flanger TumbaT Sw on Flanger SurdoHRM on Flanger Shaker2 on Phaser Shaker2 on

Resntr1 TumbaB2

Resntr1 TimbaleL2

38 D 1 Dist2 SurdoL3 on on

Flanger TumbaSC Sw

on Flanger SurdoHRO on Flanger Shaker3 on Phaser Shaker3 on

Resntr1 TumbaT1

Resntr1 TimbaleL3

39 D# 1 Dist2 SurdoL4 on on Flanger TumbaM on

Flanger RepiniqueL1 Sw

on Flanger Shaker4 on Phaser Shaker4 on

Resntr1 TumbaT2

Resntr1 TimbaleL4

40 E 1

Dist2 SurdoLLH1

on Flanger TumbaO Sw on

Flanger RepiniqueL2 Sw

on Flanger Shaker5 on Phaser Shaker5 on

Resntr1 TumbaSC1onResntr1 TimbaleLE

41 F 1

Dist2 SurdoLLH2

on Flanger CongaB Sw on

Flanger RepiniqueL3 Sw

on Flanger Shaker6 on Phaser Shaker6 on

Resntr1 TumbaSC2onResntr1 TimbaleLM

42 F# 1

Dist2 SurdoLRM

on Flanger CongaT Sw on

Flanger RepiniqueL4 Sw

on Flanger Shaker7 on Phaser Shaker7 on

Resntr1 TumbaSC3onResntr1 TimbaleH1

43 G 1

Dist2 SurdoLRO

Flanger CongaOS Sw

Flanger RepiniqueL5 Sw

on Flanger Shaker8 on Phaser Shaker8 on Resntr1 TumbaM on

Resntr1 TimbaleH2

44 G# 1 Dist2 SurdoM1 on on Flanger CongaM on

Flanger RepiniqueL6 Sw

on Flanger Shaker9 on Phaser Shaker9 on

Resntr1 TumbaO1

Resntr1 TimbaleH3

45 A 1 Dist2 SurdoM2 on on Flanger CongaO Sw on Flanger RepiniqueL7 on on Flanger Shaker10 on Phaser Shaker10 on

Resntr1 TumbaO2

Resntr1 TimbaleH4

46 A# 1 Dist2 SurdoM3 on on Flanger CongaStick on Flanger RepiniqueL8 on on Flanger Shaker11 on Phaser Shaker11 on

Resntr1 TumbaO3

Resntr1 TimbaleHR1

47 B 1 Dist2 SurdoM4 on on Flanger QuintoR Sw on Flanger RepiniqueL9 on on Flanger Shaker12 on Phaser Shaker12 on

Resntr1 CongaB1onResntr1 TimbaleHR2

48 C 2

Dist2 SurdoMLH1

on Flanger QuintoB on

Flanger RepiniqueH1 SwonFlanger CabassaL1

on on

Phaser CabassaL1

on on

Resntr1 CongaB2onResntr1 TimbaleHE1

49 C# 2

Dist2 SurdoMLH2

on Flanger QuintoT on

Flanger RepiniqueH2 SwonFlanger CabassaL2

on on

Phaser CabassaL2

on on

Resntr1 CongaT1

Resntr1 TimbaleHE2

50 D 2

Dist2 SurdoMRM

on Flanger QuintoS Sw on

Flanger RepiniqueH3 SwonFlanger CabassaL3

on on

Phaser CabassaL3

on on

Resntr1 CongaT2

on Resntr1 PailaL1 on

51 D# 2

Dist2 SurdoMRO

on Flanger QuintoM on

Flanger RepiniqueH4 SwonFlanger CabassaL4

on on

Phaser CabassaL4

on on

Resntr1 CongaOS1

on Resntr1 PailaL2 on

52 E 2 Dist2 SurdoH1 on on Flanger QuintoO Sw on

Flanger RepiniqueH5 SwonFlanger CabassaL5

on on

Phaser CabassaL5

on on

Resntr1 CongaOS2

on Resntr1 PailaH1 on

53 F 2 Dist2 SurdoH2 on on Flanger BongoL Sw on

Flanger RepiniqueH6 SwonFlanger CabassaL6

on on

Phaser CabassaL6

on on

Resntr1 CongaOS3

on Resntr1 PailaH2 on

54 F# 2 Dist2 SurdoH3 on on Flanger BongoH1 Sw on

Flanger Pandeiro1 Sw

Flanger CabassaL7

on on

Phaser CabassaL7

on on Resntr1 CongaM on

Resntr1 TimbaleF1

55 G 2 Dist2 SurdoH4 on on Flanger BongoH2 Sw on

Flanger Pandeiro2 Sw

Flanger CabassaL8

on on

Phaser CabassaL8

on on

Resntr1 CongaO1onResntr1 TimbaleF2

56 G# 2

Dist2 SurdoHLH1onFlanger TimbaleL1 Sw

Flanger Pandeiro3 Sw

Flanger CabassaL9

on on

Phaser CabassaL9

on on

Resntr1 CongaO2onResntr1 TimbaleF3

57 A 2

Dist2 SurdoHLH2

on Flanger TimbaleLE on

Flanger Pandeiro4 Sw

Flanger CabassaL10

on on

Phaser CabassaL10

on on

Resntr1 CongaO3onResntr1 TimbaleF4

58 A# 2

Dist2 SurdoHRMonFlanger TimbaleL2 Sw

Flanger Pandeiro5 Sw

on on Flanger CaxixiL1 on Phaser CaxixiL1 on

Resntr1 CongaStick

Resntr1 TimbaleF5

59 B 2

Dist2 SurdoHRO

on Flanger TimbaleLM on Flanger Pandeiro6 on on Flanger CaxixiL2 on Phaser CaxixiL2 on

Resntr1 QuintoR1onResntr1 TimbaleF6

60 C 3 Dist2 Caixa1 on Flanger PailaL Sw on Flanger Pandeiro7 on on Flanger CaxixiL3 on Phaser CaxixiL3 on

Resntr1 QuintoR2

on Resntr1 Caixa1 on

61 C# 3 Dist2 Caixa2 on

Flanger TimbaleH1 Sw

on Flanger Caixa1 Sw on Flanger CaxixiL4 on Phaser CaxixiL4 on Resntr1 QuintoB on Resntr1 Caixa2 on

62 D 3 Dist2 Caixa3 on Flanger PailaH Sw on Flanger Caixa2 Sw on Flanger CaxixiL5 on Phaser CaxixiL5 on Resntr1 QuintoT on Resntr1 Caixa3 on 63 D# 3 Dist2 Caixa4 on

Flanger TimbaleH2 Sw

on Flanger Caixa3 Sw on Flanger CaxixiL6 on Phaser CaxixiL6 on

Resntr1 QuintoS1

on Resntr1 Caixa4 on

64 E 3 Dist2 Caixa5 on

Flanger TimbaleHR Sw

on Flanger Caixa4 Sw on Flanger CaxixiS1 on Phaser CaxixiS1 on

Resntr1 QuintoS2

on Resntr1 Caixa5 on

65 F 3 Dist2 Caixa6 on

Flanger TimbaleHE Sw

Flanger TamborimT Sw

on Flanger CaxixiS2 on Phaser CaxixiS2 on Resntr1 QuintoM on Resntr1 Caixa6 on

66 F# 3 Dist2 Caixa7 on Flanger TimbaleF1 on

Flanger Tamborim1 Sw

on Flanger CaxixiS3 on Phaser CaxixiS3 on

Resntr1 QuintoO1

on Resntr1 Caixa7 on

67 G 3 Dist2 Caixa8 on Flanger TimbaleF2 on

Flanger Tamborim2 Sw

on Flanger CaxixiS4 on Phaser CaxixiS4 on

Resntr1 QuintoO2

on Resntr1 Caixa8 on

68 G# 3 Dist2 Caixa9 on Flanger TimbaleF3 on

Flanger Tamborim3 Sw

Flanger ChekereS1

Phaser ChekereS1

on Resntr1 BongoL1 on Resntr1 Caixa9 on

69 A 3 Dist2 Caixa10 on Flanger TimbaleF4 on

Flanger Tamborim4 Sw

Flanger ChekereS2

Phaser ChekereS2

on Resntr1 BongoL2 on Resntr1 Caixa10 on

70 A# 3 Dist2 Caixa11 on

Flanger HandBellMO SwonFlanger Tamborim5 Sw

Flanger ChekereS3

Phaser ChekereS3

on Resntr1 BongoL3 on Resntr1 Caixa11 on

71 B 3 Dist2 Caixa12 on

Flanger HandBellMM SwonFlanger Tamborim6 Sw

Flanger ChekereS4

Phaser ChekereS4

Resntr1 BongoH1

on Resntr1 Caixa12 on

72 C 4

Flanger HandBellSO Sw

on Flanger Agogo1 Sw on

Flanger ChekereS5

Phaser ChekereS5

Resntr1 BongoH2

73 C# 4

Flanger HandBellSM Sw

on Flanger Agogo2 Sw on

Flanger ChekereS6

Phaser ChekereS6

Resntr1 BongoH3

74 D 4

Flanger HandBellC Sw

on Flanger Agogo3 Sw on

Flanger ChekereST

Phaser ChekereST

Resntr1 BongoH4

75 D# 4

Flanger MamboBell Sw

on Flanger FunkBell1 on Flanger ChekereL on Phaser ChekereL on

Resntr1 BongoH5

76 E 4

Flanger ChaChaBell Sw

on Flanger FunkBell2 on

Flanger ChekereLT

Phaser ChekereLT

Resntr1 BongoH6

77 F 4

Flanger SongoBellH SwonFlanger WdBlkLarge Sw

Flanger Maracas1

Phaser Maracas1

78 F# 4

Flanger SongoBellL SwonFlanger WdBlkSmall Sw

Flanger Maracas2

Phaser Maracas2

79 G 4 Flanger FunkBell1 on

Flanger TriangleL1 Sw

on on

Flanger Maracas3

Phaser Maracas3

80 G# 42 Flanger FunkBell2 on

Flanger TriangleL2 Sw

Flanger Maracas4

Phaser Maracas4

81 A 4 2

Flanger WdBlkLarge Sw

Flanger TriangleS1 Sw

on on

82 A# 4

Flanger WdBlkSmall Sw

Flanger TriangleS2 Sw

83 B 4

Flanger ChekereS1 Sw

on Flanger Shaker1 Sw on

84 C 5

Flanger ChekereS2 Sw

on Flanger Shaker2 Sw on

85 C# 5

Flanger ChekereS3 Sw

on Flanger Shaker3 Sw on

86 D 5 Flanger ChekereST on

Flanger CabassaL1 Sw

on on

87 D# 5 Flanger ChekereL on

Flanger CabassaL2 Sw

on on

88 E 5 Flanger ChekereLT on

Flanger CabassaL3 Sw

on on

89 F 5

Flanger Maracas1 Sw

on Flanger CabassaL4 on on

90 F# 5

Flanger Maracas2 Sw

on Flanger CabassaL5 on on

91 G 5 Flanger Guiro1 Sw on on Flanger CaxixiL1 Sw on 92 G# 5 Flanger Guiro2 Sw on on Flanger CaxixiL2 Sw on 93 A 5 Flanger Guiro3 Sw on Flanger CaxixiL3 Sw on 94 A# 5 Flanger Guiro4 Sw on Flanger CaxixiS1 Sw on 95 B 5 Flanger Claves1 Sw on Flanger CaxixiS2 Sw on 96 C 6 Flanger Claves2 Sw on Flanger Cuica1 on on 97 C# 6 Flanger Guira1 on on Flanger Cuica2 on on 98 D 6 Flanger Guira2 on on Flanger Cuica3 on on 99 D# 6 Flanger Guira3 on Flanger Cuica4 on on

100 E 6 Flanger Guira4 on Flanger Cuica5 on on 101 F 6 Flanger Cuica6 on on 102 F# 6 Flanger Cuica7 on on 103 G 6 Flanger Whistle1 on 104 G# 6 Flanger Whistle2 on 105 A 6 Flanger Whistle3 on on 106 A# 6 Flanger Whistle4 on on 107 B 6 Flanger Whistle5 on on 108 C 7 Flanger Whistle6 on on

Voice List

A : Alternate Group K : Key Off I : Insertion Effect : No sound

* The Alternate Group settings have been programmed only for the kits listed below.

Pgm# 4 GMPerc, Pgm#10 GMLtnDr, Pgm#23 DlyGMPrc, Pgm#24 DlyGMltn, Pgm#29 ODGMLtn, Pgm#33 Dst1GMLt, Pgm#37 Dst2GMLtn, Pgm#64 RvbGMPc, Pgm#69 RvbGMLtn

None of the other kits (excepting those above) have Alternate Group settings.

45 46 47 48 49 50 51

Rs2Kk&Sn Rs2Stick Md1AfrCb Md1Brazl Md2AfrCb Md2Brazl Md3Bells

Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I

Mod1 SurdoL1 Sw on on Mod2 SurdoL1 Sw on on Mod1 SurdoL2 Sw on on Mod2 SurdoL2 Sw on on Mod1 SurdoLLH Sw on Mod2 SurdoLLH Sw on Mod1 SurdoLRM on Mod2 SurdoLRM on Mod1 SurdoLRO on Mod2 SurdoLRO on Mod1 SurdoM1 Sw on on Mod2 SurdoM1 Sw on on Mod1 SurdoM2 Sw on on Mod2 SurdoM2 Sw on on Mod1 SurdoMLH Sw on Mod2 SurdoMLH Sw on Mod1 SurdoMRM on Mod2 SurdoMRM on Mod1 SurdoMRO on Mod2 SurdoMRO on Mod1 SurdoH1 Sw on on Mod2 SurdoH1 Sw on on Mod1 SurdoH2 Sw on on Mod2 SurdoH2 Sw on on

Resntr2 SurdoL1 on on Resntr2 SurdoL1 on on Mod1 TumbaB Sw on Mod1 SurdoHLH Sw on Mod2 TumbaB Sw on Mod2 SurdoHLH Sw on

Mod3 HandBellMO1

Resntr2 SurdoL2 on on Resntr2 SurdoL2 on on Mod1 TumbaT Sw on Mod1 SurdoHRM on Mod2 TumbaT Sw on Mod2 SurdoHRM on

Mod3 HandBellMO2

Resntr2 SurdoL3 on on Resntr2 SurdoL3 on on Mod1 TumbaSC Sw on Mod1 SurdoHRO on Mod2 TumbaSC Sw on Mod2 SurdoHRO on

Mod3 HandBellMM1

Resntr2 SurdoL4 on on Resntr2 SurdoL4 on on Mod1 TumbaM on

Mod1 RepiniqueL1 Sw

on Mod2 TumbaM on

Mod2 RepiniqueL1 SwonMod3 HandBellMM2

Resntr2 SurdoLLH1

on Resntr2 SurdoLLH1 on Mod1 TumbaO Sw on

Mod1 RepiniqueL2 Sw

on Mod2 TumbaO Sw on

Mod2 RepiniqueL2 SwonMod3 HandBellSO1

Resntr2 SurdoLLH2

on Resntr2 SurdoLLH2 on Mod1 CongaB Sw on

Mod1 RepiniqueL3 Sw

on Mod2 CongaB Sw on

Mod2 RepiniqueL3 SwonMod3 HandBellSO2

Resntr2 SurdoLRM on Resntr2 SurdoLRM on Mod1 CongaT Sw on

Mod1 RepiniqueL4 Sw

on Mod2 CongaT Sw on

Mod2 RepiniqueL4 SwonMod3 HandBellSM1

Resntr2 SurdoLRO on Resntr2 SurdoLRO on Mod1 CongaOS Sw on

Mod1 RepiniqueL5 Sw

on Mod2 CongaOS Sw on

Mod2 RepiniqueL5 SwonMod3 HandBellSM2

Resntr2 SurdoM1 on on Resntr2 SurdoM1 on on Mod1 CongaM on

Mod1 RepiniqueL6 Sw

on Mod2 CongaM on

Mod2 RepiniqueL6 SwonMod3 HandBellSM3

on Resntr2 SurdoM2 on on Resntr2 SurdoM2 on on Mod1 CongaO Sw on Mod1 RepiniqueL7 on on Mod2 CongaO Sw on Mod2 RepiniqueL7 on on Mod3 HandBellC1 on Resntr2 SurdoM3 on on Resntr2 SurdoM3 on on Mod1 CongaStick on Mod1 RepiniqueL8 on on Mod2 CongaStick on Mod2 RepiniqueL8 on on Mod3 HandBellC2 on Resntr2 SurdoM4 on on Resntr2 SurdoM4 on on Mod1 QuintoR Sw on Mod1 RepiniqueL9 on on Mod2 QuintoR Sw on Mod2 RepiniqueL9 on on Mod3 MamboBell1 on Resntr2 SurdoMLH1

on Resntr2 SurdoMLH1 on Mod1 QuintoB on

Mod1 RepiniqueH1 Sw

on Mod2 QuintoB on

Mod2 RepiniqueH1 Sw

on Mod3 MamboBell2 on

Resntr2 SurdoMLH2

on Resntr2 SurdoMLH2 on Mod1 QuintoT on

Mod1 RepiniqueH2 Sw

on Mod2 QuintoT on

Mod2 RepiniqueH2 Sw

on Mod3 MamboBell3 on

Resntr2 SurdoMRM

on Resntr2 SurdoMRM on Mod1 QuintoS Sw on

Mod1 RepiniqueH3 Sw

on Mod2 QuintoS Sw on

Mod2 RepiniqueH3 SwonMod3 ChaChaBellL1

on Resntr2 SurdoMRO

on Resntr2 SurdoMRO on Mod1 QuintoM on

Mod1 RepiniqueH4 Sw

on Mod2 QuintoM on

Mod2 RepiniqueH4 SwonMod3 ChaChaBellL2

on Resntr2 SurdoH1 on on Resntr2 SurdoH1 on on Mod1 QuintoO Sw on

Mod1 RepiniqueH5 Sw

on Mod2 QuintoO Sw on

Mod2 RepiniqueH5 Sw

on Mod3 SongoBellH1 on

Resntr2 SurdoH2 on on Resntr2 SurdoH2 on on Mod1 BongoL Sw on

Mod1 RepiniqueH6 Sw

on Mod2 BongoL Sw on

Mod2 RepiniqueH6 Sw

on Mod3 SongoBellH2 on Resntr2 SurdoH3 on on Resntr2 SurdoH3 on on Mod1 BongoH1 Sw on Mod1 Pandeiro1 Sw on Mod2 BongoH1 Sw on Mod2 Pandeiro1 Sw on Mod3 SongoBellL1 on Resntr2 SurdoH4 on on Resntr2 SurdoH4 on on Mod1 BongoH2 Sw on Mod1 Pandeiro2 Sw on Mod2 BongoH2 Sw on Mod2 Pandeiro2 Sw on Mod3 SongoBellL2 on Resntr2 SurdoHLH1

on Resntr2 SurdoHLH1 on Mod1 TimbaleL1 Sw on Mod1 Pandeiro3 Sw on Mod2 TimbaleL1 Sw on Mod2 Pandeiro3 Sw on Mod3 FunkBell1 on

Resntr2 SurdoHLH2

on Resntr2 SurdoHLH2 on Mod1 TimbaleLE on Mod1 Pandeiro4 Sw on Mod2 TimbaleLE on Mod2 Pandeiro4 Sw on Mod3 FunkBell2 on

Resntr2 SurdoHRM

on Resntr2 SurdoHRM on Mod1 TimbaleL2 Sw on Mod1 Pandeiro5 Sw on on Mod2 TimbaleL2 Sw on Mod2 Pandeiro5 Sw on on Mod3 Agogo3 on Resntr2 SurdoHRO on Resntr2 SurdoHRO on Mod1 TimbaleLM on Mod1 Pandeiro6 on on Mod2 TimbaleLM on Mod2 Pandeiro6 on on Mod3 Agogo1 on Resntr2 Caixa1 on Resntr2 RepiniqueL1 on Mod1 PailaL Sw on Mod1 Pandeiro7 on on Mod2 PailaL Sw on Mod2 Pandeiro7 on on Mod3 Agogo2 on Resntr2 Caixa2 on Resntr2 RepiniqueL2 on Mod1 TimbaleH1 Sw on Mod1 Caixa1 Sw on Mod2 TimbaleH1 Sw on Mod2 Caixa1 Sw on Mod3 Agogo4 on Resntr2 Caixa3 on Resntr2 RepiniqueL3 on Mod1 PailaH Sw on Mod1 Caixa2 Sw on Mod2 PailaH Sw on Mod2 Caixa2 Sw on Mod3 Agogo5 on Resntr2 Caixa4 on Resntr2 RepiniqueL4 on Mod1 TimbaleH2 Sw on Mod1 Caixa3 Sw on Mod2 TimbaleH2 Sw on Mod2 Caixa3 Sw on Mod3 Agogo6 on Resntr2 Caixa5 on Resntr2 RepiniqueL5 on Mod1 TimbaleHR Sw on Mod1 Caixa4 Sw on Mod2 TimbaleHR Sw on Mod2 Caixa4 Sw on Mod3 Agogo7 on Resntr2 Caixa6 on Resntr2 RepiniqueL6 on Mod1 TimbaleHE Sw on Mod1 TamborimT Sw on Mod2 TimbaleHE Sw on Mod2 TamborimT Sw on Mod3 Agogo8 on Resntr2 Caixa7 on Resntr2 RepiniqueL7 on Mod1 TimbaleF1 on Mod1 Tamborim1 Sw on Mod2 TimbaleF1 on Mod2 Tamborim1 Sw on Mod3 Agogo9 on Resntr2 Caixa8 on Resntr2 RepiniqueL8 on Mod1 TimbaleF2 on Mod1 Tamborim2 Sw on Mod2 TimbaleF2 on Mod2 Tamborim2 Sw on Resntr2 Caixa9 on Resntr2 RepiniqueL9 on Mod1 TimbaleF3 on Mod1 Tamborim3 Sw on Mod2 TimbaleF3 on Mod2 Tamborim3 Sw on Resntr2 Caixa10 on

Resntr2 RepiniqueL10

on Mod1 TimbaleF4 on Mod1 Tamborim4 Sw on Mod2 TimbaleF4 on Mod2 Tamborim4 Sw on

Resntr2 Caixa11 on

Resntr2 RepiniqueL11onMod1 HandBellMO Sw

on Mod1 Tamborim5 Sw on

Mod2 HandBellMO Sw

on Mod2 Tamborim5 Sw on

Resntr2 Caixa12 on

Resntr2 RepiniqueL12onMod1 HandBellMM Sw

on Mod1 Tamborim6 Sw on

Mod2 HandBellMM Sw

on Mod2 Tamborim6 Sw on

Resntr2 RepiniqueL13

on on

Mod1 HandBellSO Sw

on Mod1 Agogo1 Sw on

Mod2 HandBellSO Sw

on Mod2 Agogo1 Sw on

Resntr2 RepiniqueL14

on on

Mod1 HandBellSM Sw

on Mod1 Agogo2 Sw on

Mod2 HandBellSM Sw

on Mod2 Agogo2 Sw on

Resntr2 RepiniqueL15

on on Mod1 HandBellC Sw on Mod1 Agogo3 Sw on Mod2 HandBellC Sw on Mod2 Agogo3 Sw on Resntr2 RepiniqueH1 on Mod1 MamboBell Sw on Mod1 FunkBell1 on Mod2 MamboBell Sw on Mod2 FunkBell1 on Resntr2 RepiniqueH2 on

Mod1 ChaChaBell Sw

on Mod1 FunkBell2 on

Mod2 ChaChaBell Sw

on Mod2 FunkBell2 on

Resntr2 RepiniqueH3 on

Mod1 SongoBellH Sw

Mod1 WdBlkLarge Sw

Mod2 SongoBellH Sw

Mod2 WdBlkLarge Sw

Resntr2 RepiniqueH4 on Mod1 SongoBellL Sw on

Mod1 WdBlkSmall Sw

on Mod2 SongoBellL Sw on

Mod2 WdBlkSmall Sw

on Resntr2 RepiniqueH5 on Mod1 FunkBell1 on Mod1 TriangleL1 Sw on on Mod2 FunkBell1 on Mod2 TriangleL1 Sw on on Resntr2 RepiniqueH6 on Mod1 FunkBell2 on Mod1 TriangleL2 Sw on Mod2 FunkBell2 on Mod2 TriangleL2 Sw on Resntr2 RepiniqueH7 on

Mod1 WdBlkLarge Sw

on Mod1 TriangleS1 Sw on on

Mod2 WdBlkLarge Sw

on Mod2 TriangleS1 Sw on on

Resntr2 RepiniqueH8 on

Mod1 WdBlkSmall Sw

on Mod1 TriangleS2 Sw on

Mod2 WdBlkSmall Sw

on Mod2 TriangleS2 Sw on Resntr2 RepiniqueH9 on Mod1 ChekereS1 Sw on Mod1 Shaker1 Sw on Mod2 ChekereS1 Sw on Mod2 Shaker1 Sw on Resntr2 RepiniqueH10

on Mod1 ChekereS2 Sw on Mod1 Shaker2 Sw on Mod2 ChekereS2 Sw on Mod2 Shaker2 Sw on

Resntr2 RepiniqueH11

on Mod1 ChekereS3 Sw on Mod1 Shaker3 Sw on Mod2 ChekereS3 Sw on Mod2 Shaker3 Sw on

Resntr2 RepiniqueH12

on Mod1 ChekereST on Mod1 CabassaL1 Sw on on Mod2 ChekereST on Mod2 CabassaL1 Sw on on

Mod1 ChekereL on Mod1 CabassaL2 Sw on on Mod2 ChekereL on Mod2 CabassaL2 Sw on on Mod1 ChekereLT on Mod1 CabassaL3 Sw on on Mod2 ChekereLT on Mod2 CabassaL3 Sw on on Mod1 Maracas1 Sw on Mod1 CabassaL4 on on Mod2 Maracas1 Sw on Mod2 CabassaL4 on on Mod1 Maracas2 Sw on Mod1 CabassaL5 on on Mod2 Maracas2 Sw on Mod2 CabassaL5 on on Mod1 Guiro1 Sw on on Mod1 CaxixiL1 Sw on Mod2 Guiro1 Sw on on Mod2 CaxixiL1 Sw on Mod1 Guiro2 Sw on on Mod1 CaxixiL2 Sw on Mod2 Guiro2 Sw on on Mod2 CaxixiL2 Sw on Mod1 Guiro3 Sw on Mod1 CaxixiL3 Sw on Mod2 Guiro3 Sw on Mod2 CaxixiL3 Sw on Mod1 Guiro4 Sw on Mod1 CaxixiS1 Sw on Mod2 Guiro4 Sw on Mod2 CaxixiS1 Sw on Mod1 Claves1 Sw on Mod1 CaxixiS2 Sw on Mod2 Claves1 Sw on Mod2 CaxixiS2 Sw on Mod1 Claves2 Sw on Mod1 Cuica1 on on Mod2 Claves2 Sw on Mod2 Cuica1 on on Mod1 Guira1 on on Mod1 Cuica2 on on Mod2 Guira1 on on Mod2 Cuica2 on on Mod1 Guira2 on on Mod1 Cuica3 on on Mod2 Guira2 on on Mod2 Cuica3 on on Mod1 Guira3 on Mod1 Cuica4 on on Mod2 Guira3 on Mod2 Cuica4 on on Mod1 Guira4 on Mod1 Cuica5 on on Mod2 Guira4 on Mod2 Cuica5 on on

Mod1 Cuica6 on on Mod2 Cuica6 on on Mod1 Cuica7 on on Mod2 Cuica7 on on Mod1 Whistle1 on Mod2 Whistle1 on Mod1 Whistle2 on Mod2 Whistle2 on on Mod1 Whistle3 on on Mod2 Whistle3 on on Mod1 Whistle4 on on Mod2 Whistle4 on on Mod1 Whistle5 on on Mod2 Whistle5 on on Mod1 Whistle6 on on Mod2 Whistle6 on on

Voice List

PC Instrument Map MSB=79, LSB=1

A : Alternate Group K : Key Off I : Insertion Effect : No sound

* The Alternate Group settings have been programmed only for the kits listed below.

Pgm# 4 GMPerc, Pgm#10 GMLtnDr, Pgm#23 DlyGMPrc, Pgm#24 DlyGMltn, Pgm#29 ODGMLtn, Pgm#33 Dst1GMLt, Pgm#37 Dst2GMLtn, Pgm#64 RvbGMPc, Pgm#69 RvbGMLtn

None of the other kits (excepting those above) have Alternate Group settings.

Program No. 52 53 54 55 56 57 58

Kit Name Md3Shkrs Md4BrHd1 Md4BrHd2 Md5BrHd1 Md5BrHd2 PchBells PchShkrs

Note#

Note A Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I

13 C# -1 3 14 D -1 3 15 D# -1 16 E -1 17 F -1 18 F# -1 19 G -1 20 G# -1 21 A -1 22 A# -1 23 B -1 24 C 0 25 C# 0 26 D 0 27 D# 0 28 E 0 29 F 0 30 F# 0 31 G 0 32 G# 0 33 A 0 34 A# 0 35 B 0 36 C 1 Mod3 Shaker1 on Mod4 Pandeiro1 on Mod4 TriangleL1 on on Mod5 Pandeiro1 on Mod5 TriangleL1 on on

Pitch HandBellMO1

Pitch Shaker1

37 C# 1 Mod3 Shaker2 on Mod4 Pandeiro2 on Mod4 TriangleL2 on on Mod5 Pandeiro2 on Mod5 TriangleL2 on on

Pitch HandBellMO2

Pitch Shaker2

38 D 1 Mod3 Shaker3 on Mod4 Pandeiro3 on Mod4 TriangleL3 on on Mod5 Pandeiro3 on Mod5 TriangleL3 on on

Pitch HandBellMM1

Pitch Shaker3

39 D# 1 Mod3 Shaker4 on Mod4 Pandeiro4 on Mod4 TriangleL4 on Mod5 Pandeiro4 on Mod5 TriangleL4 on

Pitch HandBellMM2

Pitch Shaker4 40 E 1 Mod3 Shaker5 on Mod4 Pandeiro5 on Mod4 TriangleL5 on Mod5 Pandeiro5 on Mod5 TriangleL5 on Pitch HandBellSO1 Pitch Shaker5 41 F 1 Mod3 Shaker6 on Mod4 Pandeiro6 on Mod4 TriangleL6 on Mod5 Pandeiro6 on Mod5 TriangleL6 on Pitch HandBellSO2 Pitch Shaker6 42 F# 1 Mod3 Shaker7 on Mod4 Pandeiro7 on Mod4 TriangleS1 on on Mod5 Pandeiro7 on Mod5 TriangleS1 on on Pitch HandBellSM1 Pitch Shaker7 43 G 1 Mod3 Shaker8 on Mod4 Pandeiro8 on Mod4 TriangleS2 on on Mod5 Pandeiro8 on Mod5 TriangleS2 on on Pitch HandBellSM2 Pitch Shaker8 44 G# 1 Mod3 Shaker9 on Mod4 Pandeiro9 on Mod4 TriangleS3 on on Mod5 Pandeiro9 on Mod5 TriangleS3 on on Pitch HandBellSM3 Pitch Shaker9 45 A 1 Mod3 Shaker10 on Mod4 Pandeiro10 on Mod4 TriangleS4 on Mod5 Pandeiro10 on Mod5 TriangleS4 on Pitch HandBellC1 Pitch Shaker10 46 A# 1 Mod3 Shaker11 on Mod4 Pandeiro11 on Mod4 TriangleS5 on Mod5 Pandeiro11 on Mod5 TriangleS5 on Pitch HandBellC2 Pitch Shaker11 47 B 1 Mod3 Shaker12 on Mod4 Pandeiro12 on Mod4 TriangleS6 on Mod5 Pandeiro12 on Mod5 TriangleS6 on Pitch MamboBell1 Pitch Shaker12 48 C 2 Mod3 CabassaL1 on on Mod4 Pandeiro13 on on Mod4 Shaker1 on Mod5 Pandeiro13 on on Mod5 Shaker1 on Pitch MamboBell2 Pitch CabassaL1 on 49 C# 2 Mod3 CabassaL2 on on Mod4 Pandeiro14 on on Mod4 Shaker2 on Mod5 Pandeiro14 on on Mod5 Shaker2 on Pitch MamboBell3 Pitch CabassaL2 on 50 D 2 Mod3 CabassaL3 on on Mod4 Pandeiro15 on on Mod4 Shaker3 on Mod5 Pandeiro15 on on Mod5 Shaker3 on

Pitch ChaChaBellL1

Pitch CabassaL3 on 51 D# 2 Mod3 CabassaL4 on on Mod4 Pandeiro16 on on Mod4 Shaker4 on Mod5 Pandeiro16 on on Mod5 Shaker4 on

Pitch ChaChaBellL2

Pitch CabassaL4 on 52 E 2 Mod3 CabassaL5 on on Mod4 Pandeiro17 on on Mod4 Shaker5 on Mod5 Pandeiro17 on on Mod5 Shaker5 on Pitch SongoBellH1 Pitch CabassaL5 on 53 F 2 Mod3 CabassaL6 on on Mod4 TamborimT1 on Mod4 Shaker7 on Mod5 TamborimT1 on Mod5 Shaker7 on Pitch SongoBellH2 Pitch CabassaL6 on 54 F# 2 Mod3 CabassaL7 on on Mod4 TamborimT2 on Mod4 Shaker6 on Mod5 TamborimT2 on Mod5 Shaker6 on Pitch SongoBellL1 Pitch CabassaL7 on 55 G 2 Mod3 CabassaL8 on on Mod4 Tamborim1 on Mod4 Shaker8 on Mod5 Tamborim1 on Mod5 Shaker8 on Pitch SongoBellL2 Pitch CabassaL8 on 56 G# 2 Mod3 CabassaL9 on on Mod4 Tamborim2 on Mod4 Shaker9 on Mod5 Tamborim2 on Mod5 Shaker9 on Pitch FunkBell1 Pitch CabassaL9 on 57 A 2

Mod3 CabassaL10

on on Mod4 Tamborim3 on Mod4 Shaker10 on Mod5 Tamborim3 on Mod5 Shaker10 on Pitch FunkBell2

Pitch CabassaL10

58 A# 2 Mod3 CaxixiL1 on Mod4 Tamborim4 on Mod4 Shaker11 on Mod5 Tamborim4 on Mod5 Shaker11 on Pitch Agogo3 Pitch CaxixiL1 59 B 2 Mod3 CaxixiL2 on Mod4 Tamborim5 on Mod4 Shaker12 on Mod5 Tamborim5 on Mod5 Shaker12 on Pitch Agogo1 on Pitch CaxixiL2 60 C 3 Mod3 CaxixiL3 on Mod4 Tamborim6 on Mod4 CabassaL1 on on Mod5 Tamborim6 on Mod5 CabassaL1 on on Pitch Agogo2 on Pitch CaxixiL3 61 C# 3 Mod3 CaxixiL4 on Mod4 Tamborim7 on Mod4 CabassaL2 on on Mod5 Tamborim7 on Mod5 CabassaL2 on on Pitch Agogo4 on Pitch CaxixiL4 62 D 3 Mod3 CaxixiL5 on Mod4 Tamborim8 on Mod4 CabassaL3 on on Mod5 Tamborim8 on Mod5 CabassaL3 on on Pitch Agogo5 Pitch CaxixiL5 63 D# 3 Mod3 CaxixiL6 on Mod4 Tamborim9 on Mod4 CabassaL4 on on Mod5 Tamborim9 on Mod5 CabassaL4 on on Pitch Agogo6 on Pitch CaxixiL6 64 E 3 Mod3 CaxixiS1 on Mod4 Tamborim10 on Mod4 CabassaL5 on on Mod5 Tamborim10 on Mod5 CabassaL5 on on Pitch Agogo7 Pitch CaxixiS1 65 F 3 Mod3 CaxixiS2 on Mod4 Tamborim11 on Mod4 CabassaL6 on on Mod5 Tamborim11 on Mod5 CabassaL6 on on Pitch Agogo8 Pitch CaxixiS2 on 66 F

# 3 Mod3 CaxixiS3 on Mod4 Tamborim12 on Mod4 CabassaL7 on on Mod5 Tamborim12 on Mod5 CabassaL7 on on Pitch Agogo9 Pitch CaxixiS3 on

67 G 3 Mod3 CaxixiS4 on Mod4 Tamborim13 on Mod4 CabassaL8 on on Mod5 Tamborim13 on Mod5 CabassaL8 on on

Pitch CaxixiS4 on 68 G# 3 Mod3 ChekereS1 on Mod4 Agogo1 on Mod4 CabassaL9 on on Mod5 Agogo1 on Mod5 CabassaL9 on on Pitch ChekereS1 on 69 A 3 Mod3 ChekereS2 on Mod4 Agogo2 on

Mod4 CabassaL10

on on Mod5 Agogo2 on

Mod5 CabassaL10

on on Pitch ChekereS2 on

70 A# 3 Mod3 ChekereS3 on Mod4 Agogo3 on Mod4 CaxixiL1 on Mod5 Agogo3 on Mod5 CaxixiL1 on Pitch ChekereS3 on 71 B 3 Mod3 ChekereS4 on Mod4 Agogo4 on Mod4 CaxixiL2 on Mod5 Agogo4 on Mod5 CaxixiL2 on

Pitch ChekereS4 on 72 C 4 Mod3 ChekereS5 on Mod4 Agogo5 on Mod4 CaxixiL3 on Mod5 Agogo5 on Mod5 CaxixiL3 on

Pitch ChekereS5 on 73 C# 4 Mod3 ChekereS6 on Mod4 Agogo6 on Mod4 CaxixiL4 on Mod5 Agogo6 on Mod5 CaxixiL4 on Pitch ChekereS6 on 74 D 4 Mod3 ChekereST on Mod4 Agogo7 on Mod4 CaxixiL5 on Mod5 Agogo7 on Mod5 CaxixiL5 on Pitch ChekereST on 75 D# 4 Mod3 ChekereL on Mod4 Agogo8 on Mod4 CaxixiL6 on Mod5 Agogo8 on Mod5 CaxixiL6 on Pitch ChekereL on 76 E 4 Mod3 ChekereLT on Mod4 Agogo9 on Mod4 CaxixiS1 on Mod5 Agogo9 on Mod5 CaxixiS1 on

Pitch ChekereLT on 77 F 4 Mod3 Maracas1 on Mod4 FunkBell1 on Mod4 CaxixiS2 on Mod5 FunkBell1 on Mod5 CaxixiS2 on

Pitch Maracas1 on 78 F# 4 Mod3 Maracas2 on Mod4 FunkBell2 on Mod4 CaxixiS3 on Mod5 FunkBell2 on Mod5 CaxixiS3 on Pitch Maracas2 on 79 G 4 Mod3 Maracas3 on

Mod4 WdBlkLarge1

on Mod4 CaxixiS4 on

Mod5 WdBlkLarge1

on Mod5 CaxixiS4 on Pitch Maracas3 on

80 G# 4 2 Mod3 Maracas4 on

Mod4 WdBlkLarge2

on Mod4 Cuica1 on on

Mod5 WdBlkLarge2

on Mod5 Cuica1 on on Pitch Maracas4 on

81 A 4 2

Mod4 WdBlkSmall1

on Mod4 Cuica2 on on

Mod5 WdBlkSmall1

on Mod5 Cuica2 on on

82 A# 4

Mod4 WdBlkSmall2

on Mod4 Cuica3 on on

Mod5 WdBlkSmall2

on Mod5 Cuica3 on on 83 B 4 Mod4 Cuica4 on on Mod5 Cuica4 on on 84 C 5 Mod4 Cuica5 on on Mod5 Cuica5 on on 85 C# 5 Mod4 Cuica6 on on Mod5 Cuica6 on on 86 D 5 Mod4 Cuica7 on on Mod5 Cuica7 on on 87 D# 5 Mod4 Whistle1 on Mod5 Whistle1 on 88 E 5 Mod4 Whistle2 on Mod5 Whistle2 on 89 F 5 Mod4 Whistle3 on Mod5 Whistle3 on 90 F# 5 Mod4 Whistle4 on on Mod5 Whistle4 on on 91 G 5 Mod4 Whistle5 on on Mod5 Whistle5 on on 92 G# 5 Mod4 Whistle6 on on Mod5 Whistle6 on on 93 A 5 Mod4 Whistle7 on on Mod5 Whistle7 on on 94 A# 5 Mod4 Whistle8 on on Mod5 Whistle8 on on 95 B 5 Mod4 Whistle9 on on Mod5 Whistle9 on on 96 C 6 Mod4 Whistle10 on on Mod5 Whistle10 on on 97 C# 6 98 D 6 99 D# 6

100 E 6 101 F 6 102 F# 6 103 G 6 104 G# 6 105 A 6 106 A# 6 107 B 6 108 C 7

Voice List

A : Alternate Group K : Key Off I : Insertion Effect : No sound

* The Alternate Group settings have been programmed only for the kits listed below.

Pgm# 4 GMPerc, Pgm#10 GMLtnDr, Pgm#23 DlyGMPrc, Pgm#24 DlyGMltn, Pgm#29 ODGMLtn, Pgm#33 Dst1GMLt, Pgm#37 Dst2GMLtn, Pgm#64 RvbGMPc, Pgm#69 RvbGMLtn

None of the other kits (excepting those above) have Alternate Group settings.

59 60 61 62 63 64 65 66

PchSkins PchStick RevAfrCb RevBrazl RevMotif RevGMPrc RevAfC61 RevBrz61

Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I

Rev SurdoL1 Sw on Rev GMClick Rev SurdoL2 Sw on Rev SurdoLLH Sw Rev SurdoLRM Rev SurdoLRO Rev SurdoM1 Sw on Rev SurdoM2 Sw on Rev SurdoMLH Sw Rev SurdoMRM Rev SurdoMRO Rev SurdoH1 Sw on Rev SurdoH2 Sw on

Pitch TumbaB1

Pitch SurdoL1 on on Rev TumbaB Sw

Rev SurdoHLH Sw

Rev TumbaB Sw Rev TumbaB Sw Rev SurdoL1 Sw on

Pitch TumbaB2

Pitch SurdoL2 on Rev TumbaT Sw Rev SurdoHRM Rev TumbaT Sw Rev TumbaT Sw Rev SurdoL2 Sw on

Pitch TumbaT1

Pitch SurdoL3 on on Rev TumbaSC Sw Rev SurdoHRO Rev TumbaSC Sw Rev TumbaSC Sw Rev SurdoM1 Sw on

Pitch TumbaT2

Pitch SurdoL4 on Rev TumbaM

Rev RepiniqueL1 Sw

Rev Claves2 Sw Rev TumbaM Rev SurdoM2 Sw on

Pitch TumbaSC1

Pitch SurdoLLH1 Rev TumbaO Sw

Rev RepiniqueL2 Sw

Rev TumbaO Sw Rev TumbaO Sw Rev SurdoH1 Sw on

Pitch TumbaSC2

Pitch SurdoLLH2 Rev CongaB Sw

Rev RepiniqueL3 Sw

Rev CongaB Sw Rev CongaB Sw Rev SurdoH2 Sw on

Pitch TumbaSC3

Pitch SurdoLRM on Rev CongaT Sw

Rev RepiniqueL4 Sw

Rev CongaT Sw Rev CongaT Sw

Rev RepiniqueL1 Sw

Pitch TumbaM Pitch SurdoLRO

Rev CongaOS Sw

Rev RepiniqueL5 Sw

Rev CongaOS Sw Rev CongaOS Sw

Rev RepiniqueL2 Sw

Pitch TumbaO1

Pitch SurdoM1 on Rev CongaM

Rev RepiniqueL6 Sw Rev HandBellMO Sw

Rev CongaM

Rev RepiniqueL3 Sw

Pitch TumbaO2

Pitch SurdoM2 on Rev CongaO Sw Rev RepiniqueL7 on Rev CongaO Sw Rev CongaO Sw

Rev RepiniqueL4 Sw

Pitch TumbaO3

Pitch SurdoM3 on Rev CongaStick Rev RepiniqueL8 on

Rev HandBellSM Sw

Rev CongaStick

Rev RepiniqueL5 Sw

Pitch CongaB1

Pitch SurdoM4 on Rev QuintoR Sw Rev RepiniqueL9 on

Rev MamboBell Sw

Rev QuintoR Sw

Rev RepiniqueL6 Sw

Pitch CongaB2 Pitch SurdoMLH1

Rev QuintoB

Rev RepiniqueH1 Sw

Rev QuintoB Rev QuintoB

Rev RepiniqueL10

Pitch CongaT1 Pitch SurdoMLH2

Rev QuintoT

Rev RepiniqueH2 Sw

Rev QuintoT Rev QuintoT

Rev RepiniqueH1 Sw

Pitch CongaT2

Pitch SurdoMRM Rev QuintoS Sw

Rev RepiniqueH3 Sw

Rev QuintoS Sw Rev QuintoS Sw

Rev RepiniqueH2 Sw

Pitch CongaOS1

Pitch SurdoMRO on Rev QuintoM

Rev RepiniqueH4 Sw

Rev ChaChaBell Sw

Rev QuintoM

Rev RepiniqueH3 Sw

Pitch CongaOS2

Pitch SurdoH1 on on Rev QuintoO Sw

Rev RepiniqueH5 Sw

Rev QuintoO Sw Rev QuintoO Sw

Rev RepiniqueH4 Sw

Pitch CongaOS3

on Pitch SurdoH2 on on Rev BongoL Sw

Rev RepiniqueH6 Sw

Rev BongoL Sw Rev BongoL Sw

Rev RepiniqueH5 Sw

Pitch CongaM on Pitch SurdoH3 on on Rev BongoH1 Sw

Rev Pandeiro1 Sw

Rev BongoH1 Sw Rev BongoH1 Sw

Rev RepiniqueH6 Sw

Pitch CongaO1

on Pitch SurdoH4 on Rev BongoH2 Sw

Rev Pandeiro2 Sw

Rev BongoH2 Sw Rev BongoH2 Sw

Rev Pandeiro1 Sw

Pitch CongaO2onPitch SurdoHLH1 Rev TimbaleL1 Sw Rev Pandeiro3 Sw

Rev TimbaleL3 Rev GMCowbell

Rev TimbaleL1 Sw Rev Pandeiro2 Sw

Pitch CongaO3onPitch SurdoHLH2

Rev TimbaleLE

Rev Pandeiro4 Sw

Rev PailaL Sw Rev TimbaleLE

Rev Pandeiro3 Sw

Pitch CongaStick

on Pitch SurdoHRM on

Rev TimbaleL2 Sw Rev Pandeiro5 Sw

on Rev TimbaleH3

Rev TimbaleL2 Sw Rev Pandeiro4 Sw

Pitch QuintoR1

on Pitch SurdoHRO on Rev TimbaleLM Rev Pandeiro6 on Rev PailaH Sw Rev TimbaleLM

Rev Pandeiro5 Sw

Pitch QuintoR2onPitch RepiniqueL1

Rev PailaL Sw Rev Pandeiro7 on

Rev WdBlkLarge Sw

Rev GMBongoH Rev PailaL Sw Rev Caixa5

Pitch QuintoB on

Pitch RepiniqueL2

Rev TimbaleH1 Sw

Rev Caixa1 Sw

Rev WdBlkSmall Sw

Rev GMBongoL

Rev TimbaleH1 Sw

Rev Caixa2 Sw

Pitch QuintoT on

Pitch RepiniqueL3

Rev PailaH Sw Rev Caixa2 Sw

Rev ChekereS1 Sw

Rev GMCongaHMt

Rev PailaH Sw Rev Caixa4 Sw

Pitch QuintoS1onPitch RepiniqueL4

Rev TimbaleH2 Sw

Rev Caixa3 Sw

Rev ChekereS3 Sw Rev GMCongaHOp

Rev TimbaleH2 Sw

Rev TamborimT Sw

Pitch QuintoS2onPitch RepiniqueL5 Rev TimbaleHR Sw

Rev Caixa4 Sw Rev ChekereST Rev GMCongaL

Rev TimbaleHR Sw Rev Tamborim1 Sw

Pitch QuintoM on

Pitch RepiniqueL6onRev TimbaleHE Sw Rev TamborimT Sw

Rev Maracas1 Sw

Rev GMTimbaleH

Rev TimbaleHE Sw Rev Tamborim2 Sw

Pitch QuintoO1onPitch RepiniqueL7

Rev TimbaleF1

Rev Tamborim1 Sw

Rev Maracas2 Sw

Rev GMTimbaleL Rev TimbaleF1

Rev Tamborim3 Sw

Pitch QuintoO2onPitch RepiniqueL8

Rev TimbaleF2

Rev Tamborim2 Sw

Rev Guiro1 Sw on Rev GMAgogoH Rev Guira1 on

Rev Tamborim4 Sw

Pitch BongoL1onPitch RepiniqueL9

on Rev TimbaleF3

Rev Tamborim3 Sw

Rev Guiro3 Sw Rev GMAgogoL Rev Guira2 on

Rev Tamborim5 Sw

Pitch BongoL2onPitch RepiniqueL10

Rev TimbaleF4

Rev Tamborim4 Sw

Rev Guiro4 Sw Rev GMCabassa on Rev Guira5 on

Rev Tamborim6 Sw

Pitch BongoL3onPitch RepiniqueL11 Rev HandBellMO Sw

Rev Tamborim5 Sw

Rev SurdoL2 Sw on Rev GMMaracas

Rev HandBellMO Sw

Rev Agogo1 Sw

Pitch BongoH1onPitch RepiniqueL12 Rev HandBellMM Sw

Rev Tamborim6 Sw

Rev SurdoL1 Sw on Rev GMWhistleH on

Rev HandBellMM Sw

Rev Agogo2 Sw

Pitch BongoH2onPitch RepiniqueL13onRev HandBellSO Sw

Rev Agogo1 Sw

Rev Pandeiro3 Sw

Rev GMWhistleL on

Rev HandBellSO Sw

Rev Agogo3 Sw

Pitch BongoH3onPitch RepiniqueL14onRev HandBellSM Sw

Rev Agogo2 Sw

Rev Pandeiro2 Sw

Rev GMGuiroShort

Rev HandBellSM Sw

Rev FunkBell1

Pitch BongoH4onPitch RepiniqueL15onRev HandBellC Sw

Rev Agogo3 Sw

Rev Pandeiro4 Sw Rev GMGuiroLongonRev HandBellC Sw

Rev FunkBell2

Pitch BongoH5onPitch RepiniqueH1onRev MamboBell Sw

Rev FunkBell1

Rev Pandeiro1 Sw

Rev GMClaves

Rev MamboBell Sw

Rev WdBlkLarge Sw

Pitch BongoH6onPitch RepiniqueH2

Rev ChaChaBell Sw

Rev FunkBell2

Rev TamborimT Sw

Rev GMWoodBlockH Rev ChaChaBell Sw Rev WdBlkSmall Sw

Pitch RepiniqueH3 Rev SongoBellH Sw

Rev WdBlkLarge Sw

Rev Tamborim2 Sw

Rev GMWoodBlockL

Rev SongoBellH Sw

Rev TriangleL1 Sw

Pitch RepiniqueH4onRev SongoBellL Sw

Rev WdBlkSmall Sw

Rev Tamborim1 Sw

Rev GMCuicaMt on

Rev SongoBellL Sw

Rev TriangleL2 Sw

Pitch RepiniqueH5

on Rev FunkBell1

Rev TriangleL1 Sw

on Rev Agogo1 Sw Rev GMCuicaOp on Rev FunkBell1

Rev TriangleS1 Sw

Pitch RepiniqueH6

on Rev FunkBell2

Rev TriangleL2 Sw

Rev Agogo2 Sw

Rev GMTriangleMt

Rev FunkBell2

Rev TriangleS2 Sw

Pitch RepiniqueH7onRev WdBlkLarge Sw

Rev TriangleS1 Sw

on Rev Agogo3 Sw

Rev GMTriangleOp Rev WdBlkLarge Sw

Rev Shaker1 Sw

Pitch RepiniqueH8onRev WdBlkSmall Sw

Rev TriangleS2 Sw Rev TriangleS1 Sw

on Rev GMShaker

Rev WdBlkSmall Sw

Rev Shaker2 Sw

Pitch RepiniqueH9onRev ChekereS1 Sw

Rev Shaker1 Sw

Rev TriangleS2 Sw

Rev ChekereS1 Sw

Rev Shaker3 Sw

Pitch RepiniqueH10onRev ChekereS2 Sw

Rev Shaker2 Sw Rev Shaker1 Sw

Rev ChekereS2 Sw Rev CabassaL1 Sw

Pitch RepiniqueH11onRev ChekereS3 Sw

Rev Shaker3 Sw Rev Shaker2 Sw

Rev ChekereS3 Sw Rev CabassaL2 Sw

Pitch RepiniqueH12

on Rev ChekereST

Rev CabassaL1 Sw

on Rev Shaker3 Sw Rev ChekereST

Rev CabassaL3 Sw

Rev ChekereL

Rev CabassaL2 SwonRev CabassaL1 Sw

on Rev ChekereL Rev CaxixiL1 Sw

Rev ChekereLT

Rev CabassaL3 SwonRev CabassaL3 Sw

on Rev ChekereLT Rev CaxixiL2 Sw

Rev Maracas1 Sw

Rev CabassaL4 on Rev CaxixiS2 Sw

Rev Maracas1 Sw

Rev CaxixiL3 Sw

Rev Maracas2 Sw

Rev CabassaL5 on Rev CaxixiL1 Sw

Rev Maracas2 Sw

Rev CaxixiS1 Sw Rev Guiro1 Sw on Rev CaxixiL1 Sw Rev Cuica3 Rev Guiro1 Sw on Rev CaxixiS2 Sw Rev Guiro2 Sw on Rev CaxixiL2 Sw Rev Cuica6 Rev Guiro2 Sw on Rev Cuica3 on Rev Guiro3 Sw Rev CaxixiL3 Sw Rev Whistle3 on Rev Guiro3 Sw Rev Cuica6 on Rev Guiro4 Sw Rev CaxixiS1 Sw Rev Whistle7 on Rev Guiro4 Sw Rev Whistle1 Rev Claves1 Sw Rev CaxixiS2 Sw Rev Claves1 Sw Rev Whistle2 Rev Claves2 Sw Rev Cuica1 on Rev Claves2 Sw Rev Whistle3 on Rev Guira1 on Rev Cuica2 on Rev Guira2 on Rev Cuica3 on Rev Guira3 Rev Cuica4 on Rev Guira4 Rev Cuica5 on

Rev Cuica6 on Rev Cuica7 on Rev Whistle1 Rev Whistle2 Rev Whistle3 on Rev Whistle4 on Rev Whistle5 on Rev Whistle6 on

Voice List

PC Instrument Map MSB=79, LSB=1

A : Alternate Group K : Key Off I : Insertion Effect : No sound

* The Alternate Group settings have been programmed only for the kits listed below.

Pgm# 4 GMPerc, Pgm#10 GMLtnDr, Pgm#23 DlyGMPrc, Pgm#24 DlyGMltn, Pgm#29 ODGMLtn, Pgm#33 Dst1GMLt, Pgm#37 Dst2GMLtn, Pgm#64 RvbGMPc, Pgm#69 RvbGMLtn

None of the other kits (excepting those above) have Alternate Group settings.

Program No. 67 68 69 70 71 72 73

Kit Name RvACPgDR RvBrPgDR RvLtPgDR RevGMLtn RevLvPop RevKk&Sn RevACHnd

Note#

Note A Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I

13 C# -1 3 Rev GMSurdo1 on 14 D -1 3 Rev GMSurdo2 on 15 D# -1 Rev GMCuica1 on 16 E -1

Rev GMTamborim1

17 F -1 Rev GMCuica2 on 18 F# -1 Rev GMCuica3 on 19 G -1

Rev GMCabassa1

20 G# -1

Rev GMTamborim2

21 A -1 Rev GMCaixa1 22 A# -1 Rev GMCaixa2 Rev CongaT Sw 23 B -1 Rev GMClaves1 Rev CongaB Sw 24 C 0 Rev GMClaves2 Rev CongaO Sw 25 C# 0 Rev GMShaker1 Rev CongaM 26 D 0 Rev GMShaker2

Rev CongaOS2 Sw

27 D# 0 Rev GMShaker3 Rev CongaOS3 28 E 0 Rev GMShaker4 Rev QuintoS Sw 29 F 0

Rev GMRepinique1

on Rev TumbaT Sw

30 F# 0 Rev GMClaves3 Rev TumbaB Sw 31 G 0 Rev GMCaixa3 Rev TumbaO Sw 32 G# 0 Rev GMCaixa4 Rev TumbaM 33 A 0 Rev GMSurdo3 on

Rev TumbaSC2 Sw

34 A# 0 Rev GMCaixa5 Rev TumbaSC3 35 B 0 Rev GMSurdo4 on 36 C 1 Rev GMSurdo5 on Rev BongoH3 Rev MnSurdoL1 on

Rev MnHandBellMO1

37 C# 1

Rev GMRepinique2

Rev BongoH4 Rev MnSurdoL2 on

Rev MnHandBellMO2

38 D 1 Rev GMCaixa6 Rev BongoH5 Rev MnSurdoL3 on

Rev MnHandBellMM1

39 D# 1

Rev GMRepinique3

on Rev BongoH6 Rev MnSurdoL4 on

Rev MnHandBellMM2

40 E 1 Rev GMCaixa7 Rev BongoH7

Rev MnSurdoLLH1 Rev MnHandBellSO1

41 F 1 Rev GMSurdo6 on Rev BongoH8

Rev MnSurdoLLH2 Rev MnHandBellSO2

42 F# 1 Rev GMAgogo1 Rev BongoL2

Rev MnSurdoLRM

Rev MnHandBellSM1

43 G 1 Rev GMSurdo7 on Rev BongoL3

Rev MnSurdoLRO

Rev MnHandBellSM2

44 G# 1 Rev GMAgogo2 Rev BongoL4 Rev MnSurdoM1 on

Rev MnHandBellSM3

45 A 1 Rev GMSurdo8 on Rev BongoH9 Rev MnSurdoM2 on Rev MnHandBellC1 46 A# 1 Rev GMAgogo3 Rev BongoH10 Rev MnSurdoM3 on Rev MnHandBellC2 47 B 1 Rev GMSurdo9 on Rev BongoL5 Rev MnSurdoM4 on

Rev MnMamboBell1

48 C 2 Rev GMSurdo10 on Rev TimbaleL1 Sw

Rev MnSurdoMLH1

Rev MnMamboBell2

49 C# 2 Rev GMTriangle1 on Rev TimbaleLM

Rev MnSurdoMLH2

Rev MnMamboBell3

50 D 2 Rev GMSurdo11 on Rev TimbaleL2 Sw

Rev MnSurdoMRM Rev MnChaChaBellL1

51 D# 2

Rev GMMamboBell

Rev TimbaleLE

Rev MnSurdoMRO

Rev MnChaChaBellL2

52 E 2

Rev GMSongoBell1

Rev TimbaleF5 Rev MnSurdoH1 on

Rev MnSongoBellH1

53 F 2

Rev GMHandBell1

Rev PailaL Sw Rev MnSurdoH2 on

Rev MnSongoBellH2

54 F# 2 Rev GMPandeiro Rev TimbaleH4 Sw Rev MnSurdoH3 on

Rev MnSongoBellL1

55 G 2

Rev GMHandBell2

Rev TimbaleLM Rev MnSurdoH4 on

Rev MnSongoBellL2

56 G# 2 Rev GMFunkBell

Rev TimbaleHR Sw

Rev MnSurdoHLH1

Rev MnFunkBell1

57 A 2 Rev GMTriangle2 on Rev TimbaleLE

Rev MnSurdoHLH2

Rev MnFunkBell2

58 A# 2

Rev GMRepinique4

on Rev TimbaleF2

Rev MnSurdoHRM

Rev MnWdBlkLarge1

59 B 2

Rev GMSongoBell2

Rev PailaH Sw

Rev MnSurdoHRO

Rev MnWdBlkLarge2

60 C 3 Rev TumbaB Sw Rev SurdoL1 Sw on Rev SurdoL1 Sw on Rev GMBongo1

Rev HandBellMO Sw

Rev MnCaixa1

Rev MnWdBlkSmall1

61 C# 3 Rev TumbaT Sw Rev SurdoL2 Sw on Rev SurdoL2 Sw on Rev GMBongo2

Rev MamboBell Sw

Rev MnCaixa2

Rev MnWdBlkSmall2

62 D 3 Rev TumbaSC Sw

Rev RepiniqueH1 Sw

Rev TriangleS1 Sw on Rev GMConga1

Rev WdBlkSmall Sw

Rev MnCaixa3 Rev MnChekereS1

63 D# 3 Rev TumbaM

Rev RepiniqueH2 Sw

Rev TriangleS2 Sw Rev GMConga2

Rev WdBlkLarge Sw

Rev MnCaixa4 Rev MnChekereS2

64 E 3 Rev TumbaO Sw

Rev RepiniqueH3 Sw

Rev TumbaO Sw Rev GMTumba Rev Guiro3 Sw Rev MnCaixa5 Rev MnChekereS3

65 F 3 Rev CongaB Sw

Rev RepiniqueH4 Sw

Rev CongaB Sw Rev GMTimbale1 Rev Guiro1 Sw on Rev MnCaixa6 Rev MnChekereS4

66 F

# 3 Rev CongaT Sw

Rev RepiniqueH5 Sw

Rev CongaT Sw Rev GMTimbale2 Rev Claves2 Sw Rev MnCaixa7 Rev MnChekereS5

67 G 3 Rev CongaOS Sw

Rev RepiniqueH6 Sw

Rev CongaOS Sw Rev GMAgogo4 Rev MnCaixa8 Rev MnChekereS6

68 G# 3 Rev CongaM Rev RepiniqueL10 on Rev Claves2 Sw Rev GMAgogo5 Rev MnCaixa9 Rev MnChekereST 69 A 3 Rev CongaO Sw Rev Pandeiro1 Sw Rev CongaO Sw

Rev GMCabassa2

on Rev MnCaixa10 Rev MnChekereL

70 A# 3

Rev WdBlkLarge Sw

Rev Pandeiro2 Sw

Rev WdBlkLarge Sw

Rev GMMaracas Rev MnCaixa11 Rev MnChekereLT

71 B 3

Rev WdBlkSmall Sw

Rev Pandeiro3 Sw

Rev WdBlkSmall Sw

Rev GMWhistle1 on Rev MnCaixa12 Rev MnMaracas1

72 C 4 Rev QuintoB Rev Pandeiro4 Sw Rev BongoL Sw Rev GMWhistle2 on Rev Maracas4 Sw

Rev MnMaracas2

73 C# 4 Rev QuintoT Rev Caixa5 Rev BongoH1 Sw Rev GMGuiro1 Rev Shaker9 Sw Rev MnMaracas3 74 D 4 Rev QuintoS Sw Rev Caixa2 Sw Rev BongoH2 Sw Rev GMGuiro2 on

Rev CabassaL1 Sw

on Rev MnMaracas4

75 D# 4 Rev QuintoM Rev TamborimT Sw

Rev TamborimT Sw

Rev GMClaves4 Rev Cuica2 on Rev MnGuiro1 on

76 E 4 Rev QuintoO Sw Rev Tamborim1 Sw

Rev Tamborim1 Sw

Rev GMWdBlk1 Rev Cuica5 on Rev MnGuiro2 on

77 F 4 Rev BongoL Sw Rev Tamborim2 Sw

Rev Tamborim2 Sw

Rev GMWdBlk2 Rev Agogo3 Sw Rev MnGuiro3 on

78 F# 4 Rev BongoH1 Sw Rev Agogo1 Sw Rev Agogo1 Sw Rev GMCuica4 on Rev Agogo1 Sw Rev MnGuiro4 on 79 G 4 Rev BongoH2 Sw Rev Agogo2 Sw Rev Agogo2 Sw Rev GMCuica5 on Rev Agogo2 Sw Rev MnGuiro5 80 G# 4 2 Rev TimbaleL3 Rev Agogo3 Sw Rev Agogo3 Sw Rev GMTriangle3 Rev Agogo1 Sw Rev MnGuiro6 81 A 4 2 Rev TimbaleH3

Rev WdBlkLarge Sw

Rev TimbaleL3 Rev GMTriangle4 Rev TriangleS2 Sw Rev MnGuiro7

82 A

# 4 Rev PailaL Sw

Rev WdBlkSmall Sw

Rev TimbaleH3 Rev GMShaker5 Rev TriangleS1 Sw on Rev MnGuiro8 83 B 4 Rev PailaH Sw Rev TriangleL1 Sw on Rev PailaL Sw Rev GMCaxixi on Rev MnGuira1 on 84 C 5

Rev HandBellMO Sw

Rev TriangleL2 Sw Rev PailaH Sw

Rev GMCabassa3

on Rev MnGuira2 on

85 C# 5

Rev HandBellSM Sw

Rev TriangleS1 Sw on

Rev HandBellMO Sw

Rev MnGuira3

86 D 5

Rev MamboBell Sw

Rev TriangleS2 Sw

Rev HandBellSM Sw

Rev MnGuira4

87 D

# 5

Rev ChaChaBell Sw

Rev Shaker1 Sw

Rev MamboBell Sw

Rev MnClaves1

88 E 5

Rev SongoBellH Sw

Rev Shaker2 Sw Rev Shaker1 Sw Rev MnClaves2

89 F 5

Rev SongoBellL Sw

Rev Shaker3 Sw Rev Shaker2 Sw Rev MnClaves3

90 F

# 5 Rev Maracas1 Sw Rev CaxixiL1 Sw Rev Shaker3 Sw Rev MnClaves4

91 G 5 Rev Maracas2 Sw Rev CaxixiL3 Sw Rev Maracas1 Sw 92 G# 5 Rev Guiro1 Sw on Rev Cuica3 on Rev Maracas2 Sw 93 A 5 Rev Guiro2 Sw on Rev Cuica6 on Rev Guiro1 Sw on 94 A# 5 Rev Guiro3 Sw Rev Whistle1 Rev Guiro2 Sw on 95 B 5 Rev Guiro4 Sw Rev Whistle2 Rev Guiro3 Sw 96 C 6 Rev Claves2 Sw Rev Whistle3 on Rev Guiro4 Sw 97 C# 6 98 D 6 99 D# 6

100 E 6 101 F 6 102 F# 6 103 G 6 104 G# 6 105 A 6 106 A# 6 107 B 6 108 C 7

Voice List

A : Alternate Group K : Key Off I : Insertion Effect : No sound

* The Alternate Group settings have been programmed only for the kits listed below.

Pgm# 4 GMPerc, Pgm#10 GMLtnDr, Pgm#23 DlyGMPrc, Pgm#24 DlyGMltn, Pgm#29 ODGMLtn, Pgm#33 Dst1GMLt, Pgm#37 Dst2GMLtn, Pgm#64 RvbGMPc, Pgm#69 RvbGMLtn

None of the other kits (excepting those above) have Alternate Group settings.

74 75 76 77 78 79 80

RevBrHd1 RevBrHd2 RevBells RevShkrs RevSkins RevStck1 RevStck2

Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I Inst Name K I

Rev MnPandeiro1 Rev MnTriangleL1 on Rev MnHandBellMO1 Rev MnShaker1 Rev MnTumbaB1 Rev MnSurdoL1 on Rev MnTimbaleL1 Rev MnPandeiro2 Rev MnTriangleL2 on Rev MnHandBellMO2 Rev MnShaker2 Rev MnTumbaB2 Rev MnSurdoL2 on Rev MnTimbaleL2 Rev MnPandeiro3 Rev MnTriangleL3 on Rev MnHandBellMM1 Rev MnShaker3 Rev MnTumbaT1 Rev MnSurdoL3 on Rev MnTimbaleL3 Rev MnPandeiro4 Rev MnTriangleL4 Rev MnHandBellMM2 Rev MnShaker4 Rev MnTumbaT2 Rev MnSurdoL4 on Rev MnTimbaleL4 Rev MnPandeiro5 Rev MnTriangleL5 Rev MnHandBellSO1 Rev MnShaker5 Rev MnTumbaSC1 Rev MnSurdoLLH1 Rev MnTimbaleLE Rev MnPandeiro6 Rev MnTriangleL6 Rev MnHandBellSO2 Rev MnShaker6 Rev MnTumbaSC2 Rev MnSurdoLLH2 Rev MnTimbaleLM Rev MnPandeiro7 Rev MnTriangleS1 on Rev MnHandBellSM1 Rev MnShaker7 Rev MnTumbaSC3 Rev MnSurdoLRM Rev MnTimbaleH1 Rev MnPandeiro8 Rev MnTriangleS2 on Rev MnHandBellSM2 Rev MnShaker8 Rev MnTumbaM Rev MnSurdoLRO Rev MnTimbaleH2 Rev MnPandeiro9 Rev MnTriangleS3 on Rev MnHandBellSM3 Rev MnShaker9 Rev MnTumbaO1 Rev MnSurdoM1 on Rev MnTimbaleH3 Rev MnPandeiro10 Rev MnTriangleS4 Rev MnHandBellC1 Rev MnShaker10 Rev MnTumbaO2 Rev MnSurdoM2 on Rev MnTimbaleH4 Rev MnPandeiro11 Rev MnTriangleS5 Rev MnHandBellC2 Rev MnShaker11 Rev MnTumbaO3 Rev MnSurdoM3 on Rev MnTimbaleHR1 Rev MnPandeiro12 Rev MnTriangleS6 Rev MnMamboBell1 Rev MnShaker12 Rev MnCongaB1 Rev MnSurdoM4 on Rev MnTimbaleHR2 Rev MnPandeiro13 on Rev MnShaker1 Rev MnMamboBell2 Rev MnCabassaL1 on Rev MnCongaB2 Rev MnSurdoMLH1 Rev MnTimbaleHE1 Rev MnPandeiro14 on Rev MnShaker2 Rev MnMamboBell3 Rev MnCabassaL2 on Rev MnCongaT1 Rev MnSurdoMLH2 Rev MnTimbaleHE2 Rev MnPandeiro15 on Rev MnShaker3 Rev MnChaChaBellL1 Rev MnCabassaL3 on Rev MnCongaT2 Rev MnSurdoMRM Rev MnPailaL1 Rev MnPandeiro16 on Rev MnShaker4 Rev MnChaChaBellL2 Rev MnCabassaL4 on Rev MnCongaOS1 Rev MnSurdoMRO Rev MnPailaL2 Rev MnPandeiro17 on Rev MnShaker5 Rev MnSongoBellH1 Rev MnCabassaL5 on Rev MnCongaOS2 Rev MnSurdoH1 on Rev MnPailaH1 Rev MnTamborimT1 Rev MnShaker7 Rev MnSongoBellH2 Rev MnCabassaL6 on Rev MnCongaOS3 Rev MnSurdoH2 on Rev MnPailaH2 Rev MnTamborimT2 Rev MnShaker6 Rev MnSongoBellL1 Rev MnCabassaL7 on Rev MnCongaM Rev MnSurdoH3 on Rev MnTimbaleF1 Rev MnTamborim1 Rev MnShaker8 Rev MnSongoBellL2 Rev MnCabassaL8 on Rev MnCongaO1 Rev MnSurdoH4 on Rev MnTimbaleF2 Rev MnTamborim2 Rev MnShaker9 Rev MnFunkBell1 Rev MnCabassaL9 on Rev MnCongaO2 Rev MnSurdoHLH1 Rev MnTimbaleF3 Rev MnTamborim3 Rev MnShaker10 Rev MnFunkBell2 Rev MnCabassaL10 on Rev MnCongaO3 Rev MnSurdoHLH2 Rev MnTimbaleF4 Rev MnTamborim4 Rev MnShaker11 Rev MnAgogo3 Rev MnCaxixiL1 Rev MnCongaStick Rev MnSurdoHRM Rev MnTimbaleF5 Rev MnTamborim5 Rev MnShaker12 Rev MnAgogo1 Rev MnCaxixiL2 Rev MnQuintoR1 Rev MnSurdoHRO Rev MnTimbaleF6 Rev MnTamborim6 Rev MnCabassaL1 on Rev MnAgogo2 Rev MnCaxixiL3 Rev MnQuintoR2 Rev MnRepiniqueL1 Rev MnCaixa1 Rev MnTamborim7 Rev MnCabassaL2 on Rev MnAgogo4 Rev MnCaxixiL4 Rev MnQuintoB Rev MnRepiniqueL2 Rev MnCaixa2 Rev MnTamborim8 Rev MnCabassaL3 on Rev MnAgogo5 Rev MnCaxixiL5 Rev MnQuintoT Rev MnRepiniqueL3 Rev MnCaixa3 Rev MnTamborim9 Rev MnCabassaL4 on Rev MnAgogo6 Rev MnCaxixiL6 Rev MnQuintoS1 Rev MnRepiniqueL4 Rev MnCaixa4 Rev MnTamborim10 Rev MnCabassaL5 on Rev MnAgogo7 Rev MnCaxixiS1 Rev MnQuintoS2 Rev MnRepiniqueL5 Rev MnCaixa5 Rev MnTamborim11 Rev MnCabassaL6 on Rev MnAgogo8 Rev MnCaxixiS2 Rev MnQuintoM Rev MnRepiniqueL6 Rev MnCaixa6 Rev MnTamborim12 Rev MnCabassaL7 on Rev MnAgogo9 Rev MnCaxixiS3 Rev MnQuintoO1 Rev MnRepiniqueL7 Rev MnCaixa7 Rev MnTamborim13 Rev MnCabassaL8 on

Rev MnCaxixiS4 Rev MnQuintoO2 Rev MnRepiniqueL8 Rev MnCaixa8 Rev MnAgogo1 Rev MnCabassaL9 on Rev MnChekereS1 Rev MnBongoL1 Rev MnRepiniqueL9 Rev MnCaixa9 Rev MnAgogo2 Rev MnCabassaL10 on Rev MnChekereS2 Rev MnBongoL2 Rev MnRepiniqueL10 Rev MnCaixa10 Rev MnAgogo3 Rev MnCaxixiL1 Rev MnChekereS3 Rev MnBongoL3 Rev MnRepiniqueL11 Rev MnCaixa11 Rev MnAgogo4 Rev MnCaxixiL2

Rev MnChekereS4 Rev MnBongoH1 Rev MnRepiniqueL12 Rev MnCaixa12 Rev MnAgogo5 Rev MnCaxixiL3

Rev MnChekereS5 Rev MnBongoH2 Rev MnRepiniqueL13 on Rev MnAgogo6 Rev MnCaxixiL4 Rev MnChekereS6 Rev MnBongoH3 Rev MnRepiniqueL14 on Rev MnAgogo7 Rev MnCaxixiL5 Rev MnChekereST Rev MnBongoH4 Rev MnRepiniqueL15 on Rev MnAgogo8 Rev MnCaxixiL6 Rev MnChekereL Rev MnBongoH5 Rev MnRepiniqueH1 Rev MnAgogo9 Rev MnCaxixiS1 Rev MnChekereLT Rev MnBongoH6 Rev MnRepiniqueH2 Rev MnFunkBell1 Rev MnCaxixiS2 Rev MnMaracas1 Rev MnRepiniqueH3 Rev MnFunkBell2 Rev MnCaxixiS3 Rev MnMaracas2 Rev MnRepiniqueH4 Rev MnWdBlkLarge1 Rev MnCaxixiS4 Rev MnMaracas3 Rev MnRepiniqueH5 Rev MnWdBlkLarge2 Rev MnCuica1 on Rev MnMaracas4 Rev MnRepiniqueH6 Rev MnWdBlkSmall1 Rev MnCuica2 on Rev MnRepiniqueH7 Rev MnWdBlkSmall2 Rev MnCuica3 on Rev MnRepiniqueH8

Rev MnCuica4 on Rev MnRepiniqueH9 Rev MnCuica5 on Rev MnRepiniqueH10 Rev MnCuica6 on Rev MnRepiniqueH11 Rev MnCuica7 on Rev MnRepiniqueH12 Rev MnWhistle1 Rev MnWhistle2 Rev MnWhistle3 Rev MnWhistle4 on Rev MnWhistle5 on Rev MnWhistle6 on Rev MnWhistle7 on Rev MnWhistle8 on Rev MnWhistle9 on Rev MnWhistle10 on

DR/PC Plug-in Voice List

■ DR/PC Plug-in Voice List

(for CS6x, CS6R, S30, S80, MOTIF)

● PLG150-DR

DrPlgVc1.mid (Slot1) DrPlgVc2.mid (Slot2) DrPlgVc3.mid (Slot3)

No. Plug-in Voice Name

1 LiveRoom A

2 LiveRoom B

3 PoweredStd

4 DryStandrd

5 RockSt1

6 RockSt2

7 DryKit A

8 DryKit B

9 SmallRoom1

10 SmallRoom2

11 HeavyKit

12 RingSnares

13 Rocky

14 Trashed1

15 Trashed2

16 Trashed3

17 Weirdo

18 DarkBreak

19 BriteBreak

20 RockBreak

21 DirtyTek

22 Ethnic

23 DigiLoFi

24 NoizElec

25 BreakAmbnt

26 Electron

27 EthnicAmb

28 Flanger

29 Phaser1

30 Phaser2

31 AM/PM

32 AutoPan

33 Drone

34 SnareKit

35 CymbalsAmb

36 KitA/Hat1

37 KitB/Hat1

38 KitA/Hat2

39 KitB/Hat2

40 Spread1

41 Spread2

42 Spread3

43 Spread4

44 Kicks

45 Snares

46 Toms

47 Hats

48 Cymbals

49 AAAA/Kicks

50 ABAA/Snrs1

51 AABA/Snrs2

52 AAAB/Toms

53 ABBA/Hats

54 AABB/Cym

55 ABAB/Snrs1

56 ABBB/Snrs2

57 BBBB/Kicks

58 BABB/Snrs1

59 BBAB/Snrs2

60 BBBA/Toms

61 BAAB/Hats

62 BBAA/Cym

63 BABA/Snrs1

64 BAAA/Snrs2

No. Plug-in Voice Name

● PLG150-PC

PcPlgVc1.mid (Slot1) PcPlgVc2.mid (Slot2) PcPlgVc3.mid (Slot3)

No. Plug-in Voice Name

1 AfroCuban

2 Brazil

3 MotifLatin

4 GM Perc

5 AfroCubn61

6 Brazil61

7 AfCb-PlgDR

8 Brzl-PlgDR

9 Latn-PlgDR

10 GmLatinDrm

11 Live Pop

12 Kick&Snare

13 AfrCbnHand

14 BrazilHnd1

15 BrazilHnd2

16 Bells

17 Shakers

18 Skins

19 Sticks 1

20 Sticks 2

21 OvrDrAfrCb

22 OvrDrBrazl

23 OvrDrGMLtn

24 OvrDrKk&Sn

25 Dist1AfrCb

26 Dist1Brazl

27 Dist1GMLtn

28 Dist1Kk&Sn

29 Dist2AfrCb

30 Dist2Brazl

31 Dist2GMLtn

32 Dist2Kk&Sn

33 FlngrAfrCb

34 FlngrBrazl

35 FlangrShkrs

36 PhasrShkrs

37 DelayAfrCb

38 DelayBrazl

39 DelayGMPrc

40 DelayGMLtn

41 NsDlyAfrCb

42 NsDlyBrazl

43 Mod1AfrCbn

44 Mod1Brazil

45 Mod2AfrCbn

46 Mod2Brazil

47 Mod3Bells

48 Mod3Shakrs

49 Mod4BrzHd1

50 Mod4BrzHd2

51 Mod5BrzHd1

52 Mod5BrzHd2

53 Reso1Skins

54 Reso1Stick

55 Reso2Kk&Sn

56 Reso2Stick

57 Mod6Bells

58 Mod6Sticks

59 PitchBells

60 PitchShakr

61 PitchSkins

62 PitchStick

63 AmbntBells

64 AmbntAfrCb

No. Plug-in Voice Name

Effect List

■ DR/PC Voice Effect Parameter List

• DR/PC Native Part Parameter : This parameter can control the Voice Effect.

• Dry/Wet (Parameter No.10) is available only on the Insertion Effect.

NOTE

HALL1,HALL2 / ROOM1,ROOM2,ROOM3 / STAGE1,STAGE2 / PLATE (Reverb, Insertion)

WHITE ROOM / TUNNEL / BASEMENT (Reverb)

KARAOKE1,2,3 (Insertion)

DELAY L,C,R (Insertion)

DELAY L,R (Insertion)

ECHO (Insertion)

CROSS DELAY (Insertion)

EARLY REF1,2 (Insertion)

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 Reverb Time 0.3...30.0[s] 0 - 69 table#4 2 Diffusion 0...10 0 - 10 3 Initial Delay 0.1...99.3[ms] 0 - 63 table#5 4 HPF Cutoff Thru...8.0k[Hz] 0 - 52 table#3 5 LPF Cutoff 1.0k[Hz]...Thru 34 - 60 table#3 6 7 8

9 10 Dry/Wet D63>W...D=W...D<W63 1 - 127 INS DryWet 11 Rev Delay 0...63 0 - 63 table#5 12 Density 0...3 0 - 3 13 Er/Rev Balance E63>R...E=R...E<R63 1 - 127 14 15 Feedback Level -63...+63 1 - 127 16

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 Reverb Time 0.3...30.0[s] 0 - 69 table#4

2 Diffusion 0...10 0 - 10

3 Initial Delay 0.1...99.3[ms] 0 - 63 table#5

4 HPF Cutoff Thru...8.0k[Hz] 0 - 52 table#3

5 LPF Cutoff 1.0k[Hz]...Thru 34 - 60 table#3

6 Width 0.5...10.2[m] 0 - 37

7 Heigt 0.5...20.2[m] 0 - 73

8 Depth 0.5...30.2[m] 0 - 104

9 Wall Vary 0...30 0 - 30 10 11 Rev Delay 0...63 0 - 63 table#5 12 Density 0...3 0 - 3 13 Er/Rev Balance E63>R...E=R...E<R63 1 - 127 14 15 Feedback Level -63...+63 1 - 127 16

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 Delay Time 0.1...400[ms] 0 - 127 table#7

2 Feedback Level -63...+63 1 - 127

3 HPF Cutoff Thru...8.0k[Hz] 0 - 52 table#3

4 LPF Cutoff 1.0k[Hz]...Thru 34 - 60 table#3

9 10 Dry/Wet D63>W...D=W...D<W63 1 - 127 INS DryWet 11 12 13 14 15 16

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 Lch Delay 0.1...715.0[ms] 1 - 7150

2 Rch Delay 0.1...715.0[ms] 1 - 7150

3 Cch Delay 0.1...715.0[ms] 1 - 7150

4 Feedback Delay 0.1...715.0[ms] 1 - 7150

5 Feedback Level -63...+63 1 - 127

6 Cch Level 0...127 0 - 127

7 High Damp 0.1...1.0 1 - 10

9 10 Dry/Wet D63>W...D=W...D<W63 1 - 127 INS DryWet 11 12 13 EQ Low Frequency 50...2.0k[Hz] 8 - 40 table#3 INS EQ Low Frq 14 EQ Low Gain -12...+12[dB] 52 - 76 INS EQ Low Gain 15 EQ High Frequency 500...16.0k[Hz] 28 - 58 table#3 INS EQ High Frq 16 EQ High Gain -12...+12[dB] 52 - 76 INS EQ High Gain

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 Lch Delay 0.1...715.0[ms] 1 - 7150 2 Rch Delay 0.1...715.0[ms] 1 - 7150 3 Feedback Delay 1 0.1...715.0[ms] 1 - 7150 4 Feedback Delay 2 0.1...715.0[ms] 1 - 7150 5 Feedback Level -63...+63 1 - 127 6 High Damp 0.1...1.0 1 - 10 7 8

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 Lch Delay1 0.1...355.0[ms] 1 - 3550

2 Lch Feedback Level -63...+63 1 - 127

3 Rch Delay1 0.1...355.0[ms] 1 - 3550

4 Rch Feedback Level -63...+63 1 - 127

5 High Damp 0.1...1.0 1 - 10

6 Lch Delay2 0.1...355.0[ms] 1 - 3550

7 Rch Delay2 0.1...355.0[ms] 1 - 3550

8 Delay2 Level 0...127 0 - 127

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 L->R Delay 0.1...355.0[ms] 1 - 3550

2 R->L Delay 0.1...355.0[ms] 1 - 3550

3 Feedback Level -63...+63 1 - 127

4 Input Select L,R,L&R 0 - 2

5 High Damp 0.1...1.0 1 - 10

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 Type S-H, L-H, Rdm, Rvs, Plt, Spr 0 - 5

2 Room Size 0.1...7.0 0 - 44 table#6

3 Diffusion 0...10 0 - 10

4 Initial Delay 0.1...99.3[ms] 0 - 63 table#5

5 Feedback Level -63...+63 1 - 127

6 HPF Cutoff Thru...8.0k[Hz] 0 - 52 table#3

7 LPF Cutoff 1.0k[Hz]...Thru 34 - 60 table#3

9 10 Dry/Wet D63>W...D=W...D<W63 1 - 127 INS DryWet 11 Liveness 0...10 0 - 10 12 Density 0...3 0 - 3 13 High Damp 0.1...1.0 1 - 10 14 15 16

Effect List

GATE REVERB / REVERSE GATE (Insertion)

CHORUS1,2,3,4 / CELESTE1,2,3,4 (Insertion)

FLANGER1,2,3 (Insertion)

SYMPHONIC (Insertion)

ROTARY SPEAKER (Insertion)

TREMOLO (Insertion)

AUTO PAN (Insertion)

PHASER 1 (Insertion)

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 Type TypeA,TypeB 0 - 1 2 Room Size 0.1...7.0 0 - 44 table#6 3 Diffusion 0...10 0 - 10 4 Initial Delay 0.1...99.3[ms] 0 - 63 table#5 5 Feedback Level -63...+63 1 - 127 6 HPF Cutoff Thru...8.0k[Hz] 0 - 52 table#3 7 LPF Cutoff 1.0k[Hz]...Thru 34 - 60 table#3 8

9 10 Dry/Wet D63>W...D=W...D<W63 1 - 127 INS DryWet 11 Liveness 0...10 0 - 10 12 Density 0...3 0 - 3 13 High Damp 0.1...1.0 1 - 10 14 15 16

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 LFO Frequency 0.00...39.7[Hz] 0 - 127 table#1 INS LFO Freq

2 LFO Depth 0...127 0 - 127 INS LFO Depth

3 Feedback Level -63...+63 1 - 127

4 Delay Offset 0.0...50 0 - 127 table#2

6 EQ Low Frequency 50...2.0k[Hz] 8 - 40 table#3 INS EQ Low Frq

7 EQ Low Gain -12...+12[dB] 52 - 76 INS EQ Low Gain

8 EQ High Frequency 500...16.0k[Hz] 28 - 58 table#3 INS EQ High Frq

9 EQ High Gain -12...+12[dB] 52 - 76 INS EQ High Gain 10 Dry/Wet D63>W...D=W...D<W63 1 - 127 INS DryWet 11 12 13 14 15 Input Mode mono/stereo 0 - 1 16

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 LFO Frequency 0.00...39.7[Hz] 0 - 127 table#1 INS LFO Freq

2 LFO Depth 0...127 0 - 127 INS LFO Depth

3 Feedback Level -63...+63 1 - 127

4 Delay Offset 0...63 0 - 63 table#2

6 EQ Low Frequency 50...2.0k[Hz] 8 - 40 table#3 INS EQ Low Frq

7 EQ Low Gain -12...+12[dB] 52 - 76 INS EQ Low Gain

8 EQ High Frequency 500...16.0k[Hz] 28 - 58 table#3 INS EQ High Frq

9 EQ High Gain -12...+12[dB] 52 - 76 INS EQ High Gain 10 Dry/Wet D63>W...D=W...D<W63 1 - 127 INS DryWet 11 12 13 14 LFO Phase

Difference

-180...+180[deg] (resolution=3[deg])

4 - 124

15 16

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 LFO Frequency 0.00...39.7[Hz] 0 - 127 table#1 INS LFO Freq

2 LFO Depth 0...127 0 - 127 INS LFO Depth

3 Delay Offset 0.0...50 0 - 127 table#2

6 EQ Low Frequency 50...2.0k[Hz] 8 - 40 table#3 INS EQ Low Frq

7 EQ Low Gain -12...+12[dB] 52 - 76 INS EQ Low Gain

8 EQ High Frequency 500...16.0k[Hz] 28 - 58 table#3 INS EQ High Frq

9 EQ High Gain -12...+12[dB] 52 - 76 INS EQ High Gain 10 Dry/Wet D63>W...D=W...D<W63 1 - 127 INS DryWet 11 12 13 14 15 16

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 LFO Frequency 0.00...39.7[Hz] 0 - 127 table#1 INS LFO Freq 2 LFO Depth 0...127 0 - 127 INS LFO Depth 3 4 5 6 EQ Low Frequency 50...2.0k[Hz] 8 - 40 table#3 INS EQ Low Frq 7 EQ Low Gain -12...+12[dB] 52 - 76 INS EQ Low Gain 8 EQ High Frequency 500...16.0k[Hz] 28 - 58 table#3 INS EQ High Frq

9 EQ High Gain -12...+12[dB] 52 - 76 INS EQ High Gain 10 Dry/Wet D63>W...D=W...D<W63 1 - 127 INS DryWet 11 12 13 14 15 16

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 LFO Frequency 0.00...39.7[Hz] 0 - 127 table#1 INS LFO Freq

2 AM Depth 0...127 0 - 127 INS LFO Depth

3 PM Depth 0...127 0 - 127 INS LFO Depth

6 EQ Low Frequency 50...2.0k[Hz] 8 - 40 table#3 INS EQ Low Frq

7 EQ Low Gain -12...+12[dB] 52 - 76 INS EQ Low Gain

8 EQ High Frequency 500...16.0k[Hz] 28 - 58 table#3 INS EQ High Frq

9 EQ High Gain -12...+12[dB] 52 - 76 INS EQ High Gain 10 11 12 13 14 LFO Phase

Difference

-180...+180[deg] (resolution=3[deg])

4 - 124

15 Input Mode mono/stereo 0 - 1 16

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 LFO Frequency 0.00...39.7[Hz] 0 - 127 table#1 INS LFO Freq

2 L/R Depth 0...127 0 - 127 INS LFO Depth

3 F/R Depth 0...127 0 - 127 INS LFO Depth

4 PAN Direction L<->R,L->R,L<-

R,Lturn,Rturn,L/R

0 - 5

6 EQ Low Frequency 50...2.0k[Hz] 8 - 40 table#3 INS EQ Low Frq

7 EQ Low Gain -12...+12[dB] 52 - 76 INS EQ Low Gain

8 EQ High Frequency 500...16.0k[Hz] 28 - 58 table#3 INS EQ High Frq

9 EQ High Gain -12...+12[dB] 52 - 76 INS EQ High Gain 10 11 12 13 14 15 16

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 LFO Frequency 0.00...39.7[Hz] 0 - 127 table#1 INS LFO Freq

2 LFO Depth 0...127 0 - 127 INS LFO Depth

3 Phase Shift Offset 0...127 0 - 127

4 Feedback Level -63...+63 1 - 127

6 EQ Low Frequency 50...2.0k[Hz] 8 - 40 table#3 INS EQ Low Frq

7 EQ Low Gain -12...+12[dB] 52 - 76 INS EQ Low Gain

8 EQ High Frequency 500...16.0k[Hz] 28 - 58 table#3 INS EQ High Frq

9 EQ High Gain -12...+12[dB] 52 - 76 INS EQ High Gain 10 Dry/Wet D63>W...D=W...D<W63 1 - 127 INS DryWet 11 Stage 6...10 6 - 10 12 13 14 15 16

Effect List

PHASER 2 (Insertion)

DISTORTION / OVERDRIVE (Insertion)

AMP SIMULATOR (Insertion)

3BAND EQ (Insertion)

2BAND EQ (Insertion)

AUTO WAH (Insertion)

NO EFFECT (Reverb, Insertion)

THRU (Insertion)

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 LFO Frequency 0.00...39.7[Hz] 0 - 127 table#1 INS LFO Freq 2 LFO Depth 0...127 0 - 127 INS LFO Depth 3 Phase Shift Offset 0...127 0 - 127 4 Feedback Level -63...+63 1 - 127 5 6 EQ Low Frequency 50...2.0k[Hz] 8 - 40 table#3 INS EQ Low Frq 7 EQ Low Gain -12...+12[dB] 52 - 76 INS EQ Low Gain 8 EQ High Frequency 500...16.0k[Hz] 28 - 58 table#3 INS EQ High Frq

9 EQ High Gain -12...+12[dB] 52 - 76 INS EQ High Gain 10 Dry/Wet D63>W...D=W...D<W63 1 - 127 INS DryWet 11 Stage 3...5 3 - 5 12 13 LFO Phase

Difference

-180...+180[deg] (resolution=3[deg])

4 - 124

14 15 16

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 Drive 0...127 0 - 127 INS Drive

2 EQ Low Frequency 50...2.0k[Hz] 8 - 40 table#3 INS EQ Low Frq

3 EQ Low Gain -12...+12[dB] 52 - 76 INS EQ Low Gain

4 LPF Cutoff 1.0k[Hz]...Thru 34 - 60 table#3

5 Output Level 0...127 0 - 127

7 EQ Mid Frequency 500...10.0k[Hz] 28 - 54 table#3

8 EQ Mid Gain -12...+12[dB] 52 - 76

9 EQ Mid Width 1.0...12.0 10 - 120 10 Dry/Wet D63>W...D=W...D<W63 1 - 127 INS DryWet 11 Edge(Clip Curve) 0...127(mild...sharp) 0 - 127 12 13 14 15 16

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 Drive 0...127 0 - 127 INS Drive

2 AMP Type Off,Stack,Combo,Tube 0 - 3

3 LPF Cutoff 1.0k[Hz]...Thru 34 - 60 table#3

4 Output Level 0...127 0 - 127

9 10 Dry/Wet D63>W...D=W...D<W63 1 - 127 INS DryWet 11 Edge(Clip Curve) 0...127(mild...sharp) 0 - 127 12 13 14 15 16

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 EQ Low Gain -12...+12[dB] 52 - 76 INS EQ Low Gain

2 EQ Mid Frequency 500...10.0k[Hz] 28 - 54 table#3

3 EQ Mid Gain -12...+12[dB] 52 - 76

4 EQ Mid Width 1.0...12.0 10 - 120

5 EQ High Gain -12...+12[dB] 52 - 76 INS EQ High Gain

6 EQ Low Frequency 50...2.0k[Hz] 8 - 40 table#3 INS EQ Low Frq

7 EQ High Frequency 500...16.0k[Hz] 28 - 58 table#3 INS EQ High Frq

9 10 11 12 13 14 15 16

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 EQ Low Frequency 50...2.0k[Hz] 8 - 40 table#3 INS EQ Low Frq 2 EQ Low Gain -12...+12[dB] 52 - 76 INS EQ Low Gain 3 EQ High Frequency 500...16.0k[Hz] 28 - 58 table#3 INS EQ High Frq 4 EQ High Gain -12...+12[dB] 52 - 76 INS EQ High Gain 5 6 7 8

9 10 11 12 13 14 15 16

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

1 LFO Frequency 0.00...39.7[Hz] 0 - 127 table#1 INS LFO Freq

2 LFO Depth 0...127 0 - 127 INS LFO Depth

3 Cutoff Frequency

Offset

0...127 0 - 127

4 Resonance 1.0...12.0 10 - 120

6 EQ Low Frequency 50...2.0k[Hz] 8 - 40 table#3 INS EQ Low Frq

7 EQ Low Gain -12...+12[dB] 52 - 76 INS EQ Low Gain

8 EQ High Frequency 500...16.0k[Hz] 28 - 58 table#3 INS EQ High Frq

9 EQ High Gain -12...+12[dB] 52 - 76 INS EQ High Gain 10 Dry/Wet D63>W...D=W...D<W63 1 - 127 INS DryWet 11 12 13 14 15 16

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

9 10 11 12 13 14 15 16

No. Parameter Display Value

See

Tab le

DR/PC Native

Part Parameter

9 10 11 12 13 14 15 16

Effect List

■ Effect Default Data List

Type

Parameter Number

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

HALL1 18 10 8 13 49 00004003500640

HALL2 25 10 28 6 46 000040133740640

ROOM1 5 10 16 4 49 00004053640640

ROOM2 12 10 5 4 38 00004003500640

ROOM3 9 10 47 5 36 00004003600640

STAGE1 19101675400004003640640

STAGE2 11101675100004022640640

PLATE 251068490000023640640

WHITE ROOM 9 5 11 0 46 30 50 70 7 0 34 3 64 0 64 0

TUNNEL 48 6 19 0 44 33 52 70 16 0 20 3 64 0 64 0

BASEMENT 3630342629591540323640640

KARAOKE1 63 97 0 48 0000064000000

KARAOKE2 55 105 0 50 0000064000000

KARAOKE3 43 110 14 53 0000064000000

DELAY L,C,R 3333 1667 5000 5000 74 100 10 0 0 32 0 0 28 64 46 64

DELAY L,R 2500 3750 3752 3750 87 10 0 0 0 32 0 0 28 64 46 64

ECHO 1700 80 1780 80 10 1700 1780 0 0 40 0 0 28 64 46 64

CROSS DELAY 1700 1750 111 1 10 0000320028644664

EARLY REF1 0 19 5 16 64 0 46 0 0 32 5 0 10 0 0 0

EARLY REF2 2 7 10 16 64 3 46 0 0 32 5 2 10 0 0 0

GATE REVERB 0 15 6 2 64 0 44 0 0 32 4 3 10 0 0 0

REVERSE GATE 1 19 8 3 64 0 47 0 0 32 6 3 10 0 0 0

CHORUS1 6 54 77 106 0 28 64 46 64 64 000000

CHORUS2 8 63 64 30 0 28 62 42 58 64 000000

CHORUS3 4 44 64 110 0 28 64 46 66 64 000000

CHORUS4 9 32 69 104 0 28 64 46 64 64 000010

CELESTE1 12 32 64 0 0 28 64 46 64 127 000000

CELESTE2 28 18 90 2 0 28 62 42 60 84 000000

CELESTE3 4 63 44 2 0 28 64 46 68 127 000000

CELESTE4 8 29 64 0 0 28 64 51 66 127 000010

FLANGER1 14 14 104 2 0 28 64 46 64 96 000400

FLANGER2 32 17 26 2 0 28 64 46 60 96 000400

FLANGER3 4 109 109 2 0 28 64 46 64 127 000400

SYMPHONIC 12 25 16 0 0 28 64 46 64 127 000000

ROTARY SPEAKER 81 35 0 0 0 24 60 45 54 127 000000

TREMOLO 83 56 0 0 0 28 64 46 64 00006400

AUTO PAN 76803250286446640000000

PHASER 1 8 111 74 104 0 28 64 46 64 64 600000

PHASER 2 8 111 74 108 0 28 64 46 64 64 504000

DISTORTION 15 20 71 52 74 0 42 70 10 127 100 00000

OVERDRIVE 7 21 69 54 80 0 41 70 10 127 68 00000

AMP SIMULATOR 18 3 54 73 000001277800000

3BAND EQ 70 34 60 10 70 28 46 000000000

2BAND EQ 28 70 46 70 000000000000

AUTO WAH 42823827034693269127000000

NO EFFECT 0000000000000000

THRU 0000000000000000

Effect List

■ Effect Data Assign Table

table#1 LFO Frequency

Data Value

0 0.00 1 0.04 2 0.08 3 0.12 4 0.16 5 0.21 6 0.25 7 0.29 8 0.33

9 0.37 10 0.42 11 0.46 12 0.50 13 0.54 14 0.58 15 0.63 16 0.67 17 0.71 18 0.75 19 0.79 20 0.84 21 0.88 22 0.92 23 0.96 24 1.00 25 1.05 26 1.09 27 1.13 28 1.17 29 1.22 30 1.26 31 1.30 32 1.34 33 1.38 34 1.43 35 1.47 36 1.51 37 1.55 38 1.59 39 1.64 40 1.68 41 1.72 42 1.76 43 1.80 44 1.85 45 1.89 46 1.93 47 1.97 48 2.01 49 2.06 50 2.10 51 2.14 52 2.18 53 2.22 54 2.27 55 2.31 56 2.35 57 2.39 58 2.43 59 2.48 60 2.52 61 2.56 62 2.60 63 2.65

64 0.69 65 2.77 66 2.86 67 2.94 68 3.02 69 3.11 70 3.19 71 3.28 72 3.36 73 3.44 74 3.53 75 3.61 76 3.70 77 3.86 78 4.03 79 4.20 80 4.37 81 4.54 82 4.71 83 4.87 84 5.04 85 5.21 86 5.38 87 5.55 88 5.72 89 6.05 90 6.39 91 6.72 92 7.06 93 7.40 94 7.73 95 8.07 96 8.41 97 8.74 98 9.08

99 9.42 100 9.75 101 10.0 102 10.7 103 11.4 104 12.1 105 12.7 106 13.4 107 14.1 108 14.8 109 15.4 110 16.1 111 16.8 112 17.5 113 18.1 114 19.5 115 20.8 116 22.2 117 23.5 118 24.8 119 26.2 120 27.5 121 28.9 122 30.2 123 31.6 124 32.9 125 34.3 126 37.0 127 39.7

Data Value

table#2 Modulation Delay Offset

Data Value

0 0.0 1 0.1 2 0.2 3 0.3 4 0.4 5 0.5 6 0.6 7 0.7 8 0.8

9 0.9 10 1.0 11 1.1 12 1.2 13 1.3 14 1.4 15 1.5 16 1.6 17 1.7 18 1.8 19 1.9 20 2.0 21 2.1 22 2.2 23 2.3 24 2.4 25 2.5 26 2.6 27 2.7 28 2.8 29 2.9 30 3.0 31 3.1 32 3.2 33 3.3 34 3.4 35 3.5 36 3.6 37 3.7 38 3.8 39 3.9 40 4.0 41 4.1 42 4.2 43 4.3 44 4.4 45 4.5 46 4.6 47 4.7 48 4.8 49 4.9 50 5.0 51 5.1 52 5.2 53 5.3 54 5.4 55 5.5 56 5.6 57 5.7 58 5.8 59 5.9 60 6.0 61 6.1 62 6.2 63 6.3

64 6.4 65 6.5 66 6.6 67 6.7 68 6.8 69 6.9 70 7.0 71 7.1 72 7.2 73 7.3 74 7.4 75 7.5 76 7.6 77 7.7 78 7.8 79 7.9 80 8.0 81 8.1 82 8.2 83 8.3 84 8.4 85 8.5 86 8.6 87 8.7 88 8.8 89 8.9 90 9.0 91 9.1 92 9.2 93 9.3 94 9.4 95 9.5 96 9.6 97 9.7 98 9.8

99 9.9 100 10.0 101 11.1 102 12.2 103 13.3 104 14.4 105 15.5 106 17.1 107 18.6 108 20.2 109 21.8 110 23.3 111 24.9 112 26.5 113 28.0 114 29.6 115 31.2 116 32.8 117 34.3 118 35.9 119 37.5 120 39.0 121 40.6 122 42.2 123 43.7 124 45.3 125 46.9 126 48.4 127 50.0

Data Value

table#3 EQ Frequency

Data Value

0 THRU(20) 122 225 328 432 536 640 745 850

956 10 63 11 70 12 80 13 90 14 100 15 110 16 125 17 140 18 160 19 180 20 200 21 225 22 250 23 280 24 315 25 355 26 400 27 450 28 500 29 560 30 630 31 700 32 800 33 900 34 1.0k 35 1.1k 36 1.2k 37 1.4k 38 1.6k 39 1.8k 40 2.0k 41 2.2k 42 2.5k 43 2.8k 44 3.2k 45 3.6k 46 4.0k 47 4.5k 48 5.0k 49 5.6k 50 6.3k 51 7.0k 52 8.0k 53 9.0k 54 10.0k 55 11.0k 56 12.0k 57 14.0k 58 16.0k 59 18.0k 60 THRU(20.0k)

table#4 Reverb Time

Data Value

0 0.3 1 0.4 2 0.5 3 0.6 4 0.7 5 0.8 6 0.9 7 1.0 8 1.1

9 1.2 10 1.3 11 1.4 12 1.5 13 1.6 14 1.7 15 1.8 16 1.9 17 2.0 18 2.1 19 2.2 20 2.3 21 2.4 22 2.5 23 2.6 24 2.7 25 2.8 26 2.9 27 3.0 28 3.1 29 3.2 30 3.3 31 3.4 32 3.5 33 3.6 34 3.7 35 3.8 36 3.9 37 4.0 38 4.1 39 4.2 40 4.3 41 4.4 42 4.5 43 4.6 44 4.7 45 4.8 46 4.9 47 5.0 48 5.5 49 6.0 50 6.5 51 7.0 52 7.5 53 8.0 54 8.5 55 9.0 56 9.5 57 10.0 58 11.0 59 12.0 60 13.0 61 14.0 62 15.0 63 16.0

64 17.0 65 18.0 66 19.0 67 20.0 68 25.0 69 30.0

Data Value

Effect List

table#5 Delay Time (200.0ms)

Data Value

0 0.1 1 1.7 2 3.2 3 4.8 4 6.4 5 8.0 6 9.5 7 11.1 8 12.7

9 14.3 10 15.8 11 17.4 12 19.0 13 20.6 14 22.1 15 23.7 16 25.3 17 26.9 18 28.4 19 30.0 20 31.6 21 33.2 22 34.7 23 36.3 24 37.9 25 39.5 26 41.0 27 42.6 28 44.2 29 45.7 30 47.3 31 48.9 32 50.5 33 52.0 34 53.6 35 55.2 36 56.8 37 58.3 38 59.9 39 61.5 40 63.1 41 64.6 42 66.2 43 67.8 44 69.4 45 70.9 46 72.5 47 74.1 48 75.7 49 77.2 50 78.8 51 80.4 52 81.9 53 83.5 54 85.1 55 86.7 56 88.2 57 89.8 58 91.4 59 93.0 60 94.5 61 96.1 62 97.7 63 99.3

64 100.8 65 102.4 66 104.0 67 105.6 68 107.1 69 108.7 70 110.3 71 111.9 72 113.4 73 115.0 74 116.6 75 118.2 76 119.7 77 121.3 78 122.9 79 124.4 80 126.0 81 127.6 82 129.2 83 130.7 84 132.3 85 133.9 86 135.5 87 137.0 88 138.6 89 140.2 90 141.8 91 143.3 92 144.9 93 146.5 94 148.1 95 149.6 96 151.2 97 152.8 98 154.4

99 155.9 100 157.5 101 159.1 102 160.6 103 162.2 104 163.8 105 165.4 106 166.9 107 168.5 108 170.1 109 171.7 110 173.2 111 174.8 112 176.4 113 178.0 114 179.5 115 181.1 116 182.7 117 184.3 118 185.8 119 187.4 120 189.0 121 190.6 122 192.1 123 193.7 124 195.3 125 196.9 126 198.4 127 200.0

Data Value

table#6 Room Size

Data Value

0 0.1 1 0.3 2 0.4 3 0.6 4 0.7 5 0.9 6 1.0 7 1.2 8 1.4

9 1.5 10 1.7 11 1.8 12 2.0 13 2.1 14 2.3 15 2.5 16 2.6 17 2.8 18 2.9 19 3.1 20 3.2 21 3.4 22 3.5 23 3.7 24 3.9 25 4.0 26 4.2 27 4.3 28 4.5 29 4.6 30 4.8 31 5.0 32 5.1 33 5.3 34 5.4 35 5.6 36 5.7 37 5.9 38 6.1 39 6.2 40 6.4 41 6.5 42 6.7 43 6.8 44 7.0

table#7 Delay Time (400.0ms)

Data Value

0 0.1 1 3.2 2 6.4 3 9.5 4 12.7 5 15.8 6 19.0 7 22.1 8 25.3

9 28.4 10 31.6 11 34.7 12 37.9 13 41.0 14 44.2 15 47.3 16 50.5 17 53.6 18 56.8 19 59.9 20 63.1 21 66.2 22 69.4 23 72.5 24 75.7 25 78.8 26 82.0 27 85.1 28 88.3 29 91.4 30 94.6 31 97.7 32 100.9 33 104.0 34 107.2 35 110.3 36 113.5 37 116.6 38 119.8 39 122.9 40 126.1 41 129.2 42 132.4 43 135.5 44 138.6 45 141.8 46 144.9 47 148.1 48 151.2 49 154.4 50 157.5 51 160.7 52 163.8 53 167.0 54 170.1 55 173.3 56 176.4 57 179.6 58 182.7 59 185.9 60 189.0 61 192.2 62 195.3 63 198.5

table#8 Reverb Width;Depth;Height

Data Value

0 0.5 1 0.8 2 1.0 3 1.3 4 1.5 5 1.8 6 2.0 7 2.3 8 2.6

9 2.8 10 3.1 11 3.3 12 3.6 13 3.9 14 4.1 15 4.4 16 4.6 17 4.9 18 5.2 19 5.4 20 5.7 21 5.9 22 6.2 23 6.5 24 6.7 25 7.0 26 7.2 27 7.5 28 7.8 29 8.0 30 8.3 31 8.6 32 8.8 33 9.1 34 9.4 35 9.6 36 9.9 37 10.2 38 10.4 39 10.7 40 11.0 41 11.2 42 11.5 43 11.8 44 12.1 45 12.3 46 12.6 47 12.9 48 13.1 49 13.4 50 13.7 51 14.0 52 14.2 53 14.5 54 14.8 55 15.1 56 15.4 57 15.6 58 15.9 59 16.2 60 16.5 61 16.8 62 17.1 63 17.3

64 17.6 65 17.9 66 18.2 67 18.5 68 18.8 69 19.1 70 19.4 71 19.7 72 20.0 73 20.2 74 20.5 75 20.8 76 21.1 77 21.4 78 21.7 79 22.0 80 22.4 81 22.7 82 23.0 83 23.3 84 23.6 85 23.9 86 24.2 87 24.5 88 24.9 89 25.2 90 25.5 91 25.8 92 26.1 93 26.5 94 26.8 95 27.1 96 27.5 97 27.8 98 28.1

99 28.5 100 28.8 101 29.2 102 29.5 103 29.9 104 30.2

Data Value

64 201.6 65 204.8 66 207.9 67 211.1 68 214.2 69 217.4 70 220.5 71 223.7 72 226.8 73 230.0 74 233.1 75 236.3 76 239.4 77 242.6 78 245.7 79 248.9 80 252.0 81 255.2 82 258.3 83 261.5 84 264.6 85 267.7 86 270.9 87 274.0 88 277.2 89 280.3 90 283.5 91 286.6 92 289.8 93 292.9 94 296.1 95 299.2 96 302.4 97 305.5 98 308.7

99 311.8 100 315.0 101 318.1 102 321.3 103 324.4 104 327.6 105 330.7 106 333.9 107 337.0 108 340.2 109 343.3 110 346.5 111 349.6 112 352.8 113 355.9 114 359.1 115 362.2 116 365.4 117 368.5 118 371.7 119 374.8 120 378.0 121 381.1 122 384.3 123 387.4 124 390.6 125 393.7 126 396.9 127 400.0

Data Value

Parameter List

(XG/Modular Synthesis Plug-in System)

(Common Parameter)

(Element Parameter)

*1 : Changing the values of these parameters has no effect on the sound (even though the values change in the display).

Modular Synthesis Plug-in System XG Plug-in System (LCD of CS6x/CS6R/S80/Motif/etc.)

Parameter Name Parameter Name Group Parameter

Volume VOLUME QED*Level Vol

Pan PAN QED*Level Pan

Reverb Send REVERB SEND QED*Level RevSend

Chorus Send CHORUS SEND QED*Level ChoSend

LPF Cutoff Frequency LOW PASS FILTER CUTOFF FREQUENCY QED*Filter Cutoff

LPF Resonance LOW PASS FILTER RESONANCE QED*Filter Reso

Attack Time EG ATTACK TIME QED*EG Attack

Decay Time EG DECAY TIME QED*EG Decay

Release Time EG RELEASE TIME QED*EG Release

Pitch Bend Range BEND PITCH CONTROL CTL*Pitch Pitch Bend

Portamento Switch PORTAMENTO SWITCH *1 CTL*Pitch Portamento

Portamento Time PORTAMENTO TIME *1 CTL*Pitch Time

Mono/Poly Mode MONO/POLY MODE *1 GEN*Other Mode

Same Note Number Key On Assign SAME NOTE NUMBER KEY ON ASSIGN *1 GEN*Other Assign

Parameter Name Parameter Name Group Parameter

Plug-in Board Voice Bank MSB BANK SELECT MSB PLG*Assign Bank

Plug-in Board Voice Bank LSB BANK SELECT LSB PLG*Assign Bank

Plug-in Board Voice Program Number PROGRAM NUMBER PLG*Assign Number

Note Shift NOTE SHIFT PLG*Velocity NoteSft

Velocity Sense Depth VELOCITY SENSE DEPTH PLG*Velocity Depth

Velocity Sense Offset VELOCITY SENSE OFFSET PLG*Velocity Offset

Pitch EG Initial Level PITCH EG INITIAL LEVEL PCH*PEG InitLvl

Pitch EG Attack Time PITCH EG ATTACK TIME PCH*PEG Attack

Pitch EG Release Level PITCH EG RELEASE LEVEL PCH*PEG --Level

Pitch EG Release Time PITCH EG RELEASE TIME PCH*PEG Release

LFO Rate VIBRATO RATE LFO Param Speed

LFO Pitch Modulation Depth VIBRATO DEPTH LFO Param PMod

LFO Delay VIBRATO DELAY LFO Param Delay

HPF Cutoff Frequency HIGH PASS FILTER CUTOFF FREQUENCY QED*Filter HPF

EQ Low Gain EQ BASS GAIN EQ*Param LoGain

EQ High Gain EQ TREBLE GAIN EQ*Param HiGain

EQ Low Frequency EQ BASS FREQUENCY EQ*Param LoFreq

EQ High Frequency EQ TREBLE FREQUENCY EQ*Param HiFreq

MW Filter Control MW LOW PASS FILTER CONTROL CTL*MW Control Filter

MW LFO Pitch Modulation Depth MW LFO PMOD DEPTH CTL*MW Modulation PMod

MW LFO Filter Modulation Depth MW LFO FMOD DEPTH CTL*MW Modulation FMod

MW LFO Amplitude Modulation Depth MW LFO AMOD DEPTH CTL*MW Modulation AMod

CAT Pitch Control CAT PITCH CONTROL CTL*AT Control Pitch

CAT Filter Control CAT LOW PASS FILTER CONTROL CTL*AT Control Filter

CAT LFO Pitch Modulation Depth CAT LFO PMOD DEPTH CTL*AT Modulation PMod

CAT LFO Filter Modulation Depth CAT LFO FMOD DEPTH CTL*AT Modulation FMod

CAT LFO Amplitude Modulation Depth CAT LFO AMOD DEPTH CTL*AT Modulation AMod

AC1 Controller Number AC1 CONTROLLER NUMBER CTL*AC Control Source

AC1 Filter Control AC1 LOW PASS FILTER CONTROL CTL*AC Control Filter

AC1 LFO Pitch Modulation Depth AC1 LFO PMOD DEPTH CTL*AC Modulation PMod

AC1 LFO Filter Modulation Depth AC1 LFO FMOD DEPTH CTL*AC Modulation FMod

AC1 LFO Amplitude Modulation Depth AC1 LFO AMOD DEPTH CTL*AC Modulation AMod

MIDI Data Format

1. Channel messages

1.1 Note on/note off

These messages convey keyboard performance data.

Range of note numbers received = C-2...G8 Velocity range = 1...127 (Velocity is received only for note-on)

When the Multi Part parameter “Rcv NOTE MESSAGE” = OFF, that part will not receive these messages. When the Voice parameter “Rcv NOTE OFF” = OFF, Key Off will not be received. When the Voice parameter “Rcv NOTE ON” = OFF, Key On will not be received.

1.2 Control changes

These messages convey control operation information for volume or pan etc. Their functions are differentiated by the control number (Ctrl#). If the Multi Part parameter Rcv CONTROL CHANGE = OFF, that part will not receive control changes.

1.2.1 Bank Select This message selects the voice bank.

Control# Parameter Data Range 0 Bank Select MSB 47, 79 (Uset Voice, Preset Voice) 32 Bank Select LSB 0...127

The Bank Select data will be processed only after a Program Change is received, and then voice bank will change at that time. If you wish to change the voice bank as well as the voice, you must transmit Bank Select and Program Change messages as a set, in the following order: Bank Select MSB, LSB, and Program Change.

1.2.2 Modulation This message is used primarily to control the depth of vibrato, but the depth of the following 6 types of effect can be controlled. The effect of this message can be changed by the following parameters.

* Multi Part Parameter l. MW PITCH CONTROL

2. MW FILTER CONTROL

3. MW AMPLITUDE CONTROL

4. MW LFO PMOD DEPTH

5. MW LFO FMOD DEPTH

6. MW LFO AMOD DEPTH By default, an LFO Pitch Modulation (PMOD) effect will apply.

Control# Parameter Data Range 1 Modulation 0...127

If the Multi Part parameter Rcv MODULATION = OFF, that part will not receive Modulation.

1.2.3 Data Entry This message sets the value of the parameter which was speciﬁed by RPN (see

1.2.15) and NRPN (see 1.2.14).

Control# Parameter Data Range 6 Data Entry MSB 0...127 38 Data Entry LSB 0...127

1.2.4 Main Volume This message controls the volume of each part. (It is used to adjust the volume balance between parts.)

Control# Parameter Data Range 7 Main Volume 0...127

When the Multi Part parameter Rcv VOLUME = OFF, that part will not receive Main Volume. With a value of 0 there will be no sound, and a value of 127 will produce the maximum volume. This message is processed on the host device (e.g., MOTIF, MU128, 9000Pro, etc.)

1.2.5 Panpot This message controls the panning (stereo location) of each part.

Control# Parameter Data Range 10 Pan 0...64...127

When the Multi Part parameter Rcv PAN = OFF, that part will not receive Panpot. 0 is left, 64 is center, and 127 is right. This message is processed on the host device (e.g., MOTIF, MU128, 9000Pro, etc.)

1.2.6 Expression This message controls expression for each part. It is used to create volume changes during a song.

Control# Parameter Data Range 1l Expression 0...127

If the Multi Part parameter Rcv EXPRESSION = OFF, that part will not receive Expression. This message is processed on the host device (e.g., MOTIF, MU128, 9000Pro, etc.)

1.2.7 Holdl This message controls sustain pedal on/off.

Control# Parameter Data Range 64 Hold1 0...63, 64...127

(OFF, ON)

When this is ON, currently-sounding notes will continue to sound even if noteoff messages are received. If the Multi Part parameter Rcv HOLD1 = OFF, that part will not receive Holdl.

1.2.8 Sostenuto This message controls sostenuto pedal on/off.

Control# Parameter Data Range 66 Sostenuto 0...63, 64...127

(OFF, ON)

If sostenuto is turned on while a note is sounding, that note will be sustained until sostenuto is turned OFF. If the Multi Part parameter Rcv SOSTENUTO = OFF, that part will not receive Sostenuto.

1.2.9 Harmonic Content This message adjusts the resonance of the ﬁlter that is speciﬁed for the sound.

Control# Parameter Data Range 71 Harmonic Content 0...64...127

(-64...0...+63)

Since this is a relative change parameter, it speciﬁes an increase or decrease relative to 64. Higher values will produce a more distinctive sound. For some sounds, the effective range may be less than the possible range of settings.

1.2.10 Release Time This message adjusts the EG release time that was speciﬁed by the sound data.

Control# Parameter Data Range 72 Release Time 0...64... 127

(-64...0...+63)

Since this is a relative change parameter, it speciﬁes an increase or decrease relative to 64. Increasing this value will lengthen the release time that follows a noteoff.

1.2.11 Attack Time This message adjusts the EG attack time that was speciﬁed by the sound data.

Control# Parameter Data Range 73 Attack Time 0...64... 127

(-64...0...+63)

Since this is a relative change parameter, it speciﬁes an increase or decrease relative to 64. Increasing this value will make the attack more gradual, and decreasing this value will make the attack sharper.

1.2.12 Brightness This message adjusts the cutoff frequency of the low pass ﬁlter speciﬁed by the sound data.

Control# Parameter Data Range 74 Brightness 0...64...127

(-64...0...+63)

Since this is a relative change parameter, it speciﬁes an increase or decrease relative to 64. Lower values will produce a more mellow sound. For some sounds, the effective range may be less than the possible range of settings.

1.2.13 Data Increment/Decrement (for RPN) This message is used to increment or decrement values for parameters speciﬁed by RPN (see 1.2.15), in steps of 1.

Control# Parameter Data Range 96 RPN Increment — 97 RPN Decrement —

The data byte is ignored.

1.2.14 NRPN (Non-registered parameter number) This is a message for setting the sound for things like vibrato, ﬁlter, EG or drum setup. Use NRPN MSB and NRPN LSB to specify the parameter that you wish to modify, and then use Data Entry (see 1.2.3) to set the value for the speciﬁed parameter.

Control# Parameter Data Range 98 NRPN LSB 0...127 99 NPRN MSB 0...127

If the Multi Part parameter Rcv NRPN = OFF, that part will not receive NRPN.

MIDI Data Format

The following NRPN messages can be received.

*1 See 1.2.3 *2 “–” means that the set value will be ignored. *3 Adjusts the time after the note is played until vibrato begins to take effect.

The effect will begin more quickly for lower values, and more slowly for higher values.

1.2.15 RPN (Registered parameter number) This message is used to specify part parameters such as Pitch Bend Sensitivity or Tuning. Use RPN MSB and RPN LSB to specify the parameter that you wish to modify, and then use Data Entry (see 1.2.3) to set the value of the speciﬁed parameter.

Control# Parameter Data Range 100 RPN LSB 0 ... 127 101 RPN MSB 0 ... 127

If the Multi Part parameter Rcv RPN = OFF, that part will not receive this message.

The following RPN messages can be received.

*1 Refer to 1.2.3 *2 “–” means that the set value will be ignored.

1.2.16 Assignable controller By assigning a control change number of 0...95 to a part, application of effects can be controlled. This device allows two control change numbers (AC1 and AC2) to be speciﬁed for each part. The following parameters specify the effect of AC1 and AC2:

* Multi Part Parameter

1. AC1, AC2 PITCH CONTROL

2. AC1, AC2 FILTER CONTROL

3. AC1, AC2 AMPLITUDE CONTROL

4. AC1, AC2 LFO PMOD DEPTH

5. AC1, AC2 LFO FMOD DEPTH

6. AC1, AC2 LFO AMOD DEPTH

The AC1 control change number is speciﬁed by the Multi Part parameter ACl CONTROLLER NUMBER, and the AC2 control change number is speciﬁed by the Multi Part parameter AC2 CONTROLLER NUMBER. AC1,AC2 AMPLITUDE CONTROL is processed on the host device (e.g., MOTIF, MU128, 9000Pro, etc.)

1.3 Channel mode messages

These messages specify the basic operation of a part.

1.3.1 All Sound Off This message silences all notes being played on the corresponding channel. However, channel messages such as Note-on and Hold-on will be maintained in their present state.

Control# Parameter Data Range 120 All Sound Off 0

1.3.2 Reset All Controllers This message changes the settings of the following controllers.

The following data is not changed Parameter values speciﬁed for program change, bank select MSB/LSB, volume, pan, RPN and NRPN.

Control# Parameter Data Range 121 Reset All Controllers 0

1.3.3 All Note Off This message turns off all notes which are currently on for the corresponding part. However, if Hold 1 or Sostenuto are on, notes will continue to sound until these are turned off.

Control# Parameter Data Range 123 All Note Off 0

1.3.4 Omni Off Works the same as when All Note Off is received.

Control# Parameter Data Range 124 Omni Off 0

1.3.5 Omni On Works the same as when All Note Off is received.

Control# Parameter Data Range 125 Omni On 0

1.4 Program change

This message is used to switch voices. It changes the program number on the receiving channel. When the change is to include the voice bank, transmit the program change after sending the Bank Select message (see 1.2.1). If the Multi Part parameter Rcv PROGRAM CHANGE = OFF, that part will not receive program changes.

1.5 Pitch bend

This message conveys information on pitch bend operations.

Basically, this message is for changing the pitch of a part, but the depth of the following six effects can be controlled. The effect of this message can be modiﬁed by the following parameters.

* Multi Part Parameter

1. BEND PITCH CONTROL

2. BEND FILTER CONTROL

3. BEND AMPLITUDE CONTROL

4. BEND LFO PMOD DEPTH

5. BEND LFO FMOD DEPTH

6. BEND LFO AMOD DEPTH

By default, the Pitch Control effect is applied. If the Multi Part parameter Rcv PITCH BEND CHANGE = OFF, that part will not receive pitch bend messages. BEND AMPLITUDE CONTROL is processed on the host device (e.g., MOTIF, MU128, 9000Pro, etc.)

NRPN MSB LSB

Data Entry*1 MSB LSB

Parameter Name and Data Range

01H 08H mm – *2 Vibrato rate

mm: 00H - 40H - 7FH (-64 ...0...+63)

01H 09H mm – Vibrato depth

mm: 00H - 40H - 7FH (-64 ...0...+63)

01H 0AH mm – *3 Vibrato delay

mm: 00H - 40H - 7FH (-64 ...0...+63)

01H 20H mm – Low pass ﬁlter cutoff frequency

mm: 00H - 40H - 7FH (-64 ...0...+63)

01H 21H mm – Low pass ﬁlter resonance

mm: 00H - 40H - 7FH (-64 ...0...+63)

01H 63H mm – EG Attack Time

mm: 00H - 40H - 7FH (-64 ...0...+63)

01H 64H mm – EG Decay Time

mm: 00H - 40H - 7FH (-64 ...0...+63)

01H 66H mm – EG Release Time

mm: 00H - 40H - 7FH (-64 ...0...+63)

RPN MSB LSB

Data Entry*1 MSB LSB

Parameter name and value range

00 00H mm –*2 Pitch bend sensitivity

mm: 00-18H (0...+24 semitones) Specify up to 2 octaves in semitone steps

00 01H mm ll Fine tuning

mm ll: 00H 00H -100 cents

mm 11: 40H 00H 0 cents

:: mm ll: 7FH 7FH +100 cents Note: The next after mm 11: 00H 7FH (= -87.5) cent is 01H 00H (-87.4) cents.

00H 02H mm – Coarse tuning

mm: 28H - 40H - 58H (-24...0...+24 semitones)

7FH 7FH – – RPN Null

This empties settings from RPN and NRPN numbers. Internal data is not affected.

Controller Value

Pitch bend change Channel pressure Polyphonic key pressure Modulation Expression Hold Portamento Sostenuto RPN NRPN

±0 (Center) 0 (OFF) 0 (OFF) 0 (OFF) 127 (Max.) 0 (OFF) 0 (OFF) 0 (OFF) Number unset, internal data is not affected. Number unset, internal data is not affected.

MIDI Data Format

1.6 Channel aftertouch

This message conveys the pressure after the key is played on the keyboard (for an entire MIDI channel). The pressure can be controlled for each part. This message will affect the notes currently playing.

The effect of this message can be modiﬁed by the following parameters.

* Multi Part Parameter

1. CAT PITCH CONTROL

2. CAT FILTER CONTROL

3. CAT AMPLITUDE CONTROL

4. CAT LFO PMOD DEPTH

5. CAT LFO FMOD DEPTH

6. CAT LFO AMOD DEPTH

By default, there will be no effect. If the Multi Part parameter Rcv CHANNEL AFTER TOUCH = OFF, that part will not receive Channel Aftertouch. CAT AMPLITUDE CONTROL is processed on the host device (e.g., MOTIF, MU128, 9000Pro, etc.)

2. System exclusive messages

2.1 Parameter changes

This device uses the following parameter changes. [ UNIVERSAL REALTIME MESSAGE ]

1) Master Volume

[ UNIVERSAL NON REALTIME MESSAGE ]

1) General MIDI System On

[ XG PARAMETER CHANGE]

1) XG System on

2) XG System parameter change

3) Multi Part parameter change

[ PLG150-DR/PLG150-PC NATIVE PARAMETER CHANGE ]

PLG150-DR/PLG150-PC NATIVE CURRENT VOICE parameter change

2. PLG150-DR/PLG150-PC NATIVE USER VOICE parameter change

3. PLG150-DR/PLG150-PC NATIVE MULTI PART parameter change

[ OTHER MESSAGE ]

1) Master tuning

2.1.1 Universal realtime messages

2.1.1.1 Master Volume

11110000 F0H = Exclusive status 01111111 7FH = Universal Real Time 01111111 7FH = ID of target device 00000100 04H = Sub-ID #1=Device Control Message 00000001 01H = Sub-ID #2=Master Volume

* 0sssssss SSH = Volume LSB

0ttttttt TTH = Volume MSB 11110111 F7H = End of Exclusive

11110000 F0H = Exclusive status 01111111 7FH = Universal Real Time 0xxxnnnn XNH = Device Number, xxx = don’t care 00000100 04H = Sub-ID #1=Device Control Message 00000001 01H = Sub-ID #2=Master Volume 0sssssss SSH = Volume LSB 0ttttttt TTH = Volume MSB 11110111 F7H = End of Exclusive

When received, the Volume MSB is reﬂected in the System Parameter MASTER VOLUME.

* The binary expression 0sssssss is expressed in hexadecimal as SSH.

The same applies elsewhere.

2.1.2 Universal non-realtime messages

2.1.2.1 General MIDI System On

11110000 F0H = Exclusive status 01111110 7EH = Universal Non-Real Time 01111111 7FH = ID of target device 00001001 09H = Sub-ID #1=General MIDI Message 00000001 01H = Sub-ID #2=General MIDI On 11110111 F7H = End of Exclusive

11110000 F0H = Exclusive status 01111110 7EH = Universal Non-Real Time 0xxxnnnn XNH = N:Device Number, X:don’t care 00001001 09H = Sub-ID #1=General MIDI Message 00000001 01H = Sub-ID #2=General MIDI On 11110111 F7H = End of Exclusive

When this message is received, the SOUND MODULE MODE is set to XG, and all data except for MIDI Master Tuning will be restored to the default value. Since approximately 50ms is required to process this message, be sure to allow an appropriate interval before sending the next message.

2.1.3 XG Parameter Change This message sets XG-related parameters. Each message can set a single parameter. The message format is as follows.

11110000 F0H Exclusive status 01000011 43H YAMAHA ID 0001nnnn 1NH N:device Number 01001100 4CH Model ID 0ggggggg GGH Address High 0mmmmmmm MMH Address Mid 0lllllll LLH Address Low 0sssssss SSH Data

11110111 F7H End of Exclusive

For parameters whose Data Size is 2 or 4, the appropriate amount of data will be transmitted as indicated by Size.

2.1.3.1 XG System On

11110000 F0H Exclusive status 01000011 43H YAMAHA ID 0001nnnn 1NH N:device Number 01001100 4CH Model ID 00000000 00H Address High 00000000 00H Address Mid 01111110 7EH Address Low 00000000 00H Data 11110111 F7H End of Exclusive

When ON is received, the SOUND MODULE MODE changes to XG. Since approximately 50ms is required to process this message, be sure to allow an appropriate interval before sending the next message.

2.1.3.2 XG System parameter change This message sets the XG SYSTEM block (see Tables <1-1> and <1-2>).

2.1.3.3 Multi Part parameter change This message sets the Multi Part block (see Tables <1-1> and <1-3>).

2.1.3.4 Part Assign parameter change This message sets the PART ASSIGN block (see Tables <1-1> and <1-4>).

2.1.4 PLG150-DR/PLG150-PC Native parameter change This message sets parameters unique to the PLG150-DR/PLG150-PC. Each message sets a single parameter. The message format is as follows.

11110000 F0H Exclusive status 01000011 43H YAMAHA ID 0001nnnn 1NH N:Device Number 01100111 67H Model ID 0ggggggg GGH Address High 0mmmmmmm MMH Address Mid 0lllllll LLH Address Low 0sssssss SSH Data

11110111 F7H End of Exclusive

For parameters whose Data Size is 2 or 4, the appropriate amount of data will be transmitted as indicated by Size.

2.1.4.1

PLG150-DR/PLG150-PC NATIVE CURRENT VOICE parameter change This message sets the PLG150-DR/PLG150-PC NATIVE CURRENT VOICE block (see Tables <2-1> and <2-2>).

2.1.4.2 PLG150-DR/PLG150-PC NATIVE USER VOICE parameter change This message sets the PLG150-DR/PLG150-PC NATIVE USER VOICE block (see Tables <2-1> and <2-3>).

2.1.4.3 PLG150-DR/PLG150-PC NATIVE MULTI PART parameter change This message sets the PLG150-DR/PLG150-PC NATIVE MULTI PART block (see Tables <2-1> and <2-4>).

2.1.5 Other parameter change messages

2.1.5.1 Master Tuning This message changes the pitch of all channels simultaneously.

11110000 F0H Exclusive status 01000011 43H YAMAHA ID 0001nnnn 1NH N:device Number 00100111 27H Model ID 00110000 30H Address High 00000000 00H Address Mid 00000000 00H Address Low 0000mmmm 0MH Master Tune MSB 0000llll 0LH Master Tune LSB 0xxxxxxx XXH don’t care 11110111 F7H End of Exclusive

In general, use the Master Tune parameter in XG System (see Table <1-2>).

MIDI Data Format

2.2 Bulk dump

This device uses only the following bulk dump messages.

[ XG BULK DUMP ]

1) XG System bulk dump

2) Multi Part bulk dump

[ PLG150-DR/PLG150-PC NATIVE BULK DUMP ]

1. PLG150-DR/PLG150-PC NATIVE CURRENT VOICE bulk dump

2. PLG150-DR/PLG150-PC NATIVE USER VOICE bulk dump

3. PLG150-DR/PLG150-PC NATIVE MULTI PART bulk dump

2.2.1 XG bulk dump This message sets XG-related parameters. Unlike parameter change messages, a single message can modify multiple parameters. This message format is as follows.

11110000 F0H Exclusive status 01000011 43H YAMAHA ID 0000nnnn 0NH N:Device Number 01001100 4CH Model ID 0sssssss SSH ByteCountMSB 0ttttttt TTH ByteCountLSB 0ggggggg GGH Address High 0mmmmmmm MMH Address Mid 0lllllll LLH Address Low 0vvvvvvv VVH Data

0kkkkkkk KKH Check-sum 11110111 F7H End of Exclusive

Address and Byte Count are given in tables <1-n>. Byte Count is indicated by the total size of the Data in tables <1-n>. Bulk dump is received when the beginning of the block is speciﬁed in “Address.” “Block” indicates the unit of the data string that is indicated in tables <1-n> as “Total Size.” Check sum is the value that produces a lower 7 bits of 0 when this Start Address, Byte Count, Data, and the Check sum itself are added.

2.2.1.1 XG System bulk dump

This message sets the XG SYSTEM block (see Tables <1-1> and <1-2>).

2.2.1.2 Multi Part bulk dump

This message sets the MULTI PART block (see Tables <1-1> and <1-3>).

2.2.2 PLG150-DR/PLG150-PC Native Bulk Dump This message sets the special parameters for PLG150-DR/PLG150-PC. Unlike Parameter change, one message can modify multiple parameters.

11110000 F0H Exclusive status 01000011 43H YAMAHA ID 0000nnnn 0NH N:Device Number 01100111 67H Model ID 0sssssss SSH ByteCountMSB 0ttttttt TTH ByteCountLSB 0ggggggg GGH Address High 0mmmmmmm MMH Address Mid 0lllllll LLH Address Low 0vvvvvvv VVH Data

0kkkkkkk KKH Check-sum 11110111 F7H End of Exclusive

The detail are the same as for 2.2.1 XG Bulk Dump. However, see Tables <2-n> for the Address, Byte, Count, and block.

2.2.2.1 PLG150-DR/PLG150-PC NATIVE CURRENT VOICE bulk dump

This message sets the PLG150-DR/PLG150-PC NATIVE CURRENT VOICE block (see Tables <2-1> and <2-2>).

2.2.2.2 PLG150-DR/PLG150-PC NATIVE USER VOICE bulk dump

This message sets the PLG150-DR/PLG150-PC NATIVE USER VOICE block (see Tables <2-1> and <2-3>).

2.2.2.3 PLG150-DR/PLG150-PC NATIVE MULTI PART bulk dump

This message sets the PLG150-DR/PLG150-PC NATIVE MULTI PART block (see Tables <2-1> and <2-4>).

3. Realtime Messages

3.1 Active Sensing

a) Send

This is not transmitted.

b) Receive

After FE is received one time, if the MIDI signal does not come within 300 msec, PLG150-DR/PLG150-PC will act the same as when ALL SOUND OFF, ALL NOTE OFF, and RESET ALL CONTROLLERS are received, and return to the condition where has not been received once.

<1 - 1> Parameter Base Address MODEL ID = 4C

Parameter

DescriptionAddress

(H) (M) (L)

XG SYSTEM

00 00 00 System 00 00 7E XG System On 00 00 7F All Parameter Reset

MULTI PART

08 00 00 Multi Part 1

::: :

08 0F 00 Multi Part 16

PART ASSIGN

70 05 00 PLG150-DR Part Assign 70 06 00 PLG150-PC Part Assign

MIDI Data Format

<1-2> MIDI Parameter Change table (XG SYSTEM)

Address Size Data Parameter Description Default (H) (H) (H) (H) 00 00 00 04 NOT USED

04 01 00 - 7F MASTER VOLUME** 0...127 7F 05 01 00 - 7F MASTER ATTENUATOR** 0...127 00 06 01 28 - 58 TRANSPOSE -24...+24[semitones] 40 7D 01 NOT USED – 7E 01 00 XG SYSTEM ON 00=XG system ON (receive only) – 7F 01 00 ALL PARAMETER RESET 00=ON (receive only) –

TOTAL SIZE 07

** Processed on the platform side (Motif, MU128, 9000Pro, etc.)

<1-3> MIDI Parameter Change table (MULTI PART)

Address Size Data Parameter Description Default (H) (H) (H) (H) 08 0p 00 01 NOT USED

01 01 00 - 7F BANK SELECT MSB 0...127 part10 = 7F

other parts = 00 02 01 00 - 7F BANK SELECT LSB 0...127 00 03 01 00 - 7F PROGRAM NUMBER 1...128 00 04 01 00 - 0F,7F Rcv CHANNEL A1...A16,Off Part Number 05 01 NOT USED 06 01 NOT USED 07 01 NOT USED 08 01 28 - 58 NOTE SHIFT -24...+24[semitones] 40 09 02 00 - 0F DETUNE -12.8...+12.7[Hz] 08 (80)

00 - 0F 1st bit3-0

m bit7-4 00

2nd bit3-0 m bit3-0 0B 01 00 - 7F VOLUME** 0...127 64 0C 01 00 - 7F VELOCITY SENSE DEPTH 0...127 40 0D 01 00 - 7F VELOCITY SENSE OFFSET 0...127 40 0E 01 00,01 - 7F PAN** C,L63...R63 40 0F 01 00 - 7F NOTE LIMIT LOW C-2...G8 00 10 01 00 - 7F NOTE LIMIT HIGH C-2...G8 7F 11 01 00 - 7F DRY LEVEL** 0...127 7F 12 01 00 - 7F CHORUS SEND** 0...127 00 13 01 00 - 7F REVERB SEND** 0...127 28 14 01 00 - 7F VARIATION SEND** 0...127 00 15 01 00 - 7F VIBRATO RATE -64...+63 40 16 01 00 - 7F VIBRATO DEPTH -64...+63 40 17 01 00 - 7F VIBRATO DELAY -64...+63 40 18 01 00 - 7F

LOW PASS FILTER CUTOFF FREQUENCY

-64...+63 40 19 01 00 - 7F LOW PASS FILTER RESONANCE -64...+63 40 1A 01 00 - 7F EG ATTACK TIME -64...+63 40 1B 01 00 - 7F EG DECAY TIME -64...+63 40 1C 01 00 - 7F EG RELEASE TIME -64...+63 40 1D 01 28 - 58 MW PITCH CONTROL -24...+24[semitones] 40 1E 01 00 - 7F MW LOW PASS FILTER CONTROL -9600...+9450[cent] 40 1F 01 00 - 7F MW AMPLITUDE CONTROL -100...+100[%] 40 20 01 00 - 7F MW LFO PMOD DEPTH 0...127 0A 21 01 00 - 7F MW LFO FMOD DEPTH 0...127 00 22 01 00 - 7F MW LFO AMOD DEPTH 0...127 00 23 01 28 - 58 BEND PITCH CONTROL -24...+24[semitones] 42 24 01 00 - 7F BEND LOW PASS FILTER CONTROL -9600...+9450[cent] 40 25 01 00 - 7F BEND AMPLITUDE CONTROL -100...+100[%] 40 26 01 00 - 7F BEND LFO PMOD DEPTH 0...127 00 27 01 00 - 7F BEND LFO FMOD DEPTH 0...127 00 28 01 00 - 7F BEND LFO AMOD DEPTH 0...127 00

TOTAL SIZE 29

30 01 00 - 01 Rcv PITCH BEND Off,On 01 31 01 00 - 01 Rcv CH AFTER TOUCH(CAT) Off,On 01 32 01 00 - 01 Rcv PROGRAM CHANGE Off,On 01 33 01 00 - 01 Rcv CONTROL CHANGE Off,On 01 34 01 NOT USED 35 01 00 - 01 Rcv NOTE MESSAGE Off,On 01 36 01 00 - 01 Rcv RPN Off,On 01 37 01 00 - 01 Rcv NRPN Off,On XGmode=01, GMmode=00 38 01 00 - 01 Rcv MODURATION Off,On 01 39 01 00 - 01 Rcv VOLUME Off,On 01 3A 01 00 - 01 Rcv PAN Off,On 01 3B 01 00 - 01 Rcv EXPRESSION Off,On 01 3C 01 00 - 01 Rcv HOLD1 Off,On 01 3D 01 NOT USED 3E 01 00 - 01 Rcv SOSTENUTO Off,On 01 3F 01 00 - 01 Rcv SOFT PEDAL Off,On 01 40 01 00 - 01 Rcv BANK SELECT Off,On XGmode=01, GMmode=00

MIDI Data Format

Address Size Data Parameter Description Default (H) (H) (H) (H)

41 01 NOT USED 42 01 NOT USED 43 01 NOT USED 44 01 NOT USED 45 01 NOT USED 46 01 NOT USED 47 01 NOT USED 48 01 NOT USED 49 01 NOT USED 4A 01 NOT USED 4B 01 NOT USED 4C 01 NOT USED 4D 01 28 - 58 CAT PITCH CONTROL -24...+24[semitones] 40 4E 01 00 - 7F CAT LOW PASS FILTER CONTROL -9600...+9450[cent] 40 4F 01 00 - 7F CAT AMPLITUDE CONTROL -100...+100[%] 40 50 01 00 - 7F CAT LFO PMOD DEPTH 0...127 00 51 01 00 - 7F CAT LFO FMOD DEPTH 0...127 00 52 01 00 - 7F CAT LFO AMOD DEPTH 0...127 00 53 01 NOT USED 54 01 NOT USED 55 01 NOT USED 56 01 NOT USED 57 01 NOT USED 58 01 NOT USED 59 01 00 - 5F AC1 CONTROLLER NUMBER 0...95 10 5A 01 28 - 58 AC1 PITCH CONTROL -24...+24[semitones] 40 5B 01 00 - 7F AC1 LOW PASS FILTER CONTROL -9600...+9450[cent] 40 5C 01 00 - 7F AC1 AMPLITUDE CONTROL -100...+100[%] 40 5D 01 00 - 7F AC1 LFO PMOD DEPTH 0...127 00 5E 01 00 - 7F AC1 LFO FMOD DEPTH 0...127 00 5F 01 00 - 7F AC1 LFO AMOD DEPTH 0...127 00 60 01 00 - 5F AC2 CONTROLLER NUMBER 0...95 11 61 01 28 - 58 AC2 PITCH CONTROL -24...+24[semitones] 40 62 01 00 - 7F AC2 LOW PASS FILTER CONTROL -9600...+9450[cent] 40 63 01 00 - 7F AC2 AMPLITUDE CONTROL -100...+100[%] 40 64 01 00 - 7F AC2 LFO PMOD DEPTH 0...127 00 65 01 00 - 7F AC2 LFO FMOD DEPTH 0...127 00 66 01 00 - 7F AC2 LFO AMOD DEPTH 0...127 00 67 01 NOT USED 68 01 NOT USED 69 01 00 - 7F PITCH EG INITIAL LEVEL -64...0...+63 40 6A 01 00 - 7F PITCH EG ATTACK TIME -64...0...+63 40 6B 01 00 - 7F PITCH EG RELEASE LEVEL -64...0...+63 40 6C 01 00 - 7F PITCH EG RELEASE TIME -64...0...+63 40 6D 01 01 - 7F VELOCITY LIMIT LOW 1...127 01 6E 01 01 - 7F VELOCITY LIMIT HIGH 1...127 7F

TOTAL SIZE 3F

p = PART NUMBER

** Processed on the platform side (Motif, MU128, 9000Pro, etc.)

<1-4> MIDI Parameter Change table (PART ASSIGN)

Address Size Data Parameter Description Default (H) (H) (H) (H) 70 05 nn 01 00 - 0F,7F PLG150-DR PART ASSIGN PART1...PART16,OFF 00

06 mm 01 00 - 0F,7F PLG150-PC PART ASSIGN PART1...PART16,OFF 00

nn = PLG150-DR SERIAL NUMBER mm = PLG150-PC SERIAL NUMBER

MIDI Data Format

<2-1> Parameter Base Address MODEL ID = 67

<2-2> MIDI Parameter Change Table (PLG150-DR/PLG150-PC NATIVE CURRENT VOICE)

Address Size Data Parameter Description Default (H) (H) (H) (H) 1p 00 00 01 20 - 7F NAME 53 'S'

01 01 20 - 7F NAME 69 'i' 02 01 20 - 7F NAME 6C 'l' 03 01 20 - 7F NAME 65 'e' 04 01 20 - 7F NAME 6E 'n' 05 01 20 - 7F NAME 63 'c' 06 01 20 - 7F NAME 65 'e' 07 01 20 - 7F NAME 20 ' ' 08 01 00 - 7F VOLUME -

∞ ... 0[dB] 7F 09 01 00 - 7F REVERB SEND 00 0A 01 00 RESERVED 00 0B 01 00 RESERVED 00

TOTAL SIZE 0C

1p 00 40 01 4F RESERVED 4F

41 01 m RESERVED m 42 01 00 - 50 ORIGINAL KIT 50

TOTAL SIZE 03

m = PLG150-DR: 0

PLG150-PC: 1

1p 01 00 02 00 - 7F REVERB EFFECT TYPE MSB 00

00 - 7F REVERB EFFECT TYPE LSB 00 02 01 00 - 7F REVERB EFFECT PARAMETER 1 00 03 01 00 - 7F REVERB EFFECT PARAMETER 2 00 04 01 00 - 7F REVERB EFFECT PARAMETER 3 00 05 01 00 - 7F REVERB EFFECT PARAMETER 4 00 06 01 00 - 7F REVERB EFFECT PARAMETER 5 00 07 01 00 - 7F REVERB EFFECT PARAMETER 6 00 08 01 00 - 7F REVERB EFFECT PARAMETER 7 00 09 01 00 - 7F REVERB EFFECT PARAMETER 8 00 0A 01 00 - 7F REVERB EFFECT PARAMETER 9 00 0B 01 00 - 7F REVERB EFFECT PARAMETER 10 00 0C 01 00 - 7F REVERB EFFECT PARAMETER 11 00 0D 01 00 - 7F REVERB EFFECT PARAMETER 12 00 0E 01 00 - 7F REVERB EFFECT PARAMETER 13 00 0F 01 00 - 7F REVERB EFFECT PARAMETER 14 00 10 01 00 - 7F REVERB EFFECT PARAMETER 15 00 11 01 00 - 7F REVERB EFFECT PARAMETER 16 00 12 01 00 - 7F REVERB EFFECT RETURN 00 13 01 01 - 7F REVERB EFFECT PAN 40

TOTAL SIZE 14

Parameter

DescriptionAddress

(H) (M) (L)

PLG150-DR/PLG150-PC NATIVE CURRENT VOICE (common)

Multi Part1

Multi Part16

PLG150-DR/PLG150-PC NATIVE CURRENT VOICE (instrument)

Multi Part1

Multi Part16

PLG150-DR NATIVE USER VOICE (common)

Voice1

Voice8

PLG150-PC NATIVE USER VOICE (common)

Voice1

Voice8

PLG150-DR NATIVE USER VOICE (instrument)

Voice1

Voice8

PLG150-PC NATIVE USER VOICE (instrument)

Voice1

Voice8

PLG150-DR NATIVE MULTI PART (note select)

Native Multi Part1

Native Multi Part16

PLG150-DR NATIVE MULTI PART (note select parameter)

Native Multi Part1

Native Multi Part16

PLG150-DR NATIVE MULTI PART (effect parameter)

Native Multi Part1

Native Multi Part16

PLG150-PC NATIVE MULTI PART (note select)

Native Multi Part1

Native Multi Part16

PLG150-PC NATIVE MULTI PART (note select parameter)

Native Multi Part1

Native Multi Part16

PLG150-PC NATIVE MULTI PART (effect parameter)

Native Multi Part1

Native Multi Part16

Parameter

DescriptionAddress

(H) (M) (L)

MIDI Data Format

Address Size Data Parameter Description Default (H) (H) (H) (H) 1p 03 00 02 00 - 7F INSERTION EFFECT TYPE MSB 40

00 - 7F INSERTION EFFECT TYPE LSB 00 02 02 00 - 7F INSERTION EFFECT PARAMETER 1 MSB MSB bit6-0

m bit13-7 00

00 - 7F INSERTION EFFECT PARAMETER 1 LSB LSB bit6-0

m bit6-0 00

04 02 00 - 7F INSERTION EFFECT PARAMETER 2 MSB MSB bit6-0

m bit13-7 00

00 - 7F INSERTION EFFECT PARAMETER 2 LSB LSB bit6-0

m bit6-0 00

06 02 00 - 7F INSERTION EFFECT PARAMETER 3 MSB MSB bit6-0

m bit13-7 00

00 - 7F INSERTION EFFECT PARAMETER 3 LSB LSB bit6-0

m bit6-0 00

08 02 00 - 7F INSERTION EFFECT PARAMETER 4 MSB MSB bit6-0

m bit13-7 00

00 - 7F INSERTION EFFECT PARAMETER 4 LSB LSB bit6-0

m bit6-0 00

0A 02 00 - 7F INSERTION EFFECT PARAMETER 5 MSB MSB bit6-0

m bit13-7 00

00 - 7F INSERTION EFFECT PARAMETER 5 LSB LSB bit6-0

m bit6-0 00

0C 02 00 - 7F INSERTION EFFECT PARAMETER 6 MSB MSB bit6-0

m bit13-7 00

00 - 7F INSERTION EFFECT PARAMETER 6 LSB LSB bit6-0

m bit6-0 00

0E 02 00 - 7F INSERTION EFFECT PARAMETER 7 MSB MSB bit6-0

m bit13-7 00

00 - 7F INSERTION EFFECT PARAMETER 7 LSB LSB bit6-0

m bit6-0 00

10 02 00 - 7F INSERTION EFFECT PARAMETER 8 MSB MSB bit6-0

m bit13-7 00

00 - 7F INSERTION EFFECT PARAMETER 8 LSB LSB bit6-0

m bit6-0 00

12 02 00 - 7F INSERTION EFFECT PARAMETER 9 MSB MSB bit6-0

m bit13-7 00

00 - 7F INSERTION EFFECT PARAMETER 9 LSB LSB bit6-0

m bit6-0 00

14 02 00 - 7F INSERTION EFFECT PARAMETER 10 MSB MSB bit6-0

m bit13-7 00

00 - 7F INSERTION EFFECT PARAMETER 10 LSB LSB bit6-0 m bit6-0 00 16 01 00 - 7F INSERTION EFFECT PARAMETER 11 00 17 01 00 - 7F INSERTION EFFECT PARAMETER 12 00 18 01 00 - 7F INSERTION EFFECT PARAMETER 13 00 19 01 00 - 7F INSERTION EFFECT PARAMETER 14 00 1A 01 00 - 7F INSERTION EFFECT PARAMETER 15 00 1B 01 00 - 7F INSERTION EFFECT PARAMETER 16 00 1C 01 00 - 7F INSERTION EFFECT TO REVERB SEND 00

TOTAL SIZE 1D

2p nn 00 01 00 - 7F INSTRUMENT PITCH COARSE 40

01 01 00 - 7F INSTRUMENT PITCH FINE 40 02 01 00 - 59 - 7F INSTRUMENT LEVEL -

∞ ... 0[dB] ... +6[dB] 7F 03 01 00,01 - 7F INSTRUMENT ALTERNATE GROUP Off,Group1...127 00 04 01 00,01 - 7F INSTRUMENT PAN Random,L63...R63 40 05 01 00 - 7F INSTRUMENT REVERB SEND 40 06 01 00 RESERVED 00 07 01 00 - 01 INSTRUMENT INSERTION ON/OFF Off,On 00 08 01 00 - 01 INSTRUMENT KEY ASSIGN Single,Multi 00 09 01 00 - 01 INSTRUMENT RCV NOTE OFF Off,On 01 0A 01 00 - 01 INSTRUMENT RCV NOTE ON Off,On 01 0B 01 00 - 7F INSTRUMENT FILTER CUTOFF FREQUENCY 40 0C 01 00 - 7F INSTRUMENT FILTER RESONANCE 40 0D 01 00 - 7F INSTRUMENT EG ATTACK RATE 40 0E 01 00 - 7F INSTRUMENT EG DECAY1 RATE 40 0F 01 00 - 7F INSTRUMENT EG DECAY2 RATE 40

TOTAL SIZE 10

p = PART NUMBER nn = INSTRUMENT NUMBER

<2-3> MIDI Parameter Change Table (PLG150-DR/PLG150-PC NATIVE USER VOICE)

Address Size Data Parameter Description Default (H) (H) (H) (H) 3v 00 00 01 20 - 7F NAME 4C ' L '

01 01 20 - 7F NAME 69 ' i ' 02 01 20 - 7F NAME 76 ' v ' 03 01 20 - 7F NAME 65 ' e ' 04 01 20 - 7F NAME 52 ' R ' 05 01 20 - 7F NAME 6D ' m ' 06 01 20 - 7F NAME 20 ' ' 07 01 20 - 7F NAME 41 ' A ' 08 01 00 - 7F VOLUME -

∞ ... 0[dB] 7F 09 01 00 - 7F REVERB SEND 1A 0A 01 00 RESERVED 00 0B 01 00 RESERVED 00

TOTAL SIZE 0C

3v 00 40 01 4F RESERVED 4F

41 01 m RESERVED m 42 01 00 - 50 ORIGINAL KIT 00

TOTAL SIZE 03

m = PLG150-DR: 0

PLG150-PC: 1

MIDI Data Format

Address Size Data Parameter Description Default (H) (H) (H) (H) 3v 01 00 02 00 - 7F REVERB EFFECT TYPE MSB 02

00 - 7F REVERB EFFECT TYPE LSB 02 02 01 00 - 7F REVERB EFFECT PARAMETER 1 09 03 01 00 - 7F REVERB EFFECT PARAMETER 2 0A 04 01 00 - 7F REVERB EFFECT PARAMETER 3 1B 05 01 00 - 7F REVERB EFFECT PARAMETER 4 05 06 01 00 - 7F REVERB EFFECT PARAMETER 5 24 07 01 00 - 7F REVERB EFFECT PARAMETER 6 00 08 01 00 - 7F REVERB EFFECT PARAMETER 7 00 09 01 00 - 7F REVERB EFFECT PARAMETER 8 00 0A 01 00 - 7F REVERB EFFECT PARAMETER 9 00 0B 01 00 - 7F REVERB EFFECT PARAMETER 10 00 0C 01 00 - 7F REVERB EFFECT PARAMETER 11 00 0D 01 00 - 7F REVERB EFFECT PARAMETER 12 03 0E 01 00 - 7F REVERB EFFECT PARAMETER 13 37 0F 01 00 - 7F REVERB EFFECT PARAMETER 14 00 10 01 00 - 7F REVERB EFFECT PARAMETER 15 40 11 01 00 - 7F REVERB EFFECT PARAMETER 16 00 12 01 00 - 7F REVERB EFFECT RETURN 40 13 01 01 - 7F REVERB EFFECT PAN 40

TOTAL SIZE 14

3v 03 00 02 00 - 7F INSERTION EFFECT TYPE MSB 4D

00 - 7F INSERTION EFFECT TYPE LSB 00 02 02 00 - 7F INSERTION EFFECT PARAMETER 1 MSB MSB bit6-0

m bit13-7 00

00 - 7F INSERTION EFFECT PARAMETER 1 LSB LSB bit6-0 m bit6-0 1C 04 02 00 - 7F INSERTION EFFECT PARAMETER 2 MSB MSB bit6-0 m bit13-7 00

00 - 7F INSERTION EFFECT PARAMETER 2 LSB LSB bit6-0 m bit6-0 40 06 02 00 - 7F INSERTION EFFECT PARAMETER 3 MSB MSB bit6-0 m bit13-7 00

00 - 7F INSERTION EFFECT PARAMETER 3 LSB LSB bit6-0 m bit6-0 32 08 02 00 - 7F INSERTION EFFECT PARAMETER 4 MSB MSB bit6-0 m bit13-7 00

00 - 7F INSERTION EFFECT PARAMETER 4 LSB LSB bit6-0 m bit6-0 42 0A 02 00 - 7F INSERTION EFFECT PARAMETER 5 MSB MSB bit6-0 m bit13-7 00

00 - 7F INSERTION EFFECT PARAMETER 5 LSB LSB bit6-0 m bit6-0 00 0C 02 00 - 7F INSERTION EFFECT PARAMETER 6 MSB MSB bit6-0 m bit13-7 00

00 - 7F INSERTION EFFECT PARAMETER 6 LSB LSB bit6-0 m bit6-0 00 0E 02 00 - 7F INSERTION EFFECT PARAMETER 7 MSB MSB bit6-0 m bit13-7 00

00 - 7F INSERTION EFFECT PARAMETER 7 LSB LSB bit6-0 m bit6-0 00 10 02 00 - 7F INSERTION EFFECT PARAMETER 8 MSB MSB bit6-0 m bit13-7 00

00 - 7F INSERTION EFFECT PARAMETER 8 LSB LSB bit6-0 m bit6-0 00 12 02 00 - 7F INSERTION EFFECT PARAMETER 9 MSB MSB bit6-0 m bit13-7 00

00 - 7F INSERTION EFFECT PARAMETER 9 LSB LSB bit6-0 m bit6-0 00 14 02 00 - 7F INSERTION EFFECT PARAMETER 10 MSB MSB bit6-0 m bit13-7 00

TOTAL SIZE 1D

4v nn 00 01 00 - 7F INSTRUMENT PITCH COARSE 40

01 01 00 - 7F INSTRUMENT PITCH FINE 40 02 01 00 - 59 - 7F INSTRUMENT LEVEL -

∞ ... 0[dB] ... +6[dB] depends on voice 03 01 00,01 - 7F INSTRUMENT ALTERNATE GROUP Off,Group1...127 depends on voice 04 01 00 - 7F INSTRUMENT PAN Ramdom,L63 ... R63 40 05 01 00 - 7F INSTRUMENT REVERB SEND depends on voice 06 01 00 RESERVED 00 07 01 00 - 01 INSTRUMENT INSERTION ON/OFF Off,On depends on voice 08 01 00 - 01 INSTRUMENT KEY ASSIGN Single,Multi depends on voice 09 01 00 - 01 INSTRUMENT RCV NOTE OFF Off,On depends on voice 0A 01 00 - 01 INSTRUMENT RCV NOTE ON Off,On 01 0B 01 00 - 7F INSTRUMENT FILTER CUTOFF FREQUENCY 40 0C 01 00 - 7F INSTRUMENT FILTER RESONANCE 40 0D 01 00 - 7F INSTRUMENT EG ATTACK RATE 40 0E 01 00 - 7F INSTRUMENT EG DECAY1 RATE 40 0F 01 00 - 7F INSTRUMENT EG DECAY2 RATE 40

TOTAL SIZE 10

v = PLG150-DR: USER VOICE NUMBER(1...8) - 1

PLG150-PC: USER VOICE NUMBER(1...8) + 7

nn =INSTRUMENT NUMBER(0...127)

MIDI Data Format

<2-4> MIDI Parameter Change Table (PLG150-DR/PLG150-PC NATIVE MULTI PART)

Address Size Data Parameter Description Default (H) (H) (H) (H) 5m 0p 00 02 00 - 01 NOTE SELECT1 MSB 0...127,128: C-2...G8,Off 01 (FF)

00 - 7F NOTE SELECT1 LSB MSB bit0

m bit7 7F

LSB bit6-0

m bit6-0

02 02 00 - 01 NOTE SELECT2 MSB 0...127,128: C-2...G8,Off 01 (FF)

00 - 7F NOTE SELECT2 LSB MSB bit0

m bit7 7F

LSB bit6-0

m bit6-0

04 02 00 - 01 NOTE SELECT3 MSB 0...127,128: C-2...G8,Off 01 (FF)

00 - 7F NOTE SELECT3 LSB MSB bit0

m bit7 7F

LSB bit6-0

m bit6-0

06 02 00 - 01 NOTE SELECT4 MSB 0...127,128: C-2...G8,Off 01 (FF)

00 - 7F NOTE SELECT4 LSB MSB bit0

m bit7 7F

LSB bit6-0

m bit6-0

TOTAL SIZE 08

m = PLG150-DR: 0

PLG150-PC: 8

p = PART NUMBER

5m 0p 00 01 00 - 7F NOTE SELECT1 TUNE -64...+63[cent] 40

01 01 00 - 02 NOTE SELECT1 INSERTION EFFECT Off,On,Inst 02 02 01 00 - 7F NOTE SELECT1 LEVEL -64...+63 40 03 02 00 - 40 NOTE SELECT1 PAN MSB -127...+127 40 (2000)

00 - 7F NOTE SELECT1 PAN LSB MSB bit6-0

m bit13-7 00

MSB bit6-0 m bit6-0

05 02 00 - 40 NOTE SELECT1 REV SEND MSB -127...+127 40 (2000)

00 - 7F NOTE SELECT1 REV SEND LSB MSB bit6-0 m bit13-7 00

MSB bit6-0 m bit6-0 07 01 00 - 7F NOTE SELECT2 TUNE -64...+63[cent] 40 08 01 00 - 02 NOTE SELECT2 INSERTION EFFECT Off,On,Inst 02 09 01 00 - 7F NOTE SELECT2 LEVEL -64...+63 40 0A 02 00 - 40 NOTE SELECT2 PAN MSB -127...+127 40 (2000)

00 - 7F NOTE SELECT2 PAN LSB MSB bit6-0 m bit13-7 00

MSB bit6-0 m bit6-0 0C 02 00 - 40 NOTE SELECT2 REV SEND MSB -127...+127 40 (2000)

00 - 7F NOTE SELECT2 REV SEND LSB MSB bit6-0 m bit13-7 00

MSB bit6-0 m bit6-0 0E 01 00 - 7F NOTE SELECT3 TUNE -64...+63[cent] 40 0F 01 00 - 02 NOTE SELECT3 INSERTION EFFECT Off,On,Inst 02 10 01 00 - 7F NOTE SELECT3 LEVEL -64...+63 40 11 02 00 - 40 NOTE SELECT3 PAN MSB -127...+127 40 (2000)

00 - 7F NOTE SELECT3 PAN LSB MSB bit6-0 m bit13-7 00

MSB bit6-0 m bit6-0 13 02 00 - 40 NOTE SELECT3 REV SEND MSB -127...+127 40 (2000)

00 - 7F NOTE SELECT3 REV SEND LSB MSB bit6-0 m bit13-7 00

MSB bit6-0 m bit6-0 15 01 00 - 7F NOTE SELECT4 TUNE -64...+63[cent] 40 16 01 00 - 02 NOTE SELECT4 INSERTION EFFECT Off,On,Inst 02 17 01 00 - 7F NOTE SELECT4 LEVEL -64...+63 40 18 02 00 - 40 NOTE SELECT4 PAN MSB -127...+127 40 (2000)

00 - 7F NOTE SELECT4 PAN LSB MSB bit6-0 m bit13-7 00

MSB bit6-0 m bit6-0 1A 02 00 - 40 NOTE SELECT4 REV SEND MSB -127...+127 40 (2000)

00 - 7F NOTE SELECT4 REV SEND LSB MSB bit6-0

m bit13-7 00

MSB bit6-0

m bit6-0

TOTAL SIZE 1C

m = PLG150-DR: 1

PLG150-PC: 9

p = PART NUMBER

5m 0p 00 01 08 - 28,29 INSERTION EFFECT LOW EQ FREQUENCY 50...2.0k[Hz],Voice 29

01 01 34 - 4C,4D INSERTION EFFECT LOW EQ GAIN -12...+12[dB],Voice 4D 02 01 1C - 3A,3B INSERTION EFFECT HIGH EQ FREQUENCY 500...16.0k[Hz],Voice 3B 03 01 34 - 4C,4D INSERTION EFFECT HIGH EQ GAIN -12...+12[dB],Voice 4D 04 02 00 - 40 INSERTION EFFECT LFO FREQUENCY MSB -127...+127 40 (2000)

00 - 7F INSERTION EFFECT LFO FREQUENCY LSB MSB bit6-0

m bit13-7 00

MSB bit6-0

m bit6-0

06 02 00 - 40 INSERTION EFFECT LFO DEPTH MSB -127...+127 40 (2000)

00 - 7F INSERTION EFFECT LFO DEPTH LSB MSB bit6-0

m bit13-7 00

MSB bit6-0

m bit6-0

08 02 00 - 40 INSERTION EFFECT DRIVE MSB -127...+127 40 (2000)

00 - 7F INSERTION EFFECT DRIVE LSB MSB bit6-0

m bit13-7 00

MSB bit6-0

m bit6-0

0A 02 00 - 40 INSERTION EFFECT DRY/WET MSB -127...+127 40 (2000)

00 - 7F INSERTION EFFECT DRY/WET LSB MSB bit6-0

m bit13-7 00

TOTAL SIZE 0C

m = PLG150-DR: 2

PLG150-PC: A

p = PART NUMBER

MIDI Implementation Chart

YAMAHA [ Drums/Percussion Plug-in Board ] Date :26-APL-2002 Model PLG150-DR/PLG150-PC MIDI Implementation Chart Version : 1.0

Transmitted Recognized Remarks

Function...

Basic Default x 1 Channel Changed x 1-16

Default x 3

Mode Messages x 3,4 *2

Altered ************** x

Note x 0-127 Number : True voice ************** 13-108

Velocity Note ON x o 9nH,v=1-127

Note OFF x x

After Key's x x Touch Ch's x o *1

Pitch Bend x o 0-24 semi *1

0,32 x o *1 Bank Select 1,10 x o *1 6,38 x o *1 Data Entry

64,66 x o *1

Control 71-74 x o *1 Sound Controller

96-97 x o *1 RPN Inc,Dec

Change 98-99 x o *1 NRPN LSB,MSB

100-101 x o *1 RPN LSB,MSB

MIDI Implementation Chart

Prog x o 1-128 Change : True # ************** 1-80

System Exclusive o *3 o *3

: Song Pos. x x Common : Song Sel. x x : Tune x x

System : Clock x x Real Time: Commands x x

:All Sound Off x o(120) Aux :Reset All Cntrls x o(121) :Local ON/OFF x x Mes- :All Notes OFF x o(123) sages:Active Sense x o :Reset x x

Notes: *1 receive if switch is on.

*2 "4" is always treated as "3" regardless of its value. *3 transmit/receive if exclusive switch is on.

Mode 1 : OMNI ON , POLY Mode 2 : OMNI ON ,MONO o : Yes Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF,MONO x : No

SOFTWARE LICENSING AGREEMENT

The following is a legal agreement between you, the end user, and Yamaha Corporation (“Yamaha”). The enclosed Yamaha software program is licensed by Yamaha to the original purchaser for use only on the terms set forth herein. Please read this licensing agreement with care. Opening this package indicates that you accept all terms outlined herein. If you do not agree to the terms, return this package unopened to Yamaha for a full refund.

1. GRANT OF LICENSE AND COPYRIGHT

Yamaha grants you, the original purchaser, the right to use one copy of the enclosed software program and data (“SOFTWARE”) on a single-user computer system. You may not use it on more than one computer or computer terminal. The SOFTWARE is owned by Yamaha and is protected by Japanese copyright laws and all applicable international treaty provisions. You are entitled to claim ownership of the media in which the SOFTWARE is included. Therefore, you must treat the SOFTWARE like any other copyrighted materials.

2. RESTRICTIONS

The SOFTWARE program is copyrighted. You may not engage in reverse engineer-ing or reproduction of the SOFTWARE by other conceivable methods. You may not reproduce, modify, change, rent, lease, resell, or distribute the SOFTWARE in whole or in part, or create derivative works from the SOFTWARE. You may not transmit or network the SOFTWARE with other computers.

You may transfer ownership of the SOFTWARE and the accompanying written materials on a permanent basis provided that you retain no copies and the recipient agrees to the terms of the licensing agreement.

3. TERMINATION

The licensing condition of the software program becomes effective on the day that you receive the SOFTWARE. If any one of the copyright laws or clauses of the licensing conditions is violated, the licensing agreement shall be terminated automatically without notice from Yamaha. In this case, you must destroy the licensed SOFTWARE and its copies immediately.

4. PRODUCT WARRANTY

Yamaha warrants to the original purchaser that if the SOFTWARE, when used in normal conditions, will not perform the functions described in the manual provided by Yamaha, the sole remedy will be that Yamaha will replace any media which proves defective in materials or workmanship on an exchange basis without charge. Except as expressly set forth above, the SOFTWARE is provided “as is,” and no other war-ranties, either expressed or implied, are made with respect to this software, including, without limitation the implied warranties of merchantability and ﬁtness for a particular purpose.

5. LIMITED LIABILITY

Your sole remedies and Yamaha’s entire liability are as set forth above. In no event will Yamaha be liable to you or any other person for any damages, including without limitation any incidental or consequential damages, expenses, lost proﬁts, lost savings or other damages arising out of the use or inability to use such SOFTWARE even if Yamaha or an authorized dealer has been advised of the possibility of such damages, or for any claim by any other party.

6. GENERAL

This license agreement shall be interpreted according to and governed by Japanese laws.

SOFTWARE-LIZENZVEREINBARUNG

Die folgende Vereinbarung ist eine rechtsgültige Vereinbarung zwischen Ihnen, dem Endanwender, und der Yamaha Corporation (“Yamaha”). Yamaha erteilt dem ursprünglichen Käufer für das beiliegende Yamaha-Softwareprogramm ausschließlich zu den hier ausgeführten Bedingungen eine Lizenz zur Verwendung. Bitte lesen Sie diese Lizenzvereinbarung sorgfältig. Durch das Öffnen dieser Packung bringen Sie zum Ausdruck, daß Sie alle darin enthaltenen Bedingungen akzeptieren. Wenn Sie nicht mit den Bedingungen einverstanden sind, können Sie die Packung ungeöffnet an Yamaha zurückgeben; der Kaufpreis wird in voller Höhe zurückerstattet.

1. ERETILUNG VON LIZENZ UND COPYRIGHT

Yamaha erteilt Ihnen, dem ursprünglichen Käufer, das Recht, ein Exemplar des beiliegenden Softwareprogramms und der darin enthaltenen Daten (“SOFTWARE”) als Einzelperson auf jeweils einem Computer zu verwenden. Sie dürfen sie nicht auf mehr als einem Computer bzw. einer Computerstation verwenden. Die SOFTWARE bleibt im Besitz von Yamaha und ist durch japanische Copyrightgesetze sowie alle anwendbaren internationalen Vertragsbestimmungen geschützt. Sie haben ein Anspruchsrecht auf das Eigentum an den Medien, denen die SOFTWARE beiliegt. Daher müssen Sie die SOFTWARE wie alle anderen durch Copyright geschützten Materialien behandeln.

2. EINSCHRÄNKUNGEN

Die SOFTWARE ist durch Copyright geschützt. Sie dürfen Sie weder analysieren noch durch anderweitige Methoden reproduzieren. Sie dürfen die SOFTWARE weder ganz noch teilweise reproduzieren, modiﬁzieren, verändern, gegen Entgelt oder unentgeltlich verleihen, verkaufen oder vertreiben, und Sie dürfen auf der Grundlage der SOFTWARE keine Ableitungen erstellen. Sie dürfen die SOFTWARE nicht an andere Computer senden oder in Netzwerke einspeisen. Sie dürfen das Eigentum an der SOFTWARE und den schriftlichen Begleitmaterialien auf unbefristeter Basis unter den Voraussetzungen übertragen, daß Sie keine Kopien zurückbehalten und sich der Empfänger mit den Bedingungen der Lizenzvereinbarung einverstanden erklärt.

3. BEENDIGUNG

Die Lizenzbedingung des Softwareprogramms wird am Tag, an dem Sie die SOFTWARE erhalten, wirksam. Falls ein Copyrightgesetz oder eine Bestimmung der Lizenzbedingungen verletzt wird, wird automatisch und ohne Benachrichtigung durch Yamaha die Lizenzvereinbarung beendet. In diesem Fall müssen Sie die lizensierte SOFTWARE und ihre Kopien unverzüglich vernichten.

4. PRODUKTGARANTIE

Yamaha garantiert dem ursprünglichen Käufer, daß, falls die SOFTWARE bei Verwendung unter normalen Bedingungen nicht die in der von Yamaha bereitgestellten Anleitung beschriebenen Funktionen erfüllt, die einzige Abhilfe darin bestehen wird, daß Yamaha auf Austauschbasis kostenlos jedes Medium ersetzen wird, das Material- oder Verarbeitungsfehler aufweist. Abgesehen von dem oben Ausgeführten wird die SOFTWARE “wie die Ware liegt und steht” geliefert, und es werden keine anderen ausdrücklichen oder stillschweigenden Garantien hinsichtlich dieser Software übernommen, einschließlich, aber nicht beschränkt auf, die stillschweigenden Garantien für handelsübliche Qualität und Eignung für einen bestimmten Einsatzzweck.

5. BESCHRÄNKTE HAFTUNG

Ihre einzige Abhilfe und die gesamte Haftung Yamahas bestehen in dem oben Ausgeführten. Keinesfalls haftet Yamaha Ihnen oder einer anderen Person gegenüber für etwaige Schäden, einschließlich, aber nicht beschränkt auf, zufällige Schäden oder Folgeschäden, Kosten, Verdienstausfall, verlorene Ersparnisse oder andere Schadenersatzansprüche, die aus der Verwendung der SOFTWARE oder aus der Tatsache hervorgehen, daß diese SOFTWARE nicht verwendet werden konnte, selbst wenn Yamaha oder ein autorisierter Händler über die Möglichkeit derartiger Schadenersatzansprüche informiert wurde, oder für etwaige andere Ansprüche einer anderen Partei.

6. ALLGEMEINES

Diese Lizenzvereinbarung soll gemäß und in Übereinstimmung mit den japanischen Gesetzen ausgelegt werden.

CONTRAT DE LICENCE DE LOGICIEL

Ceci est un contrat entre vous-même, l’utilisateur ﬁnal, et Yamaha Corporation (« Yamaha »). Le logiciel Yamaha ci-inclus est concédé sous licence par Yamaha à l’acheteur original et ne peut être utilisé que dans les conditions prévues aux présentes. Veuillez lire attentivement ce contrat de licence. Le fait d’ouvrir ce coffret indique que vous acceptez l’ensemble des termes du contrat. Si vous n’acceptez pas lesdits termes, renvoyez le coffret non ouvert à Yamaha pour en obtenir le remboursement intégral.

1. CONCESSION DE LICENCE ET DROITS D’AUTEUR

Yamaha vous concède le droit d’utiliser, en tant qu’acheteur original, un exemplaire du logiciel et des données afférentes à celui-ci (« LOGICIEL ») sur un ordinateur pour utilisateur unique. Vous n’êtes pas autorisé à utiliser ces éléments sur plus d’un ordinateur ou terminal d’ordinateur. Le LOGICIEL est la propriété de Yamaha. Il est protégé par les dispositions relatives au droit d’auteur contenues dans la législation japonaise et les traités internationaux. Vous êtes en droit de revendiquer l’appartenance du support du LOGICIEL. A ce titre, vous devez traiter le LOGICIEL comme tout autre élément protégé par le droit d’auteur.

2. RESTRICTIONS

Le LOGICIEL est protégé par le droit d’auteur. Vous n’êtes pas autorisé à reconstituer la logique du LOGICIEL ou à reproduire ce dernier par quelque autre moyen que ce soit. Vous n’êtes pas en droit de reproduire, modiﬁer, prêter, louer, revendre ou distribuer le LOGICIEL en tout ou partie, ou d’utiliser le LOGICIEL à des ﬁns de création dérivée. Vous n’êtes pas autorisé à transmettre le LOGICIEL à d’autres ordinateurs ou à l’utiliser en réseau.

Vous êtes en droit de céder, à titre permanent, le LOGICIEL et la documentation imprimée qui l’accompagne, sous réserve que vous n’en conserviez aucun exemplaire et que le bénéﬁciaire accepte les termes du présent contrat.

3. RESILIATION

Les conditions énoncées dans le présent contrat de licence prennent effet à compter du jour où le LOGICIEL vous est remis. Si l’une quelconque des dispositions relatives au droit d’auteur ou des clauses du contrat ne sont pas respectées, le contrat de licence sera résilié de plein droit par Yamaha, ce sans préavis. Dans ce cas, vous devrez immédiatement détruire le LOGICIEL concédé sous licence ainsi que les copies réalisées.

4. GARANTIE PRODUIT

Si, dans des conditions normales d’utilisation, le LOGICIEL ne remplit pas les fonctions décrites dans le manuel fourni, Yamaha s’engage vis-à-vis de l’acheteur original à remplacer gratuitement, sur la base d’un échange, tout support reconnu défectueux par suite d’un défaut de matière première ou d’un vice de fabrication. Ceci constitue le seul recours opposable à Yamaha. Hormis dans les cas expressément énoncés plus haut, le LOGICIEL est livré « en l’état » et toute autre garantie expresse ou implicite le concernant, y compris, de manière non limitative, toute garantie implicite de qualité marchande et d’adéquation à un usage particulier, est exclue.

5. RESPONSABILITE LIMITEE

Votre unique recours et la seule responsabilité de Yamaha sont tels qu’énoncés précédemment. En aucun cas Yamaha ne pourra être tenu responsable, par vous-même ou une autre personne, de quelques dommages que ce soit, notamment et de manière non limitative, de dommages indirects, frais, pertes de bénéﬁces, pertes de fonds ou d’autres dommages résultant de l’utilisation ou de l’impossibilité d’utiliser le LOGICIEL, même si Yamaha ou un distributeur agréé ont été prévenus de l’éventualité de tels dommages, ou de quelque autre revendication formulée par une tierce partie.

6. REMARQUE GENERALE

Le présent contrat de licence est régi par le droit japonais, à la lumière duquel il doit être interprété.

For details of products, please contact your nearest Yamaha or the authorized distributor listed below.

Pour plus de détails sur les produits, veuillez-vous adresser à Yamaha ou au distributeur le plus proche de vous ﬁgurant dans la liste suivante.

Die Einzelheiten zu Produkten sind bei Ihrer unten aufgeführten Niederlassung und bei Yamaha Vertragshändlern in den jeweiligen Bestimmungsländern erhältlich.

Para detalles sobre productos, contacte su tienda Yamaha más cercana o el distribuidor autorizado que se lista debajo.

CANADA

Yamaha Canada Music Ltd.

135 Milner Avenue, Scarborough, Ontario, M1S 3R1, Canada Tel: 416-298-1311

U.S.A.

Yamaha Corporation of America

6600 Orangethorpe Ave., Buena Park, Calif. 90620, U.S.A. Tel: 714-522-9011

MEXICO

Yamaha de Mexico S.A. De C.V., Departamento de ventas

Javier Rojo Gomez No.1149, Col. Gpe Del Moral, Deleg. Iztapalapa, 09300 Mexico, D.F. Tel: 686-00-33

BRAZIL

Yamaha Musical do Brasil LTDA.

Av. Rebouças 2636, São Paulo, Brasil Tel: 011-853-1377

ARGENTINA

Yamaha de Panamá S.A. Sucursal de Argentina

Viamonte 1145 Piso2-B 1053, Buenos Aires, Argentina Tel: 1-4371-7021

PANAMA AND OTHER LATIN AMERICAN COUNTRIES/ CARIBBEAN COUNTRIES

Yamaha de Panamá S.A.

Torre Banco General, Piso 7, Urbanización Marbella,

Calle 47 y Aquilino de la Guardia, Ciudad de Panamá, Panamá Tel: 507-269-5311

THE UNITED KINGDOM

Yamaha-Kemble Music (U.K.) Ltd.

Sherbourne Drive, Tilbrook, Milton Keynes, MK7 8BL, England Tel: 01908-366700

IRELAND

Danfay Ltd.

61D, Sallynoggin Road, Dun Laoghaire, Co. Dublin Tel: 01-2859177

GERMANY/SWITZERLAND

Yamaha Europa GmbH.

Siemensstraße 22-34, 25462 Rellingen, F.R. of Germany Tel: 04101-3030

AUSTRIA

Yamaha Music Austria

Schleiergasse 20, A-1100 Wien Austria Tel: 01-60203900

THE NETHERLANDS

Yamaha Music Nederland

Kanaalweg 18G, 3526KL, Utrecht, The Netherlands Tel: 030-2828411

BELGIUM

Yamaha Music Belgium

Keiberg Imperiastraat 8, 1930 Zaventem, Belgium Tel: 02-7258220

FRANCE

Yamaha Musique France, Division Professionnelle

BP 70-77312 Marne-la-Vallée Cedex 2, France Tel: 01-64-61-4000

ITALY

Yamaha Musica Italia S.P.A., Combo Division

Viale Italia 88, 20020 Lainate (Milano), Italy Tel: 02-935-771

SPAIN/PORTUGAL

Yamaha-Hazen Electronica Musical, S.A.

Ctra. de la Coruna km. 17, 200, 28230 Las Rozas (Madrid) Spain Tel: 91-201-0700

GREECE

Philippe Nakas S.A.

Navarinou Street 13, P.Code 10680, Athens, Greece Tel: 01-364-7111

SWEDEN

Yamaha Scandinavia AB

J. A. Wettergrens Gata 1 Box 30053 S-400 43 Göteborg, Sweden Tel: 031 89 34 00

DENMARK

YS Copenhagen Liaison Ofﬁce

Generatorvej 8B DK-2730 Herlev, Denmark Tel: 44 92 49 00

FINLAND

F-Musiikki Oy

Kluuvikatu 6, P.O. Box 260, SF-00101 Helsinki, Finland Tel: 09 618511

NORWAY

Norsk ﬁlial av Yamaha Scandinavia AB

Grini Næringspark 1 N-1345 Østerås, Norway Tel: 67 16 77 70

ICELAND

Skifan HF

Skeifan 17 P.O. Box 8120 IS-128 Reykjavik, Iceland Tel: 525 5000

OTHER EUROPEAN COUNTRIES

Yamaha Europa GmbH.

Siemensstraße 22-34, 25462 Rellingen, F.R. of Germany Tel: 04101-3030

Yamaha Corporation, Asia-Paciﬁc Music Marketing Group

Nakazawa-cho 10-1, Hamamatsu, Japan 430-8650 Tel: 053-460-2312

TURKEY/CYPRUS

Yamaha Europa GmbH.

Siemensstraße 22-34, 25462 Rellingen, F.R. of Germany Tel: 04101-3030

OTHER COUNTRIES

Yamaha Music Gulf FZE

LB21-128 Jebel Ali Freezone P.O.Box 17328, Dubai, U.A.E. Tel: 971-4-881-5868

HONG KONG

Tom Lee Music Co., Ltd.

11/F., Silvercord Tower 1, 30 Canton Road, Tsimshatsui, Kowloon, Hong Kong Tel: 2737-7688

INDONESIA

PT. Yamaha Music Indonesia (Distributor) PT. Nusantik

Gedung Yamaha Music Center, Jalan Jend. Gatot Subroto Kav. 4, Jakarta 12930, Indonesia Tel: 21-520-2577

KOREA

Yamaha Music Korea Ltd.

Tong-Yang Securities Bldg. 16F 23-8 Yoido-dong, Youngdungpo-ku, Seoul, Korea Tel: 02-3770-0661

MALAYSIA

Yamaha Music Malaysia, Sdn., Bhd.

Lot 8, Jalan Perbandaran, 47301 Kelana Jaya, Petaling Jaya, Selangor, Malaysia Tel: 3-703-0900

PHILIPPINES

Yupangco Music Corporation

339 Gil J. Puyat Avenue, P.O. Box 885 MCPO, Makati, Metro Manila, Philippines Tel: 819-7551

SINGAPORE

Yamaha Music Asia Pte., Ltd.

11 Ubi Road #06-00, Meiban Industrial Building, Singapore Tel: 65-747-4374

TAIWAN

Yamaha KHS Music Co., Ltd.

10F, 150, Tun-Hwa Northroad, Taipei, Taiwan, R.O.C. Tel: 02-2713-8999

THAILAND

Siam Music Yamaha Co., Ltd.

121/60-61 RS Tower 17th Floor, Ratchadaphisek RD., Dindaeng, Bangkok 10320, Thailand Tel: 02-641-2951

THE PEOPLE’S REPUBLIC OF CHINA AND OTHER ASIAN COUNTRIES

Yamaha Corporation, Asia-Paciﬁc Music Marketing Group

Nakazawa-cho 10-1, Hamamatsu, Japan 430-8650 Tel: 053-460-2317

AUSTRALIA

Yamaha Music Australia Pty. Ltd.

Level 1, 99 Queensbridge Street, Southbank, Victoria 3006, Australia Tel: 3-9693-5111

NEW ZEALAND

Music Houses of N.Z. Ltd.

146/148 Captain Springs Road, Te Papapa, Auckland, New Zealand Tel: 9-634-0099

COUNTRIES AND TRUST TERRITORIES IN PACIFIC OCEAN

Yamaha Corporation, Asia-Paciﬁc Music Marketing Group

Nakazawa-cho 10-1, Hamamatsu, Japan 430-8650 Tel: 053-460-2312

NORTH AMERICA

CENTRAL & SOUTH AMERICA

EUROPE

AFRICA

MIDDLE EAST

ASIA

OCEANIA

HEAD OFFICE Yamaha Corporation, Pro Audio & Digital Musical Instrument Division

Nakazawa-cho 10-1, Hamamatsu, Japan 430-8650 Tel: 053-460-2445

SY23

V938190 206POCP26.2-01A0 Printed in Japan

This document is printed on chlorine free (ECF) paper with soy ink.

Auf Umweltpapier mit Sojatinte gedruckt.

Ce document a été imprimé sur du papier non blanchi au chlore avec de l'encre d'huile de soja.

Yamaha Web Site (English only)

www.yamahasynth.com

Yamaha Manual Library

http://www2.yamaha.co.jp/manual/english/

documentation manual, user maintenance, brochure, user reference, pdf manual

This file has been downloaded from:

User Manual and User Guide for many equipments like mobile phones, photo cameras, monther board, monitors, software, tv, dvd, and othes..

Manual users, user manuals, user guide manual, owners manual, instruction manual, manual owner, manual owner's, manual guide,

manual operation, operating manual, user's manual, operating instructions, manual operators, manual operator, manual product,

Yamaha Audio PLG150-PC, PLG150-DR User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
