Yamaha SG3000, SG2000, SG1000, RGXA2, RGX220DZ Brochure

The great contributions that the electric guitar and electric bass have made to the development of Rock music are common knowl­edge. Each has been a powerful infl uence their evolution and development.
The arrival of Yamaha’s SG guitars and BB basses in the late 70’s was a turning point in Rock history. Our guitar designers at the
time completely rethought the functions and design of the guitar, taking an entirely different approach to the construction of the
SG2000. Their efforts were greeted with high acclaim from guitarists all over the world. The BB1200 with its laminated neck also
received high acclaim from professional bassists all over the world, gaining a wide following of regular players. Its fresh design
and tight, heavy tone gave bassists greater presence in the band, and its sound played an important role in the development and
spread of trends such as beat heavy disco and slap style playing.
Fast-forward to 2010, and our latest SG and BB designs focus on Rock. This is a music that is in constant change. With all of its
variants, it is nearly impossible to categorize into a single genre anymore. In these new SG guitars and BB basses we have har­nessed Rock’s energy, giving it form in the shape of their design. That energy is released at the pluck of a string and transformed,
without loss, into musical expression. This is the reason we focus so much on the instrument’s sound. Greater performance capa­bilities deliver greater expressive power, the new SG and BB deliver a new means of expression.

Reviving Roc k: Making a Bold Statement
Yamaha’s Ev olution

IRA (Initial Response Acceleration)

If you’ve ever played another guitarist’s instrument and not been able to get the same
sound, it’s probably because you are playing a different style than what the guitar is
used to. Af ter playing the same guitar for years, the guitar adapts to the guitarist’s
playing style. It takes time for a new guitar to adapt to your own way of playing. Stress
found bet ween parts like fi nish, woods, body, neck, fi ngerboard, nut, bridge, etc., must
be released before all of the par ts can resonate together as an instrument. It takes time
and a lot of playing for this to happen.
Using IR A technology, stresses like those between the fi nish and wood are release by
applying specifi c vibrations to the completed guitars. Once this treatment is complete,
the guitar responds accurately to the guitarist’s performance, and produces sound
more easily. It also shortens the time needed for the guitar to adapt to your playing
style. And it delivers excellent sustain.

Since its spectacular debut, Yamaha SG series guitars have accompa­nied many a musician on their road to success. From its rich tone and
long sustain to its superior performance and refi ned design, all of its
signature characteristics have stood the test of time, remaining relevant
to this day. Trends and special requests by musicians over the last
30+ years have resulted in numerous spec changes and the release of
special models. And while the latest SG3000/2000/1000 guitars look
the same as the original, there are many refi nements that improve upon
their perfection.

Ove r t he cour s e of the SG’s histor y, t hese th r ee new SG s, the
SG1820/1820A/1802, represent the most dynamic approach yet. Look­ing at current trends in music and the sound requirements of today’s
guitarists, we have taken three approaches to sound

SG1820: Modern rock sound. All-around instrument delivers a clear, rich
low-end tone capable of everything from clean cutting tone to distortion.
SG1820A: Designed for the next-generation guitarist. Delivers a beautiful
hard distortion and releases an intense sound from its sharp styling.
SG1802: Sound, looks, classic styling, its all there in this model. The
combination of wide single coil pickups and SG body deliver a warm,
clear tone.

The new SG also features a wide variety of refi nements including hard-
ware modifi cations. A new page in Yamaha’s SG history starts here.

SG’s that are right for
today’s music and
musicians

Introducing 3 concepts equipped
with the latest hardware

Back Contour

Eli minating the co nto ure d back found
on pr ior m ode ls in cre ase s the v olu me
of wood in th e body to deliver a woo dier
tone.

Body Contour

Th e new S G has a mor e pro no unced
arch compared to the earlier SG
mod els. Regulating th e bal anc e in the
ma pl e top’s th ic kn es s en ha nc es m id
to low-end tone and delive rs smoother
distortion.

Small Head Design

Ba l anc e h as a g r ea t er e f fec t o n
playability than weight. Using a
des ign t hat i s sma lle r and l igh ter than
conventiona l heads m ove s the c enter
of gravity close r to the body, improving
playability.

Grover Locking Tuner

Lo ck s st rin gs i n pl ace a t th e tu ne r’s
string post. Prevents pitch problems
due to tuni ng peg slippage and makes
sp ee dy s tr in g re pl ac em en t po ss ib le.
Lightweight, sleek design does not
affect instrument sound or playability.

Seymour Duncan ‘59 Pickups
(SG1820)

This v intag e humbu cker pi ckup design
de l ive r s lo ts of w ar m , dr y t o ne w i th
smooth sustain.

Seymour Duncan SP90 Pickups
(SG1802)

This single coil delivers a tone that is
milder and warmer than an ordinary
single coil pickup.

EMG85/EMG81 Pickups
(SG1820A)

High-gain, low-noise active pickups.
An E MG 8 5 on t he f ron t de li ver s ri c h
harmonics with superior attack while an
EMG81 at the re ar is designed to deliver
distortion.

SG1820/1820A/1802

Three sound and design concepts to choose from.
SG1820: New SG body with a pair of Seymour Duncan ‘59s installed. Delivers a well-balanced, all-around
tone ranging from clean to distortion. Faithfully reproduces picking nuances with warm clear tone.
SG1820A: Black hardware and parts on the monotone body create a cool look. Equipped with EMG pick­ups (EMG85 front/EMG81 rear) delivers a hard-edged sound.
SG1802: Vintage SG look with a pair of Seymour Duncan SP90s. Delivers a wide palette of tone ranging
from warm solo to bright, crisp comping.

SG1820

Vintage White

SG1820

Brown Sunburst

SG1820

Black

SG1820/1820A/1802

Model
Construction
Scale Length
Fingerboard
Radius
Frets
Body
Neck
Bridge/Tailpiece
Pickups
Tune rs
Pickup Switch
Controls
Colors

SG1820A

Set Neck

24 3/ 4" (628. 6mm)

Rosewood

13 3 /4" ( 350m m)

22

Curved Maple, Mahogany

Mahogany

Tone pros A VRII /To nepro s T1Z

Front EM G85, Rear EM G81

Grover Locking Tuner

3-Position Toggle(Switchcraft )

Front Volu me, Rear Volume, Fron t Tone, Rear Tone

Black, Silver Burst

SG1802

Set Neck

24 3/ 4" (628. 6mm)

Rosewood

13 3 /4" ( 350m m)

22

Curved Maple, Mahogany

Mahogany

Tone pros A VRII /To nepro s T1Z

Front S. Duncan SP9 0 (Cream) , Rear S.Dunc an SP90 (C ream)

Grover Locking Tuner

3-Position Toggle(Switchcraft )

Front Volu me, Rear Volume, Fron t Tone, Rear Tone

Gold Top, Black

SG1820

Set Neck

24 3/ 4" (628. 6mm)

Rosewood

13 3 /4" ( 350m m)

22

Curved Maple, Mahogany

Mahogany

Tone pros A VRII /To nepro s T1Z

Front S. Duncan ‘59 Cove red, Rear S.Dun can ‘59 Covered

Grover Locking Tuner

3-Position Toggle(Switchcraft )

Front Volu me, Rear Volume, Fron t Tone, Rear Tone

Black, B rown Sunburst , Vintage White

Controls & Output Jack

The output jack is relocated on the
bo dy s id e an d co nt rol kn ob l ayo ut i s
modified in co nsidera tion o f playabil ity
and usa bility. Control kno bs on all three
models complement guitar designs.
SG1820: Speed Knobs, SG1820A: Metal
Knobs, SG1802: Barrel Knobs

SG1820A

Black

SG1820A

Silver Burst

SG1802

Gold Top

SG1802

Black

Head Design

The SG1820A featu res an outline head
inlay t hat e vok es a n ima ge of flo wi ng
streams of light. Its i mage is shared by
the position marker inlay and monotone
body’s binding. Both the SG1820 and
1802 feature block ty pe inlays.

Position Markers

Position marker designs complement
th e in st ru men t’s l oo ks . SG 1820: SG
Arrow, SG1820A: Outlined Arrow,
SG1802: Dot.

SG1820A

SG1820/SG1802

SG3000/2000/1000

The SG1000 with its set-neck body design and specially designed powerful pick­ups delivers great rock sound and attack. The SG2000 with its thru-neck body
and sustain plate delivers rich sustain and premium tone. The SG3000 with its
thru-neck construction and select woods delivers a rich, wood infl uenced tone.
Everything is designed specifi cally for the SG, from body and neck designs, to
pickups, bridges, circuitry, even down to the strap pins. As a last touch, Yamaha’s
Initial Response Acceleration is applied for a matured resonance.

SG3000/2000/1000

SG2000

Brown Sunburst

SG2000

Red Sunburst

SG1000

SG3000/2000

Body Neck Construction

T Cross Maple (Neck Through)
Design (SG3000/2000)

Bo dy an d ne ck ar e in te gr ated in to a
single structure that lets string vibration
loop through the string, neck, and body,
reducing energy loss and delivering long
sustai n. The cros s maple design cre ates
a T shape that blends the tonal qualiti es
of maple; good for high-range sustain,
an d m aho g an y; go o d fo r l ow -r a ng e
sustain, to produce long sustain that is
well bal anced ove r a wide tonal range.

Bi-Sound System

A qu i ck pu ll of t he to ne c o ntr ol k n o b
switche s betwee n Humbuc ker and single
coil tone.

Pickup and Escutcheon
(SG3000)

Utilizing a full cover type pickup c over
delivers a milder tone by minimizing
high frequencies. Compared to plastic,
the brass escutcheon promotes a
more effi cient fl ow of body vibrations
to the p ick up ge nerati ng su bstanti al
sustain.

Shell Binding

(SG3000)

This precision The SG’s smooth
bodylines are beautifully accented
with Mexican Abalone binding.

SG3000

Wine Red

SG3000

Gold

Model
Construction
Scale Length
Fingerboard
Radius
Frets
Body

Neck
Bridge
Pickups
Pickup Switch
Controls

Colors

SG2000

Neck Through

24 3/ 4" (628. 6mm)

Ebony

13 3 /4" ( 350m m)

22

Carved Maple, Mahogany

Maple + Ma hogany

Maple + Ma hogany 3piece ( Neck Throu gh)

T-O -M Bri dge

Yamaha Alni co V Humbucker X 2

3-Position Toggle

Front Volu me, Rear Volume, Fron t Tone

Rear Tone wit h Push-Pull Swi tch

Brown Su nburst, Red Sunb urst, Black

SG1000

Set Neck

24 3/ 4" (628. 6mm)

Ebony

13 3 /4" ( 350m m)

22

Carved Maple, Mahogany

Mahogany

Maple + Ma hogany 3piece

T-O -M Bri dge

Yamaha Alni co V Humbucker X 2

3-Position Toggle

Front Volu me, Rear Volume, Fron t Tone

Rear Tone wit h Push-Pull Swi tch

Brown Su nburst, Red Sunb urst, Black

SG1000

Red Sunburst

SG1000

Brown Sunburst

SG1000

Black

Semi Open Humbucking
Pickup

(SG2000/1000)

This original pickup was developed
with an Alnico V alloy magnet for use
on t he S G. I t pr od uc es a f at s ou nd
that i s sweet and r ich. O the r ori ginal
Yamaha d esig ns utilized h ere are the
semi- open co ver, which co ntrib ute s
both to noise prevention and power
output, a nd tripl e support escu tcheon,
which adjusts pickup height and angle.

SG3000

Neck Through

24 3/ 4" (628. 6mm)

Ebony

13 3 /4" ( 350m m)

22

Carved Maple, Mahogany

Maple + Ma hogany

Maple + Ma hogany 3piece ( Neck Throu gh)

T-O -M Bri dge

Yamaha Alni co V Covered Humbu cker X 2

3-Position Toggle

Front Volu me, Rear Volume, Fron t Tone

Rear Tone wit h Push-Pull Swi tch

Black Me tallic, Gold, Win e Red

Over Binding Frets

This precision design extends the
fr e t al l t he w a y to t he ed g e of t h e
fi n gerb oard, e ndin g at a point above
the binding. It prevents string drops
when bending or vibrating the strings,
and offers dyna mic per forman ce.

12 3 4

56 7 8

A. I. R. (Alternative Internal Resonance) Design

Using Yamaha’s original Alternative Internal Resonance technology the RGXA2 and RBX4A2 offer players
excellent lightweight characteristics without sacrifi cing sound quality.



The body consists of a lightweight core sandwiched between hard woods on top and back. (1)



Three metal tubes (sound tubes) installed under the bridge plate transmit string vibration to the
body, and return body vibration to the bridge. (2)

(The story behind the development of the RGXA2 and RBX4A2)

Design of the RGXA2 centered on developing a lightweight instrument that would bring the guitar
and player closer together. The focus was on providing the player with greater freedom, much like
an air guitar, breaking down the boundaries between what is in the player’s head and what comes
out of the amp.

In creating a lighter guitar, one absolute condition set down was that sound quality could not
be sacrifi ced. For this reason, a great deal of time and effort went into the creation of numerous
prototypes. The A2 project had to combine three crucial factors—great sound, light weight, and
suffi cient strength to withstand the huge forces generated by strings under tension. Intensive
research and development led to the creation of A.I.R. (Alternative
Internal Resonance) technology. Although it uses a solid body de­sign, the incredible resonance created by the unique construction
method produces a big, open sound that resonates throughout
the guitar’s entire body. To match and compliment this instru­ment’s unique characteristics, original bridge and pickup systems
were developed—the resulting tone and response shattering the
widely accepted concept that “lightweight means light sound”.
The RGXA2 brings a revolutionary approach to guitar design.

The quest for the perfect design naturally took the route of trying to build the lightest possible
guitar, but early prototypes, while incredibly light, didn’t deliver the sound or playing experience
that was essential. The fi nal weight for the RGXA2 was set at around 2.5kg, a perfect balance—
around 30% lighter than a regular solid body guitar but with all the feel and sound that players
were looking for. This is lightweight design taken to the extreme.

The Guitar and the Player... Becoming One

Original Pickups

Developed with the custom shop at
Yamaha Artist Services, Hollywood, the
A2 pick ups p er fec tly c omp lim ent the
tonal characteristics of the A.I.R. body.
Designed with the input of some of the
world’s greatest guitar players, the A2’s
power ful tone belies its light wei ght.

Original Bridge

In rethinking bridge design, Yamaha
has succeeded at creating a c ompac t,
lightweight bridge that delivers
outstanding function. Removing
protrud ing screw s leaves a simple design
that delivers extended performance
when pl aying close to the bridge. Spe cial
sound tubes i nstalled un der the bridge
pa s s th r ou g h th e b ody t ran s mi t ti n g
string v ibration directly to the bod y.

LED Pickup Indicator

Th e s in gle v ol ume c ont ro l an d a 3
position rotary pickup selector are
joined by LEDs surrounding the
volume control, providing bright visual
indication of the pickup in use.

RGXA2 Neck

Fi n ger b oa r d wi d th i s t he sa m e as
gu i ta r s i n th e R GX s e rie s , li ke th e
RG X 2 20 DZ , b ut w i th a m e diu m
thickness. This design makes chords
easier to hold and offers greater stability
for the l ef t ha nd. Gre ater ne ck m as s
also contribute s to a richer sound.

RGXA2

Weighing in at 2.5 kg, the RGXA2 is in the super lightweight class.
Yamaha’s revolutionar y A.I.R. technology delivers a guitar so light that it fuses
seamlessly with the player, delivering unprecedented comfort, amazing tone, and
superior performance.
The RGXA2, the guitar that lets you play the way you want to play.

* Actual we ight may vary sl ightly si nce the RGX A2 is made of woo d material.

RGXA2

White & Aircraft Gray

RGXA2

Jet Black

RGXA2 RGX220DZ/121Z/121ZL

* Left-h anded

RGX121Z/121ZL*

Bolt-on

25 1/2" (647.7mm)

Rosewood

13 3 /4" ( 350m m)

22

Alder, Agat his or Nato

Maple

Diecast

Vintag e Style Tremolo

Humbuck er x 2, Single X 1

5-position Lever

Master Volume, Master Tone

Black*, Fl at Silver*, Red Met allic

*Lef t-handed model a vailable.

Model
Construction
Scale Length
Fingerboard
Radius
Frets
Body
Neck
Tune rs
Bridge
Pickups
Pickup Switch
Controls
Colors

RGX220DZ

Bolt-on

25 1/2" (647.7mm)

Rosewood

13 3 /4" ( 350m m)

24

Alder

Maple

Diecast

Double L ocking Tremolo

Humbuck er X 2

3-position Lever

Master Volume, Master Tone

Metalli c Black, Red Met allic, Metallic B lue,

Dark Metallic Gr ay

RGXA2

Bolt-on

25 1/2" (647.7mm)

Rosewood

13 3 /4" ( 350m m)

22

A.I.R. Body

Maple

Diecast with Cylindrical knob

A.I. R. Mounting Sy stem Bridge

Alnico V hu mbucker X 2

3-position Rotary with Pickup Indicator

Master Volume

White & A ircraft Gray, Jet B lack

RGX121Z

Flat Silver

RGX220DZ

Red Metallic

RGX220DZ

Dark Metallic Gray

Ceramic Open Humbucker
Pickups (RGX220DZ)

Ce ra mi c ma gn ets a re u se d fo r th ei r
wider range and p ower. These pickups
produc e a clearer distor tion tone.

Thin Neck (RGX220DZ)

Thin and wide neck is fast and easy to
play m aking the m a great choi ce for
technical players.

Double Locking System
(RGX220DZ)

Double lockin g system used on the nut
and tre molo u nit de liver tuning that is
stable even under heavy tremolo use.

q

w

e

Controls
(RGX220DZ/121Z/121ZL)

q

3P Pickup Sel ector (RG X220DZ)

5P Pickup Selector (RGX121Z)

w

Master Volume

e

Master Tone

Model
Construction
Scale Length
Fingerboard
Radius
Frets
Body
Neck
Bridge

SA503TVL

Set Neck

24 3/4 " (628.7mm )

Rosewood

13 3 /4" ( 350m m)

22

Maple (Laminated)

Nato

Chrome Bigsby Tremolo

Pickups (SA503TVL)

The sem i-holl ow body is matched with
th ree single coil uni ts t ha t pr od uc e
a br i ght a n d cl e ar to ne w i th we ll
balanced low-end.

Two pickup swi tches prov ide access
to seven pickup combinations. (All
Access System)

Controls (SA503TVL)

q

Front Volume

w

Master Tone

Troy Van Leeuwen has navigated his way through a variety
of musical genres and has left his indelible mark in each
of them. From session work with Depeche Mode, Korn,
and Limp Bizkit to his role in A Perfect Circle, Troy has
mastered it all. Most recently, Troy joined the fantastically
bizarre Queens of the Stone Age to embark on his latest
ethereal musical journey. His guitar of choice? Troy's own
Yamaha signature model SA503 TVL.

SA503TVL

Black

SA503TVL

Troy Van Leeuwen Signature Model

q

w

e

r

e

Center Volume

r

Rear Volume

Model
Construction
Scale Length
Fingerboard
Radius
Frets
Body
Neck
Bridge
Pickups

Pickup Switch
Controls

Colors

AEX1500

Set Neck

25 1/4" (640mm)

Ebony / 20 f rets

13 3 /4" ( 350m m)

Laminat ed Satin Sycamo re

Maple

Bone + Eb ony

Yamaha Mini Humbucker

Yamaha Piezo P ickup on Bridge

3-Position Toggle

Master Vo lume, Magnetic Pic kup Tone,

3-Ba nd EQ for Piezo Picku p

Natura l, Antique Sunbur st, Faded Burs t

SA2200

Set Neck

24 3/4 " (628.7mm )

Ebony

13 3 /4" ( 350m m)

22

Laminat ed Figured Maple

Premium Gr ade Mahogany

T-O -M Bri dge

Alnico V H umbucker X 2

3-Position Toggle

Front Volu me, Rear Volume, Fron t Tone

Rear Tone wit h Push-Pull Swi tch

Violin Su nburst, Brown S unburst

Bridge Mounted Piezo Pickup

A piezo pickup mounted undern eath
the bridge saddle delivers acoustic
tone. The bridge i s height a djustable.

Mixing Magnetic & Piezo Tone

Master volume, magnetic pickup
tone control, and a 3-position
pic kup sel ect or ar e mou nte d on th e
guita r’s to p. On t he b ody’s si de are
a picku p balancer for the two pick up
syste ms, and a 3-ban d equalize r (for
the p iezo p ickup) w ith a n adjustabl e
midrange frequency control. This is an
instru ment ric h in tonal variation.

Full Acoustic Body

Top, back, and side s of the acousti c
body are crafted f rom Laminated Satin
Sycamore.

Bridge (SA2200)

Precision design offers accurate
height, tension, and octave pitch
adjustment.

Controls (AEX1500)

q

Master Volume

w

Magnetic Pickup Tone

Controls (SA2200)

q

Front Volume

w

Rear Volume

e

Front Tone (Bi-Sound Switch)

r

Rear Tone (Bi -Sound Switch)

Alnico V Humbucker “MH­AEX1” (AEX1500)

Attaching this mini humbucker to
the neck rather than the body allows
the bod y to resonate freel y while the
pickup only captures string vibration.

Pickups (SA2200)

Humbucker type with Alnico V
magnets. Three point supp ort system
provides fine height adjustment
between picku p and strings.

SA2200

Violin Sunburst

AEX1500

Antique Sunburst

SA2200/AEX1500

q

w

e

r

q

w

q

w

e

CV820WB

Wes Borland Signature Model

About Wes Borland’s String
Gauges

Wes’ signature sound is partly
at tr ibu te d to t he u se o f th e uni qu e
set of string gauges he uses on his
signature guitar.

String Tuning Gauge
1st C# .011
2nd G# .014
3rd E .022 (Wound)
4th B .032 (Wound)
5th F# .042 (Wound)
6th C# .052 (Woun d)

* The gui tar is stru ng with .010–.046 g auge
string s when shi pped fro m the factor y.

Model
Construction
Scale Length
Fingerboard
Radius

CV820WB

Set Neck

25 1/2" (647.7mm)

Rosewood

13 3 /4" ( 350m m)

Custom 33 Pickup

Designed

by YASH and Wes

The Custom 33 pickups were developed
by YASH (Yamaha Artist Service
Hollywood) in collaboration with Wes
Borland. 1st through 3rd and 4th throu gh
6t h s tr i ng po l e pi e ces a r e gr o up e d
separately in a design that emphasizes
high-end sharpnes s to produc e a clear
tone from the hollow body.

Finger Clamp Tremolo System

A lo c kin g tre mol o a nd n u t sy s te m
offer s stable tuning eve n under he avy
tremolo use. And no to ols are required
when it c omes tim e to change strings.

Original Semi Hollow Design

Desig ned by Wes Borland an d YASH,
the maple top is car ved to produce its
uniquely curved shape.

Wes Borland is well known on stage for his elaborate face paint and
black-tinted contacts as guitarist for Limp Bizkit. He has also kept him­self busy fronting his own band Black Light Burns and as a member of
such bands as Big Dumb Face, Eat the Day, and Goatslayer.

CV820WB

Black

q

Two Bridge Types

Two b r idg e t ype s a re a vai l ab l e. T h e
AES1500 is equipped with a Tune-O­Matic br idge while the AES1500B c omes
with a Bigsby B6 Vintage Vib rato.

Controls (AES1500/1500B)

q

Front Volume

w

Rear Volume

e

Front Tone (Push-Pull Switch)

r

Rear Tone (Push-Pull Switch)

Sound Character

Two DiMarzi o Q-100s produce a sound
tha t li es be tw een a sin gl e coi l an d a
humbucker. Push push tone controllers
split pickup coils allowing this guitar to
cover a wide selection of sounds from
Jazz to B lues to Rockabil ly.

Semi Hollowbody

What looks like a full acoustic guitar is
actu all y a semi-hollow d esign wit h a
center blo ck located unde rneath the
bridge to prevent feedback.

AES1500

Pearl Snow White

AES1500B

Orange Stain

AES1500B

Set Neck

25 1/2" (647.7mm)

Rosewood

13 3 /4" ( 350m m)

22

Arched S ycamore Top, Maple B ack/Sid es

Maple

Bigsby B 6 Vintage Vibr ato

DiMar zio Q-100 X 2

3-Position Toggle

Front/Rear Volume, Front/Rear Tone

with Pus h-Pull Switch

Black, Orange Stain

AES1500

Set Neck

25 1/2" (647.7mm)

Rosewood

13 3 /4" ( 350m m)

22

Arched S ycamore Top, Maple B ack/Sid es

Maple

T-O -M Bri dge

DiMar zio Q-100 X 2

3-Position Toggle

Front/Rear Volume, Front/Rear Tone

with Pus h-Pull Switch

Orange S tain, Pearl Sno w White

Model
Construction
Scale Length
Fingerboard
Radius
Frets
Body
Neck
Bridge
Pickups
Pickup Switch
Controls

Colors

AES1500/1500B

qw

e

r

From his days with the Brecker Brothers and Miles Davis to
his string of successful solo albums and tours, Mike Stern's
credentials are indisputable. Throughout his career as one
of the reigning kings of modern jazz guitar, Mike has relied
on single-cutaway guitars. His devotion to that instrument is
refl ected in the Mike Stern signature model, the PAC1511MS.

PAC1511MS

Mike Stern Signature Model

7 1/4-inch Radius Neck

Mik e Ste rn pl ays s moothl y and wit h
confi dence on this maple neck wi th a
7 1/4 inch radius.

Controls (PAC1511MS)

q

3P Picku p Selector

w

Master Volume

e

Master Tone

q

w

e

Model
Construction
Scale Length
Fingerboard
Radius

PAC1511MS

Bolt-on

25 1/2" (647.7mm)

Maple 1-Piece

7 1/4" (184mm )

PAC1511MS

Natural

Alnico V Pickups

Alnic o V mag net s are u sed for both
single co il an d humb ucker to delive r
a cl e ar s t ru m mi n g to ne w i th g o od
pr o je c ti o n p lu s a t ig h t so u nd t h at
doesn’t get burie d in the ensemble.

Coil Tap Function

A co i l tap f u nc t io n o n th e r ear
humbu cker de liver s a wide ra nge of
tonal possibilities, from hard distortion
to an edgy single coil tone. A switch in
the tone k nob allows quick switching
bet ween hu mbu cke r an d sin gle coi l
ton e. Se tt ing t he p ick up s elect or to
the 4th position automaticall y selects
th e co il t ap f un ction tha t de li ve rs a
clear h alftone from the p air of singles.

Ring Mount Rear Pickup

Like the top-end PACIFICA m odels, the
rear pickup is mounted directly to the
body. This confi guration captures body
resonance, delivering greater dynamic
tone rather than pickguard mounting.

Block Saddle Vintage Type
Tre mol o

The blo ck saddl e type vintage tre molo
offe rs excel lent op eration. The heavy
block type saddle delivers rich sustain
and dee p tone.

w

q

PAC212VFM/212VQM

Tobacco Brown

Sunburst

Caramel Brown

Caramel Brown

Translucent Black

PAC212VFM

Tobacco Brown Sunburst

PAC212VQM

Translucent Black

Model
Construction
Scale Length
Fingerboard
Radius

PAC212VF M/212VQM

Bolt-on

25 1/2" (647.7mm)

Rosewood

13 3 /4" ( 350m m)

Black

Black

PAC112VCX

Vintage White

PAC112V/112VCX /PAC112VM/112VMX

Yellow Natural Satin

Old Violin Sunburst Raspberry Red

Silver

PAC112V

Sonic Blue

PAC112J/112JL/012

Model
Construction
Scale Length
Fingerboard
Radius
Frests
Body
Neck
Tune rs
Bridge
Pickups
Pickup Switch
Controls
Colors

PAC012

Bolt-on

25 1/2" (647.7mm)

Rosewood

13 3 /4" ( 350m m)

22

Alder, Agat his or Nato

Maple

Covered

Vintag e Style Tremolo

Single X 2, H umbucker X 1

5-Position Lever

Master Volume, Master Tone

Black, R ed Metallic, Dar k Blue Metallic, W hite

PAC112J/ 112JL

Bolt-on

25 1/2" (647.7mm)

Rosewood

13 3 /4" ( 350m m)

22

Alder

Maple

Diecast

Vintag e Style Tremolo

Single X 2, H umbucker X 1

5-Position Lever

Master Volume, Master Tone

112J Colors : Old Violin Sunbur st, Lake Placid B lue,

Red Met allic, Yellow Natura l Satin, Black

112JL Color s: Black, Yellow Na tural Satin

Red Metallic

Yellow Natural Satin Lake Placid Blue

PAC012

Dark Blue Metallic

PAC112J

Old Violin Sunburst

Black

PAC112VMX

Yellow Natural Satin

PAC112V/112V CX/112V M/112VM X

Bolt-on

25 1/2" (647.7mm)

Rosewood, Maple

13 3 /4" ( 350m m)

22

Alder

Maple

Diecast

Vintag e Tremolo wit h Block Saddle

Alnico V S inglex2, Alnic o V Humbucker x1

5-position Lever

Master v olume, Master ton e with Push-Pull C oil Tap SW

112V Colors : Black, Old Violi n Sunburst, Ras pberry Red, S onic Blue, Silver, Yellow N atural Satin

112VCX Color s: Vintage Whi te, Black

112VM Color s: Black, Tobacco B rown Sunburst , Red Metallic 112VM X Colors: Yellow N atural Satin

Red Metallic

PAC112VM

Tobacco Brown Sunburst

Design of the RGXA2 focused on creating a lightweight
instrument that would bring the guitar and player closer to­gether. The response we received from its release was great.
The resulting sound shattered the widely accepted concept
that “light guitars only produce light sound”, and brought new
users to the instrument thanks to its light weight. Moreover, it
received great acclaim from discerning professional guitarists
and music dealers.
In addition to the great attention the RGXA2 received, re­quests increased daily for a bass version of this amazing
instrument. So we quickly set about developing a bass guitar
with an A.I.R structure, and produced three models; a regular
scale, medium scale, and 5-string.
The RBXA2 weighs about 20% less than its standard bass
counterpart. Matched with an original pickup system devel­oped in cooperation with Yamaha Artist Services Hollywood,
it delivers a heavy sound that is both clear and powerful.

A.I.R. (Alternative Internal Resonance)

Our A.I.R. d evelopment team took the design used on the RGXA2 and adapted
it for use w ith a bass g uitar. The instrument’s structu re consists of light weight
core mate rial sandwiched in between soli d materia ls. Strin gs passing through
the backside of the body transmit ene rgy throu ghout the entire bo dy delivering
outsta nding resonanc e and excellent response.

Original Pickups

An original pickup was developed
to match the R BXA2’s bo dy de sig n.
It produces a well-shaped attack
and c lea r ton e with presence. Tonal
character is smooth from the low
ra n ge th ro u gh to t he h i gh, a nd it
delivers some truly great distor tion.

LEDs Illuminated Volume
Controls

The 3-c ontrol system i ncl ud es fr ont
volume, rear volume, and master tone

Original Bridge

To provide the utmost in function ality,
the compact bridge is designed
withou t any protruding parts such as
sc rew s, etc. Soun d tu be s pa ssing
th r ou g h th e b ody u n de r n ea t h th e
bridge directly transmit string energy
to the body.

w

q

RBX4A2

This regular scale model weighs just 3.2 kg and offers superior balance in addition
to its ultra light weight. Fusing seamlessly with the player it offers unprecedented
playing comfort that stuns bassists who regularly play a standard bass. Light
weight, superior comfort, and easy playing action let you concentrate on your play­ing for extended periods of time. Physically it is light in weight, sonically it is anything
but. A.I.R. technology and newly developed pickups deliver a thick, robust tone that
is clear, powerful, and blends well with a wide range of musical styles.

RBX4A2/4A2M/5A2

RBX4A2

White & Aircraft Gray

RBX4A2

Jet Black

RBX5A2

Jet Black

The RBX5A 2 is a 5-str ing version of the RBX4A2.
This bass delivers clear, powerfu l, and ric h tone
all the way d own to its low open B. Its wide
sound ra nge and outstanding playa bility defy the
common concepts of previo us 5-string designs,
and open the door to a whole new range of playing
possibilities.

RBX4A2M

White & Aircraft Gray

The med ium scale version of the RBX4A2 has an

825.5mm sca le length that is 38.1mm shorte r than the
RBX4A2. Its compact bo dy and ne ck offer excellent
playabi lity, while it's A.I.R. stru cture del ivers light weight
and superior comfort. Tone production is inherently
A2—thick, cle ar, and punchy. The RBX4A2M is hi ghly
recommended for those wi th small er physiques or for
players pursuing technical playing styles or physically
active performance.

* Compat ible with r egular s cale stri ngs.

Model
Construction
Scale Length
Fingerboard
Radius
Frets
Body
Neck
Bridge
Pickups
Controls

Colors

RBX4A2

Bolt-on

34" (863.6mm)

Rosewood

10" ( 250mm )

24

A.I.R. Body

Maple

A.I. R. Mounting Sy stem Bridge

Cerami c Bar Single X 2

Front Volu me (with LED ),

Rear Volum e (with LED ), Master Tone

White & A ircraft Gray, Jet B lack

RBX4A2M

Bolt-on

32 1/2" (825.5mm)

Rosewood

10" ( 250mm )

23

A.I.R. Body

Maple

A.I. R. Mounting Sy stem Bridge

Cerami c Bar Single X 2

Front Volu me (with LED ),

Rear Volum e (with LED ), Master Tone

White & A ircraft Gray, Jet B lack

RBX5A2

Bolt-on

34" (863.6mm)

Rosewood

23 5/8" (600mm)

24

A.I.R. Body

Maple

A.I. R. Mounting Sy stem Bridge

Cerami c Bar Single X 2

Front Volu me (with LED ),

Rear Volum e (with LED ), Master Tone

White & A ircraft Gray, Jet B lack

RBX Bridge

Th e heavy d ie ca st br id ge tran sm its
string vibration directly to the body.
With its h ook design, chan ging strings
is simply a matter of hookin g the ball
end of the string into the hook, making
the whole operation quic k and easy.

Double Coil Pickups

The Humbucker pi ckups feature larg e
diameter pole pieces that produce
thick, low-end tone. Pickup covers
fe at ure buil t-i n fi ng er rests tha t ar e
simply great.

RBX Body

The d eep ly co ntou red b ody lin es are
there to provide bassists with a better
fit ting instrume nt for g reater com for t
and playabilit y.

RBX Electronics

The 4-control circuit inc ludes controls
fo r Ma ster Vo lu me , Ba la nc e, a nd a
2-band equalizer for crea ting a mo re
aggressive tone.

Controls (RBX374/375)

q

Pickup Balancer

w

Master Volume

e

Bass

r

Tre bl e

q

w

e

r

Model
Construction
Scale Length
Fingerboard
Radius
Frets
Body
Neck
Tune rs
Bridge
Pickups
Pickup Switch
Controls
Colors

RBX375/RBX374

Bolt-on

34" (863.6mm)

Rosewood

23 5/ 8" (600 mm)/10" (2 50mm)

24

Alder

Maple

Diecast

Diecast

Humbuck er X 2

N/A

Master Vo lume, Pickup Bala ncer 2-Band EQ

Black, F lat Silver, Red Meta llic

Dark Or iental Green, Mu stard Pearl Ef fect

RBX270J

Bolt-on

34" (863.6mm)

Rosewood

10" ( 250mm )

24

Alder

Maple

Diecast

Vintage Style

Split Co il X 1, Single C oil X 1

N/A

Front Volu me, Rear Volume, Mas ter Tone

Black, Mist Green, Mist Purple, Mist Raspberry,

Red Met allic, Yellow Natura l Satin, Silver, Flat B lue

RBX170

Bolt-on

34" (863.6mm)

Rosewood

10" ( 250mm )

24

Alder, Agat his or Nato

Maple

Covered

Vintage Style

Split Co il X 1, Single C oil X 1

N/A

Front Volu me, Rear Volume, Mas ter Tone

Silver, Blac k, Red Metallic, D ark Blue Metall ic

Old Viol in Sunburst, Lig ht Amber Burst

RBX374/375/270J/170

RBX374

Flat Silver

RBX375

Red Metallic

RBX270J

Black

RBX170

Silver

BBNE2 Pickups

The stack type pickups a re desig ned
in collaborati on with Nathan East. T he
Alnic o V Humbucker picku ps include a
hum-canceling coil.

Individual Bridge Pieces

The bridge consists of individual
bridge pieces that reduce interference
from other string vibration delivering a
purer tone.

Contoured Body

5-Piece Neck Through
Design

The neck through design uses a
5-p ie ce mapl e and mah ogany n eck
sa ndwic he d be tween t he m ap le on
alder body.

Active Electronics

Act iv e elect ro nic s in cl ude a spe ci al
eq u al i ze r cir cu i t ba sed o n Nat ha n
Ea st’s “ Ma gi c Box ”. The cir cu it lets
you cut of f the selected mid f requency
at the touc h of a switch for precision
sound tailoring.

Controls (BBNE2)

q

Pickup Balancer

w

Master Volume

e

Bass

r

Middle

t

Tre bl e

y

Mid Cut Fre quency

u

Mid Cut On-Off Switch

q

w

e

r

t

y

u

Model
Construction
Scale Length
Fingerboard
Radius
Frets
Body

BBNE2

Neck Through

34" (863.6mm)

Ebony

19 11/16 " (50 0mm)

24

Maple/Alder

BBNE2

White

Nathan East has appeared on countless albums and
has toured with some of the biggest names in modern
music. Whether he’s playing blues with Eric Clapton,
pop with Phil Collins, or contemporary jazz with Four­play, Nathan relies on his BBNE2 signature 5-string
bass to deliver the tone he needs.

Nathan East Signature Model

BBNE2

BB2024

Black

BB2024

Natural

BB2024X

Vintage Sunburst

BB2024X

Vintage White

New Pickups
(BB2000/1000 Series)

Des igned spe cif ically fo r the BB s eri es,
th e se n e w pic k up s a re t h e re s ult o f
numerous trials, inspections, and
artist evaluations conducted by BB
developme nt team, in the pu rsui t of the
ultimate passive pickup sound. Open­face d des igns a llow c loser mou ntin g to
the string to capture more string vibration.
Bl ade ty pe bobb in s on b oth fro nt a nd
rear handle aggressive rock picking.
Alnic o V magne ts we re ch osen fo r the
fr o nt p i cku p s to d e li v er w a rm t h an d
ceramic magnets on the rear for punch.

BB2024/2024X/2025/2025X

Diagonal Body Thru Stringing
(BB 2000/1000/400 Series)

Together with the uniquely designed
sad dle, bod y thru stringing ef fi cientl y
transfers string vibration to the body. A
Yamaha original design used on all BB
series basses places strings at a 45º
an gle at th e sa ddle re du ci ng s tre ss ,
securing tension, and maximizing
vib rat ion t ran sfe r. The 45 º cut o n the
back end of the body makes stringing
easie r and give s the BB a unique look.

With bolt on necks and passive circuit designs Yamaha’s new BB2000 series basses, the
BB2024/2024X/2025/2025X, are the ultimate in Rock bass. Everything having to do with their design—from
the selection of neck and body materials, construction, and special treatments, to the through body stringing,
neck joint, pickups, bridge, nut, hardware, and I.R.A. treatment—is focused on making the body resonant.
Specially designed pickups are utilized to convert its high quality tone into a powerfully rich sound with excel­lent attack and sustain. The end result is a new BB bass that takes fi rm command of low-end duties with
immense volume and overwhelming presence, standing out in even the loudest of rock bands.
Two versions of the new BB are available. The BB2024/2025 with traditional BB looks, and the
BB2024X/2025X trimmed with pickguard, metal plate, and metal knobs. Both versions are available in 4- or
5-string confi gurations.

BB2025

Natural

BB2025

Vintage Sunburst

BB2025X

Vintage White

BB2025X

Black

Model
Construction
Scale Length
Fingerboard
Radius
Frets
Body
Neck
Bridge
Pickups
Pickup Switch
Controls
Colors

BB2024/2024X

Bolt-on

34" ( 863.6mm)

Rosewood

10" (25 0mm)

21

Alder 3 P with A.R.E . (Spline Join t)

Maple/ Mahogany 5pcs

Vintag e Plus(B rass saddle, Ste el plate)

Front Sp lit Bar (Alnic o V) Rear Singl e Bar(Cer amic)

3-Position Toggle

Master Volume, Master Tone

2024 Col ors: Black, N atural, Vintag e Sunburst

2024X Co lors: Black , Vintage White, V intage Sunburs t

BB2025/2025X

Bolt-on

34" ( 863.6mm)

Rosewood

23 5/8” (600mm)

21

Alder 3 P with A.R.E . (Spline Join t)

Maple/ Mahogany 5pcs

Vintag e Plus(B rass saddle, Ste el plate)

Front Sp lit Bar (Alnic o V) Rear Singl e Bar(Cer amic)

3-Position Toggle

Master Volume, Master Tone

2025 C olors: Black , Natural, Vint age Sunburst

2025 X Colors: Blac k, Vintage Whi te, Vintage Sunbu rst

Nickel Silver Nut
(BB2000/1000 Series)

Nickel silver as opposed to bone or
plastic, deliver s an open str ing sound that
is closer to that of a fretted note since the
fret and n ut materi als are the same.

A.R.E. Treatment and I.R.A.
Technology (BB2000 Series)

Yamaha’s exclusive A.R.E. treatment
is a s pe ci al se as on in g proce ss t ha t
delivers a smooth, mature sound right
ou t of t he fa ct or y. I .R .A . t re at me n t,
another Yamaha exclusive, is also
applied to enhan ce body re sonanc e.

Spline Joint (3-Piece Bodies)
(BB2000/1000 Series)

Three-piece bodi es are fi tted together
using spline joints to increase surface
contac t betwee n slabs th us increasing
body resonance. Mounting the bridge
on the center piec e moves even more
string v ibration to the body.

Hard Case (BB2000 Series)

q

w

Spline

BB1024/1024X/1025/1025X/424/425

Model
Diagonal Body thru Stringing
Nickel Silver Nut
Spline Joint
A.R.E.
IRA

BB2024/X /2025/ X

●

●

●

●

●

BB1024/X/ 1025/X

●

●

●

—
—

BB424/425

●

—
—
—
—

BB1024

Vintage White

BB1025

Tobacco Brown Sunburst

BB1024X

Caramel Brown

BB1025X

Black

BB1024/1024X: Nearly identical in specs with the BB2000 series basses with
its spline joint body and 5-piece neck, diagonal body thru stringing, newly de­signed pickups and bridge. Highly recommended for players who are particu­lar about their sound.
BB1025/1025X: 5-string version of the BB1024/1024X. Low “B” 5th string
delivers heavy low-end presence and immense sound.
BB424: Sound, design and presence derived from the BB2000 series basses.
Highly recommended for entry-level players.
BB425: 5-string version of the BB424. Sound, playability, and durability all of
excellent quality.

Model
Construction
Scale Length
Fingerboard
Radius
Frets
Body
Neck
Bridge
Pickups
Pickup Switch
Controls
Colors

BB1024/1024X

Bolt-on

34" ( 863.6mm)

Rosewood

10" (25 0mm)

21

Alder 3 P (Spline Join t)

Maple/ Nato 5pcs

Vintag e Plus(B rass saddle, Ste el plate)

Front Sp lit Bar (Alnic o V) Rear Singl e Bar(Cer amic)

3-Position Toggle

Master Volume, Master Tone

1024 Color s: Black, Vint age White, Caram el Brown, Tobacco Br own Sunburst

1024X Colo rs: Black, Vin tage White, Car amel Brown, Tobacco B rown Sunburst

BB1025/1025X

Bolt-on

34" ( 863.6mm)

Rosewood

23 5/8” (600mm)

21

Alder 3 P (Spline Join t)

Maple/ Nato 5pcs

Vintag e Plus(B rass saddle, Ste el plate)

Front Sp lit Bar (Alnic o V) Rear Singl e Bar(Cer amic)

3-Position Toggle

Master Volume, Master Tone

1025 Colo rs: Black, Vi ntage White, Car amel Brown, Tobacco B rown Sunburst

1025X Co lors: Black, V intage White, C aramel Brown, Tobac co Brown Sunbur st

BB424

Bolt-on

34" ( 863.6mm)

Rosewood

10” ( 250mm )

21

Alder

Maple/ Nato 5pcs

Vintage Style

Split Sin gle x 1, Bar Single

3-Position Toggle

Master Volume, Master Tone

Red Metallic,

Tobacco Brown Sunburst,

Vintag e White, Black

BB425

Bolt-on

34" ( 863.6mm)

Rosewood

23 5/8” (600mm)

21

Alder

Maple/ Nato 5pcs

Vintage Style

Split Sin gle x 1, Bar Single

3-Position Toggle

Master Volume, Master Tone

Red Metallic,

Tobacco Brown Sunburst,

Vintag e White, Black

BB424

Vintage White

BB425

Black

BB425

Tobacco Brown Sunburst

BB424

Red Metallic

BB714BS

Black

BB714BS

Lava Red

Controls (BB714BS)

q

Woofer Pic kup Volume

w

Main

Pickup Volume

e

Master Tone Wi th Push-Pull Switch

Billy Sheehan is no stranger to the spotlight. From his days with
Talas to headlining arenas with David Lee Roth and his band Mr.
Big he has thrilled audiences the world over with his bold perfor­mances and highly evolved techniques. Constantly pushing his
skills to new limits, he has changed the way the bass guitar is
played and taking rock bass playing to new heights.
Billy’s relationship with Yamaha is long. His close collabora­tions with Yamaha Guitar Development has produce a number
of signature models, the latest being the new BB714BS. The
BB714BS represents a trip back to Billy’s roots with Yamaha, re­visiting his fi rst Yamaha signature, which was a BB series bass.

Woofer pickup designed in
collaboration with YASH*

In a d di tio n to t he sp lit p ick up , th e
BB714BS carries a special ly designed
do ub l e hu mb uck er i ns tal le d at t he
neck position where it generates great
low -end tone. T he front hum bucke r
is wired through a push-pu ll high-cut
circ uit th at lets you cho ose between
a tra ditio nal “Attu tud e” neck p ickup
tone with high-end, or a bass b oosted
ultra-low 60’s sound.

Bridge

Bridg e an d oth er hard war e are bla ck
nickel plated which is in addition
to looking great, is g ood for the
environment as we ll since it has no le ad.

Neck

Bi l ly’s B B 714 B S co m e s wi t h a
neck that is s lim, trim, an d fast. The
rosewood on maple neck is thinner
and tri mm er th an t he At ti tud e ba ss
and offers greater playing comfor t.

Billy Sheehan Signature Model

q

w

e

*YASH=Yamaha Artist Services Hollywood

ATTITUDE LTDII Neck

A big, thic k neck features jum bo frets
from frets 1-16 to produce ou tstanding
sustain. The neck is held to the bass
body with 4 scre ws to create a solid
bond an d tone. The n eck also features
scallops from frets 17 through 21 and
a slap cut ground i nto the neck t hat
provides greater string access.

ATTITUDE LTDII Bridge

The solid b rass b ridge captures and
transm its string vibration directly to the
body, creating great low-end tone and
attack.

Pickups and Electronics

Bo t h fr o nt a n d re a r pic k up s a re
custom made by DiMarzio and deliver
powerfully heavy bass tone with a
solid fundamental. Stereo output
jacks provide separate outputs for the
front and rear pickups. Mono output is
also possible. A h igh cut switch in the
front pickup tone control boosts bass
output f rom the front picku p.

Model
Construction
Scale Length
Fingerboard
Radius
Frets
Body

ATTLTDII

Bolt-on
34" (863.6mm)
Maple
10" (250mm)
21
Alder

Controls (ATTITUDE LTDII)

q

Front Volume

w

Front Tone (Front P.U. Hi-Cut Switch)

e

Rear Volume (Stereo/Mono Switch)

ATTLTDII

Black

BB714BS

Bolt-on
34" (863.6mm)

Rosewood

10" (250mm)
21
Alder

ATTITUDE LTDIIBB714BS

ATTLTDII

Lava Red

q

w

e

Billy Sheehan Signature Model

TRBJPII

John Patitucci Signature Model

In the nearly 20 years since John Patitucci fi rst gained recognition as a member of
Chick Corea's legendary Elektric Band, he's established himself as one of the best
jazz bassists of his time. Shifting seamlessly from bandleader to respected side­man, John relies on his TRB JPII signature 6-string bass to fi t any role.

White Perloid Peg Heads

Wh i te p e rlo i d pe g h ead s a id i n
bal ancing th e super long sca le ne ck
while adding gre at looks.

TRBJPII Custom Pickups

Pickup s are a custom A lnico V design.
Th e lo w- no is e doubl e- co il p ick up s
del ive r cle ar tonal image even w hen
playing chords.

Solid Brass Bridge

A massi ve solid brass bridge deli vers
a clear a nd rich so und.

Model
Construction
Scale Length
Fingerboard
Radius
Frets

TRB JPII

Bolt-on

35" (889mm)

Ebony

40" (1000mm)

26

4-Ply Laminated Body

The 4-ply la min ate d bod y is c raf ted
from plies of fi gured maple, ash, alder,
and maple. This design produces
tight and rich resonation over the
instrument’s entire range. A slap
cut on t he bod y offers greater s trin g
access.

26-Fret Neck

Th e 3 5-i n ch ( 889 m m) s u pe r l on g
scale n ec k has 26 frets. The m ap le
neck is fi tted with double truss rods to
suffi ciently counter tensi on produced
by the instrument’s six string s.

Controls (TRBJPII)

TRBJPII

Translucent Dark Red

q

e

w

r

t

TRB5PII/6PII

q

e

w

r

t

y

TRB5PII

Bubinga

TRB6PII

Maple

Alnico V Hum-Canceling Pickups

Hum-canceli ng type A lnico V pickups
are us ed to produc e clear tone. The
6- s tr i ngs o f fe r a w ide t ona l r an g e
and deliver a heavy ba ss soun d with
presence.

Model
Construction
Scale Length
Fingerboard
Radius
Frets
Body

Neck
Bridge
Pickups
Controls
Colors

TRB6PII/TRB5PII

Neck Through

35" (889mm)

Ebony

40" (1000mm)/19 11/16" (500mm)

24

Choice o f Maple, Ovangkol , or Bubinga Top & Back /

Light Ash

Maple /Premium Gr ade Mahogany 5 Pie ce

Yamah a BPZ-7

Alnico V H umcancelled X 2, Pi ezo Pickup

Master Vo lume, Pickup Bala ncer, Piezo Volume, 3-B and EQ

Maple, Ovangkol, Bubinga,

Bridge with Piezo Pickup

Individual bridges reduce influence
from string vibration. Each bridge
sa d dl e i s e qu i pp e d wit h a pie zo
pickup.

Choose Your Body Top

Th e 5 -pi e ce n e ck is s a nd w ich e d
bet wee n sla bs of l igh t ash . You can
select the top material from Maple,
Ovangkol, or Bubinga.

Neck Through Design

Th e 5- pi ec e ne ck is const ru ct ed of
plies of maple an d mahogany with a
35 -i n ch ( 88 9 mm ) su pe r l on g sca le
an d 24- fr ets. The n ec k on t he T RB
6PII is fi tted with double truss rods to
suffi ciently counter tension created by
the instrument’s six strings.

TRB 5PII/6PII Electronics

Create your favorite tonal blends using
the pickup balancer control to bala nce
output from the magnetic pickups,

q

Pickup Balancer

w

Master Volume

e

Piezo Volume

r

Bass

t

Middle

y

Tre bl e

TRB1006J

Caramel Brown

TRB1006J

Black

TRB1005J

Translucent Black

TRB1004J

Natural

Alnico V Hum-Canceling Pickups

Hum-canceli ng type A lnico V pickups
are us ed to produc e clear tone. The
6- s tr i ngs o f fe r a w ide t ona l r an g e
and deliver a heavy ba ss soun d with
presence.

Solid Brass Bridge

Th e b ras s b ri d ge tr ans m it s s tr i ng
vi b rat io n t o th e b od y w ith g rea t
effi ciency.

Maple Laminated Body

The l ami nate b ody i s crafte d from a
sl ab of a ld er w it h figur ed m ap le o n
top. A bolt on neck is us ed to ensure a
secure bond between neck and body
and create a clear, power ful sound.

5-Piece Neck

The 5-piece maple ne ck is designed
with a 35 -inch ( 889mm ) super l on g
sca le an d 24-fre ts. The neck on th e
TRB1006 is fitted with double truss
rods to sufficiently counter tension
created by the instruments si x string s.

Active 5-Control Circuit

Controls (TRB1006J/1005J/100 4J)

q

Pickup Balancer

w

Master Volume

e

Bass

TRB1006J/1005J/1004J

q

e

w

r

t

Model
Construction
Scale Length
Fingerboard
Radius
Frets
Body
Neck
Bridge
Pickups
Controls
Colors

TRB1006J

Bolt-on

35" (889mm)

Rosewood

40" (1000mm)

24

Maple/Alder

Maple

Solid Brass

Alnico V H um-Canceled X 2

Master Vo lume, Pickup Blan cer, 3-Band EQ

Black, N atural, Translucen t Black, Carame l Brown

TRB1004J

Bolt-on

35" (889mm)

Rosewood

10" ( 250mm )

24

Maple/Alder

Maple

Solid Brass

Alnico V H um-Canceled X 2

Master Vo lume, Pickup Blan cer, 3-Band EQ

Black, N atural, Translucen t Black, Carame l Brown

TRB1005J

Bolt-on

35" (889mm)

Rosewood

19 11/16 " (50 0mm)

24

Maple/Alder

Maple

Solid Brass

Alnico V H um-Canceled X 2

Master Vo lume, Pickup Blan cer, 3-Band EQ

Black, Natural, Translucent Black,

Caramel Brown

r

Middle

t

Tre bl e

SLG120NW/SLG100S/N

Paul Rodgers

Brian May

Model
Scale Length
Fingerboard
Radius
Frets
Body

SLG100S

24 15/16 " (634 mm)

Rosewood

15 3 /4" (4 00mm )

22

Maple

SLG100N

25 9/ 16" (6 50mm)

Rosewood

Flat

19

Maple

SLG120NW

25 9/ 16" (6 50mm)

Ebony

Flat

19

Maple

SLG100S SLG100N

SLG120NW

Chino Moreno

Deftones

Chris Minh Doky

Mike Ste rn, David Sanbor n

Chris Poland

Ohm

Chris Rodriguez Cornell Dupree

Photo by Michael Sherry

Dave Lopez

Flipsyde

Dave Meneketti

Y&T

Yamaha Artists

George Pajon JR

Black Eye d Peas

Glenn Hughes Greg Leisz

K.D.Lang

Jack Gibson

Exodus

James Black

Finger Eleven

James Lomenzo

Megade th, BLS, David L ee Roth

Jeff Rouse

Duff M cKagan’s Loaded

David Catching

Eagles of D eath Metal

Dino Meneghin

Michael Buble'

Doug Rappoport

Edgar Wi nter Band

Duff McKagan

Duff M cKagan’s Loaded

Felipe Andreoli

Angra

Francis Rossi, Rick Parfi tt

Status Quo

Frank Gambale

Aaron North

Nine Inch Nails

Abraham Laboriel Amir Derakh

Julien K

Bill Kelliher

Mastodon

Bill Sharpe

Cher, David B enoit

Brandon Belsky

Dead by Sunrise

Calvin Turner

Marc Broussard

Mike "Fish" Herring

Christ ina Aguilera, Sea l

Nick Rowe

Bloodsimple

Nick Annis

Black Li ght Burns

Philip Bynoe

Steve Vai B and

Rafael Bittencourt

Angra

Robby Takac

Goo Goo Dolls

Ross Bolton

Sandro Albert

Sandro Albert Quintet

Tariqh Akoni

Josh Groban

Tony Grey

Photo by Tetsuro Sato

Tony Kanal

No Doubt

Troy Sanders

Mastodon

Victor Johnson

Sammy Hagar

Vivian Campbell

Def Leppard

Kurt Rosenwinkel

Lars Stromberg

Interna tional Noise C onspiracy

Lee Sklar

Phil Collins

Marco Mendoza

Thin Liz zy, Dolores O'Ri ordan

Michael O'neill

George Benson Band

Michael Anthony Michael Thomas

Fastback

Jimmy Haslip

Yello wjacke ts

Jeph Howard

The Used

Joe Ayoub

Liz Phair

Joel Whitley

Stevie Wonder

Justin Derrico

Pink

Kirk Pengilly

INXS

Kevin Roentge

GIGMAKER

EG112C

Black

ERG121C

Black

Guitar Amplifier GA15

Guitar/Bass Tuner YT100

Picks

Strings Winder

Strap

ALL INCLUDED!

Gig Bag

Violin Sunburst

Brown Sunburst

Yellow Natural Satin

Natural Yellow Natural

Faded Burst

Blonde

Honey Burst

Old Violin Sunburst

Orange Met allic Antique Stain

Orange Stain

Light Amber Burst

Mustered Pearl Effect

Caramel Brown

Wine Red

Red Rocker Red

Translucent Blood
Red

Raspberry Red

Red Metallic

Mist Raspberry

Translucent Dark Red

Dark Blue Metallic

Faded Blue

Flat Blue

Metallic Blue

Pewter

Mist Purple

Translucent Blue

Royal Blue

Dark Metallic Gray

Lake Placid Blue

Mist Green

Aquarium Blue Sonic Blue

Mist Green Satin

Silver

Dark Oriental Green

White/Aircraft Gray

Charcoal Gray

Metallic Black

Flat Silver Pearl Snow White

Translucent Black

White

Vintage White

Black Metallic

Jet Black

Black

Amber

Tobacc o Bro wn
Sunburst

Vintage Sunburst

Guitar Finishes

Lava Red

Accessories/Amp

NE-1 Parametric Equalizer

QT-1/QT-1B/QT-1BR QUARTZ METRONOME

The QT-1 quartz metronome offers soft or bright sound settings, volume control and a
fl ashing LED atop its unique design. Tuning notes over a one octave range are provided

Parametric Equalizer Tuners & Metronomes

GA-15 Guitar Amplifi er

• Input/Output: INPUT, PHONES

• Power supply: AC120V, 60Hz

• Output Power: 15 W

• Power Consumption: 19 W

• Speaker: 16.5 cm (6.5”) X 1

• Control: DRIVE-GAIN, DRIVE-VOLUME,
DRIVE/CLEAN, CLEAN-VOLUME,
EQUALIZATION-TREBLE, EQUALIZA
TION-MIDDLE, EQUALIZATION-BASS,
POWER

• Dimensions: 295(W) X 300(H) X 190(D)
mm (11.6" X 11.8" X 7.5")

Amplifi ers

QT-1

Rear Panel

QT-1B

QT-1BR

* Little remaining stock.
