LS9 Editor Owner’s Manual

❏

Getting Started

Overview of LS9 Editor

LS9 Editor enables you to remotely control the Yamaha LS9 mixing console and to save the parameter settings on your computer. To use LS9 Editor, you must ﬁrst perform the following operations:

1 Start and conﬁgure Studio Manager.

2 Start and conﬁgure LS9 Editor.

3 Synchronize LS9 Editor with your LS9 console ( ➥ p.8).

NOTE

Conﬁguring LS9 Editor

For more information on using Studio Manager, refer to the Studio Manager Owner’s Manual.

You must conﬁgure the following settings for each open Editor.

NOTE

• Before you make the following settings, you must make settings for the DME-N Network Driver (Windows) or the Network-MIDI Driver (Mac) and select the MIDI port in the Setup window of Studio Manager.

•To open an editor, double-click the icon for the desired editor in the Studio Manager window.

System Setup

To open the System Setup window, choose [System Setup] from the [File] menu.

NOTE

Input port/Output port

From the ports you speciﬁed in Studio Manager, select the ports that the editor will use to communicate with the LS9 console.

Fast Sync

This allows synchronization to be speed up, reducing the time required. This check box enables/disables this function. You should disable this if synchronization errors occur while this functions enabled.

Window Control from Console

Allows the LS9 Editor windows to be opened and closed remotely using the USER DEFINED KEYS of the LS9 console. The check box enables/disables these operations.

Be sure to specify the Input port and Output port.

Level Meter

By disabling the meter function you can reduce the processing load caused by screen drawing and communication. This check box enables/disables the level meter function.

Conﬁrmation

These check boxes specify whether a conﬁrmation dialog box will be displayed when you store (Store Conﬁrmation), recall (Recall Conﬁrmation), patch (Patch Conﬁrmation), or patch in a way that would affect an existing patch (Steal Patch Conﬁrmation).

Administrator Password

Enter the Administrator password that was speciﬁed on the LS9 console. If this password is not entered correctly, it will not be possible to synchronize from LS9 Editor to the LS9 console.

LS9 Editor Owner’s Manual

❏

Mixer Setup

To open the Mixer Setup window, choose [Mixer Setup] from the [File] menu.

ModelSelect

Here you can specify the model of LS9 console. This is set automatically when the Editor synchronizes with the LS9 console.

Mix Bus Setup

Here you can make settings relating to the MIX buses.

Signal Type: This speciﬁes whether each two adjacent odd-numbered/even-numbered MIX buses will be used

as MONO x2 or STEREO.

Bus Type/Pre Fader Send Point: Speciﬁes whether the Send Point of each two adjacent odd-numbered/

even-numbered MIX buses will be VARI (PRE EQ), VARI (PRE FADER), or FIXED.

Pan Link: This is valid only when the Signal Type is STEREO and the BUS TYPE is VARI; when enabled, the

PAN setting sent to the stereo MIX bus will be linked with the PAN to the STEREO bus.

Matrix Bus Setup

Here you can make settings relating to the MATRIX buses.

Signal Type: This speciﬁes whether each two adjacent odd-numbered/even-numbered MATRIX buses will be

used as MONO x2 or STEREO.

LS9 Editor Owner’s Manual

❏

Creating a user key

To open the Create User Key window, choose [Create User Key] from the [File] menu. This creates a user key (with “.L9U” ﬁle name extension) that can be read from a USB storage device by the LS9

console to automatically set user-speciﬁc parameters.

2 465

O P

User Name

Specify the name of the user. You can enter up to eight single-byte characters of alphabet and numerals.

Comment

Enter a comment for each user. You can enter up to thirty-two single-byte alphanumeric characters.

Password

Enter a password that will be used when this user key is read by the LS9 console. You can enter up to eight singlebyte alphanumeric characters. Uppercase and lowercase are distinguished.

Re-Enter Password

Enter the password once again as a safeguard against mistaken entry.

POWER USER

Specify whether this user is a power user. Power users can use the LS9 console to create or edit a user authentication key with a speciﬁed user level.

Administrator Password

Enter the Administrator password that was speciﬁed on the LS9 console. This is not required if no Administrator password has been speciﬁed on the LS9 console, but if this password is incorrect you will be asked to enter it when the user key is read.

ACCESS PERMISSION

In this area, specify the parameters that this user will be allowed to operate.

LS9 Editor Owner’s Manual

CH OPERATION

INPUT, ST IN, MIX, MATRIX, ST/MONO: Select the channels whose parameters will be operable. HA: Change the operating privileges for the head amp gain and phantom power of the selected channels. PROCESSING: Change the operating privileges for overall signal processing parameters (except for fader

and [ON] key) of the selected channel. For the speciﬁc parameters included in PROCESSING, refer to the appendix of the LS9 owner’s manual.

FADER/ON:

level of the selected channels.

Set All: Clear All: Set by One Click:

select a channel. If all are already on, all will be turned off.

Change the operating privileges for the pan/balance, fader, channel on, send on/off, and send

Tu rn on HA, PROCESSING, and FADER/ON for all channels.

Tu rn off HA, PROCESSING, and FADER/ON for all channels.

If this button is on, HA, PROCESSING, and FADER/ON will all be turned on when you

SCENE LIST

STORE/SORT: Change the operating privileges for scene store and sort operations. RECALL: Change the operating privileges for scene recall operations.

LIBRARY LIST

STORE/CLEAR: Change the operating privileges for library store and clear operations. RECALL: Change the operating privileges for library recall operations.

FILE LOAD

USER SETUP: Change the operating privileges for loading user-deﬁned keys and preferences when loading a

ﬁle.

SYSTEM SETUP MONITOR SETUP:

tor setup settings when loading a ﬁle.

CURRENT SCENE: SCENE LIST: LIBRARY LIST:

Change the operating privileges for loading the current scene when loading a ﬁle.

Change the operating privileges for loading the scene list when loading a ﬁle.

Change the operating privileges for loading the library list when loading a ﬁle.

Change the operating privileges for loading system setup and moni-

CURRENT SCENE

INPUT PATCH: Change the operating privileges for input patch operations. INPUT NAME: Change the privileges for editing the input names. OUTPUT PATCH: Change the operating privileges for output patching. OUTPUT NAME: Change the privileges for editing the output names. BUS SETUP: Change the operating privileges for buses. RACK: Change the operating privileges for rack operations. MUTE GROUP ASSIGN: Change the privileges for assigning mute groups. MUTE GROUP MASTER: Change the operating privileges for enabling/disabling mute groups.

M MONITOR SETUP

OSCILLATOR: Change the operating privileges for oscillator settings. TALKBACK: Change the operating privileges for talkback settings.

N SYSTEM SETUP

MIXER SETUP: Change the privileges for making mixer setup settings. OUTPORT SETUP: Change the privileges for making outport setup settings. MIDI: Change the privileges for making MIDI settings.

O Create

Creates the user key.

P Cancel

Closes the window.

LS9 Editor Owner’s Manual

Working with Sessions

All of your console’s mix settings in LS9 Editor, including Scene and library data, are called Sessions. The following table describes how to handle Sessions.

Creating a new Session Choose [New Session] from the [File] menu.

Opening a previously saved Session Choose [Open Session] from the [File] menu.

Saving the current Session Choose [Save Session] from the [File] menu.

Saving the current Session with a new name Choose [Save Session As...] from the [File] menu.

When you save a session in the window of an editor, the settings of only that editor will be saved in a ﬁle. Session ﬁles saved by LS9 Editor have a ﬁlename extension of “.YSE”. Files in which only the LS9 console data is saved (ﬁlename extension “.L9A”) can also be handled, allowing you to use a USB storage device to exchange data with the LS9 console.

If you save a Session in the Studio Manager window, all selected Editor settings are saved in a ﬁle with a ﬁle extension of “.YSM.”

Undo/Redo Function

In LS9 Editor, you can cancel the latest operation (Undo) and also cancel the cancellation of the latest operation (Redo). If you perform an Undo operation twice in a row, you can cancel the two most-recent operations. If you perform an Undo operation three times in a row, you can cancel the three most-recent operations. In this way, you can cancel multiple recent operations. The following table describes how to use the Undo/Redo function.

Undo Choose [Undo] from the [Edit] menu.

Redo Choose [Redo] from the [Edit] menu.

Please note, however, that after you perform one of the following operations, you cannot successfully undo or redo any previous operation:

•Operations on the LS9 console

• Quitting Studio Manager

•Synchronizing with the LS9 console

•Session operations

NOTE

You cannot Undo or Redo the following operations:

• Edits in the Setup window

• Synchronization

• Opening and closing the windows

• Resizing or moving the windows There are certain other operations that cannot be undone, depending on the function.

For library or scene operations, Undo/Redo applies only to the single most recent operation. You cannot undo any operations prior to this. Undo/Redo in these windows is available only using the [UNDO] button within the respective window. Even if you perform a scene recall from the Master window, you cannot use a shortcut or menu operation to undo the recall.

LS9 Editor Owner’s Manual

Window operations

You can select and open each window from the [Windows] menu. For the Overview window and Rack window, use the sub-menu to select the channels or library you want to see.

You can choose Tile or Cascade to arrange the windows within the editor.

● Tile

● Cascade

In the Library window or Scene window, click the tabs located at the top of the window to switch between pages.

LS9 Editor Owner’s Manual

Synchronizing LS9 Editor

When LS9 Editor starts up, the parameter settings on the console and the parameter settings in LS9 Editor may be different. Therefore, you must ﬁrst match the parameter settings on the console with those in LS9 Editor. This operation is called “synchronization.” Follow the steps below to synchronize LS9 Editor.

1 Select [Synchronization], then [Re-synchronize].

The following window opens.

2 Select whether you want to transfer your settings to LS9 Edi-

tor, or vice versa.

At this time, the All Libs option determines whether or not Scene and Library data is synchronized.

PC ➔ Console: Tr ansfers the current parameter settings in LS9 Editor to your console. Console ➔ PC: Tr ansfers the current parameter settings of your console to the LS9 Editor.

3 Click [OK].

Do not operate the console while synchronization is in progress.

NOTE

• If you use the “Total Recall” function in Studio Manager, all selected Editors in Studio Manager are synchronized with the corresponding devices.

• If you synchronize using PC -> Console, and the console contains data that is set to “read-only,” a dialog box will ask you whether you want to copy the read-only data to LS9 Editor. If this data is not copied, console data that is set to read-only status will not be synchronized.

Ofﬂine Edit Function

If you do not want to synchronize your console with LS9 Editor, select [Ofﬂine Edit] from the [Synchronization] menu. To apply your off-line edits to your console, select [Re-Synchronize] from the [Synchronization] with the PC

-> Console option to synchronize the console with LS9 Editor. The Ofﬂine Edit function is also activated when you click the [ONLINE]/[OFFLINE] button in the Sync window.

NOTE

Some effect parameters in the console change their displayed values depending on the sampling frequency. If you switch LS9 Editor from OFFLINE to ONLINE, displayed parameter values may change because LS9 Editor loads the sampling frequency from the console and updates the display.

Basic operation of controllers

You can operate the controllers in the following ways.

❏ Knobs

•Drag

•Click, and then use the up/down/left/right cursor keys

•Click, and then use the PageUp/PageDown keys (greater change than the cursor keys)

•Click, and then Home sets to far left

•Click, and then End sets to far right

• <Ctrl>(< >)+click sets to default value

For send knobs etc., sets to –∞ regardless of the default value.

• <Ctrl>(< >)+<Shift>+click sets to nominal For send knobs etc., sets to nominal regardless of the default value.

LS9 Editor Owner’s Manual

❏ Faders

•Drag

•Click, and then use the up/down cursor keys (or left/right cursor keys for horizontal faders)

•Click, and then use the PageUp/PageDown keys (greater change than the cursor keys)

•Click, and then Home sets to maximum value

•Click, and then End sets to minimum value

• <Ctrl>(< >)+click sets to default value For channel faders etc., sets to –∞ regardless of the default value.

• <Ctrl>(< >)+<Shift>+click sets to nominal For channel faders etc.,sets to nominal regardless of the default value.

❏ Numerical displays only

•Click and drag up/down

•Click, and then use the up/down cursor keys

•Click, and then use the PageUp/PageDown keys (greater change than the cursor keys)

•Click, and then Home sets to maximum value

•Click, and then End sets to minimum value

• <Ctrl>(< >)+click sets to default value

❏ Bar graphs

•Drag

• <Ctrl>(< >)+click sets to –∞

• <Ctrl>(< >)+<Shift>+click sets to nominal

LS9 Editor Owner’s Manual

Master window

1 2

In the Master window you can synchronize settings with the LS9 console, recall scenes, and access the Overview window. To open this window, choose [Master] from the [Windows] menu, or assign [LS9 EDITOR CONTROL]-[MASTER] to a USER DEFINED KEY on the LS9 console, and execute that function.

❏ CHANNEL SELECT

This indicates the number and name of the channel to which your operations will apply. To switch channels, you can either click the [SELECT] button and choose from the list that appears, or you can click the left/right arrow-shaped channel select buttons. You can use the channel name text box to edit the name.

This is linked with the [SEL] keys on the LS9 itself. You can change the icon by right-clicking (<control> key + clicking) it, or change the back-

ground color by left-clicking. The background color you specify here will also be the background color for the channel

name in the Overview window.

❏ SYNC

This indicates the status of connection and synchronization between LS9 Editor and the LS9.

A [ONLINE]/[OFFLINE] button

The ONLINE/OFFLINE status will alternate each time you click this button. This has the same function as [Synchronization] menu ➔[Ofﬂine Edit]. (➥ p.8)

This indicator is shown when LS9 Editor is correctly connected to the LS9 itself. In this state, the parameters of LS9 Editor and the LS9 itself are linked.

This indicator is shown when LS9 Editor and the LS9 itself are not connected, or when there is a problem with the connection, or when Ofﬂine Edit is selected. In this state, the parameters of LS9 Editor and the LS9 itself are not linked.

LS9 Editor Owner’s Manual

B [RE SYNC] button

J K 8

477

Clicking this button opens the Synchronization dialog box. This has the same function as [Synchronization] menu ➔ [Re-Synchronize]. (➥ p.8)

❏ SCENE MEMORY

Here you can view the currently-recalled scene, and recall or store scenes.

A Scene number display 1 2 3

4 5 6

Indicates the number of the scene that is selected for store or recall.

BProtect indicator

A lock icon is shown for scene memories that are protected. Read-only scene memories are indicated by “R” displayed.

CEdit indicator

The edit indicator will light when you edit the parameters after recalling a scene.

D [STORE] button

This button stores the current scene into the number shown by the scene number display (

E [▲]/[▼] buttons

These buttons increment or decrement the number shown in the scene number display (

1). The scene number display (1) will blink until you actually store or recall, and

while blinking will not match the scene number indicated on the LS9.

1).

❏ Layer Keys

1 2 5

F [RECALL] button

This button recalls the scene of the number shown in the scene number display (1).

These keys open the respective Overview window.

These are not linked with the layer section on the LS9’s panel.

NOTE

A [1-16] button

Opens the INPUT CH 1–16 window.

B [17-32] button

Opens the INPUT CH 17–32 window.

C [33-48] button

Opens the INPUT CH 33–48 window. This is available only if you’re editing ofﬂine and have selected LS9-32 in the Model

Select ﬁeld of the Mixer Setup screen, or if you’re editing online with the LS9-32 connected.

D [49-64] button

Opens the INPUT CH 49–64 window. This is available only if you’re editing ofﬂine and have selected LS9-32 in the Model

Select ﬁeld of the Mixer Setup screen, or if you’re editing online with the LS9-32 connected.

E [MIX] button

Opens the MIX window.

F [MATRIX] button

Opens the MATRIX window.

G [STEREO] button

Opens the STEREO/MONO window.

LS9 Editor Owner’s Manual

H [ST IN] button

Opens the STEREO IN window.

I [1-16] button

Opens the Custom Fader Layer (INPUT CH) CH 1–16 window.

J [17-32] button

Opens the Custom Fader Layer (INPUT CH) CH 17–32 window. This is available only if you’re editing ofﬂine and have selected LS9-32 in the Model

Select ﬁeld of the Mixer Setup screen, or if you’e editing online with the LS9-32 connected.

K [ST IN] button

Opens the Custom Fader Layer (ST IN) window.

LS9 Editor Owner’s Manual

Overview window

INPUT CH window

This window displays the mix parameters of INPUT CH 1–16, 17–32, 33–48

(*),

or 49–64

(*).

The parameters shown in the window can be selected from the [View] menu or the menu that appears when you right-click (<control> key + click) in the window.

You can access this window in the following ways.

● From the [Windows] menu, choose [Overview] and select CH1-16/CH17-32/33-48

Use the layer keys in the Master window to turn on the [1-16] button / [17-32] button / [33-48] button

●

On the LS9 itself, assign one of the USER DEFINED KEYS to [CH1-16]/[CH17-32]/[CH33-48]

●

[OVERVIEW] of [LS9 EDITOR CONTROL], and execute the function

(*)

INPUT CH 33-48, 49-64 can be viewed only if LS9-32 is selected in the Model Select ﬁeld of the Mixer Setup window when editing ofﬂine, or when editing online with the LS9-32.

2 3

A Input patch

Click here to select the input source that will be assigned to the INPUT CH, from the following choices.

NONE No assignment IN 1–IN32 SLOT1-1...SLOT1-16,

SLOT2-1 2TR IN L, 2TR IN R L/R channels of the 2TR DIN jack PB OUT L, PB OUT R L/R channels of USB memory recorder output RACK1A, RACK1B...

RACK5L(A)...RACK8R(B)

(*)

INPUT jacks 17-32 and slot 2 can be viewed only if you’re editing ofﬂine and have selected LS9-32 in the Model Select ﬁeld of the Mixer Setup screen, or if you’re editing online with the LS9-32.

(*)

...SLOT2-16

(*)

INPUT jacks 1–32

Input channels of an I/O card installed in a slot

L/R outputs of Rack 1–8

(*)

/49-64

(*)

/ [49-64] button

/[CH49-64]

(*)

B HA GAIN

Drag the knob in the screen to adjust the gain of the internal head amp or of the external head amp (AD8HR) patched to the INPUT CH.

C 48V

Switches on/off the phantom power (+48V) of the internal head amp or of the external head amp (AD8HR) patched to the INPUT CH.

LS9 Editor Owner’s Manual

D Ø (Phase)

• Pre/on (green)

• Pre/off (green)

• Post/on (yellow)

• Post/off (yellow)

Inverts the phase of the signal after AD conversion.

6 7

E HPF (High Pass Filter)

Switches the high pass ﬁlter on/off. You can drag the numeric value up or down to edit the cutoff frequency.

F INS (Insert)

Enables/disables the insert-in. (INPUT CH 1–32 only)

G D. OUT (Direct out)

Enables/disables the direct output.

H EQ (Equalizer)

Switches the EQ on/off. The graph immediately below the button shows the approximate response of the EQ. You can drag within the graph to edit the response of the EQ. To reset the EQ to ﬂat response, hold down the <Ctrl>(< >) key of your computer keyboard and click the graph (The HPF setting will remain).

I DYN1/DYN2 (Dynamics 1/Dynamics 2)

Tu rns the two dynamics processors on/off. If Gate is assigned (Dynamics 1 only), the status of the gate is shown immediately below

the button.

Gate status

indication

On/off status On On On Off

L M

Open/closed status

Remarks

Gain reduction amount is 30 dB or more

Closed Open Open —

Gain reduction amount is 0–30 dB

Gain reduction amount is 0 dB

If something other than Gate is assigned, a GR meter is shown immediately below the button, and the amount of gain reduction is shown while this is on.

The type for each dynamics processor can be selected in the Selected Channel window.

J MIX SEND

The bar graphs located immediately below the button show the send level of the signals sent from the INPUT CH to VARI type MIX buses. You can also drag the bar graph to left or right to set the send level. While you drag the bar graph, the send level is shown in the numerical display area for PAN/TO STEREO MONO (

K).

You can set the minimum value (–∞ dB) by holding down the <Ctrl>(< >) key of your computer keyboard and clicking the bar graph, or set the nominal value (0.00 dB) by holding down the <Ctrl>(< >) key and <Shift> key and clicking the bar graph.

The bar graph display will change according to the send position (pre/post) and on/off status of the signal sent from the INPUT CH to the MIX buses.

To switch a send on/off, click the channel number located at the left of the bar graph.

NOTE

For FIXED-type MIX buses, the bar graph is ﬁxed at nominal level (0 dB), and only the on/ off status is shown.

—

LS9 Editor Owner’s Manual

L M

K PAN/TO STEREO MONO

The PAN knob adjusts the panning of the signal that is sent from the INPUT CH to the STEREO bus L/R channels (or the L/C/R channels). You can set this to the center value by holding down the <Ctrl>(< >) key of your computer keyboard and clicking this knob.

The [ST] button is an on/off switch for the signal that is sent from the INPUT CH to the STEREO bus.

The [M(C)] button is an on/off switch for the signal that is sent from the INPUT CH to the MONO bus.

If LCR MODE is selected in the Selected Channel window, the [LCR] button will appear instead of the [ST] button and [M(C)] button, and the [LCR] button will be an on/off switch for the signal that is sent from the INPUT CH to the LCR bus.

L SEL (Select)

Selects the INPUT CH for which you want to perform operations. This is linked with the INPUT section [SEL] keys on the LS9’s panel.

M CUE

This button cue-monitors the signal of the INPUT CH. This is linked with the INPUT section [CUE] keys on the LS9’s panel.

N ON

Switches the INPUT CH on/off. This is linked with the INPUT section [ON] keys on the LS9’s panel.

O Fader

Adjusts the input level of the INPUT CH. When the LS9 itself is in other than SENDS ON FADER mode, this is linked with the INPUT section faders of the LS9’s panel.

The current fader value is shown in the numerical box located immediately below the fader.

You can set this to the minimum value (–∞ dB) by holding down the <Ctrl>(< >) key of your computer keyboard and clicking the fader knob, or set it to the nominal value (0.00 dB) by holding down the <Ctrl>(< >) key and <Shift> key and clicking the fader knob.

The numbers and alphabetical letters at the right of the fader indicate the mute groups to which that channel belongs, and show the Recall Safe and Mute Safe status of the channel.

The numbers of mute groups to which this channel belongs are shown in red.

If this channel is set to Recall Safe, the R character is shown in green.

If this channel is set to Mute Safe, the M character is shown in green.

P Channel number

This is the number of the INPUT CH. You can open the Selected Channel window for this channel by double-clicking this number. If you hold down the <Ctrl>(< >) key of your computer keyboard and double-click this, the Selected Channel window will open as an additional view.

Q Channel name

This is a text box that displays the channel name. You can also edit the channel name in this text box.

The background color will be the same as the background color of the icon in the channel select area of the Selected Channel window.

LS9 Editor Owner’s Manual

ST IN window

In this window you can view and edit the mix parameters of ST IN CH 1–4. The parameters shown in the window can be selected from the [View] menu or the menu that appears when you right-click (<control> key + click) in the window.

You can access this window in the following ways.

● From the [Windows] menu, choose [Overview] and then choose “ST IN”

● Use the layer keys in the Master window to turn on the [ST IN] button

● On the LS9 console, assign a USER DEFINED KEY to [LS9 EDITOR CONTROL]-[OVERVIEW]-[ST IN], and execute it

A INPUT PATCH

2 3

4 5

This selects the input source assigned to the ST IN CH. The input sources that can be selected are the same as the INPUT CH.

B HA GAIN

Drag the knob in the screen to adjust the gain of the internal head amp or of the external head amp (AD8HR) patched to the ST IN CH.

C 48V

Switches on/off the phantom power (+48V) of the internal head amp or of the external head amp (AD8HR) patched to the ST IN CH.

D Ø (Phase)

Inverts the phase of the signal after AD conversion.

E HPF (High Pass Filter)

Switches the high pass ﬁlter on/off. You can drag the numeric value up or down to edit the cutoff frequency.

F EQ (Equalizer)

Switches the EQ on/off (the L/R settings are linked). This is the same as the equalizer for INPUT CH (➥ p.14).

LS9 Editor Owner’s Manual

J K L

N O

G DYN1/DYN2 (Dynamics 1//Dynamics 2)

These buttons switch the two dynamics processors on/off. This is the same as the dynamics 1/dynamics 2 for INPUT CH (➥ p.14).

H MIX SEND

This is the same as the mix send for INPUT CH (➥ p.14).

I BALANCE

The BALANCE knob adjusts the balance of the signal that is sent from the ST IN CH to the STEREO bus L/R channels (or the L/C/R channels). Other than the BALANCE knob, this is the same as PAN/TO STEREO MONO for an INPUT CH (➥ p.15).

J SEL (Select)

Selects the ST IN CH for which you want to perform operations. (L and R can be selected separately.) This is linked with the ST IN section [SEL] keys on the LS9’s panel.

K CUE

This button cue-monitors the signal of the ST IN CH (L/R are linked). This is linked with the ST IN section [CUE] keys on the LS9’s panel.

L ON

Switches the ST IN CH on/off (the L/R settings are linked). This is linked with the ST IN section CH [ON] keys on the LS9’s panel.

M Fader

Adjusts the input level of the ST IN CH. When the LS9 itself is in other than SENDS ON FADER mode, this is linked with the INPUT section faders of the LS9’s panel.

The current fader value is shown in the numerical box located immediately below the fader. This is the same as the fader for INPUT CH (➥ p.15).

N Channel number

This is the number of the ST IN CH. You can double-click this number to open the Selected Channel window for this channel. If you hold down the <Ctrl>(< >) key of your computer keyboard and double-click this, the Selected Channel window will open as an additional view.

O Channel name

This is a text box that displays the channel name. You can also edit the channel name in this text box.

The background color will be the same as the background color of the icon in the channel select area of the Selected Channel window.

LS9 Editor Owner’s Manual

MIX window

In this window you can view and edit the parameters of MIX channels 1–16. The parameters shown in the window can be selected from the [View] menu or the menu that appears when you right-click (<control> key + click) in the window.

You can access this window in the following ways.

● From the [Windows] menu, choose [Overview] and then choose “MIX”

● Use the layer keys in the Master window to turn on the [MIX] button

● On the LS9 console, assign a USER DEFINED KEY to [LS9 EDITOR CONTROL]-[OVERVIEW]-[MIX], and execute it

A OUTPUT PATCH

1 2

Click here to select the output port that will be assigned to the MIX channel, from the following choices.

OMNI1–OMNI16

SLOT1-1...SLOT1-16, SLOT2-1

RACK1A, RACK1B... RACK5L(A)...RACK8R(B)

2TR OUT L, 2TR OUT R L/R channels of the 2TR OUT DIGITAL jack

REC IN L, REC IN R L/R channels of the USB memory recorder input

(*) OMNI jacks 9–16 and SLOT2 can be viewed only if you’re editing ofﬂine and have selected LS9-32 in

(*)

the Model Select ﬁeld of the Mixer Setup screen, or if you’re editing online with the LS9-32 connected.

(*)

...SLOT2-16

(*)

OMNI jacks 1–16

Output channels of an I/O card installed in a slot

L/R outputs of Rack 1–8

(*)

If multiple patches have been made, only the ﬁrst port is shown. If you change the patching in this window, the port that had been assigned until then

will be cancelled, and only the newly selected port will be assigned.

B EQ (Equalizer)

Switches the EQ on/off. This is the same as the equalizer for INPUT CH (➥ p.14).

C DYN1(Dynamics 1)

Switches the dynamics processor on/off. This is the same as the dynamics 2 for INPUT CH (➥ p.14).

D INS (Insert)

Enables/disables the insert-in.

LS9 Editor Owner’s Manual

7 8 9

E MATRIX SEND

These bar graphs indicate the send levels of the signals sent from the MIX channel to MATRIX 1–8 bus. You can also adjust the send levels by dragging a bar graph to left or right. While you drag the bar graph, the send level is shown in the numerical display area for PAN/BALANCE (

The bar graph display will change as follows according to the send position (pre/post) and on/off status of the signal sent from the MIX channel to the MATRIX buses.

To switch a send on/off, click the channel number located at the left of the bar graph.

6).

• Pre/on (green))

• Pre/off (green)

• Post/on (yellow)

• Post/off (yellow)

F PAN/BALANCE

The PAN knob adjusts the panning of the signal that is sent from the mix channel to the STEREO bus L/R channels (or the L/C/R channels). You can set this to the center value by holding down the <Ctrl>(< >) key of your computer keyboard and clicking this knob. If assigned as a stereo bus, this adjusts the balance of the odd-numbered channel and even-numbered channel. The stereo bus setting can be made in Mix Bus Setup of the Mixer Setup screen.

The [ST] button is an on/off switch for the signal that is sent from the mix channel to the STEREO bus.

The [MONO] button is an on/off switch for the signal that is sent from the mix channel to the MONO bus.

If LCR MODE is selected in the Selected Channel window, the [LCR] button will appear instead of the [ST] button and [MONO] button, and the [LCR] button will be an on/off switch for the signal that is sent from the mix channel to the LCR bus.

G VARI/FIXED

Indicates the type (VARI or FIXED) of the currently selected MIX bus. This parameter can be switched in Mix Bus Setup of the Mixer Setup screen.

H SEL (Select)

Selects the MIX channel for which you want to make settings.

I CUE

This button cue-monitors the signal of the MIX channel.

J ON

Switches the MIX channel on/off.

K Fader

Adjusts the output level of the MIX channel. The current fader value is shown in the numeric box immediately below the fader. You can set this to the minimum value (–∞ dB) by holding down the <Ctrl>(< >) key of your computer keyboard and clicking the fader knob, or set it to the nominal value (0.00 dB) by holding down the <Ctrl>(< >) key and <Shift> key and clicking the fader knob.

The numbers and alphabetical letters at the right of the fader indicate the mute groups to which that channel belongs, and show the Recall Safe and Mute Safe status of the channel.

The numbers of mute groups to which this channel belongs are shown in red.

If this channel is set to Recall Safe, the R character is shown in green.

If this channel is set to Mute Safe, the M character is shown in green.

L Channel number

Indicates the number of the MIX channel. You can double-click this number to open the Selected Channel window for this channel. If you hold down the <Ctrl>(< >) key of your computer keyboard and double-click this, the Selected Channel window will open as an additional view.

M Channel name

This is a text box that displays the channel name. You can also edit the channel name in this text box.

The background color will be the same as the background color of the icon in the channel select area of the Selected Channel window.

LS9 Editor Owner’s Manual

MATRIX window

In this window you can view and edit the parameters of MATRIX channels 1–8. The parameters shown in the window can be selected from the [View] menu or the menu that appears when you right-click (<control> key + click) in the window.

You can access this window in the following ways.

● From the [Windows] menu, choose [Overview] and then choose “MATRIX”

● Use the layer keys in the Master window to turn on the [MTRX] button

● On the LS9 console, assign a USER DEFINED KEY to [LS9 EDITOR CONTROL]-[OVERVIEW]-[MATRIX], and execute

LS9 Editor Owner’s Manual

1 2

7 8

A OUTPUT PATCH

This selects the output port assigned to the MATRIX channel. The output ports that can be selected are the same as for MIX (➥ p.18).

B MIX (send levels from MIX channels)

Here you can view and edit the send levels of the signals sent from the MIX channels to the MATRIX bus. The method of operation and the meaning of the display are the same as in (

5) MATRIX SEND in the MIX window (➥ p.19).

C STEREO (Send levels from the STEREO channels to the MATRIX

bus)

Here you can view and edit the send levels of the signals sent from the STEREO channels to the MATRIX bus. While you drag the bar graph, the send level is shown in the numerical display area immediately below. The method of operation and the meaning of the display are the same as for (

5) MATRIX SEND in the MIX window (➥ p.19).

D EQ (Equalizer)

Switches the EQ on/off. The graph immediately below the button shows the approximate response of the EQ. This is the same as the equalizer for INPUT CH (➥ p.14).

E DYN1(Dynamics 1)

Switches the dynamics processor on/off. This is the same as the dynamics 2 for INPUT CH (➥ p.14).

F INS (Insert)

Enables/disables the insert-in.

G SEL (Select)

Selects the MATRIX channel for which you want to make settings.

H CUE

This button cue-monitors the signal of the MATRIX channel.

I ON

This switches the MATRIX channel on/off.

J Fader

This adjusts the output level of the MATRIX channel. The current fader value is shown in the numeric box immediately below the fader.

The numbers and alphabetical letters at the right of the fader indicate the mute groups to which that channel belongs, and show the Recall Safe and Mute Safe status of the channel. (For the signiﬁcance of the numbers and alphabetical letters, see ➥ p.19).

K Channel number

Indicates the number of the MATRIX channel. You can double-click this number to open the Selected Channel window for this channel. If you hold down the <Ctrl>(< >) key of your computer keyboard and double-click this, the Selected Channel window will open as an additional view.

L Channel name

This text box shows the channel name. You can edit the channel name within this text box.

The background color will be the same as the background color of the icon in the channel select area of the Selected Channel window.

LS9 Editor Owner’s Manual

STEREO/MONO window

In this window you can view and edit the parameters of the STEREO and MONO channels. The parameters shown in the window can be selected from the [View] menu or the menu that appears when you right-click (<control> key + click) in the window.

You can access this window in the following ways.

● From the [Windows] menu, choose [Overview] and then choose “STEREO/MONO”

● Use the layer keys in the Master window to turn on the [STEREO] button

● On the LS9 console, assign a USER DEFINED KEY to [LS9 EDITOR CONTROL]-[OVERVIEW]-[ST/MONO], and exe-

cute it

A OUTPUT PATCH

This selects the output port assigned to the STEREO/MONO channel. The output ports that can be selected are the same as for MIX (➥ p.18).

B EQ (Equalizer)

Switches the EQ on/off (the L/R settings are linked). This is the same as the equalizer for INPUT CH (➥ p.14).

C DYN1(Dynamics 1)

Switches the dynamics processor on/off. This is the same as the dynamics 2 for INPUT CH (➥ p.14).

D INS (Insert)

Enables/disables the insert-in. (The L/R settings are linked.)

E MATRIX SEND

Here you can view and edit the send levels of the signals sent from the STEREO/MONO channel to MATRIX 1–8 bus. The method of operation and the meaning of the display are the same as for MATRIX in the MIX window (➥ p.19).

LS9 Editor Owner’s Manual

7 8 9

K L

F BALANCE

Adjusts the left/right balance of the STEREO channel.

G SEL (Select)

Selects the channel for which you want to make settings. (You can specify L and R independently.) This is linked with the STEREO/MONO MASTER section [SEL] keys on the LS9’s panel.

H CUE

This button cue-monitors the signal of the STEREO/MONO channel. This is linked with the STEREO/MONO MASTER section [CUE] keys on the LS9’s panel.

I ON

This switches the STEREO/MONO channel on/off. This is linked with the STEREO/ MONO MASTER section [ON] keys on the LS9’s panel.

J Fader

Adjusts the output level of the STEREO/MONO channel. This is linked with the STEREO/MONO MASTER section faders of the LS9’s panel.

The current fader value is shown in the numeric box immediately below the fader. The numbers and alphabetical letters at the right of the fader indicate the mute groups

to which that channel belongs, and show the Recall Safe and Mute Safe status of the channel. (For the signiﬁcance of the numbers and alphabetical letters, see ➥ p.19).

K Channel number

This is the channel number (ST or M). You can double-click this number to open the Selected Channel window for this channel. If you hold down the <Ctrl>(< >) key of your computer keyboard and double-click this, the Selected Channel window will open as an additional view.

L Channel name

This text box shows the channel name. You can edit the channel name within this text box.

The background color will be the same as the background color of the icon in the channel select area of the Selected Channel window.

LS9 Editor Owner’s Manual

Custom Fader Layer window

The Custom Fader Layer allows you to create a freely selected combination of the LS9’s internal channels for each user key. For details on operating each type of channel, refer to the Overview window for that channel.

NOTE

Custom Fader Layer window

In the initial state when the Editor has never been synchronized with the LS9 console, this window will show the Administrator settings. However when you synchronize, this window will be displayed according to the user level of the console.

This window lets you view and edit the mix parameters for Custom Fader Layer CH 1–16 and 17–32

(*)

. The parameters shown in this window can be selected from the [View] menu or from the menu that appears when you rightclick in the window.

You can display this window in either of the following ways.

● From the [Windows] menu, choose [Overview] and then choose “Custom Fader Layer (CH1-16)”/“Custom Fader Layer

(CH17-32)” In the Master window, turn the Layer Keys CUSTOM [1-16] button/[17-32] button

●

(*)

Custom Fader Layer CH 17-32 can be displayed only if you’re editing ofﬂine and have selected LS9-32 in the Model Select ﬁeld of the Mixer Setup window, or if you are editing online with the LS9-32 connected.

(*)

Select the channels that you want to assign to the Custom Fader Layer (INPUT CH). You can also make these settings in the “Custom Fader Layer Setup window.”

LS9 Editor Owner’s Manual

+ 56 hidden pages

Yamaha LSP User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Getting Started

Master window

Overview window

Custom Fader Layer window
