Dear YAMAHA customer!
You are holding our current export product
line in your hands. This provides you with
information regarding the entire Yamaha
range in compact format. Illustrations and
explanatory notes will guide you through it.
You will receive detailed information,
brochures and expert advice from your
YAMAHA dealer. Of course, you can also
put the YAMAHA instruments through
their paces there.
Our address is shown overleaf should you
wish to contact us directly.
Of course, you can also submit any queries,
requests, suggestions or orders for catalogues on the Internet at www.yamaha.de.
We hope you will enjoy this brochure and,
of course, the instruments.
Your YAMAHA team
You will also find more information, software,
tips and tricks on the Internet at:
Internet: http://www.yamaha-europe.com
http://www.yamaha.co.jp
http://www.yamaha-tyros.de
http://www.clavinova.de
The descriptions and photos in this brochure are for information only. YAMAHA reserves the right to change the products
and technical data at any time without notice. As the technical data may vary from country to country, please obtain information from your Yamaha dealer. No liability is accepted for
printing errors.
Status: May 2007
CONTENTS
4
MUSIC SCHOOL
6
KEYBOARDS
Entry-level Keyboards
PSR-E213, PSR-E313 8/9
PSR-E403, PSR-450 10/11
Overview - Entry-level Keyboards 12
Light Keyboard EZ-200 13
Digital Drums DD-65 13
Portable Grand Pianos NP30, DGX-220 14/15
DGX-520, DGX-620 16/17
Overview - Portable Grand Pianos 18
Orient. Keyboards PSR-R200, PSR-A300, PSR-OR700 19
Home Keyboards PSR-S500, PSR-S700 20/21
PSR-S900 / Overview - Home Keyboards 22/23
Entertainer Keyboard Tyros2 Super Edition 24/25
26
ACCESSORIES
Microphones, Active-Boxes, Studio Monitors 26
Stagepas Portable PA System 27
EMX Power Mixer, MG Mixer 28
Power Adapter, Benches, Headphones, Cables, Pedals 29
Stands, Bags, Dust Cover, Others 30
31
OVERVIEW - DIGITAL PIANO KEYS
32
CLAVINOVA
CVP-Series - Family Entertainment
CVP-401 34
CVP-403 35
CVP-405 36
CVP-407 37
CVP-409PE 38
CVP-409PM 39
CVP-309GP / Overview - CVP-Series 40/41
CLP-Series - Clavinova Classic
YDP-S30, YDP-S30C 42/43
YDP-131 44
CLP-220, CLP-220PE 45
CLP-230, CLP-230PE 46/47
CLP-240 48
CLP-240PE 49
CLP-270 50/51
CLP-280 52
CLP-280PE/PM 53
Overview - CLP-Series / CLP-265GP 54/55
CLP-Grandpiano Series
CLP-295GP 56/57
Design Line
CLP-F01 58/59
Modus H01 60/61
62
STAGE PIANOS
CP33, CP300 63/64
P70/S, P140/S 64/65
66
SOFTWARE DOWNLOADSHOP
In the five decades of its existence, the YAMAHA music
school has developed pioneering concepts for the teaching
of music. In an international context, for example, the programmes based on fundamental research for children of preschool age are unique. At the YAMAHA music schools, cognisance is taken of current educational trends and findings,
and these are put into practice. The teaching programs are
constantly updated and are therefore always in line with the
latest trends in research into the teaching of music.
Learning with others is a particularly effective method of teaching. This is what our experience
over the last decades has shown:
by joining in, listening and making a contribution within a group,
children, young people and adults
quickly develop their musicality
and the pleasure they get from playing. The open group lesson is therefore a firm part YAMAHA's teaching programme.
The teaching programmes and highly trained teaching staff
of the YAMAHA music schools are designed to provide versatile and comprehensive musical encouragement for children from as young as 4 months. Seamless follow-up teaching programmes and methods, which are carefully designed
for communication appropriate to the particular age group,
ensure that optimum use is made of a child's current development window. Young people and adults can realise their
musical dreams in every musical genre.
WE HAVE BEEN SPECIALISING IN LEARNING
THROUGH FUN FOR DECADES!
THE YAMAHA MUSIC SCHOOL
MUSIC SCHOOL
MUSIC SCHOOL
An overview of the lesson range:
4 5
Rock/Pop Instrumental Program:
The YAMAHA Popular Music School
Even pop stars had to start somewhere! In our "YAMAHA
Popular Music School" we practice with professional
playbacks right from the start. This helps us to understand the musical relationships better, and it's also
great fun. We have courses for: Drums, E-Bass, E-Guitar,
Keyboard, Saxophone, Flute and Vocals.
For more informations see:
www.yamaha-musikschule.de
For pre-school children:
Robbie: Introducing infants from
4-18 months to music
Toddlers: Musical hour of playing
for children in the age
of 1,5-4 years
Music Wonderland: Musical early education for
children in the age of 4-6 years
Hörbie and Tönchen: Musical elementary education for
pre-school aged children,
including a keyboard instrument
Instrumental programmes:
Magic Flute: For children from 6 up, young
persons and adults
Fun with six strings: Guitar group lessons for children
from 6 up, young persons and adults
Keys 4 Music: Piano group lessons for
young persons from
10 up and adults
Fun Key Kids: Piano- or keyboard group
lessons for children in
the age of 6-10 years
Fun Key: Keyboard group lessons
for young persons from
10 up and adults
YAMAHA Keyboards - for everybody.
6 7
KEYBOARDSKEYBOARDS
Yamaha Keyboards
Yamaha Keyboards
Keyboards for beginner:
Make music = make happy + move the soul + train the brain!
With YAMAHA's keyboards for beginners, starting to play
is as easy as 1+1.
Welcome to the world of music-making pleasure!
Even the smallest YAMAHA beginner's keyboard offers
comprehensive help and learning functions, making it perfect company in music lessons and great fun at home.
From the beginning, YAMAHA keyboards are easy to use
and a pleasure to play.
Portable Grand Pianos:
"...wish I could play piano...or keyboards..."
Why not both? The super versatile Portable Grand Piano
Series lets you mix and play classical piano and modern
keyboard whenever you like.
The key spread meets a piano-man's demands and is
still portable; the built in music data-base takes care of
organising repertoire; the sound, functionality and
design are all in state of the art YAMAHA quality.
Home Keyboards:
The new middle class YAMAHA keyboard offers excellent
sound-quality and first class musical accompaniment sty-
les. It's easy to work with and a pleasure to play.
And it comes with YAMAHA's Mega-Voice-Technology and
Super-Articulation-Voices: two features, previously exclusive to the top class Tyros2, which put new life into whatever you play!
You can read your notes and lyrics from the built in display
and go online with your instrument to download the latest
songs.
You want to record your performance, vocals and all? No
problem! The Audio to USB function records to any USB
storage device as a *.wav file.
Entertainer Keyboards:
The YAMAHA top class keyboard is a state of the art
instrument for home, studio and stage.
It features YAMAHA's unique Mega-Voice-Technology,
Super-Articulation-Voices and hundreds of new referencequality accompaniment styles. More than that: the
Musicfinder's hundreds of entries keep your repertoire
organised; the notes and lyrics display supports your performance and the built in hard-disc recorder records it
whenever you want, including your own timbres and effects you made using *.wav files and including extra voices
produced using the Vocal-Harmony feature.
That's all you'll ever need to get a head start as a semi-pro
or full-time entertainer.
ENTRY-LEVEL KEYBOARDSENTRY-LEVEL KEYBOARDS
PSR-E213
Entry-level keyboards
8
PSR-E213
PSR-E313
Entry-level keyboards
The new entry-modell with many new
voices and a stereo piano sound.
The entry keyboard for the ambitious
player - now including music database!
9
•
61 standard keys
•
375 Voices
incl. 361 XG-Lite Voices
+ 12 Drum Kits
•
Stereo Piano
•
100 Styles
•
32 notes polyphony
•
Reverb
•
LC-Display
•
MIDI In/Out
•
W 93 / H 13 / D 35 cm
PSR-E313
NEW!
NEW!
NEW!
NEW!
•
61 keys with touch response
•
482 Voices
incl. 361 XG-Lite Voices
+ 12 Drum Kits
+ Sound Effect Kit
•
106 Styles
•
32 notes polyphony
•
Style File Play (SFF) and
Standard MIDI File (SMF)
•
Reverb
•
Music database
•
Backlit Display
•
MIDI In/Out
•
W 95 / H 11 / D 35 cm
PSR-E403
PSR-450
Entry-level keyboards
10
PSR-E403
PSR-450
Entry-level keyboards
Entry level keyboard for
pro level performance
Great sound and playability
are the focus.
•
61 keys with touch response •504 Voices, incl. 360
XG Lite-Voices• 3 Cool! Voices • 5 Sweet! Voices
•
155 Styles •32 notes polyphony•30 Preset-Songs
•
61 keys with touch response •627 Voices, incl. 360
XG Lite-Voices• 8 Sweet! Voices • 6 Cool! Voice • 1 Live!
Voice•140 Styles with 2 Variations •Stereo piano
•
32 notes polyphony •LC-Display •Music Database with
227 entries •DSP •Chorus •Hall •Dual & split sounds
•
One Touch Setting •Bass reflex •Floppy disk drive
•
Pitch bend wheel •MIDI In/Out• W 95 / H 17 / D 39 cm
11
ENTRY-LEVEL KEYBOARDSENTRY-LEVEL KEYBOARDS
•
Music Database with 256 entries •Pitch Bend
•
2 Assign Knobs for filter and effects •Master EQ
•
Performance Assistant •LC-Display •Flash ROM •Preset
Master EQ •USB to host• W 95 / H 15 cm / D 39
EZ-200
Light Keyboard
Digital Drum
•
61 keys with touch response
•
Lightguide (keys)
•
375 Sounds incl. 361 XG-Lite Voices
+ 12 Drum Kits
•
100 Styles
•
32 notes polyphony
•
Stereo Piano
•
MIDI In/Out
And the lights will go on!
DD-65
•
8 touch-sensitive drum pads
•
4 big, 4 small Pads
•
254 Voices
•
32 notes polyphony
•
Stereo Drum
•
Reverb
•
Master EQ (On/Off)
•
Hand Percussion Button
•
Click (Metronom)
•
MIDI In/Out
The new digital drum in
a new stylish design.
Overview new entries
PSR-E213
PSR-E313
PSR-E403
PSR-450
EZ-200
Incl. Sticks, Hi-Hat Pedal and Bass Drum Pedal!
PSR-E213 PSR-E313 PSR-E403 PSR-450 EZ-200
Keyboard light weighted Lightguide
Keys 61 61 61 61 61
Touch Response - • • • •
Styles 100 106 155 140 100
Voices 375 482 504 627 375
Polyphony 32 32 32 32 32
LC-Display • • • • •
Music Database - 100 256 227 -
Performance Assistent - - • • -
Master EQ - - • - -
Pitch-Bend Wheel - - • • -
MIDI In/Out / USB to host •/- •/- -/• •/- •/-
Floppy Disk Drive – - - • -
Measure(W x H x D)cm 93x13x35 95x11x35 95x15x39 95x17x39 95x11x35
Weight 4,4 kg 4,4 kg 7 kg 8,5 kg 4,4 kg
12 13
DIGITAL DRUMS
ENTRY-LEVEL KEYBOARDS
NEW!
NEW!
NEW!
NEW!
NEW!
NEW!
NEW!
NEW!
NEW!
NEW!
DGX-220
NP30/S
DGX-220
NP30/S
The new portable piano smooths
the way for the coming painist.
14 15
PORTABLE GRAND PIANOSPORTABLE GRAND PIANOS
New entry Portable Grand Piano
with high features
•
76 keys
with touch response
•
489 Voices
incl. 360 XG-Voices
•
3 Cool! Voices
•
5 Sweet! Voices
•
150 Styles
•
32 notes polyphony
•
30 Preset Songs
•
Music Database
with 267 entries
•
Pitch Bend Wheel
•
Performance Assistent
•
LC-Display
•
6-track song recorder
•
Flash-ROM
•
Preset Master EQ
•
USB to host
•
W 112 / H 41 / D 14 cm
•
optional: stand LW16
(page 30)
Portable Grand Pianos
Portable Grand Pianos
•
76 keys
(3 level graded touch)
•
10 Voices
•
32 notes polyphony
•
Reverb
•
Metronome
•
Half Pedal
•
MIDI In/Out
•
W 124 / H 10 / D 26 cm
NEW!
NEW!
DGX-520
DGX-520
16 17
Portable Grand Pianos
PORTABLE GRAND PIANOSPORTABLE GRAND PIANOS
Portable Grand Pianos
Portable Grand Piano
with
88 keys
DGX-620
Portable Grand Piano with
new GHS keys
•
GHS keyboard with 88 weighted keys
•
Touch response
•
500 Voices
incl. 360 XL-Lite Voices
•
3 Live! Voices
•
5 Cool! Voices
•
8 Sweet! Voices
•
150 Styles
•
32 notes polyphony
•
30 Preset Songs
•
Music Database
with 267 entries
•
Pitch Bend
•
Performance Assistant
•
Grafic-Display for lyrics and score
•
6-track -recorder
•
Flash-ROM
•
Preset Master EQ
•
USB to device
•
USB to host
•
W 140 / H 77 (incl. stand) / D 49 cm
•
88 keys with touch response
•
500 Voices incl. 360 XL-Lite Voices
•
3 Live! Voices
•
5 Cool! Voices
•
8 Sweet! Voices
•
150 Styles
•
32 notes polyphony
•
30 Preset Songs
•
Music Database with 267 entrie
•
Pitch Bend
•
Performance Assistant
•
Grafic-Display for lyrics and score
•
6-track -recorder
•
Flash ROM
•
Preset Master EQ
•
USB to device
•
USB to host
•
W 135 / H 78 (incl. stand) / D 45 cm
Incl. wooden stand nature +
power adapter and sustain-pedal
Incl. wooden stand black +
power adapter and sustain-pedal
NP30/S DGX-220 DGX-520 DGX-620
Keyboard light weighted weighted GHS
Keys 76 76 8 8 88
Touch Response • • • •
Styles - 150 150 150
Voices 10 489 500 500
Polyphony 32 32 32 32
LC-Display/Grafic-Display - • / - • / • • / •
Lyrics/Score - - • •
Music Database - 267 267 267
Performance Assistant - • • •
Master EQ - • • •
Pitch-Bend Wheel - • • •
USB to Host - • • •
USB to Device - - • •
Measure(W x H x D)cm 124x10x26 112x14x41 135x15x45 140x15x49
Weight 5,4 kg 8,3 kg 11 kg 18 kg
Power adapter PA-5 optional PA-5 optional PA-5 inkl. PA-5 inkl.
NP30/S
DGX-520
DGX-620
ORIENTAL KEYBOARDS
18 19
PORTABLE GRAND PIANOS
•
61 keys with touch response •523 voices (incl. 35 oriental
voices) •135 styles (incl. 83 oriental styles)•32 notes polyphony •Reverb •Chorus •Dual•Split •Echo/Harmony
•
Y.E.S.
5
•
MIDI In/Out • W 95 / H 13 / D 37 cm
•
61 standard-sized keys •134 voices •100 styles
•
2 notes polyphony •Reverb •Y.E.S. 5•LC-Display
•
Stereo-Piano •1 One Touch Setting for each style •Bass
port •MIDI In/Out • W 95 / D 35 / H 11 cm
The PSR-A300 is the first oriental keyboard with
professional features that offers unequalled
opportunities in this price range.
The new oriental keyboard based on PSR-S700
with bulit in 43 oriental voices, 168 normal and
146 oriental styles, 6 oriental drum kits and
oriental scale tuning.
PSR-A300
PSR-OR700
PSR-R200
The new entry keyboard with unbelievable sound,
with russian panel
Specification as PSR-S700 but without IDC.
DGX-220
Overview - Portable Grand Pianos
Oriental Keyboards
NEW!
NEW!
NEW!
NEW!
20 21
PSR-S500
The favourable
entry to the mid-class.
•
61 keys with touch response
•
659 voices incl. 361 XG-Lite
•
16 Cool! Voices
•
6 Live! Voices
•
10 Sweet! Voices
•
150 Styles with 4 Variations
•
32 notes polyphony
•
Graphic
-Display
•
Lyrics + score function
•
Music Database with 500 entries
•
4 One Touch Settings per styles
•
USB to host
•
USB to device
•
Pitch bend wheel
•
W 95 / D 40 / H 13 cm
PSR-S500
PSR-S700
PSR-S700
Explore fantastic
Keyboard worlds with
the new Mega-Voice-Technology!
•
61 keys with touch response
•
813 voices incl. XG
•
18 Cool! Voices
•
14 Live! Voices
•
10 Mega! Voices
•
11 Sweet! Voices
•
205 Styles
each with 4 Variations+ OTS
•
96 notes polyphony
•
Graphic-Display monochrome
•
Lyrics and score function
•
LAN-connection for IDC
•
Pitch bend- / Modulation wheel
•
MIDI In/Out
•
USB to host
•
USB to device
•
W 100 / H 15 / D 43 cm
HOME KEYBOARDSHOME KEYBOARDS
Home Keyboards
Home Keyboards
The straight
way into the
world wide web
NEW!
NEW!
WHAT IS IDC INTERNET
DIRECT
CONNECTION?
IDC is a feature,
that allows the keyboard user to access
the internet directly
from his instrument
to download MIDI
files.
PSR-S900
PSR-S900
Rising on the power of inovative
features: The new star of
Keyboard middle heaven.
•
61 keys with touch response
•
891 voices incl. XG
•
23 Super Articulation Voices
•
26 Cool! Voices
•
20 Live! Voices
•
15 Mega! Voices
•
22 Sweet! Voices
•
305 Styles with 4 Variations + OTS
•
128 notes polyphony
•
Colour Graphic-Display
•
Lyrics + score function
•
Pitch bend / Modulations wheel
•
MIDI In/Out
•
Microphone input
•
Vocal Harmony
•
USB Audio-Recorder
•
LAN-connection for IDC
•
Text-Viewer
•
USB to host
•
USB to device
•
W 100 / H 15 / D 43 cm
Home Keyboards
HOME KEYBOARDSHOME KEYBOARDS
22 23
PSR-S500 PSR-S700 PSR-S900
Keyboard light weighted
Keys 61 61 61
Touch Response • • •
Styles 150 205 305
Mega Voice / Style - • •
One-Touch Setting 4 4 4
Voices 659 813 891
Polyphony 32 96 128
Grafic-Display/Colour •/- •/- •/•
Lyrics-/Score • • •
Music-Database/-Finder •/- -/• -/•
Performance Assistent - • •
Master EQ - • •
Pitch-Bend Wheel • • •
Modulations Wheel - • •
LAN Port / IDC - • •
Text Viewer - - •
Video Out - - •
USB Audio Rec. (WAV) - - •
USB to Host • • •
USB to Device • • •
Measure(W x H x D)cm 95x13x40 100x15x43 100x15x43
PSR-S700
PSR-S900
PSR-S500
Overview - Home Keyboards
NEW!
NEW!
NEW!
NEW!
NEW!
NEW!
Loading...
