Page 1

POWERED LOUDSPEAKER POWERED SUBWOOFER

Reference Manual

Page 2

Introduction 3

DZR(-D), DXS-XLF(-D) Series Product Lineup .................................................... 3

Main Features ...................................................................................................... 3

Main Functions ....................................................................................................4

Structure of Manuals............................................................................................ 4

Functions 5

Full-range Speaker (Rear) ................................................................................... 5

Subwoofer (Rear)................................................................................................. 5

Rear Panel Full range Subwoofer ............................................................... 6

Power Section .............................................................................................. 7

Dante Section Dante model ......................................................................8

Panel Operations 9

Basic Operations ................................................................................................. 9

HOME Screen and Its Functions ....................................................................... 10

Alert Messages..................................................................................................12

Initialization ........................................................................................................ 12

Screen Functions 13

Screen Structure................................................................................................13

PRESET Screen ................................................................................................. 13

RECALL...................................................................................................... 14

STORE........................................................................................................ 14

CLEAR........................................................................................................ 14

TITLE .......................................................................................................... 14

PROTECT ................................................................................................... 15

HPF Screen Full range ................................................................................. 15

LPF Screen Subwoofer ................................................................................ 15

D-CONTOUR Screen Full range .................................................................. 15

D-XSUB Screen Subwoofer ......................................................................... 16

EQ Screen .........................................................................................................16

DELAY Screen ................................................................................................... 16

CARDIOID Screen Subwoofer ..................................................................... 17

ROUTER Screen................................................................................................ 18

UTILITY Screen ................................................................................................. 19

PANEL SETUP............................................................................................ 19

PANEL LOCK ............................................................................................. 20

DEVICE BACKUP....................................................................................... 23

DANTE SETUP Dante model ................................................................... 23

NETWORK Dante model ......................................................................... 25

DEVICE INFORMATION ............................................................................. 26

INITIALIZE.................................................................................................. 26

LOG ........................................................................................................... 27

UPDATE FIRMWARE.................................................................................. 27

Muting from an External Device Dante model ............................................. 28

About Dante Dante model 29

Dante Network System ...................................................................................... 29

Dante Settings ................................................................................................... 30

Connecting to Dante Devices ........................................................................... 30

Integration with Yamaha Digital Mixers ............................................................. 31

Reference 33

Precautions when Using the USB Terminal....................................................... 33

Using USB Flash Drives .................................................................................... 33

Function Tree..................................................................................................... 34

Message List ..................................................................................................... 37

Patch Correspondence Chart when Using Quick Config ................................. 39

Troubleshooting................................................................................................. 40

Dante-related Terms.......................................................................................... 41

Specifications .................................................................................................... 42

Dimensions........................................................................................................ 46

Block Diagram................................................................................................... 52

Index.................................................................................................................. 53

Page 3

Introduction

DZR(-D), DXS-XLF(-D) Series Product Lineup

Main Features

Thank you for purchasing the Yamaha DZR(-D) series POWERED LOUDSPEAKER and DXS-XLF(-D) series POWERED SUBWOOFER. (See the series product lineup below.) These products are designed for live performance, sound reinforcement and fixed installation sound system applications. This manual provides instructions on installation, setup, configuring of the connections, and detailed operation of these speakers for installers, constructors, or general users familiar with speakers. Please read this manual together with the Owner’s Manual that comes packaged with the product to get full use out of this product and its functions.

* Unless specifically noted otherwise, illustrations in this manual are based on the DZR12-D and DXS18XLF-D. * In this manual the Dante model (-D) series is referred to as DZR-D, DXS-XLF-D.

Typ e Standard Model Dante Model (-D)

3-way 15" DZR315 DZR315-D

Full Range

Subwoofer

2-way 15" DZR15 DZR15-D

2-way 12" DZR12 DZR12-D

2-way 10" DZR10 DZR10-D

18" DXS18XLF DXS18XLF-D

15" DXS15XLF DXS15XLF-D

• Strong plywood cabinet features a high output Class D amplifier. Full-range models feature powerful sound pressure capability in a lightweight package by using neodymium magnets.

• Optimized pairing of a highly durable speaker unit with a fixed directional horn, for sparkling highs with punchy and powerful bass.

• Full-range models feature an FIR filter for crossover and frequency adjustments. Low latency for DSP and AD/DA, thanks to 96 kHz sampling rate.

• LCD screen for loading presets, and for making precise graphical adjustments to EQ, delay, and routings. Easily transfer settings by using a USB flash drive.

• Dante models (-D) support the transmission of digital audio and remote control via a Dante network.

• 2-way models support use on a stand or use as a floor monitor. Rotation of the horn, several rigging points, and optional brackets allow a variety of installation methods.

Page 4

Introduction

Main Functions

Structure of Manuals

 Processing

Incorporates new FIR filter technology in addition to signal processing know-how built up through years of product development experience in order to deliver the next level in sound quality. The DSP, AD/DA sampling frequency (Fs) is 96 kHz.

 Display See page 6

The display enables users to set a broad range of functions using simple commands while finely tuning EQ, delay, routing and other settings using a graphical interface. Includes a back light for adjusting luminance.

 Presets See pages11, 13

A set of recall-only factory presets (one to three) and savable user presets (eight) are available. Select the desired preset from the factory presets when using the DZR and DXS-XLF series product together.

 Network See pages8, 29

Dante-compatible models not only allow for audio input/output across a Dante network, they also enable users to control and monitor this product on a computer, etc.

 Integration with Yamaha digital mixers See page 31

Connect a Dante-compatible model with a TF series, CL series or QL series device over a network to monitor patching and device status without a Dante Controller. Yamaha provides a unique system solution centered around its digital mixers.

 Other useful functions

• Safeguard functions are in place to prevent malfunction. Alert messages and other notifications are used to inform users when an issue occurs. See page 12

• Comes equipped with a panel lock feature preventing operational errors and tampering. Connect a USB flash drive with the PIN code saved to it to temporarily unlock the panel. Remove the stick to lock the panel again. See page 20

• Internal data can be stored on a USB flash drive, making it easy to copy the same settings to a replacement device. See page 23

• Owner’s Manual (included with the product)

This manual describes product functions and basic product operation.

• Reference Manual (this manual)

This manual describes settings and operations in detail.

Page 5

Functions

Full-range Speaker (Rear)

Bottom

FRONT

7°

0°

7°

Pole socket

Subwoofer (Rear)

35 mm diameter

M20 screw

NOTE

wqe

q Tiltable pole socket

This mount has two pole sockets. You can choose the angle of the speaker so that it is positioned horizontal to the floor or tilting down toward the floor by 7 degrees. Compatible with commercially available speaker stands and speaker poles of 35 mm diameter. (These sockets are not available on the DZR315(-D).)

w Screw holes for U-bracket

For installing with the separately sold U-brackets. (These sockets are not available on the DZR315(-D).)

e Screw holes for eye bolts

For installing the speaker using eye bolts. The screw holes for eye bolts go through the cabinet wall.

r Dual pole sockets

Compatible with commercially available speaker poles of 35 mm diameter and M20 screw.

When using a pole socket to install a speaker, observe the following conditions for safety.

Subwoofer Speaker to be installed

DXS18XLF(-D)

DXS15XLF(-D)

Weight: 26 kg or less Height: 76.0 cm or less (DZR15(-D) or smaller)

Weight: 22 kg or less Height: 64.5 cm or less (DZR12(-D) or smaller)

Weight: 18 kg or less Height: 53.7 cm or less (DZR10(-D) or smaller)

Length of

the pole

104 cm or less

82 cm or less

104 cm or less

t Feet cups

When stacking multiple speakers, align the rubber feet of the upper speaker to the feet cups of the lower one.

y Wheel mounting screws

For installing the separately sold Yamaha SPW-1 wheels. If you are not using wheels, do not remove these screws. Otherwise, the leakage of air will affect sound quality.

• For more information about installing wheels and related precautions, refer to the corresponding manual for the wheels.

• Do not install any item other than the SPW-1 wheels.

Page 6

Functions

Rear Panel

Full range Subwoofer

Available only on Dante models. See the “Dante Sec-

tion” (page 8).

NOTE

q USB terminal

Connect a USB flash drive to save/load internal memory on this product. USB flash drives are also used to perform firmware updates. You can also save a PIN code used to lock the panel to a USB flash drive, and then connect the USB flash drive to temporarily unlock the panel. For more information about using the USB terminal and USB flash drives, see “Precautions when Using

the USB Terminal” and “Using USB Flash Drives” (page 33).

w [LIMIT] indicator

Lights red when the limiter for protecting the speaker is active. If the indicator remains on, lower the level of the input signal. This flashes together with the e [POWER] indicator when a serious system error is detected at product startup. This indicator will turn off automatically when BLACKOUT is ON (see page 20).

e [POWER] indicator

Lights green when the power is on. Flashes when the protection function is active and the output is muted. (“MUTED” appears on the HOME screen in the display at this time.) This flashes together with the w [LIMIT] indicator when a serious system error is detected at product startup.

r Display

Shows the settings for various functions. Users can finely tune EQ, delay, routing and other settings using a graphical interface. The display includes a back light, enabling users to adjust the brightness and contrast of the display, configure BLACKOUT (automatic off) settings (see page 20).

• The display will darken after one minute of panel inactivity and turn off after 25 minutes of inactivity to protect the display, even if the BLACKOUT (page 20) setting is off. Either press a key on the rear panel or press the main knob to wake the display.

• The display will start flashing when the Identify function is used on a Dante Controller or Dante devices (each of the TF, CL, and QL series, etc.).

t Main knob

Turn the knob to move the cursor that appears in the display and change parameter values. Press the knob to execute a setting.

The [POWER] indicator will not automatically turn off even if BLACKOUT (page 20) is ON.

y [ ] (Back) key

Press this button to return to the previous screen. Press and hold this button for at least one second to return to the HOME screen.

u [LEVEL] controls

Adjust the level that is input to the [INPUT] jacks.

Page 7

Functions

DZR(-D) Series DXS-XLF(-D) Series

NOTE

i [INPUT] jacks

Combo jacks for line level input. Accept both XLR and phone plugs. This enables you to mix levels for two input signals separately. Not compatible with mic input.

o [THRU/OUTPUT] jacks

XLR output jacks. Switch the DZR(-D) series channel 2 and DXS-XLF(-D) series channel 1 and 2 output signals using the !0 [THRU/DSP OUT] switch. The DZR(D) series channel 1 output is fixed to [THRU].

!0 [THRU/DSP OUT] switch

This switch determines whether signals output from the output jack are passed through the input jack as is ([THRU]), or whether the signal receives DSP processing before input ([DSP OUT]). When this is set to [DSP OUT], you can set the output signal. For more information about signals that can be output, see “ROUTER Screen” – “e OUTPUT” (page 19).

!1 Vents

A cooling fan is installed on the exhaust side. The fan will start once the amp exceeds a certain temperature. Fan speed is controlled based on the temperature of the amp and power source. When the speaker is in use, make sure that all of the vents are free from obstruction.

 Power Section

!2 [AC IN] jack

Connect the supplied AC power cord here. First, connect the power cord to this product, then insert the power cord plug into the AC outlet. When removing the power cord, perform this procedure in reverse order. While the internal power supply functions within the 100V – 240V range, the limiter may not work properly if a different voltage to that shown is used, since the maximum output and limiter setting are optimized according to the voltage used. Do not use a voltage setting other than that shown.

WARNING

Use only the supplied power cord/plug.

!3 Power switch

Turns the power supply on [–] or off [ ].

WARNING

A small amount of current flows even when the power switch is off. If you intend to not use the speaker for a long time, be sure to unplug the power cord from the outlet.

• Depending on the timing when the power switch is turned on/off, it might take up to 15 seconds for the power to turn on.

• When using multiple devices, we recommend turning each device on one at a time. If multiple devices are turned on at the same time, the devices might not start up correctly due to a voltage drop at the power supply.

CAUTION

Be sure to turn the power off before connecting or disconnecting the power cord.

Insert the power cord fully until it is locked by the latching lock mechanism (V-Lock). Press the V-Lock latch to disconnect the power cord.

Page 8

Functions

Dante model

NOTE

 Dante Section

!4 Dante jacks

These are etherCON jacks for connecting with Dante devices and computers. The two jacks are primary connectors that can be linked in a daisy chain connection (see page 29). This connection cannot be used in a redundant (secondary) network.

Use STP (Shielded Twisted Pair) cables to prevent electromagnetic interference. Make sure that the metal parts of the plugs are electrically connected to the STP cable shield by conductive tape or comparable means.

!5!6 !6

!4 !7

!7 [SYNC] indicator

Lights steady or flashes green according to the Dante communication status, as shown in the following table. This indicator will turn off automatically when BLACKOUT is ON (see page 20).

Steady

Continuously flashes

Periodically flashes one time

Periodically flashes two times

Periodically flashes three times

Operating normally as a clock slave on the Dante network

Operating normally as a clock master on the Dante network

Incorrect DANTE Fs setting

Dante network cable not connected

Incorrect Dante network connection

!5 [LINK] indicator

Shows the communication status of Dante jacks. Lights green when an Ethernet cable is connected correctly to the Dante jack. This indicator will turn off automatically when BLACKOUT is ON (see page 20).

This indicator may flash for 30 seconds when the power is turned on when connected to a network device.

!6 [1G] indicator

This indicator will light up in orange when the Dante network is functioning as a Giga-bit Ethernet. This indicator will turn off automatically when BLACKOUT is ON (see page 20).

Page 9

Panel Operations

Basic Operations

Main knob

The main knob is used to move the cursor and adjust parameter values. Parameters with a broad range of values can be adjusted more quickly based on the speed at which the main knob is turned.

[ ] (Back) key

Press this key to move up one level from the current level, or to return to the previous screen. Press and hold this button for at least one second to return to the HOME screen.

1. Turn the main knob to select an item. The selected item is highlighted.

The > on the right indicates that there are deeper menu items.

3. Repeat steps 1 and 2 until you reach the edit parameter screen.

Edit selectable parameters

Turn the main knob to select. The value will be updated and the sound will change when you press the main knob to execute the change.

Edit continuous parameters

Turn the main knob to change the parameter value. The value is changed in real time as you turn the knob.

2. Press the main knob to execute a selection.

4. For selectable parameters, press the main knob to execute the edited value.

Press the [ ] (Back) key to return to the previous screen (press and hold for at least one second to return to the HOME screen).

Page 10

The HOME screen will appear when the power switch is turned on.

HOME Screen and Its Functions

!0 !1 !2

w e

!3 !4

!0 !1

w e

!3 !4

 DZR-D series

Dante model

 DXS-XLF-D series

 DZR series

Standard model

 DXS-XLF series

!0 !1

!3 !4

!0 !1 !2

!3 !4

NOTE

Refer to the HOME screen for the model in use.

Panel Operations

• Even while displaying other than the HOME screen, if you do not operate the panel for 5 minutes, the screen automatically returns to the HOME screen.

• The above screens of the Dante models are examples when setting LABEL of q to "DZR12-D" and "DXS18XLF-D," respectively.

Page 11

Panel Operations

Dante model

Full range

Subwoofer

Full range

Subwoofer

Dante model

q UNIT ID, LABEL

Shows the UNIT ID and label assigned so that DZR-D or DXS-XLF-D series devices on the Dante network can be recognized. When the DANTE MODE (page 23) is set to Quick Config, this will show as “QC,” and the name of the selected TF series output channel. Go to the DANTE SETUP screen to configure and display Dante settings.

w Input Meter

Shows analog input signal levels. On Dante models this will appear as ANA. Clipped input signals will light up at the top when clipping occurs.

e Input Meter (DNT)

Shows digital input signal (Dante) levels. Clipped input signals will light up at the top when clipping occurs.

r MASTER Level

Sets and displays output levels. (Unit: dB)

t SP Output Meter

Shows output levels. Sigma () clipping at the top will light up when clipping occurs within a channel.

y Protection (THERMAL, MUTED)

Appears when safeguard functions have been activated. “THERMAL” is shown when a high temperature is detected in the amplifier, and output levels are reduced. If operating conditions further deteriorate, this will change to “MUTED,” and the output signal will be muted.

u PRESET

Shows the preset number and title of the set preset. This enables you to save, load and change audio settings. (E symbol) will appear when parameters have been changed.

i HPF

Sets and displays the high-pass filter frequency.

o D-CONTOUR

Sets and display the D-CONTOUR mode.

D-XSUB

Sets and displays the D-XSUB mode.

!0 EQ

Shows whether the equalizer (6 Band EQ) is on or off. You can configure EQ settings while checking the frequency response characteristics.

!1 DELAY

Sets and displays the delay.

!2 CARDIOID

Sets and displays the cardioid mode.

!3 ROUTER

Configures the routing of the audio signal.

!4 UTILITY

Sets and displays the device operating settings.

• PANEL SETUP: Sets the brightness and contrast of the display, and automatic turn off settings for the display and indicators.

• PANEL LOCK: Configures panel lock settings, and saves and loads PIN codes.

• DEVICE BACKUP: Saves and loads settings data.

• DANTE SETUP : Sets and displays Dante-related settings.

• NETWORK : Sets and displays network-related settings.

• DEVICE INFORMATION: Shows device status, and device-specific information.

• INITIALIZE: Resets to the default settings.

• LOG : Shows recorded logs and saves logs to a USB flash drive.

• UPDATE FIRMWARE: Updates the firmware for the device, and the Dante module.

LPF

Sets and displays the low-pass filter frequency and the POLARITY. An indication Ø will appear when POLARITY is set to INVERTED.

Page 12

When an error occurs, an alert message will appear on the display.

Alert Messages

E.g.)

Initialization

NOTE

For more details on each error message and notification, see the “Message List”

(page37).

Panel Operations

5. When the [POWER] indicator starts flashing and the screen shown below

appears, release the main knob.

To cancel the initialization process at this point, turn the power switch off.

6. Press the main knob.

This product will be restarted automatically.

You can reset to the default settings for this product in the following two ways.

 Initializing to the default settings by navigating from the HOME

screen and selecting UTILITY → INITIALIZE

(See page 26.)

 Initializing to the default settings when you have forgotten your

PIN code, etc.

Use the following method to reset to the default settings if you are unable to select INITIALIZE on the UTILITY screen because of a forgotten PIN code, etc.

1. Disconnect all the cables except the power cord.

WARNING

A sudden loud sound might occur when initializing is completed, if an audio signal is present.

2. Turn the power switch off.

3. After the [POWER] indicator turns off, turn the power switch back on.

4. While pressing and holding the main knob, turn the main knob at least five clicks

in a counter-clockwise direction within two seconds of the [POWER] indicator light coming on. (Keep pressing and holding the main knob.)

If the procedure is not finished properly in time, the model name logo will appear. In this case, repeat the procedure again from step 2.

7. Wait until the HOME screen appears.

NOTICE

Turning the power switch off before the HOME screen appears could cause a malfunction.

Page 13

Screen Functions

Screen Structure

To the EQ screen (page 16)

To the DELAY screen (page 16)

To the CARDIOID screen

(page 17)

To the ROUTER screen (page 18)

To the UTILITY screen (page 19)

Subwoofer

To the DANTE SETUP screen

(page 23)

Dante model

To the PRESET screen (page 13)

To the HPF screen (page 15)

To the LPF screen (page 15)

Full range

Subwoofer

To the D-CONTOUR screen

(page 15)

To the D-XSUB screen

(page 16)

Full range

Subwoofer

PRESET Screen

(factory default settings)

Full range

(factory default settings)

Subwoofer

Key mark :

Indicates a protected preset

: Indicates the currently

selected preset

NOTE

Turn the main knob to move the cursor to the desired menu item and select it to move to the corresponding screen.

As presets which is sound related setting, allows you to recall/store/clear the settings, edit titles, and set the protection of the settings. The recall-only presets are always protected. An (E symbol) (page 11) will appear on the HOME screen when parameters have been changed.

q w

q INITIAL DATA

Resets to the default settings. Recall only.

w Factory presets

When using DZR and DXS-XLF series models in combination with one another, you can optimize the crossover frequency, levels and delay by loading presets for each model name. Recall only.

The presets are equipped assuming that one DZR and one DXS-XLF having the same signal routes are set up. When analog inputs are used together with Dante inputs, or when several DZR and DXS-XLF are set up, each setting must be adjusted manually.

e User preset list

Save up to eight settings. It allows you to recall/store/clear the settings, edit titles, and set protection for the settings.

Page 14

Screen Functions

E.g.) The selected preset title:

PRESET1

E.g.) Title: PRESET1

Cursor during position selection Cursor during character selection

Turn the main knob to select the preset, and press the main knob to execute it. A screen showing a list of possible actions will appear.

 RECALL

Loads a saved preset. The preset number and title of the preset selected will appear.

 STORE

Adds a title to the current setting configurations and stores it to a preset.

 CLEAR

Deletes a stored preset.

Note that protected presets, and the currently selected preset cannot be deleted.

 TITLE

Edits the title of a stored preset.

Turn the main knob to select the position to edit text, and then press the main knob to enter text input mode. When in text input mode, turn the main knob to select the character you wish to enter, and then press the main knob to enter the character. Move the cursor to BS and press the main knob to delete the last character entered. When in text input mode, press the [ ] (Back) key to resume position selection. During position selection, select OK to execute the title, or CANCEL to cancel the title changes. Note that titles of protected presets cannot be edited.

Turn the main knob to select the position to enter text, and then press the main knob to enter text input mode. When in text input mode, turn the main knob to select the character you wish to enter, and then press the main knob to enter the character. Move the cursor to BS and press the main knob to delete the last character entered. When in text input mode, press the [ ] (Back) key to resume position selection. During position selection, select OK to execute the title, or CANCEL to cancel the text entry. Note that protected presets cannot be overwritten.

Page 15

 PROTECT

NOTE

HPF Screen

Full range

LPF Screen

Subwoofer

D-CONTOUR Screen

Full range

Turns protected for a stored preset on/off.

Set this to ON to prevent presets from being overwritten (STORE), deleted (CLEAR) or preset title changes (TITLE). A key mark (page 13) will appear on the left side of the preset title on the PRESET screen.

Screen Functions

Sets the LPF (low-pass filter) cutoff frequency and the polarity.

q w

q LPF

Select the LPF cutoff frequency.

Be aware that using RESTORE FROM USB (page 23, “ DEVICE BACKUP” w) will overwrite presets even if they are protected.

Sets the HPF (high-pass filter) cutoff frequency. Select OFF or set a specific frequency.

w POLARITY

Select the polarity. When set to INVERTED, a Ø symbol will appear on the HOME screen.

Switches a D-CONTOUR preset. Set to the optimal frequency response characteristics according to the application.

• OFF (NORMAL): Turns D-CONTOUR off. This is a general-purpose frequency response characteristic setting.

• FOH/MAIN: Boosts the high and low frequency components so that the frequency response characteristic is suitable for main speaker use. The boost amount is automatically adjusted to provide well-balanced, clear audio based on the volume.

• MONITOR: Reduces the low frequency range, which could otherwise tend to be boomy if the speaker is set directly on the floor, providing vital clarity when using as a floor monitor. This reduces latency and changes the phase characteristics.

Page 16

Switches a D-XSUB preset.

D-XSUB Screen

Subwoofer

EQ Screen

DELAY Screen

NOTE

Set to the optimal frequency response characteristics according to the application and genre of music.

• OFF (NORMAL): Turns D-XSUB off. This is a general-purpose frequency response characteristic setting.

• BOOST: Boosts the frequency band accentuating a sense of punch in the audio.

• XTEND LF (extended LF): Extends playback frequencies to cover lower frequencies.

Screen Functions

e Bands A – F

Select the desired band whose parameters you wish to check. Press the main knob on the selected band to have the cursor move to the parameter display.

r Parameter Display

Shows the parameters of each band. Move the cursor to a parameter name and press the main knob to start setting parameter values. Press the [ ] (Back) key to return the cursor to the parameter name. Press the [ ] (Back) key again to return to the band selection screen.

Sets the delay time. This is used to compensate for the distance between speakers, etc. Set this by time or distance.

q w

Adjusts the frequency response characteristics for all speakers. Adjust the 6 Band EQ parameters to your liking as well the intended application.

q ON/OFF

Turns the 6 Band EQ on/off. When off, only the outline of EQ characteristics will be shown on the display.

w FLAT

Sets the amount of gain on all bands to 0 dB.

e r

q ON/OFF

Turns the delay on/off.

w TIME [ms]

Sets the delay time in milliseconds.

e DISTANCE [m, ft]

Sets the delay time by physical distance (in meters or in feet).

The three delay time indications change in conjunction. The last edited unit will appear on the HOME screen.

Page 17

Sets the cardioid mode.

CARDIOID Screen

Subwoofer

NOTE

From the mixer

To the full-range

speakers

Stage

Audience

From the mixer

Stage

Audience

Change settings based on the number of speakers in use and their orientation. Set this to OMNI (FRONT) when not using the cardioid mode.

For more information about setting up cardioid mode, see the Owner’s Manual.

 Screen when two subwoofers are placed side by side

Screen Functions

 Screen when three subwoofers are placed side by side

Page 18

Sets routing, Dante input levels, analog output levels and output levels to a Dante net-

ROUTER Screen

NOTE

 DZR-D series

Dante model

 DXS-XLF-D series

 DZR series

Standard model

 DXS-XLF series

Dante model

work.

Screen Functions

q Routing

Configure the routing of the audio signal. Check the input source (INPUT) and output destination (OUTPUT), and set at the intersecting points. By default, signals from all input jacks will be output from the speakers. Routing cannot be performed for shaded areas on the screen.

• On Dante models, the analog signal sent to the DZR-D or DXS-XLF-D can be output to the Dante network and set as the input source for the mixer.

* Dante output settings are supported by firmware V1.2.2 or later and Dante module firmware

4.1.6.7-4.1.6.5-1.1.0 or later.

• For more information about the signal flow in routing, see the “Block Diagram” (page52).

w INPUT

Sets two Dante input levels, sensitivity and the degree of delay compensation.

• DNT. IN1 LVL: Sets Dante input level D1. It can be set in 0.5 dB increments.

• DNT. IN2 LVL: Sets Dante input level D2. It can be set in 0.5 dB increments.

• DNT. SENS. (DANTE SENSITIVITY): Sets the input sensitivity for the digital signal sent from the Dante network to the amplifier. The input sensitivity set acts as the clip level for the speakers. Set this to either -14 dBFS (default setting) or -6 dBFS. When the [LEVEL] control is in the center position (0 dB), set this to -14 dBFS to ensure proper balance with the input level from the Dante network and the analog input level from devices having a maximum output of +24 dBu (which include many of Yamaha digital mixers). Make fine adjustment with DNT. IN1 LVL/ DNT. IN2 LVL.

• ALIGNMENT (DELAY ALIGNMENT): Set this to ON, and set a delay here to com- pensate for the time lag between the analog input and the Dante input. Note that the appropriate delay setting will vary depending on the Dante settings configured and the combination of connected devices. As the Dante input typically lags behind, this delay setting will apply to the analog input. When you set the ALIGNMENT, refer to the “Route Latency Values” (page44).

Page 19

e OUTPUT

 DZR-D series

Dante model

 DXS-XLF-D series

 DZR series

Standard model

 DXS-XLF series

UTILITY Screen

Dante model Standard model

Screen after scrolling downwards

Sets the output level. Output levels can be set in 0.5 dB increments.

Screen Functions

The UTILITY screen is used to configure device settings, and save and load settings data to and from a USB flash drive.

• ANA. OUT1 LVL: Sets analog output level A1 (page 7 o, channel 1 output level).

• ANA. OUT2 LVL: Sets analog output level A2 (page 7 o, channel 2 output level).

• DNT. OUT1 LVL: Sets Dante output level D1.

• DNT. OUT2 LVL: Sets Dante output level D2.

 PANEL SETUP

Sets the rear panel display method.

q BRIGHTNESS

Sets the brightness of the back light of the display. This setting can be set in 10 steps from 1 to 10.

Page 20

Screen Functions

NOTE

e r

NOTE

w CONTRAST

Sets the contrast of the display. This setting can be set in 16 steps from 1 to 16. Configure your display according to the operating environment so that it is easy to see. A higher contrast is recommended when viewing the display from above, such as with a subwoofer. Note, however, that setting the contrast too high may make the display harder to see directly from the front.

e BLACKOUT

The BLACKOUT setting is used to automatically turn the display and indicators off when the panel is not in use. Turn this on to have the display and indicators automatically turn off as follows.

• After five seconds of panel inactivity: The display darkens slightly.

• After 15 seconds of panel inactivity: The display/indicators except the [POWER] indicator will turn off (see the table below).

Either press a key on the rear panel or press the main knob to wake the display/turn on the indicators.

Display/indicator Automatically turns off when BLACKOUT is on

[POWER] indicator (page 6 e) Does not automatically turn off Display (page 6 r) Off [LIMIT] indicator (page 6 w) Off [LINK] indicator (page 8 !5) Off [1G] indicator (page 8 !6) Off [SYNC] indicator (page 8 !7) Off

 PANEL LOCK

Locks the operating panel to prevent inadvertent operating errors. When doing so, users will be able to set a four-digit PIN code identifying the user. Also, the PIN code can be saved to and loaded from a USB flash drive.

q PANEL LOCK

Sets the panel lock.

• OFF: Panel lock is off.

• PA RT IA L: Locks off operations appearing on the display panel. MASTER Level settings can still be configured.

• ALL: Disables all actions except to remove the panel lock.

• The [POWER] indicator will always remain on, even when the BLACKOUT setting is turned on.

• The display will darken after one minute of panel inactivity and turn off after 25 minutes of inactivity to protect the display, even if the BLACKOUT setting is off.

• For more information on releasing the panel lock, see “Removing a Panel Lock” (page 22).

• If a PIN code has been set, the PIN code must be entered even when the setting of the panel lock is changed from OFF to PARTIAL or ALL.

w PIN CODE

Sets a PIN code (any four digits) for the panel lock. Once a PIN code has been set, the PIN code must be entered to release the panel lock.

• If you have forgotten the PIN code, you can still release the panel lock by initializing this product. See “Initializing to the default settings when you have forgotten your PIN code, etc.”

(page 12).

• The default PIN code setting is 0000. You will not be required to enter the PIN code to release the panel lock when the PIN code is set to 0000.

Page 21

Screen Functions

NOTE

 Setting PIN Codes

1. Open the PIN code input screen.

Navigate from the HOME screen to select UTILITY → PANEL LOCK → PIN CODE. The cursor is on the first digit of the PIN code.

2. Turn the main knob to select a number, and then press the main knob to enter

it.

Once entered, the cursor will move to the next digit.

3. Enter subsequent numbers in the same way.

e SAVE TO USB

Saves the PIN code to a USB flash drive. Connect the USB flash drive to the USB terminal, and then select SAVE TO USB. Select YES on the confirmation screen. If “SAVE SUCCEEDED” appears, the process is complete. Select OK to return to the previous screen.

• If the PIN code saved to a USB flash drive matches the PIN code saved to this product, the panel lock will be released while the USB flash drive is connected to this product. (This is useful for avoiding the regular lock release process when you wish to temporarily release the lock to change a parameter, for example.)

• For more details on potential alert messages, see the “Message List” (page37).

r LOAD FROM USB

Loads the PIN code saved to a USB flash drive. You can set the same PIN code for multiple DZR, DXS-XLF series devices. Connect the USB flash drive to the USB terminal, and then select LOAD FROM USB. Select YES on the confirmation screen. If “LOAD SUCCEEDED” appears, the process is complete. Select OK to return to the previous screen.

• Retrieving a PIN code from a USB flash drive when the panel lock is turned off will set the panel lock setting to PARTIAL.

• For more details on potential alert messages, see the “Message List” (page37).

You can correct the PIN code while it is being input by pressing the [ ] (Back) key and selecting the desired digit with the main knob.

4. Press the main knob to execute OK.

This will determine the PIN code.

If the PIN code is set to 0000, the PIN code has not been set. In this state, PIN code input is not needed to set or release the panel lock.

Page 22

Screen Functions

E.g.) PIN code: 1234

NOTE

 Removing a Panel Lock

If a PIN code has not been set

The default PIN code setting is 0000. You will not be required to enter the PIN code when the PIN code is set to 0000. When the panel controls are operated while the panel is locked, the following message appears in the display.

• To permanently remove the panel lock: Turn the main knob to select OK, and then press the main knob to execute it.

• To temporarily remove the panel lock: Turn the main knob to select TEMP, and then press the main knob to execute it. Note that turning the power back on or panel inactivity for five minutes will restore the panel lock setting.

If a PIN code has been set

When the panel controls are operated while the panel is locked, the following message appears in the display.

Enter the four-digit PIN code you set. Turn the main knob to select a number, and then press the main knob to enter it.

• To permanently remove the panel lock: Turn the main knob to select OK, and then press the main knob to execute it.

You will not be required to enter the PIN code when the PIN code is set to 0000 (the default setting).

If the PIN code has been saved to a USB flash drive

Connect the USB flash drive the PIN code has been saved to this product. The panel lock will be removed for the duration that the USB flash drive is connected to this product. Remove the USB flash drive to restore the panel lock. (For more information about saving PIN codes, see “UTILITY Screen” – “ PANEL LOCK” – “e SAVE TO USB”; page 21).

Page 23

Screen Functions

q w

NOTE

Dante model

Screen after scrolling downwards

NOTE

 DEVICE BACKUP

Saves and loads the user settings to and from a USB flash drive. Use this function when you want to set multiple DZR, DXS-XLF series devices to the same setting configuration, or change to another DZR, DXS-XLF series device while retaining the same settings.

q SAVE TO USB

Saves settings data to a USB flash drive. Connect the USB flash drive to the USB terminal, and then select SAVE TO USB and enter the file name. File names can be up to 16 characters long. Only half-width alphanumeric characters and some symbols are supported. Turn the main knob to select the position to enter text, and then press the main knob to enter text input mode. When in text input mode, turn the main knob to select a character, and then press the main knob to enter the character.

For more details on potential alert messages, see the “Message List” (page37).

w RESTORE FROM USB

Loads settings files stored to a USB flash drive. Connect the USB flash drive to the USB terminal, and then select RESTORE FROM USB. A list of files stored to the USB flash drive will appear on the screen. Select the file you want to load. Up to 20 files can be displayed on the screen.

• Audio will be muted temporarily when settings are changed to avoid noise being output.

• For more details on potential alert messages, see the “Message List” (page37).

• When changing file names on your computer, make sure the new file name is 16 characters or less and only uses half-width alphanumeric characters or the following symbols: !, #, $, %, &, \', (, ), +, ,, -, ., =, @, [, ], ^, _, `, {, }, (space). Note that you will not be able to load a file that does not follow these naming conventions.

• Be aware that using RESTORE FROM USB will overwrite presets even if they are protected (see page 15, “ PROTECT”).

 DANTE SETUP

This screen is used to configure Dante settings and display the Dante network status.

q w e r t y

q MODE (DANTE MODE)

Sets the mode used when connecting this product to the Dante network.

• STANDARD: Select this when not using the TF series Quick Config function.

• Quick Config: Select this when using the TF series Quick Config function.

If there are multiple TF series devices on the Dante network, only select the TF series “with OUTPUT” check box for one device. Patches will not be applied correctly if multiple devices are selected.

Page 24

Screen Functions

NOTE

When the MODE is set to Quick ConfigPATCH screen

NOTE

*PATCH

Set the MODE to Quick Config to display the PATCH screen and add PATCH item. Select the TF series output channel to be patched to this product on the PATCH screen. For more details, see “Patch Correspondence Chart when Using Quick Con-

fig” (page39).

It will take several seconds for patches to actually change after changing the setting of PATCH.

w UNIT ID

Sets an ID assigned so that DZR-D or DXS-XLF-D series devices on the Dante network can be recognized individually. The UNIT ID set will be applied after restarting this product. Avoid using the same ID for the same model devices on the same network.

• The setting range is 01 to FE (hexadecimal range).

• This is the same UNIT ID as that on NETWORK (page 25). A UNIT ID can be changed from either menu location.

Turn the main knob to select the character you wish to enter, and then press the main knob to enter the character. When the restart confirmation screen appears, select YES. The setting will be applied after restarting this product.

e LABEL

Sets a label for this product. Set a label that clearly identifies this product to make it easier to find from the Dante Controller, etc.

• Label names can contain a maximum of 12 characters.

• Only half-width alphanumeric characters and some symbols are supported.

• The label set will form part of the Device Label.

If a LABEL is not set (default setting):

Y###-Yamaha-xxxxxxxxxx-******

#: UNIT ID x: Model name (maximum of 10 characters) ******: Last six digits of the MAC address

If a LABEL has been set:

Y###-zzzzzzzzzzzz-******

#: UNIT ID z: LABEL (maximum of 12 characters) ******: Last six digits of the MAC address

r Fs (DANTE Fs)

Sets the sampling frequency for Dante input/output. Select a sampling frequency from

44.1 kHz, 48 kHz, 88.2 kHz or 96 kHz.

t LATENCY (DANTE LATENCY)

Sets the signal latency (Dante latency) for transmitting and receiving over the Dante network. Select a latency amount from 1 ms, 2 ms or 5 ms.

The Dante latency must correspond to the connection method used and the size of the network.

1ms

2ms This setting is suited to Giga-bit Ethernet networks that include 100 Mbps nodes

5ms This setting can be safely applied to just about any network environment

The 1 ms setting may not allow enough time for data transmission on systems with 10 or more Dante devices, including network switches, etc., connected in a daisy chain, resulting in audio skips. If skipping occurs, increase the latency time setting.

Use this setting when signals pass through up to 10 devices, including network switches

If two devices with different latency settings are patched together, the slower latency time setting will be applied.

The UNIT ID set will appear on the HOME screen.

Page 25

Screen Functions

Dante model

NOTE

y LOCK

Shows the Dante Device Lock status. Use the Dante Controller to configure settings. “LOCKED” will appear when the lock setting is applied, and “UNLOCKED” will appear when the lock is released. When locked, you will not be able to change Dante settings.

u DDM (Dante Domain Manager)

This shows the status of any DDM servers on the network, and domain participation status.

• STATE: Shows the domain participation status.

- DOMAIN: Participating in a domain.

- DISCONNECTED: Participating in a domain, but not connected to a DDM server.

- UNMANAGED: Not participating in a domain.

• LOCA L: Shows the access status for Dante settings (including DANTE PATCH) configured for this product currently in use.

- READ WRITE: Changes permitted.

- READ ONLY: Changes not permitted.

 NETWORK

Configures network settings used to control this product with an external device. The settings changed will be applied after restarting this product.

q w e r t y

w IP SET. (IP SETTING)

Select how the IP address is set.

• UNIT ID: Set to 192.168.0.### (### = UNIT ID).

• DHCP: Sets an IP address assigned from the DHCP server. The IP address, NET- MASK and GATEWAY will be retrieved automatically. If the DHCP server is not on the network, a link-local address (169.254.xxx.xxx) will be used.

• STATIC IP: Sets an IP address manually.

When using this product while connected to a CL series or QL series device, set a different address using the same subnet as the IP address set on the FOR DEVICE CONTROL on the mixer.

e IP ADR.

Shows the IP address. Use this to set the IP address if STATIC IP is selected as the IP SET. setting.

r NETMASK

Shows the subnet mask. Use this to set the subnet mask if STATIC IP is selected as the IP SET. setting.

t GATEWAY

Shows the default gateway. Use this to set the default gateway if STATIC IP is selected as the IP SET. setting.

y MAC

Shows the MAC address. This address is shown for reference and cannot be changed.

q UNIT ID

Sets an ID assigned so that DZR-D or DXS-XLF-D series devices on the Dante network can be recognized individually. See “UTILITY Screen” – “ DANTE SETUP” – “w UNIT ID” (page 24).

Page 26

Screen Functions

Dante model Standard model

Screen after scrolling downwards

 DEVICE INFORMATION

Shows device status, and device-specific information.

q w

q THERMAL

Shows the amplifier temperature in five stages. The limiter will be activated based on the temperature detected.

q w

 INITIALIZE

Initializes the data of all settings.

WARNING

Disconnect all the cables except the power cord before this operation. A sudden loud sound might occur when initializing is completed, if an audio signal is present.

For initializing, when the screen shown below appears, press the main knob. When a confirmation screen appears, select YES to restart this product. If you cancel the initialization procedure, press the [ ] (Back) key when the screen shown below appears.

NOTICE

The HOME screen will appear after restarting, indicating that the initialization procedure is complete. Turning the power switch off before the HOME screen appears could cause a malfunction.

w VERSION

• FIRMWARE: Shows the firmware version.

• Dante: Shows three Dante versions.

e SERIAL

Shows the serial number.

Page 27

Screen Functions

q w

 LOG

Shows internal action logs, and saves them to a USB flash drive.

q LOG LIST

Shows all internally recorded action logs. Logs will be shown in the order that events occur. Time is displayed in “NNNN HHH:MM:SS” format. This indicates that the event occurred HHH (hours) MM (minutes) SS (seconds) after the NNNNth time the power was turned on. The column on the right shows the alert ID.

Turn the main knob to select an event, and then press the main knob to execute and display the DETAIL VIEW screen. For more details on each event message, see the

“Message List” (page37).

 UPDATE FIRMWARE

Use a USB flash drive to update this product firmware and Dante module firmware.

Download the latest update files from the Yamaha Pro Audio website.

http://www.yamahaproaudio.com/

Save the update files to the USB flash drive. Connect the USB flash drive to the USB terminal, and then select UPDATE FIRMWARE.

Select YES on the confirmation screen to restart this product.

When restarting, the following confirmation screen will appear.

w SAVE TO USB

Saves the latest action log to a USB flash drive. This function is provided for user support.

• To update: Press the main knob. The update progress will be shown as a percentage (%). When the update is complete, this product will start normally. Do not disconnect the USB flash drive while the update is in progress.

• To cancel the update: Press the [ ] (Back) key.

Page 28

You can mute speaker audio using an external device (such as the TF, CL, and QL

Muting from an External Device

Dante model

series). When muted, “MUTED from REMOTE” will appear on the HOME screen. This device can only be used to unmute muted audio. Turning the power off and on while audio is muted from an external device will cancel the mute setting.

 Unmuting audio muted from an external device

1. Turn the main knob to select “MUTED from REMOTE”.

2. Press the main knob to select this and unmute the audio.

For more information about muting audio with an external device, see the Owner’s Manual supplied with the external device in use.

Screen Functions

Page 29

About Dante

Dante model

Dante Network System

NOTE

 Connections

There are two ways to connect the DZR-D and DXS-XLF-D to a Dante network. Both

 Outline of Dante

The DZR-D and DXS-XLF-D feature not only analog input/output signals, but also Dante technology to transmit digital audio signals. Dante is a network audio protocol developed by Audinate. It is designed to deliver multi-channel audio signals at various sampling frequencies and bit rates as well as device control signals in the same network, over a Gigabit Ethernet (GbE) network.

Visit the Audinate website for more information on Dante.

http://www.audinate.com/

More information on Dante is also posted on the Yamaha Pro Audio website.

http://www.yamahaproaudio.com/

Please do not use the EEE function (*) of network switches in a Dante network. Although power management should be negotiated automatically in switches that support EEE, some switches do not perform the negotiation properly. This may cause EEE to be enabled in Dante networks when it is not appropriate, resulting in poor synchronization performance and occasional dropouts. Therefore we strongly recommend that:

• If you use managed switches, ensure that they allow EEE to be disabled. Make sure that EEE is disabled on all ports used for real-time Dante traffic.

• If you use unmanaged switches, make sure to not use network switches that support the EEE function, since EEE operation cannot be disabled in these switches.

devices can be used in combination with one another.

Daisy Chain Network

A daisy chain is a wiring scheme in which multiple devices are connected together in sequence. In this way, networking is simple and requires no network switches. If you connect a large number of devices, you must set a higher latency value to avoid audio glitches that could be caused by an increased delay in signal transfer among the devices. Also, if a connection is broken in a daisy chain network, the signal flow is interrupted at that point and no signal will be transferred beyond that point.

Star Network

In a star network, each device is connected to a central network switch. Using a GbEcompatible network switch enables you to configure a wide-band, large-scale network. We recommend a network switch that features various functions to control and monitor the network (such as QoS, the ability to assign priority to data flows—for example, clock synchronization or audio transmission on certain circuits). DZR-D and DXS-XLF-D cannot be used in a redundant (secondary) network because the two Dante jacks of DZR-D and DXS-XLF-D are primary connectors.

* EEE (Energy Efficient Ethernet) is a technology that reduces switch power consumption during

periods of low network traffic. It is also known as Green Ethernet and IEEE802.3az.

Page 30

System setup example

Configuration with Dante Models

Limit the number of Dante devices to within 10 units, including switches, in a single daisy chain. If the number of Dante devices exceeds 10 units, communication latency within the network will increase and the audio might drop out. To prevent this, set a higher Dante Latency value (page 24, t LATENCY), or use an L2 switch (that supports Giga-bit Ethernet) to create branches in the network.

(L)

MONI1 MONI2 MONI3 MONI4

I/O rack

Side (L) FOH (L) FOH (R) Side (R)

(R)

L2 switch

Digital mixer

Ethernet cable for Dante

NOTE

Dante Settings

Connecting to Dante Devices

This example uses only DZR-D and DXS-XLF-D series speakers.

Screen Functions

When using the DZR-D and DXS-XLF-D in a connection to a Dante network, use the DANTE SETUP screen to configure various Dante settings. Navigate from the HOME screen and select UTILITY → DANTE SETUP to open the DANTE SETUP screen. To open the DANTE SETUP screen, you can also navigate from the HOME screen and select UNIT ID, LABEL (the upper left of the HOME screen). See

page 13.

DANTE SETUP screen

* For more information about each function, see “Screen Functions” – “UTILITY Screen” –

“ DANTE SETUP” (page 23).

It is important to setup a well-balanced system that leverages the advantages offered by both daisy chain and star network connections.

 About Dante Controller

Dante Controller is a software application that allows configuration and audio routing of Dante networks. Use this application if you plan to connect to Dante devices other than Yamaha digital mixers compatible to integration with DZR-D and DXS-XLF-D, or apply more advanced settings.

Please download the latest version of the Dante Controller application from the website listed below.

http://www.yamahaproaudio.com/

To run Dante Controller, the computer must feature a GbE (Giga-bit Ethernet)-compatible connector.

In Dante Controller, you can apply the following main settings.

• I/O patch settings on the Routing tab in Network View

• Clock master settings on the Clock Status tab in Network View

• Sampling rate settings on the Device Config tab in Device View

Page 31

I/O patch settings and other Dante-related settings cannot be changed if Dante Device Lock has

NOTE

Integration with Yamaha Digital Mixers

NOTE

been enabled on the Dante Controller. To change these settings, first remove the Dante Device Lock on the Dante Controller.

 Dante Controller Settings

Start Dante Controller and open Network View. Set the audio routing between Dante devices in Network View. All Dante devices on the network will appear on this screen. Click the cells [+] where transmitting and receiving devices intersect to show all the channels, and then establish audio routes. A green check box icon will appear when a route has been set.

Screen Functions

The DZR-D and DXS-XLF-D can be patched with Yamaha digital mixers (each of the TF, CL, or QL series) without using Dante Controller. In such cases, the number of the devices which can be patched is 24 at the maximum, including other Dante devices. When patching with more than 25 devices, use Dante Controller.

If each of the TF, CL, or QL series devices being patched has a clock rate of 48 kHz, the DANTE Fs setting of DZR-D and DXS-XLF-D must also be set to 48 kHz. Even when this is set to 48 kHz, the DZR-D and DXS-XLF-D will still run at 96 kHz internally using an internal SRC (Sampling Rate Converter). Use Dante Controller when establishing a complex system that requires advanced settings, or large-scale systems.

The following functions are available when using the DZR-D and DXS-XLF-D in combination.

 TF series

• Automatic patch settings by Quick Config function (See page 23, “DANTE SETUP”

• Major status monitoring

• Mute control

• Identify function

For more details, see the Dante Controller User’s Manual. Also, for more information about the Dante channels assigned to the output signals from the transmitting devices (digital mixers, etc.), see the relevant manuals for the transmitting devices.

 CL series, QL series

• Patch settings from the mixer screen (Set a different UNIT ID for the DZR-D and DXSXLF-D devices connected.)

• Major status monitoring

• Major parameters control

• Identify function

If the digital mixer cannot recognize the DZR-D or DXS-XLF-D, and the DZR-D or DXS-XLF-D does not appear on the digital mixer screen, check the digital mixer firmware version.

Page 32

The Yamaha digital mixers compatible to integration with DZR-D and DXS-XLF-D, and supported firmware versions are as follows.

Digital mixer Supported firmware version

TF series V3.6 and later

CL series V5.1 and later

QL series V5.1 and later

To use the abovementioned functions, you will need to update to the supported firmware version.

For more information on the use of Yamaha digital mixers, see the relevant manual for the model in use.

http://www.yamahaproaudio.com/

Screen Functions

Page 33

Reference

Precautions when Using the USB Terminal

Using USB Flash Drives

 Compatible USB devices

• Use a USB flash drive. You will not be able to use any other USB device (USB hub, mouse, computer keyboard, etc.) when connected.

• This product is compatible with USB1.1 to 2.0 USB flash drives (however, not all USB flash drives have been verified for compatibility).

NOTICE

The USB terminal is rated at a maximum of 5V/500mA. An alert message will appear on the display when attempting to connect a device that requires a current exceeding 500mA, and the power supply will be stopped.

 Connecting a USB flash drive

• Do not insert or remove a USB flash drive while a message appears on the screen. Doing so may prevent the product from functioning properly, or may damage the USB flash drive itself and the data contained within.

• Wait several seconds before reinserting a USB flash drive after removing it.

NOTICE

When using a USB extension cable, use a cable that is no longer than 1 m.

 USB flash drive format

Use a USB flash drive formatted to FAT32 or FAT16. Format the flash drive on your computer. Note that USB flash drives formatted on other devices may not work properly with this product.

 Preventing accidental data erasure

Your USB flash drive may come with a write-protect function to prevent accidental data erasure. Use the write-protect feature to prevent important data from being overwritten. Conversely, when saving data, check that the USB flash drive’s write-protect function is off before using the flash drive.

 Turning the power off when connecting the USB flash drive

Make sure the system is not accessing the USB flash drive (check that there are no messages on the display) before turning the power off. Failure to do so may damage the USB flash drive itself and the data contained within.

Page 34

Reference

Function Tree

Function Category Settings Default value Setting range

METER Input Meter Shows analog input signal levels. (On

Input Meter (DNT) Shows digital input signal (Dante) lev-

UNIT ID Shows the ID assigned so that DZR-D

LABEL Shows the label. — 12 characters 11, 24 MASTER Level Sets the output level. (Unit: dB) 0.0dB -∞, -80 to +10.0dB   11 SP Output Meter Shows the output level. — -∞ to 0dBFS   11 Protection

(THERMAL, MUTED) MUTED from REMOTE Mutes audio from an external device. Off — 28

Function Category Parameter Default value Setting range

TUNING HPF OFF, 60Hz, 70Hz, 80Hz, 90Hz, 100Hz,

LPF 60Hz, 70Hz, 80Hz, 90Hz, 100Hz,

D-CONTOUR OFF (NORMAL), FOH/MAIN, MONI-

D-XSUB OFF (NORMAL), BOOST, XTEND LF OFF (NORMAL) OFF (NORMAL), BOOST, XTEND LF 11, 16 EQ (6 bands) ON, OFF ON ON, OFF 

DELAY ON, OFF ON ON, OFF 

CARDIOID OMNI (FRONT), CARDIO-2 (REAR),

Dante models this will appear as ANA.)

els.

or DXS-XLF-D series devices on the Dante network can be recognized.

Appears when safeguard functions have been activated.

110Hz, 120Hz

110Hz, 120Hz POLARITY NORMAL NORMAL, INVERTED 

TOR

BYPS <Bypass> ON ON, OFF  (×6)  (×6)  (×6)  (×6) FREQ <Frequency> <Each Band> 20.0Hz to 20.0kHz  (×6)  (×6)  (×6)  (×6) GAIN 0.0 -10.0 to +10.0dB  (×6)  (×6)  (×6)  (×6) Q 2.00 0.7 to 10.0  (×6)  (×6)  (×6)  (×6)

TYPE PEQ

ms 0.0ms 0.0 to 140.0ms  m 0.00m 0.00 to 48.10m  ft 0.0ft 0.0 to 157.8ft 

CARDIO-3 (REAR)

— -∞ to 0dBFS  (×2)  (×2)  (×2)  (×2) 11

— -∞ to 0dBFS  (×2)  (×2) 11

01 01 to FE 

Hidden THERMAL, MUTED 11

OFF 60Hz to 120Hz  11, 15

120Hz 60Hz to 120Hz 

OFF (NORMAL)

OMNI (FRONT)

OFF (NORMAL), FOH/MAIN,

MONITOR

PEQ, LO SHELF 6dB,

LO SHELF 12dB, HI SHELF 6dB,

HI SHELF 12dB, HPF, LPF

OMNI (FRONT), CARDIO-2 (REAR),

CARDIO-3 (REAR)

Full range Subwoofer

Standard Dante Standard Dante

Full range Subwoofer

Standard Dante Standard Dante

 11, 15

 (×6)  (×6)  (×6)  (×6)

11, 17

Page

number

11, 24,

Page

number

11, 15

11, 16

Page 35

Reference

Function Category Parameter Default value Setting range

ROUTER Routing SP OUT (On), — (Off) 

A1 <Analog OUTPUT 1> (On), — (Off)  A2 <Analog OUTPUT 2> (On), — (Off)  D1 <Dante OUTPUT 1> (On), — (Off)  D2 <Dante OUTPUT 2> (On), — (Off) 

INPUT DNT. IN1 LVL

<Dante Input Level 1> DNT. IN2 LVL

<Dante Input Level 2> DNT. SENS.

(DANTE SENSITIVITY)

ALIGNMENT (DELAY ALIGNMENT)

OUTPUT ANA. OUT1 LVL

<Analog Output Level 1> ANA. OUT2 LVL

<Analog Output Level 2> DNT. OUT1 LVL

<Dante Output Level 1> DNT. OUT2 LVL

UTILITY PANEL SETUP BRIGHTNESS 6 1 to 10 19

CONTRAST

BLACKOUT OFF OFF, ON 

PANEL LOCK PANEL LOCK OFF OFF, ON 

PIN CODE 0000 Four-digit numeral  SAVE TO USB — —  LOAD FROM USB — — 

DEVICE BACKUP SAVE TO USB — — 

RESTORE FROM USB — — 

+1.0dB -∞, -80.0 to +10.0dB 

-14dBFS -14dBFS, -6dBFS 

OFF OFF, ON 

1.70ms 0.00ms to 20.00ms 

0.0dB -∞, -80.0 to +10.0dB 

0.0dB -∞, -80.0 to +10.0dB 

0.0dB -∞, -80.0 to +10.0dB 

Full range: 5,

Subwoofer: 12

1 to 16 

Full range Subwoofer

Standard Dante Standard Dante

Page

number

Page 36

Reference

Function Category Parameter Default value Setting range

UTILITY DANTE SETUP MODE (DANTE MODE) STANDARD STANDARD, Quick Config 23

NETWORK UNIT ID 01 01 to FE 11, 25

DEVECE INFORMATION THERMAL <For display only> — — 

INITIALIZE — — — 26 LOG LOG LIST — — 

UPDATE FIRMWARE — — — 27

PRESET 0: INITIAL DATA

A to C(*): Factory presets 1 to 8: User presets

* Number values may change

depending on the model in use.

*PATCH <If the MODE is set to Quick Config>

UNIT ID 01 01 to FE 

LABEL —

Fs (DANTE Fs) 48kHz 44.1kHz, 48kHz, 88.2kHz, 96kHz  LATENCY (DANTE LATENCY) 1ms 1ms, 2ms, 5ms  LOCK <For display only> UNLOCKED UNLOCKED, LOCKED  DDM — — — — — —

STATE <For display only>

LOCAL <For display only> READ ONLY READ WRITE, READ ONLY 

IP SET. (IP SETTING) DHCP UNIT ID, DHCP, STATIC IP  IP ADR. — IPv4  NETMASK — IPv4  GATEWAY — IPv4  MAC <For display only> — — 

VERSION — — ————

FIRMWARE <For display only> — —  Dante <For display only> — — 

SERIAL <For display only> — — 

SAVE TO USB — — 

RECALL — —  STORE — —  CLEAR — —  TITLE — — 

PROTECT — — 15

NO ASSIGN

DISCONNECTED

See the “Patch Correspondence Chart

when Using Quick Config” (page39)

12 characters

(alphanumeric characters, -)

DOMAIN, DISCONNECTED,

UNMANAGED

Full range Subwoofer

Standard Dante Standard Dante

24



Page

number

11, 24

Page 37

Number Message Symptom Countermeasure

Message List

01–11 SYSTEM ERROR

12 CURRENT MEMORY ERROR

13 PRESET MEMORY ERROR

17 DUPLICATE IP ADDRESS A duplicate IP address is in use. Set the IP address to one that does not overlap with another IP address.

20 OUTPUT CURRENT OVER

22 AMP TEMP TOO HIGH step1[*] An output limiter has been applied due to

23 AMP TEMP TOO HIGH step2[*]

25 AMP TEMP TOO HIGH step3[*]

27 POWER SUPPLY TEMP TOO HIGH[*]

34 AMP PROTECT (LIMIT)[*]

35 HF/OVER TEMP PROTECT (DOWN)

50 USB: COMPATIBLE DEVICES NOT FOUND Compatible USB flash drive not connected.

51 USB: NO FILE SYSTEM

52 USB: FILE NOT FOUND

53 USB: ILLEGAL FILE Invalid file used. Replace the invalid file with a compatible file and try again.

54 USB: INCOMPATIBLE FORMAT Incompatible file format used. Replace the invalid file with a compatible file and try again.

55 USB: I/O ERROR Cannot read/write USB flash drive properly.

SYSTEM ERROR

The product does not start up properly.

Circuit protection has been activated due to excess amplifier output current.

excess temperature detected in the amplifier. (*: HF or LF)

Audio output has been muted due to excess temperature detected in the amplifier. (*: HF or LF)

A limiter was applied due to an abnormally high temperature detected in the power supply unit. (*: HF or LF)

An output limiter has been applied due to an abnormality detected in the amplifier. (*: HF or LF)

Audio output has been muted due to an abnormality detected in the amplifier.

The USB flash drive’s file system is inaccessible.

The relevant file cannot be found on the USB flash drive.

Turn the power off and wait at least six seconds before turning the power back on. If the problem persists, try initializing this product. If this still does not resolve the problem, please contact your Yamaha dealer.

The product may be faulty. Please contact your Yamaha dealer.

Either reduce the output level, or wait for the heat to subside before using again. Alternatively, keep the rear panel out of direct sunlight, and ensure that the area around the rear panel is well ventilated.

Wait for the heat to subside before using again. Alternatively, keep the rear panel out of direct sunlight, and ensure that the area around the rear panel is well ventilated.

Continuing use may cause the power supply unit to malfunction. Reduce the output level before using again.

Wait for the heat to subside before using again. The product may be faulty if symptoms persist even after cooling down. Please contact your Yamaha dealer.

Only use supported USB flash drives. For a list of USB flash drives tested to work, visit the Yamaha Pro Audio website (http://www.yamahaproaudio.com/).

Use a USB flash drive that has been properly formatted to FAT32 or FAT16.

Check that the file has been saved properly to the USB flash drive, and then try again.

Check that the USB flash drive in use works properly on a computer or some other device. Use a USB flash drive that has been tested to work. For a list of USB flash drives tested to work, visit the Yamaha Pro Audio website (http://www.yamahaproaudio.com/). If this still does not resolve the problem, please contact your Yamaha dealer.

Reference

Page 38

Number Message Symptom Countermeasure

56 USB: STORAGE FULL! Insufficient USB flash drive space. Use a USB flash drive with a sufficient amount of available space.

58 USB: LOAD ERROR

59 USB: OVER CURRENT

65 INCOMPATIBLE DATA LOADED

70 POWER TURNED ON The power turned on. —

71 POWER TURNED OFF The power turned off. —

72 SHORT INTERRUPTION

73 HOST FIRMWARE UPDATE COMPLETED Firmware update completed. —

74 PANEL UNLOCKED Removed panel lock. —

77 PRESET RECALLED[*] Recalled preset. (*: Preset number) —

78 PRESET STORED[*] Stored preset. (*: Preset number) —

79 PRESET CLEARED[*] Cleared preset. (*: Preset number) —

80 BACKUP DATA LOADED

81 PIN CODE LOADED Loaded PIN code from the USB flash drive. —

82 PIN CODE CHANGED PIN code has been changed. —

83 WRONG PIN CODE Wrong PIN code entered. —

85 Dante FIRMWARE UPDATE COMPLETED Successfully updated the Dante firmware. —

91 —

ALL DATA INITIALIZED

An error occurred while loading a file from a USB flash drive. Internal data corruption may have occurred within this product.

The power supply stopped due to excess current flowing to the USB terminal.

Changed incompatible data contained within the loaded file to the default settings.

Restarted system after performing a shutdown due to an instantaneous power failure.

Loaded settings data from the USB flash drive using RESTORE FROM USB on the DEVICE BACKUP screen.

All parameter settings reset back to their default values.

Please try again. A message appears on the display while the USB flash drive is being accessed. Do not remove the USB flash drive while the message appears.

Remove the USB flash drive from the USB terminal, and then turn on the power again.

—

Connect to a stable power source.

—

Reference

Page 39

Reference

Patch Correspondence Chart when Using Quick Config

DZR-D, DXS-XLF-D TF series

Option on the PATCH

screen

(see page 24)

NO ASSIGN

ST L

ST R

SUB

MTRX1

MTRX2

MTRX3

MTRX4

AUX 1

AUX 2

AUX 3

AUX 4

AUX 5

AUX 6

AUX 7

AUX 8

ROUTER

INPUT

D1 —

D2 —

D1 ST L

D2 —

D1 ST R

D2 —

D1 SUB

D2 —

D1 MTRX1

D2 —

D1 MTRX2

D2 —

D1 MTRX3

D2 —

D1 MTRX4

D2 —

D1 AUX 1

D2 —

D1 AUX 2

D2 —

D1 AUX 3

D2 —

D1 AUX 4

D2 —

D1 AUX 5

D2 —

D1 AUX 6

D2 —

D1 AUX 7

D2 —

D1 AUX 8

D2 —

Output channel

DZR-D, DXS-XLF-D TF series

Option on the PATCH

screen

(see page 24)

AUX 9

AUX10

AUX11

AUX12

AUX13

AUX14

AUX15

AUX16

AUX17

AUX18

AUX19

AUX20

MONI L

MONI R

ST L/R

ST L/SUB

ROUTER

INPUT

D1 AUX 9

D2 —

D1 AUX10

D2 —

D1 AUX11

D2 —

D1 AUX12

D2 —

D1 AUX13

D2 —

D1 AUX14

D2 —

D1 AUX15

D2 —

D1 AUX16

D2 —

D1 AUX17

D2 —

D1 AUX18

D2 —

D1 AUX19

D2 —

D1 AUX20

D2 —

D1 MONI L

D2 —

D1 MONI R

D2 —

D1 ST L

D2 ST R

D1 ST L

D2 SUB

Output channel

DZR-D, DXS-XLF-D TF series

Option on the PATCH

screen

(see page 24)

ST R/SUB

MTRX1/2

MTRX3/4

AUX 1/2

AUX 3/4

AUX 5/6

AUX 7/8

AUX 9/10

AUX11/12

AUX13/14

AUX15/16

AUX17/18

AUX19/20

MONI L/R

ROUTER

INPUT

D1 ST R

D2 SUB

D1 MTRX1

D2 MTRX2

D1 MTRX3

D2 MTRX4

D1 AUX 1

D2 AUX 2

D1 AUX 3

D2 AUX 4

D1 AUX 5

D2 AUX 6

D1 AUX 7

D2 AUX 8

D1 AUX 9

D2 AUX10

D1 AUX11

D2 AUX12

D1 AUX13

D2 AUX14

D1 AUX15

D2 AUX16

D1 AUX17

D2 AUX18

D1 AUX19

D2 AUX20

D1 MONI L

D2 MONI R

Output channel

Page 40

Symptom Possible causes Possible solution

Troubleshooting

Dante model

Power does not come on. Time between turning the power on/off is too short. Wait about 20 seconds after turning the power off before turning it back on again.

Reference

Routing is not appropriate.

No sound.

Level is low in DSP.

No sound, or intermittent sound. Too many Dante devices in the daisy chain for the current

Volume becomes low suddenly.

Sound is interrupted suddenly.

Display goes off after a few moments. The protection function for the display is active. Press either the main knob or the [ ] (Back) key to return to the normal display.

The screen display goes off in a few seconds.

The [LIMIT] indicator remains lit. Or, the indicator frequently lights up.

latency settings.

Protection function is active because the amp is too hot, triggering the limiter.

Protection function is active because the amp became hotter, triggering the mute function.

The speaker units are damaged.

The BLACKOUT function has been set to ON.

The input signal is too large.

On the HOME screen, if there is a signal in the INPUT meter but no signal in the SP Output Meter, check if the signal is routed to SP OUT under ROUTER in the settings.

Check the INPUT level on the ROUTER screen, and raise the level if it is too low.

With the default setting (1 msec), a single daisy chain can have up to 10 units. When connecting more than 10 units, use an L2 switch (that supports Giga-bit Ethernet) to create branches in the network.

In such cases, “THERMAL” is displayed on the HOME screen. To reduce the amplifier temperature, reduce the output level and improve the ventilation around the rear panel. Additionally, shield the rear panel from direct sunlight.

In such cases, “MUTED” is displayed on the HOME screen, and at the same time the [POWER] indicator flashes. To reduce the amplifier temperature, reduce the output level and improve the ventilation around the rear panel. Additionally, shield the rear panel from direct sunlight. The system will recover once the temperature goes down.

If there is no sound even though MUTED is not displayed on the HOME screen and there is a signal in the SP Output Meter, the speaker units might be damaged. Please contact your Yamaha dealer.

Press either the main knob or the [ ] (Back) key to return to the normal display. To turn this setting off permanently, navigate from the HOME screen to UTILITY → PANEL SETUP → BLACKOUT and turn the setting off.

To reduce the degree to which the [LIMIT] indicator turns on, either reduce the MASTER Level, or reduce the level of the input signal.

The operating panel locks up after turning the power back on, even after removing the PANEL LOCK.

Screen commands are unavailable for use.

A “USB: OVER CURRENT” message appears on the screen. Or, the USB flash drive does not work.

“Diagnosis mode” or “Service mode” appears on the screen.

This occurs when TEMPORARILY (TEMP) is selected when removing the PANEL LOCK.

You have forgotten/entered the wrong PIN code.

The connection between the product and the USB device has been cut due to excess current flowing to the USB terminal.

This product is in the mode used for service purposes. Turn the power switch off and then turn the power switch back on.

When TEMPORARILY (TEMP) is selected, the panel lock is temporarily released, but it is applied again when turning the power back on. To permanently remove the panel lock, select PERMANENTLY (OK). (See page 22)

Follow the procedure described in “Initializing to the default settings when you have forgotten your

PIN code, etc.” to reset this product. (See page 12)

Remove the USB flash drive from the USB terminal, and then turn on the power to this product again.

Page 41

Ultimo (ULT/UXT) This is a Dante module for small models. The DZR-D and the DXS-XLF-D use the 2-in/2-out Ultimo module.

Dante-related Terms

Dante Device Lock This is a lock function that prevents Dante settings from being changed. Set this in Dante Controller.

Daisy Chain A daisy chain is a wiring scheme in which multiple devices are connected together in sequence. Also referred to as a switched connection.

The DZR-D and DXS-XLF-D contain an internal L2 switch, and the two Dante jacks are primary connectors that can be linked in a daisy chain connection. This connection cannot be used in a redundant (secondary) network.

Reference

Latency This is a time setting that affects audio signal buffering. This setting is dependent on the Dante device and the number of network switch hops present. As more hops

UNIT ID Sets an ID so that connected devices recognize individual DZR-D and DXS-XLF-D devices. This enables the transmitting and receiving of audio signals over a Dante

Device Label This is used to identify Dante devices on a Dante network. Under normal circumstances, the Dante device receiving the transmission identifies the Dante device

increase the transmission delay, setting too low a latency may cause the audio transmission to lag, resulting in skips in the audio. Increasing the latency is safer, but also results in a larger delay. The minimum value for the Ultimo module is 1 ms. If two devices with different latency settings are patched together, the slower latency time setting will be applied.

network, and the use of a remote controller. Avoid using the same ID for the same model devices on the same network.

sending the transmission using its Device Label.

By default, Yamaha devices are identified as:

Y### - Yamaha - Model name - Last six digits of the MAC address (Where ### is three-digit hexadecimal representing the UNIT ID.)

E.g.) Y001-Yamaha-DXS15XLF-D-******

When setting this on this product, up to 12 characters can be used, not including the initial five characters (Y###-) and the last 7 characters (-******). When setting this on Dante Controller, though all characters can be input, the initial five characters will revert back to their original Y###- when restarting this product. To use the characters you input, keep using the initial five characters (Y###-) without changing, and set other characters as desired. This enables characters other than the initial five characters (Y###-) to appear in the LABEL (page 24). In this case, if the last six characters are matched to the MAC address of this product, these characters don't appear in the LABEL. In a system combining this product with CL series or QL series devices, should a malfunctioning unit be replaced, setting the same UNIT ID as the UNIT ID of the original unit to the replaced unit enables automatic restoring of the original patches.

Page 42

Reference

Specifications

The contents of this manual apply to the latest specifications as of the publishing date. To obtain the latest manual, access the Yamaha website then download the manual file.

 General Specifications 0 dBu is referenced to 0.775 Vrms.

DZR315(-D) DZR15(-D) DZR12(-D) DZR10(-D) DXS18XLF(-D) DXS15XLF(-D)

System Type

Frequency Range (-10 dB) 31 Hz – 20 kHz 34 Hz – 20 kHz 39 Hz – 20 kHz 44 Hz – 20 kHz 30 Hz – 150 Hz 33 Hz – 150 Hz

Coverage Angle H75° × V50°

Crossover Frequency, Type

Maximum SPL

Transducers

Enclosure Material, Finish, Color Plywood, Durable polyurea coating, Black

Floor Monitor Angle — 50° Symmetrical 50° Symmetrical 50° —

Dimensions (W × H × D, with rubber feet)

Weight 41.6 kg 25.2 kg 21.4 kg 17.9 kg 48.9 kg 40.0 kg

Grille Matte black powder coated perforated steel grille with cloth mesh

Handles Aluminium die-cast, Side × 2

Pole Socket — Ø35 mm × 2 (0° or -7°)

Rigging Points M10 × 16 M10 × 12 M10 × 8, M8 × 2 —

Magnetically Shield Non magnetically shielded

Amplifier Type Class-D Class-D

Power Rating

Cooling Fan cooling, Variable speeds.

HF 2" Voice coil, 1" Throat compression driver, Titanium diaphragm, Neodymium magnet —

Dynamic 2,000 W (LF: 1,000 W, MF/HF: 1,000 W) 1,600 W

Burst (20 ms) 1,100 W (LF: 1,000 W, MF/HF: 100 W) 1,300 W

Continuous 950 W (LF: 850 W, MF/HF: 100 W) 1,200 W

3-way, Bi-ampled Pow-

ered speaker, Bass-reflex

H90° × V50°

(Rotatable)

700 Hz (FIR-X)

2.5 kHz (Passive)

143 dB SPL 139 dB SPL 139 dB SPL 137 dB SPL 136 dB SPL 136 dB SPL

15" Cone,

3" Voice coil,

Neodymium magnet

8" Cone,

1.5" Voice coil, Ferrite magnet

550 × 897 × 520 mm 450 × 761 × 460 mm 410 × 646 × 394 mm 315 × 537 × 345 mm 550 × 657 × 720 mm 450 × 587 × 600 mm

1.7 kHz (FIR-X) 1.8 kHz (FIR-X) 1.8 kHz (FIR-X) —

15" Cone,

3" Voice coil,

Neodymium magnet

2-way, Bi-amped powered speaker, Bass-reflex Powered subwoofer, Bass-reflex

H90° × V60°

(Rotatable)

12" Cone,

3" Voice coil,

Neodymium magnet

——

H90° × V60°

(Rotatable)

10" Cone,

3" Voice coil,

Neodymium magnet

Aluminium die-cast,

Top × 1, Side × 1

—

18" Cone,

4" Voice coil,

Ferrite magnet

Aluminium die-cast, Side × 2

Ø35 mm (Depth 80 mm),

M20 (Threaded depth 25 mm)

15" Cone,

4" Voice coil,

Ferrite magnet

Page 43

DZR315(-D) DZR15(-D) DZR12(-D) DZR10(-D) DXS18XLF(-D) DXS15XLF(-D)

Latency: Analog IN to SP OUT

Controllable Signal Processing

Protection

DSP, AD/DA 96 kHz processing with 96 kHz AD/DA and FIR filter

Connectors

Residual Noise LEVEL: Min LF: -59 dBu, HF: -60 dBu -59 dBu

Fan noise level (1m from rear panel)

Idle Power Consumption 45 W 40 W

1/8 Power Consumption 150 W 180 W

Heat Dissipation 129 kcal/h 155 kcal/h

AC Power Requirements

Inrush Current (1 msec) 5.6 A (AC 220–240 V), 6.6 A (AC 120 V), 6.8 A (AC 100 V),

Temperature Range Operation: 5°C to 40°C, Storage: -20°C to 50°C

AC Cord 2.5 m (V-Lock)

Options

Except MONITOR Mode

MONITOR Mode 1.5 ms 2.0 ms

Speaker Clip limiting, Integral power protection DC-fault

Amplifier Thermal, Output over current

Power Supply Thermal, Output over voltage, Output over current

Analog IN Combo × 2, Line level (Maximum +24 dBu), Input impedance 20 kΩ

Input Sensitivity 0 dBu (Vomume: max), +10 dBu (Volume: center)

Analog OUT XLR3-32 × 2, CH1: THRU (fix), CH2: THRU or DSP OUT XLR3-32 × 2, CH1/2: THRU or DSP OUT

Dante (-D model only)

USB USB2.0 host: 5 V 500 mA

AC IN IEC AC inlet × 1 (V-Lock)

Highest Speed NC 40 NC 40

Lowest Speed NC 30 NC 30

U-bracket —

Cover SPCVR-DZR315 SPCVR-DZR15 SPCVR-DZR12 SPCVR-DZR10 SPCVR-DXS18X SPCVR-DXS15X

Wheel — SPW-1

4.5 ms 3.4 ms

MASTER Level, HPF (OFF, 60 Hz–120 Hz, 24 dB/oct BW), D-CONTOUR,

EQ (6 bands), DELAY (0–140 ms), Routing

etherCON CAT5e × 2 (Daisy Chain), 2 IN / 2 OUT (Fs: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz) and Remote Control, 1000BASE-T

Depending on area of purchase; 100–240 V or 220–240 V, 50/60 Hz

UB-DZR15H,

UB-DZR15V

UB-DZR12H,

UB-DZR12V

UB-DZR10H,

UB-DZR10V

0.6 ms

MASTER Level, LPF (60 Hz–120 Hz, 24 dB/oct BW), POLARITY, D-XSUB,

EQ (6 bands), DELAY (0–140 ms),

CARDIOID, Routing

2.5 A (AC 220–240 V), 4.4 A (AC 120 V),

5.0 A (AC 100 V)

—

Reference

*1: Measured peak SPL with pink noise @1 m. *2: Dynamic: Total peak power of individual outputs. Measured at minimum load impedance, with protection released.

Burst/Continuous: Measured at nominal impedance, with protection activated.

*3: While both devices will work at a voltage of between 100 V to 240 V, as limiter settings vary depending on the supply voltage, make sure to use this product at the supply voltage indi-

cated on the rear panel of this product.

Page 44

 Route Latency Values

Reference

DZR315(-D) DZR15(-D), DZR12(-D), DZR10(-D)

D-CONTOUR mode —

OFF (NORMAL),

FOH/MAIN

Analog IN → SP OUT 4.5 ms 1.5 ms 3.3 ms 2.0 ms 0.5 ms

DANTE Fs = 96 kHz 6.0 ms 3.0 ms 4.8 ms 3.5 ms 2.0 ms *1

Dante IN → SP OUT

Analog IN → LINE OUT 0.2 ms

Analog IN → Dante OUT

Dante IN → LINE OUT

DANTE Fs = 88.2 kHz 6.0 ms 3.0 ms 4.8 ms 3.5 ms 2.0 ms *1

DANTE Fs = 48 kHz 6.5 ms 3.5 ms 5.3 ms 4.0 ms 2.5 ms *1

DANTE Fs = 44.1 kHz 6.6 ms 3.6 ms 5.4 ms 4.1 ms 2.6 ms *1

All models

DANTE Fs = 96 kHz 1.7 ms *1

DANTE Fs = 88.2 kHz 1.7 ms *1

DANTE Fs = 48 kHz 2.2 ms *1

DANTE Fs = 44.1 kHz 2.3 ms *1

DANTE Fs = 96 kHz 1.7 ms *1

DANTE Fs = 88.2 kHz 1.7 ms *1

DANTE Fs = 48 kHz 2.2 ms *1

DANTE Fs = 44.1 kHz 2.3 ms *1

MONITOR

OFF (NORMAL),

FOH/MAIN

MONITOR —

DXS18XLF(-D),

DXS15XLF(-D)

*1: Includes Dante latency of 1 ms.

Page 45

 Current Draw and Power Consumption

1 Btu = 1,005.06 J = 0.252 kcal, 1 W = 0.86 kcal

DZR315(-D), DZR15(-D), DZR12(-D), DZR10(-D)

Reference

100V/ 50Hz

Idle 0.9 45 0 45 154 39 1/8 out LF: 3Ω / HF: 8Ω 2.3 150 78 72 512 129 1/3 out LF: 3Ω / HF: 8Ω 5.3 345 207 138 1,177 297

110V–120V/60Hz

Idle 0.7 45 0 45 154 39 1/8 out LF: 3Ω / HF: 8Ω 2.1 150 78 72 512 129 1/3 out LF: 3Ω / HF: 8Ω 4.4 340 207 133 1,160 292

220V–240V/50Hz

Idle 0.5 45 0 45 154 39 1/8 out LF: 3Ω / HF: 8Ω 1.3 150 78 72 512 129 1/3 out LF: 3Ω / HF: 8Ω 2.7 325 207 118 1,109 280

Current Draw (A)

@100 V

Current Draw (A)

@120 V

Current Draw (A)

@230 V

Power Consumption (In) Power Consumption (Out) Watts Dissipated Btu/h kcal/h

Watt (W) Thermal Dissipation

DXS18XLF(-D), DXS15XLF(-D)

100V/ 50Hz

Idle 0.7 40 0 40 137 34 1/8 out LF: 4Ω 2.7 180 100 80 614 155 1/3 out LF: 4Ω 6.1 404 267 137 1,379 347

Current Draw (A)

@100 V

Power Consumption (In) Power Consumption (Out) Watts Dissipated Btu/h kcal/h

Watt (W) Thermal Dissipation

110V–120V/60Hz

Idle 0.6 40 0 40 137 34 1/8 out LF: 4Ω 2.2 180 100 80 614 155 1/3 out LF: 4Ω 5.0 396 267 129 1,351 341

220V–240V/50Hz

Idle 0.5 40 0 40 137 34 1/8 out LF: 4Ω 1.4 180 100 80 614 155 1/3 out LF: 4Ω 2.7 380 267 113 1,297 327

Current Draw (A)

@120 V

Current Draw (A)

@230 V

Power Consumption (In) Power Consumption (Out) Watts Dissipated Btu/h kcal/h

Watt (W) Thermal Dissipation

Page 46

Dimensions

 DZR315(-D)

366 92

287

448 51

4xM10

550

897

520

41808

282

2xM10

4xM10

808

4xM10

366 92

448 51

Unit: mm

Reference

Page 47

 DZR15(-D)

Unit: mm

2xM8

3xM10

254

Reference

329

3xM10

2xM8

240 367

450

367

240

761

254

329

41672

504

460

2xM10

329

254

257240

2xM8

50°

41672

2xM10

Page 48

 DZR12(-D)

2xM8

3xM10

239

277

240 327

2xM8

3xM10

646

410

239

394

277

199.5240

41557

2xM10

41557

2xM10

240

327

239

277

444

50°

Unit: mm

Reference

Page 49

240

 DZR10(-D)

Unit: mm

Reference

2xM8

2xM10

2xM8

233

315

233

166

537

166

236

451

392

345

236

176

2xM10

145240

2xM8

50°

28474

2xM8

240

Page 50

720

550

657

Ø35

M20

16 x M6

 DXS18-XLF(-D)

Unit: mm

Reference

Page 51

Reference

 DXS15-XLF(-D)

Unit: mm

450

M20

Ø35

600

16 x M6

587

Page 52

Reference

Block Diagram

1 (LINE)

2 (LINE)

THRU/OUTPUT

OMNI/

CARDIOID

HPF 60~

120Hz

TOTAL SP-EQ

METER

LEVEL

DSP

D-XSUB:

OFF(NORMAL),

BOOST,

XTEND LF

INPUT

LIMIT

Fs 96kHz

DANTE

LEVEL

MASTER

LEVEL

DELAY

ALIGNMENT

ROUTER

SP OUT

POST EQ

DSP OUT

THRU

GAIN/

DELAY

140ms

User EQ

(IIR)

6bands

LPF 60~

120Hz

User control Factory fixed

Dante models

AMP

PROTECTION LOGIC

MUTELIMITER

Dynamic

Dante models,

remote

MUTE

METER

DANTE

SENSITIVITY

ch1

ch2

A1 A2

METER

SRC

ROUTER*

ch1

ch2

To A2

To A1

 DZR(-D)

 DXS-XLF(-D)

1 (LINE)

2 (LINE)

DANTE

Dante models

INPUT

LEVEL

ch1

ch2

ch1

ch2

DSP

Fs 96kHz

METER

SRC

A1 A2

ROUTER*

DELAY

DANTE

ALIGNMENT

METER

SENSITIVITY

User EQ

(IIR)

6bands

SP OUT

ROUTER

To A2

HPF

Off, 60~

120Hz

POST EQ

DELAY

140ms

MASTER

LEVEL

MUTE

Dante models,

remote

D-CONTOUR:

OFF(NORMAL),

FOH/MAIN,

MONITOR

User control Factory fixed

TOTAL SP-EQ

FIR-X

HPF

FIR-X

LPF

FIR

Correct

EQ *1

IIR

Correct

GAIN/

DELAY

GAIN/

DELAY

Dynamic

LIMITER

LIMIT

PROTECTION LOGIC

MUTE

MUTELIMITER

METER

AMP

(HF)

AMP

(LF)

THRU

DSP OUT

THRU

Network

3way model

THRU/OUTPUT

*1: MONITOR mode: IIR

* Dante output settings are supported by firmware V1.2.2 or later and Dante module firmware 4.1.6.7-4.1.6.5-1.1.0 or later.

Page 53

Reference

Index

Numeric

[1G] indicator...................................................................8

[AC IN] jack .....................................................................7

ALIGNMENT (DELAY ALIGNMENT) ..............................18

ALL.................................................................................20

ANA. OUT1 LVL .............................................................19

ANA. OUT2 LVL .............................................................19

[] (Back) key ........................................................6, 9

Bands.............................................................................16

BLACKOUT....................................................................20

BOOST...........................................................................16

BRIGHTNESS.................................................................19

BS ..................................................................................14

CARDIOID................................................................11, 17

cardioid mode..........................................................11, 17

CONTRAST ....................................................................20

Daisy Chain Network .....................................................29

Dante Controller.......................................................30, 31

Dante Device Lock ........................................................25

Dante jacks ......................................................................8

Dante latency.................................................................24

D-CONTOUR ...........................................................11, 15

DDM (Dante Domain Manager) ..................................... 25

DELAY ......................................................................11, 16

Device Label..................................................................24

DHCP ............................................................................. 25

Display............................................................................. 6

DISTANCE......................................................................16

DNT. IN1 LVL..................................................................18

DNT. IN2 LVL..................................................................18

DNT. OUT1 LVL..............................................................19

DNT. OUT2 LVL..............................................................19

DNT. SENS. (DANTE SENSITIVITY) ...............................18

Dual pole sockets ............................................................5

D-XSUB....................................................................11, 16

E symbol ........................................................................11

EQ ............................................................................11, 16

equalizer ........................................................................11

Factory presets ..............................................................13

Feet cups .........................................................................5

FIRMWARE.....................................................................26

FLAT...............................................................................16

FOH/MAIN......................................................................15

Fs (DANTE Fs) ...............................................................24

GATEWAY.......................................................................25

high-pass filter .........................................................11, 15

HPF ..........................................................................11, 15

INITIAL DATA ................................................................. 13

INPUT ............................................................................ 18

[INPUT] jacks................................................................... 7

Input Meter .................................................................... 11

Input Meter (DNT)..........................................................11

INVERTED................................................................ 11, 15

IP ADR. ..........................................................................25

IP SET. (IP SETTING) .....................................................25

LABEL...................................................................... 11, 24

LATENCY (DANTE LATENCY) .......................................24

[LEVEL] controls ..............................................................6

[LIMIT] indicator ..............................................................6

[LINK] indicator ............................................................... 8

LOAD FROM USB.......................................................... 21

LOCAL ...........................................................................25

LOCK .............................................................................25

LOG LIST .......................................................................27

low-pass filter........................................................... 11, 15

LPF...........................................................................11, 15

MAC............................................................................... 25

Main knob .................................................................... 6, 9

MASTER Level ............................................................... 11

MODE (DANTE MODE) .................................................23

MONITOR ......................................................................15

MUTED from REMOTE................................................... 28

NETMASK ......................................................................25

Page 54

Reference

OFF (NORMAL)........................................................15, 16

OUTPUT.........................................................................19

Parameter Display .........................................................16

PARTIAL .........................................................................20

PATCH............................................................................24

PIN CODE ......................................................................20

POLARITY ................................................................11, 15

[POWER] indicator...........................................................6

Power switch....................................................................7

PRESET....................................................................11, 13

Protection.......................................................................11

Quick Config ..................................................................23

RESTORE FROM USB ...................................................23

ROUTER...................................................................11, 18

Routing...........................................................................18

SAVE TO USB ....................................................21, 23, 27

Screw holes for eye bolts.................................................5

Screw holes for U-bracket ...............................................5

SERIAL...........................................................................26

SP Output Meter ............................................................11

STANDARD ....................................................................23

Star Network ..................................................................29

STATE .............................................................................25

STATIC IP .......................................................................25

[SYNC] indicator ..............................................................8

TEMP..............................................................................22

THERMAL ......................................................................26

[THRU/DSP OUT] switch .................................................7

[THRU/OUTPUT] jacks ....................................................7

Tiltable pole socket..........................................................5

TIME...............................................................................16

UNIT ID ..............................................................11, 24, 25

USB terminal....................................................................6

User preset list...............................................................13

UTILITY ....................................................................11, 19

Vents ................................................................................ 7

VERSION........................................................................ 26

Wheel mounting screws...................................................5

XTEND LF (extended LF)...............................................16

Published 03/2020 PO-C0

Yamaha DZR12-D, DZR10, DZR315-D, DZR315, DZR15-D User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Introduction

DZR(-D), DXS-XLF(-D) Series Product Lineup

Main Features

Main Functions

Structure of Manuals

Functions

Full-range Speaker (Rear)

Subwoofer (Rear)

Rear Panel

 Power Section

 Dante Section

Panel Operations

Basic Operations

HOME Screen and Its Functions

Alert Messages

Initialization

Screen Functions

Screen Structure

PRESET Screen

 RECALL

 STORE

 CLEAR

 TITLE

 PROTECT

HPF Screen

LPF Screen

D-CONTOUR Screen

D-XSUB Screen

EQ Screen

DELAY Screen

CARDIOID Screen

ROUTER Screen

UTILITY Screen

 PANEL SETUP

 PANEL LOCK

 DEVICE BACKUP

 DANTE SETUP

 NETWORK

 DEVICE INFORMATION

 INITIALIZE

 UPDATE FIRMWARE

Muting from an External Device

About Dante

Dante Network System

Dante Settings

Connecting to Dante Devices

Integration with Yamaha Digital Mixers

Reference

Precautions when Using the USB Terminal

Using USB Flash Drives

Function Tree

Message List

Patch Correspondence Chart when Using Quick Config

Troubleshooting

Dante-related Terms

Specifications

Dimensions

Block Diagram

Index
