Contents

CS6x/CS6R V oice List ............................................4

Drum V oice List......................................................10

Wave List................................................................13

Performance List ..................................................14

Control List ............................................................15

Arpeggio T ype List ................................................16

Effect T ype List......................................................17

Effect Parameter List ............................................17

About MIDI ............................................................26

MIDI Data Format ..................................................26

MIDI Data Table ......................................................30

MIDI Implementation Chart ..................................38

DATA LIST

4

Preset 1 (MSB=63, LSB=0)

No. Voice Name

Category

Reverb Type

Chorus Type Insertion1 Type Insertion2 Type MW PB AT FC BC FS RB Kn1 Kn2

1 Grand Pf Hall 1 Chorus 1 Thru Thru ChoSend off off off off off FLT-Frq FLT-Frq RevSend
2 Ivories Pf Hall 1 Chorus 1 3band EQ Thru CLFO-D1 off off off off off ChoSend ChoSend RevSend
3 For Ballad Pf Hall 1 Delay LR Thru Chorus 4 ELM-Lvl off off off off off Volume RevSend ChoSend
4 BasicRoadz Pf Hall 2 Chorus 1 3band EQ Auto Pan ChoSend, ChoSend off off off off off ChoSend InsL prm2 InsL prm1
5 DF Roadz Pf Hall 1 Chorus 1 3band EQ Pitch Change 1 ChoSend off off off off off ChoSend InsS prm2 InsS prm7
6 RT Roadz Pf Stage 1 Chorus 1 Auto Pan Phaser 1 InsS prm1, InsS prm2 off off off off off InsL prm1 InsL prm10 RevSend
7 SunShine Pf Stage 1 Chorus 1 Auto Pan Compressor InsS prm1 off off off off off InsS prm1 InsS prm2 RevSend
8 Club Daz Pf Room 1 Phaser Overdrive Thru InsS prm10 off off off off off ELFO-AM InsS prm1 ChoSend, RevSend

9 Fusion Pf Hall 1 Phaser Touch Wah 3Band EQ CLFO-D1 off off off off off InsS prm1 RevSend ChoSend
10 CP2000 Pf Hall 1 Flanger 3 3band EQ Thru ChoSend off off off off off ELM-Pan CLFO-D1 FLT-Frq
11 DXAtacky Pf Hall 1 Celeste 1 Chorus 3 Thru CLFO-D1 off off off off off InsS prm1 RevSend ChoSend
12 Dark DX Pf Hall 1 Chorus 1 Thru Thru CLFO-D1 off off off off off FLT-Frq FLT-Frq ChoSend, RevSend
13 Wurli Pf Plate Chorus 2 AMP Simulator Tremolo InsL prm2, InsL prm1 off off off off off ChoSend RevSend InsS prm1
14 Clavint Pf Stage 2 Phaser Thru Thru ChoSend, Volume off off off off off FLT-Rez FLT-Frq FEG-D1
15 Clav Wah Pf Stage 2 Phaser Touch Wah Thru ChoSend, Volume off off off off off FLT-Rez FLT-Frq FEG-D1
16 Full Or Hall 1 Chorus 1 3band EQ

InsL prm16, ChoSend,
ELM-Lvl off off off off off ELM-Lvl ELM-Lvl ELM-Lvl

17 Perc Org Or Hall 1 Chorus 1 3band EQ

InsL prm16, ChoSend,

ELM-Lvl off off off off off InsL prm12 InsL prm9 RevSend
18 E Bird Or Hall 1 Chorus 4 Thru Rotary Speaker 1 InsL prm1 off off off off off ELM-Lvl ELM-Lvl ELM-Lvl
19 4 Bars Or Hall 1 Chorus 1 Overdrive Rotary Speaker 1 InsL prm1 off off off off off InsS prm10 InsS prm10 ELM-Lvl
20 Jazz Or Room 1 Chorus 1 Overdrive Rotary Speaker 1 InsL prm1 off off off off off FLT-Rez InsL prm9 InsL prm1
21 Swish Or Hall 1 Chorus 1 Thru 2Way Rotary Speaker ELM-Lvl, ChoSend off off off off off FLT-Frq ELM-Lvl ELM-Lvl, InsL prm1
22 Vox Or Stage 1 Chorus 1 AMP Simulator Thru ELFO-PM off off off off off ChoSend FLT-Frq InsS prm1
23 Tube Or Hall 1 Chorus 3 AMP Simulator

2Way Rotary Speaker 3

2Way Rotary Speaker 3

2Way Rotary Speaker 3

InsL prm16, InsL prm9 off off off off off ELM-Lvl InsS prm1 InsL prm9, FLT-Frq
24 Gospel Or Hall 1 Chorus 4 Overdrive Rotary Speaker 1

InsL prm1, ChoSend,

ELM-Lvl off off off off off InsS prm5 InsL prm9 InsL prm1
25 ClickOrgan Or Hall 1 Chorus 1 Overdrive Rotary Speaker 1 InsL prm1 off off off off off InsL prm1 ELM-Lvl ELM-Lvl
26 Jimmy Or Hall 1 Chorus 1 3band EQ

Amp Simu + 2Way

Rotary Speaker InsL prm1 off off off off off InsL prm1 InsL prm14 InsS prm2
27 Accordion Or Hall 1 Ensemble Thru Thru ChoSend off off off off off FLT-Frq HPF-Frq FLT-Frq
28 Monica Rd Stage 1 Ensemble AMP Simulator Touch WAH ELFO-PM FLT-Frq ELFO-PM off off off FLT-Frq InsL prm2 ELFO-AM
29 18 String Gt Hall 2 Chorus 1 3band EQ 2Band EQ CLFO-D1 off off off off off PCH-Crs ChoSend FLT-Frq
30 New Nylon Gt Hall 1 Chorus 1 3band EQ Thru CLFO-D1 off off off off off CLFO-D1 ELM-Lvl ELM-Lvl, FLT-Frq
31 JazzGtmelo Gt Hall 1 Chorus 1 3band EQ 3Band EQ CLFO-D1 off off off off off PCH-Crs InsS prm4 ChoSend
32 Elec-Acous Gt Hall 1 Delay LR Chorus 1 Comp Distortion ELFO-PM off off off off off InsS prm1 ELM-Lvl, ELM-Lvl ChoSend
33 Acoustic Gt Hall 1 Chorus 1 Thru Thru ELFO-PM off off off off off FLT-Frq FEG-D1 ChoSend
34 ChorStrat Gt Hall 1 Chorus 4 3band EQ AMP Simulator CLFO-D1 off off off off off PCH-Crs ChoSend InsS prm2
35 Cry Gt Hall 1 Chorus 1 Auto Wah Comp+Dist+Delay ELFO-PM off off off off off InsS prm3 InsS prm1 ChoSend, Volume
36 Blood Gt Hall 1 Delay LR AMP Simulator 2Band EQ ELM-Lvl off off off off off PCH-Crs RevSend ChoSend
37 Birdy Gt Room 3 Phaser 3band EQ V-Distortion ELFO-PM off off off off off InsL prm4 InsL prm1, Volume InsL prm11
38 Mute Gt Room 3 Phaser Thru Compressor ELFO-PM, ChoSend off off off off off HPF-Frq FLT-Frq FLT-Rez
39 Feedback Gt Room 3 Chorus 4 3band EQ V-Distortion ELFO-PM off off off off off InsL prm4 InsL prm11 InsL prm1
40 100 Watts Gt Room 3 Phaser 3band EQ V-Distortion ELFO-PM off off off off off InsL prm4 InsL prm11 InsL prm1
41 Prec Bass Ba Hall 1 Chorus 1 AMP Simulator 3Band EQ CLFO-D1 off off off off off PCH-Crs ChoSend InsL prm1
42 Fing Sting Ba Hall 1 Chorus 1 Exciter 3Band EQ CLFO-D1 off off off off off PCH-Crs ChoSend InsL prm1
43 Fretless Ba Hall 1 Chorus 1 3band EQ Thru ELFO-PM off off off off off ChoSend FLT-Frq RevSend
44 Slap Ba Room 1 Chorus 1 Compressor Thru ELFO-PM off off off off off ChoSend FLT-Frq RevSend
45 Upright Ba Room 1 Chorus 1 3band EQ Thru ELFO-PM off off off off off ChoSend FLT-Frq, FLT-Frq ELM-Lvl
46 Lately Ba Room 3 Control Delay1 Compressor AMP Simulator ELFO-PM off off off off off InsL prm3 InsL prm10 ELFOSpd
47 Mini Ba Room 1 Chorus 1 3band EQ Pitch Change 1 FLT-Frq off off off off off ELM-Lvl ChoSend ELM-Lvl
48 Dry Syn Ba Hall 1 Chorus 1 Thru Thru CLFO-D1 off off off off off FLT-Frq FEG-D1 ChoSend
49 Dark Ba Stage 2 Chorus 1 Thru Thru FLT-Frq off off off off off FLT-Frq FEG-Atk, FEG-D1 ChoSend, ELM-Lvl
50 Deep Rez Ba Hall 1 Flanger 1 Thru Thru CLFO-D1 off off off off off PCH-Crs FLT-Frq FLT-Rez
51 Background St Hall 2 Chorus 1 3band EQ 3Band EQ CLFO-D1 off off off off off FLT-Frq ChoSend AEG-Atk
52 CelloSmall St Hall 1 Chorus 1 Thru Thru CLFO-D1, CLFO-D2 off off off off off Volume ELM-Lvl RevSend
53 Big String St Hall 1 Chorus 1 Thru Thru ELFO-PM off off off off off ELM-Lvl RevSend FLT-Frq, FLT-Rez
54 Cello Big St Hall 1 Chorus 1 Thru Thru CLFO-D1, CLFO-D2 off off off off off FLT-Frq ELM-Lvl RevSend
55 Mellow Str St Hall 2 Chorus 4 3band EQ Thru CLFO-D1 off off off off off PCH-Crs RevSend ChoSend
56 Pizzicato St Hall 1 Chorus 3 Thru Thru ChoSend off off off off off FLT-Rez FLT-Frq AEG-D1
57 Small Anna St Hall 1 Ensemble Thru Thru ChoSend, Volume off off off off off FLT-Frq FLT-Frq AEG-Atk, AEG-Rel
58 ObiStrings St Hall 2 Chorus 5 Exciter Cross Delay FLT-Frq, FLT-Rez off off off off off FLT-Frq InsS prm1 ChoSend
59 AnaStrings St Hall 2 Ensemble Chorus 1 Cross Delay CLFO-D1, FLT-Frq off off off off off FLT-Rez, FLT-Frq InsS prm10 ChoSend
60 Soft Syn St Hall 2 Chorus 5 Exciter Cross Delay FLT-Frq, FLT-Rez off off off off off FLT-Frq InsS prm1 ChoSend
61 Violin St Hall 1 Chorus 1 Thru Thru CLFO-D1, CLFO-D2 off off off off off Volume ChoSend RevSend
62 Agitato St Hall 1 Chorus 1 3band EQ Thru ChoSend off off off off off FLT-Frq FLT-Frq

ELFO-AM, ELFO-FM,

CLFOSpd
63 Harp St Hall 1 Celeste 2 3band EQ Thru ELFO-PM off off off off off FLT-Frq RevSend ChoSend
64 Aah Choir Vo Hall 2 Chorus 5 Exciter Thru

FLT-Frq, ELM-Lvl,
ELM-Lvl off off off off off HPF-Frq AEG-Atk InsS prm1

CS6x/CS6R Voice List

5

No. Voice Name

Category

Reverb Type

Chorus Type Insertion1 Type Insertion2 Type MW PB AT FC BC FS RB Kn1 Kn2

65 Ooh Choir Vo Hall 2 Chorus 5 Exciter Thru FLT-Frq, ELM-Lvl off off off off off HPF-Frq AEG-Atk InsS prm1
66 Choir Tak En Hall 1 Chorus 1 Exciter 3Band EQ ELFO-PM, ELFO-AM off off off off off FLT-Frq, FLT-Rez FLT-Frq FLT-Rez
67 Med Brass Br Stage 2 Chorus 1 Thru Thru ELFO-FM, ELFO-PM off

Volume,

FLT-Frq off off off off FLT-Frq ChoSend
68 Combi Br Hall 1 Ensemble Thru Thru ChoSend off off off off off HPF-Frq FLT-Frq PCH-Crs
69 Fanfare Br Hall 1 Chorus 1 3band EQ Thru CLFO-D1 off off off off off PCH-Crs ELM-Lvl RevSend
70 Dark Brass Br Hall 1 Chorus 1 Thru Thru ELFO-FM, ELFO-PM off off off off off PCH-Crs FLT-Frq ChoSend, Volume
71 Trombones Br Hall 2 Chorus 1 2band EQ Cross Delay CLFO-D1 off off off off off FLT-Frq ChoSend FLT-Frq
72 Trumpet Br Hall 1 Ensemble Thru Delay LCR ELFO-PM, ELFO-FM off off off off off FLT-Frq RevSend ChoSend, FLT-Rez
73 Mute Tpt Br Hall 1 Chorus 1 3band EQ Thru ELFO-PM ELFO-AM off off off off FLT-Frq RevSend HPF-Frq
74 Fr Horns Br Hall 1 Chorus 1 Thru Delay LCR ELFO-PM, ELFO-AM off off off off off FLT-Frq RevSend ChoSend
75 Oberhorns Br Hall 1 Chorus 4 Thru Cross Delay CLFO-D1 off off off off off FLT-Frq FEG-Atk ChoSend
76 PowerSynth Br Hall 1 Chorus 1 3band EQ Harmonic Enhancer CLFO-D1 off off off off off PCH-Crs InsL prm3 RevSend
77 Fat Brazz Br Hall 1 Chorus 4 Thru Cross Delay ELFO-PM off off off off off FLT-Frq FEG-Atk ChoSend
78 J Stabs Br Hall 1 Delay LR Thru Ensemble Detune ELFO-PM off off off off off PCH-Crs RevSend ChoSend
79 Moon Br Hall 1 Chorus 1 3band EQ Harmonic Enhancer CLFO-D1 off

FLT-Frq,

Volume off off off FLT-Frq PCH-Crs RevSend
80 M Brass Br Hall 2 Delay LR 3band EQ Chorus 4 CLFO-D1 off off off off off FLT-Frq RevSend ChoSend
81 Tenor Sax Rd Hall 1 Chorus 1 3band EQ Thru ELFO-PM, ELFO-AM off off off off off FLT-Frq FLT-Frq ChoSend
82 Alto Sax Rd Hall 1 Chorus 1 3band EQ Thru ELFO-PM, ELFO-AM off off off off off FLT-Frq FLT-Frq ChoSend
83 Soprano Rd Hall 1 Delay LR 3band EQ Thru ELFO-PM off off off off off ELFO-PM RevSend ChoSend
84 Clarinet Rd Hall 1 Chorus 1 3band EQ Thru ELFO-PM, ELFO-AM off off off off off FLT-Frq RevSend FLT-Frq, FLT-Rez
85 Oboe Rd Hall 1 Chorus 1 Thru Thru ELFO-PM, ELFO-AM off off off off off FLT-Frq RevSend FLT-Frq
86 Bassoon Rd Hall 1 Chorus 1 Thru Thru ELFO-PM ELFO-AM off off off off FLT-Frq RevSend FLT-Frq
87 Pan Flute Pi Hall 1 Chorus 1 Thru Thru ELFO-AM, ELFO-FM off off off off off FLT-Frq FLT-Frq, FLT-Rez AEG-Atk
88 Breathy Pi Hall 1 Chorus 1 Thru Thru CLFO-D1, CLFO-D2 off off off off off FLT-Frq FLT-Frq ELM-Lvl
89 Smooth Saw Ld Hall 1 Delay LR Thru Thru ELFO-PM off off off off off FLT-Frq FLT-Frq

ChoSend, Volume,

RevSend
90 Europe Ld Hall 1 Ensemble Distortion Cross Delay ELFO-PM, ELM-Lvl off ELFO-PM off off off FLT-Frq PCH-Fin PCH-Fin
91 Lucky Ld Hall 1 Chorus 3 Thru Thru ELFO-PM off off off off off FLT-Frq FLT-Frq ChoSend, Volume
92 Sneaky Ld Hall 1 Chorus 1 Thru Thru ELFO-PM off off off off off FLT-Frq FEG-Dpt FLT-Rez
93 Phazefilt Ld Hall 1 Tempo Phaser Chorus 1 Ensemble Detune ELFO-PM off off off off off PCH-Crs

InsS prm10, InsL
prm10, InsS prm2 PEG-Dpt

94 Mini Pulse Ld Hall 2 Chorus 2 Compressor Tempo Cross Delay ELFO-PM off off off off off FLT-Frq ChoSend

RevSend, InsL

prm10
95 BreathSaw Ld Hall 1 Delay LR 2band EQ Ambience ELFO-PM, ELFO-AM off off off off off FLT-Frq, FLT-Rez ELM-Lvl RevSend
96 Lovely Ld Hall 1 Ensemble Distortion Cross Delay CLFO-D1 off off off off off FLT-Frq ELM-Lvl FEG-Atk, AEG-Atk
97 Swan Pd Hall 2 Symphonic Chorus 3 Harmonic Enhancer PCH-Fin off off off off off FLT-Frq

InsS prm3, InsS

prm10, InsS prm6 InsL prm2
98 Nuages Pd Hall 1 Chorus 1 Tremolo Delay LR ELFO-PM, FLT-Frq off ELFO-PM off off off FLT-Rez FEG-Atk InsL prm10
99 Sleep Pd Hall 1 Celeste 1 Thru Thru ELFO-PM off off off off off FLT-Frq FLT-Rez ChoSend

100 Brassy Pd Hall 1 Delay LR Chorus 1 V-Flanger ELM-Lvl off off off off off PCH-Crs FLT-Frq

InsL prm14, InsL

prm2
101 5th Breath Pd Hall 2 Ensemble Exciter Cross Delay CLFO-D1 off off off off off FLT-Frq FLT-Frq, FLT-Rez InsL prm10
102 The Pad! Pd Hall 1 Chorus 1 Exciter Thru ELFO-PM, FLT-Frq off ELFO-PM off off off ChoSend FLT-Frq FLT-Rez
103 Kemistry Pd Hall 1 Chorus 1 Celeste 1 Hall 1 FLT-Frq off off off off off PCH-Crs RevSend AEG-Atk
104 JM Pad Pd Hall 2 Chorus 1 Thru Phaser 2 CLFO-D1 off off off off off FLT-Frq InsL prm1 ChoSend
105 Starlight Fx Hall 1 Chorus 1 Thru Pitch Change 2 ELFOSpd off off off off off ELM-Lvl FLT-Frq ChoSend
106 Sitar Et Hall 1 Flanger 1 3band EQ Ensemble Detune ELFO-PM off off off off off FLT-Frq ChoSend RevSend
107 Steel Drum Et Hall 1 Chorus 1 Thru Thru ChoSend off off off off off FLT-Frq, FLT-Rez FLT-Frq RevSend
108 Cyba Whip Pc Stage 2 Chorus 1 Thru V-Flanger InsL prm2 off off off off off FLT-Rez FLT-Frq AEG-Atk
109 ChimeTree Pc Hall 2 Celeste 2 Thru Thru ELFO-AM off off off off off ChoSend PCH-Crs RevSend
110 Glocken Cp Hall 2 Celeste 2 Thru Thru ChoSend off off off off off FLT-Frq RevSend ELFO-PM
111 Marimba Cp Hall 1 Celeste 2 Thru Thru ELFO-AM off off off off off FLT-Frq RevSend, ChoSend FLT-Frq, FLT-Rez
112 Eastern Cp Hall 1 Celeste 1 Chorus 1 Thru ChoSend off off off off off PCH-Crs FLT-Frq PCH-Crs
113 Gamelan Cp Hall 1 Symphonic Thru Thru ChoSend off off off off off PCH-Crs FLT-Frq AEG-Atk, AEG-Rel
114 Vibes Cp Hall 1 Celeste 2 Thru 3Band EQ ChoSend off off off off off FLT-Frq ELFO-AM ELFOSpd
115 Fingerbell Cp Hall 1 Celeste 2 Thru Thru ELFO-PM, ELFO-AM off off off off off FLT-Frq RevSend ChoSend
116 Tiny Bell Cp Hall 1 Chorus 1 Chorus 1 Thru ChoSend off off off off off ELFO-AM FLT-Frq AEG-Atk
117 Pulsate Sc Hall 1 Phaser 3band EQ Cross Delay ELFO-PM off off off off off FLT-Rez, FLT-Frq ChoSend RevSend
118 TX 802 Sc Hall 2 Celeste 3 3band EQ Pitch Change 1 ELFO-PM, ELFO-FM off off off off off ChoSend FLT-Frq, FEG-D2 InsL prm10
119 Power Keys Sc Room 1 Chorus 1 3band EQ Phaser 2

InsL prm2, InsL prm4,

InsL prm10 off off off off off ChoSend InsL prm1 RevSend
120 Arena Syn Sc Hall 1 Chorus 1 Exciter Thru ELFO-PM, FLT-Frq off ELFO-PM off off off ChoSend FLT-Frq FLT-Rez
121 Strat Pad Co Hall 1 Chorus 1 Compressor V-Distortion ELFO-PM off off off off off FLT-Frq ELM-Lvl, ELM-Lvl ChoSend
122 Wind Orch Co Hall 1 Ensemble 3band EQ Thru

CLFO-D1, CLFO-D2,

ELFO-PM, ELFO-FM off off off off off off FLT-Frq ELM-Lvl
123 Soft Dream Co Hall 2 Symphonic Celeste 4 Thru CLFO-D1, ChoSend off off off off off FLT-Frq FLT-Frq ChoSend
124 Amandla Co Stage 1 Delay LR 2band EQ Celeste 4 ELFO-PM off ELFO-PM off off off FLT-Frq RevSend ChoSend
125 Turntables Se Hall 1 Chorus 1 Thru LO-FI ELFO-PM, ELFO-FM off off off off off PCH-Crs ChoSend PCH-Crs
126 Rainstorm Se Hall 1 Chorus 3 Thru Thru FLT-Frq off off off off off ChoSend PCH-Crs ELM-Lvl
127 Sirens Se Hall 1 Chorus 1 Thru Thru RevSend off off off off off ChoSend ELFOSpd ChoSend
128 Helicopta Se Hall 1 Phaser Thru Auto Pan FLT-Rez, FLT-Frq ELFOSpd off off off off PCH-Crs ELM-Lvl RevSend

6

Preset 2 (MSB=63, LSB=1)

No. Voice Name

Category

Reverb Type

Chorus Type Insertion1 Type Insertion2 Type MW PB AT FC BC FS RB Kn1 Kn2

1 BriteGrand Pf Hall 1 Chorus 1 3band EQ Flanger 3 InsL prm10 off off off off off PCH-Crs ChoSend RevSend
2 Slamming Pf Room 3 Tempo Delay2 Compressor Voice Cancelar AEG-D1 off off off off off FLT-Frq InsL prm11 InsL prm12
3 Danzze Pf Room 1 Control Delay1 Overdrive Thru ChoSend, RevSend off off off off off AEG-D1 ELM-Pan FLT-Frq
4 House Pf Room 2 Control Delay2 Compressor Ambience RevSend off off off off off AEG-D1 InsL prm10 ChoSend, FLT-Frq
5 M25 Pf Hall 1 Tempo Delay1 Exciter Pitch Change 1 InsL prm10 off off off off off FEG-D1 PCH-Fin ChoSend
6 AcidFly Pf Stage 1 Delay LR AMP Simulator Digital Scratch ChoSend, RevSend off off off off off FLT-Frq InsL prm5 InsL prm11
7 Garage Rds Pf Hall 1 Delay LR Chorus 1 Auto WAH InsL prm2 off off off off off FLT-Frq InsL prm1

InsL prm2, InsL

prm10
8 Road Case Pf Hall 1 Tempo Delay2 Compressor Auto Pan InsL prm2 off off off off off InsL prm1 ChoSend FLT-Frq, FEG-Dpt
9 Amp Wurli Pf Room 1 Celeste 1 Overdrive Tremolo InsL prm2, Volume off off off off off FLT-Frq InsS prm10

InsS prm1,

RevSend

10 Ibiza Co Hall 1 Tempo Delay1 Compressor Celeste 4 FLT-Frq off off off off off ELM-Lvl RevSend ChoSend
11 Meltpiano Co Plate Chorus 1 Thru Symphonic ELM-Lvl off off off off off FLT-Frq ELM-Lvl ELM-Lvl
12 Ritzy Or Hall 2 Chorus 1 Thru Thru AEG-D1, ChoSend off off off off off ELM-Pan, ELM-Pan RevSend FLT-Frq
13 Old Skool Or Plate Tempo Delay1 Compressor Harmonic Enhancer ChoSend off off off off off AEG-D2 ELM-Lvl ELM-Lvl
14 Fluffy Or Room 1 Chorus 1 Overdrive Rotary Speaker 1 InsL prm1 off off off off off InsS prm1 InsL prm9 InsL prm1
15 Orbital Or Hall 1 Delay LR Thru Thru ELFO-PM off off off off off FLT-Frq RevSend ChoSend
16 Vox Conti Or Plate Chorus 1 AMP Simulator Rotary Speaker 1 InsL prm1, InsL prm2 off off off off off InsS prm1 ELM-Lvl InsL prm1
17 First Bars Or Hall 1 Chorus 1 Overdrive Rotary Speaker 1

InsL prm1, ChoSend,

ELM-Lvl off off off off off InsS prm10 ELM-Lvl ELM-Lvl
18 RhoBassFiz Or Room 1 Chorus 1 AMP Simulator Rotary Speaker 1 InsL prm1, InsL prm2 off off off off off InsS prm1 RevSend InsL prm1
19 Miles Gt Hall 1 Chorus 2 Thru Delay LR ELM-Lvl, ELM-Lvl off off off off off PCH-Crs RevSend InsL prm10
20 Sad Guitar Gt Hall 1 Symphonic AMP Simulator Pitch Change 1 ELFO-PM off off off off off FLT-Frq ChoSend RevSend
21 P.F. Echo Gt Room 3 Delay LR 3band EQ

Dist + 2Way Rotary
Speaker ELFO-PM off off off off off InsL prm1 ChoSend

InsL prm14,

Volume
22 Trancy Ba Hall 1 Chorus 4 Thru Delay LR ChoSend, ELM-Lvl off off off off off FLT-Rez FEG-Atk InsL prm10
23 Mutiny Ba Room 1 Chorus 1 Thru Thru ELFO-PM, Volume off off off off off FLT-Frq FEG-D1, FEG-Atk FLT-Rez
24 Bassline Ba Hall 1 Flanger 2 Distortion Delay LCR ChoSend, ELM-Lvl off off off off off FLT-Frq FEG-Atk

InsS prm10, InsL

prm10
25 DX100 Ba Room 3 Chorus 1 Thru Thru FLT-Frq off off off off off ELM-Pan RevSend ELFO-FM
26 Modular Ba Hall 2 Chorus 1 Thru Thru FEG-Dpt off off off off off PCH-Crs, FLT-Frq RevSend ChoSend
27 Strobe Ba Hall 1 Chorus 1 Thru Harmonic Enhancer ELFO-FM off off off off off ELFOSpd FEG-Dpt, FLT-Frq InsL prm3, Volume
28 D-sub Ba Hall 1 Flanger 1 Thru Thru ELFO-PM off off off off off PCH-Crs FLT-Frq ChoSend
29 Sine Sub Ba Stage 2 Phaser 2band EQ Distortion InsL prm10, AEG-Rel off off off off off InsL prm10

InsL prm10, AEG-

Rel InsL prm1
30 Compton Ba Room 2 Symphonic Compressor Low Resolution AEG-D1, RevSend off off off off off FLT-Frq, ChoSend ELM-Lvl AEG-Rel
31 Velo Ba Stage 2 Chorus 1 Thru Auto WAH

InsL prm10, RevSend,

ELM-Lvl off off off off off FLT-Rez FEG-Atk ChoSend
32 Boom Bass Ba Room 3 Symphonic Compressor Voice Cancelar PEG-Atk off off off off off InsL prm11 ELFO-PM ELFOSpd
33 Network Ba Room 2 Delay LR Thru Thru RevSend off off off off off FLT-Frq FEG-D1 ChoSend
34 Sonicbass Ba Hall 1 Tempo Delay2 Chorus 1 Thru off off off off off off off

ELFOSpd, PCH-Crs,
FLT-Frq

PCH-Crs, ELM-Lvl,

ChoSend
35 Snoop Ba Hall 1 Phaser 3band EQ Thru ELFO-PM off off off off off PCH-Crs FLT-Frq ChoSend, RevSend
36 Biscuit Ba Hall 1

Tempo Cross
Delay Flanger 1 Thru ELFO-FM, ELM-Lvl off off off off off InsS prm2

InsS prm10,

ChoSend InsS prm3
37 Monty Ba Room 3 Symphonic Compressor Voice Cancelar PEG-Atk off off off off off PCH-Fin ELFO-PM ELFOSpd
38 Downright Ba Hall 2 Control Delay1 Compressor

Odrv + 2Way Rotary
Speaker InsL prm14 off off off off off HPF-Frq InsL prm4 InsL prm1

39 Drone Ba Hall 2 Chorus 2 Compressor Tempo Delay 2

FLT-Frq, CLFOSpd,

FLT-Rez off off off off off ELM-Pan RevSend ChoSend
40 Additive Ba Stage 1 Chorus 1 Chorus 1 Low Resolution ELFO-FM off off off off off InsL prm1 InsL prm7 FEG-D1
41 FM Perko Ba Room 1 Chorus 2 Compressor V-Flanger

ChoSend, ELM-Lvl,

Volume off off off off off FLT-Frq RevSend FLT-Frq
42 Mediale St Hall 2 Chorus 1 Compressor Delay LCR

FLT-Frq, ChoSend,

Volume off off off off off AEG-Atk InsL prm10 ChoSend
43 Big Syn St Hall 2 Chorus 5 Exciter Cross Delay FLT-Frq, FLT-Rez off off off off off FLT-Frq ELM-Lvl ELM-Lvl
44 Chocolate St Hall 1 Chorus 1 3band EQ Cross Delay FLT-Frq, ELM-Lvl off off off off off FLT-Frq CLFO-D1 ChoSend
45 Chorus Pd Plate off Chorus 3 Talking Modulator CLFO-D1, CLFO-D2 off off off off off FLT-Frq InsL prm1 InsS prm3
46 Richchoir Vo Plate Chorus 1 3band EQ Thru CLFO-D1, CLFO-D2 off off off off off FLT-Frq CLFOSpd ChoSend
47 Chandelier Vo Hall 2 Ensemble Exciter Chorus 4

InsS prm1, ELM-Lvl,

FLT-Frq off off off off off FLT-Frq InsS prm1 FLT-Frq
48 Topia Vo Room 3 Tempo Delay1 3band EQ Ambience CLFO-D1, CLFO-D2 off off off off off FLT-Frq CLFOSpd InsL prm10
49 Sutra Vo Canyon Chorus 2 Chorus 2 Talking Modulator InsL prm1 off off off off off InsL prm1 CLFO-D1, CLFO-D2 CLFOSpd
50 Panmonks Vo Plate Delay LR Tremolo Ensemble Detune PCH-Fin off off off off off FLT-Frq InsS prm2, ELM-Lvl InsS prm1
51 Voicey Vo Hall 2 Chorus 1 Compressor Hall 2

ELM-Lvl, ELM-Lvl, FLT-

Frq off off off off off FLT-Rez RevSend ELM-Pan
52 TekkBrass Br Hall 1 Chorus 4 Distortion Cross Delay ChoSend, ELM-Lvl off ELFO-PM off off off FLT-Frq PCH-Fin ChoSend
53 CS80 Br Hall 1 Delay LR Thru Thru ELFO-PM off off off off off PCH-Crs FLT-Frq, FLT-Rez PEG-Dpt, AEG-Atk
54 One Horn Br Hall 2 Chorus 1 Compressor Tempo Cross Delay

FLT-Frq, ChoSend,

RevSend off off off off off FEG-Atk InsL prm10 FLT-Rez
55 T-Eight Br Hall 1 Delay LR Chorus 1 Compressor

ELFO-PM, CLFOSpd,

InsS prm10 off off off off off PCH-Crs FLT-Frq FEG-Atk
56 EgoSix Br Hall 2 Chorus 2 Compressor Early Ref 1

ChoSend, RevSend,

FLT-Frq off off off off off FEG-Atk InsL prm10 ChoSend
57 HausBrass Br Stage 2 Chorus 4 AMP Simulator Compressor PEG-Dpt off off off off off FLT-Frq InsS prm3 PCH-Fin
58 MX Sax Rd Room 3 Tempo Delay1 3band EQ Ambience CLFO-D1, CLFO-D2 off off off off off FLT-Frq CLFOSpd InsL prm10
59 Hoppy Sax Rd Hall 1 Chorus 2 Auto Wah LO-FI ELFO-PM, ELFOSpd off InsS prm9 off off off InsS prm3 InsL prm2 InsS prm1
60 Tech Lead Ld Hall 1 Ensemble Auto Wah Delay LR ELFO-PM off off off off off FLT-Frq InsS prm9 InsS prm1
61 Rap Lead 1 Ld Hall 1 Chorus 1 Thru Thru ELFO-PM off off off off off ChoSend FLT-Frq FLT-Rez
62 Rap Lead 2 Ld Hall 1 Chorus 1 Thru Thru ELFO-PM off off off off off ChoSend FLT-Frq FLT-Rez
63 Rap Lead 3 Ld Hall 1 Chorus 1 Thru Thru ELFO-PM off off off off off PCH-Crs FLT-Frq FLT-Rez
64 1 is more Ld Hall 1 Ensemble Thru Delay LR CLFO-D1 off off off off off FLT-Frq ChoSend AEG-Atk

7

No. Voice Name

Category

Reverb Type

Chorus Type Insertion1 Type Insertion2 Type MW PB AT FC BC FS RB Kn1 Kn2

65 EchoSaw Ld Hall 1 Tempo Delay2 2band EQ Phaser 2 CLFO-D1 off CLFO-D1 off off off FLT-Frq RevSend ChoSend
66 Sync Lead Ld Hall 1 Delay LR Exciter Ensemble Detune ELFO-PM off off off off off FLT-Frq InsS prm1 ELM-Lvl
67 X-File Ld Stage 1 Delay LR Thru V-Flanger ELFO-PM off off off off off PCH-Crs PorTime RevSend
68 Oasis Pd Hall 2 Celeste 4 Auto Pan Cross Delay ELFO-PM, ELFO-FM off off off off off FLT-Rez, FLT-Frq InsS prm1 PCH-Crs
69 Fat Sweep Pd Hall 2 Symphonic Chorus 4 Cross Delay ELFO-PM off off off off off FLT-Frq ChoSend InsL prm10
70 Luminosity Pd Hall 1 Chorus 1 Flanger 2 Delay LCR ELFO-AM off off off off off

InsS prm3, InsS
prm10 RevSend ChoSend

71 Sartori Pd Canyon Chorus 2 Phaser Auto Pan

ELM-Lvl, ELM-Lvl, FLT-

Frq off off off off off FLT-Frq InsL prm1 ChoSend
72 Jupiter Pd Hall 1 Chorus 1 Thru Celeste 2 ELFO-AM off off off off off FLT-Frq ELFOSpd InsL prm10
73 Wahbrass Pd Hall 2 Chorus 4 Exciter Tempo Phaser CLFO-D1 off off off off off FLT-Frq ELM-Lvl ELM-Lvl
74 Sine Pad Pd Hall 2 Chorus 1 Thru Symphonic CLFO-D1 off off off off off InsL prm1 ChoSend RevSend
75 RoundGlass Pd Stage 1 Celeste 1 Phaser Auto Pan ELFO-AM off off off off off PCH-Crs RevSend ChoSend
76 White Pad Pd Hall 2 Delay LR Chorus 4 Chorus 5 CLFO-D1 off off off off off FLT-Frq FLT-Frq

InsL prm1, InsL
prm2

77 Dark Angel Pd Tunnel

Tempo Cross
Delay Celeste 3 Thru

FLT-Rez, FLT-Frq,

ELM-Lvl FLT-Frq off off off off

InsS prm3, InsS

prm1 off off
78 Warmer Pd Hall 1 Chorus 1 Thru Thru CLFO-D1 off off off off off FLT-Frq RevSend ChoSend
79 Dazed Pd Hall 1 Chorus 1 Phaser Hall 1 FLT-Frq off off off off off PCH-Crs RevSend ChoSend
80 CM Pad Pd Hall 1 Symphonic Flanger 1 Cross Delay ELFO-PM off off off off off

FLT-Frq, AEG-Atk,

FLT-Rez ELM-Lvl InsS prm3
81 Panorama Pd Hall 1 Chorus 1 Thru Echo ELFO-PM off off off off off FLT-Frq ELM-Lvl ChoSend
82 Glacier Pd Stage 1

Tempo Cross
Delay Celeste 4 Harmonic Enhancer InsS prm1 off off off off off PCH-Crs ELM-Lvl ChoSend

83 Sunnydaze Pd Stage 1

Tempo Cross
Delay Chorus 1 Chorus 1 ELFO-AM, ELM-Lvl off off off off off InsL prm2

InsL prm10, InsS

prm10 ELFOSpd
84 Cronen Pd Plate off Chorus 3 Rotary Speaker 1 InsL prm1, InsL prm9 off off off off off InsS prm2 ELM-Lvl, ELM-Lvl InsS prm3
85 Sprinkler Pd Hall 1 Chorus 1 Thru V-Flanger ChoSend, Volume off off off off off PCH-Crs ELM-Lvl AEG-Atk, AEG-Rel
86 Nush Pd Room 3

Tempo Cross

Delay Celeste 3 Harmonic Enhancer ELFO-FM, ELFOSpd off off off off off ELFO-AM InsL prm1 InsL prm2
87 Ethereal Pd Plate Symphonic Thru Thru CLFO-D1 off off off off off FLT-Frq CLFOSpd ChoSend
88 HPFx Fx Hall 2 Ensemble Exciter Cross Delay CLFO-D1, ELM-Lvl off off off off off FLT-Frq FEG-Dpt InsL prm10
89 Sleep Fx Tunnel Chorus 5 Exciter Delay LR ELFO-FM off off off off off FLT-Frq InsL prm10 InsS prm2
90 Chlorophyl Fx Hall 2 Symphonic Auto Pan Talking Modulator ELM-Lvl off off off off off FLT-Frq InsS prm1 ChoSend
91 Mayflower Fx Canyon

Tempo Cross

Delay Flanger 3 Compressor ELFO-AM, PCH-Fin off off off off off PCH-Crs ELFOSpd, ELFO-PM InsS prm1
92 Light Ray Fx Hall 1 Chorus 1 Phaser Flanger 2 FLT-Frq off off off off off ELFOSpd PCH-Crs ELFO-AM
93 Algae Fx Stage 1 Symphonic Exciter Voice Cancelar InsS prm3, InsS prm2 off off off off off CLFO-D2 InsS prm1 CLFOSpd
94 So Deep Fx Hall 2 Symphonic Thru Thru FLT-Frq off off off off off PCH-Crs ELM-Lvl ChoSend
95 Jets Se Hall 1 Phaser Thru Phaser 2 ELFO-FM off off off off off InsL prm1 ChoSend FLT-Frq, PCH-Crs
96 Plukker Sc

White

Room Celeste 3 Thru Thru ELFO-PM off off off off off PCH-Crs FLT-Frq RevSend
97 G-na-G Sc Hall 2 Celeste 4 Chorus 2 Thru PCH-Fin, PCH-Fin off off off off off FLT-Frq, FLT-Rez RevSend FEG-D1
98 Del Mar Sc Stage 1 Chorus 1 Thru Delay LR FLT-Frq off off off off off FLT-Rez InsL prm10 ELM-Lvl
99 Pulse Clav Sc Hall 1 Phaser Thru Thru ELFO-PM off off off off off FLT-Frq FLT-Rez RevSend, ChoSend

100 Rezzo Sc Hall 2 Flanger 1 Compressor Control Delay1

FLT-Frq, ChoSend,

FLT-Rez off off off off off FLT-Frq FLT-Rez RevSend
101 Sebastian Sc Hall 2 Chorus 1 3band EQ Delay LCR ELFO-PM, ELFO-FM off off off off off FLT-Frq, FEG-D2 InsL prm10 ELM-Lvl
102 Saw Perc Sc Hall 1 Ensemble Flanger 1 Cross Delay ChoSend off off off off off FLT-Frq InsS prm10 InsL prm10
103 PolyPoly Sc Hall 1 Ensemble Auto Wah Delay LR FLT-Frq off off off off off FLT-Rez AEG-D2, FEG-Dpt InsS prm9
104 Portachord Sc Hall 1 Chorus 4 Thru Delay LR

FLT-Rez, FLT-Frq,

ChoSend off off off off off FLT-Frq FEG-Atk ChoSend
105 Play Hip Sc Room 1 Chorus 3 AMP Simulator Tempo Delay 2 FLT-Frq, RevSend off off off off off FLT-Rez ChoSend RevSend
106 Thin Man Sc Hall 2 Ensemble Compressor Cross Delay FLT-Frq off off off off off FLT-Frq AEG-Atk, AEG-Rel ChoSend, ELM-Lvl
107 Spitter Sc Hall 1 Chorus 1 3band EQ Flanger 1 ELFO-PM off off off off off

FLT-Frq, FLT-Rez,

FLT-Rez ELM-Lvl RevSend
108 Straight Sc Hall 1 Ensemble Celeste 4 Cross Delay ELFO-PM off off off off off FLT-Frq FLT-Rez ELM-Lvl
109 Arabesque Sc Hall 1 Chorus 1 Compressor Hall 2

FLT-Frq, ELM-Lvl,
ELM-Pan off off off off off FLT-Frq InsL prm13 AEG-D1

110 Tranzkor Sc Room 3 Chorus 2 Compressor Talking Modulator InsL prm1 off off off off off InsL prm1 ELM-Lvl

InsS prm3, InsS
prm5

111 Percolator Sc Basement Tempo Delay1 Thru Thru ELFO-PM off

ELFO-PM,

ELFOSpd off off off PCH-Crs RevSend ChoSend
112 AnalogSplt Co Hall 1 Chorus 1 Phaser Tempo Delay 2 ELFO-PM off ELFO-PM off off off FLT-Frq InsS prm1 InsL prm10
113 Opener Sq Hall 1

Tempo Cross
Delay Chorus 4 Tempo Phaser FLT-Frq, InsL prm10 off off off off off FLT-Frq FEG-Atk

ChoSend, InsL

prm10
114 Collusion Sq Stage 1 Chorus 1 Thru Delay LR FLT-Frq off off off off off ELM-Pan PCH-Crs ELFO-AM
115 Double Arp Sq Hall 1

Tempo Cross
Delay Thru Ensemble Detune FLT-Frq, InsL prm10 off off off off off FLT-Rez FEG-Atk

ChoSend, InsL

prm10
116 DX Flangi Sq Room 2 Tempo Delay1 Compressor Tempo Flanger

ChoSend, InsL prm10,
AEG-D1 off off off off off FLT-Frq ELM-Lvl RevSend

117 Circle Sq Hall 2 Phaser Compressor Tempo Delay 2

ELM-Lvl, AEG-D1,
ChoSend off off off off off FLT-Frq FLT-Rez RevSend

118 Laizer Sq Hall 2 Chorus 2 Compressor Tempo Delay 2

ELM-Lvl, FLT-Frq,

ChoSend off off off off off ELM-Lvl ELM-Dly InsL prm10
119 Healer Sq Room 1 Ensemble Phaser Delay LR ELFO-PM off off off off off PorTime RevSend InsL prm10
120 Chips Sq Hall 1

Tempo Cross
Delay Thru Ensemble Detune FLT-Frq, FEG-D1 off off off off off FLT-Frq FEG-D1, FLT-Frq InsL prm10

121 3D Light Sq Hall 2 Tempo Delay1 Phaser Hall 2

ELM-Lvl, FLT-Frq,

RevSend off off off off off ELM-Pan AEG-Atk ELM-Pan
122 Chordal Sq Hall 1 Chorus 4 Thru Delay LR AEG-D2, FLT-Frq off off off off off FLT-Frq PEG-Dpt

InsL prm10,
ChoSend

123 Soft Attck Sq Hall 1

Tempo Cross
Delay Thru Ensemble Detune AEG-D2, FEG-D1 off off off off off FLT-Frq ELM-Lvl, FLT-Frq InsL prm10

124 Orgmatic Sq Hall 2 Phaser Compressor Tempo Delay 2

InsL prm10, ELM-Lvl,

ELM-Lvl off off off off off FLT-Frq FLT-Rez RevSend
125 Short Cut Sq Hall 1 Delay LR Thru Thru FLT-Frq off off off off off FLT-Rez FEG-Atk FEG-Dpt, ELM-Lvl
126 StepSeq Sq Room 1 Ensemble Phaser Thru InsS prm10 off off off off off PCH-Crs RevSend ChoSend
127 Alone Sq Hall 1

Tempo Cross
Delay Compressor Ensemble Detune FLT-Frq FEG-D1 off off off off FLT-Frq ELM-Lvl InsL prm10

128 Spectral Sq

White
Room Ensemble Compressor Tempo Delay 1 AEG-D1, ChoSend ELM-Pan off off off off FLT-Frq FLT-Frq RevSend

8

Internal (MSB=63, LSB=8)

No. Voice Name

Category

Reverb Type

Chorus Type Insertion1 Type Insertion2 Type MW PB AT FC BC FS RB Kn1 Kn2

1 Generation Sq Hall 2

Tempo Cross

Delay Exciter Ensemble Detune FLT-Rez, FLT-Frq off off off off off FLT-Frq FLT-Rez InsS prm1
2 Champ Fx Hall 2 Delay LR Chorus 1 Ensemble Detune FLT-Rez, ELM-Lvl off off off off off FLT-Frq FEG-Atk InsL prm10
3 Puppy Sq Hall 2 Chorus 5 Auto Wah V-Distortion ELM-Lvl off off off off off RevSend InsL prm1 PCH-Crs
4

Insomnia Sc Hall 1 Tempo Phaser Compressor Thru FLT-Frq off off off off off PCH-Crs RevSend ELM-Lvl

5 Berlin Sc Hall 2 Flanger 3 Chorus 4 Cross Delay

ChoSend, ELM-Lvl,
FLT-Frq off off off off off FLT-Frq FLT-Frq PEG-Dpt

6 Frequencyz Sq off

Tempo Cross

Delay Thru Gate Reverb ChoSend off off off off off FLT-Frq, FLT-Frq FLT-Frq, FLT-Frq InsL prm10
7 1001 Sub Ba Stage 2 Ensemble Thru Echo ChoSend, ELM-Lvl off off off off off FLT-Frq FLT-Frq, FEG-D1 InsL prm10
8 Oberweich Pd Hall 1 Chorus 1 Thru Thru CLFO-D1 off off off off off FLT-Frq RevSend ChoSend
9 Hard road Sq Hall 1 Flanger 2 AMP Simulator Delay LR FEG-Atk, FLT-Frq off off off off off FLT-Frq FEG-Atk, FLT-Frq InsS prm6

10 Protection Fx Plate Symphonic Compressor Auto Synth

InsL prm10, AEG-Atk,

FEG-Atk off off off off off PCH-Fin InsL prm12 InsL prm3
11 Nodes Sq Room 3 Control Delay1 Compressor LO-FI InsL prm1 off off off off off InsL prm10 InsL prm2 PEG-Atk
12 Flangefilt Ld Hall 1

Tempo Cross
Delay Celeste 1 Tempo Flanger InsS prm10 off off off off off FLT-Frq InsL prm2, InsS prm3 InsS prm1, InsS prm2

13 FormaWheel Ba

White
Room Celeste 3 Compressor Talking Modulator InsL prm1, ChoSend off off off off off FLT-Frq, FLT-Frq AEG-Atk RevSend

14 Ambi Star Fx Hall 2 Ensemble Flanger 3 Cross Delay

FLT-Frq, FLT-Rez,

ChoSend off off off off off PCH-Crs InsS prm1 InsS prm10
15 Assembly Fx Hall 2 Celeste 4 3band EQ Talking Modulator InsL prm1, ELFO-FM off off off off off FLT-Frq InsL prm1 ELM-Lvl
16 Topnotched Fx Hall 1 Tempo Delay2 Thru Thru ChoSend off off off off off ELFO-AM ELFOSpd FLT-Frq, FLT-Frq
17 Foundation Sq Hall 1

Tempo Cross

Delay Exciter Ensemble Detune FLT-Frq off off off off off FLT-Frq InsS prm1 ChoSend
18 Sweepy Ba Hall 2 Chorus 4 Thru Delay LR FLT-Frq, ChoSend off off off off off FLT-Rez FEG-Atk InsL prm10, ChoSend
19 Roxy Fx Hall 2 Ensemble Chorus 4 Thru

CLFO-D1, CLFO-D2,

ELM-Lvl off off off off off FLT-Rez FEG-Dpt CLFOSpd
20 Quartz Sq Tunnel Control Delay1 Flanger 3 Voice Cancelar ELM-Lvl off off off off off InsS prm10 InsL prm11 InsL prm12
21 No-Tech Sq Hall 1 Ensemble Phaser Pitch Change 2 InsS prm1 off off off off off PCH-Crs ELM-Lvl InsS prm10
22 Atom Sq

White

Room Phaser Thru Talking Modulator ELFOSpd off off off off off ELM-Lvl InsL prm1 PCH-Crs
23 Mistubishi Ld Plate Chorus 2 Exciter Tech Modulation CLFO-D1, ELFO-FM off off off off off PCH-Fin InsS prm3 InsL prm2
24 Les Lee Fx Plate Ensemble Phaser Auto Pan

ELFO-FM, FLT-Frq,
ELFO-AM off off off off off InsS prm9 ELFOSpd InsL prm1

25 Synfonic Sq Hall 2 Chorus 1 Thru Tempo Cross Delay

InsL prm10, ChoSend,
FLT-Frq off off off off off FLT-Frq InsL prm10 RevSend

26 Bones Sc

White

Room Tempo Phaser Thru Noisy AEG-D1, ChoSend off off off off off FLT-Frq AEG-Atk, FLT-Frq ELM-Pan
27 Gleam Pd Hall 1 Delay LR Chorus 1 Thru ELFO-AM off off off off off PCH-Crs RevSend InsS prm10
28 Fuzzline Ba Hall 1 Phaser Distortion Delay LR ChoSend, ELM-Lvl off off off off off InsS prm4 InsS prm10, ELM-Lvl InsL prm10
29 Filtopia Sc Hall 1 Chorus 1 Compressor Hall 2

ELM-Lvl, ChoSend,

FLT-Frq off off off off off ELM-Pan FEG-Atk FLT-Frq
30 Perfecto Pd Hall 1 Delay LR Chorus 1 Thru CLFOSpd FLT-Frq off off off off FLT-Frq CLFO-D1 FLT-Frq, FLT-Frq
31 Let’s Goa Ba Plate Tempo Flanger Phaser Tempo Cross Delay ChoSend, RevSend off off off off off InsS prm2 ELM-Lvl, ELM-Lvl PCH-Crs
32 X-Talk Sq

White
Room Celeste 3 Compressor Talking Modulator

InsL prm1, ChoSend,

Volume off off off off off AEG-D1 ELM-Lvl RevSend
33 Shine Seq Sq Hall 1

Tempo Cross
Delay Chorus 1 Ensemble Detune FLT-Rez off off off off off FLT-Rez

FLT-Frq, ELM-Lvl,
CLFO-D1 FLT-Rez

34 Alphawaves Fx Canyon

Tempo Cross

Delay Phaser Flanger 3 ELFO-AM off off off off off CLFOSpd ELFOSpd, ELFOSpd ELFO-PM, CLFO-D2
35 Sheen Sc Hall 1 Chorus 1 Auto Wah Cross Delay InsS prm2 off off off off off FLT-Frq ChoSend InsL prm10
36 Vector Fx Hall 1 Ensemble Celeste 1 Flanger 1 InsS prm1 off off off off off PCH-Crs ELM-Lvl ChoSend
37 Hacker Se Hall 1

Tempo Cross

Delay Compressor Gate Reverb ELFO-FM off off off off off ELFOSpd CLFO-D1 CLFO-D2
38 Leftfield Sq Stage 1 Chorus 1 Thru Delay LR FEG-D1 off off off off off FLT-Frq ChoSend RevSend
39

DontLetGo Fx Hall 1 Control Delay1 Chorus 4 Delay LR

ELFO-PM, ELFO-FM,
ELFOSpd off off off off off FLT-Frq PCH-Crs RevSend

40 ChimzArt Fx Hall 1 Chorus 1 Compressor Hall 2

ELM-Lvl, ELM-Lvl,

Volume off off off off off FLT-Frq ChoSend ELM-Pan
41 Frontline Ld Hall 1 Ensemble Distortion Cross Delay ChoSend, ELM-Lvl off off off off off FLT-Frq PCH-Fin ChoSend
42 Kickwheel Sq Hall 1 Tempo Flanger Distortion Delay LR ELM-Lvl, ChoSend off off off off off FLT-Frq InsL prm10, ELM-Lvl HPF-Frq
43 Fat Four Sq Hall 2 Tempo Delay1 Chorus 1 Touch Wah Overdrive

ELM-Lvl, FLT-Frq,

RevSend off off off off off ELM-Pan FEG-Atk AEG-Rel
44 D-tune Ld Hall 1

Tempo Cross

Delay Thru Thru CLFO-D1 off off off off off CLFOSpd ELFOSpd, ELFO-FM PCH-Fin, PCH-Fin
45 Eb drone Fx Hall 1 Flanger 1 Thru Hall 1 AEG-D1, Volume off off off off off PCH-Crs FLT-Rez, FLT-Frq InsL prm15
46 Dreamscape Sq Plate Tempo Delay1 Thru Ensemble Detune FLT-Rez, FLT-Frq off off off off off FLT-Frq FEG-Atk, ChoSend InsL prm10
47 Hades Fx Hall 1 Delay LR Thru Celeste 2 ELFO-PM off off off off off FLT-Frq RevSend ChoSend
48 Manufactur Se Room 1 Ensemble Phaser Delay LR ELFO-PM off off off off off CLFO-D1 ELM-Pan, ELM-Pan RevSend
49 Liquito Sc Hall 1 Chorus 1 Compressor V-Flanger

AEG-Rel, FLT-Frq,
AEG-D1 off off off off off FLT-Frq FLT-Rez RevSend

50 Kustom Br Hall 2 Chorus 1 Compressor Tempo Cross Delay

FLT-Frq, RevSend,

ChoSend off off off off off FLT-Frq ELM-Lvl InsL prm10
51 S - E Se Stage 2 Chorus 1 Flanger 3 Tempo Cross Delay ELFO-PM off off off off off InsS prm3, FLT-Frq InsS prm1 InsS prm3
52 Dew Drop Fx Stage 1 Tempo Delay1 Phaser Pitch Change 2 InsS prm1 off off off off off PCH-Crs ELM-Lvl InsL prm10, ChoSend
53 Talitha Fx Room 3 Delay LR Auto Wah

2Way Rotary Speaker

2 PCH-Fin off off off off off InsS prm3 InsL prm9 InsS prm2
54 Thruster Ld Hall 1 Ensemble Distortion Cross Delay FLT-Frq off off off off off FLT-Frq InsS prm10, FEG-Atk InsL prm10, ChoSend
55 Polystar Sq Hall 1 Ensemble Thru Delay LR AEG-D2, FEG-D1 off off off off off FLT-Frq FEG-D1, FLT-Frq InsL prm10
56 Syntax Ld Hall 1 Ensemble Flanger 3 Delay LCR FLT-Frq off off off off off FLT-Frq InsS prm10 ChoSend
57 Supersnap Sq Hall 1 Phaser Compressor Delay LR ELM-Lvl off off off off off FLT-Frq ELM-Lvl ChoSend, InsL prm10
58 Noire Fx Plate Ensemble Chorus 4 Ensemble Detune ELFO-PM off off off off off FLT-Frq InsS prm3, InsS prm2 PCH-Crs
59 Shadow Pd Hall 2 Flanger 1 Celeste 4 Jump InsL prm2, ChoSend off off off off off FLT-Frq FLT-Frq InsL prm9
60 Vortex Pd

White
Room Chorus 1 Flanger 3 Thru ELFO-PM, ELFO-FM off off off off off

InsS prm3, InsS

prm2, InsS prm1 PCH-Crs off
61 BPFx Fx Hall 2 Ensemble Chorus 4 Cross Delay CLFO-D1, ELM-Lvl off off off off off FLT-Frq FEG-Dpt InsL prm10
62 Wazzo Ba Room 3 Chorus 4 Compressor Harmonic Enhancer

AEG-Atk, AEG-Rel,

Volume off off off off off FEG-Dpt ELM-Lvl InsL prm1
63 Andromeda Fx Stage 1 Delay LR Phaser Flanger 1 InsS prm1 off off off off off PCH-Crs RevSend ChoSend
64 Squeezer Sq Hall 1 Ensemble Phaser Pitch Change 2 InsS prm1 off off off off off InsS prm4 ELM-Lvl RevSend

9

No. Voice Name

Category

Reverb Type

Chorus Type Insertion1 Type Insertion2 Type MW PB AT FC BC FS RB Kn1 Kn2

65 Watergate Sq Hall 1

Tempo Cross
Delay Thru Ensemble Detune

FLT-Frq, FLT-Rez,

ELM-Lvl off off off off off FLT-Rez FLT-Frq FLT-Rez

66 Banshee Se

White

Room Phaser Flanger 1 WAH+Dist+Delay InsL prm12 off off off off off FLT-Frq InsL prm13 InsL prm2
67 Sputnik Fx Hall 1 Chorus 1 Thru Thru AEG-Atk, AEG-Rel off off off off off PCH-Crs PCH-Crs ELFOSpd, CLFOSpd
68 Massacre Ba Room 3 Symphonic Compressor

Odrv + 2Way Rotary

Speaker ELM-Lvl off off off off off FLT-Frq PEG-Dpt InsL prm4
69 NuAcid Sq Hall 2 Chorus 1 Auto Pan Delay LR FLT-Frq off off off off off ELM-Pan, ELM-Pan FEG-Dpt InsL prm5
70 DigJee Sc

White
Room Chorus 2 Compressor Tempo Delay 1

AEG-D1, ChoSend,

FLT-Frq off off off off off FLT-Frq RevSend AEG-Rel
71 Scabs Se Canyon Delay LR Thru Reverse Gate ELFOSpd, ELFO-FM off off off off off PCH-Crs ChoSend RevSend
72 Big Wing Pd Stage 1 Ensemble Celeste 4 Harmonic Enhancer ELM-Lvl off off off off off PCH-Crs InsL prm3 RevSend
73 Techbass Ba Room 1

Tempo Cross

Delay Compressor Reverse Gate ChoSend off off off off off RevSend FEG-D1, FLT-Frq ELM-Lvl, ELM-Lvl
74 Kane Ld Hall 1 Chorus 4 Distortion Cross Delay FLT-Frq off off off off off FLT-Frq InsS prm3, ELM-Lvl InsS prm1
75 Voltage Se Hall 2 Flanger 2 AMP Simulator Auto Synth InsL prm13 off off off off off InsL prm3 InsL prm1 ChoSend, ELM-Lvl
76 Rabbit Sq Hall 1 Tempo Flanger Distortion Delay LR

FEG-Atk, InsS prm9,
InsS prm1 off off off off off FLT-Frq FEG-Atk InsS prm4

77 Lenanshee Fx Hall 1 Symphonic Auto Pan Auto Synth

InsL prm10, AEG-Atk,
FEG-Atk off off off off off PCH-Fin InsL prm12 InsL prm3

78 ShineWave Pd

White
Room Ensemble Phaser V-Flanger InsL prm1 off off off off off ELFO-FM FLT-Frq

InsL prm10, InsL
prm14

79 Mr. Hook Sq Hall 1

Tempo Cross

Delay Thru Celeste 4 FLT-Frq off off off off off FLT-Frq InsL prm10, ELM-Lvl ChoSend
80 Creature Se Hall 1 Control Delay1 Thru Pitch Change 2 FLT-Frq off off off off off PCH-Crs RevSend ChoSend
81 Rezorgan Sq Hall 1

Tempo Cross

Delay Compressor Chorus 1 ELFO-FM off off off off off FLT-Frq, FLT-Frq PCH-Crs, InsL prm10 ELFOSpd
82 Popcorn Sq Hall 1 Chorus 1 Chorus 1 Delay LR CLFO-D1 off off off off off FLT-Frq RevSend InsS prm10
83 Shanti Vo Hall 1 Tempo Delay2 Flanger 1 Tempo Cross Delay ELFO-AM, Volume off off off off off ELM-Lvl ELFOSpd InsS prm3
84 FullHouz Sc

White
Room

Tempo Cross

Delay Auto Pan Noisy

ELM-Lvl, ChoSend,

AEG-D1 off off off off off FLT-Frq ChoSend RevSend
85 Brown Eyes Fx Plate Symphonic Exciter Auto Synth InsL prm10, FEG-Atk off off off off off FLT-Frq, FLT-Frq InsL prm12 InsL prm3
86 MGul Sq Hall 2 Chorus 2 Compressor Tempo Cross Delay

FLT-Frq, RevSend,

ChoSend off off off off off ELM-Pan FLT-Frq InsL prm10
87 Knobmod Se Tunnel off Thru Auto Synth ELFO-PM off off off off off InsL prm3 InsL prm1, CLFOSpd

InsL prm15, ELFO-PM
88 90th Jimi Fx Hall 1 Flanger 2 AMP Simulator Jump ChoSend, FLT-Frq off off off off off FLT-Frq FEG-Atk, FLT-Frq InsS prm6
89 Twilight Fx Canyon

Tempo Cross
Delay Celeste 4 Pitch Change 1 ELFO-AM, ELFOSpd off off off off off PCH-Crs ELFOSpd, CLFOSpd PCH-Crs

90 Wheels Fx Hall 1 Flanger 1 3band EQ Auto Synth

ELFO-AM, ELFO-PM,
InsL prm4, FLT-Rez off off off off off PCH-Crs InsL prm1 off

91 Seal Sq Hall 2

Tempo Cross

Delay Chorus 4 Ensemble Detune FLT-Rez, ELM-Lvl off off off off off FLT-Rez, ELM-Lvl ELM-Lvl ChoSend
92 Rndm Gruv Fx Hall 2 Ensemble Chorus 4 Cross Delay CLFO-D1, ChoSend off off off off off FLT-Frq ChoSend, ELM-Lvl CLFO-D2
93 Molecule Fx Hall 1

Tempo Cross

Delay Phaser Ensemble Detune

ELFO-FM, InsS prm1,

InsS prm2 off off off off off off ELFOSpd ELM-Lvl, ELM-Lvl
94 Big Wave Pd Hall 1 Delay LR Auto Pan Chorus 1 InsL prm1 off off off off off PCH-Crs RevSend ChoSend
95 Gunman Ba Hall 1 Chorus 1 Compressor Thru AEG-Atk, FLT-Frq off off off off off PCH-Fin, PCH-Fin ChoSend RevSend
96 Drumnotize Se Hall 1 Chorus 1 3band EQ AMP Simulator FLT-Frq off off off off off InsL prm10 ELFO-PM PCH-Crs
97 Capacitor Ld Plate Tempo Delay1 Compressor V-Distortion PEG-Atk ELFO-PM ELM-Lvl off off off FLT-Frq InsL prm1 InsL prm4
98 Answers Pd Hall 1 Chorus 1 Thru Delay LR PCH-Fin, PCH-Fin off off off off off ELM-Pan ELM-Dly RevSend
99 Fun(k:-) Sq Room 1 Control Delay2 Compressor Low Resolution ChoSend, RevSend off off off off off FLT-Frq AEG-D2 FLT-Frq

100 Android Sq Hall 1

Tempo Cross
Delay Compressor Ensemble Detune ELM-Lvl, InsL prm10 off off off off off ChoSend ELM-Lvl InsS prm3, InsS prm5

101 Teardrops Fx Room 3 Control Delay1 Phaser Compressor

InsS prm4, AEG-Atk,

Volume off off off off off FLT-Frq InsS prm10 InsS prm1

102 DJ Vox Sc

White
Room Chorus 2 Compressor Low Resolution

InsL prm1, ChoSend,

ELM-Lvl off off off off off FLT-Frq RevSend FLT-Frq

103 QuietEarth Pd Hall 1 Flanger 3 Phaser Harmonic Enhancer PCH-Fin, PCH-Fin off off off off off FLT-Frq, InsS prm9 ChoSend InsS prm1
104 Blackhole Sq Plate Phaser Thru Beat Change InsL prm1 off off off off off InsL prm2 InsL prm3 InsL prm4
105 Drifting Fx Plate Chorus 5 Exciter Delay LR CLFO-D1 off off off off off FLT-Frq

InsS prm2, ELM-Lvl,
ELM-Lvl InsL prm10

106 Navigator Sq Hall 2

Tempo Cross

Delay Thru Ensemble Detune FLT-Frq off off off off off FLT-Rez FEG-Atk ChoSend
107 Binary Sq Stage 1 Chorus 1 Thru Tempo Phaser PCH-Crs off off off off off FLT-Frq RevSend ELM-Lvl
108 Blu Sq Hall 1 Delay LR Thru Hall 1

FLT-Frq, FLT-Frq,

ChoSend off off off off off ELM-Lvl AEG-Rel ELM-Lvl
109 Rosy Sq Hall 1 Ensemble Thru Delay LR FLT-Frq off off off off off FLT-Frq FEG-Atk InsL prm10
110 Psycho Fx Hall 1 Chorus 1 Thru Harmonic Enhancer ELFO-PM off FLT-Rez off off off FLT-Frq, ELM-Lvl RevSend PCH-Crs
111 Dog Ba Stage 2 Chorus 1 AMP Simulator Delay LR HPF-Frq, FLT-Frq off off off off off FLT-Frq HPF-Frq InsL prm10
112 Pneumatic Sq Hall 1 Delay LR Overdrive Delay LR FLT-Frq off off off off off PCH-Crs AEG-Rel InsS prm10
113 SpaceWhirl Ld Tunnel Tempo Delay2 Compressor Tempo Phaser

InsL prm10, FLT-Frq,

AEG-Rel off off off off off FLT-Frq RevSend ChoSend
114 Phantom Fx Hall 1 Delay LR Chorus 1 Reverse Gate InsS prm10 off off off off off PCH-Crs

InsL prm10, ChoSend

ELFO-FM, CLFO-D2
115 Millennium Se Hall 1 Flanger 1 Exciter Hall 2 ELFO-PM, ELFO-FM off off off off off PEG-Dpt, FLT-Frq InsS prm1 PCH-Crs
116 Auto Saw Fx Hall 2 Chorus 4 Thru Thru ELFOSpd off off off off off FLT-Frq ELM-Lvl ELM-Lvl
117 Bel Air Fx Hall 2 Chorus 4 Exciter Flanger 3

InsS prm1, FLT-Rez,
FLT-Frq off off off off off FLT-Frq InsL prm10 ChoSend

118 Magnetic Ba Canyon

Tempo Cross
Delay Thru Compressor ELM-Lvl off off off off off ChoSend FLT-Frq, FLT-Frq CLFOSpd, ELFOSpd

119 Phalaxi Sq Hall 1 Tempo Phaser Compressor Hall 2

ChoSend, RevSend,

FLT-Frq off off off off off ELM-Pan FLT-Rez InsL prm10
120 Atlantis Pd Hall 2 Ensemble Phaser Flanger 3 CLFO-D1, CLFO-D2 off off off off off FLT-Rez FLT-Frq InsS prm10
121 Slipmat Ld Hall 1 Ensemble 3band EQ Delay LR InsL prm10 off off off off off FLT-Rez PCH-Crs ELM-Lvl
122 DigiSweep Pd Hall 2 Chorus 5 Compressor Tempo Cross Delay

FLT-Frq, FEG-Dpt,

RevSend off off off off off InsL prm10 ChoSend RevSend
123 4000 Volts Fx Hall 1 Chorus 1 Chorus 3 Flanger 1 FLT-Frq off InsL prm3 off off off ELFO-AM PEG-Dpt FEG-Atk
124 Nusic Se Hall 1 Delay LR Auto Pan Thru CLFOSpd off off off off off PCH-Crs RevSend ChoSend
125 Sahara Pd Hall 1 Chorus 1 Flanger 1 Hall 1 ELM-Lvl off off off off off PCH-Crs AEG-Atk ChoSend
126 2 Friends Sq Hall 2 Tempo Delay2 Phaser Hall 2

ELM-Lvl, ChoSend,

AEG-D1 off off off off off ELM-Pan InsS prm10 FLT-Frq
127 Modsound Se Canyon Tempo Delay2 Thru Touch WAH Distortion ELFOSpd

InsL
prm10 off off off off RevSend InsL prm1 PEG-D2, PEG-Atk

128 Machinhead Sq Stage 1 Flanger 1 Phaser Auoto WAH Overdrive InsL prm1 off off off off off InsL prm14 InsL prm10 ChoSend

10

Drum Voice List

Preset (MSB=63, LSB=32)

1 Rock Kit 2 House Kit

Note ElmAsgn Wave No. Wave Name Note ElmAsgn Wave No. Wave Name

C 0 378 Dr BdVar5 C 0 off
C#0 389 Dr SdPcBH C#0 off
D 0 391 Dr SdWdH D 0 off
D#0 392 Dr SdVar1 D#0 off
E 0 376 Dr BdVar3 E 0 on 433 Dr Crash
F 0 405 Dr SdRoll F 0 on 373 Dr BdLoJz
F#0 382 Dr SdBldH F#0 on 367 Pc CONG
G 0 400 Dr SdDry G 0 on 382 Dr SdBldH
G#0 408 Dr Stick G#0 on 367 Pc CONG
A 0 377 Dr BdVar4 A 0 on 476 Dr EuroBD
A#0 389 Dr SdPcBH A#0 on 437 Dr T8BdBm
B 0 374 Dr BdVar1 B 0 on 457 Dr T9BD2
C 1 371 Dr BdPop C 1 on 458 Dr T9BD3
C#1 407 Dr C.Rim2 C#1 on 466 Dr T9Rim
D 1 387 Dr SdHvy D 1 on 460 Dr T9SD2
D#1 358 Pc Clap D#1 on 444 Dr T8Rmst
E 1 380 Dr SdGM E 1 on 463 Dr T9SD5
F 1 418 Dr Tom2L F 1 on 467 Dr T9TomL
F#1 423 Dr HHCl5 F#1 on 470 Dr T9HHC1
G 1 418 Dr Tom2L G 1 on 468 Dr T9TomM
G#1 425 Dr HHPdl2 G#1 on 471 Dr T9HHC2
A 1 418 Dr Tom2L A 1 on 469 Dr T9TomH
A#1 426 Dr HHOpn A#1 on 472 Dr T9HHO1
B 1 417 Dr Tom2H B 1 on 469 Dr T9TomH
C 2 417 Dr Tom2H C 2 on 473 Dr T9HHO2
C#2 433 Dr Crash C#2 on 474 Dr T9Crsh
D 2 417 Dr Tom2H D 2 on 475 Dr T9Ride
D#2 429 Dr Ride D#2 on 465 Dr T9Clap
E 2 435 Dr China E 2 on 362 Pc AnvlPp
F 2 431 Dr Cup F 2 on 456 Dr T9BD1
F#2 354 Pc Tmborn F#2 on 389 Dr SdPcBH
G 2 434 Dr Crash2 G 2 on 369 Pc WdBlk
G#2 340 Pc Cowbel G#2 on 362 Pc AnvlPp
A 2 434 Dr Crash2 A 2 on 367 Pc CONG
A#2 356 Pc VbSlp A#2 on 361 Pc AnvlHt
B 2 432 Dr Cup2 B 2 on 368 Pc StlClp
C 3 336 Pc BongoH C 3 on 366 Pc Ripper
C#3 335 Pc BongoL C#3 on 367 Pc CONG
D 3 339 Pc CngSlp D 3 on 452 Dr T8CngH
D#3 338 Pc CongaH D#3 on 452 Dr T8CngH
E 3 337 Pc CongaL E 3 on 452 Dr T8CngH
F 3 345 Pc TmblsH F 3 on 452 Dr T8CngH
F#3 344 Pc TmblsL F#3 on 449 Dr T8Crsh
G 3 341 Pc AgogoL G 3 on 447 Dr T8HHCl
G#3 341 Pc AgogoL G#3 on 448 Dr T8HHOp
A 3 349 Pc Cabasa A 3 on 355 Pc TrangL
A#3 352 Pc Maracs A#3 on 455 Dr T8Mrcs
B 3 435 Dr China B 3 on 355 Pc TrangL
C 4 434 Dr Crash2 C 4 on 353 Pc Shaker
C#4 355 Pc TrangL C#4 on 361 Pc AnvlHt
D 4 101 Cp FngCym D 4 on 361 Pc AnvlHt
D#4 350 Pc Claves D#4 on 454 Dr T8Clve
E 4 348 Pc Wdblck E 4 on 365 Pc VoxDrm
F 4 348 Pc Wdblck F 4 on 477 Dr DstKik
F#4 113 Cp Timpni F#4 on 449 Dr T8Crsh
G 4 113 Cp Timpni G 4 on 357 Pc JnglBl
G#4 355 Pc TrangL G#4 on 354 Pc Tmborn
A 4 355 Pc TrangL A 4 on 354 Pc Tmborn
A#4 353 Pc Shaker A#4 on 322 Fx BigSyn
B 4 357 Pc JnglBl B 4 on 322 Fx BigSyn
C 5 370 Dr BdStd C 5 on 319 Fx Melow
C#5 394 Dr SdRim1 C#5 on 328 Fx VxAlk
D 5 382 Dr SdBldH D 5 on 328 Fx VxAlk
D#5 387 Dr SdHvy D#5 on 328 Fx VxAlk
E 5 392 Dr SdVar1 E 5 on 439 Dr T8SD1
F 5 393 Dr SdVar2 F 5 on 359 Pc Whistl
F#5 396 Dr SdAmb1 F#5 on 388 Dr SdPclH
G 5 383 Dr SdFsnH G 5 on 437 Dr T8BdBm
G#5 398 Dr SdAmb3 G#5
A 5 388 Dr SdPclH A 5
A#5 372 Dr BdHby A#5
B 5 372 Dr BdHby B 5
C 6

on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on 373 Dr BdLoJz C 6

3 Hip Kit

4 Trance Kit

Note ElmAsgn Wave No. Wave Name Note ElmAsgn Wave No. Wave Name

C 0 on 477 Dr DstKik C 0 on 437 Dr T8BdBm
C#0 on 378 Dr BdVar5 C#0 on 451 Dr T8CngM
D 0 on 377 Dr BdVar4 D 0 on 438 Dr T8Bd
D#0 on 437 Dr T8BdBm D#0 on 452 Dr T8CngH
E 0 on 456 Dr T9BD1 E 0 on 457 Dr T9BD2
F 0 on 382 Dr SdBldH F 0 on 457 Dr T9BD2
F#0 on 388 Dr SdPclH F#0 on 367 Pc CONG
G 0 on 390 Dr SdPrmH G 0 on 459 Dr T9SD1
G#0 on 439 Dr T8SD1 G#0 on 367 Pc CONG
A 0 on 399 Dr SdBkBt A 0 on 476 Dr EuroBD
A#0 on 404 Dr SdBrsL A#0 on 476 Dr EuroBD
B 0 on 437 Dr T8BdBm B 0 on 457 Dr T9BD2
C 1 on 379 Dr BdAna C 1 on 458 Dr T9BD3
C#1 on 407 Dr C.Rim2 C#1 on 466 Dr T9Rim
D 1 on 394 Dr SdRim1 D 1 on 459 Dr T9SD1
D#1 on 445 Dr T8Clap D#1 on 477 Dr DstKik
E 1 on 389 Dr SdPcBH E 1 on 462 Dr T9SD4
F 1 on 409 Dr TomF F 1 on 467 Dr T9TomL
F#1 on 420 Dr HHCL2 F#1 on 470 Dr T9HHC1
G 1 on 409 Dr TomF G 1 on 468 Dr T9TomM
G#1 on 447 Dr T8HHCl G#1 on 471 Dr T9HHC2
A 1 on 410 Dr TomL A 1 on 469 Dr T9TomH
A#1 on 426 Dr HHOpn A#1 on 472 Dr T9HHO1
B 1 on 411 Dr TomM B 1 on 469 Dr T9TomH
C 2 on 412 Dr TomHL C 2 on 473 Dr T9HHO2
C#2 on 433 Dr Crash C#2 on 474 Dr T9Crsh
D 2 on 413 Dr TomHH D 2 on 475 Dr T9Ride
D#2 on 430 Dr Ride2 D#2 on 465 Dr T9Clap
E 2 on 435 Dr China E 2 on 362 Pc AnvlPp
F 2 on 432 Dr Cup2 F 2 on 456 Dr T9BD1
F#2 on 354 Pc Tmborn F#2 on 389 Dr SdPcBH
G 2 on 434 Dr Crash2 G 2 on 369 Pc WdBlk
G#2 on 367 Pc CONG G#2 on 362 Pc AnvlPp
A 2 on 434 Dr Crash2 A 2 on 366 Pc Ripper
A#2 on 356 Pc VbSlp A#2 on 361 Pc AnvlHt
B 2 on 429 Dr Ride B 2 on 368 Pc StlClp
C 3 on 331 Fx AHoseL C 3 on 437 Dr T8BdBm
C#3 on 332 Fx AHoseR C#3 on 367 Pc CONG
D 3 on 339 Pc CngSlp D 3 on 452 Dr T8CngH
D#3 on 338 Pc CongaH D#3 on 452 Dr T8CngH
E 3 on 337 Pc CongaL E 3 on 452 Dr T8CngH
F 3 on 345 Pc TmblsH F 3 on 452 Dr T8CngH
F#3 on 344 Pc TmblsL F#3 on 449 Dr T8Crsh
G 3 on 362 Pc AnvlPp G 3 on 447 Dr T8HHCl
G#3 on 362 Pc AnvlPp G#3 on 448 Dr T8HHOp
A 3 on 353 Pc Shaker A 3 on 355 Pc TrangL
A#3 on 352 Pc Maracs A#3 on 455 Dr T8Mrcs
B 3 on 363 Pc Scrch1 B 3 on 355 Pc TrangL
C 4 on 438 Dr T8Bd C 4 on 320 Fx WndChm
C#4 on 368 Pc StlClp C#4 on 321 Fx BelAir
D 4 on 383 Dr SdFsnH D 4 on 322 Fx BigSyn
D#4 on 465 Dr T9Clap D#4 on 326 Fx Electr
E 4 on 393 Dr SdVar2 E 4 on 327 FX HH Hit
F 4 on 357 Pc JnglBl F 4 on 328 Fx VxAlk
F#4 on 470 Dr T9HHC1 F#4 on 328 Fx VxAlk
G 4 on 355 Pc TrangL G 4 on 329 Fx HiLo
G#4 on 471 Dr T9HHC2 G#4 on 329 Fx HiLo
A 4 on 355 Pc TrangL A 4 on 318 Fx VoxBel
A#4 on 472 Dr T9HHO1 A#4 on 318 Fx VoxBel
B 4 on 329 Fx HiLo B 4 on 325 Fx Eery
C 5 on 325 Fx Eery C 5 on 258 Wv FMBs1
C#5 on 474 Dr T9Crsh C#5 on 258 Wv FMBs1
D 5 on 435 Dr China D 5 on 258 Wv FMBs1
D#5 on 318 Fx VoxBel D#5 on 258 Wv FMBs1
E 5 on 319 Fx Melow E 5 on 258 Wv FMBs1
F 5 on 255 Wv MogBs1 F 5 on 258 Wv FMBs1
F#5 on 354 Pc Tmborn F#5 on 258 Wv FMBs1
G 5 on 364 Pc Scrch2 G 5 on 258 Wv FMBs1
G#5 on 475 Dr T9Ride G#5 on 258 Wv FMBs1
A 5 on 325 Fx Eery A 5 on 258 Wv FMBs1
A#5 on 327 FX HH Hit A#5 on 258 Wv FMBs1
B 5 on 323 Fx TrnCho B 5 on 258 Wv FMBs1
C 6 on 323 Fx TrnCho C 6 on 258 Wv FMBs1

off
off
off
off
off

11

5Nasty Kit 6Brush Kit

Note ElmAsgn Wave No. Wave Name

Note ElmAsgn Wave No. Wave Name

Dr T8Bd

C 0

Dr BdVar4

C#0

Pc CongaL

D 0

Dr BdAna

D#0

Dr T9BD3

E 0

Dr SdAmb2

F 0

Dr SdRim2

F#0

Dr T8SD1

G 0

Dr T8SD3

G#0

Dr SdBrsH

A 0

Dr SdAmb3

A#0

Dr EuroBD

B 0

Dr T9BD3

C 1

Fx HiLo

C#1

Dr T9SD4

D 1

Dr T8Clap

D#1

Pc WdBlk

E 1

Wv Noise

F 1

Dr HHCl5

F#1

Wv Noise

G 1

Dr T9HHC1

G#1

Wv Noise

A 1

Dr T9HHO1

A#1

Dr T om2L

B 1

Dr T om2H

C 2

Dr T9Crsh

C#2

Dr T om2H

D 2

Fx Eery

D#2

Dr China

E 2

Dr Cup2

F 2

Pc Tmborn

F#2

Dr Crash

G 2

Wv MogBs1

G#2

Dr Crash2

A 2

Pc VbSlp

A#2

Dr Ride

B 2

Fx VxAlk

C 3

FX HH Hit

C#3

Pc TmblsH

D 3

Pc CongaH

D#3

Pc CongaL

E 3

Fx BelAir

F 3

Fx Electr

F#3

Pc AnvlPp

G 3

Pc AnvlPp

G#3

Pc Shaker

A 3

Pc Maracs

A#3

Pc Bltree

B 3

Dr T8Bd

C 4

Fx VoxBel

C#4

Dr SdAmb2

D 4

Dr T9Clap

D#4

Dr SdRim1

E 4

Fx MltPno

F 4

Dr T8HHCl

F#4

Pc AnvlHt

G 4

Dr T9HHC2

G#4

Pc AnvlHt

A 4

Dr T8HHOp

A#4

Fx Eery

B 4

Fx Eery

C 5

350
404
401
403
401
405
351
404
408
376
403
377
373
403
404
358
402
414
422
414
424
414
426
415
416
433
416
429
430
431
354
434
340
434
429
432
336
335
339
338
337
345
344
341
341
349
352
359
359
343
342
350
348
348
346
347
355
355
353
357
360

Pc Claves
Dr SdBrsL
Dr SdSwep
Dr SdBrsH
Dr SdSwep
Dr SdRoll
Pc Castnt
Dr SdBrsL
Dr Stick
Dr BdVar3
Dr SdBrsH
Dr BdVar4
Dr BdLoJz
Dr SdBrsH
Dr SdBrsL
Pc Clap
Dr SdBrsS
Dr TmJzL
Dr HHCl4
Dr TmJzL
Dr HHPdl
Dr TmJzL
Dr HHOpn
Dr TmJzM
Dr TmJzH
Dr Crash
Dr TmJzH
Dr Ride
Dr Ride2
Dr Cup
Pc Tmborn
Dr Crash2
Pc Cowbel
Dr Crash2
Dr Ride
Dr Cup2
Pc BongoH
Pc BongoL
Pc CngSlp
Pc CongaH
Pc CongaL
Pc TmblsH
Pc TmblsL
Pc AgogoL
Pc AgogoL
Pc Cabasa
Pc Maracs
Pc Whistl
Pc Whistl
Pc GiroCl
Pc GuiroL
Pc Claves
Pc Wdblck
Pc Wdblck
Pc CuicaL
Pc CuicaH
Pc T rangL
Pc T rangL
Pc Shaker
Pc JnglBl
Pc Bltree

Dr T9Crsh

C#5

Dr China

D 5

Fx VoxBel

D#5

Dr T8Crsh

E 5

En VxNoiz

F 5

Pc Tmborn

F#5

Pc Ripper

G 5

Dr T9Ride

G#5

Dr T8CngL

A 5

Dr T8CngM

A#5

Dr TmJzH

B 5

C 0
C#0
D 0
D#0
E 0
F 0
F#0
G 0
G#0
A 0
A#0
B 0
C 1
C#1
D 1
D#1
E 1
F 1
F#1
G 1
G#1
A 1
A#1
B 1
C 2
C#2
D 2
D#2
E 2
F 2
F#2
G 2
G#2
A 2
A#2
B 2
C 3
C#3
D 3
D#3
E 3
F 3
F#3
G 3
G#3
A 3
A#3
B 3
C 4
C#4
D 4
D#4
E 4
F 4
F#4
G 4
G#4
A 4
A#4
B 4
C 5
C#5
D 5
D#5
E 5
F 5
F#5
G 5
G#5
A 5
A#5
B 5
C 6

on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on

438
377
337
379
458
397
395
439
441
403
398
476
458
329
462
445
369
314
423
314
470
314
472
418
417
474
417
325
435
432
354
433
255
434
356
429
328
327
345
338
337
321
326
362
362
353
352
360
438
318
397
465
394
330
447
361
471
361
448
325
325
474
435
318
449
209
354
366
475
450
451
416
448 Dr T8HHOp

C 6

on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
off
off
off
off
off
off
off
off
off
off
off
off

off
off
off
off
off
off
off
off
off
off
off
off

7Pop Kit 88o8 Kit

Note ElmAsgn Wave No. Wave Name Note ElmAsgn Wave No. Wave Name

on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on

350
404
401
403
401
405
351
442
444
379
441
437
438
443
439
445
440
446
447
446
448
446
448
446
446
449
446
449
435
431
354
434
453
434
356
430
336
335
452
451
450
345
344
341
341
349
455
359
359
343
342
454
348
348
346
347
355
355
353
357
360

Pc Claves
Dr SdBrsL
Dr SdSwep
Dr SdBrsH
Dr SdSwep
Dr SdRoll
Pc Castnt
Dr T8SD4
Dr T8Rmst
Dr BdAna
Dr T8SD3
Dr T8BdBm
Dr T8Bd
Dr T8Side
Dr T8SD1
Dr T8Clap
Dr T8SD2
Dr T8T om
Dr T8HHCl
Dr T8T om
Dr T8HHOp
Dr T8T om
Dr T8HHOp
Dr T8T om
Dr T8T om
Dr T8Crsh
Dr T8T om
Dr T8Crsh
Dr China
Dr Cup
Pc Tmborn
Dr Crash2
Dr T8Cwbl
Dr Crash2
Pc VbSlp
Dr Ride2
Pc BongoH
Pc BongoL
Dr T8CngH
Dr T8CngM
Dr T8CngL
Pc TmblsH
Pc TmblsL
Pc AgogoL
Pc AgogoL
Pc Cabasa
Dr T8Mrcs
Pc Whistl
Pc Whistl
Pc GiroCl
Pc GuiroL
Dr T8Clve
Pc Wdblck
Pc Wdblck
Pc CuicaL
Pc CuicaH
Pc T rangL
Pc T rangL
Pc Shaker
Pc JnglBl
Pc Bltree

C 0
C#0
D 0
D#0
E 0
F 0
F#0
G 0
G#0
A 0
A#0
B 0
C 1
C#1
D 1
D#1
E 1
F 1
F#1
G 1
G#1
A 1
A#1
B 1
C 2
C#2
D 2
D#2
E 2
F 2
F#2
G 2
G#2
A 2
A#2
B 2
C 3
C#3
D 3
D#3
E 3
F 3
F#3
G 3
G#3
A 3
A#3
B 3
C 4
C#4
D 4
D#4
E 4
F 4
F#4
G 4
G#4
A 4
A#4
B 4
C 5
C#5
D 5
D#5
E 5
F 5
F#5
G 5
G#5
A 5
A#5
B 5
C 6

on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on

350
404
401
403
401
405
351
400
408
376
389
377
372
406
380
358
380
410
423
410
425
411
427
411
412
433
413
429
435
431
354
434
340
434
356
432
336
335
339
338
337
345
344
341
341
349
352
359
359
343
342
350
348
348
346
347
355
355
353
357
360
399
381
392
386
394
391
382
389
384
371
372
378

Pc Claves
Dr SdBrsL
Dr SdSwep
Dr SdBrsH
Dr SdSwep
Dr SdRoll
Pc Castnt
Dr SdDry
Dr Stick
Dr BdVar3
Dr SdPcBH
Dr BdVar4
Dr BdHby
Dr C.Rim1
Dr SdGM
Pc Clap
Dr SdGM
Dr T omL
Dr HHCl5
Dr T omL
Dr HHPdl2
Dr T omM
Dr HHOpn2
Dr T omM
Dr T omHL
Dr Crash
Dr T omHH
Dr Ride
Dr China
Dr Cup
Pc Tmborn
Dr Crash2
Pc Cowbel
Dr Crash2
Pc VbSlp
Dr Cup2
Pc BongoH
Pc BongoL
Pc CngSlp
Pc CongaH
Pc CongaL
Pc TmblsH
Pc TmblsL
Pc AgogoL
Pc AgogoL
Pc Cabasa
Pc Maracs
Pc Whistl
Pc Whistl
Pc GiroCl
Pc GuiroL
Pc Claves
Pc Wdblck
Pc Wdblck
Pc CuicaL
Pc CuicaH
Pc T rangL
Pc T rangL
Pc Shaker
Pc JnglBl
Pc Bltree
Dr SdBkBt
Dr SdBldS
Dr SdVar1
Dr SdSonD
Dr SdRim1
Dr SdWdH
Dr SdBldH
Dr SdPcBH
Dr SdLdwH
Dr BdPop
Dr BdHby
Dr BdVar5

C 0
C#0
D 0
D#0
E 0
F 0
F#0
G 0
G#0
A 0
A#0
B 0
C 1
C#1
D 1
D#1
E 1
F 1
F#1
G 1
G#1
A 1
A#1
B 1
C 2
C#2
D 2
D#2
E 2
F 2
F#2
G 2
G#2
A 2
A#2
B 2
C 3
C#3
D 3
D#3
E 3
F 3
F#3
G 3
G#3
A 3
A#3
B 3
C 4
C#4
D 4
D#4
E 4
F 4
F#4
G 4
G#4
A 4
A#4
B 4
C 5
C#5
D 5
D#5
E 5
F 5
F#5
G 5
G#5
A 5
A#5
B 5
C 6

12

1HipHop Kit 2Urbanguard

ElmAsgn Wave No. Wave Name Note ElmAsgn Wave No. Wave Name

Fx HiLo
Fx HiLo

C 0
C#0
D 0
D#0
E 0
F 0
F#0
G 0
G#0
A 0
A#0
B 0
C 1
C#1
D 1
D#1
E 1
F 1
F#1
G 1
G#1
A 1
A#1
B 1
C 2
C#2
D 2
D#2
E 2
F 2
F#2
G 2
G#2
A 2
A#2
B 2
C 3
C#3
D 3
D#3
E 3
F 3
F#3
G 3
G#3
A 3
A#3
B 3
C 4
C#4
D 4
D#4
E 4
F 4
F#4
G 4
G#4
A 4
A#4
B 4
C 5
C#5
D 5
D#5
E 5
F 5
F#5
G 5
G#5
A 5
A#5
B 5
C 6

on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on

437
440
439
441
442
462
327
460
444
438
463
458
456
406
459
465
461
467
471
467
473
468
472
468
469
474
469
475
449
475
354
449
453
474
477
449
452
450
451
255
266
399
399
453
341
349
455
329
329
361
366
454
454
351
363
364
355
355
353
357
360
394
388
358
390
379
447
457
423
374
448
476
372

Dr T8BdBm
Dr T8SD2
Dr T8SD1
Dr T8SD3
Dr T8SD4
Dr T9SD4
FX HH Hit
Dr T9SD2
Dr T8Rmst
Dr T8Bd
Dr T9SD5
Dr T9BD3
Dr T9BD1
Dr C.Rim1
Dr T9SD1
Dr T9Clap
Dr T9SD3
Dr T9TomL
Dr T9HHC2
Dr T9TomL
Dr T9HHO2
Dr T9TomM
Dr T9HHO1
Dr T9TomM
Dr T9TomH
Dr T9Crsh
Dr T9TomH
Dr T9Ride
Dr T8Crsh
Dr T9Ride
Pc Tmborn
Dr T8Crsh
Dr T8Cwbl
Dr T9Crsh
Dr DstKik
Dr T8Crsh
Dr T8CngH
Dr T8CngL
Dr T8CngM
Wv MogBs1
Wv Late-S
Dr SdBkBt
Dr SdBkBt
Dr T8Cwbl
Pc AgogoL
Pc Cabasa
Dr T8Mrcs

Pc AnvlHt
Pc Ripper
Dr T8Clve
Dr T8Clve
Pc Castnt
Pc Scrch1
Pc Scrch2
Pc TrangL
Pc TrangL
Pc Shaker
Pc JnglBl
Pc Bltree
Dr SdRim1
Dr SdPclH
Pc Clap
Dr SdPrmH
Dr BdAna
Dr T8HHCl
Dr T9BD2
Dr HHCl5
Dr BdVar1
Dr T8HHOp
Dr EuroBD
Dr BdHby

C 0
C#0
D 0
D#0
E 0
F 0
F#0
G 0
G#0
A 0
A#0
B 0
C 1
C#1
D 1
D#1
E 1
F 1
F#1
G 1
G#1
A 1
A#1
B 1
C 2
C#2
D 2
D#2
E 2
F 2
F#2
G 2
G#2
A 2
A#2
B 2
C 3
C#3
D 3
D#3
E 3
F 3
F#3
G 3
G#3
A 3
A#3
B 3
C 4
C#4
D 4
D#4
E 4
F 4
F#4
G 4
G#4
A 4
A#4
B 4
C 5
C#5
D 5
D#5
E 5
F 5
F#5
G 5
G#5
A 5
A#5
B 5
C 6

on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on

378
404
401
403
401
405
314
385
408
378
389
375
373
407
380
358
391
409
419
410
424
410
426
411
412
433
413
429
435
431
354
434
453
434
356
449
336
335
339
338
337
345
344
341
341
349
352
359
359
343
342
350
348
348
346
347
355
355
353
357
360
477
477
477
477
477
477
477
477
477
477
477
477

Dr BdVar5
Dr SdBrsL
Dr SdSwep
Dr SdBrsH
Dr SdSwep
Dr SdRoll
Wv Noise
Dr SdSonA
Dr Stick
Dr BdVar5
Dr SdPcBH
Dr BdVar2
Dr BdLoJz
Dr C.Rim2
Dr SdGM
Pc Clap
Dr SdWdH
Dr TomF
Dr HHCl1
Dr TomL
Dr HHPdl
Dr TomL
Dr HHOpn
Dr TomM
Dr TomHL
Dr Crash
Dr TomHH
Dr Ride
Dr China
Dr Cup
Pc Tmborn
Dr Crash2
Dr T8Cwbl
Dr Crash2
Pc VbSlp
Dr T8Crsh
Pc BongoH
Pc BongoL
Pc CngSlp
Pc CongaH
Pc CongaL
Pc TmblsH
Pc TmblsL
Pc AgogoL
Pc AgogoL
Pc Cabasa
Pc Maracs
Pc Whistl
Pc Whistl
Pc GiroCl
Pc GuiroL
Pc Claves
Pc Wdblck
Pc Wdblck
Pc CuicaL
Pc CuicaH
Pc TrangL
Pc TrangL
Pc Shaker
Pc JnglBl
Pc Bltree
Dr DstKik
Dr DstKik
Dr DstKik
Dr DstKik
Dr DstKik
Dr DstKik
Dr DstKik
Dr DstKik
Dr DstKik
Dr DstKik
Dr DstKik
Dr DstKik

Note

Internal (MSB=63, LSB=32)

13

No. Cat./WaveName No. Cat./WaveName No. Cat./WaveName No. Cat./WaveName No. Cat./WaveName No. Cat./WaveName

1 Pf Grand 86 Or D1 1/3 171 Gt Single 256 Wv MogBs2 341 Pc AgogoL 426 Dr HHOpn
2 Pf Grand+ 87 Or D1 172 Gt SnglHi 257 Wv MogBs3 342 Pc GuiroL 427 Dr HHOpn2
3 Pf Grand- 88 Or LesGrt 173 Gt StrtF 258 Wv FMBs1 343 Pc GiroCl 428 Dr HHTip
4 Pf Brit 89 Or LesGr2 174 Gt ES335 259 Wv FMBs2 344 Pc TmblsL 429 Dr Ride
5 Pf Brit+ 90 Or Rotar 175 Gt DistCl 260 Wv FMBs3 345 Pc TmblsH 430 Dr Ride2
6 Pf Brit- 91 Or Clack 176 Gt DistMt 261 Wv FMBs4 346 Pc CuicaL 431 Dr Cup
7 Pf CP80 92 Or LesWho 177 Gt FeedBk 262 Wv FMBs5 347 Pc CuicaH 432 Dr Cup2
8 Pf CP80+ 93 Or SftTmp 178 Gt StlHrm 263 Wv FMBs6 348 Pc Wdblck 433 Dr Crash

9 Pf CP80- 94 Or Perc 179 Gt StrHrm 264 Wv FMFnk 349 Pc Cabasa 434 Dr Crash2
10 Pf Rho1P 95 Or Perc+ 180 Gt Dist2 265 Wv FMGtr 350 Pc Claves 435 Dr China
11 Pf Rho1P+ 96 Or Perc- 181 Ba Acstic 266 Wv Late-S 351 Pc Castnt 436 Dr China2
12 Pf Rho1P- 97 Or Harmnc 182 Ba Acstc+ 267 Wv Late-L 352 Pc Maracs 437 Dr T8BdBm
13 Pf Rho1L 98 Or Acrdn 183 Ba Acstc- 268 Wv P5Saw 353 Pc Shaker 438 Dr T8Bd
14 Pf Rho1L+ 99 Or Acrdn+ 184 Ba Fing 269 Wv Saw2 354 Pc Tmborn 439 Dr T8SD1
15 Pf Rho1L- 100 Or Acrdn- 185 Ba Fing+ 270 Wv 1o1Saw 355 Pc TrangL 440 Dr T8SD2
16 Pf Rho2S 101 Cp FngCym 186 Ba Fing- 271 Wv 1o1Sub 356 Pc VbSlp 441 Dr T8SD3
17 Pf Rho2S+ 102 Cp Hibasi 187 Ba Harmnc 272 Wv SawSqu 357 Pc JnglBl 442 Dr T8SD4
18 Pf Rho2S- 103 Cp StoneH 188 Ba Precsn 273 Wv SquSaw 358 Pc Clap 443 Dr T8Side
19 Pf Rho2M 104 Cp StoneS 189 Ba Prcsn+ 274 Wv MgRamp 359 Pc Whistl 444 Dr T8Rmst
20 Pf Rho2M+ 105 Cp Gamln1 190 Ba Pecsn- 275 Wv P10-1 360 Pc Bltree 445 Dr T8Clap
21 Pf Rho2M- 106 Cp Gamln2 191 Ba PrsRw 276 Wv P10-2 361 Pc AnvlHt 446 Dr T8Tom
22 Pf Rho2H 107 Cp Glock 192 Ba PrsRw+ 277 Wv P10-3 362 Pc AnvlPp 447 Dr T8HHCl
23 Pf Rho2H+ 108 Cp Marimb 193 Ba PrsRw- 278 Wv P25-1 363 Pc Scrch1 448 Dr T8HHOp
24 Pf Rho2H- 109 Cp Vibra 194 Ba Pick 279 Wv P25-2 364 Pc Scrch2 449 Dr T8Crsh
25 Pf Rho3 110 Cp Xylo 195 Ba Slap 280 Wv P50-1 365 Pc VoxDrm 450 Dr T8CngL
26 Pf Rho3+ 111 Cp HndBel 196 Ba Slap+ 281 Wv P50-2 366 Pc Ripper 451 Dr T8CngM
27 Pf Rho3- 112 Cp Crotls 197 Ba Slap- 282 Wv Tri 367 Pc CONG 452 Dr T8CngH
28 Pf Rho4 113 Cp Timpni 198 Ba Slap2 283 Wv Digi01 368 Pc StlClp 453 Dr T8Cwbl
29 Pf Rho4+ 114 Br SectnL 199 Ba Slap2+ 284 Wv Digi02 369 Pc WdBlk 454 Dr T8Clve
30 Pf Rho4- 115 Br SectnR 200 Ba Slap2- 285 Wv Digi03 370 Dr BdStd 455 Dr T8Mrcs
31 Pf Wurli 116 Br SctnSt 201 Ba Frtl1 286 Wv Digi04 371 Dr BdPop 456 Dr T9BD1
32 Pf Wurli+ 117 Br SctnL- 202 Ba Frtl1+ 287 Wv Digi05 372 Dr BdHby 457 Dr T9BD2
33 Pf Wurli- 118 Br SctnR- 203 Ba Frtl1- 288 Wv Digi06 373 Dr BdLoJz 458 Dr T9BD3
34 Pf DX1 119 Br SctSt- 204 Ba Frtl2 289 Wv Digi07 374 Dr BdVar1 459 Dr T9SD1
35 Pf DX2 120 Br Sctn2L 205 Ba Frtl2+ 290 Wv Digi08 375 Dr BdVar2 460 Dr T9SD2
36 Pf DX3 121 Br Sctn2R 206 Ba Frtl2- 291 Wv Digi09 376 Dr BdVar3 461 Dr T9SD3
37 Pf Clav1 122 Br Sct2St 207 Ba SyBass 292 Wv Digi10 377 Dr BdVar4 462 Dr T9SD4
38 Pf Clav1+ 123 Br Sct2L+ 208 En SynVox 293 Wv Digi11 378 Dr BdVar5 463 Dr T9SD5
39 Pf Clav1- 124 Br SctnR+ 209 En VxNoiz 294 Wv Digi12 379 Dr BdAna 464 Dr T9SD6
40 Pf Clav2 125 Br Sct2S+ 210 En Aah 295 Wv Bel1Wv 380 Dr SdGM 465 Dr T9Clap
41 Pf Clav2+ 126 Br Sct2L- 211 En Aah+ 296 Wv Bel2Wv 381 Dr SdBldS 466 Dr T9Rim
42 Pf Clav2- 127 Br Sct2R- 212 En Aah- 297 Wv DgVox1 382 Dr SdBldH 467 Dr T9TomL
43 Pf Clav3 128 Br Sct2S- 213 En Oooo 298 Wv DgVox2 383 Dr SdFsnH 468 Dr T9TomM
44 Pf Clav3+ 129 Br Trmbn 214 En Oooo+ 299 Wv DgVox3 384 Dr SdLdwH 469 Dr T9TomH
45 Pf Clav3- 130 Br Trmbn- 215 En Oooo- 300 Wv DgVox4 385 Dr SdSonA 470 Dr T9HHC1
46 Pf Hrpscd 131 Br SftTrb 216 En Itopia 301 Wv DgVox5 386 Dr SdSonD 471 Dr T9HHC2
47 Or JmPrc 132 Br SftFlg 217 Rd Alto 302 Wv VoxG2 387 Dr SdHvy 472 Dr T9HHO1
48 Or JmPrc- 133 Br SftFl- 218 Rd Alto+ 303 Wv VoxE3 388 Dr SdPclH 473 Dr T9HHO2
49 Or Jazz 134 Br Hermn 219 Rd Alto- 304 Wv Ep1 389 Dr SdPcBH 474 Dr T9Crsh
50 Or Jazz+ 135 Br Strgt 220 Rd Tenor 305 Wv Ep2 390 Dr SdPrmH 475 Dr T9Ride
51 Or Jazz- 136 Br TrpMed 221 Rd Tenor+ 306 Wv Ep3 391 Dr SdWdH 476 Dr EuroBD
52 Or Rock 137 Br TrpSft 222 Rd Tenor- 307 Wv Ep4 392 Dr SdVar1 477 Dr DstKik
53 Or Rock+ 138 Br Trmpt 223 Rd Bari 308 Wv Ep5 393 Dr SdVar2 478 Dr Bd Kit
54 Or Rock- 139 Br Trmpt+ 224 Rd BigSx1 309 Wv EP6 394 Dr SdRim1 479 Dr Sn Kit
55 Or Argent 140 Br Trmpt- 225 Rd BigSx2 310 Wv Org1Wv 395 Dr SdRim2
56 Or BowVb 141 Br PiclTp 226 Rd SxBrth 311 Wv Org2Wv 396 Dr SdAmb1
57 Or BowNv 142 Br F.Horn 227 Rd Soprn 312 Wv Org3Wv 397 Dr SdAmb2
58 Or Gospel 143 Br Combi1 228 Rd Soprn+ 313 Wv Sin 398 Dr SdAmb3
59 Or Green 144 Br Combi2 229 Rd Soprn- 314 Wv Noise 399 Dr SdBkBt
60 Or Santana 145 Br Combi3 230 Rd Clari 315 Wv PnoNP 400 Dr SdDry
61 Or Farfis 146 Br Combi4 231 Rd Clari+ 316 Wv EPNP 401 Dr SdSwep
62 Or Farfi- 147 St Vln 232 Rd Clari- 317 Wv VibeNP 402 Dr SdBrsS
63 Or VoxOrg 148 St Vln2 233 Rd Oboe 318 Fx VoxBel 403 Dr SdBrsH
64 Or VxOrg- 149 St Cello 234 Rd Oboe+ 319 Fx Melow 404 Dr SdBrsL
65 Or Swish 150 St EnsMx 235 Rd Oboe- 320 Fx WndChm 405 Dr SdRoll
66 Or Swish- 151 St EnsMx- 236 Rd Basoon 321 Fx BelAir 406 Dr C.Rim1
67 Or Dw1+3 152 St SmlEns 237 Rd Basoon+ 322 Fx BigSyn 407 Dr C.Rim2
68 Or Dw1+3+ 153 St SmlEn+ 238 Rd Basoon- 323 Fx TrnCho 408 Dr Stick
69 Or Dw1+3- 154 St SmlEn- 239 Pi Flute 324 Fx HanSol 409 Dr TomF
70 Or Dw2+4 155 St Pizz 240 Pi Flute+ 325 Fx Eery 410 Dr TomL
71 Or Dw2+4+ 156 St Pizz2 241 Pi Flute- 326 Fx Electr 411 Dr TomM
72 Or Dw2+4- 157 St Harp 242 Pi PnFlt 327 FX HH Hit 412 Dr TomHL
73 Or DrwEv 158 Gt Nylon 243 Pi PnFlt- 328 Fx VxAlk 413 Dr TomHH
74 Or DrwEv+ 159 Gt NylnHi 244 Wv ModSaw 329 Fx HiLo 414 Dr TmJzL
75 Or DrwEv- 160 Gt Nylhrm 245 Wv ObStr 330 Fx MltPno 415 Dr TmJzM
76 Or DrwOd 161 Gt Steel 246 Wv JpStr 331 Fx AHoseL 416 Dr TmJzH
77 Or DrwOd+ 162 Gt StelHi 247 Wv SyzStr 332 Fx AHoseR 417 Dr Tom2H
78 Or DrwOd- 163 Gt StelLo 248 Wv Padd 333 Et StlDrm 418 Dr Tom2L
79 Or D16 164 Gt JzGtr 249 Wv ObBrs 334 Et Sitar 419 Dr HHCl1
80 Or D5 1/3 165 Gt Strt 250 Wv SyncLd 335 Pc BongoL 420 Dr HHCL2
81 Or D8 166 Gt StrtN 251 Wv CS80Br 336 Pc BongoH 421 Dr HHCl3
82 Or D4 167 Gt StrtSl 252 Wv 3o3Saw 337 Pc CongaL 422 Dr HHCl4
83 Or D2 2/3 168 Gt StrtSp 253 Wv 3o3Sw2 338 Pc CongaH 423 Dr HHCl5
84 Or D2 169 Gt StrtMt 254 Wv 3o3Squ 339 Pc CngSlp 424 Dr HHPdl
85 Or D1 3/5 170 Gt Front 255 Wv MogBs1 340 Pc Cowbel 425 Dr HHPdl2

Wave List

14

Perfromance List

Internal (MSB=63, LSB=64)

No. Performance Name Category Note No. Performance Name Category Note

1 Rap Round Co 65 Infinity Co
2 Scatter Co 66 Street Co
3 Megahook Ld 67 Oktavian Sc
4 Millennium Pd 68 Obi Pad Co
5 Aquarium Fx 69 MoonChild Fx
6 Pizzi 2000 Sc 70 Block Sc
7 Del Mar Sq 71 Torture Fx
8 Neonist Gt 72 Alpine Pd

9 Front&Back Co 73 Soul Set Co
10 Nu House Dr 74 Mission Co
11 AceFlair Pf 75 ChoirPiano Co
12 Silver Sq 76 Electron Sq
13 SnowFlakes Fx 77 Whirl Sc
14 Space Pitz Sq 78 Summer Co
15 Nasty Ba 79 Bass Menu Ba
16 Superstrgs St 80 AppleSplit Co See*1
17 Transfer Co 81 Beatnik Co
18 Fighter Co 82 Continent Co
19 E-Motion Pd 83 Brother Sc
20 MagmaSweep Fx 84 Harmony Co
21 PozitiveSP Ld 85 House Menu Co
22 WaveTable Sc 86 Pizz it! Sc
23 Mythology Fx 87 R&B Menu Co
24 Pacific404 Co 88 Nylonspher Co
25 Keltic Co 89 R&B Set Co
26 AcidJz Kit Co 90 Trance Kit Co
27 NewHorizon Co 91 Quintus Sc
28 Enterprise Fx 92 Stab Menu Co
29 Mr Squidge Fx 93 Fat Stack Sc
30 Clean&Dist Sq 94 Seq Layer Fx
31 ChunkyStak Ba 95 Final Worm Fx
32 Fat Analog Br See*1 96 Small Orch En
33 Automatic Co 97 Pops -­34 NightRythm Co 98 Ballad 1 -­35 DJ Finger Ld 99 Ballad 2 -­36 Galaxy Fx 100 Unplugged -­37 Perpetual Sq 101 80's Disco -­38 Stab Boy Sc 102 Funk Rock -­39 Night Byte Sq 103 Hard Rock -­40 Ambitrance Co 104 HeavyMetal -­41 Invisible Co 105 ProgreRock -­42 HipHop Kit Co 106 Blues Rock -­43 Minor Pf 107 West Coast -­44 Rhythlog Sq 108 BritishRck -­45 Mirage Pd 109 Big Band -­46 ModernGirl Co 110 Combo Jazz -­47 Toro 2000 Ba 111 JazzBallad -- See*2
48 Euro Split Co 112 Fusion -­49 SilentMoon Co 113 Club Jazz -­50 Night Beat Co 114 House -­51 TranxTron Ld 115 Techno -­52 Pearl Fx 116 Trance -­53 Dream Gruv Sq 117 Big Beat -­54 Soft Cream Sc 118 Drum'nBass -­55 Analous Sq 119 HipHop -­56 Bell&Str Co 120 Reggae -­57 Egypt Co 121 R&B -­58 House Kit Co 122 India -­59 Chartz Pf 123 Salsa -­60 Melomatic Sq 124 Gamelan -­61 Waterflow Fx 125 Ambient -­62 Strg&Arpg Sq 126 Tango -­63 Killa Ba 127 SoundTrack -­64 Trip Split Co 128 Master KB -- See*3

*1 Performances suitable for playing on the keyboard.
*2 Performances suitable for multi-part playback using sequencer function.
*3 Performances suitable for master keyboard settings.

15

Control Set Destination Parameter

No. LCD Parameter

00 off :off
01 Volume Voice V olume
02 RevSend Reverb Send
03 ChoSend Chorus Send
04 INS1-P1:EF1 Insertion Effect 1 Parameter 1

:: :

13 INS1P10:EF1 Insertion Effect 1 Parameter 10
14 INS2-P1:EF2 Insertion Effect 2 Parameter 1

:: :

29 INS2P16:EF2 Insertion Effect 2 Parameter 16
30 CLFOSpd Common LFO Speed
31 CLFO-D1 Common LFO Depth1
32 CLFO-D2 Common LFO Depth2
33 PorTime Common Portamento Time
34 ELM-Lvl Element Level
35 ELM-Pan Element Pan
36 ELM-Dly Element Key On Delay
37 ELFOSpd Element LFO Speed
38 ELFO-PM Element LFO Pitch Modulation Depth
39 ELFO-AM Element LFO Amplitude Modulation Depth
40 ELFO-FM Element LFO Filter Modulation Depth
41 PCH-Crs Element Pitch Coarse
42 PCH-Fin Element Pitch Fine
43 PEG-Dpt Element Pitch EG Depth
44 PEG-Hld Element Pitch EG Hold Time
45 PEG-Atk Element Pitch EG Attack Time
46 PEG-D1 Element Pitch EG Decay1 Time
47 PEG-D2 Element Pitch EG Decay2 Time
48 PEG-Rel Element Pitch EG Release Time
49 AEG-Atk Element Amplitude EG Attack Time
50 AEG-D1 Element Amplitude EG Decay1 Time
51 AEG-D2 Element Amplitude EG Decay2 Time
52 AEG-Rel Element Amplitude EG Release Time
53 FEG-Dpt Element Filter EG Depth
54 FEG-Hld Element Filter EG Hold Time
55 FEG-Atk Element Filter EG Attack Time
56 FEG-D1 Element Filter EG Decay1 Time
57 FEG-D2 Element Filter EG Decay2 Time
58 FEG-Rel Element Filter EG Release Time
59 FLT-Frq Element Filter Cutoff Frequency
60 FLT-Rez Element Filter Resonance
61 HPF-Frq Element Filter HPF Cutoff Frequency

The destionation parameters 00 - 29 can be used for all Controller Sets.
However, in the case of the Plug-in voices, only the parameters 00 - 13 are
available.
The parameters 30 - 61 are available for the Normal voices except for the
Plug-in voices.
The parameters 04 - 29 are available only when Insertion effect is applied to
the voice, and the effective parameter type differs depending on the
currently selected effect type. If the destination parameter is effective, it's
actual parameter name will be displayed on the LCD. For example,
“INS1P10” of the number 13 will be replaced with the actual parameter
name. If not, the LCD displays the one like “INS1P10” shown in the above
list in the Controller Set function, and “-----” in the Play mode.

As to the parameters 16 - 25 and 28 - 37, the effective parameter type
differs depending on the currently selected effect type. If the destination
parameter is effective, it's actual parameter name will be displayed on the
LCD. For example, “REV-P10” of the number 25 will be replaced with the
actual parameter name. If not, the LCD displays the one like “REV-P10”
shown in the above list in the Controller Set function, and “-----” in the Play
mode.

System Controller Destination Parameter

00 off off
01 EQLow-G MEQ Low Gain
02 EQLow-F MEQ Low Frequency
03 EQLow-Q MEQ Low Q
04 EQLoM-G MEQ Low Mid Gain
05 EQLoM-F MEQ Low Mid Frequency
06 EQLoM-Q MEQ Low Mid Q
07 EQMid-G MEQ Mid Gain
08 EQMid-F MEQ Mid Frequency
09 EQMid-Q MEQ Mid Q
10 EQHiM-G MEQ High Mid Gain
11 EQHiM-F MEQ High Mid Frequency
12 EQHiM-Q MEQ High Mid Q
13 EQHi-G MEQ High Gain
14 EQHi-F MEQ High Frequency
15 EQHi-Q MEQ High Q
16 REV-P1 ReverbParameter 1

:: :
25 REV-P10 Reverb Parameter 10
26 REV-Rtn Reverb Return
27 REV-Pan Reverb Pan
28 CHO-P1 Chorus Parameter 1

:: :
37 CHO-P10 Chorus Parameter 10
38 CHO-Rtn Chorus Return
39 CHO-Pan Chorus Pan
40 Cho>Rev Send Chorus To Reverb
41 ARP-Typ Arpeggio Type
42 ARP-Unt Arpeggio Unit Multiply
43 ARP-Vel Arpeggio Velocity Rate
44 ARP-Gat Arpeggio Gate Time Rate
45 Tempo Arpeggio/Sequencer Tempo
46 EG-Atck QED EG Attack Time
47 EG-Decy QED EG Decay Time
48 EG-SusL QED EG Sustain Level
49 EG-Rele QED EG Release Time
50 Cutoff QED Cutoff Frequency
51 Reso QED Resonance

No. LCD Parameter

Control List

16

Control Change Number List

CONTROLLER

Name No. Remarks

PB:PITCH BEND Pitch Bend
MW:MODULATION WHELL

1 Modulation

AT:AFTER TOUCH After T ouch
BC:BREATH CONTROLLER

(2) Set in the Utility or Performance Mode

Set in the Utility or Performance Mode
Set in the Utility or Performance Mode

Set in the Utility or Performance Mode
Set in the Utility or Performance Mode

RB:RIBBON CONTROLLER

(22)

FC:FOOT CONTROLLER (4)
FS:FOOT SWITCH (88) Set in the Utility Mode

Set in the Utility Mode
Set in the Utility Mode
Set in the Utility Mode
Set in the Utility Mode

Set in the Utility Mode
Set in the Utility Mode

Set in the Utility Mode (7 or 11)

FV:FOOT VOLUME

(11)

SUS:SUSTAIN (64) Sustain(Hold 1)

SOUND CONTROL KNOB

Name No. Remarks

[CUTOFF]

74 Cutoff Freq

[RESONANCE]

71 Resonance

[REVERB]

91 Reverb Send

[CHORUS]

93 Chorus Send

[ATTACK]

73 Attack Time

[DECAY]

75 Decay Time

[SUSTAIN] *1

31 Sustain Level

[RELEASE]

72 Release Time

[PAN] 10 Panpot

[PORTAMENTO TIME]

5 Portamento Time

[ARPEGGIO GATE TIME] Parameter Change
[PHRASE CLIP PITCH] Parameter Change
[TEMPO] No MIDI output/input
[SCENE KNOB]

(14)

[KNOB A] (18)
[KNOB B] (19)
[KNOB C] (20)
[KNOB 1] (16)
[KNOB 2] (17)

SOUND CONTROL SW

Name No. Remarks

[ARPEGGIO SW] (90)
[ARPEGGIO HOLD] (89)
[PORTAMENTO SW] 65 Portamento Switch
[SCENE 1] Same as [SCENE KNOB] = Minimum
[SCENE 2] Same as [SCENE KNOB] = Maximum

*1: Use the control change message when MIDI Control Mode is mode 2, and the

parameter change message when mode 1.

The control numbers in the parentheses are the defaults.

No. Name No. Name

1 UpOct1:Sq

86 Guit4Arp:Ph

2 UpOct2:Sq

87 Harp Arp:Ph

3 UpOct4:Sq

88 BigBeat1:Dr

4 DownOct1:Sq

89 BigBeat2:Dr

5 DownOct2:Sq

90 BigBeat3:Dr

6 DownOct4:Sq

91 BigBeat4:Dr

7 U/DAOct1:Sq

92 Rock1:Dr

8 U/DAOct2:Sq

93 Rock2:Dr

9 U/DAOct4:Sq

94 Rock3:Dr

10 U/DBOct1:Sq

95 BigBeat5:Dr

11 U/DBOct2:Sq

96 BigBeat6:Dr

12 U/DBOct4:Sq

97 BigBeat7:Dr

13 RndmOct1:Sq

98 BigBeat8:Dr

14 RndmOct2:Sq

99 BigBeat9:Dr

15 RndmOct4:Sq

100 BrkTrnce:Dr

16 Oct2Up:Sq

101 House1:Dr

17 Oct4Up:Sq

102 House2:Dr

18 UnisonUp:Sq

103 House3:Dr

19 Up&Down1:Sq

104 Garage:Dr

20 Up&Down2:Sq

105 House4:Dr

21 Up&Down4:Sq

106 House5:Dr

22 Up&Alt1:Sq

107 HipHop:Dr

23 Up&Rndm1:Sq

108 JazzHop:Dr

24 Up&Rndm2:Sq

109 Abstract:Dr

25 Up&Rndm4:Sq

110 LoBeat1:Dr

26 ChdAltB1:Sq

111 LoBeat2:Dr

27 ChdAltB2:Sq

112 LoBeat3:Dr

28 ChdAltB4:Sq

113 LoBeat4:Dr

29 ChdRndm1:Sq

114 LoBeat5:Dr

30 ChdRndm2:Sq

115 LoBeat6:Dr

31 ChdRndm4:Sq

116 Drm&Bs1:Dr

32 TechnoA:Ph

117 Drm&Bs2:Dr

33 TechnoB:Ph

118 Linear:Dr

34 TechnoC:Ph

119 08beat1:Cl

35 DAHouse:Ph

120 08beat2:Cl

36 SyncopaA:Ph

121 08beat3:Cl

37 SyncopaB:Ph

122 16beat1:Cl

38 SyncpEco:Ph

123 16beat2:Cl

39 TekEchoA:Ph

124 1Bar:Cl

40 TekEchoB:Ph

125 1BarRndm:Cl

41 PulsLine:Ph

126 GateCut1:Ct

42 SeqS&H1:Ph

127 GateCut2:Ct

43 SeqS&H2:Ph

128 GateCut3:Ct

44 CleanGt1:Ph
45 CleanGt2:Ph
46 CleanGt3:Ph
47 CleanGt4:Ph
48 Pno16Bt:Ph
49 PnoLatin:Ph
50 CrvBass:Ph
51 Ocean:Ph
52 Orbit:Ph
53 X-Sweep1:Ph
54 X-Sweep2:Ph
55 X-Sweep3:Ph
56 Lamb:Ph
57 Thips:Ph
58 Hardcore:Ph
59 Harmo:Ph
60 Ascorbic:Ph
61 Doves:Ph
62 Chodal:Ph
63 Simple:Ph
64 Waggle:Ph

65 SuperArp:Ph
66 MuteArp1:Ph
67 MuteArp2:Ph
68 VelGruv1:Ph
69 VelGruv2:Ph
70 SpaceArp:Ph
71 MuteLine:Ph
72 StepLine:Ph
73 AcidLine:Ph
74 SplitArp:Ph
75 Step Seq:Ph
76 PolyArp1:Ph
77 PolyArp2:Ph
78 Ana Seq:Ph
79 Planet:Ph
80 Rosync:Ph
81 StrumArp:Ph
82 Guit1Arp:Ph
83 RolliArp:Ph
84 Guit2Arp:Ph
85 Guit3Arp:Ph

Arpeggio Type List

17

Effect Category Effect Name LCD

MSB LSB

REV CHO

InsEF1 InsEF2

--- NO EFFECT off 00 00 0 0

--- THRU Thru 00 00 0 0

REVERB

REV HALL 1 Hall1 01 00 1 1
REV HALL 2 Hall2 01 01 2 2
REV ROOM 1 Room1 01 10 3 3
REV ROOM 2 Room2 01 11 4 4
REV ROOM 3 Room3 01 12 5 5
REV STAGE 1 Stage1 01 20 6 6
REV STAGE 2 Stage2 01 21 7 7
REV PLATE Plate 01 30 8 8
REV WHITE ROOM WhiteRm 01 40 9
REV TUNNEL Tunnel 01 41 10
REV BASEMENT

Basement

01 42 11

REV CANYON Canyon 01 43 12

DELAY

DLY DELAY L,C,R

DelayLCR

02 00 9
DLY DELAY L,R DelayLR 02 10 18 10
DLY ECHO Echo 02 20 11
DLY CROSS DELAY CrossDly 02 30 12
DLY CONTROL DELAY1 (MONO) CtrlDly1 02 40 19 13
DLY CONTROL DELAY2 (STEREO) CtrlDly2 02 48 20 14
DLY TEMPO DELAY1 (MONO)

TempDly1

02 50 21 15
DLY TEMPO DELAY2 (STEREO)

TempDly2

02 58 22 16
DLY TEMPO CROSS DELAY

TempCDly

02 60 23 17

EARLY REFLECTION

ER EARLY REFLECTION 1 ER 1 03 00 18
ER EARLY REFLECTION 2 ER 2 03 01 19
ER GATE REVERB GateRev 03 10 20
ER REVERSE GATE RvrsGate 03 20 21

KARAOKE

KAR KARAOKE 1 Karaoke1 04 00 22
KAR KARAOKE 2 Karaoke2 04 01 23
KAR KARAOKE 3 Karaoke3 04 02 24

CHORUS

CHO CHORUS 1 Chorus1 05 00 1 1 25
CHO CHORUS 2 Chorus2 05 01 2 2 26
CHO CHORUS 3 Chorus3 05 02 3 3 27
CHO CHORUS 4 Chorus4 05 08 4 4 28
CHO CHORUS 5 Chorus5 05 09 5 29
CHO CELESTE 1 Celeste1 05 10 6 5 30
CHO CELESTE 2 Celeste2 05 11 7 6 31
CHO CELESTE 3 Celeste3 05 12 8 7 32
CHO CELESTE 4 Celeste4 05 18 9 8 33
CHO SYMPHONIC

Symphonc

05 20 10 34
CHO ENSEMBLE DETUNE Ensemble 05 30 11 35

FLANGER

FLG FLANGER 1 Flanger1 06 00 12 9 36
FLG FLANGER 2 Flanger2 06 01 13 10 37
FLG FLANGER 3 Flanger3 06 08 14 11 38
FLG V-FLANGER V-Flange 06 10 39
FLG TEMPO FLANGER

TempFlng

06 50 15 40

PHASER

PHA PHASER 1 Phaser1 07 00 16 12 41
PHA PHASER 2 Phaser2 07 08 42
PHA TEMPO PHASER

TempPhas

07 50 17 43

MODULATION

MOD TREMOLO Tremolo 08 00 13 44
MOD AUTO PAN AutoPan 08 10 14 45
MOD ROTARY SPEAKER1 RotrySp1 08 50 46
MOD DISTORTION+ROTARY SPEAKER1 Dt+RSp1 08 51 47
MOD OVERDRIVE+ROTARY SPEAKER1 Od+RSp1 08 52 48
MOD AMP SIM.+ROTARY SPEAKER1

Amp+RSp1

08 53 49
MOD ROTARY SPEAKER2 RotrySp2 08 60 50
MOD DISTORTION+ROTARY SPEAKER2 Dt+RSp2 08 61 51
MOD OVERDRIVE+ROTARY SPEAKER2 Od+RSp2 08 62 52
MOD AMP SIM.+ROTARY SPEAKER2

Amp+RSp2

08 63 53
MOD ROTORY SPEAKER3 RotrySp3 08 70 54
MOD ROTORY SPEAKER4 RotrySp4 08 71 55

DISTORTION

DST DISTORTION Dist 09 00 15 56
DST COMP DISTORTION Comp+Dt 09 01 57
DST V-DISTORTION V-Dist 09 10 58
DST OVER DRIVE OverDrv 09 20 16 59
DST AMP SIMULATOR AmpSim 09 30 17 60
DST DIST+DELAY Dist+Dly 09 40 61
DST OVERDRIVE+DELAY Odrv+Dly 09 41 62

DYNAMIC

DYN COMPRESSOR1 Comp1 0A 00 18 63
DYN NOISE GATE NoisGate 0A 20 19 64
DYN COMP+DIST+DELAY

CmpDtDly

0A 40 65
DYN COMP+OVERDRIVE+DELAY

CmpOdDly

0A 41 66

PITCH CHANGE

PCH PITCH CHANGE 1

PchChng1

0B 00 67

PCH PITCH CHANGE 2

PchChng2

0B 01 68

WAH

WAH AUTO WAH AutoWah 0C 00 20 69
WAH AUTO WAH + DIST AWah+Dt 0C 01 70
WAH AUTO WAH + OVERDRIVE

AWah+Od

0C 02 71
WAH TOUCH WAH

TouchWah

0C 10 21 72
WAH TOUCH WAH + DIST TWah+Dt 0C 11 73
WAH TOUCH WAH + OVERDRIVE

TWah+Od

0C 12 74
WAH WAH+DIST+DELAY WahDtDly 0C 40 75
WAH WAH+OVERDRIVE+DELAY

WahOdDly

0C 41 76

LO-FI

L-F LO-FI Lo-Fi 0D 00 77
L-F LOW RESOLUTION LowReso 0D 10 78
L-F NOISY Noisy 0D 20 79
L-F ATTACK LOFI AtkLoFi 0D 30 80
L-F DIGITAL TURNTABLE DTurnTbl 0D 50 81

TECH

TEC DIGITAL SCRATCH DScratch 0E 00 82
TEC AUTO SYNTH AutoSyn 0E 10 83
TEC TECH MODULATION TechMod 0E 20 84
TEC JUMP Jump 0E 30 85

MISC

MSC 3BAND EQ 3BandEQ 0F 00 22 86
MSC 2BAND EQ 2BandEQ 0F 01 23 87
MSC HARMONIC ENHANCER Enhancer 0F 10 24 88
MSC VOICE CANCEL VceCancl 0F 20 89
MSC AMBIENCE Ambience 0F 30 90
MSC TALKING MODULATOR TalkMod 0F 40 91
MSC BEAT CHANGE BeatChng 0F 50 92

(HEX)

No.MIDI

Effect Type List

Effect Parameter List

1. Reverb

[1] HALL1 ~ [8] PLATE

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8
9

10

[9] WHITE ROOM ~ [12] CANYON

No. Parameter Value L CD

MIDI Parameter Number

Controller

1 Reverb Time

Initial Delay
Reverb Delay
HPF Cutoff Frequency
LPF Cutoff Frequency
Diffusion
Width
Height
Depth
Wall Vary

Reverb Time
Initial Delay
Reverb Delay
HPF Cutoff Frequency
LPF Cutoff Frequency
Diffusion
Density
ER / Rev Balance
Feedback High Damp
Feedback Level

0.3s~30.0s

0.1ms~200.0ms

0.1ms~200.0ms
20Hz~8.0kHz

1.0kHz~20.0kHz
0~10

0.5m~30.2m

0.5m~30.2m

0.5m~30.2m
0~30

0.3s~30.0s

0.1ms~200.0ms

0.1ms~200.0ms
20Hz~8.0kHz

1.0kHz~20.0kHz
0~10
0~4
E63>R ~ E=R ~ E<R63

0.1~1.0

-63~+63

RevTime
InitDly
RevDly
HPF
LPF
Diffuse
Width
Height
Depth
Wall

RevTime
InitDly
RevDly
HPF
LPF
Diffuse
Density
ER/Rev
FBHiDmp
FBLevel

1
3
6
4
5
2
7
8
9

10

Ø
Ø

Ø

Ø

2
3
4
5
6
7
8
9

10

1
3

10

4
5
2
6
7
8
9

Ø
Ø

2. Chorus

[6] CELESTE1~[9] CELESTE4

No. Parameter Value LCD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

[10] SYMPHONIC

No. Parameter Value L CD

MIDI Parameter Number

Controller

1 LFO Frequency

LFO Depth
Delay Offset
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

LFO Frequency
LFO Depth
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Delay Offset
Feedback Level

0.0Hz~39.70Hz
0~127

0.0ms~50.0ms
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

0.0Hz~39.70Hz
0~127
32Hz~2.0kHz

-12dB~+12dB
500Hz~6.0kHz

-12dB~+12dB

0.0ms~50.0ms

-63~+63

Speed
Depth
DlyOfst
L.Freq
L.Gain
H.Freq
H.Gain

Speed
Depth
L.Freq
L.Gain
H.Freq
H.Gain
DlyOfst
FBLevel

1
2
5
6
7
8
4
3

Ø

Ø
Ø
Ø
Ø

Ø

2
3
4
5
6
7

1
2
3
4
5
6
7

[11] ENSEMBLE DETUNE

No. Parameter Value L CD

MIDI Parameter Number

Controller

1 Detune

Initial Delay Lch
Initial Delay Rch

-50cent~+50cent

0.0ms~50.0ms

0.0ms~50.0ms

Detune
DelayL
DelayR

2
3

1
2
3

Ø

Ø
Ø
Ø
Ø

[1] CHORUS1~[5] CHORUS5

The parameters marked with “Ø” can be
controlled using the Chorus Control.

[12] FLANGER1 ~ [14] FLANGER3

No. Parameter Value LCD

MIDI Parameter Number

Controller

1 LFO Frequency

LFO Depth
LFO Phase Difference
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Delay Offset
Feedback Level

0.0Hz~39.70Hz
0~127

-180deg~+180deg
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

0.0ms~50.0ms

-63~+63

Speed
Depth
Phase
L.Freq
L.Gain
H.Freq
H.Gain
DlyOfst
FBLevel

2
3
4
5
6
7
8
9

1
2
5
6
7
8
9
4
3

Ø

Ø
Ø
Ø
Ø

Ø

18

[15] TEMPO FLANGER

No. Parameter Value L CD

MIDI Parameter Number

Controller

1 LFO Frequency

LFO Depth
LFO Phase Difference
LFO Phase Reset
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Delay Offset
Feedback Level

5~21
0~127

-180deg~+180deg
off(free run), KeyOnReset, SEQ Start Reset
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

0.0ms~50.0ms

-63~+63

Speed
Depth
Phase
Reset
L.Freq
L.Gain
H.Freq
H.Gain
DlyOfst
FBLevel

2
3
4
5
6
7
8
9

10

1
2
6
5
7
8
9

10

4
3

Ø

Ø
Ø
Ø
Ø

Ø

[16] PHASER1

No. Parameter Value L CD

MIDI Parameter Number

Controller

1 LFO Frequency

LFO Depth
Diffusion
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Stage
Phase Shift Offset
Feedback Level

0.0Hz~39.70Hz
0~127
mono/stereo
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB
4, 5, 6
0~127

-63~+63

Speed
Depth
Diffuse
L.Freq
L.Gain
H.Freq
H.Gain
Stage
PhShift
FBLevel

2
3
4
5
6
7
8
9

10

1
2
6
7
8
9

10

5
3
4

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

[17] TEMPO PHASER

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

LFO Frequency
LFO Depth
LFO Phase Reset
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Stage
Phase Shift Offset
Feedback Level

5~21
0~127
off(free run), KeyOnReset, SEQ Start Reset
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB
4, 5, 6
0~127

-63~+63

Speed
Depth
PhaseReset
L.Freq
L.Gain
H.Freq
H.Gain
Stage
PhShift
FBLevel

1
2
6
7
8
9

10

5
3
4

Ø

Ø
Ø
Ø
Ø
Ø

Ø

9

10

[18] DELAY L,R(stereo)

No. Parameter Value L CD

MIDI Parameter Number

Controller

1 Delay Time L

Delay Time R
Feedback Time 1
Feedback Time 2
Feedback Level
Feedback High Damp
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

0.1ms~740.0ms

0.1ms~740.0ms

0.1ms~740.0ms

0.1ms~740.0ms

-63~+63

0.1~1.0
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

TimeL
TimeR
FBTime1
FBTime2
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain

2
3
4
5
6
7

1
2
3
4
5
6
7
8
9

10

Ø
Ø
Ø
Ø
Ø

8
9

10

[19] CONTROL DELAY1(mono)

No. Parameter Value L CD

MIDI Parameter Number

Controller

1 Delay Time

Delay T ransition Rate
Feedback Level
Feedback High Damp
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

0.1ms~1480.0ms
1~48

-63~+63

0.1~1.0
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

Time
Trnsitn
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain

2
3

1
2
3
4
5
6
7
8

Ø
Ø
Ø
Ø
Ø
Ø
Ø

4
5
6
7

8

[20] CONTROL DELAY2(stereo)

No. Parameter Value L CD

MIDI Parameter Number

Controller

1 Delay Time

Delay T ransition Rate
Feedback Level
Feedback High Damp
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

0.1ms~740.0ms
1~48

-63~+63

0.1~1.0
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

Time
Trnsitn
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gainl

2
3
4
5
6
7
8

1
2
3
4
5
6
7
8

Ø
Ø
Ø
Ø
Ø
Ø
Ø

[21] TEMPO DELAY1(mono)

No. Parameter Value L CD

MIDI Parameter Number

Controller

1 Delay Time

Lag
L/R Diffusion
Feedback Level
Feedback High Damp
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

2~14

-63ms~+63ms

-63ms~+63ms

-63~+63

0.1~1.0
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

Time
Lag
Diffuse
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain

2
3
4
5
6
7
8
9

1
5
4
2
3
6
7
8
9

Ø
Ø
Ø
Ø
Ø

[22] TEMPO DELAY2(stereo)

No. Parameter Value L CD

MIDI Parameter Number

Controller

1 Delay Time

Lag
L/R Diffusion
Feedback Level
Feedback High Dump
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

2~14

-63ms~+63ms

-63ms~+63ms

-63~+63

0.1~1.0
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

Time
Lag
Diffuse
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain

2
3
4
5
6
7
8
9

1
5
4
2
3
6
7
8
9

Ø
Ø
Ø
Ø
Ø

[23] TEMPO CROSS DELAY

No. Parameter Value LCD

MIDI Parameter Number

Controller

1 Delay Time L>R

Delay Time R>L
Input Select
Lag
Feedback Level
Feedback High Dump
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

2~14
2~14
L, R, L&R

-63ms~+63ms

-63~+63

0.1~1.0
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

TimeL>R
TimeR>L
Input
Lag
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain

2
3
4
5
6
7
8
9

10

1
2
5
6
3
4
7
8
9

10

Ø
Ø
Ø
Ø
Ø

3. Insertion Effect 1

[5]~[8]CELESTE1~4

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

LFO Frequency
LFO Depth
Input Mode
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Delay Offset
Feedback Level
Dry / Wet Balance

0.0Hz~39.70Hz
0~127
mono/stereo
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

0.0ms~50.0ms

-63~+63
D63>W ~D=W ~D<W63

Speed
Depth
Input
L.Freq
L.Gain
H.Freq
H.Gain
DlyOfst
FBLevel
Dry/Wet

1
2
9
5
6
7
8
4
3

10

Ø
Ø

Ø
Ø
Ø
Ø

Ø
Ø

[1]~[4]CHORUS1~4

9

10

[0] THRU (None)

[9]~[11] FLANGER1~3

No. Parameter Value L CD

MIDI Parameter Number

Controller

1 LFO Frequency

LFO Depth
LFO Phase Difference
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Delay Offset
Feedback Level
Dry / Wet Balance

0.0Hz~39.70Hz
0~127

-180deg~+180deg
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

0.0ms~50.0ms

-63~+63
D63>W ~ D=W ~ D<W63

Speed
Depth
Phase
L.Freq
L.Gain
H.Freq
H.Gain
DlyOfst
FBLevel
Dry/Wet

2
3
4
5
6
7

1
2
9
5
6
7
8
4
3

10

Ø
Ø

Ø
Ø
Ø
Ø

Ø
Ø

8
9

10

19

[12] PHASER1

No. Parameter Value L CD

MIDI Parameter Number

Controller

1 LFO Frequency

LFO Depth
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Stage
Phase Shift Offset
Feedback Level
Dry / Wet Balance

0.0Hz~39.70Hz
0~127
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB
4, 5, 6
0~127

-63~+63
D63>W ~ D=W ~ D<W63

Speed
Depth
L.Freq
L.Gain
H.Freq
H.Gain
Stage
PhShift
FBLevel
Dry/Wet

2
3

1
2
6
7
8
9
5
3
4

10

Ø
Ø
Ø
Ø
Ø
Ø
Ø

Ø
Ø

4
5
6
7

8

9

10

[13] TREMOLO

No. Parameter Value L CD

MIDI Parmeter Number

Controller

1 LFO Frequency

AM Depth
PM Depth
LFO Phase Difference
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Input Mode

0.0Hz~39.70Hz
0~127
0~127

-180deg~+180deg
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB
mono/stereo

Speed
AMDepth
PMDepth
Phase
L.Freq
L.Gain
H.Freq
H.Gain
Input

2
3
4
5
6
7
8
9

1
2
3
4
5
6
7
8
9

Ø
Ø
Ø

Ø
Ø
Ø
Ø

[14] AUTO PAN

No. Parameter Value L CD

MIDI Parameter Number

Controller

1 LFO Frequency

L/R Depth
F/R Depth
PAN Direction
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

0.0Hz~39.70Hz
0~127
0~127

L<>R, L>>R, L<<R, Lturn, Rturn, L/R (0 ~5)

32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

Speed
L/RDpth
F/RDpth
Directn
L.Freq
L.Gain
H.Freq
H.Gain

2
3
4
5
6
7
8

1
2
3
4
5
6
7
8

Ø
Ø
Ø

Ø
Ø
Ø
Ø

[16] OVERDRIVE

No. Parameter Value L CD

MIDI Parameter Number

Controller

1Drive

Edge
Output Level
EQ Low Frequency
EQ Low Gain
LPF Cutoff Frequency
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Dry / Wet Balance

0~127
0~127
0~127
32Hz~2.0kHz

-12dB~+12dB

1.0kHz~20.0kHz
100Hz~10.0kHz

-12dB~+12dB

0.1~12.0
D63>W ~ D=W ~ D<W63

Drive
Edge
OutLvl
L.Freq
L.Gain
LPF
M.Freq
M.Gain
M.Width
Dry/Wetl

2
3
4
5
6
7
8
9

10

1
8
9
2
3
7
4
5
6

10

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

[15] DISTORTION

[17] AMP SIMULATOR

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6

AMP Type
Drive
Edge
Output Level
LPF Cutoff Frequency
Dry / Wet Balance

off, stack, combo, tube
0~127
0~127
0~127

1.0kHz~20.0kHz
D63>W ~ D=W ~ D<W63

AmpType
Drive
Edge
OutLvl
LPF
Dry/Wet

2
1
4
5
3
6

Ø
Ø
Ø
Ø
Ø

[18] COMPRESSOR

No. Parameter Value L CD

MIDI Parameter Number

Controller

1 Attack

Release
Threshold
Ratio
Output Level

1ms~40ms
10ms~680ms

-48dB~-6dB
1~20.0
0~127

Attack
Release
Thrshld
Ratio
OutLvl

2
3
4
5

1
2
3
4
5

Ø
Ø
Ø
Ø
Ø

[19] NOISE GATE

No. Parameter Value L CD

MIDI Parameter Number

Controller

1 Attack

Release
Threshold
Output Level

1ms~40ms
10ms~680ms

-72dB~-30dB
0~127

Attack
Release
Thrshld
Out Lvl

2
3

1
2
3
4

Ø
Ø
Ø
Ø

4

[20] AUTO WAH

No. Parameter Value L CD

MIDI Parameter Number

Controller

1 LFO Frequency

LFO Depth
Cutoff Frequency Offset
Resonanse
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Dry / Wet Balance

0.0Hz~39.70Hz
0~127
0~127
1~12.0
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB
D63>W ~ D=W ~ D<W63

Speed
Depth
Cutoff
Reso
L.Freq
L.Gain
H.Freq
H.Gain
Dry/Wet

2
3
4
5
6
7
8

1
2
3
4
5
6
7
8
9

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

9

[21] TOUCH WAH

No. Parameter Value L CD

MIDI Parameter Number

Controller

1 Sensitive

Cutoff Frequency Offset
Resonanse
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Dry / Wet Balance

0~127
0~127
1~12.0
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB
D63>W ~ D=W ~ D<W63

Sens
Cutoff
Reso
L.Freq
L.Gain
H.Freq
H.Gain
Dry/Wet

2
3
4
5
6
7
8

1
2
3
4
5
6
7
8

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

[22] 2BAND EQ

No. Parameter Value L CD

MIDI Parameter Number

Controller

1 EQ Low Frequency

EQ Low Gain
EQ High Frequency
EQ High Gain

32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

L.Freq
L.Gain
H.Freq
H.Gain

2
3
4

1
2
3
4

Ø
Ø
Ø
Ø

[23] 3BAND EQ

No. Parameter Value L CD

MIDI Parameter Number

Controller

1 EQ Low Frequency

EQ Low Gain
EQ High Frequency
EQ High Gain
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Input Mode

50Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB
100Hz~10.0kHz

-12dB~+12dB

0.1~12.0
mono/stereo

L.Freq
L.Gain
H.Freq
H.Gain
M.Freq
M.Gain
M.Width
Input

2
3
4
5
6
7
8

1
2
6
7
3
4
5
8

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

[24] HARMONIC ENHANCER

No. Parameter Value L CD

MIDI Parameter Number

Controller

1 HPF Cutoff Frequency

Drive
Mix Level

500Hz~+16.0kHz
0~127
0~127

HPF
Drive
Mix Lvl

2
3

1
2
3

Ø
Ø
Ø

4. Insertion Effect 2

[0] THRU (None)

[1] HALL1 ~ [8] PLATE

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

Reverb Time
Initial Delay
Reverb Delay
Dry / Wet Balance
HPF Cutoff Frequency
LPF Cutoff Frequency
Diffusion
Density
ER / Rev Balance
Feedback Level
Feedback High Damp

0.3s~30.0s

0.1ms~99.3ms

0.1ms~99.3ms
D63>W ~ D=W ~ D<W63
20Hz~8.0kHz

1.0kHz~20.0kHz
0~10
0~4
E63>R ~ E=R ~ E<R63

-63~+63

0.1~1.0

RevTime
InitDly
RevDly
Dry/Wet
HPF
LPF
Diffuse
Density
ER/Rev
FBLevel
FBHiDmp

1

3
11
10

4

5

2
12
13
15
14

9
10
11

Ø
Ø
Ø

Ø
Ø

20

[9] DELAY L,C,R

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

Delay Time L
Delay Time R
Delay Time C
Dry / Wet Balance
Delay Level C
Feedback Time
Feedback Level
Feedback High Damp
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

0.1ms~1486.0ms

0.1ms~1486.0ms

0.1ms~1486.0ms
D63>W ~ D=W ~ D<W63
0~127

0.1ms~1486.0ms

-63~+63

0.1~1.0
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

TimeL
TimeR
TimeC
Dry/Wet
LevelC
FBTime
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain

1
2
3

10

6
4
5

7
13
14
15
16

9
10
11
12

Ø
Ø

Ø
Ø
Ø
Ø
Ø
Ø

[10] DELAY L,R

No. Parameter Value L CD

MIDI Parameter Number

Controller

1

2

3

4

5

6

7

8

Delay Time L
Delay Time R
Dry / Wet Balance
Feedback Time 1
Feedback Time 2
Feedback Level
Feedback High Damp
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

0.1ms~1486.0ms

0.1ms~1486.0ms
D63>W ~ D=W ~ D<W63

0.1ms~1486.0ms

0.1ms~1486.0ms

-63~+63

0.1~1.0
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

TimeL
TimeR
Dry/Wet
FBTime1
FBTime2
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain

1
2

10

3
4
5

6
13
14
15
16

9
10
11

Ø

Ø
Ø
Ø
Ø
Ø
Ø

[11] ECHO

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

Delay Time L1
Delay Time R1
Dry / Wet Balance
Feedback Level L
Feedback Level R
Feedback High Damp
Delay Time L2
Delay Time R2
Delay Level
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

0.1ms~743.0ms

0.1ms~743.0ms
D63>W ~ D=W ~ D<W63

-63~+63

-63~+63

0.1~1.0

0.1ms~743.0ms

0.1ms~743.0ms
0~127
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

TimeL1
TimeR1
Dry/Wet
FBLvlL
FBLvlR
FBHiDmp
TimeL2
TimeR2
Level2
L.Freq
L.Gain
H.Freq
H.Gain

1
3

10

2
4
5
6
7

8
13
14
15
16

9
10
11
12
13

Ø
Ø
Ø
Ø

Ø
Ø
Ø
Ø
Ø

[12] CROSS DELAY

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

Delay Time L>R
Delay Time R>L
Input Select
Dry / Wet Balance
Feedback Level
Feedback High Damp
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

0.1ms~743.0ms

0.1ms~743.0ms
L, R, L&R
D63>W ~ D=W ~ D<W63

-63~+63

0.1~1.0
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

TimeL>R
TimeR>L
Input
Dry/Wet
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain

1
2
4

10

3

5
13
14
15
16

9

10

Ø
Ø
Ø
Ø
Ø
Ø
Ø

[13] CONTROL DELAY1(mono)

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

Delay Time
Delay T ransition Rate
Dry / Wet Balance
Control Type
Feedback Level
Feedback High Damp
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

0.1ms~1486.0ms
1~48
D63>W ~ D=W ~ D<W63
normal, scratch

-63~+63

0.1~1.0
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

Time
Trnsitn
Dry/Wet
CtrType
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain

1

2

10
11

3

4

6

7

8

9

9

10

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

[14] CONTROL DELAY2(stereo)

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

Delay Time
Delay T ransition Rate
Dry / Wet Balance
Control Type
Feedback Level
Feedback High Damp
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

0.1ms~743.0ms
1~48
D63>W ~ D=W ~ D<W63
normal, scratch

-63~+63

0.1~1.0
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

Time
Trnsitn
Dry/Wet
CtrType
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain

1
2

10
11

3
4
6
7
8
9

9

10

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

[15] TEMPO DELAY1(mono)

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

Delay Time
Dry / Wet Balance
Lag
L/R Diffusion
Feedback Level
Feedback High Dump
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

2~14
D63>W ~ D=W ~ D<W63

-63ms~+63ms

-63ms~+63ms

-63~+63

0.1~1.0
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

Time
Dry/Wet
Lag
Diffuse
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain

1

10

6
5
3

4
13
14
15
16

9

10

Ø

Ø
Ø
Ø
Ø
Ø
Ø

[16] TEMPO DELAY2(stereo)

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

Delay Time
Dry / Wet Balance
Lag
L/R Diffusion
Feedback Level
Feedback High Dump
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

2~14
D63>W ~ D=W ~ D<W63

-63ms~+63ms

-63ms~+63ms

-63~+63

0.1~1.0
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

Time
Dry/Wet
Lag
Diffuse
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain

1

10

6
5
3

4
13
14
15
16

9

10

Ø

Ø
Ø
Ø
Ø
Ø
Ø

[17] TEMPO CROSS DELAY

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

Delay Time L>R
Delay Time R>L
Input Select
Dry / Wet Balance
Lag
Feedback Level
Feedback High Dump
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

2~14
2~14
L, R, L&R
D63>W ~ D=W ~D<W63

-63ms~ +63ms

-63~+63

0.1~1.0
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

TimeL>R
TimeR>L
Input
Dry/Wet
Lag
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain

1

2

6
10

8

4

5
13
14
15
16

9
10
11

Ø

Ø
Ø
Ø
Ø
Ø
Ø

[18]~[19] EARLY REF1~2

No. Parameter Value L CD

MIDI Parameter Number

Controller

1

2
3
4
5
6
7
8

Type

Room Size
Dry / Wet Balance
Diffusion
Initial Delay
Liveness
Density
HPF Cutoff Frequency
LPF Cutoff Frequency
Feedback Level
Feedback High Damp

S-hall, L-hall, random,
reverse, plate, spring

0.1~20.0
D63>W ~ D=W ~ D<W63
0 ~ 10

0.1ms~200.0ms
0 ~ 10
0 ~ 3
20Hz~8.0kHz

1.0kHz~20.0kHz

-63~+63

0.1~1.0

Type

Size
Dry/Wet
Diffuse
InitDly
Livenss
Density
HPF
LPF
FBLevel
FBHiDmp

1

2

10

3

4
11
12

6

7

5
13

9
10
11

Ø

Ø
Ø
Ø

21

[21] REVERSE GATE

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

Type
Room Size
Dry / Wet Balance
Diffusion
Initial Delay
Liveness
Density
HPF Cutoff Frequency
LPF Cutoff Frequency
Feedback Level
Feedback High Damp

Type-A, Type-B

0.1~20.0
D63>W ~ D=W ~ D<W63
0 ~ 10

0.1ms~200.0ms
0 ~ 10
0 ~ 3
20Hz~8.0kHz

1.0kHz~20.0kHz

-63~+63

0.1~1.0

Type
Size
Dry/Wet
Diffuse
InitDly
Livenss
Density
HPF
LPF
FBLevel
FBHiDmp

1
2

10

3

4
11
12

6

7

5
13

9
10
11

Ø

Ø
Ø
Ø

[20] GATE REVERB

[22]~[24] KARAOKE1~3

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5

Delay Time
Feedback Level
Dry / Wet Balance
HPF Cutoff Frequency
LPF Cutoff Frequency

0.1ms~400.0ms

-63~+63
D63>W ~ D=W ~ D<W63
20Hz~8.0kHz

1.0kHz~20.0kHz

DlyTime
FBLevel
Dry/Wet
HPF
LPF

1
2

10

3
4

Ø
Ø
Ø
Ø

[30]~[33] CELESTE1~4

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

LFO Frequency
LFO Depth
Input Mode
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Delay Offset
Feedback Leve
Dry / Wet Balance

0.0Hz~39.70Hz
0~127
mono/stereo
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB
100Hz~10.0kHz

-12dB~+12dB

0.1~12.0

0.0ms~50.0ms

-63~+63
D63>W ~ D=W ~ D<W63

Speed
Depth
Input
L.Freq
L.Gain
H.Freq
H.Gain
M.Freq
M.Gain
M.Width
DlyOfst
FBLevel
Dry/Wet

1
2

15

6
7
8

9
11
12
13

4

3
10

9
10
11
12
13

Ø
Ø

Ø
Ø
Ø
Ø
Ø
Ø
Ø

Ø
Ø

[25]~[29] CHORUS1~5

[34] SYMPHONIC

No. Parameter Value L CD

MIDI Parameter Number

Controller

1

2

3

4

5

6

7

8

LFO Frequency
LFO Depth
Delay Offset
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Dry / Wet Balance

0.0Hz~39.70Hz
0~127

0.0ms~50.0ms
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB
100Hz~10.0kHz

-12dB~+12dB

0.1~12.0
D63>W ~ D=W ~ D<W63

Speed
Depth
DlyOfst
L.Freq
L.Gain
H.Freq
H.Gain
M.Freq
M.Gain
M.Width
Dry/Wet

1
2
4
6
7
8

9
11
12
13
10

9
10
11

Ø
Ø

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

[35] ENSEMBLE DETUNE

No. Parameter Value L CD

MIDI Parameter Number

Controller

1

2

3

4

5

6

7

8

Detune
Initial Delay Lch
Initial Delay Rch
Dry / Wet Balance
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

-50cent~+50cent

0.0ms~50.0ms

0.0ms~50.0ms
D63>W ~ D=W ~ D<W63
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

Detune
DelayL
DelayR
Dry/Wet
L.Freq
L.Gain
H.Freq
H.Gain

1
2

3
10
11
12
13
14

Ø
Ø
Ø
Ø
Ø

[36]~[38] FLANGER1~3

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

LFO Frequency
LFO Depth
LFO Phase Difference
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Delay Offset
Feedback Leve
Dry / Wet Balance

0.0Hz~39.70Hz
0~127

-180deg~+180deg
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB
100Hz~10.0kHz

-12dB~+12dB

0.1~12.0

0.0ms~50.0ms

-63~+63
D63>W ~ D=W ~ D<W63

Speed
Depth
Phase
L.Freq
L.Gain
H.Freq
H.Gain
M.Freq
M.Gain
M.Width
DlyOfst
FBLevel
Dry/Wet

1
2

14

6
7
8
9

11
12
13

4
3

10

9
10
11
12
13

Ø
Ø

Ø
Ø
Ø
Ø
Ø
Ø
Ø

Ø
Ø

[39] V-FLANGER

No. Parameter Value L CD

MIDI Parameter Number

Controller

1

2

3

4

5

6

7

8

LFO Frequency
LFO Depth
LFO Wave
Modulation Phase
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Analog Feel
Feedback Gain
Feedback High Damp
Delay Offset
Dry / Wet Balance

0.0Hz~39.70Hz
0~127
Triangle, Sine, Random

-180~+180
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB
100Hz~10.0kHz

-12dB~+12dB

0.1~12.0
0~10

-100~+100%

0.1~1.0

0.09~36.21ms
D63>W ~ D=W ~ D<W63

Speed
Depth
Wave
Phase
L.Freq
L.Gain
H.Freq
H.Gain
M.Freq
M.Gain
M.Width
Analog
FBLevel
FBHiDmp
DlyOfst
Dry/Wet

1
2
3
5
6
7
8

9
11
12
13
16
14
15

4
10

9
10
11
12
13
14
15
16

Ø
Ø

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

Ø

[40] TEMPO FLANGER

No. Parameter Value LCD

MIDI Parameter Number

Controller

1

2

3

4

5

6

7

8

LFO Frequency
LFO Depth
LFO Phase Difference
LFO Phase Reset
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Delay Offset
Feedback Level
Dry / Wet Balance

5~21
0~127

-180deg~+180deg

off(free run), KeyOnReset, SEQ Start Reset

32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB
100Hz~10.0kHz

-12dB~+12dB

0.1~12.0

0.0ms~50.0ms

-63~+63
D63>W ~ D=W ~ D<W63

Speed
Depth
Phase
Reset
L.Freq
L.Gain
H.Freq
H.Gain
M.Freq
M.Gain
M.Width
DlyOfst
FBLevel
Dry/Wet

1
2

14

5
6
7
8

9
11
12
13

4

3
10

9
10
11
12
13
14

Ø
Ø

Ø
Ø
Ø
Ø
Ø
Ø
Ø

Ø
Ø

[41] PHASER1

No. Parameter Value L CD

MIDI Parameter Number

Controller

1

2

3

4

5

6

7

8

LFO Frequency
LFO Depth
Diffusion
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Stage
Phase Shift Offset
Feedback Level
Dry / Wet Balance

0.0Hz~39.70Hz
0~127
mono/stereo
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB
4, 5, 6, 7, 8, 9, 10, 11, 12
0~127

-63~+63
D63>W ~ D=W ~ D<W63

Speed
Depth
Diffuse
L.Freq
L.Gain
H.Freq
H.Gain
Stage
PhShift
FBLevel
Dry/Wet

1
2

12

6
7
8
9

11

3
4

10

9
10

Ø
Ø

Ø
Ø
Ø
Ø
Ø

Ø
Ø

11

22

[42] PHASER2

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

LFO Frequency
LFO Depth
LFO Phase Difference
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Stage
Phase Shift Offset
Feedback Level
Dry / Wet Balance

0.0Hz~39.70Hz
0~127

-180deg~+180deg
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB
3, 4, 5, 6
0~127

-63~+63
D63>W ~ D=W ~ D<W63

Speed
Depth
Phase
L.Freq
L.Gain
H.Freq
H.Gain
Stage
PhShift
FBLevel
Dry/Wet

1
2

13

6
7
8
9

11

3
4

10

9

10

Ø
Ø

Ø
Ø
Ø
Ø
Ø

Ø
Ø

11

[43] TEMPO PHASER

No. Parameter Value L CD

MIDI Parameter Number

Controller

1

2

3

4

5

6

7

8

LFO Frequency
LFO Depth
LFO Phase Difference
LFO Phase Reset
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Stage
Phase Shift Offset
Feedback Level
Dry / Wet Balance

5~21
0~127

-180deg~+180deg
off(free run), KeyOnReset, SEQ Start Reset
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB
3, 4, 5, 6
0~127

-63~+63
D63>W ~ D=W ~ D<W63

Speed
Depth
Phase
Reset
L.Freq
L.Gain
H.Freq
H.Gain
Stage
PhShift
FBLevel
Dry/Wet

1
2

13

5
6
7
8
9

11

3
4

10

9

10

Ø
Ø

Ø
Ø
Ø
Ø
Ø

Ø
Ø

11
12

[44] TREMOLO

No. Parameter Value L CD

MIDI Parameter Number

Controller

1

2

3

4

5

6

7

8

LFO Frequency
AM Depth
PM Depth
LFO Phase Difference
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Input Mode

0.0Hz~39.70Hz
0~127
0~127

-180deg~+180deg
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB
100Hz~10.0kHz

-12dB~+12dB

0.1~12.0
mono/stereo

Speed
AMDepth
PMDepth
Phase
L.Freq
L.Gain
H.Freq
H.Gain
M.Freq
M.Gain
M.Width
Input

1
2
3

14

6
7
8

9
11
12
13
15

9

10

Ø
Ø
Ø

Ø
Ø
Ø
Ø
Ø
Ø
Ø

11
12

[45] AUTO PAN

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

LFO Frequency
L/R Depth
F/R Depth
PAN Direction
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width

0.0Hz~39.70Hz
0~127
0~127

L<>R, L>>R, L<<R, Lturn, Rturn, L/R(0~5)

32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB
100Hz~10.0kHz

-12dB~+12dB

0.1~12.0

Speed
L/RDpth
F/RDpth
Directn
L.Freq
L.Gain
H.Freq
H.Gain
M.Freq
M.Gain
M.Width

1

2

3

4

6

7

8

9

11
12
13

9

10

Ø
Ø
Ø

Ø
Ø
Ø
Ø
Ø
Ø
Ø

11

[46] ROTARY SPEAKER1

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

LFO Frequency
LFO Depth
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Dry / Wet Balance

0.0Hz~39.70Hz
0~127
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB
100Hz~10.0kHz

-12dB~+12dB

0.1~12.0
D63>W ~ D=W ~ D<W63

Speed
Depth
L.Freq
L.Gain
H.Freq
H.Gain
M.Freq
M.Gain
M.Width
Dry/Wet

1

2

6

7

8

9

11
12
13
10

9

10

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

[47] DISTORTION+ROTARY SPEAKER1
[48] OVERDrive+ROTARY SPEAKER1

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

LFO Frequency
LFO Depth
Dist. Drive
Dist. LPF Cutoff Freq
Dist. Output Level
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

0.0Hz~39.70Hz
0 ~ 127
0 ~ 127

1.0kHz~18.0kHz, thru
0 ~ 127
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

Speed
Depth
Drive
LPF
DrivOut
L.Freq
L.Gain
H.Freq
H.Gain

1
2

14
15
16

6
7
8
9

9

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

[49] AMP SIMULATOR+ROTARY SPEAKER1

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

LFO Frequency
LFO Depth
AMP Type
AMP Drive
AMP LPF Cutoff Freq
AMP Output Level
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

0.0Hz~39.70Hz
0 ~ 127
off, stack, combo, tube
0 ~ 127

1.0kHz~18.0kHz, thru
0 ~ 127
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

Speed
Depth
AmpType
Drive
LPF
AmpOut
L.Freq
L.Gain
H.Freq
H.Gain

1
2
3

14
15
16

6
7
8
9

9

10

Ø
Ø

Ø
Ø
Ø
Ø
Ø
Ø
Ø

[50] ROTARY SPEAKER2

No. Parameter Value LCD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8
9

10

Rotor Speed
Drive Low
Drive High
Low / High Balance
Mic L-R Angle
Divide Frequency
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

0.0Hz~39.70Hz
0~127
0~127
L63>H ~ L=H ~ L<H63
0deg~180deg
100Hz~10.0kHz
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

Speed
DriveLo
DriveHi
Low/Hi
MicAngl
CrosOvr
L.Freq
L.Gain
H.Freq
H.Gain

1
2
3
4
5

11

6
7
8
9

Ø
Ø
Ø
Ø

Ø
Ø
Ø
Ø

[52] OVERDrive+ROTARY SPEAKER2

No. Parameter Value LCD

MIDI Parameter Number

Controller
1
2
3
4
5
6
7
8

Rotor Speed
Drive Low
Drive High
Low/High Balance
Mic L-R Angle
Divide Frequency
Dist.Drive
Dist. LPF Cutoff Freq
Dist. Output Level
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

0.0Hz~39.70Hz
0 ~ 127
0 ~ 127
L63>H ~ L=H ~ L<H63
0deg~180deg
100Hz~10.0kHz
0 ~ 127

1.0kHz~18.0kHz, thru
0 ~ 127
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

Speed
DriveLo
DriveHi
Low/Hi
MicAngl
CrosOvr
Drive
LPF
DrivOut
L.Freq
L.Gain
H.Freq
H.Gain

1
2
3

4
12
11
14
15
16

6

7

8

9

9
10
11
12
13

Ø
Ø
Ø
Ø

Ø
Ø
Ø
Ø
Ø
Ø
Ø

[51] DISTORTION+ROTARY SPEAKER2

[53] AMP SIM.+ROTARY SPEAKER2

No. Parameter Value LCD

MIDI Parameter Number

Controller
1
2
3
4
5
6
7
8

Rotor Speed
Drive Low
Drive High
Low/High Balance
Mic L-R Angle
Divide Frequency
AMP Type
AMP Drive
AMP LPF Cutoff Freq
AMP Output Level
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

0.0Hz~39.70Hz
0 ~ 127
0 ~ 127
L63>H ~ L=H ~ L<H63
0deg~180deg
100Hz~10.0kHz
off, stack, combo, tube
0 ~ 127

1.0kHz~18.0kHz, thru
0 ~ 127
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

Speed
DriveLo
DriveHi
Low/Hi
MicAngl
CrosOvr
AmpType
Drive
LPF
AmpOut
L.Freq
L.Gain
H.Freq
H.Gain

1
2
3

4
12
11
13
14
15
16

6

7

8

9

9
10
11
12
13
14

Ø
Ø
Ø
Ø

Ø
Ø
Ø
Ø
Ø
Ø
Ø

23

[55] ROTARY SPEAKER4

No. Parameter Value LCD

MIDI Parameter Number

Controller
1
2
3
4
5
6
7
8

Speed Control
SLow-Fast Time of R
SLow-Fast Time of H
Rotor Speed SLow
Horn Speed SLow
Rotor Speed Fast
Horn Speed Fast
Mic L-R Angle
Drive Low
Drive High
Low/High Balance
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

sLow, fast
0~127
0~127

0.0Hz~2.65Hz

0.0Hz~2.65Hz

2.69Hz~39.70Hz

2.69Hz~39.70Hz
0deg~180deg
0~127
0~127
L63>H ~ L=H ~ L<H63
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

Speed
Trans:Rotor
Trans:Horn
Rotor-Slw
Horn-Slw
Rotor-Fst
Horn-Fst
MicAngl
DriveLo
DriveHi
Low/Hi
L.Freq
L.Gain
H.Freq
H.Gain

16

5
6
1
2
3
4

15

7
8

9
11
12
13
14

Ø
Ø
Ø
Ø
Ø
Ø
Ø

Ø
Ø
Ø
Ø
Ø
Ø
Ø

[54] ROTARY SPEAKER3

10
11
12
13
14
15

9

No. Parameter Value LCD

MIDI Parameter Number

Controller
1
2
3
4
5
6
7
8

Drive
Edge
Output Level
EQ Low Frequency
EQ Low Gain
LPF Cutoff Frequency
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Dry / Wet Balance

0~127
0~127
0~127
32Hz~2.0kHz

-12dB~+12dB

1.0kHz~20.0kHz
100Hz~10.0kHz

-12dB~+12dB

0.1~12.0
D63>W ~ D=W ~ D<W63

Drive
Edge
OutLvl
L.Freq
L.Gain
LPF
M.Freq
M.Gain
M.Width
Dry/Wet

1

11

5
2
3
4
7
8
9

10

9

10

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

[59] OVERDRIVE

No. Parameter Value LCD

MIDI Parameter Number

Controller
1
2
3
4
5
6
7
8

Drive
Edge
Output Level
EQ Low Frequency
EQ Low Gain
LPF Cutoff Frequency
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Dry / Wet Balance

0~127
0~127
0~127
32Hz~2.0kHz

-12dB~+12dB

1.0kHz~20.0kHz
100Hz~10.0kHz

-12dB~+12dB

0.1~12.0
D63>W ~ D=W ~ D<W63

Drive
Edge
OutLvl
L.Freq
L.Gain
LPF
M.Freq
M.Gain
M.Width
Dry/Wet

1

11

5
2
3
4
7
8
9

10

9

10

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

[56] DISTORTION

[57] COMP DISTORTION

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

Attack
Release
Threshold
Ratio
EQ Low Frequency
EQ Low Gain
Drive
Output Level
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Edge
LPF Cutoff Frequency
Dry / Wet Balance

1ms~40ms
10ms~680ms

-48dB~'-6dB
1~20.0
32Hz~2.0kHz

-12dB~+12dB
0~127
0~127
100Hz~10.0kHz

-12dB~+12dB

0.1~12.0
0~127

1.0kHz~20.0kHz
D63>W ~ D=W ~ D<W63

Attack
Release
Thrshld
Ratio
L.Freq
L.Gain
Drive
OutLvl
M.Freq
M.Gain
M.Width
Edge
LPF
Dry/Wet

12
13
14
15

2
3
1
5
7
8
9

11

4

10

9
10
11
12
13
14

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

[58] V-DISTORTION

No. Parameter Value L CD

MIDI Parameter Number

Controller

1

2

3

4

5

6

7

8

Over Drive
Device
Speaker T ype
Presence
Delay Time L
Delay Time R
Feedback Time
Feedback Level
Feedback High Damp
Output Level
Delay Mix
Dry/Wet Balance

0 ~ 100%

Transister , Vintage Tube,Dsitortion1, Dsitortion2, Fuzz

Flat, Stack, Combo, Twin, Radio, Megaphone

-10 ~ 10

0.1ms~1486.0ms

0.1ms~1486.0ms

0.1ms~1486.0ms

-63~+63

0.1~1.0
0 ~ 100%
0 ~ 127
D63>W ~ D=W ~ D<W63

OverDr
Device
Speaker
Presenc
DelayL
DelayR
FBTime
FBLevel
FBHiDmp
DistLvl
DlyMix
Dry/Wet

1
2
3
4
6
7
8
9

12

5
11
10

9
10
11
12

Ø

Ø

Ø
Ø
Ø
Ø
Ø

[62] OVERDRIVE+DELAY

No. Parameter Value L CD

1
2
3
4
5
6
7
8

Dist. Drive
Dist. EQ Low Gain
Dist. EQ Mid Gain
Dist Output Level
Delay Time L
Delay Time R
Delay Feedback Time
Delay Feedback Leve
Delay mix
Dry / Wet Balance

0~127

-12dB~+12dB

-12dB~+2dB
0~127

0.1ms~1486.0ms

0.1ms~1486.0ms

0.1ms~1486.0ms

-63~+63
0~127
D63>W ~ D=W ~ D<W63

Drive
EQ-Low
EQ-Mid
DrivOut
DelayL
DelayR
FBTime
FBLevel
DlyMix
Dry/Wet

9

10

[61] DIST+DELAY

MIDI Parameter Number

Controller

6
8
9
7
1
2
3
4
5

10

Ø
Ø
Ø
Ø

Ø
Ø
Ø

[63] COMPRESSOR1

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5

Attack
Release
Threshold
Ratio
Output Level

1ms~40ms
10ms~680ms

-48dB~’-6dB
1~20.0
0~127

Attack
Release
Thrshld
Ratio
OutLvl

1
2
3
4
5

Ø
Ø
Ø
Ø
Ø

[64] NOISE GATE

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4

Attack
Release
Threshold
Output Level

1ms~40ms
10ms~680ms

-72dB~’-30dB
0~127

Attack
Release
Thrshld
OutLvl

1
2
3
4

Ø
Ø
Ø
Ø

[66] COMP+ODRV+DELAY

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

Comp. Attack
Comp. Release
Comp. Threshold
Comp. Ratio
Dist. Drive
Dist. EQ Low Gain
Dist. EQ Mid Gain
Dist Output Level
Delay Time
Delay Feedback Level
Delay Mix
Dry / Wet Balance

1ms~40ms
10ms~680ms

-48dB~-6dB
1~20.0
0~127

-12dB~+12dB

-12dB~+12dB
0~127

0.1ms~1486.0ms

-63~+63
0~127
D63>W ~ D=W ~ D<W63

Attack
Release
Thrshld
Ratio
Drive
EQ-Low
EQ-Mid
DrivOut
DlyTime
FBLevel
DlyMix
Dry/Wet

11
12
13
14

4
6
7
5
1
2
3

10

9

10

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

Ø
Ø
Ø

11
12

[65] COMP+DIST+DELAY

[68] PITCH CHANGE2

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

Pitch
Initial Delay
Feedback Level
Dry / Wet Balance
Fine1
Fine2
Pan1
Output Level1
Pan2
Output Level2

-24~+24

0.1ms~248.9ms

-63~+63
D63>W ~ D=W ~ D<W63

-50~+50

-50~+50
L63~C~R63
0~127
L63~C~R63
0~127

Pitch
InitDly
FBLevel
Dry/Wet
Fine1
Fine2
Pan1
OutLvl1
Pan2
OutLvl2

1
2
5

10

3

4
11
12
13
14

9

10

Ø
Ø

Ø
Ø
Ø
Ø

[67] PITCH CHANGE1

In [68] PITCH CHANGE 2, the unit of Fine 1 and Fine 2
(numbers 5 and 6) is cent.

[69] AUTO WAH

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

LFO Frequency
LFO Depth
Cutoff Frequency Offset
Resonance
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Dry / Wet Balance

0.0Hz~39.70Hz
0~127
0~127
1~12.0
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB
D63>W ~ D=W ~ D<W63

Speed
Depth
Cutoff
Reso
L.Freq
L.Gain
H.Freq
H.Gain
Dry/Wet

1

2

3

4

6

7

8

9

10

9

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

[60] AMP SIMULATOR

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6

AMP Type
Drive
Edge
Output Level
LPF Cutoff Frequency
Dry / Wet Balance

off, stack, combo, tube
0~127
0~127
0~127

1.0kHz~20.0kHz
D63>W ~ D=W ~ D<W63

AmpType
Drive
Edge
OutLvl
LPF
Dry/Wet

2
1

11

4
3

10

Ø
Ø
Ø
Ø
Ø

24

[71] AUTO WAH + OVERDRIVE

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

LFO Frequency
LFO Depth
Cutoff Frequency Offset
Resonance
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Dist Low Gain
Dist Mid Gain
LPF Cutoff Frequency
Drive
Output Level
Dry / Wet Balance

0.0Hz~39.70Hz
0~127
0~127
1~12.0
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

-12dB~+12dB

-12dB~+12dB

1.0kHz~20.0kHz
0~127
0~127
D63>W ~ D=W ~ D<W63

Speed
Depth
Cutoff
Reso
L.Freq
L.Gain
H.Freq
H.Gain
Drive:EQ-Low
Drive:EQ-Mid
LPF
Drive
DrivOut
Dry/Wet

1
2
3
4
6
7
8

9
12
13
14
11
15
10

9
10
11
12
13
14

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

[70] AUTO WAH + DIST

[72] TOUCH WAH

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5

Sensitive
Cutoff Frequency Offset
Resonance
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Dry / Wet Balance

0~127
0~127
1~12.0
32Hz~12.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB
D63>W ~ D=W ~ D<W63

Sens
Cutoff
Reso
L.Freq
L.Gain
H.Freq
H.Gain
Dry/Wet

1
2
3
6
7
8
9

10

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

6
7
8

[74] TOUCH WAH + OVERDRIVE

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

Sensitive
Cutoff Frequency Offset
Resonance
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Dist Low Gain
Dist Mid Gain
LPF Cutoff Frequency
Drive
Output Level
Dry / Wet Balance

0~127
0~127
1~12.0
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

-12dB~+12dB

-12dB~+12dB

1.0kHz~20.0kHz
0~127
0~127
D63>W ~ D=W ~ D<W63

Sens
Cutoff
Reso
L.Freq
L.Gain
H.Freq
H.Gain
Drive:EQ-Low
Drive:EQ-Mid
LPF
Drive
DrivOut
Dry/Wet

1
2
3
6
7
8

9
12
13
14
11
15
10

9
10
11
12
13

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

[73] TOUCH WAH + DIST

[76] WAH + OVERDRIVE + DELAY

No. Parameter Value L CD

MIDI Parameter Number

Controller

1

2

3

4

5

6

7

8

Wah sensitive
Wah Cutoff Frequency
Wah Resonance
Wah release
Dist. Drive
Dist. EQ Low Gain
Dist. EQ Mid Gain
Dist Output Level
Delay Time
Delay Feedback Leve
Delay mix
Dry / Wet Balance

0~127
0~127
1~12.0
10ms~680ms
0~127

-12dB~+12dB

-12dB~+12dB
0 ~127

0.1ms~1486.0ms

-63~+63
0~127
D63>W ~ D=W ~ D<W63

WahSens
Cutoff
Reso
Release
Drive
EQ-Low
EQ-Mid
DrivOut
Delay
FBLevel
DlyMix
Dry/Wet

11
12
13
14

4
6
7
5
1
2
3

10

9
10
11
12

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

Ø
Ø
Ø

[75] WAH + DIST + DELAY

[77] LO-FI

No. Parameter Value L CD

MIDI Parameter Number

Controller

1

2

3

4

5

6

7

8

Sampling Freq. Control
Word Length
Output Gain
Filter Type
Pre-LPF Cutoff Frequency
Pre-LPF Resonance
Bit Assign
Emphasis
Input Mode
Dry / Wet Balance

44.1KHz~344Hz
1~127

-6dB~+36dB

thru, PowerBass, Radio, Telephone, Clean, Low

63Hz~20.0kHz
1~12.0
0~6
off/on
mono/stereo
D63>W ~ D=W ~ D<W63

SmplFrq
WordLen
OutGain
FltType
Cutoff
Reso
BitAsgn
Emphasi
Input
Dry/Wet

1
2
3
5
4
6
7

8
15
10

Ø
Ø
Ø

Ø
Ø

Ø

10

9

[78] LOW RESOLUTION

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7

Mod Depth
Mod Delay Offset
Mod Mix Balance
Resolution
Mod Feedback
Phase Inverse R
Dry/Wet Balance

0~127
1~127
0~127
1,1/2~1/128

-63~+63
off, wet, wet+dry
D63>W ~ D=W ~ D<W63

ModDpth
ModDly
ModMix
Resoltn
ModFB
PhasInv
Dry/Wet

1
2
5
4
3
6
7

Ø

Ø

Ø

Ø

[79] NOISY

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

Mod Depth
Mod Speed
Mod Feedback
Mod Mix Balance
Drive
AM Speed
AM Depth
LPF Frequency
LPF Resonance
EQ Frequency
EQ Gain
EQ Width
Dry/Wet Balance

0~10
0~127

-63~+63
1~127
0~127

0.00Hz~39.7Hz
0~127

1.0kHz~20.0kHz

1.0~12.0
100Hz~10.0kHz

-12~+12dB

1.0~12.0
D63>W ~ D=W ~ D<W63

ModDpth
ModSpd
ModFB
ModMix
Drive
AMSpeed
AMDepth
Cutoff
Reso
EQFreq
EQGain
EQWidth
Dry/Wet

2
3
4
7
1
5
6
8
9

10
11
12
13

9
10
11
12
13

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

[80] ATTACK LOFI

No. Parameter Value L CD

MIDI Parameter Number

Controller

1

2

3

4

5

6

7

8

Sensitive
Resolution
Peak Frequency
LPF Frequency
Flanger Speed
Flanger LFO Wave
Flanger Depth
Fln Depth Ofst R
Flanger Delay
Fln Delay Ofst R
Flanger Feedback
Flanger FB Ofst R
Flanger FB HiDamp
FB HiDamp Ofst R
Fln Mix Balance
Dry/Wet Balance

0~127
1,1/2~1/32
100Hz~10.0kHz

1.0kHz~20.0kHz

0.00Hz~39.7Hz
tri, sine, saw up, saw down
0~127

-63~+63

0.1~650.0ms
0~884

-63~+63

-63~+63

0.1~1.0

-0.9~+0.9
1~127
D63>W ~ D=W ~ D<W63

Sens
Resoltn
PeakFrq
LPF
FlgSpd
FlgWave
FlgDpt
FlgDptR
FlgDly
FlgDlyR
Flg FB
FlgFB R
FBHiDmp
FBHiDmR
FlgMix
Dry/Wet

1
2
3
4
5
6
7
8

9
10
11
12
13
14
15
16

9
10
11
12
13
14
15
16

Ø

Ø
Ø
Ø

Ø
Ø

Ø
Ø
Ø
Ø
Ø
Ø

[81] DIGITAL TURNTABLE

No. Parameter Value L CD

MIDI Parameter Number

Controller

1

2

3

4

5

6

Click Density
Click Level
Noise Tone
Dry Send to Noise
Noise Mod Speed
Noise Mod Depth
Noise LPF Freq
Noise LPF Q
Noise Level
Dry LPF Frequency
Dry Level

0~5
0~127
0~6
0~127

0.00Hz~39.7Hz
0~127

1.0kHz~20.0kHz

1.0~12.0
0~127

1.0kHz~20.0kHz
0~127

Density
Click
NoisTon
DryNois
ModSpd
ModDpth
NoisLPF
NoiseQ
NoisLvl
DryLPF
DryLvl

1
2
3
6
4
5
7
8

9
10
11

Ø

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

7
8

9
10
11

[82] DIGITAL SCRATCH

No. Parameter Value LCD

MIDI Parameter Number

Controller

1

2

3

4

5

6

7

8

Input Level
Initial Delay
Scratch Speed
Scratch Depth
HPF Frequency
Auto Pan Speed
Auto Pan Depth
EQ Frequency
EQ Gain
EQ Width
Dry/Wet Balance

0~127

0.1~460.0ms
1~127
0~127
20Hz~8.0kHz

0.00Hz~39.7Hz
0~127
100Hz~10.0kHz

-12~+12dB

1.0~12.0
D63>W ~ D=W ~ D<W63

Input
Delay
ScrSpd
ScrDpth
HPF
PanSpd
PanDpth
EQFreq
EQGain
EQWidth
Dry/Wet

1
2
3
4

10

5
6
7
8
9

11

9

10

Ø

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø

11

25

[83] AUTO SYNTH

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

Mod Speed
Mod Wave Type
Mod Depth
Mod Depth Ofst R
HPF Frequency
LPF Frequency
Dry Mix Level
Delay Level
Delay Time
Delay Time Ofst R
Feedback Level
FB Level Ofst R
AM Speed
AM Wave
AM Depth
AM Inverse R

0~127
TypeA, TypeB, TypeC, TypeD
0~127

-63~+63
20Hz~8.0kHz

1.0kHz~20.0kHz
0~127
0~127

0.1~370.0ms
0~884

-63~+63

-63~+63

0.00Hz~39.7Hz
tri, sine, saw up, saw down
0~127
normal, inverse

ModSpd
ModWave
ModDpth
ModDpth-R Ofst
HPF
LPF
DryMix
DlyLvl
Delay
Delay-R Ofst
FBLevel
FBLevel-R Ofst
AMSpeed
AM Wave
AMDepth
AM InvR

1
2
3
4
6
5
7

12

8

9
10
11
13
14
15
16

9

10

Ø

Ø
Ø
Ø
Ø
Ø
Ø

Ø
Ø
Ø

Ø

11
12
13
14
15
16

[84] TECH MODULATION

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

Mod Speed
Mod Depth
Mod Gain
Mod Mix Balance
Pre Mod HPF Freq
Mod LPF Frequency
Mod LPF Resonance
Delay Time
Delay Time Ofst R
Feedback Level
FB Level Ofst R
Feedback Hi Damp
FB Hi Damp Ofst R
Dry/Wet Balance

0~127
0~127

-12~+12dB
D63>W ~ D=W ~ D<W63
20Hz~8.0kHz

1.0kHz~20.0kHz

1.0~12.0

0.1~740.0ms
0~884

-63~+63

-63~+63

0.1~1.0

-0.9~+0.9
D63>W ~ D=W ~ D<W63

Speed
Depth
Gain
ModMix
HPF
LPF:Cutoff
LPF:Reso
Delay
Delay-R Ofst
FBLevel
FBLevel-R Ofst
FBHiDmp
FBHiDmp-R Ofst
Dry/Wet

1

2

4

7

3

5

6

8

9
10
11
12
13
14

9

10

Ø
Ø
Ø
Ø
Ø
Ø
Ø

Ø
Ø
Ø
Ø
Ø

1
11
12
13
14

[85] JUMP

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7
8

Depth
Speed
Direction
Type
Jump Wave Type
Resolution
HPF Frequency
LPF Frequency
Dry/Wet Balance

0~127
0~127
L<>R,L>>R
TypeA,TypeB,TypeC
TypeA, TypeB, TypeC, TypeD
1,1/2~1/256
20Hz~8.0kHz

1.0kHz~20.0kHz
D63>W ~ D=W ~ D<W63

Depth
Speed
Directn
Type
JumpWave
Resolution
HPF
LPF
Dry/Wet

1

2

3

4

5

6

8

7

9

9

Ø
Ø

Ø
Ø
Ø

[86] 2BAND EQ

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4

EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

L.Freq
L.Gain
H.Freq
H.Gain

1

2

3

4

Ø
Ø
Ø
Ø

1

[87] 3BAND EQ

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4

EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Input Mode

50Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB
100Hz~10.0kHz

-12dB~+12dB

0.1~12.0
mono/stereo

L.Freq
L.Gain
H.Freq
H.Gain
M.Freq
M.Gain
M.Width
Input

6

1

7

5

2

3

4
15

Ø
Ø
Ø
Ø
Ø
Ø
Ø

5
6
7
8

[88] HARMONIC ENHANCER

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3

HPF Cutoff Frequency
Drive
Mix Level

500Hz~16.0kHz
0~127
0~127

HPF
Drive
MixLvl

1

2

3

Ø
Ø
Ø

[89] VOICE CANCELAR

No. Parameter Value LCD

MIDI Parameter Number

Controller

12Low Adjust

High Adjust

0~26
0~26

LowAdj
HighAdj

11

12

Ø
Ø

[90] AMBIENCE

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5
6
7

Delay Time
Wet Output Phase
Dry / Wet Balance
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain

0.0ms~50.0ms
normal/inverse
D63>W ~ D=W~ D<W63
32Hz~2.0kHz

-12dB~+12dB
500Hz~16.0kHz

-12dB~+12dB

DlyTime
WetPhase
Dry/Wet
L.Freq
L.Gain
H.Freq
H.Gain

1
2

10

6
7
8
9

Ø
Ø
Ø
Ø
Ø
Ø

[91] TALKING MODULATOR

No. Parameter Value LCD

MIDI Parameter Number

Controller

1
2
3
4

Vowel
Move Speed
Drive
Output Level

a/i/u/e/o
1~ 62
0~127
0~127

Vowel
Speed
Drive
OutLvl

1
2
3
4

Ø
Ø
Ø
Ø

[92] BEAT CHANGE

No. Parameter Value L CD

MIDI Parameter Number

Controller

1
2
3
4
5

Beat Change
Beat Range
Pitch Change
Pitch Range
EQ Frequency
EQ Gain
EQ Width
Accuracy T ype
Dry/Wet Balance

-63~+63
0~12

-63~+63
0~12
32Hz~2.0kHz

-12dB~+12dB

1.0~12.0
sound4~normal~rythm4
D63>W ~ D=W ~ D<W63

BeatChg
BeatRng
PchChg
PchRng
EQFreq
EQGain
EQWidth
AccType
Dry/Wet

1
2
3
4
6
7
8
5

10

Ø
Ø
Ø
Ø
Ø
Ø
Ø

Ø

9

6
7
8

26

About MIDI

MIDI is an acronym that stands for Musical Instrument Digital Interface,
which allows electronic musical instruments to “communicate” with each
other, by sending and receiving compatible Note, Control Change, Program
Change and various other types of MIDI data, or messages.
The CS6X/CS6R can control a MIDI device by transmitting note related data
and various types of controller data. The CS6x/CS6R can be controlled by
the incoming MIDI messages which automatically select MIDI channels,
voices and effects, change parameter values, and of course play the voices
specified for the various Parts in a Performance.

MIDI Messages Transmitted/Received by the
CS6x/CS6R

The MIDI messages can be divided into two groups: the Channel Messages and System
Messages. Below is a brief explanation of the various types of MIDI messages which the
CS6x/CS6R can receive/transmit.

CHANNEL MESSAGES

The Channel Messages are the data related to the performance on the keyboard for the
specific channel.

•Note On/Note Off (Key On/Key Off)

Messages which are generated when the keyboard is played. Each message includes a
specific note number which corresponds to the key which is pressed, plus a velocity
value based on how hard the key is struck.

•Control Change

Control Change messages let you select a voice bank (Bank Select), control volume,
panning, modulation, portamento time, brightness and various other controller
parameters, through specific Control Change numbers which correspond to each of the
various parameters.

•Program Change

Messages which voice to select for each Part.
With a combination of Bank Select, you can select not only basic voice numbers, but
also variation voice bank numbers.

•Channel Aftertouch

Messages which let you control the sounds by the pressure you apply to the keys after
the initial striking of the keys, over the entire channel.

•Polyphonic Key Pressure

Messages which let you control the sounds by the pressure you apply to the keys after
the initial striking of the keys, for each individual key. The internal sequencer
(CS6x/CS6R) can send this message.

•Pitch Bend

Pitch Bend messages are continuous controller messages that allow the pitch of
designated notes to be raised or lowered by a specified amount over a specified
duration.

SYSTEM MESSAGES

The System Messages are the data related to the overall system of the device.

•Exclusive Messages

Exclusive messages control various functions of the CS6x/CS6R, including bulk dump,
master volume and master tuning, effect type and various other parameters.

•Realtime Messages

Messages which control the sequencer including Start, Stop, Continue, MIDI clock and
Active Sensing messages.

•Common Messages

Messages which also control the sequencer including Song Select and Song Position
Pointer messages.

MIDI Data Format

Many MIDI messages listed in the MIDI Data Format section are expressed in hexadecimal or
binary numbers. Hexadecimal numbers may include the letter “H”as a suffix.The letter “n”
indicates a certain whole number.
The chart below lists the corresponding decimal number for each hexadecimal/binary number.

Additional Notes

• For example, 144 - 159(Decimal)/9nH/1001 0000 - 1001 1111(Binary) indicate the note-on
messages for the channels 1 through 16 respectively. 176 - 191/BnH/1011 0000 - 1011 1111
indicate the control change messages for the channels 1 through 16 respectively. 192 ­207/CnH/1100 0000 - 1100 1111 indicate the program change messages for the channels 1
through 16 respectively. 240/F0H/1111 0000 is positioned at the beginning of data to
indicate a system exclusive message.247/F7H/1111 0111 is positioned at the end of the
system exclusive message.

• aaH(Hexadecimal)/0aaaaaaa(Binary) indicates the data addresses. The data address
consists of High, Mid and Low.

• bbH/0bbbbbbb indicates byte counts.

• ccH/0ccccccc indicates tcheck sums.

• ddH/0ddddddd indicates data/value.

Decimal Hexadecimal Binary Decimal Hexadecimal Binary

0
1
2
3
4
5
6
7
8

9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63

00
01
02
03
04
05
06
07
08
09
0A
0B
0C
0D
0E
0F
10
11
12
13
14
15
16
17
18
19
1A
1B
1C
1D
1E
1F
20
21
22
23
24
25
26
27
28
29
2A
2B
2C
2D
2E
2F
30
31
32
33
34
35
36
37
38
39
3A
3B
3C
3D
3E
3F

0000 0000
0000 0001
0000 0010
0000 0011
0000 0100
0000 0101
0000 0110
0000 0111
0000 1000
0000 1001
0000 1010
0000 1011
0000 1100
0000 1101
0000 1110
0000 1111
0001 0000
0001 0001
0001 0010
0001 0011
0001 0100
0001 0101
0001 0110
0001 0111
0001 1000
0001 1001
0001 1010
0001 1011
0001 1100
0001 1101
0001 1110
0001 1111
0010 0000
0010 0001
0010 0010
0010 0011
0010 0100
0010 0101
0010 0110
0010 0111
0010 1000
0010 1001
0010 1010
0010 1011
0010 1100
0010 1101
0010 1110
0010 1111
0011 0000
0011 0001
0011 0010
0011 0011
0011 0100
0011 0101
0011 0110
0011 0111
0011 1000
0011 1001
0011 1010
0011 1011
0011 1100
0011 1101
0011 1110
0011 1111

64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98

99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127

40
41
42
43
44
45
46
47
48
49
4A
4B
4C
4D
4E
4F
50
51
52
53
54
55
56
57
58
59
5A
5B
5C
5D
5E
5F
60
61
62
63
64
65
66
67
68
69
6A
6B
6C
6D
6E
6F
70
71
72
73
74
75
76
77
78
79
7A
7B
7C
7D
7E
7F

0100 0000
0100 0001
0100 0010
0100 0011
0100 0100
0100 0101
0100 0110
0100 0111
0100 1000
0100 1001
0100 1010
0100 1011
0100 1100
0100 1101
0100 1110
0100 1111
0101 0000
0101 0001
0101 0010
0101 0011
0101 0100
0101 0101
0101 0110
0101 0111
0101 1000
0101 1001
0101 1010
0101 1011
0101 1100
0101 1101
0101 1110
0101 1111
0110 0000
0110 0001
0110 0010
0110 0011
0110 0100
0110 0101
0110 0110
0110 0111
0110 1000
0110 1001
0110 1010
0110 1011
0110 1100
0110 1101
0110 1110
0110 1111
0111 0000
0111 0001
0111 0010
0111 0011
0111 0100
0111 0101
0111 0110
0111 0111
0111 1000
0111 1001
0111 1010
0111 1011
0111 1100
0111 1101
0111 1110
0111 1111

27

SYNTHESIZER/SEQUENCER PART

1) TRANSMIT FLOW

MIDI <-[SW1]-+--- NOTE ON/OFF 9nH

OUT | |

| +--- CONTROL CHANGE
| | MODULATION BnH,01H
| | PORTAMENTO TIME BnH,05H (CS6x only)
| | PAN BnH,0AH (CS6x only)
| | SUSTAIN SWITCH BnH,40H
| | PORTAMENTO SWITCH BnH,41H (CS6x only)
| | FILTER RESONANCE BnH,47H (CS6x only)
| | EG RELEASE TIME BnH,48H (CS6x only)
| | EG ATTACK TIME BnH,49H (CS6x only)
| | FILTER CUTOFF FREQ BnH,4AH (CS6x only)
| | EG DECAY TIME BnH,4BH (CS6x only)
| | REVERB SEND BnH,5BH (CS6x only)
| | CHORUS SEND BnH,5DH (CS6x only)
| | ASSIGNABLE CONTROLLER BnH,(00H .. 5FH)
| | FOOT VOLUME BnH,(07H or 0BH)
||
| +-[SW8]--BANK SEL MSB BnH,00H
| | BANK SEL LSB BnH,20H
||
| |-[SW2]--EG SUSTAIN LEVEL BnH,1FH (CS6x only)
||
| +--- PROGRAM CHANGE CnH
||
| +--- CHANNEL AFTER TOUCH DnH
||
| +--- PITCH BEND CHANGE EnH
|
|-[SW3,4]--SYSTEM REALTIME MESSAGE
| TIMING CLOCK F8H
|
|-[SW4]---- SYSTEM REALTIME MESSAGE
| START FAH
| CONTINUE FBH
| STOP FCH
|
|
+[SW5]-+---

SYSTEM EXCLUSIVE MESSAGE
||
| |-[SW6]-

SAMPLE DUMP STANDARD
| | DUMP REQUEST F0H 7EH nnH 03H ssH ssH F7H
| | ACK F0H 7EH nnH 7FH ppH F7H
| | NAK F0H 7EH nnH 7EH ppH F7H
| | CANCEL F0H 7EH nnH 7DH ppH F7H
| | WAIT F0H 7EH nnH 7CH ppH F7H
||
| |-[SW7]-<BULK DUMP>

F0H 43H 0nH 64H bhH blH ahH amH alH ddH....ddH ccH F7H

||
| |-[SW7]-

<PARAMETER CHANGE>

F0H 43H 1nH 64H ahH amH alH ddH.....ddH F7H

|
|----------

SYSTEM EXCLUSIVE MESSAGE

| IDENTITY REPLY

F0H 7EH 7FH 06H 02H 43H 00H 41H 2DH 02H 00H 00H 00H 01H F7H
|
|---------- ACTIVE SENSING FEH

[SW1] MIDI Transmit Channel

Master Keyboard Mode = on: complies with Zone Transmit Channel.
Master Keyboard Mode = off: complies with Keyboard Transmit Channel.
The data played back using Sequencer Part will be output through the channels set for
the sequence data, ignoring [SW1] settings.
CS6R transmits BC and A-C/1-2 of ASSIGNABLE CONTROLLER, and the data from the
Sequencer Part. [SW2] MIDI Control Mode

[SW3] MIDI Sync
[SW4] MIDI Control
[SW5] MIDI Device Number

When set to all, data will be output through the channel 1.

[SW6] PHRASE CLIP MODE JOB only. Not available on S80.
[SW7] In the VOICE MODE, VOICE related data only. In the PERFORMANCE MODE, PERFORMANCE

related data only.
SYSTEM data will be transmitted/received in all modes.

[SW8] SYSTEM Bank Select Switch

2) RECEIVE FLOW

MIDI >-[SW11]+--- NOTE OFF 8nH

||
| +--- NOTE ON/OFF 9nH
||
| +--- CONTROL CHANGE
| | MODULATION BnH,01H
| | PORTAMENTO TIME BnH,05H
| | DATA ENTRY MSB BnH,06
| | DATA ENTRY LSB BnH,26H
| | MAIN VOLUME BnH,07H
| | PAN BnH,0AH
| | EXPRESSION BnH,0BH
| | SUSTAIN SWITCH BnH,40H
| | PORTAMENTO SWITCH BnH,41H
| | SOSTENUTO BnH,42H
| | HARMONIC CONTENT BnH,47H
| | EG RELEASE TIME BnH,48H
| | EG ATTACK TIME BnH,49H
| | BRIGHTNESS BnH,4AH
| | EG DECAY TIME BnH,4BH
| | EFFECT1 DEPTH BnH,5BH
| | EFFECT3 DEPTH BnH,5DH
| | DATA ENTRY INC BnH,60H
| | DATA ENTRY DEC BnH,61H
| | ASSIGNABLE CONTROLLER BnH,(00H .. 5FH)
| | RPN
| | PITCH BEND SENS BnH,64H,00H,65H,00H,06H,mmH
| | FINE TUNING BnH,64H,01H,65H,00H,06H,mmH,26H,llH *1
| | COARSE TUNING BnH,64H,02H,65H,00H,06H,mmH *1
| | RPN RESET BnH,64H,7FH,65H,7FH
| | ALL SOUND OFF BnH,78H
| | RESET ALL CONTROLLERS BnH,79H
| | ALL NOTE OFF BnH,7BH
| | OMNI MODE OFF BnH,7CH
| | OMNI MODE ON BnH,7DH
| | MONO MODE BnH,7EH
| | POLY MODE BnH,7FH
||
| +-[SW2]--EG SUSTAIN LEVEL BnH,1FH
||
| +-[SW8]--BANK SEL MSB BnH,00H
| | BANK SEL LSB BnH,20H
||
| +-[SW9]--PROGRAM CHANGE CnH
||
| +--------

CHANNEL AFTER TOUCH

DnH
||
| +--------PITCH BEND CHANGE EnH
|
|
+------+ SYSTEM EXCLUSIVE MESSAGE
| | IDENTITY REQUEST F0H 7EH 0nH 06H 01H F7H
| | REMOTE SWITCH F0H 43H 10H 64H 0AH 00H alH ddH F7H
||
| +-[SW12]- GM MODE ON F0H 7EH 7FH 09H 01H F7H
|
+[SW5]-

+ SYSTEM EXCLUSIVE MESSAGE
| | MIDI MASTER VOLUME F0H 7FH 7FH 04H 01H llH mmH F7H
||
| +-[SW6]--SAMPLE DUMP STANDARD

| | DUMP HEADER F0H 7EH nnH 01H ssH ssH ddH....ddH F7H

| | DATA PACKET F0H 7EH nnH 02H kkH ddH....ddH ccH F7H

| | CANCEL F0H 7EH nnH 7DH ppH F7H
||
| +-[SW10]-<BULK DUMP>

F0H 43H 0nH 64H bhH blH ahH amH alH ddH....ddH ccH F7H

||

| +-[SW7]--<PARAMETER CHANGE> F0H 43H 1nH 64H ahH amH alH ddH.....ddH F7H

||
| +-[SW7]--

<BULK DUMP REQUEST>

F0H 43H 2nH 64H ahH amH alH ddH.....ddH F7H

||
| +-[SW7]--

<PARAMETER REQUEST>

F0H 43H 3nH 64H ahH amH alH F7H
||
| +-[SW12]-XG SYSTEM ON F0H 43H 1nH 4CH 00H 00H 7EH 00H F7H
|
+[SW3]--------- SYSTEM REALTIME MESSAGE
| TIMING CLOCK F8H
|
+[SW4]--------- SYSTEM REALTIME MESSAGE
| START FAH
| CONTINUE FBH
| STOP FCH
|
|
+-------------- ACTIVE SENSING FEH

[SW2] MIDI Control Mode
[SW3] MIDI Sync
[SW4] MIDI Control
[SW5] MIDI Device Number

When set to the number other than off, MIDI MASTER VOLUME will be received.

[SW6] PHRASE CLIP MODE JOB only. Not available on S80.
[SW7] In the VOICE MODE, VOICE related data only. In the PERFORMANCE MODE, PERFORMANCE

related data only.
SYSTEM data will be transmitted/received in all modes.

[SW8] SYSTEM Bank Select Switch
[SW9] SYSTEM Program Change Switch (Received only in the Play Mode when Voice Mode or

Phrase Clip Mode is selected.)

[SW10] SYSTEM Bulk Protect and the conditions mentioned in SW7 above.
[SW11] MIDI Receive Channel and Receive Filter.

In Performance Mode, complies with Part Receive Channel and Part Receive Switch.
In the modes other than Performance Mode, complies with Basic Receive Channel.

[SW12] SYSTEM Receive GM/XG On

*1 Performance Mode only.

28

3) TRANSMIT/RECEIVE DATA

(3-1) CHANNEL VOICE MESSAGES

CS6R transmits BC and A-C/1-2 of ASSIGNABLE CONTROLLER, and the data from the
Sequencer Part.

(3-1-1) NOTE OFF

STATUS 1000nnnn(8nH) n = 0 ~ 15 CHANNEL NUMBER
NOTE NUMBER 0kkkkkkk k = 0 (C-2) ~ 127 (G8)
VELOCITY 0vvvvvvv ignores "v"
Receive only.

(3-1-2) NOTE ON/OFF

STATUS 1001nnnn(9nH) n = 0 ~ 15 CHANNEL NUMBER
NOTE NUMBER 0kkkkkkk k = 0 (C-2) ~ 127 (G8)
VELOCITY 0vvvvvvv(v≠0) NOTE ON

0vvvvvvv(v=0) NOTE OFF

(3-1-3) CONTROL CHANGE

STATUS 1011nnnn(BnH) n = 0 ~ 15 CHANNEL NUMBER
CONTROL NUMBER 0ccccccc
CONTROL VALUE 0vvvvvvv

* TRANSMITTED CONTROL NUMBER
c = 0 BANK SEL MSB ; v = 0,63,127 *3
c = 32 BANK SEL LSB ; v = 0,1,8,9,24,25,32,40,41,64,65 *3
c = 1 MODULATION ; v = 0 - 127
c = 5 PORTAMENTO TIME ; v = 0 - 127 *4
c = 7 MAIN VOLUME ; v = 0 - 127
c = 10 PAN ; v = 0 - 127 *4
c = 11 EXPRESSION ; v = 0 - 127
c = 31 EG SUSTAIN LEVEL ; v = 0:-64 - 64:0 - 127:+63 *4,*5
c = 64 SUSTAIN SWITCH ; v = 0, 127
c = 65 PORTAMENTO SWITCH ; v = 0-63:OFF , 64-127:ON *4
c = 71 FILTER RESONANCE ; v = 0:-64 - 64:0 - 127:+63 *4
c = 72 EG RELEASE TIME ; v = 0:-64 - 64:0 - 127:+63 *4
c = 73 EG ATTACK TIME ; v = 0:-64 - 64:0 - 127:+63 *4
c = 74 FILTER CUTOFF FREQ ; v = 0:-64 - 64:0 - 127:+63 *4
c = 75 EG DECAY TIME ; v = 0:-64 - 64:0 - 127:+63 *4
c = 91 REVERB SEND ; v = 0 - 127 *4
c = 93 CHORUS SEND ; v = 0 - 127 *4
c = 0..95 ASSIGNABLE CONTROLLER ; v = 0 - 127 *6
The Sequencer Part will play back all the recorded control change messages.

* RECEIVED CONTROL NUMBER
c = 0 BANK SEL MSB ; v = 0 - 127 *3
c = 32 BANK SEL LSB ; v = 0 - 127 *3
c = 1 MODULATION ; v = 0 - 127
c = 5 PORTAMENTO TIME ; v = 0 - 127 *2
c = 6 DATA ENTRY MSB ; v = 0 - 127 *1
c = 38 DATA ENTRY LSB ; v = 0 - 127 *1
c = 7 MAIN VOLUME ; v = 0 - 127
c = 10 PAN ; v = 0 - 127
c = 11 EXPRESSION ; v = 0 - 127
c = 31 EG SUSTAIN LEVEL ; v = 0:-64 - 64:0 - 127:+63 *2,*5
c = 64 SUSTAIN SWITCH ; v = 0-63:OFF , 64-127:ON *2
c = 65 PORTAMENTO SWITCH ; v = 0-63:OFF , 64-127:ON *2
c = 66 SOSTENUTO ; v = 0-63:OFF , 64-127:ON *2
c = 71 HARMONIC CONTENT ; v = 0:-64 - 64:0 - 127:+63
c = 72 EG RELEASE TIME ; v = 0:-64 - 64:0 - 127:+63
c = 73 EG ATTACK TIME ; v = 0:-64 - 64:0 - 127:+63
c = 74 BRIGHTNESS ; v = 0:-64 - 64:0 - 127:+63
c = 75 EG DECAY TIME ; v = 0:-64 - 64:0 - 127:+63 *2
c = 91 EFFECT1 DEPTH ; v = 0 - 127
c = 93 EFFECT3 DEPTH ; v = 0 - 127
c = 96 DATA ENTRY INC ; v = 127 *1
c = 97 DATA ENTRY DEC ; v = 127 *1
c = 0..95 ASSIGNABLE CONTROLLER ; v = 0 - 127 *6
c = 0..95 ARPEGGIO SW ; v = 0-63:OFF , 64-127:ON *6
c = 0..95 ARPEGGIO HOLD ; v = 0-63:OFF , 64-127:ON *6

*1 Used only when a value is set using RPN.
*2 Invalid with Drum Voices.
*3 Relation between BANK CHANGE and PROGRAM is as follows:

CATEGORY |MSB |LSB |PROGRAM No

Displayed on LCD

----------------------------------+--------+--------+--------------------------­Normal Voice Internal |0 |0 |0..127 (1..128)
Drum Voice Internal |127 |0 |0..1 (1..2)
Normal Voice Preset 1 |63 |0 |0..127 (1..128)

Preset 2 |63 |1 |0..127 (1..128)
Internal |63 |8 |0..127 (1..128)
External |63 |9 |0..127 (1..128)

Plug-in Voice Plug-in 1 |63 |24 |0..63 (1..64)

Plug-in 2 |63 |25 |0..63 (1..64)

Drum Voice Preset |63 |32 |0..7 (1..8)

Internal |63 |40 |0..1 (1..2)
External |63 |41 |0..1 (1..2)

Performance Internal |63 |64 |0..127 (1..128)

External |63 |65 |0..63 (1..64)

Phrase Clip Internal |63 |104 |0..3 (1..4)

*4 CS6x only.
*5 Transmitted/received only when MODE2 is selected in CONTROL CHANGE MODE.
*6 The default CONTROL NUMBERs of ASSIGNABLE CONTROLLER are as follows:

BREATH CONTROLLER 2
FOOT CONTROLLER 4 (Transmit: CS6x and S80 only)
SCENE CONTROL 14 (Transmit/Receive: CS6x only)
KNOB 1 16
KNOB 2 17
KNOB A 18
KNOB B 19
KNOB C 20
RIBBON CONTROLLER 22 (Transmit: CS6x only)
CONTROL SLIDER 7 (Transmit/Receive: S80 only)
FOOT SWITCH 88 (Transmit: CS6x, S80 only)
ARPEGGIO HOLD 89 (Transmit: CS6x only)
ARPEGGIO SWITCH 90 (Transmit: CS6x only)

PORTAMENTO TIME sets the time it takes for the pitch to reach the next note played
when PORTAMENTO SWITCH is set to on.
PAN position relatively changes according to the preset value for each voice.
EFFECT1 DEPTH controls reverb send level.
EFFECT3 DEPTH controls chorus send level.
HARMONIC CONTENT adjusts the resonance preset for each voice.
Setting a value adds to or subtracts from the center value, 64, since it is an offset
parameter.
The larger the value more resonant sound will be produced. The effective range may be
narrower than the range you can designate depending on the selected voice.
The parameters, EG ATTACK TIME, EG DECAY TIME, EG SUSTAIN LEVEL, EG RELEASE TIME
adjust the envelopes preset for each voice.
Setting these values add to or subtract from the center value, 64, since these are
offset parameters.
BRIGHTNESS adjusts the cutoff frequency preset for each voice.
Setting a value adds to or subtracts from the center value, 64, since it is an offset
parameter.
The smaller the value the cutoff frequency will be lowered. The effective range may be
narrower than the range you can designate depending on the selected voice.
Bank Select will be actually executed when the Program Change message is received.
Bank Select and Program Change numbers that are not supported by Yamaha will be
ignored.

(3-1-4) PROGRAM CHANGE

STATUS 1100nnnn(CnH) n = 0 ~ 15 CHANNEL NUMBER
PROGRAM NUMBER 0ppppppp p = 0 ~ 127

(3-1-5) CHANNEL AFTER TOUCH

STATUS 1101nnnn(DnH) n = 0 ~ 15 CHANNEL NUMBER
VALUE 0vvvvvvv v = 0 ~ 127 AFTER TOUCH VALUE

(3-1-6) PITCH BEND CHANGE

STATUS 1110nnnn(EnH) n = 0 ~ 15 CHANNEL NUMBER
LSB 0vvvvvvv PITCH BEND CHANGE LSB
MSB 0vvvvvvv PITCH BEND CHANGE MSB
Transmitted with a resolution of 7 bits.

(3-2) CHANNEL MODE MESSAGES

STATUS 1011nnnn(BnH) n = 0 ~ 15 CHANNEL NUMBER
CONTROL NUMBER 0ccccccc c = CONTROL NUMBER
CONTROL VALUE 0vvvvvvv v = DATA VALUE

(3-2-1) ALL SOUNDS OFF (CONTROL NUMBER = 78H , DATA VALUE = 0)

All the sounds currently played including the channel messages such as note-on and
hold-on in a certain channel are muted when receiving this message.

(3-2-2)

RESET ALL CONTROLLERS

(CONTROL NUMBER = 79H , DATA VALUE = 0)

Resets the values set for the following controllers.
PITCH BEND CHANGE 0 (center)
CHANNEL AFTER TOUCH 0 (minimum)
MODULATION 0 (minimum)
EXPRESSION 127 (maximum)
BREATH CONTROLLER 127 (maximum)
FOOT CONTROLLER 127 (maximum)
RIBBON CONTROLLER 0 (center)
KNOB 1 0 (center)
KNOB 2 0 (center)
SUSTAIN SWITCH 0 (off)
SOSTENUTO SWITCH 0 (off)
RPN Not assigned; No change

Doesn’t reset the following data:
PROGRAM CHANGE, BANK SELECT MSB/LSB, VOLUME, PAN.
HARMONIC CONTENT, SUSTAIN LEVEL, RELEASE TIME, ATTACK TIME, DECAY TIME, BRIGHTNESS
EFFECT SEND LEVEL 1, EFFECT SEND LEVEL 3, PORTAMENTO SWITCH
PITCH BEND SENSITIVITY, FINE TUNING, COARSE TUNING
ASSIGNABLE CONTROLLER

(3-2-3) ALL NOTES OFF (CONTROL NUMBER = 7BH , DATA VALUE = 0)

All the notes currently set to on in certain channel(s) are muted when receiving
this message. However, if Sustain or Sostenuto is on, notes will continue sounding
until these are turned off.

(3-2-4) OMNI MODE OFF (CONTROL NUMBER = 7CH , DATA VALUE = 0)

Performs the same function as when receiving ALL NOTES OFF.
Sets VOICE RECEIVE CHANNEL to "OMNI OFF," channel 1.

(3-2-5) OMNI MODE ON (CONTROL NUMBER = 7DH , DATA VALUE = 0)

Performs the same function as when receiving ALL NOTES OFF.
Sets VOICE RECEIVE CHANNEL to "OMNI ON."

(3-2-6) MONO (CONTROL NUMBER = 7EH , DATA VALUE = 0..16)

Performs the same function as when receiving ALL SOUNDS OFF. If the 3rd byte (mono)
is within 0 through 16, the channel will be Mode4(m = 1).
In VOICE MODE, the mode can be Mode2(m=1) according to VOICE RECEIVE CHANNEL.

(3-2-7) POLY (CONTROL NUMBER = 7FH , DATA VALUE = 0)

Performs the same function as when receiving ALL SOUNDS OFF. The channel will be
Mode3.
In VOICE MODE, the mode can be Mode1 according to VOICE RECEIVE CHANNEL.

(3-3) REGISTERED PARAMETER NUMBER

STATUS 1011nnnn(BnH) n = 0 ~ 15 CHANNEL NUMBER
LSB 01100100(64H)
RPN LSB 0ppppppp p = RPN LSB(Refer to the table as shown below)
MSB 01100101(65H)
RPN MSB 0qqqqqqq q = RPN MSB(Refer to the table as shown below)
DATA ENTRY MSB 00000110(06H)
DATA VALUE 0mmmmmmm m = Data Value
DATA ENTRY LSB 00100110(26H)
DATA VALUE 0lllllll l = Data Value

First, designate the parameter using RPN MSB/LSB numbers. Then, set its value with
data entry MSB/LSB.

RPN D.ENTRY
LSB MSB MSB LSB PARAMETER NAME DATA RANGE

00H 00H mmH --- PITCH BEND SENSITIVITY 00H - 18H (0 - 24 semitones)
01H 00H mmH llH MASTER FINE TUNE {mmH,llH}={00H,00H}-{40H,00H}-{7FH,7FH}

(-8192*100/8192) - 0 - (+8192*100/8192)
02H 00H mmH --- MASTER COARSE TUNE 28H - 40H - 58H (-24 - 0 - +24 semitones)
7FH 7FH --- --- RPN RESET RPN numbers will be left not designated.

The internal values are not affected.

(3-4) NON-REGISTERED PARAMETER NUMBER

There are no applicable parameters.

(3-5) SYSTEM REAL TIME MESSAGES

(3-5-1) ACTIVE SENSING

STATUS 11111110(FEH)

Transmitted at every 200 msec.
Once this code is received, the instrument starts sensing. When no status nor data
is received for over approximately 350 ms, MIDI receiving buffer will be cleared,
and the sounds currently played and the sustain switch are forcibly turned off. In
this case, each control data will be reset to a certain value.

(3-6) SYSTEM EXCLUSIVE MESSAGE

(3-6-1)UNIVERSAL NON REALTIME MESSAGE

(3-6-1-1)GENERAL MIDI MODE ON

F0H 7EH 7FH 09H 01H F7H

Received only when SYSTEM Receive GM/XG on is set to on in PERFORMANCE MODE. The
Part values will be reset according to the SYSTEM Internal Part settings.

29

(3-6-1-2)IDENTITY REQUEST(Receive only)

F0H 7EH 0nH 06H 01H F7H ("n" = Device No.However, this instrument receives under
"omni.")

(3-6-1-3)IDENTITY REPLY (Transmit only)

F0H 7EH 7FH 06H 02H 43H 00H 41H ddH ddH 00H 00H 00H 01H F7H

dd;Device Number Code

CS6x: 5C 03
CS6R: 5D 03
S80: 5E 03

(3-6-2)UNIVERSAL REALTIME MESSAGE

(3-6-2-1) MIDI MASTER VOLUME

F0H 7FH 7FH 04H 01H llH mmH F7H

Sets the MASTER VOLUME value.
The value "mm" is used to set the master volume (the value "ll" should be ignored).

(3-6-3)PARAMETER CHANGE

(3-6-3-1) XG SYSTEM ON

11110000 F0 Exclusive status
1000011 43 YAMAHA ID
0001nnnn 1n device Number
1001100 4C Model ID
0aaaaaaa 0 Address High
0aaaaaaa 0 Address Mid
0aaaaaaa 7E Address Low
0 0 Data
11110111 F7 End of Exclusive

Received only when SYSTEM Receive GM/XG on is set to on in PERFORMANCE MODE. The
Part values will be reset according to the SYSTEM Internal Part settings.
Be aware that executing this message takes ca. 170ms and that, therefore, a certain
interval before executing the following message is needed.

(3-6-3-2) NATIVE PARAMETER CHANGE, REMOTE SWITCH

11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0001nnnn 1n device Number
01100100 64 Model ID
0aaaaaaa aaaaaaa Address High
0aaaaaaa aaaaaaa Address Mid
0aaaaaaa aaaaaaa Address Low
0ddddddd ddddddd Data
||
11110111 F7 End of Exclusive

For parameters with data size of 2 or more, the appropriate number of data bytes
will be transmitted.
See the following MIDI Data Table for Address and Byte Count.
Always received no matter which device number is selected, in the case of REMOTE
SWITCH.

(3-6-4)BULK DUMP

11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0000nnnn 0n device Number
01100100 64 Model ID
0bbbbbbb bbbbbbb Byte Count
0bbbbbbb bbbbbbb Byte Count
0aaaaaaa aaaaaaa Address High
0aaaaaaa aaaaaaa Address Mid
0aaaaaaa aaaaaaa Address Low
0 0 Data
||
0ccccccc ccccccc Check-sum
11110111 F7 End of Exclusive

See the following MIDI Data Table for Address and Byte Count.
The Check sum is the value that results in a value of 0 for the lower 7 bits when
the Byte Count, Start Address, Data and Check sum itself are added.

(3-6-5) DUMP REQUEST

11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0010nnnn 2n device Number
01100100 64 Model ID
0aaaaaaa aaaaaaa Address High
0aaaaaaa aaaaaaa Address Mid
0aaaaaaa aaaaaaa Address Low
11110111 F7 End of Exclusive

See the following MIDI Data Table for Address and Byte Count.

(3-6-6) PARAMETER REQUEST

11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0011nnnn 3n device Number
01100100 64 Model ID
0aaaaaaa aaaaaaa Address Hig
0aaaaaaa aaaaaaa Address Mid
0aaaaaaa aaaaaaa Address Low
11110111 F7 End of Exclusive

See the following MIDI Data Table for Address and Byte Count.

(3-6-7)SAMPLE DUMP STANDARD

Receives sample dump headers and those data, and executes dump request.
Doesn’t send sample dump headers and those data.

DUMP REQUEST F0 7E nn 03 ss ss F7

Requests to send by designating the sample number of the source device.

ACK F0 7E nn 7F pp F7

Requests to send the following data after receiving the last packet of data.

NAK F0 7E nn 7E pp F7

Requests to send the remaining data after failing to receive the last packet of data.

CANCEL F0 7E nn 7D pp F7

Reports the cancellation of sample dump.

WAIT F0 7E nn 7C pp F7

Orders the source device not to send packets until an alternative order is given.
To resume the operation, send "ACK" or "CANCEL."

DUMP HEADER F0 7E nn 01 ss ss ee ff ff ff gg gg gg hh hh hh ii ii ii jj F7

Header of the data.

DATA PACKET F0 7E nn 02 kk < data 120 bytes > cc F7

Sample data.

nn Channel Number
ss ss Requested Sample, LSB First
pp Packet Number
ee Sample Format
ff ff ff Sample Period in Nanoseconds
gg gg gg Sample Length in Words
hh hh hh Sustain Loop Start Point Word Number (LSB First)
ii ii ii Sustain Loop End Point Word Number (LSB First)
jj Loop Type

4) SYSTEM OVERVIEW (Keyboard, Sequencer and Tone Generator)

Although three types of note on/note off data, received via MIDI, played by the
internal sequencer and played on the keyboard will be distinguished, the other
controllers (channel messages) equally affect the entire notes.

ALL SOUNDS OFF clears all the sounds in the specific channel(s) played by both the
keyboard and the data via MIDI.
ALL NOTES OFF received via MIDI clears the sounds in the specific channel(s) played
via MIDI.

SEQ KBD

TG

MIDI In

MIDI Out

From Host

To Host

Local Sw

HOST MODE = PC1/PC2/MAC

SEQ KBD

TG

MIDI In

MIDI Out

From Host

To Host

Local Sw

HOST MODE = MIDI

30

MIDI Data Table

Bank Select

Available Bank Select/Program Change

MSB (HEX) LSB (HEX) Program No. Type Memory Description

0 00 0 00 0 - 127 Normal Voice Internal

127 7F 0 00 0 - 1 Drum Voice User(Internal)

63 3F 0 00 0 - 127 Normal Voice Preset 1

1 01 0 - 127 Preset 2
8 08 0 - 127 User(Internal)

9 09 0 - 127 User(External)
24 18 0 - 63 Plug-in Voice User(Plug-in 1) Ignored in Phrase Clip Mode.
25 19 0 - 63 User(Plug-in 2)
32 20 0 - 7 Drum Voice Preset
40 28 0 - 1 User(Internal)
41 29 0 - 1 User(External)

63 3F 64 40 0 - 127 Performance User(Internal)

65 41 0 - 127 User(External)

63 3F 104 68 0 - 3 Clip Kit User Effective only in Phrase Clip Mode and Phrase

Clip Part of Performance Mode.

Plug-in Voice Bank Display

Available Bank Select/Program Change of the Plug-in Boards
(Before selecting a number, a Plug-in Board should be installed and PLG1 or PLG2 has to be selected in Voice Mode.)

MSB (HEX) LSB (HEX) Program No. Type LCD Display Description

63 3F 0 - 63 Internal PLG_INT LSB = 24H: Plug-in 1, 25H: Plug-in 2

0 00 0 - 127 XG Normal NORM/LLL LLL: Bank LSB

64 40 0 - 127 XG SFX NORM/SFX
126 7E 0 - 127 XG SFX kit KIT/SFX
127 7F 0 - 127 XG Drum kit KIT/DRM

*** ** 0 - 127 others MMM/LLL MMM: Bank MSB, LLL: Bank LSB

Only the banks that can be received by Plug-in Board are shown.

00 - 7F

18 - 19
00 - 7F
00 - 7F

00 - 7F

00 - 7F

Bank Select/Program Change made here may be
ineffective depending on the Bank Select setting
in Utility Mode. For more information refer to the
Owner's Manual.

<Table1>

Parameter Base Address

Parameter Block Description

Top Address

HML

SYSTEM 00 00 00 System

00 10 00 Plug-in Board Native System
00 20 00 Master EQ

00 70 00 Panel Knob
REMOTE SWITCH 0A 00 00 Remote Switch
BULK CONTROL 0E 00 00 Header

0F 00 00 Footer
PERFORMANCE COMMON 30 00 00 Performace Common
PERFORMANCE PART 31 00 00 Part1

:
31 0F 00 Part16
31 40 00 A/D Part
31 50 00 Phrase Clip Part
31 60 00 Plug-in 1 Part
31 61 00 Plug-in 2 Part

PERFORMANCE ZONE 32 00 00 Zone1

:
32 03 00 Zone4

VOICE COMMON 40 00 00 Common

40 01 00 Reverb
40 02 00 Chorus
40 03 00 Insertion 1
40 04 00 Insertion 2
40 05 00 Controller
40 06 00 LFO
40 70 00 Extra

VOICE ELEMENT GROUP1 41 ee 00 ee : Element No.
VOICE ELEMENT GROUP2 42 ee 00 ee : Element No.
VOICE ELEMENT GROUP3 43 ee 00 ee : Element No.
VOICE ELEMENT GROUP4 44 ee 00 ee : Element No.
KIT COMMON 46 00 00 Common
(DRUM VOICE & CLIP KIT) 46 01 00 Reverb

46 02 00 Chorus
46 03 00 Insertion 1
46 04 00 Insertion 2
46 05 00 Controller
46 70 00 Extra
46 71 00 Extra Phrase Clip

KIT ELEMENT GROUP1 47 ee 00 ee : Element No.
KIT ELEMENT GROUP2 48 ee 00 ee : Element No.
KIT ELEMENT GROUP3 49 ee 00 ee : Element No.
KIT ELEMENT GROUP4 4A ee 00 ee : Element No.
VOICE PLUGIN 4C 00 00 Common

4C 01 00 Reverb
4C 02 00 Chorus
4C 03 00 Insertion 1
4C 05 00 Controller
4C 10 00 Plug-in Element
4C 20 00 Native
4C 70 00 Extra

● “Top Address” indicates the top address of each block designated by bulk dump operation.

● “Byte Count” indicates the data size contained in each block designated by bulk dump operation.

● All blocks, from Bulk Header through Bulk Footer, of PERFORMANCE/VOICE can be received even though

they are not sent in order and/or not all of them are sent. However, squeezing a differnt block in those blocks
causes the operation invalid.

● To execute 1 Performance/1 Voice bulk dump request, designate its corresponding Bulk Header address.

● For the information about “mm” and “nn” shown in the following list, refer to MIDI PARAMETER CHANGE

TABLE (BULK CONTROL) below.

< Table 2 >

Bulk Dump Block

Parameter Block Description

Byte Count

Top Address

Dec Hex H M L

SYSTEM System 60 00 00 00

Plug-in Board Native System 32 00 10 00

Master EQ (for Voice Mode)

20 00 20 00

PERFORMANCE Bulk Header 0 00 0E mm nn

COMMON Common 68 30 00 00

Reverb 24 30 01 00
Chorus 25 30 02 00
Insertion 1 (for A/D Part) 22 30 03 00
Insertion 2 (for A/D Part) 34 30 04 00
Controller (for A/D Part) 10 30 05 00
Master EQ 20 30 10 00
Native (for InsEF Plug-in) 68 30 20 00

PARTPart1 37 310000

: 16 Blocks : : :
Part16 37 31 0F 00

A/D PART A/D Part 37 31 40 00

PHRASE CLIP PART Phrase Clip Part 37 31 50 00

PLUG-IN PART Plug-in 1 Part 37 31 60 00

Plug-in 2 Part 37 31 61 00

MASTER KEYBOARD ZONE Zone1 16 32 00 00

: 4 Blocks : : :
Zone4 16 32 03 00
Bulk Footer 0 00 0F mm nn

VOICE (NORMAL) Bulk Header 0 00 0E mm nn

COMMON Extra 56 40 70 00

Common 13 40 00 00
Reverb 24 40 01 00
Chorus 25 40 02 00
Insertion 1(S) 22 40 03 00
Insertion 2(L) 34 40 04 00
Controller 30 40 05 00
LFO 14 40 06 00

ELEMENT 1 Oscillator 13 41 00 00

Amplitude 29 41 00 20
Pitch 27 420000
Filter 48 43 00 00
EQ 8 440000
LFO 6 440040

ELEMENT 2 Oscillator 13 41 01 00

Amplitude 29 41 01 20
Pitch 27 420100
Filter 48 43 01 00
EQ 8 440100
LFO 6 440140

ELEMENT 3 Oscillator 13 41 02 00

Amplitude 29 41 02 20
Pitch 27 420200
Filter 48 43 02 00
EQ 8 440200
LFO 6 440240

ELEMENT 4 Oscillator 13 41 03 00

Amplitude 29 41 03 20
Pitch 27 420300
Filter 48 43 03 00
EQ 8 440300
LFO 6 440340
Bulk Footer 0 0F mm nn

VOICE (DRUM) Bulk Header 0 00 0E mm nn

COMMON Extra 56 46 70 00

Common 7 46 00 00
Reverb 24 46 01 00
Chorus 25 46 02 00
Insertion 1(S) 22 46 03 00
Insertion 2(L) 34 46 04 00
Controller 30 46 05 00

KEY C 0 Oscillator 18 47 00 00

Amplitude 12 47 00 20
Pitch 3 48 00 00
Filter 8 49 00 00
EQ 8 4A 00 00
: 73 Blocks : : :

KEY C 6 Oscillator 18 47 48 00

Amplitude 12 47 48 20
Pitch 3 48 48 00
Filter 8 49 48 00
EQ 8 4A 48 00
Bulk Footer 0 00 0F mm nn

3C
20
14

44
18
19
16
22
0A
14
44
25

25
25
25
25
25
10

10

38
0D
18
19
16
22
1E
0E
0D
1D
1B
30
08
06
0D
1D
1B
30
08
06
0D
1D
1B
30
08
06
0D
1D
1B
30
08
06
00

38
07
18
19
16
22
1E
12
0C
03
08
08

12
0C
03
08
08

31

VOICE (PLUG-IN) Bulk Header 0 00 0E mm nn

COMMON Extra 56 4C 70 00

Common 13 4C 00 00
Reverb 24 4C 01 00
Chorus 25 4C 02 00
Insertion 1(S) 22 4C 03 00
Controller 10 4C 05 00
Plug-in Element 35 4C 10 00
Native 68 4C 20 00
Bulk Footer 0 00 0F mm nn

Parameter Change

F0, 43, 1n, id, ah, am, al, dt, ... F7
n: Device Number

id: Model ID
ah: Parameter Address High
am: Parameter Address Middle
al: Parameter Address Low
dt: Data

Parameter Request

F0, 43, 3n, id, ah, am, al F7
n: Device Number

id: Model ID
ah: Parameter Address High
am: Parameter Address Middle
al: Parameter Address Low

Bulk Dump

F0, 43, 0n, id, bh, bl, ah, am, al, dt, ..., cc, F7
n: Device Number

id: Model ID
bh: Byte Count High
bl: Byte Count Low
ah: Parameter Address High
am: Parameter Address Middle
al: Parameter Address Low
dt: Data
cc: Check Sum of Data

Bulk Dump Request

F0, 43, 2n, id, ah, am, al, F7
n: Device Number

id: Model ID
ah: Parameter Address High
am: Parameter Address Middle
al: Parameter Address Low

38
0D
18
19
16
0A
23
44

<Table 3>

MIDI PARAMETER CHANGE TABLE (SYSTEM)

Address

Size

Data Range(HEX)

00 00 1 00 - 7F

1 28 - 58
4 00 - 0F

00 - 0F

→ bit15-12

00 - 0F

→ bit11-8

00 - 0F

→ bit7-4
→ bit3-0

1 00 - 01
1 35 - 4B
1 3D - 43
1 00 - 01
1 00 - 10,7F
1 00 - 0F,7F
1 00 - 01
1 00 - 01
1 00 - 01
1 00 - 01
1
1 00 - 03
1 00 - 04
1 01 - 7F
1 00 - 01
1 00 - 03
1 00 - 01
1 00 - 01
1 00 - 07
1 00 - 01
1 00 - 01
1 00 - 01
1 00 - 01
1
1 00 - 02
1 00 - 03
1
1
1
1
1
4
1 00 - 5F
1 00 - 33
1 00 - 33
1 00 - 33
1 00 - 5F
1 00 - 5F
1 00 - 5F
1 00 - 01
1

00 - 64

00 10 00 16 00 - 7F Plug-in 1 Native System Parameter depends on Plug-in Board depends on Plug-in Board

10 16 00 - 7F Plug-in 2 Native System Parameter depends on Plug-in Board depends on Plug-in Board

TOTAL SIZE =

32

20 (HEX)

00 20 00 1 34 -4C EQ Gain1 -12 - +12[dB]

40

for Voice Mode

01 1 04 - 28 EQ Frequency1 32 - 2000[Hz]

0C

:

02 1 01 - 78 EQ Q1 0. 1 - 12.0

07

:

03 1 00 - 01 EQ Shape1 shelv, peak

00

:

04 1 34 - 4C EQ Gain2 -12 - +12[dB]

40

:

05 1 0E - 36 EQ Frequency2 100 - 10.0[kHz]

1C

:

06 1 01 - 78 EQ Q2 0.1 - 12.0

07

:

1 NOT USED :

08 1 34 -4C EQ Gain3 -12 - +12[dB]

40

:
09 1 0E - 36 EQ Frequency3 100 - 10.0[kHz] 22 :
0A 1 01 - 78 EQ Q3 0. 1- 12.0 07 :

1 NOT USED :
0C 1 34 - 4C EQ Gain4 -12 - +12[dB] 40 :
0D 1 0E - 36 EQ Frequency4 100 - 10.0[kHz] 2E :
0E 1 01 - 78 EQ Q4 0.1 - 12.0 07 :

1 NOT USED :
10 1 34 - 4C EQ Gain5 -12 - +12[dB] 40 :
11 1 1C - 3A EQ Frequency5 0.5 - 16.0[kHz] 34 :
12 1 01 - 78 EQ Q5 0.1 - 12.0 07 :
13 1 00 - 01 EQ Shape5 shelv, peak 00 :

TOTAL SIZE =

20

14 (HEX)

00 70 00 1 00 - 7F Phrase Clip Pitch Knob 0 - 127 -- CS6x,CS6R only

Prameter Name

Master Volume
Master Note Shift
Master Tune

Controller Reset
Master Transpose
Master Octave Shift
Local Switch
Basic Receive Channel
Keyboard Tr ansmit Channel
MIDI Sync
MIDI Control
Plug-in Board 1 MIDI Sync/Control
Plug-in Board 2 MIDI Sync/Control
reserved
BC Curve (for TG)
Keyboard Velocity Curve
Keyboard Fixed Velocity
Receive GM/XG On
Receive/Transmit Bank Select
Receive Program Change
MIDI Control Mode
Thru Port
MIDI Input
Effect Bypass Reverb
Effect Bypass Chorus
Effect Bypass Insertion
reserved
GM/XG Receive Mode
Power on Mode
reserved
reserved
reserved
reserved
reserved
reserved
Scene Control Number
Knob A Destination
Knob B Destination
Knob C Destination
Knob A Control Number
Knob B Control Number
Knob C Control Number
FV Assign
FS Assign

Description

0 - 127

-24 - +24[semitones]

-102.4 - +102.3[cent]
1st bit3-0
2nd bit3-0
3rd bit3-0
4th bit3-0
hold, reset

-11 - +11(semitones)

-3 - +3
off,on
1 - 16,omni,off
1 - 16,off
int,MIDI
off,on
off,on
off,on

thru, soft, hard, wide
norm, soft, hard, wide, fixed
1 - 127
off,on
off,all,part,perform
off,on
mode1, mode2
1 - 8
MIDI,mLAN
off,on
off,on
off,on

all-part, layer-part, all-off
Performance, Voice(INT), V oice(PRE1), last

off,1 - 95
off,1 - 51
off,1 - 51
off,1 - 51
off,1 - 95
off,1 - 95
off,1 - 95
volume, express
off,1 - 95, Arp Sw, Arp Hold, SMF Play, PC

Inc, PC Dec
1 00 - 5F
1 00 - 5F
1 00 - 01
1 00 - 0F
1 00 - 5F
1 00 - 5F
1 00 - 5F
1 00 - 5F
1 00 - 5F

00
01
02

06
07
08
09
0A
0B
0C
0D
0E
0F
10
11
12
13
14
15
16
17
18
19
1A
1B
1C
1D
1E
1F
20
21
22
23
24
25
29
2A
2B
2C
2D
2E
2F
30
31

32
33
34
35
36
37
38
39
3A
3B 1 00 - 01

Notes

MIDI Master Volume

MIDI Master Tuning

CS6x, S80 only
CS6x, S80 only

CS6x, S80 only
CS6x, S80 only

CS6x only

for Voice Mode

:
:
:
:
:
:
:(CS6x only)

TOTAL SIZE =

60 3C(HEX)

ARP Switch Control Number
ARP Hold Control Number
ARP MIDI Out Switch
ARP MIDI Out Channel
KN1 Control Number
KN2 Control Number
BC Control Number
FC Control Number
RB Control Number
RB Mode

off,1 - 95

off,1 - 95

off,on

1 - 16

off,1 - 95

off,1 - 95

off,1 - 95

off,1 - 95

off,1 - 95

hold,reset

Default(HEX)

7F
40

00 04 00 00 (0400)

00
40
40
01
00
00
00
01
00
00
02
00
00
40
01
01
00
00
00
00
01
01
00
00
02
01
00
00
00
00
00
00
0E
01
07
0D
12
13
14
01
58

5A
59
00
00
10
11
02
04
16
00

32

MIDI PARAMETER CHANGE TABLE (BULK CONTROL)

Address

Size

Data Range(HEX)

Prameter Name

Default(HEX)

Notes

0E

0 - Bulk Header ­0- ­0- ­0- ­0- ­0- ­0- ­0- ­0- ­0- ­0- ­0- ­0- ­0- -

0F

0 - Bulk Footer ­0- ­0- ­0- ­0- ­0- ­0- ­0- ­0- ­0- ­0- ­0- ­0- -

08
09
0F
18
19
1F
28
29
2F
40
41
4F
68
6F
08
09
0F
18
19
1F
28
29
2F
40
41
4F
68
6F

nn
nn
nn
nn
nn
nn
nn
nn
nn
nn
nn
nn
nn
nn
nn
nn
nn
nn
nn
nn
nn
nn
nn
nn
nn
nn
nn
nn 0 - -

Description

Normal Voice INT (nn = 0 - 127)
Normal Voice EXT (nn = 0 - 127)
Normal Voice Edit Buffer (nn = 0)
Plug-in Voice PLG1 (nn = 0 - 63)
Plug-in Voice PLG2 (nn = 0 - 63)
Plug-in Voice Edit Buffer (nn = 0)
Drum Voice INT (nn = 0 - 1)
Drum Voice EXT (nn = 0 - 1)
Drum Voice Edit Buffer (nn = 0)
Performance INT (nn = 0 - 127)
Performance EXT (nn = 0 - 63)
Performance Edit Buffer (nn = 0)
Phrase Clip Kit INT (nn = 0 - 3)
Phrase Clip Kit Edit Buffer (nn = 0)
Normal Voice INT (nn = 0 - 127)
Normal Voice EXT (nn = 0 - 127)
Normal Voice Edit Buffer (nn = 0)
Plug-in Voice PLG1 (nn = 0 - 63)
Plug-in Voice PLG2 (nn = 0 - 63)
Plug-in Voice Edit Buffer (nn = 0)
Drum Voice INT (nn = 0 - 1)
Drum Voice EXT (nn = 0 - 1)
Drum Voice Edit Buffer (nn = 0)
Performance INT (nn = 0 - 127)
Performance EXT (nn = 0 - 63)
Performance Edit Buffer (nn = 0)
Phrase Clip Kit INT (nn = 0 - 3)
Phrase Clip Kit Edit Buffer (nn = 0)

<Table 4>

MIDI PARAMETER CHANGE TABLE (REMOTE SWITCH)

Address

Size

Data Range(HEX)

Prameter Name

Default(HEX)

00 1 00 - 01 OCT DOWN --

1 00 - 01 OCT UP -­1 00 - 01 SCENE1 -­1 00 - 01 SCENE2 -­1 00 - 01 ARP HOLD -­1 00 - 01 ARP ON/OFF -­1 00 - 01 PORTAMENTO ON/OFF -­1 reserved -­1 00 - 01 PHRASE CLIP -­1 00 - 01 PHRASE CLIP REC -­1 reserved -­1 reserved -­1 reserved -­1 reserved -­1 reserved -­1 reserved -­1 00 - 01 PERFORM -­1 00 - 01 VOICE -­1 00 - 01 SEQ PLAY -­1 00 - 01 UTILITY -­1 00 - 01 CARD -­1 00 - 01 PLAY/STOP -­1 00 - 01 EDIT -­1 00 - 01 JOB -­1 00 - 01 SHIFT -­1 00 - 01 EF BYPASS -­1 00 - 01 MASTER KEYBOARD -­1 00 - 01 DEC/NO -­1 00 - 01 INC/YES -­1 00 - 01 EXIT -­1 00 - 01 ENTER -­1 00 - 01 STORE -­1 00 - 01 PRE1 -­1 00 - 01 PRE2 -­1 00 - 01 INT -­1 00 - 01 EXT -­1 00 - 01 PLG1 -­1 00 - 01 PLG2 -­1 reserved -­1 00 - 01 QUICK ACCESS -­1 00 - 01 A -­1 00 - 01 B -­1 00 - 01 C -­1 00 - 01 D -­1 00 - 01 E -­1 00 - 01 F -­1 00 - 01 G -­1 00 - 01 H -­1 00 - 01 1 -­1 00 - 01 2 -­1 00 - 01 3 -­1 00 - 01 4 -­1 00 - 01 5 -­1 00 - 01 6 -­1 00 - 01 7 -­1 00 - 01 8 -­1 00 - 01 9 -­1 00 - 01 10 -­1 00 - 01 11 -­1 00 - 01 12 -­1 00 - 01 13 -­1 00 - 01 14 -­1 00 - 01 15 --

00
01
02
03
04
05
06
07
08
09
0A
0B
0C
0D
0E
0F
10
11
12
13
14
15
16
17
18
19
1A
1B
1C
1D
1E
1F
20
21
22
23
24
25
26
27
28
29
2A
2B
2C
2D
2E
2F
30
31
32
33
34
35
36
37
38
39
3A
3B
3C
3D
3E
3F 1 00 - 01 16 --

Description

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

off,on

Notes

CS6x only
CS6x only
CS6x only
CS6x only
CS6x only
CS6x only
CS6x only

CS6x,CS6R only
CS6x,CS6R only

CS6x,S80 only

S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only
CS6x,S80 only

<Table 5>

MIDI PARAMETER CHANGE TABLE (PERFORMANCE COMMON)

Size Data Range(HEX)

Prameter Name Description

Default(HEX)

Notes

30 00 00 1 20 - 7E Performance Name1 32..126(ASCII) I
30 00 01 1 20 - 7E Performance Name2 32..126(ASCII) n
30 00 02 1 20 - 7E Performance Name3 32..126(ASCII) i
30 00 03 1 20 - 7E Performance Name4 32..126(ASCII) t
30 00 04 1 20 - 7E Performance Name5 32..126(ASCII)
30 00 05 1 20 - 7E Performance Name6 32..126(ASCII) P
30 00 06 1 20 - 7E Performance Name7 32..126(ASCII) e
30 00 07 1 20 - 7E Performance Name8 32..126(ASCII) r
30 00 08 1 20 - 7E Performance Name9 32..126(ASCII) f
30 00 09 1 20 - 7E Performance Name10 32..126(ASCII)
30 00 0A 1 reserved
30 00 0B 1 reserved
30 00 0C 1 00 - 16 Performance Category 00..22(--..Sq) 00(--)
30 00 0D 1 00 - 7F Phrase Clip Pitch -64..+63 40
30 00 0E 1 00 - 02 Master Keyboard Mode split,4zone,layer 01
30 00 0F 1 00 - 7F Master Keyboard Split Point C-2..G8 3C
30 00 10 1 00 - 10 Layer Channel 1..16,BasicCh 10
30 00 11 1 00 - 01 ARP MIDI Out Switch off,on 00
30 00 12 1 00 - 10 ARP MIDI Out Channel 1..16,kbd-ch 00
30 00 13 1 00 - 7F ARP Type UpOct1 - GateCut3 00
30 00 14 1 00 - 01 ARP Switch off,on 00
30 00 15 1 00 - 02 ARP Hold sync-off,off,on 01
30 00 16 1 00 - 06 ARP Unit Multiply 50%,66%,75%,100%,133%,150%,200% 03
30 00 17 1 00 - 7F ARP Note Limit Low C-2..G8 00
30 00 18 1 00 - 7F ARP Note Limit High C-2..G8 7F
30 00 19 1 00 - 02 ARP Key Mode sort,thru,direct 01
30 00 1A 1 00 - 01 ARP Vel Mode original,thru 01
30 00 1B 2 0000 - 00C8 ARP Velocity Rate MSB 0...200% 64

ARP Velocity Rate LSB

30 00 1D 2 0000 - 00C8 ARP Gate Time Rate MSB 0...200% 64

ARP Gate TIme Rate LSB

30 00 1F 2 0019 - 012C ARP Tempo MSB 25..300 78

ARP Tempo LSB
30 00 21 1 01 - 7F QED Pan L63..C..R63 40
30 00 22 1 reserved 40
30 00 23 1 00 - 7F QED Chorus Control -64..+63 40
30 00 24 1 00 - 7F QED Release Time -64..+63 40
30 00 25 1 00 - 7F QED Sustain Level -64..+63 40
30 00 26 1 00 - 7F QED Portamento Time -64..+63 40
30 00 27 1 00 - 01 QED Portamento Switch off,on 00
30 00 28 1 00 - 7F QED KnobA -64..+63 40
30 00 29 1 00 - 7F QED KnobB -64..+63 40
30 00 2A 1 00 - 7F QED KnobC -64..+63 40
30 00 2B 1 00 - 7F QED/Scene 1 Knob1 -64..+63 40
30 00 2C 1 00 - 7F QED/Scene 1 Knob2 -64..+63 40
30 00 2D 1 00 - 7F QED/Scene 1 Cutoff Frequency -64..+63 40
30 00 2E 1 00 - 7F QED/Scene 1 Resonance -64..+63 40
30 00 2F 1 00 - 7F QED/Scene 1 Attack Time -64..+63 40
30 00 30 1 00 - 7F QED/Scene 1 Decay Time -64..+63 40
30 00 31 1 00 - 7F Scene 2 Knob1 -64..+63 40
30 00 32 1 00 - 7F Scene 2 Knob2 -64..+63 40
30 00 33 1 00 - 7F Scene 2 Cutoff Frequency -64..+63 40
30 00 34 1 00 - 7F Scene 2 Resonance -64..+63 40
30 00 35 1 00 - 7F Scene 2 Attack Time -64..+63 40
30 00 36 1 00 - 7F Scene 2 Decay Time -64..+63 40
30 00 37 1 00 - 7F Scene Control 0..127 00
30 00 38 1 00 - 7F QED Volume 0..127 7F
30 00 39 1 00 - 7F QED Reverb Send 0..127 7F
30 00 3A 1 00 - 7F QED Chorus Send 0..127 7F
30 00 3B 1 00 - 5F KN1 Control Number off,1 - 95 10
30 00 3C 1 00 - 5F KN2 Control Number off,1 - 95 11
30 00 3D 1 00 - 5F BC Control Number off,1 - 95 02
30 00 3E 1 00 - 5F FC Control Number off,1 - 95 04
30 00 3F 1 00 - 5F RB Control Number off,1 - 95 16
30 00 40 1 00 - 01 RB Mode hold,reset 00
30 00 41 1 00 - 7F Insertion Effect Part for Normal/

AD/Phrase Clip

0 - 15: Part1 ... 16 00
64: PartAD
80: PartCL
127: off

30 00 42 1 60 - 7F Insertion Effect Part for Plug-In 96 - 97: PartP1,PartP2 60

127: off

30 00 43 1 00 - 7F Insertion Plug-in Part 0 - 15: Part1 ... 16 7F

64: PartAD
80: PartCL
127: off

TOTAL SIZE = 68 44 (HEX)

Address

30 01 00 2 00 - 7F Reverb Type MSB Refer to Effect Parameter List Depends On Effect Type

00 - 7F Reverb Type LSB

30 01 02 2 00 - 7F Reverb Parameter 1 MSB

""

00 - 7F Reverb Parameter 1 LSB

30 01 04 2 00 - 7F Reverb Parameter 2 MSB

""

00 - 7F Reverb Parameter 2 LSB

30 01 06 2 00 - 7F Reverb Parameter 3 MSB

""

00 - 7F Reverb Parameter 3 LSB

30 01 08 2 00 - 7F Reverb Parameter 4 MSB

""

00 - 7F Reverb Parameter 4 LSB

30 01 0A 2 00 - 7F Reverb Parameter 5 MSB

""

00 - 7F Reverb Parameter 5 LSB

30 01 0C 2 00 - 7F Reverb Parameter 6 MSB

""

00 - 7F Reverb Parameter 6 LSB

30 01 0E 2 00 - 7F Reverb Parameter 7 MSB

""

00 - 7F Reverb Parameter 7 LSB

30 01 10 2 00 - 7F Reverb Parameter 8 MSB

""

00 - 7F Reverb Parameter 8 LSB

30 01 12 2 00 - 7F Reverb Parameter 9 MSB

""

00 - 7F Reverb Parameter 9 LSB

30 01 14 2 00 - 7F Reverb Parameter 10 MSB

""

00 - 7F Reverb Parameter 10 LSB

30 01 16 1 00 - 7F Reverb Return -

∞dB...0dB...+6dB(0...96...127) 7F

30 01 17 1 01 - 7F Reverb Pan L63...C...R63 40
TOTAL SIZE =

24 18 (HEX)

33

30 2 00 - 7F Chorus Type MSB Refer to Effect Parameter List Depends On Effect Type

00 - 7F Chorus Type LSB

30 2 00 - 7F Chorus Parameter 1 MSB

""

00 - 7F Chorus Parameter 1 LSB

30 2 00 - 7F Chorus Parameter 2 MSB

""

00 - 7F Chorus Parameter 2 LSB

30 2 00 - 7F Chorus Parameter 3 MSB

""

00 - 7F Chorus Parameter 3 LSB

30 2 00 - 7F Chorus Parameter 4 MSB

""

00 - 7F Chorus Parameter 4 LSB

30 2 00 - 7F Chorus Parameter 5 MSB

""

00 - 7F Chorus Parameter 5 LSB

30 2 00 - 7F Chorus Parameter 6 MSB

""

00 - 7F Chorus Parameter 6 LSB

30 2 00 - 7F Chorus Parameter 7 MSB

""

00 - 7F Chorus Parameter 7 LSB

30 2 00 - 7F Chorus Parameter 8 MSB

""

00 - 7F Chorus Parameter 8 LSB

30 2 00 - 7F Chorus Parameter 9 MSB

""

00 - 7F Chorus Parameter 9 LSB

30 2 00 - 7F Chorus Parameter 10 MSB

""

00 - 7F Chorus Parameter 10 LSB

30 1 00 - 7F Chorus Return -

∞dB

dB

...0dB...+6dB(0...96...127) 7F
30 1 01 - 7F Chorus Pan L63...C...R63 40
30

02

02

02

02

02

02

02

02

02

02

02

02
02
02 1 00 - 7F Send Chorus To Reverb -

∞

...

0dB(0...127) 00

TOTAL SIZE =

25 19 (HEX)

30 03 00 2 00 - 7F

Insertion-1 Type MSB (for A/D Part)

Refer to Effect Parameter List Depends On Effect Type

00 - 7F Insertion-1 Type LSB

30 03 02 2 00 - 7F Insertion-1 Parameter1 MSB

""

00 - 7F Insertion-1 Parameter1 LSB

30 03 04 2 00 - 7F Insertion-1 Parameter2 MSB

""

00 - 7F Insertion-1 Parameter2 LSB

30 03 06 2 00 - 7F Insertion-1 Parameter3 MSB

""

00 - 7F Insertion-1 Parameter3 LSB

30 03 08 2 00 - 7F Insertion-1 Parameter4 MSB

""

00 - 7F Insertion-1 Parameter4 LSB

30 03 0A 2 00 - 7F Insertion-1 Parameter5 MSB

""

00 - 7F Insertion-1 Parameter5 LSB

30 03 0C 2 00 - 7F Insertion-1 Parameter6 MSB

""

00 - 7F Insertion-1 Parameter6 LSB

30 03 0E 2 00 - 7F Insertion-1 Parameter7 MSB

""

00 - 7F Insertion-1 Parameter7 LSB

30 03 10 2 00 - 7F Insertion-1 Parameter8 MSB

""

00 - 7F Insertion-1 Parameter8 LSB

30 03 12 2 00 - 7F Insertion-1 Parameter9 MSB

""

00 - 7F Insertion-1 Parameter9 LSB

30 03 14 2 00 - 7F Insertion-1 Parameter10 MSB

""

00 - 7F Insertion-1 Parameter10 LSB

TOTAL SIZE =

22 16 (HEX)

Depends On Effect Type30

30

30

30

30

30

30

30

30

30

30

30

30

30

30

30

30

04

04

04

04

04

04

04

04

04

04

04

04

04

04

04

04

04

00

02

04

06

08

0A

0C

0E

10

12

14

16

18

1A

1C

1E

20

2

2

2

2

2

2

2

2

2

2

2

2

2

2

2

2

2

"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"

00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F

Refer to Effect Parameter List

"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"

Insertion-2 Type MSB (for A/D Part)
Insertion-2 Type LSB
Insertion-2 Parameter 1 MSB
Insertion-2 Parameter 1 LSB
Insertion-2 Parameter 2 MSB
Insertion-2 Parameter 2 LSB
Insertion-2 Parameter 3 MSB
Insertion-2 Parameter 3 LSB
Insertion-2 Parameter 4 MSB
Insertion-2 Parameter 4 LSB
Insertion-2 Parameter 5 MSB
Insertion-2 Parameter 5 LSB
Insertion-2 Parameter 6 MSB
Insertion-2 Parameter 6 LSB
Insertion-2 Parameter 7 MSB
Insertion-2 Parameter 7 LSB
Insertion-2 Parameter 8 MSB
Insertion-2 Parameter 8 LSB
Insertion-2 Parameter 9 MSB
Insertion-2 Parameter 9 LSB
Insertion-2 Parameter 10 MSB
Insertion-2 Parameter 10 LSB
Insertion-2 Parameter 11 MSB
Insertion-2 Parameter 11 LSB
Insertion-2 Parameter 12 MSB
Insertion-2 Parameter 12 LSB
Insertion-2 Parameter 13 MSB
Insertion-2 Parameter 13 LSB
Insertion-2 Parameter 14 MSB
Insertion-2 Parameter 14 LSB
Insertion-2 Parameter 15 MSB
Insertion-2 Parameter 15 LSB
Insertion-2 Parameter 16 MSB
Insertion-2 Parameter 16 LSB

TOTAL SIZE =

34 22 (HEX)

1 00 - 09

Controller Set1 Source (for A/D Part)

00

2 00 Controller Set1 Destination MSB 00

00 - 1D Controller Set1 Destination LSB
1 00 - 7F Controller Set1 Depth 40
1 reserved 00
1 00 - 09 Controller Set2 Source 00
2 00 Controller Set2 Destination MSB 00

00 - 1D Controller Set2 Destination LSB
1 00 - 7F Controller Set2 Depth

PB, MW1, ---, AT, FC, FS, RB, BC, KN1, KN2
0 - 29

-64 - +63

PB, MW1, ---, AT, FC, FS, RB, BC, KN1, KN2
0 - 29

-64 - +63

40

30
30

30
30
30
30

30
30

05
05

05
05
05
05

05
05

00
01

03
04
05
06

08
09 1

reserved 00

TOTAL SIZE =

10 0A (HEX)

1 34 - 4C EQ Gain1
1 04 - 28 EQ Frequency1
1 01 - 78 EQ Q1
1 00 - 01 EQ Shape1
1 34 - 4C EQ Gain2
1 0E - 36 EQ Frequency2
1 01 - 78 EQ Q2
1 Not Used
1 34 - 4C EQ Gain3
1 0E - 36 EQ Frequency3
1 01 - 78 EQ Q3
1 Not Used
1 34 - 4C EQ Gain4
1 0E - 36 EQ Frequency4
1 01 - 78 EQ Q4
1 Not Used
1 34 - 4C EQ Gain5
1 1C - 3A EQ Frequency5
1 01 - 78 EQ Q5

30
30
30
30
30
30
30

30
30
30

30
30
30

30
30
30
30

10
10
10
10
10
10
10

10
10
10

10
10
10

10
10
10
10

00
01
02
03
04
05
06

08
09
0A

0C
0D
0E

10
11
12
13 1 00 - 01 EQ Shape5

-12 - +12[dB]
32 - 2000[Hz]

0. 1 - 12.0
shelv,peak

-12 - +12[dB]
100 - 10.0[kHz]

0.1 - 12.0

-12 - +12[dB]
100 - 10.0[kHz]

0. 1- 12.0

-12 - +12[dB]
100 - 10.0[kHz]

0.1 - 12.0

-12 - +12[dB]

0.5 - 16.0[kHz]

0.1 - 12.0
shelv,peak

40
0C
07
00
40
1C
07

40
22
07

40
2E
07

40
34
07
00

TOTAL SIZE =

20 14 (HEX)

00 - 7F

Plug-in Board Native System Parameter

depends on Plug-in Board

00 - 7F Plug-in Board Native Parameter depends on Plug-in Board

30
30
30

20
20
20

00
10
40

16
48

3 00 - 7F Plug-in Board Type MSB

(for InsEF Plug-in)
(for InsEF Plug-in)

(for InsEF Plug-in) depends on Plug-in Board
00 - 7F Plug-in Board Type LSB
00 - 7F Plug-in Board Version Number

43 1 00 - 7F reserved

TOTAL SIZE =

68 44 (HEX)

00

02

04

06

08

0A

0C

0E

10

12

14

16
17
18

Size Data Range(HEX)

Prameter Name Description

Default(HEX)

NotesAddress

<Table 6>

MIDI P ARAMETER CHANGE TABLE (PERFORMANCE PART)

Address Size

Data Range(HEX)

Prameter Name Description

Default(HEX)

Notes

→

bit7-4

→

bit3-0

31
31
31
31
31
31
31
31
31
31
31
31
31
31
31
31
31

31
31
31
31
31
31
31
31
31
31
31

31

31

31

31
31
31
31
31

pp
pp
pp
pp
pp
pp
pp
pp
pp
pp
pp
pp
pp
pp
pp
pp
pp

pp
pp
pp
pp
pp
pp
pp
pp
pp
pp
pp

pp

pp

pp

pp
pp
pp
pp
pp

00
01
02
03
04
05
06
07
08
09
0A
0B
0C
0D
0E
0F
10

12
13
14
15
16
17
18
19
1A
1B
1C

1D

1E

1F

20
21
22
23
24

00 - 7F
00 - 7F
00 - 7F

00 - 0F, 7F

00 - 01
01 - 7F
01 - 7F
00 - 7F
00 - 7F
10 - 58
10 - 58
00 - 7F
00 - 7F
00 - 7F
01 - 7F

00 - 0F
00 - 0F

00 - 7F
00 - 7F

28 - 58
00 - 7F
00 - 7F

00 - 01
00 - 7F
00 - 01
00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F
00 - 7F

00 - 7F
00 - 7F

Bank Select MSB
Bank Select LSB
Program Number
Receive Channel
Part Mode
Velocity Limit Low
Velocity Limit High
Note Limit Low
Note Limit High
Pitch Bend Range Upper
Pitch Bend Range Lower
Velocity Sense Depth
Velocity Send Offset
Volume
Pan
reserved
Detune MSB
Detune LSB

Reverb Send
Chorus Send
reserved
Note Shift
Filter Cutoff Frequency
Filter Resonance/Width
reserved
Portamento Switch
Portamento Time
Portamento Mode
Output Select

Layer Sw
Arpeggio Sw
Receive Control Change
Receive Bank Select
Receive Program Change
Receive AT
Receive PB
Receive Volume/Expression
Receive Pan

Receive Sustain/Sostenute

Receive MW

Receive FC
Receive FS
Receive RB
Receive BC
Receive Knob1
Receive Knob2

AEG Decay2 Level (EG Sustain Level)
AEG Attack Time (EG Attack Time)
reserved
AEG Decay2 Time (EG Decay Time)
AEG Release Time (EG Release Time)

0 - 127
0 - 127
1 - 128

1..16,off(7F)
mono,poly
1 - 127
1 - 127
C-2 - G8
C-2 - G8

-48 - +24

-48 - +24
0 - 127
0 - 127
0 - 127
L63 - C - R63

-24 - +24[semitones]

-12.8 - +12.7[Hz]
1st bit3-0
2nd bit3-0
0 - 127
0 - 127

-64 - +63

-64 - +63

off,on
0 - 127
fingered,fulltime
0: L&R
8: ind1&2
64 - 69: ind1 - ind6
127: drum
bit0: Layer Sw off,on
bit1: Arpeggio Sw off,on
bit2: off,on Control Change
bit3: off,on Bank Select
bit4: off,on Program Change
bit5: off,on AT
bit6: off,on PB
bit0: off,on Volume/Expression
bit1: off,on Pan
bit2: reserved
bit3: off,on Sustain/Sostenute
bit4: reserved
bit5: off,on MW
bit6: reserved
bit0: off,on FC
bit1: off,on FS
bit2: off,on RB
bit3: off,on BC
bit4: off,on KN1
bit5: off,on KN2
bit6: reserved

-64 - +63

-64 - +63

-64 - +63

-64 - +63

00
00
00
Part No.
01
01
7F
00
7F
40
40
40
40
64
40
40
08 00 (80)

28
00
00
40
40
40
40
00
40
00
00

7C

7F

7F

40
40
40
40
40

Part1-16, P1/2
Part1-16,CL,P1/2
Part1-16,CL,P1/2
Part1-16,CL,P1/2
Part1-16,CL,P1/2
Part1-16,CL,P1/2
Part1-16,CL
Part1-16,CL,P1/2
Part1-16,CL,P1/2

Part1-16,CL,P1/2

Part1-16,CL,P1/2

Part1-16,CL,P1/2
Part1-16,CL,P1/2

Part1-16,P1/2
Part1-16,P1/2
Part1-16

Part1:on, Other:off
Part1-16,CL,P1/2

Part1-16,CL
Part1-16,CL,P1/2

Part1-16,CL,P1/2
Part1-16,CL,P1/2

TOTAL SIZE =

37 25 (HEX)

pp = part number

00 - 0F Part 1 - 16
40 Part A/D
50 Part Phrase Clip
60 Part Plug-in 1
61 Part Plug-in 2

1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2

1
1
1
1
1
1
1
1
1
1
1

1

1

1

1
1
1
1
1

<Table 7>

MIDI P ARAMETER CHANGE TABLE (MASTER KEYBOARD ZONE)

CS6x, S80 only

Addres s Si zeData Range(HEX) Prameter Name Description Default(

HEX

) Notes

1 00 - 3F Transmit Channel, MIDI/TG Switch Zone1:30, Other:00

1
1
1
1
1
1
1
1
1
1
1

32

32
32
32
32
32
32
32
32
32
32
32
32

nn

nn
nn
nn
nn
nn
nn
nn
nn
nn
nn
nn
nn

00

01
02
03
04
05
06
07
08
09
0A
0B
0C 1

32

0D 1

32

nn 0E 1

3D - 43
35 - 4B
00 - 7F
00 - 7F

00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F

00 - 7F

00 - 5F

bit0-3: Ch1..16
bit4: MIDI off,on
bit5: TG off,on

-3..+3

-11..+11(semitones)
C-2..G8
C-2..G8

0..127

0..127

0..127

0..127

1..128
bit0: off,on FV (Volume/Expression)
bit1: off,on Pan
bit2: off,on Sustain
bit3: off,on Bank Select
bit4: off,on Program Change
bit5: off,on AT
bit6: off,on PB
bit0: off,on FC
bit1: off,on FS
bit2: off,on RB
bit3: off,on BC
bit4: off,on MW
bit5: off,on Assignable KnobA,B,C
bit6: off,on Assignable Knob1,2
off,1 - 95 S80 only

32

nn 0F 1

Transpose (Octave)
Transpose (Semitone)
Note Limit Low
Note Limit High
reserved
reserved
MIDI Volume
MIDI Pan
MIDI Bank MSB
MIDI Bank LSB
MIDI Program Number
Transmit Volume/FV
Transmit Pan
Transmit Sustain
Transmit Bank Select
Transmit Program Change
Transmit AT
Transmit PB
Transmit FC
Transmit FS
Transmit RB
Transmit BC
Transmit MW
Transmit Assignable Knob (A/B/C)
Transmit Assignable Knob (1/2)
Control Slider Control Number
reserved

40
40
00
7F
01
7F
64
40
00
00
00
7F

7F

07
00

TOTAL SIZE =

16 10 (HEX)

nn = zone number 00 - 03

34

<Table 8>

MIDI PARAMETER CHANGE TABLE (NORMAL VOICE COMMON)

Size Data Range(HEX)

Prameter Name Description

Default(HEX)

Notes

1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2

2

2

1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1

20 - 7E
20 - 7E
20 - 7E
20 - 7E
20 - 7E
20 - 7E
20 - 7E
20 - 7E
20 - 7E
20 - 7E

00 - 16

00 - 7F
00 - 01
00 - 02
00 - 06
00 - 7F
00 - 7F
00 - 02
00 - 01

0000 - 00C8

0000 - 00C8

0019 - 012C

01 - 7F

00 - 7F
00 - 7F
00 - 7F

00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F

Voice Name1
Voice Name2
Voice Name3
Voice Name4
Voice Name5
Voice Name6
Voice Name7
Voice Name8
Voice Name9
Voice Name10
reserved
reserved
Voice Category
reserved
reserved
reserved
reserved
reserved
reserved
ARP Type
ARP Switch
ARP Hold
ARP Unit Multiply
ARP Note Limit Low
ARP Note Limit High
ARP Key Mode
ARP Vel Mode
ARP Velocity Rate MSB
ARP Velocity Rate LSB
ARP Gate Time Rate MSB
ARP Gate TIme Rate LSB
ARP Tempo MSB
ARP Tempo LSB
QED Pan
reserved
QED Chorus Control
QED Release Time
QED Sustain Level
reserved
reserved
QED KnobA
QED KnobB
QED KnobC
QED/Scene 1 Knob1
QED/Scene 1 Knob2
QED/Scene 1 Cutoff Frequency
QED/Scene 1 Resonance
QED/Scene 1 Attack Time
QED/Scene 1 Decay Time
Scene 2 Knob1
Scene 2 Knob2
Scene 2 Cutoff Frequency
Scene 2 Resonance
Scene 2 Attack Time
Scene 2 Decay Time
Scene Control

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

00..22(--..Sq)

UpOct1 - GateCut3
off,on
sync-off,off,on
50%,66%,75%,100%,133%,150%,200%
C-2..G8
C-2..G8
sort,thru,direct
original,thru

0...200%

0...200%

25..300

L63..C..R63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

0..127

t

I
n
i

V
o
i
c
e

00(--)

00
00
01
03
00
7F
01
01
64

64

8A

40
40
40
40
40
40
00
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
00

TOTAL SIZE =

56 38 (HEX)

1 00 - 7F Volume

64

1 00 - 0F Element Switch

01

1 00 - 01 Same Note Number Key On Assign

01

1 00 - 01 Mono/Poly Mode

01

1 00 - 1F Micro Tuning

00

1 10 - 58 Pitch Bend Range Upper

42

1 10 - 58 Pitch Bend Range Lower

3E

1 00 - 01 Portamento Mode

00

1 00 - 01 Portamento Switch

00

1 00 - 7F Portamento Time

00

1 00 - 02 Insertion Connect Type

00

1 00 - 7F Reverb Send -

∞

00

1 00 - 7F Chorus Send -

∞

0 - 127
BIT3:EL4, BIT2:EL3, BIT1:EL2, BIT0:EL1
single, multi
mono,poly
Equal - Indian

-48 - +24[semitones]

-48 - +24[semitones]
fingered,fulltime
off,on
0 - 127
1|2(Pararel), 1->2, 2->1

dB... 0dB
dB... 0dB

00

TOTAL SIZE =

13 0D (HEX)

2 00 - 7F Reverb Type MSB 0100

Depends On Effect Type

00 - 7F Reverb Type LSB

2 00 - 7F Reverb Parameter 1 MSB

00 - 7F Reverb Parameter 1 LSB

2 00 - 7F Reverb Parameter 2 MSB

"

00 - 7F Reverb Parameter 2 LSB

2 00 - 7F Reverb Parameter 3 MSB

"

00 - 7F Reverb Parameter 3 LSB

2 00 - 7F Reverb Parameter 4 MSB

"

00 - 7F Reverb Parameter 4 LSB

2 00 - 7F Reverb Parameter 5 MSB

"

00 - 7F Reverb Parameter 5 LSB

2 00 - 7F Reverb Parameter 6 MSB

"

00 - 7F Reverb Parameter 6 LSB

2 00 - 7F Reverb Parameter 7 MSB

"

00 - 7F Reverb Parameter 7 LSB

2 00 - 7F Reverb Parameter 8 MSB

"

00 - 7F Reverb Parameter 8 LSB

2 00 - 7F Reverb Parameter 9 MSB

"

00 - 7F Reverb Parameter 9 LSB

2 00 - 7F Reverb Parameter 10 MSB

"

00 - 7F Reverb Parameter 10 LSB
1 00 - 7F Reverb Return 40
1 01 - 7F Reverb Pan

Refer to Effect Parameter List

"
"
"
"
"
"
"
"
"
"

-∞dB...0dB...+6dB(0...96...127)
L63...C...R63 40

TOTAL SIZE =

24 18 (HEX)

2 00 - 7F Chorus Type MSB Refer to Effect Parameter List

00 - 7F Chorus Type LSB
2 00 - 7F Chorus Parameter 1 MSB

"

00 - 7F Chorus Parameter 1 LSB
2 00 - 7F Chorus Parameter 2 MSB

"

00 - 7F Chorus Parameter 2 LSB
2 00 - 7F Chorus Parameter 3 MSB

"

00 - 7F Chorus Parameter 3 LSB
2 00 - 7F Chorus Parameter 4 MSB

"

00 - 7F Chorus Parameter 4 LSB
2 00 - 7F Chorus Parameter 5 MSB

"

00 - 7F Chorus Parameter 5 LSB
2 00 - 7F Chorus Parameter 6 MSB

"

00 - 7F Chorus Parameter 6 LSB
2 00 - 7F Chorus Parameter 7 MSB

"

00 - 7F Chorus Parameter 7 LSB
2 00 - 7F Chorus Parameter 8 MSB

"

00 - 7F Chorus Parameter 8 LSB
2 00 - 7F Chorus Parameter 9 MSB

"

00 - 7F Chorus Parameter 9 LSB
2 00 - 7F Chorus Parameter 10 MSB

"

00 - 7F Chorus Parameter 10 LSB
1 00 - 7F Chorus Return -

∞dB...0dB...+6dB(0...96...127)

1 01 - 7F Chorus Pan L63...C...R63
1 00 - 7F Send Chorus To Reverb -

∞dB...0dB(0...127)

0500

Depends On Effect Type

"
"
"
"
"
"
"
"
"

40
40
00

TOTAL SIZE =

25 19 (HEX)

40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40

40

40

40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40

40
40
40
40
40
40
40
40
40
40
40
40
40

40

40

40

40

40

40

40

40

40

40

40

40
40

40

40

40

40

40

40

40

40

40

40

40

40
40
40

70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70

70

70

70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70

00
00
00
00
00
00
00
00
00
00
00
00
00

01

01

01

01

01

01

01

01

01

01

01

01
01

02

02

02

02

02

02

02

02

02

02

02

02
02
02

00
01
02
03
04
05
06
07
08
09
0A
0B
0C
0D
0E
0F
10
11
12
13
14
15
16
17
18
19
1A
1B

1D

1F

21
22
23
24
25
26
27
28
29
2A
2B
2C
2D
2E
2F
30
31
32
33
34
35
36
37

00
01
02
03
04
05
06
07
08
09
0A
0B
0C

00

02

04

06

08

0A

0C

0E

10

12

14

16
17

00

02

04

06

08

0A

0C

0E

10

12

14

16
17
18

Address

Size Data Range(HEX)

Prameter Name Description

Default(HEX)

Notes

2 00 - 7F Insertion-1 Type MSB Refer to Effect Parameter List 0000

Depends On Effect Type

00 - 7F Insertion-1 Type LSB

2 00 - 7F Insertion-1 Parameter1 MSB

"

00 - 7F Insertion-1 Parameter1 LSB

2 00 - 7F Insertion-1 Parameter2 MSB

""

00 - 7F Insertion-1 Parameter2 LSB

2 00 - 7F Insertion-1 Parameter3 MSB

""

00 - 7F Insertion-1 Parameter3 LSB

2 00 - 7F Insertion-1 Parameter4 MSB

""

00 - 7F Insertion-1 Parameter4 LSB

2 00 - 7F Insertion-1 Parameter5 MSB

""

00 - 7F Insertion-1 Parameter5 LSB

2 00 - 7F Insertion-1 Parameter6 MSB

""

00 - 7F Insertion-1 Parameter6 LSB

2 00 - 7F Insertion-1 Parameter7 MSB

""

00 - 7F Insertion-1 Parameter7 LSB

2 00 - 7F Insertion-1 Parameter8 MSB

""

00 - 7F Insertion-1 Parameter8 LSB

2 00 - 7F Insertion-1 Parameter9 MSB

""

00 - 7F Insertion-1 Parameter9 LSB

2 00 - 7F Insertion-1 Parameter10 MSB

""

00 - 7F Insertion-1 Parameter10 LSB

TOTAL SIZE =

22 16 (HEX)

2 00 - 7F Insertion-2 Type MSB Refer to Effect Parameter List 0000

Depends On Effect Type

00 - 7F Insertion-2 Type LSB

2 00 - 7F Insertion-2 Parameter 1 MSB

"

00 - 7F Insertion-2 Parameter 1 LSB

2 00 - 7F Insertion-2 Parameter 2 MSB

""

00 - 7F Insertion-2 Parameter 2 LSB

2 00 - 7F Insertion-2 Parameter 3 MSB

""

00 - 7F Insertion-2 Parameter 3 LSB

2 00 - 7F Insertion-2 Parameter 4 MSB

""

00 - 7F Insertion-2 Parameter 4 LSB

2 00 - 7F Insertion-2 Parameter 5 MSB

""

00 - 7F Insertion-2 Parameter 5 LSB

2 00 - 7F Insertion-2 Parameter 6 MSB

""

00 - 7F Insertion-2 Parameter 6 LSB

2 00 - 7F Insertion-2 Parameter 7 MSB

""

00 - 7F Insertion-2 Parameter 7 LSB

2 00 - 7F Insertion-2 Parameter 8 MSB

""

00 - 7F Insertion-2 Parameter 8 LSB

2 00 - 7F Insertion-2 Parameter 9 MSB

""

00 - 7F Insertion-2 Parameter 9 LSB

2 00 - 7F Insertion-2 Parameter 10 MSB

""

00 - 7F Insertion-2 Parameter 10 LSB

2 00 - 7F Insertion-2 Parameter 11 MSB

""

00 - 7F Insertion-2 Parameter 11 LSB

2 00 - 7F Insertion-2 Parameter 12 MSB

""

00 - 7F Insertion-2 Parameter 12 LSB

2 00 - 7F Insertion-2 Parameter 13 MSB

""

00 - 7F Insertion-2 Parameter 13 LSB

2 00 - 7F Insertion-2 Parameter 14 MSB

""

00 - 7F Insertion-2 Parameter 14 LSB

2 00 - 7F Insertion-2 Parameter 15 MSB

""

00 - 7F Insertion-2 Parameter 15 LSB

2 00 - 7F Insertion-2 Parameter 16 MSB

""

00 - 7F Insertion-2 Parameter 16 LSB

TOTAL SIZE =

34 22 (HEX)

1 00 - 09 Controller Set1 Source PB, MW, ---, AT, FC, FS, RB, BC, KN1, KN2 00
2 00 Controller Set1 Destination MSB 0 - 61 00

00 - 3D Controller Set1 Destination LSB

1 00 - 7F Controller Set1 Depth -64 - +63 40
1 00 - 0F Controller Set1 Element Switch BIT0:EL1, BIT1:EL2, BIT2:EL3, BIT3:EL4 00
1 00 - 09 Controller Set2 Source PB, MW, ---, AT, FC, FS, RB, BC, KN1, KN2 00
2 00 Controller Set2 Destination MSB 0 - 61 00

00 - 3D Controller Set2 Destination LSB

1 00 - 7F Controller Set2 Depth -64 - +63 40
1 00 - 0F Controller Set2 Element Switch BIT0:EL1, BIT1:EL2, BIT2:EL3, BIT3:EL4 00
1 00 - 09 Controller Set3 Source PB, MW, ---, AT, FC, FS, RB, BC, KN1, KN2 00
2 00 Controller Set3 Destination MSB 0 - 61 00

00 - 3D Controller Set3 Destination LSB

1 00 - 7F Controller Set3 Depth -64 - +63 40
1 00 - 0F Controller Set3 Element Switch BIT0:EL1, BIT1:EL2, BIT2:EL3, BIT3:EL4 00
1 00 - 09 Controller Set4 Source PB, MW, ---, AT, FC, FS, RB, BC, KN1, KN2 00
2 00 Controller Set4 Destination MSB 0 - 61 00

00 - 3D Controller Set4 Destination LSB

1 00 - 7F Controller Set4 Depth -64 - +63 40
1 00 - 0F Controller Set4 Element Switch BIT0:EL1, BIT1:EL2, BIT2:EL3, BIT3:EL4 00
1 00 - 09 Controller Set5 Source PB, MW, ---, AT, FC, FS, RB, BC, KN1, KN2 00
2 00 Controller Set5 Destination MSB 0 - 61 00

00 - 3D Controller Set5 Destination LSB

1 00 - 7F Controller Set5 Depth -64 - +63 40
1 00 - 0F Controller Set5 Element Switch BIT0:EL1, BIT1:EL2, BIT2:EL3, BIT3:EL4 00
1 00 - 09 Controller Set6 Source PB, MW, ---, AT, FC, FS, RB, BC, KN1, KN2 00
2 00 Controller Set6 Destination MSB 0 - 61 00

00 - 3D Controller Set6 Destination LSB

1 00 - 7F Controller Set6 Depth -64 - +63 40
1 00 - 0F Controller Set6 Element Switch BIT0:EL1, BIT1:EL2, BIT2:EL3, BIT3:EL4 00

TOTAL SIZE =

30 1E (HEX)

1

00 - 05 LFO Phase 0,90,120,180,240,270

1

00 - 0B LFO Wave tri,tri+,sawup,sawdwn,squ1/4,squ1/3,squ,

squ2/3,squ3/4,trpzd,S/H1,S/H2

1 00 - 50 LFO Speed 0 - 63,16th

---4thx8
1 00 - 7F LFO Delay Time 0 - 127
1 00 - 7F LFO Fade In Time 0 - 127
1 00 - 7F LFO Hold Time 0 - 127
1 00 - 7F LFO Fade Out Time 0 - 127
1 00 - 02 LFO Key On Reset off,each-on,1st-on
1 00 - 05 LFO Box1 Destination

AMD, PMD, FMD, RESO, PAN, ELEMENT LFO SPEED

1 00 - 7F LFO Box1 Depth 0 - 127
1 00 - 0F LFO Box1 Element Switch BIT0:EL1, BIT1:EL2, BIT2:EL3, BIT3:EL4
1 00 - 05 LFO Box2 Destination

AMD, PMD, FMD, RESO, PAN, ELEMENT LFO SPEED

1 00 - 7F LFO Box2 Depth 0 - 127

40

40

40

40

40

40

40

40

40

40

40

40

40

40

40

40

40

40

40

40

40

40

40

40

40

40

40

40

40
40

40
40
40
40

40
40
40
40

40
40
40
40

40
40
40
40

40
40
40
40

40
40

40
40

40
40
40
40
40
40
40
40
40
40
40
40

03

03

03

03

03

03

03

03

03

03

03

04

04

04

04

04

04

04

04

04

04

04

04

04

04

04

04

04

05
05

05
05
05
05

05
05
05
05

05
05
05
05

05
05
05
05

05
05
05
05

05
05

06
06

06
06
06
06
06
06
06
06
06
06
06
06

00

02

04

06

08

0A

0C

0E

10

12

14

00

02

04

06

08

0A

0C

0E

10

12

14

16

18

1A

1C

1E

20

00
01

03
04
05
06

08
09
0A
0B

0D
0E
0F
10

12
13
14
15

17
18
19
1A

1C
1D

00
01

02
03
04
05
06
07
08
09
0A
0B
0C
0D

1 00 - 0F LFO Box2 Element Switch BIT0:EL1, BIT1:EL2, BIT2:EL3, BIT3:EL4

TOTAL SIZE =

14

0E (HEX)

Address

00
00

20
00
00
7F
00
00
00
00
00
00
00
00

Address

Size

Data Range(HEX)

Prameter Name Description Default(HEX) Notes

2 00 - 7F Wave Number LSB 1st bit6-0

→

bit13-7 0(off),1 - 479(CS6x,CS6R)

00 01

00 - 7F Wave Number MSB 2nd bit6-0

→

bit6-0 0(off),1 - 553(S80)
1 01 - 7F Pan L63 - C - R63 40
1 00 - 7F Random Pan Depth 0 - 127 00
1 00 - 7F Alternate Pan Depth L64 - 0 - R63 40
1 00 - 7F Scaling Pan Depth -64 - +63 40
1 00 - 7F Note Limit Low 0 - 127 00
1 00 - 7F Note Limit High 0 - 127 7F
1 01 - 7F Velocity Limit Low 1 - 127 01
1 01 - 7F Velocity Limit High 1 - 127 7F
1 00 - 7F Key On Delay 0 - 127 00
1 00 - 01 reserved 00
1 00 - 02 Insertion Effect Switch thru,ins1,ins2 00

TOTAL SIZE =

13 0D(HEX)

41

41
41
41
41
41
41
41
41
41
41
41

ee

ee
ee
ee
ee
ee
ee
ee
ee
ee
ee
ee

00

02
03
04
05
06
07
08
09
0A
0B
0C

MIDI PARAMETER CHANGE TABLE (NORMAL VOICE ELEMENT)

35

()

1 00 - 7F Element Level 0 - 127 64
1 00 - 7F Level Velocity Snesitivity -64 - +63 40
1 00 reserved 00
1 00 - 7F AEG Attack Time 0 - 127 00
1 00 - 7F AEG Decay1 Time 0 - 127 00
1 00 - 7F AEG Decay2 Time 0 - 127 00
1 00 - 7F AEG Release Time 0 - 127 40
1 00 - 7F AEG Init Level 0 - 127 00
1 00 reserved 00
1 00 - 7F AEG Decay1 Level 0 - 127 7F
1 00 - 7F AEG Sustain Level 0 - 127 7F
1 00 reserved 00
1 00 - 01 AEG Time Velocity Segment attack,all 01
1 00 - 7F AEG Time Velocity Sensitivity -64 - +63 40
1 00 - 7F Level Key Follow Sensitivity -200% - +200% 40
1 00 - 7C Level Scaling Break Point 1 C -2 - E8 24

BP1<BP2<BP3<BP4

1 01 - 7D Level Scaling Break Point 2 C#-2 - F8 30

BP1<BP2<BP3<BP4

1 02 - 7E Level Scaling Break Point 3 D -2 - F#8 3C

BP1<BP2<BP3<BP4

1 03 - 7F Level Scaling Break Point 4 D#-2 - G8 48

BP1<BP2<BP3<BP4

2 00 - 01 Level Scaling Offset 1 -128 - +127 01 00

00 - 7F

2 00 - 01 Level Scaling Offset 2 -128 - +127 01 00

00 - 7F

2 00 - 01 Level Scaling Offset 3 -128 - +127 01 00

00 - 7F

2 00 - 01 Level Scaling Offset 4 -128 - +127 01 00

00 - 7F
1 00 - 7F AEG Time Key Follow Sensitivity -64 - +63 40
1 00 - 7F AEG Time Key Follow Center Note C-2 - G8 3C

TOTAL SIZE =

29 1D (HEX)

1 10 - 70 Coarse Tune -48 - +48 40

01 1 00 - 7F Fine Tune -64 - +63 40
02 1 00 reserved 00
03 1 00 - 7F Random Pitch Depth 0 - 127 00
04 1 00 - 7F PEG Hold Time 0 - 127 00
05 1 00 - 7F PEG Attack Time 0 - 127 00
06 1 00 - 7F PEG Decay1 Time 0 - 127 00
07 1 00 - 7F PEG Decay2 Time 0 - 127 00
08 1 00 - 7F PEG Release Time 0 - 127 00
09 2 00 - 01 PEG Hold Level -128 - +127 (-4800 - +4800[cent]) 01 00

00 - 7F

0B 2 00 - 01 PEG Attack Level -128 - +127 (-4800 - +4800[cent]) 01 00

00 - 7F

0D 2 00 - 01 PEG Decay1 Level -128 - +127 (-4800 - +4800[cent]) 01 00

00 - 7F

0F 2 00 - 01 PEG Sustain Level -128 - +127 (-4800 - +4800[cent]) 01 00

00 - 7F

11 2 00 - 01 PEG Release Level -128 - +127 (-4800 - +4800[cent]) 01 00

00 - 7F

13 1 00 - 7F PEG Depth -64 - +63 40
14 1 00 - 01 PEG Time Velocity Segment attack,all 01
15 1 00 - 7F PEG Time Velocity Sensitivity -64 - +63 40
16 1 00 - 7F PEG Level Velocity Sensitivity -64 - +63 40
17 1 00 - 7F Pitch Key Follow Sensitivity -200% - +200% 60
18 1 00 - 7F Pitch Key Follow Center Note C-2 - G8 3C
19 1 00 - 7F PEG Time Key Follow Sensitivity -64 - +63 40
1A 1 00 - 7F PEG Time Key Follow Center Note C-2 - G8 3C

TOTAL SIZE =

27 1B (HEX)

1 00 - 0C Filter Type

LPF12+HPF,LPF24D,LPF24A,LPF18,LPF18s,
LPF6+HPF,HPF24D,HPF12,BPF6,BPF12D
BPFw,BEF6,THRU

02

BP1<BP2<BP3<BP4
BP1<BP2<BP3<BP4
BP1<BP2<BP3<BP4
BP1<BP2<BP3<BP4

2

1
1
1
2

1
2
2

1
1
1
1
1
2

2

2

2

2

1
1
1
1
1
1
1
1
1
2

2

2

2

1
1
1

00 - 01

00 - 7F

00 - 7F

00 - 1F

00 - 7F

00 - 01

00 - 7F

40

00 00
00 - 01
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 01
00 - 7F
00 - 01
00 - 7F
00 - 01
00 - 7F
00 - 01
00 - 7F
00 - 01
00 - 7F
00 - 7F
00 - 01
00 - 7F
00 - 7F
00 - 7F
00 - 7C
01 - 7D
02 - 7E
03 - 7F
00 - 01
00 - 7F
00 - 01
00 - 7F
00 - 01
00 - 7F
00 - 01
00 - 7F
00 - 7F
00 - 7F
00 - 7F

Filter Cutoff Frequency

Filter Cutoff Velocity Sensitivity
Filter Resonance/Width/Band
Filter Resonance Velocity Sensitivity
HPF Cutoff Frequency

reserved
reserved
Filter Gain

FEG Hold Time
FEG Attack Time
FEG Decay1 Time
FEG Decay2 Time
FEG Release Time
FEG Hold Level

FEG Attack Level

FEG Decay1 Level

FEG Sustain Level

FEG Release Level

FEG Depth
FEG Time Velocity Segment
FEG Time Velocity Sensitivity
FEG Level Velocity Sensitivity
Filter Cutoff Key Follow Sensitivity
Filter Cutoff Scaling Break Point 1
Filter Cutoff Scaling Break Point 2
Filter Cutoff Scaling Break Point 3
Filter Cutoff Scaling Break Point 4
Filter Cutoff Scaling Offset 1

Filter Cutoff Scaling Offset 2

Filter Cutoff Scaling Offset 3

Filter Cutoff Scaling Offset 4

HPF Cutoff Key Follow Sensitivity
FEG Time Key Follow Sensitivity
FEG Time Key Follow Center Note

0 - 255

-64 - +63
0 - 31

-64 - +63
0 - 255

0 - 255

0 - 127
0 - 127
0 - 127
0 - 127
0 - 127

-128 - +127 (-9600 - +9600[cent])

-128 - +127 (-9600 - +9600[cent])

-128 - +127 (-9600 - +9600[cent])

-128 - +127 (-9600 - +9600[cent])

-128 - +127 (-9600 - +9600[cent])

-64 - +63
attack,all

-64 - +63

-64 - +63

-200% - +200%
C -2 - E8
C#-2 - F8
D -2 - F#8
D#-2 - G8

-128 - +127

-128 - +127

-128 - +127

-128 - +127

-200% - +200%

-64 - +63
C-2 - G8

01 7F

40
04
40
00 00

40
00 00
01 7F

00
00
00
00
00
01 00

01 00

01 00

01 00

01 00

40
00
40
40
40
24
30
3C
48
01 00

01 00

01 00

01 00

40
40
3C

TOTAL SIZE =

48 30 (HEX)

1 00 - 05 EQ Type

EQ L/H, P.EQ, Boost6, Boost12, Boost18, thru

00
1 00 - 1F EQ Resonance 0 - 31 00
2 00 - 01 EQ 1 Frequency EQ L/H: 46-182, P.EQ: 83-251 00 53

00 - 7F
1 20 - 60 EQ 1 Gain -32 - +32 40
2 00 - 01 EQ 2 Frequency EQ L/H:131-241 01 71

00 - 7F
1 20 - 60 EQ 2 Gain -32 - +32 40

TOTAL SIZE =

8 08 (HEX)

1 00 - 02 LFO Wave saw,tri,squ 00
1 00 - 01 LFO Key On Sync off,on 00
1 00 - 3F LFO Speed 0 - 63 20
1 00 - 7F LFO AMod Depth 0 - 127 00
1 00 - 7F LFO PMod Depth 0 - 127 00

41
41
41
41
41
41
41
41
41
41
41
41
41
41
41
41
41
41
41
41

41

41

41

41
41

42
42
42
42
42
42
42
42
42
42

42

42

42

42

42
42
42
42
42
42
42
42

43

44
44
44

44
44

44

44
44
44
44
44
44

ee
ee
ee
ee
ee
ee
ee
ee
ee
ee
ee
ee
ee
ee
ee
ee
ee
ee
ee
ee

ee

ee

ee

ee
ee

ee
ee
ee
ee
ee
ee
ee
ee
ee
ee

ee

ee

ee

ee

ee
ee
ee
ee
ee
ee
ee
ee

ee

ee
ee
ee

ee
ee

ee

ee
ee
ee
ee
ee
ee

20
21
22
23
24
25
26
27
28
29
2A
2B
2C
2D
2E
2F
30
31
32
33

35

37

39

3B
3C

00

00

43

43
43
43
43

43
43
43

43
43
43
43
43
43

43

43

43

43

43
43
43
43
43
43
43
43
43
43

43

43

43

43
43
43

ee

ee
ee
ee
ee

ee
ee
ee

ee
ee
ee
ee
ee
ee

ee

ee

ee

ee

ee
ee
ee
ee
ee
ee
ee
ee
ee
ee

ee

ee

ee

ee
ee
ee

01

03
04
05
06

08
09
0B

0D
0E
0F
10
11
12

14

16

18

1A

1C
1D
1E
1F
20
21
22
23
24
25

27

29

2B

2D
2E
2F

00
01
02

04
05

07

40
41
42
43
44
45 1 00 - 7F LFO FMod Depth 0 - 127 00

TOTAL SIZE =

6 06 (HEX)

ee = Element Number (00..03: Element1..4)

Size

Data Range(HEX)

Prameter Name Description

Default(HEX)

NotesAddress

<Table 9>

MIDI PARAMETER CHANGE TABLE (DRUM VOICE COMMON)

Size Data Range(HEX)

Prameter Name Description

Default(HEX)

Notes

1 20 - 7E Voice Name1
1 20 - 7E Voice Name2
1 20 - 7E Voice Name3
1 20 - 7E Voice Name4
1 20 - 7E Voice Name5
1 20 - 7E Voice Name6
1 20 - 7E Voice Name7
1 20 - 7E Voice Name8
1 20 - 7E Voice Name9
1 20 - 7E Voice Name10
1 reserved
1 reserved
1 00 - 16 Voice Category
1 reserved
1 reserved
1 reserved
1 reserved
1 reserved
1 reserved
1 00 - 7F ARP Type
1 00 - 01 ARP Switch
1 00 - 02 ARP Hold
1 00 - 06 ARP Unit Multiply
1 00 - 7F ARP Note Limit Low
1 00 - 7F ARP Note Limit High
1 00 - 02 ARP Key Mode
1 00 - 01 ARP Vel Mode
2 0000 - 00C8 ARP Velocity Rate MSB

ARP Velocity Rate LSB

2 0000 - 00C8 ARP Gate Time Rate MSB

ARP Gate TIme Rate LSB

2 0019 - 012C ARP Tempo MSB

ARP Tempo LSB
1 01 - 7F QED Pan
1 reserved
1 00 - 7F QED Chorus Control
1 reserved
1 reserved
1 reserved 40
1 reserved
1 00 - 7F QED KnobA
1 00 - 7F QED KnobB
1 00 - 7F QED KnobC
1 00 - 7F QED/Scene 1 Knob1
1 00 - 7F QED/Scene 1 Knob2
1 00 - 7F QED/Scene 1 Cutoff Frequency
1 00 - 7F QED/Scene 1 Resonance
1 00 - 7F QED/Scene 1 Attack Time
1 00 - 7F QED/Scene 1 Decay Time
1 00 - 7F Scene 2 Knob1
1 00 - 7F Scene 2 Knob2
1 00 - 7F Scene 2 Cutoff Frequency
1 00 - 7F Scene 2 Resonance
1 00 - 7F Scene 2 Attack Time
1 00 - 7F Scene 2 Decay Time

46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46

46

46

46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46

00
01
02
03
04
05
06
07
08
09
0A
0B
0C
0D
0E
0F
10
11
12
13
14
15
16
17
18
19
1A
1B

1D

1F

21
22
23
24
25
26
27
28
29
2A
2B
2C
2D
2E
2F
30
31
32
33
34
35
36
37 1 00 - 7F Scene Control

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

00..22(--..Sq)

UpOct1 - GateCut3
off,on
sync-off,off,on
50%,66%,75%,100%,133%,150%,200%
C-2..G8
C-2..G8
sort,thru,direct
original,thru

0...200%

0...200%

25..300

L63..C..R63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

0..127

I
n
i
t

V
o
i
c
e

00(--)

57
00
01
03
00
7F
01
01
64

64

8A

40
40
40
40
40

00
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
00

TOTAL SIZE =

56 38 (HEX)

1 00 - 7F Volume
1 reserved
1 10 - 58 Pitch Bend Range Upper
1 10 - 58 Pitch Bend Range Lower
1 00 - 02 Insertion Connect Type
1 00 - 7F Reverb Send -

∞

46
46
40
40
46
46
46

00
00
00
00
00
00
00

00
01
02
03
04
05
06 1 00 - 7F Chorus Send -

∞

0 - 127

-48 - +24[semitones]

-48 - +24[semitones]
1|2(Pararel), 1->2, 2->1

dB... 0dB
dB... 0dB

7F
00
42
3E
00
28
00

TOTAL SIZE =

7 07 (HEX)

2 00 - 7F Reverb Type MSB 0100

Depends On Effect Type

00 - 7F Reverb Type LSB

2 00 - 7F Reverb Parameter 1 MSB

00 - 7F Reverb Parameter 1 LSB

2 00 - 7F Reverb Parameter 2 MSB

"

00 - 7F Reverb Parameter 2 LSB

2 00 - 7F Reverb Parameter 3 MSB

"

00 - 7F Reverb Parameter 3 LSB

2 00 - 7F Reverb Parameter 4 MSB

"

00 - 7F Reverb Parameter 4 LSB

2 00 - 7F Reverb Parameter 5 MSB

"

00 - 7F Reverb Parameter 5 LSB

2 00 - 7F Reverb Parameter 6 MSB

"

00 - 7F Reverb Parameter 6 LSB

2 00 - 7F Reverb Parameter 7 MSB

"

00 - 7F Reverb Parameter 7 LSB

2 00 - 7F Reverb Parameter 8 MSB

"

00 - 7F Reverb Parameter 8 LSB

2 00 - 7F Reverb Parameter 9 MSB

"

00 - 7F Reverb Parameter 9 LSB

2 00 - 7F Reverb Parameter 10 MSB

"

00 - 7F Reverb Parameter 10 LSB

1 00 - 7F Reverb Return 40

46

46

46

46

46

46

46

46

46

46

46

46
46

01

01

01

01

01

01

01

01

01

01

01

01
01

00

02

04

06

08

0A

0C

0E

10

12

14

16
17 1 01 - 7F Reverb Pan

Refer to Effect Parameter List

"
"
"
"
"
"
"
"
"
"

-∞ 0dB...+6dB(0...96...127)
L63...C...R63 40

TOTAL SIZE =

24 18 (HEX)

2 00 - 7F Chorus Type MSB Refer to Effect Parameter List 0500

Depends On Effect Type

00 - 7F Chorus Type LSB

2 00 - 7F Chorus Parameter 1 MSB

"

00 - 7F Chorus Parameter 1 LSB

2 00 - 7F Chorus Parameter 2 MSB

""

00 - 7F Chorus Parameter 2 LSB

2 00 - 7F Chorus Parameter 3 MSB

""

00 - 7F Chorus Parameter 3 LSB

2 00 - 7F Chorus Parameter 4 MSB

""

00 - 7F Chorus Parameter 4 LSB

2 00 - 7F Chorus Parameter 5 MSB

""

00 - 7F Chorus Parameter 5 LSB

2 00 - 7F Chorus Parameter 6 MSB

""

00 - 7F Chorus Parameter 6 LSB

2 00 - 7F Chorus Parameter 7 MSB

""

00 - 7F Chorus Parameter 7 LSB

2 00 - 7F Chorus Parameter 8 MSB

""

00 - 7F Chorus Parameter 8 LSB

2 00 - 7F Chorus Parameter 9 MSB

""

00 - 7F Chorus Parameter 9 LSB

2 00 - 7F Chorus Parameter 10 MSB

""

00 - 7F Chorus Parameter 10 LSB

1 00 - 7F Chorus Return --

∞ 0dB...+6dB(0...96...127) 40

1 01 - 7F Chorus Pan L63...C...R63 40

46

46

46

46

46

46

46

46

46

46

46

46
46
46

02

02

02

02

02

02

02

02

02

02

02

02
02
02

00

02

04

06

08

0A

0C

0E

10

12

14

16
17
18 1 00 - 7F Send Chorus To Reverb -0dB(0 127) 00

TOTAL SIZE =

25 19 (HEX)

Address

70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70

70

70

70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70

dB...

-

∞

dB...

dB...

36

Size Data Range(HEX) Prameter Name Description

Default(HEX)

Notes

2 00 - 7F Insertion-1 Type MSB Refere to Effect Parameter List

00 - 7F Insertion-1 Type LSB

2 00 - 7F Insertion-1 Parameter1 MSB

"

00 - 7F Insertion-1 Parameter1 LSB

2 00 - 7F Insertion-1 Parameter2 MSB

""

00 - 7F Insertion-1 Parameter2 LSB

2 00 - 7F Insertion-1 Parameter3 MSB

""

00 - 7F Insertion-1 Parameter3 LSB

2 00 - 7F Insertion-1 Parameter4 MSB

""

00 - 7F Insertion-1 Parameter4 LSB

2 00 - 7F Insertion-1 Parameter5 MSB

""

00 - 7F Insertion-1 Parameter5 LSB

2 00 - 7F Insertion-1 Parameter6 MSB

""

00 - 7F Insertion-1 Parameter6 LSB

2 00 - 7F Insertion-1 Parameter7 MSB

""

00 - 7F Insertion-1 Parameter7 LSB

2 00 - 7F Insertion-1 Parameter8 MSB

""

00 - 7F Insertion-1 Parameter8 LSB

2 00 - 7F Insertion-1 Parameter9 MSB

""

00 - 7F Insertion-1 Parameter9 LSB

46

46

46

46

46

46

46

46

46

46

46

03

03

03

03

03

03

03

03

03

03

03

00

02

04

06

08

0A

0C

0E

10

12

14 2 00 - 7F Insertion-1 Parameter10 MSB

""

00 - 7F Insertion-1 Parameter10 LSB

TOTAL SIZE =

22 16 (HEX)

00 2 00 - 7F Insertion-2 Type MSB

00 - 7F Insertion-2 Type LSB

2 00 - 7F Insertion-2 Parameter 1 MSB

00 - 7F Insertion-2 Parameter 1 LSB

2 00 - 7F Insertion-2 Parameter 2 MSB

00 - 7F Insertion-2 Parameter 2 LSB

2 00 - 7F Insertion-2 Parameter 3 MSB

00 - 7F Insertion-2 Parameter 3 LSB

2 00 - 7F Insertion-2 Parameter 4 MSB

00 - 7F Insertion-2 Parameter 4 LSB

2 00 - 7F Insertion-2 Parameter 5 MSB

00 - 7F Insertion-2 Parameter 5 LSB

2 00 - 7F Insertion-2 Parameter 6 MSB

00 - 7F Insertion-2 Parameter 6 LSB

2 00 - 7F Insertion-2 Parameter 7 MSB

00 - 7F Insertion-2 Parameter 7 LSB

2 00 - 7F Insertion-2 Parameter 8 MSB

00 - 7F Insertion-2 Parameter 8 LSB

2 00 - 7F Insertion-2 Parameter 9 MSB

00 - 7F Insertion-2 Parameter 9 LSB

2 00 - 7F Insertion-2 Parameter 10 MSB

00 - 7F Insertion-2 Parameter 10 LSB

2 00 - 7F Insertion-2 Parameter 11 MSB

00 - 7F Insertion-2 Parameter 11 LSB

2 00 - 7F Insertion-2 Parameter 12 MSB

00 - 7F Insertion-2 Parameter 12 LSB

2 00 - 7F Insertion-2 Parameter 13 MSB

00 - 7F Insertion-2 Parameter 13 LSB

2 00 - 7F Insertion-2 Parameter 14 MSB

00 - 7F Insertion-2 Parameter 14 LSB

2 00 - 7F Insertion-2 Parameter 15 MSB

00 - 7F Insertion-2 Parameter 15 LSB

46

46

46

46

46

46

46

46

46

46

46

46

46

46

46

46

46

04

04

04

04

04

04

04

04

04

04

04

04

04

04

04

04

04

02

04

06

08

0A

0C

0E

10

12

14

16

18

1A

1C

1E

20 2 00 - 7F Insertion-2 Parameter 16 MSB

00 - 7F Insertion-2 Parameter 16 LSB

TOTAL SIZE =

34 22 (HEX)

46 1 00 - 09 Controller Set1 Source PB, MW, ---, AT, FC, FS, RB, BC, KN1, KN2
46 2 00 Controller Set1 Destination MSB 0 - 29

00 - 1D Controller Set1 Destination LSB
46 1 00 - 7F Controller Set1 Depth -64 - +63
46 1 reserved
46 1 00 - 09 Controller Set2 Source PB, MW, ---, AT, FC, FS, RB, BC, KN1, KN2
46 2 00 Controller Set2 Destination MSB 0 - 29

00 - 1D Controller Set2 Destination LSB
46 1 00 - 7F Controller Set2 Depth -64 - +63
46 1 reserved
46 1 00 - 09 Controller Set3 Source PB, MW, ---, AT, FC, FS, RB, BC, KN1, KN2
46 2 00 Controller Set3 Destination MSB 0 - 29

00 - 1D Controller Set3 Destination LSB
46 1 00 - 7F Controller Set3 Depth -64 - +63
46 1 reserved
46 1 00 - 09 Controller Set4 Source PB, MW, ---, AT, FC, FS, RB, BC, KN1, KN2
46 2 00 Controller Set4 Destination MSB 0 - 29

00 - 1D Controller Set4 Destination LSB
46 1 00 - 7F Controller Set4 Depth -64 - +63
46 1 reserved
46 1 00 - 09 Controller Set5 Source PB, MW, ---, AT, FC, FS, RB, BC, KN1, KN2
46 2 00 Controller Set5 Destination MSB 0 - 29

00 - 1D Controller Set5 Destination LSB
46 1 00 - 7F Controller Set5 Depth -64 - +63
46 1 reserved
46 1 00 - 09 Controller Set6 Source PB, MW, ---, AT, FC, FS, RB, BC, KN1, KN2
46 2 00 Controller Set6 Destination MSB 0 - 29

00 - 1D Controller Set6 Destination LSB
46 1 00 - 7F Controller Set6 Depth -64 - +63
46

05
05

05
05
05
05

05
05
05
05

05
05
05
05

05
05
05
05

05
05
05
05

05
05

00
01

03
04
05
06

08
09
0A
0B

0D
0E
0F
10

12
13
14
15

17
18
19
1A

1C
1D 1 reserved

00
00

40
00
00
00

40
00
00
00

40
00
00
00

40
00
00
00

40
00
00
00

40

00

TOTAL SIZE =

30 1E (HEX)

Address

Refer to Effect Parameter List

"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"

Depends On Effect Type

0000

"
"
"
"
"
"
"
"
"
"
"
"
"
"
"

Depends On Effect Type

0000

MIDI PARAMETER CHANGE TABLE (DRUM VOICE KEY)

Address Size

Data Range(HEX)

Prameter Name

Default(HEX)

Notes

1 00 - 01 Element Assign 00 *1
1 00 - 03 Wave Type 00
1 00 reserved 00
1 00 - 01 Receive Note Off 01
1 00 - 01 Assign Mode 01 *1

*1

1 00 - 7F Alternate Group 00
2 00 - 7F Wave Number MSB

→

bit13-7 0(off),1 - 479(CS6x,CS6R)

00

00 - 7F Wave Number LSB

→

bit6-0 0(off),1 - 553(S80) 00

3 00 - 7F Voice Bank Number MSB 00 *1

00 - 7F Voice Bank Number LSB 00 *1

00 - 7F Voice Number 00 *1
1 01 - 7F Pan 40 *1
1 00 - 7F Random Pan Depth 00
1 00 - 7F Alternate Pan Depth 40
1 00 - 7F Reverb Send Level 28 *1
1 00 - 7F Chorus Send Level 00 *1
1 00 - 02 Insertion Effect Switch 00 *1

47
47
47
47
47
47
47

47

47
47
47
47
47
47
47

ee
ee
ee
ee
ee
ee
ee

ee

ee
ee
ee
ee
ee
ee
ee

00
01
02
03
04
05
06

08

0B
0C
0D
0E
0F
10
11 1 00 - 45 Output Select 00 *1

Description

off,on
wave , vce

off,on
single,multi
0:off, 1 - 127
1st bit6-0
2nd bit6-0
0 - 127
0 - 127
0 - 127
L63 - C - R63
0 - 127
L64 - 0 - R63
0 - 127
0 - 127
thru,ins1,ins2
0: L&R
8: ind1+2
64 - 69: ind1 - ind6

TOTAL SIZE =

18 12 (HEX)

1 00 - 7F Element Level 0 - 127 *1
1 00 - 7F Level Velocity Sensitivity -64 - +63
1 00 reserved
1 00 - 7F AEG Attack Time 0 - 127
1 00 - 7F AEG Decay1 Time 0 - 127
1 00 - 7F AEG Decay2 Time 0 - 126,hold
1 00 reserved
1 00 reserved
1 00 reserved
1 00 - 7F AEG Decay1 Level 0 - 127
1 00 reserved

47
47
47
47
47
47
47
47
47
47
47
47

ee
ee
ee
ee
ee
ee
ee
ee
ee
ee
ee
ee

20
21
22
23
24
25
26
27
28
29
2A
2B 1 00 reserved

64
40
00
00
00
7E
00
00
00
7F
00
00

TOTAL SIZE =

12 0C(HEX)

1 10 - 70 Coarse Tune -48 - +48 40 *1
1 00 - 7F Fine Tune -64 - +63 40 *1

48
48
48

ee
ee
ee

00
01
02 1 00 - 7F Pitch Velocity Sensitivity -64 - +63 40

TOTAL SIZE =

3 03 (HEX)

ee 1 00 reserved

00

ee 2 00 - 01 LPF Cutoff Frequency MSB 0 - 255

01 7F

00 - 7F LPF Cutoff Frequency LSB

ee 1 00 - 7F LPF Cutoff Velocity Sensitivity -64 - +63

40

ee 1 00 - 1F LPF Resonance 0 - 31 04
ee 1 40 reserved 40

49
49

49
49
49
49 ee

00
01

03
04
05
06 2 00 - 01 HPF Cutoff Frequency MSB 0 - 255 00 00

00 - 7F HPF Cutoff Frequency LSB

TOTAL SIZE =

8 08 (HEX)

1 00 - 05 EQ Type

EQ L/H, P.EQ, Boost6, Boost12, Boost18, thru

00
1 00 - 1F EQ Resonance 0 - 31 00
2 00 - 01 EQ 1 Frequency MSB EQ L/H: 46-182, P.EQ: 83-251 00 53

00 - 7F EQ 1 Frequency LSB
1 20 - 60 EQ 1 GAIN -32 - +32 40
2 00 - 01 EQ 2 Frequency MSB EQ L/H:131-241 01 71

00 - 7F EQ 2 Frequency LSB

4A
4A
4A

4A
4A

4A

ee
ee
ee

ee
ee

ee

00
01
02

04
05

07 1 20 - 60 EQ 2 GAIN -32 - +32 40

TOTAL SIZE =

8 08 (HEX)

ee = Element Number (00...48: C0 - C6)

*1: Only this parameter is abailable when Wave/Voice type

is set to “vce” in the OSC wave screen.

37

14
15
16
17
18
19
1A
1B

1D

1F

21
22
23
24
25
26
27
28
29
2A
2B
2C
2D
2E
2F
30
31
32
33
34
35
36
37

02

04

06

08

0A

0C

0E

10

12

14

16
17

<Table 10>

MIDI PARAMETER CHANGE TABLE (PLUGIN VOICE)

Size

Data Range(HEX)

Prameter Name Description Notes

4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C

4C

4C

4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C

70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70

70

70

70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70

00
01
02
03
04
05
06
07
08
09
0A
0B
0C
0D
0E
0F
10
11
12
13

1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2

2

2

1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1

20 - 7E
20 - 7E
20 - 7E
20 - 7E
20 - 7E
20 - 7E
20 - 7E
20 - 7E
20 - 7E
20 - 7E

00 - 16

00 - 7F

00 - 01

00 - 02

00 - 06

00 - 7F

00 - 7F

00 - 02

00 - 01

0000 - 00C8

0000 - 00C8

0019 - 012C

01 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

Voice Name1
Voice Name2
Voice Name3
Voice Name4
Voice Name5
Voice Name6
Voice Name7
Voice Name8
Voice Name9
Voice Name10
reserved
reserved
Voice Category
reserved
reserved
reserved
reserved
reserved
reserved
ARP Type
ARP Switch
ARP Hold
ARP Unit Multiply
ARP Note Limit Low
ARP Note Limit High
ARP Key Mode
ARP Vel Mode
ARP Velocity Rate MSB
ARP Velocity Rate LSB
ARP Gate Time Rate MSB
ARP Gate TIme Rate LSB
ARP Tempo MSB
ARP Tempo LSB
QED Pan
reserved
QED Chorus Control
QED Release Time
reserved
reserved
reserved
QED KnobA
QED KnobB
QED KnobC
QED/Scene 1 Knob1
QED/Scene 1 Knob2
QED/Scene 1 Cutoff Frequency
QED/Scene 1 Resonance
QED/Scene 1 Attack Time
QED/Scene 1 Decay Time
Scene 2 Knob1
Scene 2 Knob2
Scene 2 Cutoff Frequency
Scene 2 Resonance
Scene 2 Attack Time
Scene 2 Decay Time
Scene Control

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

32..126(ASCII)

00..22(--..Sq)

UpOct1 - GateCut3
off,on
sync-off,off,on
50%,66%,75%,100%,133%,150%,200%
C-2..G8
C-2..G8
sort,thru,direct
original,thru

0...200%

0...200%

25..300

L63..C..R63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63

0..127

Default(HEX)

-

-

-

-

-

-

-

-

-

-

00(--)

00
00
01
03
00
7F
00
00
64

64

8A

40
40
40
40
40
40
00
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
00

TOTAL SIZE = 56 38 (HEX)

-∞

4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C

00
00
00
00
00
00
00
00
00
00
00
00
00

00
01
02
03
04
05
06
07
08
09
0A
0B
0C

00 - 7F

00 - 01

00 - 01

28 - 58

00 - 01

00 - 7F

00 - 7F

00 - 7F -∞

TOTAL SIZE =13 0D(HEX)

Reverb Type MSB
Reverb Type LSB
Reverb Parameter 1 MSB
Reverb Parameter 1 LSB
Reverb Parameter 2 MSB
Reverb Parameter 2 LSB
Reverb Parameter 3 MSB
Reverb Parameter 3 LSB
Reverb Parameter 4 MSB
Reverb Parameter 4 LSB
Reverb Parameter 5 MSB
Reverb Parameter 5 LSB
Reverb Parameter 6 MSB
Reverb Parameter 6 LSB
Reverb Parameter 7 MSB
Reverb Parameter 7 LSB
Reverb Parameter 8 MSB
Reverb Parameter 8 LSB
Reverb Parameter 9 MSB
Reverb Parameter 9 LSB
Reverb Parameter 10 MSB
Reverb Parameter 10 LSB
Reverb Return

4C

4C

4C

4C

4C

4C

4C

4C

4C

4C

4C

4C
4C

01

01

01

01

01

01

01

01

01

01

01

01
01

00 2

2

2

2

2

2

2

2

2

2

2

1
1

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

00 - 7F

01 - 7F Reverb Pan

Refer to Effect Parameter List

"
"
"
"
"
"
"
"
"
"

-∞dB...0dB... +6dB(0...96...127)
L63...C...R63

TOTAL SIZE = 24 18 (HEX)

Chorus Type MSB
Chorus Type LSB
Chorus Parameter 1 MSB
Chorus Parameter 1 LSB
Chorus Parameter 2 MSB
Chorus Parameter 2 LSB
Chorus Parameter 3 MSB
Chorus Parameter 3 LSB
Chorus Parameter 4 MSB
Chorus Parameter 4 LSB
Chorus Parameter 5 MSB
Chorus Parameter 5 LSB
Chorus Parameter 6 MSB
Chorus Parameter 6 LSB
Chorus Parameter 7 MSB
Chorus Parameter 7 LSB
Chorus Parameter 8 MSB
Chorus Parameter 8 LSB
Chorus Parameter 9 MSB
Chorus Parameter 9 LSB

00

02

04

06

08

0A

0C

0E

10

12

14 Chorus Parameter 10 MSB

Chorus Parameter 10 LSB
16 Chorus Return -∞
17 Chorus Pan

4C

4C

4C

4C

4C

4C

4C

4C

4C

4C

4C

4C
4C
4C

02

02

02

02

02

02

02

02

02

02

02

02
02
02 18

2

2

2

2

2

2

2

2

2

2

2

1
1
1

00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
01 - 7F
00 - 7F Send Chorus To Reverb -∞

Refer to Effect Parameter List

"
"
"
"
"
"
"
"
"
"

dB...0dB...+6dB(0...96...127)

L63...C...R63

dB...0dB(0...

127)

TOTAL SIZE = 25 19 (HEX)

Address

1
1
1
1
1
1
1
1
1
1
1
1
1

Volume

reserved

Same Note Number Key On Assign

Mono/Poly Mode

reserved

Pitch Bend Range

reserved

reserved

Portamento Switch

Portamento Time

reserved

Reverb Send

Chorus Send

0 - 127

single,multi
mono,poly

-24 - +24[semitones]

off,on
0 - 127

dB... 0dB
dB... 0dB

64
01
01
01
00
42
3E
00
00
40
00
00
00

0100

init value for hall1

init value for hall1

init value for hall1

init value for hall1

init value for hall1

init value for hall1

init value for hall1

init value for hall1

init value for hall1

init value for hall1

40
40

0500

init value for chorus1

init value for chorus1

init value for chorus1

init value for chorus1

init value for chorus1

init value for chorus1

init value for chorus1

init value for chorus1

init value for chorus1

init value for chorus1

40
40
00

Size

Data Range(HEX)

Prameter Name Description Notes

Default(HEX)

4C

4C

4C

4C

4C

4C

4C

4C

4C

4C

4C

03

03

03

03

03

03

03

03

03

03

03

00

02

04

06

08

0A

0C

0E

10

12

14

2

2

2

2

2

2

2

2

2

2

2

Refer to Effect Parameter List

"
"
"
"
"
"
"
"
"
"

00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F

Insertion Type MSB
Insertion Type LSB
Insertion Parameter1 MSB
Insertion Parameter1 LSB
Insertion Parameter2 MSB
Insertion Parameter2 LSB
Insertion Parameter3 MSB
Insertion Parameter3 LSB
Insertion Parameter4 MSB
Insertion Parameter4 LSB
Insertion Parameter5 MSB
Insertion Parameter5 LSB
Insertion Parameter6 MSB
Insertion Parameter6 LSB
Insertion Parameter7 MSB
Insertion Parameter7 LSB
Insertion Parameter8 MSB
Insertion Parameter8 LSB
Insertion Parameter9 MSB
Insertion Parameter9 LSB
Insertion Parameter10 MSB
Insertion Parameter10 LSB

TOTAL SIZE =22 16 (HEX)

PB, MW, ---, AT, FC, FS, RB, BC, KN1, KN2
0 - 13

-64 - +63

PB, MW, ---, AT, FC, FS, RB, BC, KN1, KN2
0 - 13

00 - 09

00

00 - 0D

00 - 7F

00 - 09

00

00 - 0D

00 - 7F -64 - +63

4C
4C

4C
4C
4C
4C

4C
4C

00
01

03
04
05
06

08
09

1
2

1
1
1
2

1
1

Controller Set1 Source
Controller Set1 Destination MSB
Controller Set1 Destination LSB
Controller Set1 Depth
reserved
Controller Set2 Source
Controller Set2 Destination
Controller Set2 Destination MSB
Controller Set2 Depth
reserved

TOTAL SIZE =10 0A (HEX)

0

4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C
4C

10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10

00
01
02
03
04
05
06
07
08
09
0A
0B
0C
0D
0E
0F
10
11
12
13
14
15
16
17
18
19
1A
1B
1C
1D
1E
1F
20
21
22

1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1

00 - 7F
00 - 7F
00 - 7F
28 - 58
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F

40
00 - 7F
00 - 7F
00 - 7F
28 - 58
00 - 7F

40
00 - 7F
00 - 7F
00 - 7F
00 - 5F
00 - 7F

40
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
00 - 7F
04 - 28
1C - 3A
00 - 7F

Voice Bank MSB
Voice Bank LSB
Voice Number
Note Shift
Velocity Sense Depth
Velocity Sense Offset
(Vibrato Rate) LFO Speed
(Vibrato Depth) LFO Pitch Depth
(Vibrato Delay) LFO Delay
MW Filter Control
reserved
MW LFO Pitch Modulation Depth
MW LFO Filter Modulation Depth
MW LFO Amplitude Modulation Depth
CAT Pitch Control
CAT Filter Control
reserved
CAT LFO Pitch Modulation Depth
CAT LFO Filter Modulation Depth
CAT LFO Amplitude Modulation Depth
AC1 Controller Number
AC1 Filter Control
reserved
AC1 LFO Pitch Modulation Depth
AC1 LFO Filter Modulation Depth
AC1 LFO Amplitude Modulation Depth
Pitch EG Initial Level
Pitch EG Attack Time
Pitch EG Release Level
Pitch EG Release Time
EQ Low Gain
EQ High Gain
EQ Low Frequency
EQ High Frequency
HPF Cutoff Frequency

0..127

0..127

0..127

-24...0...+24[semitones]

0..127

0..127

-64..+63

-64..+63

-64..+63

-64..+63

0..127

0..127

0..127

-24..+24[semitones]

-64..+63

-64..+63

0..127

0..127

0..127

0..95

-64..+63

-64..+63

0..127

0..127

0..127

-64..+63

-64..+63

-64..+63

-64..+63

-64..+63(-12 - +12[dB])

-64..+63(-12 - +12[dB])

32...2.0k[Hz]

500...16.0k[Hz]

-64...0...+63

depends on plug-in board
depends on plug-in board
depends on plug-in board
40
40
40
40
40
40
40
40
0A
00
00
40
40
40
00
00
00
10
40
40
00
00
00
40
40
40
40
40
40
0C
36
40

TOTAL SIZE =35 23 (HEX)

64 00 - 7F depends on Plugin Board 004C4C202000

40 3 00 - 7F depends on plug-in board

00 - 7F depends on plug-in board
00 - 7F depends on plug-in board

43 1 00 - 7F

Plug-in Board Native Parameter
Plug-in Board Type MSB
Plug-in Board Type LSB
Plug-in Board Version Number
reserved 00

TOTAL SIZE =68 44 (HEX)

Address

0000

0000

0000

0000

0000

0000

0000

0000

0000

0000

0040

05
05

05
05
05
05

05
05

00
00
00
40
00
00
00
00
40
00

38

TransmittedFunction... Recognized Remarks

Basic
Channel

Note
Number : True voice

Velocity

After
Touch

Pitch Bend

Control
Change

Prog
Change : True #

System Exclusive

Common : Song Pos.
: Song Sel.
: Tune

System : Clock
Real Time : Commands

: All Sound Off
Aux :

Reset All Cntrls
: Local ON/OFF
Mes- : All Notes OFF
sages: Active Sense
: Reset

Notes:

Mode

Default
Changed

Note ON
Note OFF

Key's
Ch's

0,32

1,7,11

5,10
6,38

64
65

66
71-75
91,93
96-97

100-101

1-95

1 - 16
1 - 16

Ø 9nH,v=1-127
˛ 9nH,v=0

˛
Ø *3

Ø
Ø *3
Ø *3
˛
Ø

*3

Ø *3
˛
Ø

*3

Ø *3
˛
˛
Ø

Ø 0 - 127 *1

**************

˛
˛
˛

˛
˛

˛
˛
˛
˛
Ø
˛

*1 receive if switch is on.
*2 m is always treated as "1" regardless of its value.
*3 CS6x only.

3

˛

**************

0 - 127 *3
**************

Ø

Mode 1 : OMNI ON , POLY Mode 2 : OMNI ON ,MONO
Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF,MONO

Ø *3

1 - 16
1 - 16

Ø v=1-127
˛

˛
Ø *1

Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1
Ø *1

˛
˛
˛

Ø
˛

Ø (120,126,127)
Ø (121)
˛
Ø (123-125)
Ø
˛

1
1 - 4(m=1) *2

˛

0 - 127
0 - 127

Ø

Ø *1

Ø : Yes
˛ : No

Default
Messages
Altered

YAMAHA [ Music Synthesizer --- synth. part ] Date :13-JUL-1999

Model CS6x/CS6R MIDI Implementation Chart Version : 1.0

Memorised

Memorised

Bank Select

Data Entry
Sustain Sw
Portamento Sw
Sosutenuto
Sound Controller
Effect Depth
RPN Inc,Dec
RPN LSB,MSB
Assignable Cntrl

Transpose

Ø 0 - 127

0 - 127

39

TransmittedFunction... Recognized Remarks

Basic
Channel

Note
Number : True voice

Velocity

After
Touch

Pitch Bend

Control
Change

Prog
Change : True #

System Exclusive

Common : Song Pos.
: Song Sel.
: Tune

System : Clock
Real Time : Commands

: All Sound Off
Aux :

Reset All Cntrls
: Local ON/OFF
Mes- : All Notes OFF
sages: Active Sense
: Reset

Notes:

Mode

Default
Changed

Note ON
Note OFF

Key's
Ch's

0-121

1 - 16

˛

Ø

9nH,v=1-127

˛ 9nH,v=0

Ø
Ø

Ø

Ø 0 - 127

**************

˛
˛
˛

Ø

*2

Ø *2

Ø
Ø
Ø
Ø
Ø
˛

*1 if MIDI sync is midi
*2 if MIDI control in is on

˛
˛

**************

0 - 127
**************

Ø

Mode 1 : OMNI ON , POLY Mode 2 : OMNI ON ,MONO
Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF,MONO

Ø

˛
˛

˛
˛

˛
˛

˛

˛

˛
˛
˛

Ø

*1 *2

Ø *2

˛
˛
˛
˛
˛
˛

˛
˛
˛

˛
˛

˛

˛

Ø

: Yes

˛ : No

Default
Messages
Altered

YAMAHA [ Music Synthesizer --- seq. part ] Date :13-JUL-1999

Model CS6x/CS6R MIDI Implementation Chart Version : 1.0

Memorised

This document is printed on chlorine free (ECF) Paper.

M.D.G., EMI Division, Yamaha Corporation

© 1999 Yamaha Corporation

V484990 910MWCP2.3-01A0

Printed in Japan
