LIVESTOCK VENTILATION
X-47ATR
PROFESSIONAL AXIAL FAN
Center
Position
Downward
Position
Corner
Position
Focused
Airflow
SYSTEM. BUILT FOR HIGH
PERFORMANCE
XPOWER X-47ATR Axial Fans are perfect for drying, cooling and
temperature control. Keeping facilities comfortable for animals and
employees, not only reduce energy costs but also increase productivity
and growth. XPOWER X-47ATR is an efficient axial fan equipped with
technology that surpasses other axial fans of its kind in the market,
including a sealed motor design that helps our axial fans to become resist
to dust and moisture, and durable ABS housing with injection molding
technology that can endure harsh and continuous daily operation. At 2.8
amps draw, the XPOWER X-47ATR Axial Fan will efficiently provide the
proper air circulation required to be successful in the greenhouse,
livestock, and agricultural industries.
Why XPOWER products:
• Unit Comes Completely Assembled
• 18″ Diameter Professional Axial Fan
• 1/3 HP Sealed Motor with Dual Thermal Protection
• Low 2.8 Amps Draw with Built-in Power Outlets to Connect Multiple Units
• Rack / Stand Included for Full 360 Degree Positioning Functionality
• Specially Designed Air Fin Technology for Extreme Focused Airflow
• Precise Airflow with Variable Speed Control Switch
• Set and Forget 3-hour Timer
• ETL / CETL Safety Certified
• OSHA Safety Compliance
Model No X-47ATR
Volts/Hertz
20 Ft.
360° Rotation
Built-In Power Outlets
Yes
3 Hour Timer
Unit Dimensions
21.9" x 9.8" x 22.5"
Box Dimensions
22.6" x 23.2" x 11.4"
Palle t Qty 28 Units
Motor
Power
Rated Airflow
Speeds
Cord Length
Operating Position
PRODUCT FEATURESPRODUCT FEATURES
360° Rotation Built-In Power Outlets for Daisy ChainStackable
SPECIFICATIONS
115V / 60Hz
1/3 HP
2.8 Amps
3600 CFM
Variable Speed
(Rack Included)
Stackable
Unit We ight
Box W eight
Housing
Safety Certification ETL / CETL
Dual Thermal Protec�on
Yes
5 Units
22.2 Lbs
(LxWxH)
28.7 Lbs
(LxWxH)
ABS
Yes
240 CLARY AVENUE, SAN GABRIEL, CA 91776 ● www.XPOWER.com
PHONE: (626) 285-3301 ● FAX: (626) 285-3302 ● EMAIL: info@XPOWER.com
