X-600 / X-600A / X-630 / X-630H
P-600 / P-600A / P-630 / P-630H
P-630HC
com
11
XPOWER Air Movers are ETL/CETL certified and multifunctional Air Mover with the most efficient engineering design.
Features:
• Low amp draw with a rated volumn of 2400 to 2800 on High.
• Super quiet motor and super lightweight.
• Easy carrying handle
• Easy and quick to disassemble for thorough cleaning and service.
• Power cord lengths are 20’ for P models and 25’ for X models.
• Easy cord wrap on handle.
• Safety screens on open vents.
• 3 speed switch.
• Luggage handle and wheels for "H" series models.
• Carpet clamp for "C" series models.
• Timer and filter for "TF" series models.
• 3 air-flow positions for “H” series models (0°, 20° Kickstand, 90°).
• 4 air-flow positions for other models (0°, 20° Kickstand, 45°, 90°).
• Durable and rugged housing with 5 Years Warranty.
XPOWER Air Movers are intended to move air and to dry floors,
walls, furniture, etc. Durable and easy to operate with an effective
balance of static pressure and airflow, the units are suitable for
a variety of applications.
XPOWER Air Movers are shipped ready-to-use. Prior to
plugging the unit into the power source, inspect completely
for any shipping damage.
Plug the electrical cord into a standard grounded outlet.
Carefully place the Air Mover unit on a stable, flat dry surface.
The unit is capable to be used at 4 different angles to direct
air flow, except that the unit with handle is at 3 different
angles.
Turn the switch to desired speed, while making sure unit
operates normally.
To reduce the risk of injury, close supervision is necessary
when the unit is used near children. Do not allow children to
play with the unit.
Units without “H” can
be stacked (up to 4)
on their sides.
Units with “H” can be
stacked (up to 3) on
their sides.
1. To prevent electric shock, do not operate the unit in standing water. Never plug in or unplug
the unit with wet hands or while standing in water.
2. To avoid risk of injury, do not direct air flow at face or any part of body.
3. WARING: To reduce the risk of fire or electric shock, do not use the Air Mover with any
solid-state speed control device.
4. Use only with GFCI protected receptacles. Please contact a qualified electrician for verification
and / or installation of a GFCI receptacle if necessary.
5. Do not operate any Air Mover with a damaged cord or plug. Discard the unit or return it to an
authorized service facility for examination and/or repair.
6. It’s automatically operated device. To reduce the risk of injury disconnect from power supply
before servicing.
7. Do not run the power cord under carpeting. Do not cover the power cord with throw rugs,
runners, or similar coverings. Do not route the power cord under furniture or appliances. Arrange
the power cord away from traffic area and where it will not be tripped over.
8. Do not allow children to play with an Air Mover at any time.
9. Do not move or carry an Air Mover while unit is operating.
10.An electronic instruction manual can be obtained through manufacturer’s website www.xpower.com.
When not in use, unplug and store the Air Mover in a dry indoor place out of reach of children.
Air Mover
vibrates
Model
Volt/Frequency 115V, 60Hz 115V, 60Hz 115V, 60Hz 115V, 60Hz 115V, 60Hz
Power 1/3 hp 1/3 hp 1/2 hp 1/2 hp 1/2 hp
Amp 3.8 A 3.8 A 5 A 5 A
Weight 19.8 lbs/ 18.2 lbs 21.5 lbs/19.0 lbs 20.4 lbs/ 18.7 lbs
Speeds Three Three Three
Size(H x W x D) 15.9 x 15.7 x 16.3 in. 15.9 x 15.7 x 16.3 in. 15.9 x 15.7 x 16.3 in. 16.9 x 15.7 x 16.5 in. 16.9 x 15.7 x 16.5 in.
Daisy Chain N.A. Inlc. N.A. N.A. N.A.
Cord Length 25 ft./ 20ft. 25 ft. 25 ft./ 20ft. 25 ft./ 20ft. 20ft.
Overheating
Protecting
Rated Airflow
(on high)
Positions 4(0°, 20°, 45°, 90°) 4(0°, 20°, 45°, 90°) 4(0°, 20°, 45°, 90°) 3(0°, 20°, 90°)
Housing ABS/PP ABS/PP ABS/PP ABS/PP PP
Filter System Optional Optional Optional Optional Optional
Handle/Wheel
Carpet Clamp
Timer Optional Optional Optional Optional Optional
X-600/P-600 X-600A/P-600A X-630/P-630 X-630H/P-630H P-630HC
5A
23.6 lbs/ 21.6 lbs 23.9 lbs
Three Three
Thermally
Protected
2400 CFM 2400 CFM 2800 CFM 2800 CFM
Optional Optional Optional Optional Inlc.
Thermally
Protected
Thermally
Protected
Thermally
Protected
Thermally
Protected
2800 CFM
3(0°, 20°, 90°)
Inlc. Inlc.Optional Optional Optional
* All models are ETL/CETL certified
XPOWER LIMITED WARRANTY (USA)
XPOWER’s Limited Warranty covers the unit (excludes POWER CORD AND FILTER) from defects in
material and craftsmanship. The Warranty covers normal use for a term of one year from the original
date of purchase including parts, labor and one way shipping. Non-contiguous states must pay for
roundtrip freight. A purchase receipt must be provided.
Important!
This warranty does not cover or apply to defects due directly or indirectly to misuse, abuse, disassembly, alteration, corrosive chemicals, improper voltage, fire, flood, negligence, accident, improperly or
incorrectly performed maintenance or repair, or failure to perform necessary maintenance or repair, or if
the use of this product is not in compliance with the instructions and specifications for its use.
Service
For Warranty service and parts replacement (US users only), you must:
A. Call 1-855-855-8868 for a RMA (Return-Merchandise-Authorization) number.
B. Have original proof of purchase.
C. Use the original undamaged packaging or an industrial certified packaging method.
End user will be responsible to ship the unit (with RMA Number showing on the shipping label) to the
XPOWER Service Department. XPOWER to inspect, assess and advise the repairs needed and the
applicable cost, if any.
For users outside the US, please contact XPOWER Distributor in your country or region for Warranty
service and parts replacement.
- 7 -
600-17 Capacitor
Daisy Chain Specifications (For model X-600A/P-600A )
XPOWER Air Mover Model X-600A/P-600A are daisy chainable with a low 3.8 amp draw.
The 12-amp on-board circuit breaker will allow two (2) additional same units to
run on one circuit at the same time.
Note:
Air Mover has an on-board circuit breaker. If the auxiliary
outlet overloads, the circuit breaker will trip. If the breaker
trips, unplug the units and press the circuit breaker reset
buon.
Plug the units back into the power source and turn on the
switch.
Luggage Handle & Wheels (for “H” models)
XPOWER Air Mover “H” Model comes with built-in extendable luggage
handle and wheels for easy transportation and mobility.
Carpet clamp (for “C” models)
XPOWER Air Mover “C”Model comes with a carpet clamp
specifically for drying under the carpets.
(for “F” models)
A set of filters is availale for the XPOWER Air Mover which will help prevent small debris and dust
from entering the Air Mover. To clean the filters: remove filters from the unit and wash with warm
soapy water, rinse with clean water and let dry thoroughly before reinstalling.
Installation:
Filters snap into the air inlets.
Note:
Filter I is for the Motor side,
Filter II is for the Fan side.
Filter Removal:
Pull the filters out of the blower.
Note:
After cleaning make sure
the filters are dry before
installing.
10
Warranty Registration (for US user only)
For your product warranty, please complete and mail / fax this form to XPOWER MANUFACTURE, INC.
Address: 240 Clary Ave., San Gabriel, CA 91776. Tel: 1-855-855-8868
(For your convenience, register your product online at xpower.com)
Company Name / Contact Person / Title
State / Province
Zip Country
1-855-855-8868
