Page 1
HIGH STATIC BLOWER
OWNER'S MANUAL
MODEL: BR-6, BR-15, BR-25, BR-35,
BR-252A
XPOWER MANUFACTURE, INC.
240 Clary Avenue
San Gabriel, CA 91776, USA
Tel: 626-285-3301 Fax: 626-285-3302
www.xpower.com
(115V/60HZ)
PLEASE READ AND SAVE THESE INSTRUCTIONS
Page 2
TABLE OF CONTENTS Introducon
Introducon..................................................................................................................................... 3
Operaon Intruscons .................................................................................................................... 4
Safety Instrucons ................................................................................................................... 5, 6, 7
Maintenance Instrucons ............................................................................................................... 8
Troubleshoong .............................................................................................................................. 8
Specificaons................................................................................................................................... 9
Parts List ................................................................................................................................. 10, 11
More XPOWER Products.......................................................................................................... 12, 13
XPOWER Warranty / Service ......................................................................................................... 14
Warranty Registraon Form .................................................................................................... 15, 16
Thank you for purchasing an XPOWER High Stac Blower! With over 25 years of manufacturing
experience, XPOWER Manufacture, Inc. is bringing a series of products with the most advanced
technology in today's market. Your new XPOWER blower is engineered with top quality motors
and superb housing to provide strong and lasng performance. All our products have a fully
integrated design with state-of-the art miniaturizaon, allowing them to be light weight, quiet
and rugged withou
t sacrificing power or durability. Trust in XPOWER for all of your air blower
needs. Enjoy!
Features:
• For indoor and outdoor use
• Low amperage draw with high airflow
• Weatherproof design
• Perfect for holiday decoraons and small adversement
- 3 -
Page 3
Operation Instructions Safety Instructions
XPOWER High Static Blowers are intended to fill up inflatables, advertising displays, structures,
etc. Durable and easy to operate with an effective balance of static pressure and airflow, the
units are suitable for a variety of applications.
1. XPOWER High Static Blowers are shipped ready-to-use. Prior to plugging the unit into the
power source, inspect completely for any shipping damage.
2. With the unit unplugged, carefully place the unit on stable, flat, and dry surface.
3. Snugly attach your inflatable tube around the exhaust opening by using the velcro strap or
any other form of tightener.
4. Plug the cord into a grounded GFCI outlet only. Using a 3-prong to 2-prong adapter is strictly
prohibited.
5. Turn on the switch (except BR-6) to make sure the blower is operating correctly and the
inflatable functions properly. BR-6 will work automatically when connected to power source.
6. All blowers in operation must be supervised at all times.
1. Never place the XPOWER High Static Blowers in close proximity to any heat source or open flame. The
inflatable is flammable and could cause a fire and serious injury if not handled properly.
2. Do not operate the unit close to any dangerous areas such as explosive gases, flammables, heaters
and unventilated environments that may result in explosions or electrical hazards.
3. Do not operate the blower without the inflatable attached because the blower must have back
pressure in order to avoid any damage to the motor.
4. Keep children away from the unit at all times while in operation or plugged in. This product is not a toy
and should only be used for its intended purpose.
5. Do not put fingers or other objects in any part of the unit while it is in operation or plugged in.
6. To prevent electric shock, do not drop unit into water, never plug in or unplug the appliance with wet
hands or while standing in water.
7. Avoid sands, small rocks and other small objects being sucked in the blower.
8. To avoid risk of injury, do not direct stream of air at face or body.
9. If the power cord is damaged, it must be replaced by the XPOWER Manufacture, Inc. or an XPOWER
authorized service agent or a qualified electrician in order to avoid a hazard.
10. Do not operate in pooled or accumulated water to avoid electric shock.
(Continued at Page 6)
- 5 -- 4 -
Page 4
Safety Instrucons
Grounding Instrucons:
11. Outdoor use: while the blower is being operated outdoors, it must be plugged into a grounded GFCI
outlet only. The motor must be kept dry at all mes. If the unit becomes wet, turn the electricity off
and switch the blower in the off posion; thoroughly dry the unit before the next operaon.
12. Indoor use use only with a grounded plug.
13. Never use a cord that has cuts, breaks, or any other apparent damage as harmful, electrical shock may
occur.
14. Make sure the power source is sufficient to meet the requirements of the blower (see Specificaons).
15. Keep air intakes and exhausts clean at all me
s to avoid clogging or blocking which will cause electrical
hazards, overheang or fire.
16. To avoid objects from coming in contact with the blower fan or injury to persons, do not remove any
screens or safety guards from the unit. Damage in this manner will void your warranty.
17. To reduce the risk of fire or electric shock,do not use this product with any solid-state speed control device.
18. Always place the blower on a smooth and level surface for safe operaon.
19. Do not use the unit if defecve or damaged.
20. Unplug the unit before maintenance, cleaning or servicing.
21. The blower and inflatable in operaon must be supervised at all mes.
22. Any misuse or abuse of this product will void your warranty.
This product must be grounded. In the event of an electrical short circuit, grounding reduces the risk of
electric shock by proving an escape wire for electric current. This product is equipped with a cord having
a grounding wire with an appropriate grounding plug. The plug must be plugged into an outlet that is
properly installed and grounded in accordance with all local codes and ordinances.
WARNING - Improper installaon of the grounding plug is able to result in a risk of electric shock. When
repair or replacement of the cord or pl
ug is required, do not connect the grounding wire to either flat blade
pin. The wire coated and insulated in green is the the grounding wire. Check with a qualified electrician
when you don't completely understand or have a problem to follow this instrucon. Do not modify the
original plug. If it does not fit your outlet, have the proper outlet installed by a qualified electrician.
Grounding methods
This appliance is designed to use on a nominal
120V circuit, and has a grounding plug that
looks like the plug illustrated in Figure (A).
GROUNDING
PIN
METAL SCREW
COVER OF GROUNDED
OUTLET BOX
(A)
- 7 -- 6 -
Only connect the product to an outlet having
the same configuraon as the plug. Do no use
an adapter with this product.
Page 5
Maintenance Ins
Specifica
1. Always store the unit when not in use. Store indoors in a dry and cool environment free from
debris or obstru
ons that might affect the unit.
2. To keep the blower clean, use a dry or damp towel to wipe the surface of the blower.
3. Never clean the blower with water.
4. Unplug and store at a dry indoor place unreachable for children, when not in use.
Tr
PROBLEM POSSIBLE CAUSE SOLUTION
Unit is not plugged in or switch
Motor not running
is in "OFF" mode
Def ve power outlet Check outlet or use another outlet
Faulty switch/cord Replace switch or cord
Scraping noise from blower
Obstru
exhaust of blower
ons at the intake or
Weak airflow Obstructed vents/inlets Clean out vens/inlets
Make sure the unit is plugged in
and switch is in "ON" mode
Remove obstru
ons
Model BR-6 BR-15 BR-25 BR-35 BR-252A
Volt / Frequency 120V / 60Hz 120V / 60Hz 120V / 60Hz 120V / 60Hz 120V / 60Hz
Power 1/8 HP 1/4 HP 1/3 HP 1/2 HP 1 HP
Amp 0.8 A 3.2 A 4.8 A 5.5 A 9.8 A
Rated Airflow (On
High)
RPM 3200 3200 3300 3200 3200
Unit / Box Weight 4.0 lbs. / 4.6 lbs. 8.8 lbs. / 10.4 lbs.
Unit / Box Dimension
(L x W x H)
Power Cord (Length /
Size)
Thermal Prot
Housing PP PP PP PP PP
Safety C
on Single Dual Dual Dual Dual
fica on ETL / C-ETL ETL / C-ETL ETL / C-ETL ETL / C-ETL ETL / C-ETL
120 CFM 380 CFM 480 CFM 600 CFM 1000 CFM
10.4 lbs. / 12.3
lbs.
x 8.4" x
8" x 5.7" x 8.5" /
8.7" x 6.3" x 9.4"
6' / 18AWG 6' / 18AWG 6' / 18AWG 6' / 18AWG 6' / 18AWG
12.9" x 8" x 12.2"
/ 13.4" x 13" x 9.3"
13.6"
13.7" / 14.4" x
14.2" x 9.8"
12.8 lbs. / 15.0
lbs.
14.6" x 8.4" x
14.7" / 15.4" x
15.4" x 9.4"
16.2 lbs. / 18.6
lbs.
15.5" x 11.2" X
16.7" / 17" x 12.5"
x 17"
- 9 -- 8 -
Page 6
1
Front cover
2
Impeller
3
Boom cover
Motor
4
5
Sealing ring
6
Motor cover
BR-6 Parts List
7
Sealing pad
8
Capacitor
Wiring case
9
Base board
10
11
Power cord
BR-15/25/35/252A Parts List
1
Front cover
2
Impeller
3
Sha bushing
4
Boom cover
5
Motor
6
Rear cover
Parts may vary from different models. Contact XPOWER
for more information.
7
Switch cover
8
Switch sleeving
9
Switch
Power cord
10
11
Capacitor
12
Wiring case
- 10 -
- 11 -
Page 7
More XPOWER Products Available
Jan/San - Restoration & Mitigation Equipment:
Centrifugual Fans
Low Profile Air Movers
Scented Air Mover Fans
Airrow Pro Blower
Confined Space Fans
Axial Fans
High Temp Axial Fans
Air Scrubbers
Dehumidifiers
Misting Fans
Inflatable Advertising Equipment:
High Static Blowers
Centrifugal Blowers
Vertical Advertisement Blowers
Air Pumps
Professional & Retail Pet Grooming Equipment:
Professional Pet Grooming Dryers
DIY Pet Grooming Dryers
Air Care Equipment
Learn more at www.xpower.com or call 1-855-855-8868
- 13 -- 12 -
Page 8
XPOWER Limited Warranty (USA)
XPOWER's Limited Warranty covers the unit (excludes power cord, motor brushes, and any other consumable parts) from defects
in material and crasmanship. The Warranty covers normal use for a term of one year from the original date of purchase
including parts, labor, and one way shipping. Non-conguous states must pay for roundtrip freight. Warranty honored with
original proof of purchase only.
Important!
This Warranty does not cover or apply to defects directly or indirectly due to misuse, abuse, disassembly, alteraon, corrosive
chemicals, improper voltage, fire, flood, negligence, accident, improperly or incorrectly performed maintenance or repair, or
failure to perform necessary maintenance or repair, or if the use of this product is not in compliance with the instrucons and
specificaons for its use.
Service
For Warranty service and parts replacement (US customer only), you must:
A. Call 1-855-855-8868 for a RMA (Return-Merchandise-Authorizaon) number.
B. Have original proof of purchase provided.
C. Use the original undamaged packaging or an industrial cerfied packaging method.
End user will be responsible for shipping the unit (with RMA Number showing on the shipping label) to XPOWER Customer
Service Department. XPOWER will inspect, assess and advise the repairs needed and applicable cost,
For users outside US, please contact an XPOWER Distributor in your country or region for warranty service and parts replacement.
if any.
Warranty Registration
For your product warranty, please complete and mail / fax this form to XPOWER MANUFACTURE, INC.
Address: 240 Clary Ave., San Gabriel, CA 91776. Tel: 626-285-3301 Fax: 626-285-3302
(For your convenience, register your product online at xpower.com)
Company Name / Contact Person / Title
State / Province
Zip Country
(for US customer only)
- 14 -
