XPower FD-650DC User Manual

Drum Fan Owner's Manual
Model:
FD-650DC
(115V 60HZ)
Read and save these instructions before use
www.xpower.com | 1-(855)-855-8868 | info@xpower.com
Index: NA-1-A3
Edition: 1.3.Final
Safety Instructions
!
WARNING - READ AND SAVE THIS INSTRUCTIONS BEFORE USING THIS PRODUCT.
The user of electrical products may create hazards that include, but are not limited to injury, fire, electrical shock. Failure to follow these instructions may damage and/or impair its operation and void the warranty.
•Before operating, remove all packaging material and check for any damage that may have occurred during shipping or any missing items.
•Check household power supply to ensure it matches the appliance’s specification.
•DO NOT operate any fan with a damaged cord or plug. Discard fan or return it to an
authorized service facility for examination and/or repair.
•Use only on GFCI protected receptacles. Please contact a qualified electrician for verification and / or installation of a GFCI receptacle if necessary.
•DO NOT run cord under carpeting. DO NOT cover cord with throw rugs, runners, or similar coverings. DO NOT route cord under furniture or appliances. Arrange cord away from traffic area and where it will not be tripped over.
•Suitable for use with solid state speed control.
•DO NOT touch this appliance or the plug with wet hands or while standing in water.
•DO NOT operate the appliance in any pooled water.
•DO NOT use the product in areas where gasoline, paint or other flammable goods and
objects are used or stored.
•DO NOT insert or allow objects to enter any ventilation or exhaust opening as this may damage the appliance and void the warranty.
•DO NOT cover the air inlet or outlet on the appliance.
•DO NOT direct the air flow at human faces or bodies.
•DO NOT allow children to play around or with this appliance.
•AUTOMATICALLY OPERATED DEVICE – To reduce the risk of injury, disconnect from
power supply before servicing.
•Remove the power cord from the electrical receptacle by grasping and pulling on the power cord plug-end only, DO NOT pull the cord directly.
•DO NOT attempt to repair or adjust any electrical or mechanical functions of this appliance, as this may cause danger and void the warranty.
•If the appliance is damaged or it malfunctions, DO NOT continue to use it. Unplug the product from the electrical outlet. Refer to troubleshooting guide or contact XPOWER.
•Store in a dry area, away from exposure to sunlight, extreme temperature and humidity, or other extreme environments, when not in use.
•An electronic instruction manual can be obtained through manufacture’s website www. xpower.com.
Items Included
Parts Description
Air Mover Owner's Manual
XXX Manual De Usuario (página 10)
XXX Mode d'emploi (page 18)
Model / Modelo / Modèle:
P-80 Series, P-100 Series, P-200 Series
(115V 60HZ)
Read and save these instructions before use
Lea y guarde estas instrucciones antes de usar la unidad
Lire et conserver ces instructions avant utilisation
www.xpower.com | 1-(855)-8868 | info@xpower.com
Index: NA-1-A2
Edition: 1.0.Alpha
•Owner’s Manual x 1•Drum Fan x 1
9
(1) Rack Handle (2) Friction Pad (3) Screw M8X50 (4) Housing
1 2 3
4 5 6 7 8
10 11 12
(5) Housing Handle (6) Switch Plate (7) Rear Air Grille Cover (8) Motor
(9) Front Grille Cover (10) Fan (11) Rack (12) Power Cord
Drum Fan Introduction
•XPOWER Drum Fans are designed to create a cool zone for both indoor and outdoor with its huge amount of “natural feeling” airflow and efficient powerful brushless DC motor.
•It’s perfect for indoor and outdoor activities and events where efficient ventilation, cooling or even stage effects of wind are needed.
•The brushless DC motor technology allows efficient airflow output with less energy than conventional motors as well as a wide range airflow adjustment from 10 to 9500 CFM.
Operation Guide
SWITCH PLATE
MIN
OFF
MAX
ON
OFF
Speed Control
Power Control
Power Control
•Switch to “OFF” position to disconnect the drum fan from the power. Switch to “ON position to connect the drum fan from the power.
Speed Control
•Turn to “OFF” position to switch the drum fan OFF. Turn clock-wisely to any position between “MIN” and “MAX” to switch the drum fan ON.
•You can adjust to any desired speed variably.
IMPORTANT
•When finished, turn the speed control to “OFF” position to switch the drum fan OFF first, and then turn off the power control.
