X-Micro Tech BT400GII User Manual

X-Micro Bluetooth Headset

User Manual

1

X-Micro Bluetooth Headset

User Manual

Copyright

Copyright 2003 by X-Micro Technology Corp., All rights reserved. No part of
this publication may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any language or computer language, in any
form or by any means, electronic, mechanical, magnetic, optical, chemical,
manual or otherwise, without the prior written permission of X-Micro
Technology Corp.

Disclaimer

X-Micro Technology Corp., makes no representations or warranties, either
expressed or implied, with respect to the contents hereof and specifically
disclaims any warranties, merchantability or fitness for any particular purpose.
Any software described in this manual is sold or licensed "as is". Should the
programs prove defective following their purchase, the buyer (and not X-Micro
Technology Corp, its
necessary servicing, repair, and any incidental or consequential damages
resulting from any defect in the software. Further, X-Micro Technology Corp.,
reserves the right to revise this publication and to make changes from time to
time in the contents hereof without obligation to notify any person of such
revision or change.

distributor, or its dealer) assumes the entire cost of all

All brand and product names mentioned in this manual are trademarks and/or
registered trademarks of their respective holders

.

Introduction

The X-Micro Bluetooth Headset is a most desirable gadget to connect with
your Bluetooth mobile phone cordlessly.

By wearing X-Micro Bluetooth Headset, it becomes most effortless for making
a call or receiving a call without handling your mobile phone, moreover, makes
the communication naturally.

The imperceptible Bluetooth connection can be up to 10 meters and doesn’t
need line of sight and get rid of annoying cable for good.

The X-Micro Bluetooth Headset can be used with any mobile phone which
supports the Bluetooth

Headset profile

General Ratio

Carrier Frequency : 2.4 ~ 2.480GHz

Ratio Performance – Receiver

Rx sensitivity < -80 dBm

Ratio Performance:

CSR BC02 audio Class II Chipset

Spread Spectrum

FHSS (Frequency Hopping Spread Spectrum)

Antenna

Chip Antenna

Environmental

Operating Temperature 0~ +55

Dimensions & Weight

92mm(L) x 50mm(W) x 26mm(H); 26g

LED Indicator Status

Blue: Power on mode;
Red: Low power or being charged
Blue & Red: Pairing mode

Power Spec.

5V / 500mA

Battery

3.7V / 160mA

Standby time/ Talk time

100hours / 4hours

Overview of X-Micro Bluetooth Headset 

”Volume Up ” Button
”Volume Down ” Button
”Power / Talk / Pairing ” Button

Open / Close the microphone

The microphone can be closed when the
headset doesn’t use.

DC Power In
Earhook
Speaker
Microphone

Changing the Earhook

The X-Micro Bluetooth headset can be worn on either ear. Please carry out the
following steps to shift the ear hook for wearing it on the other ear.

1. Carefully remove the earhook from the
headset

2. Change the direction of the earhook as
shown in diagram 2.

3. Carefully replace the earhook on the
headset.
