OPTIMA RT9 6KVA / 10KVA
USER MANUAL
DOUBLE CONVERSION UPS
RACK / TOWER UPS
Technical information on this manual is property of XMART
totally or partially without written approval of XMART.
XMART can introduce modifications in their products or manuals without further notice. .
XMART is not responsible of mistakes or missing information in this manual.
XMART is not responsible for wrong use a third part can do of this information.
Trademarks and logos in this manual are property of their owners.
.
This manual Information cannot be copied or distributed
ENGLISH
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
À
__________________________________________________________________________________________________________________________
TABLE OF CONTENTS
1. SAFETY
2. AVAILABLE MODELS
3.- UPS INSTALLATION: SITE PLANING
SITE INSPECTION & INSTALLATION CONDITIONS
RACK UPS INSTALLATION
TOWER UPS INSTALLATION
EXTERNAL CIRCUIT BREAKERS SELECTION
WIRING SELECTION
4.- UPS INSTALLATION: SINGLE UPS - TERMINAL BLOCK
UPS AC LINES CONFIGURATION
AC TERMINAL BLOCKS
EXTERNAL BATTERY CONNECTION
5.- UPS INSTALLATION: PARALLEL UPS - TERMINAL BLOCK
GENERAL COMMENTS
UPS AC LINES CONNECTION
PARALLEL CONTROL CABLES CONNECTION
6.- START-UP: SINGLE UPS
INSPECTION BEFORE START-UP
SINGLE UPS - START UP PROCEDURE
7.- START-UP: PARALLEL UPS
REQUIREMENTS FOR PARALLEL UPS SYSTEMS
INSPECTION BEFORE START-UP
PARALLL UPS - START UP PROCEDURE
8.- OPERATION INTERFACE
FRONT P
9.- OPERATION: SINGLE UPS
NEL: PUSH BUTTONS / LEDS / LCD
10.- OPERATION: PARALLEL UPS
REMOVING UPS FROM PARALLEL SYSTEM
ADDING UPS TO PARALLEL SYSTEM
11.- UPS CONFIGURATION
12.- ERROR CODES, ALARMS & TROUBLESHOOTING
13.- TECHNICAL SPECIFICATIONS
14.- WARRANTY
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 2
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
1. GENERAL SAFETY INSTRUCTIONS .
WARNING: It is required to read and understand this manual. Follow all instructions given in this manual for starting up and operating
this product. Only qualified technician must start-up, operate and maintain this product. Keep manuals as a guide for future consults.
WARNING: This product operates with dangerous voltages. It must be installed, operated and maintained ONLY by qualified
technicians trained for this kind of products. Service personnel MUST know and understand very well all electric risks related to this
product. UPS manufacturer or distributor will never be responsible for any accident produced by lack of knowledge or negligent
practices at the moment of install, starting up or maintain this product.
UPS manufacturer or distributor is not liable for any damage that might rise from misusing this unit or defective installation.
WARNING: If you are not qualified technician do not try to install, operate or repair this product.
WARNING: Do not try to install, operate or repair this product if you are not accompanied by another qualified person able to offer
first aid support in case of emergency or accidents.
WARNING: Internal area of this product is locked by screws. Do not try to access inside the UPS unless you are a qualified
technician. UPS must be checked, repaired and maintained by qualified personnel only.
CAUTION!!: ELECTRIC SHOCK RISK
CAUTION: There are dangerous voltages in the UPS power outlets although the equipment is not plugged to power line.
CAUTION: Inside this equipment, due to internal batteries, there are ALWAYS dangerous voltages, thought the UPS is OFF and
unplugged of power line.
CAUTION: There are dangerous voltages in DC (Direct Current) Capacitors. Please Check Capacitor location in Figure 8.4.1. Wait at
least 10 minutes after turning off UPS before opening it to access inside.
DANGER: Power off UPS and unplugged it from AC Line before opening it to Access inside this unit.
CAUTION: Before starting the opening procedure, remove all jewelry and metallic objects such as: Rings, Watches, Bracelets, etc.,
because they could contact conductive parts and components inside the UPS and this might cause discharges and/or short circuits.
Make sure using tools properly isolated to avoid electrical risks.
Transportation and Storage: Warnings and Recommendations
WARNING: This UPS must be transported only in its original package to be properly protected
WARNING: This equipment must be storage in dry and ventilated site, in upright position.
WARNING: Before storage this UPS, batteries must be recharged for 8 to 10 hours
WARNING: During long term storage UPS must be recharged periodically according to this manual.
WARNING: EQUIPMENT DISPOSAL
Out of service units: It is strongly recommended to dispose this piece of equipment according to valid directives in your country. At
the moment of disposing all pieces need to be managed appropriately to avoid possible environmental damage or for some materials
to be recycled.
Batteries: Do not throw it to fire (risk of explosion). Do not open the batteries, there are dangerous liquids inside
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 3
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
WARNING: BATTERIES MAINTENANCE
• Batteries capacity, in general (of all kinds), decrease with time and use.
• Our products contain high quality batteries only.
• Batteries useful life in our UPS is between 4 and 5 years, considering environment temperature under 25 ºC and optimal
operational conditions. This time can be dramatically reduced by high temperature and other adverse operation condition.
• Batteries life expectancy may be also affected by other operation conditions such as electrical service quality as well as
number and kind of equipments connected to UPS
• Batteries should be periodically tested to check capacity and assure and appropriate back up.
SAFETY STANDARDS
SAFETY: IEC/EN 62040-1
EMI (Radiated): IEC/EN 62040-2 (Cat 3)
EMI (Conducted): IEC/EN 62040-2 (Cat 3)
EMS Power-Frequency Magnetic Field: IEC/EN 61000-4-8 (Level 4)
EMS Low Freq. Signals: IEC/EN 61000-2-2
EMS (ESD): IEC/EN 61000-4-2 (Level 4)
EMS (RS): IEC/EN 61000-4-3 (Level 3)
EMS (EFT): IEC/EN 61000-4-4 (Level 4)
EMS (SURGE): IEC/EN 61000-4-5 (Level 4)
EMS (CS): IEC/EN 61000-4-6 (Level 3)
This product has been designed to operate in industrial and commercial applications. If it is used in different application some considerations for
avoiding interferences could be necessary.
• To enlarge batteries life expectancy it is recommendable to fully discharge
UPS one every 2 to 3 months
• During UPS storage recharge batteries according to the following table:
Storage Temperature Recharging Frequency Recharging Time
-25°C a +30°C Every 4 months During 6 hours
+30°C a +45°C Every 2 months During 6 hours
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 4
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
2. AVAILABLE MODELS
- OPTIMA RT9 6K / 10K:
UPS including UPS Module and Batteries Module with DC connector for additional external batteries
Rack-Tower mounting
Input / Output: 1Ph 208/220/230/240Vac.
Components:
- OPTIMA RT9 ISOTX (Optional Accessory)
ISOTX (isolation transformer) module for offering an isolated dual output (120Vac x 2) for RT9 6K/10K UPS
Input: 1Ph 220Vac coming from UPS output
Output: 2 isolated 120Vac outputs.
Components:
- EXBATT RT10 - EXTERNAL BATTERIES (OPTIONAL MODULE)
This UPS can operate with the batteries module included with the UPS however if additional runtime is required additional external
batteries modules (EXBATT) can be connected to the UPS. NO additional accessories are necessary to make connection to additional
EXBATTmodules.
Módulo de Baterías Externas:
Model: EXBATT-OPT-RT10
Batteries: 20 pieces:1 group of 12V-9AH
DC Voltage: 240Vdc
1 module (3U) with UPS electronic set.
1 module (3U) with UPS batteries.
1 module (3U) with ISOTX
MODEL
BATTERY MODULE
CONNECTION TO EXBATT
ISOTX
OPT RT9 6K Y Y Optional
OPT RT9 10K Y Y Optional
Note: ISOTX is an optional accessory module (3U height)
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 5
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
RACK: RACK 6KEX / 10KEX
UPS MODULE
1. RS-232
2. USB
3. EPO” (Emergency Power Off):
Open = Power Output OFF / Close = Function disable
4. Share Current Port (for parallel function)
5. Parallel Port (for parallel function)
6. SNMP Intelligent Slot
7. Cooling Fans
8. External Bypass Switch port (MBS port)
9. DC connector for EXBATT
10. Main AC Input Breaker
11. Terminal Block Cover
UPS MODULE:
BATTERY MODULE
9. DC Connectors
15. Input DC Breaker
ISOTX MODULE
16. Output terminal block cover
17. AC Input (from UPS output)
BATTERY MODULE:
ISOTX MODULE:
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 6
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
3.- UPS INSTALLATION: SITE PLANING
SAFETY INSTRUCTIONS
WARNING: Before revising this section you must read and understand very well section 1 of this manual: “GENERAL SAFETY
INSTRUCTIONS”.
WARNINGS, RECOMMENDATIONS AND LIABILITY LIMITATION
REACH AND LIABILITY LIMITATION: The preparation of the site, wiring and all protection devices must be supplied by end user and
it will not be responsibility neither the UPS distributor nor the UPS technician in charge of the start-up.
The place will be conditioned be end user or electrical contractor and must fulfill with local normative and directives and UPS
technical requirements.
This manual describes minimal conditions and technical requirements with which the site must accomplish.
Directives and requirements described in this manual, do not pretend to substitute in any way local electrical directives or normative.
In some cases, local directives or regulations might be more exigent than UPS technical requirements described by this manual. In
that case end user electrical contractor must be sure to comply with all related local electrical regulations and directives.
WARNING: Power lines must be protected by protection devices against over current (breakers) or leak currents with capacity and
technology appropriate to effectively accomplish its function. Moreover, installation grounding must be correct.
WARNING: Install the UPS in well ventilated locations and leave room enough between UPS and close objects and structures
WARNING: Do not connect to UPS equipments or devices that exceed its capacity, this would overload the UPS.
WARNING: This product has been designed to be used indoors protected from water, direct sun light, dust and extreme temperature.
WARNING: Do not put any object on the UPS; do not apply any force over UPS. Do not cover UPS ventilation.
WARNING: This UPS must be connected to appropriate electrical service according to selected model. Technical specs sticker in the
UPS shows the UPS power ratings. DO NOT connect this UPS to any of its own power outlets, this could damage the unit
permanently.
WARNING: Connect only computer related equipments to this UPS. DO NOT connect medical equipments or critical availability
equipments to this UPS. DO NOT connect AC motor based equipments. DO NOT connect home appliances (ovens, vacuum cleaners,
refrigerators, etc.) to this UPS.
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 7
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
SITE INSPECTION AND INSTALLATION CONDITIONS
REGULATIONS AND LEGAL DIRECTIVES
It is necessary to check that installation site, wiring and power protection in the installation supplied by end user, fulfill technical
parameters required by UPS.
A particular installation might accomplish with UPS requirements but not with local directives and regulations.
The end user and/or electrical contractor will be responsible of watching for complying with electrical regulations and normative
during electrical installation managed by end user.
Inspection performed by installation technician is not intended to confirm regulations and directives accomplishing but only with
technical needs for optimal UPS operation.
SITE INSPECTION
• During transport of this UPS from a cold place to a warmer and more humid one, some condensation could be generated.
Leave the UPS for at least 2 hours to climate to new installation site.
• Do not install the UPS outdoors or near water sources nor in wet environment
• Do not install the UPS in sites exposed to sun light or heat sources. Temperature at operation site should never rise over 35
ºC. Batteries’ life shortens over 25 ºC.
• Installation site must be dry, fresh, free of dust, fibers and any other objects (conductors or not) suspended in the air that
could get into the UPS thru the ventilation system (Fan).
• Do not block UPS ventilations
UPS INPUT AND OUTPUT POWER LINES PROTECTION
AC LINES PROTECTIONS DEVICES:
All UPS Inputs and outputs must be protected by circuit breakers and current leak protections. Protection capacity and type must
fulfill local regulations as well as directives from this manual. Grounding must be according to local directives as well.
DC PROTECTIONS DEVICES:
For Ex models (with external batteries) there must be also DC Circuit Breakers between UPS and battery bank.
Some Models include a DC breaker on the rear panel for external battery pack protection; otherwise an external DC Circuit breaker
must be installed.
MATERIALS AND ELECTRICAL DEVICES
WARNING: Verify that all electrical lines involved in installation are open circuits and free of dangerous voltages before starting
inspection tasks. All switches related to these electrical lines must be in “OFF” position before starting UPS installation. After
disconnecting power from electrical lines involved in installation, check again with a digital voltmeter that are free of dangerous
voltages.
IMPORTANT: Warning label must be placed on primary involved circuit breakers to alert there are maintenance personnel
working on these circuits to avoid accidental actuation on involved breakers.
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 8
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
RACK UPS INSTALLATION
Rack UPS must be installed using L-Shape type guides for supporting UPS weight. Usually this kind of supports is provided with
rack cabinets. If not, UPS distributor can provide original telescopic guides as optional accessory.
Small black handles included with the UPS are only for locking purposes. UPS cannot be supported only by these handles.
- Figure 1: Rack cabinet must include L-shape guide to support UPS.
- Figure 2: UPS must be installed on L-shape guides.
- Figure 3: Handles included with UPS are only for locking UPS to the cabinet but not for supporting UPS weight.
- Figure 4: Original telescopic guides can be provided as optional accessory if it is required.
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 9
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
TOWER INSTALLATION
This UPS can be also installed as tower UPS as indicated below.
UPS + BATTERY MODULE = 2 MODULES
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 10
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
3 MODULES = UPS + BATTERY MODULE (EXBATT) + ISOTX
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 11
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
ELECTRICAL REQUIREMENTS (MANDATORY)
* All Power lines must be protected by magneto-thermal protection devices against over current (breakers) with capacity and
technology appropriate to effectively accomplish its function as indicated in this manual. Moreover, installation grounding must be
correct.
* This UPS must be connected to appropriate electrical service according to selected model. Technical specs sticker in the UPS
shows the UPS power ratings. DO NOT connect this UPS to any of its own power outlets, this could damage the unit permanently.
LEAK CURRENT PROTECTION
In many countries, now a day, it is legally required to install protections against current leakage to protect human beings in cases of
leaks o discharges to ground. It is responsibility of the end user and/or electrical contractor selecting and including these protection
devices in the electrical circuit of the UPS.
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 12
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
CIRCUIT BREAKERS AND WIRING SELECTION
Breakers and Gauge of the wires used in the installation must be rated to drive current values in Amps as indicated in below tables.
NOTE every country has its local electrical requirements and regulations. If local electrical regulations require higher rates than
suggested values in this section, please follow local regulations.
RT9 UPS
MODEL BREAKER & WIRING BREAKER & WIRING BREAKER & WIRING
6KVA
Salida 220Vac
10KVA
Salida 220Vac
ISOTX
6KVA con ISOTX
Output 110/220V
10KVA con ISOTX
Output 110/220V
Recommended cable size according to 1999 NEC based on 30ºC air ambient temperature for 4 copper cables in conduit.
WARNING:
The wire size is strongly affected by diverse factors such as: Operation temperature, wire length, type of wire and kind of
installation. Electrical contractor must assure an appropriate selection for wire and protection devices sizing for complying
with local regulations for electrical installations. Wiring colors must be selected according to local directives and
regulations
ADVERTENCIA:
output only can supply 50% of total UPS capacity. For example for 6KVA UPS, each separate output will supply 3KVA.
You can have one 120Vac output with 100% capacity by connecting 2 separate outputs in parallel.
Above wire gauge values are only a recommendation.
INPUT 220Vac 1Ph OUTPUT 220Vac 1Ph EXT. BATT (240Vdc)
AC Breaker: 40A (Curve D)
Max. Nominal Current: 36A
Wiring (min. size):
10AWG (6 mm2)
AC Breaker: 63A (Curve D)
Max. Nominal Current: 60A
Wiring (min. size):
8AWG (10 mm2)
UNIQUE OUTPUT: 1 x 120Vac
AC Breaker: 40A (Curve D)
Max. Nominal Current: 36A
Wiring (min. size):
10AWG (6 mm2)
AC Breaker: 63A (Curve D)
Max. Nominal Current: 60A
Wiring (min. size):
8AWG (10 mm2)
SEPARE OUTPUTS: 2 x 120Vac
(100% Watts)
Unique Output Capacity: 6000VA / 5400W
Output Voltage: 120Vac
AC Breaker: 80A (Curve D)
Max. Nominal Current: 70A
Wiring (min. size): 6AWG (16 mm2)
Unique Output Capacity: 10000VA / 9000W
Output Voltage: 120Vac
AC Breaker: 125A (Curve D)
Max. Nominal Current: 120A
Wiring (min. size): 3AWG (35 mm2)
ISOTX module offers 2 separate outputs 120Vac L-N each. When outputs are used separately, each
VA/W per Output: 3000VA / 2700W
Max. Nominal Current: 36A
Wiring (min. size): 10AWG (6 mm2)
VA/W per Output: 5000VA / 4500W
Max. Nominal Current: 60A
Wiring (min. size): 8AWG (10 mm2)
Breaker: 50A DC (Curve C)
Max. Nominal Current: 30A DC
Wiring (min. size):
10 AWG (6 mm2)
Breaker: 63A DC (Curve C)
Max. Nominal Current: 50A DC
Wiring (min. size):
8 AWG (10 mm2)
(50% Watts C/U)
Output Voltage: 120Vac
AC Breaker: 40A (Curve D)
Output Voltage: 120Vac
AC Breaker: 63A (Curve D)
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 13
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
4.- UPS INSTALLATION: SINGLE UPS - TERMINAL BLOCK
AC LINES CONNECTION PROCEDURE
UPS terminal block preparation
Remove cover of terminal block at the UPS rear panel in rear panel section of this manual
DO NOT use a wall power outlet to plug UPS to AC Line as usually ratings of this kind of outlets are not enough to power 6KVA UPS.
UPS Input wire must be connected by breaker protected line to electric panel board.
UPS Input and Output Connection
First, connect Ground wires. Ground wires must be FIRST to be connected and LAST to be disconnected.
Connect UPS input and output wires according to your UPS model or configuration as described in following figures:
RT9 6-10K TERMINAL BLOCK
• Make sure the UPS is Off before starting the installation.
• Remember to check all wires to be connected are not powered (including external batteries).
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 14
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
UPS TO ISOTX WIRING
ISOTX module is an optional accessory rack module that offers 2 isolated 120Vac outputs.
UPS AC output must be connected to ISOTX input as indicated.
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 15
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
ISOTX TERMINAL BLOCK
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 16
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
ISOTX OUTPUT CONFIGURATIONS
ISOTX outputs can be configured in 3 different manners as detailed in this section.
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 17
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
EXTERNAL BATTERY CABINETS – CONNECTION PROCEDURE
1.- Check all DC breakers are in OFF position
2.- Remove all DC connector covers in UPS and EXBATT cabinets
3.- Using appropriate cable (supplied with the EXBATT) connect UPS with EXBATT 1.
In case of more than 1 EXBATT connect EXBATT 1 with EXBATT 2 and so on until last EXBATT.
4.- Activate DC breakers one by one in EXBATT cabinets to connect EXBATT batteries with internal UPS Main batteries.
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 18
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
5.- UPS INSTALLATION: PARALLEL UPS - TERMINAL BLOCK .
GENERAL COMMENTS FOR PARALLEL SYSTEMS
6K y 10KVA models allow installation of up to 3 units in parallel.
Units to work in parallel must be connected as indicated in this section.
Parallel system must be configured and started up according to instructions given dedicated section of this
manual.
Any mistake in connection, configuration or starting up procedure could produce permanent damage UPS
PARALLEL UPS CONNECTION
UPS TERMINAL BLOCK PREPARATION
Remove cover of terminal block at the UPS rear panel.
DO NOT use a wall power outlet to plug UPS to AC Line as usually ratings of this kind of outlets are not enough to power 6KVA UPS.
UPS Input wire must be connected directly to electric panel board.
UPS INPUT AND OUTPUT CONNECTIONS
First, connect ground wires. Ground wires must be FIRST to be connected and LAST to be disconnected.
a) Grounding Wires: Connect AC ground of both UPS according to figures.
b) AC Input Wires: AC Input wires must come from individual electrical circuit breakers on electrical panel board before being
c) AC Output Wires: AC output wires must be connected directly to external circuit breakers of bigger capacity.
d) If UPS is EX model, external battery banks must be connected to dedicated connector located in rear panel of UPS.
e) Control Cables for Parallel Connection: Connect Parallel Cable and shared current according to figures.
Make sure the UPS is Off before starting the installation
Remember to check all wires to be connected (including external batteries)
are not powered before manipulating them.
connected to UPS terminal block.
WARNING – EXTERNAL BATTERIES:
If UPS to be connected in parallel have external batteries it is mandatory each UPS counts with its own battery pack.
Parallel connection cannot be performed if only one of two (or two or three) UPS have external batteries. Permanent
damages will be produced in UPS if this warning is not followed.
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 19
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
PARALLEL - UPS RT9 - AC LINES CONNECTION - 2 & 3 UPS
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 20
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
PARALLEL - USING ISOTX - AC LINES CONNECTION
** NOTE 1:
WARNING:
In parallel systems with ISOTX modules, to avoid permanent damage or incorrect operation, it is important to connect output
neutral between all UPS as indicated in above drawing.
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 21
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
PARALLEL UPS - CONTROL WIRES CONNECTION
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 22
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
6.- START-UP: SINGLE UPS
INSPECTION BEFORE START UP
1. Make sure all wires are tightly connected to terminal block. Any loose connection will produce overheating, failures and
damage to UPS.
2. Make sure all instructions of sections 3 and 4 have been performed correctly.
3. Put the terminal block cover back in its position to avoid access to wiring
4. Check EPO connections.
• EPO Port closed (Wired): EPO function disabled
• EPO port connected to an emergency switch: EPO function available by activation of Emergency Switch; which
must be “Normally Closed” type in order to guarantee that UPS will shut down when circuit opens.
5. Check Maintenance Bypass Switch (MBS) located in UPS rear panel is in UPS position and its cover is duly installed.
6. Make sure all external protection devices in input and output lines are in open (OFF) position.
SINGLE UPS - START UP PROCEDURE
1. Make sure all equipments connected to UPS are off
2. Power AC input at electrical panel board by setting input AC Lines Circuit Breaker to ON
3. Put Battery Bank breaker to ON (Only for Ex Models, If using external battery pack)
4. Put AC INPUT Breaker to ON in UPS rear panel.
5. LCD in front panel starts to show bypass mode. UPS Outputs are powered although UPS is off because it is on By-Pass
mode. At this moment output power is being supplied by AC Input Power Line.
6. Start up the UPS by pressing <ON> push button in front panel to access "TURN ON" menu. Confirm "YES" option.
7. Few seconds after, the UPS leaves By-Pass mode to enter in Normal Online Mode, also known as “AC Mode”
8. Switch external output breaker to ON position (not included with the UPS).
9. Power on sequentially each protected equipments. The front panel LCD should show the load increase as equipments start.
10. Once all equipments are on, the total power consumption (load) should not exceed UPS capacity.
11. At this moment UPS working under NORMAL AC-MODE and the system is supplied by UPS.
NOTE 1: If any error or warning message in indicated in LCD please revise Troubleshooting section of this manual.
NOTE 2: UPS batteries maybe are not fully charged. UPS could require about 4 to 6 hours to recharge batteries up to 100%
of their capacity.
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 23
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
7.- START-UP: PARALLEL UPS
REQUIREMENTS FOR PARALLEL SYSTEM
WARNING: Before starting up this parallel UPS system is mandatory to comply with all below requirements.
1.- Maximum quantity of UPS to be connected in parallel is 3. Do not try to connect more than 3 units in parallel.
2.- All UPS to be connected in parallel system must be same model (all 6K or all 10K) with same firmware version. Please ask your
distributor to confirm firmware is the same in case of doubts. UPS belonging to same manufacturing batch have same firmware
version.
3.- UPS configuration (configuration parameters of LCD menu) must be the same for all UPS.
4.- All MBS (Maintenance Bypass Switch) located in rear panels must be in "UPS" position and switch covers must be properly
installed.
5.- In case of using external battery packs, each UPS must has same external battery packs quantity and type.
6.- All control parallel cables (parallel cables and current share cables) must be properly connected in UPS rear panels as indicated
in section 5 of this manual.
7.- Make sure total available capacity (in Watts) of all UPS to be connected in parallel is higher than load to be connected to UPS
system. It is recommendable total UPS power is at least 25% higher to total load. If UPS system will work as n+1 redundant
system, make sure total UPS capacity after removing one UPS is higher than maximum load to be connected. If not remaining
UPS will not be able to support connected load when one of the units was removed.
INSPECTION BEFORE START UP
1. Make sure all wires are tightly connected to terminal block. Any loose connection will produce overheating, failures and
damage to UPS.
2. Make sure all instructions of sections 3 and 5 have been performed correctly.
3. Put the terminal block cover back in its position to avoid access to wiring
4. Check EPO connections.
• EPO Port closed (Wired): EPO function disabled
• EPO port connected to an emergency switch: EPO function available by activation of Emergency Switch; which must be
“Normally Closed” type in order to guarantee that UPS will shut down when circuit opens.
5. Check Maintenance Bypass Switch (MBS) located in UPS rear panel is in UPS position and its cover is duly installed.
6. Make sure all external protection devices in input and output lines are in open (OFF) position.
7. Check control parallel cables are connected according to section 5 of this manual.
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 24
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
START UP FOR PARALLEL UPS SYSTEM
WARNING: Make sure all requirements and previous inspection have been revised and complied before initiating start up
procedure. If not please do not try to continue with start-up procedure.
1.- Make sure all equipments to be protected and connected to UPS output are in OFF condition.
2.- Check AC input breaker located in each UPS rear panel is in OFF position.
3.- Power on main AC input in external electrical panel.
4.- If UPS are using external battery packs, set to ON all DC breakers to connect external DC packs to UPS.
5.- Power on UPS # 1: Set to "ON" AC input breaker located in rear panel of UPS No. 1. Wait until UPS No.1 completes autochecking and Bypass LED lights continuously.
6.- Power on UPS # 2: Set to "ON" AC input breaker located in rear panel of UPS No. 2. Wait until UPS No.2 completes autochecking and Bypass LED lights continuously.
7.-In case of having 3 UPS in the system, power on UPS # 3.
IMPORTANT: UPS must be powered on one by one. First UPS 1, then UPS 2 and finally UPS 3. If AC input breakers are activated
all at same time, an error message could be activated. If it occurs, reinitiate procedure sequentially. Error message must be
previously reset according to warning and error section in this manual
8.- When rear panel AC breaker is set to "ON", UPS recognize all other UPS previously powered ON in the parallel system and will
get its own parallel identification as Master, Slave1 and Slave2.
UPS 1 UPS 2 UPS 3
Bypass Mode Bypass Mode Bypass Mode
Parallel: Master Parallel: Slave1 Parallel: Slave2
IP: 208.0V / 50Hz IP: 208.0V / 50Hz IP: 208.0V / 50Hz
OP: 208.0V/50Hz OP: 208.0V/50Hz OP: 208.0V/50Hz
Batt: 273.0V/99% Batt: 273.0V/99% Batt: 273.0V/99%
Load: 0% Load: 0% Load: 0%
9.- At this moment all UPS are in bypass mode waiting for been turned on.
10.- Before turning on, configuration menu in each UPS LCD must be revised to select desired configuration.
It is mandatory to use same configuration in all configuration parameters for all UPS of the system.
11.- Once configuration has been selected and verified, all UPS can be started up by selecting "ON" push button in front panel.
Please press "ON" push button for each UPS and confirm all UPS change from BYPASS mode to LINE mode.
UPS 1 UPS 2 UPS 3
Line Mode Line Mode Line Mode
Parallel: Master Parallel: Slave1 Parallel: Slave2
IP: 208.0V / 50Hz IP: 208.0V / 50Hz IP: 208.0V / 50Hz
OP: 220.0V/50Hz OP: 220.0V/50Hz OP: 220.0V/50Hz
Batt: 273.0V/99% Batt: 273.0V/99% Batt: 273.0V/99%
Load: 0% Load: 0% Load: 0%
At this moment all UPS are in ONLINE mode. UPS output is generated by UPS inverter.
12.- Now we must measure output voltage in each UPS using a digital multi-meter. All output voltages must be similar. Maximum
acceptable deviation should be 2Vac or lower. Typically 1Vac.
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 25
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
** If deviation is higher than 2Vac, we suggest to adjust voltage output in UPS by SETTING / CALIBRATION / INVERTER section
of configuration menu.
Setting: Calibration:
Control Bypass Batt: 273.0 +0,0
Measurement ECO Inv: 220.0 +0,0
Information Output Chg: 273.0 +0,0
Setting Battery
Alarm Calibration
Others
13.- If AC output voltages are as expected, please set to "ON" external output breakers for all UPS progressively. Start with UPS
Nº 1, then UPS Nº2, etc. After that, all UPS outputs are connected in parallel.
14. Check to confirm there are no error or alarm messages on LCDs. At this moment all UPS are working in NORMAL Online
mode and connected in parallel.
15.- It is time to power on equipments connected to UPS output. Power on progressively one by one. Check on UPS LCDs how
power output rises meanwhile equipments are powered on.
** Once all output load is connected check power output is below 100%.
** At this moment, UPS parallel system is powering your system in NORMAL Online mode.
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 26
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
8.- OPERATION INTERFACE
UPS FRONT PANEL: PUSH BUTTON
ON / ENTER
ON : Goes directly to "TURN-ON" menu.
ENTER : It works as <ENTER> or confirmation key for screens options
OFF / ESCAPE
OFF : Goes directly to "TURN-OFF" menu.
ESCAPE : It works as <ESCAPE> key for screens options.
UP : It works as <UP> key when navigating through screens menu.
UP
DOWN : It works as <DOWN> key when moving through screens menu.
DOWN
LCD 90º TURNING : Rotates LCD 90º.
UP + DOWN
UPS FRONT PANEL: LED INDICATOR LIGHTS
There are 4 LED indication lights in front panel, located below LCD. These 4 LEDs describe UPS condition as follow:
MODE
UPS is in Auto-check mode during start-up.
BYPASS Mode
NORMAL Mode
BATTERY Mode
BATTERY TEST in progress
ECO Mode Activated
UPS in Failure
Bypass Line Battery Fault
● ● ● ●
● ○ ○ ○
○ ● ○ ○
○ ○ ● ○
○ ● ● ○
● ● ○ ○
○ ○ ○ ●
● LED = ON / ○LED = OFF
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 27
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
UPS FRONT PANEL: LCD
This UPS has a sophisticated LCD able to display all important information related to input line, UPS status and values, operation
mode and error and alarm messages. It is a powerful information tool to know what is happening at any moment.
LCD is also the configuration interface for all configurable parameters.
MAIN INTERFACE:
Line Mode
IP: 208.0V / 50Hz
OP: 220.0V/50Hz
Batt: 273.0V/99%
Load: 0%
Warning: XX
LCD MENU:
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 28
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
9.- OPERATION: SINGLE UPS
This is a True On Line Double Conversion UPS and it is designed to offer clean, bump-less and highest quality power to your
computer related equipments protecting also your valuable data. Power delivered by UPS is 100% sine wave as main line.
According to AC Line status the UPS may operate in following modes:
ONLINE NORMAL Mode
When UPS is turned off by selecting ON push button in front panel and AC Line is normal it enters into ONLINE NORMAL mode. Under
this mode UPS Inverter powers outputs and the energy is taken from DC voltage coming from AC/DC converter. Batteries are charged
by AC Line if required.
BATTERY Mode (Also known Inverter Mode)
Under ONLINE NORMAL mode when UPS detects a problem in AC input Line or black out it enters in battery mode. Under this mode
UPS takes energy from its batteries to power outputs. There are no transfers neither micro-cuts on UPS outputs as inverter was
already working, the only difference is that energy for outputs is now coming from batteries. Transfer time is actually Zero (0 ms).
UPS also can enter in battery mode when it is turned on without an acceptable AC input.
ECO Mode
There is an energy saving function that makes UPS to power its outputs with AC Line directly. If under this mode, UPS detects AC
input is out of acceptable range it enters into Normal Online mode.
If an AC failure occurs under ECO mode the UPS’s inverter starts working draining energy from batteries. There is a transfer time of 4
ms typical. This mode is configured and activated from LCD panel. There is specific input voltage range and input frequency range to
configure for ECO mode.
BYPASS Mode
Under BYPASS mode, UPS outputs are powered by AC Line. UPS is out of the circuit. This mode can be caused by operator when
OFF button is activated, but it may also happen automatically by UPS malfunction or overload detected at UPS outputs. If external
(optional) BYPASS module is installed, UPS goes to BYPASS mode when protection cover of the bypass switch is removed.
FREQUENCY CONVERSION Function
This UPS offers a very sophisticated function named frequency conversion (CF) that allows UPS to generate power output at
determined frequency value (50Hz or 60Hz) no matter input frequency value. UPs will be able to generate output at 50Hz even input
source is at 60Hz or generate 60Hz even if connected to 50Hz source.
This function can be configured and activated by LCD. Revise configuration section of this manual.
IMPORTANT NOTES:
1.- Under CF mode, UPS will disable BYPASS mode. Since UPS has been configured to generate output with frequency value different
to input frequency, BYPASS mode is disable to avoid a not acceptable frequency value at output.
2.- When CF function is activated, maximum power output is de-rated to 60% of maximum nominal capacity. For example, for a
10KVA (8KW) model, when CF is activated maximum output is decreased to 6KVA (4.8KW).
WARNING Mode
Under some situations UPS reports an alarm or warning message in the LCD and buzzer will be activated with intermittent beep.
Usually UPS keep working in online mode.
FAULT Mode
When important problem is detected inside or outside the UPS, it goes to fault mode reporting an error message on LCD and activating buzzer with a
continuous beep. Under this mode UPS usually goes to BYPASS mode. Fault LED turns on in red color when fault mode is adopted.
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 29
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
10.- OPERATION: PARALLEL UPS
UPS operation modes for UPS in parallel are basically same than described for single UPS.
However it is important to remark all UPS in parallel system must work under same mode at same time. Parallel function does not
allow different operation modes between UPS of the system.
Removing an UPS from a Parallel System
There are 2 procedures to isolate and remove one UPs from operative parallel system:
A) Total Power-Off: Powering off all UPS of the system. This is the less risky procedure.
B) Keeping Parallel system in ONLINE mode:
First check all below requirements are complied before trying to follow this procedure.
Requirements for removing one UPS in operative UPS:
1.- This operation must be performed only by qualified and trained personnel.
2.- This operation must be coordinated with the system administrator. System administrator must know about the related risks of this
procedure since the system could be shut down during operation because external reasons like:
- If during this operation occurs a failure in main AC line, battery backup of remaining UPS could not be enough to keep system
running before reconnecting removed unit.
- External breakers could be activated randomly during operation so system could be tripped.
3.- There must be a detailed plan to perform this procedure identifying all maintenance activities to be performed on removed unit
before reconnecting it.
4.- Remaining UPS must be able to support the power system after selected unit is removed.
5.- Each UPS must have their own external protections to allow total electrical isolation
6.- There must be enough physical room to allow comfortable access to all UPS of the system.
Note: if any of the above requirements cannot be complied, below procedure must not be performed.
In case all requirements can be complied proceed as follow:
1.- Power off selected UPS by OFF button in front panel.
Note: OFF button must be selected twice. If OFF is selected only one time, UPS will not respond. Once UPS is turned off it will shut
down its outputs but remaining LCD on. This UPS will not go to bypass mode since it is working in UPS system with other UPS
generating their output from their inverters. At this moment any failure in AC main line must be supported by operative UPS.
2.- Set AC input breaker located in rear panel of the selected UPS to OFF position.
3.- Set external output breakers of selected UPS to OFF position.
4.- Set external input breakers of selected UPS to OFF position.
5.- Once LCD is turned Off, in selected UPS to be isolated, disconnect control parallel cables (parallel cables and current share
cables) from its rear panel. Other operative UPS must keep their control parallel cables connected.
NOTE: If you disconnect parallel control cables in any of the operative UPS of the system, a communication problem will occur and
the parallel system will be shut down.
At this moment selected UPS is currently powered off and isolated so that it can be serviced or simply removed.
Adding an UPS to a Parallel System
• For adding a new UPS to an operating system, all UPS must be turned off and all equipments must be disconnected from
UPS outputs.
• Total UPS quantity must be 3 or lower.
• Firmware of all UPS must be compatible for allowing parallel functionality.
• New UPs must be configured with similar LCD configuration menu than current UPS of the system.
• Follow the procedure explained in Installation Section of this manual.
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 30
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
11.- UPS CONFIGUIRATION
MAIN INTERFACE SCREEN:
This is the first screen presented on LCD when UPS is powered on (without turning UPS on).
If front panel is not operated LCD will go to this screen after few seconds.
Bypass Mode
IP: 208.0V / 50Hz
OP: 208.0V/50Hz
Batt: 273.0V/99%
Load: 0%
From this main interface all others menu screens can be selected by UP / DOWN buttons in front panel according to section 8 of
this manual.
Configurable functions according to UPS mode
Not all functions are available in all operation modes. When functions is not available under current operation mode, related option will not be
presented on screen.
Code Description Bypass AC ECO CVCF Battery
Output Voltage
1
Output Frequency
2
Voltage Range for BYPASS
3
Frequency Range for BYPASS
4
ECO Mode: Enable and Disable
5
Voltage Range for ECO mode
6
Frequency Range ECO mode
7
BYPASS mode
8
Battery Backup Security Time
9
Programmable Output (note 1)
10
Programmable Output Settings (note 1)
11
NO-Battery startup function
11
13 Battery Voltage adjustment
14 Battery Charger Voltage adjustment
15 UPS output voltage adjustment ● ● ●
”●” Function available.
Battery
Test
●
●
●
●
●
●
●
● ●
● ● ● ● ● ●
● ● ● ● ● ●
● ● ● ● ● ●
● ● ● ● ● ●
● ● ● ● ● ●
● ● ● ● ● ●
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 31
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
Configuration menu functions and screens
Screens menu is divided in 5 different modules as follow:
F1. CONTROL
F2. MEASUREMENT
F3. INFORMATION
F4. SETTING
F5. ALARM
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 32
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
F1. CONTROL FUNCTIONS:
Control Line Mode
Turn On ?
--> Turn On IP: 208.0V / 50Hz
Batt Test --> Yes OP: 220.0V/50Hz
Mute No Batt: 273.0V/99%
Para Unlock Load: 50%
Control Battery Test Mode
Battery Test ?
Turn On IP: 208.0V / 50Hz
--> Batt Test --> Yes OP: 220.0V/50Hz
Mute No Batt: 245.0V/50%
Para Unlock Load: 0%
Control Battery Mode
Mute ?
Turn On IP: 0.0V / 0.0Hz
Batt Test --> Yes OP: 220.0V/50Hz
--> Mute No Batt: 245.0V/50%
Para Unlock Load: 50%
Control Is single or Bypass Mode
parallel cable OK ??
Turn On IP: 208.0V / 50Hz
Batt Test --> Yes OP: 208.0V/50Hz
Mute No Batt: 273.0V/99%
--> Para Unlock Load: 0%
"Para Unlock" is only available when UPS are connected in parallel system.
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 33
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
F2. MEASUREMENT FUNCTIONS
Input: 1/5 Output: 2/5 Battery: 3/5
Volt: 220.0V
Volt: 220.0V Current: 43,0A Volt: 273.0V
Freq: 50.0Hz Freq: 50.0Hz Cap: 100%
Inv: 220.0V Discharge Time:
Apparent Power: 10000VA 00:00:00
Active Power: 9000W
Load: 100%
Bypass: 4/5 Charger: 5/5
Volt: 220.0V Volt: 273.0V
Freq: 50.0Hz Status: ON
F3. INFORMATION FUNCTIONS
Bypass: 1/6 ECO: 2/6 Output: 3/6
Status: Open Status: Open Volt: 220.0V
Enable High Loss: 232V Freq: Auto
High Loss: 264V Low Loss: 184V CVCF: Disable
Low Loss: 110V High Loss: 52Hz
High Loss: 54Hz Low Loss: 48Hz
Low Loss: 46Hz
Battery: 4/6 UPS Info: 5/6 Others: 5/6
Backup Time: UPS Model: 10K Hot Standby: Disable
990 min. DSP Ver: xx-xx Bypass Mute: Disable
Batt Test Type: MCU Ver: xx-xx Batt Mute: Disable
Short Time: Unit Name: XXXXXXXXXX Fault Mute: Disable
10 sec. Manufacturer: XXXXXXX
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 34
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
F4. SETTING FUNCTIONS
This menu is used to adjust most important parameters of the UPS as described in below screen. Some of below settings cannot be
changed in all operation modes. Please check functions availability according to UPS mode in first page of this section.
Setting:
-->
Bypass
ECO
Output
Battery
Calibration
Others
SETTING / BYPASS
Bypass:
-->
Status: Open
Enable
High Loss V: 264V
Low Loss: V: 110V
High Loss: F: 54Hz
Low Loss: F: 46Hz
Bypass:
-->
Status: Forbid
High Loss V: 264V
Low Loss: V: 110V
High Loss: F: 54Hz
Low Loss: F: 46Hz
.
STATUS OPEN: Bypass allowed: UPS will run at bypass depending on
ENABLE/DISABLE parameter setting.
STATUS FORBID: Bypass NOT allowed under any situation.
ENABLE: This option is available when previously has been selected
OPEN option. ENABLE allows bypass mode.
DISABLE: Manual bypass NOT allowed so when UPS is turned off it
will not go to bypass mode. Instead of that UPS will go to output
power off condition.
HIGH LOSS V: Acceptable high limit for input voltage for UPS in
bypass mode.
LOWLOSS V: Acceptable min. limit for input voltage for UPS in bypass
mode.
HIGH LOSS F: Acceptable high limit for input frequency for UPS in
bypass mode.
LOWLOSS F: Acceptable min. limit for input frequency for UPS in
bypass mode.
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 35
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
SETTING / ECO
ECO:
-->
Status: Disable
High Loss: 232V
Low Loss: 184V
High Loss: 52Hz
Low Loss: 48Hz
SETTING / OUTPUT
Output:
-->
Volt: 220.0V
Freq: Auto
CVCF: Disable
STATUS ENABLE: ECO function enable
STATUS DISABLE: ECO function disable
HIGH LOSS V: Acceptable high limit for input voltage for UPS in ECO
mode.
LOWLOSS V: Acceptable min. limit for input voltage for UPS in ECO
mode.
HIGH LOSS F: Acceptable high limit for input frequency for UPS in
ECO mode.
LOWLOSS F: Acceptable min. limit for input frequency for UPS in ECO
mode.
VOLT:
208: set output voltage to 208Vac
220: set output voltage to 2220Vac
230: set output voltage to 230Vac
240: set output voltage to 240Vac
FREQ:
50Hz: Set output to 50Hz
60Hz: Set output to 60Hz
ATO: Set output according to input frequency.
From 46-54Hz set to 50Hz. From 56 to 64Hz set to 60Hz.
CVCF: Set if frequency conversion is activated.
Enable: Output frequency is fixed in 50Hz or 60Hz according to
previous FREQ setting
Disable: Converter function disables. Output frequency will be
synchronized with input frequency.
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 36
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
SETTING / BATTERY
Battery:
-->
DisChg Protect: Enable
990 min.
Batt Test Type:
Till Batt Low
Battery:
-->
DisChg Protect: Enable
990 min.
Batt Test Type:
Short Time:
10 sec
Battery:
-->
DisChg Protect: Enable
990 min.
Batt Test Type:
Long Time:
10 min
SETTING / CALIBRATION
Calibration:
-->
Batt: 273.0 +0.0
Inv: 220.0 +0.0
Chg: 273.0 +0.0
DISCHARGE PROTECTION FUNCTION:
Enable: UPS will shutdown automatically to protect batteries.
Shutdown will be produced according to time in minutes set below
(from 000 to 990 min.)
Disable: Batteries protection disable. UPS will run until reach very low
battery level.
000-990: Set time in minutes for Discharge protection function.
BATTERY TEST TYPE:
Short Time: Battery tests will be performed during 10 seconds.
Long Time: Battery tests will be performed during 10 minutes.
Till Battery Low: Battery tests will be performed until reaching battery
low level.
BATT: Calibrate value indicated in LCD for battery voltage.
INV: Adjust the inverter output voltage. Available only in:
Online mode
Battery mode
CVCF mode
CHG: Adjust the charger output voltage. Available only in:
Bypass mode
Online mode
ECO mode
CVCF mode
** Batteries must be disconnected from charger before making any
adjustment.
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 37
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
SETTING / OTHERS
Others:
-->
Hot Standby
Backup Time
Hot Standby:
-->
Status: Disable
Backup Time:
-->
Batt Groups: 1
Batt Cap: 9AH
Factor: 1.0
F5. ALARMS & ERROR SCREEN
Alarm Info
Fault:
14: Output Short
Warning:
01: Batt Open
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 38
HOT STANDBY:
ENABLE: It allows UPS to restart after a long AC failure even UPS has
no batteries connected.
DISABLE: It allows UPS to work as standard UPS. It will only restart
when AC recovery is detected if UPS has batteries connected.
BACKUP TIME PARAMETERS:
BATT GROUPS: Set the quantity of battery groups connected from 1 to
6. Default is 1.
BATT CAP: Set the battery capacity in AH. Default is 9AH.
FACTOR: This factor is used to calculate remaining backup time
displayed on LCD. Default is 1.
In this screen warnings and faults are recorded.
Warning and error messages are described in following tables.
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
12.- ERROR CODES, ALARMS & TROUBLESHOOTING
ERROR / FAILURE CODES ON LCD
STATUS
FAULT ON-RED 01 Bus Start Fail Internal converter fails. PSDR board need to be replaced. Contact service
FAULT ON-RED 02 Bus Over Main AC input or load transient make DC BUS voltage high or converter
FAULT ON-RED 03 Bus Under Internal converter fails. PSDR board need to be replaced. Contact service
FAULT ON-RED 04 Bus Unbalance Load connected to UPS output is abnormal (too inductive or halfwave).
FAULT ON-RED 11 Inverter Start Fail Inverter Fails. Contact service support
FAULT ON-RED 12 Inverter Voltage High Inverter Fails. Contact service support
FAULT ON-RED 13 Inverter Voltage Low Inverter Fails. Contact service support
FAULT ON-RED 14 Output Short A short circuit was detected at UPS output. Solve short circuit and restart
FAULT ON-RED 1A Negative Power UPS power output is negative. There is a power feedback from UPS
FAULT ON-RED 21 Battery SCR Short Contact service support.
FAULT ON-RED 24 Inverter Relay Short Contact service support.
FAULT ON-RED 35 Parallel Comm. Fail Revise all parallel cables of the system.
FAULT ON-RED 36 Output Current Unbalance Revise AC wiring of the parallel system.
FAULT ON-RED 41 Over Temperature Internal UPS temperature above normal limit. Possible reasons: Fan
FAULT ON-RED 42 CPU Comm. Fail Contact service support.
FAULT ON-RED 43 Overload Power consumption of equipments connected to UPS output is too high.
ALARM CODES ON LCD
STATUS
WARNING OFF 01 Battery Open Check Battery cables and battery fuse
WARNING OFF 07 Over Charge Battery quantity is not OK or Charger Voltage is too high or Charger is
WARNING OFF 08 Battery Low Batteries under low voltage or Battery quantity is not OK or Battery
WARNING OFF 09 UPS overload Connected load to UPS is above UPS max capacity.
WARNING OFF 0A Fan Error Fan blocked or fan damaged or fan detection circuit damaged
WARNING OFF 0B EPO activated EPO jumper has been removed or emergency switch connected to EPO
WARNING OFF 0D Over Temperature Internal UPS temperature above normal limit. Possible reasons: Fan
WARNING OFF 0E Charger Fail Charger fail
WARNING OFF 10 Input fuse open Input AC fuse in power stage of the UPS is burnt
FAULT
LED CODE DESCRIPTION SUGGESTION
support
fails. Try to shutdown and restart UPS. If fails again contact service
support.
support
Disconnect load and shutdown and restart UPS. If fail is solved the
problem is related to kind of load connected to UPS.If fail continues
contact service support.
UPS.
outputs because a regenerative load or because a problem in current
control in a parallel system.
blocked or ventilation windows are blocked or environment temperature is
too hot combined with high load connected to UPS
Remove no critical equipment from UPS
FAULT
LED CODE DESCRIPTION SUGGESTION
damaged
exhausted
port is activated
blocked or ventilation windows are blocked or environment temperature is
too hot combined with high load connected to UPS
WARNING OFF 33 External and repetitive
overload
WARNING OFF 3A External bypass switch
cover is open
WARNING OFF 3F Parallel Protection
Activated
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 39
UPS has detected 3 repetitive overload at their output in less than 30 min.
Cover for external maintenance bypass switch has been removed or
external bypass switch cable is disconnected.
When a problem is detected in regards to parallel communication between
some UPS in parallel warning code 3F is activated. Please check all
parallel cables and go to CONTROL screen menu to unlock PARA
UNLOCK parameter before trying to restart UPS.
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
13.- TECHNICAL SPECIFICATIONS
ONLINE RT9 UPS
6K-RT9 10K-RT9
Capacity / Capacidad
Output PF / FP de Salida:
INPUT / ENTRADA
Input Voltage / Voltaje de Entrada
Input Range / Rango de Entrada
Frequency Range / Rango Frecuencia
Phase / Fases
Power Fa ctor / Factor de Pot encia
THDi
Slew Rate / Segumiento Frecuencia
OUTPUT / SALIDA
UPS
ISOTX (optional module)
Voltage Regulation / Regulación Salida
Frequency / Frecuencia (Batt. Mode)
Current Crest Ratio / Factor de Cresta
THDv
Transfer Times / Tiempos Transfer.
Waveform / Forma de Onda
Power Outlets / Salidas
OVERLOAD / SOBRECARGA
AC Mode / Modo Normal
Battery Mode / Modo Batería
EFFICIENCY / EFICIENCIA
Eco Mode / Modo ECO
AC Mode / Modo AC
Battery Mode / Modo Batería
BATTERIES / BATERIAS
Type and Qty / Tipo y Cantidad
Internal Batt. Pack / Bat. Internas
External Batt Cab. / Gab. Ext.
Typical Recharge T. / T. de Recarga
Internal Battery Pack / Bat. Internas
External batt cabinet / Gabinete Ext.
Charging Amps / Corrie nte de Carga
Charging Voltage / Voltaje Cargador
6KVA / 5.400W 10KVA / 9.000W
0.9 0.9
220Vac (single phase: L-N + ground / L-N + Tierra )
Rate d Input / Entra da Nomina l: 208/220/230/240 Va c
(176Vac-300Va c) +/- 3% @ 100% load
(110Vac-300Va c) +/- 3% @ 50% load
40 - 70 Hz
1 Pha se+Ground / 1 Fa se+Tierra
> 0.99 @ 100%load
< 5% @ 100%load
1 Hz / s
1 phase (L1-N1): 200/208/220/230/240Vac
Dua l Isolated Outputs : 2 phases ( L1-N1) + (L2-N2) : 104/110/115/120Vac (L-N)
+/- 1% (Batt. Mode / Modo Batería)
50 Hz +/- 0.1 Hz / 60 Hz +/- 0. 1 Hz
3:1 @ 100% load.
< 3% @ Linear Load / Carga Lineal
<4% @ No Linear Load / Carga no Lineal
0 ms
Sine Wave / Sinusoidal Pura
Terminal Block / Regleta de Conexión
100%~110%: 10m / 110%~130%: 1m / >130% : 1s
100%~110%: 30s / 110%~130%: 10s / >130% : 1s
96% / 92% (EX / ISO)
90% / 86% (EX / ISO)
88% / 84% (EX / ISO)
Separate Cabinet
12V/7AH x 20 pcs 12V/9AH x 20 pcs
12V/7AH x 20 pcs 12V/9AH x 20 pcs
3.5 H (90%) 4 H (90%)
Depending on external battery configuration (depende de cantidad de baterías externas)
2.0 A (Max.)
273.0 VDC
Separate Cabinet
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 40
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
ONLINE RT9 UPS
INDICATORS / INDICADORES
6K-RT9 10K-RT9
LCD / Pantalla LCD
ALARM / ALARMAS
Beep Alarm / Alarma sonora:
PRODUCT SIZE & WEIGHT / DIMENSIONES Y PESOS DEL EQUIPO
D x W x H / Prof. x Ancho x Altura (mm)
UPS module
Ext. Batt. Cabinet / Gabinete Bat. Ext.
ISOTX
Net Weight / Peso Neto (kgs)
UPS
External batt cabinet / Gabinete Ext.
ISOTX (optional module)
PACKING / EMPAQUE
D x W x H / Prof. x Ancho x Altura (mm)
UPS module
Ext. Batt. Cabinet / Gabinete Bat. Ext.
ISOTX (optional module)
Gross Weight / Peso Bruto (kgs)
UPS module
External Battery Cabinet
ISOTX (optional module)
OPERATING / AMBIENTALES
Humidity / Humedad
Temperature / Temperatura
Noise Level / Ruido Producido
COMMUNICATION / COMUNICACION
Smart RS-232 & USB port s
Intelligent Port (SNMP)
Specifications can be modified to comply with special project requirements / Las especificaciones pueden modificarse para adaptarse a proyectos especiales
Specifications may change without further notice / Por motivos comerciales o técnicos las especificaciones pueden cambiar sin previo aviso.
Available Product Models / Modelos Disponibles:
* UPS including Battery Module and able to accept additional external batteri es / UPS con módulo de baterí as con capacidad de conexión a bateríuas ext. adicionales
* ISOTX: Isolation transformer option for Dual Isolated Outputs (2 lines of 110Vac) / Transformador de aislamiento con salida dual (2 x 110Vac)
* UPS RT9 6K/10K: 2 Cabs: UPS + Battery - (ISOTX module is optional) / UPS RT9 6K/10K: 2 gabinetes: UPS + Baterías - (ISOTX esopciona l)
UPS status, Load level, Battery, Input/Output voltage, Discharge timer, and Fault conditions
Estado del UPS, Consumo, Baterías, Voltaje Entrada-Salida, Tiempo Descarga, Diagnostico
For Battery Mode, Low battery, Overload, UPS Failure /
Modo Batería, Baja batería, Sobrecargas, Falla
668x438x133 [3U]580x438x133 [3U]
580x438x133 [3U]
580x438x133 [3U]
21 23
57 65
55 75
Carton: 87x58x25 cm
Carton: 87x58x25 cm
Carton: 87x58x25 cm
23 25
59 67
57 77
<95 % (non-condensing / no condensante)
0-40 ºC
< 55dB @ 1m
Windows® 98/2000/2003/XP/Vista/2008, Windows® 7 / 8, Linux, and MAC
Optional LAN card / Comunicación LAN Ethernet opcional
AS400 optional inte rface board / Int erfaz AS400 - opcional
668x438x133 [3U]
668x438x133 [3U]
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 41
User Manual - ONLINE 6K/10K RACK-TOWER ISOTX UPS ENGLISH
__________________________________________________________________________________________________________________________
14.- LIMITED WARRANTY
Support: If a failure or problem is detected please check troubleshooting section in user manual. If problem cannot be solved please
contact authorized service center or authorized dealer.
Batteries: Rechargeable batteries can be charged and discharged hundreds of times. However they will eventually wear out. This is
not a defect or failure so that batteries wear out is not covered by this warranty.
Battery lifetime will depend of operative conditions like working temperature, type and frequency of discharging cycles. Higher the
temperature shorter will be the lifetime. Frequent and deep discharging cycles also will short lifetime. For critical applications batteries
should be revised and replaced periodically. Long storage (longer than 6 months) without required recharging will wear out batteries.
This situation is not covered by this limited warranty since this is not considered as a defect. Check recharging instructions on user
manual.
Conditions Limited Warranty “X-UPS”
1.- Subject to the conditions of this limited warranty, this product is warranted to be free from defects in materials and workmanship
at the time of XMART supplies the product.
Standard warranty times could vary depending on country/region or can be extended by purchasing warranty options. Please check
warranty plans and extensions with your local distributor or revise in our web www.xmart-ups.com.
2.- If during the warranty period, this product fails to operate under normal use and service, due to defects in materials or
workmanship, authorized distributor or service center will, at their option, either repair or replace the product in accordance with
terms and conditions stipulated herein. Transportation expenses are not covered by this limited warranty.
3.- Warranty is valid only if the original invoice issued by XMART, specifying date of purchase, serial number and name of the dealer,
is presented with the product to be revised. XMART and authorized partners reserve the right to refuse warranty service if any of this
information has been removed, changed or missing in original invoice document.
4.- If product is repaired or replaced, repaired or replaced product will be warranted for the remaining time of the original warranty or
for 90 days on repaired part from date of repair, whichever is longer.
5.- XMART or their distribution/service partners reserve the right to charge handling fee if returned product is free of failure or it is out
of warranty because any of the reasons described in this warranty.
6.- If product is out of warranty a reparation proposal will be sent to the user for his approval. If proposal is not accepted, service
center will keep product available for the user during 60 continuous days. After this period product would be disposed and user will
not be able to rise any claim.
7.- Rechargeable batteries, like included in this product, will definitively wear out even under normal operation. This is not a defect or
failure so it is not covered by this warranty.
8.- This warranty does not cover batteries wear out caused by improper or long storage (over 6 months without required recharging
indicated in product manual). Even performing recharging procedure this product cannot be storage longer than 18 months. Problems
on batteries caused by this kind of long storage are not covered by this warranty.
9.- This warranty does not cover product failures caused by installations, modifications or repair performed by non authorized person.
If product is open by not authorized technician warranty will be considered void. This warranty does not cover failure caused by
inadequate installation or maintenance, misuse, accidents, fire or floods.
10.- This product can include protection devices like input fuse or input breaker. Activation of this kind of devices is not a failure it is
caused by an improper product installation. Input fuse or breaker reset or replacement is not covered by this warranty.
11.- This warranty does not cover damages produced during transportation from user to technical service caused by improper
packing of the product by user.
12.- Warranty terms and conditions cannot be modified or extended by third parties without written approval of XMART.
Limited Warranty “X-UPS”
- XMART does not warrant that the operation of this product will be uninterrupted or error-free during its lifetime. If product fails to
work, the maximum liability of XMART under this limited warranty is expressly limited to the lesser of the price you have paid for the
product or the cost of repairing or replacement of any hardware components that malfunction in conditions of normal use.
- In no event will XMART be liable for any damages caused by the product or the failure of the product to perform, including any lost
profits or savings or special, incidental, or consequential damages. XMART is not liable for any claim made by a third party to XMART
or to final user.
- XMART is not responsible for damage that occurs as a result of your failure to follow the instructions intended for this hardware
product.
- XMART is not responsible for damage that occurs as a result of your failure to follow the instructions intended for this hardware
product.
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 42
Loading...
