Xerox 700i, 700 Utilities

Xerox 700 Digital Color Press with Integrated
Fiery

®

Color Server

Utilities

© 2008 Electronics for Imaging, Inc. The information in this publication is covered
under Legal Notices for this product.

45072726
21 April 2008

CONTENTS

CONTENTS

CONTENTS 3

INTRODUCTION 7

Terminology and conventions 8

About this document 9

About Help 9

Preparing for installation on Windows computers 10

Preparing for installation on Mac OS computers 11

Fonts 11

Installing user software 12

Installing user software on a Windows computer 12

Installing user software on a Mac OS computer 14

Integrated Fiery Color Server digital press control panel 15

Main page 15

COMMAND WORKSTATION, WINDOWS EDITION 17

Installing Command WorkStation, Windows Edition 17

Configuring the connection to the Integrated Fiery Color Server 18

Using Command WorkStation, Windows Edition 21

Additional features 22

User Authentication 22

Align Trays 22

Mixed Media 24

Virtual Printers 28

Troubleshooting 31

Command WorkStation cannot connect to the Integrated Fiery Color Server 31

Command WorkStation does not respond 31

CONTENTS 4

COMMAND WORKSTATION, MACINTOSH EDITION 32

Installing Command WorkStation, Macintosh Edition 32

Configuring the connection to the Integrated Fiery Color Server 32

Using Command WorkStation, Macintosh Edition 35

Additional features 36

User Authentication 36

Mixed Media 36

Troubleshooting 39

Command WorkStation cannot connect to the Integrated Fiery Color Server 39

Command WorkStation does not respond 39

SCAN 40

Installing and configuring Remote Scan 41

Installing Remote Scan 41

Configuring Remote Scan 41

Using Remote Scan 42

Scanning from the digital press 43

Scanning workflows 43

Default Scan Settings 44

Scanning with default scan settings 45

Modifying Scan Settings at the digital press 46

Modifying Scan Settings in WebTools 48

Creating Scan Settings in WebTools 49

Retrieving scans 49

FIERY BRIDGE 50

Installing Fiery Bridge 50

Configuring Fiery Bridge 50

Specifying servers 51

Configuring server settings 51

CONTENTS 5

Using Fiery Bridge 52

Mailbox synchronization 53

Accessing a different mailbox 54

Accessing WebTools 54

HOT FOLDERS 55

Installing Hot Folders 55

Using Hot Folders 55

Additional features 56

Preserve Document Setting 56

About Hot Folders filters 56

Using the PDF to PS filter 56

Microsoft Office filters for Hot Folders 56

Specifying filter settings for a Hot Folder 57

WEBTOOLS 58

Setting up WebTools 58

Accessing the WebTools home page 59

Using WebTools 60

Home 60

Downloads 60

Docs 60

Configure 60

Scan Settings 61

INDEX 63

INTRODUCTION

INTRODUCTION 7

The Xerox 700 Digital Color Press with Integrated Fiery Color Server media pack includes a
set of software utilities that allow you to manage the Xerox 700 Digital Color Press with
Integrated Fiery Color Server, as well as the print workflow and content of jobs on the
Xerox 700 Digital Color Press with Integrated Fiery Color Server.

This document provides an overview of how to install, configure, and use the following
Integrated Fiery Color Server utilities:

• Command WorkStation, Windows Edition

• Command WorkStation, Macintosh Edition

• Remote Scan

•Fiery Bridge

•Hot Folders

• WebTools

INTRODUCTION 8

Terminology and conventions

This document uses the following terminology and conventions.

Term or convention Refers to

Aero Integrated Fiery Color Server (in illustrations and examples)

Digital press Xerox 700 Digital Color Press

Integrated Fiery Color Server Xerox 700 Digital Color Press with Integrated Fiery Color Server

Mac OS Apple Mac OS X

Titles in italics Other documents in this set

Windows Microsoft Windows 2000, Windows XP, Windows Server 2003,

Windows Vista

Topics for which additional information is available by starting Help
in the software

Tips and information

Important information

Important information about issues that can result in physical harm to
you or others

INTRODUCTION 9

About this document

This document covers the following topics:

•

Command WorkStation, Windows Edition: Monitoring and managing the print workflow of

jobs on the Integrated Fiery Color Server.

•

Command WorkStation, Macintosh Edition: Monitoring and managing the print workflow

of jobs on the Integrated Fiery Color Server.

•

Remote Scan: Retrieving a scan on the digital press from a remote computer on the

network. Includes the Scan TWAIN plug-in module.

•

Fiery Bridge: Accessing scanned documents in your Integrated Fiery Color Server mailbox

directly from a client Windows XP/Vista computer.

•

Hot Folders: Storing and reusing frequently used print options when printing PostScript

and PDF files on the Integrated Fiery Color Server.

•

WebTools: Managing your Integrated Fiery Color Server remotely from the Internet or

your company’s intranet.

For information about installing, configuring, and using ColorWise Pro Tools, see

Color Printing.

About Help

Detailed instructions on using most Integrated Fiery Color Server utilities are provided in
Help. Wherever appropriate, this document refers you to Help for additional information and
explains how to access Help for each utility.

INTRODUCTION 10

Preparing for installation on Windows computers

Before installing Integrated Fiery Color Server software on a Windows computer, complete
the following:

• To use Integrated Fiery Color Server user software on a Windows computer, the Sun Java
file, Java Runtime Environment (JRE), provided in the Common Utilities folder on the
User Software DVD, must be installed on your computer. If the correct Sun Java file is not
installed, the Fiery User Software Installer installs it automatically before installing the
Integrated Fiery Color Server software.

NOTE: The recommended version of JRE, SE, is provided on the User Software

DVD.

• To install the Integrated Fiery Color Server software, you must have Service Pack 4
installed on a Windows 2000 computer, and Service Pack 2 installed on a Windows XP
computer. If you do not, a warning message alerts you to install the Service Pack.

Different versions of Sun Java JRE can be installed on your computer. The Integrated Fiery
Color Server software automatically finds the correct version, so you do not need to uninstall
other versions of Sun Java JRE required for third-party applications.

INTRODUCTION 11

Preparing for installation on Mac OS computers

Before installing Integrated Fiery Color Server software on a Mac OS X computer, you can
install printer fonts.

Fonts

The Fonts on the User Software DVD include screen and printer fonts that correspond to the
136 built-in PostScript and True Type printer fonts on the Integrated Fiery Color Server. To
be available to applications, the screen fonts must be installed on Mac OS X.

TO INSTALL SCREEN AND PRINTER FONTS ON MAC OS X V10.3 AND V10.4

1 Insert the User Software DVD into the DVD drive of the Mac OS X computer.

2 Start the Font Book application in Applications/Font Book.

3 Choose Add Fonts from the File menu.

4 Choose User Software/OSX/Fonts/Albertus MT.

5 Choose Select All from the Edit menu.

6 Choose one of the following from Install fonts:

• For your personal use: for your use only

• For shared use: for all users of this computer

• For Classic: for Mac OS X Classic

NOTE: For Mac OS X v10.4, you must select User, Computer, or Classic Mac OS in

Preferences/Default Install Location of Font Book beforehand.

7 Click Open.

8 Exit the Font Book application.

INTRODUCTION 12

Installing user software

You can install Integrated Fiery Color Server user software in the following ways:

• From the User Software DVD

• From the Integrated Fiery Color Server, using the Internet or intranet

If you previously installed any Integrated Fiery Color Server user software on your computer,
the installer allows you to uninstall those applications.

Installing user software on a Windows computer

All installation of user software on a Windows computer is done through the Fiery User
Software Installer. The procedures below describe installing from the DVD or over the
Internet, and also modifying the user software.

TO INSTALL USER SOFTWARE ON A WINDOWS COMPUTER FROM THE USER SOFTWARE DVD

1 Insert the User Software DVD into the DVD drive of your computer.

The installer Welcome screen appears.

2 Follow the on-screen instructions.

Do not attempt to install user software by opening the individual folders for the applications.
Always use the Fiery User Software Installer.

To modify or remove any user software after you install it on your computer, use the User
Software DVD and the following procedure.

INTRODUCTION 13

TO MODIFY USER SOFTWARE USING THE USER SOFTWARE DVD INSTALLER

1 Insert the User Software DVD into the DVD drive of your computer.

2 On the window that appears, select Modify, Repair, or Remove.

3 Follow the on-screen instructions.

If your computer does not have a DVD drive, you can install the user software from the
Integrated Fiery Color Server over the network. Ask your network administrator for the IP
address or DNS server name of the Integrated Fiery Color Server.

You can also install the Integrated Fiery Color Server user software over the Internet. Ask your
network administrator for the IP address of the Integrated Fiery Color Server.

Use your Internet browser to access WebTools. For complete information about browser and
system requirements, see Wel co me .

TO INSTALL USER SOFTWARE ON A WINDOWS COMPUTER OVER THE INTERNET

1 Start your Internet browser.

2 Type the IP address or DNS name of the Integrated Fiery Color Server.

The Integrated Fiery Color Server home page appears.

3 Click the Downloads tab.

4 Click the link for the software that you want to install.

5 Choose Run to open the file or Save to save it to your computer.

6 If you choose Run, proceed to step 9.

7 If you choose Save, browse to the location where you want to save the USERSWMI.exe file,

and then click Save.

The file is downloaded from the Integrated Fiery Color Server.

8 Double-click the USERSWMI.exe file.

9 Choose to open the file or save it to your computer.

10 Type the Integrated Fiery Color Server URL, http://<IP address>, when prompted.

11 Follow the on-screen instructions.

For complete instructions on how to use Downloads, see Downloads Help.

For more information about WebTools and Downloads, see WebTools.

Do not attempt to install user software by opening the individual folders for the applications.
Always use the Fiery User Software Installer.

INTRODUCTION 14

Installing user software on a Mac OS computer

Installation of user software on a Mac OS computer is done separately for each application.

TO INSTALL USER SOFTWARE ON A MAC OS COMPUTER FROM THE USER SOFTWARE DVD

1 Insert the User Software DVD into the DVD drive of your computer.

2 Browse to the OSX folder.

3 Double-click the installer icon for the application that you want to install.

4 Follow the on-screen instructions.

TO INSTALL USER SOFTWARE ON A MAC OS COMPUTER OVER THE INTERNET

1 Start your Internet browser.

2 Type the IP address or DNS name of the Integrated Fiery Color Server.

The Integrated Fiery Color Server home page appears.

3 Click the Downloads tab.

4 Click the link for Mac OSX Client Software Installer.

The osxutils.dmg file is downloaded to your computer and a virtual disk appears on your
desktop.

5 Follow the on-screen instructions.

For complete instructions on using Downloads, see WebTools Downloads Help.

For more information about WebTools and Downloads, see WebTools.

INTRODUCTION 15

Integrated Fiery Color Server digital press control panel

Various features are available from the Integrated Fiery Color Server digital press control panel
by accessing pages from the following tabs:

•

Main allows you to manage print connections.

•

Info displays installed options on the Integrated Fiery Color Server and allows you to print

system pages and activity logs. For more information, see Configuration and Setup.

Note: Digital press options are not shown.

•

Scan allows you to edit scan templates. For more information, see “Scanning from the

digital press” on page 43.

•

Calibrate allows you to calibrate using ColorCal. For more information, see Color Printing.

•

Setup accesses Setup options. For more information, see Configuration and Setup.

NOTE: The Integrated Fiery Color Server digital press control panel has a refresh rate of 2-3

seconds.

Main page

The Main page displays Waiting, Held, Printed, and Secure Print job queues. If you are
logged in as Administrator or Operator, you can print, print and hold, or delete jobs in the
Waiting, Held, and Printed queues. You can also change the number of copies to be printed.
The Secure Print job queues can be accessed by any user who has sent a Secure Print job from
the printer driver. You can use the Suspend Printing feature on any job.

For more information about Secure Print, see Printing from Windows and Printing from Mac

OS. For more information about Suspend Printing, see Configuration and Setup.

Procedures for accessing and using the features on the Main page are provided below.

TO ACCESS THE INTEGRATED FIERY COLOR SERVER DIGITAL PRESS CONTROL PANEL

1 Press the All Services icon at the upper-right corner of the digital press control panel.

2 Press Web Applications on the digital press control panel.

The Main page is displayed.

TO MANAGE PRINT QUEUES

1 On the Main page, click a tab to access the page for that tab.

2 To manage jobs in the Waiting, Held, and Printed pages, press Login on the digital press

control panel and log in as Administrator or Operator.

3 To page through any of the queues, press the First, Prev, Next, and Last buttons on the digital

press control panel.

4 To delete a job, press Delete on the digital press control panel for the job.

INTRODUCTION 16

5 To print a job, press Print on the digital press control panel for the job.

The Print page opens.

6 In the Print page, change the number of copies to be printed by typing the number in the

Copies field.

7 Select Print, Print and Hold, or Cancel, as desired.

8 Click More Info on the digital press control panel to open the Info page.

9 To interrupt the job that is currently printing, press Suspend Printing on the digital press

control panel.

10 Press Resume Printing on the digital press control panel when you are ready to start the job

again.

COMMAND WORKSTATION, WINDOWS EDITION 17

COMMAND WORKSTATION, WINDOWS EDITION

Command WorkStation, Windows Edition allows Integrated Fiery Color Server operators (or
users with Operator or Administrator privileges) to monitor and manage the print workflow
of jobs on the Integrated Fiery Color Server.

Command WorkStation, Windows Edition allows you to do the following:

• View the print status of jobs on the Integrated Fiery Color Server

• Hold, process, and print jobs

• Override user-assigned print option settings

• Preview the page content of a job

• Reorder pages in a job and combine pages from different jobs

• Create and use FreeForm master files for variable data printing

• Archive job files

• View job logs of recent print activity

• Define virtual printers

• Manage Fonts

Installing Command WorkStation, Windows Edition

Install Command WorkStation, Windows Edition on a Microsoft Windows computer
that has a network connection to the Integrated Fiery Color Server. For a complete list of
system requirements, see Welco m e.

The installer for Command WorkStation, Windows Edition is provided on the User Software
DVD. In addition to the Command WorkStation software, the installer installs the Java files
required to use Fiery Setup from Command WorkStation. For information about using Fiery
Setup, see Configuration and Setup.

NOTE: ColorWise Pro Tools is installed automatically when you install Command

WorkStation. For information about using ColorWise Pro Tools, see Color Printing.

Before installing the utility, complete the preliminary procedures described in “Preparing for

installation on Windows computers” on page 10.

To install Command WorkStation, Windows Edition, see “Installing user software on a

Windows computer” on page 12.

COMMAND WORKSTATION, WINDOWS EDITION 18

Configuring the connection to the Integrated Fiery Color Server

The first time you start Command WorkStation, you are prompted to configure the
connection to the Integrated Fiery Color Server.

You can also edit the configuration whenever there is any change to your Integrated Fiery
Color Server or network, such as a changed server name or IP address. If you change
Integrated Fiery Color Server Setup information, do so before you reconfigure the
connection. For information about reconfiguring the connection, see “To modify the

configuration for Command WorkStation, Windows Edition” on page 20.

BEFORE YOU BEGIN

• Print the Integrated Fiery Color Server Configuration page.

For instructions on printing the Configuration page, see Configuration and Setup.

This page contains information you need when configuring the connection, such as the
IP address of the Integrated Fiery Color Server. For TCP/IP installations, you can use the
DNS name instead of the IP address. Make sure that the Integrated Fiery Color Server is
registered in a Domain Name Server (DNS) on your network. For more information, contact
your network administrator.

TO CONFIGURE THE CONNECTION FOR COMMAND WORKSTATION, WINDOWS EDITION

1 Choose Start > Programs > Fiery > Command WorkStation to start the utility.

The Available Servers dialog box appears and displays all servers found in the local subnet.

COMMAND WORKSTATION, WINDOWS EDITION 19

2 If no Integrated Fiery Color Servers are found, click the Manual tab to search by DNS name or

IP address. Type the DNS name or IP address and click Add to add the server to the Available
Servers list.

If no Integrated Fiery Color Servers are found by Manual search, click the Auto Search tab, and
then click Advanced to search by a range of IP addresses or by the IP address and subnet
mask.

All available servers appear in the Available Servers list.

3 Select the Integrated Fiery Color Server that you want to use and click Add.

The selected Integrated Fiery Color Server is added to the Login Server window.

COMMAND WORKSTATION, WINDOWS EDITION 20

4 Click the button to the left of the server name.

The Login dialog box appears.

5 Click the key to the left of Administrator, Operator, or Guest and type the appropriate

password, if required.

6 Click Log In.

For information about setting passwords and the default Administrator password for the
Integrated Fiery Color Server, see Configuration and Setup.

Command WorkStation is now connected to the Integrated Fiery Color Server.

TO MODIFY THE CONFIGURATION FOR COMMAND WORKSTATION, WINDOWS EDITION

1 Start Command WorkStation.

The Login Server window appears.

2 Select the Integrated Fiery Color Server for which you want to modify the configuration and

click Remove.

3 Repeat “To configure the connection for Command WorkStation, Windows Edition” on

page 18.
