OPERATING INSTRUCTIONS

URC-1

PROGRAMMABLE REMOTE CONTROLLER

GENERAL

The URC-1 is a highly versatile learning remote,
capable of storing up to 32 commands on each of 4
layers. Layers are selected by a 4-position BANK
switch. Unlike many learning remotes, the URC-1
will send commands in sequences (macros), up to a
maximum of 10 steps under one or more individual
buttons. It also includes extended memory to store
the longer codes of some remote controls.

PRECAUTIONS

The URC-1 is a precision electronic instrument that uses microprocessor circuitry and should be treated with
care. Do not allow the URC-1 to get wet or excessively hot. Do not leave it in direct sunlight or store it in
hot locations, such as in a car.

INSTALLING THE BATTERIES

• The URC-1 uses four triple-A (AAA) size batteries.

• Use alkaline batteries for maximum life.

• When replacing the batteries, replace all four at the same time. Mixing old batteries with new ones will
shorten battery life. Unremoved old batteries may damage the URC-1.

CAUTION: There is backup power for approximately two to three minutes built into the URC-1. This
allows the remote control to retain its learned commands while you are changing batteries. If you exceed
this length of time however, the URC-1 will lose its memory and have to be completely re-programmed.

"Sending" IR
Window

BANK switch

Fig. 1

"Learning" IR
Window

Controllers

TEACHING THE URC-1 COMMANDS FROM OTHER REMOTE
CONTROLS

To "teach" the URC-1 commands from
other remotes, proceed as follows:

1. Place both units on a flat surface

"Learning" IR
Window

"Teaching" Remote

leaving your hands free to operate
the push buttons.

2. Place the "teaching" remote approxi-

mately 1 to 2 inches away and to the
rear of the URC-1 - see Fig. 2.

Fig. 2

1 to 2 inches

3. Press and release the recessed

LEARN button to enter the Learn mode. The LEARN

IR LED

LED will light. Refer to Fig. 3.

4. Slide the BANK switch to the desired position (TV,

Audio, Video or Aux).

5. Press and hold the desired button on the URC-1 to

store a command.

Fig. 3



LEARN button

LEARN LED

1

6. Using your other hand, press and release the desired key of the "teaching" remote. The LEARN LED

will start blinking. When the command has been learned, the IR LED will go on.

7. Release the button on the URC-1.

8. Repeat steps 4, 5 and 6 for all commands you wish the URC-1 to learn.

9. If no other key is pressed within two minutes, the URC-1 will automatically leave the learn mode and

the LEARN LED will turn off, with new commands learned. You may also press the LEARN button
if you wish to leave the learn mode more quickly.

LED INDICATORS

IR LED:

• Lights when a button press sends a stored command.

• In Learn mode, the IR LED lights when a button has accepted a command.

BATT LED:

• Lights when the batteries need replacing.

LEARN LED:

• Lights when the LEARN button is pressed.

ERROR LED:

• Lights if a button is pressed that does not have a stored command.

• Lights when the URC-1 encounters a long command code in the Learn mode. Refer to "ERROR LED
AND EXTENDED MEMORY" for details.

BUTTON USAGE

To improve visibility of the URC-1 buttons in a darkened room, certain buttons have been molded in ivory
and blue for the most frequently used commands.

• We suggest that you use them for such functions as volume, mute, and channel selection, as designated,
or for any functions you anticipate needing most frequently.

• In addition, two orange colored keys are designated for power and one red key for recording. Some TV
sets or cable boxes have a jump or flash- back key for moving immediately between the two most recently
viewed channels without having to press any other functions.

• The LAST button (meaning last viewed) on the URC-1 is used for programming this function and may also
be used for CD source select.

SHORT COMMANDS

Some commands, such as Channel Up and Channel Down, may change channels two at a time or cause
other multiple actions if memorized at full length. If a button on the original hand-held remote controller
requires only a short tap for its command to be properly executed, and results in multiple actions if the button
is pressed too long, only a short burst of it should be stored in the URC-1. Step 6, under "TEACHING THE
URC-1 -- ",, should be modified as follows for this type of command:

6. Using your other hand, press the desired button of the "teaching" remote only as long as you usually

press it when controlling the audio/video equipment directly. The LEARN LED will start blinking.
When the command has been learned, the IR LED will go on.

NOTE: It may be necessary to experiment with the length of time you press the "teaching" remote control
button to obtain the desired result.
