TYPICAL SYSTEM CONNECTIONS
ISM4 INTELLIGENT SYSTEM MANAGER
PROGRAMMING QUICK START GUIDE
Front
Rear
This ISM4 Programming Quick Start Guide provides the basic instruction to programming an ISM4. To use the Quick Start Guide, fill
out the Macro Programming Table and follow the Programming Instructions. For complete instructions on insta llation, connections and
additional programming capabilities, refer to the ISM4 Installation & Programming Manual.
The System shown on the back cover illustrates a typical Home Theater System. In the configuration as shown, when the TV is turned
ON, the ISM4 will sense the TV ON state, look at Sources 2-4 (A/V Receiver, Cable Box and DVD Player) and if any of them are OFF,
automatically output the Source ON Macros for those devices to turn them ON. If at any time, while the TV is ON, any of Sources 2-4
turns OFF, the ISM4 will automatically turn it back ON. When the TV is turned OFF, the ISM4 will sense the TV OFF state, look at
Sources 2-4, and if any of them are ON, automatically output the Source OFF Macros for those devices to turn them OFF.
There are endless applications for this type of power management. Two other system examples are shown in the ISM4 Installation &
Programming Manual for reference. See Section: System Applications.
MACRO PROGRAMMING TABLE
Source 1 Source 2 Source 3 Source 4 IR
Command
Brand
Device
Command
ON OFF ON OFF ON OFF ON OFF
PROGRAMMING INSTRUCTIONS
The following instructions cover the basic Source programming procedure. Each Source ON and OFF Macro can include up to five IR
Commands. Please refer to the ISM4 Installation & Programming Manual for complete programming instructions.
To properly Program and Test IR Commands, each of the Source IR Emitters must be connected to the appropriate ISM4 Source IR
Out Port, and attached to the appropriate device over the IR Eye.
If Source 1 is going to be turned ON/OFF manually or with a remote control, and there are no additional commands in the ON
or OFF Macros, it is not necessary to program the Source 1 ON or OFF Macros. The ISM4 will sense the ON or OFF condition of
Source 1 and automatically sync Sources 2-4.
Learn IR
1. Enter Edit Mode: Press and hold the SEQUENCE button until Source 1 LED blinks once and release. The ISM4 will
default to the SOURCE 1 (ON Macro). SOURCE 1 and PROGRAM LED’s will turn ON solid green.
Note: Read Steps 2 and 3 before entering macro commands.
2. Teach Command (SOURCE 1 (ON Macro)): Press and releas e the SEQUENCE button again to enter IR Learn
Mode for SOURCE 1 (ON Macro). The Source 1 LED will flash for about 5 seconds. This is the amount of time
allowed to teach an IR Command.
3. Position the remote control for the System Reference Device (Source 1) directly in front of the IR Learn window on
the ISM4 (1- 4 inches depending on the remote) and press and hold the ON or Power button on the remote control
until the PROGRAM LED flashes green three times. If the PROGRAM LED flashes red three times (the IR command
was not learned), return to Step 2.
4. Test Command: Press the TEST button and confirm the function of the learned command on the SOURCE 1 device.
5. Save Command: If the SOURCE 1 device responded properly to the learned command press and release the
SEQUENCE button again to save the command. The PROGRAM LED will flash once. The ISM4 will automatically
return to Edit Mode upon save. To return to Edit Mode without saving, press the PREV Button.
6. Repeat Steps 3-5 as necessary until the command is learned, tested, confirmed and saved.
Note 1: If a delay is required proceed to Step 9.
7. If there is no delay required for IR Macro Command 1, and there is at least one more IR Command in the Macro,
press and release the NEXT button. SOURCE 1 LED will flash twice indicating the ISM4 is ready to learn the IR
Command for IR Macro Command 2. Repeat Steps 2-5 to add the IR Command.
Note 2: To add IR commands 3-5 repeat the sequence (Step 7). The selected source LED will blink the number of
times for the IR command that it is presently on.
8. Teach Command (SOURCE 1 (OFF Macro)): To enter SOURCE 1 (OFF Macro) press and hold the NEXT button
until the SOURCE 1 LED blinks once and release. SOURCE 1 LED will turn ON solid green and PROGRAM LED will
turn ON solid orange. Repeat Steps 2–7.
