WX027L WX027L.9
LED 4-in-1 Light EN
Lampe LED 4-en-1 F
Luz LED 4 en 1 ES
P02
P11
P17
LED 4-in-1 Light EN
2
PRODUCT SAFETY
WARNING: This product can expose you
to chemicals including lead, phthalate
or bisphenol A which are known to the State
of California to cause cancer, birth defects or
other reproductive harm. Wash your hands
after use. For more information go to www.
P65Warnings.ca.gov.
SAFETY WARNINGS FOR LIGHT
CAUTION: Read, understand and follow all Safety
Rules and Operating Instructions in this Manual
before using this product.
SAVE THESE INSTRUCTIONS!
READ ALL INSTRUCTIONS!
SAFETY INSTRUCTIONS
WARNING: BE SURE to read and
understand all instructions in this manual
before using this portable hand-held light.
Failure to follow all instructions may result in
electric shock, fire and/or serious personal
injury.
1. Know your Light. Read operator’s manual
carefully.
Learn its applications and limitations, as well
as the specific potential hazards related to this
Light.
2. Use only recommended battery pack and
charging stand / transformer.
Any attempt to use another battery pack will
cause damage to the portable hand-held light
and it could possibly explode, cause a fire, or
personal injury.
Model Battery Pack
Charging Stand/
Transformer
WX027L
*1.5Ah
WA3520
*3-5hr charger
WA3742
3. Remove battery pack from Light before
performing any routine maintenance or
cleaning.
4. Do not disassemble the Light.
5. Do not place Light or battery pack near fire or
heat. They may explode. Also, do not dispose of
a worn out battery pack by incineration, even if
it is severely damaged or completely worn out.
The battery may explode in fire.
6. Do not operate Light or charging stand/
transformer near flammable liquids or in
gaseous or explosive atmospheres. Internal
sparks may ignite fumes.
7. To reduce the risk of electric shock, do not
put Light in water or other liquid. Do not
place or store portable hand-held light where it
can fall or be pulled into a tub or sink.
8. Do not permit children to use Light
unsupervised. It is not a toy. The
temperature of the bulb will become hot after
being on only a short period of time. This hot
temperature can cause burn injury if touched.
9. Do not use or permit use of Light in bed
or sleeping bags. This portable hand-held
lens can melt fabric and a burn injury could
result.
10. Keep light dry, clean, and free from oil
and grease. Always use a clean cloth when
cleaning. Never use brake fluid, gasoline,
petroleum-base products or any strong solvent
to clean the portable hand-held Light.
GENERAL SAFETY
WARNINGS
1) WARNING: Risk of fire and burns. Do not
disassemble, heat above 100°C (212°F), or
incinerate. Do not expose cells or batteries
to heat or fire. Avoid storage in direct
sunlight.
2) Dispose of used battery promptly. When
disposing of secondary cells or batteries,
keep cells or batteries of different
electrochemical systems separate from
each other.
3) Keep battery out of reach of children and
in original package until ready to use.
4) Never put batteries in mouth. If swallowed,
contact your physician or local poison
control center.
5) CAUTION – The battery used in this device
may present a risk of fire or chemical burn
if mistreated. Replace battery with WORX
only. Use of another battery may present a
risk of fire or explosion.
6) WARNING: Do not use a visibly damaged
battery pack or appliance as applicable.
7) WARNING: Do not modify or attempt to
repair the appliance or the battery pack as
applicable.
8) BATTERY MUST BE RECYCLED.
9) Do not short-circuit a cell or battery. Do
not store cells or batteries haphazardly in
a box or drawer where they may shortcircuit each other or be short-circuited by
conductive materials.
10) Do not subject cells or batteries to
mechanical shock.
11) Keep cells and batteries clean and dry.
Wipe the cell or battery terminals with a clean
dry cloth if they become dirty.
12) Do not maintain secondary cells and
batteries on charge when not in use.
13) Retain the original cell and battery
literature for future reference.
14) Do not use any charger other than that
specifically provided for use with the
equipment. Secondary cells and batteries
need to be charged before use. Always use the
correct charger and refer to the manufacturer’s
instructions or equipment manual for proper
charging instructions.
15) When possible, remove the battery from the
equipment when not in use.
LED 4-in-1 Light EN
3
16) Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to battery
pack, picking up or carrying the appliance.
Carrying the appliance with your finger on the
switch or energizing appliance that have the
switch on invites accidents.
17) Disconnect the battery pack from the appliance
before making any adjustments, changing
accessories, or storing appliance. Such
preventive safety measures reduce the risk of
starting the appliance accidentally.
18) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause
irritation or burns.
19) Have servicing performed by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the product is
maintained.
SYMBOLS
To reduce the risk of injury, user must
read instruction manual
Warning
Do not expose to rain or water.
Do not burn
Li-I on
Li-Ion battery, battery must be recycled
POSITEC Inc. has established a partnership with
the RBRC Corporation to recycle any Positec
batteries with the RBRC-call2recycle seal. For
environmental protection, please do not discard
batteries in the trash. After the batteries’ life cycle
is ended, please call 1-800-822-8837 for a free
service that will properly dispose of the battery.
LED 4-in-1 Light EN
4
1
2
5
4
6
9
3
8
7
LED 4-in-1 Light EN
5
TECHNICAL DATA
WX027L WX027L.9
Rated voltage 20V
Max*
Charger voltage 120 V ~ 60 Hz
Brightness
Flashlight 130 LM
Lantern 480 LM
Desk Lamp
Desk Lamp Hi 440 LM
Desk Lamp Lo 210 LM
SOS 0/480 LM
Burntime
(1.5Ah)
Flashlight 12 h /
Lantern 6 h /
Desk Lamp
Desk Lamp Hi 5 h /
Desk Lamp Lo 13 h /
SOS 9 h /
Pivoting head -72°~+72°
Light stick rotation -45°~+45°
Positions 3
Machine weight 1.72 lbs 0.88 lbs
*Voltage measured without workload. Initial battery voltage reaches maximum of 20 volts. Nominal voltage is
18 volts.
The LED bulbs in this light are designed to last 50,000 hours. They cannot be replaced.
1. LENS
2. LAMP HEAD
3. LIGHT STICK
4. PIVOT JOINT
5. FUNCTION SWITCH BUTTON
6. HANDLE
7. BATTERY PACK RELEASE BUTTON
8. BATTERY PACK
9. LANYARD
* Not all the accessories illustrated or described are included in standard delivery.
LED 4-in-1 Light EN
6
A
B
C
D1
ACCESSORIES
WX027L
WX027L.9
Battery Pack (WA3520) 1 /
Charger (WA3742) 1
/
We recommend that you purchase your accessories listed in the above list from the same store that sold you
the tool. Refer to the accessory packaging for further details. Store personnel can assist you and offer advice.
Only use the appropriate accessories intended for this tool. Accessory information can be found on the product
packaging, at a WORX dealer or on our website at www.worx.com
LED 4-in-1 Light EN
7
45
o
45
o
72
o
72
o
72
o
D2
E1
E2
E3
E4
E5
LED 4-in-1 Light EN
8
45
o
45
o
72
o
72
o
72
o
SOS
E2
E3
E4
E5
F
