Worx WG518E Instruction manual

SAFETY AND OPERATING MANUAL

ORIGINAL INSTRUCTIONS

Electric Blower WG518E

2 1

7

6

5

4

3

A

B

Click!

Click!

2

1

A

Click!

Click!

B

1

2

C

D

OFF

ON

E

I

II

PRODUCT SAFETY
GENERAL SAFETY
WARNINGS

WARNING!Read all
safety warnings and all

instructions. Failure to follow

the warnings and instructions
may result in electric shock, fire
and/or serious injury.

Save all warnings and
instructions for future
reference.

If the supply cord is damaged,
it must be replaced by the
manufacturer, its service agent
or similarly qualified persons in
order to avoid a hazard.

IMPORTANT
READ CAREFULLY BEFORE
USE.
KEEP FOR FUTURE
REFERENCE.

Safe operating practices

1) Training

a) Read the instructions carefully.

Be familiar with the controls and
the correct use of the machine.

b) Never allow children, persons

with reduced physical, sensory
or mental capabilities or lack
of experience and knowledge
or people unfamiliar with
these instructions to use the
machine, local regulations may
restrict the age of the operator.

c) Never operate the machine

while people, especially
children, or pets are nearby.

d) Keep in mind, that the operator

or user is responsible for
accidents or hazards occurring
to other people or their
property.

2) Preparation

a) While operating the machine,

always wear substantial
footwear and long trousers.
Do not operate the machine
when barefoot or wearing
open sandals. Avoid wearing
clothing that is loose fitting or
that has hanging cords or ties.

b) Do not wear loose clothing or

jewellery that can be drawn
into the air inlet. Keep long
hair away from the air inlets.

c) Obtain ear protection and

safety glasses. Wear them at
all times while operating the
machine.

d) Operate the machine in a

recommended position and
only on a firm, level surface.

e) Do not operate the machine

on a paved or gravel surface
where ejected material could
cause injury.

f) Before using, always visually

inspect to see, that the
fasteners are secure, the
housing is undamaged and
that guards and screens are
in place. Replace worn or
damaged components in sets
to preserve balance. Replace
damaged or unreadable labels.

g) Before use, check the supply

and extension cord for signs
of damage or aging. If the cord
becomes damaged during use,

5

Electric Blower WG518E

disconnect the cord from the
supply immediately. DO NOT
TOUCH THE CORD BEFORE
DISCONNECTING THE SUPPLY.
Do not use the machine if the
cord is damaged or worn.

h) Keep extension cords away

from moving hazardous parts
to avoid damages to the cords
which can lead to contact with
live parts.

i) If an extension cord is used

make sure it is for outdoor
use and marked as such.
The recommended size of
extension cord is not lighter
than 2×0.75 mm

3) Operation

a) Before starting the machine,

make certain that the feeding
chamber is empty.

b) Keep your face and body away

6

from the feed intake opening.

c) Do not allow hands or any

other part of the body or
clothing inside the feeding
chamber, discharge chute, or
near any moving part.

d) Keep proper balance and

footing at all times. Do not
overreach. Never stand at a
higher level than the base of
the machine when feeding
material into it.

e) Always stand clear of

the discharge zone when
operating this machine.

f) If the machine should start

making any unusual noise
or vibration, immediately
shut off the power source

2

.

and allow the machine to
stop. Disconnect the machine
from the supply and take
the following steps before
restarting and operating the
machine:

- Inspect for damage;

- Replace or repair any
damaged parts;

- Check for and tighten any
loose parts.

g) Do not allow processed

material to build up in the
discharge zone; this may
prevent proper discharge
and can result in kickback of
material through the intake
opening.

h) If the machine becomes

clogged, shut-off the power
source and disconnect the
machine from supply before
cleaning debris.

i) Never operate the machine

with defective guards or
shields, or without safety
devices

j) Keep the power source

clean of debris and other
accumulations to prevent
damage to the power source
or possible fire.

k) Do not transport this machine

while the power source is
running.

l) Stop the machine, and remove

plug from the socket. Make
sure that all moving parts have
come to a complete stop

- Whenever you leave the
machine,

- Before clearing blockages or

Electric Blower WG518E

unclogging chute,

- Before checking, cleaning or
working on the machine.

m) Avoid using the machine

in bad weather conditions
especially when there is a risk
of lightning.

4) Maintenance and storage

a) Keep all nuts, bolts and screws

tight to be sure the appliance is
in safe working condition;

b) Replace worn or damaged parts.
c) Use only genuine replacement

parts and accessories.

d) Store the machine in a dry

place out of the reach of
children.

e) When the machine is stopped

for servicing, inspection,
or storage, or to change an
accessory, shut off the power
source, disconnect the machine
from the supply and make sure
that all moving parts are come
to a complete stop. Allow the
machine to cool before making
any inspections, adjustments,
etc. Maintain the machine with
care and keep it clean.

f) Store the machine in a dry

place out of the reach of
children.

g) Always allow the machine to

cool before storing.

h) Never attempt to override

the interlocked feature of the
guard.

5) Recommendation

The machine should be

supplied via a residual current

device (RCD) with a tripping
current of not more than 30mA.

SYMBOLS

Read the operator’s manual

Double insulation

Wear eye protection

Wear ear protection

Keep bystanders away

7

Warning of hazard

Do not expose to rain

Disconnect the mains plug if
the cord becomes damaged or
entangled.

SWITCH OFF: Remove plug
from mains before cleaning or
maintenance.

Waste electrical products
must not be disposed of with
household waste. Please recycle
where facilities exist. Check with
your local authorities or retailer
for recycling advice.

Electric Blower WG518E

1. HANDLE

2. ON/OFF SWITCH

3. LOWER BLOWER TUBE

4. UPPER BLOWER TUBE

5. TUBE RELEASE BUTTON

6. FAN HOUSING

7. MOTOR HOUSING

Not all the accessories illustrated or de­scribed are included in standard delivery.

TECHNICAL
SPECIFICATIONS

Type WG518E (5-designation of machinery,
representative of Electric Blower)

Rated Voltage 220–240V~50/60Hz

Rated power 2500W

No load speed 26500/min

Blower speed 97km/h-177km/h

Air volume 9.1m³/min -16.7 m³/min

8

Machine weight 2.8kg

Protection degree

NOISE DATA

A weighted sound pressure LpA= 86dB(A)

A weighted sound power L

Wear ear protection

K

VIBRATION INFORMATION

a

< 2.5m/s

Typical weighted vibration

h

Uncertainty
K = 1.5m/s²

= 3.0dB(A)

pA

=101dB(A)

wA

2

The declared vibration total value may be used for
comparing one tool with another, and may also be
used in a preliminary assessment of exposure.

WARNING: The vibration emission value

during actual use of the power tool can differ
from the declared value depending on the ways in
which the tool is used dependant on the following
examples and other variations on how the tool is
used:
How the tool is used and the materials being cut or
drilled.
The tool being in good condition and well
maintained
Using the correct accessory for the tool and ensuring
it is sharp and in good condition.
The tightness of the grip on the handles and if any
anti vibration accessories are used.
And the tool is being used as intended by its design
and these instructions.

This tool may cause hand-arm vibration
syndrome if its use is not adequately managed.

WARNING: To be accurate, an estimation of

exposure level in the actual conditions of use
should also take account of all parts of the operating
cycle such as the times when the tool is switched off
and when it is running idle but not actually doing the
job. This may significantly reduce the exposure level
over the total working period.

Helping to minimise your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades
Maintain this tool in accordance with these
instructions and keep well lubricated (where
appropriate)

/II

If the tool is to be used regularly then invest in anti
vibration accessories.
Avoid using tools in temperatures of 10
Plan your work schedule to spread any high vibration
tool use across a number of days.

OPERATION

INTENDED USE:

The blower is intended for residential use only. Use
the blower outdoors to move yard debris as needed.

Assembly and Operation

ACTION FIGURE

Assembling & disassembling the
Blower Tube

Starting & Stopping
WARNING:The tool runs for a few
seconds after it has been switched
off. Let the motor come to a com­plete standstill before setting the
tool down.

0

C or less

See Fig. A&B

See Fig. C

Electric Blower WG518E

Using the Blower

Hold the blow tube approximately
8—20cm above the ground when
operating the tool.
Use a sweeping motion from side
to side. Advance slowly keeping the
accumulated debris/leaves in front
of you.
After blowing the debris/leaves into
a pile, it is easy to dispose of the
pile.

CAUTION!

—Do not blow hard objects such as
nails, bolts, or rocks.
—Do not operate the blower near
bystanders or pets.
—Use extra care when cleaning
debris from stairs or other tight
areas.
—Wear safety goggles or other
suitable eye protection, long pants
and shoes.

Adjusting the Blowing Speed
Variable Speed Switch

See Fig. D

See Fig. E

STORAGE

Store the blower and extension cord indoors, in
a cool dry location, out of reach of children and
animals.

CLEANING THE TOOL

Clean the tool regularly.
WARNING! Keep your product dry.
Under no circumstances spray with water.
— To clean the tool, use only mild soap and a damp

cloth.

— Do not use any type of detergent, cleaner or

solvent which may contain chemicals that could
seriouslydamage the plastic.

— Self lubricating bearings are used in your

product, therefore lubrication is not required.

PLUG REPLACEMENT
(ONLY FOR REWIRABLE
PLUG OF UK & IRELAND)

If you need to replace the fitted plug then follow the
instructions below.

IMPORTANT

The wires in the mains lead are colored in
accordance with the following code:

Blue = Neutral
Brown = Live

As the colors of the wires in the mains lead of this
appliance may not correspond with the colored
markings identifying the terminals in your plug,
proceed as follows. The wire which is colored blue
must be connected to the terminal which is marked
with N. The wire which is colored brown must be
connected to the terminal which is marked with L.

WARNING: Never connect live or neutral

wires to the earth terminal of the plug. Only
fit an approved 13ABS1363/A plug and the correct
rated fuse.
NOTE: If a moulded plug is fitted and has to be
removed take great care in disposing of the plug
and severed cable, it must be destroyed to prevent
engaging into a socket.

13 Amp fuse approved
to BS1362

Connect
Blue to N
(neutral)

Outer sleeve
firmly clamped

Brown L (live)

Cable grip

9

ENVIRONMENTAL
PROTECTION

Waste electrical products must not be disposed
of with household waste. Please recycle where
facilities exist. Check with your local authorities

or retailer for recycling advice.

Electric Blower WG518E

DECLARATION OF
CONFORMITYY

We,
Positec Power Tools (Europe) Ltd, PO Box 6242,
Newbury, RG14 9LT, UK

Declare that the product
Description Electric Blower Vacuum
Type WG518E (5-designation of machinery,

representative of Electric Blower)

Function Blowing debris

Complies with the following Directives,

2006/42/EC, 2014/30/EU, 2011/65/EU,
2000/14/EC amended by 2005/88/EC

2000/14/EC amended by 2005/88/EC:

- Conformity Assessment Procedure as per Annex V.

- Measured Sound Power Level 100 .1d B ( A )

- Declared Guaranteed Sound Power Level

101dB ( A )

Standards conform to

EN 60335-1 EN 50636-2-100
EN ISO 3744 EN 62233
EN 55014-1 EN 55014-2
EN 61000-3-2 EN 61000-3-3

The person authorized to compile the technical file,

Name Russell Nicholson
Address Positec Power Tools (Europe) Ltd,
PO Box 6242, Newbury, RG14 9LT, U K

10

Suzhou 2016/09/13
Allen Ding
Deputy Chief Engineer, Testing & Certification

Electric Blower WG518E

www.worx.com

Copyright © 2016, Positec. All Rights Reserved.
AR01264400
