No Touch & AirSpeed®
Quiet Economical Hand Dryers
No Touch and AirSpeed are the quiet brushless hand dryers, so no need for motor brush replacement. No Touch is an automatic operated hand dryer; Airspeed is a push-button model. Both dryers are designed for sound sensitive areas and washroomsolutionsforlighttrafficfacilities.
Product Benefits
•Quiet induction motor
•Easy maintenance brushless motor
•No Touch - Automatic
AirSpeed - push-button operation
•Durable and vandal resistant
Design Features
•Tamper resistant screws lock cover securely to base
•Resilient motor mounting rings and factory-lubricated, self-aligning bearings for long motor life
•Dynamically balanced blower wheel for vibration-free running
•Heating element is side-mounted at blower air inlet, designed for maximum heat transfer, with auto shut-off safety features controlled by an internal thermostat
•Motor is shaded pole (brushless) type operating at maximum 3,200 RPM at rated load
•Delivering 120 cubic feet per minute of air volume (5,300 LFM)
•Timer shall be electromechanical cam style with 25 amp rated switch to operate dryer for 30 seconds on push button units
Architecture & Engineering Specifications
Airspeed™ and No Touch hand dryers shall be manufactured by or for World Dryer Corporation® to include housing of .08“ thick die cast aluminum. Front panel shall be in ebony gloss for the NoTouch™ and brushed aluminum for the Airspeed™. Housing to be finished with chrome plating or white epoxy paint.
Motor shall be of shaded pole (brushless) type operating at maximum 3,200 RPM at rated load, delivering 120 cubic feet per minute of air volume (5,300 LFM). Timer shall be electromechanical cam style with 25 amp rated switch to operate dryer for 30 seconds on push button units. No Touch dryers shall be activated by means of an infrared emitting/receiving electronic control device. Hand dryers shall be listed under reexamination service of Underwriters Laboratories, Inc.
No Touch
AirSpeed
Electrical specifications:
No Touch & AirSpeed
|
110-120 V |
208-240 V |
220-240 V |
Amps |
17 |
8.5 |
8 |
Watts |
2000 |
1800 / |
1800 |
|
|
2000 |
|
|
|
|
|
Hz |
60 Hz |
60 Hz |
50 Hz |
|
|
|
|
Cover options:
No Touch - Cast Aluminum with epoxy paint or chrome Airspeed - Cast Aluminum with epoxy paint or chrome
Shipping Weight -
No Touch - 15.7 lbs / 7.1 kgs
AirSpeed - 15.3 lbs / 6.9 kgs
Shipping Size (HxWxD)-
13” x 12” x 9.3” / 330 mm x 246 mm x 241 mm
|
|
|
|
|
|
|
|
110-120 V |
208-240 V |
220-240 V |
Operation |
Mounted |
Cover Material, Cover Finish |
Unit Weight |
Unit Size (HxWxD) inch/mm |
|
|
(export 50 Hz ) |
|
|
|
|
|
|
|
|
|
|
|
|
|
NT126-005 |
NT246-005 |
NT235-005 |
Automatic |
Surface |
Aluminum, White body w/ Ebony front panel |
14 lbs / 6.4 kgs |
10.9” x 11.6” x 7.5” 277 x 295 x 191 |
|
|
|
|
|
|
|
|
NT126-004 |
NT246-004 |
NT235-004 |
Automatic |
Surface |
Aluminum, Chrome body w/ Ebony front panel |
14 lbs / 6.4 kgs |
10.9” x 11.6” x 7.5” 277 x 295 x 191 |
|
|
|
|
|
|
|
|
WA126-002 |
WA246-002 |
WA235-002 |
Push-button |
Surface |
Aluminum, White body w/ Brushed front panel |
13.6 lbs / 6.2 kgs |
10.9” x 11.6” x 7.5” 277 x 295 x 191 |
|
|
|
|
|
|
|
|
WA126-001 |
WA246-001 |
WA235-001 |
Push-button |
Surface |
Aluminum, Chrome body w/ Brushed front panel |
13.6 lbs / 6.2 kgs |
10.9” x 11.6” x 7.5” 277 x 295 x 191 |
|
|
|
|
|
|
|
|
