Spend a little Live a lot
User Manual
2.2 KW PRESSURE WASHER
ID: #05007
m
y
h
a
n
s
e
c
o
n
t
r
o
l
.
c
o
m
M
A
N
U
A
L
D
E
V
E
L
O
P
E
D
I
N
G
E
R
M
A
N
Y
User-friendly
Manual
Original instructions
QR codes take you where you want to go
quickly and easily
Whether you require product information, spare parts or
accessories, details on warranties or aftersales services, or
if you want to watch a product demonstration video, our QR
codes will take you there in no time at all.
What is a QR code?
A QR code (QR = Quick Response) is a type of matrix that can be
read with a smartphone camera and that contains a link to a
website or contact details, for example.
Advantage: You do not need to manually enter a website
address or contact details.
How it works
To scan the QR code, all you need is a smartphone with QR code
reader software and an internet connection. This type of software
can be downloaded for free from your app store.
Try it out now
Just scan the QR code with your smartphone and find
out more about the ALDI product you have purchased.
Your ALDI Service Portal
All details mentioned above can also be found in the
ALDI Service Portal at www.aldi.co.uk.
Depending on your tariff plan you may be charged for the connection.
Dok./Rev.-Nr. 194620_20161208
Overview ................................................................... 4
Package contents/device parts ...............................6
General information ................................................. 7
Reading and storing the user manual ....................... 7
Explanation of symbols ................................................ 7
Safety ........................................................................ 9
Proper use ...................................................................... 9
Safety notes ................................................................... 9
First use ................................................................... 14
Checking the washer and package contents...........14
Assembling the washer ...............................................15
Operation ................................................................ 16
Starting the washer .....................................................16
Stopping the washer ...................................................17
Adjusting the handle ................................................... 17
Using a self-suctioning washer .................................. 17
Using the cleaning attachments ............................ 18
Fitting the spray lance .................................................18
Fitting the turbo nozzle ...............................................19
Fitting the Vario pressure nozzle ..............................20
Fitting the wash brush ............................................... 20
Using the cleaner ..................................................... 21
Cleaning and maintenance .................................... 22
Cleaning the dirt filter ................................................. 23
Cleaning the high-pressure nozzle .......................... 23
Storage .................................................................... 23
Troubleshooting ..................................................... 24
Technical data ......................................................... 27
Declaration of conformity ...................................... 28
Spare parts list ........................................................ 29
Disposal ...................................................................30
Disposing of the packaging .......................................30
Disposing of the washer ............................................. 30
Contents
4
3
OFF
0
1
ON
A
2
1
4
5
6
7
8
9
10
B
5
C
12
13
14
15
16
11
17
20 19 18
6
Package contents⁄device parts
1
Handle (height-adjustable)
2
High-pressure hose (with hose clamp)
3
Hand crank (foldable)
4
Cleaning pin
5
ON/OFF switch
6
Holder for the spray gun
7
Screw connection for the water inlet hose (with adapter)
8
Button (height adjustment for the handle)
9
Cleaner container
10
Mains cord
11
Spray gun (with a swivelling lance)
12
Spray gun connection (with a quick lock)
13
Trigger
14
Safety lock
15
Quick lock (spray lance)
16
Spray lance
17
Wash brush (rotating)
18
Cleaner
19
Turbo nozzle
20
Vario pressure nozzle
General information
7
General information
Reading and storing the user manual
This user manual accompanies this 2.2 kW pressure
washer (referred to below only as “washer”).
It contains important information on start-up and handling.
Before using the washer, read the user manual carefully,
particularly the safety instructions. Failure to comply with this user
manual may result in severe injury or in damage to the washer.
The user manual is based on the standards and rules in force in
the European Union. When abroad, you must also observe
country-specific guidelines and laws.
Keep the user manual for future use. If you pass the washer on to
third parties, be sure to include this user manual.
You can also request this user manual in PDF format from our after
sales support.
Explanation of symbols
The following symbols and signal words are used in this user
manual, on the washer or on the packaging.
WARNING!
This signal symbol/word designates a
hazard with moderate degree of risk
which may lead to death or severe injury
if not avoided.
NOTICE!
This signal word warns against potential
damages to property.
This symbol provides you with useful additional
information regarding start-up or handling.
General information
8
Caution! Read the user manual prior to start-up!
This symbol indicates that the mains plug must be
disconnected from the power supply immediately if
the cord is damaged, twisted or knotted, if it has been
severed, or if the washer is left unsupervised, even
for a short period of time.
This symbol indicates that the high-pressure jet may
never be pointed directly at persons, animals, the
washer or the electrical components.
This symbol indicates that the washer must not be
connected directly to the drinking water network.
If necessary, use it only with a water backflow preventer
or an inlet hose set approved in accordance with
IEC 61770.
This symbol indicates that to wind up the high-pressure
hose the crank for the hose reel may be turned only
anticlockwise. Winding it clockwise may damage the
high-pressure hose and the washer.
98
This symbol indicates the loudness of the washer
during operation.
This symbol indicates that the washer complies with the
protection class II.
The symbol on the rear side of the washer shows the
recommended storage of the accessory parts.
The symbol “GS” indicates that the product has been
tested for safety. Products labelled with this symbol
meet the requirements of the German Product Safety
Act (ProdSG).
Safety
9
The LGA-tested quality certificate certifies consistent
quality corresponding to specific criteria that has been
tested by an independent body. It confirms the safety
and usability of the product and therefore its overall
quality.
Declaration of conformity (see chapter “Declaration of
conformity”): Products marked with this symbol meet
all applicable Community regulations for the European
Economic Area.
Safety
Proper use
The washer is designed only for cleaning façades, patios, walkways,
garden tools, machines, vehicles, tools, etc. It is only intended for
private use and is not suitable for commercial use.
Use the washer only as described in this user manual. Any other
use is deemed improper and may result in damage to property or
even personal injury. The washer is not a children’s toy.
The manufacturer or vendor accepts no liability for damage caused
by improper or incorrect use.
Safety notes
WARNING!
Risk of electric shock!
A faulty electrical installation or excessive mains voltage may result
in an electric shock.
− An experienced electrician must connect the device to the mains
and the connection must meet the requirements of IEC60364-1.
− It is recommended that the power supply for this washer
be supplied either via a fault-current circuit breaker that
interrupts the power supply as soon as the leakage current to
Safety
10
the earth exceeds 30 mA for 30 ms, or that it be equipped with
an earth tester.
− Connect the washer only if the mains voltage of the socket
corresponds to the rating plate specification.
− Connect the washer only to an easily accessible socket to allow
the washer to be disconnected from the mains quickly in the
event of a fault.
− Do not operate the washer if it is visibly damaged or if the
mains cord or mains plug is defective.
− If the supply cord of the washer is damaged, to avoid risks it
must be replaced by the manufacturer or its after sales support
or by a person with similar qualifications.
− Do not open the housing; instead, have a qualified
professional carry out the repairs. Contact a qualified
workshop for this. Liability and warranty claims are waived
in the event of repairs performed by the user, improper
connection of the device or incorrect operation.
− Only parts that comply with the original device information
may be used for repairs. This washer contains electrical and
mechanical parts which are essential for providing protection
against sources of danger.
− Do not operate the washer with an external timer or separate
telecontrol system.
− Do not immerse the washer or the mains cord or mains plug in
water or other liquids.
− Never touch the mains plug with damp hands.
− Never pull the mains plug out of the socket by the mains cord;
instead, always do so by taking hold of the mains plug.
− Never use the mains cord as a carrying handle.
− Keep the washer, mains plug and mains cord away from open
flames and hot surfaces.
− Lay the mains cord so that it does not pose a tripping hazard.
− Do not kink the mains cord and do not lay it over sharp edges.
Safety
11
− Never store the washer such that there is a risk of it falling into
a tub or a basin.
− Never reach to retrieve an electrical device if it has fallen in
water. In such a case, immediately disconnect the mains plug
from the socket.
− Make sure that children do not insert any objects in the washer.
− Always switch the washer off and pull the mains plug out of
the socket when you are not using it, when you intend to clean
it, to replace parts, or in the event of a fault.
WARNING!
Danger for children and persons with impaired physical,
sensory or mental capacities (e.g. partially disabled persons,
older persons with reduced physical and mental capacities) or
lack of experience and knowledge (e.g. older children).
− This washer may be used by persons with impaired physical,
sensory or mental capacities or those lacking experience and
knowledge if they are supervised or have been instructed in
how to safely use the washer and have understood the risks
associated with operating it.
− This washer must not be used by children. Children must be
supervised to ensure that they do not play with the device.
− Do not leave the washer unattended during operation.
− Do not let children play with the packaging. Children may get
caught in it when playing and suffocate.
− Do not allow children to play with the cleaner. Children could
swallow small parts and choke.
WARNING!
Danger of explosion!
The spraying of flammable liquids can cause an explosion.
− Do not spray any flammable liquids and do not use the washer
in explosive environments.
Safety
12
WARNING!
Risk of electric shock!
Unsuitable extension cords may be dangerous and could result in
an electric shock.
− If an extension cord is used, the mains plug and coupling must
be water-tight and must never be placed in water. Mains plug
and coupling must bear the IP44 label. Use a cord reel that
keeps the socket at least 60 mm above the ground.
WARNING!
Risk of injury!
High-pressure jets may be dangerous if used improperly.
− The high-pressure jet must not be pointed at persons, active
electrical equipment or at the washer itself.
− Do not use the washer within range of other persons unless
they are wearing protective clothing.
− Do not point the washer at yourself or other persons to clean
clothing or footwear.
− Before first start-up, familiarise yourself with the control
elements and safety functions of the washer and the spray
gun.
− When operating the washer, wear suitable personal protective
equipment (PPE) such as safety footwear, safety gloves,
protective helmets with visor, ear protection, etc.
− Before you begin any kind of cleaning, check the work area for
objects that could pose a risk. Remove all objects that you could
stumble over from the work area, e.g. toys or garden furniture.
− Ensure that you have a stable stance, especially considering
the possibility of kickback when you depress the trigger of the
spray gun.
− Be particularly careful when cleaning tyres. Car tyres and
tyre valves could be damaged or pop if handled improperly.
Safety
13
Discolouration of the tyres indicates the first signs of damage.
Damaged vehicle tyres and tyre valves pose a risk to life. Keep
the high-pressure jet at a distance of at least 30 cm!
− The high-pressure washer must not be used by children or
untrained persons.
WARNING!
Risk of injury!
Even if you use this washer in compliance with applicable
regulations, there are always residual risks. The following risks
associated with the construction and design of this washer may
occur:
− Injury to health attributed to hand and arm vibrations if the
washer is used over a prolonged period of time or if it is not
guided and maintained properly.
− Eye injury due to flying parts or particles of dirt blown about
by the high-pressure jet. Always wear suitable eye protection
when working with the washer.
− Skin injury from accidental contact with the high-pressure
jet or from flying parts or particles of dirt blown about by it.
Always wear suitable protective equipment, clothing and firm
footwear when working with the washer.
− Injury to hearing due to noise exposure. Wear suitable ear
protection to prevent damage to your hearing when working
with the washer.
NOTICE!
Risk of damage!
Improper handling of the washer may result in damage to the
washer.
− Do not use the washer if a connection line or important parts
of the washer are damaged, e.g. safety equipment, highpressure hoses, spray gun, etc.
First use
14
− High-pressure hoses, fittings and couplings are important
for guaranteeing the safety of the device. Only use highpressure hoses, fittings and couplings recommended by the
manufacturer.
− Only use original spare parts from the manufacturer or
approved by the manufacturer to guarantee the safety of the
device.
− This washer was developed to use the cleaners delivered or
recommended by the manufacturer. Using other cleaners or
chemicals can affect the safety of the washer.
− Place the washer on a stable, level surface. Operate it in an
upright position only and never in a horizontal position.
First use
Checking the washer and package contents
NOTICE!
Risk of damage!
If you are not cautious when opening the packaging with a sharp
knife or other pointed objects, you may quickly damage the washer
or the accessories.
− Be very careful when opening.
1. Carefully take the washer and the accessories out of the
packaging.
2. Check to make sure that the delivery is complete
(see Fig. A, B, and C).
3. Check whether the washer or the individual parts exhibit
damage. If any damage is visible, do not use the washer. Contact
the manufacturer at the service address specified on
the warranty card.
First use
15
WARNING!
Risk of injury!
The washer could be inadvertently activated and cause injury.
− Ensure that the washer is disconnected from the mains before
you assemble the washer.
Assembling the washer
WARNING!
Health hazard!
The washer must not be directly connected to the drinking water
network because the return flow of water poses a risk to the
drinking water.
− Use a water backflow preventer or an inlet hose set approved
in accordance with IEC 61770.
− Cleaning car motors and other objects contaminated by oil and
various lubricants is permissible only on such areas where the
waste water is diverted by an oil separator.
− Water that has flowed through the backflow preventer is
considered unfit for drinking.
1. Insert the plug connection of the high-pressure hose
2
in the
connection
12
on the handle of the spray gun
11
.
2. Insert any given cleaning nozzle onto the spray gun. See section
“Using the cleaning attachments”.
3. Connect a water inlet hose with a quick-lock coupling
(not included in the scope of supply) with the screw connection
for the water inlet hose
7
. The water temperature may amount
to no more than 40 °C.
4. Insert the mains plug into a properly installed socket with an
earthing contact and alternating voltage in accordance with the
washer’s rating plate.
Operation
16
Operation
NOTICE!
Risk of damage!
Improper handling of the washer may result in damage to the
washer.
− Familiarise yourself with all control elements before starting
up the washer. Before each use, make sure that the washer is
functional.
− Ensure that all parts of the washer are securely attached.
− Ensure that the water connection and the high-pressure hose
are not leaking.
Starting the washer
NOTICE!
Risk of damage!
Using the washer without water could result in damage to the
washer.
− Never operate the washer without water, as dry operation
could damage the pump. Use a water filter if the supplied
water is contaminated.
1. Fully open the water tap for the water intake.
2. Unlock the safety lock
14
of the spray gun
11
by pushing
downwards.
3. Press the trigger
13
until a steady stream of water is dispensed.
Then let go of the trigger.
4. To switch on the washer, move the ON/OFF switch
5
to ON.
The high-pressure pump starts to run.
5. To start the cleaning work, hold the spray gun tightly with both
hands and press the trigger again.
Operation
17
Stopping the washer
1. Release the trigger
13
. The high-pressure pump will stop
immediately.
2. Move the ON/OFF switch
5
to OFF.
3. Close the water tap for the water inlet.
4. Push the trigger until the pressure in the washer has been
released.
5. Lock the trigger by pushing
downwards onto the safety lock
14
.
Adjusting the handle
The handle can be adjusted in two positions. The washer is
supplied with a lowered handle.
1. Press the button
8
for the height adjustment and pull the
handle
1
upwards until it locks into place. The washer can be
used and easily moved in this position.
2. Press the button again to lower the handle and push the handle
downwards until it locks into place.
Using a self-suctioning washer
Alternatively, you can also supply the high-pressure washer from
an open reservoir (water butt, industrial water tank).
Use a suction hose with a suitable suction basket to protect the
pump from foreign bodies. We recommend using a high-quality
suction hose made of reinforced material, the diameter of which
should be at least 13 mm and the maximum length 3 m. You can
achieve the best results by integrating a non-return valve and filter
in addition to the suction basket.
To connect the suction hose, please proceed as follows:
1. Place the high-pressure washer in close proximity to the water
source on a stable and level surface. Observe the maximum
recommended suction height of 0.5 m.
Using the cleaning attachments
18
2. Fill the suction hose with water and allow all of the entrapped air
to escape.
3. Connect the suction hose to the washer. Remove all attachments.
4. Switch on the washer and press the trigger
13
until the washer
discharges a steady stream of water. If this is not achieved within
2 to 3 minutes, switch the washer off and check the suction hose
for entrapped air.
5. Switch off the washer and connect the desired attachment.
6. Operate the washer as usual.
In addition, please refer to the user manual of the relevant
accessory part.
Using the cleaning attachments
Fitting the spray lance
WARNING!
Risk of injury!
The high-pressure jet is very hard and can inflict injury.
− Start using the washer by working at a substantial distance
and reduce this as needed.
The spray lance
16
is equipped with a quick lock
15
to assist in
changing the cleaning attachments.
1. Insert the spray lance into the spray gun
11
in such a way that
the end of the quick lock points away from the spray gun.
2. To fix the spray lance, push it slightly downwards and turn it
clockwise at the same time.
Removing the spray lance
1. Stop the washer and move the ON/OFF switch
5
to OFF.
2. Push the trigger
13
until the pressure in the washer has been
released.
Using the cleaning attachments
19
3. Push the spray lance
16
slightly in the direction of the spray
gun
11
and turn the spray lance anticlockwise at the same time.
4. Remove the spray lance.
Fitting the turbo nozzle
NOTICE!
Risk of damage!
When using the turbo nozzle, there is a very high risk of damaging
sensitive surfaces.
− Be very careful when using the turbo nozzle during cleaning.
− Start using the washer by working at a substantial distance
and reduce this as needed.
The turbo nozzle
19
produces a rotating high-pressure jet that can
also get rid of stubborn dirt.
1. Place the turbo nozzle on the quick lock
15
of the spray lance in
such a way that the small rectangular elevation fits exactly into
the rectangular recess in the spray lance
16
.
2. Press the turbo nozzle down firmly on the spray lance.
The yellow button of the quick lock clicks once the nozzle is
positioned correctly.
Removing the turbo nozzle
1. Stop the washer and move the ON/OFF switch
5
to OFF.
2. Push the trigger
13
until the pressure in the washer has been
released.
3. Press the yellow button of the quick lock
15
on the spray lance
16
and pull off the turbo nozzle
19
.
Using the cleaning attachments
20
Fitting the Vario pressure nozzle
The Vario pressure nozzle
20
produces a fan beam at a 30° angle.
1. Place the Vario pressure nozzle on the quick lock
15
of the spray
lance in such a way that the small rectangular elevation fits
exactly into the rectangular recess in the spray lance
16
.
2. Press the Vario pressure nozzle down firmly on the spray lance.
The yellow button of the quick lock clicks if the Vario pressure
nozzle is positioned correctly.
3. Turn the Vario pressure nozzle to set the desired water pressure.
Removing the Vario pressure nozzle
1. Stop the washer and move the ON/OFF switch
5
to OFF.
2. Push the trigger
13
until the pressure in the washer has been
released.
3. Press the yellow button of the quick lock
15
on the spray lance
16
and pull off the Vario pressure nozzle
20
.
Fitting the wash brush
The wash brush
17
is suitable for cleaning surfaces delicately.
In the process, the high-pressure jet is used to operate the wash
brush; the water strikes the surface to be cleaned only at lower
pressure.
The rotating wash brush head achieves the cleaning effect and the
removed dirt is washed away with the water.
1. Remove the spray lance
16
, see section “Removing the spray
lance”.
2. Put the wash brush onto the spray gun
11
.
3. To fix the wash brush, push it slightly downwards and turn it
clockwise at the same time.
Using the cleaner
21
Removing the wash brush
1. Stop the washer and move the ON/OFF switch
5
to OFF.
2. Push the trigger
13
until the pressure in the washer has been
released.
3. Push the wash brush
17
slightly in the direction of the
spray gun
11
and turn the wash brush anticlockwise at the
same time.
4. Remove the wash brush.
Using the cleaner
NOTICE!
Risk of damage!
Using cleaners other than those recommended by the manufacturer
can affect the safety of the washer.
− Only use cleaners supplied or recommended by the
manufacturer.
WARNING!
Risk of chemical burns!
Cleaners that come into contact with the skin, eyes or mucous
membranes can cause burns.
− Do not allow the cleaners to come into contact with the skin,
eyes and mucous membranes.
− In the event of contact with the cleaners, immediately flush
the applicable areas with plenty of clean water and consult a
physician if necessary.
Switch off the washer before adding the cleaner to the
washer.
Cleaning and maintenance
22
The washer is equipped with a device for the automatic supply of
cleaners for the water jet.
1. Prepare the cleaning solution by diluting the cleaner
18
1 part
to 10 with water.
2. Lock the trigger
13
by pushing
downwards onto the safety
lock
14
.
3. Take the cap off of the cleaner container
9
and pull the hose
out.
4. Fill the cleaning solution into the cleaner container.
5. Guide the hose back into the cleaner container and screw the
cap back on.
6. Use the washer with the desired cleaning attachment.
Cleaning and maintenance
WARNING!
Risk of electric shock!
Cleaning and maintenance of the washer while it is connected to
the mains may lead to an electric shock.
− Each time before cleaning or maintenance work, switch the
washer off and disconnect it from the mains.
− Do not clean the washer with a high-pressure jet.
NOTICE!
Risk of damage!
Improper cleaning may damage the washer.
− Do not use any aggressive cleaners, brushes with metal or
nylon bristles or sharp or metallic cleaning utensils such as
knives, metal sponges and the like. These can damage the
surfaces.
1. Before cleaning, pull the mains plug out of the socket.
2. Wipe the washer and the accessories off with a slightly damp cloth.
Storage
23
Cleaning the dirt filter
The washer is equipped with a dirt filter to protect the pump. If the
dirt filter is not kept clean, the flow of water to the washer will be
restricted and the pump could be damaged.
1. Check the dirt filter after each use.
2. Screw off the adapter on the screw connection for the water
inlet hose
7
and take out the dirt filter.
3. Rinse out the dirt filter until it is free of dirt and deposits.
4. Insert the dirt filter again and screw the adapter on the screw
connection for the water inlet hose tightly.
Cleaning the high-pressure nozzle
1. Remove the cleaning pin
4
from the rear side of the washer.
2. Use the cleaning pin to clean the high-pressure nozzles of the
cleaning attachments.
3. Re-insert the cleaning pin in the rear of the washer.
Storage
NOTICE!
Risk of damage!
There is always some leftover water in the washer and the pump
that could result in damage to the washer.
− Do not store the washer at temperatures below the freezing
point, as this may result in frost damage.
− If you take the washer out of commission for a prolonged
period of time, empty the cleaner container and let the water
drain out of the high-pressure hose.
− Store the washer upright in a dry, well ventilated location
protected from access by children.
− Wind the high-pressure hose
2
using the hand crank
3
anticlockwise onto the hose reel.
Troubleshooting
24
− Secure the end of the hose with the hose clamp.
− Wind the mains cord
10
around the cord holder at the rear side
of the device.
− Store the accessory parts in the compartments provided for this
purpose on the front and rear side of the washer.
Troubleshooting
WARNING!
Risk of injury!
Tampering with the washer could pose a risk to life from electric
shock, damage the washer and void warranty claims.
− Do not make any modifications to the washer.
The following table provides assistance in the event of
malfunctions. If the solutions provided here are unsuccessful,
contact the manufacturer or an authorised service centre at the
service address specified on the warranty card.
Fault Cause Solution
No function The power supply is
interrupted.
Check the power
connection, mains
cord
10
and fuse; have
repairs performed by an
electrician if necessary.
The washer is
switched off.
Move the
ON/OFF switch
5
to ON.
Individual
components are
defective.
Contact the
manufacturer or an
authorised service
centre at the service
address specified on the
warranty card.
Troubleshooting
25
Fault Cause Solution
Washer is
working, but
keeps cutting
out.
The mains cord
10
is
damaged.
Contact the
manufacturer or an
authorised service
centre at the service
address specified on the
warranty card.
An internal electrical
connection has
become loose.
The ON/OFF switch
5
is defective.
No pressure
or only slight
pressure is built
up.
There is air in the
washer.
Operate the washer
without connecting
the spray gun
11
until
the water is dispensed
without bubbles.
There is no water or
an insufficient supply
of water.
Check your water
connection.
Check the water inlet
hose for leaks or
blockage.
The dirt filter is
clogged.
Clean the dirt filter; see
section “Cleaning the
dirt filter”.
The washer draws in
air.
Check for leaks in the
water inlet hose.
Troubleshooting
26
Fault Cause Solution
Large
fluctuations in
pressure
The high-pressure
nozzle is clogged.
Clean the high-pressure
nozzle; see section
“Cleaning the
high-pressure nozzle”.
There is only
insufficient water
pressure.
Check the water
pressure.
The water inlet hose is
kinked.
Check the water inlet
hose.
The washer has
a leak.
The connections of
the water inlet hose
are loose.
Tighten the adapter on
the screw connection
for the water inlet
hose
7
and the
screw connection on
your water tap until
hand-tight.
The pump or the
internal connections
have a leak.
Contact the
manufacturer or an
authorised service
centre at the service
address specified on the
warranty card.
Technical data
27
Technical data
Model: Q1W-SPO5-2200A
Article number: 94313
Power consumption: 2200W
Operating pressure: max. pressure: 15MPa (150bar)
Nominal pressure: 11MPa (110bar)
Input pressure/temperature max.: 1.0MPa (10bar)/40°C
Power consumption: 9A
Sound power level: L
WA
94dB (uncertainty KWA: 4 dB)
Guaranteed sound power level: LWA 98dB
Vibration emission value: ≤2.5m/s
2
(uncertainty K: 1.5m/s2)
Water consumption: max. 450l/h
Impact force of the water jet: 13N
Length of power cord: 5m
Cord specification: H05VV-F 2×1.0 mm
2
Cleaner container capacity: 1l
IP Code: IPX5
Protection class: II
Weight
without accessories:
incl. accessories:
10.7kg
12.6kg
Motor specification: Single-phase alternating current
motor, 230V~/50Hz
Pump specification: Aluminium with safety valve;
3-piston pump; piston made
of hardened stainless steel;
wobbling disc material made
of metal
The values for noise and vibration emissions were determined in
accordance with EN 60335-2-79:2012.
Declaration of conformity
28
Declaration of conformity
EU Declaration of Conformity
We,
MEROTEC GmbH
D-47877 Willich, Hanns-Martin-Schleyer Str. 18a, Germany
herewith declare that our product
High Pressure Water Cleaner
Model no. Q1W-SP05-2200 und Q1W-SP05-2200A
complies with the following directives:
Machinery Directive 2006/42/EC
EMC Directive 2014/30/EU
Noise Directive 2000/14/EC
RoHS 2011/65/EU
Applied harmonized standards:
EN 60335-1:2012+A11:2014
EN 60335-2-79:2012
EN 55014-1:2006+A1:2009+A2:2011
EN 55014-2:1997+A1:2001+A2:2008
EN 61000-3-2:2006+A1:2009+A2:2009
EN 61000-3-3:2013
EN 62233:2008
Document representative:
Dirk Wohlrab
MEROTEC GmbH
Datum: 01.12.2016
Authorised Signature:
Ronald Menken
General Manager
MEROTEC GmbH
Spare parts list
29
Spare parts list
Spare part Part number
(see package
contents page 6)
Order
number
Hand crank (foldable) 3 1172B10
Cleaning pin 4 1142005
Adapter for the water inlet 7 1151C01
Cleaner container 9 1175022
Cleaner container cap n/a 1119003
Spray gun (with a swivelling lance) 11 01106BG
Spray lance 16 1106B50
Wash brush (rotating) 17 01118BQ
Cleaner 18 1151C14
Turbo nozzle 19 1106B51
Vario pressure nozzle 20 1106B52
Right wheel n/a 1151C07
Left wheel n/a 1151C05
Disposal
30
Disposal
Disposing of the packaging
Dispose of the packaging separated into single type
materials. Dispose of cardboard and carton as waste
paper and film via the recyclable material collection
service.
Disposing of the washer
(Applicable in the European Union and other European states with
systems for the separate collection of reusable waste materials)
Old devices must not be disposed of with household
waste!
If the washer can no longer be used, every user is
required by law to dispose of old devices separately
from their household waste, e.g. at a collection point
in their community/borough. This ensures that old
devices are recycled in a professional manner and also
rules out negative consequences for the environment.
For this reason, electrical equipment is marked with the
symbol shown here.
PRODUCED IN CHINA FOR:
ALDI STORES LTD. PO BOX 26, ATHERSTONE
WARWICKSHIRE, CV9 2SH.
ALDI STORES (IRELAND) LTD.
PO BOX 726, NAAS, CO. KILDARE.
Visit us at www.aldi.com
GB IRE
Great care has gone into the manufacture of this product and
it should therefore provide you with years of good service
when used properly. In the event of product failure within its
intended use over the course of the first 3 years after date of
purchase, we will remedy the problem as quickly as possible
once it has been brought to our attention. In the unlikely
event of such an occurrence, or if you require any information
about the product, please contact us via our helpline support
services, details of which are to be found both in this manual
and on the product itself.
YEARS
WARRANTY
3
Spend a little Live a lot
MODEL:
Q1W-SPO5-2200A
support@coreservice.co.uk
+441904727501
+35319022605
AFTER SALES SUPPORT
IREGB
94313
04/2017
Loading...
