Workzone PAP110 User Manual

63569

1100W AIR COMPRESSOR WITH 11
PIECE ACCESSORY KIT

Product

Info

https://help.tools/

Ensure you keep your manual in a safe place for
future reference.

Read all safety warnings and all instructions

thoroughly before operating this product.

IM Ed3 02/2019

User Manual

Original Instruction

QR codes take you where you want to go
quicky and easily

Whether you require product information, spare parts or
accessories, details on warranties or aftersales service, or if you
want to watch a product demonstration video, our QR codes will
take you there in no time at all.

What is a QR code?

A QR-code (QR=Quick Response) is a type of matrix that can be
read with a smartphone camera and that contains a link to a
website or contact details, for example.
Advantage: You are not required to manually enter a website
address or contact details.

How it works

To scan the QR code, all you need is a smartphone with QR
codes reader software and an Internet connection*. This type of
software can be downloaded for free from your smartphone’s
app store.

Try it out now

Just scan the QR code with your smartphone and find out more
about the Aldi product you have
purchased*.

* Depending on your tariff you may be charged for the connection.

Product

Info

1

1

Contents

Pack contents / parts...................................................

................

....

02

Contents of carton....................................................

......................

...0

3

Description of symbols...................................................................04

General Safety Warnings...................................................

.............05

Air Pump Safety Warnings..................................................................05

Component List ..................................................................

.........

...06

Assembly ......................................

...............

..........................

...

......07

Operating

Instructions...

.......................

..................

..............

.........10

Intended Use ...................................

...............

..........

........................

.10

Preparation......................................

...............

..........

........................

.10

Operation.................................

..................................

.................

......11

Maintenance

........................................................................

.........

...

15

Warranty

........................................

...............

....

..............................

.17

Environmental protection.............

........

...............

......

....................

17

What your 3 year warranty means.

............

.................................. 18

Service Support..

................

...................................

..............

....

.......

.18

Accessories and After Sales Parts.

...................

.........

.................

...19

Troubleshooting..

.............

.....

...................................................

......

.20

Technical Data.

...................

.................................................

.........

... 21

2

2

Pack contents / parts

Congratulations on the purchase of your Workzone® Titanium 1100W
Air Compressor. When you open your packaging, first remove all items
and check there are no parts damaged or missing. If you find anything
wrong, do not operate the product until the parts have been replaced
or the fault has been rectified. Failure to do so could result in serious
personal injury.

NOTE: First time users or inexperienced operators pay particular
attention to the operation of the 1100W Air Compressor, including
details of starting and stopping and correct use of the 1100W Air
Compressor on pages 7-14, as well as the maintenance instructions on
pages 15-16.

Intended use of the 1100W Air Compressor

NOTE: This product is for private domestic DIY use only.

It is not suitable for commercial, industrial or trade use. This 1100W Air
Compressor is mainly used to generate compressed air for compressed­air driven tools which can be driven with an air volume of up to approx.
180 l/min (e.g. tyre inflator, blow-out pistol and paint spray gun). Due
to the limited air output it is not possible to use the compressor to drive
tools with very high air consumption (for example orbital sanders, rod
grinders and hammer screwdrivers).
Use the tool and accessories only for intended applications.

3

3

Pack contents / parts

Contents of carton

1 x 1100W Air Compressor
1 x Nozzle Adapter to suit 3-piece nozzle set
1 x 3m Compressed air hose
1 x Hose with valve adapter/connector
1 x Air Gun with Pressure Gauge
1 x Universal Adapter
1 x Screw-on Valve Adapter
1 x Deflating Adapter
1 x Universal Adapter, for valves with diameter 6 mm
1 x Blower Adapter
1 x Valve Adapter
1 x Universal Adapter, for valves with diameter 9 mm
1 x Ball Inflating Needle
1 x Instruction Manual
1 x Warranty Card & details

4

4

Description of symbols

Warning

Read operator’s manual

Electrical shock

Wear ear protection

Wear eye protection

Do not open the cock before the air hose is attached

Warning: risk of high temperature

Warning: Compressor unit may start without warning

Regulatory Compliance Mark. Appliance complies with
requirements of electrical approval & EMC in Australia.

Double insulated for additional protection.

36 Month Warranty Period.

The instruction manual, rating plate, or on the product itself, may
show these symbols. These represent important information about the
product or instructions on its use.

36

5

5

General safety warnings

WARNING Read all safety warnings and all instructions.

Failure to follow the warnings and instructions may result in

electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

- This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety.

- Children should be supervised to ensure that they do not play with
the appliance.
If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard.

Air pump safety warnings

1. High pressure air could result in death or serious injury. Never
operate above maximum operating pressure. Do not operate with
pressure switch or safety valve set above maximum allowable
working pressure.

2. Hot compressors surfaces could result in serious injury. Allow
compressor to cool before touching.

3. Inhalation hazard. Using compressor to supply breathing air could
result in death or serious injury. Do not use compressor to supply
breathing air.

4. Do not restrict compressor ventilation openings or place objects
against or on top of compressor. Operate compressor only in a clean,
dry, well ventilated area.

5. Do not operate unattended. Always turn off and unplug unit when
not in use.

Air Compressor

AFTER SALES SUPPORT

(toll free)MODEL No.: PAP110 • 02/2019 63569

e-mail: [e-mail]

AUS

6

1300 889 028

AUS

Component List

Component List

1. Carry handle

2. Power cord

3. ON/OFF switch

4. Compressor housing

5. Quick-lock coupling

6. Air gun with pressure gauge

7. Vent valve

8.

Nozzle adapter to suit 3-piece nozzle set

9. Compressed air hose

10. Hose with valve adapter/ connector

11. Universal adapter

12. Screw-on valve adapter

13. Deflating adapter

14.

Universal adapter, for valves with diameter
6 mm

15. Blower adapter

16. Valve adapter

17. Universal adapter, for valves with
diameter 9 mm

18. Ball inflating needle

19. On board storage area

20. Air gun trigger

21. Air gun inlet connection

22. Air gun outlet

23. Air gun release valve

24. Power cord storage area

1

3

7

21

4

22

20

6

10

23

11

12

13 1714 151816

2

24

5

9

8

19

Air Compressor

AFTER SALES SUPPORT

(toll free) MODEL No.: PAP110 • 02/2019 63569

e-mail: [e-mail]

AUS

7

1300 889 028

AUS

Assembly

ASSEMBLY

NOTE: You must fully assemble the appliance before using it for the

first time!
NOTE: At temperatures below +5°C, sluggishness may make starting
difficult .

Connecting the compressed air hose, air gun with pressure
gauge & hose with valve adapter/connector

WARNING! Ensure the air compressor is switched off and

disconnected from the mains power supply before undertaking

any assembly.

1. Insert the smaller fitting on the end of the compressed air hose (9)
into the quick -lock coupling (5) on the air compressor. (Fig.A) The
connection is secure when you hear a click.

2. Connect the air gun with pressure gauge (6) to the opposite end of
the compressed air hose (9), (Fig. B) by inserting the air gun inlet
connection (21) into the coupling. The connection is secure when you
hear a click.

3. Screw the hose with valve adaptor/connector (10) in a clockwise
direction to connect to the air gun with pressure gauge (6). (Fig. C)

NOTE: A 14mm spanner (not supplied) can further secure the
connection.

B

C

1

2

A

Air Compressor

AFTER SALES SUPPORT

(toll free)MODEL No.: PAP110 • 02/2019 63569

e-mail: [e-mail]

AUS

8

1300 889 028

AUS

Connecting adapters to the valve adapter / connector

WARNING: Ensure the air compressor is switched off and

disconnected from the mains power supply before undertaking

any assembly.

1. Choose the adapter required for the task to be undertaken.

2. To connect an adapter to the hose with valve adapter/connector
(10), first press the air gun release valve (23), then insert the required
adapter into the hose end and release the release valve (23) (Fig D).
Make sure that the adapter is locked in firmly.

3. When connecting the universal adapter (11), screw-on valve
adapter (12) or the deflating adapter (13), these adapters must first
be connected to the nozzle adapter to suit 3-piece nozzle set (8). To
do this, insert the either of the : universal adapter (11), screw-on valve
adapter (12) or the deflating adapter (13), through the rear of the
nozzle adapter to suit 3-piece nozzle set (8) (Fig E). Ensure that the
fitting is secure, then insert the nozzle adapter to suit 3-piece nozzle
set into the hose with valve adapter/connector (10) by pressing the air
gun release valve (23) and inserting into the hose end. Release pressure
on the air gun release valve (23) and ensure the fitting is secure.
To remove the adapter, press down the air gun release valve (23) and
pull the relevant adapter outwards.

Disconnecting the compressure air hose, air gun with pressure
gauge & hose with valve adapter/connector

1. To disconnect the compressed air hose (9) from the quick-lock
coupling (5), pull the sleeve on the quick-lock coupling backwards, and
pull the compressed air hose (9) away from the quick-lock coupling (5).

E

D

1

2

Assembly

Air Compressor

AFTER SALES SUPPORT

(toll free) MODEL No.: PAP110 • 02/2019 63569

e-mail: [e-mail]

AUS

9

1300 889 028

AUS

The quick-lock coupling (5) will click when the compressed air hose (9)
is disengaged.

WARNING: when releasing the quick-lock coupling, be sure to
hold the coupling piece to protect yourself against injury from

the rebounding hose.

2. To disconnect the air gun with pressure gauge (6) from the

compressed air hose (9), release the coupling connection by pulling the
sleeve on the coupling backwards and then remove the air gun inlet
connection (21) from the coupling connection. You will hear a click
when the air gun inlet connection (21) is disengaged.

3. To remove the hose with valve adapter/connector (10) from the air

gun with pressure gauge (6),screw the connection in an anti clockwise
direction until loose enough to remove.
NOTE: A 14mm spanner (not supplied) can also assist to loosen the
connection.

Assembly

Air Compressor

AFTER SALES SUPPORT

(toll free)MODEL No.: PAP110 • 02/2019 63569

e-mail: [e-mail]

AUS

10

1300 889 028

AUS

Operating Instructions

NOTE: Before using the tool, read the instruction book

carefully.

Intended Use

This Air Compressor is designed to generate compressed air for
compressed-air driven tools which can be driven with an air volume of
up to approx. 180 l/min (e.g. tyre inflator, blow-out pistol and paint
spray gun). Due to the limited air output it is not possible to use the air
compressor to drive tools with very high air consumption (for example
orbital sanders, rod grinders and hammer screwdrivers).

The equipment is to be used only for its prescribed purpose. Any other
use is deemed to be a case of misuse.

Preparation

Before you connect the equipment to the mains power supply make
sure that the data on the rating plate are identical to the mains data.

● Install the air compressor near the point of consumption.

● Avoid long air lines and supply lines (extension cables).

● Make sure that the intake air is dry and dust free.

● Do not install the air compressor in a damp or wet room.

● The air compressor may only be used in suitable rooms (with good

ventilation and an ambient temperature from +5 °C to 40 °C). There
must be no dust, acids, vapors, explosive gases or inflammable gases
in the room.

● The air compressor is designed to be used in dry rooms. It is
prohibited to use the compressor in areas where work is conducted
with sprayed water.

Operating Instructions

Air Compressor

AFTER SALES SUPPORT

(toll free) MODEL No.: PAP110 • 02/2019 63569

e-mail: [e-mail]

AUS

11

1300 889 028

AUS

Operating Instructions

WARNING! Do not use the machine in high temperature and
high humidity environment.

1. Connect the power plug to the main power supply and turn on.

2. To switch on the air compressor, press the “I” on the ON/OFF switch
(3).

3. To switch off the air compressor, press the “O” on the ON/OFF switch
(3), and then disconnect the power plug from the mains power supply.
(See Fig F)

4. Run the attached air tool until no compressed air remains in the hose,
by pushing in the vent valve (7).

2. Using the air gun with pressure gauge (6)

The air gun with pressure gauge (6) is used to inflate car tyres. With the
corresponding accessories it can also be used to inflate and regulate
bicycle tyres, inflatable dinghies, air mattresses, balls etc. (See Fig. G, H,
I)
Pressure can be released by pushing in the vent valve (7) .

- Pumping up balls with the help of the ball inflating needle (18).

- The valve adapter (16) enables bicycle tyres to be inflated.
NOTE: After the air nozzle is connected, rotate it 1 or 2 turns clockwise
to ensure that it does not leak. (See Fig. J)

F

Operation

1. ON/OFF switch (See Fig. F)

NOTE: It is recommended to use in conjunction

with this appliance a Residual Current Device
(RCD) of rating not exceeding 30mA.
NOTE: There will be a buzz after the air
compressor starts, and there will be automatic
pressure relief after the safety air pressure is
reached (the machine has a deflated sound).

This is normal.
NOTE: Turn off the machine without operation. Long idle conditions
can affect machine life.

Air Compressor

AFTER SALES SUPPORT

(toll free)MODEL No.: PAP110 • 02/2019 63569

e-mail: [e-mail]

AUS

12

1300 889 028

AUS

WARNING! The pressure gauge on the air gun has not been
officially calibrated! After inflating, check the air pressure with a

calibrated device.

WARNING! Before inflating the object, make sure that you

understand the allowable air pressure of the object being filled
and the state of the object being filled (such as rubber aging, surface
damage, etc.). Otherwise there is a safety risk!

WARNING! The pressure gauge displays the output air pressure

value when it is inflated, so be sure to check the air pressure
value of pressure gauge constantly to see the air pressure of the object
being filled! Otherwise there is a safety risk!

3. Using the air gun with pressure gauge as a blowing gun

You can use the blower adapter (15) as an air blow gun to clean dust
out of hollow or hard to reach areas, such as vents in electrical items or
between the keys on a computer keyboard. It is also useful for cleaning
soiled equipment.
Screw the blower adapter (15) in a clockwise direction on to the air gun
outlet (22). (See Fig. K, L)

H

G

I

J

Operating Instructions

Air Compressor

AFTER SALES SUPPORT

(toll free) MODEL No.: PAP110 • 02/2019 63569

e-mail: [e-mail]

AUS

13

1300 889 028

AUS

4. Using the Nozzle adapter to suit 3-piece nozzle set

The nozzle adapter to suit 3-piece nozzle set (8) enables you to use the
following additional capabilities of the tyre inflation device:

- Blowing up inflatable pools / boats / air mattresses with the help of
the universal adapter (11).

- Blowing up items with threaded valves (e.g. Boats) with the screw-on
valve adapter (12).

- Deflating large volume items. The deflating adapter (13) can be used
for this.

5. Using the Universal adapter/s for valves with diameter 6mm /

9mm

Insert the universal adapter for valves with diameter 6 mm (14) or
the universal adapter for valves with diameter 9 mm (17) into the
hose with valve adapter/connector (10) by pressing the air gun release
valve (23) and inserting into the hose end. Release pressure on the air
gun release valve (23) and ensure the fitting is secure. To remove the
universal adapter for valves with diameter 6 mm (14) or the universal
adapter for valves with diameter 9 mm (17), press down the air gun
release valve (23) and pull the relevant adapter outwards.

WARNING! The following behavior may cause damage to the
power cord /cable.

- Passage points, where connection cables are passed through
windows or doors.

- Kinks where the connection cable has been improperly fastened or
routed.

- Places where the connection cables have been cut due to being

K

L

1

2

Operating Instructions

Air Compressor

AFTER SALES SUPPORT

(toll free)MODEL No.: PAP110 • 02/2019 63569

e-mail: [e-mail]

AUS

14

1300 889 028

AUS

driven over.

- Insulation damage due to being ripped out of the wall outlet.

- Cracks due to the insulation ageing.

Such damaged electrical connection cables must not be used and are
life-threatening due to the insulation damage. Check the electrical
connection cables for damage regularly. Make sure that the connection
cable does not hang on the power network during the inspection.
If the power cord / cable is damaged or worn it must be replaced by
an authorised service agent or a similarly qualified person in order to
avoid hazard.

Operating Instructions

Air Compressor

AFTER SALES SUPPORT

(toll free) MODEL No.: PAP110 • 02/2019 63569

e-mail: [e-mail]

AUS

15

1300 889 028

AUS

Cleaning

Keep the equipment free of dirt and dust as far as possible. Wipe the
equipment with a clean cloth or blow it down with compressed air at
low pressure.
We recommend that you clean the equipment immediately after you
use it.
Clean the equipment regularly with a damp cloth and some soft soap.
Do not use cleaning agents or solvents; these may be aggressive to the
plastic parts in the equipment. Ensure that no water can get into the
interior of the equipment.
You must disconnect the hose and any spraying tools from the air
compressor before cleaning. Do not clean the air compressor with
water, solvents or similar cleaning agents.

Storage

Pull out the mains plug and ventilate the equipment and all connected
pneumatic tools. Switch off the air compressor and make sure that
it is secured in such a way that it cannot be started up again by any
unauthorized person.
Store the air compressor only in a dry location which is not accessible to
unauthorized persons. Always store upright, never tilted!
Storage power cord, hose and accessories .
The power cord can be stored in the power cord storage area (24).
The air hose can be stored in the on board storage area (19).

Maintenance

WARNING! Ensure the air compressor is switched off and

disconnected from the mains power supply before undertaking

any maintenance or cleaning.

WARNING! Wait until the equipment has cooled down
completely! Risk of burns!
WARNING! Always depressurize the equipment before carrying
out any cleaning and maintenance work! Risk of injury!

Maintenance

Maintenance

Air Compressor

AFTER SALES SUPPORT

(toll free)MODEL No.: PAP110 • 02/2019 63569

e-mail: [e-mail]

AUS

16

1300 889 028

AUS

Transport

When transporting the air compressor, ensure the power cord and the
accessories are securely stored in their relevant on board storage areas.
Ensure the air compressor is upright when transporting, and when
carrying the air compressor always carry using the carry handle.

Maintenance

Air Compressor

AFTER SALES SUPPORT

(toll free) MODEL No.: PAP110 • 02/2019 63569

e-mail: [e-mail]

AUS

17

1300 889 028

AUS

Warranty

Your new Workzone® Titanium 1100W Air Compressor will more than
satisfy your expectations.
It has been manufactured under stringent Workzone

®

Titanium Quality
Standards to meet superior performance criteria.
You will find your new 1100W Air Compressor easy and safe to operate,
and, with proper care, it will give you many years of dependable
service.

CAUTION. Carefully read through this entire instruction manual before
using your new Workzone

®

Titanium 1100W Air Compressor.
Take special care to heed the Cautions and Warnings.
Your Workzone

®

Titanium 1100W Air Compressor has many features
that will make your job faster and easier. Safety, performance, and
dependability have been given top priority in the development of this
1100W Air Compressor, making it easy to maintain and operate.
Use only Workzone

®

Titanium replacement parts for your product.
Non-conforming parts or modifications made to parts will void your
warranty.

Recycle unwanted materials instead of disposing of them as
waste.All tools, hoses and packaging should be sorted, taken to
the local recycling centre and disposed of in an environmentally

safe way.

Warranty/Environmental protection

Environmental protection

Air Compressor

AFTER SALES SUPPORT

(toll free)MODEL No.: PAP110 • 02/2019 63569

e-mail: [e-mail]

AUS

18

1300 889 028

AUS

Great care has gone into the manufacture of this product and it should
therefore provide you with years of good service when used properly.
In the event of product failure within its intended use over the
course of the first 3 years after the date of purchase, we will remedy
the problem as quickly as possible once it has been brought to our
attention. In the unlikely event of such an occurrence, or if you require
any information about the product please contact us via our after sales
support services, details of which can be found in this manual and on
the product itself.

After Sales Support TEL: [phone] or email:
[e-mail]

If you have any issues with the operation of your product, please call us
on 1300 889 028 for advice, or email us at [e-mail]

What your 3 year warranty means

Service Support

What your 3 year warranty means/Service Support

Air Compressor

AFTER SALES SUPPORT

(toll free) MODEL No.: PAP110 • 02/2019 63569

e-mail: [e-mail]

AUS

19

1300 889 028

AUS

1. 63569-CH:

3m Compressed
air hose

2. 63569-AGPG:

Air Gun with Pressure
Gauge

3. 63569-HVA:

Hose with valve
adapter/ connector

4. 63569-NAS:

Nozzle adapter to
suit 3-piece nozzle
set + Universal
adapter + Screw­on valve adapter +
Deflating adapter

5. 63569-AS:

Universal adapter, for valves with diameter
6 mm + Blower adapter + Valve adapter, +
Universal adapter, for valves with diameter 9
mm + Ball inflating needle

The following accessories are available for purchase by visiting
https://help.tools/ or calling our customer service hotline on:
1300 889 028

Accessories and after Sales Parts

Accessories and After Sales Parts

Air Compressor

AFTER SALES SUPPORT

(toll free)MODEL No.: PAP110 • 02/2019 63569

e-mail: [e-mail]

AUS

20

1300 889 028

AUS

Troubleshooting

Fault Possible cause Remedy

The air compressor
does not start.

No supply voltage.

Insufficient supply
voltage.

Outside temperature
is too low.

Motor is overheated.

Check whether the
power plug is connected
to the power supply.

Check whether the
input supply voltage is
correct.

Wait until the outdoor
temperature is normal.

Wait until the motor
temperature is normal

The air compressor
starts but there is no
pressure.

The non-return valve
leaks.

Check whether the
sealing performance of
valve is normal.

Troubleshooting

Air Compressor

AFTER SALES SUPPORT

(toll free) MODEL No.: PAP110 • 02/2019 63569

e-mail: [e-mail]

AUS

21

1300 889 028

AUS

This product complies with the following standards
Safety:
EN 1012-1
EN 60335-1
AS/NZS 60335.1

EMC:
EN 55014-1
EN 55014-2

Technical Data

Rated voltage 220 - 240 V~ 50 Hz
Rated power input Max. 1100 W S3 15%
No load speed 3750/min
Operating pressure 0.8MPa / 8bar / 116psi
Intake capacity approx. 180l/min
Pressure hose 3m (12mm)
Sound power level L

WA

97 dB(A)
Protection type IP20
Protection class II
Dimension 445*140*330 mm
Weight 5.0kg

Technical Data

ALDI guarantees that our exclusive brand products are developed to
our stringent quality specications. If you are not entirely satised with
this product, please return it to your nearest ALDI store, within 60 days
from the date of purchase, for a full refund or replacement, or take
advantage of our after sales support by calling the supplier’s Customer
Service Hotline.

Made in China

Workzone® Titanium is a registered trademark of ALDI Stores
DISTRIBUTED BY:
ALDI STORES
1 SARGENTS ROAD
MINCHINBURY NSW 2770
www.aldi.com.au

AUS

1300 889 028 (toll free)

MODEL No.: PAP110 • 02/2019 63569

e-mail: [e-mail]
