Multifunction Cooktop Use & Care Guide
MULTIFUNCTION COOKTOP
Contents
4 Safety Precautions
6 Multifunction Cooktop Features
7 Multifunction Cooktop Operation
9 Care Recommendations
10 Troubleshooting
11 Wolf Warranty
Customer Care
The model and serial number are printed on the enclosed
product registration card. Both numbers are also listed on
the product rating plate. Refer to page 6 for rating plate
location. For warranty purposes, you will also need the date
of installation and name of your authorized Wolf dealer.
Record this information below for future reference.
If your product ever needs attention, be sure to use a Wolf
factory certied service provider recommended by our
customer care center, or select one from our list of providers
available at wolfappliance.com/locator. All factory certied service providers are carefully selected and thoroughly
trained by us.
SERVICE INFORMATION
Model Number
Serial Number
Date of Installation
Certied Service Name
Certied Service Number
Authorized Dealer
Dealer Number
Important Note
To ensure this product is installed and operated as safely
and efciently as possible, take note of the following types
of highlighted information throughout this guide:
IMPORTANT NOTE highlights information that is especially
important.
CAUTION indicates a situation where minor injury or product
damage may occur if instructions are not followed.
WARNING states a hazard that may cause serious injury or
death if precautions are not followed.
IMPORTANT NOTE: Throughout this guide, dimensions in
parentheses are millimeters unless otherwise specied.
2 | Wolf Customer Care 800.222.7820
Thank You
Thank you for your purchase. We look forward to being part of your home for decades
to come. As a third-generation family-owned company, we take a very personal stake in
the preparation of your family’s food. We built our business and our reputation on helping
families serve the nest food possible.
With your purchase, you receive one of the strongest warranties in the appliance industry.
Take a moment to read the full warranty statement on page 11. It’s also important to
register your Wolf appliance to ensure that you don’t miss out on exclusive owner benets, such as; assurance that you will be taken care of in the unlikely event that service
becomes necessary during the warranty period, and a proof-of-purchase record in case
of a home insurance claim. You may register by one of the following options:
• Mail in the completed Wolf product registration card.
• Register online at wolfappliance.com/register and create a personalized My Sub-Zero/
Wolf account using the serial number on your product.
• Register by phone by calling Wolf Customer Care at 800-222-7820.
As a Wolf owner, you can count on ongoing support, day in and day out. Our customer
care center is available 24 hours a day, seven days a week and staffed by knowledgeable
product experts at our factory in Madison, Wisconsin. Should the need arise, simply call
800-222-7820 and speak with one of our product experts. They will help troubleshoot any
issues you might have.
We are condent this guide will answer your questions about the features, operation,
and maintenance of your Wolf, but if you have additional questions, please contact us at
800-222-7820 or visit us online at wolfappliance.com.
wolfappliance.com | 3
SAFETY PRECAUTIONS
IMPORTANT INSTRUCTIONS
WARNING
If the information in this guide is not followed
exactly, a re or explosion may result, causing
property damage, personal injury or death.
Do not store or use gasoline or other ammable
vapors and liquids in the vicinity of this or any
other appliance.
GENERAL SAFETY PRECAUTIONS
• Read this guide carefully before using this appli-
ance to reduce risk of re, electric shock or injury.
• Before performing service, shut off gas supply by
closing the gas shut-off valve and shut off electricity to this appliance.
• Keep appliance area clear and free from combus-
tible material.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call the
re department.
This appli ance must be properly installed and serviced by a qualied installer, service agency or gas
supplier and grounded by a qualied technician.
• For safety when cooking, set burner controls so
ame does not extend beyond the bottom of pan.
• Wear proper apparel. Loose-tting or hanging
garments should never be worn while using this
appliance.
• Use extreme caution when moving a grease kettle
or disposing of hot grease.
• Always use dry pot holders when removing pans
from this appliance. Wet or damp pot holders can
cause steam burns. Do not use a towel or bulky
cloth in place of pot holders.
• Clean only those parts listed in this guide.
• Do not repair or replace any part of this appli-
ance unless specically recommended in literature
accompanying this appliance.
• Do not obstruct the ow of air to ensure proper
combustion and ventilation.
•
IMPORTANT: Do not install a ventilation system
that blows air downward toward this gas cooking
appliance. This type of ventilation system may
cause ignition and combustion problems with this
gas cooking appliance resulting in personal injury
or unintended operation.
4 | Wolf Customer Care 800.222.7820
SAFETY PRECAUTIONS
IMPORTANT INSTRUCTIONS
GENERAL SAFETY PRECAUTIONS
• Do not use aluminum foil to line any part of this
appliance.
• Never use this appliance to warm or heat the room.
• When using this appliance, do not touch the grate,
burner cap, burner base or any other parts in proximity to the ame. These components may be hot
enough to cause burns.
• Do not leave children alone or unattended in the
area where this appliance is in use. Never allow
children to sit or stand on the appliance.
• Do not store items of interest to children above or
at the back of this appliance, as they could climb
on the appliance to reach items and be injured.
• Do not use water on grease res. Smother the ame
or use a dry chemical or foam-type extinguisher.
• Never leave this appliance unattended when in use.
Boilovers and greasy spills may smoke or ignite.
• Do not heat unopened food containers, such as
baby food jars and cans. Pressure build-up may
cause the container to burst and cause injury.
CALIFORNIA PROPOSITION 65
WARNING
Burning gas cooking fuel generates some byproducts that are on the list of substances known
to cause cancer or reproductive harm. To minimize
exposure to these substances, always operate
this unit according to the instructions contained in
this guide and provide good ventilation.
COMMONWEALTH OF MASSACHUSETTS
• Installations and repairs must be performed by a
qualied or licensed contractor, plumber or gas
tter, qualied or licensed by the state, province or
region where this appliance is being installed.
• Use only gas shut-off valves approved for use
within the state, province or region where this
appliance is being installed.
• A exible gas connector, when used, must not
exceed 3' (.9 m).
• Do not store ammable materials near burners or
let grease or other ammable substances accumulate on this appliance.
wolfappliance.com | 5
MULTIFUNCTION COOKTOP
Multifunction Cooktop Features
FEATURE
1
Product Rating Plate (bottom of cooktop)
2
Control Knob
3
22,000 Btu (6.5 kW) Burner
4
Burner Grate
5
Burner Pan
3
4
Multifunction Cooktop.
Getting Started
We know you are eager to start cooking, but before you
do, please take some time to read this use & care guide.
Whether you are an occasional cook or an expert chef, it
will be to your benet to familiarize yourself with the safety
practices, features, operation and care recommendations of
your Wolf multifunction cooktop.
• To ensure all residual oil from the manufacturing process
has been removed, clean the multifunction cooktop
thoroughly with hot water and a mild detergent prior to
use. Rinse and dry with a soft cloth. Refer to care recommendations on page 9.
• Verify the burner components are assembled correctly.
2
1
6 | Wolf Customer Care 800.222.7820
COOKTOP OPERATION
Cooktop Operation
BURNER CONTROL
To light the burner, push and turn the control knob counterclockwise to HI. The igniter will begin to click until the
burner is lit. Once lit, continue to turn the knob counterclockwise to the desired setting.
During a power outage, the burner can be lit manually. Turn
the control knob to HI, then light using a multi-purpose
lighter.
CAUTION
Never leave pans on a high setting unattended. Be
careful when cooking food in fat or grease; it can
become hot enough to ignite.
wolfappliance.com | 7
COOKTOP OPERATION
Wok Cooking
A wok up to 14" (356) in diameter can be used with the
multifunction cooktop. The center section of the burner
grate is removable for wok cooking. Woks distributes heat
evenly and are perfect for stir-frying, steaming, stewing and
braising.
STIR-FRYING
Stir-frying uses very little oil and requires continuous stirring.
Because food is cooked rapidly over high heat, color, avor,
texture and nutrition are preserved.
1 Heat wok over HIGH heat until hot. Drizzle in oil. Heat
until oil is hot.
2 Add meat to the wok. Cook and stir until done. Remove.
3 Add vegetables requiring the longest cooking time to the
wok, then add remaining vegetables. Cook and stir until
crisp-tender.
4 Return meat to the wok. Add sauce if desired and stir to
coat.
STEAMING
Steaming helps vegetables retain nutrients. A wok with a lid
or a bamboo steamer can be used to steam food.
1 Pour approximately 2" (51) of hot water into the wok.
2 Place wire rack or bamboo steamer in the wok. Water
level should not touch the rack or steamer.
3 Cover wok and bring water to a boil.
4 Add food and cover. Add more water as needed and
cook until steaming is complete.
8 | Wolf Customer Care 800.222.7820
CARE RECOMMENDATIONS
Care Recommendations
CLEANING
Stainless steel Use a nonabrasive stainless steel cleaner and apply with a soft lint-free cloth. To bring out the natural
luster, lightly wipe surface with a water-dampened microber cloth followed by a dry polishing chamois.
Always follow the grain of stainless steel.
Control panel Use a spray degreaser to remove ngerprints and food soil. Spray on a cloth before wiping panel.
IMPORTANT NOTE: Do not spray cleaners directly on the control panel.
Control knob Using a damp cloth, wipe with mild detergent or spray degreaser; rinse and dry. Do not spray cleaners
directly on control knob. Do not place in dishwasher.
Burner grate Remove and place on a at surface near the sink. Clean with hot water and mild detergent or paste of
baking soda and water. Do not immerse in water. Towel dry.
Burner Allow to cool. Use mild detergent or spray degreaser to clean. Rinse with water and towel dry.
Igniter Keep dry. Never spray water or cleaner directly on the igniter. Avoid contact with igniter.
Burner pan Use a spray degreaser to remove greasy spatters. Spray on a cloth and wipe the surface. Clean with
warm water and mild detergent. Rinse and dry. For hard water stains, use white vinegar and water.
wolfappliance.com | 9
TROUBLESHOOTING
Troubleshooting
OPERATION
Cooktop does not operate.
• Verify power is on.
• Verify electrical power to unit and home circuit breaker
is on.
Erratic ame, poor ignition or no ignition.
• Verify burner components are assembled correctly.
• Clean burner and igniter properly.
• Igniter is damp. Allow it to dry completely. Use hair dryer,
if desired.
• Push in knob, then release. Verify knob springs back.
SERVICE
• Maintain the quality built into your product by contacting
Wolf factory certied service. For the name of the
nearest Wolf factory certied service, check the contact
& support section of our website, wolfappliance.com or
call Wolf customer care at 800-222-7820.
• When contacting service, you will need the model and
serial number of your product. Both numbers are listed
on the product rating plate. Refer to page 6 for rating
plate location.
• For warranty purposes, you will also need the date of
installation and name of your authorized Wolf dealer. This
information should be recorded on page 2 of this guide.
Wolf, Wolf & Design, Wolf Gourmet, W & Design and the color red as applied to knobs are registered trademarks and service marks of Wolf Appliance, Inc. Sub-Zero,
Sub-Zero & Design, Dual Refrigeration, The Living Kitchen, Great American Kitchens The Fine Art of Kitchen Design, and Ingredients are registered trademarks and service marks
of Sub-Zero, Inc. All other trademarks or registered trademarks are property of their respective owners in the United States and other countries.
10 | Wolf Customer Care 800.222.7820
Wolf Appliance Residential Limited Warranty
FOR RESIDENTIAL USE
FULL TWO YEAR WARRANTY*
For two years from the date of original installation, this Wolf Appliance product warranty covers all parts
and labor to repair or replace, under normal residential use, any part of the product that proves to be
defective in materials or workmanship. All service provided by Wolf Appliance under the above warranty
must be performed by Wolf factory certied service, unless otherwise specied by Wolf Appliance, Inc.
Service will be provided during normal business hours.
LIMITED FIVE YEAR WARRANTY
For ve years from the date of original installation, Wolf Appliance will repair or replace the following
parts that prove to be defective in materials or workmanship: gas burners (excludes appearance), electric
heating elements, blower motors (ventilation hoods), electronic control boards, magnetron tubes and
induction generators. If the owner uses Wolf factory certied service, the service provider will repair or
replace these parts with the owner paying for all other costs, including labor. If the owner uses non-certied service, the owner must contact Wolf Appliance, Inc. (using the information below) to receive repaired
or replacement parts. Wolf Appliance will not reimburse the owner for parts purchased from non-certied
service or other sources.
TERMS APPLICABLE TO EACH WARRANTY
The warranty applies only to products installed for normal residential use. The warranty applies only to
products installed in any one of the fty states of the United States, the District of Columbia or the ten
provinces of Canada. This warranty does not cover any parts or labor to correct any defect caused by
negligence, accident or improper use, maintenance, installation, service or repair.
THE REMEDIES DESCRIBED ABOVE FOR EACH WARRANTY ARE THE ONLY ONES THAT WOLF APPLIANCE,
INC. WILL PROVIDE, EITHER UNDER THIS WARRANTY OR UNDER ANY WARRANTY ARISING BY OPERATION
OF LAW. WOLF APPLIANCE, INC. WILL NOT BE RESPONSIBLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES ARISING FROM THE BREACH OF THIS WARRANTY OR ANY OTHER WARRANTY, WHETHER
EXPRESS, IMPLIED OR STATUTORY.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you. This warranty gives you specic legal rights and you may also
have other legal rights that vary from state to state.
To receive parts and/or service and the name of Wolf factory certied service nearest you, contact Wolf
Appliance, Inc., P.O. Box 44848, Madison, WI 53744; check the contact & support section of our website,
wolfappliance.com, email us at customerservice@subzero.com or call 800-222-7820.
*Stainless steel (doors, panels, handles, product frames and interior surfaces) are covered by a limited
60-day parts and labor warranty for cosmetic defects.
*Replacement lters for ventilation hood recirculating kits are not covered by the product warranty.
WOLF APPLIANCE, INC. P.O. BOX 44848 MADISON, WI 53744 WOLFAPPLIANCE.COM 800.222.7820
9003620 REV-B 3/2015
Loading...
