Wolf GM15TFS User Manual
Grill Module Use & Care Guide
GRILL MODULE
Contents
4 Safety Precautions
5 Grill Module Features
6 Grill Module Operation
12 Care Recommendations
13 Troubleshooting
15 Wolf Warranty
Customer Care
The model and serial number are printed on the enclosed
product registration card. Both numbers are also listed on
the product rating plate. Refer to page 5 for rating plate
location. For warranty purposes, you will also need the date
of installation and name of your authorized Wolf dealer.
Record this information below for future reference.
If your product ever needs attention, be sure to use a Wolf
factory certied service provider recommended by our
customer care center, or select one from our list of providers
available at wolfappliance.com/locator. All factory certied service providers are carefully selected and thoroughly
trained by us.
SERVICE INFORMATION
Model Number
Serial Number
Date of Installation
Certied Service Name
Certied Service Number
Authorized Dealer
Dealer Number
Important Note
To ensure this product is installed and operated as safely
and efciently as possible, take note of the following types
of highlighted information throughout this guide:
IMPORTANT NOTE highlights information that is especially
important.
CAUTION indicates a situation where minor injury or product
damage may occur if instructions are not followed.
WARNING states a hazard that may cause serious injury or
death if precautions are not followed.
IMPORTANT NOTE: Throughout this guide, dimensions in
parentheses are millimeters unless otherwise specied.
2 | Wolf Customer Care 800.222.7820
Thank You
Thank you for your purchase. We look forward to being part of your home for decades
to come. As a third-generation family-owned company, we take a very personal stake in
the preparation of your family’s food. We built our business and our reputation on helping
families serve the nest food possible.
With your purchase, you receive one of the strongest warranties in the appliance industry.
Take a moment to read the full warranty statement on page 15. It’s also important to
register your Wolf appliance to ensure that you don’t miss out on exclusive owner benets, such as; assurance that you will be taken care of in the unlikely event that service
becomes necessary during the warranty period, and a proof-of-purchase record in case
of a home insurance claim. You may register by one of the following options:
• Mail in the completed Wolf product registration card.
• Register online at wolfappliance.com/register and create a personalized My Sub-Zero/
Wolf account using the serial number on your product.
• Register by phone by calling Wolf Customer Care at 800-222-7820.
As a Wolf owner, you can count on ongoing support, day in and day out. Our customer
care center is available 24 hours a day, seven days a week and staffed by knowledgeable
product experts at our factory in Madison, Wisconsin. Should the need arise, simply call
800-222-7820 and speak with one of our product experts. They will help troubleshoot any
issues you might have.
We are condent this guide will answer your questions about the features, operation,
and maintenance of your Wolf, but if you have additional questions, please contact us at
800-222-7820 or visit us online at wolfappliance.com.
wolfappliance.com | 3
SAFETY PRECAUTIONS
IMPORTANT INSTRUCTIONS
IMPORTANT NOTE: Read all safety instructions
before using this appliance.
• Read this guide carefully before using this appli-
ance to reduce risk of re, electric shock or injury.
• This appliance must be properly installed and ser-
viced by a qualied installer, service agency or gas
supplier and grounded by a qualied technician.
CALIFORNIA PROPOSITION 65
WARNING
This product may contain chemicals known to the
state of California to cause cancer or reproductive
harm.
GENERAL SAFETY PRECAUTIONS
• Always use dry pot holders. Wet or damp pot
holders can cause steam burns. Do not use a towel
or bulky cloth in place of pot holders.
• Do not leave children alone or unattended in the
area where this appliance is in use. Never allow
children to sit or stand on the appliance.
• Never leave this appliance unattended when in
use. Boilovers and greasy spills may smoke or
ignite.
• Do not use water on grease res. Smother
the ame or use a dry chemical or foam-type
extinguisher.
• Do not repair or replace any part of this appli-
ance unless specically recommended in literature
accompanying this appliance.
• Do not store or use gasoline or other ammable
vapors and liquids in the vicinity of this or any other
appliance.
• Do not heat unopened food containers, such as
baby food jars and cans. Pressure build-up may
cause the container to burst and cause injury.
SAVE THESE INSTRUCTIONS
4 | Wolf Customer Care 800.222.7820
GRILL MODULE
Grill Module Features
FEATURES
1
Product Rating Plate (bottom of module)
2
Control Panel
3
Control Panel Lock
4
Timer Display
5
Grilling Grate
6
Dual Heating Elements
7
Ceramic Briquette Rack
8
Removable Grease Collection Pan
5
3
GRILL MODULE ASSEMBLY
For proper operation, the grill module must be assembled
in the correct alignment. Refer to the illustration below.
Insert the grease collection pan into the grill module with the
hole for the receptacle facing front. Place the briquette rack
into the grease collection pan. Plug the heating elements
into the receptacle at the front of the module. Position the
grilling grate with feet seated into corner dimples.
5
4
6
7
8
2
1
Grill module.
Grill module assembly.
wolfappliance.com | 5
GRILL MODULE OPERATION
Getting Started
Before you start cooking, please take some time to read
this use & care guide. It will be to your benet to familiarize
yourself with the safety practices, features, operation and
care recommendations of your Wolf grill module.
To ensure all residual oil from the manufacturing process
has been removed, heat the grill module on HI for approximately 10 minutes. A small amount of smoke and odor is
normal. Clean the grill module thoroughly with hot water and
a mild detergent prior to use. Rinse and dry with a soft cloth.
Refer to care recommendations on page 12.
Sabbath
This appliance is certied by Star-K to meet strict religious
regulations in conjunction with specic instructions found
on www.star-k.org.
6 | Wolf Customer Care 800.222.7820
GRILL MODULE OPERATION
Grill Operation
CONTROL PANEL
The control panel features illuminated touch controls.
A power level indicator for front and rear heating elements
displays the heat setting from LO to HI. Refer to the illustration below.
Indicators on the control panel will illuminate to indicate
specic module operation. Refer to the chart below.
CONTROL PANEL INDICATOR
Control Panel Locked
Element(s) On
Hot Surface
Timer Set
CONTROL PANEL LOCK
The control panel lock feature prevents unwanted module
operation. Touch and hold LOCK for three seconds to lock
and unlock the control panel.
will illuminate when the
control panel is locked.
The control panel will automatically lock after 10 minutes
of inactivity. This automatic lock feature can be disabled
through the extended options menu. Refer to page 10.
When the module is powered up for the rst time and after a
power outage, the module will default to lock mode.
Control panel.
wolfappliance.com | 7
GRILL MODULE OPERATION
Grill Operation
POWER LEVEL
When the heating element is activated, the power level
indicator will illuminate indicating the level of heat. The
lowest heat is represented by the small ame, varying levels
of heat by additional indicators (dots), and the highest heat
by all indicators including the large ame. Refer to the chart
below.
SETTING POWER LEVEL USES
Low 1–6 indicators Holding food to keep warm.
Medium 6–7 indicators Grilling breads.
Medium High 7-8 indicators Grilling fresh sausage and
marinated pork.
High 8–10 (large ame)
indicators
Searing and grilling meats,
grilling vegetables.
POWER LEVEL INDICATOR
Setting controls:
1 To activate a heating element, touch ON/OFF for the
desired element (front and/or rear) on the control panel.
The power level indicator will ash and all indicators for
that element will ash. Refer to the illustration below.
2 To complete the activation, touch HI for highest heat, LO
for lowest heat, or touch the desired preset power level
indicator.
3 To change the heat setting while the element is on, touch
or slide to the desired preset power level.
4 To turn the element off, touch ON/OFF.
PREHEAT
Preheat the grill module for approximately 10 minutes before
adding food. Food is cooked directly on the grilling grate.
8 | Wolf Customer Care 800.222.7820
POWER LEVEL
INDICATOR
Power level indicator.
GRILL MODULE OPERATION
Grill Operation
TIMER
The timer can be set in one-minute increments up to 99
minutes. Once a time is set,
will illuminate on the control
panel and the countdown is visible on the timer display.
Refer to the illustration below. The timer is independent from
module operation.
Setting timer:
1 Touch TIMER.
2 Touch and hold + or – until the desired time is shown
on the timer display. Timer will begin the countdown in
minutes.
3 Timer will chime with one minute left and complete the
countdown in seconds.
4 When complete, timer will chime and continue to chime
until TIMER is touched.
HOT SURFACE INDICATOR
will illuminate on the control panel and will remain on
until the unit has cooled. It may remain illuminated even
when the grill module is off.
ALL OFF
When one or both heating elements are on, will illuminate on the control panel. To turn off both elements at the
same time, touch ALL OFF.
Timer control.
wolfappliance.com | 9
GRILL MODULE OPERATION
Grill Operation
EXTENDED OPTIONS
The extended options feature allows the user to set preferences for volume, tone, control panel lock and Sabbath
feature.
Setting extended options:
1 To unlock the control panel, touch and hold LOCK for
3 seconds.
2 To enter extended options mode, touch and hold ALL
OFF for 5 seconds.
3 Power level 1 on the rear element control will be dis-
played and ‘VO’ will appear on the timer display.
Touch LO or HI on the front element control to adjust
volume.
4 Touch + on the timer control to adjust tone. Power level
2 on the rear element control will be displayed and ‘Fr’
will appear on the timer display.
Touch LO or HI on the front element control to adjust
tone.
5 Touch + on the timer control to adjust the automatic
control panel lock. Power level 3 on the rear element
control will be displayed and ‘Lo’ will appear on the timer
display.
6 Touch + on the timer control to enter Sabbath mode.
Power level 4 on the rear element control will be displayed. Touch HI on the front element control to initiate
Sabbath feature. ‘SA’ will appear on the timer display.
Touch LO on the front element control to activate or
deactivate the feature.
7 Touch ALL OFF to conrm settings.
Touch LO or HI on the front element control to turn the
automatic lock feature off or on.
10 | Wolf Customer Care 800.222.7820
GRILL MODULE OPERATION
Grill Operation
BRIQUETTE RACK
The ceramic briquettes and briquette rack are dishwasher
safe. The briquettes should be separated from the rack
if placed in a dishwasher. For proper arrangement of the
briquettes, refer to the illustration below.
Do not operate the grill module without the briquettes and
rack installed.
FRONT
Briquette rack.
wolfappliance.com | 11
CARE RECOMMENDATIONS
Care Recommendations
CLEANING
Stainless steel Use a nonabrasive stainless steel cleaner and apply with a soft lint-free cloth. To bring out the natural luster,
lightly wipe surface with a water-dampened microber cloth followed by a dry polishing chamois. Always
follow the grain of stainless steel.
Control panel Use a spray degreaser to remove ngerprints and food soil. Spray on a cloth before wiping panel.
IMPORTANT NOTE: Do not spray cleaners directly on the control panel.
Grilling grate After grilling, operate grill on HI for ve minutes to burn off excess grease. Remove all burned-on food par-
ticles. Clean with a nonabrasive cleaner such as liquid detergent and hot water, or a paste of baking soda and
water. Do not immerse in water. Spray degreasers and mild abrasive cleaners may be used.
Heating element Do not immerse in water. If food particles are burned-on, wipe clean by hand using a damp cloth.
Ceramic briquettes Place briquettes in dishwasher or wash using a mild detergent and soft cloth. Allow to cool before placing
them back on the rack. Refer to page 11 for proper arrangement.
Briquette rack Place rack in dishwasher or wash using a mild detergent and soft cloth.
Grease collection pan Before cleaning, remove all excess grease and burned-on food particles. Wash in hot water with mild deter-
gent. Rinse and dry.
12 | Wolf Customer Care 800.222.7820
TROUBLESHOOTING
Troubleshooting
OPERATION
Grill module does not operate.
• Verify power is on.
• Verify electrical power to module and home circuit
breaker is on.
• Module is in lock mode. Touch and hold LOCK for three
seconds to unlock control panel.
Module temperature issue.
• Contact Wolf customer care at 800-222-7820 for
recommendations.
wolfappliance.com | 13
TROUBLESHOOTING
Troubleshooting
SERVICE
• Maintain the quality built into your product by contacting
Wolf factory certied service. For the name of the
nearest Wolf factory certied service, check the contact
& support section of our website, wolfappliance.com or
call Wolf customer care at 800-222-7820.
• When contacting service, you will need the model and
serial number of your product. Both numbers are listed
on the product rating plate. Refer to page 5 for rating
plate location.
• For warranty purposes, you will also need the date of
installation and name of your authorized Wolf dealer. This
information should be recorded on page 2 of this guide.
Wolf, Wolf & Design, Wolf Gourmet, W & Design and the color red as applied to knobs are registered trademarks and service marks of Wolf Appliance, Inc. Sub-Zero,
Sub-Zero & Design, Dual Refrigeration, The Living Kitchen, Great American Kitchens The Fine Art of Kitchen Design, and Ingredients are registered trademarks and service marks
of Sub-Zero, Inc. All other trademarks or registered trademarks are property of their respective owners in the United States and other countries.
14 | Wolf Customer Care 800.222.7820
Loading...
