Page 1
USE & CARE GUIDE
Gas Rangetops
Page 2
Contents
Important Note
Wolf Gas Rangetops . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Gas Rangetop Features . . . . . . . . . . . . . . . . . . . . . . . . . 8
Gas Rangetop Operation. . . . . . . . . . . . . . . . . . . . . . . . 9
Gas Rangetop Care . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Wolf Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Features and specifications are subject to change at any time
without notice. Visit our website, wolfappliance.com for the
most up-to-date information.
IMPORTANT NOTE: Throughout this guide, dimensions in
parentheses are millimeters unless otherwise specified.
o ensure the safe and efficient use of Wolf equipment,
T
please take note of the following types of highlighted
information throughout this guide:
IMPORTANT NOTE highlights information that is
especially important.
CAUTION signals a situation where minor injury or product
damage may occur if instructions are not followed.
WARNING states a hazard that may cause serious injury or
death if precautions are not followed.
Page 3
Wolf Gas Rangetops 3
wolfappliance.com
Thank You
our purchase of a Wolf gas rangetop attests to the
Y
importance you place upon the quality and performance of
your cooking equipment. We understand this importance
and have designed and built your gas rangetop with
quality materials and workmanship to give you years of
dependable service.
We know you are eager to start cooking, but before you
do, please take some time to read this use & care guide.
Whether you are a beginning cook or an expert chef, it will
be to your benefit to familiarize yourself with the safety
practices, features, operation and care recommendations
of the Wolf gas rangetop.
Your Wolf gas rangetop is protected by a warranty that is
one of the finest in the industry. Take a moment to read
the warranty statement at the end of this guide and refer
to it should service become necessary.
IMPORTANT NOTE: W
olf gas rangetops are manufactured
for use with natural gas or LP gas. Check the product
rating plate for the type of gas for your specific model. If
this appliance does not correspond to your type of gas,
contact your authorized Wolf dealer.
The rating plate is located under the drip pan that
supports the cooking grates, inside the left side panel of
the rangetop. Refer to the illustration below. The rating
plate for French top models (except model RT484F) is
located inside the right side panel.
ATING PLATE
R
Location of rating plate
(inside panel).
Page 4
Safety Instructions 4
IMPORTANT INSTRUCTIONS
GENERAL SAFETY REQUIREMENTS
•
If the information in this guide is not followed
exactly, a fire or explosion may result, causing
property damage, personal injury or death.
IMPORTANT NOTE: Read all safety instructions before
using this appliance.
•
Installation and service must be performed by a
qualified installer, service agency or the gas supplier.
•
Warranty service must be performed by a Wolf
authorized service center.
•
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
•
A ventilation hood is recommended for use with the
Wolf gas rangetop.
Read this use & care guide carefully before using
your new gas rangetop to reduce the risk of fire,
electric shock or injury to persons.
•
Ensure proper installation and servicing. This
appliance must be properly installed and grounded
by a qualified technician.
•
Have installer show you where the gas supply
shut-off valve is located in your home. Learn how
and where to turn off the gas to the rangetop.
•
Before performing any service, turn off the gas
supply by closing the gas shut-off valve and unplug
the rangetop power cord from the wall receptacle.
•
Keep igniters clean and dry for proper lighting and
performance for the burners.
•
In the event that a burner goes out and gas escapes,
open a window or a door. Wait at least five minutes
before using the rangetop.
WHAT TO DO IF YOU SMELL GAS:
•
Do not try to light any appliance.
•
Do not touch any electrical switch.
•
Do not use any phone in your building.
•
Immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions.
•
If you cannot reach your gas supplier, call the fire
department.
•
Keep appliance area clear and free from combustible
material.
•
When cooking, set burner controls so that the flame
heats only the bottom of the pan and does not
extend beyond the bottom of the pan.
•
Wear proper apparel. Never let loose clothing or
other flammable materials come in contact with the
burners while in operation. Fabric may ignite and
cause personal injury.
Page 5
Safety Instructions 5
wolfappliance.com
IMPORTANT INSTRUCTIONS
GENERAL SAFETY REQUIREMENTS
•
When deep fat frying, be certain that the pan is large
enough to accommodate the desired volume of food
without overflow caused by bubbling of the fat.
Never leave a deep fat fryer unattended. Avoid deep
fat frying of moist or frost-covered foods, as foods
with high water content may cause spattering or
spilling of the hot fat. Heat fat slowly, and stir
together any combinations of oils and fats prior to
applying heat. Utilize a deep fat frying thermometer
to avoid heating the fat to temperatures above the
flash point.
•
Always use dry pot holders when removing pans
from the rangetop. Wet or damp pot holders can
cause steam burns. Do not use a towel or bulky
cloth in place of pot holders.
•
Choose pans with easily grasped handles that will
stay cool while cooking. Refer to cookware selection
on page 21.
•
Always turn panhandles inward so they do not
extend over adjacent work areas, burners or the
edge of the rangetop.
•
Keep any ventilation filters clean to avoid grease
fires.
•
Always set pans gently onto the grates and center
them so that they are well balanced.
•
Start the ventilation hood approximately five minutes
before cooking. This establishes an air curtain and
improves the capture of vapor and moisture.
•
Clean only those parts listed in this guide.
•
Always check the positions of the control knobs to
make certain the rangetop is off when you are
finished cooking.
•
Always light each burner prior to placing a pan on
the burner grate. Also, turn the control knob to the
OFF position before removing a pan from the burner
grate.
Page 6
Safety Instructions 6
IMPORTANT INSTRUCTIONS
GENERAL SAFETY REQUIREMENTS
•
Do not repair or replace any part of the rangetop
unless specifically recommended in literature
accompanying this appliance. All service should be
referred to a qualified technician.
•
Do not obstruct the flow of air. Your kitchen must
have an adequate supply of fresh air to ensure
proper combustion and ventilation.
•
Do not use aluminum foil to line any part of the
rangetop.
•
Never use the rangetop to warm or heat the room.
•
Do not block or obstruct the holes in the rangetop
surface below the control knobs. Blocking these
holes may affect burner operation and may result in
a hazard.
•
When using the rangetop, do not touch the grates,
burner caps, burner bases or any other parts in
proximity to the flame. These components may be
hot enough to cause burns.
•
If the rangetop is near a window, do not use long
curtains as a window treatment, as they could blow
over the rangetop and create a fire hazard.
•
Do not leave children alone or unattended in the area
where the rangetop is in use. Never allow children to
sit or stand on the appliance. Do not let children play
with the rangetop.
•
Do not store items of interest to children above or at
the back of the rangetop, as they could climb on the
appliance to reach items and be injured.
Do not use water on grease fires. Smother the flame
•
or use a dry chemical or foam-type extinguisher.
•
Never leave the appliance unattended when in use.
Boilovers and greasy spills may smoke or ignite.
•
Do not cover the burners and grates with anything
except properly selected utensils. Decorative covers
should not be used.
•
Do not heat unopened food containers, such as
baby food jars and cans. Pressure build-up may
cause the container to burst and cause injury.
•
Do not store flammable materials near burners or let
grease or other flammable substances accumulate
on the rangetop.
•
Do not use abrasive or caustic cleaners or detergents on this appliance, as these may cause permanent damage. Do not use aerosol cleaners, as these
may be flammable or cause corrosion of metal parts.
•
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
•
Do not clean the rangetop while it is still hot. If using
a damp sponge or cloth, wait until the rangetop has
cooled sufficiently to prevent steam burns. Also,
some cleaners can produce harmful or unpleasant
fumes if applied to hot surfaces. Refer to care
recommendations on pages 19–20.
•
Do not allow aluminum foil, plastic, paper or cloth to
come in contact with a hot burner or grate. Do not
allow pans to boil dry.
Page 7
Safety Instructions 7
wolfappliance.com
SAFETY PRECAUTIONS
CALIFORNIA PROPOSITION 65
TO REDUCE THE RISK OF INJURY TO PERSONS
IN THE EVENT OF A RANGETOP GREASE FIRE,
OBSERVE THE FOLLOWING:
Smother flames with a close-fitting lid, baking
sheet or other metal tray; then turn off the gas
burner. Be careful to prevent burns. If the flames do
not go out immediately, evacuate and call the fire
department.
Do not use water on grease fires.
Never pick up a flaming pan, you may be burned.
USE AN EXTINGUISHER ONLY IF:
•
You know you have a class ABC extinguisher and
you already know how to operate it.
•
The fire is small and contained in the area where it
started.
•
The fire department is being called.
•
You can fight the fire with your back to an exit
(NFPA fire safety tips).
Burning gas cooking fuel generates some byproducts that are on the list of substances known
to cause cancer or reproductive harm. To minimize
exposure to these substances, always operate this
unit according to the instructions contained in this
guide and provide good ventilation.
COMMONWEALTH OF MASSACHUSETTS
•
Installations and repairs must be performed by a
qualified or licensed contractor, plumber or gas fitter,
qualified or licensed by the state, province or region
where this appliance is being installed.
•
Use only gas shut-off valves approved for use within
the state, province or region where this appliance is
being installed.
•
A flexible gas connector, when used, must not
exceed 3' (.9 m).
Page 8
Gas Rangetop Features 8
Gas Rangetop Features
Heavy-duty stainless steel exterior.
•
• Dual brass burners with flame recognition and auto-
matic reignition for safety and ease of use.
• Porcelain-coated, cast-iron burner grates for easy
cleaning and durability.
• Top configurations including: infrared charbroiler,
infrared griddle and French top with stainless steel
covers.
• Signature red control knobs with four position settings
and chrome bezels.
• Stainless steel drip tray on ball bearing slides.
• CSA certified for US and Canada.
• Two and five year residential warranty—exclusions
apply—see warranty at the end of this guide.
Burner Rating Btu (kW) Btu (kW)
SURFAC E BURNERS HIGH SIMM ER
4–8 Burners 16,000 (4.7) 500 (.1)
OPTI ONAL FEATURE S
Infrared Charbroiler 16,000 (4.7)
Infrared Griddle 18,000 (5.3)
Double Griddle 36,000 (10.6)
French Top 15,000 (4.4)
OPTIONAL ACCESSORIES
Optional accessories are available through your authorized
Wolf dealer. To obtain local dealer information, visit the
locator section of our website, wolfappliance.com.
1
• 10
/2" (267) classic stainless steel riser.
• Stainless steel island trim.
• Black control knobs.
This appliance is certified by Star-K to meet
strict religious regulations in conjunction with
specific instructions found on www.star-k.org.
GAS RANGETOP
Model RT484CG shown
Stainless steel
island trim
Dual brass
burners
Location of rating
plate
Infrared charbroiler
(optional)
Pull-out drip tray
Infrared griddle
(optional)
• Cast iron S-grates and wok grate.
• Hardwood cutting board and griddle cleaning kit
(griddle models).
• High altitude conversion kit.
Porcelain-coated
cast iron top grates
Large red control
knobs
Stainless steel
exterior finish
Griddle indicator
light
Page 9
Gas Rangetop Operation 9
IGNITER
CROSS
RING
CENTER
CAP
BURNER BASE
CENTER CAP
OUTER
BURNER RING DRIP PAN
IGNITER
wolfappliance.com
Surface Burners
spark electrode ignites each surface burner. This control
A
eliminates the need for continuous open flame pilots. For
added safety and convenience, each burner is designed
with an electronic reignition system. This feature enables
any burner to relight automatically in the event it is accidentally extinguished.
BURNER ASSEMBLY
After removing burner parts for cleaning, it is important
that you reassemble the burners correctly. Refer to the
illustrations below for proper alignment of the base and
upper burner parts. The center burner cap does not have
a special orientation but should be seated flat.
GRATE PLACEMENT
Position the porcelain-coated, cast iron burner grates with
the five fingers of each grate facing toward the front of the
gas range. The back of each grate has three fingers. Refer
to the illustration below.
Failure to position the burner parts correctly could
cause flames or gas to escape and burn between
parts, resulting in poor combustion or damage to your
gas rangetop.
Burner base. Upper burner.
Grate placement.
Page 10
Gas Rangetop Operation 10
O
F
F
H
I
G
H
L
O
W
M
E
D
S
I
M
Surface Burners
CONTROL KNOBS
The control knobs are positioned to correspond to the
surface burners they regulate. Each knob is designed as
a push-to-turn knob. Even though this is a child-safe
design, children should never be left unattended near the
rangetop while it is in use.
To light a surface burner, push in and turn the control knob
counterclockwise to HIGH. You will hear a clicking sound.
This is the electronic igniter. Once the burner is lit,
continue turning the knob counterclockwise to the desired
setting. There are four settings—HIGH, MED (medium),
LOW and SIM (simmer). You will feel a slight detent in the
knob rotation when each setting is aligned.
MANUAL LIGHTING
In case of a power outage, you can relight the surface
burners manually. Turn the control knob to HIGH, then
light the burner using a BBQ lighter. Refer to the illustration below.
FLAME HEIGHT AND APPEARANCE
Select a flame that is just high enough to maintain the
desired cooking speed and is sized to fit the base
diameter of the pan. Never extend the flame beyond the
base of the pan. Refer to the illustrations below.
A natural gas flame should be blue with a deeper blue
core. There should be minimal trace of a yellow flame. A
yellow flame indicates an improper mixture of air and gas
or impurities in the gas supply to the range. If this occurs
consistently, call a Wolf authorized service center to adjust
the mixture. With LP gas, some yellow tipping to the flame
is acceptable and may not require adjustment.
A “popping” sound may be noticed with LP gas when the
surface burner is turned off. This is normal.
Surface burner at SIMMER. Surface burner on HIGH.
Surface burner control knob. Manual lighting.
Page 11
Gas Rangetop Operation 11
wolfappliance.com
Surface Burners
TEMPERATURE SETTING GUIDE
ETTING USES
S
IM (simmer) Melting, holding chocolate
S
Melting butter
Heating, holding delicate sauces
arming foods
W
Melting large quantities
Simmering sauces
Steaming rice
LOW Heat Frying eggs
Heating milk, cream sauces and
soups, gravies and puddings
Panfrying
Simmering large quantities
Boiling vegetables in water
MED (medium) Heat Sautéing
Browning
Braising
Quick frying
HIGH Heat Boiling water
Heating broth soups, stocks
Deep fat frying (to heat oil only)
Fast boiling large quantities
BEFORE USING FOR THE FIRST TIME
Before using for the first time, you should clean your
rangetop thoroughly with hot water and a mild detergent.
Rinse and dry with a soft cloth. This removes any residual
oil and grease left on the surface from the manufacturing
process. Refer to care recommendations on pages 19–20.
IMPORTANT NOTE: Before using your gas rangetop,
check that the surface burners are assembled correctly.
The optional griddle and French top need to go through a
“burn in” period to clean oils from the bottom of these
assemblies. To prevent food from sticking and to protect
the surface from moisture, it is necessary to season the
griddle and French top prior to use. Refer to the following
pages for specific instructions on using the optional
charbroiler, griddle and French top.
The use of proper cookware is very important. Refer to
cookware selection on page 21 for recommendations.
Never leave pans on a HIGH setting unattended.
Be careful when cooking food in fat or grease; it can
become hot enough to ignite.
Page 12
Gas Rangetop Operation 12
STAINLESS
STEEL
GRATE
BLANK-OFF
PLATE
IGNITER
WIRE MESH
SCREEN
Infrared Charbroiler
he optional charbroiler has an infrared burner to give the
T
most efficient method of gas grilling. The burner becomes
an orange-red color at the surface of the ceramic tile.
When it glows, it transfers intense heat to the food. This
sears the outside of the food to lock in juices and flavor.
IMPORTANT NOTE: Cook food directly on the charbroiler
grate, do not use cookware.
INSTALL BLANK-OFF PLATE
To convert the charbroiler to a lower heat output for more
even cooking, install the blank-off plate provided with your
gas rangetop. This stainless steel plate is placed directly
on the ceramic tiles.
Install the blank-off plate when the charbroiler is off and is
completely cool. Be sure to remove the plastic film from
the blank-off plate before installing.
To install the blank-off plate, remove the stainless steel
grate and wire mesh screen. Position the blank-off plate in
the middle of the ceramic tiles. Reinstall the wire mesh
screen with the notch at the left rear. Reinstall the grate.
Refer to the illustrations below.
Use caution when positioning the blank-off plate to
avoid damage to the ceramic tiles. Avoid contact with
the igniter; it is fragile and can chip or break.
Charbroiler grate. Blank-off plate.
Page 13
Gas Rangetop Operation 13
O
F
F
H
I
G
H
wolfappliance.com
Infrared Charbroiler
CHARBROILER OPERATION
IMPORTANT NOTE:
The stainless steel cover must be
removed prior to operation of the charbroiler.
• Turn the control knob counterclockwise to the HIGH
setting. You will hear the clicking sound of the igniter
lighting the burner.
• Preheat the charbroiler for about 10 minutes before
adding food. The ceramic tiles will have an orange-red
glow.
• To turn the charbroiler off, turn the control knob clock-
wise to the OFF position.
To prevent flare-ups, never leave the charbroiler unattended during use.
CHARBROILING TIPS
• Turn on the ventilation hood five minutes prior to using
the charbroiler.
• If the knob is not set fully at HIGH, the burner may turn
blue and the automatic igniter will begin sparking. Turn
the knob back to HIGH.
• Always select lean meat or trim fat before grilling.
Flaming may occur when grilling meat and poultry with
excessive fat.
• To minimize flare-ups when grilling chicken breasts and
thighs, remove the skin. Brush pieces with peanut or
vegetable oil to reduce sticking to the grate.
• If flare-ups occur, quickly move the food to another
place on the grate with long tongs.
• Apply basting sauce halfway through cooking time.
• Use a minute timer as a reminder to turn the food over
halfway through cooking time.
• Leave the charbroiler on for approximately 10 minutes
after grilling is complete. This allows for easier cleaning
after the charbroiler has cooled sufficiently.
Charbroiler control knob.
• The suggested grilling times in the charbroiler grilling
guide on the following page are approximate. Actual
times depend on the quantity, thickness and starting
temperature of the food.
Page 14
Gas Rangetop Operation 14
Infrared Charbroiler
CHARBROILER CARE
To keep the charbroiler looking its best, it is recommended
that you clean it after every use. Allow the charbroiler
surface to cool sufficiently before cleaning.
• Charbroiler Grate (stainless steel): When cool, lift off
and set in the sink. Pour very hot water over the
cooked-on residue. Cover with wet dish towels and
pour more hot water over it. Allow the hot, moist conditions to help loosen the residue. Remove remaining
food soil with a soap-filled scouring pad. Rinse and
dry.
• Charbroiler Frame (stainless steel): Remove from the
rangetop. Soak in hot water and dish detergent. Wash
thoroughly, scrubbing with scouring pad, if needed.
• Blank-off Plate (stainless steel): Wash with hot water
and detergent. Use a soap-filled scouring pad to
remove as much cooked-on food soil as possible. The
plate will turn a metallic blue color due to the high
heat; this is a permanent change.
• Igniter (ceramic): Avoid contact with the igniter; it is
fragile and can chip or break.
CHARBROILER GRILLING GUIDE
OOD GRILLING TIME*
F
BEEF
round beef patties,
G
1 lb (.5 kg),
Steaks,
CHICKEN
Breasts, boneless and skinless 20–23 min
Breasts, bone in 30–33 min
Thighs, boneless and skinless 30 min
FISH
Steaks,1/2" (13) to3/4" (19) thick 10–12 min
FRESH VEGETABLES
Bell peppers 10–12 min
Corn on the cob, husked 15–20 min
Corn on the cob, in the husk 30–40 min
Mushrooms 6–7 min
*Grilling times are with the blank-off plate installed.
1
/2" (13) thick 12–15 min (medium well)
1
/2" (13) to3/4" (19) thick 8–9 min (rare)
0–12 min (medium)
1
14–16 min (well done)
• Mesh Screen (stainless steel): Use a wire brush to
loosen any charred food particles.
Page 15
Gas Rangetop Operation 15
O
F
F
0
0
2
0
0
1
5
0
2
5
0
3
0
0
3
1
0
0
4
5
0
wolfappliance.com
Infrared Griddle
he optional griddle is thermostatically controlled, which
T
means once the set temperature is reached, the heat
cycles to hold that temperature. To prevent food from
sticking and to protect the surface from moisture, it is
necessary to “season” the griddle prior to use. This
seasoning process as well as general use will change the
appearance of the griddle.
SEASON THE GRIDDLE
• The griddle is shipped with a protective oil coating the
surface, use hot water and detergent to clean. Rinse
and dry.
• Turn on the ventilation hood five minutes prior to using
the griddle.
• The griddle needs to go through a “burn in” period.
Turn the griddle on at 350°F (175°C) for 30 minutes to
clean oils from the bottom of the griddle. After 30
minutes, turn the griddle off and allow it to cool.
• To season, pour a teaspoon (5 ml) of peanut or
vegetable oil per single griddle in the center; spread
evenly with a paper towel, avoiding the corners. Be
careful not to apply too much oil. Excess oil will leave a
gummy residue that will have to be removed.
GRIDDLE OPERATION
IMPORTANT NOTE:
The stainless steel cover must be
removed prior to operating the griddle.
• Turn on the ventilation hood five minutes prior to using
the griddle.
• To heat the griddle, push in the control knob and turn
counterclockwise to the desired temperature. It is
normal to hear a clicking sound. This is the electronic
ignition lighting the burner. When the burner is lit, the
thermostat will control the temperature.
• When the griddle is preheated, the griddle indicator
light will go out. The light will cycle on and off as the
thermostat requires more heat to maintain the set
temperature. This will allow heat to be evenly distributed and the griddle to maintain the set temperature.
• The double griddle has two burners with separate
control knobs that act independently of each other. If
only one griddle is being used, there will be some heat
transfer to the inactive griddle.
• To turn the griddle off, turn the control knob clockwise
to the OFF position.
• Push and turn the control knob to 350°F (175°C). Heat
until you see the first signs of smoke. Turn the griddle
off. When the griddle has cooled and is only slightly
warm, wipe off any excess oil. Let the griddle cool
completely.
• Repeat with another teaspoon of oil. The brown
appearance will darken with use.
Griddle control knob.
Page 16
Gas Rangetop Operation 16
DRAIN HOLE
DRIP TRAY
GREASE
COLLECTION
TRAY
Infrared Griddle
GRIDDLE CARE
• Using a metal spatula, scrape grease into the grease
collection tray.
• When the surface has cooled, wipe it with a paper
towel to remove excess grease or oil.
1
• Scrape the griddle clean. Pour
/2 cup (118 ml) warm
water and 1 teaspoon (5 ml) griddle cleaner onto the
griddle and scrape the grease into the grease collection tray. Rinse the griddle with
1
/2 cup (118 ml) warm
water and dry with paper towels.
• Clean the grease collection tray on the drip tray and
drain hole after each use. Do not allow grease to accumulate in the tray and become a fire hazard.
• To remove the grease collection tray, slide the drip tray
out, then lift out the grease collection tray. Clean the
grease collection tray with soapy water and a clean
cloth. Refer to the illustration below.
• Apply a small amount of peanut or vegetable oil to the
griddle with a clean cloth after each cleaning.
• Occasionally, remove the seasoning and clean the
griddle thoroughly. Apply a small amount of white
vinegar and water to the surface while it is slightly
warm. Scrub with a fine wire brush or a fine-grit griddle
brick. Repeat until excess oil has been removed. Apply
a light coat of oil for seasoning.
GRIDDLE COOKING GUIDE
TEMPERATURE FOOD
200°F
(95°C) Hold cooked food at serving
temperature
120°C)
250°F (
350°F
375°F
400°F (
175°C)
(
190°C)
(
205°C)
Eggs
French toast, pancakes, grilled
sandwiches
Bacon, pork chops, lamb steaks,
sausage, flattened boneless chicken
Vegetables, sliced or grated
Grease collection tray.
Page 17
Gas Rangetop Operation 17
CENTER
PLATE
HIGH
HIGH
HIGH
LOW
LOW
LOW
LOW
MED MED
wolfappliance.com
French Top
he optional French top provides a graduated cooking
T
surface with the hottest temperature under the center
plate and the lowest temperature near the edges. This
design makes it possible to use several pans at once for a
variety of cooking tasks. For example, fry chicken toward
the center, while simmering a sauce in one corner and
keeping vegetables warm in a different corner. Place the
pan or pans toward the edge according to their contents
and quantity. Refer to the illustrations below.
The cooking surface is made of polished cast iron that is
an excellent heat conductor. The rings allow for the solid
surface to expand with the heat while remaining flat. The
rings also provide thermal breaks in the cast iron that
distribute heat in a graduated intensity, hottest in the
center and coolest around the edges.
To protect the cast iron surface from moisture, it is necessary to “season” the French top prior to use. This seasoning process as well as general use will change the
appearance of the French top.
SEASON THE FRENCH TOP
• The French top is shipped with a protective oil coating
the surface, use hot water and detergent to clean.
Rinse and dry.
• Turn on the ventilation hood five minutes prior to using
the French top.
• The French top needs to go through a “burn in” period.
Turn on the French top for 30 minutes to clean oils
from the bottom side of the surface. After 30 minutes,
turn the French top off and allow it to cool.
• To season, spread a light coating of peanut or
vegetable oil on a towel or cloth. While surface is still
slightly warm, apply oil evenly until it is absorbed into
the cast iron. Be careful not to apply too much oil.
Excess oil will leave a gummy residue that will have to
be removed.
• It is normal for the cast iron to darken with use to a
bluish-black color.
When this seasoning technique is applied correctly, food
spatters will not stain and the surface will be protected
from moisture. Its appearance darkens with use, a sign
that the French top has been fully tempered and is
properly seasoned. Regular maintenance will become
easier.
French top center plate. French top heating zones.
Page 18
Gas Rangetop Operation 18
CENTER PLATE
HOOK
French Top
FRENCH TOP OPERATION
IMPORTANT NOTE:
The stainless steel cover must be
removed prior to operating the French top.
• Turn on the ventilation hood five minutes prior to using
the French top.
• To use the French top, push and turn the control knob
counterclockwise to the HIGH setting. You will hear the
clicking sound of the igniter lighting the burner.
• Preheat for 25 to 30 minutes before cooking on the
French top. This allows the solid cast iron plate to heat
thoroughly.
• To raise or lower the cooking heat, slide the pan either
toward (higher heat) or away from (lower heat) the
center plate. This gives you total control over the most
delicate sauces. It is not necessary to adjust the flame
height.
• To turn the French top off, turn the control knob clock-
wise to the OFF position.
FRENCH TOP COOKING TIPS
FRENCH TOP CARE
• It is best to maintain a seasoned surface to protect the
cast iron from moisture.
• Clean the entire surface after each use while it is
slightly warm. Wipe the surface with a mild detergent
and water. Rinse and dry.
• Maintain the French top as you would a cast iron
skillet; keep it free from moisture.
• Reapply a light coating of peanut or vegetable oil to
the French top after each use until a sheen develops.
• Occasionally, remove the seasoning and clean the
French top thoroughly. Apply a small amount of white
vinegar and water to the surface while it is slightly
warm. Scrub and repeat until excess oil has been
removed. Apply a light coat of oil for seasoning.
• The French top burner is located below the center
plate. The plate remains in place during cooking but it
can be lifted off to check or service the burner. Use the
center plate hook provided with your rangetop as
shown in the illustration below.
• Always cook in pans. Do not cook food directly on the
surface.
• Never remove the center plate when cooking.
• When bringing large amounts of water to a boil, it is
fastest to do it on one of the surface burners.
Never leave pans on a high heat zone unattended. Be
cautious when cooking food in fat or grease. It can
become hot enough to ignite.
Center plate removal.
Page 19
Gas Rangetop Care 19
DRIP PAN
REMOVAL HOOK
DRIP PAN
wolfappliance.com
Care Recommendations
DRIP PAN REMOVAL
The drip pan removal hook is provided with the gas
rangetop to lift and remove the drip pan for cleaning.
To remove the drip pan, first remove the cast iron grates.
Insert the vinyl-coated end of the drip pan removal hook
into one of the oblong holes in the drip pan. Lift upward
and set the drip pan aside for cleaning. Refer to the
illustration below.
Drip pan removal.
RANGETOP CLEANING TIPS
• Wait until surfaces are cool before cleaning.
• For best results, wipe up spills and spatters as they
occur and immediately after the rangetop has cooled.
If splatters are allowed to cook on, they may permanently damage or stain the finish.
• Use a spray degreaser to remove fingerprints and
greasy spatters. Spray on a cloth and wipe the surface.
Buff dry immediately to avoid streaking. For hard water
stains, use white vinegar and water.
• If in doubt about using one of your cleaners, check the
label. To check if it is safe to use on your range, try a
small amount on an inconspicuous area.
• Use caution when spraying cleaners. Some contain
caustic ingredients that can damage adjacent parts
and finishes. Protect the adjacent parts by masking
them off to avoid damage by overspray.
• Do not spray cleaners on control knobs or igniters.
• Refer to care recommendations on the following page
for specific care instructions for rangetop components.
• Refer to pages 12–18 for specific care instructions for
the charbroiler, griddle and French top.
Page 20
Gas Rangetop Care 20
Care Recommendations
STAINLESS STEEL EXTERIOR
Rangetop exterior, riser and trim.
• Do not use abrasive cleaners; they will permanently
scratch stainless steel surfaces. Salt and some
cooking liquids may pit and stain the surface. Remove
these spills immediately.
• Use a spray degreaser to remove fingerprints and
greasy spatters. Spray on a cloth and wipe the surface.
Buff dry immediately to avoid streaking. For hard water
stains, use white vinegar and water.
• For general cleaning, use a soft, nonabrasive stainless
steel cleaner like Signature polish and apply with a soft
lint-free cloth. To bring out the natural luster, lightly
wipe the surface with a water-dampened microfiber
cloth followed by a dry polishing chamois. All work
should follow the grain direction of the finish. Better
results are obtained by keeping the cloth in continuous
contact with the stainless steel.
• Signature polish is available from Signature Limited
Laboratory, P. O. Box 13436, Dayton, Ohio 45413, or
call 877-376-5474.
GENERAL CLEANING
Burner drip pan.
• Do not use abrasive cleaners; they will permanently
scratch porcelain enamel surfaces. Use a clean cloth
or sponge and wipe the surface with warm water and a
mild detergent. Rinse and dry immediately.
Burner grates.
• Remove burner grates and clean with a nonabrasive
cleaner such as liquid detergent in hot water or a paste
of baking soda and water. Spray degreasers and mild
abrasive cleaners may be used.
Burner base.
• Wash in warm water and liquid detergent or mild
abrasive cleaner. Rinse and dry.
Spark igniters.
• Keep dry; never spray water or cleaner directly on the
igniter. When cleaning surface burners, avoid contact
with the igniter.
Control knobs.
• Wipe control knobs with a damp cloth and mild deter-
gent and water; rinse and dry. Do not soak the knobs
or use abrasive cleaners, they will scratch the finish
and remove markings.
Control panel.
• Use a spray degreaser to remove fingerprints and food
soils. Spray on a cloth and wipe the panel. Do not
spray directly on the panel around valve stems.
Page 21
Gas Rangetop Care 21
wolfappliance.com
Cookware Selection
or best results, we recommend medium- to heavy-weight
F
cookware. Pans should have a flat base, metal handle
and good-fitting cover. Look for pans that are made of
materials with good heat conductivity, such as aluminum
and copper. Use the following guidelines when selecting
cookware:
• Select deep pans with high sides rather than ones with
wide bases and low sides to avoid boilovers.
• Cover pans while cooking to improve cooking
efficiency. Water boils faster, using less fuel, and the
kitchen stays cooler.
• Select lower flame settings when using pans made of
cast iron, enameled steel or glass ceramic, or pans
coated with a nonstick finish. High heat may cause
“hot spots”, scorching and burning.
• Pans with oversize bases that extend beyond the
rangetop frame should not be used. On high settings,
heat may be trapped beneath the pan causing permanent damage to the surface finish.
• For ease in handling, use front burners for larger pans.
Troubleshooting
f your Wolf gas rangetop is not operating properly, use the
I
following troubleshooting guide before calling your Wolf
authorized service center. This guide will save you time
and trouble and may help you avoid the expense of a
service call.
Rangetop does not operate.
• Check that the electrical connection to the rangetop
has not been disconnected, or if the household fuse or
circuit breaker has been blown or tripped.
• A power outage may have caused a disruption in
service.
Burner flame does not burn evenly.
• Burner parts may not be assembled correctly. Refer to
burner assembly on page 9.
Burner fails to ignite.
• Igniter is damp. Allow it to dry completely.
• Use a wok with a flat bottom.
Burners extinguish themselves when using more than
one large pan simultaneously.
• Good gas combustion requires the correct amount of
airflow to maintain the flame. Using two oversized pans
simultaneously restricts air movement.
Food boils or burns more in one area of a pan.
• Pan is not centered above the burner or base of pan
does not rest flat on the burner grate.
• Pan does not conduct heat evenly.
Water does not come to a boil fast enough.
• Cover pan for most efficient use of the high setting.
• Diameter of pan is too large or base of pan is warped.
Page 22
Service Information 22
Service Information
hen requesting information, literature, replacement parts
W
or service, always refer to the model and serial number of
your gas rangetop. This information is found on the product
rating plate. The rating plate is located under the drip pan
that supports the cooking grates, inside the left side panel
of the rangetop. Refer to the illustration on page 3. The
rating plate for French top models (except model RT484F)
is located inside the right side panel. Record the rating
plate information below for future reference.
Model Number:
Serial Number:
Installation Date:
Wolf Authorized Service Center:
Phone:
Authorized Wolf Dealer:
BEFORE CALLING FOR SERVICE
Before calling a Wolf authorized service center, refer to the
troubleshooting guide on page 21.
PRODUCT REGISTRATION
Register your new Wolf product today so that we may
ensure your satisfaction. You may register by one of the
following options:
1) Mail in the completed Wolf product registration card.
2) Register online at wolfappliance.com.
3) Register by phone by calling Wolf customer service at
800-222-7820.
The model and serial numbers of your appliance are
printed on the enclosed Wolf product registration card. If
you provide us with your e-mail address, we will send you
exciting new product updates and recipes as they become
available, along with information on special events.
Phone:
The information and images in this guide are the copyright property of Wolf Appliance, Inc. Neither this guide nor any information or images contained herein
may be copied or used in whole or in part without the express written permission of Wolf Appliance, Inc. ©Wolf Appliance, Inc. all rights reserved.
Wolf, Wolf & Design, Wolf Gourmet, W & Design and the color red as applied to knobs are registered trademarks and service marks of Wolf Appliance, Inc.
Sub-Zero, Sub-Zero & Design, Dual Refrigeration, Constant Care and The Living Kitchen are registered trademarks and service marks of Sub-Zero, Inc.
(collectively,the“Company Marks.”) All other trademarks or registered trademarks arepropertyof theirrespectiveownersin the United States and othercountries.
Page 23
Wolf Appliance Products Limited Warranty
R
ESIDENTIAL USE ONLY
FULL TWO YEAR WARRANTY*
For two years from the date of original installation, your Wolf Appliance product warranty covers all parts and
labor to repair or replace any part of the product that proves to be defective in materials or workmanship. All
service provided by Wolf Appliance under the above warranty must be performed by a Wolf authorized service
center, unless otherwise specified by Wolf Appliance. Service will be provided in the home during normal
business hours.
LIMITED THIRD THROUGH FIFTH YEAR WARRANTY
From the third through fifth year from the date of original installation, Wolf Appliance will repair or replace the
following parts that prove to be defective in materials or workmanship: gas burners (excluding appearance),
electric heating elements, blower motors (ventilation hoods), electronic control boards, magnetron tubes and
induction generators. Labor to remove and replace defective parts is not covered. Wolf Appliance recommends
that you use a Wolf authorized service center to perform such service.
LIMITED LIFETIME WARRANTY
For the life of the product, Wolf Appliance will repair or replace any outdoor gas grill body or hood that rusts
through due to defective material or workmanship. Labor to remove and replace defective parts is not covered.
Wolf Appliance recommends that you use a Wolf authorized service center to perform such service.
TERMS APPLICABLE TO EACH WARRANTY
The warranty applies only to products installed for normal residential use. The warranty applies only to products
installed in any one of the fifty states of the United States, the District of Columbia or the ten provinces of
Canada. This warranty does not cover any parts or labor to correct any defect caused by negligence, accident
or improper use, maintenance, installation, service or repair.
THE REMEDIES DESCRIBED ABOVE FOR EACH WARRANTY ARE THE ONLY ONES THAT WOLF APPLIANCE,
INC. WILL PROVIDE, EITHER UNDER THIS WARRANTY OR UNDER ANY WARRANTY ARISING BY OPERATION
OF LAW. WOLF APPLIANCE, INC. WILL NOT BE RESPONSIBLE FOR ANY CONSEQUENTIAL OR INCIDENTAL
DAMAGES ARISING FROM THE BREACH OF THIS WARRANTY OR ANY OTHER WARRANTY, WHETHER
EXPRESS, IMPLIED OR STATUTORY.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you. This warranty gives you specific legal rights and you may also have
other legal rights that vary from state to state.
To receive parts and/or service and the name of the Wolf authorized service center nearest you, contact
Wolf Appliance, Inc., P. O. Box 44848, Madison, WI 53744; check the contact & support section of our website,
wolfappliance.com or call 800-332-9513.
*Stainless steel doors, panels, handles, product frames and interior surfaces are covered by a limited 60-day
parts and labor warranty for cosmetic defects.
Page 24
WO LF AP PLIAN CE, INC. P. O. BOX 44 848 MA DISON , WI 5 3744 WOLFAPP LIANC E.COM 800.332.9513
814 989 R EV-A 5/ 2010
Loading...
