Wistron Volvi, Aspire 4710 Schematic

A

B

Volvi Block Diagram

4 4

DDR2

533/667 MHz

533/667 MHz

3 3

Line In

MIC In

14

31

INT.SPKR

2 2

Line Out
(No-SPDIF)

CLK GEN.

ICS 9LPRS502
(RTM875T-605)

71.09502.00W

DDR2

RJ11

3

533/667MHz

13,14

533/667MHz

13,14

Codec

ALC268

28

OP AMP

G1431Q

29

OP AMP
G1412

29

MODEM

MDC Card

AZALIA

21

Mobile CPU

Yonah 478
Celeron M

62.10079.001

HOST BUS 400/533/667MHz@1.05V

Calistoga

AGTL+ CPU I/F
DDR Memory I/F

INTEGRATED GRAHPICS

LVDS, CRT I/F

71.CALIS.00U

X4 DMI
400MHz

ICH7M

4 PCIe ports
PCI/PCI BRIDGE
ACPI 2.0
2 SATA
1 PATA 66/100
8 USB 2.0/1.1 ports

ETHERNET (10/100/1000MbE)

High Definition Audio
LPC I/F
Serial Peripheral I/F

71.ICH7M.00U

4, 5

4, 5

6,7,8,9,10

C-Link0

15,16,17,18

G792

PCI BUS

PCIex1

LPC BUS

C

20

CRT

LCD

OZ129

1394

CardReader

Giga LAN

BCM5787MKMLG

24

TV Out

14

13

VGA Borad

22

TXFM RJ45

Mini Card

Kedron

D

Project code: 91.4U701.001
PCB P/N : 07200
REVISION : -1

PCB STACKUP

5 in 1

2323

TOP

VCC

S

S

GND

BOTTOM

25

14

1394
CONN

a/b/g/n

26

Cardreader

25

MS/MS Pro/xD/
MMC/SD

27

E

SYSTEM DC/DC

MAX8744

INPUTS

DCBATOUT

SYSTEM DC/DC

MAX8717

INPUTS OUTPUTS

DCBATOUT

TPS51100

APL5312

3D3V_S0 2D5V_S0

APL5912

1D8V_S3

Intersil CHARGER

MAX8731

DCBATOUT

CPU DC/DC

MAX8770

INPUTS

DCBATOUT

OUTPUTS
VCC_CORE

0~1.3V
48A

36

OUTPUTS

5V_S5

3V_S5

37

1D8V_S3
1D05V_S0

39

DDR_VREF1D8V_S3

39

38

1D5V_S0

40

OUTPUTSINPUTS
BT+

18V 4.0A

UP+5V

5V 100mA

35

PATA

20

SATA

CDROM

20

New card

1 1

P2231NFC1

27

28

PCI Express

HDD

USB

MINI USB
BlueTooth

MEDIA BD

22

31

Winbond

WPC8768L

Touch
Pad

KBC

INT.
KB

31 31

SPI I/F

30

CIR

USB

21

CAMERA

13

C

4 Port

A

B

W25X80-VSS

31

BIOS

LPC

DEBUG

32

CONN.

D

32

UMA

UMA

UMA

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Title

Title

BLOCK DIAGRAM

BLOCK DIAGRAM

BLOCK DIAGRAM

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
A3

A3

A3
Date: Sheet

Date: Sheet

Date: Sheet

Taipei Hsien 221, Taiwan, R.O.C.

Volvi

Volvi

Volvi

143Wednesday, April 18, 2007

143Wednesday, April 18, 2007

143Wednesday, April 18, 2007

of

of

of

E

-1

-1

-1

A

ICH7M Functional Strap Definitions

Usage/When Sampled

XOR Chain Entrance/
PCIE Port Config1 bit1,
Rising Edge of PWROK

PCIE config1 bit0,
Rising Edge of PWROK.

PCIE config2 bit0,
Rising Edge of PWROK.

Reserved
ESI Strap (Server Only)

Rising Edge of PWROK

Top-Block
Swap Override.
Rising Edge of PWROK.

Boot BIOS Destination
Selection.
Rising Edge of PWROK.

Integrated VccSus1_05,
VccSus1_5 and VccCL1_5
VRM Enable/Disable.
Always sampled.

Integrated VccLAN1_05
and VccCL1_05 VRM
Enable/Disable.
Always sampled.

PCI Express Lane
Reversal. Rising Edge
of PWROK.

No Reboot.
Rising Edge of PWROK.

XOR Chain Entrance.
Rising Edge of PWROK.

Flash Descriptor
Security Override Strap
Rising Edge of PWROK

Allows entrance to XOR Chain testing when TP3
pulled low.When TP3 not pulled low at rising edge
of PWROK,sets bit1 of RPC.PC(Config Registers:
offset 224h)

This signal has a weak internal pull-down.
Sets bit0 of RPC.PC(Config Registers:Offset 224h)

This signal has a weak internal pull-up.
Sets bit2 of RPC.PC2(Config Registers:Offset 0224h)

This signal should not be pulled high.
ESI compatible mode is for server platforms only.

This signal should not be pulled low for desttop
and mobile.

Sampled low:Top-Block Swap mode(inverts A16 for
all cycles targeting FWH BIOS space).
Note: Software will not be able to clear the
Top-Swap bit until the system is rebooted
without GNT3# being pulled down.

Controllable via Boot BIOS Destination bit
(Config Registers:Offset 3410h:bit 11:10).
GNT0# is MSB, 01-SPI, 10-PCI, 11-LPC.

Enables integrated VccSus1_05, VccSus1_5 and
VccCL1_5 VRM's when sampled high

Enables integrated VccLAN1_05 and VccCL1_05 VRM's
when sampled high

Signal has weak internal pull-up. Sets bit 27
of MPC.LR(Device 28:Function 0:Offset D8)

If sampled high, the system is strapped to the
"No Reboot" mode(ICH8 will disable the TCO Timer
system reboot feature). The status is readable
via the NO REBOOT bit.

This signal should not be pull low unless using
XOR Chain testing.

This signal has a weak internal pull-up.
Sampled low:the Flash Descriptor Security will be
overridden. If high,the security measures will be
in effect.This should only be used in manufacturing
environments.

4 4

3 3

Signal

HDA_SDOUT

HDA_SYNC

GNT2#

GPIO20
GNT1#/

GPIO51

GNT3#

GNT0#/
SPI_CS1#

INTVRMEN

LAN100_SLP

SATALED#

SPKR

TP3

GPIO33/
HDA_DOCK
_EN#

ICH8-M EDS 21762 2.0V1

Comment

B

page 16

ICH7M Integrated Pull-up
and Pull-down Resistors

SIGNAL Resistor Type/Value

HDA_BIT_CLK
HDA_RST#
HDA_SDIN[3:0]
HDA_SDOUT
HDA_SYNC
GNT[3:0]
GPIO[20]
LDA[3:0]#/FHW[3:0]#
LAN_RXD[2:0]
LDRQ[0]
LDRQ[1]/GPIO23
PME#
PWRBTN#
SATALED#
SPI_CS1#
SPI_CLK
SPI_MOSI
SPI_MISO
TACH_[3:0]
SPKR
TP[3]
USB[9:0][P,N]
CL_RST#

C

ICH8-M EDS 21762 2.0V1

PULL-DOWN 20K
NONE
PULL-DOWN 20K
PULL-DOWN 20K
PULL-DOWN 20K
PULL-UP 20K
PULL-DOWN 20K
PULL-UP 20K
PULL-UP 10K
PULL-UP 20K
PULL-UP 20K
PULL-UP 20K
PULL-UP 20K
PULL-UP 15K
PULL-UP 20K
PULL-UP 20K
PULL-UP 20K
PULL-UP 20K
PULL-UP 20K
PULL-DOWN 20K
PULL-UP 20K
PULL-DOWN 15K
PULL-UP 13K

D

E

Crestline Strapping Signals and
Configuration

Pin Name

CFG[2:0]

CFG[4:3]
CFG5

CFG9

CFG[11:10] Reserved

CFG[13:12]

CFG[15:14]
CFG16

CFG[18:17]

CFG19

CFG20

SDVOCRTL
_DATA

NOTE:

Strap Description

FSB Frequency Select

Reserved
DMI x2 Select
ReservedCFG[8:6]

Low Power PCI Express

PCI Express Graphics
Lane Reversal

XOR/ALL Z test
straps

Reserved
FSB Dynamic ODT

Reserved

DMI Lane Reversal

SDVO/PCIE
Concurrent

SDVO Present

All strap signals are sampled with respect to the leading

edge of the Crestline GMCH PWORK in signal.

Crestline EDS 20954 1.0

Configuration

001 = FSB533
011 = FSB667
010 = FSB800
others = Reserved

0 = DMI x2

1 = DMI x4

0 = Normal mode

1 = Low Power mode

0 = Reverse Lanes,15->0,14->1 ect..

1= Normal operation(Default):Lane
Numbered in order

00 = Reserved
01 = XOR mode enabled
10 = All Z mode enabled

11 = Normal Operation

Reserved

0 = Dynamic ODT Disabled

1 = Dynamic ODT Enabled

0 = Normal operation (Default):lane
Numbered in order

1 =Reverse Lane,4->0,3->1 ect...

0 = Only SDVO or PCIE x1 is
operational (Default)

1 =SDVO and PCIE x1 are operating
simultaneously via the PEG port

0 = No SDVO Card present

1= SDVO Card present

(Default)

(Default)

page 7

(Default)

(Default)

(Default)

History

2 2

ICH7M IDE Integrated Series
Termination Resistors

DIOR#,DIOW#,DD[15:0],
DDACK#, IORDY,
DCS3#,

IDEIRQ

PCIE Routing

LAN BCM5787M

LANE1
LANE2

MiniCard WLAN

LANE3 NewCard WLAN

1 1

DA[2:0],

A

DREQ,
DCS1#,

approximately 33 ohm

USB Table

USB ports definition

Pair

Device

0

USB1
USB3

1

USB2

2

USB4

3
4 MINICARD

BlueTooth

5
6

CCD

7

NewCard

PCI Routing

INT REQ

INT_PIRQG#

B

page 16

PCI_REQ#0 PCI_GNT#0AD22OZ129

GNTIDSEL

UMA

UMA

UMA

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
A3

A3

A3
Date: Sheet

Date: Sheet

C

D

Date: Sheet

Taipei Hsien 221, Taiwan, R.O.C.

Reference

Reference

Reference

Volvi

Volvi

Volvi

-1

-1

242Wednesday, April 18, 2007

242Wednesday, April 18, 2007

242Wednesday, April 18, 2007

-1

of

of

of

E

A

R318

R318
0R3-0-U-GP

3D3V_48MPWR_S0

12

C426

C426

SC4D7U6D3V3KX-GP

SC4D7U6D3V3KX-GP

DY

DY

0R3-0-U-GP

12

C422

C422

SC1U16V3ZY-GP

SC1U16V3ZY-GP

-1 0412

4 4

3D3V_CLKPLL_S0

12

12

C393

C393

C392

C392

SC4D7U6D3V3KX-GP

SC4D7U6D3V3KX-GP

SC1U16V3ZY-GP

DY

DY

3D3V_S0

H/L: 100/96MHz

12

R325

R325
10KR2J-3-GP

10KR2J-3-GP

3 3

DY

DY

SS_SEL

12

R327

R327
10KR2J-3-GP

10KR2J-3-GP

SC1U16V3ZY-GP

CL=20pF±0.2pF

C188

SB 0313 for EMI

PCLK_PCM

2 2

1 1

EC129

EC129

SC22P50V2JN-4GP

SC22P50V2JN-4GP

1 2

EMI

CLK_ICH14

SB 0313 for EMI

PCLK_KBC

CLK_ICHPCI
CLK48_ICH

EC19 SC10P50V2JN-4GP

EC19 SC10P50V2JN-4GP

1 2

EC86 SC22P50V2JN-4GPEC86 SC22P50V2JN-4GP

1 2

EC21 SC10P50V2JN-4GP

EC21 SC10P50V2JN-4GP

1 2

EC15 SC10P50V2JN-4GP

EC15 SC10P50V2JN-4GP

1 2

DY

DY

DY

DY

DY

DY

A

C188
SC27P50V2JN-2-GP

SC27P50V2JN-2-GP

1 2

12

X2 X-14D31818M-44GP

X2 X-14D31818M-44GP

82.30005.951

1 2

C189

C189
SC27P50V2JN-2-GP

SC27P50V2JN-2-GP

82.30005.951

DREFSSCLK#
DREFSSCLK

DREFCLK#
DREFCLK

CLK_CPU_BCLK#
CLK_CPU_BCLK

CLK_MCH_BCLK
CLK_MCH_BCLK#

CLK_MCH_3GPLL
CLK_MCH_3GPLL#

CLK_PCIE_PEG
CLK_PCIE_PEG#

R291

R291
0R0603-PAD

0R0603-PAD

1 2

12

C412

C412

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

-1 0411 Del R321

-1 0413

GEN_XTAL_OUT_R

1
2 3

1
2 3

1
2 3

1
2 3

2 3
1

1
2 3

3D3V_S0

12

3D3V_S0

PCLK_KBC30
PCLK_PCM24

CLK_ICHPCI16

DREFCLK7

DREFCLK#7

CLK_EN#35

RN58

RN58
SRN49D9F-GP

SRN49D9F-GP

RN60

RN60
SRN49D9F-GP

SRN49D9F-GP

RN59

RN59
SRN49D9F-GP

SRN49D9F-GP

RN57

RN57
SRN49D9F-GP

SRN49D9F-GP

RN56

RN56
SRN49D9F-GP

SRN49D9F-GP

RN55

RN55
SRN49D9F-GP

SRN49D9F-GP

MXM

MXM

B

-1 0412-1 0413

3D3V_CLKGEN_S0

12

12

C430

C430

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

12
12

12

PM_STPPCI#16

SMBC_ICH11,18

SMBD_ICH11,18

23
1

R320

R320

12

22R2J-2-GP

22R2J-2-GP
R311

R311

12

475R2F-L1-GP

475R2F-L1-GP

12

1 2

R323

R323
10KR2J-3-GP

10KR2J-3-GP

12

C399

C399

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

PCLKKBC
PCLKPCM

SS_SEL
PCLKICH

DREFCLK_1
DREFCLK#_1

GEN_XTAL_IN
GEN_XTAL_OUT

GEN_REF

GEN_IREF

DY

DY

RN52

RN52
SRN49D9F-GP

SRN49D9F-GP

2 3
1

RN51

RN51

SRN49D9F-GP

SRN49D9F-GP

2 3
1

RN49

RN49

SRN49D9F-GP

SRN49D9F-GP

2 3
1

RN54

RN54

SRN49D9F-GP

SRN49D9F-GP

2 3
1

RN53

RN53

SRN49D9F-GP

SRN49D9F-GP

1
2 3

C408

C408

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

U10

U10

56

PCI_2/REQ_SEL

3

PCI_3

4

PCI_4

5

PCI_5

9

PCIF_1/DOT96SS_SEL#

8

PCIF_0/ITP_EN

55

PCI_STOP#

46

SCLK

47

SDATA

14

DOT96

15

DOT96#

50

X1

49

X2

52

REF_0

39

IREF

10

VTT_POWER_GOOD#/PWRDWN

2

GND_PCI

6

GND_PCI

51

GND_REF

45

GND_CPU

38

GND_CORE

13

GND_48

29

GND_SRC

RTM865T-433-GP

RTM865T-433-GP

71.00865.B0W

71.00865.B0W

4

4

4

4

4

12

C416

C416

SC4D7U6D3V3KX-GP

SC4D7U6D3V3KX-GP

R328 33R2J-2-GPR328 33R2J-2-GP
R331 33R2J-2-GPR331 33R2J-2-GP

R329 33R2J-2-GPR329 33R2J-2-GP

RN31

RN31
SRN33J-5-GP-U

SRN33J-5-GP-U

UMA

UMA

4

R1190R0402-PAD R1190R0402-PAD

12

CLK_ICH1416

R319 0R2J-2-GPR319 0R2J-2-GP

3D3V_S0

4

4

4

4

4

4

B

CLK_PCIE_NEW
CLK_PCIE_NEW#

CLK_PCIE_LAN#
CLK_PCIE_LAN

CLK_PCIE_SATA
CLK_PCIE_SATA#

CLK_PCIE_ICH
CLK_PCIE_ICH#

CLK_PCIE_MINI1
CLK_PCIE_MINI1#

R297

R297
0R0603-PAD

0R0603-PAD

1 2

12

C425

C425

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

C

C

3D3V_S0

12

C396

C396

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SRC_6#/PCIE_REQ_2#

FSC/TEST_SEL/REF_1

SRC_0/DOT96SS

SRC_0#/DOT96SS#

SRC_1

SRC_1#

SRC_2

SRC_2#

SRC_3

SRC_3#

SRC_4_SATA

SRC_4_SATA#

SRC_5

SRC_5#

SRC_6/PCIE_REQ_1#

CPU_2_ITP/SRC_7

CPU_2_ITP#/SRC_7#

CPU_0

CPU_0#

CPU_1

CPU1_#

CPU_STOP#

FSB/TEST_MODE

USB48MHZ/FSA

VDD_3.3_SRC
VDD_3.3_SRC

VDD_3.3_PCI
VDD_3.3_PCI

VDD_3.3_REF
VDD_3.3_CPU

VDD_3.3_CORE

VDD_3.3_48M

VDD_3.3_SRC

DREFSSCLK_1

17

DREFSSCLK#_1

18

CLK_MCH_3GPLL_1

19

CLK_MCH_3GPLL_1#

20

CLK_PCIE_ICH_1

22

CLK_PCIE_ICH_1#

23

CLK_PCIE_NEW_R

24

CLK_PCIE_NEW#_R

25

CLK_PCIE_SATA_1

26

CLK_PCIE_SATA_1#

27

CLK_PCIE_LAN_R

31

CLK_PCIE_LAN#_R

30

CLK_PCIE_MINI_1

33

CLK_PCIE_MINI_1#

32

CLK_PCIE_PEG_1

36

CLK_PCIE_PEG_1#

35

CLK_CPU_BCLK_1

44

CLK_CPU_BCLK_1#

43

CLK_MCH_BCLK_1

41

CLK_MCH_BCLK_1#

40
54

CPU_SEL2_R

53

CPU_SEL1_R

16

CLK48

12

34
21

7
1

48
42
37
11
28

3D3V_CLKPLL_S0
3D3V_48MPWR_S0

3D3V_CLKGEN_S0

D

PM_STPCPU# 16

R324

R324

12

2K2R2J-2-GP

2K2R2J-2-GP
R314

R314

12

2K2R2J-2-GP

2K2R2J-2-GP
R317

R317

12

22R2J-2-GP

22R2J-2-GP
R316

R316

12

2K2R2J-2-GP

2K2R2J-2-GP

D

E

RN29

RN29

SRN33J-5-GP-U

DREFSSCLK_1
DREFSSCLK#_1

CLK_MCH_3GPLL_1
CLK_MCH_3GPLL_1#

CLK_PCIE_ICH_1
CLK_PCIE_ICH_1#

CLK_PCIE_NEW_R
CLK_PCIE_NEW#_R

CLK_PCIE_SATA_1
CLK_PCIE_SATA_1#

CLK_PCIE_LAN_R
CLK_PCIE_LAN#_R

CLK_PCIE_MINI_1
CLK_PCIE_MINI_1#

CLK_PCIE_PEG_1
CLK_PCIE_PEG_1#

CLK_CPU_BCLK_1
CLK_CPU_BCLK_1#

CLK_MCH_BCLK_1
CLK_MCH_BCLK_1#

CPU_SEL2 4,7
CPU_SEL1 4,7
CLK48_ICH 16
CPU_SEL0 4,7

UMA

UMA

UMA

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

SRN33J-5-GP-U

2 3

UMA

UMA

1

4

RN27

RN27

SRN33J-5-GP-U

SRN33J-5-GP-U

2 3
1

4

RN25

RN25

SRN33J-5-GP-U

SRN33J-5-GP-U

2 3
1

4

RN23

RN23

SRN33J-5-GP-U

SRN33J-5-GP-U

2 3
1

4

RN21

RN21

SRN33J-5-GP-U

SRN33J-5-GP-U

2 3
1

4

RN22 SRN33J-5-GP-URN22 SRN33J-5-GP-U

1

4

2 3

RN24 SRN33J-5-GP-URN24 SRN33J-5-GP-U

1

4

2 3

RN26 SRN33J-5-GP-U

RN26 SRN33J-5-GP-U

1

4

2 3

MXM

MXM

RN30 SRN33J-5-GP-URN30 SRN33J-5-GP-U

1

4

2 3

RN28 SRN33J-5-GP-URN28 SRN33J-5-GP-U

1

4

2 3

FSB

FSC

0
0
0
0
1

1
1

Clock Generator

Clock Generator

Clock Generator

FSA

0

0

1
0

1

10166M

1
0

0

0

1
0

1

1

1

Volvi

Volvi

Volvi

DREFSSCLK 7
DREFSSCLK# 7

CLK_MCH_3GPLL 7
CLK_MCH_3GPLL# 7

CLK_PCIE_ICH 16
CLK_PCIE_ICH# 16

CLK_PCIE_NEW 27
CLK_PCIE_NEW# 27

CLK_PCIE_SATA 15
CLK_PCIE_SATA# 15

CLK_PCIE_LAN 22
CLK_PCIE_LAN# 22

CLK_PCIE_MINI1 27
CLK_PCIE_MINI1# 27

CLK_PCIE_PEG 26
CLK_PCIE_PEG# 26

CLK_CPU_BCLK 4
CLK_CPU_BCLK# 4

CLK_MCH_BCLK 6
CLK_MCH_BCLK# 6

CPU

FSB

X

266M

533M

133M

X

200M

667M
X

333M
100M1

X
X

400M

X

Reserved

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

342Wednesday, April 18, 2007

342Wednesday, April 18, 2007

342Wednesday, April 18, 2007

E

-1

-1

of

of

of

-1

A

U39A

H_A#[31..3]6

4 4

H_ADSTB#06
H_REQ#[4..0]6

3 3

2 2

H_ADSTB#16

H_A20M#15

H_FERR#15

H_IGNNE#15

H_INTR15
H_NMI15
H_SMI#15

H_A#3
H_A#4
H_A#5
H_A#6
H_A#7
H_A#8
H_A#9
H_A#10
H_A#11
H_A#12
H_A#13
H_A#14
H_A#15
H_A#16

H_REQ#0
H_REQ#1
H_REQ#2
H_REQ#3
H_REQ#4

H_A#17
H_A#18
H_A#19
H_A#20
H_A#21
H_A#22
H_A#23
H_A#24
H_A#25
H_A#26
H_A#27
H_A#28
H_A#29
H_A#30
H_A#31

H_STPCLK#15

U39A

J4

A[3]#

L4

A[4]#

M3

A[5]#

K5

ADDR GROUP 0

ADDR GROUP 0

A[6]#

M1

A[7]#

N2

A[8]#

J1

A[9]#

N3

A[10]#

P5

A[11]#

P2

A[12]#

L1

A[13]#

P4

A[14]#

P1

A[15]#

R1

A[16]#

L2

ADSTB[0]#

K3

REQ[0]#

H2

REQ[1]#

K2

REQ[2]#

J3

REQ[3]#

L5

REQ[4]#

Y2

A[17]#

U5

A[18]#

AA1
AA4
AB2
AA3

B25

R3
W6
U4

U2
R4

W3
W5

W2

C4
D5

C6

M4
N5

C3

A[19]#
A[20]#
A[21]#

Y5

A[22]#
A[23]#
A[24]#

T5

A[25]#

T3

A[26]#
A[27]#
A[28]#

Y4

A[29]#
A[30]#

Y1

A[31]#

V4

ADSTB[1]#

A6

A20M#

A5

FERR#
IGNNE#

STPCLK#
LINT0

B4

LINT1

A3

SMI#
RSVD[01]

RSVD[02]
RSVD[03]
RSVD[04]
RSVD[05]
RSVD[06]

T2

RSVD[07]

V3

RSVD[08]

B2

RSVD[09]
RSVD[10]

RSVD[11]

BGA479-SKT6-GPU3

BGA479-SKT6-GPU3

62.10079.001

62.10079.001

ADDR GROUP 1

ADDR GROUP 1

XDP/ITP SIGNALSH CLK

XDP/ITP SIGNALSH CLK

PROCHOT#

THERMDA
THERMDC

THERM

THERM

THERMTRIP#

RESERVED

RESERVED

2nd source: 62.10053.401

XDP_TDI
XDP_TMS
XDP_TDO
H_CPURST#

XDP_DBRESET#

H1

ADS#

E2

BNR#

G5

BPRI#

H5

DEFER#

F21

DRDY#

E1

DBSY#

F1

BR0#

D20

IERR#

B3

INIT#

H4

LOCK#

CONTROL

CONTROL

B1

RESET#

F3

RS[0]#

F4

RS[1]#

G3

RS[2]#

G2

TRDY#

G6

HIT#

E4

HITM#

AD4

BPM[0]#

AD3

BPM[1]#

AD1

BPM[2]#

AC4

BPM[3]#

AC2

PRDY#

AC1

PREQ#

AC5

TCK

AA6

TDI

AB3

TDO

AB5

TMS

AB6

TRST#

C20

DBR#

D21
A24
A25

C7

A22

BCLK[0]

A21

BCLK[1]

T22

RSVD[12]

D2

RSVD[13]

F6

RSVD[14]

D3

RSVD[15]

C1

RSVD[16]

AF1

RSVD[17]

D22

RSVD[18]

C23

RSVD[19]

C24

RSVD[20]

R107 150R2F-1-GPR107 150R2F-1-GP
R111 39D2R3F-2-GPR111 39D2R3F-2-GP
R110 54D9R2F-L1-GP

R110 54D9R2F-L1-GP
R54 54D9R2F-L1-GP

R54 54D9R2F-L1-GP

R64 150R2F-1-GP

R64 150R2F-1-GP

H_RS#0
H_RS#1
H_RS#2

XDP_TCK
XDP_TDI
XDP_TDO
XDP_TMS
XDP_TRST#
XDP_DBRESET#

1 2
1 2

DY

DY

1 2

DY

DY

1 2

1 2

DY

DY

B

TP5 TPAD30TP5 TPAD30

H_ADS# 6
H_BNR# 6

H_BPRI# 6

H_DEFER# 6
H_DRDY# 6
H_DBSY# 6

H_BREQ#0 6

H_IERR#
H_INIT# 15

H_LOCK# 6
H_CPURST# 6,31

H_TRDY# 6
H_HIT# 6

H_HITM# 6

TP23 TPAD30TP23 TPAD30
TP18 TPAD30TP18 TPAD30
TP22 TPAD30TP22 TPAD30
TP21 TPAD30TP21 TPAD30
TP19 TPAD30TP19 TPAD30
TP6 TPAD30TP6 TPAD30

CPU_PROCHOT#_R

H_THERMDA 19
H_THERMDC 19

PM_THRMTRIP-A# 7,33

CLK_CPU_BCLK 3
CLK_CPU_BCLK# 3

PM_THRMTRIP#
should connect to
ICH7 and Calistoga
without T-ing

( No stub)

1D05V_S0

3D3V_S0

H_RS#[2..0] 6

1D05V_S0

12

1D05V_S0

R80

R80
56R2J-4-GP

56R2J-4-GP

Place testpoint on
H_IERR# with a GND

0.1" away

R280

R280
56R2J-4-GP

56R2J-4-GP

1 2

H_THERMDA

H_THERMDC

1D05V_S0

1 2
12

Layout Note:

0.5" max length.

R330

R330
1KR2J-1-GP

1KR2J-1-GP

R332

R332
2KR2F-3-GP

2KR2F-3-GP

H_INIT#

C

U39B

H_D#0
H_D#1
H_D#2
H_D#3
H_D#4
H_D#5
H_D#6
H_D#7
H_D#8
H_D#9
H_D#10
H_D#11
H_D#12
H_D#13
H_D#14

H_DSTBN#06
H_DSTBP#06
H_DINV#06

12

C362

C362
SC2200P50V2KX-2GP

SC2200P50V2KX-2GP

CPU_GTLREF0 COMP0

12

C173

C173

SC1KP50V2KX-1GP

SC1KP50V2KX-1GP

DY

DY

1 2

R61 1KR2J-1-GP

R61 1KR2J-1-GP

1 2

R270 51R2F-2-GPR270 51R2F-2-GP

H_D#15

H_D#16
H_D#17
H_D#18
H_D#19
H_D#20
H_D#21
H_D#22
H_D#23
H_D#24
H_D#25
H_D#26
H_D#27
H_D#28
H_D#29
H_D#30
H_D#31

H_DSTBN#16
H_DSTBP#16
H_DINV#16

DY

DY

TEST2

CPU_SEL03,7
CPU_SEL13,7
CPU_SEL23,7

U39B

E22

D[0]#

F24

D[1]#

E26

D[2]#

H22

D[3]#

F23

D[4]#

G25

D[5]#

E25

D[6]#

E23

D[7]#

K24

D[8]#

G24

D[9]#

J24

D[10]#

J23

D[11]#

H26

D[12]#

F26

D[13]#

K22

D[14]#

H25

D[15]#

H23

DSTBN[0]#

G22

DSTBP[0]#

J26

DINV[0]#

N22

D[16]#

K25

D[17]#

P26

D[18]#

R23

D[19]#

L25

D[20]#

L22

D[21]#

L23

D[22]#

M23

D[23]#

P25

D[24]#

P22

D[25]#

P23

D[26]#

T24

D[27]#

R24

D[28]#

L26

D[29]#

T25

D[30]#

N24

D[31]#

M24

DSTBN[1]#

N25

DSTBP[1]#

M26

DINV[1]#

AD26

GTLREF

C26

TEST1

D25

TEST2

B22

BSEL[0]

B23

BSEL[1]

C21

BSEL[2]

BGA479-SKT6-GPU3

BGA479-SKT6-GPU3

62.10079.001

62.10079.001

MISC

MISC

D[32]#
D[33]#
D[34]#
D[35]#

DATA GRP 0 DATA GRP 1

DATA GRP 0 DATA GRP 1

D[36]#
D[37]#
D[38]#
D[39]#
D[40]#
D[41]#

DATA GRP 2

DATA GRP 2

D[42]#
D[43]#
D[44]#
D[45]#
D[46]#

D[47]#
DSTBN[2]#
DSTBP[2]#

DINV[2]#

D[48]#

D[49]#

D[50]#

D[51]#

D[52]#

D[53]#

D[54]#

D[55]#

D[56]#

D[57]#

D[58]#

D[59]#

DATA GRP 3

DATA GRP 3

D[60]#

D[61]#

D[62]#

D[63]#
DSTBN[3]#
DSTBP[3]#

DINV[3]#
COMP[0]

COMP[1]
COMP[2]
COMP[3]

DPRSTP#

DPSLP#

DPWR#

PWRGOOD

SLP#

PSI#

D

2nd source: 62.10053.401

12

C66

C66

SC4700P50V2KX

SC4700P50V2KX

DY

DY

AA23
AB24
V24
V26
W25
U23
U25
U22
AB25
W22
Y23
AA26
Y26
Y22
AC26
AA24
W24
Y25
V23

AC22
AC23
AB22
AA21
AB21
AC25
AD20
AE22
AF23
AD24
AE21
AD21
AE25
AF25
AF22
AF26
AD23
AE24
AC20

R26
U26
U1
V1

E5
B5
D24
D6
D7
AE6

H_DINV#[3..0] 6
H_DSTBN#[3..0] 6
H_DSTBP#[3..0] 6
H_D#[63..0] 6

H_D#32
H_D#33
H_D#34
H_D#35
H_D#36
H_D#37
H_D#38
H_D#39
H_D#40
H_D#41
H_D#42
H_D#43
H_D#44
H_D#45
H_D#46

COMP1
COMP2
COMP3TEST1

H_D#47

H_D#48
H_D#49
H_D#50
H_D#51
H_D#52
H_D#53
H_D#54
H_D#55
H_D#56
H_D#57
H_D#58
H_D#59
H_D#60
H_D#61
H_D#62
H_D#63

H_DSTBN#2 6
H_DSTBP#2 6
H_DINV#2 6

H_DSTBN#3 6
H_DSTBP#3 6
H_DINV#3 6

R287 27D4R2F-L1-GPR287 27D4R2F-L1-GP

1 2

R309 54D9R2F-L1-GPR309 54D9R2F-L1-GP

1 2

R96 27D4R2F-L1-GPR96 27D4R2F-L1-GP

1 2

R102 54D9R2F-L1-GPR102 54D9R2F-L1-GP

1 2

H_DPRSTP# 15,35
H_DPSLP# 15
H_DPWR# 6

H_PWRGD 15,31,33

H_CPUSLP# 6,15
PSI# 35

E

Layout Note:
Comp0, 2 connect with Zo=27.4 ohm, make
trace length shorter than 0.5" .
Comp1, 3 connect with Zo=55 ohm, make
trace length shorter than 0.5" .

XDP_TCK

1 1

A

XDP_TRST#

R112 27D4R2F-L1-GPR112 27D4R2F-L1-GP

1 2

R113 680R3F-GPR113 680R3F-GP

1 2

All place within 2" to CPU

B

UMA

UMA

UMA

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

C

D

Date: Sheet

Taipei Hsien 221, Taiwan, R.O.C.

CPU (1 of 2)

CPU (1 of 2)

CPU (1 of 2)

Volvi

Volvi

Volvi

E

-1

-1

of

442Wednesday, April 18, 2007

of

442Wednesday, April 18, 2007

of

442Wednesday, April 18, 2007

-1

A

VCC[068]
VCC[069]
VCC[070]
VCC[071]
VCC[072]
VCC[073]
VCC[074]
VCC[075]
VCC[076]
VCC[077]
VCC[078]
VCC[079]
VCC[080]
VCC[081]
VCC[082]
VCC[083]
VCC[084]
VCC[085]
VCC[086]
VCC[087]
VCC[088]
VCC[089]
VCC[090]
VCC[091]
VCC[092]
VCC[093]
VCC[094]
VCC[095]
VCC[096]
VCC[097]
VCC[098]
VCC[099]
VCC[100]

VCCP[01]
VCCP[02]
VCCP[03]
VCCP[04]
VCCP[05]
VCCP[06]
VCCP[07]
VCCP[08]
VCCP[09]
VCCP[10]
VCCP[11]
VCCP[12]
VCCP[13]
VCCP[14]
VCCP[15]
VCCP[16]

VCCA

VID[0]
VID[1]
VID[2]
VID[3]
VID[4]
VID[5]
VID[6]

VCC_CORE_S0

AB20
AB7
AC7
AC9
AC12
AC13
AC15
AC17
AC18
AD7
AD9
AD10
AD12
AD14
AD15
AD17
AD18
AE9
AE10
AE12
AE13
AE15
AE17
AE18
AE20
AF9
AF10
AF12
AF14
AF15
AF17
AF18
AF20

V6
G21
J6
K6
M6
J21
K21
M21
N21
N6
R21
R6
T21
T6
V21
W21

B26

H_VID0

AD6

H_VID1

AF5

H_VID2

AE5

H_VID3

AF4

H_VID4

AE3

H_VID5

AF2

H_VID6

AE2

AF7

AE7

1D05V_CPU_V6

H_VID0 35
H_VID1 35
H_VID2 35
H_VID3 35
H_VID4 35
H_VID5 35
H_VID6 35

VCC_CORE_S0

4 4

3 3

2 2

U39C

U39C

A7

VCC[001]

A9

VCC[002]

A10

VCC[003]

A12

VCC[004]

A13

VCC[005]

A15

VCC[006]

A17

VCC[007]

A18

VCC[008]

A20

VCC[009]

B7

VCC[010]

B9

VCC[011]

B10

VCC[012]

B12

VCC[013]

B14

VCC[014]

B15

VCC[015]

B17

VCC[016]

B18

VCC[017]

B20

VCC[018]

C9

VCC[019]

C10

VCC[020]

C12

VCC[021]

C13

VCC[022]

C15

VCC[023]

C17

VCC[024]

C18

VCC[025]

D9

VCC[026]

D10

VCC[027]

D12

VCC[028]

D14

VCC[029]

D15

VCC[030]

D17

VCC[031]

D18

VCC[032]

E7

VCC[033]

E9

VCC[034]

E10

VCC[035]

E12

VCC[036]

E13

VCC[037]

E15

VCC[038]

E17

VCC[039]

E18

VCC[040]

E20

VCC[041]

F7

VCC[042]

F9

VCC[043]

F10

VCC[044]

F12

VCC[045]

F14

VCC[046]

F15

VCC[047]

F17

VCC[048]

F18

VCC[049]

F20

VCC[050]

AA7

VCC[051]

AA9

VCC[052]

AA10

VCC[053]

AA12

VCC[054]

AA13

VCC[055]

AA15

VCC[056]

AA17

VCC[057]

AA18

VCC[058]

AA20

VCC[059]

AB9

VCC[060]

AC10

VCC[061]

AB10

VCC[062]

AB12

VCC[063]

AB14

VCC[064]

AB15

VCC[065]

AB17

VCC[066]

AB18

VCC[067]

BGA479-SKT6-GPU3

BGA479-SKT6-GPU3

62.10079.001

62.10079.001

VCCSENSE

VSSSENSE

B

1D05V_S0

R95

R95

1 2

0R0402-PAD

0R0402-PAD

12

C161

C161
SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

VCC_CORE_S0

12

R117

R117
100R2F-L1-GP-U

100R2F-L1-GP-U

12

R118

R118
100R2F-L1-GP-U

100R2F-L1-GP-U

VCC_CORE_S0

Layout Note

1D5V_VCCA_S0 1D05V_S01D5V_S0

L19

L19

1 2

HCB1608KF121T30-GP

HCB1608KF121T30-GP

12

12

C370

C370

C372

C372

VCC_SENSE 35

VSS_SENSE 35

Layout Note:

VCCSENSE and VSSSENSE lines
should be of equal length.

Layout Note:
Provide a test point (with
no stub) to connect a
differential probe
between VCCSENSE and
VSSSENSE at the location
where the two 54.9ohm
resistors terminate the
55 ohm transmission line.

SC4D7U6D3V3KX-GP

SC4D7U6D3V3KX-GP

SCD01U16V2KX-3GP

SCD01U16V2KX-3GP

68.00230.041

68.00230.041

C

12

C99

C99

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

VCC_CORE_S0

12

C84

C84

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

D

A4

A8
A11
A14
A16
A19
A23
A26

B6

B8
B11
B13
B16
B19
B21
B24

C5

C8
C11
C14
C16
C19

C2
C22
C25

D1

D4

D8
D11
D13
D16
D19
D23
D26

E3
E6

E8
E11
E14
E16
E19
E21
E24

F5

F8
F11
F13
F16
F19

F2
F22
F25

G4

G1
G23
G26

H3

M22
M25

N23
N26

H6
H21
H24

J2

J5
J22
J25

K1

K4

K23
K26

L3

L6

L21
L24

M2
M5

N1
N4

12

12

C154

C154

C104

C104

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

12

12

C85

C85

C165

C165

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

DY

DY

12

12

C142

C142

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

12

C164

C164

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

12

C162

C162

C96

C96

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

12

12

C169

C169

C167

C167

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

12

12

C127

C127

C126

C126

SC4D7U6D3V3KX-GP

SC4D7U6D3V3KX-GP

SC4D7U6D3V3KX-GP

SC4D7U6D3V3KX-GP

12

C54

C54

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

E

U39D

U39D

VSS[082]

VSS[001]
VSS[002]

VSS[083]

VSS[003]

VSS[084]

VSS[004]

VSS[085]

VSS[005]

VSS[086]

VSS[006]

VSS[087]

VSS[007]

VSS[088]

VSS[008]

VSS[089]

VSS[009]

VSS[090]

VSS[010]

VSS[091]

VSS[011]

VSS[092]

VSS[012]

VSS[093]

VSS[013]

VSS[094]

VSS[014]

VSS[095]

VSS[015]

VSS[096]

VSS[016]

VSS[097]

VSS[017]

VSS[098]

VSS[018]

VSS[099]

VSS[019]

VSS[100]

VSS[020]

VSS[101]

VSS[021]

VSS[102]

VSS[022]

VSS[103]

VSS[023]

VSS[104]

VSS[024]

VSS[105]

VSS[025]

VSS[106]

VSS[026]

VSS[107]

VSS[027]

VSS[108]

VSS[028]

VSS[109]

VSS[029]

VSS[110]

VSS[030]

VSS[111]

VSS[031]

VSS[112]

VSS[032]

VSS[113]

VSS[033]

VSS[114]

VSS[034]

VSS[115]

VSS[035]

VSS[116]

VSS[036]

VSS[117]

VSS[037]

VSS[118]

VSS[038]

VSS[119]

VSS[039]

VSS[120]

VSS[040]

VSS[121]

VSS[041]

VSS[122]

VSS[042]

VSS[123]

VSS[043]

VSS[124]

VSS[044]

VSS[125]

VSS[045]

VSS[126]

VSS[046]

VSS[127]

VSS[047]

VSS[128]

VSS[048]

VSS[129]

VSS[049]

VSS[130]

VSS[050]

VSS[131]

VSS[051]

VSS[132]

VSS[052]

VSS[133]

VSS[053]

VSS[134]

VSS[054]

VSS[135]

VSS[055]

VSS[136]

VSS[056]

VSS[137]

VSS[057]

VSS[138]

VSS[058]

VSS[139]

VSS[059]

VSS[140]

VSS[060]

VSS[141]

VSS[061]

VSS[142]

VSS[062]

VSS[143]

VSS[063]

VSS[144]

VSS[064]

VSS[145]

VSS[065]

VSS[146]

VSS[066]

VSS[147]
VSS[148]

VSS[067]
VSS[068]

VSS[149]

VSS[069]

VSS[150]

VSS[070]

VSS[151]

VSS[071]

VSS[152]

VSS[072]

VSS[153]

VSS[073]

VSS[154]

VSS[074]

VSS[155]

VSS[075]

VSS[156]

VSS[076]

VSS[157]

VSS[077]

VSS[158]

VSS[078]

VSS[159]

VSS[079]

VSS[160]

VSS[080]

VSS[161]

VSS[081]P3VSS[162]

BGA479-SKT6-GPU3

BGA479-SKT6-GPU3

62.10079.001

62.10079.001

P6
P21
P24
R2
R5
R22
R25
T1
T4
T23
T26
U3
U6
U21
U24
V2
V5
V22
V25
W1
W4
W23
W26
Y3
Y6
Y21
Y24
AA2
AA5
AA8
AA11
AA14
AA16
AA19
AA22
AA25
AB1
AB4
AB8
AB11
AB13
AB16
AB19
AB23
AB26
AC3
AC6
AC8
AC11
AC14
AC16
AC19
AC21
AC24
AD2
AD5
AD8
AD11
AD13
AD16
AD19
AD22
AD25
AE1
AE4
AE8
AE11
AE14
AE16
AE19
AE23
AE26
AF3
AF6
AF8
AF11
AF13
AF16
AF19
AF21
AF24

12

12

C73

C73

C72

C72

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

1 1

A

B

12

12

C109

C109

C53

C53

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

12

12

C152

C152

C168

C168

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

12

12

C182

C182

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

C128

C128

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

12

C184

C184

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

C

12

12

C183

C183

C108

C108

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

12

12

C177

C177

C151

C151

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

DY

DY

DY

DY

12

12

C170

C170

C129

C129

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

DY

DY

DY

DY

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

D

Date: Sheet

Taipei Hsien 221, Taiwan, R.O.C.

CPU (2 of 2)

CPU (2 of 2)

CPU (2 of 2)

Volvi

Volvi

Volvi

E

-1

-1

of

542Wednesday, April 18, 2007

of

542Wednesday, April 18, 2007

of

542Wednesday, April 18, 2007

-1

A

H_XRCOMP

12

R272

R272
24D9R2F-L-GP

24D9R2F-L-GP

4 4

3 3

2 2

1D05V_S0

1 2

1D05V_S0

12

12

12

1D05V_S0

1 2

1D05V_S0

12

12

R59

R59
54D9R2F-L1-GP

54D9R2F-L1-GP

H_XSCOMP

R263

R263
221R2F-2-GP

221R2F-2-GP

H_XSWING

R248

R248
100R2F-L1-GP-U

100R2F-L1-GP-U

H_YRCOMP

R281

R281
24D9R2F-L-GP

24D9R2F-L-GP

R275

R275
54D9R2F-L1-GP

54D9R2F-L1-GP

H_YSCOMP

R277

R277
221R2F-2-GP

221R2F-2-GP

H_YSWING

R279

R279
100R2F-L1-GP-U

100R2F-L1-GP-U

C355

C355

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

1 2

C374

C374

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

1 2

H_D#[63..0]4

B

U38A

W11

AB7
AA9

AB8
AA4

AA7
AA2
AA6

AA10

AA1
AB4

AC9
AB11
AC11

AB3

AC2

AD1

AD9

AC1

AD7

AC6

AB5
AD10

AD4

AC8

AG2

AG1

F1

J1

H1

J6

H3

K2
G1
G2

K9

K1

K7

J8

H4

J3

K11

G4

T10

T3
U7
U9

U11
T11

W9

T1

T8

T4
W7
U5

T9
W6

T5

W4
W3

Y3

Y7
W5

Y10

W2

Y8

E1

E2

E4

Y1
U1
W1

U38A

H_D#_0
H_D#_1
H_D#_2
H_D#_3
H_D#_4
H_D#_5
H_D#_6
H_D#_7
H_D#_8
H_D#_9
H_D#_10
H_D#_11
H_D#_12
H_D#_13
H_D#_14
H_D#_15
H_D#_16
H_D#_17
H_D#_18
H_D#_19
H_D#_20
H_D#_21
H_D#_22
H_D#_23
H_D#_24
H_D#_25
H_D#_26
H_D#_27
H_D#_28
H_D#_29
H_D#_30
H_D#_31
H_D#_32
H_D#_33
H_D#_34
H_D#_35
H_D#_36
H_D#_37
H_D#_38
H_D#_39
H_D#_40
H_D#_41
H_D#_42
H_D#_43
H_D#_44
H_D#_45
H_D#_46
H_D#_47
H_D#_48
H_D#_49
H_D#_50
H_D#_51
H_D#_52
H_D#_53
H_D#_54
H_D#_55
H_D#_56
H_D#_57
H_D#_58
H_D#_59
H_D#_60
H_D#_61
H_D#_62
H_D#_63

H_XRCOMP
H_XSCOMP
H_XSWING

H_YRCOMP
H_YSCOMP
H_YSWING

H_CLKIN
H_CLKIN#

CALISTOGA

CALISTOGA

71.CALIS.00U

71.CALIS.00U

HOST

HOST

H_D#0
H_D#1
H_D#2
H_D#3
H_D#4
H_D#5
H_D#6
H_D#7
H_D#8
H_D#9
H_D#10
H_D#11
H_D#12
H_D#13
H_D#14
H_D#15
H_D#16
H_D#17
H_D#18
H_D#19
H_D#20
H_D#21
H_D#22
H_D#23
H_D#24
H_D#25
H_D#26
H_D#27
H_D#28
H_D#29
H_D#30
H_D#31
H_D#32
H_D#33
H_D#34
H_D#35
H_D#36
H_D#37
H_D#38
H_D#39
H_D#40
H_D#41
H_D#42
H_D#43
H_D#44
H_D#45
H_D#46
H_D#47
H_D#48
H_D#49
H_D#50
H_D#51
H_D#52
H_D#53
H_D#54
H_D#55
H_D#56
H_D#57
H_D#58
H_D#59
H_D#60
H_D#61
H_D#62
H_D#63

H_XRCOMP
H_XSCOMP
H_XSWING

H_YRCOMP
H_YSCOMP
H_YSWING

CLK_MCH_BCLK3

CLK_MCH_BCLK#3

H_A#_3
H_A#_4
H_A#_5
H_A#_6
H_A#_7
H_A#_8

H_A#_9
H_A#_10
H_A#_11
H_A#_12
H_A#_13
H_A#_14
H_A#_15
H_A#_16
H_A#_17
H_A#_18
H_A#_19
H_A#_20
H_A#_21
H_A#_22
H_A#_23
H_A#_24
H_A#_25
H_A#_26
H_A#_27
H_A#_28
H_A#_29
H_A#_30
H_A#_31

H_ADS#
H_ADSTB#_0
H_ADSTB#_1

H_VREF_0

H_BNR#

H_BPRI#

H_BREQ#0

H_CPURST#

H_DBSY#

H_DEFER#

H_DPWR#

H_DRDY#

H_VREF_1

H_DINV#_0
H_DINV#_1
H_DINV#_2
H_DINV#_3

H_DSTBN#_0
H_DSTBN#_1
H_DSTBN#_2
H_DSTBN#_3

H_DSTBP#_0
H_DSTBP#_1
H_DSTBP#_2
H_DSTBP#_3

H_HIT#

H_HITM#

H_LOCK#

H_REQ#_0
H_REQ#_1
H_REQ#_2
H_REQ#_3
H_REQ#_4

H_RS#_0
H_RS#_1
H_RS#_2

H_SLPCPU#

H_TRDY#

C

H_ADS# 4
H_ADSTB#0 4
H_ADSTB#1 4

H_BNR# 4

H_BPRI# 4

H_BREQ#0 4

H_CPURST# 4,31

H_DBSY# 4

H_DEFER# 4
H_DPWR# 4

H_DRDY# 4

H_A#[31..3] 4

H_VREF

H_DINV#[3..0] 4

H_DSTBN#[3..0] 4

H_DSTBP#[3..0] 4

H_REQ#[4..0] 4

H_RS#[2..0] 4

H9
C9
E11
G11
F11
G12
F9
H11
J12
G14
D9
J14
H13
J15
F14
D12
A11
C11
A12
A13
E13
G13
F12
B12
B14
C12
A14
C14
D14

E8
B9
C13
J13
C6
F6
C7
B7
A7
C3
J9
H8
K13

J7
W8
U3
AB10

K4
T7
Y5
AC4

K3
T6
AA5
AC5

D3
D4
B3

D8
G8
B8
F8
A8

B4
E6
D6

E3
E7

H_A#3
H_A#4
H_A#5
H_A#6
H_A#7
H_A#8
H_A#9
H_A#10
H_A#11
H_A#12
H_A#13
H_A#14
H_A#15
H_A#16
H_A#17
H_A#18
H_A#19
H_A#20
H_A#21
H_A#22
H_A#23
H_A#24
H_A#25
H_A#26
H_A#27
H_A#28
H_A#29
H_A#30
H_A#31

H_DINV#0
H_DINV#1
H_DINV#2
H_DINV#3

H_DSTBN#0
H_DSTBN#1
H_DSTBN#2
H_DSTBN#3

H_DSTBP#0
H_DSTBP#1
H_DSTBP#2
H_DSTBP#3

H_HIT# 4
H_HITM# 4

H_LOCK# 4

H_REQ#0
H_REQ#1
H_REQ#2
H_REQ#3
H_REQ#4

H_RS#0
H_RS#1
H_RS#2

H_CPUSLP# 4,15
H_TRDY# 4

1 2

C74

C74

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

D

1D05V_S0

12

R70

R70
100R2F-L1-GP-U

100R2F-L1-GP-U

12

R65

R65
200R2F-L-GP

200R2F-L-GP

E

DIS :PM945 KI.94501.006
UMA :GM945 KI.94501.005

1 1

Place them near to the chip ( < 0.5")

A

B

C

D

UMA

UMA

UMA

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

Taipei Hsien 221, Taiwan, R.O.C.

GMCH (1 of 5)

GMCH (1 of 5)

GMCH (1 of 5)

Volvi

Volvi

Volvi

E

of

642Wednesday, April 18, 2007

of

642Wednesday, April 18, 2007

of

642Wednesday, April 18, 2007

-1

-1

-1

A

U38B

U38B

M_CLK_DDR011
M_CLK_DDR111
M_CLK_DDR211
M_CLK_DDR311

M_CLK_DDR#011
M_CLK_DDR#111
M_CLK_DDR#211
M_CLK_DDR#311

M_OCDCOMP0
M_OCDCOMP1

12

C419

C419

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

A

M_CKE011,12
M_CKE111,12
M_CKE211,12
M_CKE311,12

M_CS0#11,12
M_CS1#11,12
M_CS2#11,12
M_CS3#11,12

M_ODT011,12
M_ODT111,12
M_ODT211,12
M_ODT311,12

M_RCOMPN
M_RCOMPP

CLK_MCH_3GPLL#3
CLK_MCH_3GPLL3

DREFCLK#3

DREFCLK3
DREFSSCLK#3
DREFSSCLK3

DMI_TXN016

DMI_TXN116

DMI_TXN216

DMI_TXN316

DMI_TXP016

DMI_TXP116

DMI_TXP216

DMI_TXP316

DMI_RXN016

DMI_RXN116

DMI_RXN216

DMI_RXN316

DMI_RXP016

DMI_RXP116

DMI_RXP216

DMI_RXP316

4 4

12

12

R92

R92

R106

R106

40D2R2F-GP

40D2R2F-GP

40D2R2F-GP

40D2R2F-GP

DY

DY

DY

DY

DDR_VREF_S3

12

C415

C415

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

3 3

3D3V_S0

RN11

RN11
SRN10KJ-5-GP

SRN10KJ-5-GP

1
2 3

1D8V_S3

2 2

12

R114

R114
80D6R2F-L-GP

80D6R2F-L-GP

M_RCOMPN
M_RCOMPP

12

R109

R109
80D6R2F-L-GP

80D6R2F-L-GP

1 1

4

PM_EXTTS#0
PM_EXTTS#1

AY35

AR1

AW7

AW40
AW35

AT1
AY7

AY40

AU20

AT20

BA29

AY29

AW13
AW12

AY21

AW21

AL20
AF10

BA13
BA12

AY20

AU21

AV9
AT9

AK1

AK41

AF33

AG33

C40
D41

AE35

AF39
AG35
AH39

AC35
AE39

AF35
AG39

AE37

AF41
AG37
AH41

AC37
AE41

AF37
AG41

A27
A26

SM_CK_0
SM_CK_1
SM_CK_2
SM_CK_3

SM_CK#_0
SM_CK#_1
SM_CK#_2
SM_CK#_3

SM_CKE_0
SM_CKE_1
SM_CKE_2
SM_CKE_3

SM_CS#_0
SM_CS#_1
SM_CS#_2
SM_CS#_3

SM_OCDCOMP_0
SM_OCDCOMP_1

SM_ODT_0
SM_ODT_1
SM_ODT_2
SM_ODT_3

SM_RCOMP#
SM_RCOMP

SM_VREF_0
SM_VREF_1

G_CLKIN#
G_CLKIN
D_REFCLKIN#
D_REFCLKIN
D_REFSSCLKIN#
D_REFSSCLKIN

DMI_RXN_0
DMI_RXN_1
DMI_RXN_2
DMI_RXN_3

DMI_RXP_0
DMI_RXP_1
DMI_RXP_2
DMI_RXP_3

DMI_TXN_0
DMI_TXN_1
DMI_TXN_2
DMI_TXN_3

DMI_TXP_0
DMI_TXP_1
DMI_TXP_2
DMI_TXP_3

CALISTOGA

CALISTOGA

71.CALIS.00U

71.CALIS.00U

CFGRSVD

CFGRSVD

DDR MUXINGCLKDMI

DDR MUXINGCLKDMI

B

PM

PM

PM_THRMTRIP#

MISC

MISC

SDVO_CTRLCLK

SDVO_CTRLDATA

NC

NC

B

RSVD_0
RSVD_1
RSVD_2
RSVD_3
RSVD_4
RSVD_5
RSVD_6
RSVD_7
RSVD_8

RSVD_9
RSVD_10
RSVD_11
RSVD_12
RSVD_13
RSVD_14
RSVD_15

CFG_0
CFG_1
CFG_2
CFG_3
CFG_4
CFG_5
CFG_6
CFG_7
CFG_8

CFG_9
CFG_10
CFG_11
CFG_12
CFG_13
CFG_14
CFG_15
CFG_16
CFG_17
CFG_18
CFG_19
CFG_20

PM_BMBUSY#
PM_EXTTS#_0
PM_EXTTS#_1

PWROK

RSTIN#

LT_RESET#

NC0
NC1
NC2
NC3
NC4
NC5
NC6
NC7
NC8

NC9
NC10
NC11
NC12
NC13
NC14
NC15
NC16
NC17
NC18

H32
T32
R32
F3
F7
AG11
AF11
H7
J19
K30
J29
A41
A35
A34
D28
D27

K16
K18
J18
F18
E15
F15
E18
D19
D16
G16
E16
D15
G15
K15
C15
H16
G18
H15
J25
K27
J26

G28
F25
H26
G6
AH33
AH34

H28
H27
K28

D1
C41
C1
BA41
BA40
BA39
BA3
BA2
BA1
B41
B2
AY41
AY1
AW41
AW1
A40
A4
A39
A3

CFG9

PM_EXTTS#0
PM_EXTTS#1

PWROK_GD
RSTIN#

CTRLCLK
CTRLDATA

MCH_ICH_SYNC# 16

GMCH_DDCCLK14
GMCH_DDCDATA14

GMCH_HSYNC14
GMCH_VSYNC14

GMCH_BLUE

GMCH_GREEN

GMCH_RED

TV_DACA

TV_DACB

TV_DACC

CPU_SEL0 3,4
CPU_SEL1 3,4
CPU_SEL2 3,4

-1 0411

R504

R504

0R0402-PAD

0R0402-PAD

PM_BMBUSY# 16

PM_THRMTRIP-A# 4,33

R298 0R0402-PADR298 0R0402-PAD

1 2

R93

R93

TP8 TPAD30TP8 TPAD30
TP7 TPAD30TP7 TPAD30

-1 0411

RN10

RN10
SRN10KJ-5-GP

SRN10KJ-5-GP

R57

R57
150R2F-1-GP

150R2F-1-GP

1 2

R56

R56
150R2F-1-GP

150R2F-1-GP

1 2

R256

R256
150R2F-1-GP

150R2F-1-GP

1 2

R49

R49
150R2F-1-GP

150R2F-1-GP

1 2

R48

R48
150R2F-1-GP

150R2F-1-GP

1 2

R47

R47
150R2F-1-GP

150R2F-1-GP

1 2

12

1 2

100R2J-2-GP

100R2J-2-GP

SC100P50V2JN-3GP

SC100P50V2JN-3GP

UMA

UMA

UMA

UMA

UMA

UMA

UMA

UMA

UMA

UMA

UMA

UMA

GMCH_LCDVDD_ON13

1
2 3

RN15

RN15
SRN0J-6-GP

SRN0J-6-GP

R305 0R2J-2-GP

R305 0R2J-2-GP

1 2

DY

DY

12

C157

C157

DY

DY

4K99R2F-L-GP

4K99R2F-L-GP
R43 0R2J-2-GP

R43 0R2J-2-GP

R45 0R2J-2-GP

R45 0R2J-2-GP

R44 0R2J-2-GP

R44 0R2J-2-GP

3D3V_S0

4

1D05V_S0

1

2 3

C

L_BKLTCTL13
GMCH_BL_ON30

CLK_DDC_EDID13
DAT_DDC_EDID13

TP3TPAD30 TP3TPAD30

4

UMA

UMA

VGATE_PWRGD 16,35

PWROK 16,19
PLT_RST1# 16,26,30

R69

R69

UMA

UMA

UMA

UMA

UMA

UMA

UMA

UMA

GMCH_BLUE14
GMCH_GREEN14
GMCH_RED14

GMCH_BL_ON
GMCH_LCDVDD_ON

LIBG

GMCH_RGB#

CRT_IREF

C

GMCH_TXACLK-13
GMCH_TXACLK+13
GMCH_TXBCLK-13
GMCH_TXBCLK+13

GMCH_TXAOUT0-13
GMCH_TXAOUT1-13
GMCH_TXAOUT2-13

GMCH_TXAOUT0+13
GMCH_TXAOUT1+13
GMCH_TXAOUT2+13

GMCH_TXBOUT0-13
GMCH_TXBOUT1-13
GMCH_TXBOUT2-13

GMCH_TXBOUT0+13
GMCH_TXBOUT1+13
GMCH_TXBOUT2+13

TV_DACA14
TV_DACB14
TV_DACC14

1 2
1 2
1 2
1 2

MXM

MXM

R262

R262
0R2J-2-GP

0R2J-2-GP

L_BKLTCTL
LCTLA_CLK

LCTLB_DATA

LIBG
L_LVBG

GMCH_RGB#

12

CRT_IREF

RN20

RN20
SRN100KJ-6-GP

SRN100KJ-6-GP

2 3
1

UMA

UMA

R53

R53
1K5R2F-2-GP

1K5R2F-2-GP

1 2

UMA

UMA

R249

R249
0R2J-2-GP

0R2J-2-GP

1 2

UMA

UMA

R76

R76
255R2F-L-GP

255R2F-L-GP

1 2

UMA

UMA

TV_IREF
TV_IRTNA
TV_IRTNB
TV_IRTNC

for calistoga configuration

U38C

U38C

D32

L_BKLTCTL

J30

L_BKLTEN

H30

L_CLKCTLA

H29

L_CLKCTLB

G26

L_DDC_CLK

G25

L_DDC_DATA

B38

L_IBG

C35

L_VBG

F32

L_VDDEN

C33

L_VREFH

C32

L_VREFL

A33

LA_CLK#

A32

LA_CLK

E27

LB_CLK#

E26

LB_CLK

C37

LA_DATA#_0

B35

LA_DATA#_1

A37

LA_DATA#_2

B37

LA_DATA_0

B34

LA_DATA_1

A36

LA_DATA_2

G30

LB_DATA#_0

D30

LB_DATA#_1

F29

LB_DATA#_2

F30

LB_DATA_0

D29

LB_DATA_1

F28

LB_DATA_2

A16

TV_DACA_OUT

C18

TV_DACB_OUT

A19

TV_DACC_OUT

J20

TV_IREF

B16

TV_IRTNA

B18

TV_IRTNB

B19

TV_IRTNC

E23

CRT_BLUE

D23

CRT_BLUE#

C22

CRT_GREEN

B22

CRT_GREEN#

A21

CRT_RED

B21

CRT_RED#

C26

CRT_DDC_CLK

C25

CRT_DDC_DATA

G23

CRT_HSYNC

J22

CRT_IREF

H23

CRT_VSYNC

CALISTOGA

CALISTOGA

71.CALIS.00U

71.CALIS.00U

4

GMCH_GREEN
GMCH_BLUE

GMCH_RED

CRT_IREF

TV_DACA
TV_DACB

TV_IREF
TV_DACC

TV_IRTNA

TV_IRTNB

TV_IRTNC

LVDS

LVDS

TV

TV

VGA

VGA

RN18

RN18
SRN0J-6-GP

SRN0J-6-GP

2 3
1

MXM

MXM

R264

R264
0R2J-2-GP

0R2J-2-GP

1 2

MXM

MXM

R75

R75
0R2J-2-GP

0R2J-2-GP

1 2

MXM

MXM

RN16

RN16
SRN0J-6-GP

SRN0J-6-GP

1
2 3

MXM

MXM

RN17

RN17
SRN0J-6-GP

SRN0J-6-GP

1
2 3

MXM

MXM

R259

R259
0R2J-2-GP

0R2J-2-GP

1 2

MXM

MXM

R260

R260
0R2J-2-GP

0R2J-2-GP

1 2

MXM

MXM

R261

R261
0R2J-2-GP

0R2J-2-GP

1 2

MXM

MXM

D

1D05V_S0

R77

R77

PEG_CMP

1D05V_S0

1D5V_S0

D40
D38

F34
G38
H34
J38
L34
M38
N34
P38
R34
T38
V34
W38
Y34
AA38
AB34
AC38

D34
F38
G34
H38
J34
L38
M34
N38
P34
R38
T34
V38
W34
Y38
AA34
AB38

F36
G40
H36
J40
L36
M40
N36
P40
R36
T40
V36
W40
Y36
AA40
AB36
AC40

D36
F40
G36
H40
J36
L40
M36
N40
P36
R40
T36
V40
W36
Y40
AA36
AB40

GTXN0
GTXN1
GTXN2
GTXN3
GTXN4
GTXN5
GTXN6
GTXN7
GTXN8
GTXN9
GTXN10
GTXN11
GTXN12
GTXN13
GTXN14
GTXN15

GTXP0
GTXP1
GTXP2
GTXP3
GTXP4
GTXP5
GTXP6
GTXP7
GTXP8
GTXP9
GTXP10
GTXP11
GTXP12
GTXP13
GTXP14
GTXP15

PEG_RXN15
PEG_RXN14
PEG_RXN13
PEG_RXN12
PEG_RXN11
PEG_RXN10
PEG_RXN9
PEG_RXN8
PEG_RXN7
PEG_RXN6
PEG_RXN5
PEG_RXN4
PEG_RXN3
PEG_RXN2
PEG_RXN1
PEG_RXN0

PEG_RXP15
PEG_RXP14
PEG_RXP13
PEG_RXP12
PEG_RXP11
PEG_RXP10
PEG_RXP9
PEG_RXP8
PEG_RXP7
PEG_RXP6
PEG_RXP5
PEG_RXP4
PEG_RXP3
PEG_RXP2
PEG_RXP1
PEG_RXP0

EXP_A_COMPI

EXP_A_COMPO

EXP_A_RXN_0
EXP_A_RXN_1
EXP_A_RXN_2
EXP_A_RXN_3
EXP_A_RXN_4
EXP_A_RXN_5
EXP_A_RXN_6
EXP_A_RXN_7
EXP_A_RXN_8

EXP_A_RXN_9
EXP_A_RXN_10
EXP_A_RXN_11
EXP_A_RXN_12
EXP_A_RXN_13
EXP_A_RXN_14
EXP_A_RXN_15

EXP_A_RXP_0

EXP_A_RXP_1

EXP_A_RXP_2

EXP_A_RXP_3

EXP_A_RXP_4

EXP_A_RXP_5

EXP_A_RXP_6

EXP_A_RXP_7

EXP_A_RXP_8

EXP_A_RXP_9
EXP_A_RXP_10
EXP_A_RXP_11
EXP_A_RXP_12
EXP_A_RXP_13
EXP_A_RXP_14
EXP_A_RXP_15

EXP_A_TXN_0

EXP_A_TXN_1

EXP_A_TXN_2

EXP_A_TXN_3

EXP_A_TXN_4

EXP_A_TXN_5

EXP_A_TXN_6

EXP_A_TXN_7

EXP_A_TXN_8

EXP_A_TXN_9
EXP_A_TXN_10
EXP_A_TXN_11
EXP_A_TXN_12

PCI-EXPRESS GRAPHICS

PCI-EXPRESS GRAPHICS

EXP_A_TXN_13
EXP_A_TXN_14
EXP_A_TXN_15

EXP_A_TXP_0
EXP_A_TXP_1
EXP_A_TXP_2
EXP_A_TXP_3
EXP_A_TXP_4
EXP_A_TXP_5
EXP_A_TXP_6
EXP_A_TXP_7
EXP_A_TXP_8

EXP_A_TXP_9
EXP_A_TXP_10
EXP_A_TXP_11
EXP_A_TXP_12
EXP_A_TXP_13
EXP_A_TXP_14
EXP_A_TXP_15

4

4

4

D

12

24D9R2F-L-GP

24D9R2F-L-GP

C45 SCD1U10V2KX-5GP

C45 SCD1U10V2KX-5GP

1 2

MXM

MXM

C57 SCD1U10V2KX-5GP

C57 SCD1U10V2KX-5GP

1 2

MXM

MXM

C43 SCD1U10V2KX-5GP

C43 SCD1U10V2KX-5GP

1 2

MXM

MXM

C58 SCD1U10V2KX-5GP

C58 SCD1U10V2KX-5GP

1 2

MXM

MXM

C60 SCD1U10V2KX-5GP

C60 SCD1U10V2KX-5GP

1 2

MXM

MXM

C67 SCD1U10V2KX-5GP

C67 SCD1U10V2KX-5GP

1 2

MXM

MXM

C83 SCD1U10V2KX-5GP

C83 SCD1U10V2KX-5GP

1 2

MXM

MXM

C90 SCD1U10V2KX-5GP

C90 SCD1U10V2KX-5GP

1 2

MXM

MXM

C94 SCD1U10V2KX-5GP

C94 SCD1U10V2KX-5GP

1 2

MXM

MXM

C102 SCD1U10V2KX-5GP

C102 SCD1U10V2KX-5GP

1 2

MXM

MXM

C113 SCD1U10V2KX-5GP

C113 SCD1U10V2KX-5GP

1 2

MXM

MXM

C120 SCD1U10V2KX-5GP

C120 SCD1U10V2KX-5GP

1 2

MXM

MXM

C130 SCD1U10V2KX-5GP

C130 SCD1U10V2KX-5GP

1 2

MXM

MXM

C136 SCD1U10V2KX-5GP

C136 SCD1U10V2KX-5GP

1 2

MXM

MXM

C145 SCD1U10V2KX-5GP

C145 SCD1U10V2KX-5GP

1 2

MXM

MXM

C150 SCD1U10V2KX-5GP

C150 SCD1U10V2KX-5GP

1 2

MXM

MXM

C39 SCD1U10V2KX-5GP

C39 SCD1U10V2KX-5GP

1 2

MXM

MXM

C50 SCD1U10V2KX-5GP

C50 SCD1U10V2KX-5GP

1 2

MXM

MXM

C37 SCD1U10V2KX-5GP

C37 SCD1U10V2KX-5GP

1 2

MXM

MXM

C51 SCD1U10V2KX-5GP

C51 SCD1U10V2KX-5GP

1 2

MXM

MXM

C52 SCD1U10V2KX-5GP

C52 SCD1U10V2KX-5GP

1 2

MXM

MXM

C65 SCD1U10V2KX-5GP

C65 SCD1U10V2KX-5GP

1 2

MXM

MXM

C76 SCD1U10V2KX-5GP

C76 SCD1U10V2KX-5GP

1 2

MXM

MXM

C87 SCD1U10V2KX-5GP

C87 SCD1U10V2KX-5GP

1 2

MXM

MXM

C89 SCD1U10V2KX-5GP

C89 SCD1U10V2KX-5GP

1 2

MXM

MXM

C98 SCD1U10V2KX-5GP

C98 SCD1U10V2KX-5GP

1 2

MXM

MXM

C110 SCD1U10V2KX-5GP

C110 SCD1U10V2KX-5GP

1 2

MXM

MXM

C114 SCD1U10V2KX-5GP

C114 SCD1U10V2KX-5GP

1 2

MXM

MXM

C121 SCD1U10V2KX-5GP

C121 SCD1U10V2KX-5GP

1 2

MXM

MXM

C131 SCD1U10V2KX-5GP

C131 SCD1U10V2KX-5GP

1 2

MXM

MXM

C138 SCD1U10V2KX-5GP

C138 SCD1U10V2KX-5GP

1 2

MXM

MXM

C144 SCD1U10V2KX-5GP

C144 SCD1U10V2KX-5GP

1 2

MXM

MXM

RN12

RN12

SRN10KJ-5-GP

LCTLA_CLK
LCTLB_DATA

GMCH_HSYNC
GMCH_VSYNC

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

SRN10KJ-5-GP

1
2 3

UMA

UMA

RN19

RN19

SRN0J-6-GP

SRN0J-6-GP

1

MXM

MXM

2 3

E

PEG_RXN[15..0] 26

PEG_RXP[15..0] 26

PEG_TXN0
PEG_TXN1
PEG_TXN2
PEG_TXN3
PEG_TXN4
PEG_TXN5
PEG_TXN6
PEG_TXN7
PEG_TXN8
PEG_TXN9
PEG_TXN10
PEG_TXN11
PEG_TXN12
PEG_TXN13
PEG_TXN14
PEG_TXN15

PEG_TXP0
PEG_TXP1
PEG_TXP2
PEG_TXP3
PEG_TXP4
PEG_TXP5
PEG_TXP6
PEG_TXP7
PEG_TXP8
PEG_TXP9
PEG_TXP10
PEG_TXP11
PEG_TXP12
PEG_TXP13
PEG_TXP14
PEG_TXP15

4

3D3V_S0

4

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

GMCH (2 of 5)

GMCH (2 of 5)

GMCH (2 of 5)

Volvi

Volvi

Volvi

E

742Wednesday, April 18, 2007

742Wednesday, April 18, 2007

742Wednesday, April 18, 2007

PEG_TXN[15..0] 26

PEG_TXP[15..0] 26

of

of

of

-1

-1

-1

A

4 4

U38D

M_A_DQ[63..0]11

3 3

2 2

1 1

M_A_DQ0
M_A_DQ1
M_A_DQ2
M_A_DQ3
M_A_DQ4
M_A_DQ5
M_A_DQ6
M_A_DQ7
M_A_DQ8
M_A_DQ9
M_A_DQ10
M_A_DQ11
M_A_DQ12
M_A_DQ13
M_A_DQ14
M_A_DQ15
M_A_DQ16
M_A_DQ17
M_A_DQ18
M_A_DQ19
M_A_DQ20
M_A_DQ21
M_A_DQ22
M_A_DQ23
M_A_DQ24
M_A_DQ25
M_A_DQ26
M_A_DQ27
M_A_DQ28
M_A_DQ29
M_A_DQ30
M_A_DQ31
M_A_DQ32
M_A_DQ33
M_A_DQ34
M_A_DQ35
M_A_DQ36
M_A_DQ37
M_A_DQ38
M_A_DQ39
M_A_DQ40
M_A_DQ41
M_A_DQ42
M_A_DQ43
M_A_DQ44
M_A_DQ45
M_A_DQ46
M_A_DQ47
M_A_DQ48
M_A_DQ49
M_A_DQ50
M_A_DQ51
M_A_DQ52
M_A_DQ53
M_A_DQ54
M_A_DQ55
M_A_DQ56
M_A_DQ57
M_A_DQ58
M_A_DQ59
M_A_DQ60
M_A_DQ61
M_A_DQ62
M_A_DQ63

A

AJ35

AJ34
AM31
AM33

AJ36
AK35

AJ32
AH31
AN35
AP33
AR31
AP31
AN38
AM36
AM34
AN33
AK26

AL27
AM26
AN24
AK28

AL28
AM24
AP26
AP23

AL22
AP21
AN20

AL23
AP24
AP20
AT21
AR12
AR14
AP13
AP12
AT13
AT12

AL14

AL12

AK9
AN7
AK8
AK7
AP9
AN9
AT5
AL5
AY2

AW2

AP1
AN2
AV2
AT3
AN1
AL2
AG7
AF9
AG4
AF6
AG9
AH6
AF4
AF8

U38D

SA_DQ0
SA_DQ1
SA_DQ2
SA_DQ3
SA_DQ4
SA_DQ5
SA_DQ6
SA_DQ7
SA_DQ8
SA_DQ9
SA_DQ10
SA_DQ11
SA_DQ12
SA_DQ13
SA_DQ14
SA_DQ15
SA_DQ16
SA_DQ17
SA_DQ18
SA_DQ19
SA_DQ20
SA_DQ21
SA_DQ22
SA_DQ23
SA_DQ24
SA_DQ25
SA_DQ26
SA_DQ27
SA_DQ28
SA_DQ29
SA_DQ30
SA_DQ31
SA_DQ32
SA_DQ33
SA_DQ34
SA_DQ35
SA_DQ36
SA_DQ37
SA_DQ38
SA_DQ39
SA_DQ40
SA_DQ41
SA_DQ42
SA_DQ43
SA_DQ44
SA_DQ45
SA_DQ46
SA_DQ47
SA_DQ48
SA_DQ49
SA_DQ50
SA_DQ51
SA_DQ52
SA_DQ53
SA_DQ54
SA_DQ55
SA_DQ56
SA_DQ57
SA_DQ58
SA_DQ59
SA_DQ60
SA_DQ61
SA_DQ62
SA_DQ63

CALISTOGA

CALISTOGA

71.CALIS.00U

71.CALIS.00U

DDR SYSTEM MEMORY A

DDR SYSTEM MEMORY A

B

SA_BS_0
SA_BS_1
SA_BS_2

SA_CAS#
SA_DM_0
SA_DM_1
SA_DM_2
SA_DM_3
SA_DM_4
SA_DM_5
SA_DM_6
SA_DM_7

SA_DQS_0
SA_DQS_1
SA_DQS_2
SA_DQS_3
SA_DQS_4
SA_DQS_5
SA_DQS_6

SA_DQS_7
SA_DQS#_0
SA_DQS#_1
SA_DQS#_2
SA_DQS#_3
SA_DQS#_4
SA_DQS#_5
SA_DQS#_6
SA_DQS#_7

SA_MA_0
SA_MA_1
SA_MA_2
SA_MA_3
SA_MA_4
SA_MA_5
SA_MA_6
SA_MA_7
SA_MA_8

SA_MA_9
SA_MA_10
SA_MA_11
SA_MA_12
SA_MA_13

SA_RAS#

SA_RCVENIN#

SA_RCVENOUT#

SA_WE#

B

AU12
AV14
BA20

AY13
AJ33
AM35
AL26
AN22
AM14
AL9
AR3
AH4

AK33
AT33
AN28
AM22
AN12
AN8
AP3
AG5
AK32
AU33
AN27
AM21
AM12
AL8
AN3
AH5

AY16
AU14
AW16
BA16
BA17
AU16
AV17
AU17
AW17
AT16
AU13
AT17
AV20
AV12

AW14
AK23
AK24
AY14

M_A_DM0
M_A_DM1
M_A_DM2
M_A_DM3
M_A_DM4
M_A_DM5
M_A_DM6
M_A_DM7

M_A_DQS0
M_A_DQS1
M_A_DQS2
M_A_DQS3
M_A_DQS4

M_A_DQS6

M_A_DQS7
M_A_DQS#0
M_A_DQS#1
M_A_DQS#2
M_A_DQS#3
M_A_DQS#4
M_A_DQS#5
M_A_DQS#6
M_A_DQS#7

M_A_A0
M_A_A1
M_A_A2
M_A_A3
M_A_A4
M_A_A5
M_A_A6
M_A_A7
M_A_A8

M_A_A9
M_A_A10
M_A_A11
M_A_A12
M_A_A13

SA_RCVENIN#
SA_RCVENOUT#

M_A_BS#0 11,12
M_A_BS#1 11,12
M_A_BS#2 11,12
M_A_CAS# 11,12
M_A_DM[7..0] 11

M_A_DQS[7..0] 11

M_A_DQS#[7..0] 11

M_A_A[13..0] 11,12

M_A_RAS# 11,12

M_A_WE# 11,12

Place Test PAD Near to Chip
as could as possible

M_B_DQ[63..0]11

TP15 TPAD30TP15 TPAD30
TP14 TPAD30TP14 TPAD30

C

U38E

M_B_DQ0
M_B_DQ1
M_B_DQ2
M_B_DQ3
M_B_DQ4
M_B_DQ5
M_B_DQ6
M_B_DQ7
M_B_DQ8
M_B_DQ9
M_B_DQ10
M_B_DQ11
M_B_DQ12
M_B_DQ13
M_B_DQ14
M_B_DQ15
M_B_DQ16
M_B_DQ17
M_B_DQ18
M_B_DQ19
M_B_DQ20
M_B_DQ21
M_B_DQ22
M_B_DQ23
M_B_DQ24
M_B_DQ25
M_B_DQ26
M_B_DQ27
M_B_DQ28
M_B_DQ29
M_B_DQ30
M_B_DQ31
M_B_DQ32
M_B_DQ33
M_B_DQ34
M_B_DQ35
M_B_DQ36
M_B_DQ37
M_B_DQ38
M_B_DQ39
M_B_DQ40
M_B_DQ41
M_B_DQ42
M_B_DQ43
M_B_DQ44
M_B_DQ45
M_B_DQ46
M_B_DQ47
M_B_DQ48
M_B_DQ49
M_B_DQ50
M_B_DQ51
M_B_DQ52
M_B_DQ53
M_B_DQ54
M_B_DQ55
M_B_DQ56
M_B_DQ57
M_B_DQ58
M_B_DQ59
M_B_DQ60
M_B_DQ61
M_B_DQ62
M_B_DQ63

C

AK39

AJ37
AP39
AR41

AJ38
AK38
AN41
AP41
AT40
AV41
AU38
AV38
AP38
AR40

AW38

AY38
BA38
AV36
AR36
AP36
BA36
AU36
AP35
AP34
AY33
BA33
AT31
AU29
AU31

AW31

AV29

AW29
AM19

AL19
AP14
AN14
AN17

AM16

AP15

AL15

AJ11
AH10

AN10
AK13
AH11
AK10

BA10

AW10

BA4

AW4
AY10

AY9

AW5

AY5
AV4
AR5
AK4
AK3
AT4
AK5

AJ9

AJ8

AJ5
AJ3

U38E

SB_DQ0
SB_DQ1
SB_DQ2
SB_DQ3
SB_DQ4
SB_DQ5
SB_DQ6
SB_DQ7
SB_DQ8
SB_DQ9
SB_DQ10
SB_DQ11
SB_DQ12
SB_DQ13
SB_DQ14
SB_DQ15
SB_DQ16
SB_DQ17
SB_DQ18
SB_DQ19
SB_DQ20
SB_DQ21
SB_DQ22
SB_DQ23
SB_DQ24
SB_DQ25
SB_DQ26
SB_DQ27
SB_DQ28
SB_DQ29
SB_DQ30
SB_DQ31
SB_DQ32
SB_DQ33
SB_DQ34
SB_DQ35
SB_DQ36
SB_DQ37
SB_DQ38
SB_DQ39
SB_DQ40
SB_DQ41
SB_DQ42
SB_DQ43
SB_DQ44
SB_DQ45
SB_DQ46
SB_DQ47
SB_DQ48
SB_DQ49
SB_DQ50
SB_DQ51
SB_DQ52
SB_DQ53
SB_DQ54
SB_DQ55
SB_DQ56
SB_DQ57
SB_DQ58
SB_DQ59
SB_DQ60
SB_DQ61
SB_DQ62
SB_DQ63

CALISTOGA

CALISTOGA

71.CALIS.00U

71.CALIS.00U

D

AT24

SB_BS_0

AV23

SB_BS_1

AY28

SB_BS_2

AR24

SB_CAS#
SB_DM_0
SB_DM_1
SB_DM_2
SB_DM_3
SB_DM_4
SB_DM_5
SB_DM_6
SB_DM_7

SB_DQS_0
SB_DQS_1
SB_DQS_2
SB_DQS_3
SB_DQS_4
SB_DQS_5
SB_DQS_6

SB_DQS_7
SB_DQS#_0
SB_DQS#_1
SB_DQS#_2
SB_DQS#_3
SB_DQS#_4
SB_DQS#_5
SB_DQS#_6
SB_DQS#_7

SB_MA_0
SB_MA_1
SB_MA_2
SB_MA_3
SB_MA_4
SB_MA_5
SB_MA_6
SB_MA_7
SB_MA_8

SB_MA_9
SB_MA_10
SB_MA_11
SB_MA_12
SB_MA_13

SB_RAS#

SB_RCVENIN#

SB_RCVENOUT#

DDR SYSTEM MEMORY B

DDR SYSTEM MEMORY B

SB_WE#

D

M_B_DM0

AK36

M_B_DM1

AR38

M_B_DM2

AT36

M_B_DM3

BA31

M_B_DM4

AL17

M_B_DM5

AH8

M_B_DM6

BA5

M_B_DM7

AN4

M_B_DQS0

AM39

M_B_DQS1

AT39

M_B_DQS2

AU35

M_B_DQS3

AR29

M_B_DQS4

AR16

M_B_DQS5

AR10

M_B_DQS6

AR7

M_B_DQS7M_A_DQS5

AN5

M_B_DQS#0

AM40

M_B_DQS#1

AU39

M_B_DQS#2

AT35

M_B_DQS#3

AP29

M_B_DQS#4

AP16

M_B_DQS#5

AT10

M_B_DQS#6

AT7

M_B_DQS#7

AP5

M_B_A0

AY23

M_B_A1

AW24

M_B_A2

AY24

M_B_A3

AR28

M_B_A4

AT27

M_B_A5

AT28

M_B_A6

AU27

M_B_A7

AV28

M_B_A8

AV27

M_B_A9

AW27

M_B_A10

AV24

M_B_A11

BA27

M_B_A12

AY27

M_B_A13

AR23
AU23

SB_RCVENIN#

AK16

SB_RCVENOUT#

AK18
AR27

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

M_B_BS#0 11,12
M_B_BS#1 11,12
M_B_BS#2 11,12
M_B_CAS# 11,12
M_B_DM[7..0] 11

M_B_DQS[7..0] 11

M_B_DQS#[7..0] 11

M_B_A[13..0] 11,12

M_B_RAS# 11,12

M_B_WE# 11,12

GMCH (3 of 5)

GMCH (3 of 5)

GMCH (3 of 5)

Volvi

Volvi

Volvi

E

TP16 TPAD30TP16 TPAD30
TP17 TPAD30TP17 TPAD30

Place Test PAD Near to Chip
ascould as possible

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

E

-1

-1

of

842Wednesday, April 18, 2007

of

842Wednesday, April 18, 2007

of

842Wednesday, April 18, 2007

-1

A

2D5V_S0

4 4

1D5V_S0

R50

R50
0R3-0-U-GP

0R3-0-U-GP

1 2

UMA

UMA

12

UMA

UMA

R55

R55
0R3-0-U-GP

0R3-0-U-GP

1 2

UMA

UMA

12

C29

C29

UMA

R285

R285

1 2

R289

R289

1 2

UMA

12

C376

C376

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

12

C397

C397

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

3 3

0R0603-PAD

0R0603-PAD

0R0603-PAD

0R0603-PAD

R273

R273
0R0603-PAD

0R0603-PAD

C33

C33

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

2D5V_3GBG_S0

12

12

C365

C365

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

12

C44

C44

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

UMA

UMA

12

C32

C32

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

UMA

UMA

12

C148

C148

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

12

C147

C147

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

1D5V_DPLLA

1D5V_DPLLB

1D5V_HPLL_S0

1D5V_MPLL_S0

-1 0411

D25

D25

DY

DY

BAT54-4-GP

1D5V_S0

1D5V_S0

BAT54-4-GP

1

2

D3

D3
BAT54-4-GP

BAT54-4-GP

1

2

3

2D5V_S0

DY

DY

3D3V_S0

1D5V_2D5V_S0

12

DY

DY

L4

L4
HCB1608KF121T30-GP

HCB1608KF121T30-GP

68.00230.041

68.00230.041

1D5V_3D3V_S0

3

12

DY

DY

A

R239

R239
10R2J-2-GP

10R2J-2-GP

1 2

L17

L17
HCB1608KF121T30-GP

HCB1608KF121T30-GP

68.00230.041

68.00230.041

UMA

UMA

R42

R42
10R2J-2-GP

10R2J-2-GP

1 2

UMA

UMA

2D5V_CRTDAC

3D3V_TVDAC

12

C353

C353

UMA

UMA

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

12

UMA

UMA

R41

R41
0R5J-6-GP

0R5J-6-GP

R242

R242
0R3-0-U-GP

0R3-0-U-GP

12

UMA

UMA

R247

R247
0R3-0-U-GP

0R3-0-U-GP

12

UMA

UMA

R246

R246
0R3-0-U-GP

0R3-0-U-GP

12

UMA

UMA

R245 0R3-0-U-GP

R245 0R3-0-U-GP

12

UMA

UMA

VCCA_CRTDAC

V_DACA

V_DACB

V_DACC

V_TVBG

2 2

1 1

Divide by Trace (Layout Rule approve)

1D5V_S0

12

C63

C63

UMA

UMA

UMA

UMA

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

B

2D5V_VCC

12

C31

C31

1D5V_S0

R89

R89
0R0603-PAD

0R0603-PAD

2D5V_S0

R240

R240
0R3-0-U-GP

0R3-0-U-GP

1 2

MXM

MXM

12

C46

C46
SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

12

C61

C61
SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

B

SC4D7U6D3V3KX-GP

SC4D7U6D3V3KX-GP

1D5V_3GPLL_S0

12

R271

R271
0R3-0-U-GP

0R3-0-U-GP

1 2

UMA

UMA

1D05V_S0

UMA

UMA

UMA

UMA

12

C47

C47

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

R310 0R0805-PADR310 0R0805-PAD

1 2

12

C141

C141

SC4D7U6D3V3KX-GP

SC4D7U6D3V3KX-GP

1D5V_S0

12

C64

C64
SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

12

C38

C38
SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

1D5V_PCIE_S0

12

C373

C373

12

C123

C123

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

2D5V_S0_LVDS

R269

R269
0R2J-2-GP

0R2J-2-GP

12

MXM

MXM

1D5V_S0

R85

R85
0R2J-2-GP

0R2J-2-GP

1 2

MXM

MXM

12

C378

C378

SC4D7U6D3V3KX-GP

SC4D7U6D3V3KX-GP

SC4D7U6D3V3KX-GP

SC4D7U6D3V3KX-GP

12

C361

C361
SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

UMA

UMA

R252 0R2J-2-GP

R252 0R2J-2-GP

1 2

R251 0R2J-2-GP

R251 0R2J-2-GP

1 2

R250 0R2J-2-GP

R250 0R2J-2-GP

1 2

R253 0R2J-2-GP

R253 0R2J-2-GP

1 2

R257

R257
0R3-0-U-GP

0R3-0-U-GP

MXM

MXM

1D5V_S0

R258

R258
0R0603-PAD

0R0603-PAD

3D3V_S0

R46

R46
0R0603-PAD

0R0603-PAD

R78

R78
0R0603-PAD

0R0603-PAD

1D5V_S0

12

2D5V_S0

12

R66

R66
0R3-0-U-GP

0R3-0-U-GP

UMA

UMA

12

C103

C103
SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

UMA

UMA

12

C367

C367

SC4D7U6D3V3KX-GP

SC4D7U6D3V3KX-GP

MXM

MXM

MXM

MXM
MXM

MXM
MXM

MXM

1D5V_S0

12

12

12

12

C139

C139

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

C

1 2

MXM

MXM

R51

R51
0R2J-2-GP

0R2J-2-GP

12

C414

C414

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

VCCA_CRTDAC

R52

R52

UMA

UMA

0R2J-2-GP

0R2J-2-GP

12

UMA

UMA

1D5V_TVDAC_S0

1D5V_TVDAC_S0

12

C35

C35
SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

3D3V_S0_VCC_HV

12

C30

C30

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

1D5V_QTVDAC_S0

12

C86

C86

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

12

12

C134

C134

C158

C158

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

C

2D5V_S0

UMA

UMA

VCCSYNC

2D5V_VCC

2D5V_3GBG_S0

1D5V_DPLLA
1D5V_DPLLB
1D5V_HPLL_S0

VSSA_LVDS

12

1D5V_MPLL_S0

V_TVBG

V_DACA
V_DACB

V_DACC

VCCD_LVDS

R265

R265
0R3-0-U-GP

0R3-0-U-GP

12

C34

C34

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

12

C149

C149

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

12

R243

R243
0R3-0-U-GP

0R3-0-U-GP

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

AJ41

AB41

AC33

AK31

AF31
AE31
AC31

AL30
AK30

AJ30
AH30
AG30

AF30
AE30
AD30
AC30
AG29

AF29
AE29
AD29
AC29
AG28

AF28
AE28
AH22

AJ21
AH21

AJ20
AH20
AH19

AH15
AH14

AG14

AF14
AE14

AF13
AE13

AF12
AE12
AD12

H22
C30

B30
A30

Y41
V41
R41
N41

G41
H41

F21
E21
G21

B26
C39
AF1

A38
B39

AF2
H20

G20

E19
F19
C20
D20
E20
F20

AH1
AH2

A28
B28
C28

D21
A23

B23
B25

H19

P19
P16

P15

Y14

L41

U38H

U38H

VCCSYNC
VCC_TXLVDS0

VCC_TXLVDS1
VCC_TXLVDS2

VCC3G0
VCC3G1
VCC3G2
VCC3G3
VCC3G4
VCC3G5
VCC3G6
VCCA_3GPLL
VCCA_3GBG
VSSA_3GBG

VCCA_CRTDAC0
VCCA_CRTDAC1
VSSA_CRTDAC

VCCA_DPLLA
VCCA_DPLLB
VCCA_HPLL

VCCA_LVDS
VSSA_LVDS

VCCA_MPLL
VCCA_TVBG

VSSA_TVBG

VCCA_TVDACA0
VCCA_TVDACA1
VCCA_TVDACB0
VCCA_TVDACB1
VCCA_TVDACC0
VCCA_TVDACC1

VCCD_HMPLL0
VCCD_HMPLL1

VCCD_LVDS0
VCCD_LVDS1
VCCD_LVDS2

VCCD_TVDAC
VCC_HV0

VCC_HV1
VCC_HV2

VCCD_QTVDAC
VCCAUX0

VCCAUX1
VCCAUX2
VCCAUX3
VCCAUX4
VCCAUX5
VCCAUX6
VCCAUX7
VCCAUX8
VCCAUX9
VCCAUX10
VCCAUX11
VCCAUX12
VCCAUX13
VCCAUX14
VCCAUX15
VCCAUX16
VCCAUX17
VCCAUX18
VCCAUX19
VCCAUX20
VCCAUX21
VCCAUX22
VCCAUX23
VCCAUX24
VCCAUX25
VCCAUX26
VCCAUX27
VCCAUX28
VCCAUX29
VCCAUX30
VCCAUX31
VCCAUX32
VCCAUX33
VCCAUX34
VCCAUX35
VCCAUX36
VCCAUX37
VCCAUX38
VCCAUX39
VCCAUX40

CALISTOGA

CALISTOGA

71.CALIS.00U

71.CALIS.00U

POWER

POWER

D

1D05V_S0

AC14

VTT_0

AB14

VTT_1

W14

VTT_2

V14

VTT_3

T14

VTT_4

R14

VTT_5

P14

VTT_6

N14

VTT_7

M14

VTT_8

L14

VTT_9

AD13

VTT_10

AC13

VTT_11

AB13

VTT_12

AA13

VTT_13

Y13

VTT_14

W13

VTT_15

V13

VTT_16

U13

VTT_17

T13

VTT_18

R13

VTT_19

N13

VTT_20

M13

VTT_21

L13

VTT_22

AB12

VTT_23

AA12

VTT_24

Y12

VTT_25

W12

VTT_26

V12

VTT_27

U12

VTT_28

T12

VTT_29

R12

VTT_30

P12

VTT_31

N12

VTT_32

M12

VTT_33

L12

VTT_34

R11

VTT_35

P11

VTT_36

N11

VTT_37

M11

VTT_38

R10

VTT_39

P10

VTT_40

N10

VTT_41

M10

VTT_42

P9

VTT_43

N9

VTT_44

M9

VTT_45

R8

VTT_46

P8

VTT_47

N8

VTT_48

M8

VTT_49

P7

VTT_50

N7

VTT_51

M7

VTT_52

R6

VTT_53

P6

VTT_54

M6

VTT_55

A6

VTT_56

R5

VTT_57

P5

VTT_58

N5

VTT_59

M5

VTT_60

P4

VTT_61

N4

VTT_62

M4

VTT_63

R3

VTT_64

P3

VTT_65

N3

VTT_66

M3

VTT_67

R2

VTT_68

P2

VTT_69

M2

VTT_70

D2

VTT_71

AB1

VTT_72

R1

VTT_73

P1

VTT_74

N1

VTT_75

M1

VTT_76

D

12

12

C92

C92

C137

C137

C101

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

VCCP_GMCH_CAP3

VCCP_GMCH_CAP2
VCCP_GMCH_CAP1

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

C101

SC2D2U6D3V3MX-1-GP

SC2D2U6D3V3MX-1-GP

SC4D7U10V5ZY-3GP

SC4D7U10V5ZY-3GP

12

C356

C356

SCD47U10V3ZY-GP

SCD47U10V3ZY-GP

12

C375

C375

SCD47U10V3ZY-GP

SCD47U10V3ZY-GP

GMCH (4 of 5)

GMCH (4 of 5)

GMCH (4 of 5)

Volvi

Volvi

Volvi

E

12

C40

C40

SCD22U16V3ZY-GP

SCD22U16V3ZY-GP

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

of

942Wednesday, April 18, 2007

of

942Wednesday, April 18, 2007

of

942Wednesday, April 18, 2007

E

-1

-1

-1

U38G

AA33

W33
N33

AA32

W32

N32
M32

AA31

W31

R31
N31

M31

AA30

W30
U30
R30
N30

M30

AA29

W29
U29

R29
M29

AB28
AA28

U28
R28
N28

M28

N27
M27

N26
N25

M25

N24

M24
AB23
AA23

N23

M23
AC22

AB22

W22

N22

M22
AC21

AA21

W21

N21

M21
AC20

AB20

W20

N20

M20
AB19

AA19

N19

M19

N18

M18

N17

M17

N16

M16

P33
L33

J33
Y32
V32

P32

L32
J32

V31
T31

P31

Y30
V30
T30
P30

L30
Y29
V29

P29
L29

Y28
V28

T28
P28

L28
P27

L27
P26

L26

L25
P24

Y23
P23

L23

Y22
P22

L22

L21

Y20
P20

L20

Y19

L19

L18
P17

L16

U38G

VCC_0
VCC_1
VCC_2
VCC_3
VCC_4
VCC_5
VCC_6
VCC_7
VCC_8
VCC_9
VCC_10
VCC_11
VCC_12
VCC_13
VCC_14
VCC_15
VCC_16
VCC_17
VCC_18
VCC_19
VCC_20
VCC_21
VCC_22
VCC_23
VCC_24
VCC_25
VCC_26
VCC_27
VCC_28
VCC_29
VCC_30
VCC_31
VCC_32
VCC_33
VCC_34
VCC_35
VCC_36
VCC_37
VCC_38
VCC_39
VCC_40
VCC_41
VCC_42
VCC_43
VCC_44
VCC_45
VCC_46
VCC_47
VCC_48
VCC_49
VCC_50
VCC_51
VCC_52
VCC_53
VCC_54
VCC_55
VCC_56
VCC_57
VCC_58
VCC_59
VCC_60
VCC_61
VCC_62
VCC_63
VCC_64
VCC_65
VCC_66
VCC_67
VCC_68
VCC_69
VCC_70
VCC_71
VCC_72
VCC_73
VCC_74
VCC_75
VCC_76
VCC_77
VCC_78
VCC_79
VCC_80
VCC_81
VCC_82
VCC_83
VCC_84
VCC_85
VCC_86
VCC_87
VCC_88
VCC_89
VCC_90
VCC_91
VCC_92
VCC_93
VCC_94
VCC_95
VCC_96
VCC_97
VCC_98
VCC_99
VCC_100
VCC_101
VCC_102
VCC_103
VCC_104
VCC_105
VCC_106
VCC_107
VCC_108
VCC_109
VCC_110

CALISTOGA

CALISTOGA

71.CALIS.00U

71.CALIS.00U

1D05V_S0

4 4

3 3

2 2

1 1

A

VCC

VCC

A

VCC_SM_0
VCC_SM_1
VCC_SM_2
VCC_SM_3
VCC_SM_4
VCC_SM_5
VCC_SM_6
VCC_SM_7
VCC_SM_8

VCC_SM_9
VCC_SM_10
VCC_SM_11
VCC_SM_12
VCC_SM_13
VCC_SM_14
VCC_SM_15
VCC_SM_16
VCC_SM_17
VCC_SM_18
VCC_SM_19
VCC_SM_20
VCC_SM_21
VCC_SM_22
VCC_SM_23
VCC_SM_24
VCC_SM_25
VCC_SM_26
VCC_SM_27
VCC_SM_28
VCC_SM_29
VCC_SM_30
VCC_SM_31
VCC_SM_32
VCC_SM_33
VCC_SM_34
VCC_SM_35
VCC_SM_36
VCC_SM_37
VCC_SM_38
VCC_SM_39
VCC_SM_40
VCC_SM_41
VCC_SM_42
VCC_SM_43
VCC_SM_44
VCC_SM_45
VCC_SM_46
VCC_SM_47
VCC_SM_48
VCC_SM_49
VCC_SM_50
VCC_SM_51
VCC_SM_52
VCC_SM_53
VCC_SM_54
VCC_SM_55
VCC_SM_56
VCC_SM_57
VCC_SM_58
VCC_SM_59
VCC_SM_60
VCC_SM_61
VCC_SM_62
VCC_SM_63
VCC_SM_64
VCC_SM_65
VCC_SM_66
VCC_SM_67
VCC_SM_68
VCC_SM_69
VCC_SM_70
VCC_SM_71
VCC_SM_72
VCC_SM_73
VCC_SM_74
VCC_SM_75
VCC_SM_76
VCC_SM_77
VCC_SM_78
VCC_SM_79
VCC_SM_80
VCC_SM_81
VCC_SM_82
VCC_SM_83
VCC_SM_84
VCC_SM_85
VCC_SM_86
VCC_SM_87
VCC_SM_88
VCC_SM_89
VCC_SM_90
VCC_SM_91
VCC_SM_92
VCC_SM_93
VCC_SM_94
VCC_SM_95
VCC_SM_96
VCC_SM_97
VCC_SM_98
VCC_SM_99

VCC_SM_100
VCC_SM_101
VCC_SM_102
VCC_SM_103
VCC_SM_104
VCC_SM_105
VCC_SM_106
VCC_SM_107

AU41
AT41
AM41
AU40
BA34
AY34
AW34
AV34
AU34
AT34
AR34
BA30
AY30
AW30
AV30
AU30
AT30
AR30
AP30
AN30
AM30
AM29
AL29
AK29
AJ29
AH29
AJ28
AH28
AJ27
AH27
BA26
AY26
AW26
AV26
AU26
AT26
AR26
AJ26
AH26
AJ25
AH25
AJ24
AH24
BA23
AJ23
BA22
AY22
AW22
AV22
AU22
AT22
AR22
AP22
AK22
AJ22
AK21
AK20
BA19
AY19
AW19
AV19
AU19
AT19
AR19
AP19
AK19
AJ19
AJ18
AJ17
AH17
AJ16
AH16
BA15
AY15
AW15
AV15
AU15
AT15
AR15
AJ15
AJ14
AJ13
AH13
AK12
AJ12
AH12
AG12
AK11
BA8
AY8
AW8
AV8
AT8
AR8
AP8
BA6
AY6
AW6
AV6
AT6
AR6
AP6
AN6
AL6
AK6
AJ6
AV1
AJ1

1D05V_S0

12

C68

C68

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

1D8V_S3

12

TC11

TC11

-1 0409

ST220U2D5VBM-2GP

ST220U2D5VBM-2GP

B

U38F

U38F
CALISTOGA

CALISTOGA

71.CALIS.00U

71.CALIS.00U

AD27

VCC_NCTF0

AC27

VCC_NCTF1

AB27

VCC_NCTF2

AA27

VCC_NCTF3

Y27

VCC_NCTF4

W27

VCC_NCTF5

V27

VCC_NCTF6

U27

VCC_NCTF7

T27

VCC_NCTF8

R27

VCC_NCTF9

AD26

VCC_NCTF10

AC26

VCC_NCTF11

AB26

VCC_NCTF12

AA26

VCC_NCTF13

Y26

VCC_NCTF14

W26

VCC_NCTF15

V26

VCC_NCTF16

U26

VCC_NCTF17

T26

VCC_NCTF18

R26

VCC_NCTF19

AD25

VCC_NCTF20

AC25

VCC_NCTF21

AB25

VCC_NCTF22

AA25

VCC_NCTF23

Y25

VCC_NCTF24

W25

VCC_NCTF25

V25

VCC_NCTF26

U25

VCC_NCTF27

T25

VCC_NCTF28

R25

VCC_NCTF29

AD24

VCC_NCTF30

AC24

VCC_NCTF31

AB24

VCC_NCTF32

AA24

VCC_NCTF33

Y24

VCC_NCTF34

W24

VCC_NCTF35

V24

VCC_NCTF36

U24

VCC_NCTF37

T24

VCC_NCTF38

R24

VCC_NCTF39

AD23

VCC_NCTF40

V23

VCC_NCTF41

U23

VCC_NCTF42

T23

VCC_NCTF43

R23

VCC_NCTF44

AD22

VCC_NCTF45

V22

VCC_NCTF46

U22

VCC_NCTF47

T22

VCC_NCTF48

R22

VCC_NCTF49

AD21

VCC_NCTF50

AD20

AD19

AD18
AC18
AB18
AA18

W18

V21
U21

T21

R21
V20

U20

T20

R20
V19

U19

T19

Y18
V18

U18

T18

VCC_NCTF51
VCC_NCTF52
VCC_NCTF53
VCC_NCTF54
VCC_NCTF55
VCC_NCTF56
VCC_NCTF57
VCC_NCTF58
VCC_NCTF59
VCC_NCTF60
VCC_NCTF61
VCC_NCTF62
VCC_NCTF63
VCC_NCTF64
VCC_NCTF65
VCC_NCTF66
VCC_NCTF67
VCC_NCTF68
VCC_NCTF69
VCC_NCTF70
VCC_NCTF71
VCC_NCTF72

NCTF

NCTF

Place these Caps close VCC_0 ~ VCC_110

12

12

C117

C117

C122

C122

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

12

12

C156

C156

SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

DY

DY

12

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

C163

C163

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

B

C112

C112

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

12

C174

C174

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

12

C95

C95

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

12

C171

C171

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

12

C111

C111

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

12

C181

C181

VSS_NCTF0
VSS_NCTF1
VSS_NCTF2
VSS_NCTF3
VSS_NCTF4
VSS_NCTF5
VSS_NCTF6
VSS_NCTF7
VSS_NCTF8

VSS_NCTF9
VSS_NCTF10
VSS_NCTF11
VSS_NCTF12

VCCAUX_NCTF0
VCCAUX_NCTF1
VCCAUX_NCTF2
VCCAUX_NCTF3
VCCAUX_NCTF4
VCCAUX_NCTF5
VCCAUX_NCTF6
VCCAUX_NCTF7
VCCAUX_NCTF8

VCCAUX_NCTF9
VCCAUX_NCTF10
VCCAUX_NCTF11
VCCAUX_NCTF12
VCCAUX_NCTF13
VCCAUX_NCTF14
VCCAUX_NCTF15
VCCAUX_NCTF16
VCCAUX_NCTF17
VCCAUX_NCTF18
VCCAUX_NCTF19
VCCAUX_NCTF20
VCCAUX_NCTF21
VCCAUX_NCTF22
VCCAUX_NCTF23
VCCAUX_NCTF24
VCCAUX_NCTF25
VCCAUX_NCTF26
VCCAUX_NCTF27
VCCAUX_NCTF28
VCCAUX_NCTF29
VCCAUX_NCTF30
VCCAUX_NCTF31
VCCAUX_NCTF32
VCCAUX_NCTF33
VCCAUX_NCTF34
VCCAUX_NCTF35
VCCAUX_NCTF36
VCCAUX_NCTF37
VCCAUX_NCTF38
VCCAUX_NCTF39
VCCAUX_NCTF40
VCCAUX_NCTF41
VCCAUX_NCTF42
VCCAUX_NCTF43
VCCAUX_NCTF44
VCCAUX_NCTF45
VCCAUX_NCTF46
VCCAUX_NCTF47
VCCAUX_NCTF48
VCCAUX_NCTF49
VCCAUX_NCTF50
VCCAUX_NCTF51
VCCAUX_NCTF52
VCCAUX_NCTF53
VCCAUX_NCTF54
VCCAUX_NCTF55
VCCAUX_NCTF56
VCCAUX_NCTF57

12

C93

C93

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

12

C176

C176

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

C

U38I

U38I

AE27
AE26
AE25
AE24
AE23
AE22
AE21
AE20
AE19
AE18
AC17
Y17
U17

AG27

1D5V_S0

AF27
AG26
AF26
AG25
AF25
AG24
AF24
AG23
AF23
AG22
AF22
AG21
AF21
AG20
AF20
AG19
AF19
R19
AG18
AF18
R18
AG17
AF17
AE17
AD17
AB17
AA17
W17
V17
T17
R17
AG16
AF16
AE16
AD16
AC16
AB16
AA16
Y16
W16
V16
U16
T16
R16
AG15
AF15
AE15
AD15
AC15
AB15
AA15
Y15
W15
V15
U15
T15
R15

12

TC2

TC2

ST220U2D5VBM-2GP

ST220U2D5VBM-2GP

-1 0409

12

12

12

C172

C172

C166

C166

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

DY

DY

12

C175

C175

C159

C159

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

AC41

VSS_0

AA41

VSS_1

W41

VSS_2

T41

VSS_3

P41

VSS_4

M41

VSS_5

J41

VSS_6

F41

VSS_7

AV40

VSS_8

AP40

VSS_9

AN40

VSS_10

AK40

VSS_11

AJ40

VSS_12

AH40

VSS_13

AG40

VSS_14

AF40

VSS_15

AE40

VSS_16

B40

VSS_17

AY39

VSS_18

AW39

VSS_19

AV39

VSS_20

AR39

VSS_21

AN39

VSS_22

AJ39

VSS_23

AC39

VSS_24

AB39

VSS_25

AA39

VSS_26

Y39

VSS_27

W39

VSS_28

V39

VSS_29

T39

VSS_30

R39

VSS_31

P39

VSS_32

N39

VSS_33

M39

L39

J39
H39
G39
F39
D39

AT38

AM38

AH38
AG38
AF38
AE38

C38

AK37
AH37
AB37
AA37

Y37

W37

V37
T37
R37
P37
N37
M37

L37

J37
H37
G37
F37
D37

AY36

AW36

AN36
AH36
AG36
AF36
AE36
AC36

C36
B36

BA35
AV35
AR35
AH35
AB35
AA35

Y35

W35

V35
T35
R35
P35
N35
M35

L35

J35
H35
G35
F35
D35

AN34

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

CALISTOGA

CALISTOGA

71.CALIS.00U

71.CALIS.00U

C

VSS_34
VSS_35
VSS_36
VSS_37
VSS_38
VSS_39
VSS_40
VSS_41
VSS_42
VSS_43
VSS_44
VSS_45
VSS_46
VSS_47
VSS_48
VSS_49
VSS_50
VSS_51
VSS_52
VSS_53
VSS_54
VSS_55
VSS_56
VSS_57
VSS_58
VSS_59
VSS_60
VSS_61
VSS_62
VSS_63
VSS_64
VSS_65
VSS_66
VSS_67
VSS_68
VSS_69
VSS_70
VSS_71
VSS_72
VSS_73
VSS_74
VSS_75
VSS_76
VSS_77
VSS_78
VSS_79
VSS_80
VSS_81
VSS_82
VSS_83
VSS_84
VSS_85
VSS_86
VSS_87
VSS_88
VSS_89
VSS_90
VSS_91
VSS_92
VSS_93
VSS_94
VSS_95
VSS_96

VSS

VSS

VSS_97
VSS_98

VSS_99
VSS_100
VSS_101
VSS_102
VSS_103
VSS_104
VSS_105
VSS_106
VSS_107
VSS_108
VSS_109
VSS_110
VSS_111
VSS_112
VSS_113
VSS_114
VSS_115
VSS_116
VSS_117
VSS_118
VSS_119
VSS_120
VSS_121
VSS_122
VSS_123
VSS_124
VSS_125
VSS_126
VSS_127
VSS_128
VSS_129
VSS_130
VSS_131
VSS_132
VSS_133
VSS_134
VSS_135
VSS_136
VSS_137
VSS_138
VSS_139
VSS_140
VSS_141
VSS_142
VSS_143
VSS_144
VSS_145
VSS_146
VSS_147
VSS_148
VSS_149
VSS_150
VSS_151
VSS_152
VSS_153
VSS_154
VSS_155
VSS_156
VSS_157
VSS_158
VSS_159
VSS_160
VSS_161
VSS_162
VSS_163
VSS_164
VSS_165
VSS_166
VSS_167
VSS_168
VSS_169
VSS_170
VSS_171
VSS_172
VSS_173
VSS_174
VSS_175
VSS_176
VSS_177
VSS_178
VSS_179

AK34
AG34
AF34
AE34
AC34
C34
AW33
AV33
AR33
AE33
AB33
Y33
V33
T33
R33
M33
H33
G33
F33
D33
B33
AH32
AG32
AF32
AE32
AC32
AB32
G32
B32
AY31
AV31
AN31
AJ31
AG31
AB31
Y31
AB30
E30
AT29
AN29
AB29
T29
N29
K29
G29
E29
C29
B29
A29
BA28
AW28
AU28
AP28
AM28
AD28
AC28
W28
J28
E28
AP27
AM27
AK27
J27
G27
F27
C27
B27
AN26
M26
K26
F26
D26
AK25
P25
K25
H25
E25
D25
A25
BA24
AU24
AL24
AW23

D

U38J

U38J

AT23

VSS_180

AN23

VSS_181

AM23

VSS_182

AH23

VSS_183

AC23

VSS_184

W23

VSS_185

K23

VSS_186

J23

VSS_187

F23

VSS_188

C23

VSS_189

AA22

VSS_190

K22

VSS_191

G22

VSS_192

F22

VSS_193

E22

VSS_194

D22

VSS_195

A22

VSS_196

BA21

VSS_197

AV21

VSS_198

AR21

VSS_199

AN21

VSS_200

AL21

VSS_201

AB21

VSS_202

Y21

VSS_203

P21

VSS_204

K21

VSS_205

J21

VSS_206

H21

VSS_207

C21

VSS_208

AW20

VSS_209

AR20

VSS_210

AM20

AA20

K20
B20

A20
AN19
AC19

W19

K19

G19

C19
AH18

P18

H18

D18

A18
AY17
AR17
AP17

AM17

AK17
AV16
AN16
AL16

J16

F16

C16
AN15

AM15

AK15

N15

M15

L15

B15

A15
BA14
AT14
AK14
AD14
AA14

U14

K14

H14

E14
AV13
AR13
AN13

AM13

AL13
AG13

P13

F13

D13

B13
AY12
AC12

K12

H12

E12
AD11
AA11

Y11

CALISTOGA

CALISTOGA

71.CALIS.00U

71.CALIS.00U

D

VSS

VSS

VSS_211
VSS_212
VSS_213
VSS_214
VSS_215
VSS_216
VSS_217
VSS_218
VSS_219
VSS_220
VSS_221
VSS_222
VSS_223
VSS_224
VSS_225
VSS_226
VSS_227
VSS_228
VSS_229
VSS_230
VSS_231
VSS_232
VSS_233
VSS_234
VSS_235
VSS_236
VSS_237
VSS_238
VSS_239
VSS_240
VSS_241
VSS_242
VSS_243
VSS_244
VSS_245
VSS_246
VSS_247
VSS_248
VSS_249
VSS_250
VSS_251
VSS_252
VSS_253
VSS_254
VSS_255
VSS_256
VSS_257
VSS_258
VSS_259
VSS_260
VSS_261
VSS_262
VSS_263
VSS_264
VSS_265
VSS_266
VSS_267
VSS_268
VSS_269
VSS_270
VSS_271
VSS_272

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

VSS_273
VSS_274
VSS_275
VSS_276
VSS_277
VSS_278
VSS_279
VSS_280
VSS_281
VSS_282
VSS_283
VSS_284
VSS_285
VSS_286
VSS_287
VSS_288
VSS_289
VSS_290
VSS_291
VSS_292
VSS_293
VSS_294
VSS_295
VSS_296
VSS_297
VSS_298
VSS_299
VSS_300
VSS_301
VSS_302
VSS_303
VSS_304
VSS_305
VSS_306
VSS_307
VSS_308
VSS_309
VSS_310
VSS_311
VSS_312
VSS_313
VSS_314
VSS_315
VSS_316
VSS_317
VSS_318
VSS_319
VSS_320
VSS_321
VSS_322
VSS_323
VSS_324
VSS_325
VSS_326
VSS_327
VSS_328
VSS_329
VSS_330
VSS_331
VSS_332
VSS_333
VSS_334
VSS_335
VSS_336
VSS_337
VSS_338
VSS_339
VSS_340
VSS_341
VSS_342
VSS_343
VSS_344
VSS_345
VSS_346
VSS_347
VSS_348
VSS_349
VSS_350
VSS_351
VSS_352
VSS_353
VSS_354
VSS_355
VSS_356
VSS_357
VSS_358
VSS_359
VSS_360

J11
D11
B11
AV10
AP10
AL10
AJ10
AG10
AC10
W10
U10
BA9
AW9
AR9
AH9
AB9
Y9
R9
G9
E9
A9
AG8
AD8
AA8
U8
K8
C8
BA7
AV7
AP7
AL7
AJ7
AH7
AF7
AC7
R7
G7
D7
AG6
AD6
AB6
Y6
U6
N6
K6
H6
B6
AV5
AF5
AD5
AY4
AR4
AP4
AL4
AJ4
Y4
U4
R4
J4
F4
C4
AY3
AW3
AV3
AL3
AH3
AG3
AF3
AD3
AC3
AA3
G3
AT2
AR2
AP2
AK2
AJ2
AD2
AB2
Y2
U2
T2
N2
J2
H2
F2
C2
AL1

E

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

GMCH (5 of 5)

GMCH (5 of 5)

GMCH (5 of 5)

Volvi

Volvi

Volvi

10 42Wednesday, April 18, 2007

10 42Wednesday, April 18, 2007

10 42Wednesday, April 18, 2007

E

-1

-1

-1

of

of

of

A

DM2

M_B_A[13..0]8,12

4 4

TPAD30

TPAD30
TPAD30

TPAD30

M_B_BS#28,12
M_B_BS#08,12

M_B_BS#18,12

M_B_DQ[63..0]8

3 3

2 2

M_B_DQS#[7..0]8

M_B_DQS[7..0]8

1 1

DDR_VREF_S3

C228

C228

TP26

TP26
TP27

TP27

SC4D7U6D3V3KX-GP

SC4D7U6D3V3KX-GP

A

M_ODT27,12
M_ODT37,12

12

DY

DY

M_B_A0
M_B_A1
M_B_A2
M_B_A3
M_B_A4
M_B_A5
M_B_A6
M_B_A7
M_B_A8
M_B_A9
M_B_A10
M_B_A11
M_B_A12
M_B_A13
M_B_A14
M_B_A15

M_B_DQ0
M_B_DQ1
M_B_DQ2
M_B_DQ3
M_B_DQ4
M_B_DQ5
M_B_DQ6
M_B_DQ7
M_B_DQ8
M_B_DQ9
M_B_DQ10
M_B_DQ11
M_B_DQ12
M_B_DQ13
M_B_DQ14
M_B_DQ15
M_B_DQ16
M_B_DQ17
M_B_DQ18
M_B_DQ19
M_B_DQ20
M_B_DQ21
M_B_DQ22
M_B_DQ23
M_B_DQ24
M_B_DQ25
M_B_DQ26
M_B_DQ27
M_B_DQ28
M_B_DQ29
M_B_DQ30
M_B_DQ31
M_B_DQ32
M_B_DQ33
M_B_DQ34
M_B_DQ35
M_B_DQ36
M_B_DQ37
M_B_DQ38
M_B_DQ39
M_B_DQ40
M_B_DQ41
M_B_DQ42
M_B_DQ43
M_B_DQ44
M_B_DQ45
M_B_DQ46
M_B_DQ47
M_B_DQ48
M_B_DQ49
M_B_DQ50
M_B_DQ51
M_B_DQ52
M_B_DQ53
M_B_DQ54
M_B_DQ55
M_B_DQ56
M_B_DQ57
M_B_DQ58
M_B_DQ59
M_B_DQ60
M_B_DQ61
M_B_DQ62
M_B_DQ63

M_B_DQS#0
M_B_DQS#1
M_B_DQS#2
M_B_DQS#3
M_B_DQS#4
M_B_DQS#5
M_B_DQS#6
M_B_DQS#7

M_B_DQS0
M_B_DQS1
M_B_DQS2
M_B_DQS3
M_B_DQS4
M_B_DQS5
M_B_DQS6
M_B_DQS7

12

C223

C223

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

DM2

102

A0

101

A1

100

A2

99

A3

98

A4

97

A5

94

A6

92

A7

93

A8

91

A9

105

A10/AP

90

A11

89

A12

116

A13

86

A14

84

A15

85

A16/BA2

107

BA0

106

BA1

5

DQ0

7

DQ1

17

DQ2

19

DQ3

4

DQ4

6

DQ5

14

DQ6

16

DQ7

23

DQ8

25

DQ9

35

DQ10

37

DQ11

20

DQ12

22

DQ13

36

DQ14

38

DQ15

43

DQ16

45

DQ17

55

DQ18

57

DQ19

44

DQ20

46

DQ21

56

DQ22

58

DQ23

61

DQ24

63

DQ25

73

DQ26

75

DQ27

62

DQ28

64

DQ29

74

DQ30

76

DQ31

123

DQ32

125

DQ33

135

DQ34

137

DQ35

124

DQ36

126

DQ37

134

DQ38

136

DQ39

141

DQ40

143

DQ41

151

DQ42

153

DQ43

140

DQ44

142

DQ45

152

DQ46

154

DQ47

157

DQ48

159

DQ49

173

DQ50

175

DQ51

158

DQ52

160

DQ53

174

DQ54

176

DQ55

179

DQ56

181

DQ57

189

DQ58

191

DQ59

180

DQ60

182

DQ61

192

DQ62

194

DQ63

11

DQS0#

29

DQS1#

49

DQS2#

68

DQS3#

129

DQS4#

146

DQS5#

167

DQS6#

186

DQS7#

13

DQS0

31

DQS1

51

DQS2

70

DQS3

131

DQS4

148

DQS5

169

DQS6

188

DQS7

114

OTD0

119

OTD1

1

VREF

2

VSS

202

GND

MH1

MH1

DDR2-200P-23-GP-U1

DDR2-200P-23-GP-U1

62.10017.A71

62.10017.A71

High 9.2mm

RAS#

WE#

CAS#

CS0#
CS1#

CKE0
CKE1

CK0

CK0#

CK1

CK1#

DM0
DM1
DM2
DM3
DM4
DM5
DM6
DM7

SDA
SCL

VDDSPD

NC#50
NC#69
NC#83

NC#120

NC#163/TEST

VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

REVERSE TYPE

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

GND
MH2

B

108
109
113

110
115

79
80

30
32

164
166

M_B_DM0

10

M_B_DM1

26

M_B_DM2

52

M_B_DM3

67

M_B_DM4

130

M_B_DM5

147

M_B_DM6

170

M_B_DM7

185

195
197

199
198

SA0

DDRB_SA0

200

SA1

50
69
83
120
163

81
82
87
88
95
96
103
104
111
112
117
118

3
8
9
12
15
18
21
24
27
28
33
34
39
40
41
42
47
48
53
54
59
60
65
66
71
72
77
78
121
122
127
128
132
133
138
139
144
145
149
150
155
156
161
162
165
168
171
172
177
178
183
184
187
190
193
196

201
MH2

10KR2J-3-GP

10KR2J-3-GP

B

R139

R139

M_B_RAS# 8,12
M_B_WE# 8,12
M_B_CAS# 8,12

M_CS2# 7,12
M_CS3# 7,12

M_CKE2 7,12
M_CKE3 7,12

M_CLK_DDR3 7
M_CLK_DDR#3 7

M_CLK_DDR2 7
M_CLK_DDR#2 7

12

1D8V_S3

0122 swap CLK2 and CLK3

M_B_DM[7..0] 8

SMBD_ICH 3,18
SMBC_ICH 3,18

C231

C231

3D3V_S0

12

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

C

C

M_A_A[13..0]8,12

M_A_BS#28,12

M_A_BS#08,12
M_A_BS#18,12

M_A_DQ[63..0]8

M_CS0#7,12
M_CS1#7,12
M_CKE07,12

M_CKE17,12
M_A_RAS#8,12
M_A_CAS#8,12

M_A_WE#8,12

DDR_VREF_S3

DY

DY

C202

C202

SC4D7U6D3V3KX-GP

SC4D7U6D3V3KX-GP

TPAD30

TPAD30
TPAD30

TPAD30

12

TP25

TP25
TP24

TP24

12

C454

C454

M_ODT07,12
M_ODT17,12

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

M_A_A0
M_A_A1
M_A_A2
M_A_A3
M_A_A4
M_A_A5
M_A_A6
M_A_A7
M_A_A8
M_A_A9
M_A_A10
M_A_A11
M_A_A12
M_A_A13
M_A_A14
M_A_A15

M_A_DQ0
M_A_DQ1
M_A_DQ2
M_A_DQ3
M_A_DQ4
M_A_DQ5
M_A_DQ6
M_A_DQ7
M_A_DQ8
M_A_DQ9
M_A_DQ10
M_A_DQ11
M_A_DQ12
M_A_DQ13
M_A_DQ14
M_A_DQ15
M_A_DQ16
M_A_DQ17
M_A_DQ18
M_A_DQ19
M_A_DQ20
M_A_DQ21
M_A_DQ22
M_A_DQ23
M_A_DQ24
M_A_DQ25
M_A_DQ26
M_A_DQ27
M_A_DQ28
M_A_DQ29
M_A_DQ30
M_A_DQ31
M_A_DQ32
M_A_DQ33
M_A_DQ34
M_A_DQ35
M_A_DQ36
M_A_DQ37
M_A_DQ38
M_A_DQ39
M_A_DQ40
M_A_DQ41
M_A_DQ42
M_A_DQ43
M_A_DQ44
M_A_DQ45
M_A_DQ46
M_A_DQ47
M_A_DQ48
M_A_DQ49
M_A_DQ50
M_A_DQ51
M_A_DQ52
M_A_DQ53
M_A_DQ54
M_A_DQ55
M_A_DQ56
M_A_DQ57
M_A_DQ58
M_A_DQ59
M_A_DQ60
M_A_DQ61
M_A_DQ62
M_A_DQ63

SMBC_ICH
SMBD_ICH

DM1

DM1

MH1

MH1

102

A0

101

A1

100

A2

99

A3

98

A4

97

A5

94

A6

92

A7

93

A8

91

A9

105

A10/AP

90

A11

89

A12

116

A13

86

A14

84

A15

85

A16_BA2

107

BA0

106

BA1

5

DQ0

7

DQ1

17

DQ2

19

DQ3

4

DQ4

6

DQ5

14

DQ6

16

DQ7

23

DQ8

25

DQ9

35

DQ10

37

DQ11

20

DQ12

22

DQ13

36

DQ14

38

DQ15

43

DQ16

45

DQ17

55

DQ18

57

DQ19

44

DQ20

46

DQ21

56

DQ22

58

DQ23

61

DQ24

63

DQ25

73

DQ26

75

DQ27

62

DQ28

64

DQ29

74

DQ30

76

DQ31

123

DQ32

125

DQ33

135

DQ34

137

DQ35

124

DQ36

126

DQ37

134

DQ38

136

DQ39

141

DQ40

143

DQ41

151

DQ42

153

DQ43

140

DQ44

142

DQ45

152

DQ46

154

DQ47

157

DQ48

159

DQ49

173

DQ50

175

DQ51

158

DQ52

160

DQ53

174

DQ54

176

DQ55

179

DQ56

181

DQ57

189

DQ58

191

DQ59

180

DQ60

182

DQ61

192

DQ62

194

DQ63

50

NC#50

69

NC#69

83

NC#83

120

NC#120

163

NC#163/TEST

110

CS0#

115

CS1#

79

CKE0

80

CKE1

108

RAS#

113

CAS#

109

WE#

197

SCL

195

SDA

114

ODT0

119

ODT1

1

VREF

201

GND

SKT-SODIMM20022U2GP

SKT-SODIMM20022U2GP

62.10017.691

62.10017.691

High 5.2mm

D

MH2

MH2

DQS0
DQS1
DQS2
DQS3
DQS4
DQS5
DQS6

DQS7
DQS0#
DQS1#
DQS2#
DQS3#
DQS4#
DQS5#
DQS6#
DQS7#

DM0
DM1
DM2
DM3
DM4
DM5
DM6
DM7

CK0

CK0#

CK1

CK1#

SA0
SA1

VDD_SPD

VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

REVERSE TYPE

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

GND

D

M_A_DQS0

13

M_A_DQS1

31

M_A_DQS2

51

M_A_DQS3

70

M_A_DQS4

131

M_A_DQS5

148

M_A_DQS6

169

M_A_DQS7

188

M_A_DQS#0

11

M_A_DQS#1

29

M_A_DQS#2

49

M_A_DQS#3

68

M_A_DQS#4

129

M_A_DQS#5

146

M_A_DQS#6

167

M_A_DQS#7

186

M_A_DM0

10

M_A_DM1

26

M_A_DM2

52

M_A_DM3

67

M_A_DM4

130

M_A_DM5

147

M_A_DM6

170

M_A_DM7

185
30

32
164
166

198
200

199

81
82
87
88
95
96
103
104
111
112
117
118

2
3
8
9
12
15
18
21
24
27
28
33
34
39
40
41
42
47
48
53
54
59
60
65
66
71
72
77
78
121
122
127
128
132
133
138
139
144
145
149
150
155
156
161
162
165
168
171
172
177
178
183
184
187
190
193
196

202

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

M_A_DQS[7..0] 8

M_A_DQS#[7..0] 8

M_A_DM[7..0] 8

M_CLK_DDR0 7
M_CLK_DDR#0 7
M_CLK_DDR1 7
M_CLK_DDR#1 7

3D3V_S0

C208

C208

12

1D8V_S3

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet of

Date: Sheet of

Date: Sheet

E

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

DDR2 Socket

DDR2 Socket

DDR2 Socket

Volvi

Volvi

Volvi

11 42Wednesday, April 18, 2007

11 42Wednesday, April 18, 2007

11 42Wednesday, April 18, 2007

E

-1

-1

-1

of

A

DDR_VREF_S0

RN32

RN32

1

8

2

7

3

6

8

4 4

3 3

2 2

1 1

7
6

8
7
6

8
7
6

8
7
6

8
7
6

8
7
6

8
7
6

8
7
6

8
7
6

8
7
6

8
7
6

8
7
6

8
7
6

A

SRN56J-5-GP

SRN56J-5-GP

RN40

RN40

SRN56J-5-GP

SRN56J-5-GP

RN39

RN39

SRN56J-5-GP

SRN56J-5-GP

RN41

RN41

SRN56J-5-GP

SRN56J-5-GP

RN45

RN45

SRN56J-5-GP

SRN56J-5-GP

RN44

RN44

SRN56J-5-GP

SRN56J-5-GP

RN43

RN43

SRN56J-5-GP

SRN56J-5-GP

RN42

RN42

SRN56J-5-GP

SRN56J-5-GP

RN38

RN38

SRN56J-5-GP

SRN56J-5-GP

RN37

RN37

SRN56J-5-GP

SRN56J-5-GP

RN35

RN35

SRN56J-5-GP

SRN56J-5-GP

RN33

RN33

SRN56J-5-GP

SRN56J-5-GP

RN36

RN36

SRN56J-5-GP

SRN56J-5-GP

RN34

RN34

SRN56J-5-GP

SRN56J-5-GP

45

1
2
3
45

1
2
3
45

1
2
3
45

1
2
3
45

1
2
3
45

1
2
3
45

1
2
3
45

1
2
3
45

1
2
3
45

1
2
3
45

1
2
3
45

1
2
3
45

1
2
3
45

M_A_A12

M_B_A9
M_B_A5

M_B_A12

M_B_A13

M_B_A2
M_B_A0
M_B_A4

M_B_A6
M_B_A7
M_B_A11

M_A_A13

M_A_A0
M_A_A2
M_A_A4

M_A_A9
M_A_A8
M_A_A5
M_A_A3

M_A_A6
M_A_A7
M_A_A11

M_A_A1
M_A_A10

PARALLEL TERMINATION

Put decap near power(0.9V) and pull-up resistor

M_CKE0 7,11
M_CKE1 7,11
M_A_BS#2 8,11

M_B_A8

M_CKE2 7,11
M_CKE3 7,11
M_B_BS#2 8,11

M_B_A3
M_B_A1
M_B_A10

M_B_WE# 8,11

M_ODT2 7,11
M_ODT3 7,11
M_B_RAS# 8,11

M_B_BS#1 8,11

M_B_BS#0 8,11
M_B_CAS# 8,11
M_CS3# 7,11
M_CS2# 7,11

M_ODT0 7,11
M_CS0# 7,11
M_A_RAS# 8,11

M_A_BS#1 8,11

M_A_CAS# 8,11
M_CS1# 7,11

M_ODT1 7,11

M_A_BS#0 8,11
M_A_WE# 8,11

B

C

D

E

Decoupling Capacitor

DDR_VREF_S0

12

C198

C198

DY

DY

M_A_A[13..0]
M_B_A[13..0]

B

M_A_A[13..0] 8,11
M_B_A[13..0] 8,11

12

C452

C452

1D8V_S3

Put decap near power(0.9V)
and pull-up resistor

12

12

C229

C229

C240

C240

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

1D8V_S3

DY

DY

12

C217

C217

12

C447

C447

12

C197

C197

DY

DY

12

C226

C226

12

C238

C238

DY

DY

C

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

12

C242

C242

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

DY

DY

Place these Caps near DM1

12

C213

C213

SC2D2U6D3V3MX-1-GP

SC2D2U6D3V3MX-1-GP

SC2D2U6D3V3MX-1-GP

SC2D2U6D3V3MX-1-GP

12

C205

C205

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

DY

DY

12

C245

C245

SC2D2U6D3V3MX-1-GP

SC2D2U6D3V3MX-1-GP

12

C224

C224

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

DY

DY

12

12

C216

C216

12

C234

C234

12

C214

C214

12

C212

C212

12

C221

C221

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

12

C211

C211

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

12

C446

C446

SC2D2U6D3V3MX-1-GP

SC2D2U6D3V3MX-1-GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

C206

C206

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

12

C210

C210

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

12

C448

C448

SC2D2U6D3V3MX-1-GP

SC2D2U6D3V3MX-1-GP

12

C209

C209

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

DY

DY

DY

DY

Place these Caps near DM2

12

C227

SC2D2U6D3V3MX-1-GP

SC2D2U6D3V3MX-1-GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

C227

12

C239

C239

DY

DY

12

C236

C236

SC2D2U6D3V3MX-1-GP

SC2D2U6D3V3MX-1-GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SC2D2U6D3V3MX-1-GP

SC2D2U6D3V3MX-1-GP

12

C222

C222

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

DY

DY

12

C207

C207

12

C199

C199

12

C235

C235

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

DY

DY

12

C243

C243

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

DY

DY

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet of

Date: Sheet of

Date: Sheet

12

C219

C219

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

12

C220

C220

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

DY

DY

SC2D2U6D3V3MX-1-GP

SC2D2U6D3V3MX-1-GP

12

C246

C246

SC2D2U6D3V3MX-1-GP

SC2D2U6D3V3MX-1-GP

D

12

12

C230

C230

C218

C218

12

C241

C241

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

12

C453

C453

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

DDR2 Termination Resistor

DDR2 Termination Resistor

DDR2 Termination Resistor

Volvi

Volvi

Volvi

E

-1

-1

of

12 42Wednesday, April 18, 2007

12 42Wednesday, April 18, 2007

12 42Wednesday, April 18, 2007

-1

R226

R226

1 2

UMA

GMCH_LCDVDD_ON7

NV_LCDVDD_ON26

UMA

0R2J-2-GP

0R2J-2-GP

LCD/INVERTER CONN

LCD1

LCD1

41

1

R225

R225

2
4

6

8
10
12
14
16
18
20
22
24
26
28
30

42

1 2

FUSE-1A6V-2-GP

FUSE-1A6V-2-GP

69.50007.721

69.50007.721

USBPN6 16
USBPP6 16

DY

DY

R227

R227

0R0402-PAD

0R0402-PAD

10KR2J-3-GPR110KR2J-3-GP

3
5
7
9
11
13
15
17
19
21
23
25
27
29
3132
3334
3536
3738
3940

ACES-CONN40A-2GP

ACES-CONN40A-2GP

20.F0993.040

20.F0993.040

F2

F2

12

0R2J-2-GP

0R2J-2-GP

12

12

R1

DCBATOUT

12

C3

SC10U35V0ZY-GPC3SC10U35V0ZY-GP

CCD_PWR

12

C1

C1
SC4D7U10V5ZY-3GP

SC4D7U10V5ZY-3GP

USB_6­USB_6+

BRIGHTNESS_CN
BLON_OUT

1 2

FUSE-3A32V-8-GP

FUSE-3A32V-8-GP

12

69.43001.111

69.43001.111

EC1

EC1

SCD1U50V3ZY-GP

SCD1U50V3ZY-GP

DY

DY

12

C340

C340

SC100P50V2JN-3GP

SC100P50V2JN-3GP

USB_6­USB_6+

3D3V_S0

NV_EDID_CLK
NV_EDID_DAT

CCD_PWR
BRIGHTNESS_CN

BLON_OUT

F1

F1

12

C2

C2
SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SB 0226

R110R0402-PAD R110R0402-PAD

1 2

R100R0402-PAD R100R0402-PAD

1 2

12

C4

SC100P50V2JN-3GPC4SC100P50V2JN-3GP

-1 0416

LCDVDD_ON_1

MXM

MXM

LCD_TXAOUT2­LCD_TXAOUT2+
LCD_TXAOUT1­LCD_TXAOUT1+
LCD_TXAOUT0­LCD_TXAOUT0+
LCD_TXACLK­LCD_TXACLK+
LCD_TXBOUT2­LCD_TXBOUT2+
LCD_TXBOUT1­LCD_TXBOUT1+
LCD_TXBOUT0­LCD_TXBOUT0+
LCD_TXBCLK­LCD_TXBCLK+

3D3V_S0

L_BKLTCTL 7
BRIGHTNESS 30

BLON_OUT 30

LCDVDD 3D3V_S0

SC1U16V3ZY-GP

1 2

R224

R224
0R2J-2-GP

0R2J-2-GP

LCDVDD

SC1U16V3ZY-GP

12

12

C338

C338

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

12

C5

C5
SCD1U25V3ZY-1GP

SCD1U25V3ZY-1GP

C339

C339

ODD CHANNEL

EVEN CHANNEL

LCD_TXBOUT0+
LCD_TXBOUT0­LCD_TXBOUT1+
LCD_TXBOUT1-

LCD_TXBOUT2+
LCD_TXBOUT2­LCD_TXBCLK+
LCD_TXBCLK-

LCD_TXAOUT2+
LCD_TXAOUT2­LCD_TXACLK+
LCD_TXACLK-

LCD_TXAOUT0+
LCD_TXAOUT0­LCD_TXAOUT1+
LCD_TXAOUT1-

U35

U35

1
2
3
4

G5281RC1U-GP

G5281RC1U-GP

74.05281.093

74.05281.093

LCD_TXBOUT1­LCD_TXBOUT1+
LCD_TXBOUT0­LCD_TXBOUT0+

LCD_TXBCLK­LCD_TXBCLK+
LCD_TXBOUT2­LCD_TXBOUT2+

LCD_TXACLK­LCD_TXACLK+
LCD_TXAOUT2­LCD_TXAOUT2+

LCD_TXAOUT1­LCD_TXAOUT1+
LCD_TXAOUT0­LCD_TXAOUT0+

RN6

RN6

1
2
3
4 5

SRN0J-7-GP

SRN0J-7-GP

RN4

RN4

1
2
3
4 5

SRN0J-7-GP

SRN0J-7-GP
RN8

RN8

1
2
3
4 5

SRN0J-7-GP

SRN0J-7-GP
RN13

RN13

1
2
3
4 5

SRN0J-7-GP

SRN0J-7-GP

IN#1
OUT
EN
GND

1
2
3
4 5

1
2
3
4 5

1
2
3
4 5

1
2
3
4 5

MXM

MXM

8
7
6

MXM

MXM

8
7
6

MXM

MXM

8
7
6

MXM

MXM

8
7
6

GND
IN#8
IN#7
IN#6
IN#5

RN7

RN7

UMA

UMA

SRN0J-7-GP

SRN0J-7-GP

RN3

RN3

UMA

UMA

SRN0J-7-GP

SRN0J-7-GP
RN9

RN9

UMA

UMA

SRN0J-7-GP

SRN0J-7-GP
RN14

RN14

UMA

UMA

SRN0J-7-GP

SRN0J-7-GP

9
8
7
6
5

8
7
6

8
7
6

8
7
6

8
7
6

LVDS_TXBOUT0+ 26

LVDS_TXBOUT0- 26

LVDS_TXBOUT1+ 26

LVDS_TXBOUT1- 26

LVDS_TXBOUT2+ 26

LVDS_TXBOUT2- 26

LVDS_TXBCLK+ 26

LVDS_TXBCLK- 26

LVDS_TXAOUT2+ 26

LVDS_TXAOUT2- 26

LVDS_TXACLK+ 26
LVDS_TXACLK- 26

LVDS_TXAOUT0+ 26

LVDS_TXAOUT0- 26

LVDS_TXAOUT1+ 26

LVDS_TXAOUT1- 26

SC1U16V3ZY-GP

SC1U16V3ZY-GP

12

C337

C337

GMCH_TXBOUT1- 7

GMCH_TXBOUT1+ 7

GMCH_TXBOUT0- 7

GMCH_TXBOUT0+ 7

GMCH_TXBCLK- 7

GMCH_TXBCLK+ 7

GMCH_TXBOUT2- 7

GMCH_TXBOUT2+ 7

GMCH_TXACLK- 7

GMCH_TXACLK+ 7

GMCH_TXAOUT2- 7

GMCH_TXAOUT2+ 7

GMCH_TXAOUT1- 7

GMCH_TXAOUT1+ 7

GMCH_TXAOUT0- 7

GMCH_TXAOUT0+ 7

LCD_TXBCLK+

LCD_TXBCLK­LCD_TXBOUT2+

LCD_TXBOUT2­LCD_TXBOUT1+

LCD_TXBOUT1­LCD_TXBOUT0+

LCD_TXBOUT0-

DY

DY

DY

DY

DY

DY

DY

DY

R9

R9
330R2J-3-GP

330R2J-3-GP

1 2

R6

R6
330R2J-3-GP

330R2J-3-GP

1 2

R7

R7
330R2J-3-GP

330R2J-3-GP

1 2

R8

R8
330R2J-3-GP

330R2J-3-GP

1 2

PWRLED#_DB31

STDBY_LED#_DB31

WLAN_TEST_LED30

PWR_G_LED30

PWR_O_LED30

EMI

Q15

Q15

GND

GND

2

IN

IN

1

CHDTC143ZUPT-GP

CHDTC143ZUPT-GP

84.00143.B1K

84.00143.B1K

PWRLED#_DB

STDBY_LED#_DB STDBY_LED#_R

GND

GND

2

IN

IN

1

BT_LED#31

Q9

Q9

GND

GND

2

R2

R2

IN

IN

DY

DY

1 2

DY

DY

1 2

DY

DY

1 2

DY

DY

1 2

1

CHDTC143ZUPT-GP

CHDTC143ZUPT-GP

Q8

Q8

GND

GND

2

IN

IN

1

CHDTC143ZUPT-GP

CHDTC143ZUPT-GP
Q27

Q27

GND

GND

2

IN

IN

1

CHDTC143ZUPT-GP

CHDTC143ZUPT-GP

R5

R5
330R2J-3-GP

330R2J-3-GP

R2

R2
330R2J-3-GP

330R2J-3-GP

R3

R3
330R2J-3-GP

330R2J-3-GP

R4

R4
330R2J-3-GP

330R2J-3-GP

R2

R2

R2

R2

BT_LED30

CHARGE_LED30

DC_BATFULL30

NV_EDID_CLK_126

NV_EDID_DAT_126

LCD_TXACLK+

LCD_TXACLK­LCD_TXAOUT2+

LCD_TXAOUT2­LCD_TXAOUT1+

LCD_TXAOUT1­LCD_TXAOUT0+

LCD_TXAOUT0-

CLK_DDC_EDID7

DAT_DDC_EDID7

OUT

OUT

3

R2

R2

R1

R1

Q14

Q14

R2

R2

R1

R1

CHDTC143ZUPT-GP

CHDTC143ZUPT-GP

84.00143.B1K

84.00143.B1K

BT_LED#

OUT

OUT

3

R1

R1

84.00143.B1K

84.00143.B1K

OUT

OUT

3

R1

R1

84.00143.B1K

84.00143.B1K

OUT

OUT

3

R1

R1

84.00143.B1K

84.00143.B1K

OUT

OUT

3

R500 100R2J-2-GPR500 100R2J-2-GP

1 2

R499 100R2J-2-GPR499 100R2J-2-GP

R333

R333

1 2

33R2J-2-GP

33R2J-2-GP

R497

R497

1 2

1 2

FRONT_PWRLED#_R

1 2

Q10

Q10

2N7002-11-GP

2N7002-11-GP

G

84.27002.W31

84.27002.W31

S D

2nd 84.00143.D1K

CHARGE_LED#_R

100R2J-2-GP

100R2J-2-GP

R498

R498

DC_BATFULL#_R

100R2J-2-GP

100R2J-2-GP

R35

R35

UMA

UMA

1 2

0R2J-2-GP

0R2J-2-GP
R29

R29

1 2

0R2J-2-GP

0R2J-2-GP

MXM

MXM

R34

R34

UMA

UMA

1 2

0R2J-2-GP

0R2J-2-GP
R28

R28

1 2

0R2J-2-GP

0R2J-2-GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

MXM

MXM

UMA

UMA

UMA

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

LED1

LED1

LED-GY-14-GP

LED-GY-14-GP

83.00195.I70

83.00195.I70

LED2

LED2

24

13

LED-GY-14-GP

LED-GY-14-GP

83.00195.I70

83.00195.I70

3D3V_S0

1

23

RN5

RN5
SRN2K2J-1-GP

SRN2K2J-1-GP

4

12

EC3

EC3

12

EC4

EC4

DY

DY

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

LCD CONN & LED

LCD CONN & LED

LCD CONN & LED

3D3V_S0

3D3V_S5

3D3V_S5

NV_EDID_CLK

NV_EDID_DAT

13 42Wednesday, April 18, 2007

13 42Wednesday, April 18, 2007

13 42Wednesday, April 18, 2007

of

of

of

13

24

WLAN_LED# 31WLAN_LED#_MC27

DY

DY

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Volvi

Volvi

Volvi

-1

-1

-1
