Wisco 660N Installation Manual
LTR SYSTEM
Label - Tape - Ribbon Dispensers
MODEL 660N
MODEL 670N
MODEL 660N/670N
FEATURES:
- Dispensers accommodate tape, labels and ribbon in any roll width having core diameters of either
1” or 3” and an overall diameter of up to 6”.
- Rolls are installed and replaced without disturbing others in place.
- 4 suction cups on bottom to secure placement of unit.
MODEL 660N
18” Version
19”L x 8-5/8”W x 4-1/8”H
SINGLE UNIT:
SHIPPING DIMENSIONS: 20”L x 9”W x 5”H
SHIPPING WEIGHT: 8 lbs.
CASE OF 6 UNITS :
SHIPPING DIMENSIONS: 19”L x 14”W x 20”H
SHIPPING WEIGHT: 50 lbs.
MODEL 670N
10” Version
11”L x 8-5/8”W x 4- 1/8”H
SINGLE UNIT :
SHIPPING DIMENSIONS: 12”L x 9”W x 5”H
SHIPPING WEIGHT: 5 lbs.
CASE OF 6 UNITS :
SHIPPING DIMENSIONS: 19”L x 14”W x 12”H
SHIPPING WEIGHT: 32 lbs.
FP140096-M
REV. 01/14
P.O. BOX #10
OREGON, WI 53575
PHONE: 608-835-3106
FAX: 608-835-8273
www .wiscoind.com
LIMITED WARRANTY:
Wisco Industries, Inc. expressly warrants the product will be free from defects in workmanship and materials for a period of
1 year from the date of shipment. WISCO DISCLAIMS AND EXCLUDES ANY AND ALL OTHER EXPRESS OR IMPLIED
WARRANTIES, INCLUDING WITHOUT LIMITATION, ANY AND ALL WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE.
Buyer agrees that its SOLE AND EXCLUSIVE REMEDY against Wisco and Wisco’s SOLE AND EXCLUSIVE LIABILITY arising
out of any defect or nonconformity in the product shall be replacement/exchange of such nonconforming countertop food service
equipment at Wisco’s expense. No countertop food service equipment shall be returned without Wisco’s consent. IT IS AGREED
THAT WISCO’S MAXIMUM LIABILITY SHALL NOT IN ANY CASE EXCEED THE SALE PRICE FOR THE COUNTERTOP
EQUIPMENT CLAIMED TO BE DEFECTIVE OR NONCONFORMING.
ASSEMBLY & LOADING INSTRUCTIONS FOR MODELS 660N/670N
STEP 1:
To aid in assembly, spray wax or other lubricant on
support rod. Two arms support each roll. Slide
loaded support arm into “J” notches and pull
forward.
STEP 2:
Place rolls of labels, tap e or ribbon in between
support arms. 3” core adaptors are included for
large core rolls.
STEP 3:
Pull labels, tape or ribbon forward so it sticks to top
flange of front wall.
STEP 4:
Threa d label, tape or ribbon stock under guide
bar and over top flange of front wall.
