Winston PF56P, PF46P Parts List

Winston
Collectramatic Fryer - 'P' Control
2345 Carton Drive Louisville, KY 40299 USA (800) 234-5286 (502) 495-5400
To order parts, contact your Winston representative or call the International office:
Winston Products Co.
(800) 234-5286 USA & Canada/USA TEL: (502) 495-5400/USA FAX: (502) 495-5458
Lit. #4275R83 - 9/96
WINSTON COLLECTRAMATIC FRYER
Table of Contents
Photo Reference .......................................................................................................... 1 - 8
Parts Descriptions & Order Numbers........................................................................... 9 - 13
How To Use This Manual
Use Photo Reference (pages 1 - 8) to identify parts. Match Photo Reference numbers with Parts Descriptions and Order Numbers (pages 9 - 13).
To order parts, contact your Winston representative or call the International office:
Winston Products Co.
(800) 234-5286 USA & Canada/USA TEL: (502) 495-5400/USA FAX: (502) 495-5458
WINSTON COLLECTRAMATIC FRYER
NOTE: See page 6 - 7
for Parts Descriptions
and Order Numbers
1 3
4
Parts Identification
12
2
16
6 7
9
10
17
18
5
8
11
19
20A
14
15
(Hidden)
13
To order parts, contact your Winston representative or call the International office:
Winston Products Co.
(800) 234-5286 USA & Canada/USA TEL: (502) 495-5400/USA FAX: (502) 495-5458
1
20B
(Inside)
21
(Hidden)
WINSTON COLLECTRAMATIC FRYER
NOTE: See page 5
for Parts Descriptions
and Order Numbers
23 24
Parts Identification
22
25
24
(Reference Only)
9
19
To order parts, contact your Winston representative or call the International office:
Winston Products Co.
(800) 234-5286 USA & Canada/USA TEL: (502) 495-5400/USA FAX: (502) 495-5458
22
WINSTON COLLECTRAMATIC FRYER
NOTE: See page 6 - 7
for Parts Descriptions
and Order Numbers
30
Parts Identification
29
(Under) 27
28
21
26
15
31
36
35
34 32
33
To order parts, contact your Winston representative or call the International office:
Winston Products Co.
(800) 234-5286 USA & Canada/USA TEL: (502) 495-5400/USA FAX: (502) 495-5458
3
WINSTON COLLECTRAMATIC FRYER
NOTE: See page 6 - 7
for Parts Descriptions
and Order Numbers
Parts Identification
37
38
39
42
(Behind)
43
40
41
To order parts, contact your Winston representative or call the International office:
Winston Products Co.
(800) 234-5286 USA & Canada/USA TEL: (502) 495-5400/USA FAX: (502) 495-5458
4
WINSTON COLLECTRAMATIC FRYER
NOTE: See page 6 - 7
for Parts Descriptions
and Order Numbers
Parts Identification
44
45
47
46
To order parts, contact your Winston representative or call the International office:
Winston Products Co.
(800) 234-5286 USA & Canada/USA TEL: (502) 495-5400/USA FAX: (502) 495-5458
5
WINSTON COLLECTRAMATIC FRYER
NOTE: See page 6 - 7
for Parts Descriptions
and Order Numbers
49
Parts Identification
48
50
51
53
(Reference Only)
52
54
(Under)
To order parts, contact your Winston representative or call the International office:
Winston Products Co.
(800) 234-5286 USA & Canada/USA TEL: (502) 495-5400/USA FAX: (502) 495-5458
6
WINSTON COLLECTRAMATIC FRYER
NOTE: See page 6 - 7
for Parts Descriptions
and Order Numbers
56
Parts Identification
55
54
52
57
59
58
To order parts, contact your Winston representative or call the International office:
Winston Products Co.
(800) 234-5286 USA & Canada/USA TEL: (502) 495-5400/USA FAX: (502) 495-5458
7
WINSTON COLLECTRAMATIC FRYER
NOTE: See page 6 - 7
for Parts Descriptions
and Order Numbers
Parts Identification
60 30
11
61
62
63
29
65
64
66
To order parts, contact your Winston representative or call the International office:
Winston Products Co.
(800) 234-5286 USA & Canada/USA TEL: (502) 495-5400/USA FAX: (502) 495-5458
8
67
WINSTON COLLECTRAMATIC FRYER
Parts Identification
Reference
Number
1 Danger Panel PS1210
Part Description Order Number
2 Latch Block
3 Hinge Block
4 Eyebrow PS1134
5 Switch Guard PS1086
6 Hi Limit Indicator Lamp PS1012/3
7 Heat On Indicator Lamp PS1012/3
8 Power On Indicator Lamp PS1012/3
9 Membrane Panel
Membrane Panel
10 Leg Front PS1933
(Front) (Pressure Lock)
(Rear)
(General Market) (KFC)
PS1399
PS1400
PS1748 PS1932
11 Collector PS1206
12 Lid Pressure Lock PS1046
13 Insulation Front Sections
14 Insulation
Insulation
15 High Limit Thermostat PS1184
To order parts, contact your Winston representative or call the International office:
(800) 234-5286 USA & Canada/USA TEL: (502) 495-5400/USA FAX: (502) 495-5458
(4 HD) (6 HD)
Winston Products Co.
9
(4 HD & 6 HD)
PS1986
PS1031 PS1792
WINSTON COLLECTRAMATIC FRYER
Parts Identification
Reference
Number
16 Mercury Relay PS1448
17 Electromechanical Relay PS1007
Part Description Order Number
18 Power Board
Power Board
19 EMI Filter PS1977
20A Fuse Holder PS1096/2
20B Fuse PS1095/6
21 Thermister Probe PS2040
22 Buzzer PS1586
23 Transformer PS1687
24 Computer
Computer
(General Market) (KFC)
(General Market) Ref. Only (KFC) Ref. Only
PS1800 PS1971
25 On/Off Switch
On/Off Switch
26 Heater
Heater
27 Heater Holder PS1430
28 Probe Guard PS1744
To order parts, contact your Winston representative or call the International office:
(800) 234-5286 USA & Canada/USA TEL: (502) 495-5400/USA FAX: (502) 495-5458
(208 Volt), (380 Volt) (240 Volt), (416 Volt)
(General Market) (KFC)
Winston Products Co.
10
PS1529 PS1970
PS1147 PS1148
WINSTON COLLECTRAMATIC FRYER
Parts Identification
Reference
Number
29 Collector Gasket PS1892/3
30 Heat Plate PS1034
31 High Limit Thermostat Clamp PS1312
32 Leg Rear With Wheel PS1934
33 Wheel Assembly PS1226/2
Part Description Order Number
34 Leg Clamp Assembly PS1621
35 Muffler PS1152
36 Back Panel
Back Panel
37 Vent Back Cap PS1729
38 Vent Back Assembly PS1156
39 Vent Assembly
Vent Assembly Vent Assembly
40 Weight
Weight Weight
Note:
When identifying correct weight for ordering, read PSI engraved on weight lifter.
(4 HD) (6 HD)
(4 HD) - GM (4 HD) - KFC Dom. (6 HD)
(4 HD) (14 PSI) - KFC Dom. (4 HD) (11.9 PSI) - GM (6 HD) (11.9 PSI)
PS1697 PS1698
PS1653 PS1458 PS1686
PS1071 PS1072 PS1073
41 Weight Lifter
Weight Lifter Weight Lifter
To order parts, contact your Winston representative or call the International office:
(800) 234-5286 USA & Canada/USA TEL: (502) 495-5400/USA FAX: (502) 495-5458
(4 HD) (14 PSI) (4 HD) (11.9 PSI) (6 HD) (11.9 PSI)
Winston Products Co.
11
PS1039 PS1040 PS1073
WINSTON COLLECTRAMATIC FRYER
Parts Identification
Reference
Number
42 Teflon Slide PS1075/3
Part Description Order Number
43 Vent Block Assembly
Vent Block Assembly
44 Vent Tube
Vent Tube
45 Vent Solenoid Spring PS1320/3
46 Vent Solenoid PS1088
47 Vent Solenoid Cotter Pin PS1121/3
48 Drain Valve PS1066
49 Drain Valve Handle PS1695
50 Lid Valve Assembly PS1127
(4 HD) (6 HD)
(4 HD) (6 HD)
PS1026 PS1684
PS1322 PS1678
51 Lid Valve Spring PS1028/3
52 Lid Valve Body
53 Lid Valve Retainer PS1057
54 Lid Valve O' Ring PS1010/3
55 Lid Lock
56 Handle Bar
To order parts, contact your Winston representative or call the International office:
(800) 234-5286 USA & Canada/USA TEL: (502) 495-5400/USA FAX: (502) 495-5458
(Pressure Lock)
(Pressure Lock)
Winston Products Co.
12
Ref. Only
PS1449
PS1168
Reference
Number
WINSTON COLLECTRAMATIC FRYER
Parts Identification
Part Description Order Number
57 Vent Block Assembly
Vent Block Assembly
58 Vent Tube O'Ring PS1005/3
59 Vent Block Nut Plate PS1704/6
60 Clamshell Basket
Clamshell Basket
61 Lid Gasket PS1891/3/12/50
62 Black Nylon Brush PS1025/1
63 White Teflon Brush PS1120/1/12
64 Drain Valve Extension PS1211
(4 HD) (6 HD)
(4 HD) (6 HD)
PS1026 PS1684
PS1159 PS1163
65 Drain Hook With Handles PS1154/1/6
66 Plugging Tool PS1179/1
67 Displacer Tool PS1209/1
NOTE: See pages 1 - 8
for Photo Reference
Lit. #4275R83 - 9/96
To order parts, contact your Winston representative or call the International office:
Winston Products Co.
(800) 234-5286 USA & Canada/USA TEL: (502) 495-5400/USA FAX: (502) 495-5458
13
