Whirlpool XBTB1064 Specifications

Portable

Air Conditioners

• Electronic touch controls

• Cooling, Fan, and

Dehumidification modes

• Auto sleep mode

• Power Failure Auto

Restart

MODEL

PERFORMANCE

BTU Performance (Cooling)
Control Type
EER
ENERGY STAR®
Dehumidication (Pts/Hr)
Adjustable Thermostat Control
Refrigerant Type

ELECTRICAL RATINGS

Voltage / 60 Hz
Amps
Watts (Cooling)

• Temperature display on

the unit 24-hour on/off
settings

• Evaporator frost control

• Wireless remote control

• Included trim kit masks

WHAP081BWC WHAP101BWC WHAP131BWC WHAP13HBWC

8,000 10,000 13,000 13,000

Electronic Electronic Electronic Electronic

10.2 10 10.5 10.3

No No No No

2.5 2.6 2.92 2.83

Yes Ye s Yes Yes

R410A R410A R410A R410A

115 V 115 V 115 V 115 V

3.9 4.3 5.8 7.3

930 1,050 1,250 1,250

FEATURES

Air Direction
Remote Controller
Power Failure Auto Restart
Energy Saver
Timer
Filter Alarm Function

Cooling Speeds

Fan Only
Outdoor Vent / Exhaust
Removable Filter
dBA

DIMENSIONS / WEIGHT

Product Dimensions (in.)
Product Weight (lb.)
Shipping Dimensions (in.)
Shipping Weight (lb.)
UPC Code

8-way 8-way 8-way 8-way

Yes Ye s Yes Yes

Yes Ye s Yes Yes

Yes Ye s Yes Yes

Yes Ye s Yes Yes

Yes Ye s Yes Yes

High, Medium, Low High, Medium, Low High, Medium, Low High, Medium, Low

Yes Ye s Yes Yes

Louvers Louvers Louvers Louvers

Yes Ye s Yes Yes

56 56 54.3 54.5

16.57 x 27.9 x 13.8 16.57 x 27.9 x 13.8 18.7 x 27.9 x 15.16 18.7 x 27.9 x 15.16

61 63 75 76

18.5 x 34.84 x 15.16 18.5 x 34.84 x 15.16 21 x 34.84 x 17.1 21 x 34.84 x 17.1

71 73 86 87

192487249307 192487249338 192487249321 192487249420

WARRANTY: 1-year full system, parts and labor.
