Whirlpool WRS950SIAM01 Owner’s Manual
THANK YOU for purchasing this high-quality product. If you should experience a problem not covered in TROUBLESHOOTING or
REFRIGERATOR
USER INSTRUCTIONS
W10416734C
PROBLEM SOLVER, please visit our website at www.whirlpool.com for additional information. If you still need assistance, call us
at 1-800-253-1301. In Canada, visit our website at www.whirlpool.ca or call us at 1-800-807-6777.
You will need your model and serial number, located on the inside wall of the refrigerator compartment.
Para obtener acceso a “Instrucciones para el usuario del refrigerador” en español, o para obtener información adicional acerca de
su producto, visite: www.whirlpool.com.
Necesitará su número de modelo y de serie, ubicado en el interior del compartimiento del refrigerador.
Table of Contents / Table des matières
REFRIGERATOR SAFETY.....................................................................2
Proper Disposal of Your Old Refrigerator...........................................3
INSTALLATION INSTRUCTIONS .........................................................3
Unpack the Refrigerator......................................................................3
Door Removal, Leveling and Alignment .............................................4
Handle Installation and Removal........................................................6
Location Requirements.......................................................................7
Electrical Requirements......................................................................8
Water Supply Requirements...............................................................8
Connect Water Supply........................................................................9
Install Air Filter...................................................................................11
Install Produce Preserver..................................................................11
REFRIGERATOR USE .........................................................................12
Using the Controls ............................................................................12
Convertible Drawer Temperature Control ........................................14
Crisper Humidity Control ..................................................................14
Chilled Door Bin ................................................................................14
Water and Ice Dispensers.................................................................14
Ice Maker and Storage Bin ...............................................................17
Water Filtration System.....................................................................18
REFRIGERATOR CARE.......................................................................18
Cleaning ............................................................................................18
Lights.................................................................................................19
Vacation and Moving Care ...............................................................19
PROBLEM SOLVER.............................................................................20
ACCESSORIES ....................................................................................24
WATER FILTER CERTIFICATIONS ....................................................24
PERFORMANCE DATA SHEET..........................................................25
WARRANTY..........................................................................................26
SÉCURITÉ DU RÉFRIGÉRATEUR .....................................................27
Mise au rebut appropriée de votre vieux réfrigérateur..................... 28
INSTRUCTIONS D'INSTALLATION ...................................................28
Déballage du réfrigérateur ................................................................ 28
Retrait, réglage de l'aplomb et alignement des portes.................... 29
Installation et démontage des poignées ..........................................32
Exigences d'emplacement ............................................................... 33
Spécifications électriques................................................................. 33
Spécifications de l’alimentation en eau............................................ 33
Raccordement de la canalisation d'eau...........................................34
Installation du filtre à air....................................................................36
Installation du sachet de conservation pour produits frais.............. 37
UTILISATION DU RÉFRIGÉRATEUR................................................. 38
Utilisation des commandes .............................................................. 38
Commande de température dans le tiroir convertible ..................... 40
Réglage de l'humidité dans le bac à légumes ................................. 40
Compartiment fraîcheur dans la porte .............................................40
Distributeurs d’eau et de glaçons..................................................... 40
Machine à glaçons et bac d'entreposage........................................43
Système de filtration de l'eau ........................................................... 44
ENTRETIEN DU RÉFRIGÉRATEUR ................................................... 45
Nettoyage..........................................................................................45
Lampes ............................................................................................. 45
Entretien avant les vacances ou lors d’un déménagement............. 45
RÉSOLUTION DE PROBLÈMES ........................................................46
ACCESSOIRES ....................................................................................52
FEUILLE DE DONNÉES SUR LA PERFORMANCE..........................53
GARANTIE............................................................................................ 54
REFRIGERATOR SAFETY
You can be killed or seriously injured if you don't immediately
You
can be killed or seriously injured if you don't
follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
IMPORTANT SAFETY INSTRUCTIONS
WARNING:
To reduce the risk of fire, electric shock, or injury when using your refrigerator, follow these basic precautions:
SAVE THESE INSTRUCTIONS
■ Plug into a grounded 3 prong outlet.
■ Do not remove ground prong.
■ Do not use an adapter.
■ Do not use an extension cord.
■ Disconnect power before servicing.
■ Replace all parts and panels before operating.
■ Remove doors from your old refrigerator.
■ Use nonflammable cleaner.
■ Keep flammable materials and vapors, such as gasoline,
away from refrigerator.
■ Use two or more people to move and install refrigerator.
■ Disconnect power before installing ice maker (on ice maker
kit ready models only).
■ Use a sturdy glass when dispensing ice (on some models).
■ Do not hit the refrigerator glass doors (on some models).
State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the State of California to cause cancer.
WARNING: This product contains one or more chemicals known to the State of California to cause birth defects or other
reproductive harm.
2
Proper Disposal of
WARNING
Suffocation Hazard
Remove doors from your old refrigerator.
Failure to do so can result in death or brain damage.
Important information to know about disposal of
refrigerants:
Dispose of refrigerator in accordance with Federal and Local
regulations. Refrigerants must be evacuated by a licensed,
EPA certified refrigerant technician in accordance with
established procedures.
WARNING
Excessive Weight Hazard
Use two or more people to move and install
refrigerator.
Failure to do so can result in back or other injury.
When Moving Your Refrigerator:
Your refrigerator is heavy. When moving the refrigerator for
cleaning or service, be sure to cover the floor with
cardboard or hardboard to avoid floor damage. Always pull
the refrigerator straight out when moving it. Do not wiggle or
“walk” the refrigerator when trying to move it, as floor
damage could occur.
Important information to know about glass shelves
and covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
Tempered glass is designed to shatter into many small,
pebble-size pieces. This is normal. Glass shelves and covers
are heavy. Use both hands when removing them to avoid
dropping.
Your Old Refrigerator
IMPORTANT: Child entrapment and suffocation are not problems
of the past. Junked or abandoned refrigerators are still dangerous,
even if they will sit for “just a few days.” If you are getting rid of
your old refrigerator, please follow these instructions to help
prevent accidents.
Before You Throw Away Your Old Refrigerator or Freezer:
■ Take off the do ors .
■ Leave the shelves in place so that children may not easily
climb inside.
INSTALLATION INSTRUCTIONS
Unpack the Refrigerator
Remove packaging materials. Do not use sharp instruments,
rubbing alcohol, flammable fluids, or abrasive cleaners to remove
tape or glue. These products can damage the surface of your
refrigerator. For more information, see “Refrigerator Safety.”
3
Door Removal, Leveling and Alignment
WARNING
Electrical Shock Hazard
Disconnect power before removing doors.
Failure to do so can result in death or electrical shock.
2A
Water Dispenser
Tubing Connection
(Style 1)
A. Face of Fitting
A
1
Base Grille
3
Wiring Connection
Bottom Hinges
(Left and Right)
7
B. Routing
Plate
A
C. Electrical
Housing
A. P-clamp D. Wiring Clip
F. Wiring
Plugs
E. Grommets
5
Door Removal
DCBA
4
Top Left Hinge
A. Do Not Remove Screws.
AAA
6
A. Do Not Remove Screws.
Top Right Hinge
Leveling
8
A. Bottom Hinge
B. Leveler Bracket
C. Leveling Foot
Door Alignment
(Bottom Right Hinge)
9
A. Alignment Screw
A
A
Lower
Raise
A
A
Raise Lower
A
B
C
FE
Doors must be
open to 90˚
2B
Water Dispenser Tubing
Connection (Style 2)
Gather the required tools and parts and read all instructions before starting installation. Save these instructions for future reference.
NOTE: Before moving your product into your home, measure the doorway of your home to see whether you need to remove the
refrigerator and freezer doors. If door removal is necessary, see the instructions below.
IMPORTANT: Before you begin, turn the refrigerator control OFF or turn cooling off. Unplug refrigerator or disconnect power. Remove
food, the ice storage bin (on some models), and any adjustable door or utility bins from doors.
TOOLS NEEDED:
Bubble level, Phillips screwdriver, ³⁄₁₆" hex key, ¹⁄₄" hex-head socket wrench, ¹⁄₄" and ⁵⁄₁₆" open-ended wrenches or adjustable wrench,
internal star drive or ³⁄₈" hex-head socket wrench
4
Remove the Doors
WARNING
Electrical Shock Hazard
Disconnect power before removing doors.
Failure to do so can result in death or electrical shock.
WARNING
Excessive Weight Hazard
Use two or more people to lift the freezer door.
Failure to do so can result in back or other injury.
WARNING
Excessive Weight Hazard
Use two or more people to lift the freezer door.
Failure to do so can result in back or other injury.
1. Unplug refrigerator or disconnect power.
2. Open both doors to 90°. Remove the base grille by removing
the two screws, then pulling out on the outside corners. See
Graphic 1.
NOTE: The doors must only be opened to 90°. If they are
opened all the way, the base grille will not come off.
3. Disconnect the water tubing, located behind the base grille on
the freezer door side. The dispenser tubing runs through the
door hinge, and must be disconnected in order to remove the
door.
■ Style 1: Press the colored outer ring against the face of
fitting and pull the water tubing free. See Graphic 2A.
NOTE: Keep the water tubing connector attached to the
tube that runs underneath the freezer. The door cannot be
removed if the connector is still attached to the tube that
runs through the door hinge.
■ Style 2: Firmly pull on the clasp to release the tube, then
pull the water tubing free. See Graphic 2B.
NOTE: Keep the clasp attached to the tube that runs
underneath the freezer.
4. Disconnect the wiring, located behind the base grille on the
freezer door side. See Graphic 3.
■ Remove the P-clamp using a ¹⁄₄" hex-head socket wrench.
Remove the small wiring bundle from the P-clamp.
■ Remove the wiring clip using a ¹⁄₄" hex-head socket
wrench.
■ Pull the electrical housing out from under the refrigerator.
Disconnect the wiring plugs from the housing.
■ Gently pull the large wiring bundle (with two white plugs)
through the routing plate.
5. Close both doors and keep them closed until you are ready to
lift them free from the cabinet.
6. Use a ³⁄₁₆" hex key to remove the top left hinge screws as
shown. See Graphic 4.
IMPORTANT: Do not remove either screw A.
7. Lift freezer door straight up off bottom hinge. See Graphic 5.
The water tubing and wiring remain attached to the freezer
door and pull through the bottom left hinge.
NOTE: This may require two people - one to lift the door and
another to feed the water tubing and wiring through the hinge.
Be sure the hole in the hinge is clear of obstructions, then
gently pull one water tube through the hinge. (Avoid kinking
the tube.) Next, gently pull the other water tube through the
hinge, again avoiding kinks. Finally, gently pull the wiring
bundle (including the grommet and wiring plugs) through the
hinge.
IMPORTANT: Rest the door on its side on a soft, clean
surface, such as a towel, blanket or piece of cardboard. This
will help avoid damaging the door, water tubing and wiring.
8. Use a ³⁄₁₆" hex key to remove the top right hinge screws as
shown. See Graphic 6.
IMPORTANT: Do not remove either screw A.
9. Lift the refrigerator door straight up off bottom hinge.
IMPORTANT: Rest the door on its side on a soft, clean
surface, such as a towel, blanket or piece of cardboard. This
will help avoid damaging the door.
10. It may not be necessary to remove the bottom hinges to move
the refrigerator through a doorway. Both bottom hinges have
similar construction.
■ If necessary, use an internal star drive or a ³⁄₈" hex-head
socket wrench to remove the bottom hinges. See
Graphic 7.
IMPORTANT: The leveler brackets are mounted behind
the hinges. If you remove the hinges, make sure that the
leveler brackets are replaced when reinstalling the hinges.
Replace the Doors and Hinges
1. Replace both bottom hinges, if removed. Make sure that the
leveler brackets are assembled behind the hinges. Tighten
screws.
IMPORTANT: When the screws are tightened properly, there
should not be any gaps between the refrigerator, leveler
bracket and hinge.
NOTE: There are two wiring bundles that run underneath the
freezer - a large bundle with a large grommet and two white plugs
at the end, and a small bundle with a small grommet and one
yellow plug at the end.
2. Before replacing the freezer door on the bottom left hinge,
feed the small wiring bundle through the hinge. Assistance
may be needed.
IMPORTANT: Do not feed the large wiring bundle through the
hinge. This bundle is intended to run directly from the door to
the connections beneath the freezer. Forcing the large bundle
through the hinge may damage the door and/or the wiring,
and will keep the door from closing properly.
3. Feed both water tubes through the bottom left hinge, then
replace the freezer door on the hinge. Assistance may be
needed.
NOTE: Provide additional support for the doors while the top
hinges are being replaced. Do not depend on the door magnets to
hold the doors in place while you are working.
4. Align and replace the top left hinge as shown. See Graphic 4.
Tighten screws.
5
5. Reconnect water tubing and wiring.
A
B
IMPORTANT: Do not intertwine the water tubing and wiring
bundles when reconnecting them.
■ Water Connection Style 1: Push the larger ⁵⁄₁₆" (7.94 mm)
water tube into the blue fitting until it stops, then push the
smaller ¹⁄₄" (6.35 mm) water tube into the green fitting until
it stops. See Graphic 2A.
Water Connection Style 2: Push the black water tube
with the blue tip into the blue fitting until it stops. Close
the clasp around the tubing, making sure it snaps into
place. Repeat this process to connect the red-tipped
black water tube and the red fitting. See Graphic 2B.
■ Reinstall the P-clamp around the small wiring bundle (with
one yellow plug), then replace the P-clamp on the top
screw hole of the routing plate. See Graphic 3.
■ Gently route the large wiring bundle (with two white plugs)
through the hole in the routing plate, so that the wiring
runs behind the right side of the routing plate. See
Graphic 3.
NOTE: The large wiring bundle should always remain
below the small wiring bundle.
■ Reconnect the wiring plugs to the electrical housing, then
push the housing back under the refrigerator. Align the left
hole in the front lip of the housing with the right hole in the
refrigerator's base crossbar. See Graphic 3.
■ Reinstall the wiring clip over the grommets. First install the
smaller grommet into the top of the clip, then install the
larger grommet into the bottom of the clip (closest to the
screw hole). See Graphic 3.
■ Align the clip's screw hole with the left hole in the electrical
housing and the right hole in the crossbar, and screw in
the clip using a single screw. Tighten screw. See
Graphic 3.
IMPORTANT: Once connected, the wiring bundles should
not be taut. Some flexibility is needed to allow the freezer
door to open properly.
6. Replace the refrigerator door by lifting the door onto the
bottom right hinge.
7. Align and replace the top right hinge as shown. See Graphic 6.
Tighten screws.
8. Replace the ice storage bin (on some models) and any
adjustable door or utility bins.
9. Plug refrigerator into a grounded 3 prong outlet.
Leveling and Door Closing
5. Use a bubble level to check the leveling of the refrigerator.
NOTE: Whenever you need to move the refrigerator, turn the
leveling feet to the right until they are no longer touching the
ground. This will allow the refrigerator to roll more easily.
Door Alignment
A refrigerator that is not level from side-to-side may appear to
have doors that are not properly aligned. If the doors appear this
way, use the instructions in the previous section to check the
leveling.
The doors are designed to be slightly different heights when the
refrigerator is empty, in order to account for the weight of food
that will be placed on the doors. If the doors are still not aligned
after checking the leveling and loading the refrigerator with food,
follow the steps below to adjust the door alignment.
1. If necessary, open both doors to 90° and remove the base
grille. See Graphic 1.
2. Locate the alignment screw on the bottom hinge of the
refrigerator door. See Graphic 9.
3. Use a ⁵⁄₁₆" open-ended or adjustable wrench to turn the screw.
To raise the refrigerator door, turn the screw to the right. To
lower the door, turn the screw to the left.
4. Check that the doors are even at the top. If necessary,
continue to turn the alignment screw until the doors are
aligned.
5. Open both doors to 90°. Replace the base grille. See
Graphic 1.
Handle Installation and Removal
Style 1 - Setscrews
PARTS INCLUDED: Door handles (2), ¹⁄₈" hex key, spare
setscrew(s)
To Install the Handles:
NOTE: The handle mounting setscrews are preinstalled in the
handle.
1. Remove the handles, which are packed inside the refrigerator.
NOTE: To avoid scratching the finish, place the handles on a
towel or other soft surface.
2. Open the freezer door. On the refrigerator door, place the
handle on the shoulder screws with the setscrews facing the
freezer.
Your refrigerator has two adjustable front feet — one on the right
and one on the left. In most cases, the refrigerator should be
steady when both feet are touching the floor. If your refrigerator
seems unsteady or if you want the doors to close more easily,
adjust the refrigerator's tilt using the instructions below:
1. Move the refrigerator into its final location. If necessary, open
both doors to 90° and remove the base grille. See Graphic 1.
2. The two leveling feet are located on the brackets on each side
of the product. See Graphic 8.
NOTE: Having someone push against the top of the refrigerator
takes some weight off the leveling feet. This makes it easier to
make adjustments.
3. Use a ¹⁄₄" open-ended or adjustable wrench to adjust the
leveling feet. Turn the leveling foot to the left to raise that side
of the product, or turn it to the right to lower that side of the
product.
4. Open both doors again and check that they close as easily as
you like. If not, tilt the refrigerator slightly more to the rear by
turning the leveling feet to the left. It may take several more
turns, and you should turn both leveling feet the same
amount.
3. Firmly push the handle toward the door until the handle base
is flush against the door.
A. Shoulder screws
B. Setscrews inside the handle
6
4. While holding the handle, insert the short end of the hex key
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or fire.
1
/
2" (1.27 cm)
2" (5.08 cm)
into the upper hole and slightly rotate the hex key until it is
engaged in the setscrew.
5. Using a clockwise motion, tighten the setscrew until it begins
to contact the shoulder screw.
6. Repeat steps 4 and 5 to begin fastening the lower setscrew.
7. Once both setscrews have been partially tightened as outlined
in the previous steps, fully tighten both the upper and lower
setscrews.
IMPORTANT: When the screws feel tight, tighten them an
additional quarter-turn. The handle is not properly installed
without this extra tightening.
8. Open the refrigerator door and close the freezer door. Repeat
steps 2 through 7 to install the other handle onto the freezer
door with the setscrews facing the refrigerator.
9. Save the hex key and all instructions.
3. Repeat the previous steps to install the refrigerator door
handle.
4. Save all instructions.
To Remove the Handles:
1. Lift the handle directly upward, and pull it off of the door.
2. If necessary, use a Phillips screwdriver to remove the shoulder
screws from the door.
NOTE: Some models have mounting brackets connected to
the shoulder screws.
Location Requirements
To Remove the Handles:
1. While holding the handle, insert the short end of the hex key
into the lower setscrew hole and slightly rotate the hex key
until it is engaged in the setscrew.
2. Using a counterclockwise motion, loosen the setscrew a
quarter-turn at a time.
3. Repeat steps 1 and 2 for the upper setscrew. Gently pull the
handle away from the door.
4. If necessary, use a Phillips screwdriver to remove the shoulder
screws from the door.
Style 2 - Slide-on
PARTS INCLUDED: Door handles (2)
To Install the Handles:
1. Remove the handles, which are packed inside the refrigerator.
NOTE: To avoid damaging the handles, place them on a towel
or other soft surface.
2. Place the handle on the shoulder screws, which are mounted
on the freezer door. Apply firm pressure on the handle to slide
it down onto the shoulder screws.
NOTE: Do not push the handle toward the door; this can
damage the door. Apply only downward pressure.
IMPORTANT: This refrigerator is designed for indoor household
use only.
To ensure proper ventilation for your refrigerator, allow for ¹⁄₂"
(1.27 cm) of space on each side and at the top. Allow for 1"
(2.54 cm) of space behind the refrigerator. If your refrigerator has
an ice maker, allow extra space at the back for the water line
connections. When installing your refrigerator next to a fixed wall,
leave a 2" (5.08 cm) minimum space on each side (depending on
your model) to allow the doors to swing open.
7
NOTES:
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
■ This refrigerator is intended for use in a location where the
temperature ranges from a minimum of 55°F (13°C) to a
maximum of 110°F (43°C). The preferred room temperature
range for optimum performance, which reduces electricity
usage and provides superior cooling, is between 60°F (15°C)
and 90°F (32°C). It is recommended that you do not install the
refrigerator near a heat source, such as an oven or radiator.
■ Normal minimum cabinet cut-out width required for product
installation is 36" (91.44 cm). However, if the product is placed
against an extended wall and the ability to remove the crisper
pans is desired, an additional 18" (45.72 cm) of cabinet width
is required, so a total cabinet opening width of 54"
(137.16 cm) is recommended.
Electrical Requirements
Before you move your refrigerator into its final location, it is
important to make sure you have the proper electrical connection.
Recommended Grounding Method
A 115 volt, 60 Hz, AC only, 15- or 20-amp fused, grounded
electrical supply is required. It is recommended that a separate
circuit serving only your refrigerator be provided. Use an outlet
that cannot be turned off by a switch. Do not use an
extension cord.
NOTE: Before performing any type of installation or cleaning, or
removing a light bulb, turn cooling off or turn the control
(Thermostat, Refrigerator or Freezer Control depending on the
model) to OFF, and then disconnect the refrigerator from the
electrical source. When you are finished, reconnect the
refrigerator to the electrical source and turn cooling on or reset the
control (Thermostat, Refrigerator or Freezer Control depending on
the model) to the desired setting. See “Using the Controls” in the
User Instructions, User Guide, or Use & Care Guide.
Water Supply Requirements
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
TOOLS NEEDED:
■ Flat-blade screwdriver
■ ⁷⁄₁₆" and ¹⁄₂" Open-end or two
adjustable wrenches
NOTE: Your refrigerator dealer has a kit available with a ¹⁄₄"
(6.35 mm) saddle-type shutoff valve, a union, and copper tubing.
Before purchasing, make sure a saddle-type valve complies with
your local plumbing codes. Do not use a piercing-type or ³⁄₁₆"
(4.76 mm) saddle valve which reduces water flow and clogs more
easily.
IMPORTANT:
■ All installations must meet local plumbing code requirements.
■ Use copper tubing and check for leaks. Install copper tubing
only in areas where the household temperatures will remain
above freezing.
Water Pressure
A cold water supply with water pressure of between 30 and
120 psi (207 and 827 kPa) is required to operate the water
dispenser and ice maker. If you have questions about your water
pressure, call a licensed, qualified plumber.
■ If your refrigerator has a water dispenser: After installation is
complete, use the water dispenser to check the water
pressure.
■ With the water filter removed, dispense 1 cup (237 mL) of
water. If 1 cup of water is dispensed in 8 seconds or less,
the water pressure to the refrigerator meets the minimum
requirement.
■ If it takes longer than 8 seconds to dispense 1 cup of
water, the water pressure to the refrigerator is lower than
recommended. See “Problem Solver” for suggestions.
Reverse Osmosis Water Supply
IMPORTANT: The pressure of the water supply coming out of a
reverse osmosis system going to the water inlet valve of the
refrigerator needs to be between 30 and 120 psi (207 and
827 kPa).
If a reverse osmosis water filtration system is connected to your
cold water supply, the water pressure to the reverse osmosis
system needs to be a minimum of 40 to 60 psi (276 to 414 kPa).
If the water pressure to the reverse osmosis system is less than
40 to 60 psi (276 to 414 kPa):
■ Check to see whether the sediment filter in the reverse
osmosis system is blocked. Replace the filter if necessary.
■ Allow the storage tank on the reverse osmosis system to refill
after heavy usage.
■ If your refrigerator has a water filter, it may further reduce the
water pressure when used in conjunction with a reverse
osmosis system. Remove the water filter. See “Water Filtration
System” in the User Instructions, User Guide, or Use & Care
Guide.
If you have questions about your water pressure, call a licensed,
qualified plumber.
■ ¹⁄₄" Nut driver
■ ¹⁄₄" Drill bit
■ Cordless drill
8
Connect Water Supply
A
B
D
C
B CA
A
B
C
DEF
G
Read all directions before you begin.
IMPORTANT:
■ Plumbing shall be installed in accordance with the
International Plumbing Code and any local codes and
ordinances.
■ The gray water tubing on the back of the refrigerator (which is
used to connect to the household water line) is a PEX
(cross-linked polyethylene) tube. Copper and PEX tubing
connections from the household water line to the refrigerator
are acceptable, and will help avoid off-taste or odor in your ice
or water. Check for leaks.
If PEX tubing is used instead of copper, we recommend the
following Whirlpool Part Numbers:
W10505928RP (7 ft [2.14 m] jacketed PEX),
8212547RP (5 ft [1.52 m] PEX), or
W10267701RP (25 ft [7.62 m] PEX).
■ Install tubing only in areas where temperatures will remain
above freezing.
TOOLS NEEDED:
Gather the required tools and parts before starting installation.
■ Flat-blade screwdriver
■ ⁷⁄₁₆" and ¹⁄₂" open-end wrenches or two adjustable wrenches
■ ¹⁄₄" nut driver
Connect to Water Line
IMPORTANT: If you turn the refrigerator on before the water line is
connected, turn the ice maker OFF.
Style 1 (Recommended)
1. Unplug refrigerator or disconnect power.
2. Turn OFF main water supply. Turn ON nearest faucet long
enough to clear line of water.
3. Use a quarter-turn shutoff valve or the equivalent, served by a
¹⁄₂" copper household supply line.
NOTE: To allow sufficient water flow to the refrigerator, a
minimum ¹⁄₂" size copper household supply line is
recommended.
A. Compression sleeve
B. Compression nut
C. Copper tubing
5. Place the free end of the tubing into a container or sink, and
turn on main water supply to flush out tubing until water is
clear. Turn off shutoff valve on the water pipe.
NOTE: Always drain the water line before making the final
connection to the inlet of the water valve, to avoid possible
water valve malfunction.
6. Bend the copper tubing to meet the water line inlet, which is
located on the back of the refrigerator cabinet as shown.
Leave a coil of copper tubing to allow the refrigerator to be
pulled out of the cabinet or away from the wall for service.
Style 2
1. Unplug refrigerator or disconnect power.
2. Turn OFF main water supply. Turn ON nearest faucet long
enough to clear line of water.
3. Locate a
pipe near the refrigerator.
IMPORTANT:
■ Make sure it is a cold water pipe.
■ Horizontal pipe will work, but drill on the top side of the
4. Determine the length of copper tubing you need. Measure
from the connection on the lower rear corner of refrigerator to
the water pipe. Add 7 ft (2.1 m) to allow for cleaning. Use ¹⁄₄"
(6.35 mm) O.D. (outside diameter) copper tubing. Be sure both
ends of copper tubing are cut square.
5. Using a cordless drill, drill a ¹⁄₄" (6.35 mm) hole in the cold
water pipe you have selected.
¹⁄₂" (1.27 cm) to 1¹⁄₄" (3.18 cm) vertical cold water
pipe, not the bottom. This will help keep water away from
the drill and normal sediment from collecting in the valve.
A. Cold water pipe
B. Pipe clamp
C. Copper tubing
D. Compression nut
E. Compression sleeve
F. Shutoff valve
G. Packing nut
6. Fasten the shutoff valve to the cold water pipe with the pipe
clamp. Be sure the outlet end is solidly in the ¹⁄₄" (6.35 mm)
drilled hole in the water pipe and that the washer is under the
A. Bulb
B. Nut
C. Copper tubing (to refrigerator)
D. Household supply line (½" minimum)
4. Now you are ready to connect the copper tubing to the shutoff
valve. Use ¹⁄₄" (6.35 mm) OD soft copper tubing to connect the
shutoff valve and the refrigerator.
■ Ensure that you have the proper length needed for the job.
Be sure both ends of the copper tubing are cut square.
■ Slip compression sleeve and compression nut onto
copper tubing as shown. Insert end of tubing into outlet
end squarely as far as it will go. Screw compression nut
onto outlet end with adjustable wrench. Do not
overtighten.
pipe clamp. Tighten the packing nut. Tighten the pipe clamp
screws slowly and evenly so the washer makes a watertight
seal. Do not overtighten, or you may crush the copper tubing.
7. Slip the compression sleeve and compression nut on the
copper tubing as shown. Insert the end of the tubing into the
outlet end squarely as far as it will go. Screw the compression
nut onto outlet end with adjustable wrench. Do not
overtighten.
8. Place the free end of the tubing in a container or sink, and turn
ON the main water supply. Flush the tubing until water is clear.
Turn OFF the shutoff valve on the water pipe. Coil the copper
tubing.
9
Loading...
