Whirlpool WRF736SDAB14 Owner’s Manual

RENCH

OTTOM

EFRIGERATOR

OOR

OUNT

U.S.: 1-800-253-1301 C

W10859983A

WWW.WHIRLPOOL.COM WWW.WHIRLPOOL.CA

& C

ARE

ANAD A

UIDE

: 1-800-807-6777

TABLE OF CONTENTS

Congratulations on your purchase and welcome to the Whirlpool Brand family of high-quality appliances. Your new Whirlpool® French Door Refrigerator combines advanced cooling technology with simple operation and high efficiency.

Each appliance that leaves our factory is inspected thoroughly to ensure that it is working properly.

REFRIGERATOR SAFETY.......................................................3

Proper Disposal of Your Old Refrigerator.............................. 3

PARTS AND FEATURES..........................................................4

What’s New Behind the Doors?............................................. 4

INSTALLATION INSTRUCTIONS............................................5

Unpack the Refrigerator..

- Remove the Packaging.........................................................5

- Clean Before Using...............................................................5

Location Requirements..........................................................5

Remove and Replace Refrigerator Doors..............................6

- Remove Right-Hand Refrigerator Door................................7

- Remove Left-Hand Refrigerator Door ..................................7

- Replace Right-Hand Refrigerator Door..

- Replace Left-Hand Refrigerator Door...................................8

- Final Steps ............................................................................8

Remove and Replace Freezer Drawer Front .........................9

- Remove Drawer Front...........................................................9

- Replace Drawer Front...........................................................9

- Final Steps ............................................................................9

Electrical Requirements....................................................... 10

Water Supply Requirements................................................ 10

Connect the Water Supply................................................... 11

- Connect to Water Line........................................................11

- Connect to Refrigerator......................................................11

- Complete the Installation....................................................12

Handle Installation and Removal.........................................12

- Install Handles.....................................................................12

- Remove the Handles ..........................................................13

Refrigerator Leveling, Door Closing and Alignment............ 14

FILTERS AND ACCESSORIES.............................................. 15

Water Filtration System........................................................15

- Install the Water Filter .........................................................15

- The Water Filter Status Light ..............................................15

- Replace the Water Filter .....................................................16

Install Air Filter......................................................................16

- Installing the Air Filter..........................................................16

- Installing the Filter Status Indicator ....................................16

- Replacing the Air Filter........................................................17

Install Produce Preserver.....................................................17

- Installing the Produce Preserver ........................................17

- Installing the Status Indicator .............................................18

- Replacing the Produce Preserver.......................................18

Accessories..........................................................................18

REFRIGERATOR USE............................................................19

Opening and Closing Doors.................................................19

Using the Controls .......................

- Viewing and Adjusting Temperature Set Points.................19

- Cooling On/Off....................................................................20

- Options................................................................................20

....................................................... 5

..............................8

........................................19

Please read the Use and Care Instructions in this guide before operating your new refrigerator. Like all appliances, your refrigerator may require maintenance or repair from time to time, but you can help to ensure that your refrigerator provides many years of reliable service by following the instructions in this guide.

- Additional Features .............................................................21

Water and Ice Dispensers....................................................21

- Flush the Water System......................................................22

- Ca

librate Measured Fill .......................................................22

- Dispensing...........................................................................23

- The Water Dispenser...........................................................23

- The Ice Dispenser ...............................................................24

- The Dispenser Light............................................................24

- The Dispenser Lock .....................................................

Ice Maker and Ice Storage Bin.............................................25

- Ice Production Rate ............................................................25

- Style 1 - Ice Maker in the Refrigerator................................25

- Style 2 - Ice Maker in the Freezer .......................................25

REFRIGERATOR FEATURES................................................26

Refrigerator Shelves....................................................

- Shelves and Shelf Frames ..................................................26

- Tuck Away Shelf..................................................................26

Crisper Drawers/Pantry Drawer/Crisper Cover ...................26

Crisper Humidity Control......................................................27

Temperature-Controlled Drawer ..........................................27

- Style 1 - Electronic Control.................................................27

- Style 2 - Manual Control .....................................................27

- Drawer Removal and Replacement....................................28

- Drawer Divider.....................................................................28

- Meat Storage Guide............................................................28

DOOR FEATURES..................................................................28

Door Bins..............................

................................................28

FREEZER FEATURES ............................................................28

Pizza Pocket and Drawer Divider.........................................28

REFRIGERATOR CARE .........................................................29

Cleaning................................................................................29

- Exterior Cleaning.................................................................29

- Interior Cleaning..................................................................29

- Condenser Cleaning ...........................................................30

Lights....................................................................................30

Vacation and Moving Care...................................................30

- Vacations.............................................................................30

- Moving.................................................................................30

TROUBLESHOOTING ............................................................31

Operation..............................................................................31

Noise.....................................................................................32

Temperature and Moisture.................................

..................33

Ice and Water .......................................................................34

Doors ....................................................................................36

PERFORMANCE DATA SHEET...................................

WARRANTY ............................................................................39

SERVICE NUMBERS......................................

....BACK COVER

.......24

.........26

..........38

REFRIGERATOR SAFETY

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages.

This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”

These words mean:

You can be killed or seriously injured if you don't immediately

DANGER

WARNING

All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed.

IMPORTANT SAFETY INSTRUCTIONS

WARNING:

Plug into a grounded 3 prong outlet. Do not remove ground prong. Do not use an adapter. Do not use an extension cord. Disconnect power before servicing. Replace all parts and panels before operating. Remove doors from your old refrigerator. Connect to a potable water supply only.

Use nonflammable cleaner. Keep flammable materials and vapors, such as gasoline,

away from refrigerator.

Use two or more people to move and install refrigerator.

To reduce the risk of fire, electric shock, or injury when using your refrigerator, follow these basic precautions:

follow instructions.

You

can be killed or seriously injured if you don't

instructions.

Disconnect power before installing ice maker (on ice maker

kit ready models only).

Use a sturdy glass when dispensing ice (on some models). Do not hit the refrigerator glass doors (on some models). This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not

play with the appliance.

SAVE THESE INSTRUCTIONS

State of California Proposition 65 Warnings: WARNING: This product contains one or more chemicals known to the State of California to cause cancer. WARNING: This product contains one or more chemicals known to the State of California to cause birth defects or other

reproductive harm.

Proper Disposal of

Your Old Refrigerator

WARNING

Suffocation Hazard Remove doors from your old refrigerator. Failure to do so can result in death or brain damage.

IMPORTANT: Child entrapment and suffocation are not problems of the past. Junked or abandoned refrigerators are still dangerous – even if they will sit for “just a few days.” If you are getting rid of your old refrigerator, please follow these instructions to help prevent accidents.

Before You Throw Away Your Old Refrigerator or Freezer:

Take off the doors. Leave the shelves in place so that

children may not easily climb inside.

Important information to know about disposal of refrigerants:

Dispose of refrigerator in accordance with Federal and Local regulations. Refrigerants must be evacuated by a licensed, EPA certified refrigerant technician in accordance with established procedures.

PARTS AND FEATURES

BA C

A. Ice maker B. Air filter C. Water filter D. Door bins E. Crispers

F. Pantry drawer G. Freezer drawer H. LED ramp-on lighting

I. In-Door-Ice

dispensing system

ice

What’s New Behind the Doors?

Your Whirlpool® French Door Refrigerator comes equipped with various

innovative storage and energy efficient features.

Energy and Normal Operating Sounds

Your new French Door Bottom Mount refrigerator has been designed to optimize energy efficiency, and better regulate temperatures to match cooling demand. You may notice that it operates differently from your previously owned refrigerator. It is normal for the high-efficiency compressor to run for extended periods of time at varying speeds in order to consume only the energy necessary for optimum efficiency. In addition, during various stages of the cooling cycle, you may hear normal operating sounds tha

t are unfamiliar to you.

More Storage Space

The French Door Bottom Mount has the most fresh food storage space available, including a full-width, temperature controlled, pantry drawer perfect for storing veggie trays or party platters.

In-Door-Ice® Ice Dispensing System

The ice storage bin located in the door provides an entire extra shelf of storage space, and the storage bin is removable for easy access to filtered ice.

Dual Evaporator (on some models)

The refrigerator and freezer compartments have dedicated evaporators to provide fresh and frozen foods with separate climates. Frozen food stays cold and dry, while fresh food remains at the ideal temperature and humidity.

Water Filter

NSF® Certified filter reduces chlorine taste and odor, particulates (class I), lead, and mercury. Replacing the water filter every 6 months ensures clean, filtered drinking water.

Air Filter

An air filter is 15 times more powerful than baking soda at reducing common food odors inside the refrigerator.

Produce Preserver (on some models)

Ethylene is a natural gas produced by fruits and vegetables to promote ripening. The Produce Preserver absorbs ethylene, to delay the over-ripening of fresh produce. As a result, certain produce items will stay fresh longer.

Water Dispenser with Measured Fill (on some models)

The measured fill feature allows you to dispense the desired amount of filtered water.

LED Lighting

The LED lights do not ever need to be replaced.

Door Alarm

A helpful alarm sounds when the refrigerator door or freezer drawer is left ajar.

Power Outage Indicator

If the power should go out while you are away from home, this indicator will let you know the refrigerator has been without power.

Unpack the Refrigerator

WARNING

Excessive Weight Hazard

Use two or more people to move and install refrigerator.

Failure to do so can result in back or other injury.

When Moving Your Refrigerator:

Your refrigerator is heavy. When moving the refrigerator for cleaning or service, be sure to cover the floor with cardboard or hardboard to avoid floor damage. Always pull the refrigerator straight out when moving it. Do not wiggle or “walk” the refrigerator when trying to move it, as floor damage could occur.

Important information to know about glass shelves and covers:

Do not clean glass shelves or covers with warm water when they are cold. Shelves and covers may break if exposed to sudden temperature changes or impact, such as bumping. Tempered glass is designed to shatter into many small, pebble-size pieces. This is normal. Glass shelves and covers are heavy. Use both hands when removing them to avoid dropping.

WARNING

Explosion Hazard

Keep flammable materials and vapors, such as gasoline, away from refrigerator.

Failure to do so can result in death, explosion, or fire.

3³⁄₄" (9.5 cm)

¹⁄₂" (1.25 cm)

INSTALLATION INSTRUCTIONS

Remove the Packaging

■ Remove tape and glue residue from surfaces before turning

on the refrigerator. Rub a small amount of liquid dish soap over the adhesive with your fingers. Wipe with warm water and dry.

■ Do not use sharp instruments, rubbing alcohol, flammable

fluids, or abrasive cleaners to remove tape or glue. These products can damage the surface of your refrigerator. For more information, see “Refrigerator Safety.”

■ Dispose of/recycle all packaging materials.

Location Requirements

Clean Before Using

After you remove all of the packaging materials, clean the inside of your refrigerator before using it. See the cleaning instructions in “Refrigerator Care.”

NOTE: This refrigerator is intended for use in a location where the temperature ranges from a minimum of 55°F (13°C) to a maximum of 110°F (43°C). The preferred room temperature range for optimum performance, which reduces electricity usage and provides superior cooling, is between 60°F (15°C) and 90°F (32°C). It is recommended that you do not install the refrigerator near a heat source, such as an oven or radiator.

IMPORTANT: This refrigerator is designed for indoor, household use only.

To ensure proper ventilation for your refrigerator, allow for a ¹⁄₂" (1.25 cm) of space on each side and at the top. Allow for a 1" (2.54 cm) space behind the refrigerator. If your refrigerator has an ice maker, allow extra space at the back for the water line connections. When installing your refrigerator next to a fixed wall, leave a 3³⁄₄" (9.5 cm) minimum space between the refrigerator and wall to allow the door to swing open.

INSTALLATION INSTRUCTIONS

WARNING

Electrical Shock Hazard

Disconnect power before removing doors. Failure to do so can result in death or electrical shock.

Door Removal and Replacement

Wiring Plug

Top Left Hinge

Style 1 – Water Dispenser

Tubing Connection

A. Outer Ring

A. ³⁄₁₆" Internal Hex-Head Screws B. Ground Wire (Do Not Remove) C. Do Not Remove Screws

Style 2 – Water Dispenser

Tubing Connection

A. Outer Ring

Top Right Hinge

A. ³⁄₁₆"

Internal Hex-Head Screws

B. Hinge Cover Screw C. Top Hinge Cover D. Top Hinge

Remove and Replace Refrigerator Doors

NOTE: Measure the width of your door opening, to see whether or not you need to remove the refrigerator doors to move the refrigerator into your home. If door removal is necessary, see the following instructions.

IMPORTANT: If the refrigerator was previously installed and you are moving it out of the home, before you begin, turn the refrigerator control OFF. Unplug the refrigerator or disconnect power. Remove food and adjustable door or utility bins from doors.

Gather the required tools and read all instructions before removing doors. TOOLS NEEDED: ³⁄₁₆" hex key wrench and a #2 Phillips screwdriver

INSTALLATION INSTRUCTIONS

WARNING

Electrical Shock Hazard Disconnect power before removing doors. Failure to do so can result in death or electrical shock.

WARNING

Excessive Weight Hazard Use two or more people to lift the refrigerator door. Failure to do so can result in back or other injury.

Remove Right-Hand Refrigerator Door

1. Unplug refrigerator or disconnect power.

2. Keep the refrigerator doors closed until you are ready to lift

them free from the cabinet. NOTE: Provide additional support for the refrigerator door

while the hinges are being removed. Do not depend on the door gasket magnets to hold the door in place while you are working.

3. Using a Phillips screwdriver, remove the cover from the Top

Hinge.

4. Using the ³⁄₁₆" hex key wrench, remove the two internal hex

head screws from the top hinge, and set aside. NOTE: Do not remove the two locator screws. These screws

will help you align the hinge when you replace the door.

Remove Left-Hand Refrigerator Door

IMPORTANT: The tubing and wiring for the water dispenser run through the left-hand door hinge, so they must be disconnected before removing the door.

1. Using a Phillips screwdriver, remove the cover from the top

hinge.

A. Top hinge cover screwB.Top hinge cover

2. Disconnect the water dispenser tubing located on top of the

door hinge. Style 1 - Press the outer ring against the face of the fitting

and gently pull the dispenser tubing free. NOTE: The water dispenser tubing remains attached to the

left-hand refrigerator door.

A. Top hinge cover screw

B. Top hinge cover

³⁄₁₆

" Internal hex head screws

D. Top hinge

5. Lift the refrigerator door from the bottom hinge pin. The top

hinge will come away with the door.

A. Outer ring B. Face of fitting

INSTALLATION INSTRUCTIONS

A B

Style 2 - Firmly pull up on the clasp. Then, pull the tubing out of the fitting.

NOTE: The water dispenser tubing remains attached to the left-hand refrigerator door.

3. Disconnect the wiring plug located on top of the door hinge.

■ Grasp each side of the wiring plug. With your left thumb,

press down to release the catch and pull the sections of the plug apart.

NOTE: Do not remove the green, ground wire. It should remain attached to the door hinge.

4. Using the ³⁄₁₆" hex key wrench, remove the two internal hex

head screws from the top hinge, and set aside.

NOTES:

■ Provide additional support for the refrigerator door while

the hinges are being removed. Do not depend on the door gasket magnets to hold the door in place while you are working.

■ Do not remove the two locator screws. These screws will

help you align the hinge when you replace the door.

5. Lift the refrigerator door from the bottom hinge pin. The top

hinge will come away with the door. NOTE: It may not be necessary to remove the bottom hinges

and brake feet assemblies to move the refrigerator through a doorway.

■ Only if necessary, use a driver with a #2 square bit tip to

remove the bottom hinges and a ³⁄₈" nut driver to remove the brake feet screws.

Replace Right-Hand Refrigerator Door

1. Set the right-hand door onto the bottom hinge pin.

2. Insert the top hinge pin into the open hole in the top of the

refrigerator door.

3. Using the two ³⁄₁₆" internal hex head screws, fasten the hinge

to the cabinet. Do not tighten the screws completely.

Replace Left-Hand Refrigerator Door

IMPORTANT: Do not intertwine the water tubing and wiring bundles when reconnecting them.

1. Set the left-hand door onto the bottom hinge pin.

2. Using the two ³⁄₁₆" internal hex head screws, fasten the hinge

to the cabinet. Do not tighten the screws completely.

3. Reconnect the water dispenser tubing. Style 1 - Insert the tubing into the fitting until it stops and the

outer ring is touching the face of fitting. Style 2 - Insert the tubing firmly into the fitting until it stops.

Close the clasp around the tubing. The clasp snaps into place between the fitting and the collar.

4. Reconnect the electrical wiring.

■ Push together the two sections of the wiring plug.

Final Steps

1. Completely tighten the four internal hex head screws (two on the right-hand door hinge and two on the left-hand door hinge).

2. Replace both top hinge covers.

³⁄₁₆

" Internal hex head screws

B. Ground wire (do not remove)

C.Locator screws (do not

remove)

INSTALLATION INSTRUCTIONS

Electrical Shock Hazard Plug into a grounded 3 prong outlet. Do not remove ground prong. Do not use an adapter. Do not use an extension cord. Failure to follow these instructions can result in death,

fire, or electrical shock.

WARNING

Remove and Replace Freezer Drawer Front

Depending on the width of your door opening, it may be necessary to remove the freezer drawer front to move the refrigerator into your home.

IMPORTANT:

■ If the refrigerator was previously installed and you are moving

it out of the home, before you begin, turn the refrigerator control OFF, and unplug the refrigerator or disconnect power. Remove food from the freezer drawer.

■ Two people may be required to remove and replace the

freezer drawer front.

Tool Needed: ¹⁄₄" hex driver

Remove Drawer Front

1. Open the freezer drawer to its full extension.

2. Remove the two screws at the top, inside the drawer front

(one on the left-hand side and one on the right-hand side) that fasten the drawer front to the drawer glides.

3. Lift up on the drawer front to release the plastic studs from

the drawer glide bracket slots.

Replace Drawer Front

1. Pull out the freezer drawer glides to their full extension.

2. Holding the drawer front by its sides, align the two plastic

studs, located at the bottom, inside the drawer front, with the drawer glide bracket slots.

NOTE: It helps if one person holds the drawer glides steady while another person aligns the drawer front and inserts the studs into the slots.

A. Drawer front screw B. Drawer front plastic stud

A. Drawer glide bracket slots

4. Slide the drawer glides back into the freezer.

3. Replace and tighten the two screws at the top of the drawer

front (one on the left-hand side and one on the right-hand side).

Final Steps

1. Plug into a grounded 3 prong outlet.

2. Reset the controls. See “Using the Control(s).”

3. Return all removable door parts to doors and the food to

refrigerator.

INSTALLATION INSTRUCTIONS

Electrical Shock Hazard Plug into a grounded 3 prong outlet. Do not remove ground prong. Do not use an adapter. Do not use an extension cord. Failure to follow these instructions can result in death,

fire, or electrical shock.

WARNING

Electrical Requirements

Recommended Grounding Method

A 115 volt, 60 Hz, AC only 15- or 20-amp fused, grounded electrical supply is required. It is recommended that a separate circuit serving only your refrigerator be provided. Use an outlet that cannot be turned off by a switch. Do not use an extension cord.

NOTE: Before performing any type of installation, cleaning, or removing a light bulb, turn Cooling OFF, and then disconnect the refrigerator from the electrical source. When you have finished, reconnect the refrigerator to the electrical source and turn Cooling ON. See “Using the Control(s).”

Before you move your refrigerator into its final location, it is important to make sure you have the proper electrical connection.

Water Supply Requirements

A cold water supply with water pressure between 35 and 120 psi (241 and 827 kPa) is required to operate the water dispenser and ice maker. If you have questions about your water pressure, call a licensed, qualified plumber.

NOTE: If the water pressure is less than what is required, the flow of water from the water dispenser could decrease or ice cubes could be hollow or irregular shaped.

Reverse Osmosis Water Supply

IMPORTANT: The pressure of the water supply coming out of a reverse osmosis system going to the water inlet valve of the refrigerator needs to be between 35 and 120 psi (241 and 827 kPa).

If a reverse osmosis water filtration system is connected to your cold water supply, the water pressure to the reverse osmosis system needs to be a minimum of 40 to 60 psi (276 to 414 kPa).

■ Check to see whether the sediment filter in the reverse

osmosis system is blocked. Replace the filter if necessary.

■ Allow the storage tank on the reverse osmosis system to refill

after heavy use. The tank capacity could be too small to keep up with the requirements of the refrigerator.

NOTE: Faucet mounted reverse osmosis systems are not recommended.

■ If your refrigerator has a water filter, it may further reduce the

water pressure when used in conjunction with a reverse osmosis system. Remove the water filter. See “Water Filtration System.”

If you have questions about your water pressure, call a licensed, qualified plumber.

Connect the Water Supply

A B

B CA

INSTALLATION INSTRUCTIONS

Read all directions before you begin.

IMPORTANT:

■ Plumbing shall be installed in accordance with the

International Plumbing Code and any local codes and ordinances.

■ The gray water tubing on the back of the refrigerator (which is

used to connect to the household water line) is a PEX (cross-linked polyethylene) tube. Copper and PEX tubing connections from the household water line to the refrigerator are acceptable, and will help avoid off-taste or odor in your ice or water. Check for leaks.

If PEX tubing is used instead of copper, we recommend the following Whirlpool Part Numbers: W10505928RP (7 ft [2.14 m] jacketed PEX), 8212547RP (5 ft [1.52 m] PEX), or W10267701RP (25 ft [7.62 m] PEX).

■ Install tubing only in areas where temperatures will remain

above freezing.

TOOLS NEEDED:

Gather the required tools and parts before starting installation.

■ Flat-blade screwdriver

■ ⁷⁄₁₆" and ¹⁄₂" open-end wrenches or two adjustable wrenches

■ ¹⁄₄" nut driver

NOTE: Do not use a piercing-type or ³⁄₁₆" (4.76 mm) saddle valve which reduces water flow and clogs easier.

Connect to Water Line

IMPORTANT: If you turn the refrigerator on before the water is connected, turn the ice maker OFF.

1. Unplug refrigerator or disconnect power.

2. Turn OFF main water supply. Turn ON nearest faucet long

enough to clear line of water.

3. Use a quarter-turn shutoff valve or the equivalent, served by a

¹⁄₂" household supply line. NOTE: To allow sufficient water flow to the refrigerator, a

minimum ¹⁄₂" size household supply line is recommended.

■ Ensure that you have the proper length needed for the

job. Be sure both ends of the copper tubing are cut square.

■ Slip compression sleeve and compression nut onto

copper tubing as shown. Insert end of tubing into outlet end squarely as far as it will go. Screw compression nut onto outlet end with adjustable wrench. Do not overtighten.

A. Compression sleeve B. Compression nut

C. Copper tubing

5. Place the free end of the tubing into a container or sink, and

turn on main water supply to flush out tubing until water is clear. Turn off shutoff valve on the water pipe.

NOTE: Always drain the water line before making the final connection to the inlet of the water valve, to avoid possible water valve malfunction.

6. Bend the copper tubing to meet the water line inlet, which is

located on the back of the refrigerator cabinet as shown. Leave a coil of copper tubing to allow the refrigerator to be pulled out of the cabinet or away from the wall for service.

Connect to Refrigerator

Follow the connection instructions specific to your model.

Style 1

1. Remove plastic cap from water valve inlet port. Attach the

copper tube to the valve inlet using a compression nut and sleeve as shown. Tighten the compression nut. Do not overtighten. Confirm copper tubing is secure by pulling on copper tubing.

2. Create a service loop with the copper tubing. Avoid kinks

when coiling the copper tubing. Secure copper tubing to refrigerator cabinet with a “P” clamp.

A. Sleeve B. Nut

C. Copper tubing (to refrigerator) D. Household supply line (½" minimum)

4. Now you are ready to connect the copper tubing to the

shutoff valve. Use ¹⁄₄" (6.35 mm) OD soft copper tubing to connect the shutoff valve and the refrigerator.

A. Copper tubing B. “P” clamp

C. Compression nut D. Compression sleeve

INSTALLATION INSTRUCTIONS

A B C

Electrical Shock Hazard

Plug into a grounded 3 prong outlet. Do not remove ground prong. Do not use an adapter. Do not use an extension cord. Failure to follow these instructions can result in death,

fire, or electrical shock.

WARNING

3. Turn on water supply to refrigerator and check for leaks.

Correct any leaks.

Style 2

1. Unplug refrigerator or disconnect power.

2. Remove and discard the short, black plastic part from the

end of the water line inlet.

3. Thread the nut onto the end of the tubing. Tighten the nut by

hand. Then tighten it with a wrench two more turns. Do not overtighten.

NOTE: To avoid rattling, be sure the copper tubing does not touch the cabinet’s side wall or other parts inside the cabinet.

A. Household water line B. Nut (purchased)

4. Install the water supply tube clamp around the water supply

line to reduce strain on the coupling.

5. Turn shutoff valve ON.

6. Check for leaks. Tighten any connections (including

connections at the valve) or nuts that leak.

7. On some models, the ice maker is equipped with a built-in

water strainer. If your water conditions require a second water strainer, install it in the ¹⁄₄" (6.35 mm) water line at either tube connection. Obtain a water strainer from your appliance dealer.

C. Ferrule (purchased) D. Refrigerator water tubing

Complete the Installation

1. Plug into a grounded 3 prong outlet.

2. Flush the water system. See “Water and Ice Dispensers.” NOTE: Allow 24 hours to produce the first batch of ice. Discard

the first three batches of ice produced. Allow 3 days to completely fill the ice storage bin.

Handle Installation and Removal

Parts Included: Door handles (2), Drawer handle(s) (1 or 2 depending on model), ¹⁄₈" hex key, spare setscrew(s)

NOTE: With the handles laying on a flat surface, the handles intended for the drawers are more curved. They will not mount flush against the doors.

Install Handles

NOTE: Handle mounting setscrews are preinstalled inside the handle.

1. Remove the handles from the packaging inside the

refrigerator, and place them on a soft surface.

2. Open a refrigerator compartment door. On the closed door,

place a handle onto the shoulder screws so that the setscrews are facing the adjacent door.

A. Shoulder screws B. Setscrews inside the handle

3. Firmly push the handle toward the door until the handle base

is flush against the door.

INSTALLATION INSTRUCTIONS

4. While holding the handle, insert the short end of the hex key

into the upper hole and slightly rotate the hex key until it is engaged in the setscrew.

5. Using a clockwise motion tighten the setscrew just until it

begins to contact the shoulder screw. Do not fully tighten.

6. Repeat steps 4 and 5 to fasten the lower setscrew.

7. Once both setscrews have been partially tightened as

instructed in the previous steps, fully tighten both setscrews. IMPORTANT: When the screws feel tight, tighten them an

additional quarter-turn. The handle is not properly installed without this extra tightening.

8. Repeat steps 2 through 7 to install the other handle onto the

adjacent refrigerator door.

9. With the drawer(s) closed, place the handle onto the shoulder

screws so that the setscrews are facing down toward the floor.

10. Firmly push the handle toward the drawer until the handle

base is flush against the drawer.

11. Insert the short end of the hex key into the left-hand hole and

slightly rotate the hex key until it is engaged in the setscrew.

12. Using a left to right motion tighten the setscrew a quarter-turn

at a time just until it begins to contact the shoulder screw. Do not fully tighten.

13. Repeat steps 11 and 12 to fasten the right-hand setscrew to

the shoulder screw.

14. Once both setscrews have been partially tightened as

instructed in the previous steps, fully tighten both setscrews. IMPORTANT: When the screws feel tight, tighten them an

additional quarter-turn. The handle is not properly installed without this extra tightening.

15. For some models, repeat steps 9 through 14 to install a

handle on the second drawer.

16. Save the hex key and all instructions.

A. Shoulder screw B. Setscrews inside the handle

Remove the Handles

1. While holding the handle, insert the short end of the hex key

into a setscrew hole and slightly rotate the hex key until it is engaged in the setscrew.

2. Using a right to left motion loosen the setscrew a quarter-turn

at a time.

3. Repeat steps 1 and 2 for the other setscrew. Slowly pull the

handle away from the door or drawer.

4. If necessary, use a Phillips screwdriver to remove the

shoulder screws from the door.

INSTALLATION INSTRUCTIONS

¹⁄₄"

Refrigerator Leveling, Door Closing and Alignment

The base grille covers the adjustable brake feet and roller assemblies located at the bottom of the refrigerator below the freezer drawer. Before making any adjustments, remove the base grille and move the refrigerator to its final location.

Tools Needed: ¹⁄₄" hex driver Tool s Prov ided : ¹⁄₈" hex key wrench

1. Remove the base grille. Grasp the grille firmly and pull it

toward you. Open the freezer drawer to access the brake feet.

NOTE: To allow the refrigerator to roll easier, raise the break feet by turning them counterclockwise. The front rollers will be touching the floor.

2. Move the refrigerator to its final location.

3. Lower the brake feet, by turning them clockwise, until the

rollers are off the floor and both brake feet are snug against the floor. This keeps the refrigerator from rolling forward when opening the refrigerator doors or freezer drawer.

IMPORTANT: If you need to make further adjustments involving the brake feet, you must turn both brake feet the same amount to keep the refrigerator level.

4. Make sure the doors close easily. If you are satisfied with the

door opening and closing, skip the next section and go to “Align the Doors.” If, however, the doors do not close easily or the doors pop open, adjust the tilt.

To Adjust the Cabinet Tilt:

■ Open the freezer drawer. Use a ¹⁄₄" hex driver to turn both

brake feet clockwise the same amount. This will raise the front of the refrigerator. It may take several turns to allow the doors to close easier.

NOTE: Having someone push against the top of the refrigerator takes some weight off the brake feet. This makes it easier to turn them.

Style 1

Style 2

A. Brake foot

5. Make sure the doors are even at the top and that the space

between the bottom of the refrigerator doors and the top of the freezer drawer is even. If necessary, align the doors.

To Align the Doors:

■ Keeping both refrigerator doors closed, pull out the

freezer drawer. Locate the bottom hinge pin of the right-hand refrigerator door. The alignment screw is inside the bottom hinge pin.

■ Insert the short end of the ¹⁄₈" hex key wrench (packed

with the Door Handle Installation Instructions) into the bottom hinge pin until it is fully engaged in the alignment screw.

To raise the refrigerator door, turn the hex key to the right. To lower the door, turn the hex key to the left.

■ Continue to turn the alignment screw until the doors are

aligned.

A. Brake foot B. Front roller

A. Bottom hinge pin B.

¹⁄₈

" Hex key wrench

6. Make sure the refrigerator is steady. If the refrigerator seems

unsteady or rolls forward when the door or drawer is pulled open, adjust the brake feet.

FILTERS AND ACCESSORIES

Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection before or after the system. Systems certified for cyst reduction may be used on disinfected waters that may contain filterable cysts.

To Steady the Refrigerator:

■ Open the freezer drawer. Using a ¹⁄₄" hex driver, turn both

brake feet clockwise the same amount until the brake feet are snug against the floor. Check again. If not satisfied, continue to adjust the brake feet by half turns of the screw until the refrigerator does not roll forward when the drawer is opened.

Water Filtration System

Install the Water Filter

1. Locate the accessory packet in the refrigerator and remove

the water filter.

2. Take the water filter out of its packaging and remove the

cover from the O-rings. Be sure the O-rings are still in place after the cover is removed.

NOTE: Having someone push against the top of the refrigerator takes some weight off the brake feet. This makes it easier to turn the screws.

7. Replace the base grille by aligning the ends of the grille with

the leveling assemblies on each side and snapping the grille into place.

4. Align the arrow on the water filter label with the cutout notch

in the filter housing and insert the filter into the housing.

5. Turn the filter clockwise 90 degrees (¹⁄₄ turn), until it locks into

the housing. NOTE: If the filter is not correctly locked into the housing, the

water dispenser will not operate. Water will not flow from the dispenser.

A. O-ring cover B. O-rings

3. The water filter compartment is located in the right-hand side

of the refrigerator ceiling. Push up on the compartment door to release the catch, then lower the door.

6. While the compartment door is still open, lift the filter up into

the compartment. Then, close the filter compartment door completely.

7. Flush the water system. See “Flushing the Water Filter” in the

“Water and Ice Dispensers” section. IMPORTANT: If you do not flush the water system, you may

experience dripping and/or decreased flow from the water dispenser.

The Water Filter Status Light

Press OPTIONS on the control panel to launch the Options menu. Press OPTIONS, under Filter Status, again to display the percentage of filter life remaining (from 99% to 0%). Press ICE/ WATER, under Back, to return to the Normal screen.

The water filter status lights will help you know when to change your water filter.

■ ORDER FILTER (yellow) - it is almost time to change the water

filter. While you are dispensing water, “Order Filter” will blink seven times and sound an alert tone three times.

■ REPLACE FILTER (red) - Replace the water filter. While you

are dispensing water, “Replace Filter” will blink seven times and an alert tone will sound three times.

FILTERS AND ACCESSORIES

■ RESET the water filter status tracking feature. After you

replace the disposable filter with a new filter, closing the filter compartment door will automatically reset the filter status tracking feature. See “Using the Control(s).”

NOTE: “REPLACE FILTER” will remain illuminated if a filter is not installed or is installed incorrectly.

Replace the Water Filter

To purchase a replacement water filter, see “Accessories” in the User Guide, Use and Care Guide or User Instructions.

Replace the disposable water filter when indicated on the water filter status display or at least every 6 months. If water flow to your dispenser or ice maker decreases noticeably, change the water filter sooner.

Install Air Filter

An air filter is 15 times more powerful than baking soda at reducing common food odors inside the refrigerator.

On some models, your refrigerator's accessory packet includes an air filter, which must be installed prior to use.

(on some models)

1. Locate the water filter compartment in the right-hand side of

the refrigerator ceiling. Push up to release and lower the compartment door.

2. Turn the water filter counterclockwise (to the left), and pull it

straight out of the compartment. NOTE: There may be some water in the filter. Some spilling

may occur. Use a towel to wipe up any spills.

3. Install the replacement water filter by following steps 2

through 7 in the “Install the Water Filter” section.

Installing the Filter Status Indicator

The filter comes with a status indicator, which should be activated and installed at the same time the air filter is installed.

1. Place the indicator face-down on a firm, flat surface.

Installing the Air Filter

Install the air filter behind the vented door, located on the rear wall near the top of the refrigerator compartment.

1. Remove the air filter from its packaging.

2. Lift open the vented door.

3. Snap the filter into place.

A. Air filter

2. Apply pressure to the bubble on the back of the indicator until

the bubble pops to activate the indicator.

3. Lift open the vented air filter door. On some models, there are

notches behind the door.

Models with notches:

■ With the indicator screen facing outward, slide the

indicator down into the notches. NOTE: The indicator will not easily slide into the notches

if the bubble has not been popped.

■ Close the air filter door, and check that the indicator is

visible through the window in the door.

A. Status indicator window B. Air filter status indicator C. Notches

FILTERS AND ACCESSORIES

CAUTION: IRRITANT

MAY IRRITATE EYES AND SKIN. DANGEROUS FUMES FORM WHEN MIXED WITH OTHER PRODUCTS.

Do not mix with cleaning products containing ammonia, bleach or acids. Do not get in eyes, on skin or clothing. Do not breathe dust. Keep out of reach of children.

FIRST AID TREATMENT: Contains potassium permanganate. If swallowed, call a Poison Control Center or doctor immediately. Do not induce vomiting. If in eyes, rinse with water for 15 minutes. If on skin, rinse with water.

CAUTION

ITA

Read cautions on back.

ATTENTION

ITA

Lisez des prudences sur le revers.

Models without notches:

■ Place the indicator somewhere it is easily visible - either

inside the refrigerator, or elsewhere in your kitchen or home.

Replacing the Air Filter

The disposable air filter should be replaced every 6 months, when the status indicator has completely changed from white to red.

Install Produce Preserver

The produce preserver absorbs ethylene, to slow the ripening process of many produce items. As a result, certain produce items will stay fresh longer.

Ethylene production and sensitivity varies depending on the type of fruit or vegetable. To preserve freshness, it is best to separate produce with sensitivity to ethylene from fruits that produce moderate to high amounts of ethylene.

Sensitivity to

Ethylene

Apples High Very High

(on some models)

Ethylene

Production

To order a replacement air filter, contact us. See “Accessories” in the User Guide, Use and Care Guide or User Instructions for information on ordering.

1. Remove the used air filter by squeezing in on the side tabs.

2. Remove the used status indicator.

3. Install the new air filter and filter status indicator using the

instructions in the previous sections.

Installing the Produce Preserver

Asparagus Med. Very Low

Berries Low Low

Broccoli High Very Low

Cantaloupe Med. High

Carrots Low Very Low

Citrus Fruit Med. Very Low

Grapes Low Very Low

Lettuce High Very Low

Pears High Very High

Spinach High Very Low

1. Find the Produce Preserver housing inside the refrigerator.

2. Open the housing by pulling up and out on the back.

3. Remove the Produce Preserver pouches from the packaging

and place them into the housing.

NOTE: For best performance, always use two pouches.

4. Adhere the Produce Preserver housing to the back wall of the

crisper drawer according to the instructions included in the package.

FILTERS AND ACCESSORIES

Installing the Status Indicator

The produce preserver comes with a status indicator, which should be activated and installed at the same time the pouches are installed.

1. Place the indicator face-down on a firm, flat surface.

2. Apply pressure to the bubble on the back of the indicator until

the bubble pops, to activate the indicator.

Accessories

The following accessories are available for your refrigerator. To order an accessory, contact us and ask for the Part Number.

In the U.S.A., visit our webpage www.whirlpool.com/ accessories or call 1-800-901-2042.

In Canada, visit our webpage www.whirlpool.ca or call 1-800-807-6777.

affresh

In U.S.A., order Part #W10355016 In Canada, order Part #W10355016B

affresh

In U.S.A., order Part #W10355049 In Canada, order Part #W10355049B

Stainless Steel Cleaner:

Stainless Steel Wipes:

3. Slide open the cap on the top of the produce preserver

housing.

4. Place the indicator in the top of the housing, facing outward.

5. Slide the cap closed, and check that the indicator is visible

through the rectangular hole in the cap. NOTE: The cap will not easily close if the indicator’s bubble

has not been popped.

Replacing the Produce Preserver

The disposable pouches should be replaced every 6 months or when the status indicator changes completely from white to red.

To order replacements, contact us. See “Accessories” for information on ordering.

1. Remove the used pouches from the produce preserver

housing.

2. Remove the used status indicator.

3. Install the replacement pouches and status indicator using

the instructions in the previous sections.

affresh® Kitchen & Appliance Cleaner:

In U.S.A., order Part #W10355010 In Canada, order Part #W10355010B

Water Filter: Order Part #W10413645A or FILTER2

Air Filter: Order Part #W10311524 or AIR1

Produce Preserver:

Order Part # W10346771A or FRESH1

Water Filter, Air Filter and Produce Preserver Bundle Pack:

Order Part # W10413643BL

Opening and Closing Doors

REFRIGERATOR USE

There are two refrigerator compartment doors. The doors can be opened and closed either separately or together.

There is a vertically-hinged seal on the left refrigerator door.

■ When the left side door is opened, the hinged seal

automatically folds inward so that it is out of the way.

■ When both doors are closed, the hinged seal automatically

forms a seal between the two doors.

Using the Controls

The controls are located above the external dispenser.

IMPORTANT: The display screen on the dispenser control panel will turn off automatically and enter “sleep” mode when the control buttons and dispenser paddles have not been used for 2 minutes or more. Press any control button to reactivate the display screen. The home screen will appear as shown.

A. Hinged seal

Viewing and Adjusting Temperature Set Points

For your convenience, your refrigerator and freezer controls are preset at the factory.

When you first install your refrigerator, make sure that the controls are still set to the recommended set points. The factory recommended set points are 37°F (3°C) for the refrigerator and 0°F (-18°C) for the freezer.

IMPORTANT:

■ Wait 24 hours before you put food into the refrigerator. If you

add food before the refrigerator has cooled completely, your food may spoil.

NOTE: Adjusting the set points to a colder than recommended setting will not cool the compartments any faster.

■ If the temperature is too warm or too cold in the refrigerator or

freezer, first check the air vents to be sure they are not blocked before adjusting the controls.

■ The recommended settings should be correct for normal

household use. The controls are set correctly when milk or juice is as cold as you like and when ice cream is firm.

NOTE: Areas such as a garage, basement or porch, may have higher humidity or extreme temperatures. You may need to adjust the temperature away from the recommended settings to accommodate for these conditions.

■ Wait at least 24 hours between adjustments. Recheck the

temperatures before other adjustments are made.

View Temperature Set Points

1. Press and hold TEMP for 3 seconds to activate Temperature

mode. NOTE: To view temperature in degrees Celsius, press the

LIGHT button, under Units, when adjust mode is activated. To return the display setting to Fahrenheit, press the LIGHT button again.

REFRIGERATOR USE

When Temperature mode is activated, press TEMP to toggle between Fridge and Freezer. The display will show the temperature set point of the selected compartment, and temperature adjusting information will appear on the display screen.

Recommended Refrigerator Temperature

Recommended Freezer Temperature

When adjusting temperature set points,

use the following chart as a guide:

CONDITION: TEMPERATURE

ADJUSTMENT:

REFRIGERATOR too cold REFRIGERATOR Setting

REFRIGERATOR too warm REFRIGERATOR Setting

FREEZER too cold FREEZER Setting

FREEZER too warm / Too little ice

1° higher

1° lower

1° higher FREEZER Setting

1° lower

Cooling On/Off

Your refrigerator and freezer will not cool when cooling is turned off.

■ To turn cooling off, press and hold the LOCK and

MEASURED FILL buttons at the same time for 3 seconds. The Cooling Off icon will blink seven times and then remain lit as shown.

IMPORTANT:

■ To avoid unintentionally locking the dispenser or changing

other settings, press both buttons at exactly the same time.

■ When cooling is off, the dispenser paddles and all

controls except Lock and Measured Fill are disabled.

Adjust Temperature Set Points

Refrigerator set point range: 33°F to 45°F (0°C to 7°C). Freezer set point range: -5°F to 5°F (-21°C to -15°C).

1. When Temperature mode is activated, press TEMPERATURE

to select the Refrigerator zone. The display will show the temperature set point of the selected compartment, as shown.

2. Press LOCK to raise the set point, or press OPTIONS to lower

the set point.

3. When you have finished viewing (and adjusting if desired) the

refrigerator set point, press TEMP, under Select Zone, to change the display to show the freezer set point. When the zone has been changed, “FREEZER” appears on the display screen.

4. Press the LOCK button to raise the set point, or press the

OPTIONS button to lower the set point.

Save/Confirm Temperature Settings

■ When you have finished adjusting both the refrigerator and

freezer set points, press MEASURED FILL to confirm and to save the settings.

NOTE: To exit Temperature mode without saving changes, press the ICE/WATER button under Back at any time, or allow about 60 seconds of inactivity. The temperature mode will turn off automatically and return to the normal screen.

A. Press LOCK and MEASURED FILL at the same time.

■ Press and hold LOCK and MEASURED FILL for 3 seconds

again to turn cooling back on.

Options

Press the OPTIONS button to open the Options menu and select between Fast Ice, Filter Status or Vacation mode.

Press the ICE/WATER button at any time to return to the Normal screen.

REFRIGERATOR USE

Fast Ice

The Fast Ice feature assists with temporary periods of heavy ice use by increasing ice production.

■ To turn on the Fast Ice feature, press the OPTIONS button to

access the Options menu, then press TEMP, under Fast Ice to activate the feature. When the feature is on, the Fast Ice icon will appear on the dispenser display screen. The Fast Ice feature will remain on for 24 hours unless manually turned off.

■ To manually turn off the Fast Ice feature, press the OPTIONS

button to enter Options mode (unless you are already in Options mode), then press TEMP, under Fast Ice, again. When the feature has been turned off, the Fast Ice icon will disappear from the dispenser display.

Filter Status

Displays the percentage of use remaining in the water filter (from 100% remaining to 0% remaining).

To access Filter Status, press the OPTIONS button to access the Options menu, then press OPTIONS, under Filter Status, to display the percent of life remaining in the water filter.

ALSO

The water filter status lights will let you know when to change your water filter.

■ ORDER FILTER (Yellow) - Order a replacement water filter.

■ REPLACE FILTER (Red) - Replace the water filter. Replacing

the disposable water filter will automatically reset the water filter status tracking feature. See “Water Filtration System.”

NOTE: REPLACE FILTER will remain illuminated if a filter is not installed or installed incorrectly.

■ To turn on Vacation mode, press the OPTIONS button to

access the Options menu, then press LOCK, under Vacation, to activate the feature. When the feature is on, the Vacation icon will appear on the dispenser display screen as shown.

■ To turn off Vacation Mode, press the OPTIONS button to

access the Options menu, then press LOCK to turn off the feature. The Vacation icon will disappear, and the screen will display the settings as they were before Vacation Mode was turned on.

NOTES:

■ During the first hour after Vacation Mode is turned on,

opening and closing the refrigerator door will not affect the setting. After 1 hour has passed, opening and closing the refrigerator door will turn off Vacation Mode.

■ While in Vacation Mode, if Fast Ice is turned on or the Door

Ajar alarm sounds, Vacation Mode will be canceled.

Additional Features

Door Ajar Alarm

The Door Ajar Alarm feature sounds an alarm when the refrigerator door(s) or freezer drawer is open for 5 minutes and cooling is turned on. The alarm will repeat every 2 minutes. Close all doors and drawer to turn it off. The feature then is reset and will reactivate when either door is left open again for 5 minutes.

■ NOTE: To mute the audible alarm while keeping the doors

open, such as while cleaning the inside of the refrigerator, press any button on the control panel. The alarm sound will be temporarily turned off, but the Door Ajar icon will still be displayed on the dispenser control panel.

Vacation Mode

In Vacation Mode, the freezer will defrost less often to conserve energy.

Water and Ice Dispensers

IMPORTANT:

■ Allow 3 hours for the refrigerator to cool down and chill water.

■ Allow 24 hours to produce the first batch of ice. Discard the

first three batches of ice produced.

Disabling Sounds

■ To turn off control and dispenser sounds, press and hold ICE/

WATER and MEASURED FILL at the same time for 3 seconds. All normal operating tones are disabled. Only alert tones will be audible.

■ To turn all sounds back on, press and hold ICE/WATER and

MEASURED FILL at the same time for 3 seconds again.

Showroom Mode

This mode is used only when the refrigerator is on display in a retail store. If you unintentionally turn on Showroom mode, the word “Showroom” will light up on the display. Exit Showroom mode by pressing and holding LIGHT and LOCK at the same time for 3 seconds.

■ The dispensing system will not operate when either the

refrigerator door or freezer drawer is open.

REFRIGERATOR USE

Flush the Water System

Air in the water dispensing system can cause the water dispenser to drip. After connecting the refrigerator to a water source or replacing the water filter, flush the water system.

Flushing the water dispensing system forces air from the water line and filter and prepares the water filter for use. Additional flushing may be required in some households.

NOTE: As air is cleared from the system, water may spurt out of the dispenser.

1. Using a sturdy container, depress and hold the water

dispenser paddle for 5 seconds.

2. Release the dispenser paddle for 5 seconds. Repeat steps 1

and 2 until water begins to flow.

3. Once water begins to flow, continue depressing and releasing

the dispenser pad (5 seconds on, 5 seconds off) until a total of 3 gal. (12 L) has been dispensed.

Calibrate Measured Fill

Household water pressure may affect the accuracy of the Measured Fill feature. So, for optimum performance of your water dispenser, you must first calibrate Measured Fill.

IMPORTANT: Flush the water system before calibrating Measured Fill.

1. Place a sturdy measuring cup (1 cup [237 mL] size) on the

dispenser tray centered in front of the ice/water dispenser paddle.

NOTE: Depending on your model, a measuring cup may be provided.

3. Press and release the ice/water dispenser paddle, as needed,

to dispense water to the 1 cup fill line. NOTE: If overfilling or spilling occurs, discard the water and

press ICE/WATER “Back” to restart the calibration process.

4. When 1 cup of water has been correctly dispensed into the

measuring cup, press the MEASURED FILL button under the word “Confirm” to confirm the calibration.

A. Ice/Water dispenser paddle B. Measuring cup (1 cup)

2. Press and hold the OPTIONS and LOCK buttons at the same

time for 3 seconds. The words “Back” and “1 Cup” will appear on the display screen. Also, the Calibrate Measured Fill icon will illuminate and remain lit while the Measured Fill feature is being calibrated.

NOTE: You may press ICE/WATER “Back” at any time to exit calibration mode. The Calibrate Measured Fill icon will disappear.

5. When Measured Fill calibration has been confirmed the icons

will disappear and the display will return to the home screen.

A. 1 cup of water

REFRIGERATOR USE

Dispensing

Press ICE/WATER to toggle through the following choices in a continuous loop:

■ Water (default) - Dispenses water

■ Cubed - Dispenses cubed ice.

■ Crushed - Dispenses crushed ice

NOTES:

■ The word “ICE” appears on the display screen when

either crushed or cubed ice is selected.

■ For crushed ice, cubes are crushed before being

dispensed. This may cause a slight delay when dispensing crushed ice. Noise from the ice crusher is normal, and pieces of ice may vary in size.

■ When changing from crushed to cubed, a few ounces of

crushed ice will be dispensed along with the first cubes.

Water Crushed Cubed

The Water Dispenser

IMPORTANT:

■ Dispense at least 1 qt (1 L) of water every week to maintain a

fresh supply.

■ If the flow of water from the dispenser decreases, it could be

caused by low water pressure.

■ With the water filter removed, dispense 1 cup (237 mL) of

water. If 1 cup (237 mL) of water is dispensed in 8 seconds or less, the water pressure to the refrigerator meets the minimum requirement.

■ If it takes longer than 8 seconds to dispense 1 cup

(237 mL) of water, the water pressure to the refrigerator is lower than recommended. See “Water Supply Requirements” and “Troubleshooting” for suggestions.

To Dispense Water (Standard):

1. Select water.

2. Press a sturdy glass against the dispenser paddle. NOTE: While dispensing water and for 3 seconds after

dispensing has stopped, the digital display will show how much water has been dispensed.

3. Remove the glass to stop dispensing.

To Dispense Water (Measured Fill):

Measured Fill allows you to dispense a specified amount of water with the touch of a few controls.

NOTE: The amount of water you select will be dispensed. Be sure that the container is empty and can hold the entire volume. If ice is in the container, you may need to adjust your selection.

1. Press MEASURED FILL to turn on the feature. When the

feature is on, the Measured Fill screen appears on the display.

NOTES:

■ The dispenser will automatically turn off Measured Fill

after 1 minute of inactivity. When Measured Fill is turned off, any changes you have made will be lost and all defaults will be restored.

■ Press ICE/WATER “Back,” to manually turn off the

Measured Fill feature.

2. Press LIGHT, under Units, to toggle among ounce, cup and

liter. The default unit is ounce. Default, minimum, and maximum volumes are listed below.

Units Default Minimum Maximum

Ounces 8 1 128

Cups 1 ¹/₄ 16 Liters 0.25 0.05 4.00

3. Press LOCK or OPTIONS to adjust the water volume as

desired. The LOCK control increases the volume, and the OPTIONS control lowers the volume.

NOTES:

■ When increasing or decreasing the dispense volumes, if

an adjustment button (-/+) is held for approximately 10 seconds or longer the control may stop responding. Release the button for approximately 2 seconds and then continue making the adjustment.

■ Most coffee cups (commonly 4 to 6 oz [118 to 177 mL]

per cup) are not the same size as a measuring cup (8 oz [237 mL]). You may need to adjust the volume to avoid unintentionally overfilling coffee cups.

4. Dispense water. NOTE: While dispensing water, the digital display will count

down how much water remains to be dispensed, according to the volume you selected. The flow of water will automatically stop once the desired volume has been dispensed.

■ Press a sturdy glass against the dispenser paddle.

■ Place the glass below the water dispenser and press

MEASURED FILL, under Dispense, for hands-free dispensing.

REFRIGERATOR USE

Cut Hazard Use a sturdy glass when dispensing ice. Failure to do so can result in cuts.

WARNING

5. To stop dispensing before the selected volume has been

dispensed, remove the glass from the dispenser paddle OR press MEASURED FILL a second time.

NOTE: If you stop dispensing before the desired volume has been dispensed, the digital display will continue to show how much water remains to be dispensed. The display will turn off after 1 minute of inactivity.

■ To select a new volume or start dispensing the same

volume again, you must first finish dispensing the selected volume, or turn off the Measured Fill feature (either by waiting 1 minute so it will automatically turn off or by pressing ICE/WATER “Back” to manually turn it off) and then turn it back on.

The Ice Dispenser

IMPORTANT:

■ If the ice cubes are hollow or have an irregular shape, it could

be because of low water pressure. See “Water Supply Requirements.”

■ Ice travels from the ice storage bin through the dispenser

chute to the dispenser. To turn off the ice maker, see “Ice Maker and Storage Bin.”

To Clean the Ice Dispenser Chute:

Humidity causes ice to naturally clump together. Ice particles can build up until the ice dispenser chute becomes blocked.

If ice is not dispensed regularly, it may be necessary to empty the ice storage bin and clean the ice delivery chute, the ice storage bin and the area beneath the storage bin every 2 weeks.

■ Remove the ice clogging the storage bin and delivery chute,

using a plastic utensil if necessary.

■ Clean the ice delivery chute and the bottom of the ice storage

bin using a warm, damp cloth, then dry thoroughly.

To Dispense Ice:

1. Select the desired type of ice. To switch between cubed ice

and crushed ice, press ICE/WATER.

The Dispenser Light

When you use the dispenser, the light will automatically turn on.

To turn on the light when you are not dispensing:

Press LIGHT to toggle through the following choices in a continuous loop:

■ OFF (default) - The dispenser light is off

■ ON - The dispenser light remains on at 100% brightness

■ DIM - The dispenser light remains on at 50% brightness

The dispenser lights are LEDs that cannot be changed. If it appears that your dispenser lights are not working, see “Troubleshooting” for more information.

ON DIM

The Dispenser Lock

The dispenser can be turned off for easy cleaning or to avoid unintentional dispensing by small children and pets.

NOTE: The lock feature does not shut off power to the refrigerator, to the ice maker, or to the dispenser light. It simply deactivates the controls and dispenser paddles. To turn off the ice maker, see “Ice Maker and Storage Bin.”

■ Press and hold LOCK for 3 seconds to lock the dispenser.

■ Press and hold LOCK a second time to unlock the dispenser.

The display screen indicates when the dispenser is locked.

2. Press a sturdy glass against the dispenser paddle. Hold the

glass close to the dispenser opening so ice does not fall outside of the glass.

IMPORTANT: You do not need to apply a lot of pressure to the paddle to activate the ice dispenser. Pressing hard will not make the ice dispense faster or in greater quantities.

3. Remove the glass to stop dispensing. NOTE: Ice may continue to dispense for several seconds after

removing the glass from the dispenser paddle. The dispenser may continue to make noise for a few seconds after dispensing.

LOCKED UNLOCKED

REFRIGERATOR USE

Ice Maker and Ice Storage Bin

IMPORTANT: To avoid low ice production and poor quality ice, flush the water system before turning on the ice maker. See “Water Dispenser.”

■ Allow 24 hours to produce the first batch of ice. Discard the

first three batches of ice produced. Allow 2 to 3 days for the storage bin to fill completely following installation.

■ The quality of your ice will be only as good as the quality of

the water supplied to your ice maker. Avoid connecting the ice maker to a softened water supply. Water softener chemicals (such as salt) can damage parts of the ice maker and lead to poor quality ice. If a softened water supply cannot be avoided, make sure the water softener is operating properly and is well maintained.

■ If the ice in the storage bin clumps together, break up ice

using a plastic utensil and discard. Do not use anything sharp to break up the ice. This can cause damage to the ice bin and the dispenser mechanism.

■ Do not store anything in the ice storage bin.

(on some models)

Ice Production Rate

■ The ice maker should produce approximately 3 lbs (1.4 kg) of

ice per day under normal operation.

■ To increase ice production, select the increased ice

production feature from the Options menu on the control panel. See “Using the Control(s).”

Style 1 - Ice Maker in the Refrigerator (on some models)

The ice maker is located on the left-hand side of the refrigerator compartment ceiling. Ice cubes are ejected into the ice storage bin, located on the left-hand refrigerator door.

Turn the Ice Maker On/Off

1. Push up on the latch on the left-hand side of the ice

compartment to open the door.

NOTES:

■ To manually turn off the ice maker, move the control to the

OFF (right) position.

■ Your ice maker has an automatic shutoff. The sensor will

automatically stop ice production if the storage bin is full, if the door is open or the storage bin is removed. The control will remain in the ON (left) position.

A. Ice storage bin release latch

3. Close the ice compartment door.

Remove and Replace the Ice Storage Bin

■ Remove the ice storage bin by inserting your fingers into the

hole at the base of the bin and squeezing the latch to release the bin from the compartment. Lift the storage bin up and pull it straight out.

■ Replace the storage bin inside the ice compartment and push

down to make sure it is firmly in place.

Style 2 - Ice Maker in the Freezer (on some models)

Turn the Ice Maker On/Off

To turn the ice maker ON, simply lower the wire shutoff arm. To manually turn the ice maker OFF, lift the wire shutoff arm to the

OFF (arm up) position and listen for the click. NOTE: Your ice maker has an automatic shutoff. As ice is made,

the ice cubes will fill the ice storage bin and the ice cubes will raise the wire shutoff arm to the OFF (arm up) position. Do not force the wire shutoff arm up or down.

A. Ice compartment door latch

2. Turn on the ice maker by moving the switch to the (left) ON

position.

NOTE: Turn off the ice maker before removing the ice storage bin to serve ice or to clean the bin. This will keep the ice cubes from dropping out of the ice maker and into the freezer compartment. After replacing the ice storage bin, turn on the ice maker.

REFRIGERATOR FEATURES

Important information to know about glass shelves and covers:

Refrigerator Shelves

The shelves in your refrigerator are adjustable to meet your individual storage needs.

Storing similar food items together in your refrigerator and adjusting the shelves to fit different heights of items will make finding the exact item you want easier. It will also reduce the amount of time the refrigerator door is open, and save energy.

Shelves and Shelf Frames

To remove and replace a shelf/shelf frame:

1. Remove the shelf/frame by tilting it up at the front and lifting it

out of the shelf supports.

2. Replace the shelf/frame by guiding the rear shelf hooks into

the shelf supports. Tilt the front of the shelf up until rear shelf hooks drop into the shelf supports.

3. Lower the front of the shelf and make sure that the shelf is in

position.

Tuck Away Shelf (on some models)

To retract and extend the front section of the shelf:

1. To retract the front-section of the shelf, slightly lift up on the

front edge and push the adjustable portion of the shelf back toward the rear of the refrigerator.

2. Extend the front of the shelf by pulling the retracted portion of

the shelf outward until it is fully extended.

Crisper Drawers/Pantry Drawer/Crisper Cover

To remove and replace the drawers:

1. Slide the drawers straight out to the stop. Lift the drawers

from the rails and pull them out the rest of the way.

2. Replace the drawers by placing them on the rails and pushing

them back into position past the drawer stop.

+ 58 hidden pages
