29" and 27" Gas Dryer
PRODUCT MODEL NUMBERS
WGD5000V WGD5510V
WGD5100V WGD5590V
WGD5200V WGD5600V
WGD5300V WGD5700V
Gas supply: This dryer is equipped for
use with Natural gas. It is design-certified by CSA International for LP (propane or butane) gases with appropriate conversion. The gas line must include 1/8" NPT minimum plugged tapping accessible for test gauge connection, immediately upstream of the gas connection to the dryer. 1/2" IPS pipe is recommended.
3/8" approved aluminum or copper tubing is acceptable for lengths under 20 ft (6.1 m) if local codes and gas supplier permit.
If you are using Natural gas, do not use copper tubing.
3/8" flare x 3/8" NPT adapter fitting between dryer pipe and 3/8" approved tubing. Lengths over 20 ft (6.1 m) should use larger tubing and a different size adapter fitting.
If your dryer has been converted to use LP gas, 3/8" LP compatible copper tubing can be used. If the total length of the supply line is more than 20 ft (6.1 m), use larger pipe. NOTE: Pipe-joint compounds that resist
the action of LP gas must be used. Do not use TEFLON®† tape.
Must include a shutoff valve.
In the U.S.A.:
An individual manual shutoff valve must be installed within six (6) feet (1.8 m) of the dryer in accordance with the National Fuel Gas Code, ANSI Z223.1.
In Canada:
An individual manual shutoff valve must be installed in accordance with the B149.1, Natural Gas and Propane Installation Code. It is recommended that an individual manual shutoff valve be installed within six (6) feet (1.8 m) of the dryer.
The location should be easy to reach for opening and closing.
Electrical: 120-volt, 60-Hz, AC-only, 15or 20-amp fused electrical supply is required. A time-delay fuse or circuit breaker is recommended. It is also recommended that a separate circuit serving only this dryer be provided. Exhaust venting: Exhaust your dryer to
the outside. 4" (102 mm) diameter vent is required. Rigid or flexible metal exhaust vent must be used. Do Not use plastic or metal foil vent. Exhaust outlet hood must be at least 12" (305 mm) from the ground or any object that may be in the path of the exhaust.
†®TEFLON is a registered trademark of E.I. Du Pont De Nemours and Company.
PRODUCT DIMENSIONS
29" Model
433/8" |
151/4" |
|
|
223/4" |
|
223/4" |
|
|
|
(387 mm) |
|
|
(578 mm) |
433/8" |
(578 mm) |
433/8" |
|
||
(1102 mm) |
|
|
433/8" |
|
|
(1102 mm) |
|
(1102 mm) |
133/4" |
|
|
(1102 mm) |
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
(349 mm) |
*26" |
|
|
*273/4" |
|
|
*273/4" |
|
*273/4" |
|
(660 mm) |
|
(705 mm) |
|
|
(705 mm) |
|
(705 mm) |
|
|
|
29" |
|
|
|
|
|
29" |
|
|
|
|
|
29" |
|
|
29" |
|
||
|
A. |
|
|
B. |
|
|
C. |
D. |
|
|
(737 mm) |
|
|
(737 mm) |
|
|
(737 mm) |
(737 mm) |
|
27" Model |
|
|
|
|
|
|
A. Small Opening Side-Swing Door |
|
|
|
|
|
|
|
|
|
|
||
43" |
(603 mm) |
43" |
|
|
|
B. Large Opening Side-Swing Door |
|
||
|
|
|
C. Wide Opening Side-Swing Door |
|
|||||
|
23 |
3/4" |
|
|
|
|
D. Wide Opening Hamper Door |
|
|
(1092 mm) |
|
|
(1092 mm) |
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
133/4" |
|
|
|
|
|
|
|
|
|
(349 mm) |
|
|
|
|
*291/2" |
|
|
*291/2" |
|
|
|
|
|
|
(749 mm) |
|
|
(749 mm) |
27 |
" |
|
|
|
|
|
27" |
|
|
|
|
|
|
||
|
B. |
|
|
D. |
|
|
|
|
|
|
(687 mm) |
|
|
(687 mm) |
|
|
|
|
Most installations require a minimum 5 1/2" (140 mm) clearance behind the dryer for the exhaust vent with elbow.
RECESSED AREA AND CLOSET INSTALLATION
For closet installation with a door, minimum ventilation openings in the top and bottom of the door are required. Louvered doors with equivalent ventilation openings are acceptable.
|
|
|
|
|
|
3"* |
|
|
|
|
14"max.* |
48in2.* 2 |
(76mm) |
18"* |
|
|
|
(356 mm) |
|
|
|
|
|
|
(310cm) |
A. Recessed area |
|
(457 mm) |
|
|
|
|
|
|
|
|
|
|
|
|
B. Side view - closet or confined area |
|
|
|
|
|
24in.2 * |
C. Closet door with vents |
|
|
|
|
|
3"* |
|
|
|
|
|
|
(155cm)2 |
(76mm) |
1" |
29" |
1" |
1"* |
27¾" |
|
|
(25mm) |
(737mm) |
(25mm) (25mm)(705mm) |
|
|
||
|
27" |
|
|
29¾"/4 |
|
|
|
A. |
|
|
1 |
|
C. |
|
|
|
B. |
|
||
|
(686mm) |
|
|
(705mm) |
|
|
EXHAUST VENTING |
|
|
|
*Required spacing |
||
|
|
|
|
|
|
Exhaust your dryer to the outside. 4" (102 mm) |
Vent System Chart |
|
|
|||
diameter vent is required. Rigid or flexible metal |
|
|
|
|
|
|
exhaust vent must be used. Do not use plastic or |
|
Number |
Type of vent |
Box/louvered |
Angled hoods |
|
metal foil vet. Exhaust hood must be at least 12" |
|
90° turns or |
|
hoods |
|
|
|
elbows |
|
|
|
||
(305 mm) from the ground or any object that may |
|
|
|
|
||
0 |
Rigid metal |
64 ft. (20 m) |
58 ft. (17.7 m) |
|||
be in the path of the exhaust. |
||||||
|
|
|
|
|
||
1 |
Rigid metal |
54 ft. (16.5 m) |
48 ft. (14.6 m) |
|||
|
||||||
|
|
|
|
|
|
|
Hood styles: Box and Louvered hoods styles are |
|
2 |
Rigid metal |
44 ft. (13.4 m) |
38 ft. (11.6 m) |
|
recommended. |
|
3 |
Rigid metal |
35 ft. (10.7 m) |
29 ft. (8.8 m) |
|
|
4 |
Rigid metal |
27 ft. (8.2 m) |
21 ft. (6.4 m) |
4" |
|
|
NOTE: Side and bottom exhaust installations for 27" wide |
||
(102 mm) |
||
|
models have a 90º turn inside the dryer. To determine maximum |
|
Box hood style |
exhaust length, add one 90º turn to the chart. |
|
|
|
|
|
|
|
|
4" |
2.5" |
Vent System Chart (29" Wide Long Vent Models Only) |
|||
|
|
|
|
|
|||||||
|
|
|
|
(102 mm) |
(64 mm) |
|
|
|
|||
|
|
4" |
|
Louvered style |
Acceptable hood style |
Number |
Type of vent |
Box, louvered, |
|||
|
|||||||||||
|
|
||||||||||
(102 mm) |
|
90° turns or |
|
or angled hoods |
|||||||
The vent system chart provides venting requirments |
elbows |
|
|
||||||||
that will help to achieve the best drying performance. |
0 |
Rigid metal |
120 ft. (36.6 m) |
||||||||
|
|
|
|
|
|
|
|
1 |
Rigid metal |
110 ft. (33.5 m) |
|
Vent system chart: NOTE: Side and bottom exhaust |
|
|
|
||||||||
2 |
Rigid metal |
100 ft. (30.5 m) |
|||||||||
installations have a 90° turn inside the dryer. To |
|
|
|
||||||||
3 |
Rigid metal |
90 ft. (27.4 m) |
|||||||||
determine maximum exhaust length, add one 90° |
|
|
|
||||||||
4 |
Rigid metal |
80 ft. (24.4 m) |
|||||||||
turn to the chart. |
|
||||||||||
|
|
|
|
||||||||
|
5 |
Rigid metal |
70 ft. (21.3 m) |
||||||||
|
|
|
|
|
|
|
|
Because Whirlpool Corporation policy includes a continuous commitment to improve our products, we reserve the right to change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details, see Installation |
Ref. W10296135 |
Instructions packed with product. Specifications subject to change without notice. |
12/2009 |
