Para obtener acceso al “Manual de uso y cuidado” en español, o para
obtener información adicional acerca de su producto, visite: www.whirlpool.com.
Dryer Safety
2
3
Check Your Vent System for Good Airow
Good air ow
Along with heat, dryers require good air ow to efciently
dry laundry. Proper venting will reduce your drying times
and improve your energy savings. See “Installation
Instructions”.
The venting system attached to the dryer plays a big role
in good air ow. Blocked or crushed vents as well as
improper venting installation will reduce air ow and dryer
performance.
Service calls caused by improper venting are not
covered by the warranty and will be paid by the customer,
regardless of who installed the dryer. To clean or repair
venting, contact a venting specialist.
Maintain good air ow by:
n
Cleaning your lint screen before each load.
n
Replace plastic or foil vent material
with 4" (102 mm) diameter heavy, rigid
vent material.
n
Use the shortest length of vent possible.
n
Use no more than four 90° elbows in a vent system;
each bend and curve reduces air ow.
GoodBetter
n
Remove lint and debris from the exhaust hood.
n
Remove lint from the entire length of the vent system
at least every 2 years. When cleaning is complete, be
sure to follow the “Installation Instructions” supplied
with your dryer for nal product check.
n
Clear away items from in front of the dryer.
Use Eco Cycles for better fabric care and energy savings
Use the Eco Cycles to provide the most energy savings and enhanced fabric care from the dryer. During Eco Cycles, drying air
temperature and moisture level are sensed in the load. This sensing occurs throughout the drying cycle and the dryer shuts off
when the load reaches the selected dryness. Use the NORMAL dryness level to provide optimal energy savings.
With Timed Dry Cycles, the dryer runs the amount of time set and sometimes results in shrinkage, wrinkling, and static due to
over-drying. Use Timed Dry Cycles for the occasional damp load that needs a little more drying time or when using the drying
rack.
Tips for getting the best performance from your steam dryer
n
Results may vary depending on fabric. 100% cotton
garments with wrinkle-free nish may yield better results
than those without. 100% cotton items may require
additional touching up after the Steam Cycle.
n
Use of fabric softener sheet is not recommended with
Steam Cycles. It may cause temporary staining on clothes.
n
It is not recommended to use Steam Cycles for items that
have been starched. Wash any starched or new garments
prior to using a Steam Cycle.
n
The Enhanced Touch Up cycle is best for reducing odors
and light wrinkles in small to medium-sized loads of dry
garments. For the Enhanced Touch Up cycle, dry time
automatically adjusts as load size is sensed. Cycle run
time cannot be manually adjusted.
n
The Quick Refresh (on some models) cycle is best for
reducing wrinkles and odors in dry garments, including
loads left in the dryer. For, Quick Refresh time is selectable
in ve minute increments based on the load to be refreshed.
4
Control Panel and Features
1
23456
Not all features and cycles are available on all models.
POWER BUTTON
1
Press to turn the dryer on and off. Press again
to stop/cancel a cycle at any time.
CYCLE CONTROL KNOB
2
Use your dryer’s cycle control knob to select available
cycles on your dryer. Turn the knob to select a cycle
for your laundry load. See “Cycle Guide” for detailed
descriptions of cycles.
EST. TIME REMAINING DISPLAY
3
When you select a cycle, its default settings will light
up and the Estimated Time Remaining (for Automatic
Cycles) or actual time remaining (for Manual Cycles)
will be displayed.
DONE/SENSING DISPLAY
4
Done
This will indicate that the selected cycle has ended
and the load may be removed from the dryer. If the
Wrinkle Shield option has been selected, the dryer
may continue to tumble the load, even if the DONE
indicator is lit.
Sensing
At the beginning of an Automatic Cycle, the sensing
light illuminates as the dryer senses the load size and
adjusts for the appropriate dry time for that load. This
indicator will not light during Timed Cycles or with
options such as Wrinkle Shield™.
ECO MONITOR
5
Your dryer is specially designed to conserve energy. Each
cycle, along with selected options, will result in different
energy usage, which will be displayed on the Eco Monitor
bar, allowing you to choose the best energy usage for each
load.
START/PAUSE BUTTON
6
Press to start a cycle, or press once while a cycle is in
process to pause it.
CYCLE OPTIONS
7
Use these buttons to select available options for your dryer.
Not all cycles and options are available on all models.
EcoBoost™ (on some models)
Press to activate EcoBoost™ option on select
Automatic cycles. The EcoBoost™ option allows you
to increase your energy savings with minimal impact on
cycle dry times.
NOTE: Selecting the EcoBoost™ option adds 5 minutes
to the default cycle time.
78
Static Reduce (on some models)
Press to add the Static Reduce option to select cycles
(see Cycle Guide). The dryer will automatically tumble
and spray to introduce a small amount of moisture
into the load to help reduce static. This option adds
approximately 8 minutes to the total cycle time.
Damp Dry Signal
When selected, a signal will sound during the drying
cycle when the load is damp but not completely dry.
This will allow you to take clothes out of the load that
do not need to dry completely. This option is available
on Heavy Duty, Normal, Sheets, Active Wear, Towels,
Casual, Jeans, and Delicate cycles. It is a default
option for the Bulky Items cycle.
Wrinkle Shield™/Wrinkle Shield™ with Steam
(on some models)
If you will be unable to remove a load immediately,
press WRINKLE SHIELD™ to add up to 140 minutes of
periodic tumbling to help reduce wrinkling. On models
with Wrinkle Shield™ with Steam, a short steam cycle
is added after 60 minutes to help smooth out wrinkles.
Cycle Signal
Use this button to turn the signal indicating the end of
a drying cycle on or off, or to adjust the volume of the
signal.
Check Vent Indicator Light
The Check Vent indicator light will come on if a
blocked vent or low airow issue is detected. For
more information on maintaining good airow, see
“Check Your Vent System for Good Airow”.
8
CYCLE MODIFIERS
Use these buttons to select available modiers for your
cycles. Not all cycles and modiers are available on all
models.
Dryness Level
You may adjust the Dryness Level on Automatic
Cycles, if desired.
NOTE: The Dryness Level modier is for use with
Automatic Cycles only. Not available on the Sanitize
cycle.
Temp
When using Manual Cycles only, you may select
a dry temperature based on the type of load you
are drying. Use the warmest setting safe for the
garments in the load. Follow garment label instructions.
NOTE: Automatic Cycles use a preset temperature
that is not adjustable.
5
Cycle Guide – Automatic Cycles
Settings and options shown in bold are default settings for that cycle. Not all features and cycles are available on all models.
Not all settings and options are available on each cycle. Default cycle times are estimated in minutes.
Use Automatic Cycles for better fabric care and energy savings
The dryer senses moisture in the load or air temperature and shuts off when the load reaches the selected dryness level.
Use the NORMAL dryness level to provide optimal energy savings. Use Automatic/Eco cycles on their default settings for optimal
energy savings.
Drying
Items to dry:Cycle:
Towels, bedding,
children’s clothing
Heavyweight items
such as towels or
heavy work clothes
Jeans and denimsJeans*MediumMore
Large loads of cotton
towels, heavyweight
items
Work clothes, casual
wear, mixed cottons,
sheets, corduroys
Or Wrinkle Shield™ with Steam (on some models). Wrinkle Shield™ with Steam is available only with High and Medium Temp settings.
* Automatic/Eco cycle
SanitizeHighMore65Wrinkle Shield
Heavy Duty*HighMore
Towels*HighMore
Normal*MediumMore
Perm press/
Casual*
Bulky Items*MediumMore
Sheets*MediumMore
Active Wear*Extra LowMore
Delicate*Extra LowMore
Temperature:
LowMore
Dryness
Level:
Normal
Less
Damp
Normal
Less
Damp
Normal
Less
Damp
Normal
Less
Damp
Normal
Less
Damp
Normal
Less
Damp
Normal
Less
Damp
Normal
Less
Damp
Normal
Less
Damp
Default
Time:
45Damp Dry Signal
50Damp Dry Signal
55Damp Dry Signal
38Damp Dry Signal
35Damp Dry Signal
55Damp Dry Signal
40Damp Dry Signal
39Damp Dry Signal
28Damp Dry Signal
Available
Options:
Wrinkle Shield†
Static Reduce
EcoBoost™
Wrinkle Shield†
Static Reduce
EcoBoost™
Wrinkle Shield†
Static Reduce
EcoBoost™
Wrinkle Shield†
Static Reduce
EcoBoost™
Wrinkle Shield†
Static Reduce
EcoBoost™
Wrinkle Shield
EcoBoost™
Wrinkle Shield†
Static Reduce
EcoBoost™
Wrinkle Shield†
Static Reduce
EcoBoost™
Wrinkle Shield†
Static Reduce
EcoBoost™
Cycle Details:
†
†
Extended high-heat drying cycle
intended to help sanitize items such
as bedding, towels, and baby wear.
This cycle is not recommended for
all fabrics. For best results, run cycle
to completion, do not interrupt.
Offers stepped drying starting with
High heat, followed by Medium heat
for enhanced fabric care and energy
savings.
Stepped drying uses High heat
initially, followed by Medium heat
to drive moisture from jeans and
denims.
This is a long cycle with High heat
to thoroughly dry towels. This cycle
is not recommended for all fabrics.
Use for large loads of heavyweight
fabrics such as cotton towels.
Uses Medium heat to dry large loads
of mixed fabrics and items. Normal
is the preferred energy cycle.
Uses a stepped drying temperature
from Medium heat to Low heat for
improved moisture removal and
enhanced fabric care.
Use for drying large, bulky items;
do not overll dryer drum. Partway
through the cycle, the signal
will sound to indicate when it
is time to rearrange items for
optimal drying.
Uses Medium heat to dry sheets
and lightweight linens.
Use for drying active wear and
performance fabrics that require
special care.
Uses Extra Low heat to gently dry
delicate items.
Load Size Recommendations
For best results, follow the wet load size recommendations noted for
each cycle.
Small load: Fill the dryer drum with 3-4 items, not more than
1/4 full.
6
Medium load: Fill the dryer drum up to about 1/2 full.
Large load: Fill the dryer drum up to about 3/4 full.
Do not overload. Items need to tumble freely.
Cycle Guide – Manual Cycles
Settings and options shown in bold are default settings for that cycle. Not all features and cycles are available on all models.
Not all settings and options are available on each cycle. Default cycle times are estimated in minutes.
Adjusting drying time on Timed Dry Cycles
When you select a Timed Dry Cycle,
the default time appears in the display.
Use the Time Adjust buttons to increase
or decrease the time in 1 minute
increments. Press and hold to change
the time in 5 minute increments.
The maximum dry time is 90 minutes.
Items to dry:
Small loads and Quick Dry High 13 Wrinkle Shield† For small loads of 3-4 items.
sportswear Medium Low
Extra Low
Air Only
Any load Timed Dry High 40 Wrinkle Shield† Use to dry items to a damp level for items that do
NOTE: Select Air Medium not require an entire drying cycle. Select a drying
Only to dry foam, Low temperature based on the type of fabrics in your
rubber, plastic, or Extra Low load. If you are unsure of the temperature to select
heat-sensitive Air Only for a load, select the lower setting rather than the
fabrics higher setting.
Small to medium Touch Up High20Wrinkle Shield† Use this setting to help smooth out wrinkles from
loads (for non-steam Medium such items as garments packed in a suitcase or models) Low garments wrinkled from being left in the dryer. Extra Low Air Only
Cycle:
Temp:
Default
Time:
Selecting the Temp
A High heat setting may be used for drying heavyweight
items such as towels and work clothes.
A Low to Medium heat setting may be used for drying
medium-weight items such as sheets, blouses, dresses,
underwear, permanent press fabrics, and some knits.
Use a no-heat (Air Only) setting for foam, rubber, plastic,
or heat-sensitive fabrics.
Line dry bonded or laminated fabrics.
NOTE: If you have questions about drying temperatures
for various loads, refer to the care label directions.
Available
Options:
Cycle Details:
†
Or Wrinkle Shield™ with Steam (on some models). Wrinkle Shield™ with Steam is available only with High and Medium Temp settings.
Cycle Guide – Steam Cycles
Settings and options shown in bold are default settings for that cycle.
Not all settings and options are available on each cycle.
Steam cycles are designed for use with dry loads to loosen wrinkles, reduce odors, and refresh fabrics.
Items to
refresh:
Mixed loads Enhanced High 22 Wrinkle Shield† Use to reduce odors and light wrinkles from small to
Touch Up MediumStatic Reduce medium-sized loads of dry items. Dry time will
automatically adjust when the load size is sensed.
Cycle run time cannot be manually adjusted.
Temperature is selectable. Do not add dryer sheets.
Shirts, blouses, Quick Medium 12 Wrinkle Shield† The Quick Refresh cycle is best for reducing light
and slacks Refresh Static Reduce wrinkles and odors from dry garments, including
(on some loads left in the dryer. For the Quick Refresh cycle,
models) time is selectable in 5 minute increments, based on
the load to be refreshed.
†
Or Wrinkle Shield™ with Steam (on some models). Wrinkle Shield™ with Steam is available only with High and Medium Temp settings.
Load Size Recommendations
For best results, follow the load size recommendations noted
for each cycle.
Cycle:
Drying
Temperature:
Default
Time:
Available
Options:
Medium load: Fill the dryer drum up to about 1/2 full.
Cycle Details:
Small load: Fill the dryer drum with 3-4 items, not more
than 1/4 full.
Large load: Fill the dryer drum up to about 3/4 full.
Do not overload. Items need to tumble freely.
7
Using Your Dryer
WARNING: To reduce the risk of re, electric shock, or injury to
persons, read the IMPORTANT SAFETY INSTRUCTIONS before
operating this appliance.
1.Clean the lint screen
3.Press POWER
Clean the lint screen before each load. Pull the lint screen
straight up. Roll lint off the screen with your ngers. Do not rinse
or wash screen to remove lint. Wet lint is hard to remove. Push
the lint screen rmly back into place.
For additional cleaning information, see “Dryer Care.”
2.Load the dryer
Open the door by pulling on the handle. Place laundry in the
dryer. Add a dryer sheet to wet load, if desired. Close the door.
IMPORTANT: Do not overload the dryer. Items need to tumble
freely. Overloading can lead to poor drying performance and
may increase wrinkling and tangling.
Press the POWER button to turn on the dryer.
4.Select the desired cycle
Select the desired cycle for your load. See the “Cycle Guide”
for more information about each cycle.
NOTE: Not all cycles are available on all models.
8
5.Adjust cycle modiers, if desired
7.Press START/PAUSE to begin cycle
Press and hold the START/PAUSE button to begin the cycle.
You may adjust different settings, depending on whether you
have selected an Automatic Cycle, or Manual Cycle. See the
“Cycle Guide” for detailed information.
NOTE: Not all options and settings are available with all cycles.
Not all cycles are on all models.
Automatic Cycles:
You can select a different Dryness Level, depending on your
load, by pressing the Dryness Level button. Selecting More,
Normal, Less, or Damp automatically adjusts the Dryness Level
at which the dryer will shut off. Once the Dryness Level is set,
it cannot be changed without stopping the cycle.
Sensor cycles give the best drying in the shortest time. Drying
time varies based on fabric type, load size, and dryness setting.
Timed Cycles:
When you select a Timed Cycle, the default
time appears in the display. Use the Time
Adjust buttons to increase or decrease the
time in 1 minute increments. Press and hold
to change the time in 5 minute increments.
The default temperature may be changed by pressing
the Temp button until the desired drying temperature lights up.
Steam Cycles:
Quick Refresh with Steam:
Reduces odors and light wrinkles from small to medium-sized
loads of dry items. Use the Time Adjust buttons to select the
time appropriate for the load you want to dry. Cycle time is
adjustable in 5 minute increments.
Enhanced Touch Up with Steam:
This cycle is best for reducing wrinkles and odors from dry
garments. Dry time will automatically adjust when the load size
is sensed. Temperature is selectable.
6.Select any additional options
8.Remove garments promptly
after cycle is nished
Promptly remove garments after cycle has completed to
reduce wrinkling. If you will be unable to remove the load
promptly, select the WRINKLE SHIELD
Steam) before pressing START/PAUSE.
Changing the Automatic Cycle settings
to increase drying time
If all your loads on all Automatic Cycles are consistently
not as dry as you would like or are too dry, you may change
the default settings to increase or decrease the default
Dryness Level.
The sensor drying settings on Automatic Cycles can be
adjusted to adapt to different installations, environmental
conditions or personal preference. This change is retained
and will affect all of your Automatic Cycles, not just the
current cycle/load.
There are 5 drying settings, they will appear in the time
display:
01 Factory preset dryness level.
02 Slightly drier clothes, 15% more drying time.
03 Much drier clothes, 30% more drying time.
04 Much damper clothes, 30% less drying time.
05 Slightly damper clothes, 15% less drying time.
To change the drying settings:
NOTE: The settings cannot be changed while the dryer
is running or paused. The dryer must be in standby mode
(the Power button is off) to adjust the default settings.
1. Before starting a cycle, press and hold the TEMP
button for 6 seconds.
2. Press the DRYNESS LEVEL button to select the dryness
level shown in the time display: 01, 02, 03, 04, or 05.
3. Press START/PAUSE to save the new Dryness Level
setting.
™
option (with or without
Add additional options such as EcoBoost™, Static Reduce,
and Wrinkle Shield™ (with or without Steam) by pressing
the button for that option.
NOTE: Not all options and settings are available with all cycles.
9
Additional Features
USING THE DRYING RACK
To obtain a drying rack for your dryer, follow the instructions
included in your dryer drum. Remove and discard any
packing material before use.
Use the Drying Rack for items that you do not want to
tumble dry, such as sweaters and tennis shoes. When you
use the drying rack, the drum continues to turn, but the rack
remains stationary.
The drying rack is intended for use with the Timed Dry
Cycles only. The drying rack cannot be used with any
Automatic Cycles.
To use the drying rack:
IMPORTANT: Do not remove the lint screen.
1. Open dryer door.
CHANGING THE DRUM LIGHT
The dryer light automatically turns on inside the dryer drum
when you open the door.
To change the drum light:
1. Unplug dryer or disconnect power.
2. Open the dryer door. Locate the light bulb cover on the
back wall of the dryer. Remove the screw located in the
lower right corner of the cover. Remove the cover.
2. Align the two hooks on the front of the drying rack with
the holes in the dryer door opening and press down fully
into holes. Rest the rear support on the dryer back ledge.
3. Place wet items on top of the drying rack. Allow space
around items for air to circulate. The drying rack does
not move, but the drum will rotate; be sure to leave
adequate clearance between items and the inside
of the dryer drum. Make sure items do not hang over
the edges or between drying rack grille.
4. Close the door.
5. Select Timed Dry. Select the Air Only, Low or Extra Low
Temp setting. Items containing foam, rubber, or plastic
must be dried on a clothesline or by using the Air Only
Temp setting.
6. When the cycle is selected, the Estimated Time
Remaining display shows the default time. You can
change the actual time in the cycle by increasing or
decreasing the cycle time.
7. Press START/PAUSE.
NOTE: Check the lint screen and remove any lint
accumulated from items dried on the drying rack
after the cycle is nished.
3. Turn bulb counterclockwise. Replace the bulb with
a 10-watt appliance bulb only. Replace the cover and
secure with the screw.
4. Plug in dryer or reconnect power.
10
Dryer Care
CLEANING THE DRYER LOCATION
Keep dryer area clear and free from items that would
block the air ow for proper dryer operation. This includes
clearing piles of laundry in front of the dryer.
CLEANING THE DRYER INTERIOR
To clean dryer drum
1. Use a mild hand dish detergent mixed at a low
concentration with very warm water, and rub with
a soft cloth.
2. Rinse well with a wet sponge or towel.
3. Tumble a load of clean clothes or towels to dry drum
OR
Use a microber cloth and hot water in a spray bottle
to clean the drum and a second microber towel to dry.
NOTE: Garments that contain unstable dyes, such as
denim blue jeans or brightly colored cotton items, may
discolor the rear of the dryer interior. These stains are
not harmful to your dryer and will not stain future loads
of clothes. Dry unstable dye items inside out to avoid
transfer of dye.
REMOVING ACCUMULATED LINT
From inside the dryer cabinet
Lint should be removed every 2 years, or more often,
depending on dryer usage. Cleaning should be done
by a qualied appliance servicer.
From the Exhaust Vent
Lint should be removed every 2 years, or more often,
depending on dryer usage.
CLEANING THE LINT SCREEN
Every load cleaning
The lint screen is located in the door opening of the dryer.
The control panel has an indicator light to remind you to
clean the lint screen after each load. A screen blocked
by lint will increase drying time.
To clean:
1. Pull the lint screen straight up. Roll lint off the screen
with your ngers. Do not rinse or wash screen to remove
lint. Wet lint is hard to remove.
2. Push the lint screen rmly back into place.
IMPORTANT:
n
Do not run the dryer with the lint screen loose,
damaged, blocked, or missing. Doing so can cause
overheating and damage to both the dryer and fabrics.
n
If lint falls off the screen into the dryer during removal,
check the exhaust hood and remove the lint. See
“Venting Requirements”.
As needed cleaning
Laundry detergent and fabric softener residue can build
up on the lint screen. This buildup can cause longer drying
times for your clothes, or cause the dryer to stop before
your load is completely dry. The screen is probably clogged
if lint falls off while the screen is in the dryer.
Clean the lint screen with a nylon brush every 6 months,
or more frequently, if it becomes clogged due to a residue
buildup.
To wash:
1. Roll lint off the screen with your ngers.
2. Wet both sides of lint screen with hot water.
3. Wet a nylon brush with
hot water and liquid detergent.
Scrub lint screen with the brush
to remove residue buildup.
4. Rinse screen with hot water.
5. Thoroughly dry lint screen with a clean towel.
Reinstall screen in dryer.
11
Loading...
+ 25 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
