Whirlpool MWF800 User Manual

MICROWAVE OVEN

Model: MWF 800

Owner's Manual

用戶使用手冊

Please read these instructions carefully before installing and operating the oven. Record in the space below the SERIAL NO. found on the nameplate on your oven and retain this information for future reference. SERIAL NO.

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE

TO EXCESSIVE MICROWAVE ENERGY

1. Do not attempt to operate this oven with the door open since open door operation can

result in harmful exposure to microwave energy . It is import ant not to defeat or t amper with the safety interlocks.

2. Do not place any object between the oven front face and the door or allow soil or cleaner

residue to accumulate on sealing surfaces.

3. Do not operate the oven if it is damaged. It is particularly important that the oven door

close properly and that there is no damage to the

a. Door (bent), b. Hinges and latches (broken or loosened), c. Door seals and sealing surfaces.

4. The oven should not be adjusted or repaired by anyone except properly qualified service

personnel.

CONTENT

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWA VE ENERGY ............. 1

IMPORTANT SAFETY INSTRUCTIONS ................................................................................................... 2

SPECIFICA TIONS ..................................................................................................................................... 4

INSTALLATION .......................................................................................................................................... 4

RADIO INTERFERENCE ........................................................................................................................... 4

MICROWAVE COOKING PRINCIPLES .................................................................................................... 5

GROUNDING INSTRUCTIONS ................................................................................................................. 5

BEFORE YOU CALL FOR SERVICE ........................................................................................................ 5

UTENSILS GUIDE ..................................................................................................................................... 6

PART NAMES ............................................................................................................................................ 6

CONTROL PANEL ..................................................................................................................................... 7

Power/Action Selector ....................................................................................................................... 7

Timer Knob ........................................................................................................................................ 7

Microwave Cooking .......................................................................................................................... 7

OPERA TION .............................................................................................................................................. 8

CLEANING AND CARE ............................................................................................................................. 8

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliance basic safety precautions should be followed, including the following:

WARNING: To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy:

1. Read all instructions before using the appliance. Carefully and keep for future reference.

2. Use this appliance only for its intended use as described in this manual. Do not use corrosive chemicals or vapors in this appliance. This type of oven is specifically designed to heat, cook or dry food. It is not designed for industrial or laboratory use.

3. Do not operate the oven when empty.

4. Do not operate this appliance if it has a damaged cord or plug, if it is not working properly or if it has been damaged or dropped. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard

5. WARNING: Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use.

6. To reduce the risk of fire in the oven cavity:

a) When heating food in plastic or paper

container, keep an eye on the oven due to the possibility of ignition.

b) Remove wire twist-ties from paper or plastic

bags before placing bag in oven.

c) If smoke is observed, switch off or unplug the

appliance and keep the door closed in order to stifle any flames.

d) Do not use the cavity for storage purposes.

Do not leave paper products, cooking utensils or food in the cavity when not in use.

7. WARNING: Liquid or other food must not be heated in sealed containers since they are liable to explode.

8. Microwave heating of beverage can result in delayed eruptive boiling, therefore care has to be taken when handle the container.

9. Do not fry food in the oven. Hot oil can damage oven parts and utensils and even result in skin burns.

10. Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode even after microwave heating has ended.

11. Pierce foods with heavy skins such as potatoes, whole squashes, apples and chestnuts before cooking.

12. The contents of feeding bottles and baby jars should be stirred or shaken and the temperature should be checked before consumption in order to avoid burns.

13. Cooking utensils may become hot because of heat transferred from the heated food. Potholders may be needed to handle the utensil.

14. Utensils should be checked to ensure that they are suitable for use in microwave oven.

15. WARNING: It is hazardous for anyone other than a trained person to carry out any service or repair operation which involves the removal of any cover which gives protection against exposure to microwave energy.

16. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

17. Children should be supervised to ensure that they do not play with the appliance.

18. The microwave oven is only used in freestanding.

19. WARNING: Do not install oven over a range cooktop or other heat-producing appliance. if installed could be damaged and the warranty would be avoid .

20. The accessible surface may be hot during operation.

21. The microwave oven shall not be placed in a cabinet unless it has been tested in a cabinet.

22. For microwave ovens having an additional decorative door, and for microwave ovens intended to be used in a cabinet, the instructions for use shall state that the microwave oven must be operated with the decorative door open.

23. The door or the outer surface may get hot when the appliance is operating.

24. The temperature of accessible surfaces may be high when the appliance is operating.

25. The appliance shall be placed against a wall .

26. WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person.

27. The instructions shall state that appliances are not intended to be operated by means of an external timer or separate remote-control

system.

28. Never remove the distance holder in the back or on the sides, as it ensures a minimum distance from the wall for air circulation.

29. Please secure the turn table before you move the appliance to avoid damages.

30. Caution: It is dangerous to repair or maintain the appliance by no other than a specialist because under these circumstances the cover have to be removed which assures protection against microwave radiation. This applies to changing the power cord or the lighting as well. Send the appliance in these cases to our service centre.

31. The microwave oven is intended for defrosting, cooking and steaming of food only.

32. Caution! Steam will escape, when opening lids or wrapping foil.

33. Only use the temperature probe recommended for this oven (for appliances having a facility to use a temperature-sensing probe).

SPECIFICATIONS

Power Consumption: 230V~50Hz, 1400W(Microwave) Rated microwave power output: 900W Operation Frequency: 2450MHz Oven Capacity: 23 Liters

INSTALLATION

1. Make sure that all the packing materials are removed from the inside of the door.

2. This microwave oven must be placed on a flat, stable surface to hold its weight and the heaviest food likely to be cooked in the oven.

3. Do not place the oven where heat, moisture, or high humidity are generated, or near combustible materials.

4. For correct operation, the oven must have sufficient airflow. Allow 20cm of space above the oven, 10cm at back and 5cm at both sides. Do not cover or block any openings on

RADIO INTERFERENCE

Operation of the microwave oven can cause interference to your radio, TV, or similar equipment. When there is interference, it may be reduced or eliminated by taking the following measures:

1. Clean door and sealing surface of the oven.

2. Reorient the receiving ante nna of radio or

the appliance. Do not remove feet.

5. Do not operate the oven without glass tr ay, roller support, and shaft in their proper positions.

6. Make sure that the power supply cord is undamaged and does not run under the oven or over any hot or sharp surface.

7. The socket must be readily accessible so that it can be easily unplugged in an emergency.

8. Do not use the oven outdoors.

television.

3. Relocate the microwave oven with respect to the receiver.

4. Move the microwave oven away from the receiver.

5. Plug the microwave oven into a different outlet so that microwave oven and receiver are on different branch circuits.

MICROWAVE COOKING PRINCIPLES

1. Arrange food carefully. Place thickest areas towards outside of dish.

2. Watch cooking time. Cook for the shortest amount of time indicated and add more as needed. Food severely overcooked can smoke or ignite.

3. Cover foods while cooking. Covers prevent spattering and help foods to cook evenly.

GROUNDING INSTRUCTIONS

This appliance must be grounded. This oven is equipped with a cord having a grounding wire with a grounding plug. It must be plugged into a wall receptacle that is properly installed and grounded. In the event of an electrical short circuit, grounding reduces risk of electric shock by providing an escape wire for the electric current. It is recommended that a separate circuit serving only the oven be provided. Using a high voltage is dangerous and may result in a fire or other accident causing oven damage. WARNING Improper use of the grounding plug can result in a risk of electric shock.

Note:

4. Turn foods over once during microwave cooking to speed cooking of such foods as chicken and hamburgers. Large items like roasts must be turned over at least once.

5. Rearrange foods such as meatballs halfway through cooking both from top to bottom and from the center of the dish to the outside.

1. If you have any questions about the grounding or electrical instructions, consult a qualified electrician or service person.

2. Neither the manufacturer nor the dealer can accept any liability for damage to the oven or personal injury resulting from failure to observe the electrical connection procedures.

The wires in this cable main are colored in accordance with the following code: Green and Yellow = EARTH Blue = NEUTRAL Brown = LIVE

BEFORE YOU CALL FOR SERVICE

If the oven fails to operate:

1. Check to ensure that the oven is plugged in securely. If it is not, remove the plug from the outlet, wait 10 seconds, and plug it in again securely.

2. Check for a tripped main circuit breaker. If these seem to be operating properly, test the

IF NONE OF THE ABOVE RECTIFIES THE SITUATION, THEN CONTACT SERVICE CENTER. DO NOT TRY TO ADJUST OR REPAIR THE OVEN YOURSELF .

outlet with another appliance.

3. Check to ensure that the control panel is programmed correctly and the timer is set.

4. Check to ensure that the door is securely closed engaging the door safety lock system. Otherwise, the microwave energy will not flow into the oven.
