Whirlpool MW A12 S INSTALLATION

FRAMTID

MW 3

ENGLISH 3

Table of contents

Safety information 3 Product description 5 Control panel 7 Daily use 8 Cleaning and maintenance 12 What to do if ... 13

Technical data 14 Installation 15 Electrical connection 15 Environmental concerns 16 IKEA GUARANTEE 17

Safety Information

Read carefully and keep for future reference Do not heat, or use ﬂ ammable materials in or near the oven. Fumes can create a ﬁ re hazard or explosion. Do not use your microwave oven for drying textiles, paper, spices, herbs, wood, ﬂ owers, fruit or other combustible materials. Fire could result. If material inside / outside the oven should ignite or smoke is observed, keep oven door closed and turn the oven off. Disconnect the power cord or shut off power at the fuse or circuit breaker panel. Do not over-cook food. Fire could result. Do not leave the oven unattended, especially when using paper, plastic or other combustible materials in the cooking process. Paper can char or burn and some plastics can melt if used when heating foods. Do not use corrosive chemicals or vapors in this appliance. This type of oven is speciﬁ cally designed to heat or cook food. It is not designed for industrial or laboratory use. Only allow children to use the appliance under adult supervision and after adequate instructions have been given, so that the child is able to use the appliance in a safe way and understands the hazards of improper use. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, unless used under the supervision of a person responsible for their safety.

WARNING! Accessible parts may

become hot during use, young children should be kept away. Do not use your microwave oven for heating anything in airtight sealed containers. The pressure increases and may cause damage when opening or may explode. The door seals and the door seal areas must be regularly inspected for damage. If these areas are damaged the appliance should not be operated until it has been repaired by a trained service technician.

IMPORTANT: Eggs: Do not use your

microwave oven for cooking or reheating whole eggs with or without shell since they may explode even after microwave heating has ended.

Important precautions General

This appliance is designed for domestic use only! The appliance should not be operated without food inside. Operation in this manner is likely to damage the appliance. If you practice operating the oven, put a glass of water inside. The water will absorb the microwave energy and the oven will not be damaged. Do not use the cavity for any storage purposes. Remove wire twist-ties from paper or plastic bags before placing bag in the oven.

ENGLISH 4

Deep-frying

Do not use your microwave oven for deepfrying, because the oil temperature cannot be controlled. Use hot pads or oven mitts to prevent burns, when touching containers, oven parts, and pan after cooking.

Liquids

E.g. beverages or water. Overheating the liquid beyond boiling point can occur without evidence of bubbling. This could result in a sudden boil over of the hot liquid. To prevent this possibility the following steps should be taken:

1. Avoid using straight-sided containers with narrow necks.

2. Stir the liquid before placing the container in the oven and let the teaspoon remain in the container.

3. After heating, allow standing for a short time, stirring again before carefully removing the container from the oven.

Careful

Always refer to a microwave cookbook for details. Especially, if cooking or reheating food that contains alcohol. After heating baby food or liquids in a baby bottle or in a baby food jar, always stir and check the temperature before serving. This will ensure that the heat is evenly distributed and the risk of scalding or burns can be avoided. Ensure the Lid and the Teat is removed before heating!

ENGLISH 5

Product description

Control Panel

Cavity Lamp

Accessories

Turntable support

Glass turntable

Baby bottle holder

Cover

Door

Steamer

ENGLISH 6

Accessories General

There are a number of accessories available on the market. Before you buy, ensure they are suitable for microwave use. Ensure that the utensils you use are oven proof and allow microwaves to pass through them before cooking. When you put food and accessories in the microwave oven, ensure that they do not come in contact with the interior of the oven. This is especially important with accessories made of metal or metal parts. If accessories containing metal comes in contact with the oven interior, while the oven is in operation, sparking can occur and the oven could be damaged. Always ensure that the turntable is able to turn freely before starting the oven.

Turntable support

Use the turntable support under the Glass turntable. Never put any other utensils on the turntable support.

- Fit the turntable support in the oven.

Glass turntable

Use the Glass turntable with all cooking methods. It collects the dripping juices and food particles that otherwise would stain and soil the interior of the oven.

- Place the Glass turntable on the turntable support.

Baby bottle holder

Use the Baby bottle Holder when heating baby food in bottles that are too tall to stand-alone in the oven. Please see also, the chapter ”Precautions”, for more information about heating baby food. (Not available in the UK and Ireland).

Cover

The Cover is used to cover food during cooking and reheating with microwaves only and helps to reduce spattering, retain food moisture as well as reducing the time needed. Use the cover for two level reheating.

Steamer

Use the steamer with the strainer in place for such foods as ﬁ sh, vegetables and potatoes. Always place the steamer on the Glass Turntable.

ENGLISH 7

Control panel

864321 75

Stop button

Power button

Memo button

Steam button

+ /- button

(use this button to set time or weight)

Daily use

Start protection / Key lock

This automatic safety function is activated one minute after the oven has returned to “stand by mode“. (The oven is in “stand by” when the 24-hour clock is displayed or if the clock has not been set, when the display is blank). The door must be opened and closed e.g. putting food into it, before the safety lock is released. Else the display will show “DOOR“.

To pause or stop cooking

To pause cooking: The cooking can be paused to check, turn or stir the food by opening the door. The setting will be maintained for 10 minutes. To continue cooking: Close the door and press the Start button ONCE. The cooking is resumed from where it was paused. Pressing the Start button TWICE will increase the time by 30 seconds. If you don’t want to continue cooking: Remove the food, close the door and press the Stop button.

Jet Defrost button

Start button

Door button

(use this button to open the door)

A beep will signal once a minute for 10 minutes when the cooking is ﬁ nished. Press the Stop button or open the door to cancel the signal. NOTE: The oven will only hold the settings for 60 seconds if the door is opened and then closed after the cooking is ﬁ nished.

Cooling down

When a function is ﬁ nished, the oven carries out a cooling procedure. This is normal. After this procedure the oven switches off automatically. The cooling procedure can be interrupted without any harm to the oven.

ENGLISH 8

Kitchen timer

Use this function when you need a kitchen timer to measure exact time for various purposes such as cooking eggs or letting the dough rise before baking etc.

312

1. Press the +/- buttons to set the desired length of the timer.

2. Press the power button repeatedly to set the power to 0 W.

3. Press the Start button.

An acoustic signal will be heard when the timer has ﬁ nished to count down.

Clock

Keep the door open while setting the Clock. This gives you 5 minutes to complete the setting of the Clock. Otherwise, each step must be accomplished within 60 seconds.

1. Press the Stop button (3 seconds) until the left-hand digit (hour’s) ﬂ icker.

2. Press the +/- buttons to set the hours.

3. Press the Start button. (The two right hand digits (minutes) ﬂ icker).

4. Press the +/- buttons to set the minutes.

5. Press the Start button again.

The Clock is set and in operation. NOTE: When the appliance is ﬁ rst plugged in or after a power failure, the display is blank. If the clock is not set, the display will remain blank until the cooking time is set. If you wish to remove the Clock from the display once it has been set, simply press the Stop button again for 3 seconds and then press the Stop button once more. To reinstate the Clock, follow the above procedure.

2/4 3/5

Cook and reheat with microwaves

Use this function for normal cooking and reheating, such as vegetables, ﬁ sh, potatoes and meat.

312

1. Press the +/- buttons to set the time.

2. Press the power button repeatedly to set the power.

3. Press the Start button.

Once the cooking process has been started: The time can easily be increased in 30-second steps by pressing the Start button. Each press increases the time with 30 seconds. You may also alter the time by pressing the +/- buttons to increase or decrease the time. Pressing the power button may also change the power level. The ﬁ rst press will show you the current power level. Press the power button repeatedly to change power level. All settings can be changed during cooking if you so desire.
