INSTALLATION

MOUNTING THE APPLIANCE

FOLLOW THE SUPPLIED separate mounting in­structions when installing the appliance.

PRIOR TO CONNECTING

C

HECK THAT THE VOLTAGE on the rating plate corre-

sponds to the voltage in your home.

D

O NOT REMOVE THE MICROWAVE INLET PROTECTION

PLATES located on the side

of the oven cavity wall.
They prevent grease & food
particles from entering the
microwave inlet channels.

NSURE the oven cavity is

E

empty before mounting.

NSURE THAT THE APPLIANCE IS NOT DAMAGED. Check

E

that the oven door closes firmly against the
door support and that the internal door seal is
not damaged. Empty the oven and clean the
interior with a soft, damp cloth.

D

O NOT OPERATE THIS APPLIANCE if it has a damaged

mains cord or plug, if it is not working proper­ly, or if it has been damaged or dropped. Do
not immerse the mains cord or plug in water.
Keep the cord away from hot surfaces. Electri­cal shock, fire or other hazards may result.

DO NOT USE EXTENSION CORD:

I

F THE POWER SUPPLY CORD IS TOO SHORT, have a

qualified electrician or serviceman install
an outlet near the appliance.

AFTER CONNECTING

T

HE OVEN CAN BE OPERATED ONLY if the oven door is

firmly closed.
THE EARTHING OF THIS APPLIANCE is compulsory. The
manufacturer will accept no responsibility for
injury to persons, animals or damage to ob­jects arising from the non-observance of this
requirement.

The manufacturers are not liable for any
problems caused by the user’s failure to ob­serve these instructions.

2

HE FIRST TIME THE OVEN IS SW ITCHED ON, you will be

T

asked to set the language and current time.
Follow the instructions under the headline
“Changing settings” in this instructions for use.
The appliance is ready to use after these two
steps have been taken.

IMPORTANT SAFETY INSTRUCTIONS

READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
DO NOT HEAT, OR USE FLAMMABLE MATERIALS in or

near the oven. Fumes can create a fire hazard
or explosion.

DO NOT USE YOUR M ICROWAVE oven for drying tex­tiles, paper, spices, herbs, wood, flowers, fruit
or other combustible materials. Fire could re­sult.

I

F MATERIAL INSIDE / OUTSIDE THE OVEN SHOULD IGNITE

OR SMOKE IS OBSERVED, keep oven door closed and

turn the oven off. Disconnect the power cord
or shut off power at the fuse or circuit break­er panel.

D

O NOT OVER-CO OK FOOD. Fire could result.

O NOT LEAVE THE OVEN UNATTENDED, especially

D

when using paper, plastic or other combusti­ble materials in the cooking process. Paper can
char or burn and some plastics can melt if used
when heating foods.

O NOT USE corrosive chemicals or vapors in this

D

appliance. This type of oven is specifically de­signed to heat or cook food. It is not designed
for industrial or laboratory use.

O

adult supervision and after adequate instructions
have been given, so that the child is able to use
the appliance in a safe way and understands the
hazards of improper use.

T

(including children) with reduced physical, senso­ry or mental capabilities, unless used under the
supervision of a person responsible for their safe­ty.

WARNING!
ACCESSI BLE PART S MAY BECOME HOT during use, young

children should be kept away.

DO NOT USE YOUR MICROWAVE oven for heat-
ing anything in airtight sealed con­tainers. The pressure increases
and may cause damage when
opening or may explode.

T

ularly inspected for damage. If these areas are
damaged the appliance should not be operat­ed until it has been repaired by a trained service
technician.

EGGS

D

ing or reheating whole eggs with or
without shell since they may
explode even after microwave
heating has ended.

NLY ALLOW CHILDREN to use the appliance under

HIS APPLIANCE IS NOT INTENDED FOR use by persons

HE DOOR SEALS AND THE DOOR SEAL AREAS must be reg-

O NOT USE YOUR MICROWAVE oven for cook-

3

IMPORTANT PRECAUTIONS

GENERAL

HIS APPLIANCE IS DESIGNED FOR DOMESTIC USE ONLY!

T

HE APPLIANCE SHOULD NOT BE OPERATED without food

T

in the oven when using microwaves. Operation in
this manner is likely to damage the appliance.

F YOU PRACTICE OPERATING the oven, put a glass

I

of water inside. The water will absorb the mi­crowave energy and the oven will not be dam­aged.

O NOT USE THE CAVITY for any storage purposes.

D

REMOVE WIRE TWIST-TIES from paper or
plastic bags before placing bag in
the oven.

DEEPFRYING

D

O NOT USE YOUR MICROWAVE oven for deep-frying,

because the oil temperature cannot be
controlled.

USE HOT PADS OR OVEN MITTS to prevent burns,
when touching containers, oven parts, and
pan after cooking.

LIQUIDS

E.

G. BEVERAGES OR WATER. Overheating the liquid

beyond boiling point can occur
without evidence of bubbling.
This could result in a sudden
boil over of the hot liquid.
To prevent this possibility the
following steps should be taken:

1. Avoid using straight-sided containers with
narrow necks.

2. Stir the liquid before placing the container
in the oven and let the teaspoon remain
in the container.

3. After heating, allow standing for a short
time, stirring again before carefully re­moving the container from the oven.

CAREFUL

A

LWAYS REFER to a microwave cookbook for de-

tails. Especially, if cooking or reheating food
that contains alcohol.

A

FTER HEATING BABY FOOD or liquids in a

baby bottle or in a baby food
jar, always stir and check the
temperature before serving.
This will ensure that the heat is evenly distributed
and the risk of scalding or burns can be avoided.

Ensure the Lid and the Teat is removed be­fore heating!

PUSH  PUSH KNOBS
THE KNOBS OF THIS OVEN are aligned with
the buttons on the panel, at delivery.
The knobs will slide out if pushed
and their various functions
can be accessed. It is not
necessary to have them petruding
from the panel during operation.
Simply push them back into the panel
when you are done with the setting and
continue to operate the oven.

4

ACCESSORIES

GENERAL

HERE ARE a number of accessories available on

T

the market. Before you buy, ensure they are
suitable for microwave use.

E

NSURE THAT THE UTENSILS YOU USE are oven proof

and allow microwaves to
pass through them before
cooking.

W

HEN YOU PUT FOOD AND ACCESSORIES in the micro-

wave oven, ensure that they do not come in
contact with the interior of the oven.

This is especially important with accesso­ries made of metal or metal parts.

F ACCESSORIES CONTAINING METAL comes in contact

I

with the oven interior, while the oven is in op­eration, sparking can occur and the oven could
be damaged.

LWAYS ENSURE that the turntable is able to turn

A

freely before starting the oven.

TURNTABLE SUPPORT
USE THE TURNTABLE SUPPORT under the
Glass turntable. Never put any oth­er utensils on the turntable sup­port.

 Fit the turntable support in the oven.

GLASS TURNTABLE

U

SE THE GLASS TURNTABLE with all cooking meth-

ods. It collects the dripping juic­es and food particles that other­wise would stain and soil the in­terior of the oven.

 Place the Glass turntable on the turntable

support.

WIRE RACK

SE THE WIRE RACK when grilling

U

using the Grill functions.

CRISP HANDLE

SE THE SUPPLIED SPECIAL CRISP HAN-

U

DLE to remove the hot Crisp plate

from the oven.

CRISP-PLATE

P

LACE THE FOOD DIRECTLY ON THE CRISP-PLATE.

Always use the Glass turn­table as support when us­ing the Crisp-plate.
DO NOT PLACE ANY UTENSILS on the
Crisp-plate since it will quickly be­come very hot and is likely to cause
damage to the utensil.
THE CRISP-PLATE may be preheated before use
(max. 3 min..). Always use the Crisp function
when preheating the crisp-plate.

STEAMER

SE THE STEAMER WITH THE

U

STRAINER in place for foods

such as fish, vegetables and
potatoes.

USE THE STEAMER WITHOUT THE

STRAINER in place for foods such as rice, pasta

and white beans.
ALWAYS place the steamer on the Glass Turnta-
ble.

COVER
THE COVER is used to cover food dur­ing cooking and reheating with mi­crowaves only and helps to reduce
spattering, retain food moisture as
well as reducing the time needed.
USE the cover for two level reheat­ing

5

START PROTECTION

THE START PROTECTION FUNCTION IS ACTIVATED ONE

MINUTE AFTER the oven has returned to

“stand by mode“.

THE DOOR MUST BE OPENED AND CLOSED e.g. putting
food into it, before the safety lock is released.

Safety Lock is activated

close door and press

KEY LOCK

19:30



PRESS THE BACK AND OK buttons simultaneously and keep pressed until two beeps are heard



(3 seconds).

U

SE THIS FUNCTIO N to hinder children from using the oven

unattended.

WHEN THE LOCK IS ACTIVE, all buttons are non-responsive.

P

LEASE NOTE: These buttons only work in conjunction

when the oven is turned OFF.

CONFIR MATION MESSAGE is displayed for 3 seconds be-

A

fore returning to the previous view.
THE KEY LOCK ID DEACTIVATED the same way it was acti-
vated.

Key Lock

has been activated

Key Lock

has been deactivated



6

DONENESS (AUTO FUNCTI ONS ONLY)

D

ONENESS IS AVAILABLE in most of the auto func-

tions. You have the possibility to personal­ly control the end result through the Adjust
doneness feature. This feature enables you to
achieve higher or lower end temperature com­pared to the default standard setting.

HEN USING one of these functions the oven

W

chooses the default standard setting. This set­ting normally gives you the best result. But if
the food you heated became too warm to eat
at once, you can easily adjust this before you
use that function the next time.

THIS IS DONE BY SELECTING A DONENESS LEVEL with the
Adjust knob before pressing the Start button.

DONENESS

EVEL EFFECT

L

EXTRA YIELDS HIGHEST END TEMPERATURE
NORMAL DEFAULT STANDARD SETTING
LIGHT YIELDS LOWEST END TEMPERATURE

400g

WEIGHT

Fruit Pie

8

AMOUNT

Extra

DONENESS

30:00300g

COOK TIME

19:30

END TIME

WEIGHT

Normal

DONENESS

Light

DONENESS

Steamed Fillets

Rolls

MESSAGES

HEN USING SOME OF THE FUNCTIO NS the oven may

W

stop and prompt you to perform an action or
simply advice on which accsessoire to use.

Insert food in steamer

Press when done

Cooking nearly finished

Please check on food

Please add milk

Press when done

W

Please use

high wire rack

HEN A MESSAGE APPEAR:

 Open the door (if needed).
 Perform the action (if needed).
 Close the door and restart by pressing the

Start button.

Please stir food

Please turn food

Temperature reached

Insert food and press

7

COOLING DOWN

T

WHEN A FUNCTION IS FIN ISHED, the oven may carry
out a cooling procedure. This is normal.

HE COOLIN G PROCEDURE can be interrupted with-

out any harm to the oven by opening the door.
After this procedure the oven switches off au­tomatically.

SHORTCUTS

TO FAVO R THE EASE OF USE, the oven automatical-
ly compiles a list of your favorite shortcuts for
you to use.
WHEN YOU BEGIN using your oven, the list con­sists of 10 empty positions marked “shortcut”.
As you use the oven over time, it will automat­ically fill in the list with shortcuts to your most
frequently used functions.
WHEN YOU ENTER THE SHORTCUT MENU, the function
you have been using mostly, will be pre-select­ed and positioned as shortcut #1.
NOTE: the order of functions presented in the
shortcut menu will automatically change ac­cording to your cooking habits.

French Fries

Pan Pizza

Lasagna

Your most used cooking functions



TURN THE MULTIFUNCTION KNOB until Shortcut is displayed



TURN THE ADJUST KNOB to choose your favorite shortcut. The most frequently used function is





.





pre-selected.

PRESS THE OK BUTTON to confirm your selection.



TURN THE ADJUST KNOB / OK BUT TON to make the needed adjustments.



PRESS THE START BUTTON.



Shortcut
Shortcut
Shortcut

Your most used cooking functions

French Fries

Shortcut

Your most used cooking functions

French Fries

Pan Pizza

Lasagna

Your most used cooking functions



8

ON/OFF

T

HE APPLIANCE IS TURNED ON OR OFF

using the On/Off button or simply
by turning the Multifunction Knob.

W

HEN THE APPLIANCE IS TURNED ON , all

buttons & knobs function normal­ly and the 24 hour clock is not dis­played.

WHEN THE APPLIANCE IS TURNED OFF , all the buttons
and the Adjust Knob is non-responsive. The 24
hour clock is displayed.

N

OTE: The oven behavior may differ from the

above described, depending on the ECO func­tion being turned ON or OFF (see ECO for more
information).

HE DESCRIPTIONS IN THIS IFU assume that the

T

oven is turned ON .

CHANGING SETTINGS

Settings



TURN THE MULTIFUNCTION KNOB until Settings is shown.



TURN THE ADJUST KNOB to choose one of the settings to adjust.



PRESS THE BACK BUTTON TO EXIT the settings function when you are done.





WHEN THE APPLIANCE IS FIRST PLUGGED IN it will ask you to set the Lan­guage and 24 hour Clock.

AFTER A POWER FAILURE the Clock will flash and needs to be reset.
YOUR OVEN HAS a number of functions which can be adjusted to your

personal taste.



LANGUAGE

Eco Mode
Language

Appliance and display settings

PRESS THE OK BUTTON .



TURN THE ADJUST KNOB to choose one of the available lan-



guages.

PRESS THE OK BUTTON again to confirm the change.



Time







Turkçe
English

Français

Please select language

Language

has been set

9

CHANGING SETTINGS

CLOCK SETTING

Time

Volume

Brightness

Appliance and display settings

TURN THE ADJUST KNOB until Time is displayed.



PRESS THE OK BUTTON . (The digits flicker).



TURN THE ADJUST KNOB to set the 24 hour clock.



PRESS THE OK BUTTON again to confirm the change.



T

HE CLOCK IS SET AND IN OPERATION.







00 : 00

(HH) (MM)

^
^

Press to set time, to confirm

Time

has been set

SOUND SETTING

Time

Volume

Brightness

Appliance and display settings

TURN THE ADJUST KNOB until Volume is displayed.



PRESS THE OK BUTTON .



TURN THE ADJUST KNOB to set the volume on high, medium, low



or mute.

PRESS THE OK BUTTON again to confirm the change.



10







For normal living conditions

has been set

Volume

High

Medium

Low

CHANGING SETTINGS

BRIGHTNESS

Volume
Brightness
Eco Mode

Appliance and display settings





TURN THE ADJUST KNOB until Brightness is displayed.



PRESS THE OK BUTTON .



TURN THE ADJUST KNOB to set the level of brightness suitable to your



preference.

PRESS THE OK BUTTON again to confirm your selection.





For normal living conditions

Medium

Brightness

has been set

High

Low

e e

e

Appliance and display settings

TURN THE ADJUST KNOB until Eco Mode is displayed.



PRESS THE OK BUTTON .



TURN THE ADJUST KNOB to turn the ECO setting ON or OFF.



PRESS THE OK BUTTON again to confirm the change.



W

HEN ECO IS ON, the display will automatically turn off after a while

to save energy. It will automatically light up again when a button is
pressed or the door is opened.
WHEN OFF IS SET, the display will not turn off and the 24 h clock will
always be visible.

ECO

Brightness

Eco Mode
Language







e

Off
On

Minimal power consumption

e

Eco Mode

has been set

11

CHANGING SETTINGS

DURING COOKING

O

NCE THE COOKIN G PROCESS HAS BEEN STARTED:

The time can easily be increased in 30-second steps by pressing
the Start button. Each press increases the time with 30 seconds. You
may also Turn the Adjust Knob to increase or decrease the time.

BY TURNING THE ADJUST KNOB, you may toggle be­tween the parameters to select which you wish
to alter.

RESSING THE OK BUTTON selects and enables it to be changed (it

P

High 07:00

GRILL POWER COOK TIME

200 g

WEIGHT

flashes). Turn the Adjust Knob to alter your setting.
PRESS THE OK BUTTON AGAIN to confirm your selection. The oven con­tinues automatically with the new setting.

Y PRESSING THE BACK BUTTON you may return directly to the last pa-

B

rameter you changed.

12

KITCHEN TIMER

00 : 00 : 00

(HH) (MM) (SS)

^
^

Press to set Timer, to Start



TURN THE OVEN OFF by turning theMultifunction Knob to the Zero position or pressing the On



/ Off button.

PRESS THE OK BUTTON .



TURN THE ADJUST KNOB to set the desired length of the timer.



PRESS THE OK BUTTON to start the timer countdown



USE THIS FUNCTIO N when you need a kitchen timer to
measure exact time for various purposes such as cook­ing eggs or letting the dough rise before baking etc.
THIS FUNCTION IS ONLY AVALIABLE when the oven is switched
off or in standby mode.

A

N ACOUSTI C SIGNAL will be heard when the timer has fin-

ished to count down.

RESSING THE ON / OFF BUTTON before the timer has finished will switch

P

the timer off.



.



00 : 59 : 59

Timer

00 : 00 : 00

Press to prolong, to switch off

^

COOK & REHEAT WITH MICROWAVES

Microwave



TURN THE MULTIFUNCTION KNOB until Microwave is shown.



TURN THE ADJUST KNOB to set the cooking time.



PRESS THE OK BUTTON to confirm your setting.



TURN THE ADJUST KNOB to set the microwave power level.



PRESS THE START BUTTON.



SE THIS FUNCTIO N for normal cooking and reheating, such as vegeta-

U

bles, fish, potatoes and meat.









750 w 00:05

POWER

Microwave

COOK TIME

19:00

END TIME

13

COOK & REHEAT WITH MICROWAVES

POWER LEVEL

MICROWAVES ONLY

P

OWER SUGGESTED USE:

R

900 W

750 W C

EHEATING OF BEVERAGES, water, clear soups, coffee, tea or other food with a high water

content. If the food contains egg or cream choose a lower power.

OOKING OF VEGETABLES, meat etc.

650 W C

500 W

350 W S
160 W D
90 W S
0 W W

OOKING OF fish.

ORE CAREFUL COOKIN G e.g. high protein sauces, cheese and egg dishes and to finish cook-

M

ing casseroles.

IMMERING STEWS, melting butter & chocolate.

EFROSTING. Softening butter, cheeses.

OFTENING Ice cream

HEN USING the Timer only.

14
