Whirlpool 6ADP 5966 Quick Reference Guide
Before using the dishwasher, read the user instructions!
6ADP 5966
Program selector knob
On / Off
Mains
Start button
Switches “on” when the dishwasher is
operating. Flashes when a fault occurs.
Switches off at the end of the programme.
Indicators
Add rinse aid
Wash cycle
Pre-Rinse Washing Drying
Programme chart
Quick Reference Guide
Options
“Half load - Multizone” button
Load the upper or lower rack
This function can be used with any programme.
Press once = upper rack (the indicator lamp comes on)
Press twice = lower rack (the indicator lamp comes on)
Press 3 times = Off (half load function deactivated).
Time and failure display
Indicates in hours the time remaining until the
start of the wash cycle. Toward the end of the
programme, during the drying cycle, the display
will indicate the time remaining in minutes.
“F...” Identification of faults for service technician
“Delayed start” button
The wash cycle can be programmed to start after 1 24 hours. With each successive touch of the button,
the delayed start indicator increases by 1 hour, and
after 24 returns to 00. Then press the Start button.
Programme
end
The dishwasher will start at the set time.
Detergent
GB
only
.
3)
2)
Consumption
3)
Programmes Loading instructions A B Litres kWh Minutes
Sensor Wash
Sensor Intensive
40-55°C
60-70°C
Pre-Rinse cold
Glass 40°C
Quickwash 40°C
1)
Normal
1) Reference program for energy label compliance with
AS/NZS 2007;
2) Refer to “User instructions“;
Important information for Test Laboratories:
For detailed information on the EN comparison test and othe r te sts, contact the following address:
“nk_customer@email.whirlpool.com”.
Whirlpool is a registered trademark of Whirlpool USA
Automatic programme recommended
for routine washes, with no dried-on
or burnt food (not for EN 50242).
Automatic programme recommended
for heavily soiled crockery with driedon or burnt food, for example pans and
saucepans.
Crockery to be washed later.
Light soiling, for example glasses and
cups.
Lightly soiled crockery with no driedon food.
Normally or heavily soiled crockery.
40°C
X X 10.0-13.0 0.80-1.05 50-110
X X 13.0-20.0 1.10-2.00 90-140
- - 4.0 0.03 14
X - 10.0 0.80 55
X - 10.0 0.65 30
X X
3) Program data obtained in conformity with European standard
EN 50242. Values may vary in relation to usage, e.g.:
different loads, water temperatures - above or below 15°C as well as water hardness and power supply voltage, etc.
(We reserve the right to make technical modifications)
17.0 0.89 98
5019 396 91273
WH/I/K/AUS
How to use the appliance
Further indications are given in the single chapters and in the user instructions.
Switch on the appliance
How to fill the detergent
Check the rinse aid level
Check the regeneration
salt level
Load the racks
Close the dishwasher door,
turn on the water tap
Select a programme
Automatic start by turning the programme selector knob (in case of
retractable knob, first press the knob to access it).
Large compartment A:
With each wash cycle.
Small compartment B:
For programmes with pre-wash only.
Mechanical indicator C.
Electric indicator on control panel (if provided).
On models with water softener
system only.
Mechanical indicator D. Electric
indicator on control panel (if provided).
Refer to the dishwasher loading instructions.
Select the desired programme.
The corresponding indicator lamp comes on.
AB
C
Select options
Press the Start button
Wash cycle
Switch off the appliance
Turn off the water tap,
unload the racks
If necessary (and if provided) the corresponding indicator lamp lights up.
The selected programme is
then memorised (even in the
event of power failure).
Only after the START button has switched off: Access the knob (in case of
retractable knob, press and then release the knob).
To accelerate the drying process, slightly open the door at the end of the
program.
WARNING: WHEN THE DOOR IS OPENED STEAM COMES OUT!
Unload the appliance, starting from the lower rack.
“Change programme”
Press the START button for 2 sec. until
the Start indicator lamp switches off;
Select another programme and
press the START button again.
- Only open the dishwasher if necessary
(Warning: beware of hot steam).
- If the appliance is switched off during a
wash cycle, when switched on again it
will resume the cycle from where it was
interrupted.
WH/II/K/AUS
