Page 1
ONE AND TW O SPEED
A UT OMATIC WASHERS
Use & Care Guide
For questions about features, operation /performance,
parts, accessories or service call: 1-800-253-1301
or visit our website at
www.estateappliances.com
Table of Contents....................... ...... ..... ...... ...............2
3953962
Page 2
TABLE OF CONTENTS
WASHER SAFETY............................................................ 3
PARTS AND FEATURES............................. ...... ....... ...... .. 4
WASHER USE ..................................................................... 5
Understanding Washer Cycles......................................... 5
Loading.............................................................................. 5
Normal Washer Sounds.................................................... 5
Starting Your Washer........................................................ 6
Selecting a Cycle and Time .............................................. 7
Rinse and Spin.................................................................. 7
Drain and Spin................................................................... 8
Adding Liquid Fabric Softener.......................................... 8
Self-Cleaning Lint Filter..................................................... 8
WASHER CARE.................................................................. 8
Cleaning Your Washer...................................................... 8
Water Inlet Hoses.............................................................. 8
Vacation, Storage and Moving Care................................. 8
TROUBLESHOOTING......................................................... 9
ASSISTANCE OR SERVICE ............................................. 11
WARRANTY....................................................................... 12
2
Page 3
W ASHER SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all
safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or
“WARNING.” These words mean:
You can be killed or seriously injured if you don't
immediately follow instructions.
You can be killed or seriously injured if you don't
follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you
what can
happen if the instructions are not followed.
IMPORTANT SAFETY INSTRUCTIONS
WARNING:
precautions, including the following:
■
Read all instructions before using the washer.
■
Do not wash articles that have been previously
cleaned in, washed in, soaked in, or spotted with
gasoline, dry-cleaning solvents, other flammable,
or explosive substances as they give off vapors
that could ignite or explode.
■
Do not add gasoline, dry-cleaning solvents, or
other flammable, or explosive substances to the
wash water. These substances give off vapors
that could ignite or explode.
■
Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been
used for 2 weeks or more. HYDROGEN GAS IS
EXPLOSIVE. If the hot water system has not
been used for such a period, before using the
washing machine, turn on all hot water faucets
and let the water flow from each for several
minutes. This will release any accumulated
hydrogen gas. As the gas is flammable, do not
smoke or use an open flame during this time.
To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow basic
■
Do not allow children to play on or in the washer. Close
supervision of children is necessary when the washer
is used near children.
■
Before the washer is removed from service or
discarded,
remove the lid.
■
Do not reach into the washer if the tub or agitator is
moving.
■
Do not install or store the washer where it will be
exposed to the weather.
■
Do not tamper with controls.
■
Do not repair or replace any part of the washer or
attempt any servicing unless specifically recommended
in this Use and Care Guide or in published user-repair
instructions that you understand and have the skills to
carry out.
■
See Installation Instructions for grounding
requirements.
SAVE THESE INSTRUCTIONS
3
Page 4
PARTS AND FEATURES
This manual covers several different models. The washer you have purchased may have some or all of the parts and features listed
below.
1
2
3
4
5
6
7
8
1. Control panel
2. Model and serial number label
3. Liquid fabri c sof te ner dispenser
4. Agitator
5. Lid
6. Liquid bleach dispenser
Control panel
7. Basket
†
8. Tub
Additional features
Self-cleaning lint filt er
White porcelain basket
†
On some models
4
Page 5
W ASHER USE
Understanding W asher Cycles
When the Cycle Control knob is set to a num ber and pulled out,
the washer fills (to the selected load size) before agitation and
timing start. The washer begins agitating immediately after filling;
agitation occurs with the washer lid up or down.
During agitation, the agitator creates a continuous rollover action
that provides a thorough cleaning of the wash load.
After agitatio n starts, th e Cycle Co ntrol k nob turns clock wise until
it points to an OFF area and the cycle ends.
NOTE: The washer pauses briefly throughout each cycle. These
pauses are normal for washer operation.
WASH RINSE
1. Fill 1. Fill
Loading
Loading suggesti ons
For these sugge ste d full -si zed lo ads , set th e LOAD SI ZE sele ctor
to the highest load size setting.
SUPER CAPACITY WASHERS
Heavy Work Clothes
3 pair pants
3 shirts
4 pair jeans
Delicates
3 camisoles
1 quilted robe
4 slips
4 panties
Towels
10 bath towels
10 hand towels
Mixed Load
3 double sheets
4 pillowcase s
8 T-shirts
6 pair shorts
1 coverall
1 overall
2 bras
2 nighties
1 baby’s dress
14 wash cloths
1 bath mat
2 shirts
2 blouses
8 handkerchiefs
2. Wash
selected
time
3. Drain
No agitation
4. Spin 4. Spin-Spray
†
The Permanent Press cycle
partially drains, fills, agitates
briefly, and drains.
Normal Washer Sounds
Your new washer may make sounds your old one didn’t. Because
2. Rinse
†
3. Drain
No agitation
rinse
5. Spin
6. Off
the sounds might be unfamiliar, you may be concerned about
them. These sounds are normal.
During washing
When you select a small load size setting, your washer has a
lower water level. This can cause a clicking sound from the upper
part of the agitator.
During drain
If water is drained quickly from your washer (depending on your
installation), you may hear air being pulled through the pump
during the end of draining.
After drain and before spin
When the cycle changes from draining to spinning, you may hear
gears engaging.
5
Page 6
Starting Y our W asher
Fire Hazard
Never place items in the washer that are
dampened with gasoline or other flammable
fluids.
No washer can completely remove oil.
Do not dry anything that has ever had any type of
oil on it (including cooking oils).
Doing so can result in death, explosion, or fire.
1. Measure detergent and pour it into the washer . If desired, add
powdered or liquid color safe bleach. Add extra detergent for
the Ex-Heavy cycle.
Drop a sorted load of clothes loosely into your washer.
■ Load evenly to maintai n w a sher balance. Mix large and
small items.
■ Items should move easily through the wash water.
Overloading can cause poor cleaning.
■ To reduce wrin kling of pe rmanent press clothes and some
synthetic knits, use a large load size to provide more
space (see step 5).
2. (OPTIONAL STEP) Pour measured liquid chlori ne bleach into
the liquid chlorine bleach dispenser. Bleach will be dispensed
automatically during the wash part of the cycle.
WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in
death, fire, or electrical shock.
■ Never use more than 1 cup (250 mL) for a full load. Use
less with a smaller load size.
■ Follow the manufacturer’s directions for safe use.
■ To avoid spilling, use a cup with a pouring spout. Do not
let bleach splash, drip, or run down into the washer
basket.
■ Use only liquid chlorine bleach in this dispenser.
3. (OPTIONAL STEP) Pour measured liquid fabric softener into
the liquid fabric softener dispenser (on some models).
Softener is added automatically during the rinse portion of
the cycle.
Dilute liquid fabric sof t en e r by fil lin g the di sp ens er wi th wa rm
water until liquid reaches the crossbar i n the opening.
■ Do not spill or drip any fabric softener on the clothes.
■ Use only liquid fabric softener in this dispenser.
NOTE: On models without
"Adding Liquid Fabric Softener."
4. Close the washer lid.
a fabric softener dispe nser, see
6
Page 7
5. Turn the LOAD SIZE selector to the correct setting for your
wash load and the type of fabric being washed.
■ Choose a load size that allows the load to move freely for
best fabric care. See "Loading".
■ You may change the load size selection after the washer
has started filling by turning the selector to a different
setting.
6. Set the TEMPERATURE selector to the correct setting for the
type of fabr ic an d soil s bei ng washe d. Use the war mest water
safe for fabric. Follow garment label instructions.
Water Temp Use For
■ Refer to “Understanding Washer Cycles” to learn what
happens during a wash cycle.
NOTE: This manua l covers several different models. The washer
you purch ased m ay v ary f ro m the mode l sho wn an d wi ll no t have
all of the cycles described.
Hot
111°F (44°C)
or above
Warm
90°-110°F
(32°-43°C)
Cold
70°-90°F
(21°-32°C)
NOTE: In wash water temperatures colder than 70ºF
(21ºC), detergents do not dissolve well. Soils can be difficult
to remove. Some fabrics can retain wear wrinkles and have
increased pilling (the formation of small lint-like balls on the
surface of garments).
7. Push in the Cycle Control knob and turn it clockwise to the
wash cycle you want. Reduce the wash time when using a
small load size setting. See “Selecting a Cycle and Time.”
Pull out the Cycle Control knob to start the washer.
To stop or restart your washer
■ To stop the washer at any time, push in the Cycle Control
knob.
■ To restart the wa sher, close the lid (if open) and pull out
the Cycle Control knob.
Whites and pastels
Heavy and greasy soils
Bright colors
Moderate to light soils
Colors that bleed or fade
Light soils
Selecting a Cyc le and Time
This section describes the available wash cycl es and will help
you make the best cycle selections for your wash loads. Each
cycle is designed for different types of fabric and soil levels.
■ The washer pauses briefly throughout each cycle. These
pauses are normal. Refer to “Normal Washer Sounds” to
learn more about the sounds you may hear during a wash
cycle.
Cycle Control knob
Normal cycl e
This cycle features high-sp eed agitation and longer spin speeds
to shorten drying time. Use this cycle for cleaning cotton and
linen fabrics. Se lect up to 14 minu tes of wa sh time, de pending on
whether your load is heavily, moderately, or lightly soiled.
Ex-Heavy - Select this 18-minute cycle to wash heavily soiled
loads that need maximum soil removal. Use two times the
recommended amount of detergent for this cycle.
Permanent Press cycle
This cycle features a cool-down rinse to help reduce wrinkling.
Select up to 10 minutes of wash time for cleaning permanent
press and some synthetic fabrics that are lightly to moderately
soiled.
Gentle/Delicates
This cycle features low agitation speed for gentle soil removal.
Low spin speeds help reduce wrinkling. Use this 6-minute cycle
for cleaning lightly to moderately soiled delicat e items and
washable knits.
Gentle cycle
This cycle features a brief series of agitations and soaks, followed
by a short spin. Select up to 6 minutes of wash time to gently
clean special-care items that are lightly to moderately soiled.
Pre-Wash cycle
This cycle features a brief period of agitation to help remove
heavy soils and stains that need pretreatment. Use the amount of
detergent or presoak additive recommended by the
manufacturer . After the Pre-Wash cycle ends, add detergent and
set a new wash cycle.
Rinse and Spin
When using extra detergent for heavily soiled clothes, or washing
special-care items, you may find an extra rinse and spin is
needed.
1. Push in the Cycle Control knob and turn it clockwise to any of
the Rinse settings.
2. Pull out the Cycle Control knob. The washer fills to the
selected load size, agitates, drains, and spins.
7
Page 8
Drain and Spin
A drain and spin may help shorten drying times for some heavy
fabrics or spe ci al - ca re items by removing excess water.
1. Push in the Cycle Control knob and turn it clockwise to any of
the Spin settings.
2. Pull out the Cycle Control knob. The washer drains, then
spins.
Adding Liquid Fabric Softener
Always dilute fabric softener with ½ to 1 cup (125 to 250 mL)
warm water. Undiluted fabric softener can stain fabrics.
■ Add diluted fabric softener only in the final rinse.
■ Fabric softener should not be mixed with other laundry
products. Greasy stains can form. To remove greasy stains,
wet the stain and rub with liquid detergent or a bar of soap.
Rewash.
■ Too much fabric softener can make some items (diapers and
towels) nonabsorbent. If this happens, use less fabric
softener, or do not use it every time.
Self-Cleaning Lint Filter
Your washer has a self-clean ing lint filter at the bottom of the
basket. Wash and rinse water flow over the filter during a gitation,
separating the lint fr om the wate r. The li nt spin s out o f the sys tem
during the spin part of the cycle.
If your washer drains into a tub, remove any lint collected in the
tub or strainer.
W ASHER CARE
Cleaning Y our Washer
Cleaning the exterior
Use a soft, damp cloth or sponge to wipe up any spills such as
detergent or bleach. Occasionally w ipe the outside of your
washer to keep it looking new.
Cleaning the interior
Clean your washer interior by mixing 1 cup (250 mL) of chlorine
bleach and 2 cups (500 mL) of detergent. Pour this into your
washer and run it through a complete cycle u sing hot water.
Repeat this process if necessary.
NOTE: Remove any hard water depo sits using only cleaners
labeled as washer safe.
Cleaning the liquid fabric softener dispenser
Flush dispenser periodically with warm water, as shown. Remove
the dispenser by grasping the top of the dispenser with both
hands and squeezing and pushing upwards with thumbs. Clean
the dispenser by rinsing it under a water faucet. Replace it after
cleaning.
NOTE: Do not wash clothes with this dispenser removed. Do not
add detergent or bleach to this dispenser; it is for liquid fabric
softener use only.
W ater Inlet Hoses
Replace inlet hoses after five years of use to reduce the risk of
hose failure. Periodically in spect and replace inlet hoses if
bulges, kinks, cuts, wear or leaks are found.
When replacing your inlet hoses, mark the date of replacement
on the label with a permanent marker.
V acation, Storage and Mo ving Care
Install and store your washer where it will not freeze. Because
some water may stay in the hoses, freezing can damage your
washer. If storing or moving your washer during freezing weather ,
winterize it.
Non-use or vacation care
Operate your washer only when you are at home. If you will be on
vacation or not using your washer for an extended period of time,
you should:
■ Unplug washer or disconnect power.
■ Turn off the water supply to the washer. This helps avoid
accidental flooding (due to a water pressure surge) while you
are away.
To winteri ze was her
1. Shut off both water faucets.
2. Disconnect and drain water inlet hoses.
3. Put 1 quart (1 L) of R.V.-type antifreeze in the basket.
4. Run washer on a d rain an d spin se tting (s ee “Dra in and S pin”)
for about 30 seconds to mix the anti f reeze and water.
5. Unplug washer or disconnect power.
To use washer again
1. Flush water pipes and hoses.
2. Reconnect water inlet hoses.
3. Turn on both water faucets.
4. Plug in washer or reconnect power.
5. Run the washer through a complete cycle with 1 cup (250 mL)
of detergent to clean out antifreeze.
8
Page 9
TROUBLESHOOTING
■
Is your voltage low?
Check your electrical source or call an electrician. Do not use
an extension cord.
First try the solutions suggested here and possibly avoid
the cost of a service call...
Washer won’t fill, rinse or agitate
■
Check the following:
Is the power cord plugged into a grounded 3 prong outlet?
Is the indicator on the Cycle Con trol knob properly lined up
with a cycle? Turn the Cycle Control knob to the right slightly
and pull to start.
Are the water inlet valve screens clogged?
Are both the hot and cold water faucets turned on?
Is the water inlet hose kinked?
■
Does the water level seem too low, or does the washer
appear to not fill completely?
The top of the agitator is much higher than the highest water
level. This creates a perception that the washer is not filling
completely. This is normal.
Washer stops
■
Check the following:
Is the power cord plugged into a grounded 3 prong outlet?
Is the indicator on the Cycle Con trol knob properly lined up
with a cycle? Turn the Cycle Control knob to the right slightly
and pull to start.
Are the water inlet valve screens clogged?
Are both the hot and cold water faucets turned on?
Is the water inlet hose kinked?
■
Is there power at the plug?
Check your electrical source or call an electrician.
■
Has a fuse blown or is the circuit breaker open?
If problem continues, call an electrician.
■
Are you using an extension cord?
Do not use an extension cord.
■
Is the washer in a normal pause in the Permanent Press
(or Hand Washables) cycle?
The washer pauses for about 2 minutes in the Permanent
Press cycle. Allow the cycle to continue.
The Hand Washables cycle (on some models) features
periods of agitation and soak.
■
Is the washer overloaded?
Wash smaller loads.
Washer continues to fill or drain, or the cycle seems
stuck
■
Is the top of drain hose lower than the water level in
washer?
The top of the ho se mus t be hig her th an th e wat er leve l in the
washer for proper operation. See the Installation Instructions.
■
Does the drain hose fit too tightly in th e standpipe, or i s i t
taped to the standpipe?
The drain hose should be loose yet fit securely. Do not seal
the drain hose with tape. The hose needs an air gap. See the
Installation Ins tructions.
Washer makes noise
■
Is the load balanced and the washer level?
The wash load should be balanced and not overloaded.
The washer must be level. The front feet should be properly
installed and the nuts tightened. Reset the rear leveling legs
(if needed). See the Installation Instructi ons.
■
Did you completely remove the yellow shipping strap with
cotter pins?
See the Installation Instructions.
■
Are the gears engaging after the drain and before spin, or
is the upper part of agitator clicking during wash?
These are normal washer noises.
Washer leaks
■
Check the following:
Are the fill hoses tight? Are the fill hose washers properly
seated? Is the drain hose clamp properly installed? See the
Installation Ins tructions.
■
Is the sink or drain clogged?
Sink and standpipe must be able to handle 17 gallons (64 L)
of water per minute.
■
Is water deflecting off the tub ring or the load?
Center the tub before starting the washer.
The wash load should be balanced and not overloaded. The
fill or spray rinses can deflec t off the load.
The washer must be level. The front feet should be properly
installed and the nuts tightened. Reset the rear leveling legs
(if needed). See the Installation Instructi ons.
■
Check household plumbing for leaks.
Washer basket is crooked
Washer won’t drain or spin
■
Is the drain hose clogged, or the end of the drain hose
more than 72 inches (183 cm) above the floor?
See the Insta llatio n Instru ction s for pr ope r inst allati on of d rain
hose.
■
Is the lid open?
The lid must be closed during operation.
■
Is there excessive sudsing?
Always measur e de te rgent. Follow manufacturer’s directions.
If you have very soft water, you might need to use less
detergent.
■
Was the washer basket pulled forward during loading?
The wash load should be balanced and not overloaded. Push
the basket to the center before starting wash.
■
Is the load balanced and the washer level?
The wash load should be balanced and not overloaded.
The washer must be level. The front feet should be properly
installed and the nuts tightened. Reset the rear leveling legs
(if needed). See the Installation Instructi ons.
■
The washer basket moves while washing.
This is normal.
9
Page 10
Agitator operation
Load is wrinkled
■
The top of the agitator is loose, or moves in only one
direction.
This is normal.
Dispensers clogged or bleach leaking
■
Did you follow the manufacturer’ s directions when adding
detergent and fabric softener to the dispensers
?
Measure detergent and fabric softener. Carefully pour into the
dispensers. Wipe up all spills.
Dilute fabric softener in the fabric softener dispenser.
■
Did you put powdered or color-safe bleach in the liquid
chlorine bleach dispenser?
Add powdered or liquid color-safe bleach directly to the
basket. Do not use the chlorine bleach dispenser for colorsafe bleach.
Load too wet
■
Did you use the right cycle for the load being washed?
Select a cycle with a higher spin speed (if available).
■
Did you use a cold rinse?
Cold rinses leave loads wetter than warm rinses. This is
normal.
Residue or lint on loa d
■
Did you sort properly?
Sort lint givers (towels, chenille) from lint takers (corduroy,
synthetics). Also sort by color.
■
Did you overload the washer?
The wash load must be balanced and not overloaded. Lint
can be trapped in the load if overloaded. Wash smaller loads.
■
Check the following:
Was paper or tissue left in the pockets?
Did you use enough detergent? Follow manufacturer’s
directions. Use enough detergent to hold the lint in the water.
Is your water colder than 70°F (21°C)? Wash water colder
than 70°F (21°C) may not completely dissolve the detergent.
Stains on load
■
Did you follow the manufacturer’ s directions when adding
detergent and fabric softener?
Measure detergent and fabric softener. Use enough detergent
to remove soil and hold it in suspension.
Dilute fabric softener and add to the rinse portion of a cycle
only. Do not drip fabric softener on clothes.
■
Is there above average iron (rust) in water?
You may need to install an iron filter.
■
Did you properly sort the load?
Sort dark clothes from whites and lights.
■
Did you unload the washer promptly?
To avoid dye transfer, unload the washer as soon as it stops.
■
Did you unload the washer promptly?
Unload the washer as soon as it stops.
■
Did you use the right cycle for the load being washed?
Use the Permanent Press cycle or another cycle with low spin
speeds (if available) to reduce wrinkling.
■
Did you overload the washer?
The wash load must be balanced and not overloaded. Loads
should move free ly during wash ing.
■
Was the wash water warm enough to relax wrinkles, or
are you using warm rinses?
If safe for the load, use warm or hot wash water. Use cold
rinse water.
■
Are the hot and cold water hoses reversed?
Check to be sure the hot and cold water hoses are connected
to the right faucets. See the Installation Instructions.
Load is tangled or twisted
■
Did you overload the washer?
The wash load must be balanced and not overloaded. Loads
should move free ly during wash ing.
■
Did you wrap items around the agitator?
Drop items loosely into the washer . Do not wrap items around
the agitator.
Gray whites, dingy colors
■
Did you properly sort the load?
Dye transfer can occur when mixi ng whites and colors in a
load. Sort dark clothes from whites and lights.
■
Was the wash temperature too low?
Use hot or warm was hes if sa fe for the l oad. Hot wa ter should
be at least 111°F (44°C) to clean heavy or greasy soils.
■
Did you use enough detergent, or do you have hard
water?
Use more detergent for washing heavy soils in cold or hard
water.
■
Are the hot and cold water hoses reversed?
Check to be sure the hot and cold water hoses are connected
to the right faucets. See the Installation Instructions.
Garment damage
■
Check the following:
Were sharp items removed from pockets before washing?
Empty pockets, zip zi ppers, snap or hook fastener s before
washing.
Were strings and sashes tied to prevent tangling?
W e re items damage d be f o re washing? Men d rips and broken
threads in seams before washing.
■
Did you overload the washer?
The wash load must be balanced and not overloaded. Loads
should move free ly during wash ing.
■
Did you properly add chlorine bleach?
Do not pour chlorine bleach directly on load. Wipe up bleach
spills. Undiluted bleach will damage fabrics.
■■■■
Did you follow the manufacturer’s care label instructions?
10
Page 11
ASSISTANCE OR SERVICE
Before calling for assistance or service, please check the
“Troublesho oting” section. It may save you the cost of a service
call. If you still need help, follow the instructions below.
When calling, please know the purchase date and the complete
model and serial number of your appliance. This information will
help us better respond to your request.
If you need replacement parts
If you need to order replacement parts, we recommend that you
only use FSP
fit right and work right, because they are made to the same
exacting specifications used to build every new ESTATE
appliance. To locate FSP replacement parts in your area, call our
Customer Interaction Center telephone number or your nearest
designated service center.
For assistance or service
Call the Customer Interaction Center at
Our consultants provide assistance with:
■ Features and specifications on our full line of appliances
■ Installation information
■ Use and main t enance procedures
■ Accessory and repair parts sales
■ Specialized customer ass istance (Spanish speaking, hearing
impaired, limited vision, etc.)
■ Referrals to local dealers, service companies, and repair parts
distributors
Estate designated service technicians are trained t o fulfill the
product warranty and provide after-warranty service, anywhere in
the United States.
To locate the Estate des ign ated service company in your area,
you can also look in your telephone directory Yellow Pages.
®
factory specified parts. FSP replacement parts will
®
1-800-253-1301
.
For further assistance
If you need further assistance, you can write to Estate with any
questions or concerns at:
Estate Brand Home Appliances
Customer In te ra ction Center
c/o Correspondence Dept.
MD 8020
553 Benson Road
Benton Harbor, MI 49022-2400
Please include a daytime phone number in your correspondence.
Gearcase assembly covered by your warranty
11
Page 12
ESTATE
®
W ASHER W ARRANTY
ONE-YEAR FULL WARRANTY
For one year from the date of purchase, when this washer is operated and maintained according to instructions attached to or furnished
with the product, Whirlpool Corporation will pay for FSP
workmanship. Service must be provided by a Whirlpool designated service company.
For five years from the date of purchase, when this washer is operated and maintained according to instructions attached to or
furnished with the product, Whirlpool Corporation w ill pay for FSP
gearcase assembly, if defective in materials or workmanship.
For ten years from the date of purchase, when this washer is operated and maintained according to instructions attached to or
furnished with the product, Whirlpool Corporatio n wi ll pa y for FSP
water, if defective in materials or workmanship.
For the lifetime of the washer, when this washer is operated and maintained according to instructions attached to or furnished with the
product, Whirlpool Corporation will pay for FSP
materials or workmanship.
Whirlpool Corporation will not pay for:
1.
Service calls to correct the installation of your washer, to instruct you how to use your washer, or to replace house fuses or correct
house wiring or plumbing.
2.
Repairs when your washer is used in other than normal, single-family household use.
3.
Damage resulting from accident, alteration, misuse, abuse, fire, flood, acts of God, improper installation, installation not in
accordance with local electrical and plumbing codes, or use of products not approved by Whirlpool Corporation.
4.
Any labor costs during the limited warranties.
5.
Replacement parts or repair labor costs for unit s operated outside the United States.
6.
Pickup and delivery. This product is designed to be repaired in the home.
7.
Repairs to parts or systems resulting from unauthorized modifications made to the appliance.
®
replacement parts for the white porcelain basket should it chip or rust due to defects in
®
replacement parts and repair labor to correct defects in materials or
FIVE-YEAR LIMITED WARRANTY
TEN-YEAR LIMITED WARRANTY
LIFETIME LIMITED WARRANTY
®
replacement parts for any top and lid rust and any part of the
®
replacement parts for the outer tub should it crack or fail to contain
WHIRLPOOL CORPORATION SHALL NOT BE LIABLE FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES.
Some states do not allow the exclusion or limitation of incidental
or consequentia l damages , so this exclu sion or limi tation may not
apply to you. Thi s warranty giv es you spe cific legal rights and you
may also have other rights which vary from st ate to state.
Keep this book and your sales slip together for future
reference. You must provi de proof of purchase or installation
date for in-warranty service.
Write down t he foll owin g informa tion a bout your washer to b etter
help you obtain assistance or service if you ever need it. You will
need to know your complete model number and serial number.
You can find this informati on on the model and serial number
label/plate, located on your appliance as shown in
“Parts and Features”.
3953962
© 2000 Whirlpo ol C or por at ion. Al l r i ght s r e s erved . ® Registered Trademark of Wh ir lpool , U.S. A. Printed in U.S.A
Outside the 50 United States, this warranty does not apply.
Contact your authorized Estate dealer to determine if
another warranty applies.
If you need service, first see “Troubleshooting”. Additional help
can be found by checking “Assi stance or Service,” or call our
Customer Interaction Center at
in the U.S.A., or write : Est ate Bra nd Home Applianc es, Cu stomer
Interaction Center, c/o Corre spondence Dept., MD 8020,
553 Benson Road, Benton Harbor, MI 49022-2400.
Dealer name_____________ ___ ____________________________________
Address______________ ___ _______________________________________
Phone number__________________________________________________
Model number ____________________ ____ __________________________
Serial number __________________________________________________
Purchase date __________________________________________________
1-800-253-1301
from anywhere
04/00
04/00
Loading...
