60cm slide out stainless steel rangehood with 2 fans, 3 speeds and top re-circulating option.
RRP AUS $249.00
WRR604SB
WRR604SB - 60cm slide out rangehood, stainless steel
Page 2
Product Details
FEATURES
340m3/hr extraction rate LED lighting 3 speed fan Dishwasher safe mesh filters
Slimline design suitable for
integration
Removable front fascia
Front fascia panel of
rangehood can be removed
and exchanged with a trim to
integrate into the kitchen
colour scheme
BENEFITS
Clear the air quickly
Our rangehoods offer powerful extraction rates ensuring your
kitchen is clear of cooking odours, vapours and excess heat in
no time at all.
Low energy, long lasting LED
With low energy use and a high illumination performance,
long-lasting LED lights make it easy to keep an eye on your
delicious cooking.
Easy-clean filters
For ease and convenience, our easily removed aluminium
micro-mesh filters can simply be washed safely in your
dishwasher or hand washed. Keep your rangehood looking great
and performing well with next to no effort.
Slimline design suitable for integration
Designed for integration, the front trim can be installed flush
with the cabinetry or be removed and replaced with the cabinet
material for total integration.
WRR604SB
WRR604SB - 60cm slide out rangehood, stainless steel
Page 3
Specifications
PRODUCT PROFILE
Domestic warranty details
(yrs)
2
Type of Rangehood slide out
Nominal width 600
Finish of Rangehood stainless steel,grey
MOTOR/FAN
Number of fans 2
Number of fans speeds 3
Type of motor centrifugal
Perimeter extraction No
Maximum airflow M3/Hr 340
Noise level dB high 66
Noise level dB low 57
Number of motors 2
Wattage of motor 125
DIMENSIONS
Total product height (mm) 175
Total product width (mm) 598
Total product depth (mm) 300
POWER
Electricity supply required
(Kw)
0.262
WRR604SB
WRR604SB - 60cm slide out rangehood, stainless steel
Page 4
DIMENSIONS
Diameter of ducting (mm) 120
Minimum installation height
from cooking surface Gas
(mm)
650
Minimum installation height
from cooking surface
Electric (mm)
600
CONTROLS
Control panel auto activated pull/push)
Safety/ display indicators automatic safety cut off
FILTERS
Number of filters 2
Type of filter multilayer aluminum
micromesh filters
Dishwasher safe Yes
LIGHTS
Number of lights 2
Wattage of light 5.5
Type of light LED
DUCTING / RECIRCULATION
Ducting optional accessory
Top or rear duct hole top
Recirculation option Yes
Recirculation kit optional accessory
Front recirculating option No
WRR604SB
WRR604SB - 60cm slide out rangehood, stainless steel
Page 5
DUCTING / RECIRCULATION
Type of filter Charcoal
Filter Optional
Number of optional filters
required
two
SHIPPING
Shipping Volume (m3) 0.058
Shipping Weight (Kg) 12.1
Product Weight (Kg) 9.2
Pack Dimensions Height
(mm)
244
Pack Dimension Width
(mm)
655
Pack Dimension Depth
(mm)
361
STUFFING QUANTITIES
20ft 459
40ft 972
40ft HC 1080
WRR604SB
WRR604SB - 60cm slide out rangehood, stainless steel
Page 6
ELECTROLUX HOME PRODUCTS AUSTRALIA
telephone: 1300 363 640
fax: 1800 350 067
email: customercare@electrolux.com.au
web: www.electrolux.com.au
ELECTROLUX HOME PRODUCTS NEW ZEALAND
telephone: 09 573 2230
fax: 09 573 2221
email: customercare@electrolux.co.nz
web: www.electrolux.co.nz
Terms and Conditions
IMPORTANT
This is a guide of product dimensions only. For complete installation instructions, refer to the manual provided with product.
PRODUCT INFORMATION
The descriptors and illustrations in this publication apply to the specific products and models described as at the date of issue. Under our policy of
continuous productdevelopment, product specifications may change without notice. Prospective purchasers should therefore check with their retailer to
ensure this publication correctly describes theproducts that are being offered for sale. All information supplied is to be used for general reference
purposes only and is on the understanding that Electrolux Home Products PtyLtd (Australia) and Electrolux (NZ) Ltd (New Zealand) will not be liable for
any loss, liability or damage of whatever kind arising as a result of reliance on such information. Colours ofproducts illustrated are as close as printing
limitations allow. Electrolux will at all times comply with its obligations pursuant to law including Trade Practices (Australian Consumer Law) Act and
Regulations.
WARRANTY
This warranty only applies to Appliances purchased and used in Australia or New Zealand and used in normal domestic applications and is in addition to
(and does not exclude, restrict, or modify in any way) any non-excludable statutory warranties in Australia or New Zealand. All warranties are subject to the
conditions set out in the warranty card accompanying the product when purchased.
