Westinghouse WRC613SB, WRC913SB User Manual

INSTALLATION AND USER MANU AL

WRC613SB Canopy Rangehood WRC913SB Canopy Rangehood

CONGRATULATIONS

CONTENTS

Congratulations and thank you for choosing our canopy rangehood. We are sure you will find your new rangehood a pleasure to use. Before you use your rangehood, we recommend that you read through the whole user manual, which provides the description of the rangehood and its function. To avoid the risks that are always present when you use an electrical appliance it is important that the canopy rangehood is installed correctly and that you read the safety instructions carefully to avoid misuse and hazards. We recommend that you keep this instruction booklet for future reference and pass it on to any future owners. After unpacking the canopy rangehood please check it is not damaged. If in doubt, do not use the appliance but contact your local Electrolux Service Centre.

Conditions of use

This appliance is intended to be used in household and similar applications such as:

working envionments

type environments

Record model and serial number here:

Important safety instructions Description of your rangehood Components list Technical specifications Rangehood dimensions Installation Using your rangehood Care & maintenance Troubleshooting Optional ducting accessories Warranty

. . . . . . . . . . . . . . . . . . . . . . . . . . 5

. . . . . . . . . . . . . . . . . . . . . 5

. . . . . . . . . . . . . . . . . . . . . 6

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

. . . . . . . . . . . . . . . . . . . . . 12

. . . . . . . . . . . . . . . . . . . . . . 12

. . . . . . . . . . . . . . . . . . . . . . . . . 14

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

. . . . . . . . . . . . . . . . . . 3

. . . . . . . . . . . . . . . . 5

. . . . . . . . . . . . . . . . 15

Model:

Serial No:

TIPS & INFORMATION

IMPORTANT – CHECK FOR ANY DAMAGES OR MARKS.

the rangehood is damaged or marked, you must report it within 7 days if you wish to claim for damage/marks under the manufacturers warranty. This does not affect your statutory rights.

UNPACKING

Check that the cooker hood has no damage.Transportation damage should immediately be reported to the company responsible for the transportation. Damage, faults and missing details should immediately be reported to the retailer. Take care of the packing materials so that small children cannot play with them.

If you find

ENVIRONMENTAL TIPS

INFORMATION ON DISPOSAL FOR USERS

dispose of those materials through your local recycling depot or by placing them in appropriate collection containers.

local authorities and ask for the correct method of disposal.

IMPORTANT SAFETY INSTRUCTIONS

This manual explains the proper use of your new Westinghouse canopy rangehood. Please read this manual carefully before using the product. This manual should be kept in a safe place for handy reference. This canopy rangehood is a domestic appliance which has been manufactured and tested to comply with Australian and New Zealand Standard AS/NZS 60335.2.31.

Meanings of symbols used in this manual are shown below:

CAUTION

This symbol indicates the possiblity of injury or damage to property.

This symbol indicates never to do this.

This symbol indicates always do this.

TIPS & INFORMATION

This symbol indicates tips and information about use of the appliance.

ENVIRONMENTAL TIPS

This symbol indicates tips and information about economical and ecological use of the appliance.

CAUTION

Read the following carefully to avoid an electric shock or fire.

GENERAL WARNINGS

The appliance must be plugged into its own dedicated 220-240V, 50Hz AC electrical outlet.

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

This canopy rangehood is not recommended for barbecues and cannot be installed for external use. Grease filters must be removed every four weeks (maximum) for cleaning to reduce the risk of fire. The exhaust from the canopy rangehood must not be discharged into any heating flue, which may carry combustion products from other sources. (Fig 1)

Exhaust air must not be discharged into a wall cavity, unless the cavity is designed for the purpose.

There must be adequate ventilation of the room when the canopy rangehood is used at the same time as appliances burning gas or other fuels.

Always cover lit gas burners with pots or pans when canopy rangehood is in use.

Always switch off gas burners before you remove pots or pans.

Do not leave lit gas burners exposed due to the risk of fire. (Fig 2)

The hood must always be disconnected from the electricity supply before beginning any maintenenace work.

Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards.

ELECTRICAL CONNECTION

Check that the mains voltage matches with the voltage on the data plate inside the canopy rangehood. Check that the installation complies with standards of local building, gas and electrical authorities. Before connecting to the mains supply ensure that the mains voltage corresponds to the voltage on the rating plate inside the cooker hood. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or similarly qualified person in order to avoid a hazard.

SAFETY WARNINGS – FOR THE INSTALLER

When installing the cooker hood, make sure you adhere to the minimum and maximum distances from the cooker hood base to the hob surface (refer to page 7). Exhaust flue installation: The following rules must be strictly followed to obtain optimal air extraction.

Keep exhaust flue short and straight. Do not reduce the size or restrict exhaust flue. Keep bends in the exhaust flue to a minimum. When using flexible flue always install duct with helix pulled taut to minimise pressure loss. Failure to observe these basic instructions will drastically reduce the performance and increase the noise levels of the cooker hood.

Exhaust air must not be discharged into a wall cavity, unless the cavity is designed for that purpose. The exhaust from the cooker hood must not be discharged into any heating flue, which may carry combustion products from other sources.

NOTE: Some installations may require the telescopic exhaust cover to be cut to length. Cut with sharp tin snips or a fine-tooth hack saw blade, taking care not to distort or dent the exhaust cover.

DESCRIPTION OF YOUR RANGEHOOD

Components list

1. Telescopic flue cover set

2. Upper Flue mounting bracket

3. Lower Flue mounting bracket

4. Exhaust transition duct

5. Main body and fan housing assembly

6. Grease filter(WRC613SB)

6. Grease filter(WRC913SB)

Technical specification

Power supply: 240 V 50 Hz. Connects to 10 A power

point

Lights: 2 x 4 watt, 240 V LED

MODEL

Width

Depth

Lighting Outlet diameter

- - - - - - - - - - - - - - - -

- - - - - - - - - - - - - -

- - - - - - - - - - - - - - - - - - -

- - - - - - - - - -

- - - - - - - - - - - - - - - -

WRC613SB

Qty.

338 W

Fig. 3

Additional items required for installation

tilt points

1 1

Worm drive clamps, Duct tape or cable ties

1 1 2 3

WRC913SB

338 W

The manufacturer reserves the right to make technical changes.

RANGEHOOD DIMENSIONS

WRC613SB

320

290

WRC913SB

320

290

Min 660 / Max1160

625

600

520

320

500

Min 660 / Max1160

625

Fig. 4

900

780

320

500
