Westinghouse L1975NW User Manual

CONTENTS

IMPORTANT PRODUCT SAFETY INSTRUCTIONS......................................2

AFETY GUIDELINES........................................................................................3

FCC C

OMPLIANCE STATEMENT ........................................................................3

CLEANING THE LCD MONITOR....................................................................4

FEATURES......................................................................................................5

OWER SAVER ................................................................................................5

LUG & PLAY..................................................................................................5

INSTALLATION...............................................................................................6

ACKAGE CONTENTS .......................................................................................6

P C

ONTROL PANEL BUTTONS...............................................................................7

NPUT CONNECTORS........................................................................................8

1. A

TTACHING THE BASE STAND TO THE LCD MONITOR......................................9

ONNECT AUDIO AND VIDEO CABLES TO A PC ...............................................9

2. C

3. C

ONNECT POWER CABLES.........................................................................10

4. T

URN THE POWER ON................................................................................10

OSD MENU FUNCTIONS..............................................................................11

MAGE MENU.................................................................................................12

UDIO MENU.................................................................................................13

OLOR MENU ...............................................................................................14

ISCELLANEOUS MENU .................................................................................15

NFORMATION MENU ......................................................................................16

I Q

UICK BRIGHTNESS OR CONTRAST ADJUSTMENT.............................................17

DISPLAY MODES .........................................................................................18

APPENDIX ....................................................................................................19

PECIFICATIONS............................................................................................19

S T

ROUBLESHOOTING.......................................................................................20

IMPORTANT PRODUCT SAFETY INSTRUCTIONS

Follow and obey all warnings and instructions marked on the LCD Monitor. For your safety, please read all the safety and operating instructions before you operate the LCD Monitor Keep this user’s manual for future reference.

Overloading

Do not overload wall outlets, extension cords, or power strips. This can result in fire or electronic shock.

Power Cord Protection

Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them. Periodically inspect the cords and each end of the cords for damage. The LCD Monitor shall be installed near a wall socket outlet and the plug on power cord shall be readily accessible.

Ventilation

Slots and openings on the cabinet are provided for ventilation purposes. To ensure reliable operation of the LCD Monitor and to protect it from overheating, these openings must not be blocked or covered.

x Do not block the openings by placing the LCD Monitor on a bed, sofa, rug or other

similar surface.

x Do not place the LCD Monitor in a built-in installation such as a bookcase or rack

unless proper ventilation is provided and the manufacturer’s instruction have been adhered to.

Other Notices

x Avoid exposing the LCD Monitor to direct sunlight or high temperatures. x Avoid exposing the LCD Monitor to moisture or high humidity. x Do not attempt repairs yourself. Your warranty does not cover repairs or attempted

repairs by anyone not authorized by Westinghouse Digital.

x If your LCD Monitor will not be used for a long period of time, unplug the LCD

Monitor.

Precautions

x Avoid touching the screen. Skin oils are difficult to remove. x Never remove the rear cover. Your LCD Monitor contains high-voltage parts. You

may be seriously injured if you touch them.

x Avoid exposing your LCD Monitor to direct sunlight or another heat source. Orient

your LCD Monitor away from direct sunlight to reduce glare.

x Always handle your LCD display with care when moving it. x Place your LCD Monitor in a well-ventilated area; don’t place the LCD Monitor in

airtight compartments. Do not place anything on your LCD Monitor that prevents heat dissipation.

x Ensure that the area around the LCD Monitor is clean and free of moisture. x Do not place heavy objects on the LCD Monitor, video cables, or power cord. x If the LCD Monitor emits smoke, abnormal noise, or a strange odor, immediately

turn it off and contact the Westinghouse Service Center.

x WARNING – To Reduce The Risk Of Fire Or Electric Shock, Do Not Expose

The LCD Monitor To Rain Or Moisture! The LCD Monitor shall not be exposed to

dripping or splashing and objects filled with liquids, such as vases, shall not be placed on the Monitor.

Safety Guidelines

CAUTION: The power supply outlet should be located near the LCD Monitor and should be easily accessible.

Always use the appropriate AC cord that is certified for your specific country. Some examples are listed below:

USA..................UL Switzerland .........SEV

Canada.............CSA Britain .................BASE/BS

Germany..........VDE Japan .................Electric Appliance Control Act

IMPORTANT NOTICE CONCERNING POWER CORD SELECTION

The specific power cord for this LCD Monitor is enclosed and has been selected according to the country of destination and must be used to prevent electric shock. Use the following guidelines if it is necessary to replace the original cord set, or if the cord set is not enclosed. The female receptacle of the cord set must meet IEC-60320 requirements and should look like Figure A1 below:

Figure A1 Figure A2

For the United States and Canada

In the United States and Canada the male plug is a NEMA5-15 style (Figure A2), UL Listed, and CSA Labeled. For LCD Monitors that are placed on a desk or table, type SVT or SJT cord sets may be used. For LCD Monitors placed directly on the floor, only SJT type cord sets may be used. The cord set must be selected according to the current rating for the LCD Monitor. Please consult the table below for the selection criteria for power cords used in the United States and Canada.

Cord Type Size of Conductors in Cord Maximum Current Rating of Unit

SJT

SVT

18 AWG 16 AWG 14 AWG 18 AWG 17 AWG

10 Amps 12 Amps 12 Amps 10 Amps 12 Amps

FCC Compliance Statement

This equipment has been tested and complies with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and may cause harmful interference to radio communications if not installed and used in accordance with the instructions. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

x Reorient or relocate the receiving antenna. x Increase the separation between the LCD Monitor and receiver. x Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

x Consult the Westinghouse Service Center or an experienced radio/Monitor technician for assistance.

FCC Warning

To assure continued FCC compliance, the user must use a grounded power supply cord and the provided shielded video interface cable with bonded ferrite cores. If a BNC cable used, use only a shielded BNC (5) cable. Also, any unauthorized changes or modifications not expressly approved by Westinghouse Digital will void the user's authority to operate this device.

CLEANING THE LCD MONITOR

x MAKE SURE THE LCD MONITOR IS TURNED OFF x NEVER SPRAY OR POUR ANY LIQUID DIRECTLY ONTO THE SCREEN OR CASE

To clean the screen:

1. Wipe the screen with a clean, soft, lint-free cloth. This removes dust and other particles.

2. If it still is not clean, apply a small amount of non-ammonia, non-alcohol based glass cleaner onto a clean, soft, lint-free cloth, and wipe the screen.

To clean the case:

1. Use a soft, dry cloth.

2. If it still is not clean, apply a small amount of non-ammonia, non-alcohol based, mild nonabrasive detergent onto a clean, soft, lint-free cloth, then wipe the surface.

Disclaimer

Westinghouse Digital does not recommend the use of any ammonia or alcohol-based cleaners on the LCD Monitor screen or case. Some chemical cleaners have been reported to damage the screen and/or LCD Monitor case. Westinghouse Digital will not be liable for damage resulting from the use of any ammonia or alcohol-based cleaners.

FEATURES

x Bright Display Image x Ultra Fast Response Time x Built-in Speakers x Power Saver x Plug & Play x Kensington Security Lock Compatible

Power Saver

A power control system, Power Saver, is installed inside the LCD monitor. If the LCD monitor has not been used for a certain period of time, the system will turn the LCD monitor to low voltage mode to save electrical power. Slight movement of the mouse or pressing any key on the keyboard will return the original screen image. You can use your PC to set the function.

The LCD monitor is compatible with EPA ENERGY STAR and NÜTEK if used with a VESA DPMS computer. To save power, turn off the LCD monitor power when not in use.

Plug & Play

VESA Plug and Play eliminates the complicated and time-consuming

installation process. Your computer system will identify and automatically adjust the LCD monitor. The LCD monitor uses Display Data Channel (DDC) to send Extended Display Identification Data (EDID) to the computer system, so the computer system can automatically adjust the LCD monitor.

INSTALLATION

Congratulations on your purchase of a Westinghouse 19” Widescreen LCD Monitor. Sleek and practical, this lightweight LCD monitor delivers a crisp and clear display optimized for 1440 x 900 display resolution.

Package Contents

Your product package includes:

x 19” Westinghouse Widescreen LCD Monitor x Detachable Base Stand x AC Power Cord x VGA Male – Male Cable x Audio Cable x User’s Manual x Warranty Card

Control Panel Buttons

Use the control buttons on the side of the LCD Monitor to display the On Screen Display (OSD). Below is a list of the control button functions. The OSD controls are defined in “OSD Functions” on page 11.

4 5 62 31

1.Turbo/ϧ

2. Auto/ϰ

3. /W

4. /X

x Switch between picture, text and economy modes. x Scroll up the OSD sub-menu list when the OSD is displayed.

x Automatically optimize positions, phase, and clock when the OSD

is not displayed (Auto Adjust).

x Scroll down the OSD sub-menu list when the OSD is displayed. x Quick contrast adjustment or decrease contrast/brightness.

x Move a selection left when the OSD is displayed. x Quick brightness adjustment and increase contrast/brightness.

x Move a selection right when the OSD is displayed.

x Enter and exit the OSD menu

x Power On and Off button x LED Power Indicator Light x Green: Normal x Orange: Power Saving x Off: Power Off

Input Connectors

1. AC IN (Power)

2. DVI-D

3. D-SUB (VGA)

4. Audio

x Connect the power cord from AC IN to a power

source.

x Using a DVI cable, connect to a computer with a

DVI output.

x Using the enclosed 15-pin VGA cable, connect to a

computer or other device with a VGA output.

x Using the enclosed 3.5 mm stereo cable, connect to

the audio output of computer

Installation

1. Attaching the Base Stand to the LCD Monitor

Attach the base stand to the LCD monitor stand neck by aligning the holes and tabs. Press in and snap the base into place. To remove the base stand, press the tabs on the bottom of the stand neck and remove the base.

2. Connect Audio and Video Cables to a PC

Connect one of the following into the back of the LCD Monitor:

IMPORTANT: Before beginning, make sure all devices are turned off.

AUDIO CONNECTION: Connect a stereo mini cable from the PC’s AUDIO-OUT port

to the AUDIO-IN port on the LCD Monitor.

DVI-D CONNECTION: Connect a Digital DVI cable from your computer to the LCD

Monitor DVI-D port.

VGA CONNECTION: Connect an analog VGA cable from your computer VGA OUT

port to the LCD Monitor D-SUB port.

3. Connect Power Cables

Connect the AC power cord to the LCD Monitor (to the connector labeled “AC-IN”) and then connect the cord into a properly grounded AC outlet.

4. Turn the Power On

Press the power button on the side of the LCD monitor. The LED light will turn green if a signal input is detected or it will be orange if no input is detected.

NOTE: If you have a problem with the video image, adjust the computer’s resolution to 1440 x 900 or turn off and reboot the computer. In addition, you may need to download the latest drivers for the graphics card used in your computer.

OSD Menu Functions

All the function settings for the LCD monitor are controlled via the control keys located on the side of the monitor. To display the OSD main menu, press the “Menu” keypad button on the control panel. (Note: The OSD menu display will disappear automatically after approximately 10 seconds, if no action is taken.)

The LCD monitor has been adjusted to optimal settings before shipment. Adjustments to the monitor settings can be made using the OSD menu.

x Press the “Menu” x Press the Turbo/ϧ or Auto/ϰ button to scroll through the sub-menus (Image, Audio,

Color, Miscellaneous, and Information Sub-Menus).

x Press the /X button to enter the sub-menu. x Press the Turbo

x Press the x To go back to the previous menu, press the

automatically.

x To exit the OSD menu press "Menu"

that have been made.

Image Menu

Audio Menu

Color Temp. Menu

Miscellaneous Menu

Information Menu

/W or /X buttons to change the current setting of the sub-function.

button to display the OSD.

/ϧ or Auto/ϰ button to select the function to be adjusted.

button. Changes are saved

again. It automatically will save any changes

Source

Resolution & Frequency

NOTES:

x Any changes are automatically saved in memory when the OSD turns off. Turning off

the power should be avoided while using the OSD menu.

x Adjustments for clock, phase, and positions are saved for each individual signal timing.

Except for these adjustments, all other adjustments have only one setting, which applies to all signal timings.

x The icon color will change from gray to blue when a sub-menu is selected.

The following is a list of the OSD sub-menus for the LCD monitor:

Image Menu

Function

Brightness

Contrast

Sharpness

Clock

Phase

H. Position

V. Position

Description

Adjust the brightness of the screen.

Adjust the contrast of the image.

Adjust the picture sharpness of low resolution pictures.

Adjust the LCD monitor clock. (VGA only)

Adjust the LCD monitor phase. (VGA only)

Move the image left or right on the screen. (VGA only)

Move the image up or down on the screen. (VGA only)

Audio Menu

Function

Vol ume

Mute

Description

Turn volume up and down

Turn volume off and on

Color Menu

Function

Color temp

Red

Green

Blue

Description

User/9300K/7500K/6500K/sRGB

Adjust red color.

Adjust green color.

Adjust blue color.

Miscellaneous Menu

Function

Language

OSD time-out

OSD position

Reset

Input Select

Auto setting

CM Engine

Optimal Aspect Ratio

Description

English, Français, Deutsch, Español, Italiano, ֲء፿, Ɋɭɫɫɤɢɣ, ᜗᧯խ֮, 亞󰪠խ֮,

Adjust OSD display time setting. Move OSD display position to any one of the following 5

positions within the overall screen.

䞲ῃ㠊

Restore the LCD monitor to the factory settings.

Analog / Digital

Adjust clock, phase and positions automatically. (VGA only)

Color Management Engine. (VGA only)

Set Aspect Ratio on or off

Information Menu

Function

Resolution

Horizontal frequency

Vertical frequency

Version

Description

Displays resolution.

Displays horizontal frequency.

Displays vertical frequency.

Displays firmware version number.

Quick Brightness or Contrast Adjustment

A Brightness or Contrast adjustment scale can be displayed directly by using the following button operations:

x Brightness: Press the

x Contrast: Press the /W Contrast button when the Menu is not displayed.

x Auto Adjustment: Press the Auto button when the Menu is not displayed.

/X Brightness button when the Menu is not displayed.

x Turbo: Press the Turbo

Display Modes. See page 17 for more detail.

/ϧ button when the Menu is not displayed to switch between

Display Modes

The monitor backlighting can be adjusted by using the Turbo/ϧ button on the control panel. There are 3 modes: Economy, Text, and Picture. To toggle between these modes,

press the Turbo change the monitor backlight levels between bright, brighter, and brightest.

/ϧ key until the mode you desire is selected. These modes automatically

1. Economy Mode – Reduced brightness

2. Text Mode – Normal brightness

3. Picture Mode – High brightness

NOTES:

x Changing to a lower brightness mode can lessen eye fatigue. x Change from Picture Mode to Text Mode when working with text. x Change from Text Mode to Economy Modes when viewing the screen for long periods.

Appendix

Specifications

Item

Panel Size

Optimum Resolution Response Time Contrast Ratio Maximum Brightness Viewing Angles

Input Signal

Power

Operating Conditions

Storage Conditions

Dimensions

Weight Regulations Power consumption

Lamp Life

Specification

Type

Video HD-15 pin D-Sub (VGA connector)

Audio 3.5mm Mini-Stereo jack

Voltage 100-240 VAC, 50/60 Hz (auto switch), 1.5A

Temperature 32° F to +95° F (0° C to +35° C)

Humidity 20% to 90% (no condensation)

Altitude Up to 3,000 meters

Temperature -4° F to +140° F (-20° C to +60° C)

Humidity 10% to 90% (no condensation)

Altitude Up to 12,000 meters

Unit 17.3 (w) x 14.7 (h) x 8.1 (d) in

Carton 21.4 (w) x 18.5 (h) x 5.8 (d) in

Unit 9.5 lb (4.3 kg)

AC On <36W (Green LED)

AC Off <2W (Orange LED)

19” Color TFT Active Matrix LCD. Anti-static and hard coated.

1440 x 900

5ms

700:1

300 Nits

150° (H) / 130° (V)

DVI-D

FCC-B, UL, CSA (CUL), Energy Star®, CCC, VCCI, Plug & Play

40,000 hours

Troubleshooting

No Power

x Make sure the AC cord is plugged into the back of the LCD monitor. x Make sure the AC power cord is securely connected to an AC outlet. x Plug another electrical device (like a radio) to the power outlet to verify that the

outlet is supplying the proper voltage.

No Image

x Make sure the power button is ON. x Check whether the LCD monitor and computer power cords are plugged in and

check the power supply.

Power is ON but No Screen Image

x ҏAdjust the brightness and contrast levels. x Make sure the VGA or DVI cable is securely connected to both the computer and

monitor.

“Out Of Range”

x Check the computer image output resolution and frequency and compare the value

with the preset values of the computer’s graphics card.

Fuzzy Image

x Adjust the Phase setting on the monitor.

Image Too Bright or Too Dark

x Adjust the brightness and contrast levels using the OSD. x Make sure that the computer is not displaying an irregular image. x Check the VGA or DVI connection between the computer and LCD monitor. x Perform Auto Adjust.

Distorted Image

x Reset the LCD monitor by performing the “Reset” function using the OSD. x Remove extra accessories (such as a VGA extension cord).

Image is Not Centered (size is not scaled correctly)

x Perform Auto Adjust x Adjust the horizontal and/or vertical position using the OSD.

x Check image size setting.

Colors are Incorrect

x Adjust the color setting using the OSD.

Cannot display the LCD monitor with resolution 1440 x 900

x Please download the video card driver from websites below:

Nvidia: http://www.nvidia.com/content/drivers/drivers.asp Intel: http://downloadfinder.intel.com/scripts-df/support_intel.asp

+ 49 hidden pages
