ETE4607, ETE5407, EBE4507, EBE5307, EBE5367, EHE5267, EFE4227, ERE5047
Refrigeration User manual
REGISTER YOUR FRIDGE WITH YOUR SMARTPHONE
Locate the label
1
on the inside of your fridge
Easy register with your smartphone
1. Photograph the camera icon, including the 4 do ts(
2. Then text it to 0488 446 622
(Australia only)
Photograph the
2
Text image to 0488 446 622
3
(Australia only)
© 2017 Electrolux Home Products Pty Ltd. EST_PhotoRegister_Fridge_70x70_Dec17
).
(
)
00000000000
CONGRATULATIONS
2 electrolux.com.au
Dear customer,
Congratulations and thank you for choosing our refrigerator. We are sure you will find your new refrigerator a pleasure to use. Before you use the refrigerator we recommend that you read through the relevant sections of this manual, which provides a description of your refrigerator and its functions.
To avoid the risks that are always present when you use an electric appliance, it is important that the refrigerator is installed correctly and that you read the safety instructions carefully to avoid misuse and hazards.
We recommend that you keep this instruction booklet for future reference and pass it on to any future owners.
After unpacking the refrigerator, please check it is not damaged. If in doubt, do not use the refrigerator but contact your local customer care centre.
The symbols you will see in this booklet have these meanings:
WARNING
This symbol indicates information concerning your personal safety.
CAUTION
This symbol indicates information on how to avoid damaging the refrigerator.
IMPORTANT
This symbol indicates tips and information about use of the refrigerator.
ENVIRONMENT This symbol indicates tips and information about economical and ecological use of the refrigerator.
CONDITIONS OF USE
This refrigerator is designed and intended to be used in normal domestic applications only.
Record model and serial number here:
Model number: ....................................................................
Serial number: .....................................................................
CONTENTS
Important safety instructions ......................................................3
Refrigerator features ......................................................................4
Top mount refrigerator features ....................................4
Bottom mount refrigerator features ..............................5
Ice & Water ...........................................................................6
French door ice & water features .................................7
French door features ..........................................................7
Single door features ............................................................8
Single door features ............................................................9
Installing your new refrigerator ...............................................10
Unpacking your refrigerator ..........................................10
Locating your refrigerator. ..............................................10
Installing your refrigerator................................................10
Fitting the handles ...............................................................11
Ice & Water models ......................................................................11
Installation ..............................................................................12
Changing the water filter .................................................14
Using your refrigerator ................................................................15
Removing Features ............................................................15
AHC (Auto humidity control............................................15
Freezer Shelves ....................................................................15
Drawers with telescopic slides ......................................15
Twist & Serve ice .................................................................16
LED Lighting ..........................................................................16
Controlling .........................................................................................17
About the User Interface .................................................17
Functions of the user interface ......................................18
The freezer user interface ..............................................20
Error Codes ...........................................................................21
General information .....................................................................22
Cleaning the refrigerator ................................................22
Food storage guide ..........................................................23
Troubleshooting ...................................................................24
Ice maker troubleshooting .............................................26
Noises ......................................................................................27
Warranty Information ...................................................................31
NOTE: You must read these warnings carefully before
IMPORTANT SAFETY INSTRUCTIONS
3
installing or using the refrigerator. If you need assistance, contact your customer care centre. The manufacturer will not accept liability, should these instructions or any other safety instructions incorporated in this book be ignored.
WARNING
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
I t is essential the power point is properly earthed to
ground. Consult a qualified electrician if you are unsure.
Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are of the type recommended by the manufacturer.
Unplug the refrigerator before cleaning or moving it
to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and pull straight out.
I f the power cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
Don’t use a steam cleaner. If live components come
into contact with condensing steam, they may short­circuit or cause an electric shock.
Do not store explosive substances
such as aerosol cans with a flammable propellant in this appliance. If pressurised aerosol containers bear the word ‘flammable’ and/or a small flame symbol, do not store them inside any refrigerator or freezer. If you do so you may cause an explosion.
Do not damage the refrigerant circuit.
This appliance contains insulation formed with
flammable blowing gases. Avoid safety hazards by carefully disposing of this appliance.
I f you wish to discard this refrigerator, please
contact your local authorities and ask for the correct method of disposal.
When you dispose of your old refrigerators and
freezers, remove any doors. Children can suffocate if they get trapped inside.
The plug must be accessible when the appliance is in
position.
Never try to repair the refrigerator yourself, only use
a qualified or authorised service person for repairs.
WARNING
R600a refrigerant warning
This appliance contains flammable R600a refrigerant. Avoid safety hazards by carefully installing, handling, servicing and disposing of this appliance.
Ensure that the tubing of the refrigerant circuit is not damaged during transportation and installation.
Leaking refrigerant may cause eye injuries or ignite.
The room for installing appliance must be at least
1m3 per 8g of refrigerant. The amount of refrigerant in the appliance can be found on the rating plate inside the appliance.
If you are unsure of the refrigerant check the rating plate inside the refrigerator compartment.
It is hazardous for anyone other than an Authorised Service Person to service this appliance. In Queensland Australia the Authorisation Service Person MUST hold a Gas Work Authorisation for hydrocarbon refrigerants to carry out servicing or repairs which involve the removal of covers.
Keep ventilation openings in the appliance enclosure or in the built-in structure, obstruction.
Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
Important Information that my impact your Manufacturer's Warranty
Adherence to the directions for use in this manual is extremely important for health and safety. Failure to strictly adhere to the requirements in this manual may result in personal injury, property damage and affect your ability to make a claim under the Electrolux your product. Products must be used, installed and operated in accordance with this manual. You may not be able to claim on the Electrolux manufacturer’s warranty in the event that your product fault is due to failure to adhere to this manual.
manufacturer’s warranty provided with
clear of
REFRIGERATOR FEATURES
4 electrolux.com.au
TOP MOUNT
LED light
TasteGuard Deodoriser
Refer to the section “Using
Twist & Serve Ice
your Refrigerator” for details on removing, relocating and
using this feature.
LED lighting
Your refrigerator is fitted
with LED lighting.
Glass shelves
The glass shelves improve
visibility.
Wire shelf
TasteGuard Deodoriser
MultiZone™ deli drawer
Use the MultiZone™ deli
drawer to store foods like
small goods, fresh or cooked
meat and cheese, or as an
additional crisper. The
drawer will prevent strong
food odours from impacting
the rest of the refrigerator.
To remove the deli drawer,
pull it forward, then lift it up
and pull it further forward.
Auto humidity control
TasteLock™ crisper
Use the crisper to store
vegetables, fruit or small
goods.
ETE5407 illustrated
Dairy compartment
This compartment can be used to store dairy.
FlexStor™ door bins
Slide the bins to meet different storage needs. To remove, lift and tilt. To replace, tilt the top and push down until locked in place.
Door storage bin
The door bin can be removed by lifting it up over the support lugs. To replace, push down over the support lugs to lock in place.
Bottle storage bin
Use the bottle bin for tall bottle storage. The bottle bin can be removed by lifting it up over the support lugs. To replace, push down over the support lugs to lock in place.
Features may vary depending on model. Not all models will have features listed.
Refrigerator/freezer control panel
From this panel you can control the temperature of the refrigerator and freezer compartments as well as setting the Boost function or resetting the door alarm.
For further information on how to use this feature refer to the section “About the User Interface”.
BOTTOM MOUNT
5 electrolux.com.au
5
Your refrigerator is fitted with
LED lighting
LED lighting.
Glass shelves
The glass shelves improve
visibility.
Wire shelf
MultiZone™ deli drawer
Use the deli drawer to store
foods like small goods, fresh
or cooked meat and cheese,
or as an additional crisper.
The drawer will prevent
strong food odours from
impacting the rest of the
refrigerator. To remove the
deli drawer, pull it forward,
then lift it up and pull it further
forward.
Auto humidity control
TasteLock™ crisper
Use the crisper to store
vegetables, fruit or small
goods.
Twist & Serve ice
Refer to the section “Using
your Refrigerator” for
details on removing and
using this feature.
Freezer storage bin
Refer to the section “Using
your Refrigerator” for
details on removing, and
using this feature.
TasteGuard Deodoriser
Dairy compartment
This compartment can be used to store dairy.
FlexStor™ door bins
Slide the bins to meet different storage needs. To remove, lift and tilt. To replace, tilt the top and push down until locked in place.
Door storage bin
The door bin can be removed by lifting it up over the support lugs. To replace, push down over the support lugs to lock in place.
Bottle storage bin
Use the bottle bin for tall bottle storage. The bottle bin can be removed by lifting it up over the support lugs. To replace, push down over the support lugs to lock in place.
EBE5307 illustrated
Features may vary depending on model. Not all models will have features listed.
Refrigerator/freezer control panel
From this panel you can control the temperature of the refrigerator and freezer compartments as well as setting the Boost function or resetting the door alarm.
For further information on how to use this feature refer to the section “About the User Interface”.
REFRIGERATOR FE
6 electrolux.com.au
ICE & WATER
ATURES
Your refrigerator is fitted
LED lighting
with LED lighting.
Replaceable water filter
Glass shelves
The glass shelves improve
visibility.
Wire shelf
MultiZone™ deli drawer
Use the deli drawer to store
foods like small goods, fresh or
cooked meat and cheese, or as
an additional crisper.
The drawer will prevent strong
food odours from impacting
the rest of the refrigerator. To
remove the deli drawer, pull
it forward, then lift it up and
pull it further forward.
Auto humidity control
TasteLock™ crisper
Use the crisper to store
vegetables, fruit or small goods.
Automatic ice maker
Refer to the section “Using
your Refrigerator” for details
on using this feature.
TasteGuard Deodoriser
Dairy compartment
This compartment can be used to store dairy.
FlexStor™ door bins
Slide the bins to meet different storage needs. To remove, lift and tilt. To replace, tilt the top and push down until locked in place.
Door storage bin
The door bin can be removed by lifting it up over the support lugs. To replace, push down over the support lugs to lock in place.
Bottle storage bin
Use the bottle bin for tall bottle storage. The bottle bin can be removed by lifting it up over the support lugs. To replace, push down over the support lugs to lock in place.
Freezer storage bin
Refer to the section “Using
your Refrigerator” for details
on removing, and using this
feature.
Features may vary depending on model. Not all models will have features listed.
EBE5367 illustrated
Refrigerator/freezer control panel
From this panel you can control the temperature of the refrigerator and freezer compartments as well as setting the Boost function controlling the Ice Maker or resetting the door alarm.
For further information on how to use this feature refer to the section “About the User Interface”.
FRENCH DOOR ICE & WATER
7
Your refrigerator is fitted
LED lighting
with LED lighting.
Replaceable water filter
Glass shelves
The glass shelves improve
visibility.
Wire shelf
MultiZone™ deli drawer
Use the deli drawer to store
foods like small goods, fresh
or cooked meat and cheese,
or as an additional crisper.
The drawer will prevent
strong food odours from
impacting the rest of the
refrigerator. To remove the
deli drawer, pull it forward,
then lift it up and pull it further
forward.
Auto humidity control
TasteLock™ crisper
Use the crisper to store
vegetables, fruit or small
goods.
TasteGuard Deodoriser
Dairy compartments
These compartments can be used to store dairy.
FlexStor™ door bins
Slide the bins to meet different storage needs. To remove, lift and tilt. To replace, tilt the top and push down until locked in place.
Bottle storage bin
Use the bottle bin for tall bottle storage. The bottle bin can be removed by lifting it up over the support lugs. To replace, push down over the support lugs to lock in place.
Automatic ice maker
Refer to the section “Using
your Refrigerator” for details
on using this feature.
Freezer storage bin
Refer to the section “Using
your Refrigerator” for details
on removing, and using this
feature.
EHE5267S illustrated
Refrigerator/freezer control panel
From this panel you can control the temperature of the refrigerator and freezer compartments as well as setting the Boost function controlling the Ice Maker or resetting the door alarm.
For further information on how to use this feature refer to the section “About the User Interface”.
Features may vary depending on model. Not all models will have features listed.
REFRIGERATOR FE
8 electrolux.com.au
SINGLE DOOR
ATURES
Your refrigerator is fitted
LED lighting
with LED lighting.
Replaceable water filter
TasteGuard Deodoriser
Glass shelves
The glass shelves improve
visibility.
Wire shelf
MultiZone™ Deli drawer
Use the deli drawer to store
foods like small goods, fresh or
cooked meat and cheese, or as
an additional crisper. The
drawer will prevent strong food
odours from impacting the rest
of the refrigerator. To remove
the deli drawer, pull it forward,
then lift it up and pull it further
forward.
FreshZone™ crispers
Use the crisper to store
vegetables, fruit or small
goods.
Dairy compartment
This compartment can be used to store dairy.
FlexStore™ door bins
Slide the bins to meet different storage needs. To remove, lift and tilt. To replace, tilt the top and push down until locked in place.
Door storage bin
The door bin can be removed by lifting it up over the support lugs. To replace, push down over the support lugs to lock in place.
Bottle storage bins Use the bottle bin for tall
bottle storage. The bottle bin can be removed by lifting it up over the support lugs. To replace, push down over the support lugs to lock in place.
Refrigerator control panel
From this panel you can control the temperature of the refrigerator compartments as well as setting the Boost function or resetting the door alarm.
For further information on how to use this feature refer to the section “About the User Interface”.
Features may vary depending on model. Not all models will have features listed.
ERE5047 illustrated
REEZER FEATURES
9
F
SINGLE DOOR
Automatic ice maker
Refer to the section
“Using your Refrigerator”
for details on using this
feature.
LED lighting
Your freezer is fitted with LED lighting.
Glass shelves
The glass shelves improve visibility.
EFE4227 illustrated
Freezer control panel
From this panel you can control the temperature of the freezer as well as setting the fast ice function or reset the door alarm.
or further information on how to use this feature refer to
F the section “About the User Interface”.
Storage bins
Refer to the section “Using your Refrigerator” for details on removing, and using this feature.
Features may vary depending on model. Not all models will have features listed.
ENVIRONMENTAL TIPS
INSTALLING YOUR NEW APPLIANCE
10 electrolux.com.au
UNPACKING
ENVIRONMENT
Most of the packing materials are recyclable. Please dispose of those materials through your local recycling depot or by placing them in appropriate collection containers.
Important – check for any damages or marks. If you find the refrigerator is damaged or marked, you must report it within 7 days should you wish to claim for damage/ marks under the manufacturers warranty. This does not affect your statutory rights.
Clean your refrigerator thoroughly following the instructions in the “Cleaning” section and wipe off any dust that has accumulated during shipping.
LOCATING THE REFRIGERATOR
CAUTION
Automatic aerosol systems (such as insect control) should not be located adjacent to the product as the spray may cause long term damage to the external surfaces of the appliance.
Do not put the refrigerator in a location that is too cold or is unprotected, for example in a garage or on a veranda. The ambient temperature should be above 10°C.
Put the refrigerator in a dry place avoiding areas of high moisture or humidity.
Ensure the refrigerator is located on an even surface.
Adequate ventilation around your refrigerator
The diagram below shows the recommended airspace to allow for ventilation of your refrigerator.
50mm
Y
Recommended
30mm
airspace
CABINET
DOOR
30mm
X
When positioned in a corner area, spacing of at least 350mm (300mm for EHE5267 model) on the hinge side will allow the doors to open enough to enable the removal of bins and shelves.
NOTE: Doors are designed to sit proud of cabinetry (not flush). The clearances shown above are the recommended minimum clearances.
The clearance at the rear must not exceed 75mm.
INSTALLING YOUR REFRIGERATOR
1. Roll the refrigerator into place.
10 - 15mm
Height adjusting nut
Fixed rear rollers
The rollers are designed for forward or backward movement only. They are not castors. Moving the refrigerator sideways may damage your floor and the
rollers. Before moving your refrigerator ensure height adjusting nut and the stability foot are fully wound up off the floor.
2. Wind the large height adjusting nut under door hinge down until the refrigerator is tilted back by 10mm (see dia
3. Wind the large height adjusting nut on the handle side down until the refrigerator is level and stable. If you have difficulty winding the nut or height adjusting foot down, have someone tilt the refrigerator back so you have better access.
gram).
If you have a cupboard above the refrigerator with a rear gap of less than 100 mm (Y), recommended clearance at the top of the refrigerator increases from 30mm to 70mm (X) minimum.
ETB4607, ETE5407 EBE4507, EBE5307 EBE5367, EFE4227 ERE5047
350mm
300mm
EHE5267
300mm
stability foot wound up
11
4. Check the alignment of the refrigerator to the surrounding cupboards to see if it is level. You can
adjust the level as detailed in step 2 and 3.
ICE AND WATER MODELS
aligned to cupboards ie even gap.
top of refrigerator is level ie horizontal.
adjust front feet for uneveness of floor eg. wind this foot down or up.
5. I f you find your refrigerator rocks from corner to corner, it means your floor is uneven. Find a piece of plastic or hardboard etc. and pack it firmly under the roller.
6. You may now need to fine-tune the installation by repeating steps 3, 4 and 5.
7. When you have the appliance in its final position, it needs to be stabilised. Wind the stability foot under the door hinge down to the floor until it just makes contact with the floor. Lift the front of the appliance to take the weight off the stability foot, then turn it half a turn further to ensure firm contact with the floor. Wind the large height adjusting nut back up to ensure all the weight is now on the front stability foot.
8. Repeat step 7 for the stability foot on the handle side. Whenever you need to move the appliance, be sure to wind the feet back up so that the appliance can roll freely and be sure to reset it when reinstalling.
WARNING
Connect to potable water supply only, if using tank or bore water in a model with an internal filter it is recommended to also use an external filter (not supplied).
The new hose sets supplied with the appliances must be used and old hose sets should not be reused.
Never connect the appliance to a hot water supply.
WATER FILTER
It should not be used on water that is micro biologically unsafe or with water of unknown quality. The service life of the filter may be reduced in water supplies that contain an excess of particles or other impurities. Reduced flow rate is an indication that a new filter is required. Failure to replace the filter when required can affect the function of the ice maker. Service calls caused by a failure to replace the filter are not covered by warranty. Replacement water filters are available from Electrolux Home Products Spare Parts Centres and can be posted to you for your convenience (refer to spare parts contact numbers on the warranty page).
Contents of installation kits
Filter Kit for single door freezer
1 x water filter with push fit connections
DATE FITTED___/___/___
2 x mounting brackets and screws
Installation Kit
Bottom mount &
single door all refrigerator)
4 metres of water tubing
1 x 1/2” tap fitting
Large height adjusting nut wound up.
stability foot wound down
9. Plug your refrigerator straight into its own power point and never use a double adapter. If you need to roll the refrigerator to get to the plug, remember to raise the stability foot first.
10. Before you put any food in your refrigerator, it’s recommended you leave it on for 2 or 3 hours to check it is running properly.
FITTING THE HANDLES
For models with ‘Pole’ handles, the handles are supplied prepackaged with your refrigerator and will require fitting.
Refer to the instructions provided in the pack.
Congratulations! You have successfully installed your new refrigerator.
4 + 1 metres of water tubing
1 x 1/2” tap fitting
2 x circlips
Water supply and plumbing
A drinkable water supply to suit a 1/2” tap fitting is required adjacent to the refrigerator. It is recommended that a licensed plumber install a new water supply outlet nearer to the appliance should the tubing supplied not be long enough. It is not recommended that the tubing be extended as this could adversely affect the flow of water to the ice maker or water dispenser. The water dispenser and automatic ice maker require a drinkable water supply with a pressure range of between 206kPa and 689kPa (30PSI and 100PSI). If the water supply is above 100psi a pressure limiting valve should be installed.
ICE AND WATER MODELS (CONTINUED)
12 electrolux.com.au
It is recommended that a noise reduction valve also be fitted in the water supply line. This will reduce water hammer and its effects from quick action household taps and fast acting valves on appliances.
The refrigerator water valve is pre-fitted with a push-fit connector for inserting the water tube. When the tap connection is other than 1/2”, adapters can be purchased from plumbing supply stores or good hardware stores.
INSTALLATION
Please read before beginning installation.
The water connection to your ice and water product can be self installed. However, it is recommended that you seek advice from a licensed plumber before commencing the installation.
IMPORTANT
Check for water leaks at all water connection points in the first 2 to 3 hours after installation, and correct it in case of any water leak. Recheck after 24 hours; if a leak still occurs, it is recommended to contact a licensed plumber for advice.
Water is to be connected as per diagrams below.
Internal Filter
Step 1.
Ensure that the refrigerator is disconnected from power supply.
Step 2.
Connect tap fitting to water supply tap. Tap must be close to the refrigerator.
Step 3.
Push the tube into tap fitting past insertion mark.
(NOTE: step 4 to step 10 relate to models with an external filter only).
Step 4.
Install brackets for filter close to tap. Plan to leave as much tubing as possible behind the refrigerator to enable it to be moved easily for cleaning or service.
Do not screw the brackets into the refrigerator as this may void your w
arranty and permanently damage the refrigerator.
Single door freezer with external filter
sink
mains water inlet
brackets
filter
Step 5.
Write date on filter. The filter will need to be replaced every 6 months.
Step 6.
Extend the collar and clip a circlip around the collar at both ends of the filter.
Step 7.
Fit the filter to brackets with water flow arrow pointing up.
water
flow
direction
kitchen cupboard
Step 8.
13
Push shorter tube into tap fitting past insertion mark.
Step 9.
Push other end into filter INLET.
be black in colour. This is residual carbon dust from the filter and is non-toxic. If the water is slow to shut off or the dispenser is dripping, air may still be in the lines. Either purge more water through the system to remove this air or allow some time for the air to be removed over subsequent dispensing. For normal use, water dispenser will automatically shut off after 2 minutes of continuous operation.
IMPORTANT
As the water cut off is not instant, leave the glass under the dispenser briefly until the water has stopped flowing to avoid spills.
Step 10.
Connect remaining tube length into filter OUTLET. Water filter contains carbon dust which is non-toxic. Using a large container, turn on water and purge the residual carbon dust from filter until water runs clear.
Step 11.
Connect other end of remaining tube length to inlet on bottom right hand side of refrigerator.
Step 12.
Turn on water and check all joints and tubes for leaks.
Step 13.
Reconnect the power.
Clean and empty the dispenser drip tray regularly to avoid overflow.
If you have not used the dispenser for some time, discard the first seven or eight cups of water (contaminants could have settled in the water pipes).
Step 15.
Switch ON Ice Maker. (except model ERE5047.) Refer to Controlling section
Once the refrigerator has been running for at least 24 hours remove the ice bin and dispose of the first few batches of ice to ensure that impurities have been flushed from the system.
Party Ice (except model EFE4227)
When the Ice Bin is removed from the cabinet the Auto Ice Maker will continue to dispense ice into the top freezer drawer.
CAUTION Water dispenser should not be used for extended periods of time. After 2 minutes of continuous use the water dispenser will automatically shut off.
Step 14.
Switch On Water Dispenser (except model EFE4227.)
Using a large container, run the water dispenser to clear air from lines. This may take a few minutes. Purge and dispense a minimum of 2 litres of water. Initial water may
ICE AND WATER MODELS (CONTINUED)
14 electrolux.com.au
CHANGING THE WATER FILTER
IMPORTANT
Always fit the filter as per
manufacturer’s instructions.
If you need to replace water tube, only use
approved water quality piping that meets the pressure requirements.
Make sure your refrigerator is level to avoid
uneven ice cubes.
Replace filter at suggested intervals to avoid
water/ice reduction and irregularities in taste.
Remove and clean ice bin once a month,
discarding unused ice cubes. This will ensure fresh, clean ice and smooth operation of your ice maker.
Clean and empty the dispenser drip tray regularly
to avoid overflow.
WARNING
If you have not used the dispenser for some time, discard the first seven or eight cups of water and any ice that the ice maker produces in the first 24 hours (contaminants could have settled in the water pipes).
6. Press a drinking glass against the water dispenser while checking for any leaks at the filter housing. Any spurts and sputters that occur as the system purges air out of the dispenser system are normal.
7. After filling one glass of water, continue flushing the system for about four minutes.
8. Turn on the ice maker. (Diagram 5).
9. When the filter has been replaced press and hold
the ‘Ice and Water’ button for three seconds to reset
the filter replace timer.
D
Diiaaggrraamm 1
DDiiaaggrraamm 2
Internal Water filter
The water filter is located at the top left side of the fresh food compartment.
Replacing the water filter
You should change the water filter every six months to ensure the highest possible water quality.
If your refrigerator has not been used for a period of time (during a house move for example), change the filter before reinstalling the refrigerator.
It is not necessary to turn the water supply off to change the filter. Be ready to wipe up any small amounts of water released during the filter replacement.
1. Ensure that the ice maker is turned off (Diagram 1).
2. Remove the filter by turning anti-clockwise 180˚.
3. Slide the old water filter cartridge straight out of the
housing and
4. Unwrap the new filter cartridge and using the alignment guide, slide it gently into filter housing until it stops against the filter connection at the back of the housing. (Diagram 3).
5. Engage the filter by firmly rotating clockwise until the filter snaps into position (once engaged the filter cannot be rotated further). (Diagram 4).
discard it. (Diagram 2).
DDiiaaggrraamm 3
DDiiaaggrraamm 4
DDiiaaggrraamm 5
USING YOUR REFRIGERATOR
15
Refrigerators work by transferring heat from the food inside to the outside air. This operation makes the back and sides of the refrigerator feel warm or even hot particularly at start-up and on warm days – this is normal.
Avoid placing food against the air vents in the refrigerator as it affects efficient circulation. If the door is opened frequently, a light frosting will occasionally occur on the freezer’s interior. This is normal and will clear after a few days. If the freezer door is accidentally kept open, a heavy frost will coat the inside walls and should be removed.
Your new refrigerator uses a high-speed compressor, along with other energy-efficient components, which may make unusual sounds and be more noticeable at night and quieter times. These sounds simply indicate your refrigerator is working how it should. They include:
Compressor running noises;
Air movement noise from the small fan motor;
A gurgling sound, similar to water boiling;
A popping noise, heard during automatic
defrosting; and
A clicking noise, prior to compressor start-up.
Further details can be found in the
Troubleshooting Guide.
IMPORTANT
For top mount refrigerators (where the freezer is on top of the fresh food compartment).
REMOVING FEATURES
AHC (Auto Humidity Control)
Auto Humidity Filter Cartridge Auto Humidity Control automatically releases excess moisture & maintains optimal humidity for your fresh vegetables, maintaining the taste, texture and freshness.
Recommended to replace filter once a year*
Replacing Filter Cartridge
Auto Humidity Filter is located at the back of the crisper handle.
Hold the tabs of the fil er cartridge.
Slide o the Right to release the filter.
Replace a new filter and slide to the Left to lock in
place.
Freezer shelf
Don’t place food forward of the ribs on the freezer floor, as it will keep the door open.
Ribs
For bottom mount refrigerators (where freezer is below the fresh food compartment):
Ensure all freezer drawers and shelves are pushed back completely to prevent them from keeping the door open.
Remove the freezer shelf by lifting the catches on the right and left underside of the shelf to release the shelf then pull the shelf toward you.
Drawers fitted with telescopic slides
To remove the drawer for cleaning.
1. Empty food from the drawer.
2 . Remove the drawer by pulling it forward and lifting
the front to unhook it from the slides. Once you have removed the drawer, ensure the slides are pushed back so they are fully closed.
WARNING
Never close the door while the telescopic slides are extended. This may damage the slide and/ or refrigerator or cause the slide to become disengaged from the refrigerator.
USING YOUR REFRIGERATOR (CONTINUED)
16 electrolux.com.au
To replace the drawer:
1. Ensure the telescopic slides are pushed in all the way.
2. Slide the drawer into place over the slides and push the bin in until it stops.
3. Drop drawer into position.
Freezer bottom bin
To remove the bin, pull the drawer out until it is open all the way then lift bin out from the front of the bin. When refitting insert the rear of the bin first then lower into position.
When replacing the bins after cleaning, we recommend fitting the lower bin first.
Twist and Serve Ice
Mounting the twist & serve dispenser to the other side of the freezer.
NOTE: This is only possible on top mount models.
Insert into the slot at the rear of the shelf Then engage into the front of the shelf
1. Refit the runner into the rear of the shelf on the right hand side and then engage the front.
2. Fit the carriage by sliding it into the runners until the front if the carriage engages with the shelf.
3. Refit the ice tray and ice bin.
WARNING
Fill the ice cube tray with potable water only.
CAUTION
LED lighting
Your appliance is fitted with long life LED lighting. In the unlikely event the LED lights should fail, then the LED lights should be serviced by the manufacturer.
Refer to the warranty page for contact details.
1. R emove the ice bin and ice cube tray. If the ice tray
assembly is frozen to the carriage, simply squeeze the tray and shelf together to break the ice.
2. Before you remove The ice carriage, remember to disengage it from the glass shelf as it may result in damage to the assembly.
3. Remove the centre runner by disengaging it at the front of the shelf,and removing it from the rear.
CONTROLLING
17
ABOUT THE USER INTERFACE
The following pages explain the various functions of the user interface to help you better understand how to get the most out of your new refrigerator.
IMPORTANT
NOTE: When you set a temperature, you set an average temperature for the whole refrigerator cabinet. Ensuring that you make only small adjustments and wait at least 24 hours to see if the new temperature is correct to your liking.
Checking the softness of ice cream is a good indication that your freezer is the right temperature, while checking the temperature of water kept in the refrigerator is a good way of checking the temperature of the food compartment.
Temperatures inside each compartment may vary, depending on how much food you store and where you place it.
High or low room temperature may also affect the actual temperature inside the refrigerator.
CONTROLLING (CONTINUED)
18 electrolux.com.au
FUNCTIONS OF THE USER INTERFACE
ETE4607, ETE5407, EBE4507,
EBE5367, EHE5267 ERE5047
EBE5300, EBE5307
1
2 3 6
8
9
9
Button / Icon Description Primary Function
1 Compartment Selector button Selects controllable compartment.
2 Lock Icon Indicates if the user interface is locked.
3 Compartment Icon Indicates controllable compartment.
4
ECO Icon
5 Digital display Indicates temperature of selected compartment.
6 Decrease button Decreases temperature of selected compartment.
7 Increase button Increases temperature of selected compartment.
8 Mode indicators (Boost, Fast Ice, Holiday) Indicates appliance operation mode.
9 Display Lock button Selects lock state of user interface.
10 Mode select button Selects oper
11 Drinks Chill button Selects drinks ch
12 Filter status indicators Indicates filter
13 Icemaker and Water on off indicators Shows operational status.
14 Ice & Water or Water on/off button Selects operation status.
15 Door sensor Senses door st
1 1
2
4
3
5
6
7
8
10
9
11
14
15
Indicates if the appliance is operating in its most energy efficient mode.
2
4
3
5
6
7
8
10
9
11
12
13
14
15
ation mode of appliance.
ill timer.
replacement timing.
ate (open or closed).
4 5 7
10
11
12
13
15
IMPORTANT
The factory default settings for the refrigerator is “3° C” and “-18°C” for the freezer. If you want to change the temperature, remember to make only small adjustments and wait 24 hours to see if it’s correct.
Function Ic
TIPS & INFORMATION
19
Setting the temperature
on
O
peration (depending on model)
Press button 1 to select compartment on icon 3 Press buttons 6 or 7 to adjust temperature up or down.
Boost mode Increases the chill rate of the refrigerator for 90mins before returning to pre-set mod
Fast Ice Decreases the freezer temperature to
-23°C for 12 hours before returning to pre-set mode.
Holiday mode The r
efrigerator to save energy when doors remain closed for an extended period.
Display Lock Deactivates th
Drinks Chill Sets a timer for between 1 and 30 minutes as a reminder for when drinks are placed in the freezer for quick chill.
e.
minimises defrosting
e user interfa
ce controls.
Press button 10 until the snowflake icon is illuminated. Boost mode can be deselected using button 10.
Press button deselected using button 10.
Press button 10 until the holiday icon is illuminated. When holiday mode is enabled the temperature settings will be set to 3°C for
the refrigerator and -18°C for the freezer. Holiday mode can be deselected using button 10 or opening the fridge door.
When holiday mode is disabled the temperature settings will revert to the previous settings.
Holiday mode can be deselected using button 10 or opening the fridge door.
To turn on/off press and hold button 9 for 3 seconds, the lock icon is illuminated when activated.
To turn on press button 11 and initial time of 20 mins will appear on digital display. To adjust time use buttons 6 and 7.
Alarm will sound when time is finished. Press button 11 to turn off during or after countdown. The time taken to chill
depends on the size of your bottle. Do not leave the bottle inside the freezer longer than the time needed
for chilling.
10 until the fast ice icon is illuminated. Fast ice mode can be
Ice Maker on/off Enables/disables ice maker and water dispensing features.
Ice Cube Size Ice cube size can be adjusted for personal preference or water pressure.
Sabbath Mode Disables all lights and other electrical activity from occurring when the refrigerator door i
Indicator Icon Operation
Eco Mode Enabled when appliance set to energy efficient operating
Order Filter Reminder when the water filter periodically r
Replace Filter Reminder replacement.
equires replacement.
when the water filter requires
to suit supply
s opened.
temperatures.
To enable/disable press button 14 to cycle through on/off modes. Indicator 13 will illuminate when either the ice maker or water dispenser are
deactivated.
Press and hold buttons 10 and 14 for 3 seconds. Press button 6 to cycle through cube sizes, small (S), medium (M), large (L) & extra large (EL). Medium symbol shown. To confirm the setting press button 10. The display will return to the preset mode after 45 seconds.
To enable and disable Sabbath mode, press and hold buttons 7 and 9 for 3 seconds.
When enabled/disabled an alarm will beep 4 times and “Sb” will appear on digital
ECO icon automatically appears when refrigerator is set between +3°C and +7°C and freezer is set between -14°C and -18°C
Order filter icon will appear as a reminder to order a replacement water filter. When the filter has been replaced press and hold button 14 for 3 seconds to
reset the filter replacement timer.
Replace filter icon and alarm will activate as a reminder to replace the water filter. Mute alarm for 1 week by pressing any button on the user interface. When the filter has been replaced press and hold button 14 for 3 seconds to reset the filter replacement timer.
display when active.
IMPORTANT
The factory default settings for the refrigerator is “3°C” and “-18°C” for the freezer. If you want to change the temperature, remember to make only small adjustments and wait 24 hours to see if it’s correct.
CONTROLLING (CONTINUED)
20 electrolux.com.au
THE FREEZER USER INTERFACE
EFE4227
Fast Ice on/off LED
Ice Maker on/off LED
Freezer temperature
scale LEDs
Description Operation / Primary Function
Fast Ice on/off LED Indicates the status of the Fast Ice function.
Ice Maker on/ off LED Indicates the status of the Ice Maker function.
Fast Ice/Ice Maker button
Use the Fast Ice function when you add a large amount of food to the freezer compartment;
Press the ‘Fast Ice/Ice Maker’ button. The Fast Ice icon will flash indicating that the Fast Ice is active. and the compressor will run continuously for 12 hours
After 12 hours the freezer will automatically return to normal mode.
Th e
Fast Ice function can be cancelled anytime by pressing the button again.
Fast Ice/ Ice maker on/off button
Temperature adjust/Replace filter button
Turning Automatic Ice Maker
Off
On/
Press and hold the ‘Fast Ice’/Ice Maker button for 3 seconds. The Ice Maker LED will activate indicating that the Ice Maker is active.
I ce Maker can be turned off at any time. Press and hold the 'Fast Ice' button for 3 seconds.
Ice cube size
Ice cube size can be adjusted for personal preference or to suit s
upply water pressure
Freezer temperature scale
Extra large Large Medium Small
Indicates the temperature setting of the freezer compartment.
Press “Temp” and “Fast Ice” buttons together for 3 seconds within first 12 seconds of appliance starting. Four pre-set ice cube sizes can be selected by the use
r. Press “Fast Ice” button to scroll
through options and press “Temp” button to confirm.
icons
Temperature adjust button Press any button to awaken control.
Press the ‘Temp’ button to decrease the compartment temperature. Once the coldest temperature is reached the display will return to the warmest setting with the next press.
Replace filter Reminder for when the water filter requires
replacement.
Replace filter alarm will activate as a reminder to replace the water filter.
An alarm will sound and the Fast Ice on/off icon will flash. Hold "TEMP" button for 3 seconds to reset.
IMPORTANT
The factory default settings for the freezer is “-18°C”. If you want to change the temperature, remember to make only small adjustments and wait 24 hours to see if it’s correct.
/Ice Maker
ERROR CODES & ALARMS
21
Alarms
Alarm Icon What it means Operation
Freezer Te (Except Single door freezer)
Activates if the freezer temperature is 10°C over set temperature for a period of 50 minutes (except during a defrost).
An alarm will sound the temperature icons will flash.
Door Alarm
Activates if the refrigerator or freezer doors are left open for longer than
An alarm will sound the affected compartment icon will flash and the temperature and icons will fade on and off.
All Freezer Model
mperature Alarm
2 minutes.
To deactivate the alarm for 50 minutes press any button.
To deactivate alarm for 12 hrs on the ice & w
ater model press and hold Select Mode for 10 seconds for non ice and water models press and hold any button for 10 seconds.
Alarm will sound and icon will flash
ind (Ice & water models)
To silence the alarm for 8 minutes while
the door is open press any button (the icons will continue to flash until door is closed).
icating which door is open.
Error codes
Error code What it means… What to do…
Communication Error
Sensor – Open Circuit /Short Circuit
If you see this icon displayed (electronic display models) or the icon is flashing it means that the control has lost contact with the main control board.
The appliance will operate at its last known setting, all auxiliary functions will not work.
If you see this icon displayed (electronic display models) or a the second and fourth temperature icons are flashing it means that an error has been detected on a sensor.
The refrigerator will run in a default cycle to prevent food spoilage.
top temperature
ny combination of
Turn the unit off at the power point for 5 minutes and then turn it
Under most circumstances this will reset the display enabling normal function to continue.
If the error re-occurs then call for service.
Call for ser
back on.
vice.
GENERAL INFORMATION
22 electrolux.com.au
CLEANING YOUR REFRIGERATOR
WARNING
BEFORE CLEANING: Turn the refrigerator off at the power point and unplug the cord to prevent any chance of electrocuting yourself.
Your stainless steel refrigerator is manufactured from mark-resistant stainless steel. This stainless steel has a special advanced protective coating that eases the removal of marks such as fingerprints and water spots. To keep its appearance, clean it regularly with lukewarm soapy water and a soft cloth.
CAUTION
Never use stainless steel cleaners, abrasive pads or other cleaners that will scratch the surface. Damage to the appliance after delivery is not covered by your warranty.
Interior
Clean the inside of your refrigerator regularly with a soft cloth, unscented mild soap and lukewarm water. Thoroughly dry all surfaces and removable parts and avoid getting water on the controls. Replace removable parts, plug power cord in and switch the power on before returning the food.
Many commercially available cleaning products and detergents contain solvents that will damage your refrigerator. Use only a soft cloth with an unscented mild soap and lukewarm water.
CAUTION
To clean a crisper or freezer bin with telescopic extension slides, simply wipe with a damp cloth and warm soapy water.
Never immerse the cover in water, as this could affect the operation of the slide.
Switching off your refrigerator
If you switch off your refrigerator for an extended period, follow these steps to reduce the chances of mould:
1 . Remove all food. 2 . Remove the power plug from the power point.
3. Thoroughly clean and dry the interior.
4. Ensure that all the doors are wedged open slightly for air circulation.
Ice and Water
Clean the components of the ice maker /water dispenser regularly with a soft cloth, unscented mild soap and rinsing thoroughly with lukewarm water.
For further information on the care and cleaning of your Icemaker, Ice dispenser of water dispenser refer to the section "Ice and Water Models"
Door seals
Always keep door seals clean by washing them with a mild detergent and warm water, followed by a thorough drying. Sticky food and drink can cause seals to stick to the cabinet and tear when you open the door.
Never use hot water, solvents, commercial kitchen cleaners, aerosol cleaners, metal polishes, caustic or abrasive cleaners, or scourers to clean your refrigerator.
FOOD STORAGE GUIDE
TIPS & INFORMATION
23
Category Product Refrigerator Freezer Storage Tips
Meat
Sausages and Mince 1-2 Days 2-3 Months Keep cold meat at the back of the
refrigerator where it is coldest.
Chops and Steak 3-4 Days 4-6 Months
Poultry
Seafood
Dairy
Cold Meats 3-5 Days 4-6 Months Plastic can cause meat to sweat if stored
Cuts for roasting 3-5 Days 12 Months Cuts for roasting can take up to 48 hours
Chicken 1-2 Days 2 Months If poultry takes on a smell or colour you
Roast Chicken 3-5 Days 12 Months
Eggs 6 Weeks Not Suitable Whole eggs are not suitable for freezing,
Whole fish and fillets 2-3 Days 2 Months Store in an airtight container or foil.
Lobster and crabs 1-2 Days 2 Months
Prawns 1-2 Days 2 Months Never freeze prawns in salty water as this
Milk Until Expiry Date Not Suitable If dairy takes on a smell or colour and you
in refrigerator for more than a day.
to defrost properly. Transfer frozen cuts to the refrigerator 2 days before use.
are unsure about it is best to throw it out.
slightly beaten eggs may be frozen for four months.
will dehydrate the flesh.
are unsure about it, it is best to throw it out.
Fruit & Vegetables
Yoghurt 7- 10 Days Not Suitable
Hard Cheeses 2 Weeks – 2
Months
Soft Cheeses 1-2 Weeks Not Suitable
Butter 8 Weeks 12 Months
Every fruit and vegetable has a different shelf life.
Some stay fresh for a couple of days e.g beans, others can last for a couple of months e.g. onions.
2 Months (Grated)
8-12 Months
When freezing chop and blanch in small portions.
Depending on the variety hard cheese can last from 2 weeks to 2 months.
Keep vegetables in the crisper and away from the air vents to avoid freezing.
If you wash fruit and vegetables before storing them make sure they are dry or wrap in absorbent paper before storing in the refrigerator as this can make them susceptible to rotting.
Try to keep fruit and vegetables separated as fruits that give off high levels of ethylene (the ripening agent) can prematurely ripen and spoil surrounding vegetables
IMPORTANT
Please note, use this information as a guide only, actual storage times will vary depending on how you use your refrigerator, climatic conditions and the freshness of the food.
GENERAL INFORMATION (CONTINUED)
24 electrolux.com.au
TROUBLESHOOTING
Appliance does not operate at
desired temperature
In a modern frost free refrigerator / freezer, cold air is circulated around the various compartments through air vents using a high efficiency fan.
Concern What to do
Refrigerator is too warm. Ensure food is allowed to cool before placing inside the refrigerator.
Ensure the appliance is set up as per instructions on page 11.
Ensure that contents are not obstructing the cooling vents.
Ensure the door is not held open or is being opened too frequently.
Freezer is too warm. Adjust temperature to a colder setting.
Ensure food is allowed to cool before placing inside the freezer.
Ensure the appliance is set up as per instructions on page 11.
Ensure that contents are not obstructing the cooling vents.
Ensure the door is not held open or is being opened too frequently.
Food is freezing in the refrig
erator.
Unable to change temperature settings.
Adjust temperature to a warmer setting.
Ensure that fruit and vegetables are stored in the crisper. Items with a high water content should not be placed near the cooling vents.
Refer to function guide in Controlling Your Refrigerator.
Ensure that user interface is in "awake" mode before trying to adjust temperature settings.
Appliance noise Your new refrigerator may make sounds that your old one didn’t make. Because the sounds are new to you, you
might be concerned about them. Most of the new sounds are normal. Hard surfaces, like the floor, walls and cabinets, can make the sounds seem louder than they actually are. The following describes the kinds of sounds and what may be making them.
Concern What to do
Motor noise (compressor). Nothing. This is normal as your new refrigerator uses a variable speed compressor and fan that
at start up and on warm days runs at a high speed to provide additional cooling.
When less cooling is required the compressor and fan will run at a lower speed Note that the compressor noise may seem louder at the start of the on cycle.
A clicking noise heard just before the compressor starts.
Occasional gurgling, similar to wa
ter boiling.
Airflow noise.
Rattling and other noises.
Nothing. This is normal as your new refrigerator has an automatic switching action of the temperature control,
Nothing. As each refrigeration cycle ends, you may hear a gurgling sound due to the refrigerant flowing in your refrigerator system.
Nothing, this is normal as your new refrigerator uses high efficiency fans to circulate air. Fan speed and noise may increase during periods of heavy usage or hot weather.
Ensure that the cabinet is level and stable, refer to Installation Instructions on page 11.
Check the surrounds of the appliance to ensure there is nothing touching or placed on top of the appliance.
Ensure that contents of the appliance are not placed in such a way that they are vibrating (such as bottles).
Crisper Operation
Concern What to do
Excess moisture build up in crisper.
normal for there to be some moisture and hu
midity in the crisper bin.
Crisper bin can not be removed.
It is
Ensure that the crisper is not over packed.
Adjust crisper humidity slides.
If crisper bin interferes with the door bins, remove door bins before removing crisper.
turning the compressor on and off.
Freezing items in the crisper. Adjust temperature to a warmer setting.
Position cabinet so that the door can be fully opened.
TROUBLESHOOTING
25
Refrigerator operation
Con
cern
Appliance will not run
It is normal for the freezer fan not to operate defrost cycle, or for a short time after the appliance is switched on.
Compressor motor seems to run too long
At
normal room temperatures, expect your motor to run about 40% to 80% of the time. Under warmer conditions, expect it to run even more often.
The variable speed compressor and fan that at start up and on warm days runs at a high speed to provide additional cooling. When less cooling is required the compressor and fan will run at a lower speed.
The exterior of the appliance is warm or hot to touch
This is normal because the appliance transfers heat from the inside out through the outer panels and the divider between the doors.
during the automatic
What to do
Ensure that the cord is plugged into a live power outlet and
Ensure that the household circuit breaker has not tripped or
The appliance maybe in defrost mode, check again in half an hour.
Ensure that the doors are not held open.
Check that large amounts of warm food have not just been placed inside the appliance.
Note that the appliance will run more than normal just after you install it or when adjusting to temperature setting changes.
Ensure the appliance has the external clearances recommended in the section “Installing your new appliance
The exterior of the cabinet will be much warmer on warmer days it may even feel hot to touch, as the appliance is working harder.
”.
outlet is switched on.
that the fuse has not blown.
User interface will not respond
To ensure settings are not accidentally interface will go into sleep mode when not in use.
Press any button to wake user interface.
Alarms sounding Check that all doors are fully closed.
Frost build up Check that all doors are fully closed.
Odours The interior may need cleaning, refer to cleaning guide.
Lights not working
The LED lighting is designed to dim au left opened for more than 5 minutes and turn off completely if the door is open for more than 7 minutes. Closing the door will reset the timer.
The LED lighting is also designed to turn on gradually.
changed the user
tomatically if the door is
Check that the user interface is in awake mode, refer to section “About the user interface”.
Check that the user interface is not locked, refer to section “About the user interface”.
If the user interface is frozen turn the appliance off for five minutes for the memory to clear, then
rn back on.
tu
Check that the user interface is not in Sabbath Mode, refer to control instructions. (I&W
Ensure that the over temperature alarm is not being activa
Check if the drinks timer has ended, refer control instructions.
Check if the Filter Replacement alert is activated, refer control instructions. (I&W models only)
Ensure that the doors are not opened too often.
Ensure that the return air vents are not blocked with packaging.
Ensure the seals are clean and not obstructed.
Ensure that food is stored correctly as some food, containers and wrapping can produce
Check appliance for old or unusual food.
Ensure that the cord is plugged into a live power outlet and outlet is switched on.
Ensure that the household circuit breaker has not tripped or that the fuse has not blown.
Check that the user interface is not in Sabbath Mode, refer to control instructions.
Close and re-open the door. When door has been open for 5 minutes the lights fade to 50% then
after 7 minutes they will turn off.
models only).
odours.
ted by hot food placed in the freezer.
GENERAL INFORMATION (CONTINUED)
26 electrolux.com.au
TROUBLESHOOTING
Door operation
Concern What to do
Freezer door pops open. This is normal and should re-close. This happens when the refrigerator door is
Self close not working. Check if your appliance has self closing hinges as not all models do.
closed too quickly.
If the freezer door stays open, it indicates that the appliance needs to be tilted backwards a little further. Refer to section “Installing your new appliance”.
It indicates that the appliance needs to be tilted backwards a little further. Refer to section “Installing your new appliance”.
Door not sealing properly Ensure there is nothing that is preventing the door from closing such as appliance
Door difficult to open and close If the door is difficult to open just after you have closed it this is due to the pressure
contents or items placed near the appliance.
Ensure that the crisper/freezer bin is closed completely. Refit if required as referred to in the section "Using your refrigerator".
Ensure the appliance is set up as per recommendations.
equalising, the door will open normally after a few minutes.
Automatic Ice maker system
Concern What to do
Ice maker does not produce ice or not enough ice
icemaker is designed to produce a tray
The of ice approximately every 3 hours, depending on room temperature and water temperature..
Ensure that the cord is plugged into a live power outlet and outlet is switched on.
Ensure that water is connected and turned on and there are no kinks in the water line.
Ensure that the Ice Maker is switched on at the user interface refer to "About the User Interface" for details.
Check that the water filter is not blocked or out of date.
Check the water supply flow rate.
If the freezer compartment is too warm, refer to "freezer is too warm" then wait 24 hours for the freezer to reach ideal temperature.
Turn the unit off at the mains and leave for 2 minutes then turn the appliance back on (this will reset the icemaker unit). Check for ice production after 24 hours.
Ice has bad odour or taste Cover food to ensure ice does not absorb foreign odours.
If you still require service
If you have a problem, and the problem persists after you have made the checks mentioned, contact your nearest Electrolux approved Service Centre or the dealer you bought the refrigerator from. Be ready to quote the model number, the 9-digit PNC and 8-digit serial number, which is stated on the label inside the refrigerator compartment.
Check that there is no obstruction under the ice maker and ensure the ice bin is fitted correctly.
Check that the water filter is not out of date.
Interior of appliance or ice bin may require cleaning, refer to “Cleaning your refrigerator”.
Discard stale ice monthly and allow ice maker to produce a fresh supply.
NOISES
27
SSSRR
R!
CLICK!
OK
SSSRRR!
HISSS!
SSSRRR!
HISSS!
HISSS!
BLUBB!
CLICK!
BRRR!
BRRR
CRACK!
CLICK!
BRRR!
!
BLUBB!
BLUBB!
CRACK!CRACK!
28 electrolux.com.au
NOTES
NOTES
29
30 electrolux.com.au
NOTES
Warranty
31
FOR SALES IN
APPLIANCE: ELECTROLUX REFRIGERATORS AND FREEZERS
This document sets out the terms and conditions of the product warranties for Electrolux Appliances. It is an important document. Please keep it with your proof of purchase documents in a safe place for future reference should there be a manufacturing defect in your Appliance. This warranty is in addition to other rights you may have under the Australian Consumer Law.
1. In this warranty:
(a) ‘ACL’ or ‘Australian Consumer Law’ means Schedule 2 to the
Competition and Consumer Act 2010;
(b) ‘Appliance’ means any Electrolux product purchased by you and
accompanied by this document;
(c) ‘ASC’ means Electrolux’s authorised serviced centres;
(d) ‘Electrolux’ is the brand controlled by Electrolux Home Products Pty
Ltd of 163 O’Riordan Street, Mascot NSW 2020, ABN 51 004 762 341 in respect of Appliances purchased in Australia and Electrolux (NZ) Limited (collectively “Electrolux”) of 3-5 Niall Burgess Road, Mount Wellington, in respect of Appliances purchased in New Zealand;
(e) ‘WarrantyPeriod’meanstheperiodspeciedinclause3ofthis
warranty;
(f) ‘you’ means the purchaser of the Appliance not having purchased
the Appliance for re-sale, and ‘your’ has a corresponding meaning.
2. Application: This warranty only applies to new Appliances, purchased
and used in Australia or New Zealand and is in addition to (and does not exclude, restrict, or modify in any way) other rights and remedies under a law to which the Appliances or services relate, including any non­excludable statutory guarantees in Australia and New Zealand.
3. Warranty Period: Subject to these terms and conditions, this warranty
continues for in Australia for a period of 24 months and in New Zealand for a period of 24 months, following the date of original purchase of the
Appliance.Speciccomponentsarewarrantedagainstmanufacturing
defects in Australia and New Zealand for the periods listed below;
• Comp essor – Further 3 years parts only,
• Exte nal Condenser – Further 3 years parts only
• Evaporator – Further 3 years parts onl
• Drier – Further 3 years parts onl
4. Repair or replace warranty: During the Warranty Period, Electrolux
or its ASC will, at no extra charge if your Appliance is readily accessible for service, without special equipment and subject to these terms and conditions, repair or replace any parts which it considers to be defective. Electrolux may, in its absolute discretion, choose whether the remedy
oeredforavalidwarrantyclaimisrepairorreplacement.Electroluxorits
ASC may use refurbished parts to repair your Appliance. You agree that any replaced Appliances or parts become the property of Electrolux.
5. Travel and transportation costs: Subject to clause 7, Electrolux will
bear the reasonable cost of transportation, travel and delivery of the Appliance to and from Electrolux or its ASC. Travel and transportation will be arranged by Electrolux as part of any valid warranty claim.
6. Proof of purchase is required before you can make a claim under this
warranty.
7. Exclusions: You may not make a claim under this warranty unless the
defect claimed is due to faulty or defective parts or workmanship. This warranty does not cover:
AUSTRALIA AND NEW ZEALAND
(a) lightglobes,batteries,ltersorsimilarperishableparts;
(b) parts and Appliances not supplied by Electrolux;
(c) cosmeticdamagewhichdoesnotaecttheoperationofthe
Appliance;
(d) damage to the Appliance caused by:
(i)i) negligence or accide
(ii)ii) misuse or abuse, including fa e to properly maintain or service;
(iii) improper, negligent or faulty servicing or repair works done by
anyone other than an Electrolux authorised repairer or ASC;
(iv)iv) normal wear and t
(v)v) power surges, electrical storm damage or inc ect power supply;
(vi)vi) incomplete or oper installation;
(vii)vii) i ect, improper or inappropriate operation;
(viii)viii) insect or vermin infest
(ix) failure to comply with any additional instructions supplied with
the Appliance;
In addition, Electrolux is not liable under this warranty if:
(a) the Appliance has been, or Electrolux reasonably believes that the
Appliance has been, used for purposes other than those for which the Appliance was intended, including where the Appliance has been used for any non-domestic purpose;
(b) theApplianceismodiedwithoutauthorityfromElectroluxinwriting;
(c) the Appliance’s serial number or warranty seal has been removed
or defaced.
8. How to claim under this warranty: To enquire about claiming under
this warranty, please follow these steps:
(a) carefully check the operating instructions, user manual and the
terms of this warranty;
(b) have the model and serial number of the Appliance available;
(c) have the proof of purchase (e.g. an invoice) available;
(d) telephone the numbers shown below.
9. Australia: For Appliances and services provided by Electrolux in
Australia: Electrolux goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the Appliance repaired or replaced if the Appliance fails to be of acceptable quality and the failure does not amount to a major failure. ‘Acceptable quality’ and ‘major failure’ have the same meaning as referred to in the ACL.
10. New Zealand: For Appliances and services provided by Electrolux
in New Zealand, the Appliances come with a guarantee by Electrolux pursuant to the provisions of the Consumer Guarantees Act, the Sale of Go ods Act and the Fair Trading Act. Where the Appliance was purchased in New Zealand for commercial purposes the Consumer Guarantee Act does not apply.
11.Condentiality: You accept that if you make a warranty claim, Electrolux
and its agents including ASC may exchange information in relation to you to enable Electrolux to meet its obligations under this warranty.
Before calling for service, please ensure that the steps listed in clause 8 above have been followed.
FOR SERVICE
ortondtheaddressofyournearest
authorised service centre in Australia
PLEASE CALL 13 13 49
For the cost of a local call (Australia only)
FOR SERVICE
ortondtheaddressofyournearest
authorised service centre in New Zealand
PLEASE CALL 0800 10 66 10
(New Zealand only)
EFridgeFreezer_Warr_Jun17
Important Notice
AUSTRALIA
ELECTROLUX HOME PRODUCTS
163 O’Riordan Street, Mascot NSW 2020
electrolux.com.au
NEW ZEALAND
ELECTROLUX (NZ) Limited
3-5 Niall Burgess Road, Mount Wellington
electrolux.co.nz
FOR SPARE PARTS
ortondtheaddressofyournearest
spare parts centre in Australia
PLEASE CALL 13 13 50
For the cost of a local call (Australia only)
FOR SPARE PARTS
ortondtheaddressofyournearest
spare parts centre in New Zealand
PLEASE CALL 0800 10 66 20
(New Zealand only)
shop.electrolux.com.au
telephone: 1300 363 640
Electrolux Home Products Australia
fax: email: web:
Electrolux Home Products New Zealand telephone: 0800 436 245 fax: email: web:
1800 350 067 customercare@electrolux.com electrolux.com.au
0800 225 088 customercare@electrolux.co electrolux.co.nz
To add a touch of professional inspiration to your home, visit electrolux.com.au or electrolux.co.nz
electrolux.com.au
or electrolux.co.nz
P/No.
© 2018 Electrolux Home Products Pty Ltd. ABN 51 004 762 341
EMAN_Refrigeration_Factory_Oct18
Loading...
