TABLE OF CONTENTS
QUICK START………………………………………...…………...…..……………2
DIAGRAM OF THE DIGITAL PHOTO FRAME...………………………………3
KEYPAD BUTTON FUNCTIONS...……..…………………………………………4
DIGITAL PHOTO FRAME NAVIGATION…..……………....…………………...5
OSD MENU FUNCTIONS…………………………………….…………………….6
MOSAICVIEWTM AND ADDITIONAL PHOTO FRAME FEATURES.....…..…7
ADDITIONAL FEATURES CONTINUED…...……………....…………………...8
USING THE MINI-USB FOR FILE TRANSFER…..…………………….………9
SAVING AND DELETING FILE FROM INTERNAL MEMORY..…….………10
TECHINICAL SPECIFICATIONS…..…………………………………………....11
FREQUENTLY ASKED QUESTIONS….………………………………………...12
IMPORTANT SAFETY INSTRUCTIONS……………………………………….13
CLEANING THE DIGITAL PHOTO FRAME…………………………………..15
WARRANTY INFORMATION……………………………………………………16
1
Congratulations on your purchase of a Westinghouse 14.1” LCD Digital Photo
Frame. We are excited to bring you a new experience in viewing your digital
memories with MosaicView
TM
Technology. Contents include an AC/DC Power
Supply Adapter and User’s Manual. Please read carefully and follow all
warnings and instructions in this User's Manual and those marked on the
product before you use the Digital Photo Frame. Failing to follow warnings can
result in personal injury or damage to the Digital Photo Frame. Please keep
this User’s Manual in a convenient location for future reference.
Important: Save the original box and all packing material for future shipping
needs.
Quick Start
1. Attach the adjustable stand with the screws on the back of the
Digital Photo Frame. You must first unscrew them to attach the
stand. Plug the AC adapter into the Digital Photo Frame and plug it
into a power outlet.
2. Insert a memory card into one of the four slots:
Slot 1 - Secure DigitalTM or MultiMedia CardTM
Slot 2 - Compact FlashTM or Micro Drive
Slot 3 - xD-Picture CardTM
Slot 4 - Memory StickTM, Memory Stick PROTM, Memory Stick
DuoTM, or Memory Stick PRO DuoTM
Or insert a USB Thumbnail Drive into the USB port.
Note: To view a sample of how the Photo Frame displays digital photos, simply
turn on the frame without inserting a memory card.
3. Push the power button for a few seconds on the back of the Digital
Photo Frame to turn on the frame.
4. Once the Digital Photo Frame has turned on, it will enter into Slide
Show automatically.
5. To view photos individually, press the Exit button to enter Thumbnail
View. Using the Arrow Buttons (<<) and (>>), highlight a photo and
press the Play (4) button to view the image. To enter into Slide
Show again, press the Play (4) button.
Note: To delete photos from the internal memory or save photos to the internal
memory, please refer to page 9 or 10 for instructions.
TM
2
Power
Button
Diagram of the Digital Photo Frame
USB Port for USB Flash Drives
Mini USB Port for File Transfer
xD-Picture CardTM Slot
Keypad
Memory StickTM, Memory Stick
PROTM, Memory Stick DuoTM, and
Memory Stick PRO DuoTM Slot
Secure DigitalTM and
Multi Media CardTM Slot
Compact FlashTM and
Micro DriveTM Slot
AC Power Input
Adjustable Stand
3
Keypad Button Functions
On Screen Display Functions
Note: To enter the On Screen Display (OSD), press the Menu button at any
time (except when in Slide Show or playing a video). To exit the OSD, simply
press the Exit button.
Button
<<
Play
>>
Exit
Menu
Viewing Images Individually
Button Command
<< Go to Previous Image
Play Start Slide Show
>> Go to Next Image
Exit
Menu Enter OSD Menu
Thumbnail View / Select Mode Page / Card Select Page
Button Command
<< Left
Play Select
>> Right
Exit
Menu Enter OSD Menu
Viewing Video Files
Button Command
<< Go to Previous Video File
Play Play / Pause Video File
>> Go to Next Video File
Exit
Menu Enter OSD Menu
Command
Up
Select
Down
Exit OSD Menu
Enter OSD Menu
Return to Thumbnail View
Go one page back
Exit Video
4
Digital Photo Frame Navigation
Using the Play and Exit button, you will be able to advance or go back a Menu
Page within the Digital Photo Frame.
The top Menu Page is the “Select Card” Page. To enter this selection, press
the Exit button twice from Thumbnail View.
Select Card Page
SD / MMC
MS / MS Duo
CF / MD
XD
Built-in Memory
Selecting an option that is highlighted will take you to the next page.
Select Mode Page
Photo – Selecting “Photo” will allow you to preview your photos through
Thumbnail View.
Slideshow – This selection will automatically start Slide Show.
Video – Selecting “Video” will list all video files available for viewing.
Select a file and press the “Play” button to view. (No audio will be available.)
5
