West Bend 100-CUP, 60-CUP, 55-CUP, 36-CUP User Manual

 2017 West Bend

®

www.westbend.com

LARGE CAPACITY COFFEEMAKERS

Instruction Manual

Important Safeguards ............................................................................................... 2

Instructions for Making Coffee .................................................................................. 3

Helpful Hints ............................................................................................................. 5

Cleaning Your Coffeemaker ..................................................................................... 6

Warranty ................................................................................................................... 7

SAVE THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE

English - 2

IMPORTANT SAFEGUARDS

To prevent personal injury or property damage, read and follow all instructions
and warnings.

When using electrical appliances, basic safety precautions should always be
followed including the following:

• Read all instructions.

• Do not use appliance for other than intended use.

• Do not place on or near a hot gas or electric burner, or in a heated oven.

• Do not operate when the appliance is not working properly or when it has been

damaged in any manner. For service information see warranty page.

• The use of accessory attachments not recommended by West Bend may result in
fire, electric shock or injury to persons.

• Do not attempt to repair this appliance yourself.

• Do not use this appliance on the stovetop, under a broiler, in the oven, or in the

refrigerator or freezer.

• Do not touch hot surfaces. Use handles and knobs where provided. Use hot pads
or oven mitts when handling hot surfaces.

• Extreme caution must be used when moving an appliance containing hot oil or
other hot liquids.

• Make sure cover, basket and stem are properly assembled before the appliance is
plugged in (see “Instructions for Making Coffee” section). No part of the appliance
should be removed during the brewing cycle as scalding could occur.

• Scalding may occur if the lid is removed during the brewing cycle.

• To protect against fire, electric shock and injury to persons do not immerse cord,

plugs, or other electric parts in water or other liquids.

• Do not operate any appliance with a damaged cord or plug.

• Do not use this appliance outdoors.

• Be sure switch is turned to “OFF” before plugging the cord into wall outlet. If the

appliance does not have a switch, be sure the appliance contains water or brewed
coffee before plugging in. Do not leave appliance plugged in when it is not being used.

• This appliance has a polarized plug (one blade is wider than the other). To reduce
the risk of electric shock, this plug is intended to fit into a polarized outlet only one
way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not
fit, contact a qualified electrician. Do not attempt to modify the plug in any way.

• Always unplug from outlet when not in use and before cleaning. Allow to cool
before putting on or taking off parts and before cleaning.

• A short power-supply cord is provided to reduce risks resulting from becoming
entangled in or tripping over a longer cord.

• Longer extension cords are available, but care must be exercised in their use.
While use of an extension cord is not recommended, if you must use one, ensure
that the marked electrical rating of the extension cord is equal to or greater than
that of the appliance. If the plug is of the grounded type, the extension cord must
be a grounding-type 3-wire cord. To avoid pulling, tripping or entanglement,
position the extension cord so that it does not hang over the edge of the counter,
table or other area where it can be pulled on by children or tripped over.

English - 3

• Do not use an outlet or extension cord if the plug fits loosely or if the outlet or
extension cord feels hot.

• Keep cord away from hot parts of the appliance and hot surfaces during operation.

• Close supervision is necessary when this appliance is used by or near children.

• Do not let cord hang over edge of table or counter, or touch hot surfaces.

SAVE THESE INSTRUCTIONS

INSTRUCTIONS FOR MAKING COFFEE

1. Before using the coffeemaker for the first time, clean it thoroughly. Refer to

“Cleaning your Coffeemaker.”

2. Always use the coffeemaker on a dry, level, heat-resistant surface, away from

any edge.

3. With the basket and stem removed, fill the coffeemaker with COLD water to just

above the faucet. Check for any dripping. If dripping occurs between the faucet
and the coffeemaker body, tighten the nut inside the coffeemaker. If the dripping
occurs from the faucet spout, tighten the faucet cap. If there is no dripping
present, or has been stopped, fill the coffeemaker with cold water to the desired
cup level. Marks on inside of the coffeemaker show cup levels. Do not fill past
maximum cup level.

4. Place the stem and basket in the coffeemaker. For models with a plastic basket,

you may find it easier to insert the stem in the opening in the basket then
squeeze the top of the basket to hold the stem in place. Place the stem into the
heating well in the bottom of the coffeemaker. Or, place the stem into the heating
unit well, angle the stem away from you, then place the basket on the
stem. When they’re connected, let the basket and stem tip upright. Add electric
perk or regular grind coffee to the basket using the chart below for the amount to
use depending on the cup level. Spread the grounds evenly in the basket. Use
standard measuring cups to measure the grounds. Do not let any grounds fall
into the stem opening. Do not use “Drip” or finely ground coffee because the
basket can flood. The amount of ground coffee recommended will make mild­strength coffee which most people prefer. The amount of coffee used can be
adjusted to suit your preference.

5. Place the cover on the coffeemaker and turn to lock into the handle slots. Note

the arrows on the cover for correct turning. To reduce coffee spills, especially if
the coffeemaker is tipped over, make sure that the cover has been turned
clockwise until the cover is completely locked into the handle slots. Note: While
moving an appliance containing hot liquids is not recommended, if you must
move the coffeemaker, extreme caution should be used because the cover only
temporarily reduces coffee from spilling if the coffeemaker is tipped over.

6. Plug the cord into a 120 volt AC grounded electric outlet ONLY. If applicable, set

the “ON/OFF” switch to “ON.”

7. The coffeemaker will stop perking automatically (each cup requires no longer

than 1 minute brewing time). Coffee is ready when the light in the base glows.
Coffee will remain at serving temperature as long as the coffeemaker is plugged
in (and the switch is “ON”). Before serving, turn the cover to remove the basket
and stem. Using a hot pad, remove the coffee basket, and stem. If the coffee
basket and stem are not removed, bitter oils from the extracted grounds will drip
into the coffee. Replace the cover making sure it is completely locked into the
handle slots.

English - 4

8. For single-cup filling, press the faucet handle down. Release the handle when

filled. For continuous flow when filling the coffee server, lift handle straight up
until it locks into the open position. Lower the handle when the server is filled.

9. When about 3 cups of coffee remain in the coffeemaker, or when the coffee can

no longer be seen in the view tube, turn the switch “OFF” and unplug the cord
from the electrical outlet. Note: Liquid must always cover the inside bottom of the
appliance at all times. Falling below the minimum level could cause overheating
and damage to internal components and will void the warranty.

SPECIAL NOTE ON GRINDING COFFEE BEANS: If you grind your own coffee

beans, grind to medium coarseness for best results. DO NOT grind too fine
(powder-like) because this can cause the basket to flood.

100-CUP MODEL

Water Level Measure of Ground Coffee

100 cups 6 ¼ cups
80 cups 5 cups
60 cups 4 cups
40 cups 2½ cups

Do not make less than 40 or more than 100 cups of coffee at one time.

60-CUP MODEL

Water Level Measure of Ground Coffee

60 cups 3½ cups
50 cups 3 cups
40 cups 2½ cups
30 cups 2 cups

Do not make less than 30 or more than 60 cups of coffee at one time.

55-CUP MODEL

Water Level Measure of Ground Coffee

55 cups 3½ cups
45 cups 2¾ cups
35 cups 2 cups
25 cups 1½ cups

Do not make less than 25 cups or more than 55 cups of coffee at one time.

36-CUP MODEL

Water Level Measure of Ground Coffee

36 cups 2 cups
30 cups 1¾ cups
24 cups 1½ cups
18 cups 1¼ cups
12 cups 1 cup

Do not make less than 12 cups or more than 36 cups of coffee at one time.

English - 5

INSTRUCTIONS FOR HEATING WATER FOR INSTANT BEVERAGES

Plain water may be heated in your coffeemaker for use with instant beverages. Simply
fill the clean coffeemaker with cold water to the desired cup level, insert the stem and
the clean, empty basket into position the same as for making coffee. Secure the cover
in place and plug the coffeemaker in. If applicable, set the “ON/OFF” switch to “ON.”
Heat the water until perking stops and the light on the base glows. Remove the cover,
lift out the basket and stem with a hot pad, and replace the cover, making sure it is
locked in place. Unplug the coffeemaker when less than 3 cups of water remain. The
inside of the coffeemaker may darken after heating water, which is normal and does
not affect the coffeemaker or the water heated.

Other than making coffee or heating water, no other liquid should be heated in
the coffeemaker because damage to the heating unit can occur.

When the coffeemaker is used to heat water only, it must be cleaned well after each
use in addition to special weekly cleaning with white distilled vinegar for removal of
mineral deposits. If these deposits are not removed, pitting of the metal can occur and
result in damage to the coffeemaker. See “Special Cleaning – Every Two Weeks” in
this manual.

Improper cleaning of the coffeemaker, especially the heating unit well, will affect
the performance, resulting in weak, lukewarm coffee and may even cause the
coffeemaker to stop perking. To keep the coffeemaker working properly, it is
very important to follow the regular and special cleaning instructions.

HELPFUL HINTS

• Never make less than the minimum or more than the maximum amount of coffee
for your coffee urn.

• Do not use soft water, as flooding of the basket may occur.

• Use regular electric perk grind coffee or coffee ground for all coffeemakers for best

results. Do not use drip or finely ground coffee as flooding of the coffee basket can
occur. If grinding your own coffee beans, grind to medium coarseness for best
results. Do not grind coffee too finely, powder-like, as this can cause the coffee
basket to flood.

• Do not use paper filters in your basket. If you find that grounds are falling through,
wet the basket before adding coffee grounds.

• Remove coffee basket with grounds as soon as the brewing cycle is completed.
This also helps maintain the coffee flavor. Use the coffee maker cover as a
carrying tray when disposing of wet grounds.

• If dripping occurs between the faucet and the coffeemaker body, tighten the nut
inside the coffeemaker. If the dripping occurs from the faucet spout, tighten the
faucet cap. Do not over tighten. If the faucet continues to drip or is damaged,
contact customer service; see information on warranty page.

• Liquid must always cover the inside bottom of the appliance at all times. Falling
below the minimum level could cause overheating and damage to internal
components and will void the warranty.

• A small amount of smoke or odor may occur upon heating due to the release of
manufacturing oils – this is normal.

• Some minor expansion or contraction sounds may occur during heating and
cooling – this is normal.

• Do not allow ground coffee to fall into the stem.

• If more coffee is immediately desired, partially fill the coffeemaker with cold water to

reset the thermostat. Empty the water out of the coffeemaker, then repeat steps 3-9.

English - 6

CLEANING YOUR COFFEEMAKER

1. Unplug the coffeemaker and allow it to cool. Drain any coffee out of the

coffeemaker.

2. Wash the basket, stem, and cover in warm, soapy water with a dishcloth or

sponge. Rinse and dry. Coffee stains on the metal can be removed with a
scouring pad. Plastic parts may be washed in the dishwasher, top rack only.
Washing any aluminum parts in the dishwasher may cause them to discolor.

3. Clean the inside of the coffee maker by filling with warm water about one-third of

its capacity. Add dish soap and wash with a sponge or cloth. Scour the heating
unit well (where the stem fits) with the special cleaning tool provided and a
scouring pad. Twist the pad inside the heating unit well to clean. The heating
unit well must be kept clean for coffeemaker to work properly. Rinse with
warm water after cleaning and dry.

4. Clean the outside of the coffeemaker with a damp cloth and dry with a soft cloth.

Do not use abrasive metal scouring pads or cleansers on the outside of the
coffeemaker because scratching will occur.

This appliance has no user serviceable parts.

SPECIAL CLEANING - EVERY TWO WEEKS

If coffeemaker is used daily, a special cleaning every 2 weeks, or every week if
it is used for heating water, is necessary to thoroughly clean the heating unit
well. If not kept clean, the coffeemaker will not work properly.

1. Fill the coffeemaker with 1 quart EACH of water and white distilled vinegar. (If a
white mineral buildup has formed on the inside of coffeemaker, use an additional
2 cups of vinegar). Place the stem and empty basket in place and lock the cover
onto the coffeemaker. If applicable, set the “ON/OFF” switch to “ON.” Allow the
coffeemaker to complete the perking cycle, then let stand for 20 minutes.

2. Turn “OFF” and unplug the cord from the outlet. Drain the coffeemaker and allow
it to cool. Wash the inside and the parts following the regular cleaning
instructions, making sure to thoroughly clean the heating unit well.

3. If applicable, clean the coffee level view tube with a soft brush. Unscrew the
gauge cap and lift out the tube. Wash in warm, soapy water with a brush and
rinse. Replace the tube and secure with the gauge cap.

4. To clean the faucet, unscrew the handle. Move a small brush up and down
through the faucet, then insert the brush through the opening on the inside of the
coffeemaker to clean the faucet connection. Wash the faucet handle in warm,
soapy water and rinse. Replace the faucet.

DO NOT USE BAKING SODA TO CLEAN THE COFFEEMAKER BECAUSE IT

CAN DISCOLOR AND PIT THE METAL.

To Remove Discoloration: Inside of the coffeemaker can discolor when used for

heating water, which is normal. To remove/lighten discoloration, fill coffeemaker with
water to the level of discoloration (at least to the minimum cup level, but not past
maximum cup level). Place stem and empty basket in place. For every 12 cups of
water added to coffeemaker, add 2 teaspoons cream of tartar to basket. Secure
cover onto coffeemaker, plug cord into coffemaker and then into outlet and allow
coffeemaker to complete perk cycle. Let stand for 15 to 20 minutes or until
discoloration is lightened. Unplug cord and drain coffeemaker. Allow to cool and
follow general cleaning instructions.

English - 7

L5613F 04/17 West Bend® Printed in China

PRODUCT WARRANTY

Appliance 1 Year Limited Warranty

West Bend® (“the Company”) warrants this appliance from failures in the material and
workmanship for one (1) year from the date of original purchase with proof of purchase,
provided that the appliance is operated and maintained in conformity with the Instruction
Manual. Any failed part of the appliance will be repaired or replaced without charge at the
Company’s discretion. This warranty applies to indoor household use only.

This warranty does not cover any damage, including discoloration, to any non-stick surface of
the appliance. This warranty is null and void, as determined solely by the Company, if the
appliance is damaged through accident, misuse, abuse, negligence, scratching, or if the
appliance is altered in any way.

THIS WARRANTY IS IN LIEU OF ALL IMPLIED WARRANTIES, INCLUDING WARRANTIES
OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, PERFORMANCE, OR
OTHERWISE, WHICH ARE HEREBY EXCLUDED. IN NO EVENT SHALL THE COMPANY
BE LIABLE FOR ANY DAMAGES, WHETHER DIRECT, INDIRECT, INCIDENTAL,
FORSEEABLE, CONSEQUENTIAL, OR SPECIAL ARISING OUT OF OR IN CONNECTION
WITH THIS APPLIANCE.

If you think the appliance has failed or requires service within its warranty period, please
contact the Customer Care Department at [phone], or e-mail us at
[e-mail]. A receipt proving the original purchase date will be required for
all warranty claims, hand written receipts are not accepted. You may also be required to
return the appliance for inspection and evaluation. Return shipping costs are not refundable.
The Company is not responsible for returns lost in transit.

Valid only in USA and Canada

REPLACEMENT PARTS

Replacement parts, if available, may be ordered directly from the Company several ways.
Order online at www.westbend.com, e-mail [e-mail], over the phone by
calling [phone], or by writing to:

West Bend
Attn: Customer Care Dept.
P. O. Box 53
West Bend, WI 53095

To order with a check or money order, please first contact Customer Care for an order total.
Mail your payment along with a letter stating the model or catalog number of your appliance,
which can be found on the bottom or back of the appliance, a description of the part or parts
you are ordering, and the quantity you would like.

Your state/province’s sales tax and a shipping fee will be added to your total charge. Please

allow two weeks for processing and delivery.

This manual contains important and helpful information regarding the safe use and care of your
product. For future reference, attach dated sales receipt for warranty proof of purchase and
record the following information:

Date purchased or received as gift: _______________________________________________
Where purchased and price, if known: _____________________________________________
Item number and Date Code (shown bottom/back of product):___________________________

 2017 West Bend

®

www.westbend.com

CAFETIÈRES DE GRANDE CAPACITÉ

Manuel d’instructions

Précautions Importantes .......................................................................................... 2

Instructions Pour la Préparation du Café .................................................................. 3

Astuces .................................................................................................................... 5

Nettoyage de Votre Cafetière ................................................................................... 6

Garantie ................................................................................................................... 8

CONSERVEZ CE MANUEL D’INSTRUCTIONS POUR RÉFÉRENCE FUTURE
