441
Flash/Multi-Tone Sounder Combination
Optical-Audible
Signal Devices
• Multi-Tone Sounder in
Combination with Xenon Flash
• 32 tones for a diverse range of
applications
• 2 tones can be triggered
externally
• Optical and audible signal can
be triggered separately
• Adjustable sound output up to 110 dB
TECHNICAL SPECIFICATIONS:
Dimensions (L x H x W): 165 mm x 169 mm x 132 mm
Housing: PC/ABS-Blend
Connection: Screw terminal max. 2.5 mm
Cable entry: Cable gland M20 x 1.5 mm
(not included in assembly)
Flash frequency: 1 Hz
Flash energy: 2.5 Ws
Tone types and frequencies: Selectable via DIP switch
ORDER SPECIFICATIONS:
Voltage 9-60 V DC 230 V AC
Current consumption 230 mA 35 mA
Housing / Flash
red / red 441 010 55 441 010 68
red / yellow 441 030 55 441 030 68
grey / red 441 110 55 441 110 68
grey / yellow 441 130 55 441 130 68
2
Size comparison
ACCESSORIES:
Cable gland M20 x 1.5 mm 975 444 01
TONE TYPES AND FREQUENCIES:
For further details see www.werma.com.
TECHNICAL DIAGRAMS:
see page 305
in combination with a
See note
on page 347
800 g
+75°C
IP 66
-25°C
2,5
Ws
Multi-Tone Sounder
powerful Xenon Flash
32
110 dB
208
