RW SERIES DRAWER WARMERS
Wells Drawer Warmers can keep a variety of foods
hot and ready to serve. Their deep drawers accept all
standard 12” x 20” pans up to 6” deep, and are ideal for
warming dinner rolls, breads, baked potatoes, tortilla chips,
corn on the cob, vegetables, rice and more. All Wells
warmers come with individual controls on each drawer
for temperature and humidity, so one drawer’s food can
be hot and crispy, while another drawer’s food is kept
warm and moist.
RW SERIES DRAWER WARMERS
Specifications
Overall Dimensions: Inches MM
Width 29 1/4 743
Depth 21 1/2 546
Height (incl. 4” legs)
RW-1 series 14 7/8 378
RW-2 series 25 635
Height (no legs)
RW-3 series 31 1/8 791
RW-4 series 41 1/8 1045
Temperature Range: Fahrenheit Celsius
RW series 90° to 210° 32° to 99°
Pre-Heat Time to 175º F: 120V & 240V 208V
RW series 15 minutes 22 minutes
Weights: Lbs. KG
RW-1 series:
Installed 65 29
Shipping 77 35
RW-2 series:
Installed 102 46
Shipping 126 57
RW-3 series:
Installed 134 61
Shipping 170 77
RW-4 series:
Installed 162 73
Shipping 210 95
Export
The following models are available for export
and meet the standards for CE:
• RW-1EU, 220-240V, 1Ø, 450 watts, 22330
• RW-2EU, 2
• RW-1HDEU, 220-240V, 1Ø, 450 watts, 22334
• RW-2HDEU, 220-240V, 1Ø, 900 watts, 22335
20-240V, 1Ø, 900 watts, 22331
Features
• Individual thermostatic temperature control on each
drawer gives these warmers maximum versatility.
• Durable stainless steel tracks and bearings provide
for smooth operation.
• Adjustable front vent allows for humidity control on
each drawer.
• A stainless steel, 12” x 20”, 6” deep pan is provided
with each drawer.
• Fully insulated for maximum efficiency.
• Models with optional built-in thermometer (T)
are NSF approved for potentially hazardous foods.
• Heavy Duty (HD) models have reinforced construction
and are recommended for use with heavier products.
• The RW series Drawer Warmers are Underwriters
Laboratories, Inc. LISTED and meet the National
Sanitation Foundation and Canadian standards.
• A one-year warranty against defects covers
parts and labor.
Accessories / Options
Humitrol Rack, stainless steel, one per drawer,
non-splash, 20624
Optional Thermometer (T), for individual drawers,
contact factory
Caster Kit, 10” high casters, set of four, includes 2
each with front brakes, 21034
Caster Kit, 3 1/2” high casters, set of four with brakes,
3” diameter, 21947
Caster Kit, 2 1/4” high casters, set of four, includes 2
each with front brakes, 2” diameter, 22025
Leg Kit, set of four, metal, 6”, 21607
Leg Kit, set of four, metal, 4”, 20563
Leg Kit, set of four, plastic, 4”, 20314
R A I S I N G T H E S T A N D A R D
WELLS
W E L L S M A N U F A C T U R I N G
WELLS
R
R R
C
R
R R
C
(102)
4
(546)
21 1/2
(365)
14 3/8
(533)
21
(743)
29 1/4
CORD
SUPPLY
POWER
(102)
4
(276)
10 7/8
(546)
21 1/2
(365)
14 3/8
(743)
29 1/4
CORD
SUPPLY
POWER
LISTED STD.4 E6070 EXPORT
E6070 MODELS
ONLY
D I M E N S I O N S :
(MM)
M O D E L S
R W - 1 , R W - 1 E U , R W T - 1
R W T- 1 E U , R W - 1 H D, R W - 1 H D E U
R W T- 1 H D , R W T- 1 H D E U
D R A W E R W A R M E R S
INCH
R W - 1 S E R I E S E L E C T R I C A L S P E C I F I C AT I O N S :
MODELS VOLTS WATTS AMPS PHASE POWER SUP PLY CORD
RW-1 120 450 3.8 SINGLE NEMA 5-15P
RW-1 208 338 1.6 SINGLE NEMA 6-15P
RW-1 240 450 1.9 SINGLE NEMA 6-15P
RW-1EU 220-240 450 1.9 SINGLE SUPPLIED
All models with a ‘T' or 'HD' suffix have the same electrical specs as the standard versions.
Denotes export (EU) products.
NOTE: Specifications are subject to change without notice.
