Weider WESY5993.2 User Manual
Model No. WESY5993.2
Visit our website at
www.weiderfitness.com
new products, prizes,
fitness tips, and much more!
erial No.
S
Write the serial number in the
pace above for future reference.
s
Serial Number Decal (under seat)
QUESTIONS?
As a manufacturer, we are committed to providing complete
customer satisfaction. If you
have questions, or if a part is
damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT
DIRECTLY.
CALL TOLL-FREE:
1-877-992-5999
Mon.–Fri., 6 a.m.–6 p.m. MST
ON THE WEB:
www.weiderservice.com
A
A
D
D
V
V
A
A
N
N
T
T
A
A
G
G
E
E
CAUTION
Read all precautions and instructions in this manual before
using this equipment. Save this
manual for future reference.
USER’S MANUAL
TABLE OF CONTENTS
Keep hands and
fingers clear of
this area.
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
EFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
B
SSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
A
ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
CABLE DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
EXERCISE GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
Note: A PART IDENTIFICATION CHART and a PART LIST/EXPLODED DRAWING are attached in the center of
this manual. Remove the PART IDENTIFICATION CHART and PART LIST/EXPLODED DRAWING before beginning assembly.
WARNING DECAL PLACEMENT
The decals shown here have been
placed on the resistance system. If a
decal is missing or illegible, call the
toll-free telephone number on the front
cover of this manual and order a free
replacement decal. Apply the decal in
the location shown.
MAX by WEIDER is a trademark of ICON IP
2
, Inc.
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of serious injury, read the following important precautions
before using the resistance system.
1. Read all instructions in this manual and all
arnings on the resistance system before
w
using the resistance system. Use the resistance system only as described in this manual.
2. It is the responsibility of the owner to ensure
that all users of the resistance system are
adequately informed of all precautions.
3. The resistance system is intended for home
use only. Do not use the resistance system in
any commercial, rental, or institutional setting.
4. Keep the resistance system indoors, away
from moisture and dust. Place the resistance
system on a level surface, with a mat
beneath it to protect the floor or carpet. Make
sure that there is enough clearance around
the resistance system to mount, dismount,
and use the resistance system.
5. Inspect and properly tighten all parts regular-
ly. Replace any worn parts immediately.
6. Keep children under 12 and pets away from
the resistance system at all times.
7. Keep hands and feet away from moving parts.
12. Make sure the storage knob is in place and
ully tightened each time the resistance sys-
f
tem is used.
13. When adding resistance, both ends of the
resistance bar must rest under the two “U”channels. Add and remove resistance bars
from the “U”-channels one resistance bar at
a time.
14. Keep clear of the area around the “U”-chan-
nels while the resistance system is in use.
Do not add or remove resistance bars from
the “U”-channels while the end of the long
cable is pulled out.
15. Always adjust the resistance bar assembly to
the horizontal position and make sure the
fulcrum knob is secure before using the
resistance system.
16. Make sure the rings on the resistance bars
are pushed against the tray before using the
resistance system.
17. Always disconnect the lat bar from the short
cables when performing an exercise that
does not require it.
18. The resistance system is designed to be
8. Always wear athletic shoes for foot protec
tion while exercising.
9. The top frame is not designed to be used for
pull-up exercises. Do not hang on the top
frame.
10. The resistance system is designed to support a maximum user weight of 300 pounds.
11. Pull on the low pulley cable only while sitting
on the bench or standing on the base plate.
Pull on the high pulley cables only while sitting on the bench, with the seat in one of the
three positions closest to the upright base,
or while standing on the base plate.
used with the included resistance, and the
resistance included with a MAX by WEIDER
ACK. Do not use the resistance sys
P
MAX
tem with any other type of resistance.
Make sure that the cables remain on the pul
19.
leys at all times. If the cables bind as you are
exercising, stop immediately and make sure
that the cables are on the pulleys. Replace all
cables at least every two years.
20. If you feel pain or dizziness while exercising,
stop immediately and begin cooling down.
-
WARNING:Before beginning this or any exercise program, consult your physician. This
is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
3
-
BEFORE YOU BEGIN
Thank you for selecting the innovative MAX by
WEIDER
ance system offers a selection of stations designed to
evelop every major muscle group of the body. Whether
d
your goal is to tone your body, build dramatic muscle
size and strength, or improve your cardiovascular system, the resistance system will help you to achieve the
specific results you want.
For your benefit, read this manual carefully before
using the resistance system.
after reading this manual, see the front cover of this
™
ADVANTAGE resistance system. The resist-
If you have questions
ASSEMBLED DIMENSIONS:
Height: 82 in. / 208 cm
Width: 66 in. / 168 cm
Depth: 80 in. / 203 cm
Fulcrum Knob
manual. To help us assist you, please note the product
model number and serial number before calling. The
model number is WESY5993.2. The serial number can
e found on a decal attached to the resistance system
b
(see the front cover of this manual).
To avoid a registration fee for any service needed
under warranty, you must register the resistance
system at www.weiderservice.com/registration.
Before reading further, please review the drawing below
and familiarize yourself with the parts that are labeled.
Top Frame
Lat Tower
High Pulley
Resistance
Bars
Upright
Storage Knob
Backrest
Seat Knob
Leg Lever
“U”-Channel
Foot Plate
Low Pulley
Base Plate
Seat
Lat Bar
4
ASSEMBLY
Make Things Easier for Yourself
This manual is designed to ensure that the resistance system can be assembled successfully by
most people. However, it is important to realize
that the versatile resistance system has many
parts and that the assembly process will take
time. Most people find that by setting aside plenty
of time, assembly will go smoothly.
Before beginning assembly, carefully read the
following information and instructions:
Assembly requires two persons.
•
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until assembly is completed.
•
For help identifying small parts, use the PART
IDENTIFICATION CHART.
parts may have been pre-attached for shipping. If
a part is not in the parts bag, check to see if it
has been pre-attached.
Note: Some small
• Tighten all parts as you assemble them, unless
instructed to do otherwise.
s you assemble the resistance system, make
• A
sure all parts are oriented as shown in the drawings.
The included Allen wrenches and the following tools (not included) are required for assembly:
• Two adjustable wrenches
• One rubber mallet
• One standard screwdriver
• One Phillips screwdriver
• Lubricant, such as grease or petroleum jelly,
and soapy water.
Assembly will be more convenient if you have a
socket set, a set of open-end or closed-end
wrenches, or a set of ratchet wrenches.
1.
Before beginning assembly, make sure that
you have read and understand the information in the box above.
Press two 2” Square Inner Caps (98) into the
Base (1).
Attach two Plastic Feet (53) and two Large Plastic
Feet (102) to the Base (1) with four #8 x 3/4” Tec
Screws (60).
Attach the Upright (3) to the Base (1) with two
3/8” x 2 3/4” Carriage Bolts (83), two 3/8” x 2 3/4”
Bolts (64), and four 3/8” Nylon Locknuts (76) as
shown.
plete if the Upright and Base are tipped on
their sides.
Note: This step will be easier to com
1
3
64
76
-
53
76
1
53
60
98
76
102
60
83
98
102
60
5
2. Attach a Wheel (31) to the outside of the Base (1)
with a 3/8” x 4 1/4” Bolt (81), three 3/8” Washers
75), and a 3/8” Nylon Locknut (76). D
(
tighten the Locknut; the Wheel must be able
o turn easily.
t
Attach the other Wheel (not shown) in the
same manner.
o not over-
2
76
75
75
81
31
1
3. Press a 1 1/2” x 2 1/2” Inner Cap (41) into each
end of the Cross Tube (11).
Orient the Cross Tube (11) as shown, with the
welded tubes at the bottom. Attach the Foot Plate
(23) and the Cross
two 3/8” x 5 1/2” Carriage Bolts (73), two 3/8”
Washers (75), and two 3/8” Nuts (47).
insert a bolt into the top hole in the Foot Plate
yet.
4. Press two 2 1/4” Round Outer Caps (27) onto the
ends of the Front Leg (6).
Orient the Bench Rail (5) as shown. Slide the Rail
Bracket (105) into the indicated end of the Bench
Rail, and align the holes in the Bracket with the
holes in the Bench Rail.
Orient the Front Leg (6) as shown. Attach the
Front Leg to the Bench Rail (5) with the Rail
Bracket (105), four 5/16” x 1” Button Screws (46),
and four 5/16” Split Washers (52).
Tube to the Upright (3) with
Do not
3
23
73
4
105
52
27
46
3
5
46
6
41
Holes
52
27
75
11
Welded
47
41
Tube
5. See the inset drawing. Snap the Seat Knob (45)
into the Seat Carriage (12) and attach it with two
M6 x 16mm Screws (82) and two M6 Black Nylon
Locknuts (69). Make sure the slot in the Knob
is aligned with the slot in the Seat Carriage.
Orient the Seat (13) and the Seat Backing (9) as
shown.
the Seat Carriage (12) with four M6 x 16mm
Screws (82).
Attach the Seat and the Seat Backing to
5
13
Round
End
12
82
82
9
12
Slot
45
82
69
6
6. Pull the Seat Knob (45, not shown) out as far as
it will go, and slide the Seat Carriage (12) onto
he Bench Rail (5). Engage the Seat Knob into
t
the third hole from the end of the Bench Rail.
6
45
Third
ole
H
See the inset drawing. Thread the Hook (104)
into the bottom of the Bench Rail (5). Do not
overtighten the Hook, or the Bench Rail will
be difficult to assemble in step 7.
Press the two Rail Inner Caps (99), with the wide
ends on the top or bottom (as indicated), into the
ends of the Bench Rail (5). Attach the Caps with
four #8 x 3/4” Screws (62).
Locate the Leg Lever Cable (32), which has three
ends connected in the middle with a bracket.
Route the end of the Cable with the eyebolt under
a “V”-pulley (92). Attach the “V”-pulley to the
Front Leg (6) with a 3/8” x 4 1/4” Bolt (81) and a
3/8” Nylon Locknut (76).
ends of the Cable onto the Hook (104).
7. Attach the Bench Rail (5) to the Upright (3) with a
3/8” x 5 1/2” Bolt (66), a 3/4” Spacer (17), a 7/8”
Spacer (106), and a 3/8” Nylon Locknut (76).
Fully tighten the Storage Knob (30) into the
Upright and the Bench Rail.
Slide the other two
Wide
End
7
99
2
6
76
Eyebolt
5
12
62
32
92
6
Wide
End
62
104
81
76
99
62
5
30
3
8. Attach the Lat Tower (4) to the Upright (3) with
four 3/8” x 1” Button Screws (87) and four 3/8”
Split Washers (103).
ower (4)
Attach the Name Plate (89) to the Lat
with two #8 x 3/4” Screws (62).
T
17
5
106
8
4
87
62
89
62
3
103
66
87
7
9. Press two 1 1/2” Round Inner Caps (38) into the
ends of the Top Frame (10).
Attach two Eyebolts (34) to the Top Frame (10)
ith two 5/16” Washers (59) and two 5/16” Nylon
w
Locknuts (65). Do not overtighten the Locknuts;
the Eyebolts must be able to rotate freely.
Attach the Top Frame (10) to the Lat Tower (4)
with two 3/8” x 3” Button Screws (70), two 3/8”
Washers (75), and the Top Frame Cover (93).
Make sure that the Eyebolts (34) are oriented
as shown in the inset drawing. If they are not,
turn the Top Frame around and reattach it.
9
Side View
10
34
59
3
65
8
34
70
75
3
9
10
4
34
65
59
38
4
10. Attach the two 10-pound Short Caps (20) to the
10-pound Center Resistance Bar (44) with two
M4 x 12mm Flat Head Screws (85).
Using ten M4 x 12mm Flat Head Screws (85),
attach the two 10-pound Caps (101) to the 10pound Removable Resistance Bar (67), the two
20-pound Caps (88) to the 20-pound Removable
Resistance Bar (36), the four 80-pound Caps
(100) to the two 80-pound Resistance Bars (95),
and the two 40-pound Caps (79) to the 40-pound
Resistance Bar (96).
Locate the Fulcrum (18) on the Lat Tower (4) (see
1.
1
the inset drawing). Slide the T
rods on the Fulcrum.
ented as shown in the drawing.
Make sure the Tray is ori-
ray (35) onto the
10
1
96
95
79
36
67
44
85
85
1
72
85
101
20
86
Edges
85
85
100
88
up
Set the Resistance Bars into the Tray (35) in the
following order: the 10-pound Removable
Resistance Bar
Resistance Bar
(95), the 10-pound Center Resistance Bar (44), an
80-pound Resistance Bar (95), and the 40-pound
Resistance Bar (96).
rings are on the side shown and the arrows
point toward the Tray.
Attach the Cover Plate (72), with the edges up, to
the Tray (35) with two 5/16” x 3/4” Button Screws
(86).
(67), the 20-pound Removable
(36), an 80-pound
Make sure the indicated
Resistance Bar
8
Rings on
this side
4
18
35
18
Rods
67
96
44
95
95
36
Loading...
