WEG Electric CFW11 Quick Reference

Parameter Function Adjustable Range Factory Setting

User

Setting

Proprieties Groups Pag.

P0000 Access to Parameters 0 to 9999 0 - - 5-2 P0001 Speed Reference 0 to 18000 rpm - RO 09 16-1 P0002 Motor Speed 0 to 18000 rpm - RO 09 16-1 P0003 Motor Current 0.0 to 4500.0 A - RO 09 16-2

P0004 DC Link Voltage (U

) 0 to 2000 V - RO 09 16-2

P0005 Motor Frequency 0.0 to 300.0 Hz - RO 09 16-2 P0006 VFD Status 0 = Ready

- RO 09 16-2 1 = Run 2 = Undervoltage 3 = Fault 4 = Self-Tuning 5 = Configuration 6 = DC-Braking 7 = STO

P0007 Motor Voltage 0 to 2000 V - RO 09 16-3 P0009 Motor Torque -1000.0 to 1000.0 % - RO 09 16-3 P0010 Output Power 0.0 to 6553.5 kW - RO 09 16-4 P0012 DI8 to DI1 Status Bit 0 = DI1

- RO 09, 40 13-11 Bit 1 = DI2 Bit 2 = DI3 Bit 3 = DI4 Bit 4 = DI5 Bit 5 = DI6 Bit 6 = DI7 Bit 7 = DI8

P0013 DO5 to DO1 Status Bit 0 = DO1

- RO 09, 41 13-19 Bit 1 = DO2 Bit 2 = DO3 Bit 3 = DO4 Bit 4 = DO5

P0014 AO1 Value 0.00 to 100.00 % - RO 09, 39 13-6 P0015 AO2 Value 0.00 to 100.00 % - RO 09, 39 13-6 P0016 AO3 Value -100.00 to 100.00 % - RO 09, 39 13-6 P0017 AO4 Value -100.00 to 100.00 % - RO 09, 39 13-6 P0018 AI1 Value -100.00 to 100.00 % - RO 09, 38, 95 13-1 P0019 AI2 Value -100.00 to 100.00 % - RO 09, 38, 95 13-1 P0020 AI3 Value -100.00 to 100.00 % - RO 09, 38, 95 13-1 P0021 AI4 Value -100.00 to 100.00 % - RO 09, 38, 95 13-1 P0023 Software Version 0.00 to 655.35 - RO 09, 42 6-2 P0027 Accessories Config. 1 0000h to FFFFh - RO 09, 42 6-2

P0028 Accessories Config. 2 0000h to FFFFh - RO 09, 42 6-2 P0029 Power Hardware Config Bit 0 to 5 = Rated

- RO 09, 42 6-4 Current Bit 6 and 7 = Rated Voltage Bit 8 = EMC Filter Bit 9 = Safety Relay Bit 10 = (0)24V/(1) DC Link Bit 11 = (0)RST/(1) DC Link Bit 12 = Dyn.Brak. IGBT Bit 13 = Special Bit 14 and 15 = Reserved

P0030 IGBTs Temperature U -20.0 to 150.0 °C - RO 09, 45 15-4

Parameter Function Adjustable Range Factory Setting

User

Setting

Proprieties Groups Pag.

P0031 IGBTs Temperature V -20.0 to 150.0 °C - RO 09, 45 15-4 P0032 IGBTs Temperature W -20.0 to 150.0 °C - RO 09, 45 15-4 P0033 Rectifier Temperature -20.0 to 150.0 °C - RO 09, 45 15-4 P0034 Internal Air Temp. -20.0 to 150.0 °C - RO 09, 45 15-4 P0036 Fan Heatsink Speed 0 to 15000 rpm - RO 09 16-5 P0037 Motor Overload Status 0 to 100 % - RO 09 16-5 P0038 Encoder Speed 0 to 65535 rpm - RO 09 16-6 P0039 Encoder Pulses Count 0 to 40000 0 RO 09 16-6

P0040 PID Process Variable 0.0 to 100.0 % - RO 09, 46 20-8 P0041 PID Setpoint Value 0.0 to 100.0 % - RO 09, 46 20-8 P0042 Time Powered 0 to 65535 h - RO 09 16-6 P0043 Time Enabled 0.0 to 6553.5 h - RO 09 16-7 P0044 kWh Output Energy 0 to 65535 kWh - RO 09 16-7 P0045 Fan Enabled Time 0 to 65535 h - RO 09 16-7 P0048 Present Alarm 0 to 999 - RO 09 16-8 P0049 Present Fault 0 to 999 - RO 09 16-8 P0050 Last Fault 0 to 999 - RO 08 16-8 P0051 Last Fault Day/Month 00/00 to 31/12 - RO 08 16-9 P0052 Last Fault Year 00 to 99 - RO 08 16-10 P0053 Last Fault Time 00:00 to 23:59 - RO 08 16-10 P0054 Second Fault 0 to 999 - RO 08 16-8 P0055 Second Flt. Day/Month 00/00 to 31/12 - RO 08 16-9 P0056 Second Fault Year 00 to 99 - RO 08 16-10 P0057 Second Fault Time 00:00 to 23:59 - RO 08 16-10 P0058 Third Fault 0 to 999 - RO 08 16-8

P0059 Third Fault Day/Month 00/00 to 31/12 - RO 08 16-9 P0060 Third Fault Year 00 to 99 - RO 08 16-10 P0061 Third Fault Time 00:00 to 23:59 - RO 08 16-10 P0062 Fourth Fault 0 to 999 - RO 08 16-8 P0063 Fourth Flt. Day/Month 00/00 to 31/12 - RO 08 16-9 P0064 Fourth Fault Year 00 to 99 - RO 08 16-10 P0065 Fourth Fault Time 00:00 to 23:59 - RO 08 16-10 P0066 Fifth Fault 0 to 999 - RO 08 16-8 P0067 Fifth Fault Day/Month 00/00 to 31/12 - RO 08 16-9 P0068 Fifth Fault Year 00 to 99 - RO 08 16-10 P0069 Fifth Fault Time 00:00 to 23:59 - RO 08 16-10 P0070 Sixth Fault 0 to 999 - RO 08 16-8 P0071 Sixth Fault Day/Month 00/00 to 31/12 - RO 08 16-9 P0072 Sixth Fault Year 00 to 99 - RO 08 16-10 P0073 Sixth Fault Time 00:00 to 23:59 - RO 08 16-10 P0074 Seventh Fault 0 to 999 - RO 08 16-8 P0075 Seventh Flt.Day/Month 00/00 to 31/12 - RO 08 16-9 P0076 Seventh Fault Year 00 to 99 - RO 08 16-10 P0077 Seventh Fault Time 00:00 to 23:59 - RO 08 16-10 P0078 Eighth Fault 0 to 999 - RO 08 16-8 P0079 Eighth Flt. Day/Month 00/00 to 31/12 - RO 08 16-9 P0080 Eighth Fault Year 00 to 99 - RO 08 16-10 P0081 Eighth Fault Time 00:00 to 23:59 - RO 08 16-10 P0082 Ninth Fault 0 to 999 - RO 08 16-9

P0083 Ninth Fault Day/Month 00/00 to 31/12 - RO 08 16-9 P0084

Ninth Fault Year 00 to 99 - RO 08 16-10

P0085 Ninth Fault Time 00:00 to 23:59 - RO 08 16-10 P0086 Tenth Fault 0 to 999 - RO 08 16-9 P0087 Tenth Fault Day/Month 00/00 to 31/12 - RO 08 16-9

Parameter Function Adjustable Range Factory Setting

User

Setting

Proprieties Groups Pag.

P0088 Tenth Fault Year 00 to 99 - RO 08 16-10 P0089 Tenth Fault Time 00:00 to 23:59 - RO 08 16-11 P0090 Current At Last Fault 0.0 to 4000.0 A - RO 08 16-11 P0091 DC Link At Last Fault 0 to 2000 V - RO 08 16-11 P0092 Speed At Last Fault 0 to 18000 rpm - RO 08 16-11 P0093 Reference Last Fault 0 to 18000 rpm - RO 08 16-12 P0094 Frequency Last Fault 0.0 to 300.0 Hz - RO 08 16-12 P0095 Motor Volt.Last Fault 0 to 2000 V - RO 08 16-12 P0096 DIx Status Last Fault Bit 0 = DI1

- RO 08 16-12 Bit 1 = DI2 Bit 2 = DI3 Bit 3 = DI4 Bit 4 = DI5 Bit 5 = DI6 Bit 6 = DI7 Bit 7 = DI8

P0097 DOx Status Last Fault Bit 0 = DO1

- RO 08 16-13 Bit 1 = DO2 Bit 2 = DO3 Bit 3 = DO4 Bit 4 = DO5

P0100 Acceleration Time 0.0 to 999.0 s 20.0 s - 04, 20 12-1 P0101 Deceleration Time 0.0 to 999.0 s 20.0 s - 04, 20 12-1 P0102 Acceleration Time 2 0.0 to 999.0 s 20.0 s - 20 12-1 P0103 Deceleration Time 2 0.0 to 999.0 s 20.0 s - 20 12-1 P0104 S Ramp 0 = Off

0 = Off - 20 12-2 1 = 50% 2 = 100%

P0105 1st/2nd Ramp Select. 0 = 1

Ramp

2 = DIx CFG 20 12-3

1 = 2nd Ramp 2 = DIx 3 = Serial/USB 4 = Anybus-CC 5 = CANOpen/ DeviceNet 6 = SoftPLC 7 = PLC11

P0120 Speed Ref. Backup 0 = Off

1 = On - 21 12-3 1 = On

P0121 Keypad Reference 0 to 18000 rpm 90 rpm - 21 12-4 P0122 JOG/JOG+ Reference 0 to 18000 rpm 150 (125) rpm - 21 12-4 P0123 JOG- Reference 0 to 18000 rpm 150 (125) rpm Vector 21 12-5 P0124 Multispeed Ref. 1 0 to 18000 rpm 90 (75) rpm - 21, 36 12-7 P0125 Multispeed Ref. 2 0 to 18000 rpm 300 (250) rpm - 21, 36 12-7 P0126 Multispeed Ref. 3 0 to 18000 rpm 600 (500) rpm - 21, 36 12-7 P0127 Multispeed Ref. 4 0 to 18000 rpm 900 (750) rpm - 21, 36 12-7 P0128 Multispeed Ref. 5 0 to 18000 rpm 1200 (1000) rpm - 21, 36 12-7 P0129 Multispeed Ref. 6 0 to 18000 rpm 1500 (1250) rpm - 21, 36 12-7 P0130 Multispeed Ref. 7 0 to 18000 rpm 1800 (1500) rpm - 21, 36 12-7 P0131 Multispeed Ref. 8 0 to 18000 rpm 1650 (1375) rpm - 21, 36 12-7 P0132 Max. Overspeed Level 0 to 100 % 10 % CFG 22, 45 12-5 P0133 Minimum Speed 0 to 18000 rpm 90 (75) rpm - 04, 22 12-6 P0134 Maximum Speed 0 to 18000 rpm 1800 (1500) rpm - 04, 22 12-6 P0135 Max. Output Current 0.2 to 2xI

nom-HD

1.5xI

nom-HD

V/f and VVW 04, 26 9-7

P0136 Manual Torque Boost 0 to 9 1 V/f 04, 23 9-2 P0137 Autom. Torque Boost 0.00 to 1.00 0.00 V/f 23 9-2

Parameter Function Adjustable Range Factory Setting

User

Setting

Proprieties Groups Pag.

P0138 Slip Compensation -10.0 to 10.0 % 0.0 % V/f 23 9-3 P0139 Output Current Filter 0.0 to 16.0 s 0.2 s V/f and VVW 23, 25 9-4 P0140 Dwell Time At Start 0.0 to 10.0 s 0.0 s V/f and VVW 23, 25 9-5 P0141 Dwell Speed At Start 0 to 300 rpm 90 rpm V/f and VVW 23, 25 9-5 P0142 Max. Output Voltage 0.0 to 100.0 % 100.0 % CFG and Adj 24 9-6 P0143 Interm.Output Voltage 0.0 to 100.0 % 50.0 % CFG and Adj 24 9-6 P0144 3Hz Output Voltage 0.0 to 100.0 % 8.0 % CFG and Adj 24 9-6 P0145 Field Weakening Speed 0 to 18000 rpm 1800 rpm CFG and Adj 24 9-6 P0146 Intermediate Speed 0 to 18000 rpm 900 rpm CFG and Adj 24 9-6 P0150 DC Regul. Type V/f 0 = Ramp Hold

1 = Ramp Accel.

P0151 DC Regul. Level V/f 339 to 400 V

585 to 800 V 585 to 800 V 585 to 800 V 585 to 800 V 809 to 1000 V 809 to 1000 V 924 to 1200 V 924 to 1200 V

0 = Ramp Hold CFG, V/f and

VVW

400 V (P0296=0)

V/f and VVW 27 9-12 800 V (P0296=1) 800 V (P0296=2) 800 V (P0296=3) 800 V (P0296=4)

1000 V (P0296=5) 1000 V (P0296=6) 1000 V (P0296=7) 1200 V (P0296=8)

27 9-12

P0152 DC Link Regul. P Gain 0.00 to 9.99 1.50 V/f and VVW 27 9-13 P0153 Dyn. Braking Level 339 to 400 V

585 to 800 V 585 to 800 V 585 to 800 V 585 to 800 V 809 to 1000 V 809 to 1000 V 924 to 1200 V 924 to 1200 V

375 V (P0296=0) 618 V (P0296=1) 675 V (P0296=2) 748 V (P0296=3) 780 V (P0296=4) 893 V (P0296=5) 972 V (P0296=6) 972 V (P0296=7)

1174 V (P0296=8)

- 28 14-1

P0154 Dyn. Braking Resistor 0.0 to 500.0 ohm 0.0 ohm - 28 14-2 P0155 Dyn. B. Resist. Power 0.02 to 650.00 kW 2.60 kW - 28 14-3 P0156 Overl.Curr.100% Speed 0.1 to 1.5xI P0157 Overl.Curr. 50% Speed 0.1 to 1.5xI P0158 Overl.Curr. 5% Speed 0.1 to 1.5xI P0159 Motor Thermal Class 0 = Class 5

nom-ND

1.05xI

nom-ND

0.9xI

nom-ND

0.5xI

nom-ND

1 = Class 10 CFG 45 15-6

- 45 15-4

- 45 15-5

1 = Class 10 2 = Class 15 3 = Class 20 4 = Class 25 5 = Class 30 6 = Class 35 7 = Class 40 8 = Class 45

P0160 Speed Regul. Optimiz. 0 = Normal

1 = Saturated

0 = Normal CFG and

Vector

90 11-15

P0161 Speed Prop. Gain 0.0 to 63.9 7.4 Vector 90 11-16 P0162 Speed Integral Gain 0.000 to 9.999 0.023 Vector 90 11-16 P0163 LOC Reference Offset -999 to 999 0 Vector 90 11-17 P0164 REM Reference Offset -999 to 999 0 Vector 90 11-17 P0165 Speed Filter 0.012 to 1.000 s 0.012 s Vector 90 11-17 P0166 Speed Diff. Gain 0.00 to 7.99 0.00 Vector 90 11-17 P0167 Current Prop. Gain 0.00 to 1.99 0.50 Vector 91 11-18 P0168 Current Integral Gain 0.000 to 1.999 0.010 Vector 91 11-18 P0169 Max. CW Torque Curr. 0.0 to 650.0 % 125.0 % Vector 95 11-26 P0170 Max. CCW Torque Curr. 0.0 to 650.0 % 125.0 % Vector 95 11-26 P0171 CW Torque Cur at Nmax 0.0 to 650.0 % 125.0 % Vector 95 11-27

Parameter Function Adjustable Range Factory Setting

P0172 CCW TorqueCur at

0.0 to 650.0 % 125.0 % Vector 95 11-27

User

Setting

Proprieties Groups Pag.

Nmax

P0173 Max Torque Curve Type 0 = Ramp

0 = Ramp Vector 95 11-28

1 = Step

P0175 Flux Proport. Gain 0.0 to 31.9 2.0 Vector 92 11-18 P0176 Flux Integral Gain 0.000 to 9.999 0.020 Vector 92 11-19 P0178 Rated Flux 0 to 120 % 100 % Vector 92 11-19 P0179 Maximum Flux 0 to 120 % 120 % Vector 92 11-19 P0181 Magnetization Mode 0 = General Enable

1 = Run/Stop

0 = General Enable CFG and

Encoder

92 11-20

P0182 Speed for I/F Activ. 0 to 90 rpm 18 rpm Sless 93 11-21 P0183 Current in I/F Mode 0 to 9 1 Sless 93 11-21 P0184 DC Link Regul. Mode 0 = With losses

1 = Without losses

1 = Without losses CFG and

Vector

96 11-28

2 = Enab/Disab DIx

P0185 DC Link Regul. Level 339 to 400 V

585 to 800 V 585 to 800 V 585 to 800 V 585 to 800 V 809 to 1000 V 809 to 1000 V 924 to 1200 V 924 to 1200 V

400 V (P0296=0) 800 V (P0296=1) 800 V (P0296=2) 800 V (P0296=3)

800 V (P0296=4) 1000 V (P0296=5) 1000 V (P0296=6) 1000 V (P0296=7) 1200 V (P0296=8)

Vector 96 11-29

P0186 DC Link Prop. Gain 0.0 to 63.9 18.0 Vector 96 11-30 P0187 DC Link Integral Gain 0.000 to 9.999 0.002 Vector 96 11-30 P0188 Voltage Proport. Gain 0.000 to 7.999 0.200 Vector 92 11-20 P0189 Voltage Integral Gain 0.000 to 7.999 0.001 Vector 92 11-20 P0190 Max. Output Voltage 0 to 690 V

0 to 690 V 0 to 690 V 0 to 690 V 0 to 690 V 0 to 690 V 0 to 690 V 0 to 690 V 0 to 690 V

P0191 Encoder Zero Search 0=Off

209 V (P0296=0)

Vector 92 11-20 361 V (P0296=1) 380 V (P0296=2) 418 V (P0296=3) 456 V (P0296=4) 499 V (P0296=5) 546 V (P0296=6) 570 V (P0296=7) 656 V (P0296=8)

0=Off - 12-22

1=On

P0192 Status Encoder Zero

P0193 Day of the Week 0 = Sunday

0=Off 1=Finished

0=Off RO 12-22

0 = Sunday 30 5-3 1 = Monday 2 = Tuesday 3 = Wednesday 4 = Thursday 5 = Friday 6 = Saturday

P0194 Day 01 to 31 01 - 30 5-3 P0195 Month 01 to 12 01 - 30 5-3 P0196 Year 00 to 99 06 - 30 5-3 P0197 Hour 00 to 23 00 - 30 5-3 P0198 Minutes 00 to 59 00 - 30 5-3 P0199 Seconds 00 to 59 00 - 30 5-3 P0200 Password 0 = Off

1 = On - 30 5-4 1 = On 2 = Change Pass.

Parameter Function Adjustable Range Factory Setting

P0201 Language 0 = Português

0 = Português - 30 5-4

User

Setting

Proprieties Groups Pag.

1 = English 2 = Español 3 = Deutsch

P0202 Type of Control 0 = V/f 60 Hz

1 = V/f 50 Hz 2 = V/f Adjustable 3 = Sensorless

0 = V/f 60 Hz CFG 05, 23, 24,

25, 90, 91, 92, 93, 94,

95, 96 4 = Encoder 5 = VVW

P0203 Special Function Sel. 0 = None

0 = None CFG 46 20-9

1 = PID Regulator

P0204 Load/Save Parameters 0 = Not Used

0 = Not Used CFG 06 7-1 1 = Not Used 2 = Reset P0045 3 = Reset P0043 4 = Reset P0044 5 = Load 60Hz 6 = Load 50Hz 7 = Load User 1 8 = Load User 2 9 = Load User 3 10 = Save User 1 11 = Save User 2 12 = Save User 3

P0205 Read Parameter Sel. 1 0 = Not selected

2 = Motor Speed # - 30 5-4 1 = Speed Refer. # 2 = Motor Speed # 3 = MotorCurrent # 4 = DC Link Volt # 5 = Motor Freq. # 6 = MotorVoltage # 7 = Motor Torque # 8 = Output Power # 9 = Process Var. # 10 = Setpoint PID # 11 = Speed Refer. 12 = Motor Speed 13 = MotorCurrent 14 = DC Link Volt 15 = Motor Freq. 16 = MotorVoltage 17 = Motor Torque 18 = Output Power 19 = Process Var. 20 = Setpoint PID -

P0206 Read Parameter Sel. 2 See options in P0205 3 = Motor Current # - 30 5-4 P0207 Read Parameter Sel. 3 See options in P0205 5 = Motor Freq. # - 30 5-4 P0208 Ref. Scale Factor 1 to 18000 1800 (1500) - 30 5-5 P0209 Ref. Eng. Unit 1 32 to 127 114 - 30 5-6 P0210 Ref. Eng. Unit 2 32 to 127 112 - 30 5-6 P0211 Ref. Eng. Unit 3 32 to 127 109 - 30 5-6 P0212 Ref. Decimal Point 0 = wxyz

0 = wxyz - 30 5-5 1 = wxy.z 2 = wx.yz 3 = w.xyz

P0213 Full Scale Read 1 0.0 to 200.0 % 100.0 % CFG 30 5-7 P0214 Full Scale Read 2 0.0 to 200.0 % 100.0 % CFG 30 5-7

9-5

Parameter Function Adjustable Range Factory Setting

User

Setting

Proprieties Groups Pag.

P0215 Full Scale Read 3 0.0 to 200.0 % 100.0 % CFG 30 5-7 P0216 HMI Display Contrast 0 to 37 27 - 30 5-7 P0217 Zero Speed Disable 0 = Off

0 = Off CFG 35, 46 12-10

1 = On

P0218 Zero Speed Dis. Out 0 = Ref. or Speed

0 = Ref. or Speed - 35, 46 12-10

1 = Reference

P0219 Zero Speed Time 0 to 999 s 0 s - 35, 46 12-11 P0220 LOC/REM Selection Src 0 = Always LOC

1 = Always REM

2 = LR Key LOC CFG 31, 32, 33,

110 2 = LR Key LOC 3 = LR Key REM 4 = DIx 5 = Serial/USB LOC 6 = Serial/USB REM 7 = Anybus-CC LOC 8 = Anybus-CC REM 9 = CANop/DNet LOC 10 = CANop/DNet REM 11 = SoftPLC LOC 12 = SoftPLC REM 13 = PLC11 LOC 14 = PLC11 REM

P0221 LOC Reference Sel. 0 = Keypad

1 = AI1

0 = Keypad CFG 31, 36, 37,

38, 110 2 = AI2 3 = AI3 4 = AI4 5 = Sum AIs > 0 6 = Sum AIs 7 = E.P. 8 = Multispeed 9 = Serial/USB 10 = Anybus-CC 11 = CANop/DNet 12 = SoftPLC 13 = PLC11

P0222 REM Reference Sel. See options in P0221 1 = AI1 CFG 32, 36, 37,

38, 110

P0223 LOC FWD/REV Selection 0 = Always FWD

2 = FR Key FWD CFG 31, 33, 110 13-29 1 = Always REV 2 = FR Key FWD 3 = FR Key REV 4 = DIx 5 = Serial/USB FWD 6 = Serial/USB REV 7 = Anybus-CC FWD 8 = Anybus-CC REV 9 = CANop/DNet FWD 10 = CANop/DNet REV 11 = AI4 Polarity 12 = SoftPLC FWD 13 = SoftPLC REV 14 = AI2 Polarity 15 = PLC11 FWD 16 = PLC11 REV

13-28

Parameter Function Adjustable Range Factory Setting

P0224 LOC Run/Stop Sel. 0 = I,O Keys

0 = I,O Keys CFG 31, 33, 110 13-30

User

Setting

Proprieties Groups Pag.

1 = DIx 2 = Serial/USB 3 = Anybus-CC 4 = CANop/DNet 5 = SoftPLC 6 = PLC11

P0225 LOC JOG Selection 0 = Disable

1 = JOG Key CFG 31, 110 13-30 1 = JOG Key 2 = DIx 3 = Serial/USB 4 = Anybus-CC 5 = CANop/DNet 6 = SoftPLC 7 = PLC11

P0226 REM FWD/REV Sel. See options in P0223 4 = DIx CFG 32, 33, 110 13-29 P0227 REM Run/Stop Sel. See options in P0224 1 = DIx CFG 32, 33, 110 13-30

P0228 REM JOG Selection See options in P0225 2 = DIx CFG 32, 110 13-30 P0229 Stop Mode Selection 0 = Ramp to Stop

0 = Ramp to Stop CFG 31, 32, 33, 3413-30 1 = Coast to Stop 2 = Fast Stop

P0230 Dead Zone (AIs) 0 = Off

0 = Off - 38 13-1

1 = On

P0231 AI1 Signal Function 0 = Speed Ref.

0 = Speed Ref. CFG 38, 95 13-2 1 = No Ramp Ref. 2 = Max.Torque Cur 3 = Process Var. 4 = PTC 5 = Not Used 6 = Not Used 7 = PLC Use

P0232 AI1 Gain 0.000 to 9.999 1.000 - 38, 95 13-3 P0233 AI1 Signal Type 0 = 0 to 10V/20mA

0 = 0 to 10V/20mA CFG 38, 95 13-5 1 = 4 to 20 mA 2 = 10V/20mA to 0 3 = 20 to 4 mA

P0234 AI1 Offset -100.00 to 100.00 % 0.00 % - 38, 95 13-4 P0235 AI1 Filter 0.00 to 16.00 s 0.00 s - 38, 95 13-4 P0236 AI2 Signal Function See options in P0231 0 = Speed Ref. CFG 38, 95 13-2 P0237 AI2 Gain 0.000 to 9.999 1.000 - 38, 95 13-3 P0238 AI2 Signal Type 0 = 0 to 10V/20mA

0 = 0 to 10V/20mA CFG 38, 95 13-5 1 = 4 to 20 mA 2 = 10V/20mA to 0 3 = 20 to 4 mA 4 = -10 to +10V

P0239 AI2 Offset -100.00 to 100.00 % 0.00 % - 38, 95 13-4 P0240 AI2 Filter 0.00 to 16.00 s 0.00 s - 38, 95 13-4 P0241 AI3 Signal Function 0 = Speed Ref.

0 = Speed Ref. CFG 38, 95 13-2 1 = No Ramp Ref. 2 = Max.Torque Cur 3 = Process Var. 4 = PTC 5 = Not Used 6 = Not Used 7 = PLC Use

P0242 AI3 Gain 0.000 to 9.999 1.000 - 38, 95 13-4
